Warning! Safety instructions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER TO QUALIFIED SERVICE PERSONNEL.

This symbol is intended to alert the user to the presence of

uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a risk
of electric shock to persons.

This symbol is intended to alert the user to the presence of

important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.

WARNING : TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK,
DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

• Clean only with dry cloth. Do not place the TV and/or remote
control in the following environments:

- A location exposed to direct sunlight

- An area with high humidity such as a bathroom

- Near any heat source such as stoves and other devices that
produce heat

- Near kitchen counters or humidifiers where they can easily be
exposed to steam or oil

- An area exposed to rain or wind

- Near containers of water such as vases

Otherwise, this may result in fire, electric shock, malfunction or
product deformation.

• Do not place the product where it might be exposed to dust. This
may cause a fire hazard.

• Mains Plug is the TV connecting/disconnecting device to AC
mains electric supply. This plug must remain readily attached and
operable when TV is in use.

• Do not touch the power plug with wet hands. Additionally, if the
cord pin is wet or covered with dust, dry the power plug completely
or wipe dust off. You may be electrocuted due to excess moisture.

• Make sure to connect Mains cable to compliant AC mains socket
with Grounded earth pin. (Except for devices which are not
grounded on earth.) Otherwise possibility you may be electrocuted
or injured.

• Insert power cable plug completely into wall socket otherwise if
not secured completely into socket, fire ignition may break out.

• Ensure the power cord does not come into contact with hot objects
such as a heater. This may cause a fire or an electric shock hazard.

• Do not place a heavy object, or the product itself, on power cables.
Otherwise, this may result in fire or electric shock.

• Bend antenna cable between inside and outside building to
prevent rain from flowing in. This may cause water damaged inside
the Product and could give an electric shock.

• When mounting TV onto wall make sure to neatly install and
isolate cabling from rear of TV as to not create possibility of electric
shock / fire hazard.

• Do not plug too many electrical devices into a single multiple
electrical outlet. Otherwise, this may result in fire due to over­heating.

• Do not drop the product or let it fall over when connecting external
devices. Otherwise, this may result in injury or damage to the
product.

• Keep the anti-moisture packing material or vinyl packing out of the
reach of children. Anti-moisture material is harmful if swallowed.
If swallowed by mistake, force the patient to vomit and visit the
nearest hospital. Additionally, vinyl packing can cause suffocation.
Keep it out of the reach of children.

• Do not let your children climb or cling onto the TV. Otherwise, the
TV may fall over, which may cause serious injury.

• Dispose of used batteries carefully to ensure that a small child
does not consume them. Please seek Doctor- Medical Attention
immediately if child consumes batteries.

• Do not insert any metal objects/conductors (like a metal chopstick/
cutlery/screwdriver) between power cable plug and Wall Socket.
Additionally, do not touch the power cable right after plugging into
the wall. You may be electrocuted.

• Do not put or store inflammable substances near the product.
There is a danger of combustion/explosion or fire due to careless
handling of the inflammable substances.

• Do not drop metallic objects such as coins, hair pins, chopsticks
or wire into the product, or inflammable objects such as paper
and matches. Children must pay particular attention. Electrical
shock, fire or injury can occur. If a foreign object is dropped into the
product, unplug the power cord and contact the service centre.

• Do not spray water on the product or scrub with an inflammable
substance (thinner or benzene). Fire or electric shock accident can
occur.

• Do not allow any impact, shock or any objects to fall into the unit,
and do not drop anything onto the screen. You may be injured or
the product can be damaged.

• Never touch this product or antenna during a thunder or lighting
storm. You may be electrocuted.

• Never touch the wall outlet when there is leakage of gas, open the
windows and ventilate. It may cause a fire or a burn by a spark.

MFL69830001_OLED_W7_S_HK_Eng.indd 2 2017-01-06  4:03:50

3

ENGLISH

• Do not disassemble, repair or modify the product at your own
discretion. Fire or electric shock accident can occur. Contact the
service centre for check, calibration or repair.

• If any of the following occur, unplug the product immediately and
contact your local service centre.

- The product has been damaged

- Foreign objects have entered the product

- The product produced smoke or a strange smell

• This may result in fire or electric shock.

• Unplug the TV from AC mains wall socket if you do not intend to
use the TV for a long period of time. Accumulated dust can cause
fire hazard and insulation deterioration can cause electric leakage/
shock/fire.

• Apparatus shall not be exposed to dripping or splashing and no
objects filled with liquids, such as vases, shall be placed on the
apparatus.

• Do not install this product on a wall if it could be exposed to oil or
oil mist. This may damage the product and cause it to fall.

• If water or another substance enters the product (like a AC adapter,
power cord, TV), disconnect the power cord and contact the service
centre immediately.
Otherwise, this may result in fire or electric shock.

• Only use an authorized AC adapter and power cord approved by
LG Electronics. Otherwise, this may result in fire, electric shock,
malfunction or product deformation.

• Never Disassemble the AC adapter or power cord. This may result in
fire or electric shock.

• Handle the adapter carefully to avoid dropping or striking it. An
impact could damage the adapter.

• Make sure the power cord is connected securely to the power plug
on the TV.

• Install the product where no radio wave occurs.

• There should be enough distance between an outside antenna and
power lines to keep the former from touching the latter even when
the antenna falls. This may cause an electric shock.

• Do not install the product on places such as unstable shelves or
inclined surfaces. Also avoid places where there is vibration or
where the product cannot be fully supported. Otherwise, the
product may fall or flip over, which may cause injury or damage to
the product.

• If you install the TV on a stand, you need to take actions to prevent
the product from overturning. Otherwise, the product may fall
over, which may cause injury.

• Only use the attachments / accessories specified by the
manufacturer.

• When installing the antenna, consult with a qualified service
technician. If not installed by a qualified technician, this may create
a fire hazard or an electric shock hazard.

• We recommend that you maintain a distance of at least 2 to 7
times the diagonal screen size when watching TV. If you watch TV
for a long period of time, this may cause blurred vision.

• Only use the specified type of battery. This could cause damage to
the remote control.

• Do not mix new batteries with old batteries. This may cause the
batteries to overheat and leak.

• Batteries should not be exposed to excessive heat. For example,
keep away from direct Sunlight , open fireplace and electric
heaters.

• Signal from Remote Control can be interrupted due to external/
internal lighting eg Sunlight, fluorescent lighting. If this occurs turn
off lighting or darken viewing area.

• When connecting external devices such as video game consoles,
make sure the connecting cables are long enough. Otherwise,
the product may fall over, which may cause injury or damage the
product.

• Do not turn the product On/Off by plugging-in or unplugging
the power plug to the wall outlet. (Do not use the power plug for
switch.) It may cause mechanical failure or could give an electric
shock.

• Please follow the installation instructions below to prevent the
product from overheating.

- The distance between the product and the wall should be more
than 10 cm.

- Do not install the product in a place with no ventilation (e.g., on
a bookshelf or in a cupboard).

- Do not install the product on a carpet or cushion.

- Make sure the air vent is not blocked by a tablecloth or curtain.

This may result in fire.

• Take care not to touch the ventilation openings when watching the
TV for long periods as the ventilation openings may become hot.
This does not affect the operation or performance of the product.

• Periodically examine the cord of your appliance, and if its
appearance indicates damage or deterioration, unplug it,
discontinue use of the appliance, and have the cord replaced with
an exact replacement part by an authorized servicer.

• Prevent dust collecting on the power plug pins or outlet. This may
cause a fire hazard.

• Protect the power cord from physical or mechanical abuse, such as
being twisted, kinked, pinched, closed in a door, or walked upon.
Pay particular attention to plugs, wall outlets, and the point where
the cord exits the appliance.

• Do not press strongly upon the panel with a hand or sharp object
such as nail, pencil or pen, or make a scratch on it, as it may cause
damage to screen.

• Avoid touching the screen or holding your finger(s) against it for
long periods of time. Doing so may produce some temporary or
permanent distortion/damage to screen.

MFL69830001_OLED_W7_S_HK_Eng.indd 3 2017-01-06  4:03:50

4

ENGLISH

• As long as this unit is connected to the AC wall outlet, it is not
disconnected from the AC power source even if you turn off this
unit by SWITCH.

• When unplugging the cable, grab the plug and unplug it, by
pulling at the plug.

• Don’t pull at the cord to unplug the power cord from the power
board, as this could be hazardous.

• When moving the product, make sure you turn the power off first.
Then, unplug the power cables, antenna cables and all connecting
cables.
The TV set or power cord may be damaged, which may create a fire
hazard or cause electric shock.

• When moving or unpacking the product, work in pairs because the
product is heavy. Otherwise, this may result in injury.

• Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has
been dropped.

• Do not use high voltage electrical goods near the TV(e.g. electric
mosquito-swatter). This may result in product malfunction.

• When cleaning the product and its components, unplug the power
first and wipe it with a soft cloth. Applying excessive force may
cause scratches or discolouration. Do not spray with water or
wipe with a wet cloth on the panel. Never use glass cleaner, car or
industrial shiner, abrasives or wax, benzene, alcohol etc., which
can damage the product and its panel. Otherwise, this may result
in fire, electric shock or product damage (deformation, corrosion or
breakage). When cleaning the top surface of the Companion Box
(AV Box), spray water on a soft cloth and then wipe gently. Do not
spray directly on the Companion Box (AV Box).

WARNING!

Never place a television set in an unstable location. A television set
may fall, causing serious personal injury or death. Many injuries,
particularly to children, can be avoided by taking simple precautions
such as:

• Using cabinets or stands recommended by the manufacturer of the
television set.

• Only using furniture that can safely support the television set.

• Ensuring the television set is not overhanging the edge of the
supporting furniture.

• Not placing the television set on tall furniture (for example,
cupboards or bookcases) without anchoring both the furniture and
the television set to a suitable support.

• Not placing the television set on cloth or other materials that may
be located between the television set and supporting furniture.

• Educating children about the dangers of climbing on furniture to
reach the television set or its controls.

If your existing television set is being retained and relocated, the
same considerations as above should be applied.

Symbols

Refers to alternating current(AC).

Refers to direct current(DC).

Refers to class II equipment.

Refers to stand-by.

Refer to “ON” (power).

Refers to dangerous voltage.

Preparing

• If the TV is turned on for the first time after it was shipped from the
factory, initialization of the TV may take a few minutes.

• Image shown may differ from your TV.

• Your TV’s OSD (On Screen Display) may differ slightly from that
shown in this manual.

• The available menus and options may differ from the input source
or product model that you are using.

• New features may be added to this TV in the future.

• The items supplied with your product may vary depending on the
model.

• Product specifications or contents of this manual may be changed
without prior notice due to upgrade of product functions.

• For an optimal connection, HDMI cables and USB devices should
have bezels less than 10 mm thick and 18 mm width. Use an
extension cable that supports USB 2.0 if the USB cable or USB
memory stick does not fit into your TV’s USB port.

A

B

A

B

*A ≤ 10 mm

*B ≤ 18 mm

• Use a certified cable with the HDMI logo attached.

• If you do not use a certified HDMI cable, the screen may not display
or a connection error may occur.

• Recommended HDMI Cable Types (3m or less)

- High-Speed HDMI®/TM cable

- High-Speed HDMI ®/TM cable with Ethernet

MFL69830001_OLED_W7_S_HK_Eng.indd 4 2017-01-06  4:03:51

5

ENGLISH

• When supported cable doesn’t enough as length to
connect TV set with Companion Box (AV Box), You can
use the extension cable.

• Please do not pile the stuff up or press strongly
the speaker. This may result in product damage or
degradation.

• Do not use any unapproved items to ensure the safety
and product’s lifespan.

• Any damages or injuries by using unapproved items are
not covered by the warranty.

• Some models appear to have a thin film on the screen.
It is actually part of the screen; do not remove it.

• When attaching the stand to the TV set, place the
screen facing down on a cushioned table or flat surface
to protect the screen from scratches. (Only OLED65W7S)

• Make sure that the screws are fastened completely. (If
they are not fastened securely enough, the TV may tilt
forward after being installed.) Do not use too much
force and over tighten the screws; otherwise screw
may be damaged and not tighten correctly. (Only
OLED65W7S)

• Make sure to wring any excess water or cleaner from
the cloth.

• Do not spray water or cleaner directly onto the TV
screen.

• Make sure to spray just enough of water or cleaner onto
a dry cloth to wipe the screen.

Separate purchase

Separate purchase items can be changed or modified for quality
improvement without any notification. Contact your dealer to buy
these items. These devices only work with certain models.
The model name or design may be changed depending on the
upgrade of product functions, manufacturer’s circumstances or
policies.

(Depending on model)

AN-MR650A

Magic Remote

Lifting and moving the TV

Please note the following advice to prevent the TV from being
scratched or damaged and for safe transportation regardless of its
type and size.

• It is recommended to move the TV in the box or packing material
that the TV originally came in.

• Before moving or lifting the TV, disconnect the power cord and all
cables.

• When holding the TV, the screen should face away from you to
avoid damage.

• Hold the top and bottom of the TV frame firmly. Make sure not to
hold the transparent part, speaker, or speaker grill area.

• When transporting a large TV, there should be at least 2 people.

• When transporting the TV by hand, hold the TV as shown in the
following illustration.

• When transporting the TV, do not expose the TV to jolts or excessive
vibration.

• When transporting the TV, keep the TV upright, never turn the TV
on its side or tilt towards the left or right.

• Do not apply excessive pressure to cause flexing /bending of frame
chassis as it may damage screen.

• When handling the TV, be careful not to damage the protruding
buttons.

• Avoid touching the screen at all times, as this may
result in damage to the screen.

• Do not move the TV by holding the cable holders, as the
cable holders may break, and injuries and damage to
the TV may occur.

• Make sure to attach the Companion Box (AV Box) fixing
supporter to the Companion Box (AV Box) before you
lift the product and move. Moving the product without
attaching it to the Companion Box (AV Box) first may
cause injury to your fingers.

MFL69830001_OLED_W7_S_HK_Eng.indd 5 2017-01-06  4:03:54

6

ENGLISH

Using the button

(Depending on model)

You can simply operate the TV functions, using the button.

Basic Functions

Power on (Press)

Power Off (Press and hold)

1

Volume Control

Programmes Control

1 All running apps will close, and any recording in progress will stop.

Adjusting the Menu

When the TV is turned on, press the button one time.
You can adjust the Menu items using the buttons.

Turns the power off.

Clears on-screen displays and returns to TV viewing.
Changes the input source.
Accesses the setting menu.

Mounting on a table

(Only OLED65W7S)

1 Lift and tilt the TV into its upright position on a table.

- Leave a 10 cm (minimum) space from the wall for proper
ventilation.

10 cm

10 cm

10 cm

10 cm

10 cm

2 Connect the power cord to a wall outlet.

• Do not place the TV near or on sources of heat, as this
may result in fire or other damage.

• Do not apply foreign substances (oils, lubricants, etc.)
to the screw parts when assembling the product.
(Doing so may damage the product.)

Mounting on a wall

10 cm

10 cm

10 cm

10 cm

Provided Item

Wall-mount Punching Guide

Wall mounting screw Wall mounting anchor

MFL69830001_OLED_W7_S_HK_Eng.indd 6 2017-01-06  4:03:56

7

ENGLISH

Tools you will need

• Phillips head + driver (manual or motorized), Ø 3/6/8mm Drill bit,
Level, Stud finder, Drill

How to attach to masonry walls

Please follow the below direction.

1 Use a drill bit Ø 8 mm to drill a hole for the anchor location within

a depth of 80 mm to 100 mm.

2 Clean the drilled hole.

3 Inser t the sealed wall mounting anchor to the hole. (When

inserting the anchor, use a hammer.)

Wall mounting anchor

4 Set the wall mount on the wall by aligning to the location of the

hole. and, set the angle adjusting part to face upward.

5 Align the wall mounting screw to the hole and tighten it. Then,

fasten the screws at torque of 45 kgf/cm to 60 kgf/cm.

Wall mounting screw

• Check the material of the wall and the thickness of the finishing.

• Use the Wall mount anchor for wall material of concrete, light
concrete, strong natural stone, soft natural stone masonry brick
and hallow block that do not crack.

Wall Material Tools Wall Width

Concrete

Wall mounting anchor,
Wall mounting screw,
Ø 3/6/8mm Drill bit

45 mm

Brick

Natural stone

Metal Panel

Plywood

Wall mounting screw,
Ø 3/6/8mm Drill bit

30 mm

EPS Panel Penerate the wall

Plasterboard +
Plywood

30 mm

• Do not mount the device on the walls made from plasterboard or
medium density fiberboard (MDF). In this case, the anchor and
screws must be inserted into the concrete behind the finish surface.
If there is no concrete on the other side, then you must first install a
separate hanger to securely install the anchors and screws.

• When installing the product on wall material not designated,
install the product so that each location can withstand the pull out
load of 70 kgf (686 N) and shear load of 100 kgf (980 N) or above.

• Use the Ø 8 mm drill bit for concrete and hammer (Impact) drill.

MFL69830001_OLED_W7_S_HK_Eng.indd 7 2017-01-06  4:03:58

8

ENGLISH

• Make sure that children do not climb on or hang on
the TV.

• Use a platform or cabinet that is strong and large
enough to support the TV securely.

• When installing the product, first check that the
wall is strong enough. Use the anchors and screws
provided.

- If you use anchors and screws that are not specified
by the manufacturer, they may not hold the weight
of the product, causing safety issues.

• Be sure to use the accessory cable provided.
Otherwise, friction between the product and the wall
may cause damage to the connector.

• When drilling holes into the wall, make sure you use
a drill and drill bit with the specified diameter. Ensure
that you also follow the instructions regarding the
depth of the holes.

- Otherwise, the product may be installed incorrectly
and cause safety issues.

• Wear safety gloves when installing the product. Do
not use your bare hands.

- Otherwise, it may cause personal injury.

• If some parts of the wall mount do not touch the wall
after it is attached, in addition to the other mounting
hardware, add the double sided tape included with
the accessories to stick the mount to the wall.

• If you want to connect the TV Cable is connected to
the back panel partition, please use the enclosed
Punching guide.

Using the kensington security system (optional)

(For OLED65W7P)

The Kensington security system connector is located at the rear of
the Companion Box (AV Box). For more information of installation
and using, refer to the manual provided with the Kensington security
system or visit http://www.kensington.com.

Connections (notifications)

Connect various external devices to the TV and switch input modes to
select an external device. For more information of external device’s
connection, refer to the manual provided with each device.
Available external devices are: HD receivers, DVD players, VCRs, audio
systems, USB storage devices, PC, gaming devices, and other external
devices.

• The external device connection may differ from the model.

• Connect external devices to the TV regardless of the order of the
TV port.

• If you record a TV program on a DVD recorder or VCR, make sure to
connect the TV signal input cable to the TV through a DVD recorder
or VCR. For more information of recording, refer to the manual
provided with the connected device.

• Refer to the external equipment’s manual for operating
instructions.

• If you connect a gaming device to the TV, use the cable supplied
with the gaming device.

• In PC mode, there may be noise associated with the resolution,
vertical pattern, contrast or brightness. If noise is present, change
the PC output to another resolution, change the refresh rate to
another rate or adjust the brightness and contrast on the PICTURE
menu until the picture is clear.

• In PC mode, some resolution settings may not work properly
depending on the graphics card.

• Some USB Hubs may not work. If a USB device connected using
a USB Hub is not detected, connect it to the USB port on the TV
directly.

• If Ultra HD content is played on your PC, video or audio may
become disrupted intermittently depending on your PC’s
performance.

• When connecting via a wired LAN, it is recommended to use a CAT
7 cable.

MFL69830001_OLED_W7_S_HK_Eng.indd 8 2017-01-06  4:03:59

9

ENGLISH

Antenna connection

Connect the TV to a wall antenna socket with an RF cable (75 Ω).

• Use a signal splitter to use more than 2 TVs.

• If the image quality is poor, install a signal amplifier properly to
improve the image quality.

• If the image quality is poor with an antenna connected, try to
realign the antenna in the correct direction.

• An antenna cable and converter are not supplied.

• Supported DTV Audio: MPEG, Dolby Digital, Dolby Digital Plus,
HE-AAC

• This TV cannot receive ULTRA HD (3840 x 2160 pixels) broadcasts
directly because the related standards have not been confirmed.

Other connections

Connect your TV to external devices. For the best picture and audio
quality, connect the external device and the TV with the HDMI cable.
Some separate cable is not provided.

• → → → General → HDMI ULTRA HD Deep Colour

- On: Support 4K @ 50/60 Hz (4:4:4, 4:2:2, 4:2:0)

- Off: Support 4K @ 50/60 Hz 8bit (4:2:0)

• If the device connected to Input Port also supports ULTRA HD Deep
Colour, your picture may be clearer. However, if the device doesn’t
support it, it may not work properly. In that case, connect the
device to a different HDMI port or change the TV’s ULTRA HD Deep
Colour setting to Off.

• Supported HDMI Audio format :
Dolby Digital / Dolby Digital Plus (32 kHz, 44.1 kHz, 48 kHz), DTS
(44.1 kHz, 48 kHz), PCM (32 kHz, 44.1 kHz,48 kHz,96 kHz,192 kHz)
(Depending on model)

Slim remote control

(Some buttons and services may not be provided depending on
models or regions.)

The descriptions in this manual are based on the buttons on the
remote control. Please read this manual carefully and use the
TV correctly. To replace coin batteries, turn the battery cover
counterclockwise by using a coin. Then, take the battery cover. Insert
and fix the battery (CR2032) with the facing forward. And, Put
the battery cover on the remote control and turn it clockwise to close.
To remove the coin batteries, perform the installation actions in
reverse.
Make sure to point the remote control toward the remote control
sensor on the TV.

A

(POWER) Turns the TV on or off.

You can turn your set-top box on or off by adding the set-top

box to the universal remote control for your TV.

Adjusts the volume level.

(MUTE) Mutes all sounds.

Scrolls through the saved programmes.

B

Returns to the previous screen.

* Clears on-screen displays and returns to last input viewing.

(HOME) Accesses the Home menu.

(INPUT) Changes the input source.

- Pressing and holding the (INPUT ) button displays all the lists
of external inputs.

Selects menus or options and confirms your input.

Navigation buttons (up/down/left/right) Press
the up, down, left, or right button to scroll the menu.

MFL69830001_OLED_W7_S_HK_Eng.indd 9 2017-01-06  4:04:00

10

ENGLISH

Magic remote functions

(Some buttons and services may not be provided depending on
models or regions.)

When the message “Magic remote battery is low. Change the battery.”
is displayed, replace the battery.
To replace batteries, open the battery cover, replace batteries
(1.5 V AA) matching the and ends to the label inside the
compartment, and close the battery cover. Be sure to point the magic
remote toward the remote control sensor on the TV. To remove the
batteries, perform the installation actions in reverse.

It is recommended that an Access Point (AP) be located more than 0.2
m away from the TV. If the AP is installed closer than 0.2 m the Magic
remote may not perform as expected due to frequency interference.

• In Analogue TV and some countries, some remote
control buttons may not work.

•

A

(POWER) Turns the TV on or off.

You can turn your set-top box on or off by adding the set-top box

to the universal remote control for your TV.

Number buttons Enters numbers.

Accesses the saved programmes list.

(Space) Opens an empty space on the screen keyboard.

* You can access the application or Live TV using the

number buttons corresponding to the features.

(Screen remote) Displays the Screen Remote.

- Accesses the Universal Control Menu.
Adjusts the volume level.

(MUTE) Mutes all sounds.

(Voice recognition)

Network connection is required to use the voice recognition function.

1 Press the voice recognition button.

2 Speak when the voice display window appears on the TV screen.

* (SEARCH) Search for content such as TV programmes, movies

and other videos, or perform a web search by entering text in the
search bar.

Scrolls through the saved programmes.

B

(HOME) Accesses the Home menu.

* Shows the previous history.

(Q. Settings) Accesses the Quick Settings.

- Pressing and holding the (Q. Settings) button displays the All
Settings menu.

Wheel (OK) Press the center of the Wheel button to select a

menu. You can change programmes by using the Wheel button.

Navigation buttons (up/down/left/right)
Press the up, down, left or right button to scroll the menu. If you
press buttons while the pointer is in use, the pointer
will disappear from the screen and Magic Remote will operate like a
general remote control. To display the pointer on the screen again,
shake Magic Remote to the left and right.

Returns to the previous screen.

* Clears on-screen displays and returns to last input viewing.

Shows programmes guide.

Streaming Service buttons Connects to the Video

Streaming Service.

(INPUT) Changes the input source.

- Pressing and holding the (INPUT ) button displays all the lists
of external inputs.

Teletext buttons ( , ) These buttons are used for
teletext.

Shows information on the current program.

, Control buttons for media contents

By zooming in on the selected area, you can view it in full

screen.

* You can zoom in on the area where the remote control is

pointed.

, , , These access special functions in some

menus.
* To use the button, press and hold for more than 3 seconds.

MFL69830001_OLED_W7_S_HK_Eng.indd 10 2017-01-06  4:04:01

11

ENGLISH

Registering magic remote

How to register the magic remote

To use the Magic Remote, first pair it with your TV.

1 Put batteries into the Magic Remote and turn the TV on.

2 Point the Magic Remote at your TV and press the Wheel (OK)

on the remote control.

- If the TV fails to register the Magic Remote, try again after
turning the TV off and back on.

How to deregister the magic remote

Press and hold the and (HOME) buttons at the same time
for five seconds, to unpair the Magic Remote with your TV.

- Pressing and holding the button will let you cancel and
reregister Magic Remote at once.

Licenses

Supported licenses may differ by model. For more information about
licenses, visit

www.lg.com

.

Open source software notice information

To obtain the source code under GPL, LGPL, MPL, and other open
source licenses, that is contained in this product, please visit

http://

opensource.lge.com

.

In addition to the source code, all referred license terms, warranty
disclaimers and copyright notices are available for download.
LG Electronics will also provide open source code to you on CD-ROM
for a charge covering the cost of performing such distribution (such
as the cost of media, shipping, and handling) upon email request to

[email protected]

. This offer is valid for three (3) years from the

date on which you purchased the product.

External control device setup

(Depending on model)

To obtain the external control device setup information, please visit

www.lg.com

.

Troubleshooting

• Cannot control the TV with the remote control.

- Check the remote control sensor on the product and try again.

- Check if there is any obstacle between the product and the
remote control.

- Check if the batteries are still working and properly installed (
to , to ).

• No image display and no sound is produced.

- Check if the product is turned on.

- Check if the power cord is connected to a wall outlet.

- Check if there is a problem in the wall outlet by connecting other
products.

• The TV turns off suddenly.

- Check the power control settings. The power supply may be
interrupted.

- Check if the Sleep Timer / Timer Power Off is activated in the
TIMERS settings.

- If there is no signal while the TV is on, the TV will turn off
automatically after 15 minutes of inactivity.

• When connecting to the PC (HDMI), ‘No signal’ or ‘Invalid Format’
is displayed.

- Turn the TV off/on using the remote control.

- Reconnect the HDMI cable.

- Restar t the PC with the TV on.

• A blue light blinks on the front of the Companion Box (AV Box).

- The TV may have a problem with the cooling fan or the
temperature in the TV may be too high. Contact an authorized
service center.

• A magenta light blinks on the front of the Companion Box (AV Box).

- The TV may have a problem in the moving speaker. Contact an
authorized service center.

• An orange light blinks on the front of the Companion Box (AV Box).

- The cable from panel may not be properly connected to the
Companion Box (AV Box). Unplug the power cord and reconnect
the cable and then plug the power cord and press the power
button. If it still doesn’t work after the steps above, contact an
authorized service center.

MFL69830001_OLED_W7_S_HK_Eng.indd 11 2017-01-06  4:04:04

12

ENGLISH

Abnormal Display

• If the product feels cold to the touch, there may be a small “flicker”
when it is turned on. This is normal, there is nothing wrong with
product.

• This panel is an advanced product that contains millions of pixels.
You may see tiny black dots and/or brightly coloured dots (red, blue
or green) at a size of 1 ppm on the panel. This does not indicate a
malfunction and does not affect the performance and reliability
of the product.
This phenomenon also occurs in third-party products and is not
subject to exchange or refund.

• You may find different brightness and color of the panel depending
on your viewing position(left/right/top/down).
This phenomenon occurs due to the characteristic of the panel.
It is not related with the product performance, and it is not
malfunction.

• Displaying a still image for a prolonged period of time may cause
image sticking. Avoid displaying a fixed image on the TV screen for
a long period of time.

• Some horizontal lines may appear when the Pixel Refresher feature
is performed. It is normal and there is no need to be concerned.

Generated sound

• “Cracking” noise: A cracking noise that occurs when watching or
turning off the TV is generated by plastic thermal contraction due
to temperature and humidity. This noise is common for products
where thermal deformation is required.

• Electrical circuit humming/panel buzzing: A low level noise is
generated from a high-speed switching circuit, which supplies a
large amount of current to operate a product. It varies depending
on the product.
This generated sound does not affect the performance and
reliability of the product.

Specifications

• The annual energy consumption indicated on the energy label is
measured in accordance with IEC 62087 and the Hong Kong Energy
Efficiency Labelling Scheme (EELS) (depending on the model).

• The actual energy consumption depends on the usage environment
(the content watched, TV settings, etc.).

Wireless module Specification

• As band channels can vary per country, the user cannot change or
adjust the operating frequency. This product is configured for the
regional frequency table.

• For consideration of the user, this device should be installed and
operated with a minimum distance of 20 cm between the device
and the body.

Wireless module (LGSBWAC61) Specifications

Wireless LAN (IEEE802.11a/b/g/n/ac)

Frequency range

Output power

(Max.)

2400 to 2483.5 MHz

5150 to 5250 MHz
5725 to 5850 MHz

15.5 dBm

17.5 dBm

8.0 dBm

Bluetooth

Frequency range

Output power

(Max.)

2400 to 2483.5 MHz 10 dBm

Environment

condition

Operating

Temperature

0 °C to 40 °C

Operating

Humidity

Less than 80 %

Storage

Temperature

-20 °C to 60 °C

Storage Humidity Less than 85 %

Digital TV Analogue TV

Television system DTMB PAL D/K, PAL I, NTSC M

Programme

coverage

DTMB : 21~69

PAL D/K : VHF/UHF 1~69,
CATV 1~47
PAL I : VHF/UHF 1~69, CATV
1~47
NTSC M : VHF/UHF 2~78,
CATV 1~71

External antenna

impedance

75 Ω

MFL69830001_OLED_W7_S_HK_Eng.indd 12 2017-01-06  4:04:04

MFL69830001_OLED_W7_S_HK_Eng.indd 13 2017-01-06  4:04:04

MFL69830001_OLED_W7_S_HK_Eng.indd 14 2017-01-06  4:04:04

MFL69830001_OLED_W7_S_HK_Eng.indd 15 2017-01-06  4:04:04

Record the model number and serial number of the TV.
Refer to the label on the back cover and quote this
information to your dealer when requiring any service.

MODEL

SERIAL

MFL69830001_OLED_W7_S_HK_Eng.indd 16 2017-01-06  4:04:05
