OWNER’S MANUAL

MFL71101831

DVD MINI HI-FI SYSTEM

Please read this manual carefully before operating your set and retain it for future reference.

MODEL

CL65D (CL65D, CLS65F)

2003_Rev03

www.lg.com

Page 2

Getting Started2

Safety Information

Getting Started

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE REFER

SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN

OR MOISTURE.

CAUTION: The apparatus should not be exposed to water (dripping or splashing) and no objects lled with liquids, such as vases, should be placed on the apparatus.

WARNING: Do not install this equipment in a conned space such as a book case or similar unit.

CAUTION: Do not use high voltage products around this product. (ex. Electrical swatter) This product may malfunction due to electrical shock.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

CAUTION: This product employs a Laser System. To ensure proper use of this product, please read this owner’s manual carefully and retain it for future reference. Shall the unit require maintenance, contact an authorized service center. Use of controls, adjustments or the performance of procedures other than those specied herein may result in hazardous radiation exposure. To prevent direct exposure to laser beam, do not try to open the enclosure.

CAUTION: Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to protect it from over heating. The openings should never be blocked by placing the product on a bed, sofa, rug or other similar surface. This product should not be placed in a builtin installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instruction has been adhered to.

NOTICE: For safety marking information including product identication and supply ratings, please refer to the main label on the bottom or the other surface of the product.

Page 3

Getting Started 3

CAUTION concerning the Power Cord

The Power Plug is the disconnecting device. In case of an emergency, the Power Plug must remain readily accessible.

Check the specication page of this owner’s manual to be certain of the current requirements.

Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets, extension cords, frayed power cords, or damaged or cracked wire insulation are dangerous. Any of these conditions could result in electric shock or re. Periodically examine the cord of your device, and if its appearance indicates damage or deterioration, unplug it, discontinue use of the device, and have the cord replaced with an exact replacement part by an authorized service center. Protect the power cord from physical or mechanical abuse, such as being twisted, kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and the point where the cord exits the device.

CAUTION: Be careful to make sure children do not put their hands or any objects into the *speaker duct.

* speaker duct : A hole for plentiful bass sound on speaker cabinet (enclosure)

CAUTION: No naked ame sources, such as lighted candles, should be placed on the apparatus.

Symbols

Refers to alternating current (AC).

Refers to direct current (DC).

Refers to class II equipment.

Refers to stand-by.

Refers to “ON” (power).

Refers to dangerous voltage.

Getting Started

Page 4

Table of Contents4

Table of Contents

1 Getting Started

2 Safety Information 6 Unique Features 7 Introduction 7 – Playable Discs 7 – About the “7” Symbol Display 7 – Symbols Used in this Manual 7 – Regional Codes 8 Playable file Requirement 8 – Music file requirement 8 – Photo file requirement 9 – Video file requirement 9 – Compatible USB Devices 9 – USB device requirement 10 Remote control 12 Front panel 14 Rear panel

2 Connecting

16 Connections to Your TV 16 – HDMI Out Connection 17 – Resolution Setting 18 Connecting to speakers 18 – Attaching the speakers to the unit 18 – Attaching the speaker light cables to the

unit 19 Optional Equipment Connection 19 – AUX IN 1 Connection 19 – AUX IN 2 Connection 20 – USB Connection 20 – Antenna Connection

3 System Setting

21 Adjust the setup settings 21 – OSD Initial language settings - Optional 21 – To display and exit the Setup menu 22 – Language 22 – Display 23 – Audio 24 – Lock (Parental Control)

4 Operating

25 Using the Home Menu 26 Basic Operations on Disc 27 Advanced Operations on Disc 27 – Displaying Disc Information

on-screen 27 – To display the DVD Menu 27 – To display the DVD title 27 – 1.5 times speed playback 27 – Screen Saver 28 – Starting play from selected time 28 – Resume playback 28 – Changing subtitle code page 29 – Marked Playback 30 – Viewing a PHOTO file 31 Basic Operations on USB 32 – Selecting a folder and

an MP3/WMA file 33 – Deleting a file/folder or format 34 Advanced Operations on USB 34 – JUKE BOX Playback 35 Playback Effect

35 – AUTO DJ

Page 5

Table of Contents 5

36 Using BLUETOOTH® wireless technology 36 – Listening to music stored on the Bluetooth

devices 39 Using the LG XBOOM App 39 – About “LG XBOOM” App 39 – Install “LG XBOOM” App onto Your

Bluetooth Device 40 – Activate Bluetooth with “LG XBOOM” App 41 Radio Operations 41 – Listening to the radio 41 – Improving poor FM reception 41 – Presetting the Radio Stations 41 – Deleting all the saved stations 42 Sound adjustment 42 – Setting the sound mode 43 Advanced Operations 43 – Recording to USB 45 Other Operations 45 – Turn off the sound temporarily

45 – DEMO

45 – Resume stop 45 – CHILDSAFE Mode 45 – Last Scene Memory 45 – Power Resume - Optional 45 – System Select - Optional 46 – Using Microphone

48 – LIGHTING

49 – Sleep Timer Setting

49 – Dimmer 50 – AUTO POWER On

50 – Auto function change 51 Setting the Clock 51 – Setting the Clock through “LG XBOOM” App 51 – Using your player as an alarm clock 52 LG Sound Sync 53 WIRELESS PARTY LINK Connection

5 Troubleshooting

54 Troubleshooting

54 – General

55 – NOTES to release Demo mode

6 Appendix

56 Controlling a TV with the Supplied Remote

Control 56 – Setting up the remote to control your TV 57 Area Code List 58 Language code List 59 Trademarks and Licenses 60 Maintenance 60 – Notes on Discs

60 – Handling the Unit

61 Specifications 62 Speakers specifications

Page 6

Getting Started6

Unique Features

BLUETOOTH®

Listens to music stored on your Bluetooth device.

Getting Started

AUTO DJ

Blends the end of one song into the beginning of another for seamless playback.

USB Direct Recording

Records music to your USB device.

LG XBOOM

LG XBOOM is an app designed to let you take control of some of LG’s latest audio devices. (Page 39-40)

LG Sound Sync

Controls volume level of this unit by the remote control of your LG TV that is compatible with LG Sound Sync.

Full HD up-scaling

Views Full HD picture quality with simple setup.

Page 7

Getting Started 7

Introduction

Playable Discs

This unit plays DVD±R/RW and CD-R/RW that contains audio titles, MP3, WMA and/or JPEG les. Some DVD±RW/DVD±R or CD-RW/CD-R cannot be played on this unit due to the recording quality or physical condition of the disc, or the characteristics of the recording device and authoring software.

DVD-VIDEO (8 cm/12 cm disc)

Discs such as movies that can be purchased or rented.

DVD±R (8 cm/12 cm disc)

Video mode and nalized only.

DVD-RW (8 cm/12 cm disc)

Video mode and nalized only.

DVD+R: Video mode only

Supports the double layer disc also.

DVD+RW (8 cm/12 cm disc)

Video mode and nalized only.

Audio CD: Music CDs or CD-R/CDRW in music CD format that can be purchased.

About the “7” Symbol Display

“7” may appear on your TV display during operation and indicates that the function explained in this owner’s manual is not available on that specic media.

Symbols Used in this Manual

y u

Note

Indicates special notes and operating features.

Caution

Indicates cautions for preventing possible damages from abuse.

DVD-Video, DVD±R/RW in Video mode or VR mode and nalized

Audio CDs

Video les contained in the Disc

Audio les contained in the Disc

Photo les contained in the Disc

Regional Codes

This unit has a regional code printed on the rear of the unit. This unit can play only DVD discs labeled same as the rear of the unit or “ALL”.

yMost DVD discs have a globe with one or more

numbers in it clearly visible on the cover. This number must match your unit’s regional code or the disc cannot play.

yIf you try to play a DVD with a different regional

code from your unit, the message “Check Regional Code” appears on the TV screen.

Getting Started

Page 8

Getting Started8

Playable file Requirement

Getting Started

Music file requirement

MP3/WMA le compatibility with this unit is limited as follows.

ySampling frequency: within 32 to 48 kHz (MP3),

within 32 to 48 kHz (WMA)

yBit rate: within 32 to 320 kbps (MP3),

40 to 192 kbps (WMA)

ySupport Version: v2, v7, v8, v9

yMaximum les: Disc: 999 / USB: 2,000

yMaximum folders : Disc: 99 / USB: 200

yFile extensions: “.mp3”/ “.wma”

yCertain MP3/WMA les may not be played

depending on the type or format of the le.

yCD-ROM le format: ISO 9660/ JOLIET

yWe recommend that you use Easy-CD Creator,

which creates an ISO 9660 le system.

yA protected le by DRM (Digital rights

management) cannot be played on the unit.

yThe DTS disc is not supported.

You have to set the disc format option to [Mastered] in order to make the discs compatible with the LG players when formatting rewritable discs. When setting the option to Live File System, you cannot use it on LG players.

(Mastered/Live File System: Disc format system for Windows Vista)

Photo file requirement

Photo le compatibility with this unit is limited as follows:

yMax pixel in width: 2760 x 2048 pixel

yMaximum les: Under 999

ySome discs may not operate due to a different

recording format or the condition of disc.

yFile extensions: “.jpg”

yCD-ROM le format: ISO9660/ JOLIET

Page 9

Getting Started 9

Video file requirement

Video le compatibility with this unit is limited as follows:

yAvailable resolution: within 720 x 576 (W x H)

pixels.

yThe le name of the Video subtitle should be

entered within 45 characters.

yIf there is impossible code to express in the Video

le, it may be displayed as “ _ “ mark on the display.

yFrame rate: less than 30 fps.

yIf the video and audio structure of recorded les is

not interleaved, either video or audio is outputted.

yPlayable Video le: “.avi”, “.mpg”, “.mpeg”

yPlayable Subtitle format: SubRip (*.srt/ *.txt), SAMI

(*.smi), SubStation Alpha (*.ssa/ *.txt), MicroDVD (*.sub/ *.txt), SubViewer 2.0 (*.sub/ *.txt), Vobsub (*.sub)

yPlayable Codec format:

“Xvid”, “MPEG-1”, “MPEG-2”

yPlayable Audio format: “AC3”, “PCM”, “MP3”,

“WMA”,

ySampling frequency: within 32 to 48 kHz (MP3),

within 32 to 48 kHz (WMA)

yBit rate: within 32 to 320 kbps (MP3),

40 to 192 kbps (WMA)

yFor Discs formatted in Live le system, you can not

it on this unit.

yIf the name of movie le is different from that of

the subtitle le, during playback of a Video le, subtitle may not be display.

yIf you play a Xvid le differ from Xvid spec, it may

not operate normally.

yIf you play GMC video le which is more than

1-warp point, video playback screen will not smooth.

Compatible USB Devices

y MP3 Player: Flash type MP3 player.

y USB Flash Drive:

Devices that support USB2.0 or USB1.1.

y The USB function of this unit does not support all

USB devices.

USB device requirement

yDevices which require additional program

installation when you have connected it to a computer, are not supported.

yDo not extract the USB device while in operation.

yFor a large capacity USB, it may take longer than a

few minute to be searched.

yTo prevent data loss, back up all data.

yIf you use a USB extension cable or USB hub, the

USB device is not recognized.

yUsing NTFS le system is not supported. (Only

FAT(16/ 32) le system is supported.)

yThis unit recognizes up to 2,000 les.

yExternal HDD, Card readers, Locked devices, or

hard type USB devices are not supported.

yUSB port of the unit cannot be connected to PC.

The unit cannot be used as a storage device.

ySome USB may not work with this unit.

Getting Started

Page 10

Getting Started10

(R03)

Remote control

Getting Started

Replacement of battery

Remove the battery cover on the rear of the remote control, and insert the battery with 4 and 5 matched correctly.

• • • • • • • • • • • • • •a • • • • • • • • • • • • •

(Standby): Turns the power on or off.

F (Function): Selects the function and input source.

Input source / Function Display

Disc DVD/CD

USB USB 1 / USB 2

AUX (3.5 mm) input AUX 1

AUX input AUX 2

Bluetooth BT

LG Sound Sync (Wireless) LG TV

Radio FM

(Open/Close): Opens and closes the disc tray.

0-9 numerical buttons: Selects numbered options in a menu.

AUTO DJ: Selects the AUTO DJ mode. (Page 35)

REPEAT: Listens to your les/tracks/chapters

repeatedly or randomly.

• • • • • • • • • • • • • •b • • • • • • • • • • • • •

(Skip): Skips backward or forward.

C/V

(Scan): Scans for a section within a track/file/

c/v

chapter.

(Stop):

- Stops playback.

- Cancels DELETE function.

(Play):

- Starts playback.

- Selects stereo/mono.

(Pause): Pauses playback.

SPECIAL EQ: Chooses special equalizer.

VOL (Volume) +/-: Adjusts speaker volume.

MARKER/JUKEBOX:

- Marks play list. (Page 29)

- Selects JUKE BOX mode. (Page 34)

- Makes JUKE BOX list.

EQUALIZER: Chooses sound impressions.

(Mute): Mutes the sound.

[

Page 11

Getting Started 11

• • • • • • • • • • • • • •c • • • • • • • • • • • • •

(Home): Displays the [Home Menu] on a DVD/CD

function.

DISC MENU: Accesses the menu on a DVD disc.

TITLE: If the current DVD title has a menu, the title

menu appears on the screen. Otherwise, the disc menu may not appear.

W/S/A/D

navigate on-screen displays.

PRESET/FOLDER +/-:

- Chooses a preset number for a radio station. (Page 41)

- Searches for a folder of MP3/WMA les. When a USB containing MP3/WMA les in several folders is being played, press PRESET/FOLDER +/- to select the folder you want to play.

TUNING +/-: Tunes in the desired radio station.

(Select):

- Acknowledges menu selection.

- Presetting the radio stations.

(Close): Moves backwards in the menu or exits

]

the setup menu.

INFO/DISPLAY

- Accesses On-Screen Display.

- Sees information about your music (USB). An MP3

le often come with ID3 tag. The tag gives the Title, Artist, Album or Time information.

- Sees Bluetooth device name of the unit in BT READY.

- Sees the name of connected all Bluetooth device in Bluetooth mode.

- When th ese units are successfully connected

each other in WIRELESS PARTY LINK mode, each of connected device names appears in the each unit.

CLEAR/DELETE:

- Removes a number when setting the password.

- Deletes MP3/WMA les. (USB only). (Page 33)

- Deletes a song on the JUKE BOX list.

- Deletes all the saved stations.

(up/ down/ left/ right): Used to

• • • • • • • • • • • • • •d • • • • • • • • • • • • •

CLOCK: Sets a clock and checks a time.

ALARM: With the ALARM function you can turn on

Discs, USB play and tuner reception at a desired time.

SET: Conrms the setting.

: This button is not available.

VOCAL EFFECTS: Selects various vocal effects mode.

SLEEP: Sets the system to turn off automatically at

a specified time. (Dimmer: The display window will be darkened by half.)

USB REC:

- Records to USB.

- Stops recording.

MIC (Microphone) ECHO: Selects ECHO mode

VOICE CANCELLER: You can reduce the vocal tones

during music playback from various input sources.

: This button is not available.

MIC VOL (Microphone Volume) -/+ : Adjusts microphone volume.

KEY CHANGER (L/l): Changes the key to suit your vocal range.

TV Control buttons: Controls the TV. (Page 56) You can control the TV on or off and input source.

Getting Started

Page 12

Front panel

Getting Started

Getting Started12

b c d e f

USB 1 Port

You can play sound files by connecting the USB

device.

(Standby)

b 1

Turns the power on or off.

Display window

(Remote sensor)

TWIN

e 3

Connects two speakers for TWIN mode in

WIRELESS PARTY LINK.

USB 2 Port

You can play sound files by connecting the USB

device.

VOLUME

- Adjust speaker volume.

- Adjust microphone volume.

MIC VOL (Microphone volume)

Selects microphone volume mode.

MIC (Microphone) ECHO

Selects ECHO mode.

VOICE CANCELLER

You can reduce the vocal tones during music

playback from various input sources.

VOCAL EFFECTS

Selects various vocal effects mode.

hijklmn

F (Function)

Selects the function and input source.

Input source / Function Display

Disc DVD/CD

USB USB 1 / USB 2

AUX (3.5 mm) input AUX 1

AUX input AUX 2

Bluetooth BT

LG Sound Sync (Wireless) LG TV

Radio FM

(Play/Pause)

- Starts or pauses playback.

- Selects stereo/mono.

(Skip/Scan)

- Skips forward.

- Scans for a section within a track/file/chapter.

- Selects the radio stations.

KEY CHANGER (L/l)

Changes the key to suit your vocal range.

Page 13

Getting Started 13

Disc tray

USB REC / DEMO

- Records to USB.

- Stops Recording.

- In power off status, if you press USB REC /

DEMO, show DEMO mode.

Z (Stop)

Stops playback or cancels DELETE function.

(Skip/Scan)

- Skips backward.

- Scans for a section within a track/le/chapter.

- Selects the radio stations.

B (Open/Close)

Opens and closes the disc tray.

AUTO DJ

Selects the AUTO DJ mode.

LIGHTING

Selects the lighting mode.

SPECIAL EQ / BASS BLAST (or BASS BLAST+)

- Chooses special equalizer.

- Press and hold to select BASS (or BASS+) effect

directly.

Moves to folder or file in selection mode.

(USB only)

Selects a folder when searching a file.

MIC (Microphone) jack

AUX IN 1 jack

EQUALIZER / SEARCH & MULTI

- Chooses sound impressions.

- Searches a folder or a le. (USB only)

- Selects the lighting effects.

Getting Started

Page 14

Getting Started14

Rear panel

ba c d e

Getting Started

100 100

g f

Power cord

SPEAKERS terminals

SPEAKER LIGHTING SYSTEM

Connect the speaker lighting cables.

AUX IN 2 (L/R)

Connect an auxiliary device.

ANTENNA (FM)

HDMI OUT TO TV

Connect to TV.

SERVICE ONLY

S/W download connector.

Page 15

Useful functions for using the unit

Function Description To do Do this

BT Lock On/Off

(Page 38)

Auto Power On

(Page 50)

It allows you to connect a Bluetooth device only on BT (Bluetooth) and LG TV functions.

Initial setting of this function was set to off.

It allows the unit to turn on automatically by input signals: BT (Bluetooth) or LG TV

ON Press and hold X on the remote control

or N on the unit for 5 seconds in BT (Bluetooth) function.

OFF Press and hold X on the remote control

or N on the unit for 5 seconds in BT (Bluetooth) function.

ON Turn off the unit by pressing 1 on the unit

for 5 seconds.

OFF Turn off the unit by pressing 1 on the unit

for 5 seconds.

Getting Started 15

Getting Started

Page 16

Connecting16

Connections to Your TV

HDMI Out Connection

If you have a HDMI TV or monitor, you can connect it to this unit using a HDMI cable (Type A, High Speed HDMI™ Cable). Connect the HDMI OUT jack on the unit to the HDMI IN jack on a HDMI compatible TV or monitor.

Set the TV’s source to HDMI (refer to TV’s Owner’s

Connecting

manual).

100 100

Unit

Caution

yChanging the resolution when the connection

has already been established may result in malfunctions. To solve the problem, turn off the unit and then turn it on again.

yWhen the HDMI connection with HDCP is

not veried, TV screen is changed to black or green screen or the snow noise may occur on the screen. In this case, check the HDMI connection, or disconnect the HDMI cable.

yMake sure the unit is connected directly to

the TV. Tune the TV to the correct video input channel.

Note

yYou can fully enjoy digital audio and video

signals together with this HDMI connection.

yWhen you use HDMI connection, you can

change the resolution for the HDMI output. (Page 17)

Page 17

Note

yIf a connected HDMI device does not accept

the audio output of the unit, the HDMI device’s audio sound may be distorted or may not output.

yWhen you connect a HDMI or DVI compatible

device make sure of the following:

- Try switching off the HDMI/DVI device and this unit. Next, switch on the HDMI/DVI device and leave it for around 30 seconds, then switch on this unit.

- The connected device’s video input is set correctly for this unit.

- The connected device is compatible with 720 x 480i (or 576i), 720 x 480p (or 576p), 1280 x 720p, 1920 x 1080i or 1920 x 1080p video input.

yNot all HDCP-compatible HDMI or DVI devices

will work with this unit.

- The picture will not be displayed properly with non-HDCP device.

- This unit does not playback and TV screen is changed to black or green screen or the snow noise may occur on the screen.

yIf there is noise or lines on the screen, please

check the HDMI cable and use a higher version cable than High Speed HDMI™ Cable.

yThe HDMI sounds output only DVD/CD

function.

Connecting 17

Resolution Setting

The unit provides several output resolutions for HDMI. You can change the resolution using [Setup] menu.

1. Press ! on the remote control.

2. Use

W/S/A/D

select the [Setup] and press m on the remote control. The [Setup] menu appears.

3. Use

W/S

[Display] option then press D on the remote control to move to the second level.

4. Use

W/S

[Resolution] option then press D on the remote control to move to the third level.

5. Use

W/S

desired resolution then press m on the remote control to confirm your selection.

Note

yIf your TV does not accept the resolution you

have set on the player, you can set resolution to 480p (or 576p) as follows: Press Z for more than 5 seconds.

y[Home Menu] appears only on DVD/CD

function.

on the remote control to

on the remote control to select

on the remote control to select the

Connecting

Page 18

Connecting18

Connecting to speakers

Attaching the speakers to the unit

To connect the cable to the unit, press each plastic nger pad to open the connection terminals on the unit. Insert the wire and release the nger pad.

Connect the black of each wire to the terminals

Connecting

marked - (minus) and the other end to the terminals marked + (plus).

Attaching the speaker light cables to the unit

To connect the speaker light cable to the unit, insert the cable to SPEAKER LIGHTING SYSTEM connectors on the unit.

Caution

yWhen you connect the speakers to the unit,

make sure to connect the speaker’s cable and plug to the corresponding speaker connector.

yCheck the volume level before playing music

to prevent inrm, child, and pregnant women from being shocked by the sudden and loud sound from the unit.

yDo not use the unit in a limited space. It may

damage a person’s hearing. It is recommended to use it in a wide space.

yUse the speaker supplied with this unit

only. Using any other speaker may cause malfunction.

yThe speakers contain magnet parts, so color

irregularity may occur on the TV screen or PC monitor screen. Please use the speakers far away from either TV screen or PC monitor.

yAvoid looking at the speaker lights for a long

time. It may cause damage to eyesight.

Caution

yMake sure that the jacks and the speakers

are matched correctly.

yMake sure to connect the cables to

connectors tightly on the unit.

Page 19

Connecting 19

Optional Equipment Connection

AUX IN 1 Connection

Connect an output (earphone or line out) of portable device (MP3 or PMP etc) to the AUX IN 1 (3.5 mm) connector.

3.5 mm stereo cable

AUX IN 2 Connection

Connect an output of auxiliary device (Camcorder, TV, Player, etc) to the AUX IN 2 (L/R) connector.

If your device has only one output for audio(mono), connect it to the left(white) audio jack on the unit.

100 100

White

Red

DVD, Blu-ray player etc.

Audio cable

Connecting

Listening to music from your portable player or external device

The unit can be used to play the music from many types of portable player or external device.

1. Connect the portable player to the AUX IN 1 connector of the unit.

Connect the external device to the AUX IN 2

connector of the unit.

2. Turn the power on by pressing 1.

3. Press

4. Turn on the portable player or external device and

to select AUX 1 or AUX 2 function.

start it playing.

Note

Automatically switches to the AUX 1 function when you connect the portable device to the AUX IN 1 connector.

Page 20

Connecting20

USB Connection

Connect a USB device (or MP3 player, etc.) to the USB ports on the unit.

USB device

Connecting

Note

Removing the USB device from the unit:

1. Choose a different function/mode or press twice in a row.

2. Remove the USB device from the unit.

Antenna Connection

Connect the supplied FM antenna for listening to the radio.

FM antenna

100 100

Note

Be sure to fully extend the FM wire antenna.

Page 21

System Setting 21

Adjust the setup settings

By using the Setup menu, you can make various adjustments to items such as picture and sound.

You can also set a language for the subtitles and the Setup menu, among other things. For details on each Setup menu item, see pages 21 to 24.

OSD Initial language settings Optional

During the rst use of this unit, the initial language setup menu appears on your TV screen. You must complete initial language selection before using the unit. English will be selected as the initial language.

1. Press 1 to turn the unit on. The language setup menu will appear on the screen.

2. Use

W/S/A/D

select a language then press m on the remote control. The confirm menu will appear.

3. Use

A/D

[Enter] then m on the remote control to finish the language setup.

on the remote control to

on the remote control to select the

To display and exit the Setup menu

1. Press !on the remote control. Displays the [Home Menu].

2. Select an [Setup] by using control.

3. Press mon the remote control. Displays the [Setup].

4. Press !on the remote control or ] on the remote control to exit in the [Setup] Menu.

About help menu for Setup

Menu Buttons Operation

W/S

Move

]

Select

[Home Menu] appears only on DVD/CD function.

Note

W/S

]

on the remote

A/D

Moving to another menu.

Moving to previous level.

Moving to next level or selecting menu.

To exit the [Setup] menu.

To conrm menu.

System Setting

Page 22

System Setting22

Language

Menu Language

Select a language for the Setup menu and on screen display.

Disc Audio / Disc Subtitle / Disc Menu

Select the language you prefer for the audio track (disc audio), subtitles, and the disc menu.

[Original]

Refers to the original language in which the disc was recorded.

System Setting

[Other]

To select another language, press numeric buttons and then m on the remote control to enter the corresponding 4-digit number according to the language code list on the page

58. If you enter the wrong language code, press

CLEAR/DELETE on the remote control.

[Off (for Disc Subtitle)]

Turns off Subtitle.

Display

TV Aspect

Select the screen aspect to use based on the shape of your TV screen.

[4:3]

Select when a standard 4:3 TV is connected.

[16:9]

Select when a 16:9 wide TV is connected.

Display Mode

The Display Mode setting works only when the TV Aspect mode is set to 4:3.

[Letterbox]

Displays a wide picture with bands on the upper and lower portions of the screen.

[Panscan]

Automatically displays the wide picture on the entire screen and cuts off the portions that do not t. (If the disc/le is not compatible with Pan Scan, the picture is displayed at Letterbox ratio.)

Resolution

Sets the output resolution of HDMI video signal. Refer to “Resolution Setting” for details about the resolution (page 17).

[Auto]

If the HDMI jack is connected to TVs providing display information (EDID), automatically selects the resolution best suited to the connected TV.

[1080p]

Outputs 1080 lines of progressive video.

[1080i]

Outputs 1080 lines of interlaced video.

[720p]

Outputs 720 lines of progressive video.

[480p (or 576p)]

Outputs 480 (or 576) lines of progressive video.

[480i (or 576i)]

Outputs 480 (or 576) lines of interlaced video.

Page 23

Audio

DRC (Dynamic Range Control)

Make the sound clear when the volume is turned down and prevent a sudden sound increase (Dolby Digital only). Set to [On] for this effect.

HD AV Sync

Sometimes Digital TV encounters a delay between picture and sound. If this happens you can compensate by setting a delay on the sound so that it effectively ‘waits’ for the picture to arrive: this is called HD AV Sync. Use to scroll up and down through the delay amount, which you can set at anything between 0 and 300ms.

on the remote control

W/S

System Setting 23

System Setting

Page 24

System Setting24

Lock (Parental Control)

Initial Setting the Area Code

When you use this unit for the rst time, you have to set the Area Code.

1. Select the [Lock] menu and then press D on the remote control.

2. Press D on the remote control. To access the [Lock] options, you must input the password you have created. Input a password and press m on the remote control. Enter it again and press m on the remote control to verify. If you make a mistake before pressing m on the

System Setting

remote control, press CLEAR/DELETE on the remote control.

3. Select the first character using remote control.

4. Press m on the remote control and select the second character using control.

5. Press m on the remote control to confirm your Area code selection.

W/S

Rating

Blocks playback of rated DVDs based on their contents. Not all discs are rated.

1. Select [Rating] on the [Lock] menu then press D on the remote control.

2. Input a password and press m on the remote control.

3. Select a rating from 1 to 8 using the the remote control.

[Rating 1-8]

Rating one (1) has the most restrictions and rating eight (8) is the least restrictive.

[Unlock]

If you select unlock, parental control is not active and the disc plays in full.

4. Press m on the remote control to confirm your rating selection.

on the

W/S

on the remote

W/S

Password

You can enter or change password.

1. Select [Password] on the [Lock] menu and then press D on the remote control.

2. Press m on the remote control.

3. Input a password and press m on the remote control.

To change the password, press m on the remote

control when the [Change] option is highlighted. Input a password and press m on the remote control. Enter it again and press m on the remote control to verify.

4. Press ! on the remote control to exit the menu.

Note

If you forget your password, you can clear it using the following steps:

1. Select the [Setup] menu on the [Home Menu].

2. Input the 6-digit number “210499” and pressmon the remote control. The password is cleared.

Area Code

Enter the code of the area whose standards were used to rate the DVD video disc, based on the list on page 57.

1. Select [Area Code] on the [Lock] menu then press D on the remote control.

2. Input a password and press m on the remote control.

3. Select the first character using remote control.

4. Press m on the remote control and select the second character using control.

5. Press m on the remote control to confirm your Area code selection.

W/S

on the

W/S

on the remote

Page 25

Using the Home Menu

1. Press !on the remote control. Displays the [Home Menu].

Operating 25

2. Select an option by using control.

3. Press m on the remote control then selected option menu.

[Music] – Displays [MUSIC] menu.

[Movie] – Start video media’s playback or displays the

[MOVIE] menu.

[Photo] – Displays [PHOTO] menu.

[Setup] – Displays the [SETUP] menu.

Note

y[Home Menu] appears only on DVD/CD

function.

yUSB function is only available on music

playback.

A/D

on the remote

Operating

Page 26

Operating26

Basic Operations on Disc

1. Insert the disc by using the B.

2. Press ! on the remote control. Displays the [Home Menu].

Select an option by using control

4. Press m on the remote control then selected option menu.

To Do this

Stop Press Z.

Playback

Pause

Operating

Frame-by-

Frame playback

Skipping to the

next/ previous

chapter/ track/

le

Press X on the remote control or N on the unit.

Press M on the remote control

or N on the unit.

Press M on the remote control

repeatedly to play title Frameby-Frame. (DVD Movie title, Movie le only)

During playback, press

C/V

chapter/ track/ le or to return to the beginning of the current chapter/ track/ le.

Press C twice briey to step

back to the previous chapter/ track/ le.

A/D

to go to the next

on the remote

To Do this

Press h REPEAT on the remote control repeatedly, and the current title, chapter

Playing

repeatedly or

randomly

Slowing down

the playing

speed

Selecting

a track/le

directly

or track will be played back repeatedly or randomly.

- DVD: Chapter/ Title/ Off

- Video(MOVIE): Title/ All/ Off

- Audio CD/ MP3/ WMA: Track/ All/ Random/ Off

In the pause mode

c/v

r press and hold the unit repeatedly required speed. (DVD Movie title only)

In the pause mode, press

on the remote control

or press and hold V unit repeatedly required speed. (Movie le only)

Press 0 to 9 numerical buttons on the remote control to go to the desired le or track directly.

on the remote control

Press

C/V

to select the

on the

l to select the

Locating a

point quickly by

playing a le in

fast forward or

fast reverse

During playback, press on the remote control or press and hold

C/V

repeatedly to select the required scan speed.

To return to normal speed, press X on the remote control or N on the unit.

c/v

on the unit

Page 27

Operating 27

Advanced Operations on Disc

Displaying Disc Information on-screen

You can display various information about the disc loaded on-screen.

1. Press m INFO/DISPLAY on the remote control to show various playback information. The displayed items differ depending on the disc type or playing status.

2. You can select an item by pressing remote control and change or select the setting by pressing

Title – Current title number/ total number of titles.

Chapter – Current chapter number/ total number of

Time – Elapsed playing time.

Audio – Selected audio language or channel.

Subtitle – Selected subtitle.

Angle – Selected angle/ total number of angles.

chapters.

Note

If any button is not pressed for a few seconds, the on-screen display disappears.

on the remote control.

A/D

W/S

on the

To display the DVD title

When you play a DVD which contains several title, you can select the title you want using the Menu.

1. Press TITLE on the remote control. The disc’s title appears.

2. Select the menu by pressing the remote control.

3. Press m on the remote control to conrm.

W/S/A/D

1.5 times speed playback

The 1.5 speed allows you to watch the pictures and listen to the sound quicker than playing at a normal speed.

1. During playback, press X on the remote control to play at 1.5 times speed. “dX1.5” appears on the screen.

2. Press X on the remote control again to exit.

Screen Saver

The screen saver appears when you leave the unit in Stop mode for about ve minutes.

Operating

To display the DVD Menu

When you play a DVD which contains several menu, you can select the menu you want using the Menu.

1. Press DISC MENU on the remote control. The disc’s menu appears.

2. Select the menu by using remote control.

3. Press m on the remote control to conrm.

W/S/A/D

on the

Page 28

Operating28

Starting play from selected time

To start playing at any chosen time on the le or title.

1. Press m INFO/DISPLAY on the remote control during playback.

2. Press time clock icon and “--:--:--” appears.

3. Input the required start time in hours, minutes, and seconds from left to right. If you enter the wrong numbers, press CLEAR/ DELETE on the remote control to remove the numbers you entered. Then input the correct numbers. For example, to nd a scene at 1 hour, 10 minutes, and 20 seconds, enter “11020” by using numerical buttons on the remote control.

4. Press m on the remote control to conrm. Playback starts from the selected time.

Operating

on the remote control to select the

W/S

Resume playback

ryut

The unit records the point where you pressed the Z depending on the disc. If “MZ (Resume Stop)” appears on the screen briey, press X on the remote control or N on the unit to resume playback (from the scene point).

If you press Z twice or unload the disc, “Z”(Complete Stop) appears on the screen. The unit will clear the stopped point.

Note

yThe resume point may be cleared when a

button is pressed (for example; 1, B, etc).

yThis function may not work on some disc or

title/track.

Changing subtitle code page

If the subtitle is not displayed properly, you can change the subtitle code page to view the subtitle le properly.

1. During playback, press m INFO/DISPLAY on the remote control to display the On-Screen display.

2. Use [Code Page] option.

3. Use desired code option.

4. Press ] on the remote control to exit the OnScreen display.

on the remote control to select the

W/S

on the remote control to select

A/D

Page 29

Operating 29

Marked Playback

The mark function enables you to store your favourite les from any disc in the unit memory.

1. Select [Music] on the [Home Menu].

Returning to the upper folder. (MP3/ WMA only)

File information will be displayed according to the ID3 TAG information on the appropriate music le. (MP3 only)

Selecting all tracks/les.

Deselecting all tracks/les.

Moving to the previous or next

2. Select a desired music on the [List] by using the

3. Press mon the remote control.

4. Select the play mode by using the

on the remote control then press

W/S

MARKER/JUKEBOX on the remote control to appears the mark on the list.

Displays the play mode.

the remote control and press mon the remote control.

W/S

le list.

To delete a Marker

1. Use track that you wish to erase from the marked le.

2. Press MARKER/JUKEBOX on the remote control.

on the remote control to select the

W/S

To delete all Markers

Use

W/S/A/D

[Deselect All] then press m on the remote control in program edit mode.

Note

The markers are also cleared when the disc is removed, the unit is switched to power off or the function is switched to others.

on the remote control to select

Operating

[Mark Play]

Marked playback.

[Current Play]

Normal playback.

Note

If you want to select all les on the list, select [Select All] and press m on the remote control.

Page 30

Operating30

Viewing a PHOTO file

This unit can play discs with photo les.

1. Select [Photo] on the [Home Menu] and press on the remote control

Moving to the previous or next

Returning to the upper folder.

Operating

2. Press

folder, and then press mon the remote control.

3. If you want to view a slide show, press

the remote control to highlight a file and press

on the remote control.

About help menu in the [Photo] menu

Menu Buttons Operation

Slide

Show

W/S/

A/D

Move

Select

]

on the remote control to select a

W/S

W/S/A/D

]

le list.

W/S

Viewing a slide show.

Moving to another le or content.

Viewing a particular le.

Returning to the [Home Menu].

About help menu in the full screen

Menu Buttons Operation

INFO/

DISPLAY

A/D

a/d

Prev./ Next

]

List

Options while viewing a photo

You can use various options during viewing a photo in full screen.

1. While viewing a photo in full screen, press INFO/DISPLAY on the remote control to

display the option menu.

2. Select an option using

remote control.

Displaying the Option menu.

Moving to another le.

Returning to the

]

[Photo] menu.

W/S/A/D

on the

b c d e

Current photo/ Total number of photos –

Use

previous/next photo.

Slide Show d/M – Press m on the remote

control to start or pause slide show.

Speed x3/ x2/ x1 – Use m on the remote

control to select a delaying speed between photos in a slide show.

Rotate – Press m on the remote control to

rotate the photo.

Go to list – Press m on the remote control to

return [Photo] menu.

on the remote control to view

A/D

Page 31

Basic Operations on USB

1. Connect the USB device to the USB port.

Select USB function by pressing F.

To Do this

Stop Press Z.

Playback

Pause

Scanning for a section within

a le

Selecting a le

directly

Skipping to

the next/

previous le

Press X on the remote control or

on the unit

Press M on the remote control or

on the unit.

Press and hold C/V or

on the remote control

c/v

during playback and release it at the point you want to listen to.

Press 0 to 9 numerical buttons on the remote control to go to the desired le directly.

- In stop status,

Press C/V to go to the next/

previous le.

- During playback,

(1) By using C/V buttons:

Press V to go to the next le.

Playing in less than 3 seconds, press C to go to the previous le.

Playing after 3 seconds, press C to go to the beginning of the le.

(2) By using SEARCH buttons:

Rotate EQUALIZER / SEARCH & MULTI on the unit or C/V and press N on the unit to play the le.

Operating 31

Note

yRepeat/Shufe playback operates as follows.

On Diplay Description

OFF

ONE Plays a same song repeatedly.

FOLDER Plays songs in a folder repeatedly.

ALL Plays all the songs on repeatedly.

SHUFFLE

yWhen you play JUKE BOX list, only ONE and

ALL are available.

yEven after restarting the unit or switching

one function to another, you can listen to music from the point where it’s last been played.

yUSB function is only available on music

playback.

Plays songs in order and stops the playback.

Plays all the songs once randomly, and stops the playback.

Operating

Playing

repeatedly or

randomly

Press h REPEAT on the remote control repeatedly. Refer to the note for details about the display change.

Page 32

Operating32

Selecting a folder and an MP3/WMA file

On the unit

1. Press SEARCH and rotate EQUALIZER / SEARCH & MULTI or C/V until a desired file

appears. You can also search a folder if you press SEARCH again.

2. Press OK or N to play the selected file. When you search a folder, press OK to select a file in the folder, then press OK or N again. The selected file is played.

On the remote control

1. Press PRESET/FOLDER +/- repeatedly until a desired folder appears.

2. Select the file you want by using C/V.

3. Press X to play it.

Operating

Note

yUSB Folders/Files are recognized as below.

yIf there is no le in a folder, the folder will not

appear.

yFolders will be presented as the following

order; ROOT

FOLDER 1 FOLDER 3 FOLDER 7 FOLDER 8 FOLDER 5 FOLDER 6

yFile will be played from $ le No.1 to $ le

No.14 one by one.

yFiles and folders will be presented in order

recorded and may be presented differently according to the record circumstances.

*ROOT: The rst screen you can see when a computer recognize the USB is “ROOT”.

Page 33

Deleting a file/folder or format

You can delete le, folder on your USB or format the USB.

1. Select USB function by pressing F.

2. Press CLEAR/DELETE on the remote control repeatedly, the display changes as followings.

DEL FILE

On Display Description

DEL FILE Select the le you want to delete

DEL DIR

FORMAT Select to format the USB device.

If you want to exit the current mode, press Z.

3. To delete file/folder or format, press and hold CLEAR/DELETE on the remote control.

yDo not extract the USB device during

operation. (play, delete, etc.)

yRegular back up is recommended to prevent

data loss.

yThe delete function may not be supported

according to the USB status. (lock, etc.)

DEL DIR FORMAT

Select the folder you want to

delete

Caution

Operating 33

Operating

Page 34

Operating34

Advanced Operations on USB

JUKE BOX Playback

JUKE BOX function enables you to make a playlist of your favorite les from a USB. A playlist of up to 100 les can be entered.

Making JUKE BOX list

1. Press and hold MARKER/JUKEBOX on the remote control to enter the edit mode. (Playing will be stopped when you press MARKER/JUKEBOX on the remote control.)

2. Select a file by pressing C/V on the remote control.

3. Press MARKER/JUKEBOX on the remote control

Operating

to save the file.

4. Repeat steps 2 - 3 to store other files. (You can modify the list by pressing PRESET/ FOLDER +/- on the remote control to select the JUKE BOX program number.)

5. Press MARKER/JUKEBOX on the remote control once again.

To play the JUKE BOX list, press X on the remote control after you make the list.

Note

When making or modifying the JUKE BOX list, REPEAT mode is off.

Enjoying JUKE BOX

Press MARKER/JUKEBOX on the remote control once. “ON - JUKE BOX” appears on the display window.

To play JUKE BOX list, press X on the remote control.

To cancel it, press MARKER/JUKEBOX on the remote control once. “OFF - JUKE BOX” appears on the display window.

Editing JUKE BOX

1. Press and hold MARKER/JUKEBOX on the remote control to enter the edit mode. (Playing will be stopped when you press MARKER/JUKEBOX on the remote control.)

2. Press PRESET/FOLDER +/- on the remote control to select a file to edit.

3. Press C/V on the remote control.

4. Press MARKER/JUKEBOX on the remote control.

5. Repeat 2 to 4 to store the other files.

6. Press MARKER/JUKEBOX on the remote control once again.

To play the JUKE BOX list, press X on the remote control after you edit the list.

Deleting JUKE BOX list

Deleting function only works in the edit mode.

1. Press and hold MARKER/JUKEBOX on the remote control to enter the edit mode.

Press CLEAR/DELETE on the remote control

while JUKE BOX is played to enter the edit mode.

2. Select a song by pressing PRESET/FOLDER

on the remote control repeatedly.

3. Press CLEAR/DELETE on the remote control while a song is selected.

Note

yIf there is no JUKE BOX list, “NO PROG”

appears on the display window when you press MARKER/JUKEBOX on the remote control.

yJUKE BOX is switched off in the case below.

- Changing to a different function.

- Turning off and on the unit.

- Operating the numerical buttons on the

remote control.

- Playing a le by using SEARCH and EQUALIZER / SEARCH & MULTI on the

unit.

yJUKE BOX list is cleared in the case below.

- Removing the USB device.

- Deleting or recording music les in the USB

device.

+/-

Page 35

Playback Effect

AUTO DJ

AUTO DJ blends the end of one song into the beginning of another for seamless playback. It equalizes volume across tracks/les for uninterrupted playback.

Press AUTO DJ on the remote control repeatedly, the display changes as followings.

RANDOM (SHUFFLE)

On Display Description

OFF -

RANDOM

(SHUFFLE)

SEQUENTIAL

Note

yAUTO DJ mode does not support searching

for a section within a track/le or to play repeatedly or randomly.

yIf you move to other functions or stop the

music using Z on AUTO DJ mode, AUTO DJ will be disabled.

yAUTO DJ is not supported in the music le

whose length is less than 60 seconds.

yOnly SEQUENTIAL is selected when played

JUKE BOX list.

yIn USB function, SHUFFLE displays instead of

RANDOM.

SEQUENTIAL OFF

The music is played randomly on this mode.

The music is played repeatedly on this mode.

Operating 35

Operating

Page 36

Operating36

Using BLUETOOTH® wireless technology

About Bluetooth

Bluetooth is wireless communication technology for

short range connection.

The sound may be interrupted when the connection interfered by the other electronic wave or you connect the Bluetooth in the other rooms.

Connecting individual devices under Bluetooth wireless technology does not incur any charges. A mobile phone with Bluetooth wireless technology can be operated via the Cascade if the connection was made via Bluetooth wireless technology.

yAvailable Devices: Smart phone, MP3, Notebook,

etc.

yVersion: 4.0

yCodec: SBC, AAC

Operating

Bluetooth Profiles

In order to use Bluetooth wireless technology, devices must be able to interpret certain proles. This unit is compatible with following prole.

A2DP (Advanced Audio Distribution Prole)

Listening to music stored on the Bluetooth devices

Pairing your unit and Bluetooth device

Before you start the pairing procedure, make sure the Bluetooth feature is activated on your Bluetooth device. Refer to your Bluetooth device’s user guide. Once a pairing operation is performed, it does not need to be performed again.

1. Turn on the unit.

Note

When Bluetooth connection lock is activated, you can search Bluetooth device in BT function.

2. Operate the Bluetooth device and perform the pairing operation. When searching for this unit with the Bluetooth device, a list of the devices found may appear in the Bluetooth device display depending on the type of Bluetooth device. Your unit appears as “LG CL65D (XX)”.

Note

yXX means the last two digits of

Bluetooth address. For example, if your unit has a Bluetooth address such as 9C:02:98:4A:F7:08, you will see “LG CL65D (08)” on your Bluetooth device.

yDepending on the Bluetooth device type,

some devices have a different pairing way. For details about Bluetooth pairing, refer to your Bluetooth device manual.

yYou can connect this unit with up to 3

Bluetooth devices simultaneously using the same method as described above, only in the Bluetooth function.

yThe multi phone pairing connection is only

supported on Android devices. (Multi phone pairing connection may not be supported depending on the connected device specications.)

yRemovable/detachable Bluetooth devices

(Ex: Dongle etc.) will not support multi phone pairing.

Page 37

Operating 37

3. When this unit is successfully connected with your Bluetooth device, “PAIRED” appears on the display window and change to Bluetooth device name soon. Then “BT” will appear on the display window.

Note

y“PAIRED” will momentarily appear on the

display when you connect other devices for multi phone pairing.

yIf the device name is unavailable, “_” will be

displayed.

4. Listen to music. To play a music stored on your Bluetooth device, refer to your Bluetooth device’s user guide.

Note

yWhen using Bluetooth technology, you have

to make a connection between the unit and the Bluetooth device as close as possible and keep the distance. However, it may not work well in certain situations as described below:

- There is an obstacle between the unit and the Bluetooth device.

- There is a device using same frequency

with Bluetooth technology such as a medical equipment, a microwave or a wireless LAN device.

yIf Bluetooth connection does not work well,

try pairing it again.

yEven if this unit is connected to up to 3

Bluetooth devices in the Bluetooth mode, you can play and control music by using only one of the connected devices.

Note

yThe sound may be interrupted when the

connection has interference from other electronic devices.

yDepending on the type of the device, you may

not be able to use the Bluetooth function.

yYou can enjoy wireless system using phone,

MP3, Notebook, etc.

yThe more distance between the unit and the

Bluetooth device, the lower the sound quality becomes.

yBluetooth connection will be disconnected

when the unit is turned off or the Bluetooth device gets too far from the unit.

yWhen Bluetooth connection is disconnected,

connect the Bluetooth device to the unit again.

yWhen a Bluetooth device is not connected,

“BT READY” appears on the display window.

yWhen you use the Bluetooth function,

adjust the volume to a proper level on the Bluetooth device.

yWhen you connect Bluetooth device (iOS

device etc.) to this unit or operate the device, the volume level can be synchronized with each other.

yBluetooth connection will be disconnected

when you change the Bluetooth function to some other function. In “LG XBOOM” app connection, only one device which you are playing keeps Bluetooth connection. You can control the Bluetooth device with this unit but you cannot use sound output.

yWhen entering the Bluetooth function,

this unit automatically connects to the last connected Bluetooth device or the device which played back last. (Auto connection may not be supported depending on the connected device specications.)

Operating

Page 38

Operating38

Controls connected Bluetooth device

You can control connected Bluetooth device by the unit; play, pause, stop, skip.

Note

yOnly Android OS and iOS is available to use

this function.

yThis function may not be supported

depending on the Bluetooth device, or operated differently.

Bluetooth connection lock (BT LOCK)

You can limit Bluetooth connection to only BT (Bluetooth) and LG TV function to prevent unintended Bluetooth connection.

To turn this function on, press and hold Xon the remote control or N on the unit for 5 seconds in BT (Bluetooth) function. “ON-BT LOCK” appears then you can limit Bluetooth

connection.

Operating

To turn this function off, press and hold Xon the remote control or N on the unit for 5 seconds in BT (Bluetooth) function.

“OFF-BT LOCK” appears.

Note

Even if you set up Bluetooth connection lock to On, this unit turns on by Auto Power function. Turn off Auto Power function to prevent it. (Page 50)

Page 39

Operating 39

Using the LG XBOOM App

Note

yOnly Android OS is available to use “LG

XBOOM” app with this unit.

yIt is recommended to use the latest version

of app.

About “LG XBOOM” App

“LG XBOOM” app brings a suite of new features to this unit.

To enjoy more features, you are recommended to download and install free “LG XBOOM” app.

Below introduces you to a feature of “LG XBOOM” app.

Multi Juke box: Your entertainment increases three fold when you connect up to 3 Bluetooth phones at the same time. Play music from three phones and create a customized playlist from all phones.

Install “LG XBOOM” App onto Your Bluetooth Device

There are two ways to install “LG XBOOM” App onto Your Bluetooth Device.

Install “LG XBOOM” App through QR code

1. Install “LG XBOOM” app through QR code. Use the scanning software to scan the QR code.

2. Tap an icon for installation.

Note

yMake sure that your Bluetooth device is

connected to the Internet.

yMake sure that your Bluetooth device

has a scanning software application. If you don’t have one, download one from “Google Android Market (Google Play Store)”.

yDepending on the area, QR code may not

work.

Operating

Page 40

Operating40

Install “LG XBOOM” App through “Google Android Market (Google Play Store)”

1. Tap the “Google Android Market (Google Play Store)” icon.

2. In the search bar, type in the “LG XBOOM” and search it.

3. In the search result list, find and tap “LG XBOOM” to start downloading Bluetooth app.

4. Tap an icon for installation.

Note

yMake sure that your Bluetooth device is

connected to the Internet.

yMake sure that your Bluetooth device is

equipped with “Google Android Market (Google Play Store)”.

Operating

Activate Bluetooth with “LG XBOOM” App

“LG XBOOM” app helps to connect your Bluetooth device to this unit.

Tap “LG XBOOM” app icon on the home screen to open “LG XBOOM” app, and go to the main menu.

Note

y“LG XBOOM” app will be available in the

software version as follow;

- Android O/S: Ver 5.0 (or later)

yIf you use “LG XBOOM” app for operation,

there would be some differences between “LG XBOOM” app and the supplied remote control. Use the supplied remote control as necessary.

yDepending on the Bluetooth device, “LG

XBOOM” app may not work.

yAfter connection of “LG XBOOM” app, music

may be output from your Bluetooth device. In this case, try connecting procedure again.

yIf you operate the other applications or

change the settings on your Bluetooth device while using “LG XBOOM” app, “LG XBOOM” app may operate abnormally.

yWhen “LG XBOOM” app operates abnormally,

check your Bluetooth device and the connection of “LG XBOOM” app and then try to connect again.

yDepending on the smart phone's operating

system, you have some differences for “LG XBOOM” operation.

yCheck Bluetooth setting on your Bluetooth

device if “LG XBOOM” app connection does not work well.

Page 41

Operating 41

Radio Operations

Be sure that FM antenna is connected. (Page 20)

Listening to the radio

1. Press F until FM appears in the display window. The last received station is tuned in.

2. Auto tuning: Press and hold TUNING-/+ on the remote control or C/V on the unit until the frequency indication starts to change, then release. Scanning stops when the unit tunes in a station.

Manual tuning:

Press TUNING-/+ on the remote control or

C/V

3. Adjust the volume by pressing VOL +/- on the remote control or rotating VOLUME knob on the unit repeatedly.

Improving poor FM reception

Press X on the remote control or N on the unit.

This will change the tuner from stereo to mono and usually improve the reception.

on the unit repeatedly.

Presetting the Radio Stations

You can preset 50 stations for FM.

Before tuning, make sure to turn down the volume.

1. Press F until FM appears in the display window.

2. Select the desired frequency by pressing TUNING-/+ on the remote control or C/V on the unit.

3. Press m on the remote control. A preset number will blink in the display window.

4. Press PRESET/FOLDER +/- on the remote control to select the preset number you want.

5. Press m on the remote control. The station is stored.

6. Repeat steps 2 to 5 to store other stations.

7. To listen a preset station, press PRESET/FOLDER +/- or 0 to 9 numerical buttons on the remote control.

Deleting all the saved stations

1. Press CLEAR/DELETE on the remote control. “DEL ALL” will flash up on the display window

2. Press CLEAR/DELETE on the remote control to erase all the saved radio stations. “DELETED ALL” will flash up on the unit display.

Operating

Page 42

Operating42

Sound adjustment

Setting the sound mode

This system has a number of pre-set equalizers. The displayed items for the equalizer may be different depending on sound sources and effects.

You can select a desired sound mode by using

EQUALIZER on the remote control or EQUALIZER / SEARCH & MULTI on the unit.

On Display Description

Operating

BASS (BASS BLAST)

BASS+ (BASS BLAST+)

POP

CLASSIC

ROCK

JAZZ

FOOTBALL

STANDARD

Reinforces the bass and powerful sound.

This program lends an enthusiastic atmosphere to the sound, giving you the feeling you are at an actual rock, pop, jazz or classic concert.

You can enjoy the equalizer FOOTBALL STADIUM.

You can enjoy optimized sound.

You can select a desired sound mode by using

SPECIAL EQ on the remote control or SPECIAL EQ / BASS BLAST (or BASS BLAST+) on the unit.

On Display Region Description

FUNK, REGUETON,

SAMBA,

MERENGUE, AXE,

SALSA, SERTANEJ,

FORRO

ARABIC Middle East

DANGDUT Indonesia

AFRO Africa

INDIA India

Note

yOn some speakers, sound may not be heard

or heard in low sound depending on the sound mode.

yBy pressing and holding SPECIAL EQ / BASS

BLAST (or BASS BLAST+) on the unit for 3

seconds, you can directly select BASS (BASS BLAST) or BASS+ (BASS BLAST+) effect.

Latin

America

Optimized equalizer for the music genre prefered in each region.

Page 43

Operating 43

Advanced Operations

Recording to USB

You can record a various sound source to USB. (DVD/CD, USB 1, AUX 1, AUX 2, FM)

1. Connect the USB device to the unit.

2. Press F to select a function you want to record.

3. Start the recording by pressing USB REC on the remote control or USB REC / DEMO on the unit.

Function Status Result

Play/Pause Recorded until stop

Resume stop

(Page 45)

USB 1

Full stop

Quick recorded the latest song

Quick recorded All songs

In case below, scope is limited.

- After File search (Page

32), quick recorded an indexed song.

- Only while the Folder name is displayed on the display window, quick recording All songs on Folder. (Folder Search Mode is released when there is no button input for a few seconds after entering the folder search mode.) (Page 32)

- After JUKE BOX On (Page 34), quick recorded All songs of JUKE BOX.

To stop recording

To stop recording, press USB REC on the remote control or USB REC / DEMO on the unit.

To select recording bit rate

1. Press and hold USB REC on the remote control or USB REC / DEMO on the unit for 3 seconds.

2. Press C/V to select a bit rate.

3. Press USB REC on the remote control or USB REC / DEMO on the unit to finish the setting.

The making of unauthorized copies of copy-

protected material, including computer

programs, les, broadcasts and sound recordings,

may be an infringement of copyrights and

constitute a criminal offense.

This equipment should not be used for such

purposes.

Be responsible

Respect copyrights

Operating

DVD/CD,

AUX 1,

AUX 2, FM

- If you connect both USB 1 and USB 2, press USB

REC on the remote control or USB REC / DEMO on the unit when USB 1 or USB 2 which you want to record blinks in the display window.

- Recorded until stop

Page 44

Operating44

"#$'JMFOBNF %&''JMFOBNF

'*-&@3&$

'*-&@3&$'*-&@3&$

53"$,@ 53"$,@

$%@3&$%*4$@3&$

05)&34@3&$

%+@.*9@3&$

.*9@ .*9@

Operating

Note

yWhen you stop recording, the le that has

been recorded at that time will be stored. (Except when recording MP3/WMA les on the USB that are in stop status.)

yDo not remove the USB device or turn off

the unit during USB recording. If does not, an incomplete le may be made and not deleted on PC.

yIf USB recording does not work, the message

like “NO USB”, “ERROR”, “USB FULL”, “NOT SUPPORT” or “FILE MAX” is displayed on the display window.

yMulti card reader device or external HDD can

not be used for USB recording.

yA le is recorded by about 512 Mbyte when

you record for a long term.

Note

yYou can record MIC. (Except when recording

USB that are in stop status.)

yYou can control recorded microphone sound

according to microphone volume.

yYou may not store more than 2,000 les.

yIn case of the unsupported MP3/WMA le,

the le recording may be stopped.

yWhen you are recording during playback, the

sound now playing is output.

yVOICE CANCELLER or KEY CHANGER

will be reset, if you use recording function during operating VOICE CANCELLER or KEY CHANGER.

yVOICE CANCELLER or KEY CHANGER can

not be operated during recording.

yIt’ll be stored as follows

USB (MP3/WMA)

Play or pause status

'*-&@3&$

"6%*0@ "6%*0@

The other status

"#$'JMFOBNF

%&''JMFOBNF

DVD/CD Tuner

56/&3@3&$

"6%*0@ "6%*0@

"6%*0@@'.

The other source*

"6%*0@ "6%*0@

*: AUX and the like.

Tuner: The current recording frequency is shown

Page 45

Operating 45

Other Operations

Turn off the sound temporarily

Press [on the remote control to mute your sound.

You can mute your unit, for example, to answer the telephone, the “MUTE” will appear in the display window.

To cancel it, press [on the remote control again or change the volume level.

DEMO

In the power off state, press USB REC / DEMO on the unit once. The unit will power on and display the each of functions in the display window. To cancel the DEMO function, press USB REC / DEMO on the unit once more.

Resume stop

The unit records the point where you pressed Z depending on the disc or USB.

If you press Z twice, the unit will clear the stopped point.

CHILDSAFE Mode

This function helps to prevent you from being surprised when you turn on the unit in case that the volume of the unit is set at a high level.

To turn on CHILDSAFE mode, press and hold OK on the unit when the volume of the unit is “MIN”.

In CHILDSAFE mode, the volume increase gradually.

To turn off CHILDSAFE mode, press and hold OK on the unit when the volume of the unit is “MIN” and this mode is turned on.

Note

In case of USB or BT (Bluetooth) function, CHILDSAFE mode does not work after about 2 minutes from power on the unit even if this mode is enabled.

Last Scene Memory

This unit memorizes last scene from the last disc that is viewed. The last scene remains in memory even if you remove the disc from the unit or switch off the unit. If you load a disc that has the scene memorized, the scene is automatically recalled.

Power Resume - Optional

Even if the power suddenly goes out, turn on the unit and then it plays a position where the contents is being played. System will periodically save current playback status.

Operating

System Select - Optional

You must select the appropriate system mode for your TV system. Press and hold M on the remote control for more than ve seconds to be able to select a system in the [Home Menu]. (NTSC PAL)

Note

If the USB device is connected or a disc is inserted, this function is not operated.

Page 46

Operating46

Using Microphone

1. Connect your microphone to the MIC jack.

2. Play the music you want.

3. Sing along with the accompaniment. Adjust the microphone volume by pressing MIC VOL+/- on the remote control or MIC VOL on the unit and rotating VOLUME on the unit in a clockwise or counterclockwise.

Note

yWhen not using the microphone, set the MIC

volume to minimum or turn off the MIC and remove the microphone from the MIC jack.

yIf the microphone is set too near the speaker,

a howling sound may be produced. In this case, move the microphone away from the speaker or decrease the sound level by using the MIC VOL+/- on the remote control or MIC VOL on the unit and rotating

Operating

VOLUME on the unit.

yIf sound through the microphone is extremely

loud, it may be distorted. In this case, pressing MIC VOL+/- on the remote control or MIC VOL on the unit and rotating VOLUME on the unit.

yYou can give an echo effect to the sound from

the microphones by pressing MIC ECHO.

VOICE CANCELLER

You can reduce the vocal tones during music playback from various input sources.

Press VOICE CANCELLER and “ON - VOICE CANCELLER” will appear in display window.

To cancel it, press VOICE CANCELLER again.

The quality of the VOICE CANCELLER may be different depending on the recording conditions of music les.

Note

yThis function is available in the DVD/CD, USB

or BT (Bluetooth) Function.

yIf the function is not available, “NOT

SUPPORT” appears in the display window.

yThis function is available to use only when a

microphone is connected.

yIf a microphone is not connected, “INSERT

MIC” appears in the display window.

yIt is not available on the mono source.

yTo initialize it, change the function or

disconnect the microphone.

yThis function may not be initialized depending

on the status of connected devices.

Page 47

Operating 47

KEY CHANGER

You can adjust the key to 9 steps (4 steps higher, 4 steps lower and the original key).

yTo make key more sharp, one by one,

press the KEY CHANGER(L) repeatedly during playback.

yTo make the key more atten, one by one,

press the KEY CHANGER(l) repeatedly during playback.

Note

yThis function is available in the DVD/CD, USB

or BT (Bluetooth) Function.

yTo initialize it, change the function, disconnect

the microphone or change the music.

yThis function may not be initialized depending

on the status of connected devices.

yIf the function is not available, “NOT

SUPPORT” appears in the display window.

yIf a microphone is not connected, “INSERT

MIC” appears in the display window.

VOCAL EFFECTS

When you connect your microphone to the MIC jack, you can enjoy karaoke function by changing voice in the various source.

To select various vocal effects mode, pressing VOCAL EFFECTS repeatedly or pressing VOCAL EFFECTS and then turning VOLUME on the unit when vocal effects mode appears in the display window.

BASS

SOPRANO HELIUM ROBOT

DUET MAN DUET WOMAN BASS ECHO1

SOPRANO ECHO1 HELIUM ECHO1

ROBOT ECHO1 DUET MAN1 DUET WOMAN1 BASS ECHO2 SOPRANO ECHO2 HELIUM ECHO2 ROBOT ECHO2

DUET MAN2 DUET WOMAN2 OFF

Note

yIf a microphone is not connected, “INSERT

MIC” appears in the display window.

yIf you press KEY CHANGER or MIC ECHO

on VOCAL EFFECTS mode, after backing up current VOCAL EFFECTS, turn off VOCAL EFFECTS mode and operate KEY CHANGER, or ECHO mode.

yTo turn off VOCAL EFFECTS mode, press and

hold VOCAL EFFECTS.

Operating

Page 48

Operating48

ECHO

When you connect your microphone to the MIC jack, you can give an echo effect to the sound from the microphones by pressing MIC ECHO.

ECHO 1

ECHO 2 OFF

Note

yIf a microphone is not connected, “INSERT

MIC” appears in the display window.

yIf you press VOCAL EFFECTS on ECHO

mode, after backing up current ECHO, turn off ECHO mode and operate VOCAL EFFECTS mode. To operate ECHO mode, press MIC ECHO again, after backing up current VOCAL EFFECTS.

Operating

LIGHTING

This function offers a party atmosphere by operating the lighting on the unit.

Press LIGHTING on the unit repeatedly or press LIGHTING on the unit and then turn EQUALIZER / SEARCH & MULTI on the unit.

PARTY

WATER FOREST (MY STYLE) OFF

Note

yLighting function is available in all functions.

yLighting mode retains in its previous mode

when you first press LIGHTING on the unit, press again to change modes.

yIf you want to use MY STYLE, you have to

yDo not look directly at the light emitting part

when the LIGHTING is turned on.

yIf the illumination brightness is glaring, switch

on the room lights or turn off the LIGHTING of the unit.

yYou can also turn off the light by pressing and

holding LIGHTING on the unit.

Page 49

Operating 49

Sleep Timer Setting

Press SLEEP on the remote control repeatedly to select delay time between 10 and 180 minutes. After the delay time, the unit will be turned off.

To cancel the sleep function, press SLEEP on the remote control repeatedly until “OFF” appears.

Note

yYou can check the remaining time before the

unit is turned off. Press SLEEP on the remote control to check or change the remaining time.

yYou can edit the remain time when the

remaining time or “DIMMER” is displayed.

Dimmer

Press SLEEP on the remote control once. The display window will be darkened by half.

To cancel it, press SLEEP on the remote control repeatedly until “OFF” appears.

Note

All the lighting turns off when Dimmer is being operated.

Operating

Page 50

Operating50

AUTO POWER On

This unit automatically turns on and off by an input source: BT (Bluetooth) or LG TV.

When you turn on your TV connected to this unit, this unit recognizes the input signal and selects the suitable function. You can hear the sound from the unit.

If you try to connect your Bluetooth device, this unit turns on and connects your Bluetooth device. You can play your music.

When you turn off this unit by pressing 1 on the unit for 5 seconds each time, you can turn on or off the AUTO POWER function.

On Display Description

AUTO POWER function is turned on.

AUTO POWER function is turned off.

Operating

ON-AUTO POWER

OFF-AUTO POWER

Note

yDepending on the connected device, this

function may not operate.

yDepending on the connected device, the unit

turns on but Bluetooth function may not be connected.

yIf you disconnect Bluetooth connection by

this unit, some Bluetooth devices try to connect to the unit continually. Therefore it is recommended to disconnect the connection before turning off the unit.

yIf you try to connect to the “LG XBOOM” app,

Bluetooth function of this unit is turned on.

yIf you turn on the unit using LG TV or

Bluetooth function, proper function of this unit is turned on.

yIf you have already paired with this unit, this

unit can automatically turn on by an input source when this unit is turned off.

Auto function change

This unit recognizes input signals such as BT (Bluetooth), LG TV and AUX 1 and then automatically changes to the suitable function.

When you try to connect Bluetooth device

When you try to connect your Bluetooth device to this unit, Bluetooth function is selected. Play your music on the Bluetooth device.

When AUX IN 1 (3.5 mm stereo cable) is connected

When you connect the portable device to the AUX IN 1 connector, AUX 1 function is selected. Play your music on the portable device.

When LG TV is connected

When you turn on your LG TV connected by LG Sound Sync, this unit changes the function to LG TV. You can hear the sound from your TV.

Note

yThis function is not available during recording

or deleting.

yThis function only works with devices that

were previously connected.

yIf the Bluetooth connection lock function

is set, Bluetooth and LG TV connection will

be only available on Bluetooth and LG TV function. (Page 38)

Page 51

Operating 51

Setting the Clock

1. Turn the unit on.

2. Press and hold CLOCK on the remote control.

3. Select time mode by pressing C/V on the remote control.

- AM 12:00 (for an AM and PM display) or 0:00

(for a 24 hour display)

4. Press SET on the remote control to confirm your selection.

5. Select the hours by pressing C/V on the remote control.

6. Press SET on the remote control.

7. Select the minutes by pressing C/V on the remote control.

8. Press SET on the remote control.

Setting the Clock through “LG XBOOM” App

Install “LG XBOOM” app on your Android device. (Page 39-40)

Your unit’s clock will be automatically synchronized with your device by activating Bluetooth connection through “LG XBOOM” app.

Using your player as an alarm clock

1. Turn the unit on.

2. Press and hold ALARM on the remote control.

3. Press C/V on the remote control to change the hours and minutes and press SET on the remote control to save.

4. Press C/V on the remote control to select function and press SET on the remote control to save.

- Press C/V on the remote control to select a

preset number when you select tuner and then, press SET on the remote control. If there is no preset number, this step is skipped.

5. Press C/V on the remote control to change the volume and press SET on the remote control to save.

Note

yIf you set the clock time, you can check the

time by pressing CLOCK on the remote control even when the player is turned off.

yYou can set alarm after you set the clock

time.

yIf you set the clock time and alarm, you

can check the alarm setting information by pressing ALARM on the remote control even when the unit is turned off.

yYou can select ALARM ON/OFF mode by

pressing ALARM on the remote control.

yIn case of DVD/CD or USB, this function is

available when you have music le. If you do not have music le, the function is changed to Tuner.

Operating

Page 52

Operating52

LG Sound Sync

You can control some functions of this unit by your TV’s remote control with LG Sound Sync. It is compatible with LG TV that supports LG Sound Sync. Make sure your TV has the LG Sound Sync logo.

Controllable function by LG TV’s remote control: Volume up/down, mute.

Refer to the TV’s instruction manual for the details of LG Sound Sync.

1. Turn on the unit by pressing 1.

2. Press

until LG TV function is selected.

3. Set up the sound output of TV to listen to the sound through this unit: TV setting menu [Sound]

Operating

[LG Sound Sync (Wireless)]

“PAIRED” appears on the display window for

about 3 seconds and then you can see “LG TV” on the display window if the TV and this unit are connected normally.

[TV Sound output]

Note

yYou can also use the remote control of this

unit while using LG Sound Sync. If you use TV’s remote control again, the unit synchronizes with the TV. (According to TV Specifications, the volume and mute of this unit synchronize with TV.)

yIf the connection fails, check the conditions of

this unit and your TV: power, function.

yMake sure of the condition of this unit and

the connection in the cases below when using LG Sound Sync.

- The unit is turned off.

- Changing to a different function.

- Disconnecting the wireless connection

caused by interference or a distance.

yIf you try to change the function on using

the LG TV function, volume will be change according to the LG TV volume level.

yDetails of TV setting menu vary depending on

models of your TV.

yIf you turned off the unit directly by pressing

, LG Sound Sync will be disconnected.

To use this function again, you should reconnect the TV and the unit.

yThe volume may be increased when the TV

and this unit is connected by LG Sound Sync. Decrease the TV volume and then connect with this unit.

yWhen you turn on your LG TV connected

by LG Sound Sync or enter LG TV function, this unit changes the function to LG TV automatically.

yYou should set the TV Sound output manually

depending on the TV version.

yIf you control TV volume when this unit and

TV are connected by LG Sound Sync, this unit may louder the volume due to synchronizing volume with TV’s.

Page 53

WIRELESS PARTY LINK Connection

You can enjoy the sound by using two speakers. For enjoying WIRELESS PARTY LINK, you need to purchase another speaker.

It is compatible with unit that supports WIRELESS PARTY LINK.

1. Press 3 TWIN on the unit. ROLE SELECT appears in the display window.

2. Press

Two units try to connect with each other.

3. When these units are successfully connected

TWIN on the unit to select MAIN or

OTHER.

unit: Selects MAIN.

unit: Selects OTHER.

to each other, each of connected device names appears in the each unit.

Operating 53

Note

yIf you using the LG Sound Sync, this function

is not available. If you connect the LG TV Function, “NOT SUPPORT” appears in the display window.

yYou can use microphone in the OTHER unit

only. In case of OTHER unit, some functions are supported only.

yWhen WIRELESS PARTY LINK is

disconnected, OTHER unit is changed to BT(Bluetooth) function.

yIf the connection is failed, “FAILED” appears in

the display window.

yMute function is synchronized with each

other.

yWIRELESS PARTY LINK connection will be

disconnected when you turn off the unit or press

TWIN on the unit.

ySound of MAIN unit and OTHER unit may be

different depending on playback status or source.

yCheck the following information when

connecting to Bluetooth.

- You can connect only one Bluetooth device in the MAIN unit. You cannot connect Bluetooth device to the OTHER unit.

- WIRELESS PARTY LINK connection is only supported on Android devices. (WIRELESS PARTY LINK connection may not be supported depending on the connected device specications or OS.)

- Removable/detachable Bluetooth devices (ex. Dongle etc.) will not support WIRELESS PARTY LINK connection.

- When WIRELESS PARTY LINK is connected, Bluetooth connection is not available in status of recording or deleting.

- If you connect WIRELESS PARTY LINK while you are playing connected Bluetooth device, the unit may be reconnected again, depending on phone specication.

Operating

Page 54

Troubleshooting54

Troubleshooting

General

Problem Cause & Solution

The unit does not work properly

No power

No picture

No sound

Troubleshooting

The DVD picture quality is poor

A DVD/CD will not play

Humming noise heard while a DVD or CD is playing

Radio stations cannot be tuned in properly.

The unit does not start playback

yTurn off the power of this unit and the connected external device (TV,

Woofer, DVD-player, Amplier, etc.) and turn it on again.

yDisconnect the power cord of this unit and the connected external

device (TV, Woofer, DVD-player, Amplier, etc.) and then try connecting again.

yPrevious setting may not be saved when device power is shut off.

yPlug the power cord into the wall outlet securely.

yCheck whether electricity failed.

Check the condition by operating electronic devices using the same AC outlet.

ySelect the appropriate video input mode on the TV so the picture

from the unit appears on the TV screen.

yConnect the video cables securely to both the TV and unit.

yCheck whether you select right function.

Press function button and check if you have selected the right function.

yCheck to see if the speakers are connected correctly.

Connect speaker cables correctly.

yClean the disc using a soft cloth with outward strokes.

yInsert a disc.

yInsert a playable disc (check the disc type, colour system and

regional code).

yPlace the disc with the label or printed side facing upwards.

yEnter your password or change the rating level.

yClean the disc using a soft cloth with outward strokes.

yMove unit and audio components further away from your TV.

yThe antenna is positioned or connected poorly.

Connect the antenna securely.

yThe signal strength of the radio station is too weak.

Tune to the station manually.

yNo stations have been preset or preset stations have been cleared

(when tuning by scanning preset channels). Preset some radio stations, see page 41 for details.

yAn unplayable disc is inserted. Check the playable disc.

yNo disc is inserted. Insert a disc.

yThe disc is dirty. Clean the disc. (Page 60)

yThe disc is inserted upside down.

Place the disc with the label or printed side facing upwards.

Page 55

Problem Cause & Solution

yThe remote control is too far from the unit.

Operate the remote control within about 7 m (23 feet).

The remote control does not work properly.

No speaker light

LG Sound Sync does not work.

The AUTO POWER function does not work.

yThere is an obstacle in the path of the remote control and the unit.

Remove the obstacle.

yThe batteries in the remote control are exhausted.

Replace the batteries with new ones.

yCheck whether the speaker light cables are connected to the unit

correctly. Connect the speaker light cables to the unit correctly.

yCheck the speaker light effects by pressing LIGHTING on the unit.

(Page 48)

yCheck whether your LG TV supports LG Sound Sync.

yCheck connection of LG Sound Sync.

yCheck sound setting of your TV and this unit.

yCheck connection of the external device such as TV or Bluetooth

device.

yDepending on the connected device, this function may not operate.

NOTES to release Demo mode

Problem Cause & Solution

Troubleshooting 55

Troubleshooting

Can not change input source with ‘F’ key such as BT(Bluetooth), USB etc. and only DEMO mode is showing in the display.

Remote Control does not work properly.

yPress ‘DEMO’ Key on the unit for 15 seconds.

Page 56

Appendix56

Controlling a TV with the Supplied Remote Control

You can control your TV using the buttons below.

By pressing You can

(TV POWER) Turn the TV on or off.

Switch the TV’s input source between the TV and other input sources.

Appendix

AV/INPUT

Note

Depending on the unit being connected, you may not be able to control your TV using some of the buttons.

Setting up the remote to control your TV

You can operate your TV with the supplied remote control. If your TV is listed in the table below, set the appropriate manufacturer code.

1. While holding down 1 (TV POWER) on the remote control, and press the manufacturer code for your TV with the numerical buttons on the remote control (see the table below).

Manufacturer Code Number

LG 1(Default), 2

Zenith 3, 4

GoldStar 1, 2

Samsung 6, 7

Sony 8, 9

Hitachi 4

2. Release the 1 (TV POWER) on the remote control to complete setting.

Depending on your TV, some or all buttons may not function on the TV, even after entering the correct manufacturer code. When you replace the batteries of the remote, the code number you have set may be reset to the default setting. Set the appropriate code number again.

Page 57

Appendix 57

Area Code List

Choose an area code from this list.

Area Code Area Code Area Code Area Code

Afghanistan AF

Argentina AR

Australia AU

Austria AT

Belgium BE

Bhutan BT

Bolivia BO

Brazil BR

Cambodia KH

Canada CA

Chile CL

China CN

Colombia CO

Congo CG

Costa Rica CR

Croatia HR

Czech Republic CZ

Denmark DK

Ecuador EC

Egypt EG

El Salvador SV

Ethiopia ET

Fiji FJ

Finland FI

France FR

Germany DE

Great Britain GB

Greece GR

Greenland GL

Hong Kong HK

Hungary HU

India IN

Indonesia ID

Israel IL

Italy IT

Jamaica JM

Japan JP

Kenya KE

Kuwait KW

Libya LY

Luxembourg LU

Malaysia MY

Maldives MV

Mexico MX

Monaco MC

Mongolia MN

Morocco MA

Nepal NP

Netherlands NL

Antilles AN

New Zealand NZ

Nigeria NG

Norway NO

Oman OM

Pakistan PK

Panama PA

Paraguay PY

Philippines PH

Poland PL

Portugal PT

Romania RO

Russian Federation RU

Saudi Arabia SA

Senegal SN

Singapore SG

Slovak Republic SK

Slovenia SI

South Africa ZA

South Korea KR

Spain ES

Sri Lanka LK

Sweden SE

Switzerland CH

Taiwan TW

Thailand TH

Turkey TR

Uganda UG

Ukraine UA

United States US

Uruguay UY

Uzbekistan UZ

Vietnam VN

Zimbabwe ZW

Appendix

Page 58

Appendix58

Language code List

Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu].

Language Code Language Code Language Code Language Code

Afar 6565

Afrikaans 6570

Albanian 8381

Ameharic 6577

Arabic 6582

Armenian 7289

Assamese 6583

Aymara 6588

Azerbaijani 6590

Bashkir 6665

Basque 6985

Bengali; Bangla 6678

Bhutani 6890

Bihari 6672

Breton 6682

Bulgarian 6671

Burmese 7789

Byelorussian 6669

Chinese 9072

Croatian 7282

Appendix

Czech 6783

Danish 6865

Dutch 7876

English 6978

Esperanto 6979

Estonian 6984

Faroese 7079

Fiji 7074

Finnish 7073

French 7082

Frisian 7089

Galician 7176

Georgian 7565

German 6869

Greek 6976

Greenlandic 7576

Guarani 7178

Gujarati 7185

Hausa 7265

Hebrew 7387

Hindi 7273

Hungarian 7285

Icelandic 7383

Indonesian 7378

Interlingua 7365

Irish 7165

Italian 7384

Japanese 7465

Kannada 7578

Kashmiri 7583

Kazakh 7575

Kirghiz 7589

Korean 7579

Kurdish 7585

Laothian 7679

Latin 7665

Latvian, Lettish 7686

Lingala 7678

Lithuanian 7684

Macedonian 7775

Malagasy 7771

Malay 7783

Malayalam 7776

Maori 7773

Marathi 7782

Moldavian 7779

Mongolian 7778

Nauru 7865

Nepali 7869

Norwegian 7879

Oriya 7982

Panjabi 8065

Pashto, Pushto 8083

Persian 7065

Polish 8076

Portuguese 8084

Quechua 8185

Rhaeto-Romance 8277

Rumanian 8279

Russian 8285

Samoan 8377

Sanskrit 8365

Scots Gaelic 7168

Serbian 8382

Serbo-Croatian 8372

Shona 8378

Sindhi 8368

Singhalese 8373

Slovak 8375

Slovenian 8376

Spanish 6983

Sudanese 8385

Swahili 8387

Swedish 8386

Tagalog 8476

Tajik 8471

Tamil 8465

Telugu 8469

Thai 8472

Tonga 8479

Turkish 8482

Turkmen 8475

Twi 8487

Ukrainian 8575

Urdu 8582

Uzbek 8590

Vietnamese 8673

Volapük 8679

Welsh 6789

Wolof 8779

Xhosa 8872

Yiddish 7473

Yoruba 8979

Zulu 9085

Page 59

Appendix 59

Trademarks and Licenses

All other trademarks are trademarks of their respective owners.

Manufactured under license from Dolby Laboratories. Dolby, Dolby Audio, and the double-D symbol are trademarks of Dolby Laboratories.

The terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

“DVD Logo” is a trademark of DVD Format/Logo Licensing Corporation.

Notes on Copyrights

yThis product incorporates copyright protection

technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Rovi, and is intended for home and other limited viewing uses only unless otherwise authorized by Rovi. Reverse engineering or disassembly is prohibited.

yUnder the U.S. Copyright laws and Copyright

laws of other countries, unauthorized recording, use, display, distribution, or revision of television programs, videotapes, BD-ROM discs, DVDs, CDs and other materials may subject you to civil and/or criminal liability.

The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license.

Other trademarks and trade names are those of their respective owners.

Appendix

Page 60

Appendix60

Maintenance

Notes on Discs

Handling Discs

Never stick paper or tape on the disc.

Storing Discs

After playing, store the disc in its case. Do not expose the disc to direct sunlight or sources of heat and never leave it in a parked car exposed to direct sunlight.

Cleaning Discs

Fingerprints and dust on the disc can cause poor picture quality and sound distortion. Before playing, clean the disc with a clean cloth. Wipe the disc from the center to out.

Do not use strong solvents such as alcohol, benzine, thinner, commercially available cleaners, or anti-static spray intended for old vinyl records.

Handling the Unit

When shipping the unit

Please save the original shipping carton and packing materials. If you need to ship the unit, for maximum protection, re-pack the unit as it was originally packed at the factory.

Keeping the exterior surfaces clean

Do not use volatile liquids such as insecticide spray near the unit. Wiping with strong pressure may damage the surface. Do not leave rubber or plastic products in contact with the unit for a long period of time.

Cleaning the unit

To clean the player, use a soft, dry cloth. If the surfaces are extremely dirty, use a soft cloth lightly moistened with a mild detergent solution. Do not use strong solvents such as alcohol, benzine, or thinner, as these might damage the surface of the unit.

Maintaining the Unit

The unit is a high-tech, precision device. If the optical pick-up lens and disc drive parts are dirty or worn, the picture quality could be diminished. For details, please contact your nearest authorized service center.

Appendix

Page 61

Specifications

General

Power requirements Refer to the main label.

Power consumption Refer to the main label.

Dimensions (W x H x D) Approx. 350.0 mm x 163.0 mm x 251.0 mm

Operating temperature 5 °C to 35 °C

Operating humidity 5 % to 60 % RH

Inputs/ Outputs

Analog audio in (AUX IN 2) 2.7 Vrms (1 kHz), 75 Ω RCA jack (L,R)

Portable in (AUX IN 1) 1.3 Vrms (3.5 mm stereo jack) x 1

HDMI OUT (video/audio) 19 pin (Type A, HDMI™ Connector ) x 1

Microphone (MIC) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 1

Tuner

FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz

System

Frequency Response 70 to 20,000 Hz

Signal-to-noise ratio More than 75 dB

Dynamic range More than 75 dB

Bus Power Supply (USB) 5 V 0 500 mA

Amplier (RMS Output power)

Total output 950 W RMS

Front 475 W RMS X 2 (3 Ω at 1 kHz, 25 % THD)

Appendix 61

Appendix

yDesign and specications are subject to change without notice.

Page 62

Appendix62

Speakers specifications

Front speaker

Type 2 Way 2 Speaker

Impedance 3

Rated Input Power 475 W RMS

Max. Input power 950 W RMS

Dimensions (W x H x D) Approx. 300 mm x 363 mm x 253 mm

yDesign and specications are subject to change without notice.

Appendix

Page 63

LG CL65D Owner’s Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Safety Information

Getting Started

Unique Features

Introduction

Playable Discs

About the “7” Symbol Display

Symbols Used in this Manual

Regional Codes

Playable file Requirement

Music file requirement

Photo file requirement

Video file requirement

Compatible USB Devices

USB device requirement

Remote control

Front panel

Rear panel

Connections to Your TV

HDMI Out Connection

Connecting

Resolution Setting

Connecting to speakers

Attaching the speakers to the unit

Attaching the speaker light cables to the unit

Optional Equipment Connection

AUX IN 1 Connection

AUX IN 2 Connection

USB Connection

Antenna Connection

Adjust the setup settings

To display and exit the Setup menu

System Setting

Language

Display

Audio

Lock (Parental Control)

Using the Home Menu

Operating

Basic Operations on Disc

Advanced Operations on Disc

Displaying Disc Information on-screen

To display the DVD title

1.5 times speed playback

Screen Saver

To display the DVD Menu

Starting play from selected time

Resume playback

Changing subtitle code page

Marked Playback

Viewing a PHOTO file

Basic Operations on USB

Selecting a folder and an MP3/WMA file

Deleting a file/folder or format

Advanced Operations on USB

JUKE BOX Playback

Playback Effect

AUTO DJ

Using BLUETOOTH® wireless technology

Listening to music stored on the Bluetooth devices

Using the LG XBOOM App

About “LG XBOOM” App

Install “LG XBOOM” App onto Your Bluetooth Device

Activate Bluetooth with “LG XBOOM” App

Radio Operations

Listening to the radio

Improving poor FM reception

Presetting the Radio Stations

Deleting all the saved stations

Sound adjustment

Setting the sound mode

Advanced Operations

Recording to USB

Other Operations

Turn off the sound temporarily

DEMO

Resume stop
