OWNER'S MANUAL
IPS LED MONITOR
LED MONITOR*
* LG LED Monitor applies LCD screen with LED backlights.
Please read the safety information carefully
before using the product.
34UC97
34UC97C
www.lg.com
TABLE OF CONTENTS
2
ENGLISH
TABLE OF CONTENTS
3 LICENSE
4 ASSEMBLING AND
4 Product Composition
5 Product and Button Description
5 - How to Use the Joystick Button
6 - Input Connector
7 Moving and Lifting the Monitor
8 Installing the Monitor
8 - Assembling the Stand
9 - Installing on a Table
10 - Tidying up Cables
10 - Adjusting the Angle
11 - Using the Kensington Lock
11 - Installing on the Wall
13 - Installing the Wall Mount Bracket
14 USING THE MONITOR
14 Connecting to a PC
14 - HDMI Connection
15 - DisplayPort Connection
15 - Thunderbolt ( ) Connection
16 Connecting AV Devices
16 - HDMI Connection
16 Connecting Peripherals
16 - USB Cable connection - PC
17 - Connecting Headphones
PREPARING
18 USER SETTINGS
18 Activating the Main Menu
18 - Main Menu Features
19 User Settings
19 - Menu Settings
20 - Ratio
21 - Function
22 - PBP
24 - Picture
25 - Color
26 - Settings
27 - Reset
28 TROUBLESHOOTING
30 PRODUCT SPECIFICATION
32 Factory Support Mode
32 HDMI Timing (Video)
32 Power LED
33 PROPER POSTURE
33 Proper Posture for Using the Monitor
LICENSE
3
LICENSE
Each model has different licenses. Visit www.lg.com for more information on the license.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI
logo are trademarks or registered trademarks of HDMI Licensing LLC in the
United States and other countries.
VESA, VESA logo, DisplayPort compliance logo and DisplayPort compliance
logo for dual-mode source devices are all registered trademarks of the Video
Electronics Standards Association.
MaxxAudio and additional MAXX trademarks are trademarks and/or registered
trademarks of Waves Audio Ltd.
ENGLISH
ASSEMBLING AND PREPARING
4
ENGLISH
ASSEMBLING AND PREPARING
Product Composition
Please check whether all the components are included in the box before using the product. If there are
any missing components, contact the retailer where you purchased the product. Note that the product and
related components may look different from those shown here.
CD (Owner's Manual /
Software/ Guides) / Cards
DisplayPort Cable Stand Body Stand Base
Power cord AC/DC Adapter HDMI cable
4 Screws
(M4 x L10)
Screw Cover Input connector cover
Wall mount bracket
(Varies depending upon
your country or model.)
CAUTION
yAlways use genuine LG components to ensure safety and product performance.
yThe product warranty will not cover damage or injury caused by the use of unauthorized components.
yIt is recommend that use the supplied components.
yIf you use generic cables not certified by LG, the screen may not display or there may be image
noises.
NOTE
yThe components may look different from those illustrated here.
yWithout prior notice, all product information and specifications contained in this manual are subject to
change to improve the performance of the product.
yTo purchase optional accessories, visit an electronics store or an online shopping site, or contact the
retailer from which you purchased the product.
yThe power cord provided may differ depending upon the region.
ASSEMBLING AND PREPARING
5
Product and Button Description
Joystick Button
Power LED
yOn Power on
yOff Power off
ENGLISH
/
How to Use the Joystick Button
You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with
your finger.
Basic Functions
Power on
Power off
◄/►
Volume
Control
NOTE
yThe joystick button is located at the bottom of the monitor.
yBefore turning on the monitor, please make sure that the DC switch on the rear side of product is On.
Press the joystick button once with your finger to turn on the
monitor.
Press and hold the joystick button once with your finger to turn off
the monitor.
You can control the volume by moving the joystick button left/right.
6
Input Connector
ENGLISH
ASSEMBLING AND PREPARING
ON
34UC97
DC-IN
(19 V )
34UC97C
DC-IN
(19 V )
H/P
H/P
DC switch
HDMI IN 1
HDMI IN 1
HDMI IN 2
HDMI IN 2
DP-IN
DP-IN
USB UP USB IN 1
USB UP USB IN 1
5 V 1.1 A
5 V 1.1 A
USB IN 2
5 V 1.1 A
USB IN 2
5 V 1.1 A
ASSEMBLING AND PREPARING
7
Moving and Lifting the Monitor
When moving or lifting the monitor, follow these
instructions to prevent the monitor from being
scratched or damaged and to ensure safe transportation, regardless of its shape or size.
yPlace the monitor in the original box or pack-
ing material before attempting to move it.
yBefore moving or lifting the monitor, discon-
nect the power cord and all other cables.
yHold the bottom and side of the monitor frame
firmly. Do not hold the panel itself.
CAUTION
yAvoid touching the monitor screen as much as
possible.
- This may result in damage to the screen or
some of the pixels used to create images.
yIf you use the monitor panel without the stand
base, its joystick button may cause the monitor to become unstable and fall, resulting in
damage to the monitor or human injury. In
addition, this may cause the joystick button to
malfunction.
ENGLISH
yWhen holding the monitor, the screen should
face toward you to prevent it from being
scratched.
yWhen transporting the monitor, do not expose
the monitor to shock or excessive vibration.
yWhen moving the monitor, keep it upright and
never turn the monitor on its side or tilt it sideways.
ASSEMBLING AND PREPARING
8
Installing the Monitor
ENGLISH
Assembling the Stand
3
Stand Body
1
Stand Base
4
CAUTION
yTo protect the screen, place the screen face
down on the screen pad which is inside the
box.
5
2
Stand Hinge
Screw Cover
ASSEMBLING AND PREPARING
9
6
Input connector cover
CAUTION
yIllustrations in this document represent typi-
cal procedures, so they may look different
from the actual product.
yApplying excessive force when tightening
screws may cause damage to the monitor.
Damage caused in this way will not be covered by the product warranty.
yBe careful not to hurt your hand on the edges
of the screw covers.
yDo not carry the monitor upside down by just
holding the base. This may cause the monitor to fall off the stand and could result in
personal injury.
yWhen lifting or moving the monitor, do not
touch the monitor screen. The force applied
to the monitor screen may cause damage to
it.
Installing on a Table
Lift the monitor and place it on the table in an
1
upright position. Place the monitor at least
10 cm away from the wall to ensure sufficient
ventilation.
10 cm
10 cm
10 cm
10 cm
Connect the power adapter to the monitor and
2
then plug the power cord into the wall outlet.
ENGLISH
NOTE
yYou can disassemble the stand in the
reverse order of the assembly.
Press the joystick button on the bottom of the
3
monitor to turn on the monitor.
CAUTION
yUnplug the power cord before moving or
installing the monitor. There is risk of electric
shock.
ASSEMBLING AND PREPARING
-515
-515
10
ENGLISH
Tidying up Cables
Arrange the cables using the input connector cover
as shown in the illustration.
Cautions When Connecting Power Cord
100-240 V ~
yMake sure to use the power cord that is pro-
vided in the product package and connect it to
a grounded power outlet.
yIf you need another power cord, please con-
tact your local dealer or the nearest retail
store.
Adjusting the Angle
Place the monitor mounted on the stand base
1
in an upright position.
Adjust the angle of the screen. The angle of
2
the screen can be adjusted forward or backward from -5° to 15° for a comfortable
viewing experience.
-515
FrontRear
WARNING
yTo avoid injury to the fingers when adjusting
the screen, do not hold the lower part of the
monitor's frame as illustrated below.
yBe careful not to touch or press the screen
area when adjusting the angle of the monitor.
ASSEMBLING AND PREPARING
11
Using the Kensington Lock
The connector for the Kensington security system
is located at the bottom of the monitor.
For more information on installation and usage,
refer to the Kensington lock owner's manual or visit
the website at http://www.kensington.com.
Connect the monitor to a table using the Kensington security system cable.
Installing on the Wall
Install the monitor at least 10 cm away from the
wall and leave about 10 cm of space at each side
of the monitor to ensure sufficient ventilation. Detailed installation instructions can be obtained from
your local retail store. Alternatively, please refer
to the manual for how to install and set up a tilting
wall mounting bracket.
10 cm
10 cm
10 cm
To install the monitor to a wall, attach a wall mounting bracket (optional) to the back of the monitor.
Make sure that the wall mounting bracket is securely fixed to the monitor and to the wall.
10 cm
ENGLISH
NOTE
yThe Kensington security system is optional.
You can obtain optional accessories from most
electronics stores.
If you use screws longer than the standard
1
length, it may damage the inside of the
product.
A non-VESA standard screw may damage the
2
product and cause the monitor to fall. LG Electronics is not liable for any accidents relating to
the use of non-standard screws.
Wall Mount (A x B) 100 x 100
Stand Screw M4 x L10
Required Screws 4
Wall Mount Plate
(Optional)
RW120
ASSEMBLING AND PREPARING
12
ENGLISH
yWall Mount (A x B)
A
B
NOTE
yUse the screws specified by VESA standards.
yThe wall mount kit includes the installation guide
and all necessary parts.
yThe wall mounting bracket is optional. You can
obtain optional accessories from your local dealer.
yThe length of the screw may differ for each wall
mounting bracket. Be sure to use the proper
length.
yFor more information, please refer to the user
manual for the wall mounting bracket.
CAUTION
yUnplug the power cord before moving or install-
ing the monitor to avoid electric shock.
yInstalling the monitor on the ceiling or on a
slanted wall may result in the monitor falling off,
which could lead to injury. Use an authorized LG
wall mount and contact the local dealer or qualified personnel.
yApplying excessive force when tightening
screws may cause damage to the monitor. Damage caused in this way will not be covered by
the product warranty.
yUse the wall mounting bracket and screws that
conform to VESA standards. Damage caused by
the use or misuse of inappropriate components
will not be covered by the product warranty.
yWhen measured from the back of the monitor,
the length of each installed screw must be 8 mm
or less.
Wall Mount Plate
Back of the Monitor
Wall Mount Plate
Back of the Monitor
Screw
Dimensions
: M4 x L10
Max 8 mm
ASSEMBLING AND PREPARING
13
Installing the Wall Mount Bracket
1
2
Wall mount bracket
Stand Hinge
NOTE
ENGLISH
yBe careful not to apply too much force while
mounting the wall mount bracket as it may
cause damage to the screen.
yApplying excessive force when tightening
screws may cause damage to the monitor. Damage caused in this way will not be covered by
the product warranty.
3
USING THE MONITOR
14
ENGLISH
USING THE MONITOR
Press the joystick button, go to Menu → Easy control → Input, and then select the input option.
yThe following instructions are based on the
34UC97 model. Illustrations in this manual
may differ from the actual product.
CAUTION
yDo not press the screen for a prolonged time.
This may cause image distortion.
yDo not display a still image on the screen
for a prolonged time. This may cause image
retention. Use a screensaver if possible.
NOTE
yWhen connecting the power cord to the out-
let, use a grounded (3-hole) power strip or a
grounded power outlet.
yThe monitor may flicker when turned on in
an area where the temperature is low. This is
normal.
ySometimes red, green, or blue spots may ap-
pear on the screen. This is normal.
Connecting to a PC
yThis monitor supports the *Plug and Play fea-
ture.
* Plug and Play: A feature that allows you to add a
device to your computer without having to reconfigure anything or install any manual drivers.
HDMI Connection
Transmits digital video and audio signals from your
PC to the monitor. Connect your PC to the monitor
using the HDMI cable as shown in the illustration
below.
HDMI IN 1 HDMI IN 2
CAUTION
yMake sure to use the supplied HDMI cable of
the product. Otherwise, this may cause the
device to malfunction.
yConnecting your PC to the monitor using the
HDMI cable may cause device compatibility
issues.
yUsing a DVI to HDMI / DP (DisplayPort) to
HDMI cable may cause compatibility issues.
yUse a certified cable with the HDMI logo
attached. If you do not use a certified HDMI
cable, the screen may not display or a connection error may occur.
yRecommended HDMI cable types
-High-Speed HDMI
-High-Speed HDMI
®/TM
cable
®/TM
cable with Ethernet
USING THE MONITOR
US
U
15
DisplayPort Connection
Transmits digital video and audio signals from your
PC to the monitor. Connect the monitor to your PC
using the display port cable as shown in the illustration below:
DP-IN
DP OUT
NOTE
yThere may be no video or audio output de-
pending on the DP (DisplayPort) version of the
PC.
yMake sure to use the supplied DisplayPort
cable of the product. Otherwise, this may
cause the device to malfunction.
yFor using Mini DP to DP (Mini DisplayPort to
DisplayPort) cable, it is recommended that you
use DisplayPort 1.2 cable.
Thunderbolt ( ) Connection
You can connect your high-resolution display or
high-performance data device to the monitor via a
Thunderbolt port. Connect your external device to
the monitor using the Thunderbolt cable as illustrated below.
34UC97
(sold separately)
NOTE
yThe maximum data transmission rate of each
port is 20 Gb/s.
yMake sure to use a Thunderbolt (
cable. Otherwise, this may cause the device to
malfunction.
yThunderbolt (
) is supported in such environments as Windows 7, Windows 8.1, and Mac
product.
yIn accordance with Mac products may not
support the recommended resolution or the
some features. For more information, refer to
the support information card of Mac which is
provided separately.
yThe ability to set up dual monitors using the
Thunderbolt (
) and daisy-chaining technology
depends on the performance of your video
card.
) certified
ENGLISH
USING THE MONITOR
HDMI IN 1 HDMI IN 2
US
U
16
Connecting AV Devices
ENGLISH
HDMI Connection
HDMI transmits digital video and audio signals
from your AV device to the monitor. Connect your
AV device to the monitor using the HDMI cable as
shown in the illustration below.
yMake sure to use the supplied HDMI cable of
the product. Otherwise, this may cause the
device to malfunction.
yUsing a DVI to HDMI / DP (DisplayPort) to
HDMI cable may cause compatibility issues.
yUse a certified cable with the HDMI logo at-
tached. If you do not use a certified HDMI
cable, the screen may not display or a connection error may occur.
yRecommended HDMI cable types
-High-Speed HDMI
-High-Speed HDMI
HDMI IN 1 HDMI IN 2
NOTE
®/TM
cable
®/TM
cable with Ethernet
Connecting Peripherals
USB Cable connection - PC
The USB port on the product functions as a USB
hub.
NOTE
yMake sure to install the most recent Windows
OS service pack before using the product.
yPeripheral devices are sold separately.
yA keyboard, mouse, or USB device can be
connected to the USB port.
CAUTION
Cautions When Using a USB Device
yA USB device with an automatic recognition
program installed, or that uses its own driver,
may not be recognized.
ySome USB devices may not be supported or
may not work properly.
yIt is recommended to use a USB hub or hard
disk drive with power supplied. (If the power
supply is not adequate, the USB device may
not be recognized properly.)
USING THE MONITOR
USB IN 2
5 V 1.1 A
USB UP
USB U
USB IN 1
5 V 1.1 A
17
HDMI/DP (DisplayPort) connection
To use USB 3.0, connect the A-B type USB 3.0
cable of the product to the PC.
Peripheral devices connected to the USB IN port
can be controlled from the PC.
(sold separately)
USB UP
USB IN 1
5 V 1.1 A
(sold separately)
USB IN 2
5 V 1.1 A
Thunderbolt ( ) connection
Peripheral devices connected to the USB IN port
can be controlled from the PC.
If you change the input on the menu while a device
is in connection via the Thunderbolt port, then the
device in connection via the USB port may not
work properly.
34UC97
P
USB IN 1
5 V 1.1 A
USB IN 2
5 V 1.1 A
Connecting Headphones
ENGLISH
Connect peripherals to the monitor via the headphones port. Connect as illustrated.
H/P
(sold separately)
NOTE
yPeripheral devices are sold separately.
yIf you use angled earphones, it may cause
a problem with connecting another external
device to the monitor. Therefore, it is recommended to use straight earphones.
Angled Straight
yDepending on the audio settings of the PC
and external device, headphones and speaker
functions may be limited.
(sold separately)
(sold separately)
USER SETTINGS
18
ENGLISH
USER SETTINGS
Activating the Main Menu
1
2
3
Press the joystick button on the bottom of the monitor.
Move the joystick up/down (▲/▼) and left/right(◄/►) to set the options.
Press the joystick button once more to exit the main menu.
Joystick Button
Button Menu Status Description
Main menu disabled Enables the main menu.
Main menu enabled
Main menu disabled Adjusts the monitor volume level.
◄
Main menu enabled Enters the menu features.
Exits the main menu.
(Holding down the button to turn off the monitor. You can turn off
the monitor this way at any time, including when the OSD is on.)
Main menu disabled Adjusts the monitor volume level.
►
Main menu enabled Enters the PBP feature.
Main menu disabled Enables the main menu.
▲
Main menu enabled Enters the MaxxAudio feature.
Main menu disabled Enables the main menu.
▼
Main menu enabled Turns off the monitor.
Main Menu Features
MaxxAudio
Menu PBP
Long press: Monitor off
Exit
Monitor off
Main Menu Description
Menu Configures the screen settings.
MaxxAudio Sets the sound quality.
PBP Displays the screens of two input modes on one monitor.
Monitor off Turns off the monitor.
Exit Exits the main menu.
USER SETTINGS
User Settings
Menu Settings
To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the
1
Menu.
Configure the options by moving the joystick up/down/left/right.
2
To return to the upper menu or set other menu items, move the joystick to ◄ or pressing ( / OK) it.
3
If you want to exit the OSD menu, move the joystick to ◄ until you exit.
4
yWhen you enter the menu, instructions on how to use the button will appear in the bottom right corner
of the screen.
Easy control Function PBP Screen Settings Reset
Each option is described below.
19
ENGLISH
Menu Description
Easy control Brightness
Contrast
Volume Adjusts the volume level.
Adjusts the color contrast and brightness of the screen.
NOTE
yYou can adjust Mute/ Unmute by moving the joystick button to ▼ in the Volume
menu.
Input Selects the input mode.
Ratio Adjusts the aspect ratio of the screen.
Function Adjusts MaxxAudio, Reader Mode, Picture Mode, and SMART ENERGY SAVING.
PBP PBP Displays the screens of two input modes on one monitor.
Screen Picture Adjusts the Sharpness, Black level, and Response Time of the screen.
Color Adjusts Gamma, Color Temperature, Red, Green, Blue, and Six Color.
Settings Adjusts Language, Power LED, Automatic Standby, DisplayPort 1.2, and OSD Lock.
Reset Restores the default settings.
◄ Exit Exits the OSD menu.
CAUTION
yYour monitor’s OSD (On Screen Display) may differ slightly from that shown in this manual.
USER SETTINGS
20
Ratio
ENGLISH
1
2
3
4
5
Each option is described below.
To view the OSD menu, press the joystick button at the
bottom of the monitor and then enter the Menu.
Go to Easy control > Ratio by moving the joystick.
Configure the options following the instructions that appear
in the bottom right corner.
To return to the upper menu or set other menu items, move
the joystick to ◄ or pressing ( / OK) it.
If you want to exit the OSD menu, move the joystick to ◄
until you exit.
Easy control
Function
PBP
Screen
Settings
Reset
Easy control
Brightness
Contrast 70
Volume
Input HDMI1
Ratio Wide
▲/▼: Move
/ ►: OK
◄: Back
70
>
>
30
>
>
>
Menu > Easy control > Ratio Description
Wide Displays the video in widescreen, regardless of the video signal input.
Original Displays video according to the aspect ratio of the video signal input.
Cinema 1 Enlarges the screen with an aspect ratio of 21:9. (at 1080p)
Cinema 2 Enlarges the screen with an aspect ratio of 21:9, including the black box at the
bottom for subtitles. (at 1080p)
1:1 The aspect ratio is not adjusted from the original.
NOTE
yThe display may look the same for Wide, Original, and 1:1 options at the recommended resolution
(3440 x 1440).
yThe ratio is disabled in the interlaced signal.
USER SETTINGS
21
Function
To view the OSD menu, press the joystick button at the
1
bottom of the monitor and then enter the Menu.
Go to Function by moving the joystick.
2
Configure the options following the instructions that appear in
3
the bottom right corner.
To return to the upper menu or set other menu items, move
4
the joystick to ◄ or pressing ( / OK) it.
If you want to exit the OSD menu, move the joystick to ◄
5
until you exit.
Each option is described below.
Easy control
Function
PBP
Screen
Settings
Reset
Function
MaxxAudio
Reader Mode Reader Off
Picture Mode Custom
SMART ENERGY SAVING Low
▲/▼: Move
/ ►: OK
◄: Back
>
>
>
>
ENGLISH
Menu > Function Description
MaxxAudio
(Move the joystick to
▲ in the main menu
to enter the function
directly.)
MaxxAudio On MaxxAudio® by Waves, recipient of a Technical GRAMMY
Award® is a suite of studio-quality sound tools for a superior
listening experience.
Off Disables the MaxxAudio function.
MaxxAudio
Settings
The user can set the sound quality manually.
MaxxBass Bass Enhancement.
MaxxTreble Treble Enhancement.
MaxxDialog Dialog Enhancement.
Maxx3D Enhances the three dimensional effect of the sound.
Reset Returns the sound quality to the default settings.
Midnight Mode Lets you enjoy rich and full sound at a low volume.
Reader Mode Reader 1 Optimizes the screen for browsing newspapers. You can brighten the screen
in the OSD menu.
Reader 2 Optimizes the screen for looking at cartoons. You can brighten the screen in
the OSD menu.
Reader Off Reader Mode is off.
Picture Mode Custom Allows the user to adjust settings. You can adjust the color mode of the main
menu.
Photo Optimizes the screen for photos.
Cinema Optimizes the screen for videos.
Game Optimizes the screen for games.
SMART ENERGY
SAVING
High Saves energy using the high-efficiency SMART ENERGY SAVING feature.
Low Saves energy using the low-efficiency SMART ENERGY SAVING feature.
Off Disables the SMART ENERGY SAVING feature.
USER SETTINGS
22
PBP
ENGLISH
1
2
3
4
5
Each option is described below.
To view the OSD menu, press the joystick button at the
bottom of the monitor and then enter the Menu.
Go to PBP by movingthe joystick.
Configure the options following the instructions that appear in
the bottom right corner.
To return to the upper menu or set other menu items, move
the joystick to ◄ or pressing ( / OK) it.
If you want to exit the OSD menu, move the joystick to ◄
until you exit.
Easy control
Function
PBP
Screen
Settings
Reset
PBP
PBP Off
Input
Audio HDMI1
Swap
Sub Full
Ratio
PBP Preview
HDMI1
▲/▼: Move
/ ►: OK
◄: Back
>
>
>
>
Menu > PBP Description
PBP Displays the screens of two input modes on one monitor.
Sub Screen (Right)
PBP Connection
Main
Screen
(Left)
HDMI 1
HDMI 2
DisplayPort
Thunderbolt ( )
(only 34UC97
HDMI 1 HDMI 2 DisplayPort
- O X X
O -
O O - X
O O X -
model)
Input Main Selects the video signal input of the main screen.
Sub Selects the video signal input of the sub screen.
Audio Changes the audio output in PBP mode.
Swap Toggles between the main screen and sub screen in PBP mode.
Sub Full Converts the sub screen in PBP mode to wide screen.
Thunderbolt ( )
(only 34UC97
model)
X
X
USER SETTINGS
Menu > PBP Description
Ratio Adjusts the aspect ratio of the main screen or sub screen.
Main Wide Displays the video to fit the PBP screen, regardless of the
video signal input.
Original Displays the video in the aspect ratio of the video signal input
on the PBP screen.
Sub Wide Displays the video to fit the PBP screen, regardless of the
video signal input.
Original Displays the video in the aspect ratio of the video signal input
on the PBP screen.
NOTE
yWhen the PBP mode is Off, Input, Audio, Swap, Sub Full, and Ratio menus become disabled.
The Main/Sub options for Ratio become disabled if there is no signal.
yThe optimal resolution for PBP mode is set automatically when PBP mode is set. (only 34UC97C
model)
23
ENGLISH
USER SETTINGS
24
ENGLISH
1
2
3
4
5
Each option is described below.
To view the OSD menu, press the joystick button at the
bottom of the monitor and then enter the Menu.
Go to Screen > Picture by moving the joystick.
Configure the options following the instructions that appear in
the bottom right corner.
To return to the upper menu or set other menu items, move
the joystick to ◄ or pressing ( / OK) it.
If you want to exit the OSD menu, move the joystick to ◄
until you exit.
Easy control
Function
PBP
Screen
Settings
Reset
Sharpness
Black Level High
Response Time Middle
▲/▼: Move
/ ►: OK
◄: Back
5
>
>
>
Menu > Screen > Picture Description
Sharpness Adjusts the sharpness of the screen.
Black Level Sets the offset level (for HDMI only).
• Offset: as a reference for a video signal, this is the darkest color the monitor can dis-
play.
High The picture of the screen gets brighter.
Low The picture of the screen gets darker.
Response Time Sets a response time for displayed pictures based on the speed of the screen.
For a normal environment, it is recommended that you use Middle. For a fast-moving
picture, it is recommended that you use high.
Setting to High may cause image sticking.
High Sets the response time to High.
Middle Sets the response time to Middle.
Low Sets the response time to Low.
Off Does not use the response time improvement feature.
USER SETTINGS
25
Color
To view the OSD menu, press the joystick button at the
1
bottom of the monitor and then enter the Menu.
Go to Screen > Color by moving the joystick.
2
Configure the options following the instructions that appear in
3
the bottom right corner.
To return to the upper menu or set other menu items, move
4
the joystick to ◄ or pressing ( / OK) it.
If you want to exit the OSD menu, move the joystick to ◄
5
until you exit.
Each option is described below.
Easy control
Function
PBP
Screen
Settings
Reset
Color
Gamma Gamma 1
Color Temp Custom
Red
Green 50
Blue
Six Color
Reset
▲/▼: Move
/ ►: OK
◄: Back
>
>
50
>
>
50
>
>
>
ENGLISH
Menu > Screen > Color Description
Gamma Custom gamma settings: When using the gamma 0, gamma 1, and gamma 2 monitor set-
tings, higher gamma settings mean a brighter image is displayed and vice versa.
Color Temp Custom The user can adjust it to red, green, or blue by customization.
Warm Sets the screen color to a reddish tone.
Medium Sets the screen color to between a red and blue tone.
Cool Sets the screen color to a bluish tone.
Red You can customize the picture color using Red, Green, and Blue colors.
Green
Blue
Six Color Meets the user requirements for colors by adjusting the hue and saturation of the six colors
(red, green, blue, cyan, magenta, and yellow) and then saving the settings.
Hue Adjusts the tone of the screen colors.
Saturation Adjusts the saturation of the screen colors. The lower the value, the less satu-
rated and brighter the colors become. The higher the value, the more saturated
and darker the colors become.
Reset Returns color to the default settings.
USER SETTINGS
26
Settings
ENGLISH
1
2
3
4
5
Each option is described below.
To view the OSD menu, press the joystick button at the
bottom of the monitor and then enter the Menu.
Go to Settings by moving the joystick.
Configure the options following the instructions that appear in
the bottom right corner.
To return to the upper menu or set other menu items, move
the joystick to ◄ or pressing ( / OK) it.
If you want to exit the OSD menu, move the joystick to ◄
until you exit.
Easy control
Function
PBP
Screen
Settings
Reset
Settings
Language English
Power LED Off
Automatic Standby Off
DisplayPort 1.2 Disable
OSD Lock Off
▲/▼: Move
/ ►: OK
◄: Back
>
>
>
>
>
Menu > Settings Description
Language Sets the menu screen to the desired language.
Power LED Turns the power LED on the front of the monitor on or off.
On The power LED turns on automatically.
Off The power LED turns off.
Automatic
Standby
Feature that automatically turns off the monitor when there is no movement on the screen for a
period of time. You can set a timer for the auto-off function. (Off, 4 H, 6 H, and 8 H)
DisplayPort 1.2 Enables or disables DisplayPort 1.2.
NOTE
yBe sure to configure this option according to the DisplayPort version supported by your
graphics card. Set this option to Disable if your graphics card does not support DisplayPort
1.2.
OSD Lock Prevents incorrect key input.
On Disables key input
Off Enables key input
NOTE
yAll features are disabled except Brightness, Contrast, Volume, Input, OSD Lock in Settings,
and the Exit button.
USER SETTINGS
27
Reset
To view the OSD menu, press the joystick button at the
1
bottom of the monitor and then enter the Menu.
Go to Reset by moving the joystick.
2
Configure the options following the instructions that appear in
3
the bottom right corner.
To return to the upper menu or set other menu items, move
4
the joystick to ◄ or pressing ( / OK) it.
If you want to exit the OSD menu, move the joystick to ◄
5
until you exit.
Each option is described below.
Easy control
Function
PBP
Screen
Settings
Reset
Reset
Do you want to reset your settings?
Reset
Cancel
▲/▼:Move
/►:OK
ENGLISH
◄:Back
Menu > Reset Description
Do you want to reset your settings?
Reset Restores the default settings.
Cancel Cancel the reset.
TROUBLESHOOTING
28
ENGLISH
TROUBLESHOOTING
Nothing is displayed on the screen.
Is the monitor's power cord
plugged in?
Is the power LED on? yCheck the power cable connection and press the power button.
Is the power on and the power
LED displaying white?
Is the power LED blinking? yIf the monitor is in sleep mode, move the mouse, or press any key
Is the OUT OF RANGE message being displayed?
Is the No Signal message being
displayed?
The screen may not be displayed properly when configuring DisplayPort 1.2 in a Mac
product.
yCheck if the power cord is correctly plugged into the power outlet.
yCheck that the connected input is enabled (Menu - Input).
on the keyboard, to switch the display on.
yCheck if the computer is turned on.
yThis occurs when signals transferred from the PC (video card) are
out of the horizontal or vertical frequency range of the monitor.
Please see the Product Specification section of this manual to set
the appropriate frequency.
yThis is displayed when the signal cable between the PC and the
monitor is missing or disconnected. Check the cable and reconnect
it.
yDisplayPort 1.2 may not be supported depending upon the Mac
product. Please contact the manufacturer.
The OSD Lock message is being displayed.
Are some functions not available when you press the Menu
button?
The screen retains an image.
Does image sticking occur even
when the monitor is turned off?
Screen display is unstable and shaky / Images displayed on the monitor leave shadow trails.
Did you select the appropriate
resolution?
yThe OSD is locked. Go to Menu > Settings and set OSD Lock to Off.
yDisplaying a still image for a prolonged time may cause damage to
the screen, resulting in the retention of the image.
yTo extend the lifetime of the monitor, use a screensaver.
yIf the selected resolution is HDMI 1080i 60/50 Hz (interlaced), the
screen may be flickering. Change the resolution to 1080p or the
recommended resolution.
NOTE
yVertical Frequency: In order to display an image, the screen must be refreshed dozens of times per
second, like a fluorescent lamp. The number of times the screen is refreshed per second is called
vertical frequency, or refresh rate, and is represented by Hz.
yHorizontal Frequency: The time it takes to display one horizontal line is called the horizontal cycle. If
1 is divided by the horizontal interval, the result is the number of horizontal lines displayed per second.
This is called horizontal frequency and is represented by kHz.
TROUBLESHOOTING
29
NOTE
yCheck if the video card's resolution or frequency is within the range allowed by the monitor and set it to
the recommended (optimal) resolution in Control Panel > Display > Settings.
yNot setting the video card to the recommended (optimal) resolution may result in blurred text, a dimmed
screen, a truncated display area or misalignment of the display.
yThe setting methods may be different depending on the computer or operating system, and some reso-
lutions may not be available depending on the performance of the video card. If this is the case, contact
the manufacturer of the computer or video card for assistance.
ySome video cards may not support 3440 x 1440 resolution. If the resolution cannot be displayed, con-
tact the manufacturer of your video card.
The display color is abnormal.
Does the display appear discolored (16 colors)?
Does the display color appear
unstable or monochrome?
Are there spots on the screen? yWhen using the monitor, pixilated spots (red, green, blue, white, or
ySet the color to 24 bit (true color) or higher. In Windows, go to Con-
trol Panel > Display > Settings > Color Quality.
yCheck if the signal cable is connected properly. Reconnect the cable
or reinsert the PC's video card.
black) may appear on the screen. This is normal for an LCD screen.
It is not an error, nor is it related to the monitor's performance.
ENGLISH
No sound from the headphone port.
Are images displayed using
DP (DisplayPort) or HDMI input
without sound?
yMake sure that the headphone port connections are made properly.
yTry increasing the volume with the joystick.
ySet the audio output of the PC to the monitor you are using. On
Microsoft Windows, go to Control Panel > Hardware and Sound >
Sound > set the monitor as default device.
PRODUCT SPECIFICATION
30
ENGLISH
PRODUCT SPECIFICATION
34UC97
LCD Screen Type TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Screen
Color Depth HDMI 8-bit color is supported.
DP (DisplayPort) 10-bit color is supported.
Thunderbolt ( )
Pixel Pitch 0.2325 mm x 0.2325 mm
Resolution HDMI Max Resolution 3440 x 1440 @ 50 Hz
Recommended Resolution 3440 x 1440 @ 50 Hz
DP (DisplayPort)
Thunderbolt ( )
Video Signal Horizontal Frequency 30 kHz to 90 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Separate Sync.
Input Connector
Power Sources Power Rating
AC/DC Adapter LCAP31 type, manufactured by Lienchang
Stand Angle Forward/Backward: -5° to 15° (Head)
Environmental
Conditions
Audio Output 7 W + 7 W
Supported
Operating System
H/P OUT, HDMI IN 1, HDMI IN 2, DP (DisplayPort) IN, Thunderbolt ( ), USB UP,
USB IN 1, 2
Power Consumption
(Typical)
Output: 19 V 7.37 A
Operating Conditions Temperature 0 °C to 40 °C
Storing Conditions Temperature -20 °C to 60 °C
Win 7, Win 8.1, Mac OS*
Max Resolution 3440 x 1440 @ 60 Hz
Recommended Resolution 3440 x 1440 @ 60 Hz
19 V 6.0 A
Operating Mode: 80 W (Typical, USB excluded) (Outgoing
condition)
Sleep Mode ≤ 1.2 W
Off Mode ≤ 0.5 W
Off Mode ≤ 0.3 W (DC switch is off.)
Humidity Less than 80 %
Humidity Less than 85 %
8-bit color is supported.
Dimensions Monitor Size (Width x Height x Depth)
With Stand 830.5 mm x 472.9 mm x 225.6 mm
Without Stand 830.5 mm x 370.3 mm x 99 mm
Weight (Without
Packaging)
Specifications are subject to change without notice.
* In accordance with Mac products may not support the recommended resolution or the some features.
(For more information, refer to the support information card of Mac which is provided separately.)
With Stand 9.0 kg
Without Stand 8.25 kg
PRODUCT SPECIFICATION
34UC97C
LCD Screen Type TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Screen
Color Depth HDMI 8-bit color is supported.
DP (DisplayPort) 10-bit color is supported.
Pixel Pitch 0.2325 mm x 0.2325 mm
Resolution HDMI Max Resolution 3440 x 1440 @ 50 Hz
Recommended Resolution 3440 x 1440 @ 50 Hz
DP (DisplayPort) Max Resolution 3440 x 1440 @ 60 Hz
Recommended Resolution 3440 x 1440 @ 60 Hz
Video Signal Horizontal Frequency 30 kHz to 90 kHz
Vertical Frequency
Synchronization Separate Sync.
Input Connector H/P OUT, HDMI IN 1, HDMI IN 2, DP (DisplayPort) IN, USB UP, USB IN 1, 2
Power Sources Power Rating
Power Consumption
(Typical)
AC/DC Adapter ADS-110CL-19-3-190110G type, manufactured by Honor
Output: 19 V 5.79 A
Stand Angle Forward/Backward: -5° to 15° (Head)
Environmental
Conditions
Audio Output 7 W + 7 W
Supported
Operating System
Operating Conditions Temperature 0 °C to 40 °C
Storing Conditions Temperature -20 °C to 60 °C
Win 7, Win 8.1, Mac OS
56 Hz to 61 Hz
19 V 4.0 A
Operating Mode: 70 W (Typical, USB excluded) (Outgoing
condition)
Sleep Mode ≤ 1.2 W
Off Mode ≤ 0.5 W
Off Mode ≤ 0.3 W (DC switch is off.)
Humidity Less than 80 %
Humidity Less than 85 %
31
ENGLISH
Dimensions Monitor Size (Width x Height x Depth)
With Stand 830.5 mm x 472.9 mm x 225.6 mm
Without Stand 830.5 mm x 370.3 mm x 99 mm
Weight (Without
Packaging)
Specifications are subject to change without notice.
With Stand 9.0 kg
Without Stand 8.25 kg
32
Factory Support Mode
ENGLISH
PRODUCT SPECIFICATION
34UC97
34UC97C
(Preset Mode, HDMI/ DisplayPort/ Thunderbolt PC)
(Preset Mode, HDMI/ DisplayPort PC)
Preset Mode
640 x 480 31.469 59.94 -/-
800 x 600 37.879 60.317 +/+
1024 x 768 48.363 60 -/-
1152 x 864 54.347 60.05 +/+
1280 x 720 45 60 +/+
1280 x 1024 63.981 60.02 +/+
1600 x 900 60 60 +/+
1680 x 1050 65.29 59.954 -/+
1920 x 1080 67.5 60 +/-
2560 x 1080 66.7 60 -/+
3440 x 1440 43.82 29.99 +/+
3440 x 1440 73.68 49.99 +/+
3440 x 1440 88.82 59.97 +/+ HDMI is not supported.
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Polarity (H/V) Remarks
HDMI Timing (Video)
Preset Mode
480p 31.5 60
720p 45 60
1080p 67.5 60
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Remarks
Power LED
Mode LED Color
On Mode White
Sleep Mode Flashing White
Off Mode Off
PROPER POSTURE
33
PROPER POSTURE
Proper Posture for Using the Monitor
Adjust the screen so that you can comfortably look at it at a slight downward angle from your natural eye
level.
yTake a break for approximately 10 minutes every hour to reduce any fatigue caused by prolonged
usage.
yAdjust the stand angle from -5° to 15° to obtain the best view of the screen.
You should be looking
slightly down at the
screen.
Stand Angle
-5° to 15°
Adjust the position of
the screen to minimize reflections.
ENGLISH
Place your hands gently
on the keyboard,
keeping your arms bent at
the elbows and extended
horizontally in front of you.
This device meets the EMC requirements for
home appliances (Class B) and is intended for
home usage. This device can be used in all
regions. Read the owner's manual (CD) carefully
and keep it at hand. Please note that the label
attached to the product provides information for
technical support.
Model
Serial No.
Loading...
