LG 441G User Guide

Screen displays and illustrations may differ

from those you see on the actual phone.

Some of the contents of this manual may

not apply to your phone depending on your phone’s software or your service provider. All information in this document is subject to change without notice.

rights reserved. LG and the LG logo are registered trademarks of LG Group and its related entities. All other trademarks are the property of their respective owners.

Contents

Your Phone ........................5

Phone Components .....................5

Rear view ............................. 7

Getting Started .....................8

Installing the SIM card and battery .........8

Charging your phone ................... 10

On-Screen Icons .....................11

General Functions .................12

Before you begin ......................12

Making a Call ......................... 12

Making a Call with the Send Key .........12

Making International Calls ..............12

Ending a Call ........................12

Making a Call from the Contacts .......... 13

Answering a Call ......................13

Adjusting the Volume. . . . . . . . . . . . . . . . . . . 13

Vibrating Mode (Quick) ................. 13

Signal Strength ......................14

Entering Text .........................14

Changing the Text input mode ...........14

123 mode (Numbers mode) .............14

Using the 123 (Numbers) mode ..........14

Symbol mode. . . . . . . . . . . . . . . . . . . . . . . . 14

ABC mode .......................... 14

Using the ABC mode .................. 15

In-Call Menu ...................... 16

During a Call ......................... 16

Making a Second Call .................16

Swapping Between Two Calls ............16

Answering an Incoming Call .............16

Rejecting an Incoming Call ..............16

Muting the Microphone ................16

Using the Speakerphone ...............17

Prepaid ..........................18

Add airtime ..........................18

Buy airtime ..........................18

My phone number .....................18

My airtime (balance) info ...............18

Airtime display ........................ 18

Serial number ........................ 19

SIM number .......................... 19

Contacts ......................... 20

Contact list. . . . . . . . . . . . . . . . . . . . . . . . . . . 20

New contact .........................20

Groups ..............................20

Speed dial ...........................20

SIM management .....................21

Own number ......................... 21

My business card .....................21

Messages ........................22

Create message. . . . . . . . . . . . . . . . . . . . . . . 22

Inbox ...............................25

Drafts ............................... 26

Outbox ..............................26

Message settings .....................27

Message alert .......................27

Save to ............................27

Signature ...........................27

Text message .......................27

Multimedia message ..................28

Voicemail ...........................28

Recent calls ......................29

Games & apps ....................29

Email ............................30

Sending an email ..................... 30

Retrieving your email ..................30

Message folders .....................30

Changing your email settings ............31

My Folder ........................32

Audio ...............................32

Pictures .............................32

Video ............................... 32

Other files ...........................32

File manager .........................33

Tools ............................34

Voice command .......................34

Alarm clock ..........................35

Calendar ............................36

Notepad .............................37

Calculator ...........................37

Tasks ...............................37

Stopwatch ...........................38

Tip calculator .........................39

Unit converter ........................ 39

Voice recorder ........................39

Browser ..........................40

Using the Browser ....................40

Menus for the Browser .................41

Using the Navigation Keys ..............41

Music. . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Playing Music .......................42

Adding Music To Your Phone ............43

Camera ..........................44

Take photo ........................... 44

Record video .........................45

Camera album ........................ 46

Contents

Settings ..........................47

Audio & ringtones .....................47

Ringtone ........................... 47

Message tone ....................... 47

Alert tone. . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Keypad tone ........................48

Multimedia. . . . . . . . . . . . . . . . . . . . . . . . . . 48

Call ...............................48

Phone settings ........................48

Languages .......................... 48

Set hotkeys .........................48

Airplane mode .......................48

Security ............................ 49

Reset settings ....................... 49

Display .............................. 50

Wallpapers .........................50

Fonts ..............................50

Clocks & calendar ....................50

Brightness ..........................50

Backlight timer ....................... 50

Menu styles ......................... 50

Call .................................50

Send my number .....................50

Answer mode .......................51

Senior mode ........................51

Connection vibration ................... 51

Call duration ........................51

Accessibility .......................... 51

Menu readout .......................51

Keypad tone ........................52

Large text ..........................52

Invert color .........................52

Mono sound ........................52

Senior mode ........................52

TTY ...............................52

Hearing aid ......................... 52

Voice command ......................52

Bluetooth ............................52

Turn on/off ..........................53

Search new device .................... 53

My devices .........................53

My bluetooth info ..................... 53

Memory .............................54

Used space .........................54

Applications .......................... 54

Messages .......................... 54

Browser ............................54

Phone information ..................... 56

Accessories ......................57

For Your Safety ....................58

Safety Guidelines ..................64

Your Phone

Phone Components

3 4

5 6 7

8 9

10 11

Press and hold to activate/deactivate Vibration Mode.

Your Phone

1. Earpiece: Lets you hear the caller during

a call and automated prompts.

2. Main LCD: Displays phone status icons, menu items, web items, web information, pictures and more, in full color.

3. Left Selection Key/Right Selection Key: Each of these keys perform the

functions indicated by the text on the display immediately above them.

4. Camera Key: Lets you activate the Camera and take pictures.

5. Message Key: Allows you to create a new message immediately.

6. Navigation Keys

Home screen functions:

Games & apps

Contacts Alarm clock Music

- In a menu: Navigates between menus.

7. Send Key: Press this key in standby mode to quickly access the most recent missed, dialed, and received calls. Also dials a call when you enter a number.

8. Clear/Back Key: Allows you to return to the previous screen. Press and hold from standby mode to activate the Voice Command function. You can also use this key to erase text/numbers you have entered.

9. TTS mode Key: Lets you turn the TextTo-Speech mode on/off.

10. OK Key: Select options and menus.

11. End/Power Key: Allows you to power

the phone on or off, end calls, or return to standby mode.

12. Volume Keys: Allows you to control the

Master Volume while in standby mode and the earpiece volume during a call.

13. Charger/USB Port: Allows you to

connect a charger or other supported accessories.

Rear view

SIM Card Slot

Back Cover

Battery

Getting Started

Installing the SIM card and battery

1. Remove the back cover

Place your thumb at the top part of the

back cover and slide it downwards to remove it.

2. Remove the battery

Hold the top edge of the phone and use

the fingernail cutout near the bottom of the battery to lift the battery from the phone.

Warning

Do not remove the battery when the phone is turned on; this can damage the phone.

3. Install the SIM card

Slide the SIM card into the SIM card slot

(as shown below). Make sure that the gold contact area on the card is facing downwards. To remove the SIM card, slide it gently in the opposite direction.

4. Install the battery

Insert the top of the battery first into the

top edge of the battery compartment. Ensure that the battery contacts align with the terminals on the phone. Press the bottom of the battery down until it snaps into place.

5. Install the back cover

Align the back cover on the battery

compartment and slide it upwards until it locks into place.

Getting Started

Charging your phone

Locate the Charger/USB Port on the left side of your phone. Plug the charging cable into the phone (the ‘B’ side of the cable has to be facing up when connecting to the phone) and then plug the other end into the wall socket. Your phone will need to be charged until the Full Battery message appears on the screen.

Important!

You must insert the battery before charging.

Warning

Use of unauthorized accessories could damage your phone and void your warranty.

On-Screen Icons

The table below describes various display indicators or icons that appear on the phone’s display screen.

ICON/

DESCRIPTION

INDICATOR

Network signal strength (number of bars will vary)

No network signal Low battery New text message New email An alarm is set Ring profile in use Silent all profile in use EDGE network available Bluetooth is active 3G network available The browser is active

ICON/

DESCRIPTION

INDICATOR

Vibrating mode on Speakerphone Call in progress Voicemail Battery full Battery charging Airplane mode on Camera in use Camcorder in use Camcorder timer Play the current music Pause the current music

General Functions

Before you begin

Remember that you can select the menu icons from the Menu screen using the number keys if you set the Menu Styles option as List. If you set the Menu Styles option as Icon, you can only use the Navigation Keys to select the menu icons.

Making a Call

1 Make sure your phone is powered on. 2 Enter a phone number including the area

code. To edit a number on the display screen, simply press the Clear/Back Key

to erase one digit at a time.

Ź Press and hold the Clear/Back Key

to erase the entire number.

3 Press the Send Key

number.

4 To end the call, press the End/Power

Key

to call the

Making a Call with the Send Key

1 Press the Send Key to display the

most recent missed, dialed and received calls will be displayed.

2 Highlight the desired number by using the

Navigation Keys.

3 Press the Send Key

Making International Calls

1 Press and hold the key and the

international access character ‘+’ will appear.

2 Enter the country code, area code, and

the phone number.

3 Press the Send Key

number.

to call the

Ending a Call

To end a call, press the End/Power Key

Making a Call from the Contacts

You can store frequently called names and phone numbers in the SIM card as well as in your Contacts List.

You can dial a number by simply highlighting a name in the Contacts List and pressing the Send Key

1 Press the Down Navigation Key

2 Highlight the Contact and press the Send

Key

to access the Contact List.

Answering a Call

When you receive a call, the phone displays a notification on the screen and rings and/ or vibrates. If the caller can be identified, the caller’s phone number (or name, if stored in your Contacts) is displayed.

1 Press the Send Key or the Left

Selection Key Accept to answer

an incoming call. If the Answer Mode has been set as

Any Key (

Call > Answer Mode), any

Menu > Settings >

key press will answer a call, except for the End/Power Key

, and Volume Keys.

Key

2 End the call by pressing the End/Power

Key

Note

You can answer a call while using other functions or features.

Right Selection

Adjusting the Volume

Use the Volume Keys during a call to adjust the earpiece volume.

While in standby mode, you can adjust the Master Volume using the Volume Keys.

Vibrating Mode (Quick)

Vibrating Mode can be activated by pressing and holding down the

key.

General Functions

Signal Strength

If you are inside a building, being near a window may give you better reception. You can see the strength of your signal by the signal indicator on your phone’s display screen.

Entering Text

You can enter alphanumeric characters by using the phone’s keypad. For example, storing names in the Contacts, writing a message, or scheduling events in the calendar all require text to be entered.

Changing the Text input mode

Change the text input mode by pressing

when in a text entry field.

You can check the current text input mode in the upper right corner of the screen.

The following text input modes are available on the phone.

123 mode (Numbers mode)

Type numbers using one keystroke per number. To change to 123 mode in a text entry field, press the mode is displayed in the upper right corner.

key until 123

Using the 123 (Numbers) mode

The 123 mode enables you to enter numbers in a text message (a telephone number, for example) more quickly. Press the keys corresponding to the required digits before manually switching back to the appropriate text entry mode.

Symbol mode

The Symbol mode enables you to enter various symbols or special characters. To enter a symbol, press the the Navigation Keys to highlight the desired symbol and press the OK Key

key. Use

ABC mode

This mode allows you to enter letters by pressing the key labeled with the required letter.

Using the ABC mode

Use the alphanumeric keypad to enter your text.

1 Press the key labeled with the required

letter.

2 To insert a space, press the

once. To delete letters, press the Clear/

Back Key Clear/Back Key to erase all of the

entered text.

Note

Refer to the table below for more information on the characters available using the keys.

Key

1 2 3

. Press and hold down the

Characters in the order displayed

Upper case Lower case

. , ’ @ ? ! - : / 1 . , ’ @ ? ! - : / 1

A B C 2 a b c 2 D E F 3 d e f 3

key

Characters in the order displayed

Key

Upper case Lower case

G H I 4 g h i 4

J K L 5 j k l 5

M N O 6 m n o 6

P Q R S 7 p q r s 7

T U V 8 t u v 8

W X Y Z 9 w x y z 9

Space Key,

0 (Long press)

Space Key,

0 (Long press)

In-Call Menu

During a Call

Your phone provides a number of control functions that you can use during a call. To access these functions during a call, press the Left Selection Key

Options.

Making a Second Call

You can select a number you wish to dial from the Contacts to make a second call.

1 Press the Left Selection Key

Options, then select Contacts.

2 Highlight the contact, then press the Send

Key

to make a second call.

Swapping Between Two Calls

Once the second call has been dialed (or answered), you can switch between the calls by using one of the following three methods:

Press the Send Key .

Press the Left Selection Key Options and then select Swap Calls.

Press the up or down Navigation Keys.

Answering an Incoming Call

To answer an incoming call when the phone is ringing, simply press the Send Key The phone is also able to warn you of an incoming call while you are already on a call. A tone sounds in the earpiece and the display will show that a second call is waiting. This feature, known as Call Waiting, is only available if your network supports it.

If Call Waiting is turned on, you can put the first call on hold and answer the second call by pressing the Send Key

Rejecting an Incoming Call

You can reject an incoming call without answering by simply pressing the End/

Power Key .

Muting the Microphone

You can mute the microphone during a call by pressing the Right Selection Key

Mute. The phone can be unmuted by pressing the Right Selection Key Unmute. When the phone is muted, the caller cannot hear you, but you can still hear the caller.

Using the Speakerphone

You can use the integrated Speakerphone during a call by pressing the OK Key Spk. on. The loudspeaker is automatically deactivated when you end the call.

Warning

Due to increased volume levels, do not place the phone near your ear while the speakerphone is enabled.

Prepaid

Add airtime

Allows you to add airtime.

1 Press the Left Selection Key

Menu, Prepaid airtime.

2 Enter the airtime PIN and touch the Left

Selection Key

3 Read the displayed message, then select

Ye s or No.

and Add

OK.

Buy airtime

Allows you to buy additional airtime.

1 Press the Left Selection Key

Menu, Prepaid airtime.

2 Select the amount of airtime you want to

purchase and follow the instructions on the screen.

and Buy

My phone number

Allows you to view the device’s phone number.

1 Press the Left Selection Key

Menu, Prepaid number.

2 Your phone number is displayed.

and My phone

My airtime (balance) info

Allows you to check your minutes, messages, data, and service end date.

1 Press the Left Selection Key

Menu, Prepaid airtime info.

2 Your airtime info is displayed.

and My

Airtime display

Allows you to select if you want to display the Balance and/or Service end date on the home screen.

1 Press the Left Selection Key

Menu, Prepaid display.

2 Press

end date and choose your setting.

and Airtime

Balance or Service

Serial number

This menu simply displays the information of your phone's IMEI.

1 Press the Left Selection Key

Menu, Prepaid number.

2 Your serial number is displayed.

and Serial

SIM number

This menu simply displays the information of your phone's SIM number.

1 Press the Left Selection Key

Menu, Prepaid number.

2 Your SIM number is displayed.

and SIM

Contacts

Contact list

This menu allows you to save and manage contact address information. The Contact List allows you to add a new address or search saved contact addresses by name.

To access Contact list, from the standby screen, press the Left Selection Key

Menu, Contacts List.

and Contact

New contact

This menu allows you to add a new contact to the Contact List. You can enter contact address information including name, phone numbers, email addresses, group information items, memos, ringtones, and a contact Picture ID.

To access New contact, from the standby screen, press the Left Selection Key

Menu, Contacts and New

contact.

Groups

This menu allows you to manage group information. You can also configure a ringtone for a group so that the group ringtone sounds when a call from a specific contact address within that group is received and there is no ringtone configured for the specific contact address.

To access Groups, from the standby screen, press the Left Selection Key

Contacts

and Groups.

Menu,

Speed dial

This menu allows you to assign a frequentlycalled contact to the Speed Dial List. You can select a number from 2 to 9 as a speed dial.

To access Speed dial list, from the standby screen, press the Left Selection Key Menu, Contacts

and Speed dial.

SIM management

This menu allows you to copy information from your SIM card to your phone and vice versa. If a name is duplicated during the copying operation, the information is also duplicated. You can also delete information from the SIM card.

To access SIM management, from the standby screen, press the Left Selection Key

Menu, Contacts and

SIM management.

Own number

This displays your personal phone number. To access Own number, from the standby

screen, press the Left Selection Key

Menu, Contacts and Own

Number.

My business card

This displays your business card stored in the phone. You can also edit it.

To access My business card, from the standby screen, press the Left Selection Key

Menu, Contacts and

My Business Card.

Messages

This menu includes functions related to SMS (Short Message Service), MMS (Multimedia Message Service), Voicemail as well as the network’s service messages.

Create message

1 From the standby screen, press the Left

Selection Key Menu.

2 Select Messages 3 Press

You can simply press the Message Key

from the standby screen.

Note

If you insert a picture, audio, or video file while writing a multimedia message, the file loading time will take about 5 seconds. You will not be able to activate any key during the file loading time. When the file loading is complete, you will be able to continue writing your multimedia message.

Create message.

Editing a message

The following options are available when editing a message.

Using Insert While entering text, press the Right

Selection Key

options are available.

Symbol: You can insert various symbols into your message. Pressing the Left

Selection Key and Right Selection Key scrolls through the

pages.

Picture: You can select a picture to insert by using the Navigation Keys. You can preview the selected picture by pressing the Right Selection Key View.

Audio: You can insert an audio file from your saved audio files.

Video: You can insert a video clip from your saved video clips.

Take new picture: You can take and insert a picture in your message.

Insert. The following

Record new audio: You can record a new audio clip by pressing the OK Key

Record. Press the Left Selection

Key

Options before you begin recording to set the options (below). After recording a new audio clip, you can delete it by pressing the Left Selection Key Discard.

s

Quality: Set the audio’s quality to Fine, Normal, or Economy.

Record new video: You can record a new video by pressing the OK Key

Rec. When finished recording, press the OK Key

Template

s

Text: Allows you to easily insert

Insert.

frequently used sentences in the text message.

s

Multimedia: Preset multimedia

templates can be created ( Menu > Messages

Message settings > Multimedia message > Multimedia templates > New).

s

Signature: Allows you to insert your own created signature.

More: Allows you to insert vCard, vCalendar, vNote, vTask or Contact.

Note

vCard, vCalendar, vNote and vTask are created by the Contacts, Calendar, Notepad, and Tasks functions, respectively.

Using Options While entering text, press the Left Selection

Key Options.

s

Text entry mode: Sets the text input mode. For more details, refer to Entering Text (page 14).

s

Text entry settings

- Text entry language: Allows you to set the text entry language to English or Spanish.

- T9 word candidate list: Displays the word candidates as you type.

Messages

- T9 next word prediction: Allows the phone to predict the next word when typing in T9 mode.

- T9 dictionary: Allows you to add, delete, reset, and modify words.

Save to drafts: Saves the message to Drafts.

Cancel message: Allows you to exit the text input mode without saving your message.

Sending a Message

After completing a message, press the OK

Send To to select a recipient.

Key

s

Enter the recipient(s). For more options, press the Left Selection Key Options. In this menu, you can choose from the following options:

- Enter number: Allows you to enter the phone number using the keypad.

- Enter email: Allows you to enter an email address instead of a phone number.

- Insert symbol: Allows you to enter symbols.

- Caller groups: Displays Contacts Groups.

- Recent messages: Choose a Contact from Recent Messages.

- Recent calls: Choose a Contact from Recent Calls.

- Delivery options: Allows you to set the options for Add Cc and Add Bcc.

- Save to drafts: Saves the selected message to Drafts.

- Text entry mode: Allows you to change the text entry mode.

- Text entry settings: Allows you to set the options for Text entry language, T9 Word candidate list, T9 next word prediction, and T9 dictionary.

- Cancel message: Allows you to cancel the message.

Inbox

You will be alerted when you receive a message. New messages are stored in the Inbox. In the Inbox, you can identify each message by icons. If you are notified that you have received a multimedia message, you can download the whole multimedia message by selecting it in the Inbox menu. To reach the Inbox, from the standby screen, press the Left Selection Key > Messages

> Inbox.

You can reply to the sender of the message by pressing the Right Selection Key Reply.

While viewing the Inbox, press the Left Selection Key Options for the following options:

Add to contact: You can save the sender’s phone number in the Contact List.

Delete: You can delete the selected message.

Forward: You can forward the selected message to another person.

Copy to SIM/Copy to phone: You can copy the message to the phone or SIM card depending on where the text message is stored.

Move to SIM/Move to phone: You can move the message to the phone or SIM card depending on where the text message is stored.

Select multiple: You can select multiple messages to delete.

Sort by: Allows you to sort the messages by date, sender, read/unread, or subject.

Message details: You can view the following information about received messages: Type, Subject, From, and Time.

Delete all read msg: You can delete all read messages.

Messages

Drafts

Allows you to view and edit the messages saved as drafts. To access drafts, from the standby screen, press the Left Selection

Menu, Messages , and

Key

Drafts. You can delete the message by pressing the Right Selection Key Delete.

While viewing the Drafts, press the Left Selection Key following options:

Select multiple: Allows you to select multiple messages to delete.

Message details: Allows you to view the details of the message.

Outbox

Outbox is the storage place for recently sent messages. When you press the Send Key selected message.

If the message is not sent from the Outbox, you will receive a sound alert along with a Message Sending Failure notice on the screen.

Options for the

, you can call the recipient of the

To access the Outbox, from the standby screen, press the Left Selection Key Menu, Messages

, and Outbox.

The following options are available for the Outbox folder by pressing the Left Selection

Options:

Key

View status: Display the status of message.

Delete: Deletes the selected message.

Edit: Allows you to edit the selected message.

Select multiple: Allows you to select multiple messages to delete.

Sort by: Allows you to sort the messages by date and recipient.

Message detail: Allows you to view the

details of the message. Press the Right Selection Key Forward to send the selected message to another.

Message settings

To access and configure your Message Settings, from the standby screen, press the Left Selection Key

, and Message settings.

Message alert

Allows you to set the Sounds, Volume, Alert Type, and Alert Interval.

Save to

Allows you to choose whether to save messages to the SIM card or the Phone.

Signature

Allows you to create, edit, and delete your signature, which can be configured to be sent out with your outgoing messages.

Text message

Allows you to set preferences for text messages.

Menu, Messages

The following options are available:

Text templates: Predefined messages that can quickly be sent. Press the Left Selection Key

Options to access

the following available options:

s

Send: Allows you to send the selected template via Message.

s

Delete: Allows you to delete the selected template message.

s

Edit: Allows you to edit the selected template message.

s

Delete all: Deletes all messages in the folder.

s

Cancel: Returns to Text Message menu.

Msg center no.: Allows you to view the phone number for the Message center.

Insert signature: Allows you to insert your signature in outgoing messages.

Messages

Multimedia message

Allows you to set your preferences for multimedia messages.

The following options are available:

Multimedia templates: Allows you to add, edit, and delete multimedia templates. Press the Right Selection Key New to create a new multimedia template. Press the Left Selection Key Options while creating a message to access the following available options:

s

Text entry mode: Sets the text input mode. For more details, refer to Entering Text (page 14).

s

Text entry settings

- Text entry language: Allows you to

set the text entry language to English or Spanish.

- T9 word candidate list: Displays the word candidates as you type.

- T9 next word prediction: Allows the phone to predict the next word when typing in T9 mode.

- T9 dictionary: Allows you to add, delete, reset, and modify words.

s

Cancel: Allows you to exit the text input mode without saving your message.

Voicemail

Displays the voicemail number used for your voicemail service. Please do not modify unless instructed by your service provider.

Recent calls Games & apps

This menu allows you to see the list of recent calls. To access Recent Calls, from the standby screen, press the Left

Selection Key Recent calls .

You can access the following menus: All calls, Missed calls, Dialed calls, and

Received calls.

Menu and select

This menu allows you to download or access the various games.

To access the Games, from the standby screen, press the Left Selection Key Menu, and Games & apps .

Email

Sending an email

To send/receive an email, you should set up an email account.

1 Press the Left Selection Key

Menu, select Email

account you want to use.

2 Press the Left Selection Key

Options and choose Write email

to write an email.

3 Enter the recipient’s address in the To

field. Then use the down Navigation Key to access the Subject and Messages fields.

4 Enter your message using the keypad and

press the OK Key the email.

and choose the

Send to send

Retrieving your email

1 Press the Left Selection Key

Menu, and select Email

2 Select the account you want to use. 3 Press the Left Selection Key

Options and then press Refresh to connect to your email account and retrieve your new messages.

Message folders

Open Email, press the Left Selection Key

Options, and select Mailbox.

The list of folders will be displayed.

Write email: Create your new message.

Inbox: All the e-mails you receive are placed into your Inbox. From here you can reply, forward and more.

Drafts: If you don’t have time to finish writing a e-mail, you can save what you have written so far in here.

Outbox: This is a temporary storage folder while e-mail are being sent or stores the messages that are failed to sent.

Sent: Copies of all the e-mail you send are kept into your Sent folder.

Trash: All the e-mail you remove are placed into your Trash.

Changing your email settings

1 Press the Left Selection Key

Menu, choose Email Selection Key Mailbox > Options > Settings.

2 Set any of the following options.

Accounts: You can edit e-mail account settings.

Schedule: Allows you to configure the schedule for Push email account.

Notification: Choose whether or not to be alerted to new emails.

Default account: Choose which account to compose e-mail by default.

Signature: Create an email signature and switch this feature on.

> Left

Options >

My Folder

Audio

To access Audio, from the standby screen, press the Left Selection Key Menu,

My folder

Buy ringtones: Allows you to buy ringtones.

Record voice: Allows you to record voice notes.

Saved audio files are displayed in the list.

, and Audio.

Pictures

To access Pictures, from the standby screen, press the Left Selection Key Menu,

My folder

Buy graphics: Allows you to buy images.

Take photo: Allows you to take a picture.

The picture files saved on your phone are displayed.

, and Pictures.

Video

To access Video, from the standby screen, press the Left Selection Key Menu,

My folder

Record video: Allows you to record a video.

The video files saved on your phone are displayed.

Note

Please note that DRM can restrict some functions, such as sending and editing.

, and Video.

Other ﬁles

When you receive files of an undefined format (such as .vcs, .vcf, etc.) via email, the files are saved in this folder.

To access Other files, from the standby screen, press the Left Selection Key

Menu, My folder files.

, and Other

The following options are available by pressing the Left Selection Key Options:

Send via: Send the selected file via Message, Email, or Bluetooth.

Delete: Allows you to delete the selected file.

Move: Allows you to move the selected file to another folder.

Copy: Allows you to copy the selected file to another folder.

Rename: Allows you to edit the name of the selected file.

Select multiple: Allows you to select multiple files at once to perform various functions.

Sort By: Allows you to sort the files by Name, Date, and Type.

File information: Allows you to view information about the selected file or used memory space on your phone.

File manager

This function allows you to view the content in your internal phone memory.

To access File manager, from the standby screen, press the Left Selection Key

Menu, My folder , and File

manager.

Tools

Voice command

Voice Command is the function whereby your phone’s voice recognition engine identifies the voice of the user and carries out the requested commands. When the user operates the Voice Command function, there are four possible commands, Call <Name or Number>, Listen voicemail, Missed calls, and Time & date. To activate the Voice Command function, hold down the Clear/Back Key

while the phone is in standby mode or

press the Left Selection Key Menu,

, and Voice command.

Tools

1 Call <Name or Number>: This function

is activated only when the user says the command “Call” followed by the name stored in the address book or say the phone number. Please note that interfering noise might cause a problem displaying candidates. Additionally, the user has the option to select a number type at the end, such as “mobile”, “home”, or “work”.

2 Listen voicemail: This command is

activated when the user says “Listen Voicemail”. The user will then be automatically connected to voicemail.

3 Missed calls: This command is activated

when the user says the words “Missed Calls”. The mobile phone presents the missed call list.

s

Follow-up Commands Available

- Yes: Make the phone call.

- No: Moves to the next result.

- Cancel: Go back to the main Voice

Command menu.

- Exit: Terminate Voice Command.

- Next: Moves to the next result.

4 Time & date: This command is activated

when the user says “Time & Date”. The phone displays the current local time and date.

Voice command Options

When the Voice Command option is activated, you can press the Left Selection Key Options for the following options:

s

Mode

- Speed: Voice Command is abbreviated.

- Normal: Voice Command is played

normally with prompts.

s

Best match

- 1 match: The most likely match will be

displayed when finding a number from the address book.

- 4 matches: The four most likely matched names will be displayed when finding a name from the address book.

s

Sensitivity

- High: Operation and performance of

the voice recognition engine is rarely affected by the user’s voice command and surrounding sound.

- Medium: Operation of the voice recognition engine is normally affected by user’s voice command and surrounding sound.

- Low: Operation of the voice recognition engine is strongly affected by user’s voice command and surrounding sound.

s

Spk. on mode

- Automatic on: When this option is

selected, the speakerphone is turned on and the sound is loud enough so you can hear the output when the phone is away from the ear, at a distance

- Off: When this option is selected, the speakerphone is turned off and the sound comes from the earpiece, which is quieter and cannot be heard when the phone is away from the ear, at a distance

s

Call alert

- Ring only: This option will not read out

the caller name. You will only hear the selected ringtone.

- Ring after name: This option will read out the caller name once, and then will ring.

- Name repeat: This option will read out the caller name continuously.

Alarm clock

The alarm clock function allows you to set up multiple separate alarms. You can also set the time, repetition interval, and alarm tone.

Tools

If there is no alarm setting, press the Left Selection Key

alarm. To access Alarm clock, from the standby

screen, press the Left Selection Key Menu, Tools

Time: Input your desired alarm time by specifying the hour and minutes.You can also choose a predefined amount of time (15 minutes later, 30 minutes later, 45 minutes later, 1 hour later, Off).

Repeat: Select the desired repeat mode (Once, Daily, Mon ~ Fri, Sat ~ Sun, Select weekday).

Alarm tone: Press the OK Key List to access the list of available Alarm

Tones.

Volume: Set the volume of the alarm by pressing the up and down Volume Keys.

Type: Select the Ring Alert Type between Ring, Vibrate, Ring & vibrate and Vibrate after ring.

Memo: Enter an alarm name.

New to add a new

, and Alarm clock.

Snooze interval: Select the snooze interval between 5 minutes, 15 minutes, 30 minutes, 45 minutes, 1 hour and Off.

Press the Left Selection Key save your new Alarm.

Save to

Calendar

When you enter this menu, a calendar will be displayed. The red square cursor is used to locate a particular day. The bottom bar on the calendar indicates saved schedules (if any) for that day. This function helps you keep track of your schedule. The phone can sound an alarm tone if it has been set for a specific schedule item.

The chart below shows the keys that can be used to navigate the Calendar:

Key

/ / /

Description

Weekly

Daily

Annually

Monthly

To access Calendar, from the standby screen, press the Left Selection Key

, and Calendar.

Tools

The following options are available when pressing the Left Selection Key

Options:

Set holiday: Allows you to set specific dates to display as Holidays on your calendar.

Week view: Allows you to view the calendar by week.

Go to date: Allows you to jump to a specific date.

Settings: Allows you to set various calendar settings.

Menu,

Notepad

You can create up to a maximum of 30 memos.

To access Notepad, from the standby screen, press the Left Selection Key

Tools

, and Notepad.

1 Press the Left Selection Key

to create a new memo.

Menu,

New

2 Input the memo and press the OK Key

Save to save.

Calculator

The Calculator function allows you to calculate simple mathematical equations.

To access Calculator, from the standby screen, press the Left Selection Key Menu, Tools

, and Calculator.

Tasks

This feature allows you to save and manage a task.

To access Tasks, from the standby screen, press the Left Selection Key Tools , and Tasks.

1 To add a new task item, press the Left

Selection Key New.

2 Input the Due Date, Note, Priority, and

Status information for the new Task.

3 Press the Left Selection Key

to save the Task item.

Menu,

Save

Tools

The following options are available in the Task list by pressing the Left Selection Key

Options:

Mark ‘Complete’: Allows you to change the status of the selected task as Completed.

Edit: Allows you to edit a saved task.

Delete: Deletes the selected task.

Selective delete: Allows you to delete All completed/All past tasks/All tasks selectively.

Send task via: Enables the selected task to be sent via Text message, Multimedia message, Email, or Bluetooth.

Select multiple: Allows you to select multiple Tasks.

View calendar: Allows you to view the Calendar.

Stopwatch

This menu allows you to record the elapsed time of an event. The duration of an individual lap time (up to 20 laps) and the total time can also be displayed.

To access Stopwatch, from the standby screen, press the Left Selection Key Menu, Tools

Show last: Displays the last time

, and Stopwatch.

recorded (only available if previous time was not reset).

New time

1 To start timing, press the OK Key

Start. The running time is displayed as

HH.MM.SS.hh (hours, minutes, seconds, hundredths of a second).

2 During the timing, you can record an

individual lap time by pressing the Right Selection Key

Lap. Up to 20 lap

times can be recorded.

3 You can stop or restart timing by pressing

the OK Key

again.

4 To reset the stop watch, press the Right

Selection Key

Reset after stopping the time, or to save the stop watch, press the Left Selection Key Options and then select Save.

Saved times: Allows you to see a list of the saved recorded times.

Tip calculator

This feature allows you to quickly and easily calculate the tip amount based on the total bill as well as the split of the total bill based on the number of people.

To access Tip calculator, from the standby screen, press the Left Selection Key Menu, Tools

1 Enter the Total bill ($), Tip (%), and

Split amounts.

2 The Tip ($) and You owe ($) amounts

will be automatically calculated.

, and Tip calculator.

Unit converter

This function allows you to convert units of measurement.

There are 6 types of units that can be converted: Area, Length, Weight, Temperature, Volume, and Velocity.

To access Unit converter, from the standby screen, press the Left Selection Key

Menu, Tools , and Unit

converter.

Voice recorder

Allows you to record an audio clip to your phone. The recorded audio file is saved automatically in the Audio menu.

To access Voice recorder, from the standby screen, press the Left Selection Key

Menu, Tools , and Voice

recorder. The following options are available when

you press the Left Selection Key Options:

Record mode: Sets the recording mode to either MMS mode or General mode.

Quality: Allows you to set the quality of an audio clip. You can set it to Fine, Normal, or Economy.

When you press the Right Selection Key

Gallery, it will take you to the Audio

gallery.

Browser

The Browser is one of the services provided by your network operator and it gives you access to all the cool things you can do with your wireless phone.

Note

Check the availability of services, pricing, and tariffs with your network operator and/or the service provider whose service you wish to use. Service providers will also give you instructions on how to use their services.

Please contact your service provider to open an Internet account.

Launch the Browser

To launch the browser from the standby screen, press the Right Selection Key

Browser or press the Left Selection

Key Menu and select the Browser

using the Navigation Keys.

To exit the browser at any time, press the End/Power Key

Using the Browser

Once you are connected to the Internet, the following menu options are available when you press the Left Selection Key Options:

Zoom: Allows you to zoom in/out for better look.

Note

You can also adjust the Browser text and image size by pressing the up and down Volume Keys to zoom in and out.

Home: Directs you to the homepage.

Enter URL: Allows you to enter URL you desire to visit.

Send link: Allows you to send the URL link in a message.

Bookmarks: You can add or save the current page to Bookmarks or view your saved Bookmarks.

Navigation mode: Allows you to select Back, Forward, and Refresh.

Search text: Allows you to search the text.

Recent pages: Allows you to view your history of recently viewed web sites.

Settings: Allows you to set options for web pages and appearance.

Menus for the Browser

You can surf the Internet using either the phone keys or the Browser menu.

Using the Navigation Keys

When surfing the Internet, the Navigation Keys function similarly from when the phone is on standby mode.

Music

You can access Music by pressing the Left Selection Key

The following options are available:

All songs: Allows you to view all the songs in your music library.

Playlists: Allows you to create your own playlists.

Artists: Shows the list of artists of all the songs in your music library, and shows all the songs by a chosen artist.

Albums: Shows the list of albums of all the songs in your music library, and shows all the songs on a chosen album.

Genres: Shows the list of genres of all the songs in your music library, and shows all songs of a specific genre.

Shuffle songs: Allows you to play all the songs in your music library in random order.

Tip!

The music player plays formats such as MP3, WMA, AAC, AAC+, 3GP, MP4, and M4A.

Menu, and Music .

Note

Music files may be protected by copyright and intellectual property laws. Please ensure that you adhere to the applicable Terms of Use of materials laws prior to downloading or copying files.

Playing Music

To listen to music that you have in your phone, follow these quick easy steps:

1 Press the Left Selection Key

Menu and Music

2 Choose from Now playing, All songs,

Playlists, Artists, Albums and Genres.

You can also choose Shuffle songs to shuffle your collection.

s

Press the OK Key Play/Pause to play and pause a selected song. While playing, press the up or down Navigation Keys to change the volume and the left or right Navigation Keys to go to the previous or next song.

s

While playing music, press the Left Selection Key Options to access

other functions while music is playing.

Adding Music To Your Phone

Music files can be added to your phone by using one or more of the following methods:

s

Download music and ringtones over the network directly to your device.

Note

Some sites are data intensive (i.e. previews via streaming) so the user should be enrolled in an unlimited data plan before using these services to avoid per-use data charges.

Additional charges may apply when downloading music, ringtones, etc.

Camera

To access Camera from the standby screen, press the Left Selection Key and select Camera

Take photo

Using the camera you can take pictures of people or events while on the move. Additionally, you can send photos to other people in a picture message.

The following options will appear (as icons) at the bottom of the screen.

Album: Allows you to see saved image and video files.

Video: Allows you to switch to Camcorder mode.

Capture: Allows you to capture the image.

Zoom: Allows you to set the zoom level.

Brightness: Allows you to set the

Brightness. Press the Left Selection Key Settings for the following options:

Preview Tab

Image size: The resolution of the image can be captured in 1M (1280*960), VGA (640*480), and QVGA (320*240).

Color effects: Allows you to choose from Off, Mono, Sepia, or Negative.

White balance: Set the White Balance as Auto, Daylight, Cloudy, Illuminate, or Indoors.

Night mode: Set Night Mode to On or Off.

Timer: Timer can be set to Off, 3 seconds, 5 seconds, or 10 seconds.

Shot mode

- Normal: This set as normal camera

mode.

- Continuous shot: This is great for taking photos of moving objects or at sporting events. The continuous shot is only available in QVGA (320*240) mode and can be set to 3, 6, or 9 shots per event.

Image quality: The quality of the captured image can be set to Super Fine, Fine, or Normal.

Others Tab

Shutter tones: You can choose from Tone 1, Tone 2, Tone 3, or Off.

Reset settings: Allows you to set the Camera to the default settings.

Using Zoom

In Camera mode, you can zoom in and out by using the up and down Volume Keys. The maximum zoom scale depends on the resolution as follows.

Resolution Zoom scale

1M (1280*960) Not Available VGA (640*480) Level 1 ~ Level 10

QVGA (320*240) Level 1 ~ Level 10

Record video

Allows you to record a video clip with your phone.

The following options will appear (as icons) at the bottom of the screen.

Album: Allows you to see saved image and video files.

Photo: Allows you to switch to the Camera function so you to take a picture.

Rec: Allows you to begin recording the video.

Zoom: Allows you to set the zoom level.

Brightness: Allows you to set the Brightness.

Press the Left Selection Key

Settings for the following options:

Preview Tab

Color effects: Allows you to choose from Off, Mono, Sepia, or Negative.

White balance: Set the White Balance as Auto, Daylight, Cloudy, Illuminate, or Indoors.

Camera

Video quality: Allows you to set video quality to Super Fine, Fine, or Normal.

Duration: Set the recording duration to General mode or MMS video mode.

Others Tab

Recording tones: Allows you to set Recording tones to On or Off.

Reset settings: Allows you to set the Camcorder to the default settings.

Note

In Video mode, you can adjust the zoom scale by using the up and down Volume Keys. The zoom scale ranges from Level 1 to Level 9.

Camera album

Allows you to view the pictures and videos that are captured with the camera.

To access Camera album, from the standby screen, press the Left Selection Key

Menu, Camera album.

When a file is highlighted, the following options are available when you press the Left Selection Key

For image file:

Use as/Send via/Print via bluetooth/ Delete/Rename/Select multiple/File information.

For video file:

Send via/Delete/Rename/Select multiple/File information

, and Camera

Options:

Settings

Audio & ringtones

This menu allows you to configure the audio and ringtone settings for your phone. To access Audio & ringtones, from the standby screen, press the Left Selection Key

Menu, Settings , and

Audio & ringtones.

Ringtone

Sounds: Allows you to set a sound as the ringtone for your phone.

Volume: Allows you to control your ringtone volume.

Alert Type: Supports 3 ring alert types: Ring, Ring and vibration, and Ring after vibration.

Increasing ringtone: Allows you to enable or disable the Increasing Ringtone function, which is played when you receive an incoming call.

Note

Full length music tracks cannot be set as either ringtones or message tones.

Message tone

Sounds: Allows you to set a sound as your message tone.

Volume: Allows you to control your Message tone volume.

Alert type: Supports 4 message alert types: Silent, Vibrate, Ring only, Ring & vibrate.

Alert interval: Allows you to set the interval alert to Once, Every 2 min, Every 5 min, Every 10 min, or Every 15 min.

Alert tone

Sounds: Allows you to select a set of alert tones. Supports 2 alert tone types: Alert tone 1 and Alert tone 2.

Volume: This menu allows you to control your Alert tone volume.

Alert type: You can select to turn Alert tones to Ring or Silent.

Settings

Keypad tone

Sounds: Allows you to select a tone that the phone sounds when a key is pressed on the dialpad. You can select an option from Beep and Voice.

Volume: Allows you to control your Keypad tone volume.

Multimedia

This menu allows you to control your Multimedia volume.

Call

This menu allows you to control your Call volume.

Phone settings

This menu allows you to configure the Phone settings. To access Phone settings, from the standby screen, press the Left Selection Key

Menu, Settings , and

Phone settings.

Languages

Allows you to change the language for the display text on your phone. This change will also affect the Language Input mode.

Set hotkeys

Allows you to change the preferences on the Hotkeys that are currently assigned for your Navigation Keys (when in standby mode).

Airplane mode

This allows you to only use the phone’s features that do not require the use of the wireless network, excluding emergency calls, when you are in an airplane or in places where the wireless network is prohibited. If you set the Airplane mode on, the Airplane mode icon will be displayed on the screen instead of the network signal icon.

On: You cannot make (or receive) calls, excluding emergency calls, or use other features that require network coverage.

Off: You can deactivate the Airplane mode to access the network.

Security

Various codes and passwords are used to protect the features and settings of your phone.

Phone lock: You can use a security code to avoid unauthorized use of the phone. If you set the Phone Lock to When power on, the phone will request a security code whenever you switch the phone on. If you set the Phone Lock to Lock phone now, your phone will lock immediately.

Change codes: The Change Codes feature allows you to change your current password to a new one. You must enter the current password before you can specify a new one. You can change the access codes for: Security code.

Reset settings

This function allows you to restore factory settings. To do this, you need the security code.

Master reset: Restores the phone settings (e.g.: Audio, Display, Language, Bluetooth Settings) to default values.

Master clear: Deletes downloaded/user created contents (e.g.: images, videos) from the phone.

s

Phone

- Deletes all downloaded/user created

images and audios from the phone memory.

- Deletes personal information stored in the phone memory (e.g.: Contacts, Messages, Tasks, Alarm, Calendar Schedules).

- Restores the settings stored in the phone memory to the default values.

Settings

Display

This menu allows you to configure your Display settings. To access Display, from the standby screen, press the Left Selection Key Menu,

Settings

Wallpapers

This menu allows you to set a picture or color as your background.

Fonts

You can configure the font size and color of the font that your phone uses.

Clocks & calendar

This feature allows you to select a Clock or Calendar to display on the standby screen.

Brightness

You can set the brightness of the display screen.

, and Display.

Backlight timer

Use this to set the duration of the display backlight and keypad.

Menu styles

You can set the main menu style to Icon or List view.

Call

This menu allows you to configure your Call settings. To access Call, from the standby screen, press the Left Selection Key Menu,

Settings

Send my number

This network service allows you to set your phone number to be displayed or hidden from the person you are calling. You can select Set by network if you prefer to have different settings for different service providers.

, and Call.

Answer mode

This allows you to determine how to answer the phone.

Any key: Allows you to answer an incoming call by pressing any key, except the End/Power Key , Volume Keys, or the Right Selection Key .

Send key only: Allows you to only answer an incoming call by pressing the Send Key or Left Selection Key

Accept.

Flip open: Allows you to flip open the phone to answer an incoming call.

Senior mode

Senior mode is a function that amplifies a sound for seniors to hear the voice well by emphasizing a low voice. It is used for enhancing the speech quality while you are on the phone. You can set the Senior mode to On or Off.

Connection vibration

Allows you to choose if you want the phone to vibrate when a connection is established.

Call duration

Allows you to view Call duration information about Last call, Dialed calls, Received calls and All calls.

Accessibility

This menu allows you to easily control various accessibility options.

To access Accessibility, from the standby screen, press the Left Selection Key

Menu, Settings , and

Accessibility.

Menu readout

This option allows the phone to read out menus that are accessed.

Settings

Keypad tone

Sounds: Allows you to select a tone that the phone sounds when a key is pressed on the dialpad. You can select an option from Beep and Voice.

Volume: Allows you to control your Keypad tone volume.

Large text

Allows you to set a large size for text. Select from On or Off.

Invert color

Allows you to set the color contrast for better screen viewing. Select from On or Off.

Mono sound

Allows you to enable or disable the Mono sound function.

Senior mode

Allows you to turn the senior mode on or off. Senior mode enhances high frequencies to reduce the effects of hearing loss.

TTY

Allows you to enable TTY Mode in order to contact other TTY devices. Select from TTY

full, TTY talk, TTY hear, or TTY off.

Hearing aid

Allows you to enable or disable the Hearing aid function.

Voice command

Allows you to set the Voice command options. Refer to page 34.

Bluetooth

Your phone has built-in Bluetooth wireless technology, which makes it possible for you to connect your phone wirelessly to other Bluetooth devices such as a handsfree device, PC, laptop, or other phones. The devices registered in your phone can only be connected one at a time (To make a connection to the same type of device or change Bluetooth preferences, disconnect the existing device first).

You can also exchange, for example, business cards, calendar items, and pictures.

To access Bluetooth, from the standby screen, press the Left Selection Key Menu, Settings

, and Bluetooth.

Turn on/off

Allows you to turn your Bluetooth functionality on or off.

Search new device

This function allows you to search for and add new devices.

My devices

This function allows you to view the list of all devices that are paired with your phone.

My bluetooth info

This menu allows you to configure the profile for Bluetooth.

My device visibility: Allows you to set your device to be visible to other Bluetooth devices.

Device name: Allows you to change the phone’s name which can be seen by other Bluetooth devices.

Supported services: Shows you all services that the phone supports.

My bluetooth address: Displays your device’s Bluetooth address.

To pair with another device 1 From the standby screen, press the Left

Selection Key

, Bluetooth, and Search

new device.

2 If you want to stop searching, press the

Right Selection Key

3 All of the devices found are displayed. 4 Select the desired device by pressing

the OK Key password.

Menu, Settings

Cancel.

Add and entering the

Settings

Memory

This menu allows you to configure your Memory settings. To access Memory, from the standby screen, press the Left Selection Key Menu,

Settings

Used space

This function shows the memory status of the phone.

, and Memory.

Phone common This function shows the memory status of the phone and the memory being used by Audio, Pictures, Video, Multimedia msg, Email, Java, and Others types of files.

Phone reserved

This function shows the status of the reserved memory used by Text message, Contacts, Calendar, Tasks, and the Notepad.

SIM card

This function shows the status of the SIM card memory.

Applications

This menu allows you to configure application settings To access Applications, from the standby screen, press the Left Selection Key

Menu, Settings , and

Applications.

Messages

This option allows you to configure the Messaging option.

For more details, refer to Message settings on page 27.

Browser

This menu allows you to configure the Browser settings.

Appe

arance

You can choose the settings of the browser appearance (Text size, Character encoding, Show image, Java script).

Cache

The web pages you have accessed are stored in the phone memory. This menu allows you to manage that function.

Clear cache: Remove all cached data in the memory.

Cache: Allows you to turn the memory cache on or off.

Note

Cache is a type of buffer memory, which is used to store data temporarily, especially when it is online.

The information of services you have accessed are stored in what is called a cookie. From this menu, you can choose to allow cookies or to delete cookies that are already on your phone.

Clear login info.

You can delete the history of ID or Password information that you have saved previously.

Screen settings

You can change the settings of the browser screen (Rendering mode).

Security

A list of the available certificates is shown.

Certificates: You can see the list of certificates and view them in detail.

Clear session: Removes the secure session.

Navigation mode

You can change the methods of browser navigation.

4 way navigation: The cursor of the browser moves scroll amounts or follows hyperlinks.

Mouse pointer: You can move the cursor like a mouse pointer.

Settings

Secure popup

You can activate or deactivate the pop-up which indicates a secure page.

Shortcuts

If set to On, you can use the Browser more quickly and conveniently with the keypad in the phone. If Shortcuts is on, the following shortcuts are available:

1. Enter URL

3. View Bookmarks

5. Full Screen

7. Page Up

9. Zoom In *. Page Down

You can adjust the Browser text and image size by pressing the up and down Volume Keys to zoom in and out.

2. This Page

4. Info.

6. Saved Pages

8. Recent Pages

0. Search Text #. Zoom Out

Phone information

This menu is used to view My number, Manufacturer, Model name, Device ID, Hardware version, Software version, Language.

To access Phone Information, from the standby screen, press the Left Selection Key

Menu, Settings , and

Phone information.

Accessories

There are a variety of accessories available for your mobile phone, some of which may be sold separately. You can select these options according to your personal communication requirements. Consult your local dealer for availability.

Travel Adapter

This adapter allows you to charge the battery.

Battery

Standard battery is available.

Note

t"MXBZTVTFHFOVJOF-(BDDFTTPSJFT'BJMure to do this may invalidate your warranty. t"DDFTTPSJFTNBZCFEJGGFSFOUJOEJGGFSFOUSFHJPOTQMFBTFDIFDLXJUIPVSSFHJPOBMTFSWJDF

company or agent for further enquiries.

Open Source Software Notice Information

To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product, please visit http://opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com. This offer is valid for three (3) years from the date on which you purchased the product.

For Your Safety

WARNING! This product contains chemicals

known to the State of California to cause cancer and birth defects or reproductive harm.

Wash hands after handling.

Important Information

This user guide contains important information on the use and operation of this phone. Please read all the information carefully for optimal performance and to prevent any damage to or misuse of the phone. Any changes or modifications not expressly approved in this user guide could void your warranty for this equipment. Any changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.

Before You Start

Safety Instructions

WARNING! To reduce the possibility of electric shock, do not expose your phone to high humidity areas, such as the bathroom, swimming pool, etc.

Always store your phone away from heat. Never store your phone in settings

that may expose it to temperatures less than 32°F (0°C) or greater than 113°F (45°C), such as outside during extreme weather conditions or in your car on a hot day. Exposure to excessive cold or heat will result in malfunction, damage and/or catastrophic failure.

Be careful when using your phone near other electronic devices. RF emissions

from your mobile phone may affect nearby in adequately shielded electronic equipment. You should consult with manufacturers of any personal medical devices such as pacemakers and hearing aides to determine if they are susceptible to interference from your mobile phone. Turn off your phone in a medical facility or at a gas station. Never place your phone in a microwave oven as this will cause the battery to explode.

Safety Information

Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this user guide.

Do not disassemble this unit. Take it to a qualified service technician when repair work is required.

Keep away from electrical appliances such as TVs, radios, and personal computers.

The unit should be kept away from heat sources such as radiators or cookers.

Do not drop.

Do not subject this unit to mechanical vibration or shock.

The coating of the phone may be damaged if covered with wrap or vinyl wrapper.

Use dry cloth to clean the exterior of the unit. (Do not use solvent such as benzene, thinner or alcohol.)

Do not subject this unit to excessive smoke or dust.

Do not keep the phone next to credit cards or transport tickets; it can affect the information on the magnetic strips.

Do not tap the screen with a sharp object; otherwise, it may damage the phone.

Do not expose the phone to liquid or moisture.

Use the accessories like an earphone cautiously. Do not touch the antenna unnecessarily.

Memory card information and care

The memory card cannot be used for recording copyright- protected data.

Keep the memory card out of the small children’s reach.

Do not leave the memory card in extremely hot location.

Do not disassemble or modify the memory card.

For Your Safety

FCC RF Exposure Information

WARNING! Read this information before operating the phone.

In August 1996, the Federal Communications Commission (FCC) of the United States, with its action in Report and Order FCC 96-326, adopted an updated safety standard for human exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies.

The design of this phone complies with the FCC guidelines and these international standards.

CAUTION

Use only the supplied and approved antenna. Use of unauthorized antennas or modifications could impair call quality, damage the phone, void your warranty and/ or result in violation of FCC regulations. Do not use the phone with a damaged antenna.

If a damaged antenna comes into contact with skin, a minor burn may result. Contact your local dealer for a replacement antenna.

Body-worn Operation

This device was tested for typical body-worn operations with the back of the phone kept

1.5cm (0.59 inches) between the user’s body and the back of the phone. To comply with FCC RF exposure requirements, a minimum separation distance of 1.5cm (0.59 inches) must be maintained between the user’s body and the back of the phone. Any belt-clips, holsters, and similar accessories containing metallic components may not be used. Body-worn accessories that cannot maintain 1.5cm (0.59 inches) separation distance between the user’s body and the back of the phone, and have not been tested for typical body-worn operations may not comply with FCC RF exposure limits and should be avoided.

Part 15.19 statement

This device complies with part15 of FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

Part 15.21 statement

Changes or modifications that are not expressly approved by the manufacturer could void the user’s authority to operate the equipment.

Part 15.105 statement

This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

For Your Safety

Cautions for Battery

Do not disassemble or open crush, bend or deform, puncture or shred.

Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water or other liquids, expose to fire, explosion or other hazard.

Only use the battery for the system for which it is specified.

Only use the battery with a charging system that has been qualified with the system per this standard. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.

Do not short circuit a battery or allow metallic conductive objects to contact battery terminals.

Promptly dispose of used batteries in accordance with local regulations.

Battery usage by children should be supervised.

Avoid dropping the phone or battery. If the phone or battery is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection.

Improper battery use may result in a fire, explosion or other hazard.

For those host devices that utilize a USB port as a charging source, the host device’s user manual shall include a statement that the phone shall only be connected to products that bear the USBIF logo or have completed the USB-IF compliance program.

Adapter (Charger) Cautions

Using the wrong battery charger could damage your phone and void your warranty.

The adapter or battery charger is intended for indoor use only.

Do not expose the adapter or battery charger to direct sunlight or use it in places with high humidity, such as the bathroom.

Avoid damage to your hearing

Damage to your hearing can occur if you are exposed to loud sound for long periods of time. We therefore recommend that you do not turn on or off the handset close to your ear. We also recommend that music and call volumes are set to a reasonable level.

If you are listening to music while out and about, please ensure that the volume is at a reasonable level so that you are aware of your surroundings. This is particularly imperative when attempting to cross the street.

Safety Guidelines

TIA Safety Information

Provided herein is the complete TIA Safety Information for Wireless Handheld phones. Inclusion of the text covering Pacemakers, Hearing Aids, and Other Medical Devices is required in the owner’s manual for CTIA Certification. Use of the remaining TIA language is encouraged when appropriate.

Exposure to Radio Frequency Signal

Your wireless handheld portable telephone is a lowpower radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.

In August, 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S. and international standards bodies:

ANSI C95.1 (1992) * NCRP Report 86 (1986)

ICNIRP (1996) Those standards were based on

comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C95.1).

* American National Standards Institute;

National Council on Radiation Protection and Measurements; International Commission on Non-Ionizing Radiation Protection

The design of your phone complies with the FCC guidelines (and those standards).

Antenna Care

Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone and may violate FCC regulations.

Phone Operation

NORMAL POSITION: Hold the phone as you would any other telephone with the phone held upright.

Tips on Efficient Operation

For your phone to operate most efficiently:

Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.

Driving

Check the laws and regulations on the use of wireless phones in the areas where you drive. Always obey them. Also, if using your phone while driving, please:

Give full attention to driving - driving safely is your first responsibility;

Use hands-free operation, if available;

Pull off the road and park before making or answering a call if driving conditions so require.

Electronic Devices

Most modern electronic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.

Pacemakers

The Health Industry Manufacturers Association recommends that a minimum separation of 15cm (6 inches) be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research.

Persons with pacemakers:

Should ALWAYS keep the phone more than 15cm (6 inches) from their pacemaker when the phone is turned ON;

Should not carry the phone in a breast pocket.

Safety Guidelines

Should use the ear opposite the pacemaker to minimize the potential for interference.

If you have any reason to suspect that interference is taking place, turn your phone OFF immediately.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives).

HAC

This phone has been tested and rated for use with hearing aids for some of the wireless technologies that it uses. However, there may be some newer wireless technologies used in this phone that have not been tested yet for use with hearing aids. It is important to try the different features of this phone thoroughly and in different locations, using your hearing aid or cochlear implant, to determine if you hear

any interfering noise. Consult your service provider or the manufacturer of this phone for information on hearing aid compatibility. If you have questions about return or exchange policies, consult your service provider or phone retailer.

Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Health Care Facilities

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may use equipment that could be sensitive to external RF energy.

Vehicles

RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle.

You should also consult the manufacturer of any equipment that has been added to your vehicle.

Posted Facilities

Turn your phone OFF in any facility where posted notices so require.

Aircraft

FCC regulations prohibit using your phone while in the air. Turn your phone OFF before boarding an aircraft.

Blasting Areas

To avoid interfering with blasting operations, turn your phone OFF when in a ‘blasting areas or in areas posted: ‘Turn off two-way radio’. Obey all signs and instructions.

Potentially Explosive Atmosphere

Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Areas with a potentially explosive atmosphere are often, but not always, marked clearly. Potential areas may include: fueling areas (such as gasoline stations); below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles (such as grain, dust, or metal powders); and any other area where you would normally be advised to turn off your vehicle engine.

For Vehicles Equipped with an Air Bag

An air bag inflates with great force. DO NOT place objects, including either installed or portable wireless equipment, in the area over the air bag or in the air bag deployment

Safety Guidelines

area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.

Safety Information

Please read and observe the following information for safe and proper use of your phone and to prevent damage. Also, keep the user guide in an accessible place at all the times after reading it.

Do not disassemble or open crush, bend or deform, puncture or shred.

Do not modify or remanufacture, attempt to insert foreign objects into the battery, immerse or expose to water or other liquids, expose to fire, explosion or other hazard.

Only use the battery for the system for which it is specified.

Only use the battery with a charging system that has been qualified with the system per CTIA Certification Requirements for Battery System Compliance to IEEE1725. Use of an

unqualified battery or charger may present a risk of fire, explosion, leakage, or other hazard.

Do not short circuit a battery or allow metallic conductive objects to contact battery terminals.

Replace the battery only with another battery that has been qualified with the system per this standard, IEEE-Std-1725. Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard.

Promptly dispose of used batteries in accordance with local regulations.

Battery usage by children should be supervised.

Avoid dropping the phone or battery. If the phone or battery is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection.

Improper battery use may result in a fire, explosion or other hazard.

The phone shall only be connected to USB products that bear the USB-IF logo or have completed the USB-IF compliance program.

Charger and Adapter Safety

The charger and adapter are intended for indoor use only.

Battery Information and Care

Please dispose of your battery properly or take it to your local wireless carrier for recycling.

The battery does not need to be fully discharged before recharging.

Use only LG-approved chargers specific to your phone model since they are designed to maximize battery life.

Do not disassemble or impact the battery as it may cause electric shock, shortcircuit, and fire. Store the battery in a place out of reach of children.

Keep the battery’s metal contacts clean.

Replace the battery when it no longer provides acceptable performance. The battery can be recharged several hundred times before replacement.

Recharge the battery after long periods of non-use to maximize battery life.

Battery life will vary due to usage patterns and environmental conditions.

Use of extended backlighting, Mobile Web Browsing, and data connectivity kits affect battery life and talk/standby times.

The self-protection function of the battery cuts the power of the phone when its operation is in an abnormal state. In this case, remove the battery from the phone, reinstall it, and turn the phone on.

Actual battery life will depend on network configuration, product settings, usage patterns, battery and environmental conditions.

Always unplug the charger from the wall socket after the phone is fully charged to save unnecessary power consumption of the charger.

Safety Guidelines

Explosion, Shock, and Fire Hazards

Do not put your phone in a place subject to excessive dust and keep the minimum required distance between the power cord and heat sources.

Unplug the power cord prior to cleaning your phone, and clean the power plug pin when it is dirty.

When using the power plug, ensure that it is firmly connected. If it is not, it may cause excessive heat or fire.

If you put your phone in a pocket or bag without covering the receptacle of the phone (power plug pin), metallic articles (such as a coin, paperclip or pen) may short-circuit the phone. Always cover the receptacle when not in use.

Do not short-circuit the battery. Metallic articles such as a coin, paperclip or pen in your pocket or bag may short-circuit the + and – terminals of the battery (metal strips on the battery) upon moving. Short-circuit of the terminal may damage the battery and cause an explosion.

General Notice

Using a damaged battery or placing a battery in your mouth may cause serious injury.

Do not place items containing magnetic components such as a credit card, phone card, bank book or subway ticket near your phone. The magnetism of the phone may damage the data stored in the magnetic strip.

Talking on your phone for a long period of time may reduce call quality due to heat generated during use.

When the phone is not used for a long period time, store it in a safe place with the power cord unplugged.

Using the phone in proximity to receiving equipment (i.e., TV or radio) may cause interference to the phone.

Do not use the phone if the antenna is damaged. If a damaged antenna contacts skin, it may cause a slight burn. Please contact an LG Authorized Service Centre to replace the damaged antenna.

Do not immerse your phone in water. If this happens, turn it off immediately and remove the battery. If the phone does not work, take it to an LG Authorized Service Centre.

Do not paint your phone.

The data saved in your phone might be deleted due to careless use, repair of the phone, or upgrade of the software. Please backup your important phone numbers. (Ring tones, text messages, voice messages, pictures, and videos could also be deleted.) The manufacturer is not liable for damage due to the loss of data.

When you use the phone in public places, set the ring tone to vibration so as not to disturb others.

Do not turn your phone on or off when putting it in your ear.

FDA Consumer Update

The U.S. Food and Drug Administration Centre for Devices and Radiological Health Consumer Update on Mobile Phones.

1. Do wireless phones pose a health hazard?

The available scientific evidence does

not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of radiofrequency energy (RF) in the microwave range while being used. They also emit very low levels of RF when in the standby mode. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but such findings have not been confirmed by additional research. In some cases, other researchers have had difficulty in reproducing those studies, or in determining the reasons for inconsistent results.

Safety Guidelines

2. What is the FDA’s role concerning the safety of wireless phones?

Under the law, the FDA does not review

the safety of radiation-emitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit radiofrequency energy (RF) at a level that is hazardous to the user. In such a case, the FDA could require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace, or recall the phones so that the hazard no longer exists.

Although the existing scientific data do

not justify FDA regulatory actions, the FDA has urged the wireless phone industry to take a number of steps, including the following:

Support needed research into possible biological effects of RF of the type emitted by wireless phones;

Design wireless phones in a way that minimizes any RF exposure to the user that is not necessary for device function; and

Cooperate in providing users of wireless phones with the best possible information on possible effects of wireless phone use on human health.

The FDA belongs to an interagency

working group of the federal agencies that have responsibility for different aspects of RF safety to ensure coordinated efforts at the federal level. The following agencies belong to this working group:

National Institute for Occupational Safety and Health

Environmental Protection Agency

Occupational Safety and Health Administration (Administración de la seguridad y salud laborales)

Occupational Safety and Health Administration

National Telecommunications and Information Administration

The National Institutes of Health participates in some interagency working group activities, as well.

The FDA shares regulatory responsibilities

for wireless phones with the Federal Communications Commission (FCC). All phones that are sold in the United States must comply with FCC safety guidelines that limit RF exposure. The FCC relies on the FDA and other health agencies for safety questions about wireless phones.

The FCC also regulates the base stations

that the wireless phone networks rely upon. While these base stations operate at higher power than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower than those they can get from wireless phones. Base stations are thus not the subject of the safety questions discussed in this document.

3. What kinds of phones are the subject of this update?

The term ‘wireless phone’ refers here

to handheld wireless phones with built-in antennas, often called ‘cell’, ‘mobile’, or ‘PCS’ phones. These types of wireless phones can expose the user to measurable radiofrequency energy (RF) because of the short distance between the phone and the user’s head. These RF exposures are limited by FCC safety guidelines that were developed with the advice of the FDA and other federal health and safety agencies. When the phone is located at greater distances from the user, the exposure to RF is drastically lower because a person’s RF exposure decreases rapidly with increasing distance from the source. The so-called ‘cordless phones’, which have a base unit connected to the telephone wiring in a house, typically operate at far lower power levels, and thus produce RF exposures far below the FCC safety limits.

Safety Guidelines

4. What are the results of the research done already?

The research done thus far has produced

conflicting results, and many studies have suffered from flaws in their research methods. Animal experiments investigating the effects of radiofrequency energy (RF) exposures characteristic of wireless phones have yielded conflicting results that often cannot be repeated in other laboratories. A few animal studies, however, have suggested that low levels of RF could accelerate the development of cancer in laboratory animals. However, many of the studies that showed increased tumor development used animals that had been genetically engineered or treated with cancer causing chemicals so as to be pre-disposed to develop cancer in the absence of RF exposure. Other studies exposed the animals to RF for up to 22 hours per day.

These conditions are not similar to the

conditions under which people use wireless phones, so we don’t know with certainty what the results of such studies

mean for human health. Three large epidemiology studies have been published since December 2000. Between them, the studies investigated any possible association between the use of wireless phones and primary brain cancer, glioma, meningioma, or acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the studies demonstrated the existence of any harmful health effects from wireless phone RF exposures. However, none of the studies can answer questions about long-term exposures, since the average period of phone use in these studies was around three years.

5. What research is needed to decide whether RF exposure from wireless phones poses a health risk?

A combination of laboratory studies

and epidemiological studies of people actually using wireless phones would provide some of the data that are needed. Lifetime animal exposure studies could be completed in a few years. However,

very large numbers of animals would be needed to provide reliable proof of a cancer promoting effect if one exists. Epidemiological studies can provide data that is directly applicable to human populations, but 10 or more years follow-up may be needed to provide answers about some health effects, such as cancer. This is because the interval between the time of exposure to a cancer-causing agent and the time tumors develop - if they do- may be many, many years. The interpretation of epidemiological studies is hampered by difficulties in measuring actual RF exposure during day-to-day use of wireless phones. Many factors affect this measurement, such as the angle at which the phone is held, or which model of phone is used.

6. What is the FDA doing to find out more about the possible health effects of wireless phone RF?

The FDA is working with the U.S. National

Toxicology Program and with groups

of investigators around the world to ensure that high priority animal studies are conducted to address important questions about the effects of exposure to radiofrequency energy (RF). The FDA has been a leading participant in the World Health Organization International Electromagnetic Fields (EMF) Project since its inception in 1996. An influential result of this work has been the development of a detailed agenda of research needs that has driven the establishment of new research programs around the world. The project has also helped develop a series of public information documents on EMF issues. The FDA and the Cellular Telecommunications & Internet Association (CTIA) have a formal Cooperative Research and Development Agreement (CRADA) to do research on wireless phone safety. The FDA provides the scientific oversight, obtaining input from experts in government, industry, and academic organizations. CTIA-funded research is conducted through contracts with independent investigators. The initial

Safety Guidelines

research will include both laboratory studies and studies of wireless phone users. The CRADA will also include a broad assessment of additional research needs in the context of the latest research developments around the world.

7. How can I find out how much radio frequency energy exposure I can get by using my wireless phone?

All phones sold in the United States must

comply with Federal Communications Commission (FCC) guidelines that limit radio frequency energy (RF) exposures. The FCC established these guidelines in consultation with the FDA and the other federal health and safety agencies. The FCC limit for RF exposure from wireless telephones is set at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC limit is consistent with the safety standards developed by the Institute of Electrical and Electronic Engineering (IEEE) and the National Council on Radiation Protection and Measurement. The exposure limit

takes into consideration the body’s ability to remove heat from the tissues that absorb energy from the wireless phone and is set well below levels known to have effects. Manufacturers of wireless phones must report the RF exposure level for each model of phone to the FCC. The FCC website (http://www.fcc. gov/) gives directions for locating the FCC identification number on your phone so you can find your phone’s RF exposure level in the online listing.

8. What has the FDA done to measure the radio frequency energy coming from wireless phones?

The Institute of Electrical and Electronic

Engineers (IEEE) is developing a technical standard for measuring the radio frequency energy (RF) exposure from wireless phones and other wireless handsets with the participation and leadership of FDA scientists and engineers. The standard, ‘Recommended Practice for Determining the SpatialPeak Specific Absorption Rate (SAR)

in the Human Body Due to Wireless Communications Devices: Experimental Techniques’, sets forth the first consistent test methodology for measuring the rate at which RF is deposited in the heads of wireless phone users. The test method uses a tissuesimulating model of the human head. Standardized SAR test methodology is expected to greatly improve the consistency of measurements made at different laboratories on the same phone. SAR is the measurement of the amount of energy absorbed in tissue, either by the whole body or a small part of the body. It is measured in watts/kg (or milliwatts/g) of matter. This measurement is used to determine whether a wireless phone complies with safety guidelines.

9. What steps can I take to reduce my exposure to radiofrequency energy from my wireless phone?

If there is a risk from these products -

and at this point we do not know that there is - it is probably very small. But if you are concerned about avoiding

even potential risks, you can take a few simple steps to minimize your exposure to radiofrequency energy (RF). Since time is a key factor in how much exposure a person receives, reducing the amount of time spent using a wireless phone will reduce RF exposure. If you must conduct extended conversations by wireless phone every day, you could place more distance between your body and the source of the RF, since the exposure level drops off dramatically with distance. For example, you could use a headset and carry the wireless phone away from your body or use a wireless phone connected to a remote antenna. Again, the scientific data do not demonstrate that wireless phones are harmful. But if you are concerned about the RF exposure from these products, you can use measures like those described above to reduce your RF exposure from wireless phone use.

Safety Guidelines

10. What about children using wireless phones?

The scientific evidence does not show

a danger to users of wireless phones, including children and teenagers. If you want to take steps to lower exposure to radiofrequency energy (RF), the measures described above would apply to children and teenagers using wireless phones. Reducing the time of wireless phone use and increasing the distance between the user and the RF source will reduce RF exposure. Some groups sponsored by other national governments have advised that children be discouraged from using wireless phones at all. For example, the government in the United Kingdom distributed leaflets containing such a recommendation in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their recommendation to limit wireless phone use by children was strictly precautionary; it was not based on scientific evidence that any health hazard exists.

11. What about wireless phone interference with medical equipment?

Radio frequency energy (RF) from

wireless phones can interact with some electronic devices. For this reason, the FDA helped develop a detailed test method to measure electromagnetic interference (EMI) of implanted cardiac pacemakers and defibrillators from wireless telephones. This test method is now part of a standard sponsored by the Association for the Advancement of Medical instrumentation (AAMI). The final draft, a joint effort by the FDA, medical device manufacturers, and many other groups, was completed in late 2000. This standard will allow manufacturers to ensure that cardiac pacemakers and defibrillators are safe from wireless phone EMI. The FDA has tested hearing aids for interference from handheld wireless phones and helped develop a voluntary standard sponsored by the Institute of Electrical and Electronic Engineers (IEEE). This standard specifies test methods and

performance requirements for hearing aids and wireless phones so that no interference occurs when a person uses a ‘compatible’ phone and a ‘compatible’ hearing aid at the same time. This standard was approved by the IEEE in

2000. The FDA continues to monitor the use of wireless phones for possible interactions with other medical devices. Should harmful interference be found to occur, the FDA will conduct testing to assess the interference and work to resolve the problem.

12. Where can I find additional information?

For additional information, please refer to the following resources:

FDA web page on wireless phones (http://www.fda.gov/ Radiation-EmittingProducts/ RadiationEmittingProductsandProcedures/ HomeBusinessandEntertainment/CellPhones/ default.htm)

Federal Communications Commission (FCC) RF Safety Program

(http://www.fcc.gov/oet/rfsafety) International Commission on Non-lonizing

Radiation Protection (http://www.icnirp.de)

World Health Organization (WHO) International EMF Project (http://www.who.int/peh-emf/project/es)

National Radiological Protection Board (UK) (http://www.nrpb.org.uk/radiation)

10 Driver Safety Tips

Your wireless phone gives you the powerful ability to communicate by voice almost anywhere, anytime. An important responsibility accompanies the benefits of wireless phones, one that every user must uphold.

When operating a car, driving is your first responsibility.

When using your wireless phone behind the wheel of a car, practice good common sense and remember the following tips:

1 Get to know your wireless phone and its

features such as speed dial and redial. Carefully read your instruction manual

Safety Guidelines

and learn to take advantage of valuable features most phones offer, including automatic redial and memory. Also, work to memorize the phone keypad so you can use the speed dial function without taking your attention off the road.

2 When available, use a hands-free device.

A number of hands-free wireless phone accessories are readily available today. Whether you choose an installed mounted device for your wireless phone or a speaker phone accessory, take advantage of these devices if available to you.

3 Position your wireless phone within easy

reach. Make sure you place your wireless phone within easy reach and where you can reach it without removing your eyes from the road. If you get an incoming call at an inconvenient time, if possible, let your voicemail answer it for you.

4 Suspend conversations during hazardous

driving conditions or situations. Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather

conditions. Rain, sleet, snow and ice can be hazardous, but so is heavy traffic. As a driver, your first responsibility is to pay attention to the road.

5 Do not take notes or look up phone

numbers while driving. If you are reading an address book or business card, or writing a “to-do” list while driving a car, you are not watching where you are going. It is common sense. Don’t get caught in a dangerous situation because you are reading or writing and not paying attention to the road or nearby vehicles.

6 Dial sensibly and assess the traffic; if

possible, place calls when you are not moving or before pulling into traffic. Try to plan your calls before you begin your trip or attempt to coincide your calls with times you may be stopped at a stop sign, red light or otherwise stationary. But if you need to dial while driving, follow this simple tip— dial only a few numbers, check the road and your mirrors, then continue.

7 Do not engage in stressful or emotional

conversations that may be distracting. Stressful or emotional conversations and driving do not mix; they are distracting and even dangerous when you are behind the wheel of a car. Make people you are talking with aware you are driving and if necessary, suspend conversations which have the potential to divert your attention from the road.

8 Use your wireless phone to call for help.

Your wireless phone is one of the greatest tools you can own to protect yourself and your family in dangerous situations — with your phone at your side, help is only three numbers away. Dial 911 or other local emergency number in the case of fire, traffic accident, road hazard or medical emergency. Remember, it is a free call on your wireless phone!

9 Use your wireless phone to help others

in emergencies. Your wireless phone provides you a perfect opportunity to be a “Good Samaritan” in your community. If you see an auto accident, crime in

progress or other serious emergency where lives are in danger, call 911 or other local emergency number, as you would want others to do for you.

10 Call roadside assistance or a special

wireless non-emergency assistance number when necessary. Certain situations you encounter while driving may require attention, but are not urgent enough to merit a call for emergency services. But you can still use your wireless phone to lend a hand. If you see a broken-down vehicle posing no serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured or a vehicle. you know to be stolen, call roadside assistance or other special non-emergency wireless number.

For more information, please call to 888901-SAFE, or visit our website www.ctia.org.

Safety Guidelines

Consumer Information on SAR (Speciﬁc Absorption Rate)

This Model Phone Meets the Government’s Requirements for Exposure to Radio Waves.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission (FCC) of the U.S. Government. These FCC exposure limits are derived from the recommendations of two expert organizations, the National Counsel on Radiation Protection and Measurement (NCRP) and the Institute of Electrical and Electronics Engineers (IEEE). In both cases, the recommendations were developed by scientific and engineering experts drawn from industry, government, and academia after extensive reviews of the scientific literature related to the biological effects of RF energy. The exposure limit for wireless mobile phones employs a unit of measurement known as the Specific

Absorption Rate, or SAR. The SAR is a measure of the rate of absorption of RF energy by the human body expressed in units of watts per kilogram (W/kg). The FCC requires wireless phones to comply with a safety limit of 1.6 watts per kilogram (1.6 W/kg). The FCC exposure limit incorporates a substantial margin of safety to give additional protection to the public and to account for any variations in measurements. Tests for SAR are conducted using standard operating positions specified by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. Because the phone is designed to operate at multiple power levels to use only the power required to reach the network, in general, the closer you are to a wireless base station antenna, the lower the power output.

Before a phone model is available for sale to the public, it must be tested and certified to the FCC that it does not exceed the limit

established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF emission guidelines.

The highest SAR value for this model phone when tested for use at the ear is 0.47 W/kg and when worn on the body, as described in this user’s manual, is 0.56 W/kg. While there may be differences between SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/ea/fccid/ after searching on FCC ID ZNFB460.

To find information that pertains to a particular model phone, this site uses the phone FCC ID number which is usually printed somewhere on the case of the

phone. Sometimes it may be necessary to remove the battery pack to find the number. Once you have the FCC ID number for a particular phone, follow the instructions on the website and it should provide values for typical or maximum SAR for a particular phone. Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Association (CTIA) website at http://www. ctia.org/

* In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

Safety Guidelines

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices

On July 10, 2003, the U.S. Federal Communications Commission (FCC) Report and Order in WT Docket 01-309 modified the exception of wireless phones under the Hearing Aid Compatibility Act of 1988 (HAC Act) to require digital wireless phones be compatible with hearing-aids.

The intent of the HAC Act is to ensure reasonable access to telecommunications services for persons with hearing disabilities.

While some wireless phones are used near some hearing devices (hearing aids and cochlear implants), users may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to this interference noise, and phones also vary in the amount of interference they generate.

The wireless telephone industry has developed a rating system for wireless phones, to assist hearing device users to find phones that may be compatible with

their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label located on the box.

The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss. If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone successfully. Trying out the phone with your hearing device is the best way to evaluate it for your personal needs.

M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings.

T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to generate less interference to hearing devices than phones that are not labeled. T4 is the better/ higher of the two ratings.

Hearing devices may also be rated. Your hearing device manufacturer or hearing health professional may help you find this

rating. Higher ratings mean that the hearing device is relatively immune to interference noise. The hearing aid and wireless phone rating values are then added together. A sum of 5 is considered acceptable for normal use. A sum of 6 is considered for best use.

In the above example, if a hearing aid meets the M2 level rating and the wireless phone meets the M3 level rating, the sum of the two values equal M5. This should provide the hearing aid user with “normal usage” while using their hearing aid with the particular wireless phone. “Normal usage” in this context is defined as a signal quality that’s acceptable for normal operation.

The M mark is intended to be synonymous with the U mark. The T mark is intended to be synonymous with the UT mark. The M and T marks are recommended by the Alliance for Telecommunications Industries Solutions (ATIS). The U and UT marks are referenced in Section 20.19 of the FCC

Rules. The HAC rating and measurement procedure are described in the American National Standards Institute (ANSI) C63.19 standard.

To ensure that the Hearing Aid Compatibility rating for your phone is maintained, secondary transmitters such as Bluetooth components must be disabled during a call.

For information about hearing aids and digital wireless phones

Wireless Phones and Hearing Aid Accessibility

http://www.accesswireless.org/ Gallaudet University, RERC http://tap.gallaudet.edu/Voice/ FCC Hearing Aid Compatibility and Volume

Control http://www.fcc.gov/cgb/dro/hearing.html The Hearing Aid Compatibility FCC Order http://hraunfoss.fcc.gov/edocs_public/

attachmatch/FCC-03-168A1.pdf Hearing Loss Association of America [HLAA] http://hearingloss.org/content/telephones-

and-mobile-devices

LG 441G Guía del usuario

Las visualizaciones e ilustraciones de la

pantalla pueden variar de las que ve en el teléfono.

Es posible que parte del contenido de esta

guía no se aplique al teléfono, en función del software o del proveedor de servicios. Toda la información de este documento está sujeta a cambios sin previo aviso.

Contenido

El teléfono .........................5

Componentes del teléfono ...............5

Vista posterior .........................7

Introducción .......................8

Instalación de la tarjeta SIM y la batería ....8

Cargar el teléfono .....................10

Iconos en pantalla ....................11

Funciones generales ...............12

Antes de comenzar ....................12

Hacer una llamada ....................12

Hacer una llamada con la Tecla Enviar .....12

Hacer llamadas internacionales ..........12

Finalizar una llamada ..................12

Hacer una llamada desde contactos .......13

Responder una llamada ................13

Ajuste del volumen ....................14

Modo vibración (Rápido) ................ 14

Potencia de la señal ...................14

Introducir texto .......................14

Cambio del modo de entrada de texto .....14

Modo 123 (Modo de números) ...........14

Uso del modo 123 (modo de números) ..... 15

Modo de símbolos ....................15

Modo ABC ..........................15

Uso del modo ABC ....................15

Menú En llamada ..................17

Durante una llamada ...................17

Hacer una segunda llamada ............. 17

Alternar entre dos llamadas .............17

Responder una llamada entrante .........17

Rechazar una llamada entrante ..........17

Silenciar el micrófono .................. 18

Usando el altavoz .....................18

Prepago ..........................19

Añadir tiempo celular ..................19

Comprar tiempo celular ................. 19

Mi número telefónico ..................19

Mi saldo de tiempo celular (balance) ......19

Mostrar tiempo celular ................. 19

Número de serie ......................20

Número de SIM .......................20

Contactos ........................21

Lista de contactos ..................... 21

Nuevo contacto .......................21

Grupos ..............................21

Lista de marcación rápida ............... 21

Administración de la tarjeta SIM .......... 22

Número propio ........................ 22

Mi tarjeta de visita. . . . . . . . . . . . . . . . . . . . . 22

Mensajes .........................23

Nuevo mensaje .......................23

Buzón de entrada .....................26

Borradores ........................... 27

Buzón de salida ....................... 27

Config. de mensaje ....................28

Alerta de mensajes ...................28

Guardar en .........................28

Firma. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Mensaje de texto .....................28

Mensaje multimedia ...................29

Correo de voz .......................29

Llamadas recientes ................30

Juegos. . . . . . . . . . . . . . . . . . . . . . . . . . . 30

E-mail ...........................31

Enviar un correo electrónico .............31

Recuperar sus mensajes de correo

electrónico ........................ 31

Carpetas de mensajes .................31

Cambiar la configuración del correo

electrónico ........................ 32

Mi carpeta ........................33

Audio ...............................33

Imágenes ............................ 33

Video ............................... 33

Otros archivos ........................33

Admin. de archivos ....................34

Herramientas .....................35

Comando de voz ......................35

Alarma ..............................37

Calendario ...........................38

Bloc de notas ......................... 39

Calculadora ..........................39

Tareas ..............................39

Cronómetro .......................... 40

Calc. de propinas ...................... 41

Conversor de unidad ...................41

Grabador de voz ......................41

Acceso web ......................42

Inicio del acceso web ..................42

Menús del acceso web. . . . . . . . . . . . . . . . . 43

Uso de las teclas de navegación ..........43

Musica ..........................44

Reproducción de música ...............44

Agregar música al teléfono ..............45

Cámara ..........................46

Tomar foto ........................... 46

Grabar video .........................47

Álbum de la cámara ...................48

Contenido

Configuración .....................49

Audio y tonos de timbre ................49

Timbre ............................. 49

Tono de mensaje .....................49

Tono de alerta .......................49

Tono de teclado ...................... 50

Multimedia. . . . . . . . . . . . . . . . . . . . . . . . . . 50

Llamada ...........................50

Config. del teléfono ....................50

Idiomas ............................50

Establecer teclas de acceso directo .......50

Modo de avión .......................51

Seguridad .......................... 51

Restaurar configuraciones ..............51

Pantalla .............................52

Fondos de pantalla .................... 52

Fuentes ............................52

Relojes y calendario ...................52

Brillo ..............................52

Tiempo de luz de fondo ................52

Estilos de menú ......................52

Llamada ............................. 53

Enviar mi número ..................... 53

Modo de respuesta ...................53

Modo senior ........................53

Vibrar al conectarse ...................53

Duración de llamada ..................54

Accesibilidad .........................54

Lectura de menú .....................54

Tono de teclado ...................... 54

Texto grande ........................54

Invertir color. . . . . . . . . . . . . . . . . . . . . . . . . 54

Sonido mono ........................54

Modo senior ........................54

TTY ...............................55

Prótesis auditiva ...................... 55

Comando de voz .....................55

Bluetooth ............................55

Activar/Desactivar ....................55

Buscar nuevo aparato .................55

Mis aparatos ........................55

Mi info de bluetooth ................... 56

Memoria ............................56

Espacio utilizado .....................56

Aplicaciones .........................57

Mensajes ...........................57

Acceso web .........................57

Información del teléfono ................59

Accesorios .......................60

Por su seguridad ..................61

Indicaciones de seguridad ..........67

El teléfono

Componentes del teléfono

3 4

5 6 7

Toque y mantenga presionada esta tecla para activar el Modo de Vibración.

8 9

10 11

El teléfono

1. Auricular: Permite escuchar a la persona

que llama y solicitaciones automatizadas.

2. Pantalla LCD principal: Muestra los iconos de estado del teléfono, los elementos de los menús, los elementos web, la información web, las fotos y mucho más a todo color.

3. Teclas de Selección Derecha e Izquierda: Cada una de estas teclas

ejecuta las funciones indicadas por el texto en pantalla ubicado justo sobre ellas.

4. Tecla de Cámara: Permite activar la cámara y tomar fotografías.

5. Tecla Mensaje: Le permite crear un mensaje nuevo inmediatamente.

6. Teclas de Navegación

- Funciones de la pantalla principal:

Juegos

Contactos Alarma

Musica

- En un menú: Permite desplazarse por los menús.

7. Tecla Enviar:

modo de espera para acceder rápidamente a las llamadas entrantes, salientes y perdidas más recientes. También marca llamadas cuando introduce un número.

8. Tecla Borrar/Volver:

tecla para regresar a la pantalla anterior. También puede mantener oprimida para activar la función Comando de voz.

9. Tecla Modo TTS: Le permite activar o desactivar el modo de texto a voz.

10. Tecla OK

11. Tecla Fin/Encender:

o apagar el teléfono, finalizar llamadas o volver al modo de espera.

12. Teclas de Volumen:

el volumen de los tonos de timbre cuando el teléfono está en modo de espera y el volumen del auricular durante una llamada.

13. Puerto para Cargador/USB: Permite

conectar un cargador u otros accesorios admitidos.

Oprima esta tecla en el

Oprima esta

: Seleccione opciones y menús.

Permite encender

Permiten controlar

Vista posterior

Ranura para Tarjeta SIM

Tapa posterior

Batería

Introducción

Instalación de la tarjeta SIM y la batería

1. Extraiga la tapa posterior

Coloque su pulgar en la parte superior de

la tapa posterior y deslícela hacia abajo para extraerla.

2. Extraiga la batería

Sostenga el borde superior del teléfono

y use la abertura de dedos cerca de la parte inferior de la batería para levantar la batería del teléfono.

Advertencia

No retire la batería cuando el teléfono esté encendido porque puede dañarlo.

3. Inserte la tarjeta SIM

Deslice la tarjeta SIM hasta colocarla

en su ranura. Asegúrese de que el área de contactos dorados de la tarjeta esté orientada hacia abajo. Para extraer la tarjeta SIM, deslice suavemente hacia la dirección contraria.

4. Inserte la batería

Inserte primero la parte superior de

la batería en el borde superior del compartimiento de la batería. Asegúrese de que el área de contacto de la batería esté alineada con los terminales del teléfono. Oprima la parte inferior de la batería hasta que encaje en su lugar.

5. Instale la tapa posterior

Alinee la tapa posterior sobre el compartimiento de la batería y deslícela hacia arriba hasta que se trabe en su lugar.

Introducción

Cargar el teléfono

Ubique el Puerto para Cargador/USB en el lado izquierdo del teléfono. Inserte el cable del cargador en el teléfono (el lado “B” del cable debe orientarse hacia arriba al conectarlo en el teléfono) y después enchufe el otro extremo en la toma de pared. El teléfono deberá cargarse hasta que el mensaje “Batería completa” aparezca en la pantalla.

Importante

Debe insertar la batería antes de cargarla.

Advertencia

El uso de accesorios no autorizados podría dañar el teléfono y anular la garantía.

Iconos en pantalla

La tabla debajo describe varios indicadores o iconos que aparecen en la pantalla principal del teléfono.

ICONO/

INDICADOR

DESCRIPCIÓN

Potencia de la señal de red (varía la cantidad de barras)

Sin señal de red Batería baja Nuevo mensaje de texto Nuevo correo eletrónico Hay una alarma establecida Perfil de Timbre en uso Perfil de Silencio en uso Red EDGE disponible Bluetooth activo Red 3G disponible El navegador está activo

ICONO/

INDICADOR

DESCRIPCIÓN

Modo vibración activado Altavoz Llamada en curso Correo de voz Batería llena Batería cargando Modo de Avión encendido

Cámara en uso Videocámara grabando Temporizador de la videocámara Reproducir la música actual Pausar la música actual

Funciones generales

Antes de comenzar

Recuerde que puede seleccionar los iconos de menú en la pantalla Menú utilizando las teclas numéricas si establece la opción Estilos de menú como Lista. Si establece la opción Estilos de menú como Icono, sólo puede utilizar las Teclas de Navegación para seleccionar los iconos del menú.

Hacer una llamada

1 Asegúrese de que el teléfono esté

encendido.

2 Ingrese un número de teléfono, incluido

el código de área. Para modificar un número que aparece en la pantalla de visualización, sólo tiene que oprimir la Tecla Borrar/Volver y borrar los dígitos, de a uno por vez.

Mantenga oprimida la Tecla Borrar/ Volver para borrar todo el número.

3 Oprima la Tecla Enviar

al número seleccionado.

4 Para finalizar la llamada, oprima la Te cl a

Fin/Encender

para llamar

Hacer una llamada con la Tecla Enviar

1 Oprima la Tecla Enviar y

aparecerán los historiales de las llamadas recibidas, realizadas y perdidas más recientes.

2 Resalte el número que desea usar con las

Teclas de Navegación.

3 Oprima la Tecla Enviar

Hacer llamadas internacionales

1 Mantenga oprimida la tecla y

aparecerá “+”, el carácter de larga distancia internacional.

2 Introduzca el código de país, el código de

área y el número de teléfono.

3 Oprima la Tecla Enviar

Finalizar una llamada

Para finalizar una llamada, oprima la Tecla Fin/Encender .

LG 441G User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Your Phone

Phone Components

Rear view

Getting Started

Installing the SIM card and battery

Charging your phone

On-Screen Icons

General Functions

Before you begin

Making a Call

Making a Call with the Send Key

Making International Calls

Ending a Call

Making a Call from the Contacts

Answering a Call

Adjusting the Volume

Vibrating Mode (Quick)

Signal Strength

Entering Text

Changing the Text input mode

123 mode (Numbers mode)

Using the 123 (Numbers) mode

Symbol mode

ABC mode

Using the ABC mode

In-Call Menu

During a Call

Making a Second Call

Swapping Between Two Calls

Answering an Incoming Call

Rejecting an Incoming Call

Muting the Microphone

Using the Speakerphone

Prepaid

Add airtime

Buy airtime

My phone number

My airtime (balance) info

Airtime display

Serial number

SIM number

Contacts

Contact list

New contact

Groups

Speed dial

SIM management

Own number

My business card

Messages

Create message

Inbox

Drafts

Outbox

Message settings

Message alert

Save to

Signature

Text message

Multimedia message

Voicemail

Recent calls Games & apps

To access the Games, from the standby screen, press the Left Selection Key Menu, and Games & apps .

Email

Sending an email

Retrieving your email

Message folders

Changing your email settings

My Folder

Audio

Pictures

Video

File manager

Tools

Voice command

Alarm clock
