LG BD570C Owner’s Manual

OWNER’S MANUAL

ENGLISH

Network Blu-ray Disc™/
DVD Player

Please read this manual carefully before operating
your set and retain it for future reference.

MODEL

BD570C

P/NO : MFL62881816

BD572-N-BCANLLK-ENG.indd 1BD572-N-BCANLLK-ENG.indd 1 2010.1.22 8:33:31 PM2010.1.22 8:33:31 PM

http://www.lg.ca

BD572-N-BCANLLK-ENG.indd 2BD572-N-BCANLLK-ENG.indd 2 2010.1.22 8:33:33 PM2010.1.22 8:33:33 PM

1
Safety Information

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK) NO USER-

SERVICEABLE PARTS INSIDE REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

This lightning  ash with arrowhead
symbol within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous

voltage within the product’s
enclosure that may be of su cient magnitude to
constitute a risk of electric shock to persons.

The exclamation point within an
equilateral triangle is intended
to alert the user to the presence
of important operating and
maintenance (servicing) instructions

in the literature accompanying the product.

Cautions and Warnings

WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.

WARNING: Do not install this equipment in a
con ned space such as a book case or similar unit.

CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built­in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.

CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read
this owner’s manual carefully and retain it for future
reference. Shall the unit require maintenance,
contact an authorized service center.
Use of controls, adjustments or the performance of
procedures other than those speci ed herein may
result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try
to open the enclosure. Visible laser radiation when
open. DO NOT STARE INTO BEAM.

CAUTION concerning the Power Cord

Most appliances recommend they be placed upon a
dedicated circuit;

That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the speci cation page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or  re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an exact
replacement part by an authorized service center.
Protect the power cord from physical or mechanical
abuse, such as being twisted, kinked, pinched, closed
in a door, or walked upon. Pay particular attention
to plugs, wall outlets, and the point where the cord
exits the appliance. To disconnect power from the
mains, pull out the mains cord plug. When installing
the product, ensure that the plug is easily accessible.

3Safety Information

1

Safety Information

BD572-N-BCANLLK-ENG.indd 3BD572-N-BCANLLK-ENG.indd 3 2010.1.22 8:33:33 PM2010.1.22 8:33:33 PM

4 Safety Information

1

Safety Information

This device is equipped with a portable battery or
accumulator.

Safety way to remove the battery or the battery
from the equipment: Remove the old battery

or battery pack, follow the steps in reverse order
than the assembly. To prevent contamination of
the environment and bring on possible threat
to human and animal health, the old battery or
the battery put it in the appropriate container at
designated collection points. Do not dispose of
batteries or battery together with other waste.
It is recommended that you use local, free
reimbursement systems batteries and accumulators.
The battery shall not be exposed to excessive heat
such as sunshine,  re or the lile.

CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects  lled
with liquids, such as vases, shall be placed on the
apparatus.

This Class B digital apparatus complies with
Canadian ICES-003 “To prevent radio interference
to the licensed service, this device is intended to
be operated indoors and away from windows
to provide maximum shielding. Equipment (or
its transmit antenna) that is installed outdoors is
subject to licensing.”

Operation is subject to the following two
conditions :
(1) This device may not cause Interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation
of the device.

Notes on Copyrights

•

Because AACS (Advanced Access Content System)
is approved as content protection system for BD
format, similar to use of CSS (Content Scramble
System) for DVD format, certain restrictions are
imposed on playback, analog signal output, etc.,
of AACS protected contents. The operation of this
product and restrictions on this product may vary
depending on your time of purchase as those
restrictions may be adopted and/or changed by
AACS after the production of this product.

•

Furthermore, BD-ROM Mark and BD+ are
additionally used as content protection systems
for BD format, which imposes certain restrictions
including playback restrictions for BD-ROM
Mark and/or BD+ protected contents. To obtain
additional information on AACS, BD-ROM Mark,
BD+, or this product, please contact an authorized
Customer Service Center.

•

Many BD-ROM/DVD discs are encoded with
copy protection. Because of this, you should only
connect your player directly to your TV, not to a
VCR. Connecting to a VCR results in a distorted
picture from copy-protected discs.

•

This product incorporates copyright protection
technology that is protected by U.S. patents
and other intellectual property rights. Use of
this copyright protection technology must be
authorized by Macrovision, and is intended for
home and other limited viewing uses only unless
otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.

•

Under the U.S. Copyright laws and Copyright
laws of other countries, unauthorized recording,
use, display, distribution, or revision of television
programs, videotapes, BD-ROM discs, DVDs, CDs
and other materials may subject you to civil and/
or criminal liability.

BD572-N-BCANLLK-ENG.indd 4BD572-N-BCANLLK-ENG.indd 4 2010.1.22 9:19:50 PM2010.1.22 9:19:50 PM

5Safety Information

Important Safety
Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with dry cloth.

7. Do not block any ventilation openings. Install in

accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as

radiators, heat registers, stoves, or other apparatus
(including ampli ers) that produce heat.

9. Do not defeat the safety purpose of the polarized

or grounding-type plug. A polarized plug has
two blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not  t into your outlet, consult an
electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on

or pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.

11. Only use attachments/accessories speci ed by

the manufacturer.

12. Use only with the cart, stand, tripod, bracket,

or table speci ed by the
manufacturer, or sold with the
apparatus. When a cart is used,
use caution when moving the
cart/apparatus combination to
avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or
when unused for long periods of time.

14. Refer all servicing to quali ed service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.

1

Safety Information

BD572-N-BCANLLK-ENG.indd 5BD572-N-BCANLLK-ENG.indd 5 2010.1.22 8:33:34 PM2010.1.22 8:33:34 PM

6

Contents

3

Installation

14 Connecting to Your TV

14 HDMI Connection

1

15 What is SIMPLINK?

16 Component Video

Safety Information

3 Cautions and Warnings

2

Preparation

8 Introduction

8 About the “ ” Symbol

Display

8 Symbols Used in this

Manual

8 Supplied Accesorries

9 Playable Discs

10 File compatibility

11 Regional Code

11 AVCHD (Advanced Video

Codec High Defi nition)

11 Certain System

Requirements

11 Compatibility Notes

12 Remote control

13 Front panel

13 Rear panel

16 Video/Audio (Left/Right)

17 Resolution Setting

18 Connecting to an Amplifi er

18 Connecting to an Amplifi er

19 Connecting to an Amplifi er

19 Connecting to an Amplifi er

20 Connecting to your Home Network

20 Wired network connection

21 Wired Network Setup

22 Wireless Network

22 Wireless Network Setup

25 USB device connection

25 Playback content in the

27 Settings

27 Adjust the Setup Settings

27 [DISPLAY] Menu

29 [LANGUAGE] Menu

29 [AUDIO] Menu

30 [LOCK] Menu

32 [NETWORK] Menu

32 [OTHERS] Menu

Connection

Connection

via HDMI Output

via Digital Audio Output

via 2 Channel Audio Output

Connection

USB device

BD572-N-BCANLLK-ENG.indd 6BD572-N-BCANLLK-ENG.indd 6 2010.1.22 8:33:34 PM2010.1.22 8:33:34 PM

7

4

Operation

34 General Playback

36 Advanced Playback

40 On-Screen display

43 Enjoying BD-LIVE

44 Playing a movie fi le and VR disc

44 Selecting a subtitle fi le

45 Changing subtitle code

page

45 Viewing a photo

46 Options while viewing a


47 Listening to music during a

slide show

48 Listening to music

48 Audio CD Recording

50 Viewing information from

Gracenote Media Database

51 Playing content via your home

network

56 Using the NetCast™ Entertainment

Access

56 Playing YouTube™ videos

60 Viewing Picasa™ Web

Albums

63 Using the AccuWeather

6

Troubleshooting

66 General

67 Picture

67 Sound

68 Network

7

Appendix

69 Controlling a TV with the Supplied

70 Network Software Update

72 Area Code List

73 Language code List

74 Trademarks and Licenses

76 Audio Output Specifi cations

78 Video Output Resolution

79 Specifi cations

80 Important Information Relating to

81 Open source software notice

1

2

3

Remote Control

4

5

Network Services

6

5

7

Maintenance

65 Notes on Discs

65 Handling the Unit

BD572-N-BCANLLK-ENG.indd 7BD572-N-BCANLLK-ENG.indd 7 2010.1.22 8:33:35 PM2010.1.22 8:33:35 PM

8 Preparation

2
Preparation

2

Preparation

Introduction

About the “ ” Symbol Display

“ ” may appear on your TV display during
operation and indicates that the function
explained in this owner’s manual is not
available on that speci c media.

Symbols Used in this Manual

NOTE

Indicates special notes and operating features.

CAUTION

Indicates cautions for preventing possible
damages from abuse.

A section whose title has one of the following
symbols are applicable only to the disc
represented by the symbol.

BD

BD-ROM disc

MOVIE-N

MUSIC

MUSIC-N


Movie  les in the DLNA
server or PC

Music  les contained in
the USB/Disc

Music  les in the DLNA
server or PC

Photo  les

Supplied Accesorries

Video cable (1) Audio cables (1)

Remote control (1) Batteries (2)

DVD

AVC HD

ACD

MOVIE

BD572-N-BCANLLK-ENG.indd 8BD572-N-BCANLLK-ENG.indd 8 2010.1.22 8:33:35 PM2010.1.22 8:33:35 PM

DVD-Video, DVD±R/RW in
Video mode or VR mode
and  nalized

DVD±R/RW in AVCHD
format

Audio CDs

Movie  les contained in
the USB/Disc

Nero MediaHome4
Essentials software
CD-ROM (1)

9Preparation

Playable Discs

Blu-ray Disc

Discs such as movies that can

-

be purchased or rented.
BD-R/RE discs that contain

-

Movie, Music or Photo  les.

DVD-VIDEO (8 cm / 12 cm disc)
Discs such as movies that can be
purchased or rented.

DVD±R (8 cm / 12 cm disc)

Video mode and  nalized only

-

Supports the dual layer disc

-

also
Finalized AVCHD format

-

DVD±R discs that contain

-

Movie, Music or Photo  les.

DVD-RW (8 cm / 12 cm disc)

VR mode, Video mode and

-

 nalized only
Finalized AVCHD format

-

DVD-RW discs that contain

-

Movie, Music or Photo  les.

DVD+RW (8 cm / 12 cm disc)

Video mode and  nalized only

-

Finalized AVCHD format

-

DVD+RW discs that contain

-

Movie, Music or Photo  les.

Audio CD (8 cm / 12 cm disc)

CD-R/RW (8 cm / 12 cm disc)
CD-R/RW discs that contain audio
titles, Movie, Music or Photo  les.

NOTE

Depending on the conditions of the recording

•
equipment or the CD-R/RW (or DVD±R/RW )
disc itself, some CD-R/RW (or DVD±R/RW) discs
cannot be played on the unit.

Depending on the recording software & the

•
 nalization, some recorded discs (CD-R/RW,
DVD±R/RW or BD-R/RE) may not be playable.

BD-R/RE, DVD±R/RW and CD-R/RW discs

•
recorded using a personal computer or a DVD or
CD Recorder may not play if the disc is damaged
or dirty, or if there is dirt or condensation on the
player’s lens.

If you record a disc using a personal computer,

•
even if it is recorded in a compatible format,
there are cases in which it may not play because
of the settings of the application software used
to create the disc. (Check with the software
publisher for more detailed information.)

This player requires discs and recordings to meet

•
certain technical standards in order to achieve
optimal playback quality.

Pre-recorded DVDs are automatically set to

•
these standards. There are many di erent
types of recordable disc formats (including
CD-R containing MP3 or WMA  les) and these
require certain pre-existing conditions to ensure
compatible playback.

Hybrid disc have both BD-ROM and DVD (or CD)

•
layers on one side. On such discs, BD-ROM layer
will be only played back in this player.

Customers should note that permission is

•
required in order to download MP3 / WMA  les
and music from the Internet. Our company has
no right to grant such permission. Permission
should always be sought from the copyright
owner.

You have to set the disc format option to

•
[Mastered] in order to make the discs compatible
with the LG players when formatting rewritable
discs. When setting the option to Live System,
you cannot use it on LG player. (Mastered/Live
File System : Disc format system for windows
Vista)

2

Preparation

BD572-N-BCANLLK-ENG.indd 9BD572-N-BCANLLK-ENG.indd 9 2010.1.22 8:33:36 PM2010.1.22 8:33:36 PM

10 Preparation

2

Preparation

File compatibility

Overall

Available File extensions: “.jpg”, “.jpeg”, “.png”, “
.avi”, “.divx”, “.mpg”, “.mpeg”, “.mkv ”, “.mp4”, “.mp3”,
“.wma”, “.wav”

Available  le extensions di er depending

•
on the DLNA servers.

Some wav  les are not supported on this

•
player.

The  le name is limited to 180 characters.

•
Depending on the size and number of the

•
 les, it may take several minutes to read the
contents on the media.

Maximum Files/Folder: Less than 2000 (total
number of  les and folders)

CD-R/RW, DVD±R/RW, BD-R/RE Format:

ISO 9660+JOLIET, UDF and UDF Bridge format

MOVIE

Available resolution size: 1920 x 1080 (W x H)
pixels
Playable subtitle: SubRip (.srt / .txt), SAMI
(.smi), SubStation Alpha (.ssa/.txt), MicroDVD
(.sub/.txt), VobSub (.sub), SubViewer 1.0 (.sub),
SubViewer 2.0 (.sub/.txt), TMPlayer (.txt), DVD
Subtitle System (.txt)

•

VobSub (.sub) is not available in the
[Home Link] feature.

Playable Codec format: “DIVX3.xx”, “DIVX4.
xx”, “DIVX5.xx”, “XVID”, “DIVX6.xx” (Standard
playback only), H.264/MPEG-4 AVC, MPEG1 SS,
MPEG2 PS, MPEG2 TS
Playable Audio format: “Dolby Digital”, “DTS”,
“MP3”, “WMA”, “AAC”, “AC3”

Not all the WMA and AAC Audio format are

•
compatible with this unit.

Sampling frequency: within 32-48 kHz
(WMA), within 16-48 kHz (MP3)
Bit rate: within 20-320Kbps (WMA), within
32-320Kbps (MP3)

NOTE

HD movie  les contained on the CD or USB

•

1.0/1.1 may not played properly. BD, DVD or USB

2.0 are recommended to play back HD movie
 les.

This player support H.264/MPEG-4 AVC pro le

•
Main, High at Level 4.1. For a  le with higher
level, the warning message will appear on the
screen.

•

This player does not support the  le that are
recorded with GMC
encoding techniques in MPEG4 standard, like
DivX or XVID have.

*1 GMC – Global Motion Compensation
*2 Qpel – Quarter pixel

1

or Qpel

*

2

. Those are video

*

MUSIC

Sampling frequency: within 8 - 48 kHz
(WMA), within 11 - 48 kHz (MP3)
Bit rate: within 8 - 320 kbps (WMA, MP3)

NOTE

This unit cannot support the ID3 Tag embedded

•
MP3  le.

The total playback time indicated on the screen

•
may not be correct for VBR  les.


Recommended size:

Less than 4,000 x 3,000 x 24 bit/pixel
Less than 3,000 x 3,000 x 32 bit/pixel

Progressive and lossless compression photo

•
image  les are not supported.

BD572-N-BCANLLK-ENG.indd 10BD572-N-BCANLLK-ENG.indd 10 2010.1.22 8:33:37 PM2010.1.22 8:33:37 PM

11Preparation

Regional Code

This unit has a regional code printed on the
rear of the unit. This unit can play only BD-ROM
or DVD discs labeled same as the rear of the
unit or “ALL”.

AVCHD (Advanced Video Codec
High Defi nition)

This player can playback AVCHD format

•
discs. These discs are normally recorded and
used in camcorders.

•

The AVCHD format is a high de nition
digital video camera format.

The MPEG-4 AVC/H.264 format is capable

•
of compressing images at higher e ciency
than that of the conventional image
compressing format.

Some AVCHD discs use the “x.v.Color”

•
format.

•

This player can playback AVCHD discs using
“x.v.Color” format.

Some AVCHD format discs may not play

•
depending on the recording condition.

AVCHD format discs need to be  nalized.

•

•

“x.v.Color” o ers a wider color range than
normal DVD camcorder discs.

Certain System Requirements

For high de nition video playback:

High de nition display that has

•
COMPONENT or HDMI input jacks.

BD-ROM disc with high de nition content.

•
HDMI or HDCP capable DVI input on your

•
display device is required for some content
(as speci ed by disc authors).

For up-conversion of standard de nition

•
DVD, a HDMI or HDCP capable DVI input
on your display device is required for copy
protected content.

For Dolby® Digital Plus, Dolby TrueHD and DTS­HD multi-channel audio playback:

•

An ampli er/receiver with a built-in (Dolby
Digital, Dolby Digital Plus, Dolby TrueHD,
DTS or DTS-HD) decoder.

•

Main, center, surround speakers and
subwoofer as necessary for chosen format.

Compatibility Notes

Because BD-ROM is a new format,

•
certain disc, digital connection and other
compatibility issues are possible. If you
experience compatibility problems, please
contact an authorized Customer Service
Center.

Viewing high-de nition content and up-

•
converting standard DVD content may
require a HDMI-capable input or HDCP­capable DVI input on your display device.

Some BD-ROM and DVD discs may restrict

•
the use of some operation commands or
features.

Dolby TrueHD, Dolby Digital Plus and DTS-

•
HD are supported with maximum 7.1
channels if you use HDMI connection for
the audio output of the unit.

You can use a USB device that is used

•
to store some disc related information,
including downloaded on-line content. The
disc you are using will control how long this
information is retained.

2

Preparation

BD572-N-BCANLLK-ENG.indd 11BD572-N-BCANLLK-ENG.indd 11 2010.1.22 8:33:37 PM2010.1.22 8:33:37 PM

12 Preparation

Remote control

2

Preparation

Battery Installation

Remove the battery cover
on the rear of the Remote
Control, and insert two R03
(size AAA) batteries with
and matched correctly.

• • • • • • a • • • • • •

(POWER): Switches the

1

player ON or OFF.

Z

(OPEN/CLOSE): Opens and

closes the disc tray.

0-9 numerical buttons:
Selects numbered options in
a menu or inputs letters in the
keypad menu.

CLEAR: Removes a mark on
the search menu or a number
when setting the password.

REPEAT: Repeats a desired
section or sequence.

• • • • • • b • • • • • •

m/M

(SCAN): Searches

backward or forward.

./>

(SKIP): Goes to the
next or previous chapter / track
/  le.

x

(STOP): Stops playback.

N

(PLAY): Starts playback.

X

(PAUSE): Pauses playback.

• • • • • • c • • • • • •

HOME (

): Displays or exits

the [Home Menu].

MUSIC ID: When connected
to the network, can provide
information about the current
song during movie playback.

INFO/DISPLAY (

): Displays or

exits On-Screen Display.

Direction buttons: Selects an
option in the menu.

ENTER ( ): Acknowledges
menu selection.

RETURN (O): Exits the menu
or resumes playback. The
resume play function may not
work depending on the BD­ROM disc.

TITLE/POP-UP: Displays the
DVD title menu or BD-ROM’s
pop-up menu, if available.

DISC MENU: Accesses the
menu on a disc.

• • • • • • d • • • • • •

Coloured (R, G, Y, B) buttons:
Use to navigate BD-ROM
menus. They are also used for
[MOVIE], [PHOTO], [MUSIC],
[Home Link] and [NetCast]
menu.

MARKER: Marks any point
during playback.

SEARCH: Displays or exits the
search menu.

ZOOM: Displays or exits the
[Zoom] menu.

TV Control Buttons: See page

69.

BD572-N-BCANLLK-ENG.indd 12BD572-N-BCANLLK-ENG.indd 12 2010.1.22 8:33:37 PM2010.1.22 8:33:37 PM

Front panel

13Preparation

2

Preparation

Disc Tray

a

Z

(OPEN/CLOSE)

b

1

(POWER) Button

c

Display Window

d

Remote Sensor

e

Rear panel

AC power cord

a

DIGITAL AUDIO OUT (COAXIAL)

b

VIDEO OUT

c

2CH AUDIO OUT (Left/Right)

d

N/X

(PLAY / PAUSE)

f

x

(STOP)

g

./>

h

USB Port

i

LAN port

e

HDMI OUT (Type A, Version 1.3)

f

DIGITAL AUDIO OUT (OPTICAL)

g

COMPONENT VIDEO OUT (Y P

h

(SKIP)

B PR

)

BD572-N-BCANLLK-ENG.indd 13BD572-N-BCANLLK-ENG.indd 13 2010.1.22 8:33:38 PM2010.1.22 8:33:38 PM

14 Installation

3
Installation

3

Installation

Connecting to Your TV

Make one of the following connections,
depending on the capabilities of your existing
equipment.

•

HDMI connection (page 14-15)

•

Component Video connection (page 16)

•

Video/Audio (Left/Right) Connection (page

16)

NOTE

Depending on your TV and other equipment

•
you wish to connect, there are various ways you
could connect the player. Use only one of the
connections described in this manual.

Please refer to the manuals of your TV, Stereo

•
System or other devices as necessary to make
the best connections.

Do not connect the player’s AUDIO OUT jack to

•
the phono in jack (record player) of your audio
system.

Do not connect your player via your VCR. The

•
image could be distorted by the copy protection
system.

HDMI Connection

If you have a HDMI TV or monitor, you can
connect it to this player using a HDMI cable
(Type A, Version 1.3). Connect the HDMI jack
on the player to the HDMI jack on a HDMI
compatible TV or monitor.

HDMI Connection

BD Player

HDMI
Cable

TV

Set the TV’s source to HDMI (refer to TV’s
Owner’s manual).

BD572-N-BCANLLK-ENG.indd 14BD572-N-BCANLLK-ENG.indd 14 2010.1.22 8:33:38 PM2010.1.22 8:33:38 PM

15Installation

NOTE

If a connected HDMI device does not accept

•
the audio output of the player, the HDMI device
’s audio sound may be distorted or may not
output.

When you use HDMI connection, you can

•
change the resolution for the HDMI output.
(Refer to “Resolution Setting” on page 17.)

Select the type of video output from the HDMI

•
OUT jack using [HDMI Color Setting] option on
the [Setup] menu (see page 28).

Changing the resolution when the connection

•
has already been established may result in
malfunctions. To solve the problem, turn o the
player and then turn it on again.

When the HDMI connection with HDCP is not

•
veri ed, TV screen is changed to black screen.
In this case, check the HDMI connection, or
disconnect the HDMI cable.

If there are noises or lines on the screen, please

•
check the HDMI cable (length is generally
limited to 4.5m).

Additional Information for HDMI

When you connect a HDMI or DVI

•
compatible device make sure of the
following:

Try switching o the HDMI/DVI device

-

and this player. Next, switch on the
HDMI/DVI device and leave it for around
30 seconds, then switch on this player.
The connected device’s video input is set

-

correctly for this unit.
The connected device is compatible with

-

720x480p, 1280x720p, 1920x1080i or
1920x1080p video input.

Not all HDCP-compatible HDMI or DVI

•
devices will work with this player.

The picture will not be displayed properly

-

with non-HDCP device.

-

This player does not playback and TV
screen is changed to black screen.

What is SIMPLINK?

Some functions of this unit are controlled by
the TV’s remote control when this unit and LG
TV’s with SIMPLINK are connected through
HDMI connection.

Controllable functions by LG TV’s remote
control; Play, Pause, Scan, Skip, Stop, Power O ,
etc.

Refer to the TV owner’s manual for the details
of SIMPLINK function.

LG TV’s with SIMPLINK function has the logo as
shown above.

NOTE

Depending on the disc type or playing status,
some SIMPLINK operation may di er from your
purpose or not work.

3

Installation

BD572-N-BCANLLK-ENG.indd 15BD572-N-BCANLLK-ENG.indd 15 2010.1.22 8:33:39 PM2010.1.22 8:33:39 PM

16 Installation

3

Installation

Component Video Connection

Connect the COMPONENT VIDEO OUT jacks on
the player to the corresponding input jacks on
the TV using component video cable. Connect
the left and right AUDIO OUT jacks of the
player to the audio left and right IN jacks on
the TV using the audio cables.

Component Connection

BD Player

Component

video cable

Audio
cable

Video/Audio (Left/Right)
Connection

Connect the VIDEO OUT jack on the player to
the video in jack on the TV using a video cable.
Connect the left and right AUDIO OUT jacks of
the player to the audio left and right IN jacks
on the TV using the audio cables.

Video/Audio Connection

BD Player

Video cable Audio

cable

TV

TV

NOTE

When you use COMPONENT VIDEO OUT
connection, you can change the resolution for the
output. (Refer to “Resolution setting” on page 17.)

BD572-N-BCANLLK-ENG.indd 16BD572-N-BCANLLK-ENG.indd 16 2010.1.22 8:33:39 PM2010.1.22 8:33:39 PM

17Installation

Resolution Setting

The player provides several output resolutions
for HDMI OUT and COMPONENT VIDEO OUT
jacks. You can change the resolution using
[Setup] menu.

1. Press HOME ( ).

2. Use I/i to select the [Setup] and press

ENTER (

3. Use U/u to select [DISPLAY] option then
press i to move to the second level.

). The [Setup] menu appears.

NOTE

If your TV does not accept the resolution you

•
have set on the player, you can set resolution to
480p as follows:

1. Press Z to open the disc tray.
2 Press x (STOP) for more than 5 seconds.
Since several factors a ect the resolution of

•
video output, see “Video Output Resolution” on
page 78.

3

Installation

4. Use U/u to select the [Resolution] option
then press ENTER (

) to move to the third

level.

5. Use U/u to select the desired resolution
then press ENTER (

) to con rm your

selection.

BD572-N-BCANLLK-ENG.indd 17BD572-N-BCANLLK-ENG.indd 17 2010.1.22 8:33:39 PM2010.1.22 8:33:39 PM

18 Installation

3

Installation

Connecting to an
Amplifi er

Make one of the following connections,
depending on the capabilities of your existing
equipment.

•

HDMI Audio connection (page 18)

•

Digital Audio connection (page 19)

•

2CH Analog Audio connection (page 19)

Since many factors a ect the type of audio
output, see “Audio Output Speci cations” for
details (pages 76-77).

About Digital Multi-channel sound

A digital multi-channel connection provides
the best sound quality. For this, you need
a multi-channel Audio/Video Receiver that
supports one or more of the audio formats
supported by your player. Check the receiver
manual and the logos on the front of the
receiver. (PCM Stereo, PCM Multi-Ch, Dolby
Digital, Dolby Digital Plus, Dolby TrueHD, DTS
and/or DTS-HD)

Connecting to an Amplifi er via
HDMI Output

Connect the player’s HDMI OUT jack to the
corresponding in jack on your ampli er using
a HDMI cable. You will need to activate the
player’s digital output. (See “[AUDIO] Menu” on
pages 29-30.)

HDMI Connection

BD Player

HDMI cable

Receiver/Ampli er

HDMI cable

TV

Connect the ampli er’s HDMI output jack to
HDMI input jack on your TV using a HDMI cable
if your ampli er has HDMI output jack.

BD572-N-BCANLLK-ENG.indd 18BD572-N-BCANLLK-ENG.indd 18 2010.1.22 8:33:40 PM2010.1.22 8:33:40 PM

19Installation

Connecting to an Amplifi er via
Digital Audio Output

Connect the player’s DIGITAL AUDIO OUT
jack to the corresponding in jack (OPTICAL or
COAXIAL) on your ampli er. Use an optional
digital audio cable. You will need to activate
the player’s digital output. (See “[AUDIO] Menu”
on pages 29-30.)

Digital Audio Connection

BD Player

OR

OR

Coaxial
cable

Optical
cable

Connecting to an Amplifi er via
2 Channel Audio Output

Connect the Left and Right 2CH AUDIO OUT
jacks on the player to the audio left and right
in jacks on your ampli er, receiver, or stereo
system using audio cables.

2CH Analog Audio Connection

BD Player

3

Installation

Audio cable

Receiver/Ampli er

Receiver/Ampli er

BD572-N-BCANLLK-ENG.indd 19BD572-N-BCANLLK-ENG.indd 19 2010.1.22 8:33:40 PM2010.1.22 8:33:40 PM

20 Installation

3

Installation

Connecting to your
Home Network

This player can be connected to a local area
network (LAN) via the LAN port on the rear
panel or the internal wireless module.
By connecting the unit to a broadband home
network, you have access to services such
as software updates, Home Link, BD-LIVE
interactivity and streaming services.

Wired network connection

Using a wired network provides the best
performance, because the attached devices
connect directly to the network and are not
subject to radio frequency interference.
Please refer to the documentation for your
network device for further instructions.
Connect the player’s LAN port to the
corresponding port on your Modem or Router
using a commercially available LAN or Ethernet
cable (CAT5 or better with RJ45 connector).
In the example con guration for wired
connection below, this player would be able to
access content from either of the PCs.

Wired Network Connection

Router/Modem

Broadband
service

PC

PC

LAN cable

NOTE

When plugging or unplugging the LAN cable,

•

hold the plug portion of the cable. When
unplugging, do not pull on the LAN cable but
unplug while pressing down on the lock.

Do not connect a modular phone cable to the

•

LAN port.
Since there are various connection

•

con gurations, please follow the speci cations
of your telecommunication carrier or internet
service provider.

If you want to access content from PCs or DLNA

•

servers, this player must be connected to the
same local area network with them via a router.

BD572-N-BCANLLK-ENG.indd 20BD572-N-BCANLLK-ENG.indd 20 2010.1.22 8:33:40 PM2010.1.22 8:33:40 PM

BD Player

Wired Network Setup

If there is a DHCP server on the local area
network (LAN) via wired connection, this player
will automatically be allocated an IP address.
After making the physical connection, a small
number of home networks may require the
player’s network setting to be adjusted. Adjust
the [NETWORK] setting as follow.

21Installation

Preparation

Before setting the wired network, you need to
connect the broadband internet to your home
network.

1. Select [Connection Setting] option in the
[Setup] menu then press ENTER (

2. The [Connection Setting] menu appear on
the screen. Use U/
and press ENTER (

u

to select the [Wired]

).

).

NOTE

If there is no DHCP server on the network and you
want to set the IP address manually, select [Static]
then set [IP Address], [Subnet Mask], [Gateway]
and [DNS Server] using U/u/I/
buttons. If you make a mistake while entering a
number, press CLEAR to clear the highlighted part.

4. Select [OK] and press ENTER ( ) to apply
network settings.

5. The player will ask you to test the network
connection. Select [OK] and press ENTER

) to complete the network connection.

(

6. If you select [Test] and press ENTER
( ) at step 5 above, the network
connection status is displayed on the
screen.
You can also test it on the [Connection
Status] in the [Setup] menu.

i

and numerical

3

Installation

3. Use U/u/I/

i

to select the IP mode
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.

BD572-N-BCANLLK-ENG.indd 21BD572-N-BCANLLK-ENG.indd 21 2010.1.22 8:33:41 PM2010.1.22 8:33:41 PM

22 Installation

3

Installation

Wireless Network Connection

Another connection option is to use an Access
Point or a wireless router. In the example
con guration for wireless connection below,
this player would be able to access content
from either of the PCs.

The network con guration and connection
method may vary depending on the
equipment in use and the network
environment.

This player is equipped with an IEEE 802.11n
(2.4 GHz band only) wireless module, which
also supports the 802.11b/g standards. For the
best wireless performance, we recommend
using a IEEE 802.11n certi ed Wi-Fi network
(access point or wireless router).

Refer to the setup instructions supplied with
your access point or wireless router for detailed
connection steps and network settings.

Wireless Network Connection

BD Player

Wireless

Communication

PC

NOTE

For best performance, a direct wired connection
from this player to your home network’s router or
cable/DSL modem is always the best option. If the
player is far away from your router or cable/DSL
modem, Ethernet or LAN cables are available at
many stores in lengths of 50 feet and longer. If
you do chose to use the wireless option, note that
performance can sometimes be a ected by other
electronic devices in the home.

Wireless Network Setup

For the wireless network connection, the
player needs to be set up for network
communication. This adjustment can be done
from the [Setup] menu. Adjust the [NETWORK]
setting as follow. Setting up the access point
or the wireless router is required before
connecting the player to the network.

Preparation

Before setting the wireless network, you need
to:

connect the broadband internet to the

-

wireless home network.
set the access point or wireless router.

-

note the SSID and security code of the

-

network.

1. Select [Connection Setting] option in the
[Setup] menu then press ENTER (

).

Access Point or
Wireless Router

WAN

Broadband
service

BD572-N-BCANLLK-ENG.indd 22BD572-N-BCANLLK-ENG.indd 22 2010.1.22 8:33:41 PM2010.1.22 8:33:41 PM

2. The [Connection Setting] menu appear on
the screen. Use U/

u

to select [Wireless] and

press ENTER ( ).

3. Select [Yes] and press ENTER ( ) to
continue. The new connection settings
reset the current network settings.

4. The player scans the all available access
points or wireless routers within range and
display them as a list. Use U/

u

to select an
access point or wireless router on the list,
and then press ENTER ( ).

NOTE

•

WEP security mode generally have 4 keys
available on an access point or wireless router’
s setting. If your access point or wireless router
use WEP security, enter the security code of the
key “No.1” to connect on your home network.

An Access Point is a device that allows you to

•
connect to your home network wirelessly.

[Manual] – Your access point may not
be broadcasting its access point name
(SSID). Check your router settings through
your computer and either set your router
to broadcast SSID, or manually enter the
access point name (SSID) in [Manual].

[Push Button] – If your access point or
wireless router that supports the Push
Button Con guration method, select this
option and press the Push Button on your
access point or wireless router within 120
counts. You do not need to know the access
point name (SSID) and security code of your
access point or wireless router.

i

/I/

u

5. Use U/
between [Dynamic] and [Static].
Normally, select [Dynamic] to allocate an IP
address automatically.

to select the IP mode

23Installation

3

Installation

NOTE

If there is no DHCP server on the network and you
want to set the IP address manually, select [Static]
then set [IP Address], [Subnet Mask], [Gateway]
and [DNS Server] using U/u/I/
buttons. If you make a mistake while entering a
number, press CLEAR to clear the highlighted part.

If you have security on your access point
or wireless router, verify that the WEP or
WPA key that was entered into the player
matches the router’s information exactly.

6. Select [OK] and press ENTER ( ) to apply
network settings.

You need to input the security code as
necessary.

BD572-N-BCANLLK-ENG.indd 23BD572-N-BCANLLK-ENG.indd 23 2010.1.22 8:33:42 PM2010.1.22 8:33:42 PM

i

and numerical

24 Installation

3

Installation

7. The player will ask you to test the network
connection. Select [OK] and press ENTER
( ) to complete the network connection.

8. If you select [Test] and press ENTER (

)
at step 7 above, the network connection
status is displayed on the screen.
You can also test it on the [Connection
Status] in the [Setup] menu.

Notes on Network Connection:

•

Many network connection problems during
set up can often be  xed by re-setting the
router or modem. After connecting the
player to the home network, quickly power
o and/or disconnect the power cable of
the home network router or cable modem.
Then power on and/or connect the power
cable again.

Depending on the internet service provider

•
(ISP), the number of devices that can
receive internet service may be limited by
the applicable terms of service. For details,
contact your ISP.

Our company is not responsible for

•
any malfunction of the player and/or
the internet connection feature due to
communication errors/malfunctions
associated with your broadband internet
connection, or other connected equipment.

•

The features of BD-ROM discs made
available through the Internet Connection
feature are not created or provided
by our company, and our company is
not responsible for their functionality
or continued availability. Some disc
related material available by the Internet
Connection may not be compatible with
this player. If you have questions about such
content, please contact the producer of the
disc.

Some internet contents may require a

•
higher bandwidth connection.

Even if the player is properly connected and

•
con gured, some internet contents may

not operate properly because of internet
congestion, the quality or bandwidth of
your internet service, or problems at the
provider of the content.

Some internet connection operations may

•
not be possible due to certain restrictions
set by the Internet service provider (ISP)
supplying your broadband Internet
connection.

•

Any fees charged by an ISP including,
without limitation, connection charges are
your responsibility.

A 10 Base-T or 100 Base-TX LAN port is

•
required for wired connection to this player.
If your internet service does not allow for
such a connection, you will not be able to
connect the player.

You must use a Router to use xDSL service.

•

•

A DSL modem is required to use DSL service
and a cable modem is required to use cable
modem service. Depending on the access
method of and subscriber agreement with
your ISP, you may not be able to use the
internet connection feature contained in
this player or you may be limited to the
number of devices you can connect at the
same time. (If your ISP limits subscription
to one device, this player may not be
allowed to connect when a PC is already
connected.)

The use of a “Router” may not be allowed

•
or its usage may be limited depending on
the policies and restrictions of your ISP. For
details, contact your ISP directly.

The wireless network operate at 2.4GHz

•
radio frequencies that are also used by
other household devices such as cordless
telephone, Bluetooth® devices, microwave
oven, and can be a ected by interference
from them.

•

Turn o all unused network equipment in
your local home network. Some devices
may generate network tra c.

BD572-N-BCANLLK-ENG.indd 24BD572-N-BCANLLK-ENG.indd 24 2010.1.22 8:33:42 PM2010.1.22 8:33:42 PM

For the purpose of the better transmission,

•
place the player as close as possible to the
access point.

In some instances, placing the access point

•
or wireless router at least 0.45 m above the
 oor may improve the reception.

•

Move closer to the access point if possible
or re-orient the player so there is nothing
between it and the access point.

•

The reception quality over wireless depends
on many factors such as type of the access
point, distance between the player and
access point, and the location of the player.

•

Set your access point or wireless router to
Infrastructure mode. Ad-hoc mode is not
supported.

USB device
connection

This player can play movie, music and photo
 les contained in the USB device.

Playback content in the USB
device

1. Insert a USB device to the USB port until it
 ts into place.

USB device connection

25Installation

3

Installation

When you connect the USB device on the
HOME menu, the player plays a music 
le contained in the USB storage device
automatically. If the USB storage device is
containing various types of  les, a menu for
the  le type selection will appear.

File loading may takes few minutes depending
on the number of content stored in the USB
storage device. Press ENTER (
is selected to stop loading.

2. Press HOME ( ).

BD572-N-BCANLLK-ENG.indd 25BD572-N-BCANLLK-ENG.indd 25 2010.1.22 8:33:43 PM2010.1.22 8:33:43 PM

) while [Cancel]

26 Installation

3. Select [Movie], [Photo] or [Music] using

4. Select the [USB] option using I/i, and

3

Installation

5. Select a  le using U/u/I/i, and press PLAY

6. Withdraw the USB device carefully.

I/i

, and press ENTER ( ).

press ENTER ( ).

or ENTER ( ) to play the  le.

NOTE

This player supports USB  ash memory/external

•

HDD formatted in FAT16, FAT32 and NTFS when
accessing  les (music, photo, movie). However,
for BD-LIVE and Audio CD recording, only FAT16
and FAT32 formats are supported. Use the USB
 ash memory/external HDD formatted in either
FAT16 or FAT32 when using BD-LIVE and Audio
CD recording.

The USB device can be used for the local storage

•

for enjoying BD-LIVE discs with Internet.
This unit can support up to 4 partitions of the

•

USB device.
Do not extract the USB device during operation

•

(play, etc.).
A USB device which requires additional program

•

installation when you have connected it to a
computer, is not supported.

USB device: USB device that supports USB1.1

•

and USB2.0.
Movie, music and photo  les can be played.

•

For details of operations on each  le, refer to
relevant pages.

Regular back up is recommended to prevent

•

data loss.
If you use a USB extension cable, USB HUB or

•

USB Multi-reader, the USB device may not be
recognized.

Some USB device may not work with this unit.

•

Digital camera and mobile phone are not

•

supported.
USB Port of the unit cannot be connected to PC.

•

The unit cannot be used as a storage device.

BD572-N-BCANLLK-ENG.indd 26BD572-N-BCANLLK-ENG.indd 26 2010.1.22 8:33:43 PM2010.1.22 8:33:43 PM

27Installation

Settings

Adjust the Setup Settings

You can change the settings of the player in
the [Setup] menu.

1. Press HOME (

2. Use I/i to select the [Setup] and press

ENTER (

).

). The [Setup] menu appears.

4. Use U/u to select a second setup option,
and press ENTER (
level.

5. Use U/u to select a desired setting, and
press ENTER ( ) to con rm your selection.

) to move to the third

[DISPLAY] Menu

TV Aspect Ratio

Select a TV aspect ratio option according to
your TV type.

[4:3 Letter Box]

Select when a standard 4:3 TV is connected.
Displays theatrical images with masking
bars above and below the picture.

3

Installation

[4:3 Pan Scan]

3. Use U/u to select the  rst setup option, and

i

to move to the second level.

press

BD572-N-BCANLLK-ENG.indd 27BD572-N-BCANLLK-ENG.indd 27 2010.1.22 8:33:44 PM2010.1.22 8:33:44 PM

Select when a standard 4:3 TV is connected.
Displays pictures cropped to  ll your TV
screen. Both sides of the picture are cut o .

[16:9 Original]

Select when a 16:9 wide TV is connected.
The 4:3 picture is displayed with an original
4:3 aspect ratio, with black bars appearing
at the left and right sides.

[16:9 Full]

Select when a 16:9 wide TV is connected.
The 4:3 picture is adjusted horizontally (in a
linear proportion) to  ll the entire screen.

28 Installation

NOTE

You cannot select [4:3 Letter Box] and [4:3 Pan
Scan] option when the resolution is set to higher
than 720p.

1080p Display Mode

When the resolution is set to 1080p, select
[24 Hz] for smooth presentation of  lm material
(1080p/24 Hz) with a HDMI-equipped display
compatible with 1080p/24 Hz input.

3

Installation

Resolution

Sets the output resolution of the Component
and HDMI video signal. Refer to page 17 and
78 for details about the resolution setting.

[Auto]

If the HDMI OUT jack is connected to
TVs providing display information (EDID),
automatically selects the resolution
best suited to the connected TV. If the
COMPONENT VIDEO OUT is only connected,
this changes the resolution to 1080i as
default resolution.

[1080p]

Outputs 1080 lines of progressive video.

[1080i]

Outputs 1080 lines of interlaced video.

[720p]

Outputs 720 lines of progressive video.

[480p]

Outputs 480 lines of progressive video.

[480i]

Outputs 480 lines of interlaced video.

NOTE

When you select [24 Hz], you may experience

•

some picture disturbance when the video
switches video and  lm material. In this case,
select [60 Hz].

Even when [1080p Display Mode] is set to

•

[24 Hz], if your TV is not compatible with
1080p/24 Hz, the actual frame frequency of the
video output will be 60 Hz to match the video
source format.

HDMI Color Setting

Select the type of output from the HDMI
OUT jack. For this setting, please refer to the
manuals of your display device.

[YCbCr]

Select when connecting to a HDMI display
device.

[RGB]

Select when connecting to a DVI display
device.

BD572-N-BCANLLK-ENG.indd 28BD572-N-BCANLLK-ENG.indd 28 2010.1.22 8:33:44 PM2010.1.22 8:33:44 PM

29Installation

[LANGUAGE] Menu

Display Menu

Select a language for the [Setup] menu and
on-screen display.

Disc Menu/Disc Audio/Disc Subtitle

Select the language you prefer for the audio
track (disc audio), subtitles, and the disc menu.

[Original]

Refers to the original language in which the
disc was recorded.

[Other]

Press ENTER (
Use number buttons then press ENTER (
to enter the corresponding 4-digit number
according to the language code list on
page 73.

[O ] (Disc Subtitle only)

Turn o Subtitle.

Depending on the disc, your language setting may
not work.

) to select another language.

)

NOTE

[AUDIO] Menu

Each disc has a variety of audio output options.
Set the player’s Audio options according to the
type of audio system you use.

NOTE

Since many factors a ect the type of audio output,
see “Audio Output Speci cations” on page 76-77 for
details.

HDMI / Digital Output

Select the output sound format when a device
equipped with a HDMI or Digital Audio input
jack is connected to the HDMI OUT or DIGITAL
AUDIO OUT jack on this player.

[PCM Stereo]

Select if you connect this unit’s HDMI OUT
or DIGITAL AUDIO OUT jack to a device with
two-channel digital stereo decoder.

[PCM Multi-Ch] (HDMI only)

Select if you connect this unit’s HDMI OUT
jack to a device with multi-channel digital
decoder.

[DTS Re-Encode]

Select if you connect this unit’s HDMI OUT
or DIGITAL AUDIO OUT jack to a device with
DTS decoder.

3

Installation

[Primary Pass-Thru]

Select if you connect this unit’s DIGITAL
AUDIO OUT and HDMI OUT jack to a device
with LPCM, Dolby Digital, Dolby Digital Plus,
Dolby TrueHD, DTS and DTS-HD decoder.

BD572-N-BCANLLK-ENG.indd 29BD572-N-BCANLLK-ENG.indd 29 2010.1.22 8:33:45 PM2010.1.22 8:33:45 PM

30 Installation

Sampling Freq.

3

(Digital Audio Output)

Installation

Check the documentation for your A/V
Receiver or Ampli er to verify its capabilities.

NOTE

When [HDMI] option is set to [PCM Multi-Ch],

•
the audio may output as PCM Stereo if the PCM
Multi-Ch information is not detected from HDMI
device with EDID.

If the [HDMI] or [Digital Output] option is set to

•
[DTS re-encode], the DTS Re-encode audio is
output for BD-ROM discs with secondary audio
and the original audio is output for the other
discs (like [Primary Pass-Thru]).

[192 kHz]

Select this if your A/V Receiver or Ampli er
is capable of handling 192 kHz signals.

[96 kHz]

Select this if your A/V Receiver or Ampli er
is not capable of handling 192 kHz signals.
When this choice is made, this unit
automatically converts any 192 kHz signals
to 96 kHz so your system can decode them.

[48 kHz]

Select this if your A/V Receiver or Ampli er
is not capable of handling 192 kHz and
96 kHz signal. When this choice is made,
this unit automatically converts any 192 kHz
and 96 kHz signals to 48 kHz so your system
can decode them.

DRC (Dynamic Range Control)

When a title encoded in Dolby Digital or Dolby
Digital Plus is playing back, you may wish to
compress the dynamic range of the audio
output (the di erence between the loudest
sounds and the quietest ones). This allows you
to listen to a movie at a lower volume without
losing clarity of sound. Set [DRC] to [On] for
this e ect.

NOTE

The DRC setting can be changed only when a
disc is not inserted or the unit is in complete stop
mode.

[LOCK] Menu

The [LOCK] settings a ect only BD and DVD
playback.

To access the any features in [LOCK] settings,
you must enter the 4-digit security code you
have created.
If you have not entered a password yet, you are
prompted to do so. Enter a 4-digit password
twice, and press ENTER (
password.

Password

You can create, or change the password.

[None]

Enter a 4-digit password twice, and press
ENTER (

) to create a new password.

) to create a new

[Change]

Enter the current password and press ENTER

). Enter a 4-digit password twice, and

(
press ENTER ( ) to create a new password.

BD572-N-BCANLLK-ENG.indd 30BD572-N-BCANLLK-ENG.indd 30 2010.1.22 8:33:45 PM2010.1.22 8:33:45 PM

If you forget your password

If you forget your password, you can clear it
using the following steps:

1. Remove any disc that might be in the
player.

2. Select [Password] option in the [Setup]
menu.

3. Use Number buttons to enter “210499”. The
password is cleared.

NOTE

If you make a mistake before pressing ENTER ( ),
press CLEAR. Then input the correct password.

DVD Rating

Blocks playback of rated DVD based on their
content. (Not all discs are rated.)

[Rating 1-8]

Rating one (1) has the most restrictions and
rating eight (8) is the least restrictive.

31Installation

NOTE

The [BD rating] will be applied only for the BD disc
that containing the Advanced Rating Control.

Area Code

Enter the code of the area whose standards
were used to rate the DVD video disc, based
on the list on page 72.

3

Installation

[Unlock]

If you select [Unlock], parental control is not
active and the disc plays in full.

BD Rating

Sets an age limit for BD-ROM playback. Use
number buttons to input an age limit for BD­ROM viewing.

[255]

All BD-ROM can be played.

[0-254]

Prohibits play of BD-ROM with
corresponding ratings recorded on them.

BD572-N-BCANLLK-ENG.indd 31BD572-N-BCANLLK-ENG.indd 31 2010.1.22 8:33:45 PM2010.1.22 8:33:45 PM

32 Installation

3

Installation

[NETWORK] Menu

The [NETWORK] settings are needed to use
the software update, BD Live, Home Link and
NetCast features.

Connection Setting

If your home network environment is ready to
connect the player, the player needs to be set
the wired or wireless network connection for
network communication. (See “Connecting to
your Home Network” on pages 20-25.)

Connection Status

If you want to check the network status on
this player, select the [Connection Status]
options and press ENTER ( ) to check whether
a connection to the network and the internet
have been established.

BD-LIVE connection

You can restrict Internet access when BD-LIVE
functions are used.

[Permitted]

Internet access is permitted for all BD-LIVE
contents.

[Partially permitted]

Internet access is permitted only for BD­LIVE contents which have content owner
certi cates. Internet access and AACS
Online functions are prohibited for all BD­LIVE contents without a certi cate.

[OTHERS] Menu

DivX VOD

ABOUT DIVX VIDEO: DivX® is a digital video
format created by DivX, Inc. This is an o cial
DivX Certi ed device that plays DivX video.
Visit www.divx.com for more information and
software tools to convert your  les into DivX
video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX
Certi ed® device must be registered in order to
play DivX Video-on-Demand (VOD) content.
To generate the registration code, locate the
DivX VOD section in the device setup menu.
Go to vod.divx.com with this code to complete
the registration process and learn more about
DivX VOD.

[Register]

Displays the registration code of your player.

[Deregister]

Deactivate your player and display the
deactivation code.

NOTE

All the downloaded videos from DivX VOD with
this player’s registration code can only be played
back on this unit.

[Prohibited]

Internet access is prohibited for all BD-LIVE
contents.

BD572-N-BCANLLK-ENG.indd 32BD572-N-BCANLLK-ENG.indd 32 2010.1.22 8:33:46 PM2010.1.22 8:33:46 PM

33Installation

Auto Power Off

The screen saver appears when you leave
the player in Stop mode for about  ve
minutes. If you set this option to [On], the unit
automatically turns itself o after the Screen
Saver is displayed for 25 minutes.
Set this option to [O ] to leave the screen
saver until the unit is operated by the user.

Initialize

[Factory Set]

You can reset the player to its original
factory settings.

[BD Storage Clear]

Initializes the BD contents from the
connected USB storage.

NOTE

If you reset the player to its original factory settings
using [Factory Set] option, you have to set the
network settings again.

Software

[Information]

Displays the current software version.

[Update]

You can update the software by connecting
the unit directly to the software update
server (see page 70-71).

Disclaimer Notice

Press ENTER ( ) to view the notice of Network
Service Disclaimer on page 80.

3

Installation

BD572-N-BCANLLK-ENG.indd 33BD572-N-BCANLLK-ENG.indd 33 2010.1.22 8:33:46 PM2010.1.22 8:33:46 PM

34 Operation

4
Operation

4

Operation

General Playback

Playing Discs

1. Press Z (OPEN/CLOSE), and place a disc on
the disc tray.

Insert a disc

2. Press Z (OPEN/CLOSE) to close the disc
tray.

For the most Audio CD, BD-ROM and
DVD-ROM discs, playback starts
automatically.

3. Press HOME (

).

5. Select the [Disc] option using I/i, and
press ENTER (

This step is needed only when a disc and a
USB device are connected simultaneously
in this unit.

6. Select a  le using U/u/I/i, and press B
(PLAY) or ENTER ( ) to play the  le.

).

NOTE

Playback functions described in this manual are

•
not always available in every  les and media.
Some functions can be restricted depending on
many factors.

Depending on the BD-ROM titles, a USB device

•
connection may be needed for the proper
playback.

4. Select [Movie], [Photo] or [Music] using

I/i

, and press ENTER ( ).

BD572-N-BCANLLK-ENG.indd 34BD572-N-BCANLLK-ENG.indd 34 2010.1.22 8:33:46 PM2010.1.22 8:33:46 PM

35Operation

To stop playback

Press x (STOP) during playback.

To pause playback

Press X (PAUSE) during playback.
Press B (PLAY) to resume playback.

To play frame-by-frame

Press X (PAUSE) while movie playback.
Press X (PAUSE) repeatedly to play Frame-by­Frame playback.

To scan forward or backward

Press m or M to play fast forward or fast
reverse during playback.
You can change the various playback speeds
by pressing m or M repeatedly.

To slow down the playing speed

While the playback is paused, press M
repeatedly to play various speeds of slow
motion.

To skip to the next/previous
chapter/track/fi le

During playback, press . or > to go to
the next chapter/track/ le or to return to the
beginning of the current chapter/track/ le.
Press . twice brie y to step back to the
previous chapter/track/ le.

In the [Home Link] menu, there may be
many types of contents in the current folder
together. In this case, press . or > to
go to the previous or next content with same
type.

Using the disc menu

BD DVD AVC HD

To display the disc menu

The menu screen may be displayed  rst after
loading a disc which contains a menu. If you
want to display the disc menu during playback,
press DISC MENU.

Use U/u/I/i buttons to navigate through
menu items.

To display the Pop-up menu

Some BD-ROM discs contain a Pop-up menu
that appears during playback.

Press TITLE/POPUP during playback, and use

U/u/I/i

items.

buttons to navigate through menu

4

Operation

BD572-N-BCANLLK-ENG.indd 35BD572-N-BCANLLK-ENG.indd 35 2010.1.22 8:33:47 PM2010.1.22 8:33:47 PM

36 Operation

4

Operation

Resume playback

BD DVD AVC HD MOVIE MOVIE-N

ACD MUSIC MUSIC-N

The unit records the point where you pressed
the x (STOP) depending on the disc.
If “

(Resume Stop)” appears on the screen

Xx

brie y, press B (PLAY) to resume playback
(from the scene point).
If you press x (STOP) twice or unload the disc,
“x (Complete Stop)” appears on the screen.
The unit will clear the stopped point.

NOTE

The resume point may be cleared when a

•
button is pressed (for example; 1 (POWER),

(OPEN/CLOSE), etc).

Z

On BD-Video discs with BD-J, the resume

•
playback function does not work.

If you press x (STOP) once during BD-ROM

•
interactive title playback, the unit will be in
Complete Stop mode .

Advanced Playback

Repeat Playback

BD DVD AVC HD ACD MUSIC

MUSIC-N

During playback, press REPEAT repeatedly to
select a desired repeat mode.

BDs/DVDs

A- – Selected portion will be repeated

continually.

Chapter

played back repeatedly.

Title

back repeatedly.

To return to normal playback, press REPEAT
repeatedly to select [O ].

Audio CDs/Music  les

played back repeatedly.

back repeatedly.

in random order.

played back repeatedly in random order.

continually. (Audio CD only)

– The current chapter will be

– The current title will be played

– The current track or  le will be

Track

– All the tracks or  les will be played

All

– The tracks or  les will be played back

– All the tracks or  les will be

All

– Selected portion will be repeated

A-B

To return to normal playback, press CLEAR.

BD572-N-BCANLLK-ENG.indd 36BD572-N-BCANLLK-ENG.indd 36 2010.1.22 8:33:48 PM2010.1.22 8:33:48 PM

37Operation

NOTE

•

If you press > once during Repeat Chapter/
Track playback, the repeat playback cancels.

This function may not work on some disc or title.

•

Repeating a specifi c portion

BD DVD AVC HD ACD

This player can repeat a portion you have
selected.

1. During playback, press REPEAT to select [A-]
at the beginning of the portion you wish to
repeat.

2. Press ENTER (
Your selected portion will be repeated
continually.

3. To return to normal playback, press REPEAT
repeatedly to select [O ].

NOTE

You cannot select a portion less than 3 seconds.

•
This function may not work on some disc or title.

•

) at the end of the portion.

Enlarge the playback image

BD DVD AVC HD MOVIE MOVIE-N


1. During playback or pause mode, press

ZOOM to display the [Zoom] menu.

2. Use red (R) or green (G) colored button to
zoom out or in the picture.
You can move through the zoomed picture
using U/u/I/i buttons.

3. To return to the normal picture size, press
yellow (Y) colored button.

4. Press RETURN (O) to exit the [Zoom]
menu.

Marker Search

BD DVD AVC HD MOVIE MOVIE-N

You can start playback from up to nine
memorized points.

To enter a marker

1. During playback, press MARKER at the
desired point. The Marker icon appears on
the TV screen brie y.

2. Repeat step 1 to add up to nine markers.

4

Operation

To recall a marked scene

1. Press SEARCH and the search menu appears
on the screen.

2. Press a number button to select a marker
number that you want to recall. Playback
starts from the marked scene.

BD572-N-BCANLLK-ENG.indd 37BD572-N-BCANLLK-ENG.indd 37 2010.1.22 8:33:48 PM2010.1.22 8:33:48 PM

38 Operation

4

Operation

To delete a Marker

1. Press SEARCH and the search menu appears
on the screen.

2. Press u to highlight a marker number. Use

I/i

to select a marked scene that you

want to delete.

3. Press CLEAR and the marked scene is erased
from the search menu.

NOTE

•

This function may not work depending on discs,
titles, server ability.

•

All marked points are cleared if the title is in
complete stop (x) mode, the title is changed or
if you unload the disc.

If the total length of the title is less than 10

•
seconds, this function is not available.

Using the search menu

BD DVD AVC HD MOVIE MOVIE-N

To start playback from a marked
scene

1. Press SEARCH and the search menu appears
on the screen.

2. Press u to highlight a marker number. Use

I/i

to select a marked scene that you

want to playback.

3. Press ENTER ( ) to start playback from the
marked scene.

NOTE

•

This function may not work depending on discs,
titles, server ability.

•

This function may not work on some [Home
Link] content depending on the  le type and
ability of the DLNA server.

Using search menu, you can easily to  nd the
point where you want to start playback.

To search a point

1. During playback, press SEARCH to display
the search menu.

2. Press I/i to skip the playback 15 seconds
forward or backward. You can select a
point that you want to skip by pressing and
holding I/i button.

BD572-N-BCANLLK-ENG.indd 38BD572-N-BCANLLK-ENG.indd 38 2010.1.22 8:33:49 PM2010.1.22 8:33:49 PM

39Operation

Changing content list view

MOVIE MOVIE-N MUSIC MUSIC-N PHOTO

On the [Movie], [Music], [Photo] or [Home Link]
menu, you can change the content list view.

Method 1

Press red (R) coloured button repeatedly.

Viewing content information

MOVIE MOVIE-N

The player can display the content information.

1. Select a  le using U/u/I/i.

2. Press INFO/DISPLAY (

) to display the

option menu.

3. Select the [Information] option using U/u,
and press ENTER (

).

The  le information appears on the screen.

During movie playback, you can display the  le
information by pressing TITLE/POPUP.

NOTE

The information displayed on the screen may
not be correct compared to the actual content
information.

Last Scene Memory

BD DVD

This unit memorizes the last scene from the
last disc that is viewed. The last scene remains
in memory even if you remove the disc from
the unit or switch o the unit. If you load a disc
that has the scene memorized, the scene is
automatically recalled.

4

Operation

NOTE

Last Scene Memory function for a previous disc

•

Method 2

1. On the content list, press INFO/DISPLAY ( )
to display the option menu.

option.

view.

u

to select the [View Change]

) to change the content list

2. Use U/

3. Press ENTER (

BD572-N-BCANLLK-ENG.indd 39BD572-N-BCANLLK-ENG.indd 39 2010.1.22 8:33:49 PM2010.1.22 8:33:49 PM

is erased once a di erent disc is played.
This function may not work depending on the

•
disc.

On BD-Video discs with BD-J, the last scene

•
memory function does not work.

This unit does not memorize settings of a disc if

•
you switch o the unit before commencing to
play it.

40 Operation

On-Screen display

You can display and adjust various information
and settings about the content.

Displaying content information
on-screen

BD DVD AVC HD MOVIE MOVIE-N

Movie Information – Select this option

i

and press ENTER (

) to display movie
information from Gracenote Media
Database (BD/DVD only).

2. Select an option using U/u.

3. Use I/i to adjust the selected option

value.

4. Press RETURN (O) to exit the On-Screen
display.

4

Operation

1. During playback, press INFO/DISPLAY ( ) to
show various playback information.

a
b
c

d

e
f

g
h
i

Title – current title number/total number

a

of titles
Chapter – current chapter number/total

b

number of chapters
Time – elapsed playing time/total

c

playback time
Audio – selected audio language or

d

channel
Subtitle – selected subtitle

e

Angle – selected angle/total number of

f

angles
TV Aspect Ratio – selected TV aspect

g

Ratio
Picture Mode – selected picture mode

h

NOTE

If no button is pressed for a few seconds, the on-

•
screen display disappears.

A title number cannot be selected on some

•
discs.

Available items may di er depending on discs

•
or titles.

If BD interactive title is playing back, some

•
setting information is displayed on the screen
but prohibited to be changed.

To use the [Movie Information] option, the player

•
must be connected to the broadband internet
for accessing the Gracenote Media Database.

If the information from the Gracenote Media

•
Database is either not correct or does not exist,
please contact www.gracenote.com for support.

LG is a licensee of Gracenote technology and is

•
not responsible or reliable for information from
the Gracenote Media Database.

BD572-N-BCANLLK-ENG.indd 40BD572-N-BCANLLK-ENG.indd 40 2010.1.22 8:33:50 PM2010.1.22 8:33:50 PM

41Operation

Playing from selected time

BD DVD AVC HD MOVIE MOVIE-N

1. Press INFO/DISPLAY ( ) during playback.

The time search box shows the elapsed
playing time.

2. Select the [Time] option and then input the
required start time in hours, minutes, and
seconds from left to right.

For example, to  nd a scene at 2 hours, 10
minutes, and 20 seconds, enter “21020”.

Press I/i to skip the playback 60 seconds
forward or backward.

3. Press ENTER (
selected time.

NOTE

•

This function may not work on some disc or
titles.

•

This function may not work on some [Home
Link] content depending on the  le type and
ability of the DLNA server.

) to start playback from

NOTE

•

Some discs allow you to change audio selections
only via the disc menu. In this case, press TITLE/
POP-UP or DISC MENU button and choose the
appropriate audio from the selections on the
disc menu.

Immediately after you have switched sound,

•
there may be a temporary discrepancy between
the display and actual sound.

On BD-ROM disc, the multi audio format (5.1CH

•
or 7.1CH) is displayed with [MultiCH] in the on­screen display.

Selecting a subtitle language

BD DVD AVC HD MOVIE MOVIE-N

1. During playback, press INFO/DISPLAY ( ) to

display the On-Screen display.

display.

u

to select the [Subtitle] option.

i

to select desired subtitle language.

2. Use U/

3. Use I/

4. Press RETURN (O) to exit the On-Screen

4

Operation

Hearing different audio

BD DVD AVC HD MOVIE MOVIE-N

1. During playback, press INFO/DISPLAY ( ) to

display the On-Screen display.

2. Use U/

3. Use I/

u

to select the [Audio] option.

i

to select desired audio language,

NOTE

Some discs allow you to change subtitle selections
only via the disc menu. If this is the case, press
TITLE/POPUP or DISC MENU button and choose
the appropriate subtitle from the selections on the
disc menu.

audio track or audio channel.

BD572-N-BCANLLK-ENG.indd 41BD572-N-BCANLLK-ENG.indd 41 2010.1.22 8:33:50 PM2010.1.22 8:33:50 PM

42 Operation

4

Operation

Watching from a different
angle

If the disc contains scenes recorded at di erent
camera angles, you can change to a di erent
camera angle during playback.

1. During playback, press INFO/DISPLAY (

2. Use U/

3. Use I/

4. Press RETURN (O) to exit the On-Screen

BD DVD

display the On-Screen display.

u

to select the [Angle] option.

i

to select desired angle.

display.

) to

Changing the TV Aspect Ratio

BD DVD AVC HD MOVIE MOVIE-N

You can change the TV aspect ratio setting
during playback.

1. During playback, press INFO/DISPLAY ( ) to
display the On-Screen display.

option.

display.

u

to select the [TV Aspect Ratio]

i

to select desired option.

2. Use U/

3. Use I/

4. Press RETURN (O) to exit the On-Screen

Changing the Picture Mode

BD DVD AVC HD MOVIE MOVIE-N

You can change the [Picture mode] option
during playback.

1. During playback, press INFO/DISPLAY (
display the On-Screen display.

option.

display.

u

to select the [Picture Mode]

i

to select desired option.

2. Use U/

3. Use I/

4. Press RETURN (O) to exit the On-Screen

Setting the [User setting] option

1. During playback, press INFO/DISPLAY ( ) to
display the On-Screen display.

2. Use U/

3. Use I/

u

to select the [Picture Mode]

option.

i

to select the [User setting] option,

and press ENTER (

).

) to

NOTE

Even if you change the value of the [TV Aspect
Ratio] option in On-Screen display, the [TV Aspect
Ratio] option in the [Setup] menu is not changed.

BD572-N-BCANLLK-ENG.indd 42BD572-N-BCANLLK-ENG.indd 42 2010.1.22 8:33:50 PM2010.1.22 8:33:50 PM

4. Use U/u/I/
options.

Select [Default] option then press ENTER
(

) to reset the all video adjustments.

5. Use U/u/I/
and press ENTER (

i

to adjust the [Picture Mode]

i

to select the [Close] option,

) to  nish setting.

43Operation

Enjoying BD-LIVE

This unit allows you to enjoy functions such as
picture-in-picture, secondary audio and Virtual
packages, etc., with BD-Video supporting
BONUSVIEW (BD-ROM version 2 Pro le 1
version 1.1/ Final Standard Pro le). Secondary
video and audio can be played from a disc
compatible with the picture-in-picture
function. For the playback method, refer to the
instructions in the disc.

In addition to the BONUSVIEW function, BD­Video supporting BD-LIVE (BD-ROM version
2 Pro le 2) that has a network extension
function allows you to enjoy more functions
such as downloading new movie trailers by
connecting this unit to the internet.

1. Check the network connection and settings
(pages 20-25).

2. Insert a USB storage device to the USB port
on the front panel.

A USB storage device is needed to
download bonus content.

USB device connection

3. Press HOME ( ), and set the [BD-LIVE
connection] option on the [Setup] menu
(page 32).

Depending on the disc, the BD-LIVE
function may not be operated if [BD­LIVE connection] option is set to [Partially
Permitted].

4. Insert a BD-ROM with BD-LIVE.
The operations may di er depending on

the disc. Refer to the manual supplied with
the disc.

CAUTION

Do not extract the connected USB device while
content is being downloaded or a Blu-ray disc is
still in the disc tray. Doing so may damage the
connected USB device and BD-LIVE features may
not operate properly with the damaged USB
device anymore. If the connected USB device
seems damaged from such an action, you can
format the connected USB device from the PC and
reuse it with this player.

NOTE

Some BD-LIVE contents may be restrictively

•
accessed in some territories by contents
provider’s own decision.

It may take up to several minutes to load and

•
start enjoying BD-LIVE contents.

4

Operation

BD572-N-BCANLLK-ENG.indd 43BD572-N-BCANLLK-ENG.indd 43 2010.1.22 8:33:51 PM2010.1.22 8:33:51 PM

44 Operation

4

Operation

Playing a movie fi le
and VR disc

You can play DVD-RW discs that are recorded
in Video Recording (VR) format and movie  les
contained in a disc/USB device.

1. Press HOME (

2. Select [Movie] using I/i, and press ENTER

( ).

3. Select [Disc] or [USB] option using I/i, and
press ENTER (

This step is needed only when a disc and a
USB device is connected simultaneously to
this unit.

4. Select a  le using U/u/I/i, and press B
(PLAY) or ENTER ( ) to play the  le.

).

).

NOTE

The  le requirements are described on page 10.

•
You can use various playback functions. Refer to

•
pages 34-41.

Un nalized DVD VR format discs may not be

•
played in this player.

Some DVD-VR discs are made with CPRM data

•
by DVD RECORDER. This unit cannot support
these kinds of discs.

What is CPRM?

CPRM is a copy protection system (with
scramble system) only allowing the recording of
‘copy once’ broadcast programs. CPRM stands
for Content Protection for Recordable Media.

Selecting a subtitle fi le

MOVIE

If a movie  le name and the subtitle  le
name are the same, subtitle  le is played
automatically when playing the movie  le.

If the subtitle  le name is di erent with the
movie  le name, you need to select the subtitle
 le on the [Movie] menu before playing the
movie.

1. Use U/u/I/
wish to play in the [Movie] menu.

2. Press ENTER (

i

to select the subtitle  le you

).

Press ENTER ( ) again to deselect the
subtitle  le. Selected subtitle  le will be
displayed when you play the movie  le.

BD572-N-BCANLLK-ENG.indd 44BD572-N-BCANLLK-ENG.indd 44 2010.1.22 8:33:51 PM2010.1.22 8:33:51 PM

45Operation

NOTE

If you press x (STOP) during playback, the subtitle
selection is cancelled.

Changing subtitle code page

MOVIE MOVIE-N

If the subtitle is not displayed properly, you
can change the subtitle code page to view the
subtitle  le properly.

1. During playback, press INFO/DISPLAY (
display the On-Screen display.

display.

u

to select the [Code Page] option.

i

to select desired code option.

2. Use U/

3. Use I/

4. Press RETURN (O) to exit the On-Screen

) to

Viewing a photo

You can view photo  les using this player.

1. Press HOME (

2. Select [Photo] using I/i, and press ENTER

( ).

3. Select the [Disc] or [USB] option using I/i,
and press ENTER (

This step is needed only when a disc and a
USB device is connected simultaneously on
this unit.

4. Select a  le using U/u/I/i, and press
ENTER ( ) to view the photo in full screen.

).

).

4

Operation

BD572-N-BCANLLK-ENG.indd 45BD572-N-BCANLLK-ENG.indd 45 2010.1.22 8:33:52 PM2010.1.22 8:33:52 PM

46 Operation

4

Operation

To play a slide show

Press B (PLAY) to start slide show.

To stop a slide show

Press x (STOP) during slide show.

To pause a slide show

Press X (PAUSE) during slide show.
Press B (PLAY) to re-start the slide show.

To skip to the next/previous photo

While viewing a photo in full screen, press I or

i

to go to the previous or next photo.

NOTE

The  le requirements are described on page 10.

•
You can use various playback functions. Refer to

•
pages 34-41.

Options while viewing a photo

You can use various options while viewing a
photo in full screen.

1. While viewing a photo in full screen, press
INFO/DISPLAY (
menu.

2. Select an option using U/u.

) to display the option

Current photo/Total number of photos

a

– Use I/i to view previous/next photo.
Slide Show – Press ENTER (

b

pause slide show.
Music Select – Select the background

c

music for the slide show (page 47).
Music –Press ENTER (

d

background music.
Rotate – Press ENTER (

e

photo clockwise.
Zoom – Press ENTER (

f

[Zoom] menu.
E ect – Use I/i to select a transition

g

e ect between photos in a slide show.
Speed – Use I/i to select a delaying

h

speed between photos in a slide show.

3. Press RETURN (O) to exit the option menu.

) to start or

) to start or pause

) to rotate the

) to display the

a

b
c
d
e

f
g

h

BD572-N-BCANLLK-ENG.indd 46BD572-N-BCANLLK-ENG.indd 46 2010.1.22 8:33:52 PM2010.1.22 8:33:52 PM

47Operation

Listening to music during a
slide show

You can display photo  les while listening to
music  les.

1. Press HOME (

2. Select [Photo] or [Home Link] using I/i,

and press ENTER ( ).

3. Select the [Disc] or [USB] option using I/i,
and press ENTER (

Selecting a server or a share folder is
needed for [Home Link] menu.

4. Select a  le using U/u/I/i, and press
ENTER (

5. Press INFO/DISPLAY (
option menu.

6. Use U/u to select [Music Select] option,
and press ENTER ( ) to display the [Music
Select] menu.

).

).

) to view the photo.

) to display the

7. Use U/u to select a device, and press ENTER
).

(
Devices that you can select may di er

depending on the location of the photo  le
you are displaying in full screen.

Photo location Available Device

Disc Disc, USB
USB Disc, USB
Share Folder on

your PC (CIFS)
DLNA server DLNA server

8. Use U/u to select a  le or a folder you wish

to play.

Select a folder and press ENTER ( ) to
display the lower directory.

Select and press ENTER ( ) to display
the upper directory.

CIFS

NOTE

When selecting music from [Home Link], folder
selection is not available. Only  le selection is
available on the [Home Link].

9. Use i to select [OK], and press ENTER ( )

to complete music selection.

4

Operation

BD572-N-BCANLLK-ENG.indd 47BD572-N-BCANLLK-ENG.indd 47 2010.1.22 8:33:53 PM2010.1.22 8:33:53 PM

48 Operation

4

Operation

Listening to music

The player can play Audio CDs and music  les.

1. Press HOME (

2. Select [Music] using I/i, and press ENTER

( ).

3. Select the [Disc] or [USB] option using I/i,
and press ENTER (

This step is needed only when a disc and a
USB device is connected simultaneously on
this unit.

4. Select a music  le or audio track using

U/u/I/i

music.

).

).

, and press ENTER ( ) to play the

NOTE

The  le requirements are described on page 10.

•
You can use various playback functions. Refer to

•
pages 34-41.

Audio CD Recording

You can record one desired track or all of the
tracks from an Audio CD to a USB storage
device.

1. Insert a USB storage device to the USB port
on the front panel.

2. Press Z (OPEN/CLOSE), and place an Audio
CD on the disc tray.

Press Z (OPEN/CLOSE) to close the disc
tray. The playback starts automatically.

3. Press INFO/DISPLAY to display the option
menu.

4. Use U/u to select [CD Recording] option,
and press ENTER to display the [CD
Recording] menu.

5. Use U/u to select a track you wish to copy
on the menu, and press ENTER.

Repeat this step to select tracks as many as
you want.

Select all the tracks on an Audio
CD.

Selects an encoding option from
the pop-up menu (128kbps,
192kbps, 320kbps or Lossless).

Cancels the recording and
returns to the previous screen.

BD572-N-BCANLLK-ENG.indd 48BD572-N-BCANLLK-ENG.indd 48 2010.1.22 8:33:53 PM2010.1.22 8:33:53 PM

6. Use U/u/I/i to select [Start], and press
ENTER.

7. Use U/u/I/i to select a destination folder
to be copied.

If you want to create a new folder, use

U/u/I/i

to select [New Folder] and press

ENTER.
Enter a folder name using the virtual

keyboard, and press ENTER while [OK] is
selected.

8. Use U/u/I/i to select [OK], and press
ENTER to start Audio CD Recording.

If you want to stop the Audio CD
Recording, press ENTER (

) while [Cancel]

is highlighted.

9. A message appears when Audio CD
Recording is completed.
Press ENTER (

) to check the music  le

created in the destination folder.

NOTE

The table below shows the average recording

•
time from an audio track with 4 minutes of
playback time to a music  le with 192kbps as an
example.

stop mode during playback

1.4 min. 2 min.

All times in the above table are approximate.

•
Actual ripping time for USB storage device varies

•
depending on the USB storage device’s ability.

Make sure that there is minimum of 50 MB free

•
space when recording into the USB storage
device.

The length of the music should be longer than

•
20 seconds for the proper recording.

Do not turn o this player or extract the

•
connected USB storage device during Audio CD
recording.

The making of unauthorized copies of copy-

protected material, including computer programs,

 les, broadcasts and sound recordings, may be
an infringement of copyrights and constitute a

This equipment should not be used for such

criminal o ense.

purposes.

Be responsible

Respect copyrights

49Operation

4

Operation

BD572-N-BCANLLK-ENG.indd 49BD572-N-BCANLLK-ENG.indd 49 2010.1.22 8:33:54 PM2010.1.22 8:33:54 PM

50

Operation

4

Operation

Viewing information from
Gracenote Media Database

The player can access to the Gracenote Media
Database and loads the music information so
that Track name, Artist Name, Genre and other
text information can be displayed on the list.

Audio CD

When you insert an Audio CD, the player starts
playback automatically and load the music title
from the Gracenote Media Database.

If there is no music information in the database,
music titles will not be displayed on the screen.

Music fi le

1. Select a music  le using U/u/I/i.

2. Press INFO/DISPLAY (

option menu.

3. Select the [Information] option using U/u,
and press ENTER (

The player accesses Gracenote Media
Database for the music information.

) to display the

).

NOTE

The player must be connected to the broadband

•
internet for accessing the Gracenote Media
Database.

If the music information is not in the Gracenote

•
Media Database, message appears on the
screen.

If the information from the Gracenote Media

•
Database is either not correct or does not exist,
please contact www.gracenote.com for support.

•

Depending on the cases, it will takes a few
minutes to load music information from the
Gracenote Media Database.

Information may be displayed in English, if your

•
own language is not available on the Gracenote
Media Database.

•

This function is not available for NetCast on-line
content and content in DLNA servers.

•

LG is a licensee of Gracenote technology and is
not responsible or reliable for information from
the Gracenote Media Database.

BD/DVD/Movie fi le

While listening to music from the movie
playback, press MUSIC ID to start loading
music information from the Gracenote Media
Database.

BD572-N-BCANLLK-ENG.indd 50BD572-N-BCANLLK-ENG.indd 50 2010.1.22 8:33:54 PM2010.1.22 8:33:54 PM

Operation

51

Playing content via
your home network

The player can browse and play content on
your PC and DLNA certi ed media servers
connected on your home network.

About DLNA

This Player is a DLNA Certi ed digital media
player that can display and play movie,
photo and music content from your DLNA­compatible digital media server (PC and
Consumer Electronics).

The Digital Living Network Alliance (DLNA)
is a cross-industry organization of consumer
electronics, computing industry and mobile
device companies. Digital Living provides
consumers with easy sharing of digital media
through a wired or wireless network in the
home.

The DLNA certi cation logo makes it easy
to  nd products that comply with the DLNA
Interoperability Guidelines. This unit complies
with DLNA Interoperability Guidelines v1.5.

When a PC running DLNA server software or
other DLNA compatible device is connected to
this player, some setting changes of software
or other devices may be required. Please refer
to the operating instructions for the software
or device for more information.

Accessing a DLNA media
server

1. Check the network connection and settings
(pages 20-25).

2. Press HOME (

3. Select [Home Link] using I/i, and press

ENTER (

4. Select a DLNA media server from the list
using U/u, and press ENTER ( ).

If you want to rescan available media server,
press the green (G) coloured button.

NOTE

Depending on the media server, this player may
need to get permission from the server.

5. Select a  le using U/u/I/i, and press
ENTER ( ) to play the  le.

).

).

4

Operation

BD572-N-BCANLLK-ENG.indd 51BD572-N-BCANLLK-ENG.indd 51 2010.1.22 8:33:54 PM2010.1.22 8:33:54 PM

52

Operation

4

Operation

NOTE

The  le requirements are described on page 10.

•
You can use various playback functions. Refer to

•
pages 34-41.

Because the compatibility and available playback

•
functions on the [Home Link] menu are tested
on the bundle DLNA server (Nero MediaHome
4 Essentials) environment,  le requirements and
playback functions on the [Home Link] menu
may di er depending on media servers.

The  le requirements on page 10 are not always

•
compatible. There may have some restrictions
by  le features and media server’s ability.

The thumbnail of the unplayable  les can be

•
displayed in the [Home Link] menu, but those
cannot be played on this player.

If there is an unplayable music  le in the [Home

•
Link] menu, the player skip the  le and play the
next  le.

Playing a movie subtitle  les are only available

•
on DLNA media server created by supplied Nero
MediaHome 4 Essentials software on this player
package.

The subtitle  le name and movie  le name have

•
to be the same and located at the same folder.

The playback and operating quality of the

•
[Home Link] function may be a ected by your
home network condition.

The  les from removable media such as USB

•
drive, DVD-drive etc. on your media server may
not be shared properly.

About Nero MediaHome 4
Essentials

Nero MediaHome 4 Essentials is a software for
sharing movie, music and photo  les stored
on your computer to this player as a DLNA­compatiable digital media server.

NOTE

The Nero MediaHome 4 Essentials CD-ROM is

•
designed for PCs and should not be inserted in
this player or in any product other than a PC.

The supplied Nero MediaHome 4 Essentials CD-

•
ROM is a customized software edition only for
sharing  les and folders to this player.

The supplied Nero MediaHome 4 Essentials

•
software does not support following functions:
Transcoding, Remote UI, TV control, Internet
services and Apple iTunes

This manual explains operations with the

•
English version of Nero MediaHome 4 Essentials
as examples. Follow the explanation referring to
the actual operations of your language version.

Installing Nero MediaHome 4
Essentials

Before you install Nero MediaHome 4
Essentials, check the system requirement
shown below.

Windows® XP (Service Pack 2 or higher),

•
Windows Vista® (no Service Pack required),
Windows® XP Media Center Edition 2005
(Service Pack 2 or higher), Windows Server®
2003

Windows Vista® 64-bit edition (application

•
runs in 32-bit mode)

Hard drive space: 200 MB hard drive space

•
for a typical installation of Nero MediaHome
stand-alone

1.2 GHz Intel® Pentium® III or AMD

•
Sempron™ 2200+ processors

Memory: 256 MB RAM

•
Graphics card with at least 32 MB video

•
memory, minimum resolution of 800 x 600
pixels, and 16-bit color settings

Windows® Internet Explorer® 6.0 or higher

•
DirectX® 9.0c revision 30 (August 2006) or

•
higher

Network environment: 100 Mb Ethernet,

•
WLAN (IEEE 802.11b/g/n)

BD572-N-BCANLLK-ENG.indd 52BD572-N-BCANLLK-ENG.indd 52 2010.1.22 8:33:55 PM2010.1.22 8:33:55 PM

Operation

53

Start up your computer, and insert the Nero
MediaHome 4 Essentials CD-ROM into your
computer’s CD-ROM drive. An installation
wizard will walk you through the quick and
uncomplicated installation process. To install
Nero MediaHome 4 Essentials, proceed as
follows:

1. Close all Microsoft Windows programs and
exit any anti-virus software that may be
running.

2. Insert the Nero MediaHome 4 Essentials
CD-ROM into your computer’s CD-ROM
drive.

3. Click [Nero MediaHome 4 Essentials]. The
installation is prepared and the installation
wizard appears.

4. Click the [Next] button to display the serial
number input screen. Click [Next] to go to
the next step.

5. If you accept all conditions, click [I accept
the License Conditions] check box and click
[Next]. Installation is not possible without
this agreement.

6. Click [Typical] and click [Next]. The
installation process is started.

7. If you want to take part in the anonymous
collection of data, select the check box and
click the [Next] button.

8. Click the [Exit] button to complete the
installation.

Sharing fi les and folders

On your computer, you must share the folder
contained movie, music and/or photo content
to play them using [Home Link] features.

This parts explains the procedure for selecting
the shared folders on your computer.

1. Double-click the “Nero MediaHome 4
Essentials” icon on the desktop.

2. Click [Network] icon on the left and de ne
your network name in the [Network name]
 eld. The Network name you enter will be
recognized by your player.

3. Click [Shares] icon on the left.

4. Click [Local Folders] tab on the [Shares]

screen.

5. Click [Add] icon to open the [Browse Folder]
window.

6. Select the folder containing the  les you
want to share. The selected folder is added
to the list of shared folders.

7. Click [Start Server] icon to start the server.

NOTE

If the shared folders or  les are not displayed on

•
the player, click the folder on the [Local Folders]
tab and click [Rescan Folder] at the [More]
button.

Visit www.nero.com for more information and

•
software tools

4

Operation

BD572-N-BCANLLK-ENG.indd 53BD572-N-BCANLLK-ENG.indd 53 2010.1.22 8:33:55 PM2010.1.22 8:33:55 PM

54

Operation

4

Operation

Accessing a share folder from
your PC

1. Start your PC that connected on your local
area network.

2. On your PC, share folders which contain
movie, photo or music  les.

3. On the player, check the network
connection and settings (pages 20-25).

4. Press HOME (

5. Select [Home Link] using I/i, and press

ENTER (

6. Select a share folder from the list using U/u,
and press ENTER (

If you want to rescan available share folders,
press the green (G) coloured button.

NOTE

Depending on the share folder, this player may
need to input network user ID and password for
accessing the folder.

).

).

).

NOTE

The  le requirements are described on page 10.

•
You can use various playback functions. Refer to

•
pages 34-41.

The thumbnail of the unplayable  les can be

•
displayed in the [Home Link] menu, but those
cannot be played on this player.

If there is an unplayable music  le in the [Home

•
Link] menu, the player skips the  le and play
next  le.

The subtitle  le name and movie  le name have

•
to be the same and located at the same folder.

The playback and operating quality of the

•
[Home Link] function may be a ected by your
home network condition.

The  les on an removable media such as USB

•
drive, DVD-drive etc. on your PC may not be
shared properly.

You may experience connection problems

•
depending on your PC’s environment.

PC requirements

Windows® XP (Service Pack 2 or higher),

•
Windows Vista® (no Service Pack required)
Windows 7® (no Service Pack required)

1.2 GHz Intel® Pentium® III or AMD

•
Sempron™ 2200+ processors

Network environment: 100 Mb Ethernet,

•
WLAN (IEEE 802.11b/g/n)

NOTE

7. Select a  le using U/u/I/i, and press
ENTER ( ) to play the  le.

BD572-N-BCANLLK-ENG.indd 54BD572-N-BCANLLK-ENG.indd 54 2010.1.22 8:33:55 PM2010.1.22 8:33:55 PM

If you use Windows® XP or Windows Vista®, visit link
below for more information on  le share settings.

Operation

55

Entering a network user ID and the
password

Depending on your PC’s environment, you
may need to enter a network user ID and the
password for accessing a shared folder.

1. The virtual keyboard appears automatically
if the network user ID and the password are
required.

2. Use U/u/I/
press ENTER (
on the virtual keyboard.

To enter a letter with an accent mark, select
the letter from extended character set.

Example: Select “D” and then press INFO/
DISPLAY ( ) to display the extended
character set. Use
and then press ENTER ( ).

[Clear] – Clear all entered characters.
[Space] – Inserts a space at the cursor

position.
[<–] – Deletes the previous character at the

cursor position.
[ABC / abc / #+-=&] – Change the keyboard

menu settings to capital letters, small letters
or symbols.

i

to select a character then

) to con rm your selection

I/i

to select “D” or “Ď”

3. When you  nish entering the network user
ID and password, select [OK] using U/u/I/

i

and press ENTER (

) to access the folder.

The network user ID and password will
be remembered after accssing the folder
for your convenience. If you do not want
the network user ID and password to be
remembered, press red (R) coloured button
to un-tick the [Remember] check box
before accessing the folder.

4

Operation

BD572-N-BCANLLK-ENG.indd 55BD572-N-BCANLLK-ENG.indd 55 2010.1.22 8:33:56 PM2010.1.22 8:33:56 PM

56

Operation

4

Operation

Using the NetCast™
Entertainment Access

You can use various content services via
Internet with the NetCast Entertainment
Access feature.

1. Check the network connection and settings
(pages 20-25).

2. Press HOME (

3. Select the [NetCast] using I/i, and press

ENTER (

4. Select an option using I/i, and press
ENTER (

YouTube™ – See page 56-59
Picasa™ Web Albums – See page 60-62
AccuWeather – See page 63-64

5. While enjoying on-line content from
NetCast, press blue (B) colored button to go
to the NetCast Home screen.

).

).

).

Playing YouTube™ videos

You can browse, search and watch YouTube™
videos over the internet on your TV via your LG
BD player.

Watch YouTube™ videos on your TV

1. On the player, select the [YouTube™] option
in the [NetCast] menu using I/i, and press
ENTER ( ).

2. Press U to select the option menu bar.

3. Use I/

4. Use I/

Button Operation

B

i

to select an option and press

ENTER (

(

or ENTER

) to search videos.

i

to select a video and press ENTER

) or B (play) to play the video.

Starts playback of the video
with content detail.

INFO/

NOTE

Using NetCast features with wireless network

•
connection may result in improper streaming
speed due to interference from household
devices that are using radio frequencies.

The background image on the NetCast home

•
indicates the weather of your favorite city in the
AccuWeather feature.

BD572-N-BCANLLK-ENG.indd 56BD572-N-BCANLLK-ENG.indd 56 2010.1.22 8:33:56 PM2010.1.22 8:33:56 PM

DISPLAY

X

x

./>

Toggle between playback in
full screen and playback screen
with content detail.

To pause a video while it is
playing. To resume playing a
paused video, press B again.

Stops the video and displays
related videos list.

Skip the playback forward or
backward .

About the YouTube™ menu

There are various options on the
YouTube™ menu. Use
option and press ENTER (
options as described below.

Featured – The featured videos list will be
displayed.

Recent Videos – The most recently updated
videos list will be displayed.

Most Viewed – The most viewed videos list
will be displayed. The period option appears
at the bottom of the screen.

Top Rated – The best rated videos list from
YouTube™ server will be displayed. The period
option appears at the bottom of the screen.

Search – The virtual keyboard will be
displayed. See “Searching videos” on page 59
for more detail.

History – The videos list that you previously
played on this unit will be displayed.
Maximum of 25 videos can be stored.

Favorites – This option will only appear
when the unit is in sign-in status. Displays the
videos list that is arranged in the YouTube™
server with your account. Some videos may
not appear on the [Favorites] list, even if the
videos are arranged in the server.

Sign in (Sign Out) – Displays the virtual
keyboard to sign in or returns to the sign­out status. See “Sign in with your YouTube™
account” on page 59 for more details.

Local site – Choose which country’s videos
you would like to view. The countries listed on
the [Local Site] menu may be di erent from
those listed on the YouTube™ web site.

U/u/I/i

) to select the

to select an

Operation

NOTE

The YouTube™ menu can display 5 videos in the

•
videos list. Press green (G) or yellow (Y) buttons
to display previous/next 5 videos.

If you select the [Most Viewed] or [Top Rated]

•
option in the YouTube™ menu, the period
options appear at the bottom of the screen. Use

U/u/I/i

ENTER (
selected period.

The videos list searched from the player may

•
di er with the list searched from a web browser
on PC.

The playback of YouTube™ videos may be

•
paused, stopped or bu ering occurring often
depending on your broadband speed. We
recommend a minimum connection speed
of 1.5 Mbps. For the best playback condition,
a connection speed of 4.0 Mbps is required.
Sometimes your broadband speed varies based
on your ISP’s network conditions. Contact your
ISP if you have problems maintaining a fast
connection that is reliable, or if you want to
increase your connection speed. Many ISPs o er
a variety of broadband speed options.

to select a period option and press

) to display the videos list within the

57

4

Operation

BD572-N-BCANLLK-ENG.indd 57BD572-N-BCANLLK-ENG.indd 57 2010.1.22 8:33:56 PM2010.1.22 8:33:56 PM

58

Operation

4

Operation

Using the virtual keyboard

On the virtual keyboard, there are two input
modes for the entering a character. Press
the yellow (Y) coloured button to toggle the
display between keyboard mode and keypad
mode.

Keyboard Mode

UseU/u/I/i to select a letter on the screen,
and press ENTER to con rm your selection.

[Cancel] – Returns to the previous screen.
[Space] – Inserts a space at the cursor

position.
[Backspace] – Deletes the previous character

at the cursor position.
[ABC / abc / #+-=&] – Changes the virtual

keyboard settings to capital letters, small
letters or symbols.

Press CLEAR to clear all entered characters.

Keypad Mode

This mode allows you to enter letters by
pressing the buttons on the remote control.
Press the buttons with the required letter once,
twice, three or four times until the letter is
displayed.

Button Operation

CLEAR Deletes the previous character

at the cursor position.

REPEAT Inserts a space at the cursor

position.

m/M

Changes the character set of
the remote control (#+-=&,
123, ABC or abc)

NOTE

The keypad mode is available only in the
[YouTube™] and [Picasa™ Web Albums] features.

To enter a letter with an accent mark:

1. Select a letter using U/u/I/i on the virtual
key board.

2. Press INFO/DISPLAY (

) to display the

extended character set.

3. Use I/i to select a character then press
ENTER.

Available languages to enter on the keyboard
mode are as follows: English, Spanish, Italian,
French, German, Dutch, Portuguese, Swedish,
Polish and Czech.

BD572-N-BCANLLK-ENG.indd 58BD572-N-BCANLLK-ENG.indd 58 2010.1.22 8:33:57 PM2010.1.22 8:33:57 PM

Operation

59

Searching videos

You can search for videos by entering search
words of up to 128 characters.

I/i

1. Use
menu and press ENTER (
virtual keyboard.

Refer to “Using the virtual keyboard” on
page 58 for using virtual keyboard.

When you are entering a character,
maximum of 5 suggestion words will be
displayed.

2. When you  nish entering the search words,
select [OK] and press ENTER (
the related video list.

to select [Search] option from the

) to display the

) to display

Sign in with your YouTube™ account

To watch videos from your [Favorites] video list
on the YouTube™ server with your account, you
need to sign in with your YouTube™ account.

I/i

1. Use
menu and press ENTER ( ) to display the
virtual keyboard.

to select [Sign In] option from the

2. Use U/u/I/
press ENTER ( ) to con rm your selection
on the virtual keyboard.

Refer to “Using the virtual keyboard” on
page 58 for using virtual keyboard.

3. When you  nish entering the username
and the password, select [OK] and press
ENTER (

4. If you want to sign out, select the [Sign Out]
from the YouTube™ menu and press
ENTER ( ).

This unit can automatically store up to 5
username which were previously signed-in.
The username list appears when you select the
[Sign In] option.

Select a stored username on the list and press
ENTER (
the selected username entered. You will then
only need to enter the password to sign in.

Select the [X] symbol and press ENTER ( ) to
delete the stored username.

i

to select a character then

) to sign in.

) to display the keyboard menu with

4

Operation

BD572-N-BCANLLK-ENG.indd 59BD572-N-BCANLLK-ENG.indd 59 2010.1.22 8:33:57 PM2010.1.22 8:33:57 PM

60 Operation

4

Operation

Viewing Picasa™ Web Albums

Enjoy photo albums from friends and family on
the Picasa™ on-line service.

View Picasa™ Web Albums on your
TV

1. On the player, select the [Picasa™ Web
Albums] option in the [NetCast] menu
using I/i, and press ENTER ( ).

Featured photos are displayed on the
screen.

2. Use U/u/I/
ENTER (

Button Operation

B

INFO/
DISPLAY

X

x

I/i

i

to select a photo and press

) to view the photo in full screen.

Starts a slide show.

Displays the photo option
menu.

Pauses a slide show. To resume
slide show, press B again.

Stops the slide show and
return to the Picasa™ menu.

Moves to the next or previous
photo.

Options while viewing a photo

You can use various options during viewing a
photo in full screen.

1. While viewing a photo in full screen, press
INFO/DISPLAY (
menu.

2. Select an option using U/u.

Current photo/Total number of photos

a

– Use I/i to view previous/next photo.
Slide Show – Press ENTER (

b

pause slide show.
Add to NetCast Friends List – Add the

c

current photo owner to my friend list.
Rotate – Press ENTER (

d

photo clockwise.
Zoom – Press ENTER (

e

[Zoom] menu.
E ect – Use I/i to select a transition

f

e ect between photos in a slide show.
Speed – Use I/i to select a delay time

g

between photos in a slide show.

) to display the option

a
b

c
d
e
f
g

) to start or

) to rotate the

) to display the

3. Press RETURN (O) to exit the option menu.

BD572-N-BCANLLK-ENG.indd 60BD572-N-BCANLLK-ENG.indd 60 2010.1.22 8:33:58 PM2010.1.22 8:33:58 PM

61Operation

About the Picasa™ menu

There are various options on the Picasa™
menu. Use
and press ENTER (
described below.

Home – The featured photo list will be
displayed.

NetCast Friends – List of your friends will be
displayed.

Search – Enter a search word to  nd related
photos. The virtual keyboard will be displayed
(page 62).

My Photos – Displays the photos organized
in my Picasa™ Web Albums. This option is
available only when the unit is in sign-in
status.

Favorites – Displays up to 50 favorite web
albums that are arranged in the Picasa™
web server with your account. This option
is available only when the unit is in sign-in
status.

Sign in (Sign Out) – Displays the virtual
keyboard to sign in or returns to the sign-out
status (page 63)

U/u/I/i

to select an menu option

) to select the options as

Adding friends

If you add your friends on the [NetCast Friends]
menu, you can see the photos of your friend’s
public photos directly.

1. Select the [NetCast Friends] on the
Picasa™ menu using U/u/I/i, and press
ENTER (

).

2. Press ENTER ( ) to display the virtual
keyboard.

3. Enter a name using the virtual keyboard.
Refer to “Using the virtual keyboard” on

page 58 for using virtual keyboard.

4. Select [OK] using U/u/I/i, and press
ENTER (

) to display the web album of

your friend.

NOTE

If you want to delete your friend from the list,

•
press green (G) coloured button while the web
album is selected.

If you want to add more friends, press red (R)

•
coloured button on the list.

You can add more web albums of your friends

•
up to 50.

4

Operation

NOTE

Photos displayed in [My Photos] and [Favorites]
may di er from the photos from a web browser on
PC.

BD572-N-BCANLLK-ENG.indd 61BD572-N-BCANLLK-ENG.indd 61 2010.1.22 8:33:58 PM2010.1.22 8:33:58 PM

62 Operation

4

Operation

Searching photos

You can enter a search word to  nd related
photos.

1. Select the [Search] on the Picasa™ menu
using U/u/I/i, and press ENTER (

).

2. Enter a search word using the virtual
keyboard.

Refer to “Using the virtual keyboard” on
page 58 for using virtual keyboard.

3. Select [OK] using U/u/I/i, and press
ENTER (

) to display the search result.

NOTE

The search result from the player may di er from
the result when searched from a web browser on
PC.

Signing in with your account

To display photos in your web album on the
screen, you need to sign in with your Picasa™
account.

1. Select the [Sign In] on the Picasa™ menu
using U/u/I/i, and press ENTER (

).

3. Enter the password using the virtual
keyboard, and press ENTER (

) while [OK] is

selected.
Your web album is displayed on the screen.

4. If you want to sign out, select the [Sign Out]
from the Picasa™ menu and press ENTER ( ).

This unit can automatically store up to 5 user
names which were previously signed-in. The
user name list appears when you select the
[Sign In] option.

Select a stored user name on the list and press
ENTER (

) to display the virtual keyboard with
the selected user name is entered. You will
then only need to enter the password to sign
in.

Select the [X] symbol and press ENTER ( ) to
delete the stored user name.

2. Enter your user name using the virtual
keyboard, and press ENTER ( ) while [OK] is
selected.

Refer to “Using the virtual keyboard” on
page 58 for using the virtual keyboard.

BD572-N-BCANLLK-ENG.indd 62BD572-N-BCANLLK-ENG.indd 62 2010.1.22 8:33:59 PM2010.1.22 8:33:59 PM

63Operation

Using the AccuWeather

See on-line local and global weather forecasts
from AccuWeather.com.

Viewing weather information

1. On the player, select the [AccuWeather]
option in the [NetCast] menu using I/i,
and press ENTER ( ).

The city selection menu appears on the
screen.

2. Press ENTER while [Add City to Favorite City
List] is selected.

3. Select a region using U/u, and press ENTER
( ).

6. Use U/u/I/i to select [Home] and press
ENTER (

) to display weather information

of the selected city.

Press red (R) coloured button to toggle
display between Fahrenheit or Celsius
thermometer.

7. Use I/i to select previous or next city, and
press ENTER (

) to display the weather

information.
This step works only when you add more

than 1 city to the [Favorite city List].

NOTE

The weather information is not always correct.

•
The weather information may be displayed in

•
English, if your own language is not available on
the AccuWeather service.

4

Operation

4. Select a, country using U/u/I/i, and press
ENTER (

).

5. Select a city using U/u/I/i, and press
ENTER (

BD572-N-BCANLLK-ENG.indd 63BD572-N-BCANLLK-ENG.indd 63 2010.1.22 8:33:59 PM2010.1.22 8:33:59 PM

).

64 Operation

4

Operation

Adding more cities

1. Use I/i to select [Favorite City List] on the
AccuWeather menu, and press ENTER ( ).

2. Press ENTER ( ) while [Add City to Favorite
City List] is selected.

3. Select a region, country and city using

U/u/I/i

and ENTER (

4. Repeats step 2-3 to add up to 5 cities.
Select the [X] symbol and press ENTER (

to delete the stored favorite city.

5. Use U/u to select a city form the [Favorite
City List], and press ENTER (
the weather information.

).

) to display

)

BD572-N-BCANLLK-ENG.indd 64BD572-N-BCANLLK-ENG.indd 64 2010.1.22 8:34:0 PM2010.1.22 8:34:0 PM

5
Maintenance

65Maintenance

Notes on Discs

Handling Discs

Do not touch the playback side of the disc.
Hold the disc by the edges so that  ngerprints
do not get on the surface. Never stick paper or
tape on the disc.

Storing Discs

After playing, store the disc in its case. Do not
expose the disc to direct sunlight or sources of
heat and never leave it in a parked car exposed
to direct sunlight.

Cleaning Discs

Fingerprints and dust on the disc can cause
poor picture quality and sound distortion.
Before playing, clean the disc with a clean
cloth. Wipe the disc from the center to out.

Do not use strong solvents such as alcohol,
benzine, thinner, commercially available
cleaners, or anti-static spray intended for older
vinyl records.

Handling the Unit

When shipping the unit

Please save the original shipping carton and
packing materials. If you need to ship the unit,
for maximum protection, re-pack the unit as it
was originally packed at the factory.

Keeping the exterior surfaces clean

Do not use volatile liquids such as

•
insecticide spray near the unit.

Wiping with strong pressure may damage

•
the surface.

Do not leave rubber or plastic products in

•
contact with the unit for a long period of
time.

Cleaning the unit

To clean the player, use a soft, dry cloth. If
the surfaces are extremely dirty, use a soft
cloth lightly moistened with a mild detergent
solution. Do not use strong solvents such as
alcohol, benzine, or thinner, as these might
damage the surface of the unit.

Maintaining the Unit

The unit is a high-tech, precision device. If
the optical pick-up lens and disc drive parts
are dirty or worn, the picture quality could be
diminished. For details, please contact your
nearest authorized service center.

5

Maintenance

BD572-N-BCANLLK-ENG.indd 65BD572-N-BCANLLK-ENG.indd 65 2010.1.22 8:34:0 PM2010.1.22 8:34:0 PM

66 Troubleshooting

6
Troubleshooting

General

Symptom Cause & Solution

The Power does not turn
on.

The unit does not start
playback.

The angle cannot be
changed.

Cannot play music/photo/
movie  les.

The remote control does
not work properly.

6

Troubleshooting

The unit is plugged in, but
the power will not turn on
or o .

The unit is not operating
normally.

Plug the power cord into the wall outlet securely.•

Insert a playable disc. (Check the disc type, color system, and

•
regional code.)

Place the disc with the playback side down.

•
Place the disc on the disc tray correctly inside the guide.

•
Clean the disc.

•
Cancel the Rating function or change the rating level.

•

Multi-angles are not recorded on the DVD Video being

•
played.

The  les are not recorded in a format that the unit can play.

•
The unit does not support the codec of the movie  le.

•

The remote control is not pointed at the remote sensor of

•
the unit.

The remote control is too far from the unit.

•
There is an obstacle in the path of the remote control and

•
the unit.

The batteries in the remote control are exhausted.

•

You can reset the unit as follows.

1. Press and hold the POWER button for at least  ve seconds.
This will force the unit to power o then turn the unit back
on.

2. Unplug the power cord, wait at least  ve seconds, and then
plug it in again.

BD572-N-BCANLLK-ENG.indd 66BD572-N-BCANLLK-ENG.indd 66 2010.1.22 8:34:1 PM2010.1.22 8:34:1 PM


Symptom Cause & Solution

There is no picture. Select the appropriate video input mode on the TV so the

Picture noise appears You are playing a disc recorded in a color system that is

•
picture from the unit appears on the TV screen.

Connect the video connection securely.

•
Check the [HDMI Color Setting] in the [Setup] menu is

•
set to the appropriate item that conforms to your video
connection.

Your TV may not support the resolution you have set on the

•
player. Change the resolution that your TV accepts.

The player’s HDMI OUT jack is connected to a DVI device that

•
does not support copyright protection.

•
di erent from your TV.

Set the resolution which your TV accepts.

•

67Troubleshooting

Sound

Symptom Cause & Solution

There is no sound or the
sound is distorted.

Connect the audio connection securely.

•
The input source setting on the ampli er or the connection

•
to the ampli er is incorrect.

The unit is in scan, slow motion, or pause mode.

•
The sound volume is low.

•
Check that the connected ampli er is compatible with the

•
audio format output from the player.

The player’s HDMI OUT jack is connected to a DVI device. The

•
DVI jack does not accept audio signal.

Check the device connected to player’s HDMI OUT jack is

•
compatible with audio format output from the player.

6

Troubleshooting

BD572-N-BCANLLK-ENG.indd 67BD572-N-BCANLLK-ENG.indd 67 2010.1.22 8:34:1 PM2010.1.22 8:34:1 PM

68 Troubleshooting

Network

Symptom Cause & Solution

BD-LIVE feature does not
work.

Streaming video services
(such as YouTube™, etc.) are
often stopped or “bu ered”
during playback.

Shared folder or  les from
your PC or a media server
are not displayed on the
[Home Link] menu.

Cannot connect the player
to the access point or
wireless LAN router.

Access point is not

6

Troubleshooting

displayed on the “Access
point name” list.

The connected USB storage may not have enough space.

•
Connect the USB storage with at least 1GB free space.

Ensure that the unit is correctly connected to the local area

•
network and can access the internet (see pages 20-25).

Your broadband speed may not be fast enough to use the

•
BD-LIVE features. Contact your Internet Service Provider (ISP)
and increase the broadband speed is recommended.

The [BD-LIVE connection] option in the [Setup] menu is set

•
to [Prohibited]. Set the option to [Permitted].

Your broadband service speed may not be fast enough to

•
stream video services. Contact your Internet Service Provider
(ISP) and increase the broadband speed is recommended.

The  rewall or anti-virus software on your media server is

•
running. Turn o the  rewall or anti-virus software running
on your PC or media server.

The player is not connected to the local area network that

•
your PC or the media server are connected.

The wireless communication may be interrupted from

•
household devices that are using radio frequencies. Move
the player away from them.

The access point or wireless LAN router may not broadcast

•
its SSID. Set your access point to broadcast its SSID through
your computer.

Customer Support

You can update the Player using the latest software to enhance the products operation and/or
add new features. To obtain the latest software for this player (if updates have been made),
please visit http://lgservice.com or contact LG Electronics customer care center.

BD572-N-BCANLLK-ENG.indd 68BD572-N-BCANLLK-ENG.indd 68 2010.1.22 8:34:3 PM2010.1.22 8:34:3 PM

7
Appendix

69Appendix

Controlling a TV with
the Supplied Remote
Control

You can control your TV using the buttons
below.

Button Operation

1 (TV POWER)

AV/INPUT

PR/CH U/u

VOL +/–

Turn the TV on or o .

Switch the TV’s input
source between the TV
and other input sources.

Scan up or down
through memorized
channels.

Adjust the volume of
the TV

Setting up the remote to
control your TV

You can operate your TV with the supplied
remote control.
If your TV is listed in the table below, set the
appropriate manufacturer code.

1. While holding down 1 (TV POWER) button,
and press the manufacturer code for your
TV with the numerical buttons (see the
table below).

Manufacturer Code Number

LG 1(Default), 2

Zenith 1, 3, 4

GoldStar 1, 2

Samsung 6, 7

Sony 8, 9

Hitachi 4

2. Release the 1 (TV POWER) button to
complete setting.

Depending on your TV, some or all buttons
may not function on the TV, even after
entering the correct manufacturer code. When
you replace the batteries of the remote, the
code number you have set may be reset to
the default setting. Set the appropriate code
number again.

7

Appendix

NOTE

Depending on the unit being connected, you may
not be able to control your TV using some of the
buttons.

BD572-N-BCANLLK-ENG.indd 69BD572-N-BCANLLK-ENG.indd 69 2010.1.22 8:34:4 PM2010.1.22 8:34:4 PM

70

Appendix

Network Software
Update

Network update notifi cation

From time to time, performance improvements
and/or additional features or services may be
made available to units that are connected to
a broadband home network. If there is new
software available and the unit is connected
to a broadband home network, the player will
inform you about the update as follows.

Option 1:

1. The update menu will appear on the screen
when you turn on the player.

I/i

2. Use

to select a desired option and then

press ENTER ( ).

Option 2:

If the software update is available from the
update server, the “Update” icon appears at
the bottom of the Home menu. Press blue (B)
coloured button to start the update procedure.

Software Update

You can update the player using the latest
software to enhance the products operation
and/or add new features. You can update the
software by connecting the unit directly to the
software update server.

CAUTION

•

Before updating the software in your player,
remove any disc and USB Device from the player.

•

Before updating the software in your player, turn
the player o and then turn it back on.

•

During the software update procedure, do
not turn o the player or disconnect AC
power, or do not press any button.

•

If you cancel the update, turn o the power and
turn it on for stable performance.

•

This unit cannot be updated to previous
software version.

1. Check the network connection and settings

[OK]

Starts the software update.

[Cancel]

7

Appendix

BD572-N-BCANLLK-ENG.indd 70BD572-N-BCANLLK-ENG.indd 70 2010.1.22 8:34:5 PM2010.1.22 8:34:5 PM

Exits the update menu and displays it next
booting.

[Hide]

Exits the update menu and it does not
appear until next software is uploaded in
the update server.

(page 20-25).

2. Select [Software] option in the [Setup]
menu then press ENTER ( ).

Appendix

71

3. Select [Update] option, and press ENTER
(

).

The player will check for the newest update.

NOTE

Pressing ENTER while checking for the update

•
will end the process.

If there is no update available, the Message, “No

•
update is found.” appears. Press ENTER to return
to the [Home Menu].

4. If newer version exists, the message “A
new update was found. Do you want to
download it?” appears.

8. Select [OK] to start updating.
(Selecting [Cancel] will end the update and
downloaded  le will not be re-usable. To
update software the next time, the software
update procedure has to be started from
the beginning again.)

CAUTION

Do not turn o the power during the software
update.

NOTE

If the software includes the driver update, disc tray
may open during the process.

9. When update is completed, the message, “
Update is complete.” will appear, and then
power will turn o automatically after 5
seconds.

10.

Turn the power back on. The system now

operates with the new version.

NOTE

The Software Update function may not work
properly depending on your internet environment.
In this case, you can obtain the latest software from
the authorized LG Electronics Service Center then

5. Select [OK] to download the update.
(Selecting [Cancel] will end the update.)

6. The player starts downloading the newest
update from the server. (Downloading will
takes several minutes depending on your
home network condition)

7. When downloading is completed, the
message, “Download is complete. Do you
want to update?” appears.

BD572-N-BCANLLK-ENG.indd 71BD572-N-BCANLLK-ENG.indd 71 2010.1.22 8:34:5 PM2010.1.22 8:34:5 PM

update your player. Refer to “Customer Support” on
page 68.

7

Appendix

72

7

Appendix

Appendix

Area Code List

Choose an area code from this list.

Area Code Area Code Area Code Area Code

Afghanistan AF
Argentina AR
Australia AU
Austria AT
Belgium BE
Bhutan BT
Bolivia BO
Brazil BR
Cambodia KH
Canada CA
Chile CL
China CN
Colombia CO
Congo CG
Costa Rica CR
Croatia HR
Czech Republic CZ
Denmark DK
Ecuador EC
Egypt EG
El Salvador SV
Ethiopia ET

Fiji FJ
Finland FI
France FR
Germany DE
Great Britain GB
Greece GR
Greenland GL
Hong Kong HK
Hungary HU
India IN
Indonesia ID
Israel IL
Italy IT
Jamaica JM
Japan JP
Kenya KE
Kuwait KW
Libya LY
Luxembourg LU
Malaysia MY
Maldives MV
Mexico MX

Monaco MC
Mongolia MN
Morocco MA
Nepal NP
Netherlands NL
Netherlands

Antilles AN
New Zealand NZ
Nigeria NG
Norway NO
Oman OM
Pakistan PK
Panama PA
Paraguay PY
Philippines PH
Poland PL
Portugal PT
Romania RO
Russian

Federation RU
Saudi Arabia SA
Senegal SN

Singapore SG
Slovak Republic SK
Slovenia SI
South Africa ZA
South Korea KR
Spain ES
Sri Lanka LK
Sweden SE
Switzerland CH
Taiwan TW
Thailand TH
Turkey TR
Uganda UG
Ukraine UA
United States US
Uruguay UY
Uzbekistan UZ
Vietnam VN
Zimbabwe ZW

BD572-N-BCANLLK-ENG.indd 72BD572-N-BCANLLK-ENG.indd 72 2010.1.22 8:34:5 PM2010.1.22 8:34:5 PM

Appendix

Language code List

Use this list to input your desired language for the following initial settings: [Disc Audio],
[Disc Subtitle] and [Disc Menu].

Language Code Language Code Language Code Language Code

Afar 6565
Afrikaans 6570
Albanian 8381
Ameharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Aymara 6588
Azerbaijani 6590
Bashkir 6665
Basque 6985
Bengali; Bangla 6678
Bhutani 6890
Bihari 6672
Breton 6682
Bulgarian 6671
Burmese 7789
Byelorussian 6669
Chinese 9072
Croatian 7282
Czech 6783
Danish 6865
Dutch 7876
English 6978
Esperanto 6979
Estonian 6984
Faroese 7079
Fiji 7074
Finnish 7073

French 7082
Frisian 7089
Galician 7176
Georgian 7565
German 6869
Greek 6976
Greenlandic 7576
Guarani 7178
Gujarati 7185
Hausa 7265
Hebrew 7387
Hindi 7273
Hungarian 7285
Icelandic 7383
Indonesian 7378
Interlingua 7365
Irish 7165
Italian 7384
Japanese 7465
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kirghiz 7589
Korean 7579
Kurdish 7585
Laothian 7679
Latin 7665
Latvian, Lettish 7686
Lingala 7678

Lithuanian 7684
Macedonian 7775
Malagasy 7771
Malay 7783
Malayalam 7776
Maori 7773
Marathi 7782
Moldavian 7779
Mongolian 7778
Nauru 7865
Nepali 7869
Norwegian 7879
Oriya 7982
Panjabi 8065
Pashto, Pushto 8083
Persian 7065
Polish 8076
Portuguese 8084
Quechua 8185
Rhaeto-Romance

8277

Rumanian 8279
Russian 8285
Samoan 8377
Sanskrit 8365
Scots Gaelic 7168
Serbian 8382
Serbo-Croatian 8372
Shona 8378

Sindhi 8368
Singhalese 8373
Slovak 8375
Slovenian 8376
Spanish 6983
Sudanese 8385
Swahili 8387
Swedish 8386
Tagalog 8476
Tajik 8471
Tamil 8465
Telugu 8469
Thai 8472
Tonga 8479
Turkish 8482
Turkmen 8475
Twi 8487
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapük 8679
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 7473
Yoruba 8979
Zulu 9085

73

7

Appendix

BD572-N-BCANLLK-ENG.indd 73BD572-N-BCANLLK-ENG.indd 73 2010.1.22 8:34:6 PM2010.1.22 8:34:6 PM

74

Appendix

Trademarks and
Licenses

“Blu-ray Disc” is a trademark.

“BD-LIVE” logo is a trademark of Blu-ray Disc
Association.

“BONUSVIEW” is trademark of Blu-ray Disc
Association.

DLNA®, the DLNA Logo and DLNA CERTIFIED® are
trademarks, service marks, or certi cation marks of
the Digital Living Network Alliance.

“AVCHD” and the “AVCHD” logo are trademarks of
Panasonic Corporation and Sony Corporation.

This product is licensed under the AVC patent
portfolio license and VC-1 patent portfolio license
for the personal and non-commercial use of a
consumer to (i) encode video in compliance with
the AVC Standard and VC-1 Standard (“AVC/VC-1
Video”) and/or (ii) decode AVC/VC-1 Video that was
encoded by a consumer engaged in a personal and
non-commercial activity and/or was obtained from
a video provider licensed to provide AVC/VC-1 Video.
No license is granted or shall be implied for any other
use. Additional information may be obtained from
MPEG LA, LLC. See http://www.mpegla.com.

7

Appendix

Java and all Java-based trademarks and logos
are trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and other
countries.

Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories.

HDMI, the HDMI logo and High-De nition
Multimedia Interface are trademarks or registered
trademarks of HDMI licensing LLC.

“DVD Logo” is a trademark of DVD Format/Logo
Licensing Corporation.

YouTube™ is a trademark of Google Inc.

Picasa™ Web Albums is a trademark of Google Inc.

Manufactured under license under U.S. Patent #’s:
5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616;
6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 &
other U.S. and worldwide patents issued & pending. DTS
is a registered trademark and the DTS logos, Symbol,
DTS-HD and DTS-HD Master Audio are trademarks of
DTS, Inc. © 1996-2008 DTS, Inc. All Rights Reserved.

DivX is a registered trademark of DivX, Inc., and is
used under license.

BD572-N-BCANLLK-ENG.indd 74BD572-N-BCANLLK-ENG.indd 74 2010.1.22 8:34:6 PM2010.1.22 8:34:6 PM

The Wi-Fi CERTIFIED Logo is a certi cation mark of
the Wi-Fi Alliance.

“x.v.Color” is a trademark of Sony Corporation.

On the LG products, an innovative power
consumption system in stand-by mode is built.
Therefore, the small amounts of electricity
areconsumed even though the power plug is
inserted.

Gracenote®, Gracenote logo and logotype, and the
“Powered by Gracenote” logo are either registered
trademarks or trademarks of Gracenote, Inc. in the
United States and/or other countries.

Music recognition technology and related data are
provided by Gracenote®.

Portions of the content is copyright © Gracenote or
its providers.

Gracenote® End User License Agreement

This application or device contains software from
Gracenote, Inc. of Emeryville, California
(“Gracenote”). The software from Gracenote (the
“Gracenote Software”) enables this application to
perform disc and/or  le identi cation and obtain
music-related information, including name, artist,
track, and title information (“Gracenote Data”) from
online servers or embedded databases (collectively,
“Gracenote Servers”) and to perform other functions.
You may use Gracenote Data only by means of the
intended End-User functions of this application or
device.

You agree that you will use Gracenote Data, the
Gracenote Software, and Gracenote Servers for
your own personal non-commercial use only. You
agree not to assign, copy, transfer or transmit the
Gracenote Software or any Gracenote Data to any
third party. YOU AGREE NOT TO USE OR EXPLOIT
GRACENOTE DATA, THE GRACENOTE SOFTWARE,
OR GRACENOTE SERVERS, EXCEPT AS EXPRESSLY
PERMITTED HEREIN.

Appendix

You agree that your non-exclusive license to use
the Gracenote Data, the Gracenote Software, and
Gracenote Servers will terminate if you violate
these restrictions. If your license terminates, you
agree to cease any and all use of the Gracenote
Data, the Gracenote Software, and Gracenote
Servers. Gracenote reserves all rights in Gracenote
Data, the Gracenote Software, and the Gracenote
Servers, including all ownership rights. Under no
circumstances will Gracenote become liable for any
payment to you for any information that you provide.
You agree that Gracenote, Inc. may enforce its rights
under this Agreement against you directly in its own
name.

The Gracenote service uses a unique identi er to
track queries for statistical purposes. The purpose of
a randomly assigned numeric identi er is to allow
the Gracenote service to count queries without
knowing anything about who you are. For more
information, see the web page for the Gracenote
Privacy Policy for the Gracenote service.

The Gracenote Software and each item of Gracenote
Data are licensed to you “AS IS.” Gracenote makes
no representations or warranties, express or implied,
regarding the accuracy of any Gracenote Data from
in the Gracenote Servers. Gracenote reserves the
right to delete data from the Gracenote Servers or to
change data categories for any cause that Gracenote
deems su cient. No warranty is made that the
Gracenote Software or Gracenote Servers are error­free or that functioning of Gracenote Software or
Gracenote Servers will be uninterrupted. Gracenote
is not obligated to provide you with new enhanced
or additional data types or categories that Gracenote
may provide in the future and is free to discontinue
its services at any time.

GRACENOTE DISCLAIMS ALL WARRANTIES EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE, TITLE, AND
NON-INFRINGEMENT. GRACENOTE DOES NOT
WARRANT THE RESULTS THAT WILL BE OBTAINED BY
YOUR USE OF THE GRACENOTE SOFTWARE OR ANY
GRACENOTE SERVER. IN NO CASE WILL GRACENOTE
BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL
DAMAGES OR FOR ANY LOST PROFITS OR LOST
REVENUES.

© Gracenote, Inc. 2009

75

7

Appendix

BD572-N-BCANLLK-ENG.indd 75BD572-N-BCANLLK-ENG.indd 75 2010.1.22 8:34:6 PM2010.1.22 8:34:6 PM

76

Appendix

Audio Output
Specifi cations

7

Appendix

Jack/Setting

Source

Dolby Digital PCM 2ch PCM 2ch DTS Dolby Digital

Dolby Digital Plus PCM 2ch PCM 2ch DTS Dolby Digital

Dolby TrueHD PCM 2ch PCM 2ch DTS Dolby Digital

DTS PCM 2ch PCM 2ch DTS DTS

DTS-HD PCM 2ch PCM 2ch DTS DTS

Linear PCM 2ch PCM 2ch PCM 2ch DTS PCM 2ch

Linear PCM 5.1ch PCM 2ch PCM 2ch DTS PCM 2ch

Linear PCM 7.1ch PCM 2ch PCM 2ch DTS PCM 2ch

Jack/Setting

Source

Dolby Digital PCM 2ch PCM 5.1ch DTS Dolby Digital

Dolby Digital Plus PCM 2ch PCM 7.1ch DTS Dolby Digital Plus

Dolby TrueHD PCM 2ch PCM 7.1ch DTS Dolby TrueHD

DTS PCM 2ch PCM 5.1ch DTS DTS

DTS-HD PCM 2ch PCM 7.1ch DTS DTS-HD

Linear PCM 2ch PCM 2ch PCM 2ch DTS Linear PCM 2ch

Linear PCM 5.1ch PCM 2ch PCM 5.1ch DTS Linear PCM 5.1ch

Linear PCM 7.1ch PCM 2ch PCM 7.1ch DTS Linear PCM 7.1ch

Analog

2CH Output

PCM Stereo

*1 The secondary and interactive audio may

not be included in the output bitstream if
[Digital Output] or [HDMI] option is set to
[Primary Pass-Thru]. (Except LPCM Codec :
the output always includes interactive and
secondary audio.)

*2 This player automatically selects the HDMI

audio according to the decoding capability
of the connected HDMI device even though
[HDMI] option is set to [Primary Pass-Thru].

Digital Output (DIGITAL AUDIO OUT)

PCM Stereo

Multi-Ch *3DTS Re-encode

PCM

DTS Re-encode

HDMI OUT

*3 *

*3 *

5

5

*3 The [PCM Multi-CH]/[Primary Pass-Thru]

setting of the [HDMI] option and [DTS re­encode] setting of the [Digital Output]
option cannot be set together. If you set
them together, the [HDMI] or [Digital
Output] option is set to [PCM Stereo]
automatically.

*4 On the PCM audio output, the sampling

frequency of DIGITAL AUDIO OUT is limited
to 96 kHz.

4

*

Primary Pass-Thru

Primary Pass-Thru *

1 *2 *3

BD572-N-BCANLLK-ENG.indd 76BD572-N-BCANLLK-ENG.indd 76 2010.1.22 8:34:7 PM2010.1.22 8:34:7 PM

Appendix

77

*5 If the [HDMI] or [Digital Output] option is

set to [DTS re-encode], the audio output is
limited to 48 kHz and 5.1Ch. If the [HDMI]
or [Digital Output] option is set to [DTS
re-encode], the DTS Re-encode audio is
output for BD-ROM discs, and the original
audio is output for the other discs (like
[Primary Pass-Thru]).

If [HDMI] option is set to [PCM Multi-CH]

•
and [Digital Output] option is set to [Primary
Pass-Thru] while playback Dolby Digital Plus
or TrueHD audio, DIGITAL AUDIO OUT is
limited to “PCM 2ch”.

If the HDMI connection is version 1.3 and

•
Dolby Digital Plus/Dolby TrueHD is output
from HDMI OUT jack, DIGITAL AUDIO OUT
jack is limited to “PCM 2ch” (When the HDMI
and DIGITAL AUDIO OUT are connected
simultaneously).

The audio is outputted as PCM 48 kHz/

•
16 bit for MP3/WMA  le and PCM

44.1 kHz/16 bit for Audio CD while playback.
The Dolby TrueHD audio recorded on some

•
Blu-ray discs consists of Dolby Digital and
TrueHD audio. Dolby Digital audio is output
through DIGITAL AUDIO OUT jacks and “DD
” displays on the screen if TrueHD audio is
not output (for example, when [HDMI] is set
to [PCM Stereo] and [Digital Output] is set
to [Primary Pass-Thru]).

•

You must select a digital audio output and
a maximum sampling frequency that your
Ampli er (or AV receiver) accepts using
[Digital Output], [HDMI] and [Sampling
Freq.] options on the [Setup] menu (see
page 30).

With digital audio connection (DIGITAL

•
AUDIO OUT or HDMI), Disc Menu button
sounds of BD-ROM may not be heard if the
[Digital Output] or [HDMI] option is set to
[Primary Pass-Thru].

If the audio format of the digital output

•
does not match the capabilities of your
receiver, the receiver will produce a strong,
distorted sound or no sound at all.

Multi-channel Digital Surround Sound via

•
digital connection can only be obtained
if your receiver is equipped with a Digital
Multi-channel decoder.

7

Appendix

BD572-N-BCANLLK-ENG.indd 77BD572-N-BCANLLK-ENG.indd 77 2010.1.22 8:34:7 PM2010.1.22 8:34:7 PM

78

7

Appendix

Appendix

Video Output
Resolution

When the non-copy protected media is playing back

Video Out

Resolution

480i 480p 480i

480p 480p 480p

720p 720p 720p

1080i 1080i 1080i

1080p /24 Hz 1080p / 24 Hz 480i 1080i

1080p / 60 Hz 1080p / 60 Hz 480i 1080i

HDMI OUT

HDMI connected HDMI disconnected

When the copy protected media is playing back

Video Out

Resolution

480i 480p 480i

480p 480p 480p

720p 720p 480i 480p

1080i 1080i 480i 480p

1080p /24 Hz 1080p / 24 Hz 480i 480p

1080p / 60 Hz 1080p / 60 Hz 480i 480p

HDMI OUT connection

If you select a resolution manually and then

•

HDMI OUT

HDMI connected HDMI disconnected

•

connect the HDMI jack to TV and your TV
does not accept it, the resolution setting is
set to [Auto].

If you select a resolution that your TV

•
does not accept, the warning message
will appear. After resolution change,
if you cannot see the screen, please
wait 20 seconds and the resolution will
automatically revert back to the previous
resolution.

COMPONENT VIDEO OUT
Connection

BD and DVD video stream could prevent up­scaling on analog output.

COMPONENT VIDEO OUT

COMPONENT VIDEO OUT

The 1080p video output frame rate may
be automatically set to either 24 Hz or
60 Hz depending both on the capability
and preference of the connected TV and
based on the native video frame rate of the
content on the BD-ROM disc.

VIDEO OUT connection

The resolution of the VIDEO OUT jack is always
output at 480i resolution.

BD572-N-BCANLLK-ENG.indd 78BD572-N-BCANLLK-ENG.indd 78 2010.1.22 8:34:7 PM2010.1.22 8:34:7 PM

Appendix

79

Specifi cations

General

Power requirements:

AC 120 V ~, 60 Hz

Power consumption:

Dimensions (W x H x D):

Approx. 430 x 44 x 204 mm without foot

Net Weight (Approx.):

Operating temperature:

5 °C to 35 °C

Operating humidity:

5 % to 90 %

Outputs

VIDEO OUT:

1.0 V (p-p), 75 Ω, sync negative, RCA jack x 1

COMPONENT VIDEO OUT:

(Y) 1.0 V (p-p), 75 Ω, sync negative,

RCA jack x 1,

(Pb)/(Pr) 0.7 V (p-p), 75 Ω, RCA jack x 2

20 W

2 kg

System

Laser:

Semiconductor laser

wavelength:

405 nm / 650 nm

Signal system:

Standard NTSC color TV system

Frequency response:

20 Hz to 20 kHz

(48 kHz, 96 kHz, 192 kHz sampling)

Signal-to-noise ratio:

More than 100 dB

(ANALOG OUT connectors only)

Harmonic distortion:

Less than 0.008 %

Dynamic range:

More than 95 dB

LAN port:

Ethernet jack x 1, 10BASE-T/100BASE-TX

Wireless LAN (internal antenna):

Integrated IEEE 802.11n (2.4 GHz band only)

wireless networking access, compatible with

802.11b/g Wi-Fi networks.

Bus Power Supply (USB):

DC 5 V

500 mA

HDMI OUT (video/audio):

19 pin (HDMI standard, Type A, Version 1.3)

ANALOG AUDIO OUT:

2.0 Vrms (1 kHz, 0 dB), 600 Ω, RCA jack (L, R) x 1

DIGITAL OUT (COAXIAL):

0.5 V (p-p), 75 Ω, RCA jack x 1

DIGITAL OUT (OPTICAL):

3 V (p-p), Optical jack x 1

BD572-N-BCANLLK-ENG.indd 79BD572-N-BCANLLK-ENG.indd 79 2010.1.22 8:34:8 PM2010.1.22 8:34:8 PM

Design and speci cations are subject to

•
change without notice.

7

Appendix

80 Appendix

7

Appendix

Important Information
Relating to Network
Services

PLEASE READ CAREFULLY. USE OF THE NETWORK
SERVICES IS SUBJECT TO THE FOLLOWING TERMS
AND CONDITIONS.

Use of the Network Services requires an Internet
connection which is sold separately and for which
you are solely responsible. The Network Services may
be limited or restricted depending upon the quality,
capabilities and technical limitations of your Internet
service.

The Network Services belong to third parties and
may be protected by copyright, patent, trademark
and/or other intellectual property laws. The Network
Services are provided solely for your personal and
noncommercial use. Unless expressly authorized by
the respective content owner or service provider,
you shall not modify, copy, republish, upload, post,
transmit, translate, sell, create derivative works,
exploit, or distribute in any manner or medium any
content or services accessible through this product.

LG IS NOT RESPONSIBLE FOR YOUR USE OF
THE NETWORK SERVICES. THE NETWORK
SERVICES ARE PROVIDED “AS IS.” TO THE FULLEST
EXTENT PERMISSIBLE BY LAW, LG MAKES NO
REPRESENTATIONS OR WARRANTIES OF ANY KIND
WHATSOEVER (i) FOR THE ACCURACY, VALIDITY,
TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY
NETWORK SERVICE MADE AVAILABLE THROUGH
THIS PRODUCT; OR (ii) THAT THE NETWORK SERVICES
ARE FREE OF VIRUSES OR OTHER COMPONENTS
THAT MAY INFECT, HARM, OR CAUSE DAMAGE TO
THIS PRODUCT, YOUR COMPUTER, TELEVISION,
OTHER EQUIPMENT, OR ANY OTHER PROPERTY. LG
EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES,
INCLUDING BUT NOT LIMITED TO, WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.

UNDER NO CIRCUMSTANCES AND UNDER NO
LEGAL THEORY, WHETHER IN CONTRACT, TORT,
STRICT LIABILITY OR OTHERWISE, SHALL LG BE
LIABLE TO YOU OR ANY THIRD PARTY FOR ANY
DIRECT, INDIRECT, INCIDENTAL, SPECIAL, STATUTORY,
CONSEQUENTIAL OR OTHER DAMAGES OR
ATTORNEY FEES OR EXPENSES RELATING TO OR
ARISING OUT OF THE NETWORK SERVICES EVEN IF
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
IF SUCH DAMAGES COULD HAVE BEEN REASONABLY
FORESEEN.

The Network Services may be terminated or
interrupted at any time, and LG makes no
representation or warranty that any Network Service
will remain available for any period of time. Use of the
Network Services may be subject to additional terms
and conditions of the respective third party service
provider. The Network Services are transmitted by
third parties by means of networks and transmission
facilities over which LG has no control. LG EXPRESSLY
DISCLAIMS ANY RESPONSIBILITY OR LIABILITY
FOR ANY INTERRUPTION OR SUSPENSION OF ANY
NETWORK SERVICE.

LG shall be neither responsible nor liable for
customer service related to the Network Services.
Any question or request should be made directly to
the respective Network Service providers.

“Network Service(s)” means the third party services
accessible through this product including but
not limited to all data, software, links, messages,
video and other content found thereon or used in
connection therewith.

“LG” means LG Electronics, Inc. its parent company
and all of their respective subsidiaries, a liates and
related companies worldwide.

BD572-N-BCANLLK-ENG.indd 80BD572-N-BCANLLK-ENG.indd 80 2010.1.22 8:34:8 PM2010.1.22 8:34:8 PM

Open source software
notice

The following GPL executables and LGPL libraries
used in this product are subject to the GPL2.0/
LGPL2.1 License Agreements:

GPL EXECUTABLES: Linux kernel 2.6, bash, busybox,
cramfs, dhcpcd, e2fsprogs, fdisk, mkdosfs, mtd-utils,
net-tools, procps, samba-3.0.25b, sysutils, tcpdump,
tftpd, tinylogin, unzip, utelnetd

LGPL LIBRARIES: uClibc, DirectFB, blow sh, cairo,
 mpeg, iconv, libusb, mpg123

gSOAP Public License 1.3 LIBRARY: gsoap
LG El ectronics o ers to provide source code to

you on CD-ROM for a charge covering the cost of
performing such distribution, such as the cost of
media, shipping and handling upon e-mail request
to LG Electronics at: [e-mail]
This o er is valid for a period of three(3) years from
the date of the distribution of this product by LG
Electronics.

You can obtain a copy of the GPL, LGPL licenses
from http://www.gnu.org/licenses/old-licenses/gpl-

2.0.html and http://www.gnu.org/licenses/old­licenses/lgpl-2.1.html .

Also you can obtain a copy of gSOAP public license
from http://www.cs.fsu.edu/~engelen/license.html.

This software is based in part on the work of the
Independent JPEG Group copyright © 1991 - 1998,
Thomas G. Lane.

This product includes

boost C++: copyright © Beman Dawes 1999-2003

•
c-ares : copyright © 1998 by the Massachusetts

•
Institute of Technology
curl: copyright © 1996 - 2008, Daniel Stenberg

•
expat: copyright © 2006 expat maintainers

•
freetype: copyright © 2003 The FreeType Project

•
(www.freetype.org).
jpeg: This software is based in part on the work of

•
the Independent JPEG Group copyright © 1991 –
1998, Thomas G. Lane.
mng: copyright © 2000-2007 Gerard Juyn, Glenn

•
Randers-Pehrson
ntp : copyright © David L. Mills 1992-2006

•

•

OpenSSL:
– cryptographic software written by Eric Young

([e-mail]).

– software written by Tim Hudson

([e-mail]).

– software developed by the OpenSSL Project

for use in the OpenSSL Toolkit.
(http://www.openssl.org)

png: copyright © 2004 Glenn Randers-Pehrson

•
portmap : copyright © 1990 The Regents of the

•
University of California
ptmalloc : copyright © 2001-2006 Wolfram Gloger

•
UnitTest++ : copyright © 2006 Noel Llopis and

•
Charles Nicholson
UPnP SDK : copyright © 2000-2003 Intel

•
Corporation
strace :

•
copyright © 1991, 1992 Paul Kranenburg
copyright © 1993 Branko Lankester
copyright © 1993 Ulrich Pegelow
copyright © 1995, 1996 Michael Elizabeth Chastain
copyright © 1993, 1994, 1995, 1996 Rick Sladkey
copyright © 1999,2000 Wichert Akkerman
xml2 : copyright © 1998-2003 Daniel Veillard

•
XML-RPC For C/C++:

•
copyright © 2001 by First Peer, Inc. All rights
reserved.
copyright © 2001 by Eric Kidd. All rights reserved.
zlib: copyright © 1995-2002 Jean-loup Gailly and

•
Mark Adler.

All rights reserved.
Permission is hereby granted, free of charge, to

any person obtaining a copy of this software and
associated documentation  les (the “Software”), to
deal in the Software without restriction, including
without limitation the rights to use, copy, modify,
merge, publish, distribute, sublicense, and/or sell
copies of the Software, and to permit persons to
whom the Software is furnished to do so, subject to
the following conditions:

THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND NONINFRINGEMENT. IN NO EVENT
SHALL THE AUTHORS OR COPYRIGHT HOLDERS
BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
LIABILITY, WHETHER IN AN ACTION OF CONTRACT,
TORT OR OTHERWISE, ARISING FROM, OUT OF OR IN
CONNECTION WITH THE SOFTWARE OR THE USE OR
OTHER DEALINGS IN THE SOFTWARE.

81Appendix

7

Appendix

BD572-N-BCANLLK-ENG.indd 81BD572-N-BCANLLK-ENG.indd 81 2010.1.22 8:34:8 PM2010.1.22 8:34:8 PM

LG Customer Information Center

1-888-542-2623

CANADA

NERGY STAR

determined that this product or
product models meet the E
® guidelines for energy efficiency.

® Partner, LG has

NERGY STAR

As an E

ENERGY STAR® is a U.S. registered mark.

BD572-N-BCANLLK-ENG.indd 82BD572-N-BCANLLK-ENG.indd 82 2010.1.22 8:34:8 PM2010.1.22 8:34:8 PM
