1 Getting Started
Getting Started2
Safety Information
1
Getting Started
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
instructions in the literature accompanying the
product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a builtin installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This lightning ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product’s
The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing)
CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read
this owner’s manual carefully and retain it for future
reference. Shall the unit require maintenance,
contact an authorized service center.
Use of controls, adjustments or the performance of
procedures other than those specied herein may
result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not
try to open the enclosure.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
center. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. When installing the product,
ensure that the plug is easily accessible.
CM3330B-BK.DGBRLLK_ENG.indd 2 2013-02-18 8:32:20
Getting Started 3
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.
Disposal of your old appliance
1. When this crossed-out wheeled bin
symbol is attached to a product it
means the product is covered by
the European Directive 2002/96/EC.
2. All electrical and electronic products
should be disposed of separately
from the municipal waste stream
via designated collection facilities
appointed by the government or
the local authorities.
3. The correct disposal of your
old appliance will help prevent
potential negative consequences
for the environment and human
health.
4. For more detailed information about
disposal of your old appliance,
please contact your city office,
waste disposal service or the shop
where you purchased the product.
Disposal of waste batteries/accumulators
1. When this crossed-out wheeled
bin symbol is attached to batteries/
accumulators of Your product
it means they are covered by
European Directive 2006/66/EC.
2. This symbol may be combined with
chemical symbols for mercury(Hg),
cadmium(Cd) or lead(Pb) if the
battery Contains more that 0.0005%
of mercury,0.002% of cadmium or
0.004% of lead.
3. All batteries/accumulators should
be disposed separately from
the municipal waste stream via
designated collection facilities
appointed by the government or
the local authorities.
4. The correct disposal of Your old
batteries/accumulators will help
to prevent potential negative
consequences for the environment,
animal and human health.
5. For more detailed information
about disposal of Your old batteries/
accumulators, please contact Your
city office, waste disposal service or
the shop where You purchased the
product.
1
Getting Started
CM3330B-BK.DGBRLLK_ENG.indd 3 2013-02-18 8:32:21
Getting Started4
LG Electronics hereby declares that this/these
product(s) is/are in compliance with the essential
1
Getting Started
requirements and other relevant provisions of
Directive 1999/5/EC, 2004/108/EC, 2006/95/EC,
2009/125/EC and 2011/65/EU.
Please contact to the followingaddress for
obtaining a copy of the DoC (Declaration of
Conformity).
Contact oce for compliance of this product:
LG Electronics Inc.
EU Representative, Krijgsman 1,
1186 DM Amstelveen, The Netherlands
yPlease note that this is NOT a Customer
Service contact point. For Customer Service
Information, see Warranty Card or contact the
dealer that you purchased this product.
In door use only.
RF Radiation Exposure Statement
This equipment should be installed and operated
with minimum distance 20cm between the
radiator and your body.
LG Bluetooth Remote
You can control this player with your iPhone or
Android phone via Bluetooth. This player and your
phone must be connected to Bluetooth. Visit
“ Apple App Store” or “Google Android Market
(Google Play Store)” . And use this QR code to
search for “LG Bluetooth Remote” app. For detailed
information, refer to the 26 page.
POWER: This unit operates on a mains supply
of 100-240V, 50/60Hz.
WIRING: This unit is supplied with a BSI 1363
approved 13 amp mains plug, fused at 5 amp.
When replacing the fuse always use a 5 amp
BS 1362, BSI or ASTA approved type. Never use
this plug with the fuse cover omitted. To obtain
a replacement fuse cover contact your dealer.
If the type of plug supplied is not suitable for
the mains sockets in your home, then the plug
should be removed and a suitable type tted.
Please refer to the wiring instructions below:
WIRING: A mains plug removed from the
mains lead of this unit must be destroyed. A
mains plug with bared wires is hazardous if
inserted in a mains socket. Do not connect
either wire to the earth pin, marked with the
letter E or with the earth symbol
green or green and yellow. If any other plug is
tted, use a 5 amp fuse, either in the plug, or at
the distribution board.
IMPORTANT: The wires in this mains lead are
coloured in accordance with the following
codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the
colours of the wires in the mains lead of this
unit may not correspond with the coloured
marking identifying the terminals in your plug,
proceed as follows: The wire which is coloured
blue must be connected to the terminal which
is marked with the letter N or coloured black.
The wire which is coloured brown must be
connected to the terminal which is marked
with the letter L or coloured red.
or coloured
CM3330B-BK.DGBRLLK_ENG.indd 4 2013-02-18 8:32:21
Table of Contents 5
Table of Contents
1 Getting Started
2 Safety Information
6 Unique Features
6 Accessories
7 Playable file Requirement
8 Remote Control
10 Front Panel
10 Rear Panel
11 Connecting the AC adapter
2 Operating
12 Basic Operations
12 – iPod/iPhone/iPad Operation
13 – Android device Operation
15 – USB Operation
15 – CD Operation
16 – Listening to music from your portable
device
16 – Listening to music with your
headphones
17 Other Operation
17 – Programmed Playback
17 – Selecting a folder and an MP3/WMA/
FLAC file.
17 – Resume playback
18 – Deleting an MP3/WMA/FLAC file
18 – Displaying file information
18 – Turn off the sound temporarily
18 – Sleep Timer Setting
18 – Dimmer
18 – Auto Power Down
19 Sound adjustment
19 – Setting the sound mode
19 Radio Operation
19 – Antenna Connection
20 – Listening to the radio
20 – Improving poor FM reception
20 – Presetting the Radio Stations
20 – Deleting all the saved stations
21 – Seeing information about a Radio
station
21 – Listening to the DAB
21 – Aligning the service names
21 – DAB scan
21 – Deleting all of the saved DAB scan
stations
22 Setting the Clock
23 – Using your player as an alarm clock
23 Advanced Operation
23 – Recording on USB
23 – To select recording bit rate and speed
24 Using a Bluetooth wireless technology
25 – Listening to music of a Bluetooth
device
26 Using LG Bluetooth Remote app
28 Using AirPlay
29 – Connecting your Wi-Fi device to Wi-Fi
network
32 – Streaming audio from your iTunes
music library to this unit
3 Troubleshooting
34 Troubleshooting
4 Appendix
35 Trademarks and Licenses
36 Specifications
37 Maintenance
37 – Notes on Discs
37 – Handling the Unit
5 Warranty
38 Warranty
1
2
3
4
5
CM3330B-BK.DGBRLLK_ENG.indd 5 2013-02-18 8:32:21
Getting Started6
Unique Features
USB Direct Recording
1
Getting Started
Records music to your USB device.
Portable In
Listens to music from your portable device. (MP3,
Notebook, etc)
Timer
Sets alarm which go o at desired time.
Time Sync
Sets your unit’s clock automatically by using your
Bluetooth device. (LG Bluetooth Remote app)
Bluetooth®
Listens to music stored on your Bluetooth device.
AirPlay®
Listens to music stored on your Apple device.
Accessories
Please check and identify the supplied accessories.
Remote Control (1) Battery (1)
AC adapter(1) Power cord(1)
FM Antenna (1) DAB antenna (1)
CM3330B-BK.DGBRLLK_ENG.indd 6 2013-02-18 8:32:22
Getting Started 7
Playable file
Requirement
MP3/ WMA/FLAC music file
requirement
MP3/ WMA/FLAC le compatibility with this unit is
limited as follows :
y Sampling frequency :
MP3 : within 8 to 48 kHz
WMA : within 8 to 48 kHz
FLAC : within 8 to 96 kHz(USB),
within 8 to 48 kHz(CD)
y Bit rate : within 8 to 320 kbps (MP3),
40 to 192 kbps (WMA)
yMaximum les : Under 999
yFile extensions : “.mp3”/ “.wma”/”.ac”
CD-ROM le format : ISO9660/ JOLIET
y
ySupport channel(FLAC) : Up to 2 channel
Support output bit/sample (FLAC) : 16bit
y
ybps(FLAC) : Up to 2.5Mbps
You have to set the disc format option to
y
[Mastered] in order to make the discs compatible
with the LG players when formatting rewritable
discs. When setting the option to Live File System,
you cannot use it on LG players. (Mastered/ Live
File System : Disc format system for Windows
Vista)
Compatible USB Devices
MP3 Player : Flash type MP3 player.
y
y USB Flash Drive :
Devices that support USB2.0 or USB1.1.
y The USB function of this unit does not support all
USB devices.
USB device requirement
y Devices which require additional program
installation when you have connected it to a
computer, are not supported.
y Do not extract the USB device while in operation.
y For a large capacity USB, it may take longer than a
few minutes to be searched.
yTo prevent data loss, back up all data.
y If you use a USB extension cable or USB hub, the
USB device is not recognized.
y Using NTFS le system is not supported. (Only
FAT(16/ 32) le system is supported.)
y This unit is not supported when the total number
of les is 1 000 or more.
y External HDD, Card readers, Locked devices, or
hard type USB devices, mobile phone are not
supported.
y USB port of the unit cannot be connected to PC.
The unit cannot be used as a storage device.
ySome USB may not work with this unit.
In power on state, you can charge your iPod/
y
iPhone/iPad/Android device via USB port. (This is
available when you selects USB function.)
1
Getting Started
CM3330B-BK.DGBRLLK_ENG.indd 7 2013-02-18 8:32:22
Getting Started8
Remote Control
1
Getting Started
• • • • • • • • • a • • • • • • • • • •
(Power) : Switches the unit ON or OFF.
1
(Insert/Eject) : Inserts or ejects a disc from a slot
loader.
VOL +/- : Adjusts speaker volume.
FUNCTION : Selects the function and input source.
PRESET/FOLDER W/S :
-
Searches for a folder of MP3/WMA/FLAC les.
When a CD/USB containing MP3/WMA/FLAC
les in several folders is being played, press
PRESET/FOLDER W/S to select the folder you
want to play.
-
Chooses a preset number for a radio station.
MUTE : Mutes the sound.
@
• • • • • • • • •
PROGRAM/MEMORY :
- Stores radio stations.
- Creates a playlist you want to listen to.
SOUND EFFECT : Chooses sound impressions.
INFO : Sees information about your music.
• • • • • • • • • •
b
SLEEP : Sets the system to turn off automatically at
a specified time.
REPEAT(MENU) :
- Listens to your tracks/les repeatedly or randomly.
- Move to the previous menu when you select USB
function to play iPod/iPhone/iPad.
DELETE : Deletes MP3/WMA/FLAC files. (USB only)
Y/U
- Skips Fast backward or Forward.
- Searches for a section within a track/file.
CH/TUNING-/+ :
- Selects a DAB display mode.
-
Selects the radio stations.
I
- Stops playback or recording.
- Cancels DELETE function.
- Conrms the clock and the alarm setting.
• • • • • • • • • c
CLOCK : Sets a clock and checks a time.
T
- Starts or pauses playback.
- Selects Stereo/Mono.
TIMER : Uses your player as an alarm clock.
RDS/SET :
- RDS(Radio Data System)
- Conrms the clock and the alarm setting.
(Refer to the 21 page)
DAB MODE :
- DAB radio type.
- Changes the display information of DAB channel.
USB REC : Starts recording
PTY : Searches radio stations by radio type.
SORT/SCAN :
- Searches radio stations by radio type.
- Aligns the service names DAB band scanning.
(Skip/Search) :
ENTER :
• • • • • • • • •
(Play/Pause) :
CM3330B-BK.DGBRLLK_ENG.indd 8 2013-02-18 8:32:23
Getting Started 9
Battery Installation
You have two ways to open the battery
compartment.
1. Turn the battery compartment
counterclockwise by using a coin or your finger.
Then take a battery compartment out.
Caution
>
If you have long nails, do not open the battery
compartment by using your nger. Or else,
your nail would be broken.
3. Put the battery compartment on the remote
control and turn it clockwise to close.
Caution
>
The battery used in this device may present a
re or chemical burn hazard if mistreated. Do
not recharge, disassemble, incinerate, or heat
above 100 °C (212 °F). Replace the battery part
no. CR2025 only. Use of another battery may
present a risk of re or explosion. Dispose of
used battery. Keep battery away from children.
Do not disassemble or dispose of in re.
1
Getting Started
2. Insert and fix the battery with the minus(-)
facing in the same direction as the minus(-).
+
+
CM3330B-BK.DGBRLLK_ENG.indd 9 2013-02-18 8:32:23
Getting Started
Getting Started10
Front Panel
1
Speaker
a
b 1/!
Switches the unit ON or OFF.
F(Function)
Selects the function and input source.
- Starts and pauses playback.
- Selects Stereo/Mono.
Stops playback.
(Power ON/OFF)
(Play/Pause)
T
(Stop)
I
Rear Panel
DAB ANT.
a
Connects the DAB antenna.
FM ANT.
Connects the FM wired antenna.
(AirPlay)
b
Connects your unit to the existing Wi-Fi
network.
Air Direct/Reset
- Creates new Wi-Fi network with your unit.
- Initializes Wi-Fi network’s Security Mode.
-/+ (Volume)
Adjusts volume level.
(Insert/Eject)
R
Inserts or ejects a disc from a slot loader.
Display Window
c
Disc slot
d
Loads a disc.
DC IN(AC adapter input)
c
PORT.IN
d
Listens to music from your portable device.
PHONES
Listens to music with your headphone.
(3.5 mm)
USB Port
e
Plays and records the audio les by
connecting the USB device.
CM3330B-BK.DGBRLLK_ENG.indd 10 2013-02-18 8:32:24
Caution
>
Precautions in using the touch buttons
yUse the touch buttons with clean and dry
hands.
- In a humid environment, wipe out any
moisture on the touch buttons before
using.
yDo not press the touch buttons hard to
make it work.
- If you apply too much strength, it can
damage the sensor of the touch buttons.
yTouch the button that you want to work in
order to operate the function correctly.
yBe careful not to have any conductive
material such as metallic object on the
touch buttons. It can cause malfunctions.
Caution
>
There are speakers at the bottom of your unit.
Be careful of this, when you handle it.
Getting Started 11
Connecting the AC
adapter
1. Connect the supplied AC power cord to the AC
adapter.
2.
Connect the AC adapter cable to DC IN adapter
input.
3. Plug the AC power cord into an AC outlet.
1
Getting Started
Caution
>
Only use the AC adapter supplied with this
device. Do not use a power supply from
another device or manufacturer. Using any
other power cable or power supply may cause
damage to the device and void your warranty.
CM3330B-BK.DGBRLLK_ENG.indd 11 2013-02-18 8:32:24
Operating12
Basic Operations
iPod/iPhone/iPad Operation
You can enjoy the sound with your iPod/iPhone/
iPad. For details about iPod/iPhone/iPad, refer to
the iPod/iPhone/iPad User Guide.
1. Connect iPod/iPhone/iPad to the USB port by
2
Operating
using the iPod/iPhone/iPad’s cable.
If you turn this unit on, your iPod/iPhone/
iPad will be automatically turned on and start
recharging.
2. Press FUNCTION on the remote control or F on
the unit to select USB function. You can operate
your iPod/iPhone/iPad through an iPod/iPhone/
iPad’s display by using the remote control and
controlling your iPod/iPhone/iPad.
To
ON UNIT ON REMOTE
Pauses or
restart
Skip -
Search -
Move to the
previous
menu
Move to the
desired item
Chooses a
item
Do this
T T
Y/U
Press and hold
Y/U
-
-
I
REPEAT
(MENU)
PRESET/
FOLDER
W/S
ENTER
I
Compatible iPod/iPhone/iPad
The unit supports the models as follows ;
iPad mini
iPad 4G
iPad 3G
iPad 2G
iPad
iPhone 5
iPhone 4S
iPhone 4
iPhone 3GS
iPod touch 5G
iPod touch 4G
iPod touch 3G
iPod nano 7G
iPod nano 6G
iPod nano 5G
iPod nano 4G
Depending on your iPod/iPhone/iPad’s software
version, you may not control your iPod/iPhone/
iPad from the unit.
Depending on your iPod/iPhone/iPad device,
you may not control your iPod/iPhone/iPad
from the unit.
CM3330B-BK.DGBRLLK_ENG.indd 12 2013-02-18 8:32:25
Loading...
