OWNER’S MANUAL

LED TV

* LG LED TVs are LCD TVs with LED backlighting.

Please read this manual carefully before operating your TV and retain it for future reference.

29UT55V

www.lg.com

ENGLISH

TABLE OF CONTENTS

3 LICENSES

3 OPEN SOURCE SOFTWARE

NOTICE

4 ASSEMBLING AND

PREPARING

4 Unpacking 6 Parts and buttons 6 - Using the Joystick button 8 Lifting and moving the TV 10 Setting up the TV 10 - Attaching the Stand 11 - Detaching the Stand 13 - Mounting on a table 14 - Tidying cables 15 Mounting on a wall

17 WATCHING TV

17 Turning the TV on for the first time 19 TV display (5:9 OSD) 19 - Programme Guide 20 PIP function

35 REMOTE CONTROL

36 INSTALLING LG MONITOR

SOFTWARE

38 CUSTOMIZING SETTINGS

38 Accessing the Main Menus 38 - TV, Component, AV 55 - HDMI1, HDMI2, DisplayPort

63 MAINTENANCE

63 Cleaning Your TV 63 Screen and frame 63 Cabinet and stand 63 Power cord 64 Preventing “Image burn” or “Burn-in” on

your TV screen

65 TROUBLESHOOTING

67 SPECIFICATIONS

22 MAKING CONNECTIONS

22 Connecting an antenna 23 Satellite connection 24 External Device Connections 24 - HDMI connection 25 - Component connection 26 - Composite connection 27 - Euro Scart connection 28 Headphone connection 29 Connecting a USB Device 30 CI module connection 31 Connecting to a wired network 32 Connecting to a PC 33 - HDMI connection 34 - Display Port connection

WARNING

yIf you ignore the warning message, you

may be seriously injured or there is a possibility of accident or death.

CAUTION

yIf you ignore the caution message, you may

be slightly injured or the product may be damaged.

NOTE

yThe note helps you understand and use

the product safely. Please read the note carefully before using the product.

LICENSES / OPEN SOURCE SOFTWARE NOTICE

LICENSES

Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

The terms HDMI and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a

subsidiary of Rovi Corporation. This is an ofcial DivX Certied® device that has

passed rigorous testing to verify that it plays DivX video. Visit divx.com for more

information and software tools to convert your les into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certied® device must be

registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

“DivX Certied® to play DivX® video up to HD 1080p, including premium content.”

“DivX®, DivX Certied® and associated logos are trademarks of Rovi Corporation

or its subsidiaries and are used under license.”

“Covered by one or more of the following U.S. patents : 7,295,673; 7,460,668; 7,515,710; 7,519,274”

VESA, VESA logo, Display Port Compliance Logo and Display Port Compliance Logo for dual-mode source are all registered trademarks of the Video Electronics Standards Association.

ENGLISH

MaxxAudio and additional MAXX trademarks are trademarks and/or registered trademarks of Waves Audio Ltd.

OPEN SOURCE SOFTWARE NOTICE

To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http://opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. This offer is valid for three (3) years from the date on which you purchased the product.

ASSEMBLING AND PREPARING

ENGLISH

NOTE

yImage shown may differ from your TV. yYour TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. yThe available menus and options may differ from the input source or product model that you are

using.

yNew features may be added to this TV in the future. yThe TV can be placed in standby mode in order to reduce the power consumption. And the TV should

be turned off if it will not be watched for some time, as this will reduce energy consumption.

yThe energy consumed during use can be signicantly reduced if the level of brightness of the picture

is reduced, and this will reduce the overall running cost.

ASSEMBLING AND PREPARING

Unpacking

Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and item.

CAUTION

yDo not use any pirated items to ensure the safety and product life span. yAny damages or injuries by using pirated items are not covered by the warranty.

NOTE

yThe items supplied with your product may vary depending on the model. yProduct specications or contents of this manual may be changed without prior notice due to upgrade

of product functions.

yFor an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick

and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB memory

stick does not t into your TV’s USB port.

*A 10 mm

18 mm

ASSEMBLING AND PREPARING

ENGLISH

Remote control, Batteries (AAA)

(See p. 35)

Stand Base

(See p.11)

Power Cord

(See p. 13)

CD (Owner's Manual / Software) / Guides / Cards

Stand Screws

2 EA, M4 x L10 (See p.10,12)

AC-DC Adapter

(See p. 13)

Stand Body

(See p.10,11)

Stand Screw cover

(See p.10,12)

Cable Holder

(See p. 14)

HDMI Cable

(See p. 24, 33)

ASSEMBLING AND PREPARING

ENGLISH

Parts and buttons

Screen

Speakers

Joystick button

(*This button is located below the TV screen.)

NOTE

yYou can set the power indicator light to on or off by selecting

Remote control sensor

Power Indicator

Red : When the power is turned off Off : When the power is turned on Amber : When the power is in power saving mode

OPTION

in the main menus.

Using the Joystick button

You can simply operate the TV functions, pressing or moving the joystick button up, down, left or right.

Basic Functions

When the TV is turned off, place your nger on the joystick

Power On

Power Off

Volume Control

Programmes Control

button and press it once and release it. (However, if the Menu button is on the screen, pressing the joystick button will let you exit the Menu.)

When the TV is turned on, place your nger on the joystick

button and press it once for a few seconds and release it.

If you place your nger over the joystick button and move it left

or right, you can adjust the volume level you want.

If you place your nger over the joystick button and move it up

or down, you can scroll through the saved programmes what you want.

ASSEMBLING AND PREPARING

입력

PIP

입력

NOTE

yWhen your nger over the joystick button push it to the up, down, left or right, be careful not to press

the joystick button. If you press the joystick button rst, you can not adjust the volume level and saved

programmes.

Adjusting the Menu

When the TV is turned on, press the joystick button one time.

You can adjust the Menu items (

Input

Exit

Monitor off

PIP

, ,

, , ) moving the joystick button up, down, left or right.

Input Changes the input source.

PIP Turns the PIP mode on or off.

Monitor Off Turns the power off.

Menu Congures the settings.

Exit Exits the OSD menu.

ENGLISH

ASSEMBLING AND PREPARING

ENGLISH

Lifting and moving the TV

Please note the following advice to prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size.

CAUTION

yAvoid touching the screen at all times, as

this may result in damage to the screen.

yIt is recommended to move the TV in the

box or packing material that the TV originally came in.

yBefore moving or lifting the TV, disconnect the

power cord and all cables.

yWhen holding the TV, the screen should face

away from you to prevent the screen from scratches.

yHold the top and bottom of the TV frame rmly.

Make sure not to hold the transparent part.

yWhen transporting the TV, do not expose the

TV to jolts or excessive vibration.

yWhen transporting the TV, keep the TV

upright, never turn the TV on its side or tilt towards the left or right.

yDo not apply excessive pressure to cause

exing / bending of frame chassis as it may

damage screen.

CAUTION

yWhen handling the TV, be careful not to

damage the protruding joystick button.

ASSEMBLING AND PREPARING

CAUTION

yDo not carry the TV upside-down as this

may cause it to fall off its stand, resulting in damage or injury.

yDo not carry the TV upside-down by

holding the stand body as this may cause it to fall off, resulting in damage or injury.

yThe illustration shows a general example of

installation and may look different from the actual product.

ENGLISH

ASSEMBLING AND PREPARING

ENGLISH

Setting up the TV

Attaching the Stand

Check the orientation (front and rear) of the stand base and mount the Stand Body to the Stand

Hinge as shown in the gure.

Stand Body

CAUTION

yWhen attaching the stand to the TV set,

place the screen facing down on a cushioned

table or at surface to protect the screen

from scratches.

Stand Hinge

Turn the screw to the right into the back of the stand body and close the Stand Screw Cover.

Stand Screw

Cover

NOTE

yIf you don`t fasten the screw tightly, TV will

fall down and get damaged.

yTighten the screws rmly to prevent the TV

from tilting forward. Do not over tighten.

ASSEMBLING AND PREPARING

Fix the Stand Base to the Stand Body and turn the screws on the Stand Base to the right.

Stand Body

Stand

Base

Detaching the Stand

Turn the screw to the left, and then pull out the Stand Base from the Stand Body.

Stand Body

Stand Base

ENGLISH

ASSEMBLING AND PREPARING

ENGLISH

Open the Stand Screw Cover on the back of the Stand Body and turn the screws on the stand body to the left.

Stand Screw

Cover

Detach the Stand Body from the TV.

Stand Body

CAUTION

yWhen detaching the stand to the TV

set, place the screen facing down on a cushioned table or flat surface to protect the screen from scratches.

Stand Hinge

CAUTION

yTo remove the stand screw cover, use a

screwdriver, coin or similar object.

yRemoving the cover by hand may cause

injury.

ASSEMBLING AND PREPARING

Mounting on a table

1 Lift and tilt the TV into its upright position on a

table. Leave a 10 cm (minimum) space from the wall for proper ventilation.

10 cm

2 Connect the AC-DC Adapter and Power Cord

to a wall outlet.

Adjusting the angle of the TV to suit view

Tilt from -5 to +20 degrees up or down to adjust the angle of the TV to suit your view.

-5 20

Front Rear

WARNING

yWhen you adjust the angle, do not hold the

button of the TV frame as shown on the following illustration, as may injure your

ngers.

ENGLISH

DC-IN

(19V )

CAUTION

yDo not place the TV near or on sources

of heat, as this may result in re or other

damage.

yDisconnect the power cord rst, and then

move or install the TV. Otherwise electric shock may occur.

ASSEMBLING AND PREPARING

ENGLISH

CAUTION

yBe careful not to touch or press the screen

area when adjusting the angle of the TV.

y Be careful not to press the screen with your

ngers or palm.

Tidying cables

1 Gather and bind the cables with the supplied

cable holder.

2 Place the cable on the hook located on the

stand base.

Cable Holder

ASSEMBLING AND PREPARING

Mounting on a wall

10 cm

For proper ventilation, allow a clearance of 10 cm on each side and from the wall. Detailed installation instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide.

If you intend to mount the TV to a wall, attach Wall mounting interface (optional parts) to the back of the TV. When you install the TV using the wall mounting interface (optional parts), attach it carefully so it will not drop.

1 If you use screw longer than standard, the

TV might be damaged internally.

2 If you use improper screw, the product

might be damaged and drop from mounted position. In this case, LG Electronics is not responsible for it.

Wall mount (A x B) 75 x 75

Standard screw M4 X L10

Number of screws 4

Wall mount bracket (optional)

10 cm

RW120

yWall mount (A x B)

ENGLISH

ASSEMBLING AND PREPARING

ENGLISH

CAUTION

yDisconnect the power first, and then

move or install the TV. Otherwise electric shock may occur.

yIf you install the TV on a ceiling or slanted

wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel.

yDo not over tighten the screws as this

may cause damage to the TV and void your warranty.

yUse the screws and wall mounts that

meet the VESA standard. Any damages or injuries by misuse or using an improper accessory are not covered by the warranty.

yScrew length from outer surface of back

cover should be under 8mm.

Wall mount Pad

Back Cover

Wall mount Pad

Back Cover

Standard screw

: M4 x L10

Using the Kensington security system

The Kensington security system connector is located at the back of the TV. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit

http://www.kensington.com

Connect the Kensington security system cable between the TV and a table.

NOTE

yThe Kensington security system is optional.

You can obtain additional accessories from most electronics stores.

Max.8mm

NOTE

yUse the screws that are listed on the

VESA standard screw specifications.

yThe wall mount kit includes an installation

manual and necessary parts.

yThe wall mount bracket is optional. You

can obtain additional accessories from your local dealer.

yThe length of screws may differ

depending on the wall mount. Be sure to use the proper length.

yFor more information, refer to the

instructions supplied with the wall mount.

WATCHING TV

Turning the TV on for the rst time

When you access the TV for the rst time, the Factory Reset screen appears. Select a language and

customize the basic settings.

1 Connect the power cord to a power outlet. 2 Standby Light is turned on. Set the joystick buttons on the TV or press the power, TV/PC, P

INPUT, number buttons on the remote control to turn the TV on. The Standby Light is turned off.

3 The Factory Reset screen appears if you access the TV for the rst time.

NOTE

yIf you do not operate the TV within 40 seconds when the setting menu screen appears, the setting

menus will disappear.

4 Follow the on-screen instructions to customize your TV according to your preferences.

Language Selects a language for the display.



Country Selects a country to display.



Mode Setting



Power Indicator



Time Zone



Set Password



Network Setting



Auto Tuning Scans and saves available programmes automatically.

Selects Home Use for the home environment.

Selects the Standby Light. If you select On, the TV turns on the Standby Light in the front panel when the TV is off.

Selects the time zone and daylight saving. (When Russia is selected for Country)

Set the password. (When France/Italy is selected for Country)

(If there is LAN port) selects Network Setting to display. (Only UK, **UT55V models)

ENGLISH

WATCHING TV

ENGLISH

NOTE

yFor those countries without conrmed DTV broadcasting standards, some DTV features might not

work, depending on the DTV broadcasting environment.

yWhen France is selected for Country, the initial password is not ‘0’, ‘0’, ‘0’, ‘0’ but ‘1’, ‘2’, ‘3’, ‘4’. yTo display images in the best quality for your home environment, select Home Use mode. yStore Demo mode is suitable for the retail environment. yIf you select Store Demo mode, the previously customized settings will switch to the default settings

of Store Demo mode in 5 minutes.

5 When the basic settings are complete, press OK .

NOTE

yIf you do not complete the Factory Reset, it will appear whenever you access the TV.

6 To turn the TV off, press the power button on the remote control or joystick button for a few second.

The Standby Light is turned on.

CAUTION

yDisconnect the power cord from the power outlet when you do not use the TV for a long period of

time.

NOTE

yYou can also switch the TV from PC mode to TV mode, press TV/PC. yYou can also access Factory Reset by accessing

OPTION

in the main menus.

WATCHING TV

TV/PC

4 5 6

7 8 9

LIST

SUBTITLE

TEXT

INFO

T.OPT

Q.VIEW

2 3

INPUT

TV/

RAD

TV display (5:9 OSD)

Programme Guide

Press the GUIDE button on the remote control while you are watching TV.

- On the right-hand side (5:9 OSD) of the TV screen, the details of programme you are currently watching and the programme organization information are displayed.

- DTV channels are marked only in ‘Other Channels’ list.

NO. Description

Displays the programme you are currently watching.

Displays the broadcasting type of the programme you are currently watching.

Displays the broadcasting type icon.

(e.g., HD, Dolby, Digital, etc.)

Displays the current date and time.

Displays the current programme schedule or the entire programme list.

Displays the information of programme you are currently watching.

Displays the running time of the programme.

- Displays the progress including start and end times of the programme.

Displays the available functions.

- If the programme you are currently watching is focused, the Watch function is displayed.

- If the programme you are not currently watching is focused, the Remind function is displayed.

- If other channel guide is focused, the Watch function is displayed.

Displays the programme guide for all programmes.



%57

5 6





















: : 

▶

◀

Time All

DOLBY DIGITAL

▶

▶ /

▶

FAV

GUIDE

MUTE

Schedule











.FOV$IBOHF



▶

Watch

ENGLISH

WATCHING TV

TV/PC

4 5 6

7 8 9

LIST

SUBTITLE

TEXT

SETTINGS

Q.MENU

INFO

T.OPT

Q.VIEW

FAV

GUIDE

MUTE

2 3

INPUT

TV/ RAD

PIP SETTINGS

TV/PC

4 5 6

7 8 9

LIST

SUBTITLE

TEXT

INFO

T.OPT

Q.VIEW

FAV

GUIDE

MUTE

2 3

INPUT

TV/ RAD

ENGLISH

PIP function

Press the PIP button on the remote control while you are watching HDMI1, 2, DisplayPort.

- Congured Sub screen is saved until change the Main screen.

While watching PIP, press the PIP SETTINGS button on the remote control to display the Sub Menu.

PIP

Sub

Off

PIP Preview

V GaG

Move OK Back

SETTINGS

PIP SETTINGS

REC/

Component

HDMI2

DisplayPort

oktpX

VඖGaG

EXIT

ඔGaG

Q.MENU

East control

Function

PIP

Screen

Settings

Reset

PIP Sub

Size Position Audio Ratio Transparency

PIP Preview

)%.* 57

ⶸ ⶼ

Move OK

①



②

SubMain

ⶺ

Back

ⶾ

WATCHING TV

NO. Description

Sub

Size Sets the size of the PIP Sub window. (Small / Medium / Large / Balanced)

Position

Audio

Ratio

Transparency

Displays the congured OSD icon and its name.

PIP Map

Current

input

Sets the position of the PIP Sub window. (Bottom Right / Bottiom Left / Top Left / Top Right)

* This function is disabled when the size is set to [Balanced].

Selects the audio input.

* Only the items that are available under the current combination are enabled

Sets the aspect ratio of PIP Sub.

* This function is enabled when Size is set to [Balanced].

Sets the opacity of PIP. (Off / 25 % / 50 % / 75 %)

* This function is disabled when Size is set to [Balanced].

HDMI1 X O O O O X X

HDMI2 O X O O O X X

DisplayPort O O X O O X X

TV X X X X X X X

Component X X X X X X X

AV1 X X X X X X X

AV2 X X X X X X X

(PIP Main / PIP Sub).

HDMI1 HDMI2

Display

Port

PIP Sub

TV Component AV1 AV2

ENGLISH

MAKING CONNECTIONS

ENGLISH

MAKING CONNECTIONS

Connect various external devices to the TV and switch input modes to select an external device. For more information about an external device’s connection, refer to the manual supplied with each device. Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, camcorders or cameras, gaming devices, and other external devices.

NOTE

yIf you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input

cable to the TV through a DVD recorder or VCR. For more information about recording, refer to the

manual supplied with the connected device.

yThe external device connection may differ from the model. yConnect external devices to the TV regardless of the order of the TV port.

Connecting an antenna

Connect an antenna, cable or cable box to watch TV referring to the following. The illustrations may differ from the actual accessories and an RF cable is optional.

Connect the TV to a wall antenna socket with an RF cable (75 Ω).

Wall Antenna Socket

NOTE

yUse a signal splitter to use more than 2

TVs.

yIf the image quality is poor, install a signal

amplifier properly to improve the image quality.

yIf the image quality is poor with an

antenna connected, aim the antenna to the proper direction.

http://AntennaWeb.org

yVisit

information about the antenna and cable connection.

for more

(Not Provided)

yMake sure not to bend the copper wire

of the RF cable.

Copper wire

yComplete all connections instructions

between devices, and then connect the power cord to the power outlet to prevent damages to your TV.

Outdoor Antenna

yVHF Antenna yUHF Antenna

CAUTION

MAKING CONNECTIONS

Satellite connection

Connect the TV to a satellite dish to a satellite socket with a satellite RF cable (75 Ω).

(Not Provided)

13/18 V 700mA Max LNB IN

Satellite

ENGLISH

MAKING CONNECTIONS

ENGLISH

External Device Connections

Connect a HD receiver, DVD Player, VCR or Gaming device to the TV and select an appropriate input mode.

HDMI connection

HDMI is the best way to connect a device.

Transmits the digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown on the following illustration.

NOTE

yHDMI cable to the HDMI input and a digital broadcast receiver, connect the HDMI output. Video,

with sound output.

yPress the yDolby Digital and DTS are not supported. If no sound is coming out, set the audio output of the

connected device to PCM.

yUsing a non-standard HDMI cable may cause a problem with some of the functions. It is highly

recommended to use a standard cable.

INPUT

button on the remote control to select either HDMI IN 1 or HDMI IN 2.

HDMI IN 1

HDMI IN 2

yChoose any HDMI input port to connect. yIt does not matter which port you use.

HDMI OUT

DVD / Blu-Ray / HD Cable Box /

HD STB / Gaming device

MAKING CONNECTIONS

Component connection

Transmits the analogue video and audio signals from an external device to the TV. Connect the external device and the TV with the component cable as shown on the following illustration. To display images by using progressive scan, make sure to use a component cable.

NOTE

yIf cables are installed incorrectly, image is displayed as black-and-white or abnormal colour. yCheck to ensure each cable is matched with the corresponding colour connection. yPress the

INPUT

button on the remote control to select component.

COMPONENT IN Y

VIDEO

(Not Provided) (Not Provided)

ENGLISH

DVD / Blu-Ray / HD Cable Box /

HD STB / Gaming device

MAKING CONNECTIONS

ENGLISH

Composite connection

Transmits the analogue video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown on the following illustration.

NOTE

yCheck to ensure each cable is matched with the corresponding colour connection. yPress the

INPUT

button on the remote control to select AV2.

COMPONENT IN Y

VIDEO

(Not Provided)

DVD / Blu-Ray / HD Cable Box /

HD STB / Gaming device

MAKING CONNECTIONS

Euro Scart connection

Transmits the video and audio signals from an external device to the TV. Connect the external device and the TV with the Euro Scart cable as shown on the following illustration.

Output Type

Current input mode

Digital TV Digital TV

Analogue TV Analogue TV

Component, AV, HDMI Analogue TV

1 TV Out : Outputs Analogue TV or Digital TV signals.

NOTE

yAny Euro cable used must be shielded for signal quality.

AV1 (TV Out1)

ENGLISH

DVD / Blu-Ray / HD Cable Box

(Not Provided)

MAKING CONNECTIONS

ENGLISH

Headphone connection

Transmits the headphone signal from the TV to an external device. Connect the TV with the headphone as shown on the following illustration.

NOTE

yAUDIO menu items are disabled when connecting a headphone. yHeadphone impedance: 16 yMax audio output of headphone: 2.5 mW to 5.5 mW yHeadphone jack size: 0.35 cm

(Not Provided)

Headphone

MAKING CONNECTIONS

Connecting a USB Device

Connect a USB storage device such as s USB ash memory, external hard drive, MP3 player or a USB memory card reader to the TV and select input as USB to use various multimedia les.

NOTE

yIt may not work when USB 3.0 devices are connected.

ENGLISH

USB / HDD

(Not Provided)

1 The USB port provides 0.5 A electric current. If you need more electric current in the case of an HDD,

use a separate power adaptor.

MAKING CONNECTIONS

ENGLISH

CI module connection

View the encrypted (pay) services in digital TV mode. This feature is not available in all countries.

NOTE

yCheck if the CI module is inserted into the PCMCIA CARD SLOT in the right direction. If the module is

not inserted properly, this can cause damage to the TV and the PCMCIA CARD SLOT.

yIf the TV does not display any video and audio when CI+ CAM is connected, please contact to the

Antenna/Cable/Satellite Service Operator.

▲ PCMCIA ▲

CARD SLOT

(Not Provided)

▲ PCMCIA ▲

CARD SLOT

MAKING CONNECTIONS

Connecting to a wired network

(Only UK)

Connect the TV to a local area network (LAN) via the LAN port as shown on the following illustration and set up the network settings. After making a physical connection, a small number of home networks may require the TV network settings to be adjusted. For most home networks, the TV will connect to automatically without any adjustments. For detail information, contact your internet provider or router manual.

CAUTION

yDo not connect a modular phone cable to the LAN port. ySince there are various connection methods, please follow the specifications of your

telecommunication carrier or internet service provider.

LAN

ENGLISH

(Not Provided)

1 2 3 4

LAN

NOTE

yUK: LAN port is available. (The LAN port is added to support HD MHEG.) yOther areas: LAN port is not available.

MAKING CONNECTIONS

ENGLISH

Connecting to a PC

Your TV supports the Plug & Play* feature.

* Plug & Play: The function when a PC recognizes a connected device and requires no driver to be

installed.

NOTE

yIt is recommended to use an TV with the HDMI connection for the best image quality. yIf you turn the TV on when the set is cold, the screen may icker. This is normal. ySome red, green, or blue spots may appear on the screen. This is normal. yDo not press the screen with your nger for a long time as this may result in temporary distortion on

the screen.

yAvoid displaying a xed image on the screen for a long period of time to prevent image burn. Use a

screensaver if possible.

yWhen connecting the power cord to the outlet, use a grounded (3-hole) multi-socket or a grounded

power outlet.

MAKING CONNECTIONS

HDMI connection

Transmits the digital video and audio signals from your PC to the TV. Connect the PC and the TV with an HDMI cable as shown in the following illustrations.

NOTE

yUse a High Speed HDMI® cable. yPlease check your PC settings if you cannot hear any sound in HDMI mode. yPress the yUsing a DVI to HDMI cable may cause compatibility issues. yIf the PC is connected through a HDMI, the device may cause compatibility issues. yDolby Digital and DTS are not supported. If no sound is coming out, set the audio output of the

connected device to PCM.

yUsing a non-standard HDMI cable may cause a problem with some of the functions. It is highly

recommended to use a standard cable.

INPUT

button on the remote control to select either HDMI IN 1 or HDMI IN 2.

HDMI IN 1

HDMI IN 2

yChoose any HDMI input port to connect. yIt does not matter which port you use.

ENGLISH

HDMI OUT

MAKING CONNECTIONS

ENGLISH

Display Port connection

Transmits the digital video and audio signals from your PC to the TV. Connect your PC to the TV using the display port cable as illustrated below.

NOTE

ySound may not hear depending on the DP version of your PC. yDolby Digital and DTS are not supported. If no sound is coming out, set the audio output of the

connected device to PCM.

yPress the yUsing a DP to HDMI or DP to DVI cable may cause compatibility issues. yHDMI signals are not converted to DP signals. If you use a DP to HDMI cable, you can watch your

media on a PC or other device with DP output by using the HDMI port.

INPUT

button on the remote control to select DisplayPort.

DP - IN

DP OUT

(Not Provided)

REMOTE CONTROL

The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching the and ends to the label inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse.

CAUTION

yDo not mix old and new batteries, as this may damage the remote control.

Make sure to point the remote control toward the remote control sensor on the TV.

(POWER) Turns the TV on or off. TV/RAD Selects Radio, TV and DTV programme. SUBTITLE Recalls your preferred subtitle in digital mode.

AD By pressing the AD button, audio descriptions function will be

enabled.

TV/PC Selects TV or PC mode.

INPUT Changes the input source.

Number buttons Enters numbers. LIST Accesses the saved programme list. Q.VIEW Returns to the previously viewed programme.

Adjusts the volume level.

FAV Accesses your favourite programme list. GUIDE Shows programme guide. MUTE Mutes all sounds.

Scrolls through the saved programmes

PAGE Moves to the previous or next screen.

Teletext buttons( TEXT / T.OPT) These buttons are used for

teletext.

INFO Views the information of the current programme and screen.

SETTINGS Accesses the main menus. PIP SETTINGS PIP Displays the Menu screen for the PIP mode. Q. MENU Accesses the quick menus. Navigation buttons (up/down/left/right) Scrolls through menus or

options.

OK Selects menus or options and conrms your input.

BACK Returns to the previous level.

EXIT Clears all on-screen displays and return to TV viewing.

PIP

Turns the PIP mode on or off.

Starts to record and displays record menu. (Depending on

model)

Control buttons ( ) Controls the USB menus, or the compatible devices (USB). Colour buttons These access special functions in some menus. ( : Red, : Green, : Yellow, : Blue)

(Backlight)

the screen backlight.

Adjusts the brightness of the screen by controlling

SUBTITLE

TV/PC

2 3

4 5 6

7 8 9

LIST

SETTINGS

PIP SETTINGS

TEXT

PIP

FAV

GUIDE

MUTE

INFO

REC/

TV/ RAD

INPUT

Q.VIEW

T.OPT

Q.MENU

EXIT

ENGLISH

NOTE

y On MHEG programme, you cannot adjust the backlight with the yellow or blue key.

INSTALLING LG MONITOR SOFTWARE

ENGLISH

INSTALLING LG MONITOR SOFTWARE

Insert the the Software CD included in the product package into your PC's CD driver and install the LG Monitor Software.

1 Set up Internet Explorer as the default web

browser.

2 Click 'LG Monitor Software' on the CD's main

screen. When the le download window

appears, click 'Run'. (Although the screen below may differ depending on your operating system or Internet Explorer version, the installation methods are the same.)

NOTE

yWindows 7 must be updated to Service Pack

1 or higher.

yVersions before internet explorer 7 and

internet explorer 7 may not be supported.

3 Follow the instructions to proceed with the

installation.

4 Check 'I accept the terms of the agreement'

on the License Agreement screen and then click the 'Next' button.

5 Select the programme that you want to

install.

NOTE

yScreen Split : This program automatically

splits the program window as desired.

yAuto Resolution: This is a program that

auto-matically changes the resolution to the optimal settings when connecting the monitor to the PC in PIP mode.

※

This program is not supported in Clone

Mode.

※

Extended Mode is not supported when

using a single display.

6 The LG Monitor Software starts the

installation as shown below:

7 The program you selected on the FUNCTION

page will install automatically.

INSTALLING LG MONITOR SOFTWARE

8 When the installation is complete, restart

your system.

NOTE

1 If you run Screen Split, the Screen Split

icon [ ] appears in the system tray at the

right bottom of the PC screen.

2 Right-click the Screen Split icon and select

a layout you want.

ENGLISH

CUSTOMIZING SETTINGS

ENGLISH

CUSTOMIZING SETTINGS

Accessing the Main Menus

The menus displayed on the TV screen may vary depending on the selected input mode.

TV, Component, AV

1 Press 2 Press the Navigation buttons to scroll to one of the following menus and press 3 Press the Navigation buttons to scroll to the setting or option you want and press 4 When you are nished, press

SETTINGS

When you return to the previous menu, press

PICTURE Adjusts the image size, quality or effect.

AUDIO Adjusts the sound quality, effect or volume level.

SETUP Sets up and edit programmes.

TIME Sets the time, date or Timer feature.

LOCK Locks or unlocks channels and programmes.

OPTION Customizes the general settings.

NETWORK Sets the network. (Apply: UK country)

to access the main menus.

EXIT

BACK

CUSTOMIZING SETTINGS


To select Picture Mode

SETTINGS> PICTURE> Picture Mode

Select the picture mode optimized for the viewing environment or the programme. Depending on input signal, available range of picture modes may differ.

ꕋ Expert mode is for picture tuning professionals to control and ne-tune using a specic image. For

normal images, the effects may not be dramatic.

Vivid Heightens contrast, brightness and sharpness to display vivid images.

Standard Displays images in standard levels of contrast, brightness and sharpness.

Eco

Cinema / Game Displays the optimum picture for movie, game.

Sport [This feature is available in certain countries only.] Optimised picture mode for

ꕋ Expert1 ꕋ Expert2

To ne-tune picture mode

SETTINGS> PICTURE> Picture Mode> Backlight / Contrast / Brightness / Sharpness / Colour / Tint / Colour Temp.

First select a Picture Mode of your choice. Depending on the input signal or other picture settings, the range of detailed items for adjustment may differ.

Backlight

Contrast

Brightness

Sharpness

Colour

Tint

Colour Temp. Adjusts the overall tint of the picture.

To set Advanced Control / Expert Control

SETTINGS> PICTURE> Picture Mode> Advanced Control / Expert Control

For each picture mode, screen can be calibrated; or for a special screen, picture settings can be adjusted. Select the desired Picture Mode. Depending on input signal or other picture settings, the range of detailed items for adjustment may differ.

Dynamic Contrast Adjusts the contrast to the optimal level according to the image’s brightness.

Dynamic Colour Adjusts colours to make the image appear in more natural colours.

Skin Colour Sets Skin colour spectrum separately to implement the skin colour as dened by

Sky Colour Sky colour is set separately.

Grass Colour Natural colour spectrum (meadows, hills, etc.) can be separately set.

Gamma Sets the gradation curve according to the output of picture signal in relation to the

Color Gamut

Edge Enhancer

[This feature is available in certain countries only] The Energy Saver feature changes settings on the TV to reduce power consumption.

sport. The pitch and kits are presented in vibrant colours, with crystal-clear images even for fast movements.

Menu for adjusting picture quality that allows experts and amateurs to enjoy the

best TV viewing. This menu for adjustment is provided for ISF-certied picture tuning professionals. (ISF logo can only be used on ISF-certied TVs.) ISFccc: Imaging Science Foundation Certied Calibration Control

The ISF function is only available on some models.

Adjusts the display brightness by varying the brightness of the LCD panel.

Adjusts the Colour contrast and brightness of the screen.

Adjusts the sharpness of the screen.

Adjusts the Colour depth of the screen.

Adjusts the gamma, Colour temperature and Colour of the screen.

In Expert mode, you can ne-tune the picture using the Gamma or Method options.

the user.

input signal.

Selects the range of colors that can be expressed.

Shows clearer and distinctive yet natural edges of the video.


ENGLISH

CUSTOMIZING SETTINGS

ENGLISH

Expert Pattern [This feature is available on certain models only] Patterns used for expert

Color Filter Filters a specic color spectrum in RGB colors to ne-tune color saturation and hue

Color Temperature Adjusts the overall tone of the screen as desired. In Expert mode, detailed ne-

Color Management System

To set Picture Option

SETTINGS> PICTURE> Picture Mode> Picture Option

Adjusts detailed setting for images. Depending on input signal or other picture settings, the range of detailed items for adjustment may differ.

Noise Reduction Eliminates noise in the picture

MPEG Noise Reduction Eliminates noise generated while creating digital picture signals.

Black Level Adjusts the screen’s brightness and contrast to t them to the input picture’s

Real Cinema Optimizes the screen for movie viewing.

Motion Eye Care [This feature is available on certain models only.] Saves power consumption

To set Picture Reset

SETTINGS> PICTURE> Picture Mode> Picture Reset

Resets picture settings that the user customizes. Each picture mode is reset. Select the desired picture mode to reset.

To adjust Aspect Ratio

Selects the screen aspect ratio.

SETTINGS> PICTURE> Aspect Ratio

16:9

21:9

Just Scan Displays video images in the original size without removing parts of the edge of the

Original When your TV receives a wide screen signal it will automatically change to the

Full Wide When TV receives the wide screen signal, it will let you adjust the picture horizontally

4:3 Resizes the image ratio to t 4:3 screen.

14:9 You can view a picture format of 14:9 or a general TV programme in the 14:9 mode.

Zoom Resizes the image to t the screen width. The top and bottom parts of the image may

Cinema Zoom 1

While viewing an external device, these cases may result in image burn:

- a video with stationary caption (such as network name)

- 4 : 3 aspect ratio mode for an extended period Take caution when using these functions. Available picture size may differ depending on the input signal.

adjustment.

accurately.

tuning can be set via Gamma method, etc.

This system is used by experts to adjust color with a test pattern. They can select from six color areas (Red/ Green/Blue/Cyan/Magenta/Yellow) without affecting other colors. For normal images, adjustments may not result in noticeable color changes.

black level by using the blackness (black level) of the screen.

by adjusting the brightness corresponding to the movement of the image on the screen.

Resizes the image ratio to t 16:9 screen.

Resizes the image ratio to t 21:9 screen.

image. In DTV, Component(over 720 p) mode, Just Scan is available.

picture format broadcasted.

or vertically, in a linear proportion,to ll the entire screen fully. 4:3 and 14:9 video is

supported in full screen without any video distortion through DTV input. [This function is only available in the EU, China, and Hong Kong.] In Analogue/DTV/AV/Scart mode, Full Wide is available.

The 14:9 screen is viewed in the same way as in 4:3, but is moved up or down.

be cut off.

Choose Cinema Zoom when you want to enlarge the picture in correct proportion.

CUSTOMIZING SETTINGS

AUDIO

To use Sound Mode

SETTINGS> AUDIO> Sound Mode

Adjusts TV audio to an optimal level based on a selected sound mode.

Standard

News / Music / Cinema / Sport / Game

Using the Sound Effect function

SETTINGS> AUDIO> Sound Effect

the user can select various sound effects. Sound Effect function is available only for Standard mode in Sound Mode menu.

To adjust Clear Voice ll function

SETTINGS> AUDIO> Sound Effect> Clear Voice ll

Boosts voice clarity from the TV.

To use MaxxAudio

SETTINGS> AUDIO> Sound Effect> MaxxAudio

MaxxAudio® by Waves, recipient of a Technical GRAMMY Award® is a suite of studio-quality sound tools for a superior listening experience.

To adjust User Setting function

SETTINGS> AUDIO> Sound Effect> User Setting

Adjusts the volume to a level of your choice using the User EQ.

Reset

To adjust audio balance

SETTINGS> AUDIO> Sound Effect> Balance

Adjusts left/right audio balance.

Initializing the Sound Effect function

SETTINGS> AUDIO> Sound Effect> Reset

Initialize the applied effect under the Sound Effect menu.

To set Auto Volume

SETTINGS> AUDIO> Auto Volume

Auto Volume to On. Varying volume output from channel to channel is automatically adjusted for convenient TV watching when clicking through different programme.

To set sound out

SETTINGS> AUDIO> Sound Out

TV Speaker Sound is output through the TV speaker.

Headphone

Suitable for all types of video.

Sets audio optimized for a specic genre.

Sport : This feature is available in certain countries only. News : This feature is available on certain models only.

Resets voice options that the user has changed.

[Only available for models with an earphone/headphone port] Sound is output through the headphone connected to the earphone/headphone port. If you connect headphones while the TV is powered on, it automatically detects the headphones and sounds through them.

AUDIO

ENGLISH

CUSTOMIZING SETTINGS

ENGLISH

To use DTV Audio Setting function

SETTINGS> AUDIO> DTV Audio Setting

[Depending on model] When different audio types exist in an input signal, this function allows you to select the audio type you want. If set to AUTO, the search order is HE-AAC → Dolby Digital+ → Dolby Digital → MPEG and output is

produced in the rst Audio Format found.

In Italy / Latvia / Lithuania only, the search order is HE-AAC → Dolby Digital+ → MPEG → Dolby Digital.

- If the selected Audio Format is not supported, another Audio Format may be used for output

To set AV Sync

SETTINGS> AUDIO> AV Sync. Adjust

Synchronizes video and audio directly when they do not match.

To use Sound Optimizer function

SETTINGS> AUDIO> Sound Optimizer

Optimized sound for custom TV installation.

Normal General sound mode.

Wall Mount Type Optimizes sound for a wall-mounted TV.

Stand Type Optimizes sound for a stand-mounted TV.

CUSTOMIZING SETTINGS

SETUP

To view programme information

Press 'INFO' button.

Displays information on current programme and/or current time, etc.

TV Guide

Press 'GUIDE' button.

[In Digital mode only] Obtains information about programmes and airtime. Checks the broadcasting time of the desired programme and schedule viewing.

Automatically Setting Up Programme

SETTINGS> SETUP> Auto Tuning

Automatically tunes the programmes.

1.Select Country where the TV is used. Programme settings change depending on the country you choose.

2.Initiate Auto Tuning.

3.Select Input Source of your choice.

4.Set Auto Tuning following screen instructions. If Input Source is not connected properly, programme registration may not work.

Auto Tuning only nds programmes that are currently broadcasting.

If Lock System is turned on, a pop-up window will appear asking for password.

Cable DTV Setting option

When searching for programmes using FULL setting it can take a long time. The following values are needed in order to search all available programmes quickly and correctly. The commonly used values are provided as “default”.

Frequency

Symbol rate Enter a user-dened symbol rate (Symbol rate: Speed at which a device such as

Modulation Enter a user-dened modulation. (Modulation: Loading of audio or video signals

Network ID

Start Frequency

End Frequency

Cable DTV Setting

SETTINGS> SETUP> Cable DTV Setting

[In Cable mode only] When Channel Auto Update is On, you can update information for all the programmes that can be updated, including the programme currently being watched. When Channel Auto Update is Off, you can only update information for the programme currently being watched. The range that a user can select from the Service Operator menu differs depending on number of Service Operator supported by each country. If number of supported Service Operator for each country is 1, corresponding function becomes inactive.

To use Manual Tuning

SETTINGS> SETUP> Manual Tuning

Adjusts programmes manually and saves the results. For digital broadcasting, signal strength and signal quality can be checked.

For analogue broadcasting, you can set up station names and use ne tuning. Normally ne tuning is

only necessary if reception is poor. [This feature is available on certain models only] You can also adjust the Frequency(KHz) and Bandwidth.

Enter a user-dened frequency.

modem sends symbols to a programme).

onto carrier).

Unique identier allocated for each user.

Enter a user-dened start frequency range.

Enter a user-dened end frequency range.

SETUP

ENGLISH

CUSTOMIZING SETTINGS

ENGLISH

To edit programmes

SETTINGS> SETUP> Programme Edit

Edits the saved programmes. Set as favourite programme, block/unblock programme, skip programme etc. of the selected programme.

To set favourite programmes

SETTINGS> SETUP> Programme Edit

[This feature is available on certain models only.]

1.Select the channel you want.

2.Press the FAV button to select Favourite Group and then OK. You can check your favourite channels by pressing the LIST button on the remote control.

To use Favourite

Press the 'FAV' button.

You can only view the channels you set as favourites.

SETTINGS> SETUP> Programme Mode

[Depending on model] This function allows you to watch a tuned program in Antenna, Cable, Satellite, or CAM Mode.

- You can only watch programs in the selected mode.

- The CAM menu is only available when the CAM Mode is enabled. The menu name may vary depending on the CAM type.

CI Information

SETTINGS> SETUP> CI Information

- This function enables you to watch some encrypted services (pay services).

- If you remove the CI Module, you cannot watch pay services.

- CI (Common Interface) functions may not be possible depending upon the country broadcasting circumstances.

- When the module is inserted into the CI slot, you can access the module menu.

- To purchase a module and smart card, contact your dealer.

- When the TV is turned on after inserting a CI Module, you may not have any sound output. The Smart Card may not be compatible with the CI module.

- When using a CAM(Conditional Access Module), please make sure it meets fully the requirements of either DVB-CI or CI plus.

- An abnormal process of CAM(Conditional Access Module) may cause a bad picture.

- [Depending on model] If the TV does not display any video and audio when CI+ CAM is connected, please contact to the Antenna/Cable/Satellite Service Operator.

Teletext [Depending on the country]

Press 'TEXT' button.

Teletext is a free service provided by the TV station that offers text-based information about TV programmes, news and weather. The teletext decoder of this TV can support the SIMPLE, TOP and FASTEXT systems.

- Colour button: To select the preceding or following page.

- Number button: Enters the desired page number.

- P

: To select the preceding or following page.

Press 'T.OPT' button.

* Special Teletext Function Select the Text Option menu.

- Index : Select each index page.

- Time : When viewing a TV programme, select this menu to display the time at the top right hand corner of the screen.

- Hold : Stops the automatic page change which will occur if a teletext page consists of 2 or more sub pages.

- Reveal : Select this menu to display concealed information, such as solutions to riddles or puzzles.

- Update : Displays the TV picture on the screen while waiting for a new teletext page.

- Language [In Digital Mode Only] : Sets Teletext language.

CUSTOMIZING SETTINGS

Digital Teletext

Press the 'TEXT' button.

[In UK/Ireland only] The TV gives you access to digital teletext which gives much better text,graphics etc. than older

analogue teletext. This digital teletext can access special digital teletext services and specic services

which broadcast digital teletext.

* Teletext within digital service

1.Press the numeric or P button to select a certain service which broadcasts digital teletext.

2.Follow the indications on digital teletext and move onto the next step by pressing TEXT, OK, Navigation, Red, Green, Yellow, Blue or NUMBER buttons etc..

3.Press the number or P button to use a different digital teletext service.

* Teletext in digital service

1.Press the numeric or P button to select a certain service which broadcasts digital teletext.

2.Press the TEXT or colour button to switch on teletext.

3.Follow the indications on digital teletext and move onto the next step by pressing OK, Navigation, Red, Green, Yellow, Blue or NUMBER buttons etc..

4.Press the TEXT or colour button to switch off digital teletext and return to TV viewing.

TIME

To set current time

SETTINGS> TIME> Clock

Checks or changes the time while watching TV.

Auto

Manual

To set the TV to turn on and off automatically

SETTINGS> TIME> Off Time / On Time

Sets On / Off time. Select Off on Repeat to discontinue On Time / Off Time. To use On Time / Off Time, set the current time correctly. Even when the On Time function is on, the TV will turn off automatically in 120 minutes when no button is pressed within that time.

To use Sleep Timer

SETTINGS> TIME> Sleep Timer

Turns off the TV after a preset number of minutes. To cancel the Sleep Timer, select Off.

To set Automatic Standby

SETTING> TIME> Automatic Standby

[This function is available on certain models or in certain countries only] If you do not press any button on the TV or remote control for a certain period, the TV will automatically switch to standby mode. This function does not work on Store Demo mode or while software update.

Synchronizes the TV clock to the digital time information sent by the TV station.

Sets the time and date manually if the auto setup does not correspond to the current time.

TIME

ENGLISH

CUSTOMIZING SETTINGS

ENGLISH

LOCK

To set the password

SETTINGS> LOCK> Set Password

Set or change the TV password. The initial password is set as [0000]. When France is selected for Country, password is not ‘0’,‘0’,‘0’,‘0’ but ‘1’,’2’,’3’,’4’. When France is selected for Country, password cannot be set as ‘0’,‘0’,‘0’,‘0’ .

To lock the system

SETTINGS> LOCK> Lock System

Locks the selected programme. First set Lock System to On.

Block Programme Blocks programmes with content inappropriate for children. Programmes can

be selected but the screen is blank and the audio is muted. To watch a locked programme, enter the password.

Parental Guidance This function operates according to information from the broadcaster. Therefore

if the signal has incorrect information, this function does not operate. Prevents children from watching certain adult TV programmes according to the ratings limit set. Enter a password to watch a blocked programme. Ratings differ by country.

To use Key Lock

SETTINGS> LOCK> Key Lock

Locks control buttons on the TV. Key Lock function remains intact even in case of power outage or when the power cord is removed from the wall socket. Key Lock function can only be set by remote control, and not by the button on the TV. Even with Key Lock ON, TV’s buttons can turn on the power.

LOCK

CUSTOMIZING SETTINGS

OPTION

SETTINGS> OPTION> Language(Language)

You can select the language of the menu displayed on the screen and the digital sound broadcasting.

Menu Language Selects a language for the display text.

Audio Language [In Digital mode Only]: Selects the desired language when watching digital

Subtitle Language [In Digital mode Only]: [This feature is available in certain countries only.]

Text Language [In Digital mode Only]: [This feature is available in certain countries only.]

SETTINGS> OPTION> Country

[Depending on country] Sets the country that the TV uses. TV settings are changed according to the broadcast environment of the selected country. If the country setting is changed, the Auto Tuning information screen may appear.

In a country that Digital broadcasting regulation isn’t xed, some DTV functions may not work depending

on digital broadcasting circumstances. If the country setting is set to “--”, European terrestrial digital standard broadcasting programmes are available, but some DTV functions may not work properly.

SETTINGS> OPTION> Disability Assistance

Audio commentary or subtitles are provided for those who are hard of hearing or visually impaired.

Hard of Hearing This function is used for the hearing impaired. If it is set to on, the subtitle is

Audio Description This function is for the blind, and provides explanatory audio describing the

To set Power Indicator

SETTINGS> OPTION> Standby Light

[This function is available on certain models or in certain countries only.] Turns the standby light in the front panel of the TV on/off.

To set up USB storage

SETTINGS> OPTION> Divx(R) VOD

Registration Checks DivX Reg. Code for replaying DivX protected videos. Register at http://

Deregistration

broadcasting containing several voice languages.

Use the Subtitle function when two or more subtitle languages are broadcast.

- If subtitle data in a selected language is not broadcast, the default language subtitle will be displayed.

Use the Text language function when two or more Text languages are broadcast.

- If teletext data in a selected language is not broadcast, the default Text language will be displayed.

- If you select the wrong local country, teletext may not appear correctly on the screen and some problems may occur during teletext operation.

displayed by default.

current situation in a TV programme in addition to the basic audio. When Audio Description is selected On, basic audio and Audio Description are provided only for those programmes that have Audio Description included.

vod.divx.com. Use Reg. Code to rent or purchase movies at www.divx.com/vod.

yRented/purchased DivX files cannot be played if the DivX Registration Code

of a different device is used. Use only the DivX Registration Code granted to this specific device.

yConverted files not conforming to the DivX Codec Standard may not play or

may produce abnormal sound.

Deregisters DivX.

ENGLISH

CUSTOMIZING SETTINGS

ENGLISH

To specify Factory Reset

SETTINGS> OPTION> Factory Reset

All stored information is deleted and TV settings are reset. TV turns itself off and back on, and all settings are reset. When Lock System is in place, a pop-up window appears and asks for password. Do not turn off the power during initialization.

To change TV mode

SETTINGS> OPTION> Mode Setting

Selects Standard or Store Demo. When in use in home, please select Standard. Store Demo mode is for store display.

SETTINGS> OPTION> Customer Support> Software Update

Uses Software Update to check and obtain the latest version. If not updated, certain functions may not work properly.

Software Update Set it to On. If an update is available, a prompt will appear to perform the update.

Automatic update mode

Check Update Version

yWhen the update starts, the update progress window appears for a short time and disappears. yThe latest version can be obtained via the digital broadcast signal or an internet connection.

[Depending on model]

yChanging the programme while downloading the software via a digital broadcast signal interrupts the

download process. Returning to the initial programme allows downloading to resume.

yIf software is not updated, certain functions may not work properly. y[For Finland/Sweden/Denmark/Norway models.]

If the software update is performed via the broadcasting signal, you will be prompted to continue the

update regardless of whether the Automatic update mode is enabled or not.

y[This feature is available in certain countries only.] It is also possible to check manually for available

updates.

SETTINGS> OPTION> Customer Support> Picture Test

[This feature is available on certain models only.]

Run an Picture Test rst to verify that the image signal output is normal.

If there is no problem with the test image, check connected external devices and the broadcast signal.

SETTINGS> OPTION> Customer Support> Sound Test

[This feature is available on certain models only.]

Run a Sound Test rst to verify that the sound signal output is normal.

If there is no problem with the test sound, check connected external devices and the broadcast signal.

Data Service

SETTINGS> OPTION> Data Service

[Depending on country] This function allows users to choose between MHEG (Digital Teletext) and Teletext if both exist at the same time. If only one of them exists, either MHEG or Teletext is enabled regardless of which option you selected.

[This feature is available on certain models only] If an update is available, the update automatically starts without prompting.

[This feature is available on certain models only] Checks the latest update version installed. When a new update is available, the download process can be performed manually.

CUSTOMIZING SETTINGS

To connect a USB device

Plays content stored on a USB device (external HDD, USB memory stick) directly on the TV, easily and conveniently. Connect the USB storage device to the TV's USB IN terminal. The connected USB storage device can be used immediately.

To remove the USB device

Q.MENU> USB device

Select a USB storage device that you want to remove. When you see a message that the USB device has been removed, separate the device from the TV. Once a USB device has been selected for removal, it can no longer be read. Remove the USB storage device and then re-connect it.

Using a USB storage device - warning

yIf the USB storage device has a built-in auto recognition program or uses its own driver, it may not

work.

ySome USB storage devices may not work or may work incorrectly. yUse only USB storage devices formatted with the Windows FAT32 or NTFS File System. yFor external USB HDDs, it is recommended that you use devices with a rated voltage of less than 5

V and a rated current of less than 500 mA.

yIt is recommended that you use USB memory sticks of 32 GB or less and USB HDDs of 1 TB or

less.

yIf a USB HDD with power-saving function does not work properly, turn the power off and on. For

more information, refer to the user manual of the USB HDD.

yData in the USB storage device can be damaged, so be sure to back up important files to other

devices. Data maintenance is the user's responsibility and the manufacturer is not responsible for

data loss.

To use USB storage

INPUT> USB> All Media / Movie List / Photo List / Music List

Selects a file from the list. Displays the file that you choose. Sets play related settings by checking option during disk playback.

yMovie List : This feature is available on certain models only.

ENGLISH

USB supporting file

Maximum data transfer rate

External subtitle formats supported

Internal subtitle formats supported

20 Mbps (megabits per second)

*.smi, *.srt, *.sub (MicroDVD, SubViewer 1.0/2.0), *.ass, *.ssa, *.txt (TMPlayer), *.psb (PowerDivX)

XSUB (supports internal subtitles generated from DivX6)

CUSTOMIZING SETTINGS

ENGLISH

Available video file

Maximum: 1920 x 1080 @ 30 p (only Motion JPEG 640 x 480 @ 30 p)

.asf, .wmv [Video] VC-1 Advanced Prole, VC-1 Simple and Main Proles, MP43

.3gp, .3gp2 [Video] H.264/AVC, MPEG-4 Part2

.divx, .avi [Video] DivX3.11, DivX4, DivX5, DivX6, XViD, H.264/AVC, Motion JPEG

.mp4, .m4v, .mov [Video] H.264/AVC, MPEG-4 Part 2, XViD

.mkv [Video] H.264/AVC, XViD, MPEG-4 Part2

.ts, .trp, .tp, .mts, .m2ts

.vob [Video] MPEG-1, MPEG-2

.mpg, .mpeg, .mpe [Video] MPEG-1

*DTS : Depending on model

Available music file

mp3 [Bit rate] 32 Kbps - 320 Kbps

AAC [Bit rate] Free Format

M4A [Bit rate] Free Format

OGG [Bit rate] Free Format

WMA [Bit rate] 128 kbps ~ 320 kbps

WMA 10 Pro [Bit rate] ~ 768 kbps

[Audio] WMA Standard

[Audio] AAC, AMR(NB/WB)

[Audio] MPEG-1 Layer I, II, Dolby Digital, MPEG-1 Layer III (MP3), *DTS

[Audio] AAC, MPEG-1 Layer III (MP3)

[Audio] HE-AAC, Dolby Digital, MPEG-1 Layer III (MP3), *DTS

[Video] H.264/AVC, MPEG-2 [Audio] MPEG-1 Layer I, II, MPEG-1 Layer III (MP3), Dolby Digital, Dolby Digital Plus, AAC

[Audio] Dolby Digital, MPEG-1 Layer I, II, DVD-LPCM

[Audio] MPEG-1 Layer I, II

[Sample freq.] 16 kHz - 48 kHz [Support] MPEG1, MPEG2, Layer2, Layer3

[Sample freq.] 8 kHz ~ 48 kHz [Support] ADIF, ADTS

[Sample freq.] 8 kHz ~ 48 kHz [Support] MPEG-4

[Sample freq.] ~ 48 kHz [Support] Vorvis

[Sample freq.] 8 kHz ~ 48 kHz [Support] WMA7, 8, 9 Standard

[Channel / Sample freq.]

- M0 : Up to 2 / 48 kHz

- M1 : Up to 5.1 / 48 kHz

- M2 : Up to 5.1 / 96 kHz [Support] WMA 10 Pro

CUSTOMIZING SETTINGS

Available photo file

2D(jpeg, jpg, jpe), 3D(jps)

3D (mpo) [Available le type] mpo

BMP [Photo size]

PNG [Available le type] Interlace, Non-Interlace

yBMP and PNG format files may be slower to display than JPEG. yThe 3D function may differ, depending on the model.

Items to note when playing videos

ySome subtitles created by users may not work properly. yThe video and subtitle files should be placed in the same folder. For subtitles to display correctly,

the video and subtitle files must have the same name.

yWe do not support any stream that contains GMC (Global Motion Compensation) or Qpel (Quarterpel

Motion Estimation).

yOnly H.264/AVC profile level 4.1 and lower is supported. yVideo files that exceed 50 GB (gigabyte) are not supported for playback. The file size limit is

dependent on the encoding environment.

yThe DTS is supported only for playback of USB and HDMI video files [depending on the model]. yThe DTS support may vary depending on your country and model.

[Available le type]

SOF0: baseline, SOF1: Extend Sequential, SOF2: Progressive [Photo size] Minimum: 64 x 64 Maximum: Normal Type: 15360 (W) x 8640 (H) Progressive Type: 1920 (W) x 1440 (H)

[Photo size] 4:3 size: 3,648 x 2,736 / 2,592 x 1,944 / 2,048 x 1,536 3:2 size: 3,648 x 2,432

Minimum : 64 x 64 Maximum : 9600 x 6400

[Photo size] Minimum : 64 x 64 Maximum : Interlace : 1200 x 800 Non-Interlace : 9600 x 6400

ENGLISH

CUSTOMIZING SETTINGS

ENGLISH

NETWORK

To connect to the network [Depending on model]

SETTINGS> NETWORK> Network Setting

Set IP Mode to IP Auto Setting or IP Manual Setting.

IP Auto Setting

IP Manual Setting

If you select IP Manual Setting, type in the IP address. Select OK to connect to the network.

Setting a network - warning

yUse a standard LAN cable (Cat5 or higher with RJ45 connector, 10 Base-T or 100 Base TX LAN

port).

yResetting your modem can cause network connection problems. To resolve the problem, turn the

power off, disconnect and reconnect, and then turn the power back on.

yLG Electronics is not responsible for any Internet connection problems or any faults, malfunctions

and errors caused by an Internet connection.

yA network connection may not work properly depending on the Internet service provider. yA DSL modem is required for a DSL service; a cable modem is required for a cable service. Only

a limited number of Internet connections may be available, and TV network setting may not be

available depending on your contract with your Internet Service Provider (ISP). (If only one device is

allowed per line and the PC is already connected, other devices cannot be used.)

yIf you do not turn off the entire local home network, network traffic may occur on some devices. yInvalid settings on network devices can cause the TV to run slowly or not operate properly. Install

the devices correctly according to the appropriate manual and set the network.

SETTINGS> NETWORK> Network Status

Display the network status.

- Internet is connected : Externally connected

- Network is connected : Only internally connected

- Not connected : When there is no network connection

Select this mode if your Internet service is broadband.

Select this mode if you are using the Internet in an ofce (for example, xed IP).

NETWORK

CUSTOMIZING SETTINGS

If the following symptoms occur, please carry out the checks and adjustments described below. There may be no malfunction.

Operational problems

Cannot view certain programmes.

Adjust the location or orientation of the antenna. Save the programmes you wish to view using Auto Tuning or Programme Edit.

There is a delay after the TV is switched on before the image is fully visible.

This is normal. Any delay is due to an image deletion process which cleans up image noise that may

occur when the TV is rst switched on.

Image problems

Images from previous programme or other programmes linger or the screen displays annoying lines.

Adjusts the orientation of the antenna to the TV transmitter, or refer to the manual for instructions on connecting the antenna.

Vibrating horizontal /vertical lines and fishnet patterns appear momentarily

Such a problem may happen when there is strong electronic interference. Turn off other electronic devices such as mobile phones, power tools and other small electrical appliances.

The screen display freezes or does not work properly during a digital broadcast.

This may occur in case of a weak signal or unstable reception. Adjust the antenna orientation and cable connections.

If the signal strength or quality is low on Manual Tuning, check with the TV station or administration ofce.

Digital broadcasting is not available even though the cable is connected.

Check with the cable operator providing your subscription and/or signal. (Depending on your subscription, digital broadcasting may not be supported.)

The display is inactive or unclear when connected to an HDMI® source.

Check the HDMI® cable specications. If your HDMI® cable is not genuine, images may fade in and out or not be displayed properly. Ensure that all cables are securely connected. When connections are not secure, images may not be properly displayed.

Does not work with a USB storage device.

Verify that the USB device and cable is version 2.0 or higher.

ENGLISH

CUSTOMIZING SETTINGS

ENGLISH

Sound problems

Screen display is on but there is no sound.

Check other TV programmes. [Depending on model] Ensure the TV Speaker is set to On.

For an analogue broadcast, stereo is not clear or sound comes from one speaker only.

In a poor reception area (areas with weak or unstable signals) or if Multi Audio is not stable, select Mono on Multi Audio. Adjust the Balance using the Navigation Button.

TV sound is not in sync with the image or the sound breaks up occasionally.

If the issue affects a specic TV programme only, it may be caused by problems with the broadcast

signal for the individual station. Check with the TV station or your cable operator.

The volume changes when I change programme.

Volume can vary from programme to programme. Set Auto Volume to On.

On certain programmes, there is no sound at all, or only the background music can be heard (in case of a programme created for overseas viewers).

In Language, set Language → Audio Language to the language of your choice. Even if you change the

language on Multi Audio, you can go back to the default setup once you turn off the power or change the programme.

There is no sound when connected to an HDMI® / USB source.

Make sure that the High Speed HDMI™ or HDMI® cable is high speed. Check that the USB device and cable is version 2.0 or higher.

Use only regular music (*mp3) les.

PC connection problem (Only for models supporting PC connection)

The screen display does not come on after connecting to the computer.

Make sure that the computer and the TV are securely connected. Check whether the resolution is correctly set for PC input. To use the TV as a secondary monitor, check if the connected desktop or laptop supports dual monitor display.

There is no sound after connecting the computer with the HDMI cable.

Check with manufacturer of your video card to ensure it supports HDMI voice output. (Video cards in DVI format require connection of a separate sound cable.)

When connected to the computer, the display is partially cut off or shifts to one side.

Set the resolution to support PC input. (If this does not work, reboot the computer.)

Problems replaying movies in USB

[This feature is available on certain models only.]

I cannot view the files on the Movie List.

Check whether the le on the USB storage device can be read on a computer. Check whether the le extension is supported.

The file is invalid. The above error message appears. Sound, video or subtitles is not normal.

Make sure that the le replays normally on the computer’s video player. (Check for damaged les.) Check if USB media can support the selected le.

yFor information on requesting service, refer to the following menu.

[This feature is available on certain models only.]

SETTINGS> OPTION> Customer Support> Product/Service Info.

CUSTOMIZING SETTINGS

HDMI1, HDMI2, DisplayPort

Easy control

Each option is described below.

Easy control

Function

PIP

Screen Picture

Settings

Reset

SETTINGS

When you return to the previous menu, press

Menu Description

to access the main menus.

EXIT

Function PIP Screen Settings Reset

Brightness

Contrast

Volume

Input

Ratio

Color

Adjusts the brightness and contrast of the screen.

Adjusts the volume level.

Changes the input source.

Adjusts the screen ratio.

Adjusts SES, picture mode and MaxxAudio.

Displays the screens of two input modes on one TV.

Adjusts the sharpness, black level, and response time of the screen.

Adjusts the gamma, Colour temperature and Colour balance of the screen.

Sets the Language, Standby Light, Automatic Standby and Key Lock.

Resets to the default settings as of the day of purchase.

BACK

ENGLISH

CUSTOMIZING SETTINGS

ENGLISH

Ratio Settings

1 Press 2 Press the Navigation buttons to scroll to one of the

3 Press the Navigation buttons to scroll to the setting or

4 When you are nished, press

SETTINGS

following menus and press

option you want and press

to access the main menus.

EXIT

When you return to the previous menu, press

BACK

Ratio

Wide

Original

Cinema1

Cinema2

XGaGX

 V GaG

Move OK Back

V ඖGaG

ඔGaG

Each option is described below.

Menu> Easy control> Ratio Description

Wide

Original

Cinema1

Displays the video in wide-screen, regardless of the video signal input.

Displays a video according to the input video signal aspect ratio.

Enlarges the screen with an aspect ratio of 21:9. (at 1080 p)

Cinema2 Enlarges the screen with an aspect ratio of 21:9 including the black box

area at the bottom for subtitles. (at 1080 p)

1:1

The aspect ratio is not adjusted from the original.

NOTE

yThe display may look the same for Wide, Original and 1:1 options at the recommended resolution

(2560 x 1080).

yThe ratio is disabled in the interlaced signal.

CUSTOMIZING SETTINGS

Function Settings

1 Press

SETTINGS

to access the main menus.

2 Press the Navigation buttons to scroll to one of

the following menus and press OK .

3 Press the Navigation buttons to scroll to the

setting or option you want and press OK .

4 When you are nished, press

EXIT

When you return to the previous menu, press

BACK

Each option is described below.

Menu> Function Description

MaxxAudio On

MaxxAudio® by Waves, recipient of a Technical GRAMMY Award® is a suite of studio-quality sound tools for a superior listening experience.

Off

SES

On Enables the SES function, which allows you to save energy according

(Super Energy Saving)

Off

Picture Mode Custom

Disables the MaxxAudio function.

to the SES efficiency level.

Disables the SES function.

Allows the user to adjust each element. The Colour mode of the main menu can be adjusted.

Reader 1

Adjusts the screen to improve the visual effects to read the news. if you want to make the screen brighter, you can adjust it on OSD menu.

Reader 2

Adjusts the screen to improve the visual effects to display the cartoon. if you want to make the screen brighter, you can adjust it on OSD menu.


Cinema

Game

Optimizes the screen to view photos.

Optimizes the screen to improve the visual effects of a video.

Optimizes the screen for game play.

Easy control

Function

PIP

Screen

Settings

Reset

Function

MaxxAudio On

SUPER ENERGY SAVING

Picture Mode Custom

▲/▼ : Move

/▶ : Ok

◀

: Back

ENGLISH

CUSTOMIZING SETTINGS

ENGLISH

PIP Settings

1 Press 2 Press the Navigation buttons to scroll to one of

3 Press the Navigation buttons to scroll to the

4 When you are nished, press

SETTINGS

to access the main menus.

the following menus and press OK .

setting or option you want and press OK .

EXIT

When you return to the previous menu, press

BACK

Easy control

Function

PIP

Screen

Settings

Reset

PIP

Sub

Size

Position

Audio

Ratio

Transparency

PIP Preview

▲/▼ : Move

yOn page 20 for the setting of that option "PIP function" section for more information.

HDMI1

/▶ : Ok

◀

: Back

CUSTOMIZING SETTINGS

Picture Settings

1 Press 2 Press the Navigation buttons to scroll to one

3 Press the Navigation buttons to scroll to the

SETTINGS

to access the main menus.

of the following menus and press OK .

Easy control

Screen


Color

Function

setting or option you want and press OK .

4 When you are nished, press

When you return to the previous menu, press

BACK

EXIT

PIP

Screen

Settings

Reset

▲/▼ : Move

Each option is described below.

Menu> Screen> Picture Description

Sharpness

Black Level

Adjusts the sharpness of the screen.

Sets the offset level (for HDMI only).

Offset:

as a reference for a video signal, this is the darkest Colour the TV

can display.

Response Time

High

Low

Sets a response time for displayed pictures based on the speed of the

The picture of the screen gets brighter.

The picture of the screen gets darker.

screen. For a normal environment, it is recommended that you use Normal. For a fast-moving picture, it is recommended that you use High. Setting to High may cause image sticking.

High

Middle

Low

Off

Sets the response time to High.

Sets the response time to Middle.

Sets the response time to Low.

Off the response time.

/▶ : Ok

◀

ENGLISH

: Back

CUSTOMIZING SETTINGS

ENGLISH

Color Settings

1 Press 2 Press the Navigation buttons to scroll to one of

3 Press the Navigation buttons to scroll to the

4 When you are nished, press

Each option is described below.

Menu> Screen> Color

Gamma

Color Temp

Red / Green / Blue

Six Color

Reset

SETTINGS

to access the main menus.

the following menus and press OK .

setting or option you want and press OK .

EXIT

When you return to the previous menu, press

BACK

Custom gamma setting: When using the gamma 0, gamma 1, and gamma 2 TV settings, higher gamma settings mean a brighter image is displayed and vice versa.

Selects the factory default picture Colour.

Custom:

You can customize the picture Colour.

Warm:

Sets the screen Colour to a reddish tone.

Medium:

Sets the screen Colour between a red and blue tone.

Cool:

Sets the screen Colour to a bluish tone.

You can customize the picture Colour using Red, Green, and Blue Colours.

Meets the user requirements for Colours through adjusting the Colour and saturation of the six Colours (red, green, blue, cyan, magenta, yellow) and saving the settings.

Hue

Saturation

Adjusts tone of the screen.

Adjusts the saturation of the screen Colours. The lower the value, less saturated and bright the Colours become. The higher the value, the more saturated and dark the Colours become.

Returns the Colour settings to the default settings.

Easy control

Function

PIP

Screen

Settings

Reset

Description

Screen


Color

▲/▼ : Move

/▶ : Ok

◀

: Back

CUSTOMIZING SETTINGS

Settings

1 Press 2 Press the Navigation buttons to scroll to one

3 Press the Navigation buttons to scroll to the

4 When you are nished, press

SETTINGS

to access the main menus.

of the following menus and press OK .

setting or option you want and press OK .

EXIT

When you return to the previous menu, press

BACK

Easy control

Settings

Language English

Standby Light On

Automatic Standby Off

Function

Key Lock Off

PIP

Screen

Settings

Reset

▲/▼ : Move

Each option is described below.

Menu> Settings Description

Language Sets the menu screen to the desired language.

Standby Light Turns the power indicator on the front side of the TV on/off.

On The Standby Light is automatically turned on.

Off The Standby Light is turned off.

Automatic Standby Off The Automatic Standby mode is turned off.

4H / 6H / 8H Sets the time frame of the Automatic Standby mode.

Key Lock Prevents incorrect key input.

On Key input is disabled.

Off Key input is enabled.

/▶ : Ok

◀

ENGLISH

: Back

CUSTOMIZING SETTINGS

ENGLISH

Reset

1 Press

SETTINGS

to access the main menus.

2 Press the Navigation buttons to scroll to one of

the following menus and press OK .

3 Press the Navigation buttons to scroll to the

setting or option you want and press OK .

4 When you are nished, press

EXIT

When you return to the previous menu, press

BACK

Each option is described below.

Menu> Reset Description

Do you want to reset your settings?

Reset

Cancel

Resets to the default settings.

Cancel the reset.

Easy control

Function

PIP

Screen

Settings

Reset

Do you want to reset your settings?

Reset

Cancel

▲/▼ : Move

/▶ : Ok

◀

: Back

MAINTENANCE

Cleaning Your TV

Clean your TV regularly to keep the best performance and to extend the product's lifespan.

CAUTION

yMake sure to turn the power off and disconnect the power cord and all other cables first. yWhen the TV is left unattended and unused for a long time, disconnect the power cord from the

wall outlet to prevent possible damage from lightning or power surges.

Screen and frame

To remove dust, wipe the surface with a dry and soft cloth. To remove major dirt, wipe the surface with a soft cloth dampened in clean water or a diluted mild detergent. Then wipe immediately with a clean and dry cloth.

CAUTION

yDo not push, rub, or hit the surface with your fingernail or a sharp object, as this may result in

scratches on the screen and image distortions.

yDo not use any chemicals, such as waxes, benzene, alcohol, thinners, insecticides, air fresheners,

lubricants, as these may damage the screen’s finish and cause discolourations.

Cabinet and stand

To remove dust, wipe the cabinet with a dry and soft cloth. To remove major dirt, wipe the cabinet with a soft cloth dampened in a clean water or water containing a small amount of mild detergent.

ENGLISH

CAUTION

yDo not spray liquid onto the surface. If water enters the TV, it may result in fire, electric shock, or

malfunction.

yDo not use any chemicals as this may deteriorate the surface.

Power cord

Remove the accumulated dust or dirt on the power cord regularly.

MAINTENANCE

ENGLISH

Preventing “Image burn” or “Burn-in” on your TV screen

yIf a xed image displays on the TV screen for a long period of time, it will be imprinted and become

a permanent disgurement on the screen. This is “image burn” or “burn-in” and not covered by the

warranty.

yIf the aspect ratio of the TV is set to 4:3 for a long period of time, image burn may occur on the

letterboxed area of the screen.

yAvoid displaying a xed image on the TV screen for a long period of time (2 or more hours for LCD) to

prevent image burn.

TROUBLESHOOTING

Symptom Troubleshooting

No image is displayed. yCheck whether there is a power cut or whether the power

The 'Out of Range' message is displayed on the screen.

The 'No Signal' message is displayed on the screen.

The screen position is incorrect when using a PC.

There are still images sticking after power off.

The display is discoloured (16 Colour).

The screen Colour is unstable or the images are displayed in only one Colour.

Spots appear on the screen. yWhen using the Product, pixilated spots (red, green, blue,

The 'Key Locked' message displays on the screen.

The remote control is not working. yMake sure that there are no obstacles between the remote

Nothing is displayed on the TV screen.

cord is properly connected to the power outlet.

yCheck if the standby indicator is turned off. yIf the screen is turned off due to use of the Energy Saving

mode, press any button on the remote control to disable

the Energy Saving mode and display the image.

yMove the mouse or press any key, then the screen will

appear.

yThis symptom occurs when signals from the PC (video

card) are out of the horizontal or vertical frequency range of

the product. Please see the Product Specification section

of this manual and configure your display again.

yThis symptom occurs when the signal cable between the

PC and the product is not connected. Check the signal

cable and connect it again.

yCheck if the input setting is correct when the PC and the

product are connected.

yCheck whether the resolution or frequency of the video

card is set within the appropriate range for the product

and go to Control Panel> Display> Settings to set it to the

recommended resolution.

yDisplaying a still image for a prolonged time may cause

damage to the screen, resulting in the retention of the

image.

yUse a screen saver to protect the screen when using the

product for a prolonged period of time.

ySet the Colour to 24 bit (true Colour) or higher. In Windows,

go to Control Panel> Display> Settings> Colour Quality.

yCheck if the signal cable is connected properly. Reconnect

the cable or reinsert the PC's video card.

white or black) may appear on the screen. This is normal

for the LCD screen. It is not an error nor is it related to the

Product's performance.

yThe key lock is enabled. Go to Menu> Settings (Lock) and

set 'Key Lock' to Off.

control and the Product.

yCheck whether the batteries are correctly inserted with the

correct polarity.

yIf the batteries are weak, replace both of the batteries with

new ones.

yThe product may malfunction in a place where a lamp with

an electronic stabilizer (3-wavelength lamp) is installed.

yUse the TV/PC switch key to select TV.

ENGLISH

TROUBLESHOOTING

ENGLISH

NOTE

yVertical Frequency

second like a uorescent lamp. The number of times the screen is refreshed per second is called vertical frequency or refresh rate and is represented by Hz.

yHorizontal Frequency

The number of horizontal lines displayed in one second can be calculated by dividing one by the horizontal cycle. This is called horizontal frequency and is represented by kHz.

yCheck if the video card's resolution or frequency is within the range allowed by the Product and set to

the recommended (optimal) resolution in

yFailing to set the video card to the recommended (optimal) resolution may result in blurred text, a

dimmed screen, a truncated display area or misalignment of the display.

yThe conguration procedure may differ depending on your computer and/or operating system. Also,

some video cards may not support certain resolutions. If this is the case, contact the manufacturer of the computer or video card for assistance.

ySome video cards may not support the 2560 x 1080 resolution.

If the resolution cannot be displayed, contact the manufacturer of your video card.

: In order to display an image, the screen must be refreshed dozens of times per

: The time it takes to display one horizontal line is called the horizontal cycle.

Control Panel> Display> Settings

SPECIFICATIONS

Satellite Digital TV1Digital TV Analogue TV

Television system DVB-T/T2

Programme coverage VHF, UHF

Maximum number of storable programmes

1 Only DVB-T2 support models 2 Except for Nordic countries (Denmark, Finland, Norway and Sweden)

Panel Screen Type 730 mm Wide

Video Signal Max. Resolution 2560 × 1080 @ 60 Hz

Input Connector TV, Component, AV1(SCART), AV2(CVBS), HDMI*2,

Power Rated Voltage

AC/DC Adapter Manufacturer : LIEN CHANG, Model : LCAP39

Tilt Tilt Range -5 to 20°

Dimensions (Width x Height x Depth) Weight

Environmental conditions

Product specifications shown above may be changed without prior notice due to upgrade of product functions.

DVB-C DVB-S/S2

C-Band, Ku-Band

6,000 1,500

Pixel Pitch 0.2628 mm (H) x 0.2628 mm (V)

Recommended Resolution 2560 × 1080 @ 60 Hz

Horizontal Frequency 30 kHz to 90 kHz

Vertical Frequency 56 Hz to 75 Hz

Synchronization Type Digital

Power Consumption On Mode : 45 W (typ.)

Operating Temperature Operating Humidity

Storage Temperature Storage Humidity

DVB-T DVB-C

VHF, UHF VHF: E2 to E12, UHF : E21 to E69,

USB, DP, PCMCIA, LAN(Only UK)

19 V 3.2 A

Off Mode 0.5 W

Manufacturer : APD, Model : DA-65G19

With Stand

703.0 mm x 414.2 mm x 213.2 mm

5.7 kg

Without Stand

703.0 mm x 328.5 mm x 64.0 mm

5.2 kg

10 °C to 35 °C 20 % to 80 %

-10 °C to 60 °C 5 % to 90 %

PAL/SECAM B/G/D/K, PAL I/I’, SECAM L/L’

CATV: S1 to S21, HYPER: S21 to S47

ENGLISH

SPECIFICATIONS

ENGLISH

HDMI / DisplayPort(PC) supported mode

Resolution

720 x 400 31.468 70.080

640 x 480

800 x 600

1024 x 768

1152 x 864 67.500 75.000

1280 x 720 45.000 60.000

1280 x 1024

1600 x 900 60.000 60.000

1680 x 1050 65.290 59.954

1920 x 1080 67.500 60.000

2560 x 1080 66.700 60.000

Horizontal Frequency(kHz)

31.469

37.500

37.879

46.875

48.363

60.023

63.981

79.976

Vertical Frequency(Hz)

59.940

75.000

60.317

75.000

60.004

75.029

60.020

75.025

NOTE

yThe recommended resolution is

2560 x 1080 / 60 Hz. However, it may not be supported depending on your PC or AV model.

HDMI(VIDEO) supported mode

Resolution

720 x 480 31.500 60.000

720 x 576 31.250 50.000

1280 x 720

1920 x 1080

Horizontal Frequency(kHz)

37.500

45.000

33.750

28.125

33.750

56.250

67.500

Vertical Frequency(Hz)

50.000

60.000

50.000

30.000

50.000

60.000

Component supported mode

Resolution

720 x 480

720 x 576 15.625 50.000

720 x 480

720 x 576 31.250 50.000

1280 x 720

1920 x 1080

Horizontal Frequency(kHz)

15.730

15.750

31.470

31.500

44.960

45.000

37.500

33.720

33.750

28.125

56.250

67.432

67.500

Vertical Frequency(Hz)

59.940

60.000

59.940

60.000

59.940

60.000

50.000

59.940

60.000

50.000

59.940

60.000

Component port connecting information

Component ports on the TV

Video output ports on DVD player

Y P

Y B-Y R-Y

Y Cb Cr

Y Pb Pr

NOTE

yAvoid keeping a fixed image on the set’s

screen for prolonged periods of time. The fixed image may become permanently imprinted on the screen. Use a screen saver when possible.

yThere may be interference relating to

resolution, vertical pattern, contrast or brightness in PC mode. Change the PC mode to another resolution or change the refresh rate to another rate or adjust the brightness and contrast on the menu until the picture is clear. If the refresh rate of the PC graphic card can not be changed, change the PC graphic card or consult the manufacturer of the PC graphic card.

yThe synchronization input waveform for

Horizontal and Vertical frequencies are separate.

yIf using a sound card, adjust PC sound as

required.

Make sure to read the Safety Precautions before using the product. Keep the Owner’s Manual (CD) in an accessible place for future reference. The model and serial number of the TV is located on the back and one side of the TV. Record it below should you ever need service.

MODEL

SERIAL

LG 29UT55V User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

TABLE OF CONTENTS

LICENSES

OPEN SOURCE SOFTWARE NOTICE

ASSEMBLING AND PREPARING

Unpacking

Parts and buttons

Using the Joystick button

Lifting and moving the TV

Setting up the TV

Attaching the Stand

Detaching the Stand

Mounting on a table

Tidying cables

Mounting on a wall

WATCHING TV

TV display (5:9 OSD)

Programme Guide

PIP function

MAKING CONNECTIONS

Connecting an antenna

Satellite connection

External Device Connections

HDMI connection

Component connection

Composite connection

Euro Scart connection

Headphone connection

Connecting a USB Device

CI module connection

Connecting to a wired network

Connecting to a PC

HDMI connection

Display Port connection

REMOTE CONTROL

INSTALLING LG MONITOR SOFTWARE

CUSTOMIZING SETTINGS

Accessing the Main Menus

TV, Component, AV

HDMI1, HDMI2, DisplayPort

MAINTENANCE

Cleaning Your TV

Screen and frame

Cabinet and stand

Power cord

Preventing “Image burn” or “Burn-in” on your TV screen

TROUBLESHOOTING

SPECIFICATIONS
