Page 1
Not for Reproduction
Page 2
Not for Reproduction
Page 3
Pictorial index
Not for Reproduction
For safety
1
and security
Search by illustration
Make sure to read through them
2
Instrument cluster
Operation of each
3
component
4
Driving
5
Interior features
Maintenance
6
and care
When trouble
7
arises
Vehicle
8
specifications
How to read the gauges and meters, the variety of warning
lights and indicators, etc.
Opening and closing the doors and windows, adjustment
before driving, etc.
Operations and advice which are necessary for driving
Usage of the interior features, etc.
Caring for your vehicle and maintenance procedures
What to do in case of malfunction or emergency
Vehicle specifications, customizable features, etc.
Index
Search by symptom
Search alphabetically
Page 4
TABLE OF CONTENTS2
Not for Reproduction
For your information...................................8
Reading this manual.................................. 12
How to search ............................................. 13
Pictorial index.............................................. 14
1
For safety and security
1-1. For safe use
Before driving.................................26
For safe driving...............................28
Seat belts ..........................................30
SRS airbags .....................................38
Safety information
for children.....................................51
Child restraint systems...............52
Installing child restraints.............60
Exhaust gas precautions ............ 70
1-2. Theft deterrent system
Engine immobilizer
system...............................................71
Alarm .................................................72
2
Instrument cluster
2. Instrument cluster
Warning lights and
indicators......................................80
Gauges and meters.....................86
Multi-information display...........90
Head-up display............................98
Fuel consumption
information..................................103
Operation of
3
each component
3-1. Key information
Keys ..................................................108
3-2. Opening, closing and locking
the doors
Side doors........................................114
Back door....................................... 122
Smart entry & start
system...........................................132
Page 5
3
Not for Reproduction
3-3. Adjusting the seats
Front seats......................................138
Rear seats.........................................141
Driving position
memory........................................150
Head restraints.............................154
3-4. Adjusting the steering wheel
and mirrors
Steering wheel .............................157
Inside rear view mirror..............159
Outside rear view
mirrors............................................161
3-5. Opening and closing the
windows and moon roof
Power windows............................165
Moon roof......................................168
4
Driving
4-1. Before driving
Driving the vehicle.......................174
Cargo and luggage....................183
Trailer towing................................185
4-2. Driving procedures
Engine (ignition) switch............196
Automatic transmission............201
Turn signal lever........................ 208
Parking brake..............................209
4-3. Operating the lights and
wipers
Headlight switch.......................... 212
AHS (Adaptive High-beam
System).........................................215
Automatic High Beam.............220
Fog light switch...........................225
Windshield wipers and
washer .........................................226
Rear window wiper and
washer .........................................229
Headlight cleaner switch......... 231
4-4. Refueling
Opening the fuel
tank cap.......................................232
1
2
3
4
5
6
7
8
Page 6
TABLE OF CONTENTS4
Not for Reproduction
4-5. Using the driving support
systems
Lexus Safety System +.............235
PCS (Pre-Crash Safety
system).........................................240
LDA (Lane Departure
Alert).............................................251
Dynamic radar cruise control
with full-speed range.............260
Cruise control .............................272
Driving mode select
switch ...........................................275
Lexus parking
assist-sensor..............................278
4-Wheel AHC (Active
Height Control
Suspension)..............................285
Four-wheel drive
system..........................................293
Crawl Control (with
Turn Assist function)..............297
Multi-terrain Select...................302
Multi-terrain Monitor..............305
BSM
(Blind Spot Monitor)..............354
• BSM function........................358
• RCTA function......................362
DPF (Diesel Particulate
Filter) system............................368
Driving assist systems...............372
4-6. Driving tips
Off-road precautions...............378
Winter driving tips......................381
5
Interior features
5-1. Remote Touch screen
Remote Touch/12.3-inch
display......................................... 386
5-2. Lexus Climate Concierge
Lexus Climate Concierge......392
5-3. Using the air conditioning
system and defogger
Front automatic air
conditioning system...............394
Rear air conditioning
system..........................................407
Heated steering wheel/
seat heaters/
seat ventilators..........................410
5-4. Using the interior lights
Interior lights list...........................414
• Interior lights...........................415
• Personal lights........................416
Page 7
5
Not for Reproduction
5-5. Using the storage features
List of storage features.............418
• Glove box ................................419
• Overhead console ..............420
• Cup holders ...........................420
• Bottle holders ........................422
• Auxiliary boxes .....................423
Luggage compartment
features........................................425
5-6. Using the other interior
features
Other interior features............427
• Cool box ..................................427
• Sun visors.................................428
• Vanity mirrors........................428
• Clock.........................................429
• Power outlet...........................429
• Wireless charger..................432
• Armrest................................... 438
• Rear door sunshades..........439
• Coat hooks .............................439
• Assist grips..............................440
6
Maintenance and care
6-1. Maintenance and care
Cleaning and protecting
the vehicle exterior.................442
Cleaning and protecting
the vehicle interior..................445
6-2. Maintenance
Maintenance
requirements.............................448
1
2
3
4
5
6
7
8
Page 8
TABLE OF CONTENTS6
Not for Reproduction
6-3. Do-it-yourself maintenance
Do-it-yourself service
precautions...............................450
Hood ...............................................452
Engine compartment................453
Tires .................................................468
Tire inflation pressure...............476
Wheels............................................478
Air conditioning filter...............480
Electronic key battery..............482
Checking and
replacing fuses.........................484
Light bulbs.................................... 488
7
When trouble arises
7-1. Essential information
Emergency flashers...................494
If your vehicle has to
be stopped in an
emergency.................................495
If the vehicle is trapped
in rising water............................496
7-2. Steps to take in an
emergency
If your vehicle needs
to be towed................................497
If you think something
is wrong......................................503
Fuel pump shut off system
(gasoline engine only).......... 504
If a warning light
turns on or a warning
buzzer sounds......................... 505
If a warning message
is displayed....................................511
If you have a flat tire (vehicles
with a spare tire).......................516
If you have a flat tire (vehicles
with an emergency tire
puncture repair kit) ............... 528
If the engine will
not start....................................... 538
If the electronic key does
not operate properly............ 540
If the vehicle battery
is discharged.............................543
If your vehicle overheats.........546
If you run out of fuel
and the engine stalls
(diesel engine only)................549
If the vehicle becomes
stuck.............................................550
Page 9
8
For vehicles with a navigation system or a multimedia system, refer to the
“Navigation System Owner’s Manual” for information regarding the equipment listed below.
• Navigation system
• Hands-free system
(for cellular phone)
• Rear seat entertainment system
• Audio/video system
Not for Reproduction
Vehicle specifications
8-1. Specifications
Maintenance data
(fuel, oil level, etc.)...................554
Fuel information..........................566
8-2. Customization
Customizable features........... 568
8-3. Initialization
Items to initialize........................585
7
1
2
3
Index
What to do if...
(Troubleshooting)..............................588
Alphabetical index.................................592
4
5
6
7
8
Page 10
8
Not for Reproduction
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equipment, including
options. Therefore, you may find some explanations for equipment not installed on your
vehicle.
All specifications provided in this manual are current at the time of printing. However,
because of the Lexus policy of continual product improvement, we reserve the right to
make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ from your
vehicle in terms of color and equipment.
Accessories, spare parts and modification of your Lexus
A wide variety of non-genuine spare parts and accessories for Lexus vehicles are currently available in the market. Using these spare parts and accessories which are not
genuine Lexus products may adversely affect the safety of your vehicle, even though
these parts may be approved by certain authorities in your country. Toyota Motor Corporation therefore cannot accept any liability or guarantee spare parts and accessories
which are not genuine Lexus products, nor for replacement or installation involving such
parts.
This vehicle should not be modified with non-genuine Lexus products. Modification with
non-genuine Lexus products could affect its performance, safety or durability, and may
even violate governmental regulations. In addition, damage or performance problems
resulting from the modification may not be covered under warranty.
Page 11
Installation of an RF-transmitter system
Not for Reproduction
The installation of an RF-transmitter system in your vehicle could affect electronic systems such as:
● Multiport fuel injection system/sequential multiport fuel injection system
● Lexus Safety System +
● Cruise control system
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
Be sure to check with your Lexus dealer for precautionary measures or special instructions regarding installation of an RF-transmitter system.
Further information regarding frequency bands, power levels, antenna positions and
installation provisions for the installation of RF-transmitters, is available on request at
your Lexus dealer.
Vehicle data recording
The vehicle is equipped with sophisticated computers that will record certain data, such
as:
The recorded data varies according to the vehicle grade level and options with which it is
equipped.
These computers do not record conversations or sounds, and only record images outside of the vehicle in certain situations.
• Engine speed/Electric motor speed (traction motor speed)
• Accelerator status
•Brake status
• Vehicle speed
• Operation status of the driving assist systems, such as the ABS and pre-crash safety
system
● Data usage
Lexus may use the data recorded in this computer to diagnose malfunctions, conduct
research and development, and improve quality.
Lexus will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehicle
is leased
• In response to an official request by the police, a court of law or a government
agency
• For use by Lexus in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or vehicle
owner
9
Page 12
10
Not for Reproduction
Event data recorder
This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR
is to record, in certain crash or near crash-like situations, such as an airbag deployment
or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems
performed. The EDR is designed to record data related to vehicle dynamics and safety
systems for a short period of time, typically 30 seconds or less. However, data may not
be recorded depending on the severity and type of a crash.
The EDR in this vehicle is designed to record such data as:
• How various systems in your vehicle were operating;
• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,
• How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in which
crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs;
no data are recorded by the EDR under normal driving conditions and no personal data
(e.g., name, gender, age, and crash location) are recorded. However, other parties, such
as law enforcement, could combine the EDR data with the type of personally identifying
data routinely acquired during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as
law enforcement, that have the special equipment, can read the information if they have
access to the vehicle or the EDR.
● Disclosure of the EDR data
Lexus will not disclose the data recorded in an EDR to a third party except when:
• An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is
obtained
• In response to an official request by the police, a court of law or a government
agency
• For use by Lexus in a lawsuit
However, if necessary, Lexus may:
• Use the data for research on vehicle safety performance
• Disclose the data to a third party for research purposes without disclosing information about the specific vehicle or vehicle owner
Page 13
Scrapping of your Lexus
WARNING
Not for Reproduction
The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive
chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as
they are, this may cause an accident such as fire. Be sure to have the systems of the SRS
airbag and seat belt pretensioner removed and disposed of by a qualified service shop or
by your Lexus dealer before you scrap your vehicle.
■ General precautions while driving
Driving under the influence: Never drive your vehicle when under the influence of
alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol and
certain drugs delay reaction time, impair judgment and reduce coordination, which
could lead to an accident that could result in death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or
pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that distracts the
driver, such as adjusting controls, talking on a cellular phone or reading can result in a
collision with resulting death or serious injury to you, your occupants or others.
■ General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to have or use
the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is also a
danger that children may injure themselves by playing with the windows, the moon
roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
11
Page 14
12
Not for Reproduction
Reading this manual
WARNING:
Explains something that, if not obeyed, could cause death or serious injury
to people.
NOTICE:
Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment.
Indicates operating or working procedures. Follow the steps in
numerical order.
Indicates the action (pushing,
turning, etc.) used to operate
switches and other devices.
Indicates the outcome of an
operation (e.g. a lid opens).
Indicates the component or position being explained.
Means “Do not”, “Do not do this”,
or “Do not let this happen”.
Page 15
How to search
Not for Reproduction
■ Searching by name
• Alphabetical index............... P. 592
■ Searching by installation position
• Pictorial index ............................. P. 14
■ Searching by symptom or sound
• What to do if...
(Troubleshooting) ................P. 588
13
■ Searching by title
• Table of contents .........................P. 2
Page 16
14
1
2
3
Not for Reproduction
Pictorial index
Pictorial index
■ Exterior
Side doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 114
Locking/unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 114
Opening/closing the door glasses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 165
Locking/unlocking by using the mechanical key . . . . . . . . . . . . . . . . . . . . . . . P. 540
Warning lights/warning messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 507, 511
Back door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 122
Opening from outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 123
Warning lights/warning messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 507, 511
Outside rear view mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 161
Adjusting the mirror angle. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 161
Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 162
Defogging the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 401
Page 17
Pictorial index
4
5
6
7
8
9
10
11
12
13
14
15
Not for Reproduction
Windshield wipers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 226
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 381
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 443
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 232
Refueling method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 232
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 557
Tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 468
Tire size/inflation pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 564
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 381
Checking/rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 468
Coping with flat tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 516, 528
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 452
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 452
Engine oil. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 558
Coping with overheat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 546
Camera* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 305
Light bulbs of the exterior lights for driving
(Replacing method: P. 488, Watts: P. 565)
Headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 212
Front position lights/daytime running lights . . . . . . . . . . . . . . . . . . . . . . . . P. 212
Front fog lights/rear fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 225
Cornering lights* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 212
Turn signal lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
Stop/tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 212
Hill-start assist control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 372
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 212
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 201
15
*: If equipped
Page 18
16
1
2
3
Not for Reproduction
Pictorial index
■ Instrument panel
Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 196
Starting the engine/changing the modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 196
Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 495
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 538
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 511
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 201
Changing the shift position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 201
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 497
When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 206
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 86
Reading the meters/adjusting the instrument panel light. . . . . . . . . . . . . . . . .P. 86
Warning lights/indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 80
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 505
Page 19
Pictorial index
4
5
6
7
8
9
10
11
12
13
Not for Reproduction
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 90
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 90
When the warning messages are displayed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 511
Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 381
Warning buzzer/message. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 211, 511
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
Headlight switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 212
Headlights/front position lights/tail lights/daytime running lights . . . . . . . P. 212
Front fog lights/rear fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 225
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 226
Rear window wiper and washer switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 229
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 226, 229
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 464
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 443
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 494
Fuel filler door opener . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 234
Hood lock release lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 452
Tilt and telescopic steering control switch. . . . . . . . . . . . . . . . . . . . . . . . . . P. 157
Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 157
Driving position memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 150
Front automatic air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 394
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 394
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 401
Audio system*
Hands-free system*
17
*: Refer to the “Navigation System Owner’s Manual”.
Page 20
18
1
2
3
4
5
6
7
8
9
10
11
12
13
Not for Reproduction
■ Switches
Pictorial index
Outside rear view mirror switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 161
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 165
Door lock switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 117
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 165
Driving position memory buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 150
Easy access mode switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 285
HUD (Head-up display) switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 98
Headlight cleaner switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 231
Automatic High Beam switch
Adaptive High-beam System switch
“RSCA OFF” switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 50
DPF system switch
Instrument panel light control dial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 88
Odometer/trip meter and trip meter reset button . . . . . . . . . . . . . . . . . . P. 87
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 368
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 220
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 215
Page 21
Pictorial index
1
2
3
4
5
6
7
Not for Reproduction
Tire pressure warning reset switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 469
PCS (Pre-Crash Safety system) switch
Heater idle up switch
Power back door switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 122
Power back door main switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 122
VIEW switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 305
Lexus parking assist-sensor switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 278
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 402
* . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 240
19
*: If equipped
Page 22
20
1
2
3
4
5
6
7
8
Not for Reproduction
Pictorial index
Audio remote control switches*
Talk switch*
Telephone switches*
Meter control switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 91
Vehicle-to-vehicle distance switch
LDA (Lane Departure Alert) switch
Cruise control switch
Cruise control*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 272
Dynamic radar cruise control with full-speed range*2. . . . . . . . . . . . . . . . . P. 260
Paddle shift switches*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 203
1
1
1
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 260
2
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 251
Page 23
Pictorial index
1
2
3
4
5
6
7
8
9
10
Not for Reproduction
Height select/height control OFF switches . . . . . . . . . . . . . . . . . . . . . . . .P. 285
Four-wheel drive control switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 293
Second start mode switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 202
Center differential lock/unlock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 293
VSC OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 373
Crawl Control switches/Multi-terrain Select mode
selector switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 297, 302
Driving mode select switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 275
2
*
Front seat heater/ventilator switches
Heated steering wheel switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 410
1
*
Remote Touch
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 386
. . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 410
21
1
*
: Refer to the “Navigation System Owner’s Manual”.
2
*
: If equipped
Page 24
22
1
2
3
4
5
6
7
8
9
10
11
12
13
Not for Reproduction
■ Interior
Pictorial index
SRS airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 38
Floor mats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 26
Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 138
Rear seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 141
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 154
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 30
Cool box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 427
Inside lock buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 117
Cup holders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 420
Auxiliary boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 423
Rear air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 407
1, 2
Rear seat entertainment system
Assist grips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 440
*
Page 25
Pictorial index
1
2
3
4
5
6
*
1
: If equipped
*
2
: Refer to the “Navigation System Owner’s Manual”.
*
3
: NEVER use a rearward facing child restraint on
a seat protected by an ACTIVE AIRBAG in
front of it, DEATH or SERIOUS INJURY to the
CHILD can occur. (P. 68)
Not for Reproduction
Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 159
3
*
Sun visors
Vanity mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 428
Personal/interior lights
Moon roof switches
Intrusion sensor and tilt sensor cancel switch . . . . . . . . . . . . . . . . . . . . . . . P. 75
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 428
4
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 414
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 168
23
4
*
: The illustration shows the front, but they are also equipped in the rear.
Page 26
24
Not for Reproduction
Pictorial index
Page 27
25
Not for Reproduction
For safety and security
1
1-1. For safe use
Before driving.................................26
For safe driving..............................28
Seat belts..........................................30
SRS airbags.....................................38
Safety information
for children.....................................51
Child restraint systems...............52
Installing child restraints.............60
Exhaust gas precautions............70
1-2. Theft deterrent system
Engine immobilizer
system...............................................71
Alarm................................................. 72
Page 28
26
*
Not for Reproduction
1-1. For safe use
Before driving
Floor mat
Use only floor mats designed specifically for vehicles of the same model and
model year as your vehicle. Fix them securely in place onto the carpet.
1
Insert the retaining hooks (clips) into
the floor mat eyelets.
2
Turn the upper knob of each retaining hook (clip) to secure the floor
mats in place.
*: Always align the marks.
The shape of the retaining hooks (clips) may differ from that shown in the illustration.
Page 29
1-1. For safe use
WARNING
● Check that the floor mat is securely fixed in
the correct place with all the provided retaining hooks (clips). Be especially careful to perform this check after cleaning the floor.
● With the engine stopped and the shift lever in
P, fully depress each pedal to the floor to
make sure it does not interfere with the floor
mat.
Not for Reproduction
Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering with the pedals while driving. An unexpectedly high speed may result or it may become difficult to
stop the vehicle. This could lead to an accident, resulting in death or serious injury.
■ When installing the driver’s floor mat
● Do not use floor mats designed for other models or different model year vehicles,
even if they are Lexus Genuine floor mats.
● Only use floor mats designed for the driver’s seat.
● Always install the floor mat securely using the retaining hooks (clips) provided.
● Do not use two or more floor mats on top of each other.
● Do not place the floor mat bottom-side up or upside-down.
■ Before driving
27
1
For safety and security
Page 30
28
Not for Reproduction
1-1. For safe use
For safe driving
For safe driving, adjust the seat and mirror to an appropriate position before
driving.
Correct driving posture
1
Adjust the angle of the seatback so
that you are sitting straight up and so
that you do not have to lean forward
to steer. (P. 138)
2
Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the elbow
when gripping the steering wheel.
(P. 138)
3
Lock the head restraint in place with the center of the head restraint closest to
the top of your ears. (P. 154)
4
Wear the seat belt correctly. (P. 30)
Correct use of the seat belts
Make sure that all occupants are wearing their seat belts before driving the vehicle. (P. 30)
Use a child restraint system appropriate for the child until the child becomes
large enough to properly wear the vehicle’s seat belt. (P. 52)
Page 31
1-1. For safe use
WARNING
Not for Reproduction
Adjusting the mirrors
Make sure that you can see backward clearly by adjusting the inside and outside
rear view mirrors properly. (P. 159, 161)
29
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
● Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the seat tracks and stop
the seat from locking in place. This may lead to an accident and the adjustment mechanism may also be damaged.
● Always observe the legal speed limit when driving on public roads.
● When driving over long distances, take regular breaks before you start to feel tired.
Also, if you feel tired or sleepy while driving, do not force yourself to continue driving
and take a break immediately.
1
For safety and security
Page 32
30
Release button
1
Not for Reproduction
1-1. For safe use
Seat belts
Make sure that all occupants are wearing their seat belts before driving the
vehicle.
Correct use of the seat belts
● Extend the shoulder belt so that it
comes fully over the shoulder, but
does not come into contact with the
neck or slide off the shoulder.
● Position the lap belt as low as possi-
ble over the hips.
● Adjust the position of the seatback.
Sit up straight and well back in the
seat.
● Do not twist the seat belt.
Fastening and releasing the seat belt (except for the third center seat)
To fasten the seat belt, push the plate
into the buckle until a click sound is
heard.
2
To release the seat belt, press the
release button.
Page 33
1-1. For safe use
Tab B
Tab A
Tab B
Buckle B
Tab A
Buckle A
Release button
Not for Reproduction
Fastening and releasing the third center seat belt (if equipped)
1
Pull out the tab.
2
Push tab B into buckle B until a clicking sound is heard.
3
Push tab A into buckle A until a
clicking sound is heard.
To release, push the release button on
buckle A.
31
1
For safety and security
Page 34
32
Buckle A
Tab A
Buckle B
Buckle B
Tab A
Tab B
Not for Reproduction
1-1. For safe use
Releasing and stowing the third center seat belt (if equipped)
1
Push the release button on buckle A.
2
Push either the mechanical key or
tab A into buckle B.
When releasing and storing the seat
belt, hold the belt while winding it back
gently.
3
Put tabs A and B together and stow
them in the holder.
To reattach the seat belt, reverse the
above procedure, pulling out the tabs
and inserting tab B into buckle B.
Page 35
1-1. For safe use
1
Not for Reproduction
Adjusting the seat belt shoulder anchor height (front and second outboard seats)
Push the seat belt shoulder anchor
down while pressing the release button.
2
Push the seat belt shoulder anchor
up.
Move the height adjuster up and down
as needed until you hear a click.
Seat belt pretensioners (front and second outboard seats)
The pretensioner helps the seat belt to
quickly restrain the occupant by
retracting the seat belt when the vehicle is subjected to certain types of
severe frontal collision or a vehicle rollover.
The pretensioners do not activate in the
event of a minor frontal impact, a side
impact or a rear impact.
33
1
For safety and security
Page 36
34
Not for Reproduction
■ Emergency locking retractor (ELR)
■ When the third center seat belt cannot be extended (if equipped)
■ Child seat belt usage
■ Replacing the belt after the pretensioner has been activated
■ Seat belt regulations
1-1. For safe use
The retractor will lock the belt during a sudden stop or on impact. It may also lock if you
lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can
move around fully.
Put your fingers between the seat belt and the
holder.
Pull the seat belt forcefully in the direction of the
arrow and then release it to unlock.
The seat belts of your vehicle were principally designed for persons of adult size.
● Use a child restraint system appropriate for the child, until the child becomes large
enough to properly wear the vehicle’s seat belt. (P. 52)
● When the child becomes large enough to properly wear the vehicle’s seat belt, follow
the instructions on P. 30 regarding seat belt usage.
If the vehicle is involved in multiple collisions, the pretensioner will activate for the first
collision, but will not activate for the second or subsequent collisions.
If seat belt regulations exist in the country where you reside, please contact your Lexus
dealer for seat belt replacement or installation.
Page 37
1-1. For safe use
WARNING
Obtain medical advice and wear the seat belt
in the proper way. (P. 30)
Women who are pregnant should position the
lap belt as low as possible over the hips in the
same manner as other occupants, extending
the shoulder belt completely over the shoulder
and avoiding belt contact with the rounding of
the abdominal area.
If the seat belt is not worn properly, not only the
pregnant woman, but also the fetus could suffer
death or serious injury as a result of sudden
braking, sudden swerving or a collision.
Not for Reproduction
Observe the following precautions to reduce the risk of injury in the event of sudden
braking, sudden swerving or an accident.
Failure to do so may cause death or serious injury.
■ Wearing a seat belt
● Ensure that all passengers wear a seat belt.
● Always wear a seat belt properly.
● Each seat belt should be used by one person only. Do not use a seat belt for more
than one person at once, including children.
● Lexus recommends that children be seated in the rear seat and always use a seat belt
and/or an appropriate child restraint system.
● To achieve a proper seating position, do not recline the seat more than necessary. The
seat belt is most effective when the occupants are sitting up straight and well back in
the seats.
● Do not wear the shoulder belt under your arm.
● Always wear your seat belt low and snug across your hips.
■ Pregnant women
35
1
For safety and security
Page 38
36
WARNING
Do not use the third center seat belt with either
buckle released. Fastening only one of the
buckles may result in death or serious injury in
case of sudden braking, sudden swerving or an
accident.
Not for Reproduction
1-1. For safe use
■ People suffering illness
Obtain medical advice and wear the seat belt in the proper way. (P. 30)
■ When children are in the vehicle
Do not allow children to play with the seat belt. If the seat belt becomes twisted around
a child’s neck, it may lead to choking or other serious injuries that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to cut the
belt.
■ Seat belt pretensioners
If the pretensioner has activated, the SRS warning light will come on. In that case, the
seat belt cannot be used again and must be replaced at your Lexus dealer.
■ Adjustable shoulder anchor
Always make sure the shoulder belt is positioned across the center of your shoulder.
The belt should be kept away from your neck, but not falling off your shoulder. Failure to
do so could reduce the amount of protection in an accident and cause death or serious
injuries in the event of a sudden stop, sudden swerve or accident. (P. 33)
■ When using the third center seat belt (if equipped)
■ Seat belt damage and wear
● Do not damage the seat belts by allowing the belt, plate, or buckle to be jammed in
the door.
● Inspect the seat belt system periodically. Check for cuts, fraying, and loose parts. Do
not use a damaged seat belt until it is replaced. Damaged seat belt cannot protect an
occupant from death or serious injury.
● Ensure that the belt and plate are locked and the belt is not twisted.
If the seat belt does not function correctly, immediately contact your Lexus dealer.
● Replace the seat assembly, including the belts, if your vehicle has been involved in a
serious accident, even if there is no obvious damage.
● Do not attempt to install, remove, modify, disassemble or dispose of the seat belts.
Have any necessary repairs carried out by your Lexus dealer. Inappropriate handling
may lead to incorrect operation.
Page 39
1-1. For safe use
WARNING
Not for Reproduction
■ For Australian owners
Observe the following additional WARNINGS.
WARNING: Seatbelts are designed to bear upon the bony structure of the body, and
should be worn low across the front of the pelvis or the pelvis, chest and shoulders, as
applicable; wearing the lap section of the belt across the abdominal area must be
avoided.
Seatbelts should be adjusted as firmly as possible, consistent with comfort, to provide
the protection for which they have been designed. A slack belt will greatly reduce the
protection afforded to the wearer.
Care should be taken to avoid contamination of the webbing with polishes, oils and
chemicals, and particularly battery acid. Cleaning may safely be carried out using mild
soap and water. The belt should be replaced if webbing becomes frayed, contaminated
or damaged.
It is essential to replace the entire assembly after it has been worn in a severe impact
even if damage to the assembly is not obvious.
Belts should not be worn with straps twisted.
Each belt assembly must only be used by one occupant; it is dangerous to put a belt
around a child being carried on the occupant’s lap.
WARNING: No modifications or additions should be made by the user which will
either prevent the seat belt adjusting devices from operating to remove slack, or prevent the seat belt assembly from being adjusted to remove slack.
37
1
For safety and security
Page 40
38
Not for Reproduction
1-1. For safe use
SRS airbags
The SRS airbags inflate when the vehicle is subjected to certain types of
severe impacts that may cause significant injury to the occupants. They work
together with the seat belts to help reduce the risk of death or serious injury.
Page 41
1-1. For safe use
1
2
3
4
5
Not for Reproduction
◆ SRS front airbags
SRS driver airbag/front passenger airbag
Can help protect the head and chest of the driver and front passenger from
impact with interior components
SRS knee airbags
Can help provide driver and front passenger protection
◆ SRS side and curtain shield airbags
SRS front side airbags
Can help protect the torso of the front seat occupants
SRS rear side airbags
Can help protect the torso of occupants in the second outboard seats
SRS curtain shield airbags
Can help protect primarily the head of occupants in the outboard seats
39
1
For safety and security
Page 42
40
10
11
12
13
14
15
16
17
Not for Reproduction
1-1. For safe use
SRS airbag system components
1
Knee airbags
2
Curtain shield airbags
3
Front passenger airbag
4
Side impact sensors (front door)
5
Front side airbags
6
SRS warning light and “RSCA OFF”
indicator light
7
Side impact sensors (rear)
8
Rear side airbags (second outboard
seat)
9
Driver airbag
Driver’s seat belt buckle switch
Safing sensor (rear)
Airbag sensor assembly
Front impact sensors
Seat belt pretensioners and force
limiters (front seats)
Driver’s seat position sensor
“RSCA OFF” switch
Seat belt pretensioners (second
outboard seats)
Page 43
1-1. For safe use
WARNING
Not for Reproduction
The main SRS airbag system components are shown above. The SRS airbag system is controlled by the airbag sensor assembly. As the airbags deploy, a chemical reaction in the inflators quickly fills the airbags with non-toxic gas to help
restrain the motion of the occupants.
41
■ SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may cause death or serious injury.
● The driver and all passengers in the vehicle must wear their seat belts properly.
The SRS airbags are supplemental devices to be used with the seat belts.
● The SRS driver airbag deploys with considerable force, and can cause death or seri-
ous injury especially if the driver is very close to the airbag.
Since the risk zone for the driver’s airbag is the first 50 - 75 mm (2 - 3 in.) of inflation,
placing yourself 250 mm (10 in.) from your driver airbag provides you with a clear
margin of safety. This distance is measured from the center of the steering wheel to
your breastbone. If you sit less than 250 mm (10 in.) away now, you can change your
driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals comfortably.
• Slightly recline the back of the seat. Although vehicle designs vary, many drivers
can achieve the 250 mm (10 in.) distance, even with the driver seat all the way forward, simply by reclining the back of the seat somewhat. If reclining the back of
your seat makes it hard to see the road, raise yourself by using a firm, non-slippery
cushion, or raise the seat if your vehicle has that feature.
• If your steering wheel is adjustable, tilt it downward. This points the airbag toward
your chest instead of your head and neck.
The seat should be adjusted as recommended above, while still maintaining control of
the foot pedals, steering wheel, and your view of the instrument panel controls.
1
For safety and security
Page 44
42
WARNING
● Do not sit on the edge of the seat or lean
against the dashboard.
● Do not allow a child to stand in front of the
SRS front passenger airbag unit or sit on the
knees of a front passenger.
● Do not allow the front seat occupants to hold
items on their knees.
Not for Reproduction
1-1. For safe use
■ SRS airbag precautions
● The SRS front passenger airbag also deploys with considerable force, and can cause
death or serious injury especially if the front passenger is very close to the airbag. The
front passenger seat should be as far from the airbag as possible with the seatback
adjusted, so the front passenger sits upright.
● Improperly seated and/or restrained infants and children can be killed or seriously
injured by a deploying airbag. An infant or child who is too small to use a seat belt
should be properly secured using a child restraint system. Lexus strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front
passenger seat. (P. 52)
Page 45
WARNING
■ SRS airbag precautions
● Do not lean against the door, the roof side rail
or the front, side and rear pillars.
● Do not allow anyone to kneel on the passen-
ger seats toward the door or put their head or
hands outside the vehicle.
● Do not attach anything to or lean anything
against areas such as the dashboard, steering
wheel pad and lower portion of the instrument panel.
These items can become projectiles when the
SRS driver, front passenger and knee airbags
deploy.
Not for Reproduction
1-1. For safe use
43
1
For safety and security
Page 46
44
WARNING
● Do not attach anything to areas such as a
door, windshield glass, side door glass, front,
side or rear pillars, roof side rail and assist
grip. (Except for the speed limit sticker
P. 536)
Not for Reproduction
1-1. For safe use
■ SRS airbag precautions
● Do not hang coat hangers or other hard objects on the coat hooks. All of these items
could become projectiles and may cause death or serious injury, should the SRS curtain shield airbags deploy.
● If the vinyl cover is put on the area where the SRS knee airbag will deploy, be sure to
remove it.
Page 47
1-1. For safe use
WARNING
Not for Reproduction
■ SRS airbag precautions
● Do not use seat accessories which cover the parts where the SRS side airbags inflate
as they may interfere with inflation of the airbags. Such accessories may prevent the
side airbags from activating correctly, disable the system or cause the side airbags to
inflate accidentally, resulting in death or serious injury.
● Do not strike or apply significant levels of force to the area of the SRS airbag compo-
nents.
Doing so can cause the SRS airbags to malfunction.
● Do not touch any of the component parts immediately after the SRS airbags have
deployed (inflated) as they may be hot.
● If breathing becomes difficult after the SRS airbags have deployed, open a door or
window to allow fresh air in, or leave the vehicle if it is safe to do so. Wash off any residue as soon as possible to prevent skin irritation.
● If the areas where the SRS airbags are stored, such as the steering wheel pad and
front, side and rear pillar garnishes, are damaged or cracked, have them replaced by
your Lexus dealer.
■ Modification and disposal of SRS airbag system components
Do not dispose of your vehicle or perform any of the following modifications without
consulting your Lexus dealer. The SRS airbags may malfunction or deploy (inflate)
accidentally, causing death or serious injury.
● Installation, removal, disassembly and repair of the SRS airbags
● Repairs, modifications, removal or replacement of the steering wheel, instrument
panel, dashboard, seats or seat upholstery, front, side and rear pillars or roof side rail
● Repairs or modifications of the front fender, front bumper, or side of the occupant
compartment
● Installation of a grille guard (bull bars, kangaroo bar, etc.), snow plows, winches or
roof luggage carrier
● Modifications to the vehicle’s suspension system
● Installation of electronic devices such as mobile two-way radios (RF-transmitter) and
CD players
45
1
For safety and security
Page 48
46
Not for Reproduction
■ If the SRS airbags deploy (inflate)
■ SRS airbag deployment conditions (SRS front airbags)
■ SRS airbag deployment conditions (SRS side and curtain shield airbags)
■ Conditions under which the SRS airbags may deploy (inflate), other than a collision
1-1. For safe use
● Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the
extremely high speed deployment (inflation) by hot gases.
● A loud noise and white powder will be emitted.
● Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the
front seats, parts of the front, side and rear pillars and roof side rail, may be hot for several minutes. The airbag itself may also be hot.
● The windshield may crack.
● The SRS front airbag will deploy in the event of an impact that exceeds the set threshold
level (the level of force corresponding to an approximately 20 - 30 km/h [12 - 18 mph]
frontal collision with a fixed wall that does not move or deform).
However, this threshold velocity will be considerably higher in the following situations:
• If the vehicle strikes an object, such as a parked vehicle or sign pole, which can move
or deform on impact
• If the vehicle is involved in an underride collision, such as a collision in which the
front of the vehicle “underrides”, or goes under, the bed of a truck
● Depending on the type of collision, it is possible that only the seat belt pretensioners will
activate.
● The SRS side and curtain shield airbags will deploy in the event of an impact that
exceeds the set threshold level (the level of force corresponding to the impact force
produced by an approximately 1500 kg [3300 lb.] vehicle colliding with the vehicle
cabin from a direction perpendicular to the vehicle orientation at an approximate
speed of 20 - 30 km/h [12 -18 mph]).
● The SRS curtain shield airbags will deploy in the event of vehicle rollover.
● The SRS side and curtain shield airbags will deploy in the event of a severe frontal colli-
sion.
The SRS front airbags and SRS side and curtain shield airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the
illustration.
● Hitting a curb, edge of pavement or hard sur-
face
● Falling into or jumping over a deep hole
● Landing hard or falling
Page 49
1-1. For safe use
Not for Reproduction
The SRS curtain shield airbags may also deploy under the situations shown in the illustration.
● The angle of vehicle tip-up is marginal
● The vehicle skids and hits a curb stone
■ Types of collisions that may not deploy the SRS airbags (SRS front airbags)
The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear
collision, if it rolls over, or if it is involved in a low-speed frontal collision. But, whenever a
collision of any type causes sufficient forward deceleration of the vehicle, deployment of
the SRS front airbags may occur.
● Collision from the side
● Collision from the rear
● Vehicle rollover
47
1
For safety and security
■ Types of collisions that may not deploy the SRS airbags
(SRS side and curtain shield airbags)
The SRS side and curtain shield airbag system may not activate if the vehicle is subjected
to a collision from the side at certain angles, or a collision to the side of the vehicle body
other than the passenger compartment.
● Collision from the side to the vehicle body
other than the passenger compartment
● Collision from the side at an angle
Page 50
48
Not for Reproduction
1-1. For safe use
The SRS side airbags do not generally inflate if the vehicle is involved in a rear collision, if
it rolls over, or if it is involved in a low-speed side or low-speed frontal collision.
● Collision from the rear
● Vehicle rollover
The SRS curtain shield airbags do not generally inflate if the vehicle is involved in a rear
collision, if it pitches end over end, or if it is involved in a low-speed side or low-speed
frontal collision.
● Collision from the rear
● Pitching end over end
Page 51
1-1. For safe use
Not for Reproduction
■ When to contact your Lexus dealer
In the following cases, the vehicle will require inspection and/or repair. Contact your
Lexus dealer, as soon as possible.
● Any of the SRS airbags have been inflated.
● The front of the vehicle is damaged or
deformed, or was involved in an accident that
was not severe enough to cause the SRS front
airbags to inflate.
● A portion of a door or its surrounding area is
damaged or deformed, or the vehicle was
involved in an accident that was not severe
enough to cause the SRS side and curtain
shield airbags to inflate.
● The pad section of the steering wheel, dash-
board near the front passenger airbag or
lower portion of the instrument panel is
scratched, cracked, or otherwise damaged.
49
1
For safety and security
Page 52
50
WARNING
Not for Reproduction
1-1. For safe use
● The surface of the seats with the side airbag is
scratched, cracked or otherwise damaged.
● The portion of the front, side and rear pillars or
roof side rail garnishes (padding) containing
the curtain shield airbags inside is scratched,
cracked or otherwise damaged.
Deactivating the curtain shield airbags in a vehicle rollover
ON/OFF (hold for a few seconds)
The “RSCA OFF” indicator turns on
(only when the engine switch is in IGNITION ON mode.)
The roll sensing function for the curtain
shield airbags and seat belt pretensioners will turn back on automatically each
time the engine switch is turned to
IGNITION ON mode.
■ This switch only should be used
In a situation where the inflation is not desired (such as during extreme off road driving).
■ Operating conditions when the “RSCA OFF” indicator is on
● The curtain shield airbags and seat belt pretensioners will not activate in a vehicle roll-
over.
● The curtain shield airbags will activate in a severe side impact.
● The seat belt pretensioners will activate in a severe frontal collision.
■ For normal driving
Make sure the “RSCA OFF” indicator is not turned on. If it is left on, the curtain shield
airbag will not activate in the event of an accident, which may result in death or serious
injury.
Page 53
1-1. For safe use
WARNING
Not for Reproduction
Safety information for children
Observe the following precautions when children are in the vehicle.
Use a child restraint system appropriate for the child, until the child becomes
large enough to properly wear the vehicle’s seat belt.
● It is recommended that children sit in the rear seats to avoid accidental con-
tact with the shift lever, wiper switch etc.
● Use the rear door child-protector lock or the window lock switch to avoid
children opening the door while driving or operating the power window accidentally. (P. 118, 165)
● Do not let small children operate equipment which may catch or pinch body
parts, such as the power window, hood, back door, seats etc.
Never leave children unattended in the vehicle, and never allow children to have or use
the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is also a
danger that children may injure themselves by playing with the windows, the moon roof
(if equipped) or other features of the vehicle. In addition, heat build-up or extremely
cold temperatures inside the vehicle can be fatal to children.
51
1
For safety and security
Page 54
52
Not for Reproduction
1-1. For safe use
Child restraint systems
Lexus strongly urges the use of child restraint systems.
Points to remember
Studies have shown that installing a child restraint on a rear seat is much safer
than installing one on the front passenger seat.
● Choose a child restraint system that suits your vehicle and is appropriate to
the age and size of the child.
● For installation details, follow the instructions provided with the child restraint
system.
General installation instructions are provided in this manual. (P. 60)
● If child restraint system regulations exist in the country where you reside,
please contact your Lexus dealer for the child restraint system installation.
● Lexus recommends that you use a child restraint system which conforms to
the regulation ECE No.44.
Page 55
1-1. For safe use
Not for Reproduction
Types of child restraints
Child restraint systems are classified into the following 5 groups according to the
regulation ECE No.44.
Group 0: Up to 10 kg (22 lb.) (0 - 9 months)
Group 0+: Up to 13 kg (28 lb.) (0 - 2 years)
Group I: 9 to 18 kg (20 to 39 lb.) (9 months - 4 years)
Group II: 15 to 25 kg (34 to 55 lb.) (4 years - 7 years)
Group III: 22 to 36 kg (49 to 79 lb.) (6 years - 12 years)
In this owner’s manual, the following 3 types of popular child restraint systems
that can be secured with the seat belts are explained:
Baby seat (infant seat) Child seat (convertible seat)
53
1
For safety and security
Equal to Group 0 and 0+ of ECE
No.44
Junior seat (booster seat)
Equal to Group II and III of ECE No.44
Equal to Group 0+ and I of ECE
No.44
Page 56
54
Not for Reproduction
1-1. For safe use
Child restraint system suitability for various seating positions
If your child restraint system is of “universal” category, you can install it on the
positions mentioned by U or UF in the table below (UF is for forward-facing child
restraint systems only). Child restraint systems category and mass group can be
found in the child restraint system manual.
If your child restraint system is not of the “universal” category (or if you cannot
find information in the table below), please refer to the child restraint system
“vehicle list” for compatibility information or ask the retailer of your child seat.
Seating position
Mass groups
0
Up to 10 kg (22 lb.)
(0 - 9 months)
0+
Up to 13 kg (28 lb.)
(0 - 2 years)
I
9 to 18 kg
(20 to 39 lb.)
(9 months - 4 years)
II, III
15 to 36 kg
(34 to 79 lb.)
(4 - 12 years)
Front
passenger
seat
X UUUX
X UUUX
Rearwardfacing — X
Forward-
facing —
1, 2
UF
*
1, 2
UF
*
Second seat
Outboard Center Outboard Center
U
U*
2
*
2
U*
U*
2
2
Third seat
(if equipped)
2
U*
2
U*
X
X
Key of letters inserted in the above table:
X: Not suitable seat position for children in this mass group.
U: Suitable for “universal” category child restraint systems approved for use in
this mass group.
UF: Suitable for forward-facing “universal” category child restraint systems
approved for use in this mass group.
Page 57
1-1. For safe use
Not for Reproduction
1
*
: Adjust the seatback to the most upright position. Move the front seat fully rearward. If
the passenger seat height can be adjusted, move it to the upper most position.
2
*
: If the head restraint interferes with your child restraint system, and the head restraint
can be removed, remove the head restraint. Otherwise, put the head restraint in the
upper most position.
When securing some types of child restraint systems in second or third row
seats, it may not be possible to properly use the seat belts in positions next to the
child restraint without interfering with it or affecting seat belt effectiveness.
Be sure your seat belt fits snugly across your shoulder and low on your hips. If it
does not, or if it interferes with the child restraint, move to a different position.
Failure to do so may result in death or serious injury.
55
1
For safety and security
Page 58
56
Not for Reproduction
1-1. For safe use
Child restraint system suitability for various seating positions
(with ISOFIX rigid anchors)
ISOFIX child restraint systems are divided in different “size class”. According to
this “size class”, you will be allowed to use it in the vehicle seating position mentioned in the table below. To know your child restraint system “size class” and
“mass group”, please refer to the child restraint system manual.
If your child restraint system has no “size class” (or if you cannot find information
in the table below), please refer to the child restraint system “vehicle list” for compatibility information or ask the retailer of your child seat.
Size class Description
A Full-height, forward-facing child restraint systems
B Reduced-height forward-facing child restraint systems
B1 Reduced-height forward-facing child restraint systems
C Full-size rearward-facing child restraint systems
D Reduced-size rearward-facing child restraint systems
E Rearward-facing infant seat
F Left lateral-facing (carrycot) infant seat
G Right lateral-facing (carrycot) infant seat
Page 59
1-1. For safe use
Not for Reproduction
Seating position
57
Mass groups
Carrycot
0
Up to 10 kg (22 lb.)
0+
Up to 13 kg (28 lb.)
I
9 to 18 kg
(20 to 39 lb.)
Key of letters inserted in the above table:
X: Not suitable seat position for ISOFIX child restraint systems in this mass
group and/or size class.
IUF: Suitable for ISOFIX forward-facing child restraint systems of “universal”
category approved for use in this mass group.
IL: Suitable for ISOFIX child restraint systems of the categories for “specific
vehicles”, “restricted”, or “semi-universal”, approved for use in this mass
group.
Size
class
FXXXXX
GXXXXX
EXILXXX
EXILXXX
DXILXXX
CXILXXX
DXILXXX
CXILXXX
BXIUF
B1 X IUF
AXIUF
Front
seat
Passenger seat
Second seat
Out-
board
Center
* XXX
* XXX
* XXX
Third seat
(if equipped)
Out-
board
Center
*: If the head restraint interferes with your child restraint system, and the head restraint
can be removed, remove the head restraint.
Otherwise, put the head restraint in the upper most position.
When securing some types of child restraint systems in second or third row
seats, it may not be possible to properly use the seat belts in positions next to the
child restraint without interfering with it or affecting seat belt effectiveness. Be
sure your seat belt fits snugly across your shoulder and low on your hips. If it does
not, or if it interferes with the child restraint, move to a different position. Failure
to do so may result in death or serious injury.
1
For safety and security
Page 60
58
Not for Reproduction
■ When installing a child restraint system on the front passenger seat
■ Selecting an appropriate child restraint system
1-1. For safe use
When you have to use a child restraint system on the front passenger seat, adjust the following:
● The seatback to the most upright position
● The seat cushion to the fully rearward and
highest position
● The seat belt height to the lowest position
● Use a child restraint system appropriate for the child until the child becomes large
enough to properly wear the vehicle’s seat belt.
● If the child is too large for a child restraint system, sit the child on a rear seat and use the
vehicle’s seat belt. (P. 30)
Page 61
1-1. For safe use
WARNING
Not for Reproduction
■ Using a child restraint system
The use of a child restraint system not suitable for the vehicle may not properly secure
the infant or child. It may result in death or serious injury (in the event of sudden braking, sudden swerving or an accident).
■ Child restraint precautions
● For effective protection in automobile accidents and sudden stops, a child must be
properly restrained, using a seat belt or child restraint system depending on the age
and size of the child. Holding a child in your arms is not a substitute for a child restraint
system. In an accident, the child can be crushed against the windshield, or between
you and the vehicle’s interior.
● Lexus strongly urges the use of a proper child restraint system that conforms to the
size of the child, installed on the rear seat. According to accident statistics, the child is
safer when properly restrained in the rear seat than in the front seat.
● Never install a rear-facing child restraint system on the front passenger seat.
In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.
● A forward-facing child restraint system may be installed on the front passenger seat
only when it is unavoidable. A child restraint system that requires an upper anchorage
strap should not be used in the front passenger seat since there is no anchor fitting for
the front passenger seat. Adjust the seatback as upright as possible and always move
the seat as far back as possible because the front passenger airbag could inflate with
considerable speed and force. Otherwise, the child may be killed or seriously injured.
● Do not allow the child to lean his/her head or any part of his/her body against the
door or the area of the seat, front, side and rear pillars or roof side rails from which the
SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in the
child restraint system. It is dangerous if the SRS side airbags and curtain shield airbags inflate, and the impact could cause death or serious injury to the child.
● Make sure you have complied with all installation instructions provided by the child
restraint manufacturer and that the system is properly secured. If it is not secured
properly, it may cause death or serious injury to the child in the event of a sudden
stop, sudden swerve or accident.
■ When children are in the vehicle
Do not allow children to play with the seat belt. If the seat belt becomes twisted around
a child’s neck, it may lead to choking or other serious injuries that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to cut the
belt.
■ When the child restraint system is not in use
● Keep the child restraint system properly secured on the seat even if it is not in use. Do
not store the child restraint system unsecured in the passenger compartment.
● If it is necessary to detach the child restraint system, remove it from the vehicle or
store it securely in the luggage compartment. This will prevent it from injuring passengers in the event of a sudden stop, sudden swerve or accident.
59
1
For safety and security
Page 62
60
Not for Reproduction
1-1. For safe use
Installing child restraints
Follow the child restraint system manufacturer’s instructions. Firmly secure
the child restraints using a seat belt or ISOFIX rigid anchor (ISOFIX child
restraint system). Attach the upper anchorage strap when installing a child
restraint.
Seat belts (An ELR belt requires a locking clip.)
ISOFIX rigid anchor (ISOFIX child
restraint system)
These exclusive fixing bars are provided
for the second outboard seats. (Buttons
displaying the location of the anchors
are attached to the seats.)
Child restraint anchor fitting
Anchor fittings are provided for all second seats.
Page 63
1-1. For safe use
1
2
3
4
Not for Reproduction
Installing child restraints using a seat belt
■ Rear-facing Baby seat (infant seat)/child seat (convertible seat)
Fold the seatback while pulling
the seatback angle lever. Return
the seatback and secure it at the
first lock position. (P. 141)
Place the child restraint system
on the second seat or the third
outboard seat facing the rear of
the vehicle.
61
1
For safety and security
Run the seat belt through the
child restraint system and insert
the plate into the buckle. Make
sure that the belt is not twisted.
Install a locking clip near the tab
of the lap and shoulder belt by
inserting the lap and shoulder
webbing through the recesses of
the locking clip.
Page 64
62
5
1
2
3
Not for Reproduction
1-1. For safe use
Latch the attaching clip of the
upper anchorage strap onto the
anchor fitting. (P. 65)
Make sure the seat belt is tightly
secured, and that there is not slack in
the belt.
■ Forward-facing Child seat (convertible seat)
Fold the seatback while pulling
the seatback angle lever. Return
the seatback and secure it at the
first lock position. (P. 141)
Place the child restraint system
on the second or third seat facing
the front of the vehicle.
Run the seat belt through the
child restraint system and insert
the plate into the buckle. Make
sure that the belt is not twisted.
Keep the lap portion of the belt
tight.
Page 65
Install a locking clip near the tab
4
5
1
2
Not for Reproduction
of the lap and shoulder belt by
inserting the lap and shoulder
webbing through the recesses of
the locking clip. Buckle the belt
again. If the belt has any slack,
release the buckle and reinstall
the locking clip.
Latch the attaching clip of the
upper anchorage strap onto the
anchor fitting. (P. 65)
Make sure the seat belt is tightly
secured, and that there is not slack in
the belt.
■ Junior seat (booster seat)
Fold the seatback while pulling
the seatback angle lever. Return
the seatback and secure it at the
first lock position. (P. 141)
1-1. For safe use
63
1
For safety and security
Place the child restraint system
on the seat facing the front of the
vehicle.
Page 66
64
3
1
Not for Reproduction
1-1. For safe use
Sit the child in the child restraint
system. Fit the seat belt to the
child restraint system according
to the manufacturer’s instructions
and insert the plate into the
buckle. Make sure that the belt is
not twisted.
Check that the shoulder belt is correctly positioned over the child’s
shoulder, and that the lap belt is as
low as possible. (P. 30)
Removing a child restraint installed with a seat belt
Push the buckle release button and fully
retract the seat belt.
Installation with ISOFIX rigid anchor (ISOFIX child restraint system)
Fold the seatback forward and then
back to the 1st lock position (most
upright position) until it locks into
place.
2
Take off the covers between the seat
cushion and seatback, then confirm
the position of the ISOFIX rigid
anchors below the symbol in the
seatback.
Page 67
Check the positions of the exclusive
3
1
Front of
vehicle
2
Not for Reproduction
fixing bars, and install the child
restraint system to the seat.
The bars are installed in the clearance
between the seat cushion and seatback.
If the child restraint system has an upper
anchorage strap, the upper anchorage
strap should be latched onto the anchor
fitting.
Using the child restraint anchor fitting
Second outboard seats
Secure the child restraint system
using a seat belt or ISOFIX rigid
anchors, and move the head
restraint in place at the upmost
position.
1-1. For safe use
65
1
For safety and security
Open the anchor fitting cover,
latch the attaching clip onto the
anchor fitting and tighten the
upper anchorage strap.
Make sure the upper anchorage
strap is securely latched.
1
Attaching clip
2
3
Upper anchorage strap
Anchor fitting
Page 68
66
3
1
Front of
vehicle
2
3
Not for Reproduction
1-1. For safe use
Adjust the head restraint to the
downmost position.
Second center seat
Secure the child restraint system
using a seat belt and remove the
head restraint.
Open the anchor fitting cover,
latch the attaching clip onto the
anchor fitting and tighten the
upper anchorage strap.
Make sure the upper anchorage
strap is securely latched.
1
Attaching clip
2
Upper anchorage strap
3
Anchor fitting
Install the head restraint.
Page 69
1-1. For safe use
WARNING
● If the driver’s seat interferes with the child
restraint system and prevents it from being
attached correctly, attach the child restraint
system to the left-hand second seat.
● Adjust the front passenger seat so that it does
not interfere with the child restraint system.
● Child restraint system installed on the third
seat should not contact the second seatbacks.
● Only put a forward facing child restraint sys-
tem on the front seat when unavoidable.
When installing a forward-facing child
restraint system on the front passenger seat,
move the seat as far back as possible. Failing
to do so may result in death or serious injury if
the airbags deploy (inflate).
Not for Reproduction
■ When installing a child restraint system
You need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a
locking clip, you can purchase the following item from your Lexus dealer.
Locking clip for child restraint system
(Part No. 73119-22010)
67
1
■ When installing a child restraint system
Follow the directions given in the child restraint system installation manual and fix the
child restraint system securely in place.
If the child restraint system is not correctly fixed in place, the child or other passengers
may be seriously injured or even killed in the event of sudden braking, sudden swerving
or an accident.
For safety and security
Page 70
68
WARNING
● Extreme Hazard! Do not use a rearward fac-
ing child restraint on a seat protected by an
airbag in front of it! This is because the force
of the rapid inflation of the front passenger
airbag can cause death or serious injury to
the child.
There is a label(s) on the passenger side sun
visor, indicating it is forbidden to attach a
rear-facing child restraint system to the front
passenger seat.
Details of the label(s) are shown in the illustration below.
Not for Reproduction
1-1. For safe use
■ When installing a child restraint system
● If child restraint system regulations exist in the country where you reside, please con-
tact your Lexus dealer for the child restraint system installation.
● When installing a child restraint system on the second center seat, adjust both seat
cushions to the same position and align both seatbacks at the same angle. The seatbacks must be adjusted to the same angle. Otherwise, the child restraint system cannot be securely restrained and this may cause death or serious injuries in the event of
sudden braking, sudden swerving or an accident.
Page 71
1-1. For safe use
WARNING
● When using the right-hand second seat for
the child restraint system, do not sit in the center second seat.
Seat belt function may be impaired, such as
being positioned overly high or loose-fitting,
which may result in death or serious injury in
the event of sudden braking, sudden swerving
or an accident.
Not for Reproduction
■ When installing a child restraint system
● When a junior (booster) seat is installed, always ensure that the shoulder belt is posi-
tioned across the center of the child’s shoulder. The belt should be kept away from the
child’s neck, but not so that it could fall off the child’s shoulder. Failing to do so may
result in death or serious injury in the event of sudden braking, sudden swerving or an
accident.
● Ensure that the belt and plate are securely locked and the seat belt is not twisted.
● Shake the child restraint system left and right, and forward and backward to ensure
that it has been securely installed.
● After securing a child restraint system, never adjust the seat.
● Follow all installation instructions provided by the child restraint system manufacturer.
■ To correctly attach a child restraint system to the anchors
When using the lower anchors, be sure that there are no foreign objects around the
anchors and that the seat belt is not caught behind the child restraint system. Make sure
the child restraint system is securely attached, or it may cause death or serious injury to
the child or other passengers in the event of a sudden stop, sudden swerve or accident.
■ Using child restraint anchorages
WARNING: child restraint anchorages are designed to withstand only those loads
imposed by correctly fitted child restraints. Under no circumstances are they to be
used for adult seatbelts, harnesses, or for attaching other items or equipment to the
vehicle.
69
1
For safety and security
Page 72
70
WARNING
Not for Reproduction
1-1. For safe use
Exhaust gas precautions
Harmful substance to the human body is included in exhaust gases if inhale.
Exhaust gases include harmful carbon monoxide (CO), which is colorless and odorless.
Observe the following precautions.
Failure to do so may cause exhaust gases enter the vehicle and may lead to an accident
caused by light-headedness, or may lead to death or a serious health hazard.
■ Important points while driving
● Keep the back door closed.
● If you smell exhaust gases in the vehicle even when the back door is closed, open the
windows and have the vehicle inspected at your Lexus dealer as soon as possible.
■ When parking
● If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop the
engine.
● Do not leave the vehicle with the engine running for a long time.
If such a situation cannot be avoided, park the vehicle in an open space and ensure
that exhaust fumes do not enter the vehicle interior.
● Do not leave the engine running in an area with snow build-up, or where it is snowing.
If snowbanks build up around the vehicle while the engine is running, exhaust gases
may collect and enter the vehicle.
■ Exhaust pipe
The exhaust system needs to be checked periodically. If there is a hole or crack caused
by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle
inspected and repaired by your Lexus dealer.
Page 73
1-2. Theft deterrent system
NOTICE
Not for Reproduction
Engine immobilizer system
The vehicle’s keys have built-in transponder chips that prevent the engine
from starting if a key has not been previously registered in the vehicle’s onboard computer.
Never leave the keys inside the vehicle when you leave the vehicle.
This system is designed to help prevent vehicle theft but does not guarantee
absolute security against all vehicle thefts.
The indicator light flashes after the
engine switch has been turned off to
indicate that the system is operating.
The indicator light stops flashing after
the engine switch has been turned to
ACCESSORY or IGNITION ON
mode to indicate that the system has
been canceled.
■ System maintenance
The vehicle has a maintenance-free type engine immobilizer system.
■ Conditions that may cause the system to malfunction
● If the key is in contact with a metallic object
● If the key is in close proximity to or touching a key to the security system (key with a
built-in transponder chip) of another vehicle
71
1
For safety and security
■ To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation of
the system cannot be guaranteed.
Page 74
72
Not for Reproduction
1-2. Theft deterrent system
Alarm
The alarm
The alarm uses light and sound to give an alert when an intrusion is detected.
The alarm is triggered in the following situations when the alarm is set:
● A locked door is unlocked or opened in any way other than using the entry
function or wireless remote control. (The doors will lock again automatically.)
● The hood is opened.
● The intrusion sensor detects something moving inside the vehicle. (An
intruder gets in the vehicle.)
● The tilt sensor detects a change of vehicle inclination.
● The quarter windows or back door window are broken.
● The battery is disconnected.
● The battery is reconnected.
Setting the alarm system
Close the doors and hood, and lock all
the doors using the entry function or
wireless remote control. The system will
be set automatically after 30 seconds.
The indicator light changes from being
on to flashing when the system is set.
Page 75
1-2. Theft deterrent system
Not for Reproduction
Deactivating or stopping the alarm
Do one of the following to deactivate or stop the alarm.
● Unlock the doors using the entry function or wireless remote control.
● Turn the engine switch to ACCESSORY or IGNITION ON mode, or start
the engine. (The alarm will be deactivated or stopped after a few seconds.)
■ System maintenance
The vehicle has a maintenance-free type alarm system.
■ Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following.
● Nobody is in the vehicle.
● The windows and moon roof (if equipped) are closed before the alarm is set.
● No valuables or other personal items are left in the vehicle.
73
1
For safety and security
Page 76
74
NOTICE
Not for Reproduction
■ Triggering of the alarm
1-2. Theft deterrent system
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
● The doors are unlocked using the mechanical
key.
● A person inside the vehicle opens a door or
hood, or unlocks the vehicle using an inside
lock button.
● The battery is recharged or replaced when the
vehicle is locked. (P. 543)
● The battery is disconnected when the vehicle
is locked.
■ Alarm-operated door lock
In the following cases, depending on the situation, the door may automatically lock to
prevent improper entry into the vehicle:
● When a person remaining in the vehicle unlocks the door and the alarm is activated.
● While the alarm is activated, a person remaining in the vehicle unlocks the door.
● When recharging or replacing the battery.
■ To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation of
the system cannot be guaranteed.
Page 77
1-2. Theft deterrent system
1
2
Not for Reproduction
Intrusion sensor and tilt sensor
● The intrusion sensor detects intruders or movement in the vehicle.
● The tilt sensor detects changes in vehicle inclination, such as when the vehicle
is towed away.
This system is designed to deter and prevent vehicle theft but does not guarantee
absolute security against all intrusions.
■ Canceling the intrusion sensor and tilt sensor
If you are leaving pets or other moving things inside the vehicle, make sure to
disable the intrusion sensor and tilt sensor before setting the alarm, as they will
respond to movement inside the vehicle.
Turn the engine switch off.
Press the intrusion sensor and tilt
sensor cancel switch.
A message will be shown on the
multi-information display in the
instrument cluster.
The intrusion sensor and tilt sensor
will revert to on each time the engine
switch is turned to IGNITION ON
mode.
75
1
For safety and security
■ Canceling and automatic re-enabling of the intrusion sensor and tilt sensor
● The alarm will still be set even when the intrusion sensor and tilt sensor are canceled.
● After the intrusion sensor and tilt sensor are canceled, pressing the engine switch or
unlocking the doors using the entry function or wireless remote control will re-enable
the intrusion sensor and tilt sensor.
● The intrusion sensor and tilt sensor will automatically be re-enabled when the alarm
system is deactivated.
■ Intrusion sensor considerations
The sensor may trigger the alarm in the following situations:
● People or pets are in the vehicle.
Page 78
76
Not for Reproduction
1-2. Theft deterrent system
● A window or the moon roof (if equipped) is
open.
In this case, the sensor may detect the follow-
ing:
• Wind or the movement of objects such as
leaves and insects inside the vehicle
• Ultrasonic waves emitted from devices
such as the intrusion sensors of other vehicles
• The movement of people outside the vehicle
● Unstable items, such as dangling accessories
or clothes hanging on the coat hooks, are in
the vehicle.
● The vehicle is parked in a place where extreme
vibrations or noises occur, such as in a parking
garage.
● Ice or snow is removed from the vehicle, caus-
ing the vehicle to receive repeated impacts or
vibrations.
● The vehicle is inside an automatic or high-pressure car wash.
● The vehicle experiences impacts, such as hail, lightning strikes, and other kinds of
repeated impacts or vibrations.
Page 79
1-2. Theft deterrent system
NOTICE
● To ensure that the sensors operate properly,
do not touch or cover them.
● Do not spray air fresheners or other products
directly into the sensor holes.
Not for Reproduction
■ Tilt sensor detection considerations
The sensor may trigger the alarm in the following situations:
● The vehicle is transported by a ferry, trailer, train, etc.
● The vehicle is parked in a parking garage.
● The vehicle is inside a car wash that moves the vehicle.
● Any of the tires loses air pressure.
● The vehicle is jacked up.
● An earthquake occurs or the road caves in.
● Cargo is loaded onto or unloaded from the roof luggage carrier.
■ To ensure the intrusion sensor functions correctly
77
1
For safety and security
● Installing accessories other than genuine Lexus parts or leaving objects between the
driver’s seat and front passenger’s seat may reduce the detection performance.
Page 80
78
Not for Reproduction
1-2. Theft deterrent system
Page 81
79
Not for Reproduction
Instrument cluster
2
2. Instrument cluster
Warning lights and
indicators.......................................80
Gauges and meters.....................86
Multi-information display ..........90
Head-up display............................98
Fuel consumption
information .................................103
Page 82
80
Not for Reproduction
2. Instrument cluster
Warning lights and indicators
The warning lights and indicators on the instrument cluster and center panel
inform the driver of the status of the vehicle’s various systems.
For the purpose of explanation, the following illustration display all warning
lights and indicators illuminated.
Page 83
2. Instrument cluster
Not for Reproduction
Warning lights
Warning lights inform the driver of malfunctions in any of the vehicle’s systems.
81
1, 4
*
(if equipped)
1
*
Brake system warning light
(P. 505)
1
*
Charging system warning
light (P. 505)
1
*
Malfunction indicator lamp
(P. 505)
1
*
SRS warning light
(P. 505)
1
*
ABS warning light
(P. 506)
PCS warning light
(P. 506)
1
*
Slip indicator light
(P. 506)
2
Low speed four-wheel
*
drive indicator light
(P. 506)
2
*
Center differential lock
indicator light (P. 506)
Open door warning light
(P. 507)
Low fuel level warning light
(P. 507)
Driver’s seat belt reminder
light (P. 507)
3
*
Front passenger’s seat belt
reminder light (P. 507)
1
*
Master warning light
(P. 507)
2
Instrument cluster
1
Automatic headlight
*
leveling system warning
light (P. 507)
1
*
Tire pressure warning light
(P. 507)
Page 84
82
Not for Reproduction
2. Instrument cluster
2
*
Parking brake indicator
(P. 507)
Power steering system
warning light (P. 507)
1
*
Brake system warning light
(P. 507)
1
*
: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine is
on, or after a few seconds. There may be a malfunction in a system if the lights do not
turn on, or turn off. Have the vehicle inspected by your Lexus dealer.
2
*
: The light flashes to indicate a malfunction.
3
*
: This light illuminates on the center panel.
4
*
: The light flashes or illuminates to indicate a malfunction.
5
*
: This light is displayed on the multi-information display.
5
*
Brake Override System
warning light (P. 175)
Page 85
2. Instrument cluster
Not for Reproduction
Indicators
The indicators inform the driver of the operating state of the vehicle’s various systems.
83
(if equipped)
Turn signal indicator
(P. 208)
Tail light indicator
(P. 212)
Headlight high beam
indicator (P. 212)
Front fog light indicator
(P. 225)
Rear fog light indicator
(P. 225)
1
*
Eco Driving Indicator
Light (P. 85)
Automatic High Beam
1
*
indicator (P. 220)
Adaptive High-beam
System indicator
(P. 215)
Cruise control indicator
(P. 272, 260)
(if equipped)
(if equipped)
1, 2
*
1, 3
*
Dynamic radar cruise
control indicator
(P. 260)
LDA indicator (P. 251)
Slip indicator (P. 373)
1
*
VSC OFF indicator
(P. 373)
Multi-terrain Select
indicator (P. 302)
1
*
Crawl Control indicator
(P. 297)
“RSCA OFF” indicator
(P. 50)
Automatic transmission
second start indicator
(P. 201)
2
Instrument cluster
“SET” indicator
(P. 272, 260)
Low speed four-wheel
drive indicator light
(P. 293)
Page 86
84
Not for Reproduction
2. Instrument cluster
1, 3
*
(if equipped)
(if equipped)
*
Center differential lock
indicator (P. 293)
Turn Assist indicator
(P. 297)
1
*
Easy access mode
indicator (P. 287)
Lexus parking
assist-sensor indicator
(P. 278)
PCS warning light
(P. 240)
“BSM” (Blind Spot
Monitor) indicator
(P. 354)
7
Smart entry & start system
indicator (P. 196, 541)
(if equipped)
4, 5
*
(if equipped)
(if equipped)
*
*
RCTA (Rear Cross Traffic
Alert) indicator (P. 362)
BSM (Blind Spot Monitor)
outside rear view mirror
indicators (P. 354)
Engine preheating
indicator (P. 196)
Parking brake indicator
(P. 209)
3
TRC OFF indicator
(P. 373)
6
Low outside temperature
indicator (P. 86)
1
*
: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine is
on, or after a few seconds. There may be a malfunction in a system if the lights do not
turn on, or turn off. Have the vehicle inspected by your Lexus dealer.
2
*
: The light flashes to indicate that the system is operating.
3
*
: The light turns on when the system is turned off.
4
*
: In order to confirm operation, the BSM outside rear view mirror indicators illumi-
nate in the following situations:
• When the engine switch is turned to IGNITION ON mode while the system is set
to on.
• When the system is set to on while the engine switch is in IGNITION ON mode.
If the system is functioning correctly, the BSM outside rear view mirror indicators
will turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminate or do not turn off,
there may be a malfunction with the system.
If this occurs, have the vehicle inspected by your Lexus dealer.
Page 87
2. Instrument cluster
WARNING
Not for Reproduction
5
*
: This light illuminates on the outside rear view mirrors.
6
*
: When the outside temperature is approximately 3C (37F) or lower, the indicator
will flash for approximately 10 seconds, then stay on.
7
*
: This light is displayed on the multi-information display.
■ Eco Driving Indicator Light
During Eco-Friendly acceleration operation
(Eco driving), Eco Driving Indicator Light will
turn on. When the acceleration exceeds Zone
of Eco driving (P. 96), or when the vehicle is
stopped, the light turns off.
Eco Driving Indicator Light will not operate in
the following conditions:
● The shift lever is in any position other than D.
● The vehicle is set to second start mode. (P. 201)
● The vehicle is set to sport mode or customized mode. (P. 275)
● The vehicle speed is approximately 130 km/h (81 mph) or higher.
● The Crawl Control is operating. (P. 297)
● The paddle shift switch (if equipped) is operating.
85
2
Instrument cluster
■ If a safety system warning light does not turn on
Should a safety system light such as Multi Terrain ABS and the SRS warning light not
turn on when you start the engine, this could mean that these systems are not available
to help protect you in an accident, which could result in death or serious injury. Have
the vehicle inspected by your Lexus dealer immediately if this occurs.
Page 88
86
1
7
Not for Reproduction
2. Instrument cluster
Gauges and meters
Engine oil pressure gauge
Displays the engine oil pressure
2
Tachometer
Displays the engine speed in revolutions per minute
3
Speedometer
Displays the vehicle speed
4
Voltmeter
Displays the charge state
5
Fuel gauge
Displays the quantity of fuel remaining in the tank
6
Engine coolant temperature gauge
Displays the engine coolant temperature
Multi-information display
Presents the driver with a variety of driving-related data (P. 90)
Page 89
2. Instrument cluster
Not for Reproduction
8
Odometer and trip meter display
Odometer:
Displays the total distance the vehicle has been driven.
Trip meter:
Displays the distance the vehicle has been driven since the meter was last reset. Trip
meters A and B can be used to record and display different distances independently.
9
Shift position and shift range display
Displays the selected shift position or selected shift range (P. 201)
10
4-Wheel AHC display
Display the status of 4-Wheel AHC (Active Height Control Suspension). (P. 285)
11
Outside temperature
Displays the outside temperature within the range of -40C (-40F) to 50C
(122F). Low outside temperature indicator comes on when the ambient temperature
is 3C (37F) or lower.
12
Clock
Time displayed is linked to the analog clock on the instrument panel. (P. 429)
13
Odometer/trip meter display change button
Switches between odometer and trip meter displays
14
Instrument panel light control dial
The brightness of the instrument panel light can be adjusted
87
2
Instrument cluster
Changing the display
Switches between odometer and trip
meter displays. When the trip meter is
displayed, pressing and holding the
button will reset the trip meter.
Page 90
88
WARNING
Not for Reproduction
2. Instrument cluster
Instrument panel light control
The brightness of the instrument panel lights can be adjusted by turning the dial.
1
Darker
2
Brighter
■ The meters and display illuminate when
The engine switch is in IGNITION ON mode.
■ The brightness of the instrument panel lights
When the tail lights are turned on, the meter’s brightness will be reduced slightly unless
the meter brightness level adjustment is set to the brightest setting.
If the tail lights are turned on when the surroundings are dark, the meter’s brightness will
be reduced slightly. However, when the surroundings are bright, such as during the daytime, the meter’s brightness will not be reduced even if the tail lights are turned on.
■ Customization
The meter display can be customized on the multi-information display. (P. 568)
■ The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal information
display. At extremely low temperatures, the information display monitor may respond
slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear number
appearing on the display. This lag could cause the driver to downshift again, causing
rapid and excessive engine braking and possibly an accident resulting in death or
injury.
Page 91
2. Instrument cluster
NOTICE
Not for Reproduction
■ To prevent damage to the engine and its components
● Do not let the indicator needle of the tachometer enter the red zone, which indicates
the maximum engine speed.
● The engine may be overheating if the engine coolant temperature gauge is in the red
zone (H). In this case, immediately stop the vehicle in a safe place, and check the
engine after it has cooled completely. (P. 546)
■ Voltmeter
When the voltmeter indicates 19 V or higher or 9 V or lower while the engine is running, there may be a battery or charging system malfunction. Have the vehicle
inspected at your Lexus dealer
■ Engine oil pressure gauge
When the value of the engine oil pressure gauge drops while the engine is running,
stop the vehicle in a safe place immediately and check the amount of engine oil.
(P. 456)
When the oil pressure drops even though the engine oil amount has not decreased, or
if the oil pressure does not increase when engine oil is added, contact your Lexus
dealer, as there may be a problem with the lubrication system.
89
2
Instrument cluster
Page 92
90
Not for Reproduction
2. Instrument cluster
Multi-information display
Display contents
The following information will be displayed when a menu icon is selected.
(P. 91)
Some of the information may be displayed automatically depending on the
situation.
Drive information
Select to display various drive data. (P. 92)
Vehicle information display (if equipped)
Select to display the vehicle information. (P. 93)
Navigation system-linked display
Select to display the following navigation system-linked information.
• Route guidance
• Compass display (north-up display/heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the display using the
meter control switches.
Driving assist system information (if equipped)
Select to display the operational status of the following systems:
• Dynamic radar cruise control with full-speed range (P. 260)
When the vehicle is in constant speed control mode (P. 268), the menu
icon will change to .
• LDA (Lane Departure Alert) (P. 251)
Page 93
2. Instrument cluster
1
2
3
4
Not for Reproduction
Warning message display
Select to display warning messages and measures to be taken if a malfunction is
detected. (P. 511)
Settings display
Select to change the meter display settings and the operation settings of some
vehicle functions. (P. 94)
Operating the meter control switches
The multi-information display is operated using the meter control switches.
:Switch menu
: Change displayed con-
tent, scroll up/down the
screen and move the
cursor up/down
Press: Enter/Set
Press and hold: Reset
Return to the previous screen
Press: Displays the screen registered to
When no screen has been registered, the drive information screen will be displayed.
Press and hold: Registers the currently displayed screen to
When the confirmation screen is displayed, select yes to register the screen. If the
selected screen cannot be registered, a registration failure message will be shown.
91
2
Instrument cluster
Page 94
92
Not for Reproduction
2. Instrument cluster
Drive information
■ Drive information
4 of the following items can be registered and displayed as the drive information 1 and the drive information 2 (2 items on each screen).
Refer to P. 94 for the registration method of the drive information 1 and the
drive information 2.
● Current fuel consumption (bar type/value type)
Displays the current rate of fuel consumption.
● Average fuel consumption (after reset*
Displays the average fuel consumption since the function was reset, the
engine was started, and the vehicle was refueled, respectively.
● Average vehicle speed (after reset*
Displays the average vehicle speed since the function was reset and the
engine was started, respectively.
● Elapsed time (after reset*
Displays the elapsed time since the function was reset and the engine was
started, respectively
● Distance (driving range/after start)
Displays the estimated maximum distance that can be driven with the
quantity of fuel remaining.
• This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that
displayed.
• When only a small amount of fuel is added to the tank, the display may
not be updated.
When refueling, turn the engine switch off. If the vehicle is refueled without turning the engine switch off, the display may not be updated.
1
*
: Use the displayed average fuel consumption as a reference.
2
*
: The function can be reset by pressing for longer than 1 second when the item to
reset is displayed. If there is more than one item that can be reset, the item selection
screen will appear.
2
/after start)
2
/after start/after refuel)*
2
/after start)
1
Page 95
2. Instrument cluster
Not for Reproduction
■ Eco Indicator (Eco Driving Indicator Zone Display)
P. 96
■ Speed
Displays the vehicle speed.
■ Outside temperature
Displays the outside temperature within the range of -40C (-40F) to 50C
(122F).
■ Sway warning (if equipped)
Detects the sway of the vehicle within a lane, which is often associated with a
decrease in the driver’s attention level, and displays the decrease in attention
using a bar display.
The shorter the bar length, the more the driver may need to rest.
This display is a part of the LDA (Lane Departure Alert) system. The display is
enabled when the operating conditions of the vehicle sway warning are met.
(P. 251)
■ Blank screen (display off)
Drive information is not displayed.
Vehicle information
93
2
Instrument cluster
■ Front tire angle (if equipped)
Displays the direction of the front tires.
The tire direction is displayed in 3 stages for both left and right, in accordance with
the angle of the tire.
If a battery terminal is disconnected and reconnected, the display may be disabled
temporarily. After driving the vehicle for a while, the display will be enabled.
■ Tire inflation pressure
Displays inflation pressure of each tire.
The inflation pressure of the spare tire will be displayed.
■ DPF indicator (if equipped)
Displays the amount of DPF deposition.
■ Oil maintenance (if equipped)
Displays the remaining distance before the next maintenance is required.
Page 96
94
Not for Reproduction
2. Instrument cluster
Settings display
The settings of some features can be changed by using the meter control
switches.
■ Setting procedure
For functions that can be enabled or disabled, the function switches between
on and off each time is pressed.
■ Setting items
● LDA (Lane Departure Alert)*
Select to set up LDA. (P. 568)
• Alert method
• Alert sensitivity
• Sway warning
• Sway sensitivity
● BSM (Blind Spot Monitor)*
Select to set up BSM. (P. 568)
•BSM on/off
• RCTA (Rear Cross Traffic Alert) on/off
● Head-up display
Select to set up Head-up display. (P. 568)
• Display brightness/location
•Display content
● Oil maintenance*
Select to reset the engine oil maintenance information
Page 97
2. Instrument cluster
Not for Reproduction
● Meter settings
Select to set the following items.
•Language
Select to change the language on the display.
•Units
Select to change the unit for measure.
• Eco Driving Indicator Light
Select to activate/deactivate the Eco Driving Indicator Light. (
• switch settings
You can register 1 screen as the top screen. To register, press and hold
while the desired screen is displayed.
• Drive information 1 and 2
Select to select up to 2 items that will be displayed on a drive information screen, up to 2 drive information screens can be set.
•Clock
Select to set the display mode of the clock.
• Pop-up display
Select to set the pop-up displays, which may appear in some situations,
on/off. (
•Accent color
Select to change the accent colors on the screen, such as the cursor
color.
• Initialization
Registered or changed meter settings will be deleted or returned to
their default setting.
P. 96)
*: If equipped
95
P. 85)
2
Instrument cluster
Page 98
96
1
Not for Reproduction
■ Eco Driving Indicator
■ When disconnecting and reconnecting battery terminals
■ Pop-Up display
■ Tire inflation pressure
2. Instrument cluster
Eco Driving Indicator Light (P. 85)
2
Eco Driving Indicator Zone Display
Suggests the Zone of Eco driving with current
Eco driving ratio based on acceleration.
3
Eco driving ratio based on acceleration
If the acceleration exceeds Zone of Eco driv-
ing, the right side of Eco Driving Indicator
Zone Display will illuminate.
4
Zone of Eco driving
The drive information will be reset (only items that can be reset manually).
The pop-up display is displayed on the multi-information display according to the operating conditions of the following functions:
● Route guidance display of the navigation system-linked system
● Incoming call display of the hands-free phone system (if equipped)
The pop-up display function can be disabled. (P. 94)
● It may take a few minutes to display the tire inflation pressure after the engine switch is
turned to IGNITION ON mode. It may also take a few minutes to display the tire inflation pressure after inflation pressure has been adjusted.
● “---” may be displayed if the tire information cannot be determined due to unfavorable
radio wave conditions.
● Tire inflation pressure changes with temperature. The displayed values may also be dif-
ferent from the values measured using a tire pressure gauge.
Page 99
2. Instrument cluster
WARNING
NOTICE
Not for Reproduction
■ When setting up the display
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P.
■ Suspension of the settings display
In the following situations, the settings display using the meter control switches will be
suspended.
● When a warning message appears on the multi-information display
● When the vehicle begins to move
■ Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is characteristic
of liquid crystal displays, and there is no problem continuing to use the display.
■ Caution for use while driving
For safety, avoid operating the meter control switch while driving as much as possible,
and do not look continuously at the multi-information display while driving. Stop the
vehicle and operate the meter control switch. Failure to do so may cause a steering
wheel operation error, resulting in an unexpected accident.
■ Cautions while setting up the display
As the engine needs to be running during setting up the display, ensure that the vehicle
is parked in a place with adequate ventilation. In a closed area such as a garage,
exhaust gases including harmful carbon monoxide (CO) may collect and enter the
vehicle. This may lead to death or a serious health hazard.
97
2
Instrument cluster
■ While setting up the display
To prevent battery discharge, ensure that the engine is running while setting up the display features.
Page 100
98
3
Not for Reproduction
2. Instrument cluster
Head-up display
Summary of functions
The head-up display is linked to the meters and navigation system and projects a
variety of information in front of the driver, such as the current vehicle speed and
route guidance to a set destination.
1
Warning and information icons (P. 100)
2
Message display area (P. 100)
Displays the following items:
• Warning/Message (if equipped)
• Audio system operation status
• Outside temperature
Navigation system-linked display area (P. 100)
Displays the following items, which are linked to the navigation system:
• Route guidance to destination
•Compass
Loading...
