LG 49UF771V-ZA, 49UF77-ZB Schematic

Internal Use Only

North/Latin America http://aic.lgservice.com Europe/Africa http://eic.lgservice.com Asia/Oceania http://biz.lgservice.com

LED TV

SERVICE MANUAL

CHASSIS : LD53H / LD53J

MODEL : 49UF77** 49UF77**-ZB/ZF/ZP/ZQ

49UF771V 49UF771V-ZA

CAUTION

BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

Printed in KoreaP/NO : MFL68762610 (1503-REV00)

CONTENTS

CONTENTS .............................................................................................. 2

SAFETY PRECAUTIONS ........................................................................ 3

SERVICING PRECAUTIONS .................................................................... 4

SPECIFICATION ....................................................................................... 6

ADJUSTMENT INSTRUCTION .............................................................. 15

BLOCK DIAGRAM .................................................................................. 25

EXPLODED VIEW .................................................................................. 36

SCHEMATIC CIRCUIT DIAGRAM ........................................... APPENDIX

TROUBLE SHOOTING GUIDE ................................................ APPENDIX

Only for training and service purposes

- 2 -

SAFETY PRECAUTIONS

IMPORTANT SAFETY NOTICE

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the Schematic Diagram and Exploded View. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer.

General Guidance

An isolation Transformer should always be used during the servicing of a receiver whose chassis is not isolated from the AC power line. Use a transformer of adequate power rating as this protects the technician from accidents resulting in personal injury from electrical shocks.

It will also protect the receiver and it's components from being damaged by accidental shorts of the circuitry that may be inadvertently introduced during the service operation.

If any fuse (or Fusible Resistor) in this TV receiver is blown, replace it with the specified.

When replacing a high wattage resistor (Oxide Metal Film Resistor, over 1 W), keep the resistor 10 mm away from PCB.

Keep wires away from high voltage or high temperature parts.

Before returning the receiver to the customer,

always perform an AC leakage current check on the exposed metallic parts of the cabinet, such as antennas, terminals, etc., to be sure the set is safe to operate without damage of electrical shock.

Leakage Current Cold Check(Antenna Cold Check)

With the instrument AC plug removed from AC source, connect an electrical jumper across the two AC plug prongs. Place the AC switch in the on position, connect one lead of ohm-meter to the AC plug prongs tied together and touch other ohm-meter lead in turn to each exposed metallic parts such as antenna terminals, phone jacks, etc. If the exposed metallic part has a return path to the chassis, the measured resistance should be between 1 MΩ and 5.2 MΩ. When the exposed metal has no return path to the chassis the reading must be infinite. An other abnormality exists that must be corrected before the receiver is returned to the customer.

Leakage Current Hot Check (See below Figure)

Plug the AC cord directly into the AC outlet.

Do not use a line Isolation Transformer during this check. Connect 1.5 K / 10 watt resistor in parallel with a 0.15 uF capacitor between a known good earth ground (Water Pipe, Conduit, etc.) and the exposed metallic parts. Measure the AC voltage across the resistor using AC voltmeter with 1000 ohms/volt or more sensitivity. Reverse plug the AC cord into the AC outlet and repeat AC voltage measurements for each exposed metallic part. Any voltage measured must not exceed 0.75 volt RMS which is corresponds to

0.5 mA. In case any measurement is out of the limits specified, there is possibility of shock hazard and the set must be checked and repaired before it is returned to the customer.

Leakage Current Hot Check circuit

Only for training and service purposes

- 3 -

SERVICING PRECAUTIONS

CAUTION: Before servicing receivers covered by this service manual and its supplements and addenda, read and follow the

SAFETY PRECAUTIONS on page 3 of this publication. NOTE: If unforeseen circumstances create conict between the

following servicing precautions and any of the safety precautions on page 3 of this publication, always follow the safety precautions. Remember: Safety First.

General Servicing Precautions

1. Always unplug the receiver AC power cord from the AC power source before;

a. Removing or reinstalling any component, circuit board

module or any other receiver assembly.

b. Disconnecting or reconnecting any receiver electrical plug

or other electrical connection.

c. Connecting a test substitute in parallel with an electrolytic

capacitor in the receiver. CAUTION: A wrong part substitution or incorrect polarity installation of electrolytic capacitors may result in an explosion hazard.

2. Test high voltage only by measuring it with an appropriate high voltage meter or other voltage measuring device (DVM, FETVOM, etc) equipped with a suitable high voltage probe. Do not test high voltage by "drawing an arc".

3. Do not spray chemicals on or near this receiver or any of its assemblies.

4. Unless specied otherwise in this service manual, clean

electrical contacts only by applying the following mixture to the contacts with a pipe cleaner, cotton-tipped stick or comparable non-abrasive applicator; 10 % (by volume) Acetone and 90 % (by volume) isopropyl alcohol (90 % - 99 % strength)

CAUTION: This is a ammable mixture. Unless specied otherwise in this service manual, lubrication

of contacts in not required.

5. Do not defeat any plug/socket B+ voltage interlocks with which receivers covered by this service manual might be equipped.

6. Do not apply AC power to this instrument and/or any of its electrical assemblies unless all solid-state device heat sinks are correctly installed.

7. Always connect the test receiver ground lead to the receiver chassis ground before connecting the test receiver positive lead. Always remove the test receiver ground lead last.

8. Use with this receiver only the test xtures specied in this

service manual.

CAUTION: Do not connect the test xture ground strap to any

heat sink in this receiver.

Electrostatically Sensitive (ES) Devices

Some semiconductor (solid-state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES

devices are integrated circuits and some eld-effect transistors

and semiconductor “chip” components. The following techniques should be used to help reduce the incidence of component damage caused by static by static electricity.

1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any electrostatic charge on your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging wrist strap device, which should be removed to prevent potential shock reasons prior to applying power to the unit under test.

2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.

3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.

4. Use only an anti-static type solder removal device. Some sol-

der removal devices not classied as “anti-static” can generate electrical charges sufcient to damage ES devices.

5. Do not use freon-propelled chemicals. These can generate

electrical charges sufcient to damage ES devices.

6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable conductive material).

7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material to the chassis or circuit assembly into which the device will be installed. CAUTION: Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.

8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the brushing together of your clothes fabric or the lifting of your

foot from a carpeted oor can generate static electricity sufcient to damage an ES device.)

General Soldering Guidelines

1. Use a grounded-tip, low-wattage soldering iron and appropriate tip size and shape that will maintain tip temperature within the range or 500 °F to 600 °F.

2. Use an appropriate gauge of RMA resin-core solder composed of 60 parts tin/40 parts lead.

3. Keep the soldering iron tip clean and well tinned.

4. Thoroughly clean the surfaces to be soldered. Use a mall wirebristle (0.5 inch, or 1.25 cm) brush with a metal handle. Do not use freon-propelled spray-on cleaners.

5. Use the following unsoldering technique

a. Allow the soldering iron tip to reach normal temperature.

(500 °F to 600 °F) b. Heat the component lead until the solder melts. c. Quickly draw the melted solder with an anti-static, suction-

type solder removal device or with solder braid.

CAUTION: Work quickly to avoid overheating the circuit

board printed foil.

6. Use the following soldering technique. a. Allow the soldering iron tip to reach a normal temperature

(500 °F to 600 °F)

b. First, hold the soldering iron tip and solder the strand

against the component lead until the solder melts.

c. Quickly move the soldering iron tip to the junction of the

component lead and the printed circuit foil, and hold it there only until the solder ows onto and around both the component lead and the foil. CAUTION: Work quickly to avoid overheating the circuit board printed foil.

d. Closely inspect the solder area and remove any excess or

splashed solder with a small wire-bristle brush.

Only for training and service purposes

- 4 -

IC Remove/Replacement

Some chassis circuit boards have slotted holes (oblong) through which the IC leads are inserted and then bent at against the circuit foil. When holes are the slotted type, the following technique should be used to remove and replace the IC. When working with boards using the familiar round hole, use the standard technique as outlined in paragraphs 5 and 6 above.

Removal

1. Desolder and straighten each IC lead in one operation by gently prying up on the lead with the soldering iron tip as the solder melts.

2. Draw away the melted solder with an anti-static suction-type solder removal device (or with solder braid) before removing the IC.

Replacement

1. Carefully insert the replacement IC in the circuit board.

2. Carefully bend each IC lead against the circuit foil pad and solder it.

3. Clean the soldered areas with a small wire-bristle brush. (It is not necessary to reapply acrylic coating to the areas).

"Small-Signal" Discrete Transistor Removal/Replacement

1. Remove the defective transistor by clipping its leads as close as possible to the component body.

2. Bend into a "U" shape the end of each of three leads remaining on the circuit board.

3. Bend into a "U" shape the replacement transistor leads.

4. Connect the replacement transistor leads to the corresponding leads extending from the circuit board and crimp the "U" with long nose pliers to insure metal to metal contact then solder each connection.

Power Output, Transistor Device Removal/Replacement

1. Heat and remove all solder from around the transistor leads.

2. Remove the heat sink mounting screw (if so equipped).

3. Carefully remove the transistor from the heat sink of the circuit board.

4. Insert new transistor in the circuit board.

5. Solder each transistor lead, and clip off excess lead.

6. Replace heat sink.

Diode Removal/Replacement

1. Remove defective diode by clipping its leads as close as possible to diode body.

2. Bend the two remaining leads perpendicular y to the circuit board.

3. Observing diode polarity, wrap each lead of the new diode around the corresponding lead on the circuit board.

4. Securely crimp each connection and solder it.

5. Inspect (on the circuit board copper side) the solder joints of the two "original" leads. If they are not shiny, reheat them and if necessary, apply additional solder.

3. Solder the connections. CAUTION: Maintain original spacing between the replaced component and adjacent components and the circuit board to prevent excessive component temperatures.

Circuit Board Foil Repair

Excessive heat applied to the copper foil of any printed circuit board will weaken the adhesive that bonds the foil to the circuit board causing the foil to separate from or "lift-off" the board. The following guidelines and procedures should be followed whenever this condition is encountered.

At IC Connections

To repair a defective copper pattern at IC connections use the following procedure to install a jumper wire on the copper pattern side of the circuit board. (Use this technique only on IC connections).

1. Carefully remove the damaged copper pattern with a sharp knife. (Remove only as much copper as absolutely necessary).

2. carefully scratch away the solder resist and acrylic coating (if used) from the end of the remaining copper pattern.

3. Bend a small "U" in one end of a small gauge jumper wire and carefully crimp it around the IC pin. Solder the IC connection.

4. Route the jumper wire along the path of the out-away copper pattern and let it overlap the previously scraped end of the good copper pattern. Solder the overlapped area and clip off any excess jumper wire.

At Other Connections

Use the following technique to repair the defective copper pattern at connections other than IC Pins. This technique involves the installation of a jumper wire on the component side of the circuit board.

1. Remove the defective copper pattern with a sharp knife. Remove at least 1/4 inch of copper, to ensure that a hazardous condition will not exist if the jumper wire opens.

2. Trace along the copper pattern from both sides of the pattern break and locate the nearest component that is directly connected to the affected copper pattern.

3. Connect insulated 20-gauge jumper wire from the lead of the nearest component on one side of the pattern break to the lead of the nearest component on the other side. Carefully crimp and solder the connections. CAUTION: Be sure the insulated jumper wire is dressed so the it does not touch components or sharp edges.

Fuse and Conventional Resistor Removal/Replacement

1. Clip each fuse or resistor lead at top of the circuit board hollow stake.

2. Securely crimp the leads of replacement component around notch at stake top.

Only for training and service purposes

- 5 -

SPECIFICATION

NOTE : Specifications and others are subject to change without notice for improvement

.

1. Application range

This specification is applied to the LED TV used LD53H / LD53J chassis.

2. Requirement for Test

Each part is tested as below without special appointment.

1) Temperature: 25 °C ± 5 °C(77 °F ± 9 °F), CST: 40 °C ± 5 °C

2) Relative Humidity: 65 % ± 10 %

3) Power Voltage : Standard input voltage (AC 100-240 V~, 50/60 Hz) * Standard Voltage of each products is marked by models.

4) Specification and performance of each parts are followed

each drawing and specification by part number in accordance with BOM.

5) The receiver must be operated for about 20 minutes prior to

the adjustment.

3. Test method

1) Performance: LGE TV test method followed

2) Demanded other specification

- Safety : CE, IEC specification

- EMC : CE, IEC specification

4. Model General Specification

No. Item Specication Remarks

DTV & Analog (Total 37 countries)

DTV (MPEG2/4, DVB-T) : 26 countrie

Germany, Netherland, Switzerland, Hungary, Austria, Slovenia, Bulgaria, France, Spain, Belgium, Luxemburg, Greece, Czech, Turkey, Morocco, Ireland, Latvia, Estonia, Lithuania, Poland, Portugal, Romania, Albania, Bosnia, Slovakia, Belarus

1 Market EU/CIS(PAL Market-37Countries)

DTV (MPEG2/4, DVB-T2) :11 countries

UK(Ireland), Sweden, Denmark, Finland, Norway, Ukraine, Kazakhstan, Russia, Italy, Croatia, Serbia

DTV (MPEG2/4, DVB-C) : 37 countries

Germany, Netherland, Switzerland, Hungary, Austria, Slovenia, Bulgaria, France, Spain, Italy, Belgium, Russia, Luxemburg, Greece, Czech, Croatia, Turkey, Morocco, Ireland, Latvia, Estonia, Lithuania, Poland, Portugal, Romania, Albania, Bosnia, Serbia, Slovakia, Belarus, UK, Sweden, Denmark, Finland, Norway, Ukraine, Kazakhstan

DTV (MPEG2/4,DVB-S) : 37 countries

Germany, Netherland, Switzerland, Hungary, Austria, Slovenia, Bulgaria, France, Spain,Belgium, Luxemburg, Greece, Czech, Turkey, Morocco, Ireland, Latvia, Estonia, Lithuania, Poland, Portugal, Romania, Albania, Bosnia, Slovakia, Belarus, UK(Ireland), Sweden, Denmark, Finland, Norway, Ukraine, Kazakhstan,Russia, Italy, Croatia, Serbia

Supported satellite : 35 satellites

ABS1 75.0E, AMOS 4.0W, ASIASAT3S 105.5E, ASTRA 19.2E, ASTRA

23.5E, ASTRA 28.2E, ASTRA 4.8E, ATLANTIC BIRD2 8.0W, ATLANTIC BIRD3 5.0W, BADR 26.0E, DIRECTV-1R 56.0E, EUROBIRD 9A 9.0E, EUROBIRD3 33.0E, EUTELSAT 36 A/B 36.0E,EUTELSAT W2A 10.0E, EUTELSAT W3A 7.0E, EUTELSAT7WA 7.3WEUTELSAT 16.0E, EXPRESS AM1 40.0E, EXPRESS AM3 140.0E, EXPRESS AM33 96.5E, HELLASSAT 39.0E, HISPASAT 1CDE 30.0WHOTBIRD 13.0E, INTELSAT10&7 68.5E, INTELSAT15 85.2E, INTELSAT1R 50.0W, INTELSAT903 33.5W, INTELSAT904 60.0E, NILESAT 7.0W, NSS12 57.0E, THOR 0.8W, TURKSAT 42.0E,YAMAL201 90.0E, OTHER

Only for training and service purposes

- 6 -

No. Item Specication Remarks

2 Broadcasting system

3 Program coverage

4 Receiving system

(1)PAL/SECAM B/G/I/D/K, SECAM L/L’ (2)DVB-T/T2, C, S/S2

(1) Digital TV

- VHF, UHF

- C-Band, Ku-Band

(2) Analogue TV

-VHF : E2 to E12

-UHF : E21 to E69

-CATV : S1 to S20

-HYPER : S21 to S47

Analog : Upper Heterodyne Digital : COFDM, QAM

► DVB-T

- Guard Interval(Bitrate_Mbit/s) 1/4, 1/8, 1/16, 1/32

- Modulation : Code Rate QPSK : 1/2, 2/3, 3/4, 5/6, 7/8 16-QAM : 1/2, 2/3, 3/4, 5/6, 7/8 64-QAM : 1/2, 2/3, 3/4, 5/6, 7/8

► DVB-T2

- Guard Interval(Bitrate_Mbit/s) 1/4, 1/8, 1/16, 1/32, 1/128, 19/128, 19/256,

- Modulation : Code Rate QPSK : 1/2, 2/5, 2/3, 3/4, 5/6 16-QAM : 1/2, 2/5, 2/3, 3/4, 5/6 64-QAM : 1/2, 2/5, 2/3, 3/4, 5/6 256-QAM : 1/2, 2/5, 2/3, 3/4, 5/6

5 Input Voltage AC 100 ~ 240V 50/60Hz

► DVB-C

- Symbolrate : 4.0 Msymbols/s to 7.2 Msymbols/s

- Modulation : 16QAM, 64-QAM, 128-QAM and 256-QAM

► DVB-S/S2

- symbolrate : DVB-S2 (8PSK / QPSK) : 2 ~ 45 Msymbol/s DVB-S (QPSK) : 2 ~ 45 Msymbol/s

- viterbi DVB-S mode : 1/2, 2/3, 3/4, 5/6, 7/8 DVB-S2 mode : 1/2, 2/3, 3/4, 3/5, 4/5, 5/6, 8/9, 9/10

Only for training and service purposes

- 7 -

5. External Input Format

5.1. 2D Mode

(1) Component (Y, CB/PB, CR/PR)

No. Resolution H-freq(kHz) V-freq(Hz) Pixel clock(MHz) Proposed

1 720*480 15.73 60 13.5135 SDTV ,DVD 480I

2 720*480 15.73 59.94 13.5 SDTV ,DVD 480I

3 720*480 31.50 60 27.027 SDTV 480P

4 720*480 31.47 59.94 27.0 SDTV 480P

5 1280*720 45.00 60.00 74.25 HDTV 720P

6 1280*720 44.96 59.94 74.176 HDTV 720P

7 1920*1080 33.75 60.00 74.25 HDTV 1080I

8 1920*1080 33.72 59.94 74.176 HDTV 1080I

9 1920*1080 67.500 60 148.50 HDTV 1080P

10 1920*1080 67.432 59.94 148.352 HDTV 1080P

11 1920*1080 27.000 24.000 74.25 HDTV 1080P

12 1920*1080 26.97 23.976 74.176 HDTV 1080P

13 1920*1080 33.75 30.000 74.25 HDTV 1080P

14 1920*1080 33.71 29.97 74.176 HDTV 1080P

Only for training and service purposes

- 8 -

(2) HDMI(PC/DTV)

1) DTV mode

No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed Remarks

1 640*480 31.46 59.94 25.13 SDTV 480P

2 640*480 31.50 60.00 25.13 SDTV 480P

3 720*480 15.73 59.94 13.50 SDTV, DVD 480I(525I)

Spec. out but display4 720*480 15.75 60.00 13.51 SDTV, DVD 480I(525I)

5 720*576 15.62 50.00 13.50 SDTV, DVD 576I(625I) 50Hz

6 720*480 31.47 59.94 27.00 SDTV 480P

7 720*480 31.50 60.00 27.03 SDTV 480P

8 720*576 31.25 50.00 27.00 SDTV 576P

9 1280*720 44.96 59.94 74.18 HDTV 720P

10 1280*720 45.00 60.00 74.25 HDTV 720P

11 1280*720 37.50 50.00 74.25 HDTV 720P

12 1920*1080 28.12 50.00 74.25 HDTV 1080I

13 1920*1080 33.72 59.94 74.18 HDTV 1080I

14 1920*1080 33.75 60.00 74.25 HDTV 1080I

15 1920*1080 26.97 23.97 63.30 HDTV 1080P

16 1920*1080 27.00 24.00 63.36 HDTV 1080P

17 1920*1080 33.71 29.97 79.12 HDTV 1080P

18 1920*1080 33.75 30.00 79.20 HDTV 1080P

19 1920*1080 56.25 50.00 148.50 HDTV 1080P

20 1920*1080 67.43 59.94 148.35 HDTV 1080P

21 1920*1080 67.50 60.00 148.50 HDTV 1080P

22 3840*2160 53.95 23.98 297.00 UDTV 2160P UHD only

23 3840*2160 54.00 24.00 297.00 UDTV 2160P UHD only

24 3840*2160 56.25 25.00 297.00 UDTV 2160P UHD only

25 3840*2160 61.43 29.97 297.00 UDTV 2160P UHD only

26 3840*2160 67.50 30.00 297.00 UDTV 2160P UHD only

27 3840*2160 112.50 50.00 594.00 UDTV 2160P(DVB)

28 3840*2160 135.00 59.94 593.41 UDTV 2160P

29 3840*2160 135.00 60.00 594.00 UDTV 2160P

30 4096*2160 53.95 23.98 297.00 UDTV 2160P UHD only

31 4096*2160 54.00 24.00 297.00 UDTV 2160P UHD only

32 4096*2160 56.25 25.00 297.00 UDTV 2160P UHD only

33 4096*2160 61.43 29.97 297.00 UDTV 2160P UHD only

34 4096*2160 67.50 30.00 297.00 UDTV 2160P UHD only

35 4096*2160 112.50 50.00 594.00 UDTV 2160P(DVB)

36 4096*2160 135.00 59.94 593.41 UDTV 2160P

37 4096*2160 135.00 60.00 594.00 UDTV 2160P

UHD only(Port1,2)-LM15U Only

Only for training and service purposes

- 9 -

2) PC mode

No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed Remarks

1 640*350 31.46 70.09 25.17 EGA

2 720*400 31.46 70.08 28.32 DOS

3 640*480 31.46 59.94 25.17 VESA(VGA)

4 800*600 37.87 60.32 40.00 VESA(SVGA)

5 1024*768 48.36 60.00 65.00 VESA(XGA)

6 1152*864 54.34 60.05 80.00 VESA

7 1280*1024 63.98 60.02 109.00 VESA(SXGA) FHD only

8 1360*768 47.71 60.01 85.00 VESA(WXGA)

9 1920*1080 67.50 60.00 158.40 WUXGA(CEA 861D) FHD only

10 3840*2160 67.50 30.00 297.00 UDTV 2160P UHD only

11 3840*2160 56.25 25.00 297.00 UDTV 2160P UHD only

12 3840*2160 54.00 24.00 297.00 UDTV 2160P UHD only

13 4096*2160 53.95 23.97 296.703 UDTV 2160P UHD only

14 4096*2160 54.00 24.00 297.00 UDTV 2160P UHD only

6.1. 3D Mode

(1) RF Input

No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed Remarks

1 1280*720 37.500 50 74.25 HDTV 720P 2D to 3D, Side by Side, Top & Bottom

2 1920*1080 28.125 50 74.25 HDTV 1080I 2D to 3D, Side by Side, Top & Bottom

Only for training and service purposes

- 10 -

(2) HDMI Input (3D Supported mode manually)

No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) VIC 3D input proposed mode Proposed

1 640*480

2 720*480

3 720*576

4 1280*720

5 1920*1080

31.469 / 31.5 59.94/ 60 25.125/25.2 1

31.469 / 31.5 59.94/ 60 50.35/50.4 1 Side-by-side(Full) (SDTV 480P)

62.938/63 59.94/ 60 50.35/50.4 1

31.469 / 31.5 59.94 / 60 27.00/27.03 2,3

31.469 / 31.5 59.94 / 60 54/54.06 2,3 Side-by-side(Full) (SDTV 480P)

62.938/63 59.94 / 60 54/54.06 2,3

31.25 50 27 17,18

31.25 50 54 17,18 Side-by-side(Full) (SDTV 576P)

62.5 50 54 17,18

15.625 50 27 21

37.50 50 74.25 19

37.50 50 148.5 19 Side-by-side(Full) (HDTV 720P)

44.96 / 45 59.94 / 60 74.17/74.25 4

44.96 / 45 59.94 / 60 148.35/148.5 4 Side-by-side(Full) (HDTV 720P)

75.00 50.00 148.50 19

89.91/90 59.94 / 60 148.35/148.5 4

28.12 50.00 74.25 20

28.12 50.00 148.50 20 Side-by-side(Full) (HDTV 1080I)

33.72 / 33.75 59.94 / 60.00 74.17/74.25 5

33.72 / 33.75 59.94 / 60.00 148.35/148.50 5 Side-by-side(Full) (HDTV 1080I)

56.25 50.00 148.50 20

67.43/67.50 59.94 / 60.00 148.35/148.50 5

26.97 / 27.00 23.97 / 24.00 74.17 / 74.25 32

26.97 / 27.00 23.97 / 24.00 148.35 / 148.50 32 Side-by-side(Full) (HDTV 1080P)

28.12 25.00 74.25 33

28.12 25.00 148.50 33 Side-by-side(Full) (HDTV 1080P)

33.71 / 33.75 29.97 / 30.00 74.18/74.25 34 Side-by-side(Full) (HDTV 1080P)

33.71 / 33.75 29.97 / 30.00 148.35/148.50 34

43.94/54.00 23.97 / 24.00 148.35/148.50 32

56.25 25.00 148.50 33

67.43 / 67.5 29.97 / 30.00 148.35/148.50 34

56.25 50.00 148.50 31

67.43 / 67.50 59.94 / 60.00 148.35/148.50 16

Top-and-Bottom Side-by-side(half)

Frame packing Line alternative

Top-and-Bottom Side-by-side(half)

Frame packing Line alternative

Top-and-Bottom Side-by-side(half)

Frame packing Line alternative

Frame packing Field alternative Side-by-side(Full) Top-and-Bottom Side-by-side(half)

Top-and-Bottom Side-by-side(half)

Frame packing Line alternative

Top-and-Bottom Side-by-side(half)

Frame packing Line alternative

Top-and-Bottom Side-by-side(half)

Frame packing Field alternative

Top-and-Bottom Side-by-side(half)

Frame packing Line alternative

Top-and-Bottom Side-by-side(half)

Secondary(SDTV 480P) Secondary(SDTV 480P)

Secondary(SDTV 480P) (SDTV 480P)

Secondary(SDTV 480P) Secondary(SDTV 480P)

Secondary(SDTV 480P) (SDTV 480P)

Secondary(SDTV 576P) Secondary(SDTV 576P)

Secondary(SDTV 576P) (SDTV 576P)

Secondary(SDTV 576I) (SDTV 576I (SDTV 576I Secondary(SDTV 576I) Secondary(SDTV 576I)

Primary(HDTV 720P) Primary(HDTV 720P)

Primary(HDTV 720P) (HDTV 720P)

Primary(HDTV 720P) Primary(HDTV 720P)

Primary(HDTV 720P) (HDTV 720P)

Secondary(HDTV 1080I) Primary(HDTV 1080I)

Primary(HDTV 1080I) (HDTV 1080I)

Primary(HDTV 1080P) Primary(HDTV 1080P)

Secondary(HDTV 1080P) Secondary(HDTV 1080P)

Primary(HDTV 1080P) (HDTV 1080P)

Secondary(HDTV 1080P) (HDTV 1080P)

Primary(HDTV 1080P) (HDTV 1080P)

Primary(HDTV 1080P) Secondary(HDTV 1080P)

Only for training and service purposes

- 11 -

(3) DTV(3D) (3D supported mode automatically)

No. Signal H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode

1 Frame compatible 48.36 60 65 HDTV 768P Side by Side(half), Top & Bottom

(4) DTV/ATV(CVBS/SCART) Input(3D) (3D supported mode manually)

No. Signal H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode

1 HD/SD 48.36 60 65 HDTV 768P

2 SD Side by Side(half), Top & Bottom

(5) Component Input (3D) (3D Supported mode manually)

No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode

1 1280*720 37.50 50.00 74.25 HDTV 720P 2D to 3D, Side by Side(half), Top & Bottom

2 1280*720 45.00 60.00 74.25 HDTV 720P 2D to 3D, Side by Side(half), Top & Bottom

3 1280*720 44.96 59.94 74.18 HDTV 720P 2D to 3D, Side by Side(half), Top & Bottom

4 1920*1080 33.75 60.00 74.25 HDTV 1080I 2D to 3D, Side by Side(half), Top & Bottom

5 1920*1080 33.72 59.94 74.18 HDTV 1080I 2D to 3D, Side by Side(half), Top & Bottom

6 1920*1080 28.12 50.00 74.25 HDTV 1080I 2D to 3D, Side by Side(half), Top & Bottom

7 1920*1080 67.50 60.00 148.50 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom

8 1920*1080 67.43 59.94 148.35 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom

9 1920*1080 27.00 24.00 74.25 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom

10 1920*1080 28.12 25.00 74.25 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom

11 1920*1080 56.25 50.00 74.25 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom

12 1920*1080 26.97 23.97 74.18 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom

13 1920*1080 33.75 30.00 74.25 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom

14 1920*1080 33.71 29.97 74.18 HDTV 1080P 2D to 3D, Side by Side(half), Top & Bottom

2D to 3D, Side by Side(half) Top & Bottom

(6) HDMI-PC Input (3D) (3D supported mode manually)

No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode

1 1024*768 48.36 60.00 65.00 HDTV 768P

2 1360*768 47.71 60.00 HDTV 768P

3 1920*1080 67.50 60.00 148.50 HDTV 1080P

3840*2160

4

(Ultea HD model only)

4096*2160

5

(Ultea HD model only)

6 Others - - -

54.00 24.00 296.70

56.25 25.00 297.00

67.50 30.00 296.70

54 24.00 297.00 HDTV 2160P

HDTV 2160P

640*350 720*400 640*480 800*600 1152*864

- 12 -

Only for training and service purposes

2D to 3D, Side by Side(half), Top & Bottom

2D to 3D, Side by Side(half), Top & Bottom, Checker Board, Frame Sequential, Row Interleaving, Column Interleaving

2D to 3D, Top & Bottom(half) Side by Side(half)

2D to 3D, Side by Side(half), Top & Bottom

(7) HDMI-DTV (3D supported mode manually)

No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed 3D input proposed mode

1 720*480 31.50 60.00 27.03 SDTV 480P

2

720*576

3 37.50 50.00 74.25 HDTV 720P

4 1920*1080

5 1920*1080

3840*2160 4096*2160

6

(Ultra HD model only)

31.25 50.00 27.00 SDTV 576P

33.75 60.00 74.25 HDTV 1080I

28.12 50.00 74.25 HDTV 1080I

27.00 24.00 74.25 HDTV 1080P

28.12 25.00 74.25 HDTV 1080P

33.75 30.00 74.25 HDTV 1080P

67.50 60.00 148.50 HDTV 1080P

56.25 50.00 148.50 HDTV 1080P

53.95 23.97 297.00

54.00 24.00 296.70

56.25 25.00 297.00

61.43 29.97 297.00

67.50 30.00 296.70

112.50

135.00

50.00(HDMI1, HDMI2 Only)

60.00(HDMI1, HDMI2 Only)

594.00

HDTV 2160P

HDTV 2160P 2D to 3D, Side by Side(half), Top & Bottom

2D to 3D, Side by Side(Half), Top & Bottom, Checker Board, Frame Sequential, Row Interleaving, Column Interleaving

2D to 3D, Side by Side(Half), Top & Bottom

2D to 3D, Side by Side(Half), Top & Bottom, Checker Board, Row Interleaving, Column Interleaving

2D to 3D, Side by Side(Half), Top & Bottom, Checker Board, Single Frame Sequential, Row Interleaving, Column Interleaving

2D to 3D, Top & Bottom(half), Side by Side(half)

(8) USB - Movie (3D) (3D supported mode manually)

No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode

1 Under 704x480 - - - 2D to 3D

Over 704x480

2

Under 1080P interlaced

Over 704x480

3

Under 1080P progressive

4 Over 2160P - 24/25/30/50/60 - 2D to 3D, Side by Side(Half), Top & Bottom

(9) USB, DLNA -Photo (3D) (3D supported mode manually)

No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode

1 USB(photo) - - - 2D to 3D, Side by Side(Half), Top & Bottom

- - - 2D to 3D, Side by Side(Half), Top & Bottom

2D to 3D, Side by Side(Half), Top & Bottom, Checker

- 50 / 60 -

- others -

Board, Row Interleaving, Column Interleaving, Frame Sequential

2D to 3D, Side by Side(Half), Top & Bottom, Checker Board, Row Interleaving, Column Interleaving

Only for training and service purposes

- 13 -

(10) Miracast Intel WIDI (3D supported mode manually)

No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode

1 1024*768p - 30/60 -

2D to 3D, Side by Side(Half), Top & Bottom2 1280*720p - 30/60 -

3 1920*1080p - 30/60 -

4 Others - - - 2D to 3D

(11) USB, DLNA (3D) (3D supported mode automatically)

No. Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed mode

1 1080p 33.75 30 74.25 Side by Side(Half), Top & Bottom, Checker Board

2 2160p 67.5 30 297 MPO(Photo), JPS(Photo)

■ Remark: 3D Input mode

No. Side by Side Top & Bottom Checker board

Single Frame

Sequential

Frame

Packing

Row

Interleaving

Column

Interleaving

2D to 3D

1

ii.

iii.

iv.

v.

vi.

Only for training and service purposes

- 14 -

ADJUSTMENT INSTRUCTION

1. Application Range

This specification sheet is applied to all of the LED TV with LD53H / LD53J chassis.

2. Designation

(1) Because this is not a hot chassis, it is not necessary to

use an isolation transformer. However, the use of isolation

transformer will help protect test instrument. (2) Adjustment must be done in the correct order. (3) The adjustment must be performed in the circumstance of

25 °C ± 5 °C of temperature and 65 % ± 10 % of relative

humidity if there is no specific designation. (4) The input voltage of the receiver must keep AC 100-240

V~, 50/60 Hz. (5) The receiver must be operated for about 5 minutes prior to

the adjustment when module is in the circumstance of over

15.

In case of keeping module is in the circumstance of 0 °C, it should be placed in the circumstance of above 15 °C for 2 hours.

In case of keeping module is in the circumstance of below

-20 °C, it should be placed in the circumstance of above 15 °C for 3 hours.

[Caution] When still image is displayed for a period of 20 minutes or longer (Especially where W/B scale is strong. Digital pattern 13ch and/or Cross hatch pattern 09ch), there can some afterimage in the black level area.

3.2. LAN Inspection

3.2.1. Equipment & Condition

▪ Each other connection to LAN Port of IP Hub and Jig

3.2.2. LAN inspection solution

▪ LAN Port connection with PCB ▪ Network setting at MENU Mode of TV ▪ setting automatic IP ▪ Setting state confirmation

- If automatic setting is finished, you confirm IP and MAC Address.

3.2.3. WIDEVINE key Inspection

- Confirm key input data at the "IN START" MENU Mode.



3. Automatic Adjustment

3.1. MAC address D/L, CI+ key D/L, Widevine key D/L, ESN D/L, HDCP2.0 D/L

Connect: USB port Communication Prot connection

▪ Com 1,2,3,4 and 115200(Baudrate)

Mode check: Online Only

▪ Check the test process: DETECT → MAC → CI → Widevine

→ ESN → HDCP20 ▪ Play: Press Enter key ▪ Result: Ready, Test, OK or NG ▪ Printer Out (MAC Address Label)

Only for training and service purposes

- 15 -

3.3. LAN PORT INSPECTION(PING TEST)

Connect SET → LAN port == PC → LAN Port

SET PC

3.3.1. Equipment setting

(1) Play the LAN Port Test PROGRAM. (2) Input IP set up for an inspection to Test Program.

*IP Number : 12.12.2.2

3.3.2. LAN PORT inspection(PING TEST)

(1) Play the LAN Port Test Program. (2) Connect each other LAN Port Jack. (3) Play Test (F9) button and confirm OK Message. (4) Remove LAN cable.

3.4. Model name & Serial number Download

3.4.1. Model name & Serial number D/L

▪ Press "P-ONLY" key of service remote control.

(Baud rate : 115200 bps)

▪ Connect RS-232C Signal to USB Cable to USB. ▪ Write Serial number by use USB port. ▪ Must check the serial number at Instart menu.

3.4.2. Method & notice

(1) Serial number D/L is using of scan equipment. (2) Setting of scan equipment operated by Manufacturing

Technology Group.

(3) Serial number D/L must be conformed when it is produced

in production line, because serial number D/L is mandatory by D-book 4.0.

* Manual Download (Model Name and Serial Number)

If the TV set is downloaded by OTA or service man, sometimes

model name or serial number is initialized.(Not always)

It is impossible to download by bar code scan, so It need

Manual download.

1) Press the "Instart" key of Adjustment remote control.

2) Go to the menu "7.Model Number D/L" like below photo.

3) Input the Factory model name(ex 47LB650V-ZA) or Serial number like photo.

3.5. CI+ Key checking method

- Check the Section 3.1 Check whether the key was downloaded or not at ‘In Start’ menu. (Refer to below).

=> Check the Download to CI+ Key value in LGset.

3.5.1. Check the method of CI+ Key value

(1) Check the method on Instart menu (2) Check the method of RS232C Command

1) Into the main ass’y mode(RS232: aa 00 00)

CMD 1 CMD 2 Data 0

A A 0 0

2) Check the key download for transmitted command (RS232: ci 00 10)

CMD 1 CMD 2 Data 0

C I 1 0

3) Result value

- Normally status for download : OKx

- Abnormally status for download : NGx

3.5.2. Check the method of CI+ key value(RS232)

1) Into the main ass’y mode(RS232: aa 00 00)

CMD 1 CMD 2 Data 0

A A 0 0

2) Check the mothed of CI+ key by command (RS232: ci 00 20)

CMD 1 CMD 2 Data 0

C I 2 0

3) Result value i 01 OK 1d1852d21c1ed5dcx

CI+ Key Value

3.6. WIFI MAC ADDRESS CHECK

(1) Using RS232 Command

H-freq(kHz) V-freq.(Hz)

Transmission [A][I][][Set ID][][20][Cr] [O][K][X] or [NG]

(2) Check the menu on in-start

4) Check the model name Instart menu. → Factory name

displayed. (ex 47LB650V-ZA)

5) Check the Diagnostics.(DTV country only) → Buyer

model displayed. (ex 47LB650V-ZA)

Only for training and service purposes

- 16 -

4. Manual Adjustment

* ADC adjustment is not needed because of OTP(Auto ADC

adjustment)

4.1. EDID(The Extended Display Identification Data)/DDC(Display Data Channel) download

4.1.1. Overview

It is a VESA regulation. A PC or a MNT will display an optimal resolution through information sharing without any necessity of user input. It is a realization of "Plug and Play".

4.1.2. Equipment

- Since embedded EDID data is used, EDID download JIG, HDMI cable and D-sub cable are not need.

- Adjustment remote control

4.1.3. Download method

(1) Press "ADJ" key on the Adjustment remote control, then

select "12.EDID D/L", By pressing "Enter" key, enter EDID D/L menu.

For HDMI EDID

DVI-D to HDMI or HDMI to HDMI

(2) Select "Start" button by pressing "Enter" key, HDMI1/

HDMI2/ HDMI3/ HDMI4 are writing and display OK or NG.

4.1.4. EDID DATA

▪ Reference

- HDMI1 ~ HDMI3

- In the data of EDID, bellows may be different by Input mode.

0 1 2 3 4 5 6 7 8 9 A B C D E F

0x00 00 FF FF FF FF FF FF 00 1E 6D

ⓒ

0x01 0x02 0F 50 54 A1 8 00 31 40 45 40 61 40 71 40 81 80 0x03 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 0x04 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30 0x05 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A 0x06 3E 1E 53 10 00 0A 20 20 20 20 20 20 0x07 0x00 02 03 3A F1 4E 10 9F 04 13 05 14 03 02 12 20 21 0x01 22 15 01 29 3D 06 C0 15 07 50 0x02 0x03 0x04 2D 40 58 2C 45 00 40 84 63 00 00 1E 01 1D 80 18 0x05 71 1C 16 20 58 2C 25 00 40 84 63 00 00 9E 01 1D 0x06 00 72 51 D0 1E 20 6E 28 55 00 40 84 63 00 00 1E 0x07 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00

01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26

ⓓ

ⓕ

10 28 10 E3 05 03 01 02 3A 80 18 71 38

ⓕ

ⓐ Product ID ⓑ Serial No: Controlled on production line. ⓒ Month, Year: Controlled on production line:

ex) Monthly : ‘01’ → ‘01’, Year : ‘2015’ → ‘19’

ⓓ Model Name(Hex): LGTV ⓔ Checksum(LG TV): Changeable by total EDID data. ⓕ Vendor Specific(HDMI)

ⓐ ⓑ

ⓕ

ⓓ

ⓔ1

01

ⓔ2

(1) EDID for 2D Model

1) DTS # HDMI 1(C/S : A0 C7) - HDMI UHD Deep On Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58 40 8 A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40 50 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3 A 60 3E 1E 88 3C 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 A0

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 47 F1 58 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 60 61 5D 5E 5F 65 66 62 63 64 29 3D 06 A0 C0 15 07 50 09 57 07 6E 03 0C 00 10 00 B8 3C 20 B0 00 80 01 02 03 04 67 D8 5D C4 01 78 80 03 E3 05

C0 C0 00 E4 0F 00 C0 18 66 21 50 B0 51 00 1B 30 40 D0 70 36 00 40 84 63 00 00 1E 01 1D 00 72 51 D0 1E E0 20 6E 28 55 00 40 84 63 00 00 1E 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 C7

# HDMI 1(C/S : E6 1D) - HDMI UHD Deep Off Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30 50 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A 60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E6

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 38 F1 54 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 5D 5E 5F 62 63 64 29 3D 06 C0 15 07 50 A0 09 57 07 6E 03 0C 00 10 00 B8 3C 20 00 80 01 02 B0 03 04 E5 0E 60 61 65 66 01 1D 80 18 71 1C 16 20 C0 58 2C 25 00 40 84 63 00 00 9E 01 1D 00 72 51 D0 D0 1E 20 6E 28 55 00 40 84 63 00 00 1E 00 00 00 00 E0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 1D

# HDMI 2(C/S : A0 B7) - HDMI UHD Deep On Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58 40 8A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40 50 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3 A 60 3E 1E 88 3C 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 A0

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 47 F1 58 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 60 61 5D 5E 5F 65 66 62 63 64 29 3D 06

A0 C0 15 07 50 09 57 07 6E 03 0C 00 20 00 B8 3C 20 B0 00 80 01 02 03 04 67 D8 5D C4 01 78 80 03 E3 05 C0 C0 00 E4 0F 00 C0 18 66 21 50 B0 51 00 1B 30 40 D0 70 36 00 40 84 63 00 00 1E 01 1D 00 72 51 D0 1E E0 20 6E 28 55 00 40 84 63 00 00 1E 00 00 00 00 00 70 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 B7

Only for training and service purposes

- 17 -

# HDMI 2(C/S : E6 0D) - HDMI UHD Deep Off Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30 50 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A 60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E6

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 38 F1 54 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 5D 5E 5F 62 63 64 29 3D 06 C0 15 07 50 A0 09 57 07 6E 03 0C 00 20 00 B8 3C 20 00 80 01 02 B0 03 04 E5 0E 60 61 65 66 01 1D 80 18 71 1C 16 20 C0 58 2C 25 00 40 84 63 00 00 9E 01 1D 00 72 51 D0 D0 1E 20 6E 28 55 00 40 84 63 00 00 1E 00 00 00 00 E0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 0D

# HDMI 3(C/S : E6 FD) - HDMI UHD Deep Off Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30 50 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A 60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E6

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 38 F1 54 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 5D 5E 5F 62 63 64 29 3D 06 C0 15 07 50 A0 09 57 07 6E 03 0C 00 30 00 B8 3C 20 00 80 01 02 B0 03 04 E5 0E 60 61 65 66 01 1D 80 18 71 1C 16 20 C0 58 2C 25 00 40 84 63 00 00 9E 01 1D 00 72 51 D0 D0 1E 20 6E 28 55 00 40 84 63 00 00 1E 00 00 00 00 E0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 FD

* Checksum(HDMI 1/2/3)

Input

HDMI1 A0 C7 E6 1D

HDMI2 A0 B7 E6 0D

HDMI3 E6 FD E6 FD

HDMI Deep Color On

FFh (Checksum)

HDMI Deep Color Off

FFh (Checksum)

2) AC3 # HDMI 1(C/S : A0 D0) - HDMI UHD Deep On Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58 40 8A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40 50 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3 A 60 3E 1E 88 3C 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 A0

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 44 F1 58 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 60 61 5D 5E 5F 65 66 62 63 64 26 15 07 A0 50 09 57 07 6E 03 0C 00 10 00 B8 3C 20 00 80 01 B0 02 03 04 67 D8 5D C4 01 78 80 03 E3 05 C0 00 E4 C0 0F 00 C0 18 66 21 50 B0 51 00 1B 30 40 70 36 00 D0 40 84 63 00 00 1E 01 1D 00 72 51 D0 1E 20 6E 28 E0 55 00 40 84 63 00 00 1E 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 D0

# HDMI 1(C/S : E6 26) – HDMI UHD Deep Off Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30 50 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A 60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E6

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 35 F1 54 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 5D 5E 5F 62 63 64 26 15 07 50 09 57 07 A0 6E 03 0C 00 10 00 B8 3C 20 00 80 01 02 03 04 E5 B0 0E 60 61 65 66 01 1D 80 18 71 1C 16 20 58 2C 25 C0 00 40 84 63 00 00 9E 01 1D 00 72 51 D0 1E 20 6E D0 28 55 00 40 84 63 00 00 1E 00 00 00 00 00 00 00 E0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 26

# HDMI 2(C/S : A0 C0) - HDMI UHD Deep On Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58 40 8A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40 50 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3 A 60 3E 1E 88 3C 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 A0

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 44 F1 58 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 60 61 5D 5E 5F 65 66 62 63 64 26 15 07 A0 50 09 57 07 6E 03 0C 00 20 00 B8 3C 20 00 80 01 B0 02 03 04 67 D8 5D C4 01 78 80 03 E3 05 C0 00 E4 C0 0F 00 C0 18 66 21 50 B0 51 00 1B 30 40 70 36 00 D0 40 84 63 00 00 1E 01 1D 00 72 51 D0 1E 20 6E 28 E0 55 00 40 84 63 00 00 1E 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 C0

Only for training and service purposes

- 18 -

# HDMI 2(C/S : E6 16) - HDMI UHD Deep off Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30 50 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A 60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E6

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 35 F1 54 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 5D 5E 5F 62 63 64 26 15 07 50 09 57 07 A0 6E 03 0C 00 20 00 B8 3C 20 00 80 01 02 03 04 E5 B0 0E 60 61 65 66 01 1D 80 18 71 1C 16 20 58 2C 25 C0 00 40 84 63 00 00 9E 01 1D 00 72 51 D0 1E 20 6E D0 28 55 00 40 84 63 00 00 1E 00 00 00 00 00 00 00 E0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 16

# HDMI 3(C/S : E6 06) - HDMI UHD Deep off Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30 50 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A 60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E6

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 35 F1 54 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 5D 5E 5F 62 63 64 26 15 07 50 09 57 07 A0 6E 03 0C 00 30 00 B8 3C 20 00 80 01 02 03 04 E5 B0 0E 60 61 65 66 01 1D 80 18 71 1C 16 20 58 2C 25 C0 00 40 84 63 00 00 9E 01 1D 00 72 51 D0 1E 20 6E D0 28 55 00 40 84 63 00 00 1E 00 00 00 00 00 00 00 E0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 06

* Checksum(HDMI 1/2/3)

Input

HDMI1 A0 D0 E6 26

HDMI2 A0 C0 E6 16

HDMI3 E6 06 E6 06

HDMI Deep Color On

FFh (Checksum)

HDMI Deep Color Off

FFh (Checksum)

3) PCM # HDMI 1(C/S : A0 42) - HDMI UHD Deep On Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58 40 8A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40 50 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3 A 60 3E 1E 88 3C 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 A0

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 41 F1 58 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 60 61 5D 5E 5F 65 66 62 63 64 23 09 57 A0 07 6E 03 0C 00 10 00 B8 3C 20 00 80 01 02 03 04 B0 67 D8 5D C4 01 78 80 03 E3 05 C0 00 E4 0F 00 C0 C0 18 66 21 50 B0 51 00 1B 30 40 70 36 00 40 84 63 D0 00 00 1E 01 1D 00 72 51 D0 1E 20 6E 28 55 00 40 E0 84 63 00 00 1E 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 42

# HDMI 1(C/S : E6 98) - HDMI UHD Deep off case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 40 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30 50 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A 60 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E6

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 32 F1 54 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 5D 5E 5F 62 63 64 23 09 57 07 6E 03 0C A0 00 10 00 B8 3C 20 00 80 01 02 03 04 E5 0E 60 61 B0 65 66 01 1D 80 18 71 1C 16 20 58 2C 25 00 40 84 C0 63 00 00 9E 01 1D 00 72 51 D0 1E 20 6E 28 55 00 D0 40 84 63 00 00 1E 00 00 00 00 00 00 00 00 00 00 E0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 98

# HDMI 2(C/S : A0 32) - HDMI UHD Deep On Case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F

0 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 10 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 20 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 30 01 01 01 01 01 01 08 E8 00 30 F2 70 5A 80 B0 58 40 8A 00 40 84 63 00 00 1E 02 3A 80 18 71 38 2D 40 50 58 2C 45 00 40 84 63 00 00 1E 00 00 00 FD 00 3 A 60 3E 1E 88 3C 00 0A 20 20 20 20 20 20 00 00 00 FC 70 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 A0

Only for training and service purposes

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 41 F1 58 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 60 61 5D 5E 5F 65 66 62 63 64 23 09 57 A0 07 6E 03 0C 00 20 00 B8 3C 20 00 80 01 02 03 04 B0 67 D8 5D C4 01 78 80 03 E3 05 C0 00 E4 0F 00 C0 C0 18 66 21 50 B0 51 00 1B 30 40 70 36 00 40 84 63 D0 00 00 1E 01 1D 00 72 51 D0 1E 20 6E 28 55 00 40 E0 84 63 00 00 1E 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 32

- 19 -

# HDMI 2(C/S : E6 88) - HDMI UHD Deep off case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 00 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 01 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 0F 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 01 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 45 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30 40 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A 3E 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC 00 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E6

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 32 F1 54 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 5D 5E 5F 62 63 64 23 09 57 07 6E 03 0C A0 00 20 00 B8 3C 20 00 80 01 02 03 04 E5 0E 60 61 B0 65 66 01 1D 80 18 71 1C 16 20 58 2C 25 00 40 84 C0 63 00 00 9E 01 1D 00 72 51 D0 1E 20 6E 28 55 00 D0 40 84 63 00 00 1E 00 00 00 00 00 00 00 00 00 00 E0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 88

# HDMI 3(C/S : E6 78) - HDMI UHD Deep off case EDID Block 0, Bytes 0-127 [00H-7FH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 00 00 FF FF FF FF FF FF 00 1E 6D 01 00 01 01 01 01 01 01 19 01 03 80 A0 5A 78 0A EE 91 A3 54 4C 99 26 0F 0F 50 54 A1 08 00 31 40 45 40 61 40 71 40 81 80 01 01 01 01 01 01 01 02 3A 80 18 71 38 2D 40 58 2C 45 45 00 40 84 63 00 00 1E 66 21 50 B0 51 00 1B 30 40 40 70 36 00 40 84 63 00 00 1E 00 00 00 FD 00 3A 3E 3E 1E 53 10 00 0A 20 20 20 20 20 20 00 00 00 FC 00 00 4C 47 20 54 56 0A 20 20 20 20 20 20 20 01 E6

EDID Block 1, Bytes 128-255 [80H-FFH]

0 1 2 3 4 5 6 7 8 9 A B C D E F 80 02 03 32 F1 54 10 9F 04 13 05 14 03 02 12 20 21 90 22 15 01 5D 5E 5F 62 63 64 23 09 57 07 6E 03 0C A0 00 30 00 B8 3C 20 00 80 01 02 03 04 E5 0E 60 61 B0 65 66 01 1D 80 18 71 1C 16 20 58 2C 25 00 40 84 C0 63 00 00 9E 01 1D 00 72 51 D0 1E 20 6E 28 55 00 D0 40 84 63 00 00 1E 00 00 00 00 00 00 00 00 00 00 E0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 F0 00 00 00 00 00 00 00 00 00 00 00 00 00 00 00 78

* Checksum(HDMI 1/2/3)

Input

HDMI1 A0 42 E6 98

HDMI2 A0 32 E6 88

HDMI3 E6 78 E6 78

HDMI Deep Color On

FFh (Checksum)

HDMI Deep Color Off

FFh (Checksum)

4.1.5. Green Eye Inspection Guide

Step 1) Turn on the TV set. Step 2). Press “EYE” button on the Adjustment remote control.



Step 3) Block the Intelligent Sensor module on the front C/A

about 6 seconds. When the “Sensor Data” is lower than 20, you can see the “OK” message

→ If it doesn’t show “OK” message, the Sensor

Module is defected one. You have to replace that with a good one.



Step 4) After check the “OK” message come out, take out

your hand from the Sensor module.

→ Check “Backlight” value change from “0” to “100” or

not. If it doesn’t change the value, the sensor is also defected one. You have to replace it.

4.2. White Balance Adjustment

4.2.1. Overview

▪ W/B adj. Objective & How-it-works

(1) Objective: To reduce each Panel's W/B deviation (2) How-it-works : When R/G/B gain in the OSD is at 192, it

means the panel is at its Full Dynamic Range. In order to prevent saturation of Full Dynamic range and data, one of R/G/B is fixed at 192, and the other two is lowered to find the desired value.

(3) Adjustment condition : normal temperature

1) Surrounding Temperature : 25 °C ± 5 °C

2) Warm-up time: About 5 Min

3) Surrounding Humidity : 20 % ~ 80 %

Only for training and service purposes

4.2.2. Equipment

(1) Color Analyzer: CA-210 (LED Module : CH 14) (2) Adjustment Computer(During auto adj., RS-232C protocol

is needed) (3) Adjustment Remote control (4) Video Signal Generator MSPG-925F 720p/216-Gray

(Model: 204, Pattern: 49)

→ Only when internal pattern is not available

• Color Analyzer Matrix should be calibrated using CS-100.

- 20 -

4.2.3. Equipment connection MAP

Color Analyzer

Probe

RS- 232C

Signal Source

* If TV internal pattern is used, not needed

RS-232C

Computer

RS-232C

Pattern Generator

4.2.4. Adj. Command (Protocol)

START 6E A 50 A LEN A 03 A CMD A 00 A VA L A CS STOP

- LEN: Number of Data Byte to be sent

- CMD: Command

- VAL: FOS Data value

- CS: Checksum of sent data

- A: Acknowledge Ex) [Send: JA_00_DD] / [Ack: A_00_okDDX]

▪ RS-232C Command used during auto-adjustment.

RS-232C COMMAND

[CMD ID DATA]

wb 00 00 Begin White Balance adjustment

wb 00 10 Gain adjustment(internal white pattern)

wb 00 1f Gain adjustment completed

wb 00 20 Offset adjustment(internal white pattern)

wb 00 2f Offset adjustment completed

wb 00 ff

End White Balance adjustment (internal pattern disappears )

Ex) wb 00 00 → Begin white balance auto-adj.

wb 00 10 → Gain adj. ja 00 ff → Adj. data

jb 00 c0 ... ...

wb 00 1f -> Gain adj. completed *(wb 00 20(Start), wb 00 2f(end)) → Off-set adj. wb 00 ff -> End white balance auto-adj.

▪ Adj. Map

Command

(lower case ASCII)

CMD1 CMD2 MIN MAX

Cool

Medium

Warm

Adj. item

R Gain j g 00 C0

G Gain j h 00 C0

B Gain j i 00 C0

R Cut

G Cut

B Cut

R Gain j a 00 C0

G Gain j b 00 C0

B Gain j c 00 C0

R Cut

G Cut

B Cut

R Gain j d 00 C0

G Gain j e 00 C0

B Gain j f 00 C0

R Cut

G Cut

Explanation

Data Range

(Hex.)

Default

(Decimal)

4.2.5. Adj. method

(1) Auto adj. method

1) Set TV in adj. mode using POWER ON key.

2) Zero calibrate probe then place it on the center of the Display.

3) Connect Cable.(RS-232C to USB)

4) Select mode in adj. Program and begin adj.

5) When adj. is complete (OK Sign), check adj. status pre mode. (Warm, Medium, Cool)

6) Remove probe and RS-232C cable to complete adj.

▪ W/B Adj. must begin as start command “wb 00 00”, and

finish as end command “wb 00 ff”, and Adj. offset if need.

(2) Manual adjustment. method

1) Set TV in Adj. mode using POWER ON.

2) Zero Calibrate the probe of Color Analyzer, then place it on the center of LCD module within 10 cm of the surface.

3) Press ADJ key → EZ adjust using adj. R/C → 7. WhiteBalance then press the cursor to the right(key ►).

(When right key(►) is pressed 216 Gray internal pattern

will be displayed)

4) One of R Gain / G Gain / B Gain should be fixed at 192, and the rest will be lowered to meet the desired value.

5) Adjustment is performed in COOL, MEDIUM, WARM 3 modes of color temperature.

** G-fix adjustment Adjust modes (Cool), Fix the G gain to 172 (default data) and change the others (G/B Gain). Adjust two modes(Medium / Warm), Fix the one of R/G/B gain to 192 (default data) and decrease the others. If internal pattern is not available, use RF input. In EZ Adj. menu 7.White Balance, you can select one of 2 Testpattern: ON, OFF. Default is inner(ON). By selecting OFF, you can adjust using RF signal in 216 Gray pattern.

▪ Adjustment condition and cautionary items

1) Lighting condition in surrounding area

Surrounding lighting should be lower 10 lux. Try to isolate adj. area into dark surrounding.

2) Probe location

: Color Analyzer(CA-210) probe should be within 10 cm

and perpendicular of the module surface (80° ~ 100°)

3) Aging time

- After Aging Start, Keep the Power ON status during 5 Minutes.

- In case of LCD, Back-light on should be checked using no signal or Full-white pattern.

Only for training and service purposes

- 21 -

4.2.6. Reference (White balance adjusmtment coordinate and color temperature)

▪ Luminance : 206 Gray ▪ Standard color coordinate and temperature using CS-1000

(over 26 inch)

Mode

Cool 0.271 0.270 13000 K 0.0000

Medium 0.286 0.289 9300 K 0.0000

Warm 0.313 0.329 6500 K 0.0000

▪

Standard color coordinate and temperature using CA-210(CH 14)

Mode

Cool 0.271 ± 0.002 0.270 ± 0.002 13000 K 0.0000

Medium 0.286 ± 0.003 0.289 ± 0.003 9300 K 0.0000

Warm 0.313 ± 0.002 0.329 ± 0.002 6500 K 0.0000

Coordinate

x y

Coordinate

x y

Temp ∆uv

4.3. Local Dimming Function Check

(1) Turn on TV. (2) At the Local Dimming mode, module Edge Backlight

moving right to left Back light of IOP module moving. (3) Confirm the Local Dimming mode. (4) Press “exit” Key.

4.4. Magic Motion Remote control test

- Equipment : RF Remote control for test, IR-KEY-Code

Remote control for test

- You must confirm the battery power of RF-Remote control

before test(recommend that change the battery per every lot)

- Sequence (test)

1) If you select the ‘start key(OK)’ on the Adjustment remote control, you can pairing with the TV SET.

2) You can check the cursor on the TV Screen, when select the "OK" key on the Adjustment remote control.

3) You must remove the pairing with the TV Set by select ‘Mute + OK Key’ on the Adjustment remote control.

4.2.7. EDGE & IOL LED White balance table

▪ Edge & ALEF LED module change color coordinate because

of aging time.

▪ Apply under the color coordinate table, for compensated

aging time.

▪ (Normal line) Edge & ALEF LED White balance table

- gumi(Mar.~Dec.) & Global Model : (normal line)LGD, CMI

web

Aging

OS

2.0

time

(Min)

1 0-2 277 280 292 299 319 339 2 3-5 276 279 291 298 318 338 3 6-9 275 277 290 296 317 336 4 10-19 274 275 289 294 316 334 5 20-35 273 274 288 293 315 333 6 36-49 273 272 288 291 315 331 7 50-79 272 271 287 290 314 330 8 80-119 272 271 287 290 314 330 9 Over 120 271 270 286 289 313 329

- gumi(Jan~Feb) & Global Model : (normal line)LGD

web

Aging

OS

2.0

time

(Min)

1 0-5 286 295 301 314 328 354 2 6-10 284 290 299 309 326 349 3 11-20 282 287 297 306 324 346 4 21-30 279 283 294 302 321 342 5 31-40 276 278 291 297 318 337 6 41-50 274 275 289 294 316 334 7 51-80 273 272 288 291 315 331 8 80-119 272 271 287 290 314 330 9 Over 120 271 270 286 289 313 329

Cool Medium Warm

x y x y x y

271 270 286 289 313 329

Cool Medium Warm

x y x y x y

271 270 286 289 313 329

4.5. 3D function test

(Pattern Generator MSHG-600, MSPG-6100[Support HDMI1.4]) * HDMI mode NO. 872 , pattern No.83 (1) Please input 3D test pattern like below.

(2) When 3D OSD appear automatically, then select green key.

(3) Don't wear a 3D Glasses, Check the picture like below.

Only for training and service purposes

- 22 -

4.6. Option selection per country

4.6.1. Overview

- Option selection is only done for models in AJ/JA/IL

4.6.2.Method

(1) Press "ADJ" key on the Adjustment remote control, then

select Country Group Menu.

(2) Depending on destination, select Country Group Code or

Country Group then on the lower Country option, select

US, CA, MX. Selection is done using +, - or ►◄ KEY.

4.7. HDMI ARC Function Inspection

(1) Test equipment

- Optic Receiver Speaker

- MSHG-600 (SW: 1220 ↑)

- HDMI Cable (for 1.4 version)

(2) Test method

1) Insert the HDMI Cable to the HDMI ARC port from the master equipment. (HDMI2)

5. GND and Internal Pressure check

5.1. Method

(1) GND & Internal Pressure auto-check preparation

- Check that Power Cord is fully inserted to the SET. (If loose, re-insert)

(2) Perform GND & Internal Pressure auto-check

- Unit fully inserted Power cord, Antenna cable and A/V arrive to the auto-check process.

- Connect D-terminal to AV JACK TESTER

- Auto CONTROLLER(GWS103-4) ON

- Perform GND TEST

- If NG, Buzzer will sound to inform the operator.

- If OK, changeover to I/P check automatically. (Remove CORD, A/V form AV JACK BOX.)

- Perform I/P test

- If NG, Buzzer will sound to inform the operator.

- If OK, Good lamp will lit up and the stopper will allow the pallet to move on to next process.

5.2. Checkpoint

▪ TEST voltage

- GND: 1.5 KV / min at 100 mA

- SIGNAL: 3 KV / min at 100 mA

▪ TEST time: 1 second ▪ TEST POINT

- GND TEST = POWER CORD GND & SIGNAL CABLE

METAL GND

- Internal Pressure TEST = POWER CORD GND & LIVE &

NEUTRAL

▪ LEAKAGE CURRENT: At 0.5 mArms

2) Check the sound from the TV Set.

3) Check the Sound from the Speaker or using AV & Optic TEST program (It’s connected to MSHG-600)

4.8. Tool Option selection

- Method : Press "ADJ" key on the Adjustment remote control, then select Tool option.

Model EU/CIS Tool 1 Tool 2 Tool 3 Tool 4 Tool 5 Tool 6 Tool 7 Tool 9

55UF77_V-Z_ EU 34598 4628 57513 64601 25254 2379 32911 4098

55UF77_9-Z_ EU 34598 4628 57513 64601 25254 2379 33423 4098

55UF77_V-Z_ CIS 34598 4632 57481 64601 25254 2379 33423 4098

4.9. Ship-out mode check (In-stop)

- After final inspection, press In-Stop key of the Adjustment

remote control and check that the unit goes to Stand-by mode.

6. Audio

No. Item Min Typ Max Unit

Audio practical max

1

Output, L/R (Distor-

tion=10% max Output)

Speaker

2

(8 Ω Impedance)

Measurement condition: (1) RF input: Mono, 1 KHz sine wave signal, 100 % Modulation (2) CVBS, Component: 1 KHz sine wave signal 0.5 Vrms

10 12 W

8.10 10.8 Vrms

10 12 W

EQ Off

AVL Off

Clear Voice Off

EQ On

AVL On

Clear Voice On

Only for training and service purposes

- 23 -

7.

USB S/W Download(Service only)

(1) Put the USB Stick to the USB socket. (2) Go to General menu then enter to About This TV.

- If your downloaded program version in USB Stick is Lower, it didn’t work.

But your downloaded version is Higher, USB data is

automatically detecting. (Download Version High & Power only mode, Set is automatically Download)

(3) Show the message “Copying files from memory”.

(4) Updating is starting. (5) Updating completed, the TV will restart automatically

(6) If your TV is turned on, check your updated version and

Tool option. (explain the Tool option, next stage)

* If downloading version is more new than your TV have,

TV can lost all channel data. In this case, you have to channel recover. if all channel data is cleared, you didn’t have a DTV/ATV test on production line.

* After downloading, have to adjust Tool Option again.

(1) Push "IN-START" key in service remote control. (2) Select "Tool Option 1" and push "OK" key. (3) Punch in the number. (Each model has their number)

Only for training and service purposes

- 24 -

1. External

BLOCK DIAGRAM

4b’1010

Chip Config

M)

(512MB X 2EA)

DDR3 1866 X 32

(512MB X 2EA)

DDR3 1866 X 32

X_TAL

24MHz

(256MB X 2EA)

DDR3 1866 X 32

C

B

A

T/C Demod

(256Kb)

EEPROM(NVRA

I2C 1

P_TS

Analog Demod

(4GB)

eMMC

51P

Vx1

I2C 6

Mstar

B-CAS

USB

(NTP7514)

MAIN Audio AMP

I2S Out

I2C 4

LM15U

HDMI

SUB

ASSY

X_TAL

WIFI/BT Combo

USB_WIFI

IR / KEY

LOGO LIGHT(Ready

CVBS/YPbPr

CVBS/RGB

(RENESAS

Sub Micom

R5F100GEAFB)

I2C 3

(HW Port)

ETHERNET

SPDIF OUT

32.768KHz

P_TS

CI Slot

P_TS

T2/C/S2 W/O AD

TUNER

Air/

Cable

OCP

P_TS

IF (+/-)

R

CVBS

SMARTCARD_I/F

(S2)

DEMOD

(S2)

(T2/C/A)

TUNER

DVB-S

E

A

R

B-CAS

(JAPAN)

LNB

OCP

HDMI3

HDMI1

USB3 (2.0)

USB2 (2.0)

USB1 (3.0)

HDMI2(ARC)

H/P

SCART

(IN/OUT)

AV/COMP

LAN

OPTIC

Only for training and service purposes

- 25 -

1-1. External (+ URSA9)

DDR3 1866 X 32

X_TAL

DDR3 1866 X 32

(512MB X 2EA)

24MHz

4b’1010

Chip Config

51P/41P

M)

(512MB X 2EA)

(256MB X 2EA)

DDR3 1866 X 32

C

B

A

T/C Demod

(256Kb)

EEPROM(NVRA

I2C 1

P_TS

Analog Demod

(4GB)

eMMC

Vx1

(1Gb X 4EA)

DDR3 1866 X 32

9

URSA

Mstar

LM15U

B-CAS

USB

(NTP7515)

MAIN Audio AMP

I2C 4

I2S Out

HDMI

SUB

ASSY

WIFI/BT Combo

USB_WIFI

CVBS/YPbPr

IR / KEY

LOGO LIGHT(Ready)

CVBS/RGB

X_TAL

(RENESAS

Sub Micom

I2C 3

SPDIF OUT

32.768KHz

R5F100GEAFB)

(HW Port)

ETHERNET

CI Slot

T2/C/S2 W/O AD

P_TS

OCP

P_TS

IF (+/-)

TUNER

Air/

Cable

E

R

CVBS

SMARTCARD_I/F

(S2)

DEMOD

(S2)

(T2/C/A)

TUNER

DVB-S

A

R

B-CAS

(JAPAN)

LNB

OCP

HDMI3

HDMI1

USB3 (2.0)

USB2 (2.0)

USB1 (3.0)

HDMI2(ARC)

H/P

RS232C

SCART

(IN/OUT)

AV/COMP

LAN

OPTIC

Only for training and service purposes

- 26 -

2. Internal

Only for training and service purposes

- 27 -

3. I2C

LNB

IC6900

TUNER

TU6704

IC102

NVRAM

TUNER

TU6704

LM15U

I2C_SDA2(HW)

33Ω

I2C_SCL2(HW)

33Ω

1.8KΩ

+3.3V_NORMAL

I2C_SCL3 (HW)

I2C_SDA3 (HW)

+3.3V_LNA_TU

I2C_SCL1(HW)

I2C_SDA1(HW)

I2C_SDA6

1.8KΩ

I2C_SCL6

I2C_SDA5(HW)

33Ω

I2C_SCL5(HW)

I2C_SCL7 (HW)

I2C_SDA7 (HW)

33Ω

+3.3V_TU

I2C_SCL4

I2C_SDA4

1.8KΩ

+3.3V_NORMAL

100Ω

IC5600

NTP7515(Main AMP)

Only for training and service purposes

33Ω

1.8KΩ

+3.3V_NORMAL

IC3000

RENESAS

+3.3V_NORMAL

MICOM

1.8KΩ

+3.3V_NORMAL

0Ω

P7201

LCD Panel

1.8KΩ

33Ω

IC2500

URSA9

+URSA model Only

- 28 -

t(x

t

(x

(x16)

866

866866

4. URSA9

V x1

8 lane 41P

(4MB)

SPI FLASH

Data_Format_0

Data_Format_1

I2C_SCL6

I2C_SDA6

HTPDn_IN

LOCKn_IN

V x1

I2C_SCL7

(+12V)

PANEL_VCC

8 lane 51P

I2CS_SCL

I2C_SDA7

LOCK n

HTPD n

Data_Format_1

XO_URSA

X-Tal

(24Mhz)

XIN_URSA

SPI_DI

3D_EN

Data_Format_2

L_DIM_EN

IRE

SPI_DO/CK/CS

I2CS_SCL

UART1_TX

UART2_RX

I2CS_SDA

UART2_TX

B_DDR3_DQ[31:0]

BA[2:0]/CLK/CKE B_DDR3_A[15:0]/

DDR3 SDRAM

- 1Gbit (x16)

- 1866

DDR3 SDRAM

- 1Gbit (x16)

- 1866

URSA9

A_DDR3_DQ[31:0]

URSA9_CONNECT

I2CS_SDA

4 Pin

I2C_S Port

Jig Download

BA[2:0]/CLK/CKE A_DDR3_A[15:0]/

DDR3 SDRAM

- 1Gbit (x16)

- 1866

DDR3 SDRAM

5 Pin

PANEL_VCC

T-CON POWER

- 1Gbit (x16)

- 1866

Switch

URSA

DEBUG

UART

URSA9

PQ

UART2_TX

UART2_RX

+1.5V_U_DDR

(URSA DDR)

DC-DC Converter

(BD9D320EFJ _3A)

Power +12V

Only for training and service purposes

Vx1 VIDEO 8Lane

Vx1 OSD 4Lane

SDA2_+3.3V_DB

SCL2_+3.3V_DB

UART

URSA9

SYS

IRE

UART1_TX

+1.15V (URSA)

LOCKAn_OSD / LOCKAN_Video

LM15U

DC-DC Converter

(MP8762HGLE-Z _10A)

- 29 -

5. Power

LDO DCDC

URSA9

LM15U

DCDC efficiency 80%

DDR_VTT

1.5V

IC402

DDR_VTT

1.5V

IC407

LM15U

eMMC

D.Demod_

DDR_VTT

1.8V

eMMC

1A IC2301

LM15U

DDR3*6EA

Core 2A

LM15U

URSA

Tuner

IC6500

1.5V

URSA9

DDR_VTT

IC13100

URSA

DDR_VTT

URSA9

DDR3*4EA

H/P AMP

WIFI

Combo

NTP7515

NVRAM

USB1

CI SLOT

USB2/3

NTP7514

LNB option

MICOM

LM15U

IR Ass’y

LNB

PANEL VCC

3.3V

3.5V

IC201

AVDD

3.3V NORMAL / 5A

IC2302

1.5V DDR / 3A

IC2303

1.1V Core / 10A

IC2501

1.1V CPU Core / 6A

IC2300

12V

IC13408

1.15V URSA Core / 10A

1.5V_U_DDR / 3A

IC13403

5V NORMAL / 6A

IC2305

24V

Only for training and service purposes

- 30 -

6. Tuner/CI

CI Slot

VCC

+5V_CI_ON

CI 5V

Power detect

+5V_CI_ON

PCM_5V_CTL

LNB

IC6900

LM15U

CI_CD1

/CI_CD1

10K Ω

OR

CAM_CD1_N

AE3[GPIO_PM4]

REG

PCM_RESET

CAM_WAIT_N

CAM_IREQ_N

CI_OE

CAM_IREQ_N

CI_WE

/EB_WE_N

/EB_OE_N

TS_OUT_SYNC

TS_OUT_VAL

TS_OUT_CLK

CI_TS_SYNC

CI_TS_VAL

CI_TS_CLK

CI_IOWR

CI_IORD

CI_ADDR[0-14]

CI_CD2

CI_MISTRT

CI_MIVA_ERR

CI_MCLKI

PCM_CE1

/CI_CD2

/PCM_CE1

EB_BE_N1

EB_BE_NO

EB_DATA[0-7]

PCM_RESET

CAM_WAIT_N

CAM_REG_N

TS_OUT[0-7]

TPI_DATA[0-7]

33Ω

TS_IN[0-7]

CI_MDI[0-7]

33Ω

GATE

EB_DATA[0-7] CI_DATA[0-7]

EB_ADDR[0-14] CI_ADDR[0-14]

TPI_CLK

TPI_VAL

TPI_SOP

TPI_DATA[0-7]

FE_DEMOD1_TS_DATA [0-7]

AT13-AT18

AR17[PCMCD]

AP13[TS2CLK]

AP12[TS2VALID]

AM13[TS2SYNC]

AM13[PCMCEN]

AU10-AR19

AR15PCMIORD]

AT15[PCMIOWR]

AU11[PCMRST]

AR14[PCMREG]

AT10[PCMWAIT]

AU20[PCMIRQA]

AN17[TS1CLK]

AT21[PCMOEN]

AR11[[PCMWEN]

AN16~AP19

[TPI_DATA[0-7]]

AM14~AM15

AN16[TS1SYNC]

AM17[TS1VALID]

[TPO_DATA[0-7]]

+2.5V_NORMAL

+3.3V_TUNER

[+3.3V_TUNER] 11

[+3.3V_LNA_TU] 1

[3.3V_Demod_TU] 26

TDJM-G301D

1.8KΩ

+3.3V_TU

Demod_Core

[+2.5V_DEMOD] 38

[1,1V_D_Demod_Core] 28

10 [TONECTRL]

LNB_TX

A8303SESTR-TB

2 [LNB]

7 [SCL]

8 [SDA]

33Ω

I2C_SCL2

LNB_OUT

[LNB_TX] 29

[LNB_OUT] 31

[I2C_SCL2_TU] 27

AN11[TS0CLK]

AP9(TS0SYNC]

F5[SCK2]

F6 [SDA2]

F10[SCK5]

G10[SDA5]

33 Ω

I2C_SDA2

[I2C_SDA2_TU] 30

1.8KΩ

+3.3V_LNA_TU

FE_DEMOD1_TS_ERROR

I2C_SCL5

I2C_SDA5

[I2C_SCL5_TU] 4

[I2C_SDA5_TU] 5

AN9[TS0VALID]

FE_DEMOD1_TS_CLK

FE_DEMOD1_TS_SYNC

FE_DEMOD1_TS_VAL

[FE_DEMOD1_TS_VAL] 16

[FE_DEMOD1_TS_SYNC] 15

[FE_DEMOD1_1_TS_CLK] 14

[FE_DEMOD1_TS_ERROR_TU] 12

AP10~AM9

[TS0DATA[0-7]

A15 [GPIO159]

RF_SWITCH_CTL

AP1 [VIFP]

AP2 [VIFM]

A12 [GPIO62]

/TU_RESET1

AN2[SIFP]

AE5[CVBS0]

AP3[IF_AGC]

ADC_I_INP

ADC_I_INN

FILTER

IF_P

IF_N

TU_CVBS

TUNER_SIF

IF_AGC

FE_DEMOD1_TS_DATA [0-7]

[IF_P] 6

[IF_N] 7

[TU_SIF_TU] 8

[IF_AGC_TU] 3

[RF_SWITCH_CTL] 2

[/TU_RESET1_TU] 25

FE_DEMOD1_TS_DATA[0] 17

FE_DEMOD1_TS_DATA[1] 18

FE_DEMOD1_TS_DATA[2] 19

FE_DEMOD1_TS_DATA[3] 20

FE_DEMOD1_TS_DATA[4] 21

FE_DEMOD1_TS_DATA[5] 22

FE_DEMOD1_TS_DATA[6] 23

FE_DEMOD1_TS_DATA[7] 24

[TU_CVBS_TU] 9

Only for training and service purposes

- 31 -

7. Video/Audio In

LM15U

SoC

Jack Side

[RIN1P]

[BIN1P]

[GIN1P]

COMP1_Y

Side

COMP1_Y

COMP1_Pr

COMP1_Pb

COMP1_Pr

JK3802

[CVBS1]

[LINE_IN_0L]

[LINE_IN_0R]

COMP1/AV1/DVI_L_IN

COMP1/AV1/DVI_R_IN

COMP1/AV1/DVI_L_IN

AV1_CVBS_IN AV1_CVBS_IN

COMP1/AV1/DVI_R_IN

[CVBS2]

SC_CVBS_IN

SCART

[RIN0P,GIN0P,BIN0P]

[VSYNC0,HSYNC0]

SC_FB/ID

[LINE_IN_1L,LINE_IN_1R]

[CVBSOUT1]

[LINE_IN_0L,LINE_IN_0R]

SC_R/G/B

SC_L/R_IN

SC_R/G/B

SC_L/R_IN

DTV/MNT_L/R_OUT

DTV/MNT_V_OUT

DTV/MNT_L/R_OUT

DTV/MNT_V_OUT1

[CVBS0]

[SIFP,VIFP/VIFM]

[TS0CLK,TS0SYNC,TS0VALID]

TU_CVBS

TUNER_SIF, IF_P/N

FE_DEMOD1/2_TS_ERROR,CLK,SYNC,VAL

TUNER_SIF, IF_P/N_TU

TU_CVBS_TU

FE_DEMOD1/2_TS_ERROR,CLK,SYNC,VAL

JK4600

Tuner

Only for training and service purposes

- 32 -

8. Audio Out

SPEAKER_L

SPEAKER_R

SCART

JK4600

DTV/MNT_L/R_OUT

LPF

S

CART

TR) (

Mute CTRL

P AMP

IC6000

O

Z4580MTR A

CART_L/Rout S

LINE_OUT_2R]

[ LINE_OUT_2L]

[

DVB only

_

E

MUT

4P WAFER

LPF

TP7515

IC5800

udio AMP

N

A

UD_SCK

UD_LRCK A

AUD_LRCH

I2S_OUT_SD] [

[ I2S_OUT_WS]

2C_SCL4

I

I2C_SDA4

A

[ I2S_OUT_BCK]

AMP_RESET_N

[ GPIO160]

[ DDCDC_DA/ GPIO47]

[ DDCDC_CK/ GPIO46]

AMP_MUTE

IC3000

MICOM

EAD PHONE H

JK3803

SIDE_HP_MUTE

LPF

HP_LOUT / HP_ROUT

[EARPHONE_OUT_L]

[ EARPHONE_OUT_R]

LM15U

LINE_IN_0L] [

OMP1/AV1/ DVI_L_IN

OMP1/AV1/ DVI_R_IN

C

Only for training and service purposes

LINE_IN_0R] [

JK3802

SCART

[ LINE_IN_1L]

[ LINE_IN_1R]

DVB only

SC_L_IN / SC_R_IN

JK4600

[ SIFP]

TUNER_SIF

TR BUF

[ SPDIF_OUT]

SPDIF_OUT

Tuner

JK3800

- 33 -

9. HDMI

CEC_REMOTE

Q3001

HDMI_CEC_MICOM

HDMI3

HDMI2 & ARC

HDMI1

RENESAS

MICOM(IC3000)

32.768kHz

X-Tal(X3000)

DDC_SCL_1

DDC_SDA_1

TMDS Link 8bits

Only for training and service purposes

DDC_SCL_2

DDC_SDA_2

TMDS Link 8bits

LM15U

HDMI_ARC

- 34 -

DDC_SCL_3

DDC_SDA_3

TMDS Link 8bits

MHL_DET_LM15

* TMDS Link 8bits = TMDS DATA 6bits(DATA0,1,2)+ TMDS CLK 2bits

10. USB / WIFI / M-REMOTE / UART

[USB_DM]

[USB_DP]

[GPIO162] [GPIO163]

[USB2_DM]

[USB2_DP]

[GPIO50] [GPIO51]

LM15U

[USB0_DM]

[USB0_DP]

[USB_SSRX]

[USB_SSTX]

[USB1_DM]

[USB1_DP]

[GPIO57]

[GPIO14] [GPIO18]

USB_DM1

USB_DP 1

/USB_OCD1

USB_CTL1

USB_DM2

USB_DP 2

/USB_OCD2

USB_CTL2

USB_DM3

USB_DP3

SSUSB_RXP/SSUSB_RXN

SSUSB_TXP/SSUSB_TXN

/USB_OCD3

USB_CTL3

WIFI_DM

WIFI_DP

M_RFModule_RESET

USB3

USB2

USB1

+5V_USB_1

+5V_USB_2

+5V_USB_3

6A

DCDC

IC2305

OCP

IC4300

USB2.0

USB3.0

WIFI Combo

[TX1]

[RX1]

Only for training and service purposes

SOC_TX

SOC_RX

RENESAS MICOM(IC3000)

- 35 -

RS232C_Debug(4P wafer)

EXPLODED VIEW

IMPORTANT SAFETY NOTICE

Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by in the Schematic Diagram and EXPLODED VIEW. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer.

400

800

521

540

500

A10

A22

120

Stand screw

121

910

900

901

902

LV1

200

Only for training and service purposes

530

- 36 -

401

911

910

570

820

900

NVRAM

LGE Internal Use Only

Atmel_NVRAM

IC102

AT24C256C-SSHL-T

EAN61133501

A0

1

A1

2

A2

A0’h

3

GND

4

SPI_CK_SOC SPI_DI_SOC SPI_DO_SOC

/SPI_CS

FRC_FLASH_SEL

FRC_FLASH_WP

TXOSD_3P TXOSD_3N TXOSD_2P TXOSD_2N TXOSD_1P TXOSD_1N TXOSD_0P TXOSD_0N

COMPENSATION_DONE

FAN_ON

LM15U HW Option

BIT0 BIT1

BIT2

BIT3

BIT4

BIT5

BIT6

BIT7

BIT8

BIT9

BIT10

BIT11

BIT12

BIT13

20140701 version

BIT(0/1)

BIT4

BIT5 BIT6

DVB

TW/COL

00

CN/HK

01

10

11

Display

Resolution

Model

VCC

8

WP

7

SCL

6

SDA

5

URSA9_CONNECT

L/D_VSYNC_SOC

L/D_CLK_SOC

L/D_DI_SOC

URSA_RESET_SoC

EU

AJJA

IC102-*1

BR24G256FJ-3

A0

VCC

1

BIT4_1

R116 10K

BIT4_0

R115 10K

A1

2

A2

3

GND

4

Rohm_NVRAM

I2C_SCL1 I2C_SDA1

R118 10K

OPT

R117 10K

BIT(7/8)

00

01

10

11

8

WP

7

SCL

6

SDA

5

BIT6_1

R120 10K

BIT6_0

R119 10K

BIT7_1

R122 10K

BIT7_0

R121 10K

B/E(FRC)

URSA11-P

URSA11

+3.3V_NORMAL

C103

0.1uF

LOCKAn_OSD

BIT0_1

R104 10K

BIT0_0

R103 10K

ATSC

US

KR

BR/PH

Sri Lanka

Low

FHD

LM15U only

Write Protection

- Low : Normal Operation

- High : Write Protection

AR100 33

LM15U+URSA9

OLED LM15U_ONLY

DATA_FORMAT_1_SOC

DATA_FORMAT_0_SOC

+3.3V_NORMAL

10K

BIT2_1

BIT1_1

BIT1_0

R108

10K

R107

LM15U+URSA

R110 10K

BIT2_0

R109 10K

JP

High

OLEDLCD

UHD

BIT3_1

R112 10K

BIT3_0

R111 10K

CHIP CONFIG

CHIP_CONFIG[3:0] {LED1, SPI_DI,LED0, PWM_PM}

Value Mode Description 4’b1000 SB51_ExtSPI 51 boot from SPI 4’b1001 HEMCU_ExtSPI ARM boot from SPI 4’b1010 HEMCU_ROM_EMMC ARM boot from ROM; outer storage is eMMC 4’b1011 HEMCU_ROM_NAND ARM boot from ROM; outer storage is NAND 4’b1100 DBUS for test only 4’b0000 SB51_ExtSPI + Authentication 51 boot from SPI with ARM authentication 4’b0001 SB51_ExtSPI + Authentication HEMCU_ExtSPI + Authentication 4’b0011 HEMCU_ROM_NAND + Authentication ARM boot from ROM with authentication;

OPT

BIT8_1

R124 10K

R181 10K

R183 10K

NON_HDMI_EXT_EDID

BIT8_0

R123 10K

R182 10K

R159 10K

HDMI_EXT_EDID

NONE

URSA9

+3.3V_NORMAL

OPT

R157 4.7K

R161 4.7K

R163 4.7K

R165 4.7K

OPT

R158 4.7K

R164 4.7K

R162 4.7K

R166 4.7K

+3.3V_NORMAL

OPT

R155

FRC_FLASH_SEL

OPT

R185 10K

R156 10K

R188 10K

OPT

R184 10K

R186 10K

R189 10K

EU/CIS

00

T2/C/S2 PIP

01

T2/C/S2

10

11

T/C

4.7K

FRC_FLASH_WP

AJJA

T2/C PIP

T2/C/S2

T2

LED1 SPI_DI_SOC LED0 PWM_PM

FRC_FLASH_SEL

R167

0

+3.3V_NORMAL

R126

10K OPT

R179

10K

U_SPI_WP_f_SoC

WOL_WAKE_UP

TW/COL

T2/C PIP

T ATSC

CN/HKBIT(2/3)

Default

T2/C

T/C

PWM_DIM

PWM_DIM2

FAN_ON

AMP_RESET_N

M_RFModule_RESET

PWM_PM

/USB_OCD2

USB_CTL2

SPI_CK_SOC SPI_DI_SOC SPI_DO_SOC

/SPI_CS

DDCA_CK DDCA_DA

SOC_TX SOC_RX

/TU_RESET2

I2C_SCL6 I2C_SDA6

DDTS_TX DDTS_RX

/TU_RESET1

URSA_RESET_SoC

COMPENSATION_DONE

BIT0 BIT1 BIT2 BIT3

BIT4 BIT12 BIT13

I2C_SCL3 I2C_SDA3

I2C_SCL1 I2C_SDA1

AVDD_3P3

CPU_VID0

CORE_VID0

LED0

R131 10K

LED1

KR

ATSC NIM+T2

ATSC+T2

ATSC PIP

R168

WOL_WAKE_UP

North.AM

IC100

LGE5331(LM15U)

A16

PWM0/GPIO157

C15

PWM1/GPIO158

A15

PWM2/GPIO159

B15

PWM3/GPIO160

C14

PWM4/GPIO161

E4

PWM_PM/GPIO10

H6

SAR0/GPIO50

J6

SAR1/GPIO51

G5

SAR2/GPIO52

J5

SAR3/GPIO53

D1

SAR5

D2

SPI_CK/GPIO1

D3

SPI_DI/GPIO2

E2

SPI_DO/GPIO3

F1

R1870

E3 F2

N5 P5

C9

A10

E9

F9 F10 G10

D9

M7

P6

N6

A12 A13 C12

B12 C11 B10 C10 B11

F6

F5

K6

L7 C16 B16

D5

D4

H4

H5

L5

BR

ISDB PIPDefault

ISDB EXT

ISDB INT

SPI_CZ0/GPIO0 SPI_CZ1/GPIO_PM6/GPIO19 SPI_CZ2/GPIO_PM10/GPIO23

DDCA_CK/UART0_RX/GPIO11 DDCA_DA/UART0_TX/GPIO12

GPIO67/TX1 GPIO68/RX1 GPIO69/TX2 GPIO70/RX2 GPIO71/TX3 GPIO72/RX3 GPIO76/TX4 GPIO77/RX4 GPIO94/TX5 GPIO95/RX5

GPIO62 GPIO63 GPIO64

GPIO65 GPIO66 GPIO73 GPIO74 GPIO75 GPIO81/TX2 GPIO82/RX2

GPIO88/SCK0 GPIO89/SDA0 DDCR_CK/GPIO59 DDCR_DA/GPIO58

VID0/GPIO55 VID1/GPIO56 LED0/GPIO32 LED1/GPIO33 WOL/GPIO57

JP

Default

0

OPT

LVSYNC/VBY0M LHSYNC/VBY0P

A0M/VBY_OSD_0M A0P/VBY_OSD_0P A1M/VBY_OSD_1M A1P/VBY_OSD_1P A2M/VBY_OSD_2M

A2P/VBY_OSD_2P ACKM/VBY_OSD_3M ACKP/VBY_OSD_3P

A4M/OSD_LOCKN A4P/OSD_HTPDN

GPIO_PM0/GPIO13 GPIO_PM2/GPIO15 GPIO_PM3/GPIO16 GPIO_PM4/GPIO17 GPIO_PM7/GPIO20 GPIO_PM8/GPIO21 GPIO_PM9/GPIO22

GPIO_PM13/GPIO26 GPIO_PM17/GPIO30 GPIO_PM18/GPIO31

GPIO_PM1/GPIO14 GPIO_PM5/GPIO18

GPIO_PM11/GPIO24 GPIO_PM12/GPIO25

AV_LNK/GPIO9

GPIO112/SPI1_DI GPIO111/SPI1_CK GPIO114/SPI2_DI GPIO113/SPI2_CK

GPIO110/VSYNC_LIKE

GPIO115/DIM0 GPIO116/DIM1 GPIO117/DIM2 GPIO118/DIM3

EXTERNAL EDID

BIT9

FOR HDMI2.0

BIT10

BIT11

BIT12

Reserved

BIT13

LDE/VBY1M LCK/VBY1P

B0M/VBY2M B0P/VBY2P B1M/VBY3M B1P/VBY3P B2M/VBY4M

B2P/VBY4P BCKM/VBY5M BCKP/VBY5P

B3M/VBY6M

B3P/VBY6P

B4M/VBY7M

B4M/VBY7P

A3M/LOCKN

A3P/HTPDN

TEST

Support

Division

CI+

VID

V-BY-ONE

AB36 AB35 AC36 AC37

AD37 AD36 AD35 AE36 AF36 AF37 AF35 AG37 AG35 AH36 AH35 AJ36

AJ35 AK37 AK36 AK35 AL35 AM36 AM37 AM35 AJ33 AJ34 AJ32 AJ31

R172

10K

AD5 AD6 AE2 AE3 AF4 AG5 AG6 AH6 AJ5 AJ4

K5 L6 M5 M6

L4 J15

A18 B18 C17 B17 C18 D18 E18 F18 E17

Low

EXTERNAL

NON_Division

VID Enable VID Disable

TXVBY1_0N TXVBY1_0P TXVBY1_1N TXVBY1_1P

TXVBY1_2N TXVBY1_2P TXVBY1_3N TXVBY1_3P TXVBY1_4N TXVBY1_4P TXVBY1_5N TXVBY1_5P TXVBY1_6N TXVBY1_6P TXVBY1_7N TXVBY1_7P

TXOSD_0N TXOSD_0P TXOSD_1N TXOSD_1P TXOSD_2N TXOSD_2P TXOSD_3N TXOSD_3P

R173

10K

HTPDAn_OSD_Pull_down

HTPDAn_Video_Pull_down

HTPDAn_Video HTPDAn_OSD

OPT

COMP1_DET

R1800

3D_EN

AV2_CVBS_DET

PCM_5V_CTL

5V_DET_HDMI_1 5V_DET_HDMI_2 5V_DET_HDMI_3

BIT7 BIT8

/USB_OCD3

USB_CTL3 DATA_FORMAT_0_SOC DATA_FORMAT_1_SOC

BIT5 BIT6

L/D_DI_SOC

L/D_CLK_SOC L/D_VSYNC_SOC BIT11 AV1_CVBS_DET HP_DET SC_DET

High

NON_EXTERNAL

4_Division

New CI PathOld CI Path

EB_DATA[0-7]

EB_ADDR[0-14]

C NXP_VBY1_LOCK_LED_TR

Q100-*1

B

MMBT3906(NXP)

E

LOCKAn_Video HTPDAn_Video LOCKAn_OSD HTPDAn_OSD

+3.3V_NORMAL

LD1 00

VBY1_LOCK_LED

3.3K R195

19- 21/R 6C-F R1S1 L/3T

VBY1_LOCK_LED

E

Q100 2N3906S-RTK

B

KEC_VBY1_LOCK_LED_TR

C

EMMC_DATA[0-7]

R175 22

R176

1K

+3.3V_NORMAL

URSA9_CONNECT

CAM_IREQ_N

CAM_CD1_N PCM_RESET CAM_REG_N

CAM_WAIT_N

TCON_I2C_EN

R177

10K

OPT

R178

10K OPT

L_DIM_EN

BIT9

BIT10

EB_OE_N EB_BE_N1 /PCM_CE1

EB_WE_N

EB_BE_N0

EMMC_CMD

EMMC_CLK

EMMC_RST

EMMC_STRB

RF_SWITCH_CTL

EB_DATA[0] EB_DATA[1] EB_DATA[2] EB_DATA[3] EB_DATA[4] EB_DATA[5]

EB_DATA[6] EB_DATA[7]

EB_ADDR[0] EB_ADDR[1] EB_ADDR[2] EB_ADDR[3] EB_ADDR[4] EB_ADDR[5] EB_ADDR[6] EB_ADDR[7] EB_ADDR[8] EB_ADDR[9] EB_ADDR[10] EB_ADDR[11] EB_ADDR[12]

EB_ADDR[13] EB_ADDR[14]

EMMC_DATA[6] EMMC_DATA[7] EMMC_DATA[2] EMMC_DATA[1] EMMC_DATA[0]

EMMC_DATA[3]

EMMC_DATA[4] EMMC_DATA[5]

R174 0

OPT

R1910

AT13

PCMDATA[0]/GPIO152

AT9

PCMDATA[1]/GPIO153

AR13

PCMDATA[2]/GPIO154

AT17

PCMDATA[3]/GPIO124

AR16

PCMDATA[4]/GPIO125

AT16

PCMDATA[5]/GPIO126

AR21

PCMDATA[6]/GPIO127

AT18

PCMDATA[7]/GPIO128

AU10

PCMADR[0]/GPIO151

AT14

PCMADR[1]/GPIO150

AR10

PCMADR[2]/GPIO148

AT19

PCMADR[3]/GPIO147

AR18

PCMADR[4]/GPIO146

AU19

PCMADR[5]/GPIO144

AT11

PCMADR[6]/GPIO143

AT12

PCMADR[7]/GPIO142

AT20

PCMADR[8]/GPIO136

AU14

PCMADR[9]/GPIO134

AU16

PCMADR[10]/GPIO130

AR20

PCMADR[11]/GPIO132

AR12

PCMADR[12]/GPIO141

AU13

PCMADR[13]/GPIO137

AR19

PCMADR[14]/GPIO138

AU20

PCMIRQA/GPIO140

AT21

PCMOEN/GPIO131

AR15

PCMIORD/GPIO133

AU17

PCMCEN/GPIO129

AR11

PCMWEN/GPIO139

AR17

PCMCD/GPIO156

AU11

PCMRST/GPIO155

AR14

PCMREG/GPIO149

AT15

PCMIOWR/GPIO135

AT10

PCMWAIT/GPIO145

D7

NAND_ALE/GPIO194

F7

NAND_WPZ/GPIO193

G7

NAND_CEZ/EMMC_CMD/GPIO188

E6

NAND_CLE/GPIO190

F8

NAND_REZ/EMMC_CLK/GPIO191

E7

NAND_WEZ/GPIO192

E8

NAND_RBZ/EMMC_RSTN/GPIO195

D6

NAND_CEZ1/GPIO189

D8

NAND_DQS/GPIO196

A6

NAND_AD0/EMMC_D6/GPIO226

C6

NAND_AD1/EMMC_D7/GPIO225

A7

NAND_AD2/EMMC_D2/GPIO224

B7

NAND_AD3/EMMC_D1/GPIO223

C7

NAND_AD4/EMMC_D0/GPIO199

B8

NAND_AD5/EMMC_D3/GPIO198

C8

NAND_AD6/EMMC_D4/GPIO197

B9

NAND_AD7/EMMC_D5/GPIO227

AM4

PCM2_CD/GPIO123

AP4

PCM2_CE/GPIO119

AL5

PCM2_IRQA/GPIO120

AN4

PCM2_WAIT/GPIO121

AL4

PCM2_RESET/GPIO122

IC100

LGE5331(LM15U)

TS2DATA_[7]/VSENSE/GPIO210

TS1DATA_[0]/GPIO187 TS1DATA_[1]/GPIO186 TS1DATA_[2]/GPIO185 TS1DATA_[3]/GPIO184 TS1DATA_[4]/GPIO183 TS1DATA_[5]/GPIO182 TS1DATA_[6]/GPIO181 TS1DATA_[7]/GPIO180

TS1CLK/GPIO177

TS1VALID/GPIO179

TS1SYNC/GPIO178

TS0DATA_[0]/GPIO166 TS0DATA_[1]/GPIO167 TS0DATA_[2]/GPIO168 TS0DATA_[3]/GPIO169 TS0DATA_[4]/GPIO170 TS0DATA_[5]/GPIO171 TS0DATA_[6]/GPIO172 TS0DATA_[7]/GPIO173

TS0CLK/GPIO176

TS0VALID/GPIO174

TS0SYNC/GPIO175

TS2DATA_[0]/GPIO200 TS2DATA_[1]/GPIO204 TS2DATA_[2]/GPIO205 TS2DATA_[3]/GPIO206 TS2DATA_[4]/GPIO207 TS2DATA_[5]/GPIO208 TS2DATA_[6]/GPIO209

TS2CLK/GPIO203

TS2VALID/GPIO201

TS2SYNC/GPIO202

TS3DATA_[0]/GPIO211 TS3DATA_[1]/GPIO212 TS3DATA_[2]/GPIO213 TS3DATA_[3]/GPIO214 TS3DATA_[4]/GPIO215 TS3DATA_[5]/GPIO216 TS3DATA_[6]/GPIO217 TS3DATA_[7]/GPIO218

TS3CLK/GPIO221

TS3VALID/GPIO219

TS3SYNC/GPIO220

VIFP VIFM

SIFP SIFM

IF_AGC

TGPIO0/GPIO162 TGPIO1/GPIO163 TGPIO2/GPIO164 TGPIO3/GPIO165

AL6 AM6 AP8 AN7 AM5 AM7 AN5 AN6 AL7 AP5 AP6

AP10 AN10 AM8 AM10 AM11 AM12 AN8 AM9 AN11 AN9 AP9

AM14 AP15 AN12 AN15 AN14 AM16 AN13 AM15 AP13 AP12 AM13

AM18 AP16 AM19 AN18 AP19 AN20 AP18 AN19 AN17 AM17 AN16

AP1 AP2

AN2 AN1

AP3

AR2 AM2 AK5 AK6

/USB_OCD1 USB_CTL1

I2C_SCL7 I2C_SDA7

TPO_DATA[0] TPO_DATA[1] TPO_DATA[2] TPO_DATA[3] TPO_DATA[4] TPO_DATA[5] TPO_DATA[6] TPO_DATA[7]

TPO_CLK TPO_VAL TPO_SOP

TPI_CLK TPI_VAL TPI_SOP

FE_DEMOD1_TS_DATA[0] FE_DEMOD1_TS_DATA[1] FE_DEMOD1_TS_DATA[2] FE_DEMOD1_TS_DATA[3] FE_DEMOD1_TS_DATA[4] FE_DEMOD1_TS_DATA[5]

FE_DEMOD1_TS_DATA[6] FE_DEMOD1_TS_DATA[7]

FE_DEMOD1_TS_CLK FE_DEMOD1_TS_VAL FE_DEMOD1_TS_SYNC

FE_DEMOD3_TS_DATA

FE_DEMOD3_TS_CLK FE_DEMOD3_TS_VAL FE_DEMOD3_TS_SYNC

TPI_DATA[0-7]

TPI_DATA[0]

TPI_DATA[1] TPI_DATA[2] TPI_DATA[3] TPI_DATA[4] TPI_DATA[5] TPI_DATA[6] TPI_DATA[7]

TPI_DATA[0-7]

Close to MSTAR

R140 100 C118 0.1uF

R141 100

C120 0.1uF C121 0.1uF

ANALOG SIF

Close to MSTAR

R142 10K

TPO_DATA[0-7]

FE_DEMOD1_TS_DATA[0-7]

C119 0.1uF

R144 47

R145 47

PZ1608U121-2R0TF

R143

0

C124 1000pF OPT

OPT C122

100pF

R146 300

OPT

+3.3V_NORMAL

L100

C125

0.1uF

C127

0.047uF 25V

OPT C123 33pF

DTV_IF

IF_P

IF_N

OPT C126 33pF

TU_SIF

IF_AGC

Mstart Debug

MSTAR_DEBUG_OLD

MSTAR_DEBUG_NEW

P101

12507WS-04L

1

2

DDCA_CK

3

DDCA_DA

4

5

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

P103

12505WS-04A00

1

2

3

4

5

RS232C_Debug

UART_4PIN_WAFER

P102

12507WS-04L

5

+3.5V_ST

1

2

3

4

OPT

R100 10K

R147

1.8K

R148

1.8K

+3.3V_LNA_TU

+3.3V_NORMAL

R128

1.8K

R129

1.8K

R127

1.8K

I2C_SDA_MICOM I2C_SCL_MICOM

R130

1.8K

+3.3V_TU

SOC_RX

OPT

R101 10K

SOC_TX

I2C PULL UP

R133

1.8K

R134

1.8K

R135

1.8K

AR101 33

R136

1.8K

R106

1.8K

R125

1.8K

I2C_SDA3 I2C_SCL3

R132

1.8K

R139

1.8K

I2C_SDA7 I2C_SCL7

I2C_SDA6 I2C_SCL6 I2C_SDA1 I2C_SCL1 I2C_SDA3 I2C_SCL3

I2C_SDA4 I2C_SCL4

I2C_SDA5 I2C_SCL5

I2C_SDA2 I2C_SCL2

I2C for URSA9 (URSA9 Only)

I2C for LCD Module

I2C for NAVRAM

I2C for Micom

I2C for Main Amp / Woofer AMP

I2C for tuner

I2C for tuner&LNB

GPIO PULL UP

+3.3V_NORMAL

OPT

R171 10K

R149 10K

R153 10K

R151 10K

R152 10K

R150 10K

OPT

R160 10K

R169 10K

R154 10K

R170 10K

/TU_RESET1 RF_SWITCH_CTL AMP_RESET_N

TCON_I2C_EN

/USB_OCD1

USB_CTL1

/USB_OCD2

USB_CTL2

M_RFModule_RESET

PCM_5V_CTL

DDTS_Debug

P100

12507WS-04L

5

+3.3V_NORMAL

1

2

3

4

OPT

R102 10K

DDTS_RX

OPT

R105 10K

DDTS_TX

2014-12-17LM15U

MAIN1_SYSTEM

1

DVDD_NODIE

LGE Internal Use Only

C200

1uF 25V

VDDC15_M0

DVDD_DDR11

+1.1V_VDDC_CPU

+1.1V_VDDC

AVDDL_MOD11

DVDD_DDR11

AF18 AF19 AF20 AG18 AG19 AG20 AG21 AG22 AH18 AH19 AH20 AH21 AH22

AF14 AF15

AA21 AA27 AA28 AA29 AB21 AB22 AB23 AB24 AB25 AB26 AB27 AB28 AB29 AC21 AC22 AC23 AC24 AC25 AC26 AC27 AC28 AC29 AC30 AD27 AD28 AD29 AD30

AF24

AF25

L10 L11 L12 L13 L14 M10 M11 M12 M13 M14 N10 N11 N12 N13 V12 V13 V14 W12 W13 W14 Y12 Y13 Y14

W23 Y23 W24 Y24 Y25 Y26

N14

R22 R24

P22 T24

LGE5331(LM15U)

VDDC_1 VDDC_2 VDDC_3 VDDC_4 VDDC_5 VDDC_6 VDDC_7 VDDC_8 VDDC_9 VDDC_10 VDDC_11 VDDC_12 VDDC_13 VDDC_14 VDDC_15 VDDC_16 VDDC_17 VDDC_18 VDDC_19 VDDC_20 VDDC_21 VDDC_22 VDDC_23 VDDC_24 VDDC_25 VDDC_26 VDDC_27 VDDC_28 VDDC_29 VDDC_30 VDDC_31 VDDC_32 VDDC_33 VDDC_34 VDDC_35 VDDC_36

AVDDL_PREDRV_1 AVDDL_PREDRV_2 AVDDL_MOD_1 AVDDL_MOD_2 AVDD15_MOD_1 AVDD15_MOD_2

AVDDL_USB3_1 AVDDL_USB3_2

VDDC_CPU_1 VDDC_CPU_2 VDDC_CPU_3 VDDC_CPU_4 VDDC_CPU_5 VDDC_CPU_6 VDDC_CPU_7 VDDC_CPU_8 VDDC_CPU_9 VDDC_CPU_10 VDDC_CPU_11 VDDC_CPU_12 VDDC_CPU_13 VDDC_CPU_14 VDDC_CPU_15 VDDC_CPU_16 VDDC_CPU_17 VDDC_CPU_18 VDDC_CPU_19 VDDC_CPU_20 VDDC_CPU_21 VDDC_CPU_22 VDDC_CPU_23 VDDC_CPU_24 VDDC_CPU_25 VDDC_CPU_26 VDDC_CPU_27

DVDD_NODIE

DVDD_DDR_1 DVDD_DDR_2 DVDD_DDR_C DVDD_DDR_RX_A DVDD_DDR_RX_B DVDD_DDR_RX_C

IC100

AVDD_NODIE

AVDDL_MHL3_1

AVDDL_MHL3_2 AVDD3P3_MHL3_1 AVDD3P3_MHL3_2

AVDD3P3_ETH AVDD3P3_DADC_1 AVDD3P3_DADC_2

AVDD3P3_ADC_1 AVDD3P3_ADC_2 AVDD3P3_USB_1

AVDD3P3_USB_2 AVDD3P3_USB3_1 AVDD3P3_USB3_2

AVDD_AU33

AVDD_EAR33

AVDD3P3_DMPLL

VDDP_1 VDDP_2

AVDD_MOD_1

AVDD_MOD_2 AVDD_LPLL_1 AVDD_LPLL_2

AVDD_PLL_A

AVDD_PLL_B

AVDD_PLL_C

VDDP_3318_A_CAP VDDP_3318_C_CAP

VDDP_3318_A VDDP_3318_C

AVDD_DDR_A_CMD_1 AVDD_DDR_A_CMD_2

AVDD_DDR_A_MCK AVDD_DDR_A_DAT_1 AVDD_DDR_A_DAT_2 AVDD_DDR_A_DAT_3 AVDD_DDR_A_DAT_4 AVDD_DDR_B_CMD_1 AVDD_DDR_B_CMD_2

AVDD_DDR_B_MCK AVDD_DDR_B_DAT_1 AVDD_DDR_B_DAT_3 AVDD_DDR_B_DAT_4 AVDD_DDR_B_DAT_2 AVDD_DDR_C_CMD_1 AVDD_DDR_C_CMD_2

AVDD_DDR_C_MCK AVDD_DDR_C_DAT_1 AVDD_DDR_C_DAT_2 AVDD_DDR_C_DAT_3 AVDD_DDR_C_DAT_4

AVDD_DDR_LDO_A

AVDD_DDR_LDO_B

AVDD_DDR_LDO_C

AVDD_HDMI_5V_PA AVDD_HDMI_5V_PC

GND_EFUSE

AVDD_DDR_VBP_A_1 AVDD_DDR_VBP_A_2

AVDD_DDR_VBN_A_1 AVDD_DDR_VBN_A_2

AVDD_DDR_VBP_B_1 AVDD_DDR_VBP_B_2

AVDD_DDR_VBN_B_1 AVDD_DDR_VBN_B_2

AVDD_DDR_VBP_C_1 AVDD_DDR_VBP_C_2

AVDD_DDR_VBN_C_1 AVDD_DDR_VBN_C_2

V7

T13 T14 L8 M8

W7 AD7 AD8 Y7 Y8 AL10 AL11 AH14 AH15 AH7 AG7 AL12 AK15 AL15

W26 Y27 Y28 Y29

U18 U19 AL18

L17 L15 G8 H7

M20 M21 N21 M22 N22 N23 N24 N25 N26 P25 R25 T25 U25 R26 AE25 AE26 AF26 AE22 AE23 AE24 AF22

N20 P24 AD25

U7 P7

P8

L20 L21

M24 M25

U27 V27

U26 V26

AD21 AD22

AD23 AD24

DVDD_DDR11

AVDD33

VDDC15_M0

VDDC15_M1

OPT

AVDD_PLL33

AVDD5V_MHL

C2100.47uF C2270.47uF

C2110.47uF C2290.47uF

C2120.47uF C2300.47uF

C2130.47uF C2310.47uF

C2140.47uF C2340.47uF

C2150.47uF C2400.47uF

AVDD33

AVDD_AU33

VDDP_NAND

VDDC15_M1

VDDC15_M0

VDDC15_M1

AVDD_3P3

C216

4.7uF

C219

0.1uF

C220

4.7uF

C221

0.1uF

WOL POWER ENABLE CONTROL

+3.5V_ST

PZ1608U121-2R0TF

L204

+3.3V_NORMAL

C239

0.1uF

WOL_CTL

+3.5V_WOL

R201 1K OPT

R2020

+3.5V_WOL

1st layer

C237 10uF 10V

C233 0.1uF

Close to chip side

C205

0.1uF 16V

AP2151WG-7

IN

5

EN

4

IC201

AP2121N-3.3TRE1

VIN

3

IC200

1

2

3

0.1uF

C250

Close to chip side

VOUT

2

1

GND

+1.1V_Bypass Cap(CLOSE TO CHIP SIDE)

+1.1V_VDDC

L226

+3.5V_WOL

OUT

GND

FLG

AVDD_3P3

4th layer

0.1uF

C249

AVDD_3P3

C206 1uF 10V

+1.1V_VDDC

+1.1V_VDDC_CPU

C228

0.1uF

10uF 10V

C232

C235

C261

0.1uF

10uF 10V

C277

C275

1st layer

C263

0.1uF

10uF 10V

C276

C278

Close to chip side

0.1uF

L202

PZ1608U121-2R0TF

2A

AVDDL_MOD11

C264 10uF 10V

C285

0.1uF

C265

0.1uF

PZ1608U121-2R0TF

2A

4th layer

0.1uF

C320

Close to chip side

4th layer

10uF

C322

Close to chip side

C323 10uF 10V

C271 10uF 10V

DVDD_DDR11

0.1uF

C306

C310

0.1uF

4th layer

0.1uF

C324

Close to chip side

+3.3V_Bypass Cap

AVDD_PLL33

L215

PZ1608U121-2R0TF

2A

C256 10uF 10V

1st layer

0.1uF

C274

0.1uF

C286

4th layer

0.47uF

C311

0.47uF

C241

5V_HDMI_3

R200

10

AVDD5V_MHL

+3.3V_NORMAL

C222 10uF 10V

+1.5V_DDR

PZ1608U121-2R0TF

+1.5V_Bypass Cap

VDDC15_M0

L227

L200

C207

2A

10uF 10V

C209 0.1uF

VDDC15_M1

L201

C208

2A

10uF 10V

C218 0.1uF

1st layer

C201 10uF 10V

Close to chip side

1st layer

C202 10uF 10V

Close to chip side

C203 0.1uF C224 0.1uF

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

C225 0.1uF

C204 0.1uF

C226 0.1uF

Close to chip side

C287 0.1uF

Close to chip side

4th layer

0.47uF

C314

4th layer

C315

0.47uF

C316 10uF 10V

C317 10uF 10V

C223 10uF 10V

C242 10uF 10V

FOR_EMI

C325 20pF 50V

VDDC15_M1

FOR_EMI

C326 20pF 50V

FOR_EMI C327 20pF 50V

+3.3V_NORMAL

+1.8V

GND JIG POINT

OPT

L222

PZ1608U121-2R0TF

2A

L223

PZ1608U121-2R0TF

2A

JP202

JP204

JP203

JP205

VDDP_NAND

C302 10uF 10V

C304

0.1uF

L203

PZ1608U121-2R0TF

2A

L212

PZ1608U121-2R0TF

2A

Close to chip side

AVDD33

C217 10uF 10V

C238 0.1uF

C244 0.1uF

AVDD_AU33

0.1uF

C236 10uF 10V

C243

LM15U

MAIN2_POWER

0.1uF

C252

Close to chip side

4th layer

0.1uF

C251

C245 0.47uF

Close to chip side

4th layer

0.1uF

C253

Close to chip side

2014-11-26

2

IC100

LGE Internal Use Only

LGE5331(LM15U)

M0_DDR_A0 M0_DDR_A1 M0_DDR_A2 M0_DDR_A3 M0_DDR_A4 M0_DDR_A5 M0_DDR_A6 M0_DDR_A7

M0_DDR_A8

M0_DDR_A9 M0_DDR_A10 M0_DDR_A11 M0_DDR_A12 M0_DDR_A13 M0_DDR_A14 M0_DDR_A15

M0_DDR_BA0 M0_DDR_BA1

M0_DDR_BA2 M0_DDR_RASN M0_DDR_CASN

M0_DDR_WEN M0_DDR_ODT M0_DDR_CKE

M0_DDR_RESET_N_1

M0_D_CLK

M0_D_CLKN

M0_DDR_CS1 M0_DDR_CS2

M0_DDR_DQ0 M0_DDR_DQ1 M0_DDR_DQ2 M0_DDR_DQ3 M0_DDR_DQ4 M0_DDR_DQ5 M0_DDR_DQ6 M0_DDR_DQ7 M0_DDR_DM0

M0_DDR_DQS0

M0_DDR_DQS_N0

M0_DDR_DQ8

M0_DDR_DQ9 M0_DDR_DQ10 M0_DDR_DQ11 M0_DDR_DQ12 M0_DDR_DQ13 M0_DDR_DQ14 M0_DDR_DQ15

M0_DDR_DM1 M0_DDR_DQS1

M0_DDR_DQS_N1

M0_DDR_DQ16 M0_DDR_DQ17 M0_DDR_DQ18 M0_DDR_DQ19 M0_DDR_DQ20 M0_DDR_DQ21 M0_DDR_DQ22 M0_DDR_DQ23

M0_DDR_DM2 M0_DDR_DQS2

M0_DDR_DQS_N2

M0_DDR_DQ24 M0_DDR_DQ25 M0_DDR_DQ26 M0_DDR_DQ27 M0_DDR_DQ28 M0_DDR_DQ29 M0_DDR_DQ30 M0_DDR_DQ31

M0_DDR_DM3 M0_DDR_DQS3

M0_DDR_DQS_N3

M0_DDR_RESET_N_1

F21

A_A0

C21

A_A1

E21

A_A2

F22

A_A3

B22

A_A4

E22

A_A5

A21

A_A6

D21

A_A7

C20

A_A8

E20

A_A9

B23

A_A10

B21

A_A11

D24

A_A12

F20

A_A13

B20

A_A14

E24

A_A15

E23

A_BA0

C22

A_BA1

F23

A_BA2

G26

A_RASZ

F25

A_CASZ

E25

A_WEZ

F24

A_ODT

C23

A_CKE

F19

A_RST

A24

A_MCLK

B24

A_MCLKZ

E19

A_CSB1

D19

A_CSB2

C27

A_DQ[0]

B26

A_DQ[1]

B28

A_DQ[2]

C25

A_DQ[3]

B29

A_DQ[4]

C24

A_DQ[5]

C28

A_DQ[6]

B25

A_DQ[7]

C26

A_DQM[0]

A27

A_DQS[0]

B27

A_DQSB[0]

D27

A_DQ[8]/DQU0

D30

A_DQ[9]/DQU1

E26

A_DQ[10]/DQU2

D31

A_DQ[11]/DQU3

F27

A_DQ[12]/DQU4

E30

A_DQ[13]/DQU5

D26

A_DQ[14]/DQU6

E29

A_DQ[15]/DQU7

E28

A_DQM[1]

D28

A_DQS[1]

E27

A_DQSB[1]

C32

A_DQ[16]/DQL0

C30

A_DQ[17]/DQL1

B33

A_DQ[18]/DQL2

A30

A_DQ[19]/DQL3

C33

A_DQ[20]/DQL4

C29

A_DQ[21]/DQL5

A33

A_DQ[22]/DQL6

B30

A_DQ[23]/DQL7

B31

A_DQM[2]

B32

A_DQS[2]

C31

A_DQSB[2]

E33

A_DQ[24]/DQU0

C35

A_DQ[25]/DQU1

E31

A_DQ[26]/DQU2

D35

A_DQ[27]/DQU3

D33

A_DQ[28]/DQU4

D34

A_DQ[29]/DQU5

E32

A_DQ[30]/DQU6

C34

A_DQ[31]/DQU7

B35

A_DQM[3]

A35

A_DQS[3]

B34

A_DQSB[3]

OPT

R4400

M0_DDR_RESET_N

C

R434

NXP_DDR_RES0_TR

1K

Q400

B

MMBT3904(NXP)

M1_DDR_RESET_N_1

E

B

C

KEC_DDR_RES0_TR Q400-*1 2N3904S

E

R435

10K

M2_DDR_RESET_N_1

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

B_RASZ B_CASZ

B_MCLK

B_MCLKZ

B_CSB1 B_CSB2

B_DQ[0] B_DQ[1] B_DQ[2] B_DQ[3] B_DQ[4] B_DQ[5] B_DQ[6]

B_DQ[7] B_DQM[0] B_DQS[0]

B_DQSB[0]

B_DQ[8]/DQU0

B_DQ[9]/DQU1 B_DQ[10]/DQU2 B_DQ[11]/DQU3 B_DQ[12]/DQU4 B_DQ[13]/DQU5 B_DQ[14]/DQU6 B_DQ[15]/DQU7

B_DQM[1] B_DQS[1]

B_DQSB[1]

B_DQ[16]/DQL0 B_DQ[17]/DQL1 B_DQ[18]/DQL2 B_DQ[19]/DQL3 B_DQ[20]/DQL4 B_DQ[21]/DQL5 B_DQ[22]/DQL6 B_DQ[23]/DQL7

B_DQM[2] B_DQS[2]

B_DQSB[2]

B_DQ[24]/DQU0 B_DQ[25]/DQU1 B_DQ[26]/DQU2 B_DQ[27]/DQU3 B_DQ[28]/DQU4 B_DQ[29]/DQU5 B_DQ[30]/DQU6 B_DQ[31]/DQU7

B_DQM[3] B_DQS[3]

B_DQSB[3]

C_RASZ C_CASZ

C_MCLK

C_MCLKZ

C_CSB1 C_CSB2

C_DQ[0] C_DQ[1] C_DQ[2] C_DQ[3] C_DQ[4] C_DQ[5] C_DQ[6]

C_DQ[7] C_DQM[0] C_DQS[0]

C_DQSB[0]

C_DQ[8]/DQU0

C_DQ[9]/DQU1 C_DQ[10]/DQU2 C_DQ[11]/DQU3 C_DQ[12]/DQU4 C_DQ[13]/DQU5 C_DQ[14]/DQU6 C_DQ[15]/DQU7

C_DQM[1] C_DQS[1]

C_DQSB[1]

C_DQ[16]/DQL0 C_DQ[17]/DQL1 C_DQ[18]/DQL2 C_DQ[19]/DQL3 C_DQ[20]/DQL4 C_DQ[21]/DQL5 C_DQ[22]/DQL6 C_DQ[23]/DQL7

C_DQM[2] C_DQS[2]

C_DQSB[2]

C_DQ[24]/DQU0 C_DQ[25]/DQU1 C_DQ[26]/DQU2 C_DQ[27]/DQU3 C_DQ[28]/DQU4 C_DQ[29]/DQU5 C_DQ[30]/DQU6 C_DQ[31]/DQU7

C_DQM[3] C_DQS[3]

C_DQSB[3]

B_A10 B_A11 B_A12 B_A13 B_A14 B_A15 B_BA0 B_BA1 B_BA2

B_WEZ B_ODT B_CKE B_RST

C_A10 C_A11 C_A12 C_A13 C_A14 C_A15 C_BA0 C_BA1 C_BA2

C_WEZ C_ODT C_CKE C_RST

G33

B_A0

J36

B_A1

H34

B_A2

J32

B_A3

J35

B_A4

H33

B_A5

J37

B_A6

G36

B_A7

H37

B_A8

F35

B_A9

K35 H35 K34 F36 H36 L33 K33 K36 J33 M33 M32 K32 L32 L36 F37 M37 L35 F34 E37

R36 N35 R35 N36 T35 M36 T36 M35 P36 R37 P35

N32 T34 N33 T32 P33 U33 N34 T33 R33 R32 P32

Y36 V36 Y35 V37 AA36 U36 AA37 U35 V35 W35 W36

W33 AA32 U32 AA34 V33 AA33 V32 Y32 W32 Y33 W34

AM34

C_A0

AR35

C_A1

AP34

C_A2

AM33

C_A3

AT34

C_A4

AN33

C_A5

AU35

C_A6

AR36

C_A7

AU36

C_A8

AR37

C_A9

AT33 AT35 AP31 AP35 AT37 AN31 AN32 AR34 AM32 AM29 AM30 AN30 AM31 AR33 AP37 AU32 AT32 AN34 AP36

AR29 AT30 AT28 AR31 AT27 AR32 AR28 AT31 AR30 AU29 AT29

AN27 AP25 AN29 AN24 AN28 AN25 AP28 AN26 AM26 AM27 AM28

AR24 AR26 AT23 AU26 AR23 AR27 AU23 AT26 AT25 AT24 AR25

AN23 AN21 AM25 AM21 AM23 AM22 AM24 AT22 AR22 AP21 AP22

M1_DDR_A0 M1_DDR_A1 M1_DDR_A2 M1_DDR_A3 M1_DDR_A4 M1_DDR_A5 M1_DDR_A6 M1_DDR_A7 M1_DDR_A8 M1_DDR_A9 M1_DDR_A10 M1_DDR_A11 M1_DDR_A12 M1_DDR_A13 M1_DDR_A14 M1_DDR_A15 M1_DDR_BA0 M1_DDR_BA1 M1_DDR_BA2 M1_DDR_RASN M1_DDR_CASN M1_DDR_WEN M1_DDR_ODT M1_DDR_CKE M1_DDR_RESET_N_1 M1_D_CLK M1_D_CLKN M1_DDR_CS1 M1_DDR_CS2

M1_DDR_DQ0 M1_DDR_DQ1 M1_DDR_DQ2 M1_DDR_DQ3 M1_DDR_DQ4 M1_DDR_DQ5 M1_DDR_DQ6 M1_DDR_DQ7 M1_DDR_DM0 M1_DDR_DQS0 M1_DDR_DQS_N0

M1_DDR_DQ8 M1_DDR_DQ9 M1_DDR_DQ10 M1_DDR_DQ11 M1_DDR_DQ12 M1_DDR_DQ13 M1_DDR_DQ14 M1_DDR_DQ15 M1_DDR_DM1 M1_DDR_DQS1 M1_DDR_DQS_N1

M1_DDR_DQ16 M1_DDR_DQ17 M1_DDR_DQ18 M1_DDR_DQ19 M1_DDR_DQ20 M1_DDR_DQ21 M1_DDR_DQ22 M1_DDR_DQ23 M1_DDR_DM2 M1_DDR_DQS2 M1_DDR_DQS_N2

M1_DDR_DQ24 M1_DDR_DQ25 M1_DDR_DQ26 M1_DDR_DQ27 M1_DDR_DQ28 M1_DDR_DQ29 M1_DDR_DQ30 M1_DDR_DQ31 M1_DDR_DM3 M1_DDR_DQS3 M1_DDR_DQS_N3

M2_DDR_A0 M2_DDR_A1 M2_DDR_A2 M2_DDR_A3 M2_DDR_A4 M2_DDR_A5 M2_DDR_A6 M2_DDR_A7 M2_DDR_A8 M2_DDR_A9 M2_DDR_A10 M2_DDR_A11 M2_DDR_A12 M2_DDR_A13 M2_DDR_A14 M2_DDR_A15 M2_DDR_BA0 M2_DDR_BA1 M2_DDR_BA2 M2_DDR_RASN M2_DDR_CASN M2_DDR_WEN M2_DDR_ODT M2_DDR_CKE M2_DDR_RESET_N_1 M2_D_CLK M2_D_CLKN M2_DDR_CS1 M2_DDR_CS2

M2_DDR_DQ0 M2_DDR_DQ1 M2_DDR_DQ2 M2_DDR_DQ3 M2_DDR_DQ4 M2_DDR_DQ5 M2_DDR_DQ6 M2_DDR_DQ7 M2_DDR_DM0 M2_DDR_DQS0 M2_DDR_DQS_N0

M2_DDR_DQ8 M2_DDR_DQ9 M2_DDR_DQ10 M2_DDR_DQ11 M2_DDR_DQ12 M2_DDR_DQ13 M2_DDR_DQ14 M2_DDR_DQ15 M2_DDR_DM1 M2_DDR_DQS1 M2_DDR_DQS_N1

M2_DDR_DQ16 M2_DDR_DQ17 M2_DDR_DQ18 M2_DDR_DQ19 M2_DDR_DQ20 M2_DDR_DQ21 M2_DDR_DQ22 M2_DDR_DQ23 M2_DDR_DM2 M2_DDR_DQS2 M2_DDR_DQS_N2

M2_DDR_DQ24 M2_DDR_DQ25 M2_DDR_DQ26 M2_DDR_DQ27 M2_DDR_DQ28 M2_DDR_DQ29 M2_DDR_DQ30 M2_DDR_DQ31 M2_DDR_DM3 M2_DDR_DQS3 M2_DDR_DQS_N3

OPT

R4410

M1_DDR_RESET_N

C

R436

NXP_DDR_RES1_TR

1K

Q401

B

MMBT3904(NXP)

E

R437

10K

OPT

R4420

M2_DDR_RESET_N

C

R438

NXP_DDR_RES2_TR

1K

B

Q402 MMBT3904(NXP)

E

R439

10K

B

C

KEC_DDR_RES1_TR Q401-*1 2N3904S

E

C

KEC_DDR_RES2_TR Q402-*1 2N3904S

E

M0_DDR_RESET_N

M0_DDR_DQS0

M0_DDR_DQS_N0

M0_DDR_DQS1

M0_DDR_DQS_N1

M0_DDR_DM0 M0_DDR_DM1

M2_DDR_RESET_N

M2_DDR_DQS0

M2_DDR_DQS_N0

M2_DDR_DQS1

M2_DDR_DQS_N1

M2_DDR_DM0 M2_DDR_DM1

M0_DDR_RASN M0_DDR_CASN

M0_DDR_DQ10 M0_DDR_DQ11 M0_DDR_DQ12 M0_DDR_DQ13 M0_DDR_DQ14 M0_DDR_DQ15

M2_DDR_A10 M2_DDR_A11 M2_DDR_A12 M2_DDR_A13 M2_DDR_A14 M2_DDR_A15

M2_DDR_BA0 M2_DDR_BA1 M2_DDR_BA2

M2_DDR_CKE

M2_DDR_CS1 M2_DDR_ODT

M2_DDR_RASN

M2_DDR_CASN

M2_DDR_WEN

M2_DDR_DQ0 M2_DDR_DQ1 M2_DDR_DQ2 M2_DDR_DQ3 M2_DDR_DQ4 M2_DDR_DQ5 M2_DDR_DQ6 M2_DDR_DQ7

M2_DDR_DQ8

M2_DDR_DQ9 M2_DDR_DQ10 M2_DDR_DQ11 M2_DDR_DQ12 M2_DDR_DQ13 M2_DDR_DQ14 M2_DDR_DQ15

Hynix_DDR3_4Gb_29n

H5TQ4G63AFR-RDC

M0_DDR_A0 M0_DDR_A1 M0_DDR_A2 M0_DDR_A3 M0_DDR_A4 M0_DDR_A5 M0_DDR_A6 M0_DDR_A7 M0_DDR_A8

M0_DDR_A9 M0_DDR_A10 M0_DDR_A11 M0_DDR_A12 M0_DDR_A13 M0_DDR_A14 M0_DDR_A15

M0_DDR_BA0 M0_DDR_BA1 M0_DDR_BA2

M0_D_CLK

M0_D_CLKN M0_DDR_CKE

M0_DDR_CS1 M0_DDR_ODT

M0_DDR_WEN

M0_DDR_DQ0 M0_DDR_DQ1 M0_DDR_DQ2 M0_DDR_DQ3 M0_DDR_DQ4 M0_DDR_DQ5 M0_DDR_DQ6 M0_DDR_DQ7

M0_DDR_DQ8 M0_DDR_DQ9

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

T7

A14

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

+1.5V_Bypass Cap Close to DDR Power Pin

VDDC15_M0

C402 0.1uF

C400 0.1uF

C401 0.1uF

Hynix_DDR3_4Gb_29n

H5TQ4G63AFR-RDC

M2_DDR_A0 M2_DDR_A1 M2_DDR_A2 M2_DDR_A3 M2_DDR_A4 M2_DDR_A5 M2_DDR_A6 M2_DDR_A7 M2_DDR_A8 M2_DDR_A9

M2_D_CLK

M2_D_CLKN

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

T7

A14

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

+1.5V_Bypass Cap Close to DDR Power Pin

VDDC15_M1

C493 0.1uF

C492 0.1uF

C482 0.1uF

IC400

EAN63053201

DDR3 4Gbit (x16)

IC405

EAN63053201

DDR3 4Gbit (x16)

VREFCA

VREFDQ

VDDQ_1 VDDQ_2 VDDQ_3 VDDQ_4 VDDQ_5 VDDQ_6 VDDQ_7 VDDQ_8 VDDQ_9

VSS_10 VSS_11 VSS_12

VSSQ_1 VSSQ_2 VSSQ_3 VSSQ_4 VSSQ_5 VSSQ_6 VSSQ_7 VSSQ_8 VSSQ_9

VREFCA

VREFDQ

VDD_1 VDD_2 VDD_3 VDD_4 VDD_5 VDD_6 VDD_7 VDD_8 VDD_9

VDDQ_1 VDDQ_2 VDDQ_3 VDDQ_4 VDDQ_5 VDDQ_6 VDDQ_7 VDDQ_8 VDDQ_9

VSS_1 VSS_2 VSS_3 VSS_4 VSS_5 VSS_6 VSS_7 VSS_8

VSS_9 VSS_10 VSS_11 VSS_12

VSSQ_1 VSSQ_2 VSSQ_3 VSSQ_4 VSSQ_5 VSSQ_6 VSSQ_7 VSSQ_8 VSSQ_9

VDD_1 VDD_2 VDD_3 VDD_4 VDD_5 VDD_6 VDD_7 VDD_8 VDD_9

VSS_1 VSS_2 VSS_3 VSS_4 VSS_5 VSS_6 VSS_7 VSS_8 VSS_9

M0_DDR_VREFDQ

M8

H1

L8

R400

ZQ

VDDC15_M0

B2 D9 G7 K2 K8 N1 N9 R1 R9

A1 A8 C1 C9 D2 E9 F1 H2 H9

J1

NC_1

J9

NC_2

L1

NC_3

L9

NC_4

A9 B3 E1 G8 J2 J8 M1 M9 P1 P9 T1 T9

B1 B9 D1 D8 E2 E8 F9 G1 G9

240

C410

0.1uF

C411

0.1uF

DDR3 1.5V bypass Cap - Place these caps near Memory

SS_DDR3_4Gb_25n

Hynix_DDR3_4Gb_25n

IC400-*1

IC400-*2

K4B4G1646D-BCMA

H5TQ4G63CFR_RDC

M8

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

M8

N3

VREFCA

A0

P7

A1

P3

A2

H1

N2

H1

VREFDQ

A3

VREFDQ

P8

A4

P2

A5

R8

L8

A6

ZQ

R2

A7

T8

A8

R3

B2

A9

VDD_1

L7

D9

A10/AP

VDD_2

R7

G7

A11

VDD_3

K2

N7

K2

A12/BC

VDD_4

K8

T3

K8

VDD_5

A13

VDD_5

T7

N1

A14

VDD_6

N9

M7

VDD_7

NC_5

R1

VDD_8

R9

M2

VDD_9

BA0

N8

BA1

M3

BA2

A1

VDDQ_1

A8

J7

VDDQ_2

CK

C1

K7

VDDQ_3

CK

C9

K9

VDDQ_4

CKE

D2

VDDQ_5

E9

L2

VDDQ_6

CS

F1

K1

VDDQ_7

ODT

H2

J3

VDDQ_8

RAS

H9

K3

VDDQ_9

CAS

L3

WE

J1

NC_1

J9

T2

NC_2

RESET

L1

NC_3

L9

NC_4

T7

F3

NC_6

DQSL

G3

DQSL

A9

C7

VSS_1

DQSU

B3

B7

VSS_2

DQSU

E1

VSS_3

G8

E7

VSS_4

DML

J2

D3

VSS_5

DMU

J8

VSS_6

M1

E3

VSS_7

DQL0

M9

F7

VSS_8

DQL1

P1

F2

VSS_9

DQL2

P9

F8

VSS_10

DQL3

T1

H3

VSS_11

DQL4

T9

H8

VSS_12

DQL5

G2

DQL6

H7

DQL7

B1

VSSQ_1

B9

D7

VSSQ_2

DQU0

D1

C3

VSSQ_3

DQU1

D8

C8

VSSQ_4

DQU2

E2

C2

VSSQ_5

DQU3

E8

A7

VSSQ_6

DQU4

F9

A2

VSSQ_7

DQU5

G1

B8

VSSQ_8

DQU6

G9

A3

VSSQ_9

DQU7

M0_DDR_A0 M0_DDR_A1 M0_DDR_A2 M0_DDR_A3 M0_DDR_A4 M0_DDR_A5 M0_DDR_A6 M0_DDR_A7 M0_DDR_A8

M0_DDR_A9 M0_DDR_A10 M0_DDR_A11 M0_DDR_A12 M0_DDR_A13 M0_DDR_A14 M0_DDR_A15

M0_DDR_BA0 M0_DDR_BA1 M0_DDR_BA2

M0_D_CLK

M0_D_CLKN M0_DDR_CKE

M0_DDR_CS2 M0_DDR_ODT

M0_DDR_RASN M0_DDR_CASN

M0_DDR_WEN

M0_DDR_RESET_N

M0_DDR_DQS2

M0_DDR_DQS_N2

M0_DDR_DQS3

M0_DDR_DQS_N3

M0_DDR_DM2 M0_DDR_DM3

M0_DDR_DQ16 M0_DDR_DQ17 M0_DDR_DQ18 M0_DDR_DQ19 M0_DDR_DQ20 M0_DDR_DQ21 M0_DDR_DQ22 M0_DDR_DQ23

M0_DDR_DQ24 M0_DDR_DQ25 M0_DDR_DQ26 M0_DDR_DQ27 M0_DDR_DQ28 M0_DDR_DQ29 M0_DDR_DQ30 M0_DDR_DQ31

VDDC15_M0

M2_DDR_VREFDQ

M8

H1

L8

R406

N3 P7 P3 N2 P8 P2 R8 R2 T8 R3 L7 R7 N7 T3

M7

M2 N8 M3

J7 K7 K9

L2 K1 J3 K3 L3

T2

F3 G3

C7 B7

E7 D3

E3 F7 F2 F8 H3 H8 G2 H7

D7 C3 C8 C2 A7 A2 B8 A3

C502 C503

SS_DDR3_4Gb_25n

IC405-*1

K4B4G1646D-BCMA

A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10/AP A11 A12/BC A13

NC_5

BA0 BA1 BA2

CK CK CKE

CS ODT RAS CAS WE

RESET

DQSL DQSL

DQSU DQSU

DML DMU

DQL0 DQL1 DQL2 DQL3 DQL4 DQL5 DQL6 DQL7

DQU0 DQU1 DQU2 DQU3 DQU4 DQU5 DQU6 DQU7

240

0.1uF

DDR3 1.5V bypass Cap - Place these caps near Memory

Hynix_DDR3_4Gb_25n

SS_DDR3_2Gb

IC405-*2

IC405-*3

H5TQ4G63CFR_RDC

M8

VREFCA

H1

VREFDQ

L8

ZQ

B2

VDD_1

D9

VDD_2

G7

VDD_3

K2

VDD_4

K8

VDD_5

N1

VDD_6

N9

VDD_7

R1

VDD_8

R9

VDD_9

A1

VDDQ_1

A8

VDDQ_2

C1

VDDQ_3

C9

VDDQ_4

D2

VDDQ_5

E9

VDDQ_6

F1

VDDQ_7

H2

VDDQ_8

H9

VDDQ_9

J1

NC_1

J9

NC_2

L1

NC_3

L9

NC_4

T7

NC_6

A9

VSS_1

B3

VSS_2

E1

VSS_3

G8

VSS_4

J2

VSS_5

J8

VSS_6

M1

VSS_7

M9

VSS_8

P1

VSS_9

P9

VSS_10

T1

VSS_11

T9

VSS_12

B1

VSSQ_1

B9

VSSQ_2

D1

VSSQ_3

D8

VSSQ_4

E2

VSSQ_5

E8

VSSQ_6

F9

VSSQ_7

G1

VSSQ_8

G9

VSSQ_9

K4B2G1646Q-BCMA

M8

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

T7

A14

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

M8

N3

VREFCA

A0

P7

A1

P3

A2

H1

N2

VREFDQ

A3

P8

A4

P2

A5

L8

R8

L8

ZQ

A6

ZQ

R2

A7

T8

A8

R3

B2

A9

VDD_1

L7

D9

A10/AP

VDD_2

R7

G7

A11

VDD_3

K2

N7

A12/BC

VDD_4

K8

T3

VDD_5

A13

N1

VDD_6

N9

M7

VDD_7

NC_5

R1

VDD_8

R9

M2

VDD_9

BA0

N8

BA1

M3

BA2

A1

VDDQ_1

A8

J7

VDDQ_2

CK

C1

K7

VDDQ_3

CK

C9

K9

VDDQ_4

CKE

D2

VDDQ_5

E9

L2

VDDQ_6

CS

F1

K1

VDDQ_7

ODT

H2

J3

VDDQ_8

RAS

H9

K3

VDDQ_9

CAS

L3

WE

J1

NC_1

J9

T2

NC_2

RESET

L1

NC_3

L9

NC_4

T7

F3

NC_6

DQSL

G3

DQSL

A9

C7

VSS_1

DQSU

B3

B7

VSS_2

DQSU

E1

VSS_3

G8

E7

VSS_4

DML

J2

D3

VSS_5

DMU

J8

VSS_6

M1

E3

VSS_7

DQL0

M9

F7

VSS_8

DQL1

P1

F2

VSS_9

DQL2

P9

F8

VSS_10

DQL3

T1

H3

VSS_11

DQL4

T9

H8

VSS_12

DQL5

G2

DQL6

H7

DQL7

B1

VSSQ_1

B9

D7

VSSQ_2

DQU0

D1

C3

VSSQ_3

DQU1

D8

C8

VSSQ_4

DQU2

E2

C2

VSSQ_5

DQU3

E8

A7

VSSQ_6

DQU4

F9

A2

VSSQ_7

DQU5

G1

B8

VSSQ_8

DQU6

G9

A3

VSSQ_9

DQU7

ZQ

VDDC15_M1

B2 D9 G7 K2 K8 N1 N9 R1 R9

A1 A8 C1 C9 D2 E9 F1 H2 H9

J1

NC_1

J9

NC_2

L1

NC_3

L9

NC_4

A9 B3 E1 G8 J2 J8 M1 M9 P1 P9 T1 T9

B1 B9 D1 D8 E2 E8 F9 G1 G9

N3 P7 P3 N2 P8 P2 R8 R2 T8 R3 L7 R7 N7 T3 T7 M7

M2 N8 M3

J7 K7 K9

L2 K1 J3 K3 L3

T2

F3 G3

C7 B7

E7 D3

E3 F7 F2 F8 H3 H8 G2 H7

D7 C3 C8 C2 A7 A2 B8 A3

Hynix_DDR3_2Gb

IC405-*4

H5TQ2G63FFR-RDC

A0 A1 A2 A3 A4 A5 A6 A7 A8 A9 A10/AP A11 A12/BC A13 A14 NC_5

BA0 BA1 BA2

CK CK CKE

CS ODT RAS CAS WE

RESET

DQSL DQSL

DQSU DQSU

DML DMU

DQL0 DQL1 DQL2 DQL3 DQL4 DQL5 DQL6 DQL7

DQU0 DQU1 DQU2 DQU3 DQU4 DQU5 DQU6 DQU7

M8

VREFCA

H1

VREFDQ

L8

ZQ

B2

VDD_1

D9

VDD_2

G7

VDD_3

K2

VDD_4

K8

VDD_5

N1

VDD_6

N9

VDD_7

R1

VDD_8

R9

VDD_9

A1

VDDQ_1

A8

VDDQ_2

C1

VDDQ_3

C9

VDDQ_4

D2

VDDQ_5

E9

VDDQ_6

F1

VDDQ_7

H2

VDDQ_8

H9

VDDQ_9

J1

NC_1

J9

NC_2

L1

NC_3

L9

NC_4

A9

VSS_1

B3

VSS_2

E1

VSS_3

G8

VSS_4

J2

VSS_5

J8

VSS_6

M1

VSS_7

M9

VSS_8

P1

VSS_9

P9

VSS_10

T1

VSS_11

T9

VSS_12

B1

VSSQ_1

B9

VSSQ_2

D1

VSSQ_3

D8

VSSQ_4

E2

VSSQ_5

E8

VSSQ_6

F9

VSSQ_7

G1

VSSQ_8

G9

VSSQ_9

M2_DDR_A0 M2_DDR_A1 M2_DDR_A2 M2_DDR_A3 M2_DDR_A4 M2_DDR_A5 M2_DDR_A6 M2_DDR_A7 M2_DDR_A8 M2_DDR_A9

M2_DDR_A10 M2_DDR_A11 M2_DDR_A12 M2_DDR_A13 M2_DDR_A14 M2_DDR_A15

M2_DDR_BA0 M2_DDR_BA1 M2_DDR_BA2

M2_D_CLK

M2_D_CLKN

M2_DDR_CKE

M2_DDR_CS2

M2_DDR_ODT M2_DDR_RASN M2_DDR_CASN

M2_DDR_WEN

M2_DDR_RESET_N

M2_DDR_DQS2

M2_DDR_DQS_N2

M2_DDR_DQS3

M2_DDR_DQS_N3

M2_DDR_DM2

M2_DDR_DM3

M2_DDR_DQ16 M2_DDR_DQ17 M2_DDR_DQ18 M2_DDR_DQ19 M2_DDR_DQ20 M2_DDR_DQ21 M2_DDR_DQ22 M2_DDR_DQ23

M2_DDR_DQ24 M2_DDR_DQ25 M2_DDR_DQ26 M2_DDR_DQ27 M2_DDR_DQ28 M2_DDR_DQ29 M2_DDR_DQ30 M2_DDR_DQ31

VDDC15_M1

Hynix_DDR3_4Gb_29n

IC401

H5TQ4G63AFR-RDC

EAN63053201

N3

DDR3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

T7

A14

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

+1.5V_Bypass Cap Close to DDR Power Pin

C412 0.1uF

C413 0.1uF

C415 0.1uF

Hynix_DDR3_4Gb_29n

H5TQ4G63AFR-RDC

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

T7

A14

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

+1.5V_Bypass Cap Close to DDR Power Pin

C506 0.1uF

C504 0.1uF

C505 0.1uF

4Gbit (x16)

IC406

EAN63053201

DDR3 4Gbit (x16)

VREFCA

VREFDQ

VDDQ_1 VDDQ_2 VDDQ_3 VDDQ_4 VDDQ_5 VDDQ_6 VDDQ_7 VDDQ_8 VDDQ_9

VSS_10 VSS_11 VSS_12

VSSQ_1 VSSQ_2 VSSQ_3 VSSQ_4 VSSQ_5 VSSQ_6 VSSQ_7 VSSQ_8 VSSQ_9

VREFCA

VREFDQ

VDD_1 VDD_2 VDD_3 VDD_4 VDD_5 VDD_6 VDD_7 VDD_8 VDD_9

VDDQ_1 VDDQ_2 VDDQ_3 VDDQ_4 VDDQ_5 VDDQ_6 VDDQ_7 VDDQ_8 VDDQ_9

VSS_1 VSS_2 VSS_3 VSS_4 VSS_5 VSS_6 VSS_7 VSS_8

VSS_9 VSS_10 VSS_11 VSS_12

VSSQ_1 VSSQ_2 VSSQ_3 VSSQ_4 VSSQ_5 VSSQ_6 VSSQ_7 VSSQ_8 VSSQ_9

VDD_1 VDD_2 VDD_3 VDD_4 VDD_5 VDD_6 VDD_7 VDD_8 VDD_9

VSS_1 VSS_2 VSS_3 VSS_4 VSS_5 VSS_6 VSS_7 VSS_8 VSS_9

M0_1_DDR_VREFDQ

M8

H1

L8

R403

ZQ

VDDC15_M0 B2 D9 G7 K2 K8 N1 N9 R1 R9

A1 A8 C1 C9 D2 E9 F1 H2 H9

J1

NC_1

J9

NC_2

L1

NC_3

L9

NC_4

A9 B3 E1 G8 J2 J8 M1 M9 P1 P9 T1 T9

B1 B9 D1 D8 E2 E8 F9 G1 G9

240

C440

0.1uF

C441

0.1uF

DDR3 1.5V bypass Cap - Place these caps near Memory

SS_DDR3_4Gb_25n

Hynix_DDR3_4Gb_25n

IC401-*1

IC401-*2

K4B4G1646D-BCMA

H5TQ4G63CFR_RDC

M8

N3

VREFCA

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

M8

N3

VREFCA

A0

P7

A1

P3

H1

A2

VREFDQ

N2

H1

A3

VREFDQ

P8

A4

P2

L8

A5

ZQ

R8

L8

A6

ZQ

R2

A7

T8

B2

A8

VDD_1

R3

B2

D9

A9

VDD_1

VDD_2

L7

D9

G7

A10/AP

VDD_2

VDD_3

R7

G7

K2

A11

VDD_3

VDD_4

N7

K2

K8

A12/BC

VDD_4

VDD_5

T3

K8

N1

A13

VDD_5

VDD_6

T7

N1

N9

A14

VDD_6

VDD_7

N9

M7

R1

VDD_7

NC_5

VDD_8

R1

R9

VDD_8

VDD_9

R9

M2

VDD_9

BA0

N8

BA1

M3

A1

BA2

VDDQ_1

A1

A8

VDDQ_1

VDDQ_2

A8

J7

C1

VDDQ_2

CK

VDDQ_3

C1

K7

C9

VDDQ_3

CK

VDDQ_4

C9

K9

D2

VDDQ_4

CKE

VDDQ_5

D2

E9

VDDQ_5

VDDQ_6

E9

L2

F1

VDDQ_6

CS

VDDQ_7

F1

K1

H2

VDDQ_7

ODT

VDDQ_8

H2

J3

H9

VDDQ_8

RAS

VDDQ_9

H9

K3

VDDQ_9

CAS

L3

J1

WE

NC_1

J1

J9

NC_1

NC_2

J9

T2

L1

NC_2

RESET

NC_3

L1

L9

NC_3

NC_4

L9

T7

NC_4

NC_6

F3

DQSL

G3

DQSL

A9

VSS_1

A9

C7

B3

VSS_1

DQSU

VSS_2

B3

B7

E1

VSS_2

DQSU

VSS_3

E1

G8

VSS_3

VSS_4

G8

E7

J2

VSS_4

DML

VSS_5

J2

D3

J8

VSS_5

DMU

VSS_6

J8

M1

VSS_6

VSS_7

M1

E3

M9

VSS_7

DQL0

VSS_8

M9

F7

P1

VSS_8

DQL1

VSS_9

P1

F2

P9

VSS_9

DQL2

VSS_10

P9

F8

T1

VSS_10

DQL3

VSS_11

T1

H3

T9

VSS_11

DQL4

VSS_12

T9

H8

VSS_12

DQL5

G2

DQL6

H7

B1

DQL7

VSSQ_1

B1

B9

VSSQ_1

VSSQ_2

B9

D7

D1

VSSQ_2

DQU0

VSSQ_3

D1

C3

D8

VSSQ_3

DQU1

VSSQ_4

D8

C8

E2

VSSQ_4

DQU2

VSSQ_5

E2

C2

E8

VSSQ_5

DQU3

VSSQ_6

E8

A7

F9

VSSQ_6

DQU4

VSSQ_7

F9

A2

G1

VSSQ_7

DQU5

VSSQ_8

G1

B8

G9

VSSQ_8

DQU6

VSSQ_9

G9

A3

VSSQ_9

DQU7

M1_DDR_RESET_N

M1_DDR_DQS0

M1_DDR_DQS_N0

M1_DDR_DQS1

M1_DDR_DQS_N1

M1_DDR_DM0 M1_DDR_DM1

M1_DDR_A0 M1_DDR_A1 M1_DDR_A2 M1_DDR_A3 M1_DDR_A4 M1_DDR_A5 M1_DDR_A6 M1_DDR_A7 M1_DDR_A8

M1_DDR_A9 M1_DDR_A10 M1_DDR_A11 M1_DDR_A12 M1_DDR_A13 M1_DDR_A14 M1_DDR_A15

M1_DDR_BA0 M1_DDR_BA1 M1_DDR_BA2

M1_D_CLK

M1_D_CLKN M1_DDR_CKE

M1_DDR_CS1 M1_DDR_ODT

M1_DDR_RASN M1_DDR_CASN

M1_DDR_WEN

M1_DDR_DQ0 M1_DDR_DQ1 M1_DDR_DQ2 M1_DDR_DQ3 M1_DDR_DQ4 M1_DDR_DQ5 M1_DDR_DQ6 M1_DDR_DQ7

M1_DDR_DQ8 M1_DDR_DQ9

M1_DDR_DQ10 M1_DDR_DQ11 M1_DDR_DQ12 M1_DDR_DQ13 M1_DDR_DQ14 M1_DDR_DQ15

Hynix_DDR3_4Gb_29n

IC403

H5TQ4G63AFR-RDC

EAN63053201

N3

DDR3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

T7

A14

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

+1.5V_Bypass Cap Close to DDR Power Pin

4Gbit (x16)

VREFCA

VREFDQ

VDD_1 VDD_2 VDD_3 VDD_4 VDD_5 VDD_6 VDD_7 VDD_8 VDD_9

VDDQ_1 VDDQ_2 VDDQ_3 VDDQ_4 VDDQ_5 VDDQ_6 VDDQ_7 VDDQ_8 VDDQ_9

VSS_1 VSS_2 VSS_3 VSS_4 VSS_5 VSS_6 VSS_7 VSS_8

VSS_9 VSS_10 VSS_11 VSS_12

VSSQ_1 VSSQ_2 VSSQ_3 VSSQ_4 VSSQ_5 VSSQ_6 VSSQ_7 VSSQ_8 VSSQ_9

NC_1 NC_2 NC_3 NC_4

VDDC15_M0

C444 0.1uF

C445 0.1uF

C446 0.1uF

M2_1_DDR_VREFDQ

M8

H1

L8

R407

ZQ

VDDC15_M1 B2 D9 G7 K2 K8 N1 N9 R1 R9

A1 A8 C1 C9 D2 E9 F1 H2 H9

J1

NC_1

J9

NC_2

L1

NC_3

L9

NC_4

A9 B3 E1 G8 J2 J8 M1 M9 P1 P9 T1 T9

B1 B9 D1 D8 E2 E8 F9 G1 G9

240

C514

0.1uF

C515

0.1uF

DDR3 1.5V bypass Cap - Place these caps near Memory

SS_DDR3_4Gb_25n

Hynix_DDR3_4Gb_25n

IC406-*1

IC406-*2

K4B4G1646D-BCMA

H5TQ4G63CFR_RDC

M8

VREFCA

VREFDQ

ZQ

VDD_1 VDD_2 VDD_3 VDD_4 VDD_5 VDD_6 VDD_7 VDD_8 VDD_9

VDDQ_1 VDDQ_2 VDDQ_3 VDDQ_4 VDDQ_5 VDDQ_6 VDDQ_7 VDDQ_8 VDDQ_9

NC_1 NC_2 NC_3 NC_4 NC_6

VSS_1 VSS_2 VSS_3 VSS_4 VSS_5 VSS_6 VSS_7 VSS_8 VSS_9 VSS_10 VSS_11 VSS_12

VSSQ_1 VSSQ_2 VSSQ_3 VSSQ_4 VSSQ_5 VSSQ_6 VSSQ_7 VSSQ_8 VSSQ_9

K4B2G1646Q-BCMA

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

SS_DDR3_2Gb

M8

N3

VREFCA

A0

P7

A1

P3

A2

H1

N2

VREFDQ

A3

P8

A4

P2

A5

L8

R8

L8

A6

ZQ

R2

A7

T8

A8

R3

B2

A9

VDD_1

L7

D9

A10/AP

VDD_2

R7

G7

A11

VDD_3

K2

N7

A12/BC

VDD_4

K8

T3

VDD_5

A13

T7

N1

A14

VDD_6

N9

M7

VDD_7

NC_5

R1

VDD_8

R9

M2

VDD_9

BA0

N8

BA1

M3

BA2

A1

VDDQ_1

A8

J7

VDDQ_2

CK

C1

K7

VDDQ_3

CK

C9

K9

VDDQ_4

CKE

D2

VDDQ_5

E9

L2

VDDQ_6

CS

F1

K1

VDDQ_7

ODT

H2

J3

VDDQ_8

RAS

H9

K3

VDDQ_9

CAS

L3

WE

J1

NC_1

J9

T2

NC_2

RESET

L1

NC_3

L9

NC_4

T7

F3

DQSL

G3

DQSL

A9

C7

VSS_1

DQSU

B3

B7

VSS_2

DQSU

E1

VSS_3

G8

E7

VSS_4

DML

J2

D3

VSS_5

DMU

J8

VSS_6

M1

E3

VSS_7

DQL0

M9

F7

VSS_8

DQL1

P1

F2

VSS_9

DQL2

P9

F8

VSS_10

DQL3

T1

H3

VSS_11

DQL4

T9

H8

VSS_12

DQL5

G2

DQL6

H7

DQL7

B1

VSSQ_1

B9

D7

VSSQ_2

DQU0

D1

C3

VSSQ_3

DQU1

D8

C8

VSSQ_4

DQU2

E2

C2

VSSQ_5

DQU3

E8

A7

VSSQ_6

DQU4

F9

A2

VSSQ_7

DQU5

G1

B8

VSSQ_8

DQU6

G9

A3

VSSQ_9

DQU7

Hynix_DDR3_2Gb

IC406-*3

IC406-*4

H5TQ2G63FFR-RDC

M8

N3

VREFCA

A0

P7

A1

P3

A2

H1

N2

VREFDQ

A3

P8

A4

P2

A5

L8

R8

ZQ

A6

R2

A7

T8

A8

R3

B2

A9

VDD_1

L7

D9

A10/AP

VDD_2

R7

G7

A11

VDD_3

K2

N7

A12/BC

VDD_4

K8

T3

VDD_5

A13

T7

N1

A14

VDD_6

N9

M7

VDD_7

NC_5

R1

VDD_8

R9

M2

VDD_9

BA0

N8

BA1

M3

BA2

A1

VDDQ_1

A8

J7

VDDQ_2

CK

C1

K7

VDDQ_3

CK

C9

K9

VDDQ_4

CKE

D2

VDDQ_5

E9

L2

VDDQ_6

CS

F1

K1

VDDQ_7

ODT

H2

J3

VDDQ_8

RAS

H9

K3

VDDQ_9

CAS

L3

WE

J1

NC_1

J9

T2

NC_2

RESET

L1

NC_3

L9

NC_4

T7

F3

NC_6

DQSL

G3

DQSL

A9

C7

VSS_1

DQSU

B3

B7

VSS_2

DQSU

E1

VSS_3

G8

E7

VSS_4

DML

J2

D3

VSS_5

DMU

J8

VSS_6

M1

E3

VSS_7

DQL0

M9

F7

VSS_8

DQL1

P1

F2

VSS_9

DQL2

P9

F8

VSS_10

DQL3

T1

H3

VSS_11

DQL4

T9

H8

VSS_12

DQL5

G2

DQL6

H7

DQL7

B1

VSSQ_1

B9

D7

VSSQ_2

DQU0

D1

C3

VSSQ_3

DQU1

D8

C8

VSSQ_4

DQU2

E2

C2

VSSQ_5

DQU3

E8

A7

VSSQ_6

DQU4

F9

A2

VSSQ_7

DQU5

G1

B8

VSSQ_8

DQU6

G9

A3

VSSQ_9

DQU7

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

M1_DDR_A0 M1_DDR_A1 M1_DDR_A2 M1_DDR_A3 M1_DDR_A4 M1_DDR_A5 M1_DDR_A6 M1_DDR_A7 M1_DDR_A8

M1_DDR_A9 M1_DDR_A10 M1_DDR_A11 M1_DDR_A12 M1_DDR_A13 M1_DDR_A14 M1_DDR_A15

M1_DDR_BA0 M1_DDR_BA1 M1_DDR_BA2

M1_D_CLK

M1_D_CLKN M1_DDR_CKE

M1_DDR_CS2 M1_DDR_ODT

M1_DDR_RASN M1_DDR_CASN

M1_DDR_WEN

M1_DDR_RESET_N

M1_DDR_DQS2

M1_DDR_DQS_N2

M1_DDR_DQS3

M1_DDR_DQS_N3

M1_DDR_DM2 M1_DDR_DM3

M1_DDR_DQ16 M1_DDR_DQ17 M1_DDR_DQ18 M1_DDR_DQ19 M1_DDR_DQ20 M1_DDR_DQ21 M1_DDR_DQ22 M1_DDR_DQ23

M1_DDR_DQ24 M1_DDR_DQ25 M1_DDR_DQ26 M1_DDR_DQ27 M1_DDR_DQ28 M1_DDR_DQ29 M1_DDR_DQ30 M1_DDR_DQ31

M8

VREFCA

H1

VREFDQ

L8

ZQ

B2

VDD_1

D9

VDD_2

G7

VDD_3

K2

VDD_4

K8

VDD_5

N1

VDD_6

N9

VDD_7

R1

VDD_8

R9

VDD_9

A1

VDDQ_1

A8

VDDQ_2

C1

VDDQ_3

C9

VDDQ_4

D2

VDDQ_5

E9

VDDQ_6

F1

VDDQ_7

H2

VDDQ_8

H9

VDDQ_9

J1

NC_1

J9

NC_2

L1

NC_3

L9

NC_4

A9

VSS_1

B3

VSS_2

E1

VSS_3

G8

VSS_4

J2

VSS_5

J8

VSS_6

M1

VSS_7

M9

VSS_8

P1

VSS_9

P9

VSS_10

T1

VSS_11

T9

VSS_12

B1

VSSQ_1

B9

VSSQ_2

D1

VSSQ_3

D8

VSSQ_4

E2

VSSQ_5

E8

VSSQ_6

F9

VSSQ_7

G1

VSSQ_8

G9

VSSQ_9

Hynix_DDR3_4Gb_29n

IC404

H5TQ4G63AFR-RDC

EAN63053201

N3

DDR3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

T7

A14

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

+1.5V_Bypass Cap Close to DDR Power Pin

4Gbit (x16)

VREFCA

VREFDQ

VDD_1 VDD_2 VDD_3 VDD_4 VDD_5 VDD_6 VDD_7 VDD_8 VDD_9

VDDQ_1 VDDQ_2 VDDQ_3 VDDQ_4 VDDQ_5 VDDQ_6 VDDQ_7 VDDQ_8 VDDQ_9

VSS_1 VSS_2 VSS_3 VSS_4 VSS_5 VSS_6 VSS_7 VSS_8

VSS_9 VSS_10 VSS_11 VSS_12

VSSQ_1 VSSQ_2 VSSQ_3 VSSQ_4 VSSQ_5 VSSQ_6 VSSQ_7 VSSQ_8 VSSQ_9

NC_1 NC_2 NC_3 NC_4

VDDC15_M0

C475 0.1uF

C476 0.1uF

C480 0.1uF

M1_DDR_VREFDQ

DDR_VTT

AR400

M8

H1

L8

R404

ZQ

VDDC15_M0

B2 D9 G7 K2 K8 N1 N9 R1 R9

A1 A8 C1 C9 D2 E9 F1 H2 H9

J1 J9 L1 L9

A9 B3 E1 G8 J2 J8 M1 M9 P1 P9 T1 T9

B1 B9 D1 D8 E2 E8 F9 G1 G9

240

C468

0.1uF

C469

0.1uF

DDR3 1.5V bypass Cap - Place these caps near Memory

SS_DDR3_4Gb_25n

Hynix_DDR3_4Gb_25n

IC403-*1

IC403-*2

K4B4G1646D-BCMA

H5TQ4G63CFR_RDC

M8

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

M8

N3

VREFCA

A0

P7

A1

P3

A2

H1

N2

H1

VREFDQ

A3

VREFDQ

P8

A4

P2

A5

R8

L8

A6

ZQ

R2

A7

T8

A8

R3

B2

A9

VDD_1

L7

D9

A10/AP

VDD_2

R7

G7

A11

VDD_3

K2

N7

K2

A12/BC

VDD_4

K8

T3

K8

VDD_5

A13

VDD_5

T7

N1

A14

VDD_6

N9

M7

VDD_7

NC_5

R1

VDD_8

R9

M2

VDD_9

BA0

N8

BA1

M3

BA2

A1

VDDQ_1

A8

J7

VDDQ_2

CK

C1

K7

VDDQ_3

CK

C9

K9

VDDQ_4

CKE

D2

VDDQ_5

E9

L2

VDDQ_6

CS

F1

K1

VDDQ_7

ODT

H2

J3

VDDQ_8

RAS

H9

K3

VDDQ_9

CAS

L3

WE

J1

NC_1

J9

T2

NC_2

RESET

L1

NC_3

L9

NC_4

T7

F3

NC_6

DQSL

G3

DQSL

A9

C7

VSS_1

DQSU

B3

B7

VSS_2

DQSU

E1

VSS_3

G8

E7

VSS_4

DML

J2

D3

VSS_5

DMU

J8

VSS_6

M1

E3

VSS_7

DQL0

M9

F7

VSS_8

DQL1

P1

F2

VSS_9

DQL2

P9

F8

VSS_10

DQL3

T1

H3

VSS_11

DQL4

T9

H8

VSS_12

DQL5

G2

DQL6

H7

DQL7

B1

VSSQ_1

B9

D7

VSSQ_2

DQU0

D1

C3

VSSQ_3

DQU1

D8

C8

VSSQ_4

DQU2

E2

C2

VSSQ_5

DQU3

E8

A7

VSSQ_6

DQU4

F9

A2

VSSQ_7

DQU5

G1

B8

VSSQ_8

DQU6

G9

A3

VSSQ_9

DQU7

M1_1_DDR_VREFDQ

M8

H1

L8

R419

ZQ

VDDC15_M0 B2 D9 G7 K2 K8 N1 N9 R1 R9

A1 A8 C1 C9 D2 E9 F1 H2 H9

J1 J9 L1 L9

A9 B3 E1 G8 J2 J8 M1 M9 P1 P9 T1 T9

B1 B9 D1 D8 E2 E8 F9 G1 G9

240

C490

0.1uF

C491

0.1uF

DDR3 1.5V bypass Cap - Place these caps near Memory

SS_DDR3_4Gb_25n

Hynix_DDR3_4Gb_25n

IC404-*1

IC404-*2

K4B4G1646D-BCMA

H5TQ4G63CFR_RDC

M8

N3

A0

P7

A1

P3

A2

N2

A3

P8

A4

P2

A5

R8

A6

R2

A7

T8

A8

R3

A9

L7

A10/AP

R7

A11

N7

A12/BC

T3

A13

M7

NC_5

M2

BA0

N8

BA1

M3

BA2

J7

CK

K7

CK

K9

CKE

L2

CS

K1

ODT

J3

RAS

K3

CAS

L3

WE

T2

RESET

F3

DQSL

G3

DQSL

C7

DQSU

B7

DQSU

E7

DML

D3

DMU

E3

DQL0

F7

DQL1

F2

DQL2

F8

DQL3

H3

DQL4

H8

DQL5

G2

DQL6

H7

DQL7

D7

DQU0

C3

DQU1

C8

DQU2

C2

DQU3

A7

DQU4

A2

DQU5

B8

DQU6

A3

DQU7

M8

N3

VREFCA

A0

P7

A1

P3

A2

H1

N2

H1

VREFDQ

A3

VREFDQ

P8

A4

P2

A5

R8

L8

A6

ZQ

R2

A7

T8

A8

R3

B2

A9

VDD_1

L7

D9

A10/AP

VDD_2

R7

G7

A11

VDD_3

K2

N7

K2

A12/BC

VDD_4

K8

T3

K8

VDD_5

A13

VDD_5

T7

N1

A14

VDD_6

N9

M7

VDD_7

NC_5

R1

VDD_8

R9

M2

VDD_9

BA0

N8

BA1

M3

BA2

A1

VDDQ_1

A8

J7

VDDQ_2

CK

C1

K7

VDDQ_3

CK

C9

K9

VDDQ_4

CKE

D2

VDDQ_5

E9

L2

VDDQ_6

CS

F1

K1

VDDQ_7

ODT

H2

J3

VDDQ_8

RAS

H9

K3

VDDQ_9

CAS

L3

WE

J1

NC_1

J9

T2

NC_2

RESET

L1

NC_3

L9

NC_4

T7

F3

NC_6

DQSL

G3

DQSL

A9

C7

VSS_1

DQSU

B3

B7

VSS_2

DQSU

E1

VSS_3

G8

E7

VSS_4

DML

J2

D3

VSS_5

DMU

J8

VSS_6

M1

E3

VSS_7

DQL0

M9

F7

VSS_8

DQL1

P1

F2

VSS_9

DQL2

P9

F8

VSS_10

DQL3

T1

H3

VSS_11

DQL4

T9

H8

VSS_12

DQL5

G2

DQL6

H7

DQL7

B1

VSSQ_1

B9

D7

VSSQ_2

DQU0

D1

C3

VSSQ_3

DQU1

D8

C8

VSSQ_4

DQU2

E2

C2

VSSQ_5

DQU3

E8

A7

VSSQ_6

DQU4

F9

A2

VSSQ_7

DQU5

G1

B8

VSSQ_8

DQU6

G9

A3

VSSQ_9

DQU7

* DDR_VTT

VDDC15_M0

DDR_VTT

R443 10K

1/16W 1%

L400

CIS2 1J121

C417

C414

C535

10uF

25V

C421 10uF 10V

1%

10K

R444

1/16W

M0_DDR_A14

M0_DDR_A8

M0_DDR_A11

M0_DDR_A6

M0_DDR_A1

M0_DDR_A4 M0_DDR_A12 M0_DDR_BA1

M0_DDR_A13

M0_DDR_A9

M0_DDR_A7

M0_DDR_A2

M0_DDR_A5

M0_DDR_A3

M0_DDR_A0

M0_DDR_BA0 M0_DDR_BA2 M0_DDR_A15 M0_DDR_A10

M0_DDR_WEN

M0_DDR_CASN

M0_DDR_ODT

M0_DDR_RASN

M0_DDR_CKE

M0_D_CLKN

M0_D_CLK

M2_DDR_A14

M2_DDR_A8

M2_DDR_A11

M2_DDR_A6

M2_DDR_A1

M2_DDR_A4 M2_DDR_A12 M2_DDR_BA1

M2_DDR_A13

M2_DDR_A9

M2_DDR_A7

M2_DDR_A2

M2_DDR_A5

M2_DDR_A3

M2_DDR_A0

M2_DDR_BA0 M2_DDR_BA2 M2_DDR_A15 M2_DDR_A10

M2_DDR_WEN

M2_DDR_CASN

M2_DDR_ODT

M2_DDR_RASN

M2_DDR_CKE

M2_D_CLKN

M2_D_CLK

AP2303MPTR-G1

VIN

GND

VREFEN

VOUT

C543

0.1uF 16V

56

AR414 56 1/16W

AR415 56 1/16W

AR416 56 1/16W

AR417 56 1/16W

AR418 56 1/16W

AR419 56 1/16W

AR420 56 1/16W

1/16W

AR401 56 1/16W

AR402 56 1/16W

AR403 56 1/16W

AR404 56 1/16W

AR405 56 1/16W

AR406 56 1/16W

DDR_VTT_1

C424 0.1uF

C425 0.1uF

C426 0.1uF

C427 0.1uF

C428 0.1uF

C429 0.1uF

C430 0.1uF

C431 0.1uF

C432 0.1uF

C433 0.1uF

C434 0.1uF

C435 0.1uF

C436 0.1uF

C437 0.1uF

C520 0.1uF

C521 0.1uF

C522 0.1uF

C523 0.1uF

C524 0.1uF

C525 0.1uF

C526 0.1uF

C527 0.1uF

C528 0.1uF

C529 0.1uF

C530 0.1uF

C531 0.1uF

C532 0.1uF

M1_DDR_A14

M1_DDR_A8

M1_DDR_A11

M1_DDR_A6

M1_DDR_A1

M1_DDR_A4 M1_DDR_A12 M1_DDR_BA1

M1_DDR_A13

M1_DDR_A9

M1_DDR_A7

M1_DDR_A2

M1_DDR_A5

M1_DDR_A3

M1_DDR_A0

M1_DDR_BA0 M1_DDR_BA2 M1_DDR_A15 M1_DDR_A10

M1_DDR_WEN

M1_DDR_CASN

M1_DDR_ODT

M1_DDR_RASN

M1_DDR_CKE

M1_D_CLKN

M1_D_CLK

VDDC15_M0

VDDC15_M1

1K

C533 0.1uF

+3.3V_NORMAL

VDDC15_M0

M0_1_DDR_VREFDQ

R416

1K 1%

C479

0.1uF C483 1000pF 50V

R417

1K 1%

VDDC15_M0

M1_1_DDR_VREFDQ

R414

1K 1%

C518

0.1uF C519

1000pF 50V

R415

1K 1%

VDDC15_M1

C544 10uF

L401

10V

DDR_VTT_1

CIS2 1J121

C536 10uF 25V

R446 10K

L402

1/16W 1%

CIS2 1J121

C541

C542

10uF

1%

25V

1/16W

VDDC15_M0

M0_DDR_VREFDQ

R410

1K 1%

C472

0.1uF C474 1000pF

R411

50V

1K 1%

VDDC15_M0

M1_DDR_VREFDQ

R408

1K 1%

C516

0.1uF C517 1000pF

R409

50V

1K 1%

IC402

[EP]

NC_3

1

8

NC_2

9

2

7

THERMAL

VCNTL

3

6

NC_1

4

5

LM15U

AR407 56 1/16W

AR408 56 1/16W

AR409 56 1/16W

AR410 56 1/16W

AR411 56 1/16W

AR412 56 1/16W

AR413 56 1/16W

R405

M0_DDR_RESET_N

R422

R420

C537 10uF 10V

C546

0.1uF

10K

R445

16V

M1_DDR_RESET_N

M2_DDR_RESET_N

VDDC15_M1

R425

1K 1%

R426

1K 1%

VIN

GND

VREFEN

VOUT

DDR_VTT

C453 0.1uF

C454 0.1uF

C455 0.1uF

C456 0.1uF

C457 0.1uF

C458 0.1uF

C459 0.1uF

C460 0.1uF

C461 0.1uF

C462 0.1uF

C463 0.1uF

C464 0.1uF

C465 0.1uF

C466 0.1uF

M0_DDR_CKE

R412 56 1%

R413 56 1%

M1_DDR_CKE

M2_DDR_CKE

M2_DDR_VREFDQ

C470

0.1uF C471 1000pF 50V

IC407

AP2303MPTR-G1

1

9

2

THERMAL

3

4

C477

0.01uF 50V

R427 56 1%

R428 56 1%

R421 56 1%

R423 56 1%

[EP]

NC_3

8

NC_2

7

VCNTL

6

NC_1

5

1K

R418

M0_D_CLK

M0_D_CLKN

1K

R433

M1_D_CLK

C497

0.01uF 50V

M1_D_CLKN

1K

R424

M2_D_CLK

C534

0.01uF 50V

M2_D_CLKN

VDDC15_M1

R431

1K 1%

R432

1K 1%

+3.3V_NORMAL

2014-12-18

M2_1_DDR_VREFDQ

C473

0.1uF C478

1000pF 50V

L403

CIS2 1J121

C545 10uF 10V

MAIN3_DDR 4

COMPENSATION_DONE_1

LGE Internal Use Only

DPC_CTRL

12V_ON

OLED

TDI0

TDI0_1

R602 0

R603 0 OPT

+3.3V_NORMAL

Jtag I/F

JTAG

1K

R614

For Main

JTAG

1K

R616

TRST_N0 TDI0 TDO0 TMS0 TCK0 SOC_RESET

Clock for MSD808KWD

MAIN Clock(24Mhz)

5pF

C614

5pF

C615

System Clock for Analog block(24Mhz)

GND_1

2

3

X-TAL_2

X-TAL_1

1

4

GND_2

24MHz

X600

R635

1M

XIN_MAIN

XOUT_MAIN

C600

0.1uF

SW600

JS2235S

1

OPT

2

3

JTAG

6

5

4

R604 0

R605 0 OPT

TDO0

OPT

TDO0_1

JTAG

P600

12505WS-10A00

JTAG

11

1

2

3

4

5

6

7

8

9

10

JTAG

1K

R612

1K

JTAG

R609

MHL Port

TMS0

TDI0_1

D0-_HDMI3 D0+_HDMI3 D1-_HDMI3 D1+_HDMI3 D2-_HDMI3 D2+_HDMI3 CK-_HDMI3 CK+_HDMI3 DDC_SCL_3 DDC_SDA_3

HDMI_HPD_3

I2C_SCL5

D0-_HDMI2 D0+_HDMI2 D1-_HDMI2 D1+_HDMI2 D2-_HDMI2 D2+_HDMI2 CK-_HDMI2 CK+_HDMI2 DDC_SCL_2 DDC_SDA_2

HDMI_HPD_2

I2C_SDA5

I2C_SCL4 I2C_SDA4

CPU_VID1

CORE_VID1

D0-_HDMI1 D0+_HDMI1 D1-_HDMI1 D1+_HDMI1 D2-_HDMI1 D2+_HDMI1 CK-_HDMI1 CK+_HDMI1 DDC_SCL_1 DDC_SDA_1

HDMI_HPD_1

JTAG R600

SPDIF_OUT

JTAG R601

0

R636 0 R637 0

R607 0

R617 0

T2

RXA0N

T3

RXA0P

U2

RXA1N

U3

RXA1P

V2

RXA2N

V1

RXA2P

R3

RXACKN

T1

RXACKP

W1

DDCDA_CK/GPIO42

W2

DDCDA_DA/GPIO43

V3

HOTPLUGA/GPIO34

W3

CEC/GPIO5

N2

RXB0N

N3

RXB0P

P2

RXB1N

P3

RXB1P

R2

RXB2N

R1

RXB2P

M3

RXBCKN

N1

RXBCKP

V5

DDCDB_CK/GPIO44

V6

DDCDB_DA/GPIO45

U4

HOTPLUGB/GPIO35

W6

CEC_1/GPIO6

G2

RXC0N

G3

RXC0P

H2

RXC1N

H3

RXC1P

J2

RXC2N

J1

RXC2P

F3

RXCCKN

G1

RXCCKP

R5

DDCDC_CK/GPIO46

R6

DDCDC_DA/GPIO47

P4

HOTPLUGC/GPIO36

T6

CEC_2/GPIO7

K2

RXD0N

K3

RXD0P

L2

RXD1N

L3

RXD1P

M2

RXD2N

M1

RXD2P

J3

RXDCKN

K1

RXDCKP

T5

DDCDD_CK/GPIO48

T4

DDCDD_DA/GPIO49

U6

HOTPLUGD/GPIO37

U5

CEC_3/GPIO8

F14

SPDIF_IN/GPIO101

G14

SPDIF_OUT/GPIO102

IC100

LGE5331(LM15U)

I2S_OUT_BCK/GPIO105 I2S_OUT_MCK/GPIO104

I2S_OUT_WS/GPIO103

I2S_OUT_SD/GPIO106 I2S_OUT_SD1/GPIO107 I2S_OUT_SD2/GPIO108 I2S_OUT_SD3/GPIO109

LINE_IN_0L LINE_IN_0R LINE_IN_1L LINE_IN_1R LINE_IN_2L LINE_IN_2R LINE_IN_3L LINE_IN_3R

LINE_OUT_0L LINE_OUT_0R LINE_OUT_2L LINE_OUT_2R

EARPHONE_OUT_L EARPHONE_OUT_R

ARC0

AUVAG AUVRM

I2S_IN_BCK/GPIO99 I2S_IN_SD/GPIO100

I2S_IN_WS/GPIO98

GPIO_PM14/GPIO27 GPIO_PM15/GPIO28 GPIO_PM16/GPIO29

IC100

LGE5331(LM15U)

AG2 AG1 AG3 AH1 AH2 AH3 AJ2 AJ3

AK3 AL1 AL2 AL3

AF2 AF3

Y6

AK2 AK1

C13 B14 B13

F16 F15 E16 D16 E15 D15 E14

AJ6 AH5 AH4

0

JTAG

DPC_CTRL 12V_ON

R6440

MHL_DET_LM15 COMPENSATION_DONE_1 /MHL_OCP

R606

2.2uF

C605 1uF

HP_LOUT

HP_ROUT

TCK0

C601 C602 C603 C604

JTAG

R610 22

R611 22

1K

22pF

C607

COMP1/AV1/DVI_L_IN COMP1/AV1/DVI_R_IN SC_L_IN SC_R_IN

SCART_Lout SCART_Rout

HP_LOUT

HP_ROUT

HDMI_ARC

C606 10uF 10V

+3.3V_NORMAL

R608

C608 22pF

JTAG

R613 0

R639 100

OPT

R638 100

1uF

C609

R618 22

C635

0.01uF

C636

0.01uF

L60 0

PZ1 608U 121- 2R0T F

JTAG

C611 22pF

TDO0_1

OPT

R615

22K

47K

R640

R641

AUD_SCK

AUD_LRCK AUD_LRCH

HP_LOUT_MAIN

OPT

HP_ROUT_MAIN

OPT

TRST_N0

TU_CVBS

AV1_CVBS_IN

SC_CVBS_IN

DTV/MNT_V_OUT

SC_R

SC_G

SC_B

SC_ID SC_FB

COMP1_Pr

COMP1_Y

COMP1_Pb

C612

1000pF

OPT

R623 68 R624 33

68

R625

33

R626 R627 68 R628 33

R629 68 R630 33

68

R631

33

R632 R633 68 R634 33

R619 68

C613 0.047uF

R620 33 R621 33 R622 33

50V

C619

0.047uF C620

0.047uF

C621

0.047uF

C622

0.047uF

C623

0.047uF

C624

0.047uF

C625

1000pF

0.047uF

C626

0.047uF

C627

0.047uF C628

0.047uF C629

0.047uF

C630

0.047uF

C631

1000pF

C632

C616 0.047uF C617 0.047uF C618 0.047uF

AB2

RIN0M

AB1

RIN0P

AA3

GIN0M

AA1

GIN0P

Y3

BIN0M

Y2

BIN0P

AA2

SOGIN0

W5

HSYNC0

W4

VSYNC0

AE1

RIN1M

AD3

RIN1P

AD1

GIN1M

AD2

GIN1P

AC2

BIN1M

AB3

BIN1P

AC3

SOGIN1

Y5

HSYNC1

Y4

VSYNC1

AC5

RIN2M

AB4

RIN2P

AB5

GIN2M

AC6

GIN2P

AA6

BIN2M

AA5

BIN2P

AB6

SOGIN2

AC4

HSYNC2

AE4

VCOM

AE5

CVBS0

AF6

CVBS1

AE6

CVBS2

AF5

CVBSOUT1

GPIO80/LED[1] GPIO79/LED[0]

USB_SSTXP_1

USB_SSTXN_1 USB_DM_PSS_1 USB_DP_PSS_1

USB_SSRXP_1

USB_SSRXN_1

USB_SSTXP_0

USB_SSTXN_0 USB_DM_PSS_0 USB_DP_PSS_0

USB_SSRXP_0

USB_SSRXN_0

HWRESET

XOUT

IRIN

USB0_DM USB0_DP USB1_DM USB1_DP USB2_DM USB2_DP

B1

TN

C1

TP

A2

RN

B2

RP

E5 F4

G4

AU2

XIN

AT2

K4

C5 B5 C4 B4 A4 B3 AR4 AT4 AU4 AR5 AU5 AT5 AR7 AT7 AU7 AR8 AU8 AT8

AC-coupling CAP

C633 0.1uF

C634 0.1uF

Place near by MST

EPHY_TDN EPHY_TDP EPHY_RDN EPHY_RDP

0

R642

I2C_SCL2 I2C_SDA2

R6430

SOC_RESET

XIN_MAIN XOUT_MAIN

WIFI_DM WIFI_DP USB_DM2 USB_DP2 USB_DM1 USB_DP1

SSUSB_TXP SSUSB_TXN USB_DM3 USB_DP3 SSUSB_RXP SSUSB_RXN

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

Close to Main soc

LM15U

MAIN4_EXT_IN/OUTPUT

2014-11-20

04

AF33

LGE Internal Use Only

AF34

AG8

AG9

AG10

AG11

AG12

AG13

AG16

AG17

AG23

AG24

AG25

AG26

AG27

AG28

AG29

AG30

AG31

AG32

AG33

AG34

AG36

AH8

AH9

AH10

AH11

AH12

AH13

AH16

AH17

AH23

AH24

AH25

AH26

AH27

AH28

AH29

AH30

AH31

AH32

AH33

AH34

AJ7

AJ8

AJ9

AJ10

AJ11

AJ12

AJ13

AJ14

AJ15

AJ16

AJ17

AJ18

AJ19

AJ20

AJ21

AJ22

AJ23

AJ24

AJ25

AJ26

AJ27

AJ28

AJ29

AJ30

AJ37

AK7

AK8

AK9

AK10

AK11

AK12

AK13

AK14

AK16

AK17

AK18

AK19

AK20

AK21

AK22

AK23

AK24

AK25

AK26

AK27

AK28

AK29

AK30

AK31

AK32

AK33

AK34

AL8

AL9

AL13

AL14

AL16

AL17

AL19

AL20

AL21

AL22

AL23

AL24

AL25

AL26

AL27

AL28

AL29

AL30

AL31

AL32

AL33

AL34

AL36

AM3

AM20

AN3

AN22

AN35

AN36

AN37

AP7

AP24

AP27

AP30

AP33

AR1

AR3

AR6

AR9

AT1

AT3

AT6

AT36

AU22

AU25

AU28

AU31

AU34

GND_430

GND_431

GND_432

GND_433

GND_434

GND_435

GND_436

GND_437

GND_438

GND_439

GND_440

GND_441

GND_442

GND_443

GND_444

GND_445

GND_446

GND_447

GND_448

GND_449

GND_450

GND_451

GND_452

GND_453

GND_454

GND_455

GND_456

GND_457

GND_458

GND_459

GND_460

GND_461

GND_462

GND_463

GND_464

GND_465

GND_466

GND_467

GND_468

GND_469

GND_470

GND_471

GND_472

GND_473

GND_474

GND_475

GND_476

GND_477

GND_478

GND_479

GND_480

GND_481

GND_482

GND_483

GND_484

GND_485

GND_486

GND_487

GND_488

GND_489

GND_490

GND_491

GND_492

GND_493

GND_494

GND_495

GND_496

GND_497

GND_498

GND_499

GND_500

GND_501

GND_502

GND_503

GND_504

GND_505

GND_506

GND_507

GND_508

GND_509

GND_510

GND_511

GND_512

GND_513

GND_514

GND_515

GND_516

GND_517

GND_518

GND_519

GND_520

GND_521

GND_522

GND_523

GND_524

GND_525

GND_526

GND_527

GND_528

GND_529

GND_530

GND_531

GND_532

GND_533

GND_534

GND_535

GND_536

GND_537

GND_538

GND_539

GND_540

GND_541

GND_542

GND_543

GND_544

GND_545

GND_546

GND_547

GND_548

GND_549

GND_550

GND_551

GND_552

GND_553

GND_554

GND_555

GND_556

GND_557

GND_558

GND_559

GND_560

GND_561

GND_562

GND_563

GND_564

GND_565

GND_566

GND_567

GND_568

GND_569

GND_570

GND_571

V23

GND_279

V24

GND_280

GND_281

V25

GND_282

V28

V29

GND_283

V30

GND_284

GND_285

V31

GND_572

GND_286

W8

GND_287 GND_288 GND_289 GND_290 GND_291 GND_292 GND_293 GND_294 GND_295 GND_296 GND_297 GND_298 GND_299 GND_300 GND_301 GND_302 GND_303 GND_304 GND_305 GND_306 GND_307 GND_308 GND_309 GND_310 GND_311 GND_312 GND_313 GND_314 GND_315 GND_316 GND_317 GND_318 GND_319 GND_320 GND_321 GND_322 GND_323 GND_324 GND_325 GND_326 GND_327 GND_328 GND_329 GND_330 GND_331 GND_332 GND_333 GND_334 GND_335 GND_336 GND_337 GND_338 GND_339 GND_340 GND_341 GND_342 GND_343 GND_344 GND_345 GND_346 GND_347 GND_348 GND_349 GND_350 GND_351 GND_352 GND_353 GND_354 GND_355 GND_356 GND_357 GND_358 GND_359 GND_360 GND_361 GND_362 GND_363 GND_364 GND_365 GND_366 GND_367 GND_368 GND_369 GND_370 GND_371 GND_372 GND_373 GND_374 GND_375 GND_376 GND_377 GND_378 GND_379 GND_380 GND_381 GND_382 GND_383 GND_384 GND_385 GND_386 GND_387 GND_388 GND_389 GND_390 GND_391 GND_392 GND_393 GND_394 GND_395 GND_396 GND_397 GND_398 GND_399 GND_400 GND_401 GND_402 GND_403 GND_404 GND_405 GND_406 GND_407 GND_408 GND_409 GND_410 GND_411 GND_412 GND_413 GND_414 GND_415 GND_416 GND_417 GND_418 GND_419 GND_420 GND_421 GND_422 GND_423 GND_424 GND_425 GND_426 GND_427 GND_428 GND_429

W9 W10 W11 W15 W16 W17 W18 W19 W20 W21 W22 W27 W28 W29 W30 W31 Y9 Y10 Y11 Y15 Y16 Y17 Y18 Y19 Y20 Y21 Y22 Y30 Y31 Y34 Y37 AA7 AA8 AA9 AA10 AA11 AA12 AA13 AA14 AA15 AA16 AA17 AA18 AA19 AA20 AA22 AA23 AA24 AA25 AA26 AA30 AA31 AA35 AB7 AB8 AB9 AB10 AB11 AB12 AB13 AB14 AB15 AB16 AB17 AB18 AB19 AB20 AB30 AB31 AB32 AB33 AB34 AC7 AC8 AC9 AC10 AC11 AC12 AC13 AC14 AC15 AC16 AC17 AC18 AC19 AC20 AC31 AC32 AC33 AC34 AC35 AD9 AD10 AD11 AD12 AD13 AD14 AD15 AD16 AD17 AD18 AD19 AD20 AD31 AD32 AD33 AD34 AE7 AE8 AE9 AE10 AE11 AE12 AE13 AE14 AE15 AE16 AE17 AE18 AE19 AE20 AE27 AE28 AE29 AE30 AE31 AE32 AE33 AE34 AE35 AF7 AF8 AF9 AF10 AF11 AF16 AF17 AF27 AF28 AF29 AF30 AF31 AF32

A3

GND_1

A9

GND_2

A19

GND_3

A22

GND_4

A25

GND_5

A28

GND_6

A31

GND_7

A34

GND_8

A36

GND_9

B6

GND_10

B19

GND_11

B36

GND_12

B37

GND_13

C2

GND_14

C3

GND_15

C19

GND_16

C36

GND_17

C37

GND_18

D10

GND_19

D11

GND_20

D12

GND_21

D13

GND_22

D14

GND_23

D22

GND_24

D25

GND_25

D29

GND_26

D32

GND_27

D36

GND_28

D37

GND_29

E10

GND_30

E11

GND_31

E12

GND_32

E13

GND_33

E34

GND_34

E35

GND_35

E36

GND_36

F11

GND_37

F12

GND_38

F13

GND_39

F17

GND_40

F26

GND_41

F28

GND_42

F29

GND_43

F30

GND_44

F31

GND_45

F32

GND_46

F33

GND_47

G6

GND_48

G9

GND_49

G11

GND_50

G12

GND_51

G13

GND_52

G15

GND_53

G16

GND_54

G17

GND_55

G18

GND_56

G19

GND_57

G20

GND_58

G21

GND_59

G22

GND_60

G23

GND_61

G24

GND_62

G25

GND_63

G27

GND_64

G28

GND_65

G29

GND_66

G30

GND_67

G31

GND_68

G32

GND_69

G35

GND_70

H8

GND_71

H9

GND_72

H10

GND_73

H11

GND_74

H12

GND_75

H13

GND_76

H14

GND_77

H15

GND_78

H16

GND_79

H17

GND_80

H18

GND_81

H19

GND_82

H20

GND_83

H21

GND_84

H22

GND_85

H23

GND_86

H24

GND_87

H25

GND_88

H26

GND_89

H27

GND_90

H28

GND_91

H29

GND_92

H30

GND_93

H31

GND_94

H32

GND_95

J7

GND_96

J8

GND_97

J9

GND_98

J10

GND_99

J11

GND_100

J12

GND_101

J13

GND_102

J14

GND_103

J16

GND_104

J17

GND_105

J18

GND_106

J19

GND_107

J20

GND_108

J21

GND_109

J22

GND_110

J23

GND_111

J24

GND_112

J25

GND_113

J26

GND_114

J27

GND_115

J28

GND_116

J29

GND_117

J30

GND_118

J31

GND_119

K7

GND_120

K8

GND_121

K9

GND_122

K10

GND_123

K11

GND_124

K12

GND_125

K13

GND_126

K14

GND_127

K15

GND_128

K16

GND_129

K17

GND_130

K18

GND_131

K19

GND_132

K20

GND_133

K21

GND_134

K22

GND_135

K23

GND_136

K24

GND_137

K25

GND_138

K26

GND_139

K27

GND_140

K28

GND_141

K29

GND_142

K30

GND_143

GND_144

GND_145L9GND_146

GND_147

GND_148

GND_149

GND_150

GND_151

GND_152

GND_153

GND_154

GND_155

GND_156

GND_157

GND_158

GND_159

GND_160

GND_161M9GND_162

GND_163

GND_164

GND_165

GND_166

K31

L16

L18

L19

L22

L23

L24

L25

L26

L27

L28

L29

L30

L31

L34

GND_167

L37

M15

M16

M17

M18

M19

M26

LGE5331(LM15U)

GND_168

GND_169

GND_170

GND_171

GND_172

GND_173N7GND_174N8GND_175N9GND_176

GND_177

GND_178

GND_179

GND_180

GND_181

GND_182

GND_183

GND_184

GND_185

GND_186P9GND_187

GND_188

GND_189

GND_190

GND_191

GND_192

GND_193

M27

M28

M29

M30

M31

N15

N16

N17

N18

N19

N27

N28

N29

N30

N31

GND_194

P10

P11

P12

P13

P14

P15

P16

P17

P18

IC100

GND_195

GND_196

GND_197

GND_198

GND_199

GND_200

GND_201

GND_202

GND_203

GND_204

GND_205

P19

P20

P21

GND_206R7GND_207R8GND_208R9GND_209

P27

P28

P29

P30

P31

P34

P37

R10

R11

GND_210

R12

GND_211

R13

GND_212

GND_213

R14

R15

GND_214

R16

GND_215

R17

GND_216

GND_217

R18

GND_218

R19

R20

GND_219

GND_220

R21

R27

GND_221

R28

GND_222

R29

GND_223

GND_224

R30

R31

GND_225

GND_226T7GND_227T8GND_228T9GND_229

GND_230

GND_231

GND_232

GND_233

GND_234

GND_235

GND_236

GND_237

GND_238

GND_239

GND_240

GND_241

GND_242

GND_243

GND_244

GND_245

GND_246U8GND_247U9GND_248

GND_249

GND_250

GND_251

GND_252

GND_253

GND_254

GND_255

GND_256

GND_257

GND_258

GND_259

GND_260

GND_261

GND_262

GND_263

GND_264

GND_265

GND_266

GND_267V8GND_268V9GND_269

GND_270

GND_271

GND_272

GND_273

GND_274

GND_275

GND_276

GND_277

T10

T11

T12

T15

T16

T17

T18

T19

T20

T21

T22

T23

T27

T28

T29

T30

T31

U10

U11

U12

U13

U14

U15

U16

U17

U20

U21

U22

U23

U24

U28

U29

U30

U31

U34

U37

V10

V11

GND_278

V15

V16

V17

V18

V19

V20

V21

V22

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

LM15U_GND

2014-1-21 05

CI Region

LGE Internal Use Only

CI SLOT

+5V_CI_ON

CI_DATA[0-7]

* Option name of this page : CI_SLOT

(because of Hong Kong)

CI TS INPUT

+5V_NORMAL

R900 10K

CI_SLOT

CLOSE TO MSTAR

CI DETECT

/CI_CD2 /CI_CD1

/CI_CD1

TPI_DATA[4] TPI_DATA[5] TPI_DATA[6] TPI_DATA[7]

CI_IORD CI_IOWR

CI_MDI[0] CI_MDI[1] CI_MDI[2] CI_MDI[3]

CI_MDI[4] CI_MDI[5] CI_MDI[6] CI_MDI[7]

PCM_RESET

CAM_WAIT_N

TPI_CLK TPI_VAL

TPI_SOP

TPI_DATA[0] TPI_DATA[1] TPI_DATA[2] TPI_DATA[3]

CLOSE TO MSTAR

CI_MISTRT

CI_MIVAL_ERR

CI_MCLKI

REG

CI_SLOT

IC900

74LVC1G32GW

1B 5 VCC

3GND2A4 Y

OR_GATE_CI_TI

IC900-*1

SN74LVC1G32DCKR

1A5

B

2

GND

3

CI_SLOT

R901 R902

CI_SLOT

AR900

/CI_CD2

CI_SLOT

C900 2pF 50V

+3.3V_NORMAL

OR_GATE_CI_TOSHIBA

IC900-*2

TOSHIBA ELECTRONICS KOREA CORPORATION

VCC

IN_B

1

IN_A

2

Y

GND

4

3

AR901

33

47 47

33

+5V_NORMAL

CI_SLOT

CI_SLOT CI_SLOT

VCC

5

OUT_Y

4

+5V_NORMAL

R906

10K

CI_SLOT

R907

10K

CI_SLOT

R908 10K

CI_SLOT

GND

AR910 33 CI_SLOT

+3.3V_NORMAL

C901

0.1uF

R909

R910

CI_SLOT

R911

CI_SLOT

C902

10uF

10V

CI_SLOT

JK900

CI_SLOT

R912

100

10K

10125901-115LF

35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59

65 66 67 68

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 2660 2761 2862 2963 3064 31 32 33 34

G1G2

69

R914

R915

C903

0.1uF

CI_SLOT

47

CI_SLOT

100

GND

100

GND

CI_DATA[3] CI_DATA[4] CI_DATA[5] CI_DATA[6] CI_DATA[7]

CI_DATA[0] CI_DATA[1] CI_DATA[2]

CI_DATA[0-7]

R916

CI_ADDR[10]

CI_ADDR[11]

CI_ADDR[9]

CI_ADDR[8] CI_ADDR[13] CI_ADDR[14]

CI_ADDR[12]

CI_ADDR[7]

CI_ADDR[6]

CI_ADDR[5]

CI_ADDR[4]

CI_ADDR[3]

CI_ADDR[2]

CI_ADDR[1]

CI_ADDR[0]

10K

/PCM_CE1

CI_OE

+5V_NORMAL

R917 10K

CI_SLOT

CI_WE

GND

CI_ADDR[0-14]

CAM_IREQ_N

C904

0.1uF

CI_SLOT

CLOSE TO MSTAR

OLED_CI_SLOT

JK900-*1

10125901-015LF

35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59

65 66 67 68

69

CI HOST I/F

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 2660 2761 2862 2963 3064 31 32 33 34

G1G2

10K

R913 47

CAM_CD1_N

CI_MDI[7] CI_MDI[6] CI_MDI[5] CI_MDI[4]

CI_MDI[3] CI_MDI[2] CI_MDI[1] CI_MDI[0]

CI_MISTRT

CI_MIVAL_ERR

CI_MCLKI

CI_ADDR[0] CI_ADDR[1] CI_ADDR[2] CI_ADDR[3]

CI_ADDR[4] CI_ADDR[5] CI_ADDR[6] CI_ADDR[7]

CI_ADDR[8]

CI_ADDR[9] CI_ADDR[10] CI_ADDR[11]

CI_ADDR[12] CI_ADDR[13] CI_ADDR[14]

CI_IORD CI_IOWR

REG

CI_OE CI_WE

CI_DATA[0] CI_DATA[1] CI_DATA[2] CI_DATA[3]

CI_DATA[4] CI_DATA[5] CI_DATA[6]

CI_DATA[0-7]

CI_DATA[7]

CI_SLOT

AR903 33

CI_SLOT

AR902

R918 33 R919 33 R920 100

CI_SLOT

AR908 33

AR909 33

AR913 33

CI_SLOT

AR904 33

CI_SLOT

AR905 33

33

CI_SLOT

AR906

33

CI_SLOT

AR907 33

CI_SLOT

TPO_DATA[7] TPO_DATA[6] TPO_DATA[5]

TPO_DATA[4]

TPO_DATA[3]

TPO_DATA[2]

TPO_DATA[1]

TPO_DATA[0]

EB_ADDR[8] EB_ADDR[9] EB_ADDR[10] EB_ADDR[11]

EB_ADDR[12] EB_ADDR[13] EB_ADDR[14] CAM_REG_N

EB_OE_N EB_WE_N

EB_DATA[0] EB_DATA[1] EB_DATA[2] EB_DATA[3]

EB_DATA[4] EB_DATA[5] EB_DATA[6] EB_DATA[7]

EB_ADDR[0] EB_ADDR[1] EB_ADDR[2] EB_ADDR[3]

EB_ADDR[4] EB_ADDR[5] EB_ADDR[6] EB_ADDR[7]

EB_BE_N1 EB_BE_N0

TPO_SOP TPO_VAL TPO_CLK

EB_DATA[0-7]

TPO_DATA[0-7]

CI POWER ENABLE CONTROL

+5V_NORMAL

C905

0.1uF 50V

CI_SLOT

R922

PCM_5V_CTL

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

R921 10K

CI_SLOT

100

IN

EN

IC901

AP2151WG-7

5

CI_SLOT

4

CI_DATA[0-7]

EB_DATA[0-7]

+5V_CI_ON

OUT

1

GND

2

FLG

3

C906 1uF 25V

CI_SLOT

R923 10K

CI_SLOT

LM15U

PCMCI

2014-10-17

9

+3.5V_ST

LGE Internal Use Only

R2301

1

RL_ON

+3.5V_ST

Digital Power B/D

R2300 10K

L2301

UBW2012-121F

C2302

0.1uF 16V

O

X

+12V

10K

C2304

0.1uF 50V

40 ~ 65

70 ~ 79

INCH

2

3

PWM_DIM

UBW2012-121F

2

Q2300 2N3906S-RTK

KEC_RL_ON_TR

L2302

L2303

24 PIN

NC

GND

’15 UHD POWER

+3.3V - eMMC

+3.3V_NORMAL

3.3V_EMMC

L2304

PZ1608U121-2R0TF

C2308

C2309

0.1uF 22uF

16V

10V

+1.8V - LM15U, eMMC & Vx1 pull-up

+3.3V_NORMAL

1

3

OS MODULE

L/D_CLK

L/D_DI

R2304

22 PIN

SMA W200 -H28 S5K[ MIRR OR]

NXP_RL_ON_TR

Q2300-*1 MMBT3906(NXP)

100

GND

24V

+1.8V

L2305

PZ1608U121-2R0TF

OS MODULE

P23 01

PWR _ON PDI M#1

L/D _CLK

L/D _DI

DVDD18_EMMC

3.5 V

C2307

0.1uF 16V

GND 12V 12V 12V GND 24V 24V GND

1

1 3

3 5

5 7

7 9

9 11

11 13

13 15

15 17

17 19

19 21

21 22 23

23 24 25 27

LGE MODULE

SMA W200 -H24 S5[M IRRO R]

P23 00

INV _CTL

2

PDI M#2

4

GND

6

3.5 V

8

GND

10

12V

12

12V

14

GND

16

24V

18

24V

20

GND or 24V

22

NC or G ND

24

GND

26

L/D _VSY NC

28

25

29

.

C2312 22uF 10V

+1.8V

R2311 100 R2313

NON_DIGITAL_POWER_B/D

DIGITAL_POWER_B/D

L2315

UBW2012-121F

L2316

UBW2012-121F

NON_DIGITAL_POWER_B/D

+3.3V_NORMAL

100

L2317

UBW2012-121F

L2307

UBW2012-121F

L2308

UBW2012-121F

OS MODULE

L/D_VSYNC

+3.3V_NORMAL

R2314 1K

+12V

C2316 10uF 16V

LD2300

3.3V_LED

R23 15

3.3 K

3.3V_LED

INV_CTL

C2319

0.1uF

PWM_DIM2

50V

C2317 10uF 16V

+24V

C2318 10uF 16V

+12V

L2321

L2322

MLB-201209-0120P-N2

PANEL_CTL

+12V

L2309

PZ1608U121-2R0TF

C2324

C2322

0.1uF

10uF 16V

1.0V_DCDC_TI C2332-*1

3300pF 50V

Switching freq: 700K

PANEL_POWER

MLB-201209-0120P-N2

C23 27 10u F 25V

OPT

C2371 10uF 10V

R2328 10K

C2330

0.1uF 25V

C2331

0.01uF 50V

R2329

R2331

1.8K

B

DDR +1.5V

R2320

R2321

18K

R1

C2325 100pF

50V

4.7K

1%

R2322 22K

1%

R2

Vout=0.765*(1+R1/R2)=1.554V

10K

C

E

R2326

10K

C2328 1uF 10V

OPT

C2335

C2367

10uF

25V

Q2321 2N3904S KEC_PANEL_CTL_TR

C

Q2321-*1

B

MMBT3904(NXP)

NXP_PANEL_CTL_TR

E

POWER_ON/OFF2_3

ROHM_BD9D321_1.5V_DDR_DCDC

EN

FB

VREG

SS

C2332 2200pF 50V

1.0V_DCDC_ROHM

OPT C2315 1uF 25V

IC2303

BD9D321EFJ

1

9

2

THERMAL

3

4

3A

AOS_PANEL_POWER_FET

AO4447A

S_1

1

S_2

2

S_3

3

G

4

C2368

10uF 25V

OPT

[EP]

VIN

8

BOOT

7

SW

6

GND

5

RESET_IC_DIODES

IC2307-*1

TYP 6000mA

PANEL_VCC

IC2309

D_4

8

D_3

7

D_2

6

D_1

5

R2359 2K OPT

R2360 2K

OPT

S_1

S_2

S_3

C23 69 10u F 25V

OPT

ROHM_PANEL_POWER_FET

IC2309-*1

RRH140P03TB

1

2

3

4G5

C2370

0.1uF 25V

D_4

8

D_3

7

D_2

6

D_1

Power_DET

+12V

PD_+12V

R2335

2.7K 1%

PD_+12V

R2336

1.2K 1%

PD_UHD_24V

R2340-*2

9.1K 1%

PD_UHD_24V

R2341-*2

1.6K 1%

PD_20V R2340-*1

5.6K

1%

PD_20V R2341-*1

1.3K 1%

+24V

+3.5V_ST

PD_24V R2340

8.2K 1%

PD_24V R2341

1.5K 1%

PD_+3.5V R2343 0 5%

C2350

0.1uF 16V

C2351

0.1uF 16V

PD_20_24V

R2349 100K

RESET_IC_ROHM

IC2307

BD48K28G

VDD

3

PD_20_24V

R2348 100K

PD_20_24V_ROHM

IC2308

BD48K28G

VDD

3

+3.5V_ST

R2354 10K OPT

VOUT

2

1

GND

R2355

0

PWR_DET_MERGE

R2356

VOUT

2

1

GND

0

PWR_DET_SEPARATE

ST_3.5V-->3.5V

APX803D29

RESET

2

1

PD_20_24V_DIODES

IC2308-*1 APX803D29

RESET

2

1

POWER_DET

C2364

0.1uF 16V

not to RESET at 8kV ESD

C2365

0.1uF

PWR_DET_SEPARATE

16V

POWER_DET_1

24V-->3.48V 20V-->3.51V 12V-->3.58V

VCC

3

GND

VCC

3

GND

+5.0V normal & USB

16V

0.1uF C2336

PS064T-2R2MS

L2312

2.2uH

C2338

22uF

10V

+1.5V_DDR

C2339 22uF 10V

TI_TPS54327_1.5V_DDR_DCDC

IC2303-*1

TPS54327DDAR

EN

1

VFB

2

THERMAL

VREG5

3

SS

4

ZD2302

2.5V DCDC_DIODE

C2347

OPT

2200pF

R23 39 1 6K 1%

RSET228AGND

27

IC2305

6A

9EN10

SW_OUT211SW_OUT1

10K

+5V_USB_1

POWER_ON/OFF1

R23 4215 0K 1%

COMP25RLIM26RSET1

SW_EN213SW_EN1

+5V_USB_2

50V

R2344 10K

12

USB_CTL1

USB_CTL2

+24V

[EP]GND

VIN

8

VBST

9

7

SW

6

GND

5

L2314

120-ohm

C2340 10uF 35V

OPT

C2341 10uF 35V

VIN_1

VIN_2

VIN_3

C2344

0.1uF 50V

PGND_1

PGND_2

PGND_3

1uF

25V

C23 43

C2346

0.0068uF

R23 37 1 6K 1 %

[EP]

1

THERMAL

2

29

3

4

SN1302001(TPS65286RHDR)

5

6

V7V

7

8

MODE/SYNC

50V

R2338

22SS23FB24

21

20

19

18

17

16

15

14

NFAULT2

/USB_OCD1

C2352

C2349

0.047uF

100pF

25V

50V

LX_3

LX_2

LX_1

BST

SW_IN2

SW_IN1

NFAULT1

Vout=0.6*(1+R1/R2)

5.1V:R1-51K, R2-6.8K

C2357

5%

82pF

50V

L2313

4.7uH

C2355

0.047uF 25V

100K

R2350

1/16W

/USB_OCD2

R2

1%

R1

1%

R2353

1/16W

6.8K

51K

5%

R2351

R2352

100K

C2359 22uF 10V

C2360 1uF 10V

C2362 22uF 10V

C2363 10uF 10V

+5V_NORMAL

ZD2303

DCDC_DIODE

+12V

L2300

PZ1608U121-2R0TF

C2300 10uF 25V

Switching freq: 700K

IC2301

AZ1117EH-ADJTRG1

OUTIN

ADJ/GND

1%

1/16W

1%

1/16W

+3.3V_NORMAL

R2303

1%

R2302

R2305

R2

10K

51K

C2303

15K

1%

C2305

1uF

0.015uF

10V

50V

Vout=0.765*(1+R1/R2)

POWER_ON/OFF2_1

R1

C2301 100pF

50V

OPT

75

R2307

33

R2308

EN

VFB

VREG5

SS

R2309 1

C2310 10uF 10V

IC2302

TPS54427DDA

1

9

2

THERMAL

3

4

4A

8

7

6

5

C2311 10uF 10V

[EP]GND

VIN

VBST

SW

GND

0.1uF C2306

16V

D2302

DCDC_DIODE

PS064T-2R2MS

L2306

2.2uH

C2313

22uF

10V

2.5V

MAX A

+3.3V_NORMAL

DCDC_DIODE

C2314 22uF 10V

ZD2300

+1.1V or +1.15V _CPU CORE

+12V

L2310

PZ1608U121-2R0TF

Placed on SMD-TOP

C2320 10uF 16V

C2321 10uF 16V

C2323

0.1uF 16V OPT

Vout=0.8*(1+R1/R2)

R1:15K/R2:56K, V=1.00V(CPU_VID0=L,CPU_VID1=L) Voltage drop 0.01V R1:15K/R2:56K//240K, V=1.05V(CPU_VID0=H,CPU_VID1=L) Voltage drop 0.01V R1:15K/R2:56K//240K, V=1.05V(CPU_VID0=L,CPU_VID1=H) Voltage drop 0.01V R1:15K/R2:56K//240K//240K, V=1.10V(CPU_VID0=H,CPU_VID1=H) Voltage drop 0.01V

PGND

VIN

AGND

FB

IC2300

BD86106EFJ

EAN62653301

1

2

THERMAL

3

4

6A

L2311

C2329

0.0068uF 50V

R2325

10K

2uH

OPT

C2353 10uF 10V

POWER_ON/OFF2_4

[EP]

SW_2

8

SW_1

9

7

EN

6

R2324

6.8K

COMP

5

C2326

0.1uF 16V

C2333

C2334

10uF

100uF

10V

+3.3V_NORMAL

R2327 10K

CPU_VID0

D

G

S

DIODEDS_CPU_CORE_VID_FET

OPT

C2354 10uF 10V

R2330

0 5%

Q2302-*1 2N7002K

OPT

C2356 10uF 10V

R2-1.13V

R2332

20K 1%

R2333 200K 1%

G

C2337 47pF 50V

D

CPU_VID1

S

2N7002KA

Q2302

KEC_CPU_CORE_VID_FET

MAX 2.7A

R2-1.13V

+3.3V_NORMAL

R2306

10K

R2310

0 5%

D

Q2303-*1

G

2N7002K

S

DIODEDS_CPU_CORE_VID_FET

R2312

20K 1%

R2316 200K 1%

G

D

R2-1.1V

S

2N7002KA

Q2303

KEC_CPU_CORE_VID_FET

+1.1V_VDDC_CPU

R2334

R1

15K

1%

R2345

13K

1%

R2346 43K

1%

LM15 Power SEQUENCE

POWER_ON/OFF1(5V)

POWER_ON/OFF2_1(3.3V)

2.5V

ZD2301

R2

POWER_ON/OFF2_3(1.5V, 2.5V)

DCDC_DIODE

POWER_ON/OFF2_4(1.1V)

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

LM15U_PWR_1_UHD

2014-12-15

23

CORE_VID1

LGE Internal Use Only

+3.3V_NORMAL

R2516

10K

R2517

0 5%

POWER_ON/OFF2_4

OPT C2500

0.1uF 16V

R2-3

R25 18

120 K

1%

1/1 6W

D

G

S

D

G

S

+1.1V or +1.15V _CORE

R2507

1K

R1

1%

R2

1/1 6W

1%

30K

R25 19

CORE_VID0

2N7002KA

Q2501

KEC_CORE_DCDC_FET

Q2501-*1 2N7002K

DIODES_CORE_DCDC_FET

+3.3V_NORMAL

R2500

10K

R2501

0 5%

R2-2

R25 02

120 K

1%

G

D

Q2500-*1

G

2N7002K DIODES_CORE_DCDC_FET

S

1/1 6W

30K

1/1 6W

D

S

1/1 6W

R2505

12K

R25 06

1%

R25 03

2N7002KA

Q2500

KEC_CORE_DCDC_FET

13K

R25 04

1/16W

1%

1/1 6W

1%

C2501

1uF

10V

R2-1

C2502

0.033uF 50V

R2508 100K

1/16W 1%

R2510 100

1/16W

IC2501

MP8762HGLE-Z

EN

1

FREQ

2

FB

3

SS

4

AGND

5

10A

PG

6

VCC

7

BST

8

R2509 33

1/16W 5%

1%

16

15

14

13

12

11

10

9

C2503

0.1uF 16V

SW_2

SW_1

IN_2

PGND_4

PGND_3

PGND_2

PGND_1

IN_1

1%

1/16W

R2512 220K

1/10W 5%

430K

R2511

LPBN8050T-1R0N

L2500

1.0uH

C2504 10uF 25V

C2506

330pF

50V

C2505 10uF 25V

C2507 22uF 10V

C2508

22uF 10V

L2501

+1.1V_VDDC

C2509 22uF 10V

DCDC_DIODE

+12V

2.5V

ZD2500

Vout=0.611*(1+R1/R2)

R1:13K/R2:22K, V=0.95V(CORE_VID0=L,CORE_VID1=L) Voltage drop 0.02V R1:13K/R2:22K//150K, V=1.00V(CORE_VID0=H,CORE_VID1=L) Voltage drop 0.02V R1:13K/R2:22K//150K, V=1.00V(CORE_VID0=L,CORE_VID1=H) Voltage drop 0.02V

R1:13K/R2:22K//150K//150K, V=1.05V(CORE_VID0=H,CORE_VID1=H) Voltage drop 0.02V

MAX 7A

POWER_ON/OFF2_3

+3.3V_NORMAL

TU_JP

C2510

0.1uF 16V

+2.5V

TU_JP

R2513

10K

TU_JP

IC2502

TU_JP

C2512

0.1uF

TJ4220GDP-ADJ

1

NC_1

2

EN2

3

VIN3

2A

4

NC4

EAN62206201

9

THERMAL

Vout=0.6*(1+R1/R2)

8

7

6

5

[EP]GND

GND

ADJ/SENSE

VOUT

NC_2

TU_JP

R2514

R25 15

+2.5V_Normal

22K

R2

R1

TU_JP

47K

TU_JP C2513 10uF 10V

5V

OPT

ZD2501

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

LM15U_PWR_2_ALL

2014-11-26

25

Renesas MICOM

LGE Internal Use Only

For Debug

+3.5V_ST

X3000-*1

32.768KHz

EPSON_MICOM_CRYSTAL

MICOM_DEBUG

P3000

12507WS-04L

5

1

2

3

4

Don’t remove R3016, not making float P40

R3016 1K

R3014 10K

MICOM_DEBUG

LM15 Power SEQUENCE

POWER_ON/OFF1(5V)

POWER_ON/OFF2_1(3.3V)

POWER_ON/OFF2_3(1.5V)

POWER_ON/OFF2_4(1.1V)

SOC_RESET

MICOM MODEL OPTION

+3.5V_ST

MICOM_DEBUG

MICOM_RESET

I2C_SCL_MICOM

I2C_SDA_MICOM

3D&L_DIM_EN

PANEL_CTL

WOL/WIFI_POWER_ON

HDMI_CEC_MICOM

POWER_ON/OFF2_3

EYE_SDA

EYE_SCL

+3.5V_ST

50V

12pF

C3002

DAISHINKU_MICOM_CRYSTAL

HDMI_WAUP:HDMI_INIT

MHL_DET_LM15

+3.5V_ST

C3000

0.1uF

P62 P63

R30370

10K

GND

R3032

C3001 0.47uF

P121/X1

REGC

VSS

VDD

46

47

48

1 2 3 4 5 6

R5F100GEAFB#30 7 8 9 10 11 12

13

14

15

MHL_DET_LM15

+3.5V_ST

R3021

LCD

5%

10K

R3021-*1

1K

OLED

1/16W

P60/SCLA0 P61/SDAA0

P31/TI03/TO03/INTP4

IR

P75/KR5/INTP9/SCK01/SCL01

R3038

P74/KR4/INTP8/SI01/SDA01

100

P73/KR3/SO01 P72/KR2/SO21

P71/KR1/SI21/SDA21

P70/KR0/SCK21/SCL21

P30/INTP3/RTC1HZ/SCK11/SCL11

AR3000

3.3K

EYE_Q

C3003

X3000

32.768KHz R3028

4.7M

OPT

POWER_DET_1

P124/XT2/EXCLKS

P123/XT1

P137/INTP0

P122/X2/EXCLK

41

42

43

44

45

IC3000

16

17

18

19

20

MICOM_RESET

R3029 33

P40/TOOL0

RESET

40

21

LOGO_LIGHT

MICOM_DEBUG

LOGO_LIGHT

WIFI_EN

C3004

0.1uF 16V

P120/ANI19

P41/TI07/TO07

37

38

39

36 35 34 33 32 31 30 29 28 27 26 25

22

23

24

+3.5V_ST

10K

MICOM_RESET_SW

SW3000

R3030

JTP-1127WEM

1%

OPT

270K

R3031

1/1 6W

12

4 3

P140/PCLBUZ0/INTP6 P00/TI00/TXD1 P01/TO00/RXD1 P130 P20/ANI0/AVREFP P21/ANI1/AVREFM P22/ANI2 P23/ANI3 P24/ANI4 P25/ANI5 P26/ANI6 P27/ANI7

RL_ON

SCART_MUTE

POWER_ON/OFF2_4

POWER_ON/OFF2_1

KEY2

KEY1

MODEL1_OPT_3

MODEL1_OPT_0

SIDE_HP_MUTE

MHL_EN

MODEL1_OPT_1

SCART_MUTE

POWER_ON/OFF2_4

MHL_EN

P146

MICOM MODEL OPTION

OPT

R3006 10K

R3004 10K

R3008 10K

MICOM_OLED

MICOM_LCD

R3009 10K

R3013 10K

MICOM_LOGO

R3012 10K

MICOM_NON_LOGO

MODEL1_OPT_0 MODEL1_OPT_1

MODEL1_OPT_3

MODEL_OPT_0

MODEL_OPT_1

MODEL_OPT_3 LM15U

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

0

NON LOGO

LCD

P147/ANI18

P17/TI02/TO02

1

LOGO

OLED

H15

P51/INTP2/SO11

P50/INTP1/SI11/SDA11

P16/TI01/TO01/INTP5

POWER_DET

WOL_WAKE_UP

POWER_ON/OFF1

LM15U : Active high reset

P13/TXD2/SO20

P10/SCK00/SCL00

P14/RXD2/SI20/SDA20

P12/SO00/TXD0/TOOLTXD

P15/PCLBUZ1/SCK20/SCL20

P11/SI00/RXD0/TOOLRXD/SDA00

LED_R

WOL_CTL

SOC_RESET

INV_CTL

R3015

10K

MICOM_LM15U

SOC_TX

SOC_RX

EDID_WP

AMP_MUTE

URSA_RESET_MICOM

CEC_REMOTE

LM15U

MICOM

D3000

BAT54_SUZHO

S

For CEC

R3033 27K

G

Q3001-*1

SI1012CR-T1-GE3 D VISHAY_CEC_FET

+3.5V_ST

G

D

S

Q3001 RUE003N02

ROHM_CEC_FET

R3034

120K

HDMI_CEC_MICOM

2014-12-30

30

BODY_SHIELD

LGE Internal Use Only

FOOSUNG_HDMI_JACK

BODY_SHIELD

FOOSUNG_HDMI_JACK

MHL

+5V_NORMAL

20

19

HOT_PLUG_DETECT

18

VDD[+5V]

17

DDC/CEC_GND

16

SDA

15

SCL

14

RESERVED

13

CEC

12

TMDS_CLK-

11

TMDS_CLK_SHIELD

10

TMDS_CLK+

9

TMDS_DATA0-

8

TMDS_DATA0_SHIELD

7

TMDS_DATA0+

6

TMDS_DATA1-

5

TMDS_DATA1_SHIELD

4

TMDS_DATA1+

3

TMDS_DATA2-

2

TMDS_DATA2_SHIELD

1

TMDS_DATA2+

DAADR019A

JK3301

20

19

HOT_PLUG_DETECT

18

VDD[+5V]

17

DDC/CEC_GND

16

SDA

15

SCL

14

RESERVED

13

CEC

12

TMDS_CLK-

11

TMDS_CLK_SHIELD

10

TMDS_CLK+

9

TMDS_DATA0-

8

TMDS_DATA0_SHIELD

7

TMDS_DATA0+

6

TMDS_DATA1-

5

TMDS_DATA1_SHIELD

4

TMDS_DATA1+

3

TMDS_DATA2-

2

TMDS_DATA2_SHIELD

1

TMDS_DATA2+

DAADR019A

JK3300

L3300

PZ1608U121-2R0TF

MHL

5V_MHL

5V_HDMI_1

MHL C3300

0.1uF 16V

VA3300

5V_HDMI_2

HDMI_ARC

CEC_REMOTE

ESD_HDMI

VA3302

ESD_HDMI

CEC_REMOTE

VA3301

ESD_HDMI

Q3300

2N3904S

R3300

100K

KEC_HDMI_HPD_3_TR

Q3300-*1

MMBT3904(NXP)

NXP_HDMI_HPD_3_TR

R3301

100K

MMBT3904(NXP)

VA3303

NXP_HDMI_HPD_2_TR

ESD_HDMI

5V_MHL

MHL

MHL_DET_LM15

R3302

R3337

1K

33

C

OPT

1K

B

R3303

E

C

B

E

D3302

RCLAMP7534P

OPT

1

5

2

4

3

D3303

RCLAMP7534P

OPT

1

5

2

4

3

R3304

1K

C

Q3301

2N3904S

E

KEC_HDMI_HPD_2_TR

C

Q3301-*1

E

D3301

RCLAMP7534P

OPT

1

5

2

4

3

D3300

RCLAMP7534P

OPT

1

5

2

4

3

C3301

ZD3300

0.1uF

5V OPT

16V

R3305

4.7K

NON_HDMI_EXT_EDID

VA3304

ESD_HDMI

OPT R3338 33

R3306 1K

B

GND

HDMI_HPD_1

R3339

4.7K HDMI_EXT_EDID

33

VA3306

ESD_HDMI

CK-_HDMI1 CK+_HDMI1

D0-_HDMI1 D0+_HDMI1

D1-_HDMI1 D1+_HDMI1

D2-_HDMI1 D2+_HDMI1

R3308

1.8K

R3307

4.7K

HDMI_HPD_2

VA3305

ESD_HDMI

CK-_HDMI2 CK+_HDMI2

D0-_HDMI2 D0+_HDMI2

D1-_HDMI2 D1+_HDMI2

D2-_HDMI2 D2+_HDMI2

Current Limit

IC3300

TPS2553DBV

IN

1

MHL

2

EN

3

/MHL_OCP

R3309

1.8K

R3329

DDC_SDA_1

R333033

DDC_SCL_1

5V_DET_HDMI_2

R3310

3.3K

R333133 R333233

VA3307

ESD_HDMI

HDMI2 with ARC

L3301

BLM31PG500SN1

50-ohm

MHL

R3311

D3304

1%

20K

/MHL_OCP

OUT

6

ILIM

5

FAULT

4

5V_DET_HDMI_1

R3312

3.3K

HDMI3

DDC_SDA_2

DDC_SCL_2

MHL

30V OPT

R3313

100K

MHL

5V_HDMI_3

MHL C3302

10uF

10V

TMDS_DATA2_SHIELD

TMDS_DATA1_SHIELD

TMDS_DATA0_SHIELD

TMDS_CLK_SHIELD

HOT_PLUG_DETECT

VA3313

ESD_5V_HDMI_3

TMDS_DATA2+

TMDS_DATA2-

TMDS_DATA1+

TMDS_DATA1-

TMDS_DATA0+

TMDS_DATA0-

TMDS_CLK+

TMDS_CLK-

RESERVED

DDC/CEC_GND

VDD[+5V]

CNPLUS_HDMI_JACK

JK3300-*1 5501-56219

1

2

3

4

5

6

7

8

9

10

11

12

CEC

13

14

SCL

15

SDA

16

17

18

19

20

BODY_SHIELD

TMDS_DATA2+

TMDS_DATA2_SHIELD

TMDS_DATA2-

TMDS_DATA1+

TMDS_DATA1_SHIELD

TMDS_DATA1-

TMDS_DATA0+

TMDS_DATA0_SHIELD

TMDS_DATA0-

TMDS_CLK+

TMDS_CLK_SHIELD

TMDS_CLK-

RESERVED

DDC/CEC_GND

VDD[+5V]

HOT_PLUG_DETECT

CNPLUS_HDMI_JACK

JK3301-*1

5501-56219

1

2

3

4

5

6

7

8

9

10

11

12

CEC

13

14

SCL

15

SDA

16

17

18

19

20

BODY_SHIELD

TMDS_DATA2+

TMDS_DATA2_SHIELD

TMDS_DATA2-

TMDS_DATA1+

TMDS_DATA1_SHIELD

TMDS_DATA1-

TMDS_DATA0+

TMDS_DATA0_SHIELD

TMDS_DATA0-

TMDS_CLK+

TMDS_CLK_SHIELD

TMDS_CLK-

RESERVED

DDC/CEC_GND

VDD[+5V]

HOT_PLUG_DETECT

CNPLUS_HDMI_JACK

JK3302-*1

5501-56219

1

2

3

4

5

6

7

8

9

10

11

12

CEC

13

14

SCL

15

SDA

16

17

18

19

20

BODY_SHIELD

20

19

HOT_PLUG_DETECT

18

VDD[+5V]

17

DDC/CEC_GND

16

SDA

15

SCL

14

RESERVED

13

CEC

12

TMDS_CLK-

11

TMDS_CLK_SHIELD

10

TMDS_CLK+

9

TMDS_DATA0-

8

TMDS_DATA0_SHIELD

7

TMDS_DATA0+

6

TMDS_DATA1-

5

TMDS_DATA1_SHIELD

4

TMDS_DATA1+

3

TMDS_DATA2-

2

TMDS_DATA2_SHIELD

1

TMDS_DATA2+

DAADR019A

JK3302

FOOSUNG_HDMI_JACK

EDID external EEPROM

MMBT3904(NXP)

E

Q3302-*1

C

NXP_HDMI_EXT_EDID_TR

A0

A1

A2

GND

B

ROHM_HDMI_EXT_EDID

IC3301

BR24G02FJ-3GTE2

1

2

3

4

8

7

6

5

DDC pull-up

5V_HDMI_2

AR3302

47K

1/16W

5V_HDMI_3

VA3308

ESD_HDMI

VA3312

ESD_HDMI

CEC_REMOTE

R3314

0

NON_MHL

KEC_HDMI_EXT_EDID_TR

2N3904S

VCC

WP

SCL

SDA

+5V_NORMAL

A2CA1 MMBD6100 D3305

DDC_SDA_2

DDC_SCL_2

R3315

100K

VA3309

ESD_HDMI

VA3310

5.6V

Q3302

5V_DET_HDMI_3

MHL R3325 0

C

E

AR3 304

47K

R3324

1.8K

Q3303 2N3904S KEC_MHL_TR

Q3303-*1 MMBT3904(NXP)

NXP_MHL_TR

5V_HDMI_1

+3.5V_ST

MHL

DDC_SDA_3

DDC_SCL_3

R3335

+3.5V_ST

MHL

R3326

10K

MHL R3327 10K

B

C

B

E

R3328

NON_MHL

HDMI1 with MHL

+5V_NORMAL

A1

A2 MMBD6100 D3309

C

AR3305 1/16W 47K

A1

A2

MMBD6100 D3310

C

3.3K

10K

E

C

DDC_SCL_1

2N3906S-RTK

Q3304

KEC_MHL_TR

EDID_WP

DDC_SDA_1

C

Q3304-*1

B

MMBT3906(NXP)

NXP_MHL_TR

E

MHL_DET_LM15

ATMEL_HDMI_EXT_EDID

IC3301-*1

AT24C02C-SSHM-T

A0

1

A1

2

A2

3

GND

4

VCC

8

WP

7

SCL

6

SDA

5

OPT

R3316

R3336

1K

33

OPT

Q3305

2N3904S

C

E

VA3311 ESD_HDMI

R3318 1K

B

OPT

D3306

RCLAMP7534P

OPT

1

5

2

4

3

D3307

RCLAMP7534P

OPT

1

5

2

4

3

MHL R3317

1K

C3303

0.1uF 16V

OPT

MHL

R333333 R333433

MHL R3320 300K

MHL Spec

OPT

R3319

4.7K

HDMI_HPD_3

DDC_SDA_3

DDC_SCL_3

CK-_HDMI3 CK+_HDMI3

D0-_HDMI3 D0+_HDMI3

D1-_HDMI3 D1+_HDMI3

D2-_HDMI3 D2+_HDMI3

B

E

B

C

HDMI_EXT_EDID

R3323

4.7K

R3321 22

HDMI_EXT_EDID

R3322 22

HDMI_EXT_EDID

5V_HDMI_3

+5V_NORMAL

A2CA1

MMBD6100 D3308

1/1 6W

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

HDMI

2014-11-04

10

AV/COMPONENT REAR

LGE Internal Use Only

VA3806

5.5V

Place JACK Side

C3822 150pF OPT

MOLD_B/C_ESD

R3832-*1

3.3

1/10W 5%

1608 sizs For EMI/ESD

NON_MOLD_B/C_ESD

R3832

0

C3805 27pF 50V OPT

C3806 100pF 50V OPT

R3808751/4W

SIGN380008

C3811 47pF

1%

50V

R3830 0

R3831 0

AV1_CVBS_IN

COMP1_Y

SPDIF_OUT

SPDIF OUT

+3.3V_NORMAL

VA3807

C3800

5.5V

18pF 50V

OPT

C3818

0.1uF

R3801

+3.3V_NORMAL

R3807 10K

R3803 1K

VA3803

5.6V

470K

+3.3V_NORMAL

R3810 10K

VA3800

5.6V

AV1_CVBS_DET

R3802 1K

1608 sizs For EMI

R3805

0

C3801 560pF 50V OPT

1608 sizs For EMI

R3806

0

C3802 560pF 50V OPT

COMP1_DET

C3803 100pF 50V OPT

C3804 100pF 50V

OPT

MOLD_B/C_ESD

R3811-*1

3.3

1/10W 5%

MOLD_B/C_ESD

R3809-*1

3.3

1/10W 5%

1608 sizs For EMI/ESD

NON_MOLD_B/C_ESD

0

R3811

C3810 27pF 50V OPT

NON_MOLD_B/C_ESD

1608 sizs For EMI/ESD

0

R3809

C3809 27pF 50V

FOR EMI

OPT

R3812 10K

C3807 1000pF 50V OPT

R3813 10K

C3808 1000pF 50V OPT

C3812 27pF 50V OPT

C3813 27pF 50V OPT

R3814 12K

R3815 12K

R3816 75

R3817 75

1%

C3815 10pF 50V

C3814 10pF 50V

COMP1/AV1/DVI_L_IN

COMP1/AV1/DVI_R_IN

COMP1_Pb

COMP1_Pr

PPJ245N2-01

RS232C

JK3801

PEJ034-01

E_SPRING

R_SPRING

T_SPRING

B_TERMINAL2

T_TERMINAL2

3

4

5

7B

6B

TP3800

GND

Fiber Optic

1

VCC

2

VINPUT

16V

JK3800

JST1223-001

3

4

FIX_POLE

RIN1

DOUT1

TP3801

RIN1

JK3802

[GN/YL]E-LUG

6A

5A

[GN/YL]O-SPRING

4A

[GN/YL]CONTACT

5B

[BL]O-SPRING

7C

[RD1]E-LUG-S

5C

[RD1]O-SPRING

4C

[RD1]CONTACT

5D

[WH]O-SPRING

4E

[RD2]CONTACT

5E

[RD2]O-SPRING

6E

[RD2]E-LUG

VA3804

5.5V

VA3805

5.5V

VA3801

5.6V

R3800

470K

SIGN380006

VA3802

5.6V

HP OUT

PZ1608U121-2R0TF

HP_LOUT_AMP

PZ1608U121-2R0TF

HP_ROUT_AMP

L3800

L3801

C3816

0.22uF 25V

C3817

0.22uF 25V

R3818 150

1/10W 5%

R3819 150

1/10W 5%

HP_DET

R3822 100

1/16W 5%

+3.3V_NORMAL

R3823

10K

VA3808

5.6V

E_SPRING

R_SPRING

T_SPRING

B_TERMINAL2

T_TERMINAL2

3

4

5

7B

6B

JK3803

PEJ034-01

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

JACK_COMMON_H

2014-12-22

38

WIFI POWER ENABLE CONTROL

LGE Internal Use Only

+3.5V_ST

WIFI_EN

C4100

0.1uF

R4101 33

R4100 10K

OPT

C4113

0.1uF 16V

IN

EN

IC4100

AP2191WG-7

5

4

+3.5V_WIFI

OUT

1

GND

2

FLG

3

R4119 10K

OPT

P4100

+3.5V_ST

SMAW200-H18S5

C4110

+3.5V_ST

22uF

10V

R4113 0

R4114 0

C4109 5pF 50V

UG87_EMS

C4111

0.1uF

WIFI_DM

WIFI_DP

R4115

10K

C4112

0.1uF UG87_EMS

C4108

GND

NC WOL SDA SCL GND

IR

1 3 5 7 9 11 13 15 17

19

R4111

R4112

100

M_RFModule_RESET

WOL/WIFI_POWER_ON

EYE_SDA

EYE_SCL

IR

LOGO_LIGHT_WAFER

LED_R

IR

AR4101

LOGO_LIGHT

R41080

LED_R

R4109

1.8K

OPT

C4102

0.1uF 16V

100

R4110

10K

5%

C4103

0.1uF

C4104

0.1uF

+3.5V_ST

C4105 100pF

50V

BT_RESET

LED_R

2 4 6

8 10 12 14 16 18

GND

+3.5V_WOL

USB_DM USB_DP GND GND KEY1 KEY2 +3.5V_ST GND

D4100

RCLAMP0502BA

0.1uF

Place Near Wafer C4107 5pF 50V

C4106 1000pF 50V

WIFI_EMI

+3.5V_ST

R4116

1%

For UG87 EMS RS

10K 1%

+3.5V_WIFI

AR4102

100

KEY1 KEY2

Place Near Micom

LOGO_LIGHT

R4102

10K

LOGO_LIGHT

C4101

0.1uF 16V

LOGO_LIGHT

IC4101

AO-R123C7G-LG

GND

G

VS

V

OUT

O

IR_PROTO

1K

R4104

LOGO_LIGHT

R4103

330

IR_PROTO

LOGO_LIGHT

B

Q4100 MMBT3904(NXP)

1/16W

5%

IR_PROTO

LOGO_LIGHT

C

E

R4105471/10W

AR4100 33 1/16W

5%

SMD bottom -> Page 135

LOGO_LIGHT_WAFER

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

IR/KEY

2014-12-25

41

+5V_USB FOR USB3->USB1

LGE Internal Use Only

/USB_OCD3

USB_CTL3

R4304

10K

+3.3V_NORMAL

R4305

4.7K

OCP USB3->USB1

+5V_NORMAL

C4300

0.1uF 16V

IC4300

BD2242G

VIN

1

GND

2

EN

3

+5V_USB_1

+5V_USB_3

USB_DM1

VOUT

6

ILIM

5

1%

OC

4

14K

R4306

USB_DP1

USB_DM2

USB_DP2

D4303

5V

D4301

+5V_USB_2

C4310

5V

10uF

C4322

10uF

10V

USB1->USB3

USB_DM/DP_2.2ohm R4300-*1

2.2 USB_DM/DP_2.2ohm

R4301-*1

2.2

USB_DM/DP_0ohm R4300 0

USB_DM/DP_0ohm R4301 0

C4323

22uF

10V

D4302

RCLAMP0502BA

USB_DM/DP_2.2ohm R4302-*1

2.2 USB_DM/DP_2.2ohm

R4303-*1

2.2

USB_DM/DP_0ohm R4302 0

USB_DM/DP_0ohm R4303 0

C4311

22uF

10V

D4300

RCLAMP0502BA

MAX 1.0A

USB2

MAX 1.0A

1234

JK4302

USB DOWN STREAMUSB DOWN STREAM

3AU04S-305-ZC-(LG)

5

1234

JK4300

3AU04S-305-ZC-(LG)

5

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

USB_DM3

USB_DP3

SSUSB_RXP

SSUSB_RXN

SSUSB_TXP

SSUSB_TXN

USB3.0_TVS

D4304 RCLAMP0544T.TCT

6.5VTO11.0V

1 8 2 7 3 6 4 5

9

USB3.0_TVS

D4305 RCLAMP0544T.TCT

6.5VTO11.0V

1 8 2 7 3 6 4 5

9

C4312 22uF

10V

C4313 10uF 10V

ZD4302

5V

+5V_USB_3

USB3->USB1 (3.0)

MAX 1.2A

JK4301

SJ113262

VBUS

1

D-

2

D+

3

GND

4

STDA_SSRX-

STDA_SSRX+

STDA_SSTX-

STDA_SSTX+

GND_DRAIN

5

6

7

8

9

10

SHIELD

LM15U

USB3_HUB

2014-12-10

43

AV2

LGE Internal Use Only

JK4601

PPJ231-01

4

5

7

8

6

Full Scart

EU

AV2

0

R4618

PSC008-01

JK4600

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

AV_DET

COM_GND

SYNC_IN

SYNC_OUT

SYNC_GND2

SYNC_GND1

RGB_IO

R_OUT

RGB_GND

R_GND

D2B_OUT

G_OUT

D2B_IN

G_GND

ID

B_OUT

AUDIO_L_IN

B_GND

AUDIO_GND

AUDIO_L_OUT

AUDIO_R_IN

AUDIO_R_OUT

R4629 0

+3.3V_NORMAL

EU/AV2

CLOSE TO JUNCTION R4601 10K

EU R4602 100

SC_DET

AV2

EU/AV2

R4630

L4600

L4601

EU/AV2 R4600 470K

EU/AV2 R4603 470K

C4602 4700pF

EU

C4603 4700pF

C4604

0.1uF

1%

EU

75 R4604

SIGN460006

EU/AV2

R4605 10K

EU/AV2

R4606 10K

EU

100

AV2_CVBS_DET

C4605 47pF 50V

C4606 68pF 50V

SC_CVBS_IN

EU

R4615 0

EU

R4614

22

EU

R4616

15K

SC_L_IN

SC_R_IN

DTV/MNT_V_OUT

OPT C4607 68pF 50V

SC_FB

SC_R

SC_G

SC_B

R4617

3.9K

SC_ID

OPT

75

1/4W

EU/AV2

R460 7

EU R4610 75

EU R4608 75

EU R4611 75

EU R4609 75

R4612 12K

EU/AV2

R4613 12K

EU/AV2

DTV/MNT_L_OUT

DTV/MNT_R_OUT

VA4601

5.6V EU/AV2

VA4609

5.5V

EU/AV2

VA4610

5.5V EU

EU

VA4606

5.6V

EU/AV2

VA4607

5.6V

VA4608

VA4602

5.6V EU

VA4603

5.5V

EU

VA4604

5.5V EU

VA4605

5.5V EU

VA4600 20V

EU

VA4611

5.6V EU/AV2

EU

BLM18PG121SN1D

EU

5.6V EU

C4600 1000pF 50V

EU

BLM18PG121SN1D

EU C4601 1000pF 50V

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

SCART_JACK_H

LM15U

SCART JACK_H

2014-12-05

46

NEW_LAN_JACK_ESD

LGE Internal Use Only

JK5000-*1

BS-RV30330

1

2

3

4

5

6

7

8

9

Ethernet Block

C5001

C5000

0.01uF

0.1uF 50V

16V

OLD_LAN_JACK

JK5000

RJ45VT-01SN002

1

2

3

4

5

6

7

8

1

2

3

4

5

6

7

8

9

VA5000

5.5V

VA5001

5.5V

VA5002

5.5V

VA5003

5.5V

EPHY_TDP

EPHY_TDN

EPHY_RDP

EPHY_RDN

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

LAN_H

2014-12-15

50

AUDIO AMP(NTP7515)

LGE Internal Use Only

+24V_AMP

L5800

R5800

10K

C

Q5800-*1

MMBT3904(NXP)

NXP_AMP_MUTE_TR

E

AR5800

100

+3.3V_NORMAL

R5801

10K

C

B

Q5800

2N3904S

KEC_AMP_MUTE_TR

E

PZ1608U121-2R0TF

C5800

1uF

10V

C5801 1uF 10V

C5802 33pF 50V

R5804

100

1000pF

AMP_MUTE

+24V

AUD_LRCH

AUD_LRCK

I2C_SDA4 I2C_SCL4

UBW2012-121F

B

C5803

50V

+3.3V_NORMAL

L5801

C5805

0.1uF 16V

C5804 33pF 50V

AMP_RESET_N

AUD_SCK

VDD_PLL

R5805 100

1/16W

NC_1

NC_2

GND NC_3 DVDD

SDATA

WCK NC_4

SDA

R5806

4.7K

[EP]GND

1 2 3 4 5 6 7 8 9 10

TP5801

TP5802

C5806 1000pF 50V

GND_IO

VDD_IO

39

40

THERMAL

11

12

SCL

FAULT

AD

CLK_I

37

38

41

IC5800

NTP7515

0x54

13

14

MONITOR_0

MONITOR_1

C5808

22000pF

I2S_AMP

WOOFER_MUTE

I2S_AMP

50V

C5807

22000pF

OUT1A

PGND1A

BST1A

RESET

33

34

35

36

15

16

17

18

BST2B

OUT2B

PGND2B

MONITOR_2

50V

+24V_AMP

PVDD1B

PVDD1A

31

32

30 29 28 27 26 25 24 23 22 21

19

20

PVDD2B

PVDD2A

C5809 10uF 35V

OUT1B PGND1B BST1B VDR1 NC_5 AGND VDR2 BST2A PGND2A OUT2A

+24V_AMP

C5810 10uF 35V

C5811 22000pF 50V

C5812 22000pF 50V

R5807

3.3

R5808

3.3

R5809

3.3

R5810

3.3

1/10W

C5813 390pF

50V

C5814 390pF

50V

1/10W

C5815 390pF 50V

C5816 390pF 50V

1/10W

5%

C5817 1uF 10V

5%

SM-6045-100

GET_AMP_COIL

L5802-*1

10.0uH

TAIYO_AMP_COIL

NRS6045T100MMGK

L5802

10.0uH

TAIYO_AMP_COIL

NRS6045T100MMGK

L5805

10.0uH

GET_AMP_COIL

C5818 1uF 10V

TAIYO_AMP_COIL

NRS6045T100MMGK

L5803

10.0uH

TAIYO_AMP_COIL

NRS6045T100MMGK

L5804

10.0uH

SM-6045-100

GET_AMP_COIL

L5804-*1

10.0uH

SM-6045-100

L5805-*1

10.0uH

SM-6045-100

GET_AMP_COIL

L5803-*1

10.0uH

C5819

0.47uF 50V

C5820

0.47uF

50V

SPK_L+

SPK_L-

SPK_R+

SPK_R-

C5821

0.1uF 50V

C5822

0.1uF 50V

C5823

0.1uF 50V

C5824

0.1uF

50V

SPK_L+

R5811

4.7K

R5812

4.7K

SPK_L-

SPK_R+

R5813

4.7K

R5814

4.7K

SPK_R-

4P Box type

WAFER-ANGLE

4

3

2

1

P5800

SPEAKER_L

SPEAKER_R

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

STM_AMP

2014-10-17

58

+12V

LGE Internal Use Only

EU

L6000

AUD_OUT >> EU/CHINA_HOTEL_OPT

330pF C6009

EU

C6000

10uF

DTV/MNT_L_OUT

SCART_Lout

CLOSE TO MSTAR

Near Place Scart AMP

EU

R6019

EU

0

10K

1/16W

5%

R60 03

EU

R6018

EU

0

1/16W

10K R6001

5%

EU

R6000

2.2K

6800pF

SCART_AMP_R_FB

SCART_AMP_L_FB

C6002

220K

R6005

EU

OPT

R6002

470K

SCART_AMP_L_FB

EU

R6006

5.6K

EU

R6004 33K

C6003 33pF

EU

R6020 0

1/16W 5%

IC6000

AZ4580MTR-E1

EU

VCC

8

OUT2

7

IN2-

6

IN2+

5

OPT

OUT1

1

IN1-

2

IN1+

3

VEE

4

R6007

100K

1/16W

5%

OPT

R6009

100K

1/16W

5%

OPT

R6012

100K

R6015

100K

1/16W

5%

1/16W

5%

EU C6004

0.1uF 50V

SIGN600013

R6008 33K

C6005

EU

R6021 0

1/16W 5%

EU

33pF

EU

R6016

5.6K

OPT R6010

470K

SCART_AMP_R_FB

EU

R6017

220K

OPT C6007 6800pF

C6012 330pF

EU

C6008

R6011

2.2K

EU

10uF

DTV/MNT_R_OUT

SCART_Rout

[SCART AUDIO MUTE]

DTV/MNT_L_OUT

Q6000

MMBT3904(NXP)

DTV/MNT_R_OUT

Q6001

MMBT3904(NXP)

C

E

C

E

EU

R6013

1K

B

EU

R6014

1K

B

EU

EU_SCART_MUTE_ISAHAYA

Q6002 RT1P141C-T112

E

C

B

EU_SCART_MUTE_NXP

SCART_MUTE

PDTA114ET

Q6002-*1

E

C

B

CLOSE TO MSTAR

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

UF71/7500

SCART AMP

2014-05-19

17

EARPHONE AMP

LGE Internal Use Only

IC6100

TPA6138A2

HP_ROUT_MAIN

HP_ROUT_AMP

OPT

R6107

0

SIDE_HP_MUTE

C6100 1uF 10V

R6100 10K

C6104

18pF

R6103

+3.3V_NORMAL

43K

4.7K

R6105

+INR

1

R6106 43K

1%

C6108 10pF 50V

C6102 1uF 10V

-INR

OUTR

GND_1

MUTE

VSS

2

3

4

5

6

CN

7

C6103 1uF

10V

+INL

14

C6106 10pF 50V

R6104 43K

1%

-INL

13

OUTL

12

UVP

11

GND_2

10

VDD

9

CP

8

C6109 18pF

1%

R6102

43K

+3.3V_NORMAL

C6105 1uF

16V

10V

C6107

0.1uF

R6101 10K

C6101 1uF 10V

OPT

R6108

0

HP_LOUT_MAIN

HP_LOUT_AMP

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

2014-11-22

HP_AMP 61

B-CAS (SMART CARD) INTERFACE

LGE Internal Use Only

SMARTCARD_PWR_SEL

TPO_DATA[1]

R6300 33

JAPAN

+3.3V_NORMAL

2.7K

R6301

R6303

JAPAN

OPT

R6302

R6304

OPT

2.7K JAPAN

R6305

R6306

CLKDIV1 CLKDIV2 : F_CRD_CLK

2.7K

---------------------------- 1 0 CLKIN

JAPAN

+5V_NORMAL

OPT

BLM18PG121SN1D

JAPAN

L6300

SIGN630005

JAPAN

C6301

10uF 10V

C6302

0.1uF

INT CMDVCC : STATUS

+3.3V_NORMAL

IC6300

TDA8024TT

CLKDIV1

1

CLKDIV2

2

5V/3V

3

PGND

4

S2

5

VDDP

VUP

PRES

I/O

AUX2

AUX1

CGND

6

S1

7

JAPAN

8

9

10

11

12

13

14

JAPAN

C6303

0.1uF 16V

JAPAN

16V

AUX2UC

28

AUX1UC

27

I/OUC

26

XTAL2

25

XTAL1

24

OFF

23

GND

22

VDD

21

RSTIN

20

CMDVCC

19

PORADJ

18

VCC

17

RST

16

CLK

15

C6304

0.1uF

JAPAN

16V

R6307 33 R6308 33 R6309 33 R6310 33

JAPAN JAPAN JAPAN JAPAN

JAPAN

R6311 33

Place CLK C3 far from C2,C7,C4 and C8

75 ohm in I/O is for short circuit Protection

OPT

JAPAN

R6317

1.2K

L6301

JAPAN

BLM18PG121SN1D

JAPAN

C6305

0.1uF 16V

JAPAN

R6318

1.2K

R6315

JAPAN

C6306

0.1uF

16V

+3.3V_NORMAL

10K

R6312

1.2K

JAPAN

R6313 75

OPT

R6319

1.2K

JAPAN

R6316

1.2K

+3.3V_NORMAL

JAPAN

C6307

0.33uF 16V

JAPAN

R6314 1K

ZD6300

5V

JAPAN

TPO_DATA[6]

TPO_DATA[5]

TPO_DATA[3]

TPO_DATA[4]

TPO_DATA[2]

10057542-1311FLF(B CAS Slot)

RESERVED_1

RESERVED

ZD6301 5V

JAPAN

VCC

RST

CLK

GND

VPP

I/O

SW1

SW2

SMARTCARD_DATA

SMARTCARD_CLK SMARTCARD_DET SMARTCARD_RST

SMARTCARD_VCC

B-CAS SLOT

P6300

C1

C2

C3

C4

C5

JAPAN

C6

C7

C8

S1

S2

-------------------------------- HIGH HIGH CARD PRESENT LOW HIGH CARD not PRESENT

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

JAPAN B-CAS

2011.04.17

63

FE_DEMOD1_TS_ERROR

LGE Internal Use Only

FE_DEMOD2_TS_ERROR

Global F/E Option Name

1. TU

2. Tuner Name = TDJ’H’,TDj’M’...

3. Country Name = KR,US,BR,EU ...

Example of Option name TU_ALL_IntDemod = All Tuner type for Internal demod TU_M/W = apply TDSM&TDSW Type Tuner

14’ Tuner Type for Global TDJ’H’-G101D : Half NIM for EU,AJJA TDJ’H’-H101F : Half NIM for US, KR TDJ’K’-T101F : Half NIM for TW TDJ’M’-C301D,F : FULL NIM for China TDJ’M’-B101F : Brazil NIM with Isolater Type TDJ’M’-K101F : colombia NIM TDJ’M’-G101D,G105D,G151D : EU Combo&Full NIM TDJ’M’-H101F,H151F : Korea PIP tuner TDJ’W’-A151D : AJJA T2 PIP

1

2

3

4

5

6

7

8

9

10

11



12

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

34

36

37

38

39

40

45

close to Tuner

L6500

+3.3V_LNA_TU

RF_SWITCH_CTL_TU

IF_AGC_TU

I2C_SCL5_TU

I2C_SDA5_TU

IF_P_TU

should be guarded by ground,Match GND VIA

IF_N_TU

TU_SIF_TU

TU_CVBS_TU

+3.3V_TU

FE_DEMOD1_TS_ERROR

FE_DEMOD1_TS_CLK

FE_DEMOD1_TS_SYNC

FE_DEMOD1_TS_VAL

FE_DEMOD1_TS_DATA[0]

FE_DEMOD1_TS_DATA[1]

FE_DEMOD1_TS_DATA[2]

FE_DEMOD1_TS_DATA[3]

FE_DEMOD1_TS_DATA[4]

FE_DEMOD1_TS_DATA[5]

FE_DEMOD1_TS_DATA[6]

FE_DEMOD1_TS_DATA[7]

/TU_RESET1_TU

+3.3V_DEMOD_TU

I2C_SCL2_TU

D_Demod_Core

LNB_TX

I2C_SDA2_TU

LNB_OUT

FE_DEMOD2_TS_ERROR

FE_DEMOD2_TS_SYNC

FE_DEMOD2_TS_CLK

+2.5V_DEMOD

FE_DEMOD2_TS_VAL

FE_DEMOD2_TS_DATA

/TU_RESET2_TU

PZ1608U121-2R0TF

C6501

0.1uF

TU_ALL_IntDemod

C6502

0.1uF

16V

+3.3V_TUNER

close to Tuner

close to TUNER

TU_K/M/W_TW/BR/CO

C6504

R6503

0.1uF

10K

C6505 47pF 50V OPT

C6503 47pF 50V OPT

R6504 10

TU_ALL_IntDemod

R6505 10

TU_ALL_IntDemod

FE_DEMOD1_TS_DATA[0] FE_DEMOD1_TS_DATA[1] FE_DEMOD1_TS_DATA[2] FE_DEMOD1_TS_DATA[3]

FE_DEMOD1_TS_DATA[4] FE_DEMOD1_TS_DATA[5]

FE_DEMOD1_TS_DATA[6] FE_DEMOD1_TS_DATA[7]

TU_M/W

C6507

16V

0.1uF

PZ1608U121-2R0TF

TU_M/W

C6506

0.1uF

LNB_TX

LNB_OUT

FE_DEMOD2_TS_ERROR

FE_DEMOD2_TS_SYNC

FE_DEMOD2_TS_CLK

FE_DEMOD2_TS_VAL

FE_DEMOD2_TS_DATA

R6507

TU_K/M/W_TW/BR/CO

R6506

1K

TU_ALL_IntDemod

TU_ALL AR6500

33

C6519 33pF

TU_H/M_EU/BR/TW/CO/KR/US

C6520 33pF

TU_H/M_EU/BR/TW/CO/KR/US

TU_M_KR/EU // W_ALL

PZ1608U121-2R0TF

TU_M/W

R6501 100

TU_M_KR/EU // W_ALL

/TU_RESET1

Demod_Core

BLM18PG121SN1D

C6509

0.1uF TU_JP

R6527 100

TU_JP

close to Tuner

TU_M/W

L6505

C6514

16V

0.1uF TU_JP

1K

I2C_SCL5

I2C_SDA5

L6502

OPT

L6501

C6510

0.1uF

FE_DEMOD1_TS_ERROR FE_DEMOD1_TS_CLK

FE_DEMOD1_TS_SYNC

FE_DEMOD1_TS_VAL

FE_DEMOD1_TS_DATA[0-7]

TU_M/W

L6503

PZ1608U121-2R0TF

C6511

TU_M/W

0.1uF

OPT

C6512 18pF 50V

+2.5V_Normal

L6506

TU_JP

/TU_RESET2

TU_W_BR/TW

AR6500-*1 200 1/16W

IF_P

IF_N

+3.3V_TUNER

OPT

C6513 18pF 50V

1. should be guarded by ground

2. No via on both of them

3. Signal Width >= 12mils Signal to Signal Width = 12mils

RF_SWITCH_CTL

Ground Width >= 24mils

IF_AGC

TU_ALL_2178B R6513 0

AR6501 33

TU_M/W

I2C_SCL2 I2C_SDA2

TU_SIF

+3.3V_TUNER

TU_ALL_2178B

R6516 200

B

1608 perallel because of derating

TU_ALL_2178B

R6517

200

E

KEC_TU_ALL_2178B_TR Q6502 2N3906S-RTK

C

FE_DEMOD1_TS_CLK_1

FE_DEMOD1_TS_SYNC_1

FE_DEMOD1_TS_VAL_1

FE_DEMOD1_TS_DATA0_1

FE_DEMOD2_TS_CLK

FE_DEMOD2_TS_SYNC

FE_DEMOD2_TS_VAL

FE_DEMOD2_TS_DATA

TU_CVBS

E

NXP_TU_ALL_2178B_TR

B

Q6502-*1 MMBT3906(NXP)

C

+3.3V_NORMAL

TU_K/M/W_NON_JP TU_K/M/W_NON_JP TU_K/M/W_NON_JP TU_K/M/W_NON_JP

Close to Tuner

TU_M/W

TU_JP TU_JP TU_JP TU_JP

C6500

0.1uF 16V

R65020 R65110 R65120 R65140

R65150 R65180 R65200 R65220

+5V_NORMAL

TU_M/W

C6515 1uF 25V

+3.3V_NORMAL

C6517

22uF

10V

TU_M/W

IC6500

AP2132MP-2.5TRG1

R6500

10K

TU_M/W

VCTRL

PG

1

EN

2

VIN

3

2A

4

TU_M/W

C6516

0.1uF

Vout=0.6*(1+R1/R2)

FE_DEMOD1_TS_CLK FE_DEMOD1_TS_SYNC FE_DEMOD1_TS_VAL FE_DEMOD1_TS_DATA[0]

L6504

PZ1608U121-2R0TF

[EP]

GND

8

ADJ

9

7

THERMAL

VOUT

6

NC

5

+3.3V_TUNER

C6508

0.1uF 16V

FE_DEMOD3_TS_CLK

FE_DEMOD3_TS_SYNC

FE_DEMOD3_TS_VAL

FE_DEMOD3_TS_ERROR

FE_DEMOD3_TS_DATA

T2 : Max 1.7A

else : Max 0.7A

Demod_Core

TU_M/W C6518 10uF 10V

R6521-*1

R6519-*1

TU_M/W_1.2V

10K

R65 21

R65 19

10. 5K

TU_M/W_1.2V

R2

R1

18K

TU_M/W_1.1V

16K

TU_M/W_1.1V

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

TU_CIRCUIT

2014-12-30

65

TU_H_US

LGE Internal Use Only

TU6705 TDJH-H301F

TU_H_BR

TU6701 TDJK-T301F

TU_H_T2_KR

TU6704 TDJM-H401F

TU_M_EU

TU6702 TDJM-G301D

TU_W_JP

TU6703 TDJW-J202F

B1[+3.3V]

1

NC_1

2

NC_2

3

SCL_RF

4

SDA_RF

5

NC_3

6

NC_4

7

NC_5

8

NC_6

9

NC_7

10

B2[+3.3V]

11

NC_8

12

GND_1

13

M_RESET_DEMOD

25

B3[+3.3V]

26

SCL_DEMOD

27

B4[+1.2V]

28

NC_9

29

SDA_DEMOD

30

LNB

31

GND_2

32

NC_10

33

M_ERROR

34

GND_3

35

M_SYNC

36

M_MCLK

37

B5[+2.5V]

38

M_VALID

39

M_DATA

40

S_ERROR

41

S_SYNC

42

S_MCLK

43

S_VALID

44

S_RESET_DEMOD

45

S_DATA

46

B1

TU_GND_B

+3.3V_LNA_TU

RF_SWITCH_CTL_TU

IF_AGC_TU

I2C_SCL5_TU

I2C_SDA5_TU

IF_P_TU

IF_N_TU

TU_SIF_TU

TU_CVBS_TU

+3.3V_TU

FE_DEMOD1_TS_ERROR

FE_DEMOD1_TS_CLK_1

FE_DEMOD1_TS_SYNC_1

FE_DEMOD1_TS_VAL_1

FE_DEMOD1_TS_DATA0_1

FE_DEMOD1_TS_DATA[1]

FE_DEMOD1_TS_DATA[2]

FE_DEMOD1_TS_DATA[3]

FE_DEMOD1_TS_DATA[4]

FE_DEMOD1_TS_DATA[5]

FE_DEMOD1_TS_DATA[6]

FE_DEMOD1_TS_DATA[7]

/TU_RESET1_TU

+3.3V_DEMOD_TU

I2C_SCL2_TU

D_Demod_Core

LNB_TX

I2C_SDA2_TU

LNB_OUT

FE_DEMOD2_TS_ERROR

FE_DEMOD2_TS_SYNC

FE_DEMOD2_TS_CLK

+2.5V_DEMOD

FE_DEMOD2_TS_VAL

FE_DEMOD2_TS_DATA

FE_DEMOD3_TS_ERROR

FE_DEMOD3_TS_SYNC

FE_DEMOD3_TS_CLK

FE_DEMOD3_TS_VAL

/TU_RESET2_TU

FE_DEMOD3_TS_DATA

1

2

3

4

5

6

7

8

9

10

11

12

13

14

16

17

18

19

20

21

22

23

24

25

26

27

30

31

32

33

34

35

36

40

41

42

43

44

45

46

47

48

49

B1

TU_H_T2_CO

A1

1

2

3

4

5

6

7

8

9

47

+3.3V

NC

DIF_AGC

SCL_RF

SDA_RF

DIF[P]

DIF[N]

SIF

CVBS

B1

TU6704-*1 TDJM-K301F

+3.3V

1

NC_1

2

NC_2

3

SCL_RF

4

SDA_RF

5

NC_3

6

NC_4

7

SIF

8

CVBS

9

NC_5

10

+3.3V_RF

11

ERROR

12

GND_1

13

MCLK

14

SYNC

15

VAILD

16

D0

17

D1

18

D2

19

D3

20

D4

21

D5

22

D6

23

D7

24

RESET_DEMOD

25

+3.3V_DEMOD

26

SCL_DEMOD

27

+1.2V_DEMOD

28

NC_6

29

SDA_DEMOD

30

B1B1A1

SHIELD

TU_GND_B

+3.3V

1

NC_1

2

NC_2

3

SCL_RF

4

SDA_RF

5

NC_3

6

NC_4

7

SIF

8

CVBS

9

NC_5

10

+3.3V_RF

11

ERROR

12

GND_1

13

MCLK

14

SYNC

15

VAILD

16

D0

17

D1

18

D2

19

D3

20

D4

21

D5

22

D6

23

D7

24

RESET_DEMOD

25

+3.3V_DEMOD

26

SCL_DEMOD

27

+1.2V_DEMOD

28

NC_6

29

SDA_DEMOD

30

A1

B1

+3.3V

1

NC_1

2

AIF_AGC

3

SCL_RF

4

SDA_RF

5

AIF[P]

6

AIF[N]

7

SIF

8

CVBS

9

NC_2

10

+3.3V_RF

11

ERROR

12

GND_1

13

MCLK

14

SYNC

15

VALID

16

D0

17

D1

18

D2

19

D3

20

D4

21

D5

22

D6

23

D7

24

RESET_DEMOD

25

+3.3V_DEMOD

26

SCL_DEMOD

27

+1.2V_DEMOD

28

NC_3

29

SDA_DEMOD

30

LNB

31

GND

32

+3.3V

1

NC_1

2

DIF_AGC

3

SCL_RF

4

SDA_RF

5

DIF[P]

6

DIF[N]

7

SIF

47

SHIELD

8

CVBS

9

B1

A1

47

SHIELD

TU_GND_B

TU_GND_A

TDJH-G301D

TU6705-*1 TDJH-G301D

+3.3V

1

NC_1

2

IF_AGC

3

SCL_RF

4

SDA_RF

5

IF[P]

6

IF[N]

7

SIF

8

CVBS

9

A1

B1

47

A1

TU_GND_A

A1

SHIELD

EMS Page --> Sheet : 135

47

B1

TU_GND_A

SHIELD

TU_GND_B

A1

47

SHIELD

JAPAN TUNER (RDA5817)_Don’t USE_Just Ready

A1A1B1

47

TU_W_JP_RDA5817

TU6703-*1 TDJW-J301F

10

11

12

13

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

SHIELD

+3.3V_LNA

1

NC_1

2

NC_2

3

SCL_RF

4

SDA_RF

5

NC_3

6

NC_4

7

NC_5

8

NC_6

9

NC_7

+3.3V_RF

NC_8

GND_1

RESET_M_DEMOD

+3.3V_DEMOD

SCL_DEMOD

+1.2V_DEMOD

NC_9

SDA_DEMOD

LNB

GND_2

NC_10

M_ERROR

GND_3

M_SYNC

M_MCLK

+2.5V_DEMOD

M_VALID

M_DATA

S_ERROR

S_SYNC

S_MCLK

S_VALID

S_RESET_DEMOD

S_DATA

B1

TDJM-C401D

TU6702-*4 TDJM-C401D

+3.3V

1

NC_1

2

NC_2

3

SCL_RF

4

SDA_RF

5

NC_3

6

NC_4

7

SIF

8

CVBS

9

NC_5

10

+3.3V_RF

11

ERROR

12

GND_1

13

MCLK

14

SYNC

15

VAILD

16

D0

17

D1

18

D2

19

D3

20

D4

21

D5

22

D6

23

D7

24

RESET_DEMOD

25

+3.3V_DEMOD

26

SCL_DEMOD

27

+1.2V_DEMOD

28

NC_6

29

SDA_DEMOD

30

A1

B1B1A1

47

SHIELD

TDJM-B301F

TU6702-*3 TDJM-B301F

+3.3V

1

NC_1

2

NC_2

3

SCL_RF

4

SDA_RF

5

NC_3

6

NC_4

7

SIF

8

CVBS

9

NC_5

10

+3.3V_RF

11

ERROR

12

GND_1

13

MCLK

14

SYNC

15

VAILD

16

D0

17

D1

18

D2

19

D3

20

D4

21

D5

22

D6

23

D7

24

RESET_DEMOD

25

+3.3V_DEMOD

26

SCL_DEMOD

27

+1.2V_DEMOD

28

NC_6

29

SDA_DEMOD

30

A1

B1B1A1

47

SHIELD

A1

TU_GND_A

TU_M_AJ

TU6702-*2 TDJM-G305D

+3.3V

1

NC_1

2

NC_2

3

SCL_RF

4

SDA_RF

5

NC_3

6

NC_4

7

SIF

8

CVBS

9

NC_5

10

+3.3V_RF

11

ERROR

12

GND_1

13

MCLK

14

SYNC

15

VAILD

16

D0

17

D1

18

D2

19

D3

20

D4

21

D5

22

D6

23

D7

24

RESET_DEMOD

25

+3.3V_DEMOD

26

SCL_DEMOD

27

+1.2V_DEMOD

28

NC_6

29

SDA_DEMOD

30

B1B1A1

47

SHIELD

TU_GND_B

TU_M_CN

TU6702-*1 TDJM-C301D

B1[+3.3V]

1

RF_SW_CTL

2

NC_1

3

SCL_RF

4

SDA_RF

5

NC_2

6

NC_3

7

SIF

8

CVBS

9

NC_4

10

NC_5

11

ERROR

12

GND_1

13

MCLK

14

SYNC

15

VAILD

16

D0

17

D1

18

D2

19

D3

20

D4

21

D5

22

D6

23

D7

24

RESET_DEMOD

25

B2[+3.3V]

26

SCL_DEMOD

27

B3[+1.1V]

28

NC_6

29

SDA_DEMOD

30

A1

B1B1A1

47

SHIELD

TU_GND_A

A1

47

SHIELD

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

TU_SYMBOL_H

2014-09-11

19

DVB-S2 LNB Part Allegro

LGE Internal Use Only

LNB_OUT

(Option:LNB)

C6900

0.1uF LNB

Close to Tuner Surge protectioin

C6901 33pF

LNB

D6900

LNB

R6900

2.2K 1W

LNB

LNB_TSC

SS23L D6901-*1

LNB_TSC

MBR230LSFT1G

LNB_ONSEMI

C6902

0.22uF

LNB

25V

A_GND

2A

D6902-*1 SS23L

30V

D6901

30V

D6902

LNB_ONSEMI

30V

C6903

0.01uF 50V LNB

LNB

C6905 10uF 25V

LNB

close to Boost pin(#1)

C6904

0.1uF 50V

A_GND

D6903 LNB_SMAB34

40V

D6903-*1 LNB_SX34

40V

C6906 10uF 25V

LNB

A_GND

C6907 10uF 25V

LNB

NC_1

LNB

NC_2

TDI

TDO

[EP]

1

2

3

4

5

C6908 0.1uF

THERMAL

21

IC6900-*1

DT1803

LNB_DMBT

7

SCL9ADD

SDA6IRQ

8

D6904-*1

40V

LNB_SX34

D6904

40V

LNB_SMAB34

LNB_ALLEGRO

VCP

LNB

NC_1

TDI

TDO

PGND18NC_319NC_420BOOST

16LX17

VIN

15

GND

14

VREG

13

ISET

12

TCAP

11

10

TONECTRL

LPH6050T-150M-R

A_GND

NC_2

NC_3

BOOST

[EP]GND

18

19

20

1

THERMAL

2

21

3

IC6900

A8303SESTR-T

4

LNB_ALLEGRO

5

7

8

6

SCL9ADD

SDA

IRQ

GNDLX

16LX17

10

TONECTRL

+12V

LNB

L6900

3.5A

15uH

VIN

15

GND

14

VREG

13

ISET

12

TCAP

11

+3.3V_NORMAL

OPT

3.3K

R6907

LNB

R6906

0

3A

Max 1.3A

C6909 10uF 25V

LNB

A_GND

close to VIN pin(#15)

C6910

0.1uF 50V

LNB

C6912

LNB

0.1uF

LNB

C6911 0.22uF

Input trace widths should be sized to conduct at least 3A Ouput trace widths should be sized to conduct at least 2A

LNB R6903

39K

1/16W 1%

Caution!! need isolated GND

A_GND



R6904 0

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LNB

R6901 33

I2C_SCL2

LNB

R6902 33

I2C_SDA2

R6905

LNB_Tx

LNB_TX

0

R6908

LNB_NON_Tx

LM15U

LNB

2014-08-25

20

[51P Vx1 output wafer]

LGE Internal Use Only

Non REVERSE Type

P7201

SP14-11592-01-51Pin

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

R7203 10K

OPT

R7202

LGD_Module

R7201

0

TXDAP7_L

TXDAN7_L

TXDAP6_L

TXDAN6_L

TXDAP5_L

TXDAN5_L

TXDAP4_L

TXDAN4_L

TXDAP3_L

TXDAN3_L

TXDAP2_L

TXDAN2_L

TXDAP1_L

TXDAN1_L

TXDAP0_L

TXDAN0_L

LOCKAn_IN

HTPDAn_IN

10K

OPT

EXT_FRC_TEMP

R7232 0

EXT_FRC_TEMP

R7233 0

R7134 0

EXT_FRC_TEMP

0

R7237 NON_EXT_FRC_TEMP

0

R7231

NON_EXT_FRC_TEMP

R7235 0 NON_EXT_FRC_TEMP

[OPTION]EXT_FRC_TEMP Only for Using External FRC B/D

L/D_EN(Pin30)

- T-Con L/D Function HIGH : Enable LOW or NC : Disable



BIT_SEL(Pin31)

- Bit Selection HIGH or NC : 10Bit LOW : 8Bit

+3.3V_NORMAL

LGD_Module R7204

4.7K 33

R7205

1K

R7206 LGD_Module

OPT

I2C_SCL7

I2C_SDA7

R7136

URSA_RESET_SoC

+3.3V_NORMAL

R7208

1K

LGD_Module

OPT

0

MLB-201209-0120P-N2

R7207

10K

OPT

3D&L_DIM_EN

URSA_RESET_MICOM

L7200

C7200 10uF 25V

+3.3V_NORMAL

PANEL_VCC

C7201 10uF 25V

R7234

4.7K

OPT

R7200

33

OPT

+3.3V_NORMAL

D

DIODES_LGD_Module_TCON_I2C_EN_FET

Q7200-*1

G

2N7002K

S

+3.3V_NORMAL

Q7200

2N7002KA

OPT

R7212

4.7K

S

4.7K

OPT

R7214

R7213

2N7002KA

DATA_FORMAT_0_SOC

+3.3V_NORMAL

3D&L_DIM_EN

OPT R7209 10K

R7211

33

R7210 10K

OPT

KEC_LGD_Module_TCON_I2C_EN_FET

G

R7218

D

0

LGD_Module

OPT

33

G

Q7201

KEC_LGD_Module_TCON_I2C_EN_FET

R7219

D

S

0

LGD_Module

R7215

33 OPT

G

+3.3V_NORMAL

R7216 10K

R7217 10K

D

DIODES_LGD_Module_TCON_I2C_EN_FET

Q7201-*1 2N7002K

S

OPT

33 R7220

OPT

LOCKAn_IN

HTPDAn_IN

TCON_I2C_EN

I2C_SCL6

TCON_I2C_EN

I2C_SDA6

DATA_FORMAT_1_SOC

OPT

Data Input Format[1:0]

*Mode 3 (4 Division)

- Data Format 0(Pin37) = Low Data Format 1(Pin36) = High

*Mode 2 (2 Division)

- Data Format 0(Pin37) = High Data Format 1(Pin36) = Low

+3.3V_NORMAL

+1.8V

LOCKAn_3.3VPullup

R7222 10K

LOCKAn_3.3VPullup

R7224 100

B

+3.3V_NORMAL

HTPDAn_3.3VPullup

+1.8V

HTPDAn_3.3VPullup

R7221 10K

HTPDAn_3.3VPullup

R7223 100

B

LOCKAn_3.3VPullup

R7226 10K

LOCKAn_3.3VPullup

C

KEC_LOCKAn_HTPDAn_3.3VPullup_TR

E

R7225 10K

HTPDAn_3.3VPullup

C

Q7202 2N3904S KEC_LOCKAn_HTPDAn_3.3VPullup_TR

E

LOCKAn_3.3VPullup

R7228

10K

B

Q7203 2N3904S

C

Q7203-*1

B

MMBT3904(NXP) NXP_LOCKAn_HTPDAn_3.3VPullup_TR

E

HTPDAn_3.3VPullup

R7227

10K

B

C

Q7202-*1

B

MMBT3904(NXP)

NXP_LOCKAn_HTPDAn_3.3VPullup_TR

E

R7230 10K

C

E

R7229 10K

C

Q7204 2N3904S

E

LOCKAn

Q7205 2N3904S KEC_LOCKAn_HTPDAn_3.3VPullup_TR

B

HTPDAn

KEC_LOCKAn_HTPDAn_3.3VPullup_TR

C

B

E

C

Q7205-*1 MMBT3904(NXP)

NXP_LOCKAn_HTPDAn_3.3VPullup_TR

E

Q7204-*1 MMBT3904(NXP)

NXP_LOCKAn_HTPDAn_3.3VPullup_TR

L_DIM_EN 3D_EN

T-con power

P7203

20037WR-05A00

5P_12V_WAFER

1

2

3

4

5

6

C7202 10uF 25V

5P_12V_WAFER

L7201

MLB-201209-0120P-N2

C7203

5P_12V_WAFER

0.1uF 25V

5P_12V_WAFER

L7202

C7204 10uF 25V

OPT

PANEL_VCC

5P_12V_WAFER

C7205

0.1uF 25V

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

51P Vx1

2015-01-07

71

eMMC I/F

LGE Internal Use Only

DVDD18_EMMC

3.3v power delete, 131120

10K

1/16W

AR8104

EMMC_DATA[0-7]

EMMC_DATA[0] EMMC_DATA[1] EMMC_DATA[2]

EMMC_DATA[3] EMMC_DATA[4] EMMC_DATA[5] EMMC_DATA[6]

EMMC_DATA[7]

EMMC_CLK EMMC_CMD EMMC_RST

AR8100 0 1/16W

R81040 R81050 R81060 R81070

AR8102 0 1/16W

C8107 10pF

OPT

50V

C8100

0.1uF

OPT

16V

Don’t Connect Power At VDDI

(Just Interal LDO Capacitor)

10K

1/16W

DAT3

AR8103

DAT4

DAT5

DAT6

10K

R8117

EMMC_CLK_BALL

EMMC_CMD_BALL

10K

R8116

DVDD18_EMMC

EMMC_RESET_BALL

Bottom

OPT

C8108

0.1uF 16V

EMMC_VDDI

eMMC V5.0 GND

3.3V_EMMC

OPT

C8109

2.2uF 10V

C8102

0.1uF 16V

EMMC_STRB

C8105

0.1uF 16V

C8103

2.2uF 10V

DAT3 DAT4 DAT7

DAT5

C8106

2.2uF 10V

Bottom

OPT

C8111

4.7uF 10V

DAT6

OPT

C8101 1uF 10V

DVDD18_EMMC

DAT7

10K

R8103

pattern 0.2mm

C8104

2.2uF 10V

THGBMBG5D1KBAIL

A3

DAT0

A4

DAT1

A5

DAT2

B2

DAT3

B3

DAT4

B4

DAT5

B5

DAT6

B6

DAT7

M6

CLK

M5

CMD

A6

VSS_1

A7

RFU_2

C5

NC_21

E5

RFU_4

E8

RFU_5

E9

VSF_1

E10

VSF_2

F10

VSF_3

G3

RFU_9

G10

RFU_10

H5

DS

J5

VSS_5

K6

RFU_13

K7

RFU_14

K10

RFU_15

P7

RFU_16

P10

RFU_17

K5

RSTN

C6

VCCQ_1

M4

VCCQ_2

N4

VCCQ_3

P3

VCCQ_4

P5

VCCQ_5

E6

VCC_1

F5

VCC_2

J10

VCC_3

K9

VCC_4

C2

VDDI

E7

VSS_2

G5

VSS_3

H10

VSS_4

K8

VSS_6

C4

VSSQ_1

N2

VSSQ_2

N5

VSSQ_3

P4

VSSQ_4

P6

VSSQ_5

A1

NC_1

A2

NC_2

A8

NC_3

A9

NC_4

A10

NC_5

A11

NC_6

A12

NC_7

A13

NC_8

A14

NC_9

B1

NC_10

B7

NC_11

B8

NC_12

B9

NC_13

B10

NC_14

B11

NC_15

B12

NC_16

B13

NC_17

B14

NC_18

C1

NC_19

C3

NC_20

C7

NC_22

IC8100

C8

NC_23

C9

NC_24

C10

NC_25

C11

NC_26

C12

NC_27

C13

NC_28

C14

NC_29

D1

NC_30

D2

NC_31

D3

NC_32

D4

NC_33

D12

NC_34

D13

NC_35

D14

NC_36

E1

NC_37

E2

NC_38

E3

NC_39

E12

NC_40

E13

NC_41

E14

NC_42

F1

NC_43

F2

NC_44

F3

NC_45

F12

NC_46

F13

NC_47

F14

NC_48

G1

NC_49

G2

NC_50

G12

NC_51

G13

NC_52

G14

NC_53

H1

NC_54

H2

NC_55

H3

NC_56

H12

NC_57

H13

NC_58

H14

NC_59

J1

NC_60

J2

NC_61

J3

NC_62

J12

NC_63

J13

NC_64

J14

NC_65

K1

NC_66

K2

NC_67

K3

NC_68

K12

NC_69

K13

NC_70

K14

NC_71

L1

NC_72

L2

NC_73

L3

NC_74

L12

NC_75

L13

NC_76

L14

NC_77

M1

NC_78

M2

NC_79

M3

NC_80 NC_81 NC_82 NC_83 NC_84 NC_85 NC_86 NC_87 NC_88 NC_89 NC_90 NC_91 NC_92 NC_93 NC_94 NC_95 NC_96 NC_97 NC_98

NC_99 NC_100 NC_101 NC_102 NC_103 NC_104 NC_105 NC_106 NC_107

M7 M8 M9 M10 M11 M12 M13 M14 N1 N3 N6 N7 N8 N9 N10 N11 N12 N13 N14 P1 P2 P8 P9 P11 P12 P13 P14

EMMC5.0_4G_TOSHIBA

DAT5

EMMC_STRB

EMMC_RESET_BALL

EMMC_CLK_BALL

EMMC_CMD_BALL

DAT6

THGBMBG6D1KBAIL

A3

DAT0

A4

DAT1

A5

DAT2

B2

DAT3

B3

DAT4

B4

DAT5

B5

DAT6

B6

DAT7

M6

CLK

M5

CMD

A6

VSS_1

A7

RFU_2

C5

NC_21

E5

RFU_4

E8

RFU_5

E9

VSF_1

E10

VSF_2

F10

VSF_3

G3

RFU_9

G10

RFU_10

H5

DS

J5

VSS_5

K6

RFU_13

K7

RFU_14

K10

RFU_15

P7

RFU_16

P10

RFU_17

K5

RSTN

C6

VCCQ_1

M4

VCCQ_2

N4

VCCQ_3

P3

VCCQ_4

P5

VCCQ_5

E6

VCC_1

F5

VCC_2

J10

VCC_3

K9

VCC_4

C2

VDDI

E7

VSS_2

G5

VSS_3

H10

VSS_4

K8

VSS_6

C4

VSSQ_1

N2

VSSQ_2

N5

VSSQ_3

P4

VSSQ_4

P6

VSSQ_5

A1

NC_1

A2

NC_2

A8

NC_3

A9

NC_4

A10

NC_5

A11

NC_6

A12

NC_7

A13

NC_8

A14

NC_9

B1

NC_10

B7

NC_11

B8

NC_12

B9

NC_13

B10

NC_14

B11

NC_15

B12

NC_16

B13

NC_17

B14

NC_18

C1

NC_19

C3

NC_20

C7

NC_22

IC8100-*1

C8

NC_23

C9

NC_24

C10

NC_25

C11

NC_26

C12

NC_27

C13

NC_28

C14

NC_29

D1

NC_30

D2

NC_31

D3

NC_32

D4

NC_33

D12

NC_34

D13

NC_35

D14

NC_36

E1

NC_37

E2

NC_38

E3

NC_39

E12

NC_40

E13

NC_41

E14

NC_42

F1

NC_43

F2

NC_44

F3

NC_45

F12

NC_46

F13

NC_47

F14

NC_48

G1

NC_49

G2

NC_50

G12

NC_51

G13

NC_52

G14

NC_53

H1

NC_54

H2

NC_55

H3

NC_56

H12

NC_57

H13

NC_58

H14

NC_59

J1

NC_60

J2

NC_61

J3

NC_62

J12

NC_63

J13

NC_64

J14

NC_65

K1

NC_66

K2

NC_67

K3

NC_68

K12

NC_69

K13

NC_70

K14

NC_71

L1

NC_72

L2

NC_73

L3

NC_74

L12

NC_75

L13

NC_76

L14

NC_77

M1

NC_78

M2

NC_79

M3

NC_80

M7

NC_81

EMMC5.0_8G_TOSHIBA

NC_82 NC_83 NC_84 NC_85 NC_86 NC_87 NC_88 NC_89 NC_90 NC_91 NC_92 NC_93 NC_94 NC_95 NC_96 NC_97 NC_98

NC_99 NC_100 NC_101 NC_102 NC_103 NC_104 NC_105 NC_106 NC_107

M8 M9 M10 M11 M12 M13 M14 N1 N3 N6 N7 N8 N9 N10 N11 N12 N13 N14 P1 P2 P8 P9 P11 P12 P13 P14

A3 A4 A5 B2 B3 B4 B5 B6

M6 M5

A7 E5 G3 K6 K7 E8

E9 E10 F10 G10 K10 P10

H5

K5

C6

M4

N4

P3

P5

E6

F5 J10

K9

C2

C4

N2

N5

P4

P6

A6

E7

G5 H10

J5

K8

A1

A2

A8

A9 A10 A11 A12 A13 A14

B1

B7

B8

B9 B10 B11 B12 B13 B14

C1

C3

C5

IC8100-*2

H26M41103HPR

DAT0 DAT1 DAT2 DAT3 DAT4 DAT5 DAT6 DAT7

CLK CMD

RFU_1 RFU_2 RFU_3 RFU_4 RFU_5 VSF_1 VSF_2 VSF_3 VSF_4 VSF_5 VSF_6 VSF_7 DS

RSTN

VCCQ_1 VCCQ_2 VCCQ_3 VCCQ_4 VCCQ_5

VCC_1 VCC_2 VCC_3 VCC_4

VDDI

VSSQ_1 VSSQ_2 VSSQ_3 VSSQ_4 VSSQ_5 VSS_1 VSS_2 VSS_3 VSS_4 VSS_5 VSS_6

NC_1 NC_2 NC_3 NC_4 NC_5 NC_6 NC_7 NC_8 NC_9 NC_10 NC_11 NC_12 NC_13 NC_14 NC_15 NC_16 NC_17 NC_18 NC_19 NC_20 NC_21

C7

NC_22

C8

NC_23

C9

NC_24

C10

NC_25

C11

NC_26

C12

NC_27

C13

NC_28

C14

NC_29

D1

NC_30

D2

NC_31

D3

NC_32

D4

NC_33

D12

NC_34

D13

NC_35

D14

NC_36

E1

NC_37

E2

NC_38

E3

NC_39

E12

NC_40

E13

NC_41

E14

NC_42

F1

NC_43

F2

NC_44

F3

NC_45

F12

NC_46

F13

NC_47

F14

NC_48

G1

NC_49

G2

NC_50

G12

NC_51

G13

NC_52

G14

NC_53

H1

NC_54

H2

NC_55

H3

NC_56

H12

NC_57

H13

NC_58

H14

NC_59

J1

NC_60

J2

NC_61

J3

NC_62

J12

NC_63

J13

NC_64

J14

NC_65

K1

NC_66

K2

NC_67

K3

NC_68

K12

NC_69

K13

NC_70

K14

NC_71

L1

NC_72

L2

NC_73

L3

NC_74

L12

NC_75

L13

NC_76

L14

NC_77

M1

NC_78

M2

NC_79

M3

NC_80 NC_81 NC_82 NC_83 NC_84 NC_85 NC_86 NC_87 NC_88 NC_89 NC_90 NC_91 NC_92 NC_93 NC_94 NC_95 NC_96 NC_97 NC_98

NC_99 NC_100 NC_101 NC_102 NC_103 NC_104 NC_105 NC_106 NC_107 NC_108

M7 M8 M9 M10 M11 M12 M13 M14 N1 N3 N6 N7 N8 N9 N10 N11 N12 N13 N14 P1 P2 P7 P8 P9 P11 P12 P13 P14

EMMC5.0_8G_HYNIX

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

eMMC

2014-11-17

81

RS-232C Control INTERFACE

LGE Internal Use Only

+3.5V_ST

RS232C

R6820 100

RS232C

R6821 100

DOUT1

RIN1

RS232C

C6808

0.1uF

C6809

0.1uF

C6810

0.1uF

C6811

0.1uF

C1+

C1-

C2+

C2-

DOUT2

RIN2

V+

V-

RS232C

IC6801

MAX3232CDR

1

2

3

4

5

6

7

8

EAN41348201

OPT ZD6802

ADUC 20S 02 010L

RS232C

C6813

0.1uF

VCC

16

GND

15

DOUT1

14

RIN1

13

ROUT1

12

DIN1

11

DIN2

10

ROUT2

9

SOC_RX

SOC_TX

20V

OPT ZD6803

ADUC 20S 02 010L 20V

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

UF71/7500

RS232C

2014-05-19

22

[LM15U_ONLY]

LGE Internal Use Only

CLIP Top Side for Covershield

OPT

M13500

EAG64250901

M13502

EAG64250901

M13504

EAG64250901

CLIP 1 - PUSH TYPE

SMD Top Side for Covershield

OPT

GASKET_8.0X6.0X8.5H

M13501

MDS62110209

OPT

GASKET_8.0X6.0X8.5H

M13503

MDS62110209

GASKET_8.0X6.0X8.5H

MDS62110209

8.5T

SMD bottom for ESD

OPT

GASKET_8.0X6.0X10.5H

M4102

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4103

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4104

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4105

MDS62110225

TU_JP

GASKET_8.0X6.0X10.5H

M4106

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4107

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4110

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4114

MDS62110225

OPT

M13505

HDMI1

HDMI1_BOT_SMD_10.5T

GASKET_8.0X6.0X10.5H

M4100

MDS62110225

HDMI1_BOT_SMD_8.5T GASKET_8.0X6.0X8.5H

M4100-*1

MDS62110209

TOP_SMD_GASKET

GASKET_8.0X6.0X8.5H

M13507

MDS62110209

HDMI1_BOT_SMD_11.5T

GASKET_8.0X6.0X11.5H

M4100-*3

MDS62110228

To connect 28pin Wafer

To connect 51P wafer

TXVBY1_0N TXVBY1_0P TXVBY1_1N TXVBY1_1P

TXVBY1_2N TXVBY1_2P TXVBY1_3N TXVBY1_3P TXVBY1_4N TXVBY1_4P TXVBY1_5N TXVBY1_5P TXVBY1_6N TXVBY1_6P TXVBY1_7N TXVBY1_7P

HDMI2

HDMI2_BOT_SMD_10.5T

GASKET_8.0X6.0X10.5H

M4108

MDS62110225

HDMI2_BOT_SMD_8.5T GASKET_8.0X6.0X8.5H

M4108-*1

MDS62110209

L/D_VSYNC_SOC

L/D_CLK_SOC

L/D_DI_SOC

HDMI2_BOT_SMD_11.5T GASKET_8.0X6.0X11.5H

M4108-*2

MDS62110228

0

OS_MODULE

R13500

0

OS_MODULE

R13501

0

OS_MODULE

R13502

C135000.1uF C135010.1uF C135020.1uF TXDAN1_L C135030.1uF

C135040.1uF C135050.1uF C135060.1uF C135070.1uF C135080.1uF C135090.1uF C135100.1uF C135110.1uF C135120.1uF C135130.1uF C135140.1uF C135150.1uF

HDMI3

HDMI3_BOT_SMD_8.5T

GASKET_8.0X6.0X8.5H

L/D_VSYNC L/D_CLK L/D_DI

M4115

MDS62110209

TXDAN0_L TXDAP0_L

TXDAP1_L

TXDAN2_L TXDAP2_L TXDAN3_L TXDAP3_L TXDAN4_L TXDAP4_L TXDAN5_L TXDAP5_L TXDAN6_L TXDAP6_L TXDAN7_L TXDAP7_L

LOCKAn HTPDAn

HDMI3_BOT_SMD_10.5T

GASKET_8.0X6.0X10.5H

M4115-*1

MDS62110225

HDMI3_BOT_SMD_9T

GASKET_8.0X6.0X9.0H

M4115-*2

MDS62110226

0 0

R13503 R13504

LOCKAn_Video HTPDAn_Video

OPT

GASKET_8.0X6.0X10.5H

M4101

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4117

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4118

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4112

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4119

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4109

MDS62110225

OPT

GASKET_8.0X6.0X10.5H

M4120

MDS62110225

USB3 USB2

USB3_BOT_SMD_10.5T

GASKET_8.0X6.0X10.5H

M4111

MDS62110225

USB3_BOT_SMD_8.5T

GASKET_8.0X6.0X8.5H

M4111-*1

MDS62110209

OPT

GASKET_8.0X6.0X10.5H

M4121

MDS62110225

USB3_BOT_SMD_11.5T

GASKET_8.0X6.0X11.5H

M4111-*2

MDS62110228

OPT

GASKET_8.0X6.0X10.5H

M4122

MDS62110225

USB2_BOT_SMD_10.5T

GASKET_8.0X6.0X10.5H

USB2_BOT_SMD_8.5T

GASKET_8.0X6.0X8.5H

M4113

MDS62110225

M4113-*1

MDS62110209

USB2_BOT_SMD_11.5T

GASKET_8.0X6.0X11.5H

M4113-*2

MDS62110228

USB1

USB1_BOT_SMD_8.5T

GASKET_8.0X6.0X8.5H

M4116

MDS62110209

USB1_BOT_SMD_10.5T

GASKET_8.0X6.0X10.5H

M4116-*1

MDS62110225

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

LM15U

LM15U_ONLY

2014-11-27

135

LM15U ONLY, LM15U+URSA

LGE Internal Use Only

TUNER EMS GND SEPERATION

TU_GND_A1_0ohm

TU_GND_A1_1nF

R6701-*1 1000pF

TU_GND_A

GND A_1

GND A_2

GND A_3

GND A_4

GND A_5

TU_GND_A

TU_GND_A4_22nF

C6700

0.022uF

TU_GND_A5_22ohm

630V

R6703

22

TU_GND_A4_1nF

C6700-*1 1000pF

TU_GND_B2_22ohm

630V

R6701

0

630V

TU_GND_A2_1nF

C6706 1000pF

630V

TU_GND_A2_22nF

C6706-*1

0.022uF 630V

TU_GND_A3_0ohm

R6700

0

TU_GND_A3_22nF

R6700-*1

0.022uF 630V

GND_A GND_B

0 ohm

X

X 22 nF

0 ohm

X

0 ohm

X

22 nF

X

22 nF

22 ohm

0 ohm

X

0 ohm

X

TU_GND_B

TU_GND_B1_22nF

C6703

0.022uF 630V

R6704 22

TU_GND_B2_0ohm

0

R6704-*1

X

22 nF

22 nFX

22 ohm

TU_GND_B3_1nF

C6707 1000pF 630V

TU_GND_B3_22nF

C6707-*1

0.022uF 630V

JPAJJA TW/COLEU/CIS North.AMCN/HK KR BR BRKR JPNorth.AMTU_GND_B AJJA TW/COL CN/HKEU/CIS

0 ohm

1 nF

TU_GND_B4_1nF

C6708 1000pF 630V

TU_GND_B4_22nF

C6708-*1

0.022uF 630V

GND B_1

GND B_2

0 ohm

1 nF

22 ohm

GND B_3

GND B_4

X

X X

1 nF

X

1 nF

22 nF 22 nF

22 ohm 22 ohm

22 nF

X

1 nF

22 nF

X

1 nF

TU_BOT_SMD1

GASKET_8.0X6.0X10.5H

M13700

MDS62110225

TU_BOT_SMD3

GASKET_8.0X6.0X10.5H

M13702

MDS62110225

TU_BOT_SMD2

GASKET_8.0X6.0X10.5H

M13701

MDS62110225

TU_BOT_SMD

SMD1

SMD2

SMD3

AJJA

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.

CN/HK North.AMEU/CIS

BR

JPKRTW/COL

LM15U

2014-11-11

Tuner_GND 137

Repair Guide

LGE Internal Use Only

`15 years New Models

Contents of Standard Repair Process

LGE Internal Use Only

No. Error symptom (High category) Error symptom (Mid category) Page Remarks

1

2 No video/No audio 2

3 Picture broken/ Freezing 3

4 Color error 4

5

6

7

8

9 Wrecked audio/discontinuation/noise 9

10

11

A. Video error

B. Power error

C. Audio error

No video/Normal audio 1

Vertical/Horizontal bar, residual image,

light spot, external device color error

No power 6

Off when on, off while viewing, power

auto on/off

No audio/Normal video 8

Remote control & Local switch checking

MR15 operating checking 11

10

5

7

12

13 Camera operating checking 13

14 External device recognition error 14

15 E. Noise Circuit noise, mechanical noise 15

16 F. Exterior error Exterior defect 16

D. Function error

First of all, Check whether there is SVC Bulletin in GCSC System for these model.

Wifi operating checking 12

Standard Repair Process

LGE Internal Use Only

Error

symptom

A. Video error

No video/ Normal audio

Established

date

Revised date

First of all, Check whether all of cables between board is inserted properly or not.

(Main B/D↔ Power B/D, LVDS Cable, Speaker Cable, IR B/D Cable,,,)

☞A18 ☞A1

N

Y

Check Back Light On with naked eye

☞A18

Check Power Board 24V output

On

Normal voltage

N

Repair Power Board or parts

Y N Check Power

Board 24V, 12V,3.5V etc.

Replace Inverter

Y

or module

Normal

voltage

N

Repair Power Board or parts

End

Replace T-con/Main

Y

Board or module And Adjust VCOM

No video Normal audio

Normal

audio

Move to No video/No audio

1/16

※Precaution

Always check & record S/W Version and White Balance value before replacing the Main Board

☞A4 & A2

Replace Main Board

1

Re-enter White Balance value

Standard Repair Process

LGE Internal Use Only

Error

symptom

No Video/ No audio

☞A18

Check various voltages of Power Board ( 3.5V,12V, 24V…)

A. Video error

No video/ No audio

Normal

voltage?

Replace Power Board and repair parts

Y

N

Check and replace MAIN B/D

Established

date

Revised date

End

2/16

2

Standard Repair Process

LGE Internal Use Only

Error

symptom

☞ A3

Check RF Signal level

Normal Signal?

N

Check RF Cable

Connection

1. Reconnection

2. Install Booster

Normal

Picture?

Y

Close

Y

N

A. Video error

Picture broken/ Freezing

Established

date

Revised date

. By using Digital signal level meter . By using Diagnostics menu on OSD

( Advanced→ Channels→ Channel Tuning→ Manual Tuning → Check the Signal )

- Signal strength (Normal : over 50%)

- Signal Quality (Normal: over 50%)

Check whether other equipments have problem or not.

(By connecting RF Cable at other equipment)

→ DVD Player ,Set-Top-Box, Different maker TV etc`

☞ A4

Normal

Picture?

Contact with signal distributor

or broadcaster (Cable or Air)

Y

S/W Version

N

Check

SVC

Bulletin?

S/W Upgrade

Normal

Picture?

Y

N

Y

N

Check

Tuner soldering

N

Replace

Main B/D

3/16

Y

Close

3

Standard Repair Process

LGE Internal Use Only

Error

symptom

☞A6

Check color by input

-External Input

-COMPONENT

-AV

-HDMI

☞A8

Check Test pattern

Color

error?

N

Check error color input mode

A. Video error

☞ A7

※ Check

and replace

Y

Link Cable (V by one) and contact condition

External Input/

Component

error

Color error

Check external device and cable

Color

error?

N

Y

Replace Main B/D

Established

date

Revised date

External

device/Cable

normal

N

Color

error?

End

Y

4/16

Y

Replace module

N

Replace Main/T-con B/D

HDMI

error

Check external

device and cable

4

Request repair

for external

device/cable

N

External

device/Cable

normal

Y

Replace Main/T-con B/D

Standard Repair Process

LGE Internal Use Only

Error

symptom

Vertical / Horizontal bar, residual image,

A. Video error

light spot, external device color error

Vertical/Horizontal bar, residual image, light spot

☞A6

Check color condition by input

-External Input

-Component

-HDMI

☞A8

Check Test pattern

Screen

normal?

N

Replace module

Check external

Y

device connection condition

Normal?

N

Request repair

for external device

External device screen error-Color error

☞ A7

Check and

Y

replace Link Cable

Established

date

Revised date

Screen

normal?

End

N

Y

Replace Main/T-con B/D (adjust VCOM)

For LGD panel

Replace Main B/D

For other panel

5/16

Replace Module

N

Screen

normal?

Y

End

Check S/W Version

Check

version

S/W Upgrade

Normal

screen?

End

N

Y

N

Y

Check screen

condition by input

-External Input

-Component

-HDMI/DVI

External

Input

error

Component

error

HDMI/

DVI

5

Connect other external device and cable

(Check normal operation of External Input, Component, RGB and HDMI/DVI by connecting Jig, pattern Generator ,Set-top Box etc.

Connect other external device and cable

(Check normal operation of External Input, Component, RGB and HDMI/DVI by connecting Jig, pattern

Generator ,Set-top Box etc.

Screen

normal?

Request repair for external device

Screen

normal?

N

Y

N

Replace Main/T-con B/D

Replace Main /T-con B/D

Standard Repair Process

LGE Internal Use Only

Error

symptom

☞A17

Check Logo LED

. Stand-By: Red or Turn On . Operating: Turn Off

Check Power cord was inserted properly

Power

LED On?

N

Normal?

Y

Close

Y

N

Check ST-BY 3.5V

☞A18

B. Power error

No power

DC Power on by pressing Power Key On Remote control

Normal

Y

voltage?

N

Normal

operation?

Measure voltage of each output of Power B/D

Y

Normal

voltage?

Replace Power B/D

Established

date

Revised date

☞A18

N

Check Power On ‘”High”

Y

☞A18

Y

N

Replace Main B/D

OK?

Y

6/16

Replace

Power B/D

Replace Power B/D

6

Standard Repair Process

LGE Internal Use Only

Error

symptom

Check outlet

Check A/C cord

Check for all 3- phase power out

Off when on, off while viewing, power auto on/off

Error?

Y

Fix A/C cord & Outlet and check each 3 phase out

N

B. Power error

☞A19

Check Power Off Mode

☞A18

(If Power Off mode is not displayed) Check Power B/D voltage

※ Caution Check and fix exterior of Power B/D Part

Established

date

Revised date

CPU

Abnormal

1

Normal

voltage?

N

Replace Power B/D

Replace Main B/D

Y

Replace Main B/D

7/16

Normal?

Replace Power B/D

Y

N

End

* Please refer to the all cases which can be displayed on power off mode.

Status Power off List Explanation

"POWEROFF_REMOTEKEY" Power off by REMOTE CONTROL

"POWEROFF_OFFTIMER" Power off by OFF TIMER

"POWEROFF_SLEEPTIMER" Power off by SLEEP TIMER "POWEROFF_INSTOP" Power off by INSTOP KEY "POWEROFF_AUTOOFF" Power off by AUTO OFF

Normal

Abnormal

"POWEROFF_ONTIMER" Power off by ON TIMER "POWEROFF_RS232C" Power off by RS232C "POWEROFF_RESREC" Power off by Reservated Record "POWEROFF_RECEND" Power off by End of Recording "POWEROFF_SWDOWN" Power off by S/W Download

"POWEROFF_UNKNOWN" Power off by unknown status except listed case

"POWEROFF_ABNORMAL1" Power off by abnormal status except CPU trouble "POWEROFF_CPUABNORMAL" Power off by CPU Abnormal

7

Standard Repair Process

LGE Internal Use Only

Error

symptom

No audio Screen normal

C. Audio error

No audio/ Normal video

☞A20 ☞A21+A18

Check user menu > Speaker off

Off

Y

Cancel OFF

Check audio B+

N

24V of Power Board

Established

date

Revised date

Normal voltage

Replace Power Board and repair parts

Y

N

8/16

Check Speaker disconnection

Disconnection

Y

Replace Speaker

8

N

Replace MAIN Board

End

Standard Repair Process

LGE Internal Use Only

symptom

Check input signal

-RF

-External Input

signal

Established

date

Revised date

Error

C. Audio error

Wrecked audio/ discontinuation/noise

→ abnormal audio/discontinuation/noise is same after “Check input signal” compared to No audio

☞A21+A18

Check audio B+ Voltage (24V)

Y

Normal

voltage?

N

Replace Power B/D

Replace Main B/D

N

Y

Signal

normal?

N

Y

(When RF signal is not received)

Request repair to external

cable/ANT provider

(In case of

External Input

signal error) Check and fix external device

Wrecked audio/ Discontinuation/

Noise for

all audio

Wrecked audio/

Discontinuation/

Noise only

for D-TV

Wrecked audio/

Discontinuation/

Noise only

for Analog

Wrecked audio/

Discontinuation/

Noise only

for External Input

Check and replace speaker and connector

Replace Main B/D

Connect and check other external device

Normal

audio?

9/16

End

Check and fix external device

9

Standard Repair Process

LGE Internal Use Only

Error

symptom

D. Function error

Remote control & Local switch checking

1. Remote control(R/C) operating error

☞A22

Check R/C itself

Operation

Check R/C Operating

When turn off light

in room

If R/C operate,

Explain the customer

cause is interference

from light in room.

operating?

Normal

Check & Replace

Y

N

Baterry of R/C

Normal

operating?

Replace R/C

Check & Repair Cable connection Connector solder

Y

Close

N

Normal

operating?

Y

Close

☞A22

N

Check B+

On Main B/D

Established

date

Revised date

Y

N

3.5V

Normal

Voltage?

☞A18

Check 3.5v on Power B/D

Replace Power B/D or

Replace Main B/D

(Power B/D don’t have problem)

☞A22

Check IR

Output signal

10/16

Replace

Main B/D

Normal

Signal?

N

Repair/Replace

IR B/D

Y

10

Standard Repair Process

LGE Internal Use Only

Error

symptom

D. Function error

MR15 operating checking

2. MR15(Magic Remote control) operating error

☞A4

Check the

INSTART menu

RF Receiver ver

is “00.00”?

☞A23

Check & Repair

connection

Y

RF assy

☞A4

RF Receiver ver

is “00.00”?

Y

N

Check MR15

itself Operation

N

Close

Check & Replace

Battery of MR15

Normal

operating?

N

Normal

operating?

N

Replace

MR13

Y

Press the

wheel

Close

Established

date

Revised date

Is show ok

message?

Y

Close

Is show ok

message?

Close

Y

Turn off/on the

N

set and press

the wheel

N

11/16

Press the back

key about 5sec

Down load the Firmware

* INSTART MENU14.RF

Remocon Test3. Firmware

download

* If you conduct the loop at 3times, change the M4.

11

Standard Repair Process

LGE Internal Use Only

Error

symptom

3. Wifi operating error

☞A4

Check the

INSTART menu

Wi-Fi Mac value

is “NG”?

☞A24

Check & Repair

Y

Wifi cable

connection

☞A4

Wi-Fi Mac value

is “NG”?

D. Function error

Wifi operating checking

☞A24

N

Check the Wifi wafer

N

Close

1pin

Established

Revised date

Normal

Voltage?

Y

Close

date

N

12/16

Replace

Main B/D

Change the Wifi

Y

assy

12

Standard Repair Process

LGE Internal Use Only

Error

symptom

4. Camera operating error

☞A4

Check the

INSTART menu

Camera Ver.

Change the

Camera module

D. Function error

is “NULL”?

Y

Camera operating checking

☞A25

N

Reconnect the

Camera module

Established

Revised date

Normal

operation?

Y

Close

date

N

13/16

Replace

Main B/D

13

Standard Repair Process

LGE Internal Use Only

Error

symptom

Check input signal

Y

Signal

input?

N

Check and fix

external device/cable

D. Function error

External device recognition error

Check technical information

- Fix information

- S/W Version

Technical

information?

Fix in

accordance

with technical

information

Y

External Input and

N

Component

Recognition error

HDMI/

DVI, Optical

Recognition error

Established

date

Revised date

14/16

Replace Main B/D

14

Standard Repair Process

LGE Internal Use Only

symptom

Identify nose type

Error

Circuit noise, mechanical noise

Circuit

noise

Mechanical

noise

Check location of noise

※ Mechanical noise is a natural phenomenon, and apply the 1st level description. When the customer does not agree, apply the process by stage. ※ Describe the basis of the description in “Part related to nose” in the Owner’s Manual.

E. Noise

Replace PSU

OR

Established

date

Revised date

※ When the nose is severe, replace the module (For models with fix information, upgrade the

S/W or provide the description)

※ If there is a “Tak Tak” noise from the cabinet, refer to the KMS fix information and then proceed as shown in the solution manual (For models without any fix information, provide the description)

15/16

15

Standard Repair Process

LGE Internal Use Only

Error

symptom

Zoom part with exterior damage

Module

damage

Cabinet

damage

Remote

control

damage

F. Exterior defect

Exterior defect

Replace module

Replace cabinet

Replace remote control

Established

date

Revised date

16/16

Stand

dent

Replace stand

16

Contents of Standard Repair Process Detail Technical Manual

LGE Internal Use Only

No. Error symptom Content Page Remarks

1

A. Video error_ No video/Normal audio

2 Check White Balance value A2

4

A. Video error_ video error /Video lag/stop

5 Version checking method A4

6 Tuner Checking Part A5

A. Video error _Vertical/Horizontal bar,

7

residual image, light spot

8

A. Video error_ Color error

9 Adjustment Test pattern - ADJ Key A8

10

11 Exchange Main Board (2) A-2/5

12 Exchange Power Board (PSU) A-3/5

Defected Type caused by T-Con/

Inverter/ Module

13 Exchange Module (1) A-4/5

Check LCD back light with naked eye A1

TUNER input signal strength checking method

connection diagram A6

Check Link Cable (EPI) reconnection condition

Exchange Main Board (1) A-1/5

A3

A7

14 Exchange Module (2) A-5/5

Continue to the next page

Contents of Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Continued from previous page

No. Error symptom Content Page Remarks

16

B. Power error_ No power

17 Check power input Voltage & ST-BY 3.5V A18

18

19

20

21

22

23 Wifi operation checking method A24

B. Power error_Off when on, off while viewing

C. Audio error_ No audio/Normal video

D. Function error

Check front display LED A17

POWER OFF MODE checking method A19

Checking method in menu when there is no audio

Voltage and speaker checking method

when there is no audio

Remote control operation checking method

Motion Remote operation checking method

A20

A21

A22

A23

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

<65UF850V-ZB>

A. Video error_No video/Normal audio

Check LCD back light with naked eye

Established

date

Revised

date

A1

After turning on the power and disassembling the case, check with the naked eye, whether you can see light from locations.

A1

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

<55/65UG87>

A. Video error_No video/Normal audio

Check LCD back light with naked eye

Established

date

Revised

date

A1

After turning on the power and disassembling the case, check with the naked eye, whether you can see light from locations.

A1

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

A. Video error_No video/Normal audio

Check White Balance value

Established

date

Revised

date

A2

Entry method

1. Press the ADJ button on the remote control for adjustment.

2. Enter into White Balance of item 10.

3. After recording the R, G, B (GAIN, Cut) value of Color Temp (Cool/Medium/Warm), re-enter the value after replacing the MAIN BOARD.

A2

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

A. Video error_Video error, video lag/stop

TUNER input signal strength checking method

Established

date

Revised

date

Advanced Channels  Channel Tuning Manual Tuning

A3

When the signal is strong,

use the attenuator (-10dB, -

15dB, -20dB etc.)

A3

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

A. Video error_Video error, video lag/stop

Version checking method

Established

date

Revised

date

A4

1. Checking method for remote control for adjustment

Version

v

Press the IN-START with the remote control for adjustment

A4

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

A. Video error_Video error, video lag/stop

TUNER checking part

Established

date

Revised

date

A5

Checking method:

1. Check the signal strength or check whether the screen is normal when the external device is connected.

2. After measuring each voltage from power supply, finally replace the MAIN BOARD.

3. If you can`t see the UHD live TV, please connect signal at left side of jack. (Korea model only)

A5

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

A. Video error _Vertical/Horizontal bar,

residual image, light spot

Connection diagram (1)

Established

date

Revised

date

A6

As the part connecting to the external input, check the screen condition by signal

A6

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

Check Link Cable(VX1) reconnection condition

A. Video error_Color error

Established

date

Revised

date

A7

Check the contact condition of the Link Cable, especially dust or mis insertion.

A7

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

A. Video error_Color error

Adjustment Test pattern - ADJ Key

Established

date

Revised

date

A8

You can view 6 types of patterns using the ADJ Key

Checking item : 1. Defective pixel 2. Residual image 3. MODULE error (ADD-BAR,SCAN BAR..)

4.Video error (Classification of MODULE or Main-B/D!)

A8

Appendix : Exchange Main Board (1)

LGE Internal Use Only

Solder defect, CNT Broken

T-Con Defect, CNT Broken

Solder defect, CNT Broken

T-Con Defect, CNT Broken

Solder defect, CNT Broken

Abnormal Power Section

Solder defect, Short/Crack

Abnormal Power Section Solder defect, Short/Crack

A - 1/5

Appendix : Exchange Main Board (2)

LGE Internal Use Only

Abnormal Power Section

Solder defect, Short/Crack

Abnormal Power Section

Fuse Open, Abnormal power section

Solder defect, Short/Crack

Abnormal Display

GRADATION

Noise

A - 2/5

GRADATION

Appendix : Exchange Power Board (PSU)

LGE Internal Use Only

No Light

Dim Light

No picture/Sound Ok

A - 3/5

Appendix : Exchange the Module (1)

LGE Internal Use Only

Panel Mura, Light leakage

Crosstalk

Panel Mura, Light leakage

Press damage

Crosstalk

Un-repairable Cases In this case please exchange the module.

Press damage

A - 4/5

Appendix : Exchange the Module (2)

LGE Internal Use Only

Vertical Block

Source TAB IC Defect

Horizontal Block

Gate TAB IC Defect

Vertical Line

Source TAB IC Defect

Horizontal Block

Gate TAB IC Defect

Vertical Block

Source TAB IC Defect

Horizontal line Gate TAB IC Defect Gate TAB IC Defect

Un-repairable Cases In this case please exchange the module.

Horizontal Block

Gate TAB IC Defect

A - 5/5

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

ST-BY condition: On or Off Power ON condition: Turn Off

B. Power error _No power

Check front Power Indicator

Established

date

Revised

date

A17

Standard Repair Process Detail Technical Manual

LGE Internal Use Only

Error symptom

Content

B. Power error _No power

Check power input voltage and ST-BY 3.5V

Established

date

Revised

date

A18

Check the DC 24V, 12V, 3.5V.

<55/65UG87>

<49/55/60/65UF85>

A18

LG 49UF771V-ZA, 49UF77-ZB Schematic

Specifications and Main Features

Frequently Asked Questions

User Manual
