LG 49LS75A, 55LS75A, 42LS73B, 49LS73B, 55LS73B User Guide

OWNER’S MANUAL

MONITOR SIGNAGE

Please read this manual carefully before operating the your set and retain it

for future reference.

42LS75A 49LS75A 55LS75A

42LS73B 49LS73B 55LS73B

www.lg.com

TABLE OF CONTENTS

ENGLISH

TABLE OF CONTENTS

3 LICENSES

4 ASSEMBLY AND

PREPARATION

4 Accessories

5 Optional Accessories

7 Parts and Buttons

8 Connecting the Stand

8 Connecting the Speakers

9 Connecting IR & Light Sensor

9 Portrait Layout

10 Connecting the OPS

12 Attaching and Removing the LG

Logo Bracket

13 Installing on a Wall

15 REMOTE CONTROL

17 MAKING CONNECTIONS

17 Connecting to a PC

18 External Device Connection

20 Daisy Chain Monitors

21 - Using the Multi Display Mode

Function

22 Using the Input List

22 ENTERTAINMENT

31 SuperSign Contents

31 Information

31 File Manager

32 PICTURE ID Settings

33 USER SETTINGS

33 Main Menu Settings

33 - Quick Settings 34 - Picture Settings 38 - Sound Settings 39 - Network Settings 41 - General Settings

43 TROUBLESHOOTING

46 PRODUCT SPECIFICATIONS

56 IR CODES

58 TO CONTROL MULTIPLE

PRODUCTS

58 Connecting the Cable

58 RS-232C Configurations

58 Communication Parameter

59 Command Reference List

61 Transmission/Reception Protocol

22 Using My Media

22 - Connecting USB Storage Devices 24 - Files Supported by My Media 27 - Viewing Videos 29 - Viewing Photos 29 - Listening to Music 30 - Settings

LICENSES

Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

This DivX Certified® device has passed rigorous testing to ensure it plays DivX® video. To play purchased DivX movies, first register your device at vod. divx.com. Find your registration code in the DivX VOD section of your device setup menu.

DivX Certified® to play DivX® video up to HD 1080p, including premium content.

DivX®, DivX Certified® and associated logos are trademarks of DivX, LLC and are used under license.

Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

ENGLISH

For DTS patents, see http://patents.dts.com. Manufactured under license from DTS Licensing Limited. DTS, the Symbol, & DTS and the Symbol together are registered trademarks, and DTS 2.0 Channel is a trademark of DTS, Inc. © DTS, Inc. All Rights Reserved.

NOTE

• The warranty will not cover any damage caused by using the product in an excessively dusty

environment.

ASSEMBLY AND PREPARATION

ENGLISH

ASSEMBLY AND PREPARATION

Accessories

Please check whether all the components are included in the box before using the product. If there are any missing components, contact the retail store where you purchased the product. The illustrations in this manual may differ from the actual product and accessories.

Remote Control,

Batteries (AAA) 2 EA

CD (Owner’s Manual) /

Card

Power Cord IR & Light Sensor

HDMI Cable Mounting Cable Tie

CAUTION

• Always use genuine components to ensure safety and product performance.

• The product warranty will not cover damage or injury caused by the use of counterfeit components.

NOTE

• The accessories provided with your product may vary depending on the model or region.

• Product specifications or contents in this manual may be changed without prior notice due to

upgrade of product functions.

• SuperSign Software & Manual

- Downloading from the LG Electronics website.

- Visit the LG Electronics website (www.lgecommercial.com/supersign) and download the latest software for your model.

ASSEMBLY AND PREPARATION

Optional Accessories

Without prior notice, optional accessories are subject to change to improve the performance of the product, and new accessories may be added. The illustrations in this manual may differ from the actual product and accessories.

Stand

ST-200T

Diameter 4.0 mm x Pitch 0.7 mm x

Length 10 mm (including spring washer)

Stand kit

Screws

ENGLISH

Speakers

SP-2100

Cable Holders/

Cable Ties

Screws

Diameter 4.0 mm x Pitch

0.7 mm x Length 8 mm

(including spring washer)

Screws

Diameter 4.0 mm x Pitch

1.6 mm x Length 10 mm

Speaker kit

NOTE

• Cable holder/Cable tie may not be available in some areas or for some models.

• Optional accessories are available for some models. If necessary, please purchase them separately.

ENGLISH

ASSEMBLY AND PREPARATION

KT-OPSA

Power Cord

AN-WF500

Wi-Fi Dongle kit

Screws

Card (Easy Setup Guide)

OPS kit

Connecting

Cable

KT-SP0

Pixel sensor kit

NOTE

• Optional accessories are available for some models. If necessary, please purchase them separately.

• Pixel sensor is sold separately. You can obtain additional accessories from your local retail store.

ASSEMBLY AND PREPARATION

Parts and Buttons

Buttons

ENGLISH

Buttons Description

INPUT Changes the input source.

MENU Accesses the main menus, or saves your input and exits the menus.

Adjust the up and down.

Moves left and right.

AUTO/SET Displays the current signal and mode.

/ I

Turns the power on or off.

Connection

Panel

ASSEMBLY AND PREPARATION

ENGLISH

Connecting the Stand

Connecting the Speakers

- For certain models only.

- The image may be different according to the model

1 Place a soft cloth on the table and place the

product with the screen facing downward.

2 Use the screws to secure the stand to the

back of the product as shown below.

- For certain models only.

- The image may be different according to the model.

1 Connect an input signal cable before

installing the speakers.

2 Mount the speakers by using screws as

shown below. Make sure the power cable is

disconnected before making a connection.

3 Connect the speaker cables noting the

correct polarity. Use cable holders and cable

ties to organize the speaker cables.

ASSEMBLY AND PREPARATION

NOTE

• Please turn off the power before removing

the cable. Connecting or removing the speaker cable while turned on may result in no sound.

Connecting IR & Light Sensor

When you connect the cable to the product, the feature for receiving remote control signals is activated. The IR & light sensor is magnetic. Attach it to the front edge of the product for use.

[Front]

Portrait Layout

When installing in a portrait layout, rotate the monitor counterclockwise 90 degrees (when facing the screen).

Using Kensington Lock

(This is not available for all models.)

The Kensington security system connector is located at the back of the monitor. For more information on installation and use of this system, refer to the manual provided with the Kensington security system or visit

kensington.com

Connect the Kensington security system cable between the monitor and a table.

http://www.

ENGLISH

CAUTION

NOTE

• The signal strength of the IR and Light

sensor will decrease if the sensor is not placed in front of the product.

NOTE

• The Kensington security system is optional.

You can obtain additional accessories from most electronics retail stores.

ASSEMBLY AND PREPARATION

ENGLISH

Connecting the OPS

- For certain models only.

- The image may be different according to the model.

1 Lay a clean cloth on the floor, put the

monitor on it with the screen facing

downward, and then remove the screws

from the OPS hole cover on the rear of the

monitor with a screwdriver.

OPS Hole Cover

3 Align the KT-OPSA along the four screw

holes on the rear of the set and attach it

to the rear of the set using the four screws

provided.

KT-OPSA

4 Open the top cover of the KT-OPSA and

connect the cable provided to the connector

inside the set and the connector on the KT-

OPSA.

2 Lift the left side (round part) of the OPS hole

cover. Remove the cover.

Connector on the KT-OPSA

Connector inside the set

5 Close the top cover of the KT-OPSA and

tighten it on the left and right with the two

screws provided.

ASSEMBLY AND PREPARATION

ENGLISH

6 Insert the OPS Player (sold separately) into

the bottom hole of the KT-OPSA and finish

the installation by tightening the two screws

provided on the bottom.

OPS Player

ASSEMBLY AND PREPARATION

ENGLISH

Attaching and Removing the LG Logo Bracket

- For certain models only.

- The image may be different according to the model.

Removing the LG Logo

1 Lay a clean cloth on the floor, and then put

the monitor on it with the screen face down.

Remove the two screws that secure the LG

Logo Bracket to the bottom of the rear side

of the monitor using a screwdriver.

LG Logo Bracket

2 After removing the screws, remove the

LG Logo. When re-attaching the LG Logo,

follow the process in reverse order.

Attaching the LG Logo on the right side

1 Lay a clean cloth on the floor, and then put

the monitor on it with the screen face down.

Remove the two screws that secure the LG

Logo Bracket to the bottom of the rear side

of the monitor using a screwdriver.

2 After removing the screws, remove the LG

Logo. Attach the LG Logo Bracket with the

two screws, aligning it with the holes at the

right side.

Hole

ASSEMBLY AND PREPARATION

Installing on a Wall

For proper ventilation, allow a clearance of 10 cm on each side and from the wall. Detailed installation instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide.

10 cm

To install your monitor on a wall, attach a wall mounting bracket (optional part) to the back of the monitor.

Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall.

1 Use only screws and wall mounting brackets

that conform to VESA standards.

2 Screws which are longer than standard

length may damage the inside of the

monitor.

3 A non-VESA standard screw may damage

the product and cause the monitor to fall.

LG Electronics is not liable for any accidents

related to the use of non-standard screws.

4 Please use VESA standard as below.

• 785 mm and above

* Fixing screws: Diameter 6.0 mm x Pitch

1.0 mm x Length 12 mm

10 cm

CAUTION

• Disconnect the power cord before moving or

installing the monitor to avoid risk of electric shock.

• If you install the monitor on a ceiling

or slanted wall, it may fall and result in injury. Use an authorized LG wall mount and contact your local dealer or qualified personnel to assist with the installation.

• Do not over tighten the screws as this may

damage the monitor and void your warranty.

• Use only screws and wall mounting brackets

that meet the VESA standard. Any damage or injuries caused by misuse or use of improper accessories are not covered by the warranty.

• To prevent injury, this apparatus must be

securely attached to the wall in accordance with the installation instructions. (This pertains only to Australia and New Zealand.)

NOTE

• The wall mount kit includes the installation

guide and all necessary parts.

• The wall mounting bracket is optional. You

can obtain additional accessories from your local dealer.

• The length of screws required may differ

depending on the wall mount. Be sure to use the correct length.

• For more information, please refer to the

guide provided with the wall mount.

ENGLISH

785 mm

ASSEMBLY AND PREPARATION

ENGLISH

Securing the monitor to a wall (optional)

Procedure may differ depending on the model.

1 Insert and tighten the eyebolts, or brackets

and bolts on the back of the monitor.

- If there are already bolts inserted in the

eyebolts’ position, remove the other bolts first.

2 Mount the wall brackets with the bolts to the

wall. Match the location of the wall bracket and the eyebolts on the rear of the monitor.

3 Connect the eyebolts and wall brackets

tightly with a sturdy cord. Make sure the securing cord is horizontal with the flat surface.

WARNING

• If the monitor is not positioned in a

sufficiently stable location, there is a danger that it will fall. Many injuries, particularly to children, can be avoided by taking simple precautions such as:

»» Using cabinets or stands

recommended by the manufacturer.

»» Only using furniture that can safely

support the monitor.

»» Ensuring the monitor is not

overhanging the edge of the supporting furniture.

»» Not placing the monitor on tall furniture

(for example, cupboards or bookcases) without anchoring both the furniture and the monitor to a suitable support.

»» Not placing cloth or other materials

between the monitor and supporting furniture.

»» Educating children about the dangers

of climbing on furniture to reach the monitor or its controls.

CAUTION

• Make sure that children do not climb on or

hang from the monitor.

NOTE

• Use a platform or cabinet that is large

and strong enough to support the monitor securely.

• Brackets, bolts, and cords are sold

separately. You can obtain additional accessories from your local retail store.

• The illustration shows a general example of

installation and may look different from the actual product.

REMOTE CONTROL

The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully to use the monitor correctly.

To install batteries, open the battery cover, place batteries (1.5 V AAA) matching and terminals to the labels inside the compartment, and close the battery cover.

To remove the batteries, perform the installation actions in reverse. The illustrations may differ from the actual accessories.

CAUTION

• Do not mix old and new batteries, as this

may damage the remote control.

• Be sure to point the remote control toward

the remote control sensor on the monitor.

Turns the monitor on or off.

(POWER)

MONITOR ON

Turns the monitor on.

MONITOR OFF

Turns the monitor off.

1/a/A Button

Toggles between numerical

and alphabetical.

(Depending upon the model,

this feature may not be

supported.)

ARC

Selects the Aspect Ratio

mode.

Volume Up/Down

Button

Adjusts the volume.

PSM

Selects the Picture Mode.

MUTE

Mutes all sounds.

ENERGY SAVING( )

Adjusts the brightness of the picture to reduce energy consumption.

INPUT

Selects the input mode.

This model does not support this.

Number and Alphabet buttons

Enters numerical or alphabetical characters depending upon the setting. (Depending upon the model, this feature may not be supported.)

CLEAR

Deletes the entered numerical or alphabetical character. (Depending upon the model, this feature may not be supported.)

BRIGHTNESS Button

Adjusts the brightness of the display. PAGE Function is not supported in the this model. (Depending upon the model, this feature may not be supported.)

ENGLISH

REMOTE CONTROL

ENGLISH

Activates the Launcher.

Accesses the main menus

or saves your input and exit

Selects menus or options and

Allows you to move back one step

in the user interaction function.

various multimedia devices to

enjoy multimedia simply by using

(Depending upon the model, this

feature may not be supported.)

confirms your input.

Allows you to control

the remote control

through the SimpLink menu.

HOME

SETTINGS

menus.

BACK

AUTO

Automatically adjusts picture position and minimizes image instability (available for RGB input only). (Depending upon the model, this feature may not be supported.)

W.BAL

This model does not support this.

S.MENU

SuperSign menu key (Depending upon the model, this feature may not be supported.)

Navigation Buttons

Scrolls through menus or options.

Exit

Quit all OSD tasks and applications.

TILE

This model does not support this.

When the Picture ID number

ID ON/OFF

matches the Set ID number, you

can control whichever monitor you

want in multi-display format.

USB Menu Control Buttons

Controls media playback.

MAKING CONNECTIONS

You can connect various external devices to your monitor. Change the input mode and select the external device you want to connect. For more information about external device connections, see the user manual provided with each device.

Connecting to a PC

The illustrations may differ from the actual accessories. Some of the cables are not provided. This monitor supports the Plug & Play* feature. * Plug & Play: a feature that enables a PC to recognize devices attached by the user without device configuration or user intervention when powering up.

(not included)

ENGLISH

(not included)

DP OUT

DVI OUT

(not included)

HDMI

(not included)

DVI OUT

MAKING CONNECTIONS

ENGLISH

External Device Connection

Connect a HD receiver, DVD, or VCR player to the monitor and select an appropriate input mode.

The illustrations may differ from the actual accessories. Some of the cables are not provided. For the best picture and sound quality, connecting external devices to your monitor using HDMI cables is recommended.

ฒખ

(not included)

Direct Connection/

Using the Router/

Using the Internet

USB

(not included)

Network

HDMI

HD Receiver/DVD/VCR

Camcorder/Camera/Gaming Device

MAKING CONNECTIONS

NOTE

• For the best image quality, using the monitor with HDMI connection is recommended.

• To comply with the standard specifications of the product, use a shielded interface cable with a ferrite

core, such as a DVI cable.

• If you turn the monitor on when the set is cold, the screen may flicker. This is normal.

• Sometimes red, green, or blue spots may appear on the screen. This is normal.

• Use a High Speed HDMI®/TM cable.

• Use a certified cable with the HDMI logo attached. If you do not use a certified HDMI cable, the

screen may not display or a connection error may occur.

• Recommended HDMI Cable Types

- High-Speed HDMI®/TM Cable

- High-Speed HDMI®/TM Cable with Ethernet

• If you cannot hear any sound in HDMI mode please check your PC settings. Some PCs require you

to manually change the default audio output to HDMI.

• If you want to use HDMI-PC mode, you must set your PC/DTV to PC mode.

• You may experience compatibility issues if you use HDMI-PC mode.

• Make sure the power cable is disconnected.

• If you connect a gaming device to the monitor, use the cable provided with the gaming device.

• It is recommended to use the speakers that are provided as optional accessories.

• High Speed HDMI®/TM cables transmit a HD signal up to 1080p and higher.

CAUTION

• Connect the signal input cable and tighten it by turning the screws clockwise.

• Do not press the screen with your finger for a prolonged period as this may

result in temporary distortion on the screen.

• Avoid displaying static images on the screen for a long period of time to

prevent image burn. Use a screensaver if possible.

• A wireless communication device near your monitor can affect the image.

ENGLISH

MAKING CONNECTIONS

ENGLISH

Daisy Chain Monitors

To use different products connected to each other, connect one end of the signal input cable (DP Cable) to the DP Out connector of Monitor 1 and connect the other end to the DP In connector of the other product.

* DP Cable - Use a DP cable that is certified to DP1.1a (SST), DP1.2 (MST) or higher.

Monitor 1 Monitor 2 Monitor 3 Monitor 4

NOTE

• If the signal is stable and there is no cable loss, in general, up to 100 monitors can be connected via

the DP Out port (at the recommended resolution). If you want to connect more than this number of monitors, use a booster.

• If you set the tile mode using DVI or HDMI, you will not be able to watch HDCP-encrypted content.

• If the signal cable between the product and your PC is too long, make sure to use the Booster or

optical cable.

MAKING CONNECTIONS

Using the Multi Display Mode Function

The Multi Display Mode function displays a video signal received from DP In either in single mode (SST: Single Stream Transport) or multi-mode (MST: Multi Stream Transport) through DP Out.

• This function can be configured in the Installation Menu (For more information, refer to the

Installation Menu manual.)

• If it is On, the image of each display is displayed in multi-mode.

• If it is Off, the image of each display is displayed in single mode.

• The multi-mode is available in a PC supporting DISPLAYPORT 1.2.

• Multi-mode can connect up to only four monitors. (at the recommended resolution)

• When this function is used, your monitor may not work properly depending on the video card. Reboot

the PC after setting the function to Off for stable screen output when not in use.

• In case of using DVI/HDMI Input to DP daisy chain, please set ‘Multi Display mode function’ to off.

ENGLISH

ENTERTAINMENT

ENGLISH

Using the Input List

Remote Control (HOME)

Input Mode Description

HDMI1

HDMI2/OPS

DISPLAYPORT

DVI

You can watch content on a PC, DVD player, digital set-top box, and other high definition devices.

CAUTION

• If the OPS kit is connected to the HDMI2/

OPS port, the HDMI2/OPS port is used as the OPS port.

ENTERTAINMENT

Using My Media

Connecting USB Storage Devices

Connect a USB storage device such as a USB flash memory or an external hard drive to the display and use multimedia features.

Connect a USB flash memory or USB memory card reader to the display as shown in the following illustration.

CAUTION

• Do not turn off the monitor or remove a

USB storage device when the My Media screen is activated. This could result in loss of files or damage to the USB storage device.

• Back up files you have saved on a USB

storage device frequently, as loss or damage to the files may be not covered by the warranty.

+ 50 hidden pages
