Specifications
Smart Hybrid Cooler |
|
49WEC-CB |
32WEC-DB |
||
|
|
Screen Size |
49" |
32" |
|
|
|
Panel Technology |
IPS (M+) |
IPS (M+) |
|
|
|
Transmittance |
9.50% |
8.63% |
|
|
|
Aspect Ratio |
16:9 |
16:9 |
|
PANEL |
|
Native Resolution |
1,920 x 1,080 (FHD) |
1,920 x 1,080 (FHD) |
|
|
Brightness |
100 cd/m2 (Typ), 80 cd/m2 (Min) / |
100 cd/m2 (Typ), 80 cd/m2 (Min) / |
||
|
|
||||
|
|
(Integratedwithprotectionglass +white reflectorsheet(TXD-225)) |
(Integratedwithprotectionglass +white reflectorsheet(TXD-225)) |
||
|
|
|
|||
|
|
Color Depth |
16.7 Million |
8 bit , 16.7 Million |
|
|
|
Response Time (Typ) |
9 ms (G to G BW) |
9ms (G to G BW) |
|
|
|
Orientation |
Portrait |
Portrait |
|
|
|
Input |
- |
HDMI |
|
Connectivity |
Output |
- |
Audio |
||
|
|
External Control |
IR Receiver, USB |
RS232C, RJ45, IR Receiver, USB |
|
|
|
Bezel Color |
Silver |
Dia Black |
|
|
|
Bezel Width |
184.6 mm (T), 223.6 mm (D), 60 mm (L/R) |
124.8 mm (T), 123.3 mm (B), 117.3 mm (L/R) |
|
Physical |
|
Cooler Dimension |
730 x 773 x 1,861 mm |
636.7 x 651 x 1,045.5 mm |
|
|
Net Weight |
114 kg |
75 kg |
||
Specification |
|
||||
|
Carton Dimensions |
765 x 801 x 2,037.5 mm |
751 x 699 x 1,195 |
||
|
|
||||
|
|
Packed Weight |
162 kg |
88.7 kg (TBD) |
|
|
|
Handle |
Yes |
Yes (Door side Mold Cover) |
|
SPECIAL FEATURES |
|
Temperature Sensor, File Play with USB, Internal Memory 8 GB (System 4 GB + |
Temperature Sensor, File Play with USB, Internal Memory 8 GB (System 4 GB + |
||
|
Available4GB), Wi-Fi (In-Box),USB Cloning |
Available4GB), Wi-Fi (In-Box),USB Cloning |
|||
|
|
|
|||
Environment Conditions |
|
Operation Temperature |
5°C to 35°C |
5°C to 35°C |
|
|
Operation Humidity |
10% ~ 80% |
10% ~ 80% |
||
|
|
||||
|
|
Power Supply |
220-240V~50Hz 2.5A |
220-240V~50Hz TBDA |
|
Power |
|
Power Type |
Adaptor(Built-in) |
Adaptor(Built-in) |
|
|
|
300Wh (Typ),450Wh(Max)-TestCondition |
TBD(Typ),TBD (Max) -Test Condition |
||
|
|
|
|||
|
|
Power Consumption( Typ./Max) |
:NormalTemperature(25+/-2°C) |
:NormalTemperature(25+/-2°C) |
|
|
|
|
: Keep the door closed condition. Do not allowed door open/close. |
: Keep the door closed condition. Do not allowed door open/close. |
|
|
|
Safety |
CE |
CE |
|
STANDARD (CERTIFICATION) |
EMC |
CE |
CE |
||
|
|
ErP / Energy Star |
N/A |
TBD |
|
Software Compatibility |
|
SuperSign W/Lite |
Yes |
Yes |
|
|
SuperSign C |
Yes |
Yes |
||
|
|
||||
|
|
Basic |
Remote Controller (including battery 2ea), WiFi Dongle, |
Remote Controller (including battery 2ea), IR Receiver |
|
Accessories |
Anker Bolt(1 set), Rubber Pad(12ea) |
||||
|
|
||||
|
|
Optional |
X |
AN-WF500 |
|
|
|
Protection Glass |
3.2T Tempered Glass |
3.2T Tempered Glass |
|
|
|
Hybrid Display |
Hybrid/ Semi-Tranparent |
Hybrid/ Semi-Tranparent |
|
Transparent Cooler |
Brightness Control |
Yes |
Yes |
||
|
|
Compatible Cooler Body |
PremierFRS-500R |
PremierTGM-7SD |
|
|
|
Sensor |
ProximitySensor(Lower-centerdoor),Door sensor |
ProximitySensor(Lower-center door), Door sensor |
|
|
|
Volume |
479 L |
215 L |
|
|
|
Temperature Adjust |
0°C ~ 10.0°C (32°F ~ 50°F) |
0°C ~ 10.0°C (32°F ~ 50°F) |
|
|
|
Compressor Power |
1/4 HP |
1/4 HP |
|
|
|
Shelves |
4 |
3 |
|
|
|
Foaming Agent |
Cyclopentane |
Cyclopentane |
|
|
|
Safety / EMC |
CE / CE (Class B) |
CE / CE (Class B) |
|
Cooler Body |
|
Manufacturer |
TurboAir Korea |
TurboAir Korea |
|
|
Power Input |
220-240V~50 Hz |
220-240V~50 Hz |
||
|
|
||||
|
|
RoHS |
RoHS, REACH |
RoHS, REACH |
|
|
|
Refrigent Type |
R-134a |
R-134a |
|
|
|
Charge |
0.220 kg |
0.125 kg |
|
|
|
GWP |
1,430 (kgCO2-eq) |
1,430 (kgCO2-eq) |
|
|
|
CO2-Equivalent |
0.315 (Ton) |
0.179 (Ton) |
|
|
|
Door Lock |
None |
Yes |
|
|
|
|
|
*Contains fluorinated greenhouse gases / *Hermetically sealed |
|
|
Open Frame |
|
|
|
|
49WFB |
32WFC |
|||
|
|
|
|
Screen Size |
|
48.5" diagonal |
31.55" diagonal |
|||
|
|
|
|
Panel Technology |
IPS |
IPS |
||||
|
|
|
|
Aspect Ratio |
16:9 |
16:9 |
|
|||
|
|
|
|
Native Resolution |
1,920 x 1,080 (FHD) |
1,920 x 1,080 (FHD) |
||||
|
|
|
|
Transmittance |
9.50% |
8.63% (center 1point, typ) |
||||
|
PANEL |
|
|
Contrast Ratio |
1300 |
- |
|
|||
|
|
|
ViewingAngle(HxV) |
178 x 178 |
Viewinganglefree |
|||||
|
|
|
|
|||||||
|
|
|
|
Color Depth |
8 bit, 16.7 Million colors |
8 bit, 16.7 Million colors |
||||
|
|
|
|
Response Time |
- |
8 ms (G to G) |
||||
|
|
|
|
Surface Treatment |
Hard coating (2H), |
Hard coating (2H), |
||||
|
|
|
|
Anti-reflectiontreatmentofthefrontpolarizer(Reflectance <2%) |
Anti-reflection treatmentofthefrontpolarizer(Reflectance< 2%) |
|||||
|
|
|
|
|
|
|
|
|||
|
|
|
|
Orientation |
|
Landscape & Portrait |
Landscape & Portrait |
|||
|
Connectivity |
|
|
Input |
|
LVDS |
LVDS |
|||
|
|
|
|
Color |
|
Black |
Black |
|||
|
|
|
|
Bezel Width |
64.1 mm (U), 18.7 mm (D), 18.7 mm (L), 125.86 mm (R) |
83.05 mm (U), 17.5 mm (D), 17.5 mm (L), 17.5 mm (R) |
||||
|
Physical Specification |
|
Monitor Dimension (W x H x D) |
1,222.34 × 690.8 × 11.2 mm |
743.2 x 504.2 x 11.2 mm |
|||||
|
|
Weight |
|
5.4 kg |
2.6 kg |
|||||
|
|
|
|
|
||||||
|
|
|
|
Carton Dimensions (W x H x D) |
1,303 x 771 x 118 mm |
834.0 x 570.0 x 114 mm |
||||
|
|
|
|
Packed Weight |
9.0 kg |
3.8 kg |
||||
|
Environment Conditions |
|
Operation Temperature |
0°C to 40°C |
0°C to 40°C |
|||||
|
|
Operation Humidity |
10% to 80% |
10% to 80% |
||||||
|
|
|
|
|||||||
|
Power Consumption |
Typ. |
|
5.4W (12VInput) |
6.3 W(Typ.)(12VInput) |
|||||
|
Accessory |
|
|
|
|
|
|
Simple Book (1) |
Simple Book (1) |
|
Download LG Commercial Display Mobile App |
|
|
|
Learn More www.lg.com/b2b |
|
|
||||
|
|
|
|
|
||||||
|
|
|
|
|
|
|
youtube.com/c/LGECommercialDisplay |
|
|
|
|
|
|
|
|
|
|
LG may make changes to specifications and product descriptions without notice. |
|
|
|
|
|
|
|
|
|
|
|
|
||
Apple App Store |
Google Play Store |
|
|
Copyright © 2017 LG Electronics Inc. All rights reserved. “LG Life’s Good” is a registered trademark of LG Corp. |
||||||
|
|
The names of products and brands mentioned here may be the trademarks of their respective owners. |
||||||||
|
|
|
|
|
|
|
||||
New Concept with Hybrid View
LG Smart Hybrid Cooler/Open Frame
49/32WEC is a transparent cooler that allows the customer in the shop to view not only the beverages in the cooler but also the advertisement on the transparent display by a proximity sensor. By eliminating the air gap between the door glass and transparent LCD panel, the LG Smart Hybrid cooler gives unprecedentedly accurate image & color representation. Specially designed for the LG Smart Hybrid cooler, the M+ panel (with additional white pixel & enhanced transparency) renders brighter images for a vivid digital content experience. In short, this transparent cooler is able to strengthen the effectiveness of the advertising displays in the store.
Key Features
Hybrid View Hybrid View with Proximity Sensor
With proximity sensor enabled, the display switches from advertising mode to transparentmodeenablingsee-thruview.
Advertising mode : Digital content is vividly shown.
Transparent mode :
Products inside the cooler are shown together with digital content.
Advanced |
Direct Bonding Technology |
Picture |
By eliminating air gap between the door glass and |
Quality |
transparent LCD panel, the LG Smart Hybrid cooler |
|
gives unprecedentedly accurate image & color. |
Panel
Conventional |
49/32WEC |
|
|
Resin |
|
|
|
||||
|
|
|
Glass |
||
|
|
|
|
|
|
|
|
|
|
|
|
Enhanced Brightness
Specially designed for the LG Smart Hybrid cooler M+ panel (with additional white pixel & enhanced
transparency) renders brighter images for a vivid digital content.
|
|
|
|
Normal RGB |
+ White |
M+ (RGBW) |
|
Sub Pixel |
|||
New Concept with Hybrid View
LG Smart Hybrid Cooler/Open Frame
Screen Sizes |
49WEC/32WEC/49WFB/32WFC |
49'', 32'' |
•IPSTechnology |
|
• Portrait Mode |
|
• Full HD (1,920 X 1,080) |
|
•Transparency Rate : 9.5% (49WEC, 49WFB), 8.6% (32WEC, 32WFC) |
49WEC |
32WEC |
Other Features
Easy Content Management
Simple Network Management Protocol
With SuperSign W digital signage solution, you can remotely manage content distribution via the
Internet. Built-in SoC* allows you to play content just by uploading the content via USB.
- High Performance SoC
- Content management through SuperSign W - Play content with WiFi / USB
SoC |
USB |
HDMI |
LAN |
|
|
*HDMI, LAN : 32WEC Only |
|
*SoC : System on Chip
User-convenience
Door Sensor |
IR Sensor |
Rich Resonance Sound |
||
When the cooler door is opened, the door backlight |
Remote control for display menu selection. |
Built-inspeakers(2x10watts)withhigh |
||
is adjusted to prevent dazzling. |
|
efficientacousticenclosure |
||
|
|
|
|
|
|
|
|
|
|
(2 x 10 watts)
LED Lignt On |
LED Lignt Minimized |
* 49WEC Only
Dimension (unit : mm)
49WEC
730 x 773 x 1,861 /
114 kg
45 |
773 |
1,444 |
730
1,861
32WEC
636.7 x 651 x 1,045.5 /
75 kg
49WFB
1,222.34 x 690.8 x 11.2 /
5.4 kg
32WFC
743.2 x 504.2 x 11.2 /
2.6 kg
636.6 |
|
392.9 (Active Area) |
|
698.4 (Active Area) |
1,046.5 |
651.1 |
591 |
14 |
969.4 |
63.1 |
1,222.34 (Set Size)
|
18.7 |
125.86 |
|
64.1 |
|
690.8 (Set Size) |
|
1,073.78 (Active Area) |
604 (Active Area) |
393.8 |
|
|
18.7 |
|
|
|
743.2 |
708.2 (Bezel Area)
17.5
17.5
Area) |
Area) |
504.2 |
392.85(Active |
403.65(Bezel |
|
693.4 (Active Area) |
|
|
|
83.05 |
|
|
17.5 |
|
100 |
|
|
158 |
100 |
|
Mount Ready Hole (M3 / Depth 7mm) |
|
|
|
Mount Ready Hole (M3 / Depth 7mm) |
130 |
|
|
|
|
|
|
LVDS Cable (Dedicated cable) |
|
|
|
Mount Ready Hole (M3 / Depth 7mm) |
130 |
100 |
4-3 |
Mount Ready Hole (M3 / Depth 7mm) |
|
100 |
|
|
112.8 |
11.2
46.6 |
125 |
65.1 |
|
75 |
Mount Ready Hole |
|
(M3 / Depth 7mm) |
75 |
Mount Ready Hole |
|
(M3 / Depth 7mm) |
129.1 |
|
51.6 |
110 |
|
125 |
46.6 |
|
|
65.1 |
Mount Ready Hole |
|
75 |
(M3 / Depth 7mm) |
|
|
Mount Ready Hole |
|
75 |
(M3 / Depth 7mm) |
|
|
|
|
129.1 |
LVDS Cable |
110 |
51.6 |
(Dedicated cable) |
|
|
4-3
