ENGLISH
OWNER’S MANUAL
LED TV
LG LED TV applies LCD screen with LED backlights.
Please read this manual carefully before operating the your TV and
retain it for future reference.
22MA53D 22MA53V 22MA53S
23MA53D 23MA53V 23MA53S
24MA53D 24MA53V 24MA53S
27MA53D 27MA53V 27MA53S
www.lg.com
TABLE OF CONTENTS
2
ENGLISH
TABLE OF CONTENTS
3 LICENSES
4 INSTALLATION PROCEDURE
5 ASSEMBLING AND PREPARING
5 Unpacking
8 Parts and buttons
10 Lifting and moving the TV
11 Setting up the TV
11 - Attaching the Stand
13 - Mounting on a table
14 - Tidying cables
15 - Detaching the Stand
16 - Mounting on a wall
18 WATCHING TV
18 Turning the TV on for the first time
35 REMOTE CONTROL
37 CUSTOMIZING SETTINGS
37 Accessing main menus
38 USING THE USER GUIDE
38 Accessing User Guide menu.
38 - Using the TV menu
38 - Using the Remote Control
39 MAINTENANCE
39 Cleaning Your TV
39 Screen and frame
39 Cabinet and stand
39 Power cord
40 Preventing “Image burn” or “Burn-in” on
your TV screen
20 MAKING CONNECTIONS
20 Connecting an antenna
21 Satellite connection
22 Connecting to a HD receiver, DVD, VCR
player or Gaming device
22 - HDMI connection
23 - HDMI to DVI connection
24 - Component connection
25 - Composite connection
26 - Euro Scart connection
27 Connecting to an audio system
27 - Headphone connection
28 Connecting to a USB
28 Connecting to a CI Module
29 MHL connection
30 Connecting to a wired network
31 Connecting to a PC
32 - HDMI connection
33 - HDMI to DVI connection
34 - RGB connection
41 TROUBLESHOOTING
41 General
42 SPECIFICATIONS
LICENSES
3
LICENSES
Supported licenses may differ by model. For more information of the licenses, visit www.lg.com.
Manufactured under license from Dolby Laboratories. Dolby and the
double-D symbol are trademarks of Dolby Laboratories.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX Certified® device that
plays DivX video. Visit divx.com for more information and software tools to
convert your files into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be
registered in order to play purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how to complete
your registration.
ENGLISH
DivX Certified® to play DivX® video up to HD 1080p, including premium
content.
DivX®, DivX Certified® and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used under license.
Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668;
7,515,710; 7,519,274
INSTALLATION PROCEDURE
4
ENGLISH
INSTALLATION PROCEDURE
1
2
3
Open the package and make sure all the accessories are included.
Attach the stand to the TV.
Connect an external device to the TV.
NOTE
Image shown may differ from your TV.
Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
The available menus and options may differ from the input source or product model that you are
using.
New features may be added to this TV in the future.
ASSEMBLING AND PREPARING
5
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local
dealer where you purchased your product. The illustrations in this manual may differ from the actual
product and accessories.
NOTE
The accessories supplied with your product may vary depending on the model.
Product specifications or contents in this manual may be changed without prior notice due to
upgrade of product functions.
CAUTION
Do not use any pirated items to ensure the safety and product life span.
Any damages or injuries by using pirated items are not covered by the warranty.
NOTE
The items supplied with your product may vary depending on the model.
Product specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.
For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick
and 18 mm width. Use an extension cable that supports USB 2.0 if the USB cable or USB memory
stick does not fit into your TV’s USB port.
ENGLISH
B
A
B
*A 10 mm
*B
A
18 mm
6
ENGLISH
ASSEMBLING AND PREPARING
Remote control.
Batteries (AAA).
(See p.35, See p.36)
Power Cord.
(Depending on the country)
(See p.13)
CD (Owner's Manual).
Cards.
AC-DC Adapter.
(See p.13)
Stand Base.
(See p.11, See p.15)
or
AC-DC Adapter.
(Depending on the country)
(See p.13)
Cable Tie.
(See p.14)
or
Isolator
(Depending on the country)
(See p.11, See p.15)
RGB Cable.Stand Body.
(See p.34)
ASSEMBLING AND PREPARING
7
NOTE
Antenna Isolator Installation Guide
-Use this to install TV in a place where there is a voltage difference between TV Set and GND of
antenna signal.
»If there is a voltage difference between TV Set and GND of antenna signal, the antenna contact
might be heated and excessive heat might cause an accident.
-You can improve the safety when watching TV by efficiently removing power voltage from TV
antenna. It is recommended to mount the isolator to the wall. If it cannot be mounted to the wall,
mount it on the TV. Avoid disconnecting the antenna Isolator after installation.
-Before starting, be sure that the TV antenna is connected.
Wall
ANTENNA/
CABLE IN
Cable / Antenna
or
Isolator
Connect one end of the isolator to cable/antenna jack and the other to TV set or set-top box.
“Equipment connected to the protective earthing of the building installation through the mains
connection or through other equipment with a connection to protective earthing - and to a cable
distribution system using coaxial cable, may in some circumstances create a fire hazard. Connection to
a cable distribution system has therefore to be provided through a device providing electrical isolation
below a certain frequency range (galvanic isolator, see EN 60728-11)”
1. Connect to TV.
2. Connect to Set-Top box.
ENGLISH
When applying the RF Isolator, a slight loss of signal sensitivity can occur.
8
Parts and buttons
ENGLISH
ASSEMBLING AND PREPARING
Remote Control Sensor
Standby Light
Lighting On: When Power is turend off
Lighting Off: When Power is turned on
Touch Buttons
Touch button Description
Scrolls through the saved programmes.
Adjusts the volume level.
OK Selects the highlighted menu option or confirms an input.
SETTINGS Accesses the main menus, or saves your input and exits the menus.
INPUT Changes the input source.
/ I
Turns the power on or off.
NOTE
All of the buttons are touch sensitive and can be operated through simple touch with your finger.
ASSEMBLING AND PREPARING
LAN
(19V )
(19V )
(19V )
9
ENGLISH
23MA53D22MA53D
24MA53D 27MA53D
22MA53S 24MA53S23MA53S 27MA53S
23MA53V 22MA53V 24MA53V
27MA53V
Only UK
Connection panel (See p.20)
10
Lifting and moving the TV
ENGLISH
When moving or lifting the TV, read the following
to prevent the TV from being scratched or
damaged and for save transportation regardless of
its type and size.
ASSEMBLING AND PREPARING
CAUTION
Avoid touching the screen at all times, as
this may result in damage to the screen or
some of the pixels used to create images.
It is recommended to move the TV in the
box or packing material that the TV originally
came in.
Before moving or lifting the TV, disconnect
the power cord and all cables.
Hold the top and bottom of the TV frame
firmly. Make sure not to hold the transparent
part, speaker, or speaker grill area.
When holding the TV, the screen should face
away from you to prevent the screen from
scratches.
When transporting the TV, do not expose the
TV to jolts or excessive vibration.
When transporting the TV, keep the TV
upright, never turn the TV on its side, or tilt
towards the left or right.
Setting up the TV
Attaching the Stand
If you are not mounting the TV to a wall, use the
following instructions to attach the stand.
Place the TV with the screen side down on a
1
flat and cushioned surface.
ASSEMBLING AND PREPARING
Attach the Stand Base from the TV.
3
11
ENGLISH
CAUTION
Lay a foam mat or soft protective cloth
on the surface to protect the screen from
damage.
When attaching the stand to the TV,
place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
Attach the Stand Base from Stand Body by
2
turning the screw to the right with a Coin.
CAUTION
Tighten the screws firmly to prevent the TV
from tilting forward. Do not over tighten.
12
ENGLISH
ASSEMBLING AND PREPARING
CAUTION
Do not carry the monitor upside-
down as this may cause it to fall off
its stand, resulting in damage or
injury.
The illustration shows a general
example of installation and may look
different from the actual product.
Do not carry the monitor upside-
down by holding the stand body as
this may cause it to fall off, resulting
in damage or injury.
The illustration shows a general
example of installation and may look
different from the actual product.
Mounting on a table
Lift and tilt the TV into its upright position on a
1
table.
Leave a 10 cm (4 inches) (minimum) space
from the wall for proper ventilation.
10 cm
10 cm
ASSEMBLING AND PREPARING
Connect the AC-DC Adapter and Power Cord
2
to a wall outlet.
13
ENGLISH
10 cm
10 cm
WARNING
When you adjust the angle, do not hold the
buttom of the TV frame as shown on the
following illustration, as may injure your fingers.
or
CAUTION
Disconnect the power cord first, and then move
or install the TV. Otherwise electric shock may
occur.
CAUTION
Do not place the TV near or on sources of
heat, as this may result in fire or other damage.
ASSEMBLING AND PREPARING
14
ENGLISH
NOTE
Tilt from +20 to -5 degrees up or down to
adjust the angle of the TV to suit your view.
+20-5
Front Rear
Using the Kensington security system
The Kensington security system connector is
located at the back of the TV. For more information
of installation and using, refer to the manual
supplied with the Kensington security system or
visit
http://www.kensington.com
Connect the Kensington security system cable
between the TV and a table.
.
Tidying cables
Gather and bind the cables with the supplied
cable tie.
NOTE
The Kensington security system is optional.
You can obtain additional accessories from
most electronics stores.
Detaching the Stand
ASSEMBLING AND PREPARING
15
ENGLISH
Place the TV with the screen side down on a
1
flat and cushioned surface.
CAUTION
Lay a foam mat or soft protective cloth
on the surface to protect the screen from
damage.
When detaching the stand to the TV,
place the screen facing down on a
cushioned table or flat surface to protect
the screen from scratches.
Turn the screw to the left, and then pull out the
3
Stand Base from the Stand Body.
Pull out the Stand Body from the TV.
2
16
A
B
Mounting on a wall
ENGLISH
For proper ventilation, allow a clearance of 10
cm on each side and from the wall. Detailed
installation instructions are available from your
dealer, see the optional Tilt Wall Mounting Bracket
Installation and Setup Guide.
ASSEMBLING AND PREPARING
10 cm
Please use VESA standard as below.
5
784.8 mm (30.9 inch) and under
* Wall Mount Pad Thickness : 2.6 mm
* Screw : Φ 4.0 mm x Pitch 0.7 mm x
Length 10 mm
787.4 mm (31.0 inch) and above
* Please use VESA standard wall mount pad
and screws.
VESA (A x B) 100 x 100
Standard screw M4
Number of screws 4
Wall mount bracket
(optional)
RW120
10 cm
10 cm
If you intend to mount the TV to a wall, attach Wall
mounting interface (optional parts) to the back of
the TV.
When you install the TV using the wall mounting
interface (optional parts), attach it carefully so it
will not drop.
Please, Use the screw and wall mount interface
1
in accordance with VESA Standards.
If you use screw longer than standard, the TV
2
might be damaged internally.
If you use improper screw, the product might
3
be damaged and drop from mounted position.
In this case, LG Electronics is not responsible
for it.
VESA compatible only with respect to screw
4
mounting interface dimensions and mounting
screw specifications.
10 cm
VESA (A x B)
CAUTION
Disconnect the power cord first, and then
move or install the TV. Otherwise electric
shock may occur.
If you install the TV on a ceiling or slanted
wall, it may fall and result in severe injury.
Use an authorized LG wall mount and
contact the local dealer or qualified
personnel.
Do not over tighten the screws as this may
cause damage to the TV and void your
warranty.
Use the screws and wall mounts that meet
the VESA standard. Any damages or injuries
by misuse or using an improper accessory
are not covered by the warranty.
ASSEMBLING AND PREPARING
17
ENGLISH
NOTE
Use the screws that are listed on the VESA
standard screw specifications.
The wall mount kit includes an installation
manual and necessary parts.
The wall mount bracket is optional. You can
obtain additional accessories from your local
dealer.
The length of screws may differ depending
on the wall mount. Be sure to use the proper
length.
For more information, refer to the instructions
supplied with the wall mount.
WATCHING TV
18
ENGLISH
WATCHING TV
Turning the TV on for the first time
When you access the TV for the first time, the initial setting screen appears. Select a language and
customize the basic settings.
1
2
3
4
Connect the power cord to a power outlet.
Press on the TV or power button on the remote control to turn the TV on.
The Standby Light is turned off.
NOTE
When the TV is in Power saving mode, the Standby Light turns amber.
The initial setting screen appears if you access the TV for the first time.
NOTE
If you do not operate the TV within 40 seconds when the setting menu screen appears, the setting
menus will disappear.
Follow the on-screen instructions to customize your TV according to your preferences.
Language
Mode Setting
Power Indicator
Country
Time Zone
Network Setting
Set Password
User Guide and FAQ
Auto Tuning
Selects a language for the display.
Selects Home Use for the home environment.
Selects the Standby Light. If you select On, the TV turns on the Standby Light in
the front panel when the TV is off.
Selects a country to display.
Selects the time zone and daylight saving. (When Russia is selected for Country)
(If there is LAN port) selects Network Setting to display. (Only UK, **MA53V
models)
Set the password. (When France/Italy is selected for Country)
Shows how to use User Guide and FAQ.
Scans and saves available programmes automatically.
WATCHING TV
NOTE
For those countries without confirmed DTV broadcasting standards, some DTV features might not
work, depending on the DTV broadcasting environment.
When France is selected for Country, the initial password is not ‘0’, ‘0’, ‘0’, ‘0’ but ‘1’, ‘2’, ‘3’, ‘4’.
To display images in the best quality for your home environment, select Home Use mode.
Store Demo mode is suitable for the retail environment.
If you select Store Demo mode, the previously customized settings will switch to the default
settings of Store Demo mode in 5 minutes.
When the basic settings are complete, press OK.
5
NOTE
If you do not complete the initial setting, it will appear whenever you access the TV.
To turn the TV off, press on the TV.
6
The Standby Light is turned on.
19
ENGLISH
CAUTION
Disconnect the power cord from the power outlet when you do not use the TV for a long period of
time.
NOTE
You can also switch the TV from PC mode to TV mode, press TV/PC.
You can also access Factory Reset by accessing OPTION in the main menus.
MAKING CONNECTIONS
AV 1
20
ENGLISH
MAKING CONNECTIONS
Connect various external devices to the TV and switch input modes to select an external device. For more
information about an external device’s connection, refer to the manual supplied with each device.
Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC,
camcorders or cameras, gaming devices, and other external devices.
Connecting an antenna
Connect an antenna, cable or cable box to watch TV referring to the following. The illustrations may differ
from the actual accessories and an RF cable is optional.
Connect the TV to a wall antenna socket with an RF cable (75Ω).
NOTE
If you record a TV program on a DVD recorder or VCR, make sure to connect the TV signal input
cable to the TV through a DVD recorder or VCR. For more information about recording, refer to the
manual supplied with the connected device.
The external device connection may differ from the model.
Connect external devices to the TV regardless of the order of the TV port.
(Not Provided)
Outdoor Antenna
VHF Antenna
Wall Antenna Socket
NOTE
Use a signal splitter to use more than 2 TVs.
If the image quality is poor, install a signal
amplifier properly to improve the image
quality.
If the image quality is poor with an antenna
connected, aim the antenna to the proper
direction.
Visit
http://AntennaWeb.org
information about the antenna and cable
connection.
for more
CAUTION
Make sure not to bend the copper wire of
the RF cable.
Copper wire
Complete all connections instructions
between devices, and then connect the
power cord to the power outlet to prevent
damages to your TV.
UHF Antenna
MAINTENANCE
21
Satellite connection
Only **MA53V, **MA53S model
Connect the TV to a satellite dish to a satellite socket with a satellite RF cable (75Ω).
(Not Provided)
ENGLISH
22
Connecting to a HD receiver, DVD, VCR player or Gaming device
ENGLISH
Connect a HD receiver, DVD, VCR player or Gaming device to the TV and select an appropriate input mode.
HDMI connection
HDMI is the best way to connect a device.
Transmits the digital video and audio signals from an external device to the TV. Connect the external device
and the TV with the HDMI cable as shown on the following illustration.
MAKING CONNECTIONS
NOTE
Use a High Speed HDMI™ Cable.
High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.
Supported HDMI Audio format: Dolby Digital, PCM (Up to 192 KHz, 32k/44.1k/48k/88k/96k/176k/
192k, DTS Not supported.)
(Not Provided)
DVD / Blu-Ray / HD Cable Box /
HD STB / Gaming Device
MAKING CONNECTIONS
23
HDMI to DVI connection
Transmits the digital video signal from an external device to the TV. Connect the external device and the TV
with the HDMI to DVI cable as shown in the following illustration. To transmit an audio signal, connect an
optional audio cable.
NOTE
If you do not use an optional external speaker, connect the external device to the TV with the optional
audio cable.
ENGLISH
(Not Provided)
(Not Provided)
DVD / Blu-Ray / HD Cable Box /
HD STB / Gaming Device
24
Component connection
ENGLISH
Transmits the analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the component cable as shown on the following illustration. To display images by
using progressive scan, make sure to use the component cable.
MAKING CONNECTIONS
NOTE
If cables are installed incorrectly, it could case the image to display in black and white or with distorted
color.
Check to ensure the cable are matched with the corresponding color connection.
(Not Provided)
(Not Provided)
DVD / Blu-Ray / HD Cable Box /
HD STB / Gaming Device
MAKING CONNECTIONS
Composite connection
Transmits the analog video and audio signals from an external device to the TV. Connect the external
device and the TV with the composite cable as shown on the following illustration.
NOTE
Check to ensure the cable are matched with the corresponding color connection.
25
ENGLISH
(Not Provided)
DVD / Blu-Ray / HD Cable Box /
HD STB / Gaming Device
26
Euro Scart connection
ENGLISH
Transmits the video and audio signals from an external device to the TV. Connect the external device
and the TV with the Euro Scart cable as shown on the following illustration. To display images by using
progressive scan, make sure to use the Euro Scart cable.
MAKING CONNECTIONS
Output Type
Current
input mode
Digital TV Digital TV
Analogue TV Analogue TV
Component, AV, HDMI,
RGB
1 TV Out : Outputs Analogue TV or Digital TV signals.
AV1 (TV Out1)
X
NOTE
Any Euro scart cable used must be signal shielded.
(Not Provided)
DVD / Blu-Ray / HD Cable Box
MAKING CONNECTIONS
27
Connecting to an audio system
Use an optional external audio system instead of the built-in speaker.
Headphone connection
Transmits the headphone signal from the TV to an external device. Connect the TV with the headphone as
shown on the following illustration.
NOTE
AUDIO menu items are disabled when connecting a headphone.
Headphone impedance: 16
Max audio output of headphone: 10 mW to 15 mW
Headphone jack size: 0.35 cm
ENGLISH
(Not Provided)
Headphone
28
Connecting to a USB
ENGLISH
Connect a USB storage device such as s USB flash memory, external hard drive, MP3 player or a USB
memory card reader to the TV and access the USB menu to use various multimedia files.
MAKING CONNECTIONS
or
USB
(Not Provided)
Connecting to a CI Module
View the encrypted (pay) services in digital TV mode. This feature is not available in all countries.
NOTE
Check if the CI module is inserted into the PCMCIA card slot in the right direction. If the module is
not inserted properly, this can cause damage to the TV and the PCMCIA card slot.
If the TV does not display any video and audio when CI+ CAM is connected, please contact to the
Terrestrial/Cable/Satellite Service Operator.
(Not Provided)
PCMCIA Card
MAKING CONNECTIONS
29
MHL connection
Mobile High-definition Link (MHL) is an interface for transmitting digital audiovisual signals from mobile
phones to television sets.
NOTE
Connect the mobile phone to the HDMI IN 2(MHL) port to view the phone screen on the TV.
The MHL passive cable is needed to connect the TV and a mobile phone.
This only works for the MHL-enabled phone.
Some applications can be operated by the remote control.
ENGLISH
(Not Provided)
Mobile phone
30
(19V )
Connecting to a wired network
ENGLISH
Only **MA53V model (Only UK)
Connect the TV to a local area network (LAN) via the LAN port as shown on the following illustration
and set up the network settings. After making a physical connection, a small number of home networks
may require the TV network settings to be adjusted. For most home networks, the TV will connect to
automatically without any adjustments.
For detail information, contact your internet provider or router manual.
MAKING CONNECTIONS
CAUTION
Do not connect a modular phone cable to the LAN port.
Since there are various connection methods, please follow the specifications of your
telecommunication carrier or internet service provider.
LAN
(Not Provided)
1 2 3 4
LAN
NOTE
[**MA53V Model]
U.K: LAN port is available. (The LAN port is added to support HD MHEG.)
Other areas: LAN port is not available.
MAKING CONNECTIONS
31
Connecting to a PC
Your TV supports the Plug & Play* feature and has the built-in speakers with Virtual Surround that
reproduces sound clearly with a rich bass.
* Plug & Play: The function when a PC recognizes a connected device that users connect to a PC and turn
on, without device configuration or user intervention.
NOTE
It is recommended to use the TV with the HDMI connection for the best image quality.
If you do not use an optional external speaker, connect the PC to the TV with the optional audio
cable.
If you turn the TV on when the set becomes cold, the screen may flicker. This is normal.
Some red, green, or blue spots may appear on the screen. This is normal.
Connect the signal input cable and tighten it by turning the screws clockwise.
Do not press the screen with your finger for a long time as this may result in temporary distortion on
the screen.
Avoid displaying a fixed image on the screen for a long period of time to prevent image burn. Use a
screensaver if possible.
ENGLISH
NOTE
If you want to use HDMI-PC mode, you must set the input label to PC mode.
The OSD (On Screen Display) is displayed on the screen as shown below.
» When turning the product on in HDMI input.
» When switching to HDMI input.
Is the input connected to your PC?
Yes No
Do not show message again.
If you select "Yes" the size and image quality are optimised for your PC.
If you select "No" the size and image quality are optimised for the AV device (DVD player, set-top
box, gaming device).
If you select "Do not show message again" this message does not appear until the TV is reset. You
can change the set value in SETTINGS INPUT Input Label.
32
HDMI connection
ENGLISH
Transmits the digital video and audio signals from your PC to the TV. Connect the PC and the TV with the
HDMI cable as shown in the following illustrations. You should set PC as an input label to connect the PC to
the TV with an HDMI connection.
MAKING CONNECTIONS
NOTE
Use a High Speed HDMI™ Cable.
High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher.
If you want to use HDMI-PC mode, you must set the input label to PC or DVI mode.
Supported HDMI Audio format: Dolby Digital, PCM (Up to 192 KHz, 32k/44.1k/48k/88k/96k/176k/
192k, DTS Not supported.)
(Not Provided)
PC
MAKING CONNECTIONS
33
HDMI to DVI connection
Transmits the digital video signal from your PC to the TV. Connect the PC and the TV with the HDMI to DVI
cable as shown the following illustrations. To transmit an audio signal, connect an optional audio cable.
NOTE
If you want to use HDMI-PC mode, you must set the input label to DVI mode.
If you do not use an optional external speaker, connect the PC to the TV with the optional audio cable.
ENGLISH
(Not Provided)
(Not Provided)
PC
34
RGB connection
ENGLISH
Transmits the analog video signal from your PC to the TV. Connect the PC and the TV with the D-sub 15
pin cable as shown the following illustrations. To transmit an audio signal, connect an optional audio cable.
MAKING CONNECTIONS
NOTE
If you do not use an optional external speaker, connect the PC to the TV with the optional audio cable.
(Not Provided)
PC
REMOTE CONTROL
35
REMOTE CONTROL
The descriptions in this manual are based on the buttons of the remote control. Please read this manual
carefully and use the TV correctly.
To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching and ends to the
label inside the compartment, and close the battery cover.
To remove the batteries, perform the installation actions in reverse.
CAUTION
Do not mix old and new batteries, as this may
damage the remote control.
Make sure to point the remote control to the remote control sensor on the TV.
(POWER)
Turns the TV on or off.
SUBTITLE
Recalls your preferred subtitle
in digital mode.
Number buttons
Enters numbers.
LIST
Displays the programme
table.
+
Adjusts the volume level.
-
PAGE
TV/RAD
Selects Radio, TV and DTV
programme.
INPUT
Selects the input mode.
AD
Switches the Audio
Description On or Off.
PIP
Turns the PIP mode on or off.
(User Guide)
Accesses the User Guide
menu.
Q.VIEW
Returns to the previously
viewed programme.
P
Selects a programme.
PAGE
Moves to the previous or next
screen.
ENGLISH
FAV
Displays the selected
favourite programme.
GUIDE
Shows programme guide.
MUTE
Mutes all sounds.
36
ENGLISH
REMOTE CONTROL
Accesses the main menus
SETTINGS
or saves your input and exit
menus.
Navigation buttons
Scrolls through menus or
options.
OK
Selects menus or options and
confirms your input.
BACK
Returns to the previous level.
SSIMPLINK
Accesses the AV devices
connected with the HDMI cable
through HDMI-CEC.
Opens the SIMPLINK menu.
TV/PC
Selects TV or PC mode.
Teletext buttons
These buttons are used for
teletext.
ⓘ
INFO
Views the information of the
currently program and the
screen.
Q.MENU
Accesses the quick menus.
EXIT
Clears all on-screen displays
and returns to TV viewing from
any menu.
USB Menu control
buttons
USB menu(Photo List and
Music List or Movie List).
These buttons are used for
Coloured buttons
teletext (on TELETEXT
models only), Programme
edit.
Backlight
Adjusts the brightness of
the screen by controlling the
screen backlight.
NOTE
On MHEG channel, you cannot adjust the backlight with the yellow or blue key.
CUSTOMIZING SETTINGS
37
CUSTOMIZING SETTINGS
Accessing main menus
Press SETTINGS to access the main menus.
1
Press the Navigation buttons to scroll to one of the following menus and press OK.
2
Press the Navigation buttons to scroll to the setting or option you want and press OK.
3
When you are finished, press EXIT.
4
When you return to the previous menu, press BACK.
PICTURE Adjusts the image size, quality or effect.
AUDIO Adjusts the sound quality, effect or volume level.
SETUP Sets up and edit programmes.
TIME Sets the time, date or Timer feature.
LOCK Locks or unlocks channels and programs.
ENGLISH
OPTION Customizes the general settings.
INPUT Views the input sources with their labels. (Except: UK country, **MA53V models)
NETWORK Sets the network. (Apply: UK country **MA53V models)
MY MEDIA Using integrated media feature.
Press RED button to access the Customer Support menus.
Press GREEN Button to access the FAQ menus.
Press OK( ) to set programme settings.
Exit
Customer Support
Using Customer Support feature.
Software Update
Picture Test
Sound Test
Signal Test
Product/Service Info.
Network Test (Only UK, **MA53V models)
User Guide
Customer Support FAQ
FAQ
Shows answers to frequently asked
questions about TV viewing and sets
the related menus.
USING THE USER GUIDE
38
ENGLISH
USING THE USER GUIDE
Accessing User Guide menu.
Using the TV menu
1
2
3
4
5
Using the Remote Control
Press SETTINGS to access the main menus.
Press the RED button to access the Customer
Support menus.
Press the Navigation button to scroll to User
Guide and press OK.
Press the Navigation buttons to scroll to the
option you want and press OK.
When you are finished, press EXIT.
When you return to the previous menu, press
BACK.
Image shown may differ from your TV.
User Guide
3
2
To use input device
CHANNEL Setting
PICTURE, SOUND Setting
OPTION
Advanced Function
Information
To set ODC (Over Driving Circuit)
To use PIP (Picture In Picture)
To set time options
To set TV lock options
To set language
To set country
1
Allows to select the category you want.
1
Allows to select the item you want.
2
You can use ꕌ/ꕍto move between pages.
Allows to browse the description of the
3
function you want from the index.
User Guide
PROGRAMME Setting
PICTURE, SOUND Setting
OPTION
Advanced Function
Information
1
OPTION > To set language
SETTING OPTION Language
You can select the language of the menu displayed on the screen and the digital
sound broadcasting.
Menu Language : Selects a language for the display text.
Audio Language [In Digital mode Only] : Select the desired language when
watching digital broadcasting containg several voice languages.
Subtitle Language [In Digital mode Only] : Use the Subtitle function when two
or more subtitle languages are broadcast.
✎ If subtitle data in a selected language is not broadcast, the default
language subtitle will be displayed.
Zoom In
2
Close
Press (User Guide) to access the User
1
Guide.
Press the Navigation buttons to scroll to the
2
option you want and press OK.
When you are finished, press EXIT.
3
When you return to the previous menu, press
BACK.
SETTING OPTION Language
You can select the language of the menu displayed on the screen and the digital
sound broadcasting.
Menu Language : Selects a language for the display text.
Audio Language [In Digital mode Only] : Select the desired language when
watching digital broadcasting containg several voice languages.
Subtitle Language [In Digital mode Only] : Use the Subtitle function when two
or more subtitle languages are broadcast.
✎ If subtitle data in a selected language is not broadcast, the default
language subtitle will be displayed.
Zoom Out
2
1
Shows the description of the selected menu.
Close
You can use ꕌ/ꕍto move between pages.
2
Zooms in or out the screen.
MAINTENANCE
39
MAINTENANCE
Cleaning Your TV
Clean your TV regularly to keep the best performance and to extend the product lifespan.
CAUTION
Make sure to turn the power off and disconnect the power cord and all other cables first.
When the TV is left unattended and unused for a long time, disconnect the power cord from the wall
outlet to prevent possible damage from lightning or power surges.
Screen and frame
To remove dust, wipe the surface with a dry and soft cloth.
To remove major dirt, wipe the surface with a soft cloth dampened in clean water or a diluted mild
detergent. Then wipe immediately with a clean and dry cloth.
CAUTION
Do not push, rub, or hit the surface with your fingernail or a sharp object, as this may result in
scratches on the screen and image distortions.
Do not use any chemicals, such as waxes, benzene, alcohol, thinners, insecticides, air fresheners,
lubricants, as these may damage the screen’s finish and cause discolorations.
ENGLISH
Cabinet and stand
To remove dust, wipe the cabinet with a dry and soft cloth.
To remove major dirt, wipe the cabinet with a soft cloth dampened in a clean water or water containing a
small amount of mild detergent.
CAUTION
Do not spray liquid onto the surface. If water enters the TV, it may result in fire, electric shock, or
malfunction.
Do not use any chemicals as this may deteriorate the surface.
Power cord
Remove the accumulated dust or dirt on the power cord regularly.
40
Preventing “Image burn” or “Burn-in” on your TV screen
ENGLISH
MAINTENANCE
If a fixed image displays on the TV screen for a long period of time, it will be imprinted and become
a permanent disfigurement on the screen. This is “image burn” or “burn-in” and not covered by the
warranty.
If the aspect ratio of the TV is set to 4:3 for a long period of time, image burn may occur on the
letterboxed area of the screen.
Avoid displaying a fixed image on the TV screen for a long period of time (2 or more hours for LCD)
to prevent image burn.
TROUBLESHOOTING
41
TROUBLESHOOTING
General
Problem Resolution
Cannot control the TV with
the remote control.
No image display and no
sound is produced.
The TV turns off suddenly.
Check the remote control sensor on the product and try again.
Check if there is any obstacle between the product and the remote control.
Check if the batteries are still working and properly installed ( to , to ).
Check if the product is turned on.
Check if the power cord is connected to a wall outlet.
Check if there is a problem in the wall outlet by connecting other products.
Check the power control settings. The power supply may be interrupted.
Check if the Auto sleep feature is activated in the Time settings.
If there is no signal while the TV is on, the TV will turn off automatically after
15 minutes of inactivity.
ENGLISH
SPECIFICATIONS
42
ENGLISH
SPECIFICATIONS
1 Only satellite models
2 Only DVB-T2 support models
3 Except for DVB-T2 support models
Satellite Digital TV1Digital TV
Television system DVB-T
DVB-C
DVB-S/S2
Programme coverage VHF, UHF
C-Band, Ku-Band
Maximum number of
storable programmes
6,000 1,500
DVB-T/T2
DVB-C
DVB-S
2
Digital TV Analogue TV
DVB-T
DVB-C
VHF, UHF VHF: E2 to E12, UHF: E21 to
PAL/SECAM B/G/D/K
PAL-I/I’,
SECAM L/L’
E69, CATV: S1 to S20,
HYPER: S21 to S47
3
22MA53D 22MA53V 22MA53S
Panel Screen Type 550 mm Wide (21.5 inch)
Visible diagonal size : 550 mm
Pixel Pitch 0.248 mm (H) x 0.248 mm (V)
Video Signal Max. Resolution 1920 × 1080 @ 60 Hz
Recommended Resolution 1920 × 1080 @ 60 Hz
Horizontal Frequency 30 kHz to 83 kHz
Vertical Frequency 56 Hz to 75 Hz
Synchronization Type
Input Connector 22MA53D, 22MA53S
Power Rated Voltage 19 V 2.0 A
Power Consumption On Mode : 30 W (typ.)
AC/DC Adapter
Tilt Tilt Range -5 to 20°
Dimensions (Width x Depth x Height)
Weight
Environmental
conditions
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Separate Sync, Digital
TV, D-Sub Analog, PC Audio In, Component, AV1(SCART),
AV2(CVBS), HDMI*2, USB, PCMCIA
22MA53V
TV, D-Sub Analog, PC Audio In, Component, AV1(SCART),
AV2(CVBS), HDMI*2, USB, PCMCIA, LAN JACK(Only UK)
Off Mode 0.4 W
Manufacturer: Lien Chang, Model LCAP16B-E
Manufacturer: LG Innotek, Model PSAB-L205B
Manufacturer: Lien Chang, Model LCAP25B
Manufacturer: LG Innotek, Model PSAB-L204B
With Stand
508.6 mm x 178.3 mm x 389.6 mm
3.3 kg
Without Stand
508.6 mm x 73 mm x 315.0 mm
3.1 kg
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
SPECIFICATIONS
43
ENGLISH
Product specifications shown above may be changed without prior notice due to upgrade of product
functions.
44
ENGLISH
23MA53D 23MA53V 23MA53S
SPECIFICATIONS
Panel Screen Type 580 mm Wide (23 inch)
Visible diagonal size : 580 mm
Pixel Pitch 0.265 mm (H) x 0.265 mm (V)
Video Signal Max. Resolution 1920 × 1080 @ 60 Hz
Recommended Resolution 1920 × 1080 @ 60 Hz
Horizontal Frequency 30 kHz to 83 kHz
Vertical Frequency
Synchronization Type Separate Sync, Digital
Input Connector 23MA53D, 23MA53S
Power Rated Voltage 19 V 2.0 A
Power Consumption On Mode : 33 W (typ.)
AC/DC Adapter Manufacturer: Lien Chang, Model LCAP16B-E
Tilt Tilt Range -5 to 20°
Dimensions (Width x Depth x Height)
Weight
Environmental
conditions
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
56 Hz to 75 Hz
TV, D-Sub Analog, PC Audio In, Component, AV1(SCART),
AV2(CVBS), HDMI*2, USB, PCMCIA
23MA53V
TV, D-Sub Analog, PC Audio In, Component, AV1(SCART),
AV2(CVBS), HDMI*2, USB, PCMCIA, LAN JACK(Only UK)
Off Mode 0.4 W
Manufacturer: LG Innotek, Model PSAB-L205B
Manufacturer: Lien Chang, Model LCAP25B
Manufacturer: LG Innotek, Model PSAB-L204B
With Stand
544.0 mm x 178.3 mm x 409.4 mm
3.6 kg
Without Stand
544.0 mm x 73 mm x 335.0 mm
3.36 kg
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
Product specifications shown above may be changed without prior notice due to upgrade of product
functions.
SPECIFICATIONS
24MA53D 24MA53V 24MA53S
Panel Screen Type 600 mm Wide (23.8 inch)
Visible diagonal size : 600 mm
Pixel Pitch 0.275 mm (H) x 0.275 mm (V)
Video Signal Max. Resolution 1920 × 1080 @ 60 Hz
Recommended Resolution 1920 × 1080 @ 60 Hz
Horizontal Frequency 30 kHz to 83 kHz
Vertical Frequency
Synchronization Type Separate Sync, Digital
Input Connector 24MA53D, 24MA53S
Power Rated Voltage 19 V 2.0 A
Power Consumption On Mode : 33 W (typ.)
AC/DC Adapter Manufacturer: Lien Chang, Model LCAP16B-E
Tilt Tilt Range -5 to 20°
Dimensions (Width x Depth x Height)
Weight
Environmental
conditions
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
56 Hz to 75 Hz
TV, D-Sub Analog, PC Audio In, Component, AV1(SCART),
AV2(CVBS), HDMI*2, USB, PCMCIA
24MA53V
TV, D-Sub Analog, PC Audio In, Component, AV1(SCART),
AV2(CVBS), HDMI*2, USB, PCMCIA, LAN JACK (Only UK)
Off Mode 0.4 W
Manufacturer: LG Innotek, Model PSAB-L205B
Manufacturer: Lien Chang, Model LCAP25B
Manufacturer: LG Innotek, Model PSAB-L204B
With Stand
566.8 mm x 178.3 mm x 420.8 mm
3.8 kg
Without Stand
566.8 mm x 73 mm x 346.1 mm
3.53 kg
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
45
ENGLISH
Product specifications shown above may be changed without prior notice due to upgrade of product
functions.
46
ENGLISH
SPECIFICATIONS
27MA53D 27MA53V 27MA53S
Panel Screen Type 690 mm Wide (27 inch)
Visible diagonal size : 690 mm
Pixel Pitch 0.311 mm (H) x 0.311 mm (V)
Video Signal Max. Resolution 1920 × 1080 @ 60 Hz
Recommended Resolution 1920 × 1080 @ 60 Hz
Horizontal Frequency 30 kHz to 83 kHz
Vertical Frequency
Synchronization Type Separate Sync, Digital
Input Connector 27MA53D, 27MA53S
Power Rated Voltage 19 V 2.4 A
Power Consumption On Mode : 35 W (typ.)
AC/DC Adapter Manufacturer: LG Innotek, Model PSAB-L101A
Tilt Tilt Range -5 to 20°
Dimensions (Width x Depth x Height)
Weight
Environmental
conditions
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
56 Hz to 75 Hz
TV, D-Sub Analog, PC Audio In, Component, AV1(SCART),
AV2(CVBS), HDMI*2, USB, PCMCIA
27MA53V
TV, D-Sub Analog, PC Audio In, Component, AV1(SCART),
AV2(CVBS), HDMI*2, USB, PCMCIA, LAN JACK (Only UK)
Off Mode 0.4 W
Manufacturer: Lite-On, Model PA-1650-64
With Stand
641.2 mm x 193.0 mm x 462.2 mm
5.28 kg
Without Stand
641.2 mm x 83 mm x 391.0 mm
4.84 kg
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
Product specifications shown above may be changed without prior notice due to upgrade of product
functions.
SPECIFICATIONS
47
RGB (PC) / HDMI (PC) supported mode
Resolution
Horizontal
Frequency(kHz)
720 x 400 31.468 70.080
640 x 480 31.469 59.940
640 x 480 37.500 75.000
800 x 600 37.879 60.317
800 x 600 46.875 75.000
1024 x 768 48.363 60.004
1024 x 768
Only HDMI(PC)
56.476 70.069
1024 x 768 60.023 75.029
1152 x 864 67.500 75.000
1280 x 720 45.000 60.000
1280 x 800 49.702 59.810
1280 x 1024 63.981 60.020
1280 x 1024 79.976 75.025
1400 x 1050 65.317 59.978
1440 x 900 55.935 59.887
1600 x 900 60.000 60.000
1680 x 1050 64.674 59.883
1680 x 1050 65.290 59.954
1920 x 1080 67.500 60.000
Vertical
Frequency(Hz)
Component supported mode
Resolution
Horizontal
Frequency(kHz)
720 x 480 15.730 59.940
720 x 480 15.750 60.000
720 x 576 15.625 50.000
720 x 480 31.470 59.940
720 x 480 31.500 60.000
720 x 576 31.250 50.000
1280 x 720 44.960 59.940
1280 x 720 45.000 60.000
1280 x 720 37.500 50.000
1920 x 1080 33.720 59.940
1920 x 1080 33.750 60.000
1920 x 1080 28.125 50.000
1920 x 1080 56.250 50.000
1920 x 1080 67.432 59.940
1920 x 1080 67.500 60.000
Vertical
Frequency(Hz)
Component port connecting information
Component ports on the
TV
Y P
B
ENGLISH
P
R
HDMI (DTV) supported mode
Resolution
Horizontal
Frequency(kHz)
720 x 480 31.469
31.500
720 x 576 31.250 50.000
1280 x 720 37.500 50.000
1280 x 720 44.960
45.000
1920 x 1080 33.720
33.750
1920 x 1080 28.125 50.000
1920 x 1080 27.000 24.000
1920 x 1080 33.750 30.000
1920 x 1080 56.250 50.000
1920 x 1080 67.430
67.500
Vertical
Frequency(Hz)
59.940
60.000
59.940
60.000
59.940
60.000
59.940
60.000
Video output ports
on DVD player
Y P
P
B
Y B-Y R-Y
Y Cb Cr
Y Pb Pr
R
SPECIFICATIONS
48
ENGLISH
NOTE
Avoid keeping a fixed image on the set’s screen for prolonged periods of time. The fixed image may
become permanently imprinted on the screen. Use a screen saver when possible.
There may be interference relating to resolution, vertical pattern, contrast or brightness in PC mode.
Change the PC mode to another resolution or change the refresh rate to another rate or adjust the
brightness and contrast on the menu until the picture is clear. If the refresh rate of the PC graphic
card can not be changed, change the PC graphic card or consult the manufacturer of the PC graphic
card.
The synchronization input waveform for Horizontal and Vertical frequencies are separate.
Connect the signal cable from the RGB output port of the PC to the RGB (PC) port of the TV or the
signal cable from the HDMI output port of the PC to the HDMI IN port on the TV.
Connect the audio cable from the PC to the Audio input on the TV. (Audio cables are not included
with the TV).
If using a sound card, adjust PC sound as required.
If the graphic card on the PC does not output analogue and digital RGB simultaneously, connect only
one of either RGB or HDMI IN to display the PC output on the TV.
If the graphic card on the PC does output analogue and digital RGB simultaneously, set the TV to
either RGB or HDMI. (The other mode is set to Plug and Play automatically by the TV.)
DOS mode may not work depending on the video card if you use an HDMI to DVI cable.
If you use too long an RGB-PC cable, there may be interference on the screen. We recommend using
under 5 m of cable. This provides the best picture quality.
Make sure to read the Safety Precautions
before using the product.
Keep the Owner’s Manual (CD) in an
accessible place for future reference.
The model and serial number of the TV is
located on the back and one side of the
TV. Record it below should you ever need
service.
MODEL
SERIAL
To obtain the source code under GPL, LGPL,
MPL and other open source licenses, that is
contained in this product, please visit http://
opensource.lge.com.
In addition to the source code, all referred
license terms, warranty disclaimers and
copyright notices are available for download.
LG Electronics will also provide open source
code to you on CD-ROM for a charge covering
the cost of performing such distribution (such
as the cost of media, shipping and handling)
upon email request to opensource@lge.com.
This offer is valid for three (3) years from the
date on which you purchased the product.
Loading...
