Page 1

LG 49 0

USER GUIDE

ENGLISH

LG 490

Please read this manual carefully before operating your mobile phone. Retain it for future reference.

P/N : MMBB0202101(1.0

USER GUIDE

)

Page 2

Copyright ©2006 LG Electronics, Inc. All rights reserved. LG and the LG logo are registered trademarks of LG Group and its related entities. All other trademarks are the property of their respective owners.

Page 3

IMPORTANT SAFETY PRECAUTIONS

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.

WARNING! Violation of the instructions may cause serious injury or death.

1. Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode.

2. Never place your phone in a microwave oven as it will cause the battery to explode.

3. Never store your phone in temperatures less than -4°F or greater than 122°F.

4. Do not dispose of your battery by fire or with hazardous or flammable materials.

5. When riding in a car, do not leave your phone or set up the hands-free kit near to the air bag. If wireless equipment is improperly installed and the air bag is deployed, you may be seriously injured.

6. Do not use a hand-held phone while driving.

7. Do not use the phone in areas where its use is prohibited. (For example: aircraft, hospital)

IMPORTANT SAFETY PRECAUTIONS

Page 4

IMPORTANT SAFETY PRECAUTIONS

1.Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom.

2.Do not use harsh chemicals (such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. This could cause a fire.

3. Do not drop, strike, or shake your phone severely. It may harm the internal circuit boards of the phone.

4. Do not use your phone in high explosive areas as the phone may generate sparks.

5. Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause a fire or electric shock.

6. Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause electric shock or fire.

7. Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.

8. Do not disassemble the phone.

Page 5

1. Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.

2. Do not hold or let the antenna come in contact with your body during a call.

3. Make sure that no sharp-edged items such as animal’s teeth or nails, come into contact with the battery. This could cause a fire.

4. Store the battery out of reach of children.

5. Be careful that children do not swallow any parts. This could cause asphyxiation or suffocation resulting in serious injury or death.

6. Unplug the power cord and charger during lightning storms to avoid electric shock or fire.

7. Only use the batteries and chargers provided by LG. The warranty will not be applied to products provided by other suppliers.

8. Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.

9. An emergency call can be made only within a service area. For an emergency call, make sure that you are within a service area and that the phone is turned on.

IMPORTANT SAFETY PRECAUTIONS

Page 6

TABLE OF CONTENTS

IMPORTANT SAFETY PRECAUTIONS 1

TABLE OF CONTENTS

TABLE OF CONTENTS 4

Welcome 9

Important Information 9

FCC Part 15 Class B Compliance 9

Industry Canada Compliance 9

TECHNICAL DETAILS 10

Technical Details 10

FCC RF Exposure Information 11

Bodily Contact During Operation 11

Some of contents in this user guide maybe different from your phone depending on the software of the phone or your service provider. Features and specifications might be subject to change without prior notice.

Vehicle-Mounted External Antenna 11

Caution 11

Phone Overview 12

Menus Overview 14

Getting Started with Your Phone 16

The Battery 16

Installing the Battery 16

Removing the Battery 16

Charging the Battery 16

Battery Charge Level 16

Turning the Phone On and Off 17

Turning the Phone On 17

Turning the Phone Off 17

Signal Strength 17

Screen Icons 18

Making Calls 19

Correcting Dialing Mistakes 19

Redialing Calls 19

Receiving Calls 19

Quick Access to Convenient Features 20

Vibrate Mode 20

Lock Mode 20

Mute Function 20

Page 7

Volume Quick Adjustment 20

Call Waiting 21

Caller ID 21

Speed Dialing 21

Using Phone Menus 22

Menu Access 22

Contacts 22

Access and Options 22

1. List Entries 22

2. New Entry 23

3. Groups 23

4. Speed Dials 24

5. Voice Dials 24

6. Erase All Contacts 24

Call History 25

Access and Options 25

1. All Calls 25

2. Incoming Calls 26

3. Outgoing Calls 26

4. Missed Calls 26

5. Erase History 27

6. Call Timers 27

Messaging 27

Access and Options 27

1. Voice Mail 28

2. Text and Multimedia 29

1. Send New 29

2. Inbox 30

3. Outbox 31

4. Templates 31

5. Drafts 32

6. Saved 32

7. Erase Messages 33

8. Settings 33

9. Memory Info 34

3. E-mail 34

4. IM & Chat 35

5. Web Alerts 35

6. Short Codes 35

TABLE OF CONTENTS

Page 8

TABLE OF CONTENTS

Wireless Web 35

Access and Options 35

TABLE OF CONTENTS

Media 37

Access and Options 37

1. Ringtones 37

2. Wallpaper 38

3. Camera 38

4. My Albums 39

4.1 Sound Album 39

4.2 Picture Album 40

4.3 Online Album 40

Shop 40

Access and Options 40

Games 41

Access and Options 41

Tools & Apps 41

Access and Options 41

1. Get New 41

2. GPS Services 42

3. Calculator 42

4. Alarm Clock 42

5. Scheduler 43

6. Notepad 43

7. EZ Tip Calc 43

8. World Clock 44

9. Voice Memo 44

Settings 45

Access and Options 45

1. Sound 46

1.1 Ringers 46

1.2 Keypad 46

1.3 Volume 47

1.4 Alerts 48

2. Display 48

2.1 Banner 48

2.2 Wallpaper 48

2.3 Backlight 49

2.4 Keypad Light 49

2.5 Time and Date 49

2.6 Menu Style 49

2.7 Dialing Fonts 50

Page 9

2.8 Theme Color 50

3. Games / Tools 50

3.1 Backlight Settings 50

3.2 Volume 50

3.3 Notification 50

3.4 Others 51

3.5 Memory Info 51

4. Bluetooth 51

4.1 Power 52

4.2 Device List 52

4.3 Discovery Mode 53

4.4 Device Name 53

4.5 Bluetooth Info 53

5. GPS 53

6. Others 54

6.1 Nav. Key Shortcuts 54

6.2 Call Setup 54

6.3 Language 55

6.4 TTY Mode 55

6.5 Data Setup 57

6.6 Memory Info 57

7. Sy s t e m 57

7.1 Phone Info 57

7.2 System 58

7.3 Security 59

8. Airplane Mode 60

Safety 61

TIA(Telecommunications Industry Association) Safety Information 61

Exposure to Radio Frequency Signal 61

Antenna Care 61

Phone Operation 61

Tips on Efficient Operation 62

Driving 62

Electronic Devices 62

Pacemakers 62

Persons with Pacemakers: 62

Hearing Aids 62

Other Medical Devices 63

Health Care Facilities 63

TABLE OF CONTENTS

Page 10

TABLE OF CONTENTS

Vehicles 63

Posted Facilities 63

TABLE OF CONTENTS

Aircraft 63

Blasting Areas 63

Potentially Explosive Atmosphere 63

For Vehicles Equipped with an Air Bag 64

Charger and Adapter Safety 64

Battery Information and Care 64

Safety Information 65

Explosion, Shock, and Fire Hazards 65

General Warnings and Cautions 66

Avoid damage to your hearing 67

FDA Consumer Update 67

Consumer Information on SAR 74

Accessories 76

Warranty Information 77

Index 79

Page 11

WELCOME

Congratulations for choosing the advanced and compact LG 490 cellular phone, designed to operate with the latest digital mobile communication technology, Code Division Multiple Access (CDMA). Along with the many advanced features of the CDMA system, such as greatly enhanced voice clarity, this phone offers:

1. Large, easy-to-read, 8-line backlit LCD with status icons.

2. Paging, messaging, Voice Mail and Caller ID.

3. Fastap

4. Long battery standby and talk time.

5. Menu-driven interface with prompts for easy operation

6. Any Key Answer, Auto Answer, Auto Retry, One-Touch

7. Bluetooth

8. Bilingual capabilities (English and French)

Fas ta pTMkeypad technology, invented by Digit Wireless, Inc. and introduced by TELUS Mobility for the LG 490 phone makes text entry easy for messaging, web browsing, contact entry and other data entry needs.

Keypad Technology: Full Alphanumeric

Keypad.

and configuration.

Dial and speed dialing with 99 memory locations.

wireless technology.

Important Information

This user’s guide provides important information on the use and operation of your phone. Please read all the information carefully prior to using the phone for the best performance and to prevent any damage to or misuse of the phone. Any unapproved changes or modifications will void your warranty.

FCC Part 15 Class B Compliance

This device and its accessories comply with part 15 of FCC rules. Operation is subject to the following two conditions: (1) This device and its accessories may not cause harmful interference, and (2) this device and its accessories must accept any interference received, including interference that causes undesired operation.

Industry Canada Compliance

This phone complies with Industry Canada RSS 133. This phone complies with the Class B limits for radio noise emissions as set out in the interference causing standard entitled "Digital Apparatus" ICES-003 of Industry Canada.

WELCOME

Page 12

TECHNICAL DETAILS

Technical Details

The LG 490 is a trimode phone that operates on both Code Division Multiple Access (CDMA) frequencies: cellular services at 800 MHz and Personal Communication

TECHNICAL DETAILS

Services (PCS) at 1.9 GHz. The LG 490 also works on Advanced Mobile Phone Service (Amps). Since this phone operates on these three Wireless networks the call fail rate is less than on a conventional dual-mode or single-mode phone.

CDMA technology uses a feature called DSSS (Direct Sequence Spread Spectrum) that enables the phone to keep communication from being crossed and to use one frequency channel by multiple users in the same specific area. This results in a 10-fold capacity increase when compared with analog mode. In addition, features such as soft/softer handoff, hard Handoff, and dynamic RF power control technologies combine to reduce call interruptions.

The Cellular and PCS CDMA networks consist of MSO (Mobile Switching Office), BSC (Base Station Controller), BTS (Base Station Transmission System), and MS (Mobile Station).

* TSB -74: Protocol between an IS-95A system and

ANSI J-STD-008

1xRTT system receives twice as many subscribers in the wireless section as IS-95. Its battery life is twice as long as IS-95. High-speed data transmission is also possible.

The following table lists some major CDMA standards.

CDMA Standard

Basic Air Interface

Network

Service

Performance

Designator Description

TIA/EIA/IS-95A/B/C TSB-74 ANSI J-STD-008 TIA/EIA-IS2000

TIA/EIA/IS-634 TIA/EIA/IS/651 TIA/EIA/IS-41-C TIA/EIA/IS-124

TIA/EIA/IS-96-B TIA/EIA/IS-99 TIA/EIA/IS-637 TIA/EIA/IS-657 IS-801 TIA/EIA/IS-707-A

TIA/EIA/IS-97 TIA/EIA/IS-98 ANSI J-STD-018 ANSI J-STD-019 TIA/EIA/IS-125

CDMA Trimode Air Interface

14.4kbps radio link protocol and inter-band operations IS-95 adapted for PCS frequency band CDMA2000 1xRTT Air Interface

MAS-BS PCSC-RS Intersystem operations Non-signaling data comm.

Speech CODEC

Async Data and Fax

Short message service

Packet Data

Position Determination Service High Speed Packet Data

Cellular base station Cellular mobile station PCS personal station PCS base station Speech CODEC

Page 13

FCC RF Exposure Information

WARNING! Read this information before operating

the phone.

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to Radio Frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by U.S., Canada and international standards bodies.

The design of this phone complies with the FCC guidelines and these international standards.

Bodily Contact During Operation

This device was tested for typical use with the back of the phone kept 0.6 inches (1.5 cm) from the body. To comply with FCC RF exposure requirements, a minimum separation distance of 0.6 inches (1.5 cm) must be maintained between the user’s body and the back of the phone, including the antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories containing metallic components should not

be used. Avoid the use of accessories that cannot maintain 0.6 inches (1.5 cm) distance between the user’s body and the back of the phone and have not been tested for compliance with FCC RF exposure limits.

Vehicle-Mounted External Antenna

(Optional, if available.)

A minimum separation distance of 8 inches (20 cm) must be maintained between the user / bystander and the vehicle-mounted external antenna to satisfy FCC RF exposure requirements. For more information about RF exposure, visit the FCC website at www.fcc.gov.

Caution

Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could impair call quality, damage the phone, void your warranty and/or result in violation of FCC regulations.

Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin a minor burn may result. Contact your local dealer for a replacement antenna.

TECHNICAL DETAILS

Page 14

PHONE OVERVIEW

Flip

LCD Screen

Headset Jack

Left Soft Key

SEND Key

Side Keys

Voice Dial/

Voice Memo Key

Vibrate Mode Key

Earpiece

Camera Lens

External Display

Flash

Navigation Keys

Right Soft Key

END Key

Side Camera Key BACK/Speaker Key

Fastap™ Keypad

Lock Mode Key

Microphone

Alphabetical

Numeric

Hotkeys

: Bluetooth® functionality

: Calculator

: Messaging

: Wireless Web

TELUS Mobility and the TELUS Mobility logo are trademarks used with permission from TELUS Corporation.

The trademarks and logos related to Fastap™ are the property of Digit Wireless, Inc. and are used with their permission.

Page 15

Earpiece

Open the case to answer an incoming call and

Flip

close to end the call.

LCD Screen

Left Soft Key

the left screen of the phone.

Displays messages and indicator icons.

Use to access the menu assigned to

Headset Jack

BACK/Speaker Key

character. Press and hold to delete entire words. Press this key once in a menu to go back one level. Use for quick access to Speakerphone Mode (from standby mode press and hold for about 3 seconds).

SEND Key

Side Keys

mode and the earpiece volume during a call.

Use to adjust the ringer volume in standby

Voice Dial/Voice Memo Key

the Voice Dial. Press and hold for two seconds or more to access Voice Memo.

Vibrate Mode Key

standby mode press and hold for about 3 seconds).

Press to delete a single space or

Use to place or answer calls.

Press once to access

Use to set the mode (from

Navigation Keys

All Calls.

Right Soft Key

the right screen of the phone.

Side Camera Key

function (Press and hold for about 3 seconds to use camera function on the outside/inside display).

END Key

call. Also use to return to the main menu display screen.

Fastap™ Keypad

and symbols much faster than any other keypad we have offered.

Lock Mode Key

standby mode press and hold for about 3 seconds).

Use for quick access to Messaging,

Use to access the menu assigned to

Use for quick access to Camera

Use to turn the power on/off and to end a

Use to enter numbers, characters

Use to set the lock function (from

Microphone Camera Lens

Flash External Display

Hotkeys

: Bluetooth® functionality

: Calculator

: Messaging

: Wireless Web

PHONE OVERVIEW

Page 16

MENUS OVERVIEW

1. Contacts

1. List Entries

2. New Entry

3. Groups

4. Speed Dials

5. Voice Dials

6. Erase All Contacts

2. Call History

1. All Calls

2. Incoming Calls

3. Outgoing Calls

4. Missed Calls

5. Erase History

1. All Calls

2. Incoming Calls

3. Outgoing Calls

4. Missed Calls

6. Call Timers

1. Last Call

2. Recent Calls

3. Life Time

4. Data Transferred

5. Connection Time

6. Reset Timer

3. Messaging

1. Voice Mail

2. Clear Voice Mail Icon

2. Text and Multimedia

1. Send New

2. Inbox

3. Outbox

4. Templates

5. Drafts

6. Saved

7. Erase Messages

8. Settings

9. Memory Info

3. E-mail Get New Online E-mail

4. IM & Chat Get New Online IM

5. Web Alerts

6. Short Codes

1. Short Code List

4. Wireless Web

5. Media

1. Ringtones

2. Wallpaper

3. Camera

4. My Albums

1. Sound Album

2. Picture Album

3. Online Album

Page 17

6. Shop

7. Games

Get New

8. Tools & Apps

Get New GPS Services Calculator Alarm Clock Scheduler Notepad EZ Tip Calc World Clock Voice Memo

9. Settings

1. Sound

1. Ringers

2. Keypad

3. Volume

4. Alerts

2. Display

1. Banner

2. Wallpaper

3. Backlight

4. Keypad Light

5. Time and Date

6. Menu Style

7. Dialing Fonts

8. Theme Color

3. Games / Tools

1. Backlight Settings

2. Volume

3. Notification

4. Others

5. Memory Info

4. Bluetooth

1. Power

2. Device List

3. Discovery Mode

4. Device Name

5. Bluetooth Info

5. GPS

6. Others

1. Nav. Key Shortcuts

2. Call Setup

3. Language

4. TTY Mode

5. Data Setup

6. Memory Info

7. System

1. Phone Info

2. System

3. Security

8. Airplane Mode

MENUS OVERVIEW

Page 18

GETTING STARTED WITH YOUR PHONE

The Battery

Note

It is important to fully charge the battery before initial use of the phone.

The phone comes with a rechargeable battery. Keep

GETTING STARTED WITH YOUR PHONE

the battery charged while not in use in order to maximize talk and standby time. The battery charge level is shown at the top of the LCD screen.

Installing the Battery

To install the battery, insert the battery into the opening on the back of the phone. Put the battery cover on the battery and push it slightly upwards.

Removing the Battery

Turn the power off. Pull the battery cover downward and remove it. Then remove the battery by pressing the upper area of it.

Charging the Battery

To use the charger provided with your phone:

WARNING! Use only the charger provided with the

phone. Using any charger other than the one included with the LG 490 may damage your phone or battery.

1. Plug the end of the adapter into the phone's charger port and the other end into an electrical outlet.

2. The charge time varies depending upon the battery level.

Battery Charge Level

The battery charge level is shown at the top right of the LCD screen. When the battery charge level becomes low, the low battery sensor alerts you in three ways: sounding an audible tone, blinking the battery icon, and displaying battery charge level becomes exceedingly low, the phone automatically switches off and any function in progress is not saved.

Battery Low.

If the

Page 19

Turning the Phone On and Off

Turning the Phone On

1. Install a charged battery or connect the phone to an external power source such as a vehicle power charger or hands-free car kit.

2. Press for a few seconds until the LCD screen lights up.

Note

Like any other radio device, avoid any unnecessary contact with the antenna while your phone is on.

Turning the Phone Off

1. Press and hold until the display turns off.

Signal Strength

Call quality depends on the signal strength in your area. The signal strength is indicated on the screen as the number of bars next to the signal strength icon: The more bars, the better the signal strength. If the signal quality is poor, move to an open area. If you are in a building, the reception may be better near a window.

GETTING STARTED WITH YOUR PHONE

Page 20

GETTING STARTED WITH YOUR PHONE

Screen Icons

To see the icons below, go to Menu -> Settings -> System -> Phone Info -> Icon Glossary.

GETTING STARTED WITH YOUR PHONE

Signal Strength indicator. The strength of the signal received by the phone is indicated by the number of bars displayed.

Airplane Mode.

In Call State. A call is in progress. * No icon indicates the phone is in standby mode.

No Service indicator. The phone is not receiving a system signal.

SSL.

TTY.

1X service indicator.

Digital indicator. Digital service is available.

Roaming indicator. The phone is outside of the home service area.

New Voice Mail.

New Message.

Voice Only.

Alarm.

Schedule.

Data Session.

Vibrate Mode.

Ring Mode.

Silent Mode.

Speaker Mode.

GPS On.

Battery Indicator. Indicates battery charge level.

Bluetooth On.

Bluetooth Audio Device Connected

Shown To All

Page 21

Making Calls

1. Make sure the phone is turned on. If not, press

for about 3 seconds.

2. Enter the phone number (include the area code if needed).

3. Press .

lf the phone is locked, enter the lock code. Call Failed - indicates the call did not go through.

4. Press to end the call.

Correcting Dialing Mistakes

If you make a mistake while dialing a number, press

once to delete the last digit entered or hold

down for at least 2 seconds to delete all digits.

Letter Dialing

With FastapTMyou can dial a phone number using number and letter keys.

1. For example, using the Fastap 1-800-OCANADA and press .

2. Watch the phone screen closely: The phone

Keypad type

automatically converts the letters to the correct numbers.

Redialing Calls

1. Press twice to redial the last number you dialed. The last 90 numbers are stored in the call history list and you can also select one of these to redial.

Receiving Calls

1. When the phone rings or vibrates, press to answer.

Note

If you press Left Soft Key phone is ringing, the ringing or vibration is muted for that call.

[Quiet]

while the

Note

If you press Right Soft Key phone is ringing, the call will end.

2. Press to end the call.

[Ignore]

while the

GETTING STARTED WITH YOUR PHONE

Page 22

QUICK ACCESS TO CONVENIENT FEATURES

Vibrate Mode

Sets the phone to vibrate instead of ring. To set Vibrate Mode press and hold . To return to Normal Mode, press and hold .

Lock Mode

Sets your phone to require your 4-digit password in order to use the phone.

Note

Until you change it, the lock code/password is the last 4 digits of your phone number.

To quickly lock your phone press for three seconds and enter your lock code. To cancel, press Right Soft Key

[Unlock]

and enter the password.

Mute Function

The Mute function prevents the other party from hearing your voice, but allows you to hear the other party. To quickly activate Mute press Left Soft Key

[Mute]

, then to cancel press Left Soft Key

[Unmute]

Volume Quick Adjustment

Quickly adjust ringer and earpiece volumes by pressing the upper side key to increase and lower key to decrease.

Note

The earpiece volume can only be adjusted during a call and Key Beep volume can only be adjusted through the Menu.

Page 23

Call Waiting

Your cellular service provider may offer call waiting. While a call is in progress, one beep indicates another incoming call. When call waiting is enabled, you may put the active call on hold while you answer the other incoming call. Press to receive a waiting call then press again to switch between calls. Check with your service provider for more information about this function.

Caller ID

Caller ID displays the number and/or name of the incoming call. Check with your service provider to ensure they offer this feature.

Speed Dialing

Speed Dialing allows you to make phone calls quickly and easily with a few key presses. Speed Dial number 1 is set to call your Voicemail.

To dial Speed Dials

For Speed Dials 1 to 9 press and hold the Speed Dial number.

For Speed Dials 10 to 99 press the first digit, then press and hold the key of the last digit.

Note

Another way to Speed Dial is to enter the speed dial number(s), then press .

QUICK ACCESS TO CONVENIENT FEATURES

Page 24

USING PHONE MENUS

CONTACTS

Menu Access

Press Left Soft Key nine phone menus. There are two methods of accessing menus and submenus:



Use the navigation key to highlight and select, or



Press the number key that corresponds to the submenu.

[Menu]

Contacts

The Contacts menu allows you to store names, phone numbers and other information in your

CONTACTS

phone’s memory.

Access and Options

1. Press Left Soft Key

2. Press

3. Select a sub-menu.

to have access to

[Menu]

Contacts

1. List Entries

2. New Entry

3. Groups

4. Speed Dials

5. Voice Dials

6. Erase All Contacts

1. List Entries

Allows you to view your Contacts list.

1. Press

2. Options from here:



,, .

Press to scroll through your Contacts alphabetically.

Press Right Soft Key of the following:

New Message/ Delete/ Edit/ Delete All / Send via Bluetooth

Press Left Soft Key Entry.

Press

[View]

[New]

to view the contact information.

[Options]

to store a New

to select one

Page 25

CONTACTS

2. New Entry

Allows you to add a new number to your Contacts.

Note

Using this submenu, the number is saved as a new Contact. To save the number into an existing Contact, edit the Contact entry.

1. Press

2. Enter the name and press .

3. Use to select the phone number types such

4. Enter the numbers as necessary and enter other

,, .

Mobile 1/Home/ Work/Mobile 2/Fax

information such as

Ringtone/Email 2

Email 1/Group/Picture

3. Groups

Allows you to view your grouped Contacts, add a new group, change the name of a group, delete a group, or send a message to everyone in the selected group.

1. Press

2. Press to highlight a group to view, then



,, .

press .

Press Left Soft Key to the list.

Use to highlight a group then press Right Soft Key

[Options]

[New]

to add a new group

Delete/ Message/ Rename Group/ Set Group

Ringtone

In customize ringtones using the sub-options.

Delete All

Set Group Ringtone

option, you can

No Ringtone/ Default Ringtone/ Downloaded

Press

[View]

to view the contact information.

CONTACTS

Page 26

CONTACTS

4. Speed Dials

Allows you to view your list of Speed Dials or designate Speed Dials for numbers entered in your Contacts.

1. Press

2. Use to highlight the Speed Dial position,

3. Use to highlight the Contact then press

CONTACTS

5. Voice Dials

Allows you to view the list of numbers programmed with voice dialing or add a Voice Dial command to a number stored in your Contacts.

1. Press

2. Press Left Soft Key

,, .

and press .

,, .

[New]

to record a new

Voice Dial command. Follow the phone’s prompts.



Select if you want to start recording when the pop up message is displayed.

Note

Recordings should be made in a normal use position (speaker by your ear and microphone near your mouth) while using a clear voice. Hands-free car kits or headsets should be used if the phone is primarily used with them.

6. Erase All Contacts

Allows you to erase all of your Contacts at once.

1. Press

2. Press

,, .

Ye s

Note

Search Contacts

1. Press Right Soft Key

2. Within the Search Bar press the letter to jump to that section in your contacts. (For example, press to jump down to Glenn)

[Contacts]

Page 27

CALL HISTORY

Call History

The Call History menu is a list of the last phone numbers or Contact entries for calls you placed, accepted, or missed. It is continually updated as new numbers are added to the beginning of the list and the oldest entries are removed from the bottom of the list.

Access and Options

1. Press Left Soft Key

2. Press

3. Select a sub-menu.

Call History

1. All Calls

2. Incoming Calls

3. Outgoing Calls

4. Missed Calls

5. Erase History

6. Call Timers

[Menu]

Shortcut

To view a quick list of all your recent calls, press from the standby mode.

1. All Calls

Allows you to view the list of all calls; (up to 90) entries.

1. Press

2. Use to highlight an entry, then



,, .

Press to view the entry.

Press to place a call to the number.

Press Right Soft Key

[Options]

Save Contact / View Contact/ Dial 1 + Number

Delete/ Delete All

Press Left Soft Key message.

[Message]

CALL HISTORY

to select:

to send a

Page 28

CALL HISTORY

2. Incoming Calls

Allows you to view the list of incoming calls; up to 30 entries.

1. Press

,, .

2. Use to highlight an entry, then



Press to view the entry.



Press to place a call to the number.



Press Right Soft Key

[Options]

Save Contact / View Contact/ Dial1+Number

CALL HISTORY

Delete/ Delete All



Press Left Soft Key

[Message]

message.

3. Outgoing Calls

Allows you to view the list of outgoing calls; up to 30 entries.

1. Press

2. Use to highlight an entry, then



,, .

Press to view the entry.

to select:

to send a



Press to place a call to the number.



Press Right Soft Key

[Options]

to select:

Save Contact / View Contact/ Dial 1 + Number

Delete/ Delete All



Press Left Soft Key

[Message]

to send a

message.

4. Missed Calls

Allows you to view the list of missed calls; up to 30 entries.

1. Press , , .

2. Use to highlight an entry, then



Press to view the entry.



Press to place a call to the number.



Press Right Soft Key

Save Contact / View Contact/ Dial 1 + Number

Delete/ Delete All



Press Left Soft Key message.

[Options]

[Message]

to select:

to send a

Page 29

MESSAGING

5. Erase History

Allows you to erase selected call list(s).

1. Press , , .

2. Use to highlight the list of calls to erase, then press .

All Calls/ Incoming Calls/ Outgoing Calls Missed Calls

3. Press

Ye s

6. Call Timers

Allows you to view the duration and view the list of received and transmitted data calls.

1. Press , , .

2. Use to highlight a list.

Last Call

Transferred

Recent Calls

Connection Time/ Reset Timer

Life Time/ Data

Messaging

Access and Options

Shortcut

To instantly access Messaging, press and hold for one second.

1. Press Left Soft Key

2. Press

3. Select a sub-menu.

1. Voice Mail

2. Text and Multimedia

3. E-mail

4. IM & Chat

5. Web Alerts

6. Short Codes

Text messages, multimedia messages, and the voice mail box become available as soon as the phone is powered on.



Check types of messages by pressing the message key .

Messaging

[Menu]

MESSAGING

Page 30

MESSAGING



Make a call to the callback number by pressing

The phone can store up 521 messages (for example, 1 voice mail, 50 inbox text messages, 100 inbox multimedia messages, 100 inbox multimedia notification messages, 50 outbox/sent text messages, 50 outbox/sent multimedia messages, 50 template messages, 50 draft messages, 20 saved text messages, 50 saved multimedia messages). The information stored in the message is determined by phone mode and service capability. Other limits to available characters per message may exist. Please

MESSAGING

check with your service provider for system features and capabilities.

New Message Alert

There are three ways your phone alerts you to new messages.

1. The phone displays a message on the screen.

2. One of over 30 ring types is heard, if selected.

3. The message icon ( ) is displayed on the screen.

during an Inbox message check.

Note

If you receive the same message twice, your phone deletes the older one and the new one is stored as a Duplicate.

1. Voice Mail

Allows you to view new voice messages recorded in the Voice Mail box. When you have a new voice message, your phone will alert you.

Checking Your Voice Mail Box

1. Press , , , .

2. Options from here:



Press Left Soft Key information, and then press



Press to listen to the message(s).

3. Select

Clear Voice Mail Icon

delete it.

[Clear]

to delete

when you want to

Ye s

Page 31

2. Text and Multimedia

1. Send New

Allows you to send text messages and picture messages. Each message has a destination and information. These are dependent upon the type of message you want to send.

The Basics of Sending a Message

1. Press , , , .

2. Enter the phone number of the recipient or the email address.

Press Right Soft Key

[Options]

Select the option(s) to customize.



Contacts

to select a recipient from your Contacts

list.



Call History

to select a recipient from your Call

History.



Group

to select a recipient from your Group.



Set as Cc

to set another recipient as carbon copy

like in your online email.

MESSAGING



Set as Bcc

Copy like in your online email.

3. Press .

4. Enter the subject in the subject field and press

5. Type your message in the text field. Press Right Soft Key



Add



Save As



Settings Number



Save Quick Text

template for future use.

6. Use to highlight

Use to select

Album

Select

7. Use to highlight

to set another recipient as Blind Carbon

[Options]

to select

Quick Text

to select

Draft

Template

Priority Level

Signature

Callback

to save your message as quick


and Left Soft Key

[Add]

Take Picture


and press Left Soft Key

Sound

and Left Soft Key

[Add]


[Select]

MESSAGING

Page 32

MESSAGING

Use to select

Record New

Select a sound and press Left Soft Key

Press Right Soft Key

For

Record New

option, you can control Quality of

[Options]

the sound you record with the options

Medium/Low

You can also set

Seconds

1 Minute

Recording Time

For Sound Album, navigate what you want to select and try playing it by pressing

MESSAGING

8. Press

[Send]

A sending screen is displayed.

2. Inbox

The phone alerts you in 3 ways when you receive a new message:



By displaying a message notification on the screen.



By sounding a beep or vibrating, if set.



By displaying .

Sound Album

High

as either

[Play]

[Select]

Received text messages and multimedia messages

may be searched and the contents viewed. Received

messages are displayed from newest to oldest.

Out of Memory Warning

If the memory is full, no more messages can be received until enough memory space becomes available. The warning message is displayed and new messages are not accepted.

Viewing Your Inbox

1. Press , , , .

2. Use to highlight a message and press .

3. Options from here:



Left Soft Key



Right Soft Key

Delete

[Reply]

[Options]

Deletes the selected message from the Inbox.

Forward

Forwards a received message to other destination address(es).

Move to Saved

Saves the message into the Saved folder.

Page 33

MESSAGING

Detail

Lock/Unlock

Allows you to check the received message information.

Locks or unlocks the selected message.

3. Outbox

Up to 50 sent messages can be stored in Outbox View lists and contents of sent messages and verify whether the transmission was successful or not.

1. Press , , , .

2. Use to highlight an Outbox message.

3. Options from here:



Left Soft Key



Right Soft Key

Delete

Forward

Move to Saved

[Resend]

[Options]

Deletes the selected message.

Forwards a received message to other destination address(es).

Saves the message into the Saved folder.

Detail

Lock/Unlock

Allows you to check the selected message information.

Locks or unlocks the selected message.

4. Templates

Allows you to create, save and set a template to be used as text in your messages.

1. Press , , , .

[Add]

2. Press Left Soft Key template.



When you create a template at first, the options are:

to create a new

Add/ Save As/ Settings/ Save Quick Text

3. Use to highlight a message.

4. Press Right Soft Key

Delete

Lock/Unlock

[Options]

Deletes the selected message from Templates.

Locks or unlocks the selected message.

MESSAGING

Page 34

MESSAGING

5. Press to send the selected message.

5. Drafts

Displays draft messages.

1. Press , , , .

2. Use to highlight a message.

3. Press Right Soft Key

Delete

MESSAGING

Lock/Unlock

4. Press to send the selected message.

Deletes the selected message from the Drafts.

Locks or unlocks the selected message.

[Options]

6. Saved

Displays saved messages.

1. Press , , , .

2. Use to highlight a message.

3. Press Right Soft Key

Delete

Forward

Detail

Lock/Unlock

4. Press to view the message.

[Options]

Deletes the selected message from the Saved.

Forwards a message to other destination address(es).

Allows you to check the selected message information.

Locks or unlocks the selected message.

Page 35

MESSAGING

7. Erase Messages

Allows you to erase all messages stored in your Inbox, Outbox, Templates, Drafts or Saved messages. You can also erase all messages at the same time.

1. Press , , , .



Press

[Inbox]

to erase all messages stored

in Inbox.



Press

[

Outbox]

to erase all messages

stored in Outbox.



Press

[Templates]

to erase all messages

stored in Templates.



Press

[Drafts]

to erase all messages

stored in Drafts.



Press

[Saved]

to erase all messages

stored in Saved messages.



Press

[All Messages]

to erase all messages stored in the Inbox, Outbox/Sent, Templates, Drafts or Saved messages.

Ye s

2. Press

8. Settings

Allows you to configure ten settings for messages.

1. Press , , , .

2. Use to highlight a setting, then press .

Message Settings Sub-Menu Descriptions

Save To Outbox (Auto Save / Prompt / Do Not Save)

Allows you to automatically save sent messages in Outbox when transmitted.

MESSAGING

Auto Delete Inbox (On / Off)

Allows you to automatically delete read messages when you exceed the storage limit.

Quick Text

Allows you to display, edit and add text phrases. These text strings allow you to reduce manual text input into messages.

Page 36

MESSAGING

Default Entry Mode (Abc / abc / ABC)

Allows you to select the default input method

abc, ABC

including Abc,

Auto Download (On / Off)

Allows you to auto display the content when receiving a message.

Message Priority (High / Normal / Low)

Gives priority to the message.

MESSAGING

Delivery Report (On / Off)

Set delivery report to let you know if your message is delivered to the recipient.

Read Report (On / Off)

Set read report, and you can check out if your message has been read by the recipient.

Callback #

Allows you to automatically send a designated callback number when you send a message.

Signature

Allows you to create and/or edit the signature.

9. Memory Info

Provides you with the memory information of all the messages stored in each folder.

1. Press , , , .

2. Use to check the used and remaining memory.

3. E-mail

Allows you to send and receive a text email by

New

or by

Online E-mail

WAP page of the service provider and logging on. Contact your service provider for availability.

1. Press , , .

2. Use to select then press .

after connecting to the

Get New

Online E-mail

Get

Page 37

WIRELESS WEB

4. IM & Chat

Allows you to send and receive instant message at any time. Allows you to chat with Internet Messenger users. The messages are updated anytime.

1. Press , , .

5. Web Alerts

Web Alerts is special links or message provided from the service provider to inform you of special offers, bulletins and announcements.

1. Press , , .

6. Short Codes

Shows you the Short Codes List.

1. Press , , .

Short Code List

Wireless Web

The Wireless Web feature allows you to view Internet content, especially designed for your mobile phone. Access and selections within this feature are dependent upon your service provider. For specific information on Wireless Web access through your phone, contact your service provider.

Access and Options

Allows you to initiate an Wireless Web session.

Shortcut

To instantly access Wireless Web, press and hold

for one second.

1. Press Left Soft Key

2. Press After a few seconds, you see the Home Page.

Wireless Web

[Menu]

WIRELESS WEB

Page 38

WIRELESS WEB

Overview

The Wireless Web allows the user to use a variety of Internet services. Using the Wireless Web on the phone allows you to:

Send and receive Internet e-mail.



Browse and search the World Wide Web via web pages especially designed for wireless phone customers.



Set bookmarks to directly access your favorite sites.



WIRELESS WEB

Retrieve information, such as stock quotes and flight schedules from the Internet.

Quality of Browser

Browsing the web via the phone is not like using your home computer. Site providers have selected only the critical aspects of their site to present to wireless phone users and have removed most graphics.

Ending the Wireless Web Session

You can end a Wireless Web session by pressing

Navigating through the Browser

While using the Wireless Web, you will find the following content:



Numbered options (some options may not be numbered);



Links embedded in content;



Text or numeric input;



Simple text.

You can act on the options or the links by using the Soft Keys.

Page 39

MEDIA

Media

Allows you to download ringtones or wallpapers once the Get New is executed and connected to Browser. In the application homepage, the downloaded ringtones are located under the wallpapers,

Media -> Wallpaper

Access and Options

Media -> Ringtones

1. Press Left Soft Key

2. Press

3. Select a sub-menu.

Media

1. Ringtones

2. Wallpaper

3. Camera

4. My Albums

. For

[Menu]

1. Ringtones

Allows you to download new Ringtones.

1. Press , , .

2. Press

3. When connected to the application homepage and you download ringtones, the downloaded files are located under

4. The following options are available:



[Get New]

Set As

Contact/ Caller ID/ Unknown Calls/ Roaming.

Delete

Deletes the selected file.

Delete All

Details

Displays the information of the files.

Memory Info

Media -> Ringtones

Deletes all the selected file.

Displays the memory information.

MEDIA

Page 40

MEDIA

2. Wallpaper

Allows you to download new Wallpaper. Use this menu when you want to get another wallpaper other than the default wallpapers in

1. Press , , .

2. Press

[Get New]

3. When connected to the application homepage and you download wallpapers, the downloaded files are located under

4. The following options are available:



Set As

Main Wallpaper/ Sub Wallpaper/ Picture ID



Delete

Deletes the selected file.



Rename

Renames the name of the wallpaper.



Delete All



Information

files.



Memory Info

Display

Wallpaper

Media

Wallpaper

Deletes all the selected files.

Displays the information of the

Displays the memory information.

menu.

3. Camera

View, take, and trade your digital pictures and video right from your wireless phone.

1. Press , , .

Note

Pressing and holding the Side Camera Key from standby mode is a hot key to Take Photo.

2. Set the brightness , zoom , flash , and press Right Soft Key other settings.



Select the option(s) to customize.

Resolution

640X480 / 320X240 / 16 0 X 120

Quality Zoom Brightness Flash Multishot Self-timer

Fine / Normal / Economy x1 to x10

-2.0 to +2.0 On / Off 1 Shots / 3 Shots None / 3 Seconds /

5 Seconds / 10 Seconds

[Options]

to change

Page 41

MEDIA

White Balance

Night Mode Filter Effects

Shutter Sound

Auto / Sunny / Cloudy / Tungsten / Fluorescent

On / Off Normal / Sepia / Mono /

Negative Shutter1 / Shutter2 /

Shutter3 / Shutter4

Note

When the Flash is On, take the photo within 12 inches of the subject.

3. Take a picture by pressing .

4. Press . The picture is stored in Picture Album.

Using the Side Camera Key

You can use the Side Camera Key to take a picutre when the flip is closed. The picture is shown on the outside display.

1. Press the Side Camera Key for about 3 seconds to enter the Take Photo mode.

2. Take a picture by pressing Side Camera Key .

3. Press the Side Camera Key for about 3 seconds to exit camera mode.

4. My Albums

4.1 Sound Album

1. Press , , , .

2. Select your desired sound with and press Right Soft Key

3. Select one of the following options:

Send Message

Delete

Rename

Delete All

Information

Upload Online Album

[Options]

Sends a message.

Yes / No

Rename the selected Sound.

Yes / No

Name / Size / Type

Accesses the Online Album.

MEDIA

Page 42

SHOP

4.2 Picture Album

Allows you to view pictures stored in the phone.

1. Press , , , .

2. Select your desired picture with and press Right Soft Key

Send Message Delete Rename Delete All Icon View(List View) Information

Set As

Upload Online Album

4.3 Online Album

Access the Online Album.

1. Press , , , .

[Options]

Sends a message. Yes / No Rename the selected picture. Yes / No

Name / Size / Resolution / Type

Main Wallpaper / Sub Wallpaper / Picture ID

Accesses the Online Album.

Shop

Allows you to search a variety of contents provided by your service provider and buy some if you want.

Access and Options

1. Press Left Soft Key

2. Press

After a few seconds, you see the Home Page.

Shop

[Menu]

Page 43

GAMES/TOOLS & APPS

Games

Allows you to download ringtones or wallpapers once the Get New is executed and connected to Browser. In the application homepage, the downloaded MIDlet (type of JAVA application) files are located under Games menu. Use Left Soft Key to run the selected MIDlet and Right Soft Key to select options.



Run



Properties

Access and Options

Open the MIDlet to run. Displays the information of MIDlet.

1. Press Left Soft Key

2. Press

3. Select a sub-menu.

[Get New]

Games

[Menu]

Tools & Apps

Allows you to make use of various tools and applications.

Access and Options

1. Press Left Soft Key

2. Press

3. Select a sub-menu.

Get New GPS Services

Calculator Alarm Clock Scheduler Notepad EZ Tip Calc World Clock Voice Memo

1. Get New

1. Press , .

2. Scroll to

Get New

After a few seconds, you will see the Home Page.

and press .

Tools & Apps

[Menu]

GAMES /TOOLS & APPS

Page 44

TOOLS & APPS

2. GPS Services

You can get services about global positioning system.

1. Press , .

2. Scroll to

3. Press After a few seconds, you will see the Home Page.

3. Calculator

Shortcut

To instantly access Calculator, press and hold for

TOOLS & APPS

one second.

You can enter numbers up to the third decimal place.

1. Press , .

2. Scroll to

3. Enter data.



GPS Services

Get New

Calculator

and press .

Use keypad to enter numbers. Use to enter decimals. Use to enter brackets. Press Left Soft Key to clear the entry. Press Right Soft Key to enter algebraic operators.



Use Navigation Key to enter operators.



Press to complete equation.

4. Alarm Clock

Your phone comes with a built-in alarm clock with multiple alarm capabilities.

1. Press , .

2. Scroll to

3. Press Left Soft Key

4. Use to select

5. Set the time for alarm and press .

6. Press to select one of the following:

7. Use to highlight

8. Use to select

9. Press .

Alarm Clock

and press .

New

to add a new alarm.

Off/ Manual/ 10 Min Later

20 Min Later/ 30 Min Later/ 1 Hour Later

then press .

Once/ Daily/ Mon~Fri/ Sat~Sun

Alarm Tone

setting), press Left Soft Key

(ring type

List

, and select

your desired ring.

Note

then type your note

using the keypad.

Page 45

TOOLS & APPS

5. Scheduler

Allows you to conveniently keep and access your agenda(s). Simply store your appointments and your phone will alert you with a reminder of your appointment.

1. Press , .

2. Scroll to

Scheduler

3. Using your navigation key, highlight the day to which you would like to add an event and press Left Soft Key

4. Enter your schedule information including:



Date



Reminder (On Time / 15 min before / 30 min before / 1 hour before / 1 day before / 3 days before / 1 week before / No Reminder)



Repeat (Once/Daily/Mon~Fri/Weekly/Month (1st Fri)/Month(7th)/Year(7/Jul)



Expiration (Set Expiration/ No Expiration)

5. Press .

and press .

New



Time



Subject

6. Notepad

Allows you to add, read, edit, and erase notes to yourself.

1. Press , .

2. Scroll to

Notepad

3. Press Left Soft Key

and press .

New

to write a new note.

4. Type your note using the numeric keypad and press .

7. EZ Tip Calc

Allows you to quickly and easily calculate the total amount, using the total of the bill, the amount of the tip and the number of people as variables.

1. Press , .

2. Scroll to

EZ Tip Calc

3. Use your keypad and navigation key to enter the bill amount and desired tip percentage. The correct tip will be calculated instantly.

and press .

TOOLS & APPS

Page 46

TOOLS & APPS

4. If you’re splitting the check, highlight enter the number of people in your party (An equal split of the bill will be calculated and displayed).

8. World Clock

Allows you to determine the current time in another time zone or country.

1. Press , .

2. Scroll to

TOOLS & APPS

3. Use to move the cross hairs across the map or press Right Soft Key specific city.

4. Press Left Soft Key Saving Time for the selected city.

World Clock

and press .

[Cities]

[Set DST]

to set Daylight

Split

and

to enter a

9. Voice Memo

Allows you to add, listen to, and erase short verbal reminders.

Shortcut

Press the voice dial/ voice memo key for 3 seconds to access voice memo.

Recording a Voice Memo

1. Press , .

2. Scroll to

3. Press to record a new Voice Memo (The

4. To finish recording, press

Playing a Voice Memo

1. Press , .

2. Scroll to

3. Press Left Soft Key

Voice Memo

phone prompts you to start recording after the beep).

Voice Memo

and press .

[Save]

and press .

[List]

Page 47

TOOLS & APPS/SETTINGS

Options from here:

Select your desired Voice Memo with and press Right Soft Key

Send Message

Delete

Rename

Delete All

Information

Upload Online Album

[Options]

Sends a message.

Yes / No

Rename the selected Sound.

Yes / No

Name / Size / Type

Accesses the Online Album.

Settings

The Settings menu has options to customize your phone.

Access and Options

1. Press Left Soft Key

2. Press

3. Select a sub-menu.

1. Sound

2. Display

3. Games / Tools

4. Bluetooth

5. GPS

6. Others

7. System

8. Airplane Mode

Settings

[Menu]

TOOLS & APPS/SETTINGS

Page 48

SETTINGS

1. Sound

Allows you to customize various sounds emitted from the phone.

1.1 Ringers

1.1.1 Voice Calls

Allows you to set ringtones for different types of incoming calls.

1. Press

2. Select an incoming call type.

3. Use to select a ringer, then press Left Soft

1.1.2 Messages

1. Press

2. Select an incoming call type.

, , , , .

Caller ID / Unknown Calls / Roaming

Set

Key

to save the sound.

, , , , .

Voice Mail / Text and Multimedia / Web Alerts / Reminder

3. Use to select a ringer, then press Left Soft

Select

Key

1.1.3 Meeting / Silent Mode

1. Press , , , , .

2. Use to set the setting, then press to save the change.

On / Off

1.2 Keypad

1.2.1 Keypad Sound

1. Press , , , , .

2. Use to adjust the volume of the keypad, then press to save the change.

1.2.2 DTMF Length

Allows you to set the DTMF.

1. Press

2. Use to select a length, then .

to save the sound.

, , , , .

Page 49

SETTINGS

Short

Long

Sends out a tone for a fixed period of time even if you keep the key pressed.

Sends out a continuous tone for as long

as you keep the key pressed.

1.3 Volume

1.3.1 Ringer

Allows you to set ringer volume settings.

1. Press , , , , .

2. Use to adjust the volume, then press to save the change.

1.3.2 Earpiece

Allows you to set earpiece volume settings.

1. Press , , , , .

2. Use to adjust the earpiece volume, then press to save the change.

1.3.3 Speaker

Allows you to set speaker volume.

1. Press , , , , .

2. Use to adjust the volume, then press to save the change.

1.3.4 Power On/Off

Allows you to set the phone to sound a tone when the phone is powered on and off.

1. Press , , , , .

2. Use to set the alert tone, then press to save the change.

On / Off

SETTINGS

Page 50

SETTINGS

1.4 Alerts

1. Press , , , .

1.4.1 Service Change

Alerts you when service changes. (On/Off)

1.4.2 Minute Beep

Alerts you 10 seconds before the end of every minute during a call. (On/Off)

1.4.3 Call Connect

Alerts you when the call is connected. (On/Off)

1.4.4 Call Lost

Alerts you when the call is disconnected. (On/Off)

1.4.5 No Service

Alerts you when there is no service. (On/Off)

2. Display

Options to customize the phone's display screen.

2.1 Banner

Allows you to enter a string of up to 13 characters which display on the LCD screen.

1. Press , , , .

2. Use to select

3. Enter your banner text, then press .

2.2 Wallpaper

Allows you to choose the kind of background to be displayed on the phone.

1. Press , , , .

2. Select a sub-menu and press .

Main Display

3. Select from different images, then press .

4. Press Left Soft Key

, then press .

Front Display

[Set]

Page 51

SETTINGS

2.3 Backlight

Allows you to set the duration for illuminating the LCD backlight.

1. Press , , , .

2. Select a sub-menu and press .

Main Display

3. Use to select a setting, then press to save the change.

7 Seconds / 15 Seconds / 30 Seconds / Always On / Always Off

2.4 Keypad Light

Allows you to set the duration for illuminating the phone's keypad.

1. Press , , , .

2. Use to select a setting, then press to save the change.

7 Seconds / 15 Seconds / 30 Seconds / Always Off

2.5 Time and Date

Allows you to choose the clock format displayed on the LCD screen.

1. Press , , , .

2. Select a sub-menu and press .

Main Display

2. Use to select the clock format, then press .

Main Display

Front Display

2.6 Menu Style

Allows you to view the Menus as icons or in a list format.

1. Press , , , .

2. Use to select a menu format, then press .

Icon/ List

Front Display

: Off / Small Digital / Large Digital /

Analog

: Normal / Minimize

SETTINGS

Page 52

SETTINGS

2.7 Dialing Fonts

Allows you to set the size and color of the font for calling digits.

1. Press , , , .

2. Use to choose a setting, then press .

Normal/ Large

2.8 Theme Color

Allows you to choose the color of the background screen.

1. Press , , , .

2. Use to choose a setting, then press .

Style 1/ Style 2/ Style 3

3. Games / Tools

3.1 Backlight Settings

Allows you to set the duration for illuminating the backlight.

1. Press , , , .

2. Use to select a setting, then press to save the change.

7 Seconds / 15 Seconds / Always On / Always Off

3.2 Volume

Allows you to set volume settings.

1. Press , , , .

2. Use to adjust the volume, then press to save the change.

3.3 Notification

Allows you to set notification settings.

1. Press , , , .

Page 53

SETTINGS

2. Select a sub-menu and press .

Voice Mail

Text Message

3. Use to set the alert setting, then press to save the change.

On / Off

3.4 Others

Displays or deletes the list of files created by downloaded JAVA contents.

1. Press , , , .

3.5 Memory Info

Shows you the memory information of the phone.

1. Press , , , .

4. Bluetooth

The LG 490 is compatible with devices that support the Bluetooth You may create and store 20 pairings within the LG 490 and connect to one device at a time. The approximate communication range for Bluetooth wireless technology is up to 30 feet (10 meters).

This device is compliant with

1.1 and supports the following profiles:



Object push profile (OPP) for vCard 2.1: No support for image/sound.



Dial-up networking profile (DUN): Tethered data connection over



Generic object exchange profile (GOEP)



Headset profile (HSP): In-band ringtone not supported.



Hands-free profile (HFP): Three way calling and Phone number to a Voice tag not supported.



Generic access profile (GAP)



Serial port profile (SPP)



Service discovery application profile (SDAP)

headset and hands-free profile(s).

Bluetooth

Specification

Bluetooth

SETTINGS

Page 54

SETTINGS

The LG 490 offers integrated

Bluetooth

wireless support for headset and hands-free accessories. However, the software used in the LG 490 available in Canada from LG Electronics Inc. does not support the transfer of data files.

NOTES



Read user guide of each

Bluetooth

accessory that you are trying to pair with your phone because the instructions may be different.



The Bluetooth®word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by LG Electronics is under license. Other trademarks and trade names are those of their respective owners.



Your phone is based on the Bluetooth specification, but it is not guaranteed to work with all devices enabled with Bluetooth

wireless technology.

Shortcut

To instantly access hold for one second.

Bluetooth

menu, press and

4.1 Power

Allows you to set the

Bluetooth

power On/Off.

1. Press , , , .

2. Use to select a setting, then press .

On / Off

NOTE

By default, your device’s Bluetooth®functionality is turned off.

4.2 Device List

Pairing is the process that allows the handset to locate, establish and register 1-to-1 connection with the target device.

For pairing new Bluetooth®device

1. Press , , , .

2. Follow the the device to pairing mode.

3. Press Right Soft Key for Select

4. If prompted to turn power on. Select

Bluetooth

accessory instructions to set

New

Search New

device is set to off, you will be

Options

Ye s

Page 55

SETTINGS

5. The device will appear in the Found Devices menu once it has been located. Highlight the device and press .

6. The handset will prompt you for the passkey. Consult the the appropriate passkey (typically “0000”). Enter the passkey and press .

7. Once pairing is successful, select connect with the device.

8. Once connected, you will see the device listed in the Paired Devices menu and the

Bluetooth

will show at the top of the LCD screen.

accessory instructions for

Ye s

Bluetooth

icon

4.3 Discovery Mode

Allows you to set On (60 secs) / Off.

1. Press , , , .

2. Use to select a setting, then press .

On(60 secs) / Off

NOTE

If you turn on My Visibility, your device is able to be searched by other in-range Bluetooth

devices.

4.4 Device Name

Allows you to edit the name of the Bluetooth®device.

1. Press , , , .

2. Press to clear the existing name.

3. Use the numeric keypad to enter a new custom name.

4. Press to save and exit.

4.5 Bluetooth Info

1. Press , , , .

5. GPS

1. Press , , .

2. Use to select a setting, then press .

On / Emergency Only

SETTINGS

Page 56

SETTINGS

6. Others

6.1 Nav. Key Shortcuts

Assign a shortcut to your favorite and most frequently used function. Select it from the list, and then access it directly by pressing in standby mode.

1. Press , , , .

2. Read the disclaimer and press .

3. Select a menu and press .

Left Nav Key / Right Nav Key

6.2 Call Setup

6.2.1 Call Answer

Allows you to determine how to handle an answered call.

1. Press , , , , .

2. Use to select a setting, then press .

Send Key / Any Key / Flip Open

6.2.2 Auto Answer

Allows you to set the length of the time before the phone automatically answers a call. This feature is intended for use with hands free devices, but is an independent feature of the phone and must be manually turned on/off when connected or disconnected from the device.

1. Press , , , , .

2. Use to select a setting, then press .

Off / 2 Seconds / 4 Seconds / 8 Seconds

6.2.3 Auto Prepend

This option will automatically prepend 1 when dialing 10 digit numbers. However 1 will not prepend when dialing numbers that has less than 10 digits.

1. Press , , , , .

2. Use to select a setting, then press .

On / Off

Page 57

SETTINGS

6.2.4 Auto Redial

Allows you to set the length of time the phone waits before automatically redialing a number when the attempted call fails.

1. Press , , , , .

2. Use to select a setting, then press .

On / Off

6.3 Language

Allows you to set the bilingual feature according to your preference. Choose between English and Français.

1. Press , , , .

English

Français

2. Use to select .

, then press

6.4 TTY Mode

Allows you to attach a TTY device enabling you to communicate with parties also using a TTY device. A phone with TTY support is able to translate typed characters to voice. Voice can also be translated into characters and then displayed on the TTY.

* TTY: Text Telephone (or Teletypewriter).

1. Press , , , .

2. Read the disclaimer and press .

3. Use to select a setting, then press .

TTY Full / TTY + Talk / TTY + Hear / TTY Off

1. TTY Full :

Users who cannot talk and hear send and receive a text message through TTY equipment.

2. TTY + Talk :

Users who can talk but cannot hear receive a text message and send voice through TTY equipment.

3. TTY + Hear :

Users who can hear but cannot talk send a text message and receive voice through TTY equipment.

SETTINGS

Page 58

SETTINGS

4. TTY Off :

Normal users send and receive without TTY equipment.

Connecting TTY Equipment and a Terminal

1. Connect a TTY cable to TTY connection on the terminal. (TTY connection location is same as the hands free earjack)

2. Enter the phone menu and set up the desired TTY mode.

3. After setting a TTY mode, check the LCD screen of the phone for the TTY icon.

4. Connect the TTY equipment to the power source and turn it on.

5. Make a phone connection to the desired number.

6. When connection is made, use the TTY equipment to type in and send a text message or send voice.

7 The voice or text message from the receiver end

displays on the TTY equipment display.

Menu User Feat ure

For

TTY

hearing-

Full

/verbally-

impaired

Off

For hearingimpaired

For verballyimpaired

For

regular

users

verbal

audible

TTY+

Talk

TTY+

Hear

TTY

Transmission/

Receiving

Mode

text message transmission, text message

receiving

voice transmission, text message

receiving

text message transmission,

voice

receiving

voice transmission,

voice

receiving

When making

communications

with a normal

terminal

operator

required

operator

required

operator

required

Page 59

SETTINGS

6.5 Data Setup

6.5.1 Data/Fax

Allows you to use your phone to transmit data and faxes.

1. Press , , , , .

2. Use to select a setting, then press .

Off / Fax In Once / Fax In Always / Data In Once / Data In Always

NOTE

The Data Connection Kit allows you to connect your PC or PDA to your LG wireless phone, freeing you from having to locate a telephone outlet. You can send or receive an e-mail, a fax, or access the Internet anytime, anywhere.

6.5.2 PC Connection

Allows you to select the data port.

1. Press , , , , .

2. Use to select a setting, then press .

USB / Bluetooth / Closed

NOTE

When using the 1X HSPD data service via a USB data cable, you may get better port speed if the port speed is set to 230,400 rather than 115,200.

6.6 Memory Info

Shows you the memory information of the phone.

6.6.1 Common Memory

1. Press , , , , .

6.6.2 Reserved Memory

1. Press , , , , .

7. S y s t e m

Options for specific system network settings.

7.1 Phone Info

The Phone Info menu provides you with specific information pertaining to your phone model.

7.1.1 NAM

Allows you to view your phone number.

1. Press , , , , .

SETTINGS

Page 60

SETTINGS

7.1.2 Software Version

Allows you to view the software version.

1. Press , , , , .

7.1.3 Hardware Version

Allows you to view the hardware version.

1. Press , , , , .

7.1.4 ESN

Allows you to view the ESN.

1. Press , , , , .

7.1.5 PRL

Allows you to view the PRL version.

1. Press , , , , .

7.1.6 Browser Version

Allows you to view the Browser version.

1. Press , , , , .

7.1.7 Serving System

Identifies the channel number of a system that is served and a SID Number. This information is only for technical support.

1. Press , , , , .

7.1.8 Icon Glossary

Allows you to view all the icons and their meanings.

1. Press , , , , .

7.2 System

The System menu allows you to designate specific system network settings.

7.2.1 Set Mode

Allows you to set up the phone producer’s management environment. Leave the default setting unless you want to alter the system selection as instructed by your service provider.

1. Press , , , , .

Page 61

SETTINGS

2. Use to select a setting, then press .

Digital Only/ Analog Only/ Home Only / Automatic

7.2.2 Set NAM

Allows you to select the phone's NAM (Number Assignment Module) if the phone is registered with multiple service providers.

1. Press , , , , .

2. Use to select a NAM, then press .

NAM 1 / NAM 2

7.2.3 Call Guard

Call Guard alerts you when roaming charges apply.

1. Press , , , , .

2. Use to select a setting, then press .

On / Off

7.3 Security

Allows you to secure the phone electronically.

7.3.1 Lock Phone

Keeps your phone from unauthorized use. Once the phone is locked, it is in restricted mode until the lock code is entered. You can receive phone calls and still make emergency calls. You can modify the lock code using the Change Lock code within the Security menu.

1. Press , , , .

2. Enter the 4-digit password.

The lock code is commonly the last 4 digits of your phone number.

3. Press

4. Use to select a setting, then press .

Unlock Lock

On Power Up

Lock Phone

The phone is never locked. The phone is always locked. When

locked, you can only receive incoming calls or make emergency calls.

The phone is locked when it is turned on.

SETTINGS

Page 62

SETTINGS

7.3.2 Change Lock Code

Allows you to change to a new four-digit lock code.

1. Press , , , .

2. Enter the 4-digit password.

The lock code is commonly the last 4 digits of your phone number.

3. Press

4. Enter a old four-digit lock code.

5. Enter a new four-digit lock code.

6. Enter the new lock code again to confirm the original entry.

7.3.3 Reset Defaults

Allows you to reset your phone to the factory default settings.

1. Press , , , .

2. Enter the 4-digit password.

The lock code is commonly the last 4 digits of your phone number.

Change Lock Code

3. Press

4. Read the screen message, then press .

5. Press back to the factory defaults or press to exit without changing.

Reset Defaults

Revert

to change your phone settings

Cancel

8. Airplane Mode

Airplane Mode allows you to use many of your phone’s features, such as Games, Notepad, Voice Memos, etc., when you are in an airplane or in any other area where making or receiving calls or data is prohibited. When your phone is in Airplane Mode, it cannot send or receive any calls or access online information.

1. Press , , .

2. Use to select a setting, then press .

On / Off

Page 63

SAFETY

TIA(Telecommunications Industry Association) Safety Information

The following is the complete TIA Safety Information for wireless handheld phones.

Exposure to Radio Frequency Signal

Your wireless handheld portable phone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out Radio Frequency (RF) signals. In August, 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S. and international standards bodies:



ANSI C95.1 (1992) *



NCRP Report 86 (1986)



ICNIRP (1996)



Health Canada, Safety Code 6, 1999.

Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1).

The design of your phone complies with the FCC guidelines, IC Regulations (and those standards).

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthoriaed antennas, modifications, or attachments could damage the phone and may violate FCC regulations.

Phone Operation

NORMAL POSITION: Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder.

SAFETY

Page 64

SAFETY

Tips on Efficient Operation

For your phone to operate most efficiently:

Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

Driving

Check the laws and regulations on the use of wireless phones in the areas where you drive and always obey them. Also, if using your phone while driving, please observe the following:



Give full attention to driving -- driving safely is your first responsibility;



Use hands-free operation, if available;



Pull off the road and park before making or answering a call if driving conditions or the law so require.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of six inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.

Persons with Pacemakers:



Should ALWAYS keep the phone more than six inches from their pacemaker when the phone is turned ON;



Should not carry the phone in a breast pocket;



Should use the ear opposite the pacemaker to minimize the potential for interference;



Should turn the phone OFF immediately if there is any reason to suspect that interference is taking place.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives.) Optional for each phone manufacturer.

Page 65

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Health Care Facilities

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may use equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Turn your phone OFF in any facility where posted notices so require.

Aircraft

FCC and Transport Canada regulations prohibit using your phone while in the air. Switch OFF your phone before boarding an aircraft.

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off two-way radio”. Obey all signs and instructions.

Potentially Explosive Atmosphere

Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always marked clearly. Potential areas may include: fueling areas (such as gasoline stations); below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles (such as grain, dust, or metal powders); and any other area where you would normally be advised to turn off your vehicle engine.

SAFETY

Page 66

SAFETY

For Vehicles Equipped with an Air Bag

An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

Charger and Adapter Safety



The charger and adapter are intended for indoor use only.



Do not expose the battery charger or adapter to direct sunlight or use it in places with high humidity, such as a bathroom.

Battery Information and Care



Please dispose of your battery properly or take it to your local wireless carrier for recycling.



Do not dispose of your battery by fire or with hazardous or flammable materials..



Never use an unapproved battery since this could damage the phone and/or battery and could cause the battery to explode.



The battery does not need to be fully discharged before recharging.



Use only LG-approved chargers specific to your phone model since they are designed to maximize battery life.



Do not disassemble or short-circuit the battery.



Keep the battery’s metal contacts clean.



Replace the battery when it no longer provides acceptable performance. The battery can be recharged several hundred times before replacement.



Recharge the battery after long periods of non-use to maximize battery life.



Battery life will vary due to usage patterns and environmental conditions.



Use of extended backlighting, MiniBrowser, and data connectivity kits affect battery life and talk/standby times.

Page 67

Safety Information

Please read and observe the following information for safe and proper use of your phone and to prevent damage. Also, keep the user’s guide in an accessible place at all the times after reading it.

Explosion, Shock, and Fire Hazards



Unplug the power cord and charger during lightning storms to avoid electric shock or fire.



Make sure that no sharp-edged items such as animal’s teeth, nails, come into contact with the battery. There is a risk of this causing a fire.



Do not use harsh chemicals(such as alcohol, benzene, thinners, etc.) or detergents to clean your phone. There is a risk of this causing a fire.



Do not handle the phone with wet hands while it is being charged. It may cause an electric shock or seriously damage your phone.



Do not drop, strike, or shake your phone severely. Such actions may harm the internal circuit boards of the phone.



Do not put your phone in a place subject to excessive dust and keep the minimum required distance between the power cord and heat sources.



Unplug the power cord prior to cleaning your phone, and clean the power plug pin when it is dirty.



Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the plug if it is loose as it may cause a fire or electric shock.



When using the power plug, ensure that it is firmly connected. If it is not, it may cause excessive heat or fire.



Do not place any heavy items on the power cord. Do not allow the power cord to be crimped as it may cause fire or electric shock.



Do not disassemble the phone.



Do not place or answer calls while charging the phone as it may short-circuit the phone and/or cause electric shock or fire.



If you put your phone in a pocket or bag without covering the receptacle of the phone (power plug pin), metallic articles (such as a coin, paperclip or pen) may short-circuit the phone. Always cover the receptacle when not in use.

SAFETY

Page 68

SAFETY



Do not short-circuit the battery. Metallic articles such as a coin, paperclip or pen in your pocket or bag may short-circuit the + and – terminals of the battery (metal strips on the battery) upon moving. Short-circuit of the terminal may damage the battery and cause an explosion.



Never place your phone in a microwave oven as it will cause the battery to explode.

General Warnings and Cautions



Only use the batteries, antennas, and chargers provided by LG. The warranty will not be applied to products provided by other suppliers.



Store the battery in a place out of reach of children.



Using a damaged battery or placing a battery in your mouth may cause serious injury.



Do not place items containing magnetic components such as a credit card, phone card, bank book or subway ticket near your phone. The magnetism of the phone may damage the data stored in the magnetic strip.



Do not hold or let the antenna come in contact with your body during a call.



Talking on your phone for a long period of time may reduce call quality due to heat generated during use.



When the phone is not used for a long period time, store it in a safe place with the power cord unplugged.



Using the phone in proximity to receiving equipment (i.e., TV or radio) may cause interference to the phone.



Only authorized personnel should service the phone and its accessories. Faulty installation or service may result in accidents and consequently invalidate the warranty.



Do not use the phone if the antenna is damaged. If a damaged antenna contacts skin, it may cause a slight burn. Please contact an LG Authorized Service Center to replace the damaged antenna.



Do not use the phone in areas where its use is prohibited. (For example: aircraft).



Do not immerse your phone in water. If this happens, turn it off immediately and remove the battery. If the phone does not work, take it to an LG Authorized Service Center.

Page 69



Use accessories, such as earphones and headsets, with caution. Ensure that cables are tucked away safely and do not touch the antenna unnecessarily.

If you are listening to music whilst out and about, please ensure that the volume is at a reasonable level so that you are aware of your surroundings. This is particularly imperative when attempting to cross the street.

Avoid damage to your hearing

Damage to your hearing can occur if you are exposed to loud sound for long periods of time. We therefore recommend that you do not turn on or off the handset close to your ear. We also recommend that music and call volumes are set to a reasonable level.

FDA Consumer Update

The U.S. Food and Drug Administration’s Center for Devices and Radiological Health Consumer Update on Mobile Phones:

1. Do wireless phones pose a health hazard?

The available scientific evidence does not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of radiofrequency energy (RF) in the microwave range while being used. They also emit very low levels of RF when in the Main Menu Screen. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but such findings have not been confirmed by additional research. In some cases, other researchers have had difficulty in reproducing those studies, or in determining the reasons for inconsistent results.

SAFETY

Page 70

SAFETY

2. What is the FDA's role concerning the safety of wireless phones?

Under the law, the FDA does not review the safety of radiation-emitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit radiofrequency energy (RF) at a level that is hazardous to the user. In such a case, the FDA could require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace, or recall the phones so that the hazard no longer exists.

Although the existing scientific data do not justify FDA regulatory actions, the FDA has urged the wireless phone industry to take a number of steps, including the following:



Support needed research into possible biological effects of RF of the type emitted by wireless phones;



Design wireless phones in a way that minimizes any RF exposure to the user that is not necessary for device function; and



Cooperate in providing users of wireless phones with the best possible information on possible effects of wireless phone use on human health.

The FDA belongs to an interagency working group of the federal agencies that have responsibility for different aspects of RF safety to ensure coordinated efforts at the federal level. The following agencies belong to this working group:



National Institute for Occupational Safety and Health



Environmental Protection Agency



Occupational Safety and Health Administration



National Telecommunications and Information Administration

The National Institutes of Health participates in some interagency working group activities, as well.

The FDA shares regulatory responsibilities for wireless phones with the Federal Communications Commission (FCC). All phones that are sold in the United States must comply with FCC safety guidelines that limit RF exposure.

The FCC relies on the FDA and other health agencies for safety questions about wireless phones.

Page 71

The FCC also regulates the base stations that the wireless phone networks rely upon. While these base stations operate at higher power than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower than those they can get from wireless phones. Base stations are thus not the subject of the safety questions discussed in this document.

3. What kinds of phones are the subject of this update?

The term “wireless phone” refers here to handheld wireless phones with built-in antennas, often called “cell”, “mobile”, or “PCS” phones. These types of wireless phones can expose the user to measurable radiofrequency energy (RF) because of the short distance between the phone and the user’s head. These RF exposures are limited by FCC safety guidelines that were developed with the advice of the FDA and other federal health and safety agencies. When the phone is located at greater distances from the user, the exposure to RF is drastically lower because a person's RF exposure decreases rapidly with increasing distance from the source. The socalled “cordless phones,” which have a base unit

connected to the telephone wiring in a house, typically operate at far lower power levels, and thus produce RF exposures far below the FCC safety limits.

4. What are the results of the research done already?

The research done thus far has produced conflicting results, and many studies have suffered from flaws in their research methods. Animal experiments investigating the effects of radiofrequency energy (RF) exposures characteristic of wireless phones have yielded conflicting results that often cannot be repeated in other laboratories. A few animal studies, however, have suggested that low levels of RF could accelerate the development of cancer in laboratory animals. However, many of the studies that showed increased tumor development used animals that had been genetically engineered or treated with cancer-causing chemicals so as to be pre-disposed to develop cancer in the absence of RF exposure. Other studies exposed the animals to RF for up to 22 hours per day. These conditions are not similar to the conditions under which people use wireless phones, so we don’t know with certainty what the results of

SAFETY

Page 72

SAFETY

such studies mean for human health. Three large epidemiology studies have been published since December 2000. Between them, the studies investigated any possible association between the use of wireless phones and primary brain cancer, glioma, meningioma, or acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the studies demonstrated the existence of any harmful health effects from wireless phone RF exposures. However, none of the studies can answer questions about long-term exposures, since the average period of phone use in these studies was around three years.

5. What research is needed to decide whether RF exposure from wireless phones poses a health risk?

A combination of laboratory studies and epidemiological studies of people actually using wireless phones would provide some of the data that are needed. Lifetime animal exposure studies could be completed in a few years. However, very large numbers of animals would be needed to provide reliable proof of a cancer promoting effect if one exists. Epidemiological studies can provide data that

is directly applicable to human populations, but 10 or more years follow-up may be needed to provide answers about some health effects, such as cancer. This is because the interval between the time of exposure to a cancer-causing agent and the time tumors develop — if they do — may be many, many years. The interpretation of epidemiological studies is hampered by difficulties in measuring actual RF exposure during day-to-day use of wireless phones. Many factors affect this measurement, such as the angle at which the phone is held, or which model of phone is used.

6. What is the FDA doing to find out more about the possible health effects of wireless phone RF?

The FDA is working with the U.S. National Toxicology Program and with groups of investigators around the world to ensure that high priority animal studies are conducted to address important questions about the effects of exposure to radio frequency energy (RF). The FDA has been a leading participant in the World Health Organization International Electromagnetic Fields (EMF) Project since its inception in 1996. An influential result of this work has been the development of a detailed agenda of research needs

Page 73

that has driven the establishment of new research programs around the world. The project has also helped develop a series of public information documents on EMF issues. The FDA and the Cellular Telecommunications & Internet Association (CTIA) have a formal Cooperative Research and Development Agreement (CRADA) to do research on wireless phone safety. The FDA provides the scientific oversight, obtaining input from experts in government, industry, and academic organizations. CTIA-funded research is conducted through contracts with independent investigators. The initial research will include both laboratory studies and studies of wireless phone users. The CRADA will also include a broad assessment of additional research needs in the context of the latest research developments around the world.

7. How can I find out how much radio frequency energy exposure I can get by using my wireless phone?

All phones sold in the United States must comply with Federal Communications Commission (FCC) guidelines that limit radio frequency energy (RF) exposures. The FCC established these guidelines in consultation with the FDA and the other federal health and safety agencies. The FCC limit for RF exposure from wireless telephones is set at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC limit is consistent with the safety standards developed by the Institute of Electrical and Electronic Engineering (IEEE) and the National Council on Radiation Protection and Measurement. The exposure limit takes into consideration the body’s ability to remove heat from the tissues that absorb energy from the wireless phone and is set well below levels known to have effects. Manufacturers of wireless phones must report the RF exposure level for each model of phone to the FCC. The FCC website (http://www.fcc.gov/oet/ rfsafety) gives directions for locating the FCC identification number on your phone so you can find your phone’s RF exposure level in the online listing.

SAFETY

Page 74

SAFETY

8. What has the FDA done to measure the radio frequency energy coming from wireless phones?

The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical standard for measuring the radio frequency energy (RF) exposure from wireless phones and other wireless handsets with the participation and leadership of FDA scientists and engineers. The standard, “Recommended Practice for Determining the SpatialPeak Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications Devices: Experimental Techniques,” sets forth the first consistent test methodology for measuring the rate at which RF is deposited in the heads of wireless phone users. The test method uses a tissue-simulating model of the human head. Standardized SAR test methodology is expected to greatly improve the consistency of measurements made at different laboratories on the same phone. SAR is the measurement of the amount of energy absorbed in tissue, either by the whole body or a small part of the body. It is measured in watts/kg (or milliwatts/g) of matter. This measurement is used to determine whether a wireless phone complies with safety guidelines.

9. What steps can I take to reduce my exposure to radio frequency energy from my wireless phone?

If there is a risk from these products — and at this point we do not know that there is — it is probably very small. But if you are concerned about avoiding even potential risks, you can take a few simple steps to minimize your exposure to radio frequency energy (RF). Since time is a key factor in how much exposure a person receives, reducing the amount of time spent using a wireless phone will reduce RF exposure. If you must conduct extended conversations by wireless phone every day, you could place more distance between your body and the source of the RF, since the exposure level drops off dramatically with distance. For example, you could use a headset and carry the wireless phone away from your body or use a wireless phone connected to a remote antenna. Again, the scientific data do not demonstrate that wireless phones are harmful. But if you are concerned about the RF exposure from these products, you can use measures like those described above to reduce your RF exposure from wireless phone use.

Page 75

10. What about children using wireless phones?

The scientific evidence does not show a danger to users of wireless phones, including children and teenagers. If you want to take steps to lower exposure to radio frequency energy (RF), the measures described above would apply to children and teenagers using wireless phones. Reducing the time of wireless phone use and increasing the distance between the user and the RF source will reduce RF exposure. Some groups sponsored by other national governments have advised that children be discouraged from using wireless phones at all. For example, the government in the United Kingdom distributed leaflets containing such a recommendation in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their recommendation to limit wireless phone use by children was strictly precautionary; it was not based on scientific evidence that any health hazard exists.

11. What about wireless phone interference with medical equipment?

Radio frequency energy (RF) from wireless phones can interact with some electronic devices. For this reason, the FDA helped develop a detailed test method to measure electromagnetic interference (EMI) of implanted cardiac pacemakers and defibrillators from wireless telephones. This test method is now part of a standard sponsored by the Association for the Advancement of Medical instrumentation (AAMI). The final draft, a joint effort by the FDA, medical device manufacturers, and many other groups, was completed in late 2000. This standard will allow manufacturers to ensure that cardiac pacemakers and defibrillators are safe from wireless phone EMI. The FDA has tested hearing aids for interference from handheld wireless phones and helped develop a voluntary standard sponsored by the Institute of Electrical and Electronic Engineers (IEEE). This standard specifies test methods and performance requirements for hearing aids and wireless phones so that no interference occurs when a person uses a “compatible” phone and a “compatible” hearing aid at the same time. This standard was approved by the IEEE in 2000. The

SAFETY

Page 76

SAFETY

FDA continues to monitor the use of wireless phones for possible interactions with other medical devices. Should harmful interference be found to occur, the FDA will conduct testing to assess the interference and work to resolve the problem.

12. Where can I find additional information?

For additional information, please refer to the following resources:

FDA web page on wireless phones (http://www.fda.gov/cdrh/phones/index.html)

Federal Communications Commission (FCC) RF Safety Program (http://www.fcc.gov/oet/rfsafety)

International Commission on Non-lonizing Radiation Protection (http://www.icnirp.de)

World Health Organization (WHO) International EMF Project (http://www.who.int/emf)

National Radiological Protection Board (UK) (http://www.nrpb.org.uk/)

Consumer Information on SAR

(Specific Absorption Rate)

This Model Phone Meets the Government’s Requirements for Exposure to Radio Waves. Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating positions specified by the FCC with the phone transmitting at

Page 77

its highest certified power level in all tested frequency bands. Although SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. Because the phone is designed to operate at multiple power levels to use only the power required to reach the network, in general, the closer you are to a wireless base station antenna, the lower the power output.

Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model.

The highest SAR value for this model phone when tested for use at the ear is 0.784 W/kg and when worn on the body, as described in this user guide, is

0.686 W/kg (body-worn measurements differ among phone models, depending upon available accessories and FCC/IC requirements). While there may be differences between SAR levels of various phones and at various positions, they all meet the

government requirement for safe exposure. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF emission guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID BEJAX490. Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Association (CTIA) website at http ://www.ctia.org.

* In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

SAFETY

Page 78

ACCESSORIES

There are a variety of accessories available for your mobile phone. Consult your local dealer for availability.

Optional items are sold separately.

Battery Charger

The battery charger allows you to charge your phone.

Battery

Standard battery is available.

Vehicle Power Charger

ACCESSORIES

The vehicle power charger allows you to operate the phone and trickle charge the phone’s battery from your vehicle.

USB Data Cable

The USB data cable kit, enables you to connect your phone to your PC.

Headset

Connects to your phone, allowing hands-free operation. Includes earpiece, microphone, and integrated call answer / termination button.

Page 79

WARRANTY INFORMATION

1. WHAT THIS WARRANTY COVERS :

LG offers you a limited warranty that the enclosed subscriber unit and its enclosed accessories will be free from defects in material and workmanship, according to the following terms and conditions:

(1) The limited warranty for the product extends

for ONE (1) year beginning on the date of purchase of the product by the original end user.

(2) The limited warranty extends only to the

original end user of the product and is not assignable or transferable to any subsequent purchaser/end user.

(3) This warranty is good only to the original end

user of the product during the warranty period as long as it is in Canada.

(4) Upon request from LG, the consumer must

provide information to reasonably prove the date of purchase.

(5) During the applicable warranty period, LG will

repair or replace at LG’s sole option, without charge to the original end user, any defective component part of the phone or accessory.

(6) LG may, use rebuilt, reconditioned, or new parts

or components when repairing any product or replace a product with a rebuilt, reconditioned or new product.

2. WHAT THIS WARRANTY DOES NOT COVER :

(1) Defects or damages resulting from use of the

product in other than its normal and customary manner.

(2) Defects or damages from abnormal use,

abnormal conditions, improper storage, exposure to moisture or dampness, unauthorized modifications, unauthorized connections, unauthorized repair, misuse, neglect, abuse, accident, alteration, improper installation, or other acts which are not the fault of LG, including damage caused by spills of food or liquids.

(3) Breakage or damage to antennas unless caused

directly by defects in material or workmanship.

(4) If the carrier’s or manufacturer’s Customer

Service Centre was not notified by the end user of the alleged defect or malfunction of the product, during the warranty period.

WARRANTY INFORMATION

Page 80

WARRANTY INFORMATION

(5) Products which have had their serial numbers

removed or made illegible.

(6) Damage resulting from use of non-LG approved

accessories.

(7) All plastic surfaces and all other externally

exposed parts that are scratched or damaged due to normal customer use.

(8) Products serviced by non-authorized persons or

companies.

Notes:

(1) This limited warranty is in lieu of all other

warranties, express or implied either in fact or by operations of law, statutory or otherwise, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose.

(2) Shipping damage is the sole responsibility of

the shipping company.

3. EXCLUSION OF LIABILITY :

No other express warranty is applicable to this product. THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MARKETABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN. LG ELECTRONICS CANADA, INC. SHALL NOT BE LIABLE FOR THE LOSS OF THE USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, DIRECT OR CONSEQUENTIAL, ARISING OUT OF THE USE OF, OR INABILITY TO USE, THIS PRODUCT OR FOR ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY APPLICABLE TO THIS PRODUCT.

4. HOW TO GET WARRANTY SERVICE :

To obtain warranty service, please call the following telephone number from anywhere in Canada:

LG Electronics Canada, Inc.

Tel. 1-888-542-2623

Page 81

INDEX

ACCESSORIES 76

Airplane Mode 60

Alarm Clock 42

Alerts 48

All Calls 25

Avoid damage to your

hearing 67

Backlight 49

Backlight Settings 50

Banner 48

Battery 16

Battery Charge Level 16

Battery Information and

Care 64

Bluetooth Info 53

Bluetooth

Calculator 42

Call History 25

Call Setup 54

Call Timers 27

Call Waiting 21

Caller ID 21

Camera 38

Charger and Adapter

Safety 64

Charging the Battery 16

Consumer Information on

SAR 74

Contacts 22

Data Setup 57

Device List 52

Device Name 53

Dialing Fonts 50

Discovery Mode 53

Display 48

E-mail 34

Erase All Contacts 24

Erase History 27

Erase Messages 33

EZ Tip Calc 43

FDA Consumer Update 67

Games 41

Games / Tools 50

Get New 41

GPS 53

GPS Services 42

Groups 23

IM & Chat 35

IMPORTANT SAFETY

PRECAUTIONS 1

Incoming Calls 26

Keypad 46

Language 55

List Entries 22

Lock Mode 20

Making Calls 19

Media 37

Memory Info 51,57

Menu Access 22

Menu Style 49

Menus Overview 14

INDEX

Page 82

INDEX

Messaging 27

Missed Calls 26

Mute Function 20

My Albums 39

Nav. Key Shortcuts 54

New Entry 23

Notepad 43

Notification 50

Others 51,54

Outgoing Calls 26

Phone Info 57

Phone Overview 12

Powe r 5 2

Receiving Calls 19

Redialing Calls 19

Ringers 46

Ringtones 37

Safety Information 65

Scheduler 43

Screen Icons 18

Security 59

Settings 33, 45

Shop 40

Short Codes 35

Signal Strength 17

Sound 46

Speed Dialing 21

Speed Dials 24

System 57,58

Text and Multimedia 29

Theme Color 50

TIA(Telecommunications

Industry Association) Safety Information 61

Time and Date 49

Tools & Apps 41

TTY Mode 55

Turning the Phone On and

Off 17

Vibrate Mode 20

Voice Dials 24

Voice Mail 28

Voice Memo 44

Volume 47,50

Volume Quick

Adjustment 20

Wallpaper 38,48

Warranty Information 77

Web Alerts 35

Wireless Web 35

World Clock 44

Page 83

MEMO
