Pictorial index
For safety
1
and security
Search by illustration
Make sure to read through them
2
Instrument cluster
Operation of
3
each component
4
Driving
5
Interior features
Maintenance
6
and care
When trouble
7
arises
Vehicle
8
specifications
9
For owners
How to read the gauges and meters, the variety of
warning lights and indicators, etc.
Opening and closing the doors and windows,
adjustment before driving, etc.
Operations and advice which are necessary for driving
Usage of the interior features, etc.
Caring for your vehicle and maintenance procedures
What to do in case of malfunction or emergency
Vehicle specifications, customizable features, etc.
Reporting safety defects for U.S. owners, and seat belt,
SRS airbag and headlight aim instructions for
Canadian owners
Index
GX460_OM_OM60R27U_(U)
Search by symptom
Search alphabetically
Page 2
TABLE OF CONTENTS2
For your information................................... 8
Reading this manual...................................12
How to search..............................................13
Pictorial index...............................................14
1
For safety and security
1-1. For safe use
Before driving ................................ 26
For safe driving ..............................28
Seat belts.......................................... 30
SRS airbags..................................... 36
Front passenger occupant
classification system ..................47
Safety information for
children ..........................................53
Child restraint systems............... 54
Installing child restraints.............58
Exhaust gas precautions............ 70
1-2. LEXUS Enform
LEXUS Enform Safety
Connect........................................... 71
1-3. Theft deterrent system
Engine immobilizer system........76
Alarm................................................. 78
2
Instrument cluster
Operation of each
3
component
3-1. Key information
Keys.................................................. 100
3-2. Opening, closing and
locking the doors
Side doors...................................... 104
Back door ..........................................111
Glass hatch ..................................... 116
Smart access system with
push-button start........................ 121
3-3. Adjusting the seats
Front seats ..................................... 128
Rear seats ...................................... 130
Driving position memory........... 141
Head restraints.............................146
3-4. Adjusting the steering
wheel and mirrors
Steering wheel..............................149
Inside rear view mirror ...............151
Outside rear view mirrors .......153
3-5. Opening, closing the windows
and moon roof
Power windows............................156
Moon roof.......................................159
2. Instrument cluster
Warning and indicators
lights ................................................82
Gauges and meters.....................88
Multi-information display ............91
Fuel consumption
information ...................................98
GX460_OM_OM60R27U_(U)
Page 3
3
4
Driving
4-1. Before driving
Driving the vehicle ......................164
Cargo and luggage ....................172
Vehicle load limits .......................176
Trailer towing
(with towing hitch).................... 177
Dinghy towing.............................. 195
4-2. Driving procedures
Engine (ignition) switch.............196
Automatic transmission ..........202
Turn signal lever......................... 207
Parking brake..............................208
4-3. Operating the lights
and wipers
Headlight switch ........................209
Automatic High Beam...............212
Fog light switch.............................217
Windshield wipers and
washer.......................................... 218
Rear window wiper and
washer......................................... 222
Headlight cleaner switch........ 224
4-4. Refueling
Opening the fuel tank cap .....225
4-5. Using the driving support
systems
Lexus Safety System +............. 229
PCS (Pre-Collision
System) .......................................235
LDA (Lane Departure
Alert)............................................ 246
Dynamic radar cruise
control .........................................254
Intuitive parking assist.............. 266
Rear view monitor system.......274
Multi-terrain Select...................284
Multi-terrain Monitor...............288
Rear height control air
suspension................................. 335
AVS (Adaptive Variable
Suspension System) ..............339
Four-wheel drive system ........340
Crawl Control............................. 344
Downhill assist control
system..........................................348
Driving assist systems ................351
BSM (Blind Spot Monitor)..... 357
• The Blind Spot Monitor
function ......................................361
• The Rear Cross Traffic
Alert function......................... 364
4-6. Driving tips
Winter driving tips..................... 367
Off-road precautions............... 370
1
2
3
4
5
6
7
8
9
GX460_OM_OM60R27U_(U)
Page 4
TABLE OF CONTENTS4
5
Interior features
5-1. Using the air conditioning
system and defogger
Front automatic air
conditioning system............... 376
Rear air conditioning
system..........................................386
Heated steering wheel/seat
heaters/seat ventilators .......389
5-2. Using the interior lights
Interior lights list .........................392
• Personal/interior lights
main switch.............................393
• Personal/interior lights .....393
5-3. Using the storage features
List of storage features............395
• Glove box............................... 396
• Console box ..........................396
• Coin holder ............................398
• Cup holders/bottle
holders/door pockets........398
• Auxiliary boxes.....................400
Luggage compartment
features .......................................402
5-4. Using the other interior
features
Other interior features............409
• Cool box.................................. 409
• Sun visors................................... 411
• Vanity mirror ............................ 411
• Conversation mirror ............412
• Clock ..........................................412
• Power outlets ..........................413
• USB charging ports..............417
• Armrest......................................419
• Coat hooks.............................420
• Assist grips ............................. 420
Compass.........................................421
Garage door opener ...............425
GX460_OM_OM60R27U_(U)
Page 5
5
6
Maintenance and care
6-1. Maintenance and care
Cleaning and protecting
the vehicle exterior ................434
Cleaning and protecting
the vehicle interior.................. 437
6-2. Maintenance
Maintenance
requirements ............................440
General maintenance.............. 443
Emission inspection and
maintenance (I/M)
programs....................................446
6-3. Do-it-yourself maintenance
Do-it-yourself service
precautions................................ 447
Hood...............................................450
Engine compartment .................451
Tires................................................. 464
Tire inflation pressure .............. 476
Wheels...........................................480
Air conditioning filter ...............482
Electronic key battery..............484
Checking and replacing
fuses.............................................. 486
Headlight aim..............................489
Light bulbs ......................................491
7
When trouble arises
7-1. Essential information
Emergency flashers..................500
If your vehicle has
to be stopped in
an emergency ........................... 501
If the vehicle is trapped in
rising water................................502
7-2. Steps to take in an emergency
If your vehicle needs
to be towed ...............................503
If you think something is
wrong...........................................509
Fuel pump shut off system....... 510
If a warning light turns
on or a warning buzzer
sounds ............................................511
If a warning message is
displayed ....................................520
If you have a flat tire ..................524
If the engine will not start........538
If the electronic key does
not operate properly.............540
If the vehicle battery is
discharged.................................543
If your vehicle overheats......... 546
If the vehicle becomes
stuck............................................. 549
1
2
3
4
5
6
7
8
9
GX460_OM_OM60R27U_(U)
Page 6
TABLE OF CONTENTS6
For vehicles with navigation system or multimedia system, refer to the “NAVIGATION SYSTEM OWNER’S MANUAL” or “MULTIMEDIA OWNER’S
MANUAL” for information regarding the equipment listed below.
• Navigation system
• Audio/video system
• Rear seat entertainment system
• Hands-free system (for cellular phone)
• Lexus Enform
8
Vehicle specifications
Index
8-1. Specifications
Maintenance data
(fuel, oil level, etc.).................. 552
Fuel information ......................... 562
Tire information..........................565
8-2. Customization
Customizable features............ 576
8-3. Items to initialize
Items to initialize.........................585
9
For owners
Reporting safety defects
for U.S. owners ................................... 588
Seat belt instructions
for Canadian owners
(in French)..............................................589
SRS airbag instructions
for Canadian owners
(in French)............................................... 591
Headlight aim instructions
for Canadian owners
(in French)..............................................599
What to do if...
(Troubleshooting)............................... 604
Alphabetical index ................................608
GX460_OM_OM60R27U_(U)
Page 7
7
1
2
3
4
5
6
7
8
9
GX460_OM_OM60R27U_(U)
Page 8
8
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equipment, including
options. Therefore, you may find some explanations for equipment not installed on your
vehicle.
All specifications provided in this manual are current at the time of printing. However,
because of the Lexus policy of continual product improvement, we reserve the right to
make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ from your
vehicle in terms of color and equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound coming from
under the vehicle for several minutes. This is the sound of a fuel evaporation leakage
check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Lexus
A wide variety of non-genuine spare parts and accessories for Lexus vehicles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any
damage they may cause to, or adverse effect they may have on, your Lexus vehicle.
This vehicle should not be modified with non-genuine Lexus products. Modification with
non-genuine Lexus products could affect its performance, safety or durability, and may
even violate governmental regulations. In addition, damage or performance problems
resulting from the modification may not be covered under warranty.
Installation of a mobile two-way radio system
The installation of a mobile two-way radio system in your vehicle could affect electronic
systems such as:
● Multiport fuel injection system/sequential multiport fuel injection system
● Lexus Safety System +
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
Be sure to check with your Lexus dealer for precautionary measures or special instructions regarding installation of a mobile two-way radio system.
GX460_OM_OM60R27U_(U)
Page 9
Vehicle data recording
The vehicle is equipped with sophisticated computers that will record certain data, such
as:
• Engine speed/Electric motor speed (traction motor speed)
• Accelerator status
•Brake status
• Vehicle speed
• Operation status of the driving assist systems
• Images from the cameras
Your vehicle is equipped with cameras. Contact your Lexus dealer for the location
of recording cameras.
The recorded data varies according to the vehicle grade level and options with which it is
equipped.
These computers do not record conversations or sounds, and only record images outside of the vehicle in certain situations.
● Data Transmission
Your vehicle may transmit the data recorded in these computers to Lexus without notification to you.
● Data usage
Lexus may use the data recorded in this computer to diagnose malfunctions, conduct
research and development, and improve quality.
Lexus will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehicle
is leased
• In response to an official request by the police, a court of law or a government
agency
• For use by Lexus in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or vehicle
owner
● Recorded image information can be erased by your Lexus dealer.
The image recording function can be disabled. However, if the function is disabled,
data from when the system operates will not be available.
● To learn more about the vehicle data collected, used and shared by Lexus,
please visit www.lexus.com/privacyvts/
.
9
Usage of data collected through Lexus Enform (U.S. mainland only)
If your Lexus has Lexus Enform and if you have subscribed to those services, please refer
to the Lexus Enform Telematics Subscription Service Agreement for information on data
collected and its usage.
● To learn more about the vehicle data collected, used and shared by Lexus,
please visit www.lexus.com/privacyvts/
GX460_OM_OM60R27U_(U)
.
Page 10
10
Event data recorder
This vehicle is equipped with an event data recorder (EDR). The main purpose of an EDR
is to record, in certain crash or near crash-like situations, such as an air bag deployment
or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems
performed. The EDR is designed to record data related to vehicle dynamics and safety
systems for a short period of time, typically 30 seconds or less.
The EDR in this vehicle is designed to record such data as:
• How various systems in your vehicle were operating;
• Whether or not the driver and passenger safety belts were buckled/fastened;
• How far (if at all) the driver was depressing the accelerator and/or brake pedal; and,
• How fast the vehicle was traveling.
These data can help provide a better understanding of the circumstances in which
crashes and injuries occur.
NOTE: EDR data are recorded by your vehicle only if a non-trivial crash situation occurs;
no data are recorded by the EDR under normal driving conditions and no personal data
(e.g., name, gender, age, and crash location) are recorded. However, other parties, such
as law enforcement, could combine the EDR data with the type of personally identifying
data routinely acquired during a crash investigation.
To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. In addition to the vehicle manufacturer, other parties, such as
law enforcement, that have the special equipment, can read the information if they have
access to the vehicle or the EDR.
● Disclosure of the EDR data
Lexus will not disclose the data recorded in an EDR to a third party except when:
• An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is
obtained
• In response to an official request by the police, a court of law or a government
agency
• For use by Lexus in a lawsuit
However, if necessary, Lexus may:
• Use the data for research on vehicle safety performance
• Disclose the data to a third party for research purposes without disclosing information about the specific vehicle or vehicle owner
GX460_OM_OM60R27U_(U)
Page 11
Scrapping of your Lexus
WARNING
The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive
chemicals. If the vehicle is scrapped with the airbags and seat belt pretensioners left as
they are, this may cause an accident such as fire. Be sure to have the systems of the SRS
airbag and seat belt pretensioner removed and disposed of by a qualified service shop or
by your Lexus dealer before you scrap your vehicle.
Perchlorate Material
Special handling may apply,
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These components may
include airbag, seat belt pretensioners, and wireless remote control batteries.
■ General precautions while driving
Driving under the influence: Never drive your vehicle when under the influence of
alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol and
certain drugs delay reaction time, impair judgment and reduce coordination, which
could lead to an accident that could result in death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other drivers or
pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that distracts the
driver, such as adjusting controls, talking on a cellular phone or reading can result in a
collision with resulting death or serious injury to you, your occupants or others.
■ General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to have or use
the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is also a
danger that children may injure themselves by playing with the windows, the moon
roof, or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
11
GX460_OM_OM60R27U_(U)
Page 12
12
Reading this manual
WARNING:
Explains something that, if not obeyed, could cause death or serious injury
to people.
NOTICE:
Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment.
Indicates operating or working procedures. Follow the steps in
numerical order.
Indicates the action (pushing,
turning, etc.) used to operate
switches and other devices.
Indicates the outcome of an
operation (e.g. a lid opens).
Indicates the component or position being explained.
Means “Do not”, “Do not do this”,
or “Do not let this happen”.
GX460_OM_OM60R27U_(U)
Page 13
How to search
■ Searching by name
• Alphabetical index...............P. 608
■ Searching by installation position
• Pictorial index.............................P. 14
■ Searching by symptom or sound
• What to do if...
(Troubleshooting)................P. 604
13
■ Searching by title
• Table of contents.........................P. 2
GX460_OM_OM60R27U_(U)
Page 14
14
Pictorial index
Pictorial index
■ Exterior
1
Side doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 104
Locking/unlocking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 104
Opening/closing the door glasses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 156
Locking/unlocking by using the mechanical key . . . . . . . . . . . . . . . . . . . . . . . P. 540
Warning lights/warning messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 110, 513
2
Back door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 111
Opening from outside . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 112
Opening/closing the glass hatch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 116
Warning lights/warning messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 110, 513
3
Outside rear view mirrors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 153
Adjusting the mirror angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 153
Folding the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 153
Driving position memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 141
Defogging the mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 381
GX460_OM_OM60R27U_(U)
Page 15
Pictorial index
8
9
12
4
Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 218
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 367
To prevent freezing (windshield wiper de-icer
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 435
5
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 225
Refueling method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 225
Fuel type/fuel tank capacity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 554
6
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 464
Tire size/inflation pressure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 560
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 367
Checking/rotation/tire pressure warning system . . . . . . . . . . . . . . . . . . . . . . P. 464
Coping with flat tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 524
7
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 450
Opening. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 450
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 554
Coping with overheat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 546
Warning lights/warning messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 110, 513
*) . . . . . . . . . . . . . . . . . . . . . . . .P. 381
Camera*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 274, 288
Light bulbs of the exterior lights for driving
(Replacing method: P. 491, Watts: P. 561)
15
Headlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
10
Parking lights/daytime running lights. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
11
Fog lights
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 207
13
Stop/tail lights
Hill-start assist control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 352
Downhill assist control system
14
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
15
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
16
Side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 348
*: If equipped
GX460_OM_OM60R27U_(U)
Page 16
16
Pictorial index
■ Instrument panel
1
Engine switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 196
Starting the engine/changing the modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 196
Emergency stop of the engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 501
When the engine will not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 538
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 520
2
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
Changing the shift position. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 202
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 503
When the shift lever does not move. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 205
3
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 88
Reading the meters/adjusting the instrument panel light . . . . . . . . . . . . . . . . .P. 88
Warning lights/indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 82
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 511
GX460_OM_OM60R27U_(U)
Page 17
Pictorial index
8
11
12
13
4
Multi-information display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 91
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 91
When the warning messages are displayed . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 520
5
Parking brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
Applying/releasing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 368
Warning buzzer/message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 208, 512
6
Turn signal lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 207
Headlight switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 209
Headlights/parking lights/tail lights/daytime running lights . . . . . . . . . . . . P. 209
Fog lights
7
Windshield wiper and washer switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 218
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 217
Rear window wiper and washer switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 222
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 218, 222
Adding washer fluid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 463
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 463
Emergency flasher switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 500
9
Fuel filler door opener. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 227
10
Hood lock release lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 450
Tilt and telescopic steering control switch . . . . . . . . . . . . . . . . . . . . . . . . . . P. 149
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 149
Driving position memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 141
Air conditioning system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 376
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 376
Rear window defogger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 381
Audio system*
Hands-free system*
2
2
17
1
*
: If equipped
2
*
: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL” or
“MULTIMEDIA OWNER’S MANUAL”.
GX460_OM_OM60R27U_(U)
Page 18
18
7
10
13
■ Switches
1
2
3
4
5
6
8
9
11
12
14
Pictorial index
Outside rear view mirror switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 153
Instrument cluster light control switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 89
1
*
VIEW switch
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 292
Odometer/trip meter and trip meter reset button . . . . . . . . . . . . . . . . . . P. 89
1
*
Heated steering wheel switch
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 389
Automatic High Beam switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 212
VSC OFF switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 353
1
*
Headlight cleaner switch
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 224
Second start mode switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 203
Center differential lock/unlock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 341
Window lock switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 156
Door lock switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 106
Power window switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 156
Driving position memory buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 141
GX460_OM_OM60R27U_(U)
Page 19
Pictorial index
19
1
Audio remote control switches*
2
Talk switch*
3
Telephone switches*
4
Meter control switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 92
5
Vehicle-to-vehicle distance switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 260
6
LDA (Lane Departure Alert) switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 248
7
Cruise control switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 254
2
2
2
GX460_OM_OM60R27U_(U)
1
*
: If equipped
2
*
: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL” or
“MULTIMEDIA OWNER’S MANUAL”.
Page 20
20
Pictorial index
1
Front seat heater/ventilator switches* . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 389
2
Height control switch
3
Height control OFF button* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 335
4
AVS switch
5
Four-wheel drive control switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 340
6
Multi-terrain Select mode selector switch
Crawl Control speed selector switch
7
Crawl Control ON/OFF switch
8
“DAC” switch
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 339
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 335
* . . . . . . . . . . . . . . . . . . . . . . . P. 284
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 344
*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 344
* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 348
GX460_OM_OM60R27U_(U)
Page 21
■ Interior
7-passenger models
Pictorial index
21
GX460_OM_OM60R27U_(U)
*: If equipped
Page 22
22
7
10
13
6-passenger models
Pictorial index
1
SRS airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 36
2
Floor mats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 26
3
Front seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 128
4
Second seats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 130
5
Third seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 130
6
Head restraints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 146
Seat belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 30
8
Console box
Cool box
9
Inside lock buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 106
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 396
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 409
Cup holders. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 398
11
Auxiliary boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 400
12
Rear air conditioning system
Rear seat entertainment system*
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 386
1, 2
GX460_OM_OM60R27U_(U)
Page 23
Pictorial index
1
Inside rear view mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 151
2
Sun visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 411
3
Vanity mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 411
4
Personal/interior lights
5
Moon roof switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 159
6
Conversation mirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 412
3
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 393
Auxiliary boxes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 400
7
“SOS” button
8
Garage door opener buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 425
1
*
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 71
23
3
*
: The illustration shows the front, but they are also equipped in the rear.
GX460_OM_OM60R27U_(U)
1
*
2
*
: Refer to “NAVIGATION SYSTEM OWNER’S MANUAL” or
“MULTIMEDIA OWNER’S MANUAL”.
: If equipped
Page 24
24
Pictorial index
GX460_OM_OM60R27U_(U)
Page 25
25
For safety and security
1
1-1. For safe use
Before driving................................. 26
For safe driving ..............................28
Seat belts ..........................................30
SRS airbags .....................................36
Front passenger occupant
classification system.................. 47
Safety information for
children ..........................................53
Child restraint systems ...............54
Installing child restraints.............58
Exhaust gas precautions............70
1-2. LEXUS Enform
LEXUS Enform Safety
Connect...........................................71
1-3. Theft deterrent system
Engine immobilizer system....... 76
Alarm .................................................78
GX460_OM_OM60R27U_(U)
Page 26
26
1
*
2
1-1. For safe use
Before driving
Floor mat
Use only floor mats designed specifically for vehicles of the same model and
model year as your vehicle. Fix them securely in place onto the carpet.
Insert the retaining hooks (clips) into
the floor mat eyelets.
Turn the upper knob of each retaining hook (clip) to secure the floor
mats in place.
*: Always align the marks.
The shape of the retaining hooks (clips) may differ from that shown in the illustration.
GX460_OM_OM60R27U_(U)
Page 27
1-1. For safe use
WARNING
● Check that the floor mat is securely fixed in
the correct place with all the provided retaining hooks (clips). Be especially careful to perform this check after cleaning the floor.
● With the engine stopped and the shift lever in
P, fully depress each pedal to the floor to
make sure it does not interfere with the floor
mat.
Observe the following precautions.
Failure to do so may cause the driver’s floor mat to slip, possibly interfering with the pedals while driving. An unexpectedly high speed may result or it may become difficult to
stop the vehicle. This could lead to an accident, resulting in death or serious injury.
■ When installing the driver’s floor mat
● Do not use floor mats designed for other models or different model year vehicles,
even if they are Lexus Genuine floor mats.
● Only use floor mats designed for the driver’s seat.
● Always install the floor mat securely using the retaining hooks (clips) provided.
● Do not use two or more floor mats on top of each other.
● Do not place the floor mat bottom-side up or upside-down.
■ Before driving
27
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 28
28
4
1-1. For safe use
For safe driving
For safe driving, adjust the seat and mirror to an appropriate position before
driving.
Correct driving posture
1
Adjust the angle of the seatback so
that you are sitting straight up and so
that you do not have to lean forward
to steer. (P. 128)
2
Adjust the seat so that you can
depress the pedals fully and so that
your arms bend slightly at the elbow
when gripping the steering wheel.
(P. 128)
3
Lock the head restraint in place with the center of the head restraint closest to
the top of your ears. (P. 146)
Wear the seat belt correctly. (P. 30)
Correct use of the seat belts
Make sure that all occupants are wearing their seat belts before driving the vehicle. (P. 30)
Use a child restraint system appropriate for the child until the child becomes
large enough to properly wear the vehicle’s seat belt. (P. 54)
GX460_OM_OM60R27U_(U)
Page 29
1-1. For safe use
WARNING
Adjusting the mirrors
Make sure that you can see backward clearly by adjusting the inside and outside
rear view mirrors properly. (P. 151, 153)
29
Observe the following precautions.
Failure to do so may result in death or serious injury.
● Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle.
● Do not place a cushion between the driver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint.
● Do not place anything under the front seats.
Objects placed under the front seats may become jammed in the seat tracks and stop
the seat from locking in place. This may lead to an accident and the adjustment mechanism may also be damaged.
● Always observe the legal speed limit when driving on public roads.
● When driving over long distances, take regular breaks before you start to feel tired.
Also, if you feel tired or sleepy while driving, do not force yourself to continue driving
and take a break immediately.
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 30
30
Release button
1-1. For safe use
Seat belts
Make sure that all occupants are wearing their seat belts before driving the
vehicle.
Correct use of the seat belts
● Extend the shoulder belt so that it
comes fully over the shoulder, but
does not come into contact with the
neck or slide off the shoulder.
● Position the lap belt as low as possi-
ble over the hips.
● Adjust the position of the seatback.
Sit up straight and well back in the
seat.
● Do not twist the seat belt.
Fastening and releasing the seat belt
1
To fasten the seat belt, push the plate
into the buckle until a click sound is
heard.
2
To release the seat belt, press the
release button.
GX460_OM_OM60R27U_(U)
Page 31
1-1. For safe use
Adjusting the seat belt shoulder anchor height (front and outer second
seats for 7-passenger models, front and second seats for 6-passenger
models)
1
Push the seat belt shoulder anchor
down while pressing the release button.
2
Push the seat belt shoulder anchor
up.
Move the height adjuster up and down
as needed until you hear a click.
Seat belt pretensioners (front and outer second seats for 7-passenger
models, front and second seats for 6-passenger models)
The pretensioners help the seat belts to
quickly restrain the occupants by
retracting the seat belts when the vehicle is subjected to certain types of
severe frontal or side collision or a vehicle rollover.
The pretensioners do not activate in the
event of a minor frontal impact, a minor
side impact or a rear impact.
31
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 32
32
■ Emergency locking retractor (ELR)
1-1. For safe use
The retractor will lock the belt during a sudden stop or on impact. It may also lock if you
lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can
move around fully.
■ Automatic locking retractor (ALR)
When a passenger’s shoulder belt is completely extended and then retracted even
slightly, the belt is locked in that position and cannot be extended. This feature is used to
hold the child restraint system (CRS) firmly. To free the belt again, fully retract the belt
and then pull the belt out once more. (P. 58)
■ Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult size.
● Use a child restraint system appropriate for the child, until the child becomes large
enough to properly wear the vehicle’s seat belt. (P. 54)
● When the child becomes large enough to properly wear the vehicle’s seat belt, follow
the instructions on P. 30 regarding seat belt usage.
■ Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate for the first
collision, but will not activate for the second or subsequent collisions.
■ Seat belt extender
If your seat belts cannot be fastened securely
because they are not long enough, a personalized seat belt extender is available from your
Lexus dealer free of charge.
GX460_OM_OM60R27U_(U)
Page 33
1-1. For safe use
WARNING
Obtain medical advice and wear the seat belt
in the proper way. (P. 30)
Women who are pregnant should position the
lap belt as low as possible over the hips in the
same manner as other occupants, extending
the shoulder belt completely over the shoulder
and avoiding belt contact with the rounding of
the abdominal area.
If the seat belt is not worn properly, not only the
pregnant woman, but also the fetus could suffer
death or serious injury as a result of sudden
braking, sudden swerving or a collision.
Observe the following precautions to reduce the risk of injury in the event of sudden
braking, sudden swerving or an accident.
Failure to do so may cause death or serious injury.
■ Wearing a seat belt
● Ensure that all passengers wear a seat belt.
● Always wear a seat belt properly.
● Each seat belt should be used by one person only. Do not use a seat belt for more
than one person at once, including children.
● Lexus recommends that children be seated in the rear seat and always use a seat belt
and/or an appropriate child restraint system.
● To achieve a proper seating position, do not recline the seat more than necessary. The
seat belt is most effective when the occupants are sitting up straight and well back in
the seats.
● Do not wear the shoulder belt under your arm.
● Always wear your seat belt low and snug across your hips.
■ Pregnant women
33
1
For safety and security
■ People suffering illness
Obtain medical advice and wear the seat belt in the proper way. (P. 30)
GX460_OM_OM60R27U_(U)
Page 34
34
WARNING
■ When the children are in the vehicle
1-1. For safe use
Do not allow children to play with the seat belt. If the seat belt becomes twisted around
a child’s neck, it may lead to choking or other serious injuries that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to cut the
belt.
■ Seat belt pretensioners
● Do not place anything, such as a cushion, on the front passenger’s seat. Doing so will
disperse the passenger’s weight, which prevents the sensor from detecting the passenger’s weight properly. As a result, the seat belt pretensioner for the front passenger’s seat may not activate in the event of a collision.
● If the pretensioner has activated, the SRS warning light will come on. In that case, the
seat belt cannot be used again and must be replaced at your Lexus dealer.
■ Adjustable shoulder anchor
Always make sure the shoulder belt is positioned across the center of your shoulder.
The belt should be kept away from your neck, but not falling off your shoulder. Failure to
do so could reduce the amount of protection in an accident and cause death or serious
injuries in the event of a sudden stop, sudden swerve or accident. (P. 31)
■ Seat belt damage and wear
● Do not damage the seat belts by allowing the belt, plate, or buckle to be jammed in
the door.
● Inspect the seat belt system periodically. Check for cuts, fraying, and loose parts. Do
not use a damaged seat belt until it is replaced. Damaged seat belt cannot protect an
occupant from death or serious injury.
● Ensure that the belt and plate are locked and the belt is not twisted.
If the seat belt does not function correctly, immediately contact your Lexus dealer.
● Replace the seat assembly, including the belts, if your vehicle has been involved in a
serious accident, even if there is no obvious damage.
● Do not attempt to install, remove, modify, disassemble or dispose of the seat belts.
Have any necessary repairs carried out by your Lexus dealer. Inappropriate handling
may lead to incorrect operation.
GX460_OM_OM60R27U_(U)
Page 35
1-1. For safe use
WARNING
NOTICE
■ Using a seat belt extender
● Do not wear the seat belt extender if you can fasten the seat belt without the extender.
● Do not use the seat belt extender when installing a child restraint system because the
belt will not securely hold the child restraint system, increasing the risk of death or
serious injury in the event of an accident.
● The personalized extender may not be safe on another vehicle, when used by another
person, or at a different seating position other than the one originally intended.
■ Using a seat belt extender
When releasing the seat belt, press on the buckle release button on the extender, not
on the seat belt.
This helps prevent damage to the vehicle interior and the extender itself.
35
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 36
36
1-1. For safe use
SRS airbags
The SRS airbags inflate when the vehicle is subjected to certain types of
severe impacts that may cause significant injury to the occupants. They work
together with the seat belts to help reduce the risk of death or serious injury.
◆ SRS front airbags
1
SRS driver airbag/front passenger airbag
Can help protect the head and chest of the driver and front passenger from
impact with interior components
2
SRS knee airbags
Can help provide driver and front passenger protection
GX460_OM_OM60R27U_(U)
Page 37
1-1. For safe use
◆ SRS side and curtain shield airbags
3
SRS front side airbags
Can help protect the torso of the front seat occupants
4
SRS rear side airbags
Can help protect the torso of occupants in the outer second seats (7-passenger models) or second seats (6-passenger models)
5
SRS curtain shield airbags
● Can help protect primarily the head of occupants in the outer seats
● Can help prevent the occupants from being thrown from the vehicle in
the event of vehicle rollover
37
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 38
38
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1-1. For safe use
SRS airbag system components
Knee airbags
Curtain shield airbags
Front passenger airbag
Side impact sensors (front door)
“AIR BAG ON” and
“AIR BAG OFF” indicator lights
Front side airbags
SRS warning light
Side impact sensors (rear)
Rear side airbags (outer second
seats [7-passenger models] or second seats [6-passenger models])
Driver airbag
Driver’s seat belt buckle switch
Safing sensor (rear)
Front passenger’s seat belt buckle
switch
Airbag sensor assembly
Front impact sensors
Seat belt pretensioners and force
limiters
Front passenger occupant classifi-
cation system (ECU and sensors)
GX460_OM_OM60R27U_(U)
Page 39
1-1. For safe use
WARNING
Your vehicle is equipped with ADVANCED AIRBAGS designed based on the
US motor vehicle safety standards (FMVSS208). The airbag sensor assembly
(ECU) controls airbag deployment based on information obtained from the sensors etc. shown in the system components diagram above. This information
includes crash severity and occupant information. As the airbags deploy, a
chemical reaction in the inflators quickly fills the airbags with non-toxic gas to
help restrain the motion of the occupants.
■ SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may cause death or serious injury.
● The driver and all passengers in the vehicle must wear their seat belts properly.
The SRS airbags are supplemental devices to be used with the seat belts.
● The SRS driver airbag deploys with considerable force, and can cause death or seri-
ous injury especially if the driver is very close to the airbag. The National Highway
Traffic Safety Administration (NHTSA) advises:
Since the risk zone for the driver’s airbag is the first 2 - 3 in. (50 - 75 mm) of inflation,
placing yourself 10 in. (250 mm) from your driver airbag provides you with a clear
margin of safety. This distance is measured from the center of the steering wheel to
your breastbone. If you sit less than 10 in. (250 mm) away now, you can change your
driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals comfortably.
• Slightly recline the back of the seat. Although vehicle designs vary, many drivers
can achieve the 10 in. (250 mm) distance, even with the driver seat all the way forward, simply by reclining the back of the seat somewhat. If reclining the back of
your seat makes it hard to see the road, raise yourself by using a firm, non-slippery
cushion, or raise the seat if your vehicle has that feature.
• If your steering wheel is adjustable, tilt it downward. This points the airbag toward
your chest instead of your head and neck.
The seat should be adjusted as recommended by NHTSA above, while still maintaining control of the foot pedals, steering wheel, and your view of the instrument panel
controls.
39
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 40
40
WARNING
● If the seat belt extender has been connected
to the front seat belt buckles but the seat belt
extender has not also been fastened to the
latch plate of the seat belt, the SRS front airbags will judge that the driver and front passenger are wearing the seat belt even though
the seat belt has not been connected. In this
case, the SRS front airbags may not activate
correctly in a collision, resulting in death or
serious injury in the event of a collision. Be
sure to wear the seat belt with the seat belt
extender.
● Do not sit on the edge of the seat or lean
against the dashboard.
● Do not allow a child to stand in front of the
SRS front passenger airbag unit or sit on the
knees of a front passenger.
● Do not allow the front seat occupants to hold
items on their knees.
■ SRS airbag precautions
1-1. For safe use
● The SRS front passenger airbag also deploys with considerable force, and can cause
death or serious injury especially if the front passenger is very close to the airbag. The
front passenger seat should be as far from the airbag as possible with the seatback
adjusted, so the front passenger sits upright.
● Improperly seated and/or restrained infants and children can be killed or seriously
injured by a deploying airbag. An infant or child who is too small to use a seat belt
should be properly secured using a child restraint system. Lexus strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front
passenger seat. (P. 54)
GX460_OM_OM60R27U_(U)
Page 41
WARNING
■ SRS airbag precautions
● Do not lean against the door, the roof side rail
or the front, side and rear pillars.
● Do not allow anyone to kneel on the passen-
ger seats toward the door or put their head or
hands outside the vehicle.
● Do not attach anything to or lean anything
against areas such as the dashboard, steering
wheel pad and lower portion of the instrument panel.
These items can become projectiles when the
SRS driver, front passenger and knee airbags
deploy.
1-1. For safe use
41
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 42
42
WARNING
● Do not attach anything to areas such as a
door, windshield, side door glass, front or rear
pillar, roof side rail and assist grip.
■ SRS airbag precautions
1-1. For safe use
● Do not hang coat hangers or other hard objects on the coat hooks. All of these items
could become projectiles and may cause death or serious injury, should the SRS curtain shield airbags deploy.
● If a vinyl cover is put on the area where the SRS knee airbag will deploy, be sure to
remove it.
● Do not use seat accessories which cover the parts where the SRS side airbags inflate
as they may interfere with inflation of the SRS airbags. Such accessories may prevent
the side airbags from activating correctly, disable the system or cause the side airbags
to inflate accidentally, resulting in death or serious injury.
● Do not strike or apply significant levels of force to the area of the SRS airbag compo-
nents.
Doing so can cause the SRS airbags to malfunction.
● Do not touch any of the component parts immediately after the SRS airbags have
deployed (inflated) as they may be hot.
● If breathing becomes difficult after the SRS airbags have deployed, open a door or
window to allow fresh air in, or leave the vehicle if it is safe to do so. Wash off any residue as soon as possible to prevent skin irritation.
● If the areas where the SRS airbags are stored, such as the steering wheel pad and
front and rear pillar garnishes, are damaged or cracked, have them replaced by your
Lexus dealer.
● Do not place anything such as a cushion on the front passenger’s seat. Doing so will
disperse the passenger’s weight, which prevents the sensor from detecting the passenger’s weight properly. As a result, the SRS front airbags for the front passenger
may not deploy in the event of a collision.
GX460_OM_OM60R27U_(U)
Page 43
1-1. For safe use
WARNING
■ Modification and disposal of SRS airbag system components
Do not dispose of your vehicle or perform any of the following modifications without
consulting your Lexus dealer. The SRS airbags may malfunction or deploy (inflate)
accidentally, causing death or serious injury.
● Installation, removal, disassembly and repair of the SRS airbags
● Repairs, modifications, removal or replacement of the steering wheel, instrument
panel, dashboard, seats or seat upholstery, front, side and rear pillars or roof side rails
● Repairs or modifications of the front fender, front bumper, or side of the occupant
compartment
● Installation of a grille guard (bull bars, kangaroo bar, etc.), snow plows, winches or
roof luggage carrier
● Modifications to the vehicle’s suspension system
● Installation of electronic devices such as mobile two-way radios and CD players
● Modifications to your vehicle for a person with a physical disability
■ If the SRS airbags deploy (inflate)
● Slight abrasions, burns, bruising etc., may be sustained from SRS airbags, due to the
extremely high speed deployment (inflation) by hot gases.
● A loud noise and white powder will be emitted.
● Parts of the airbag module (steering wheel hub, airbag cover and inflator) as well as the
front seats, parts of the front and rear pillars and roof side rails, may be hot for several
minutes. The airbag itself may also be hot.
● The windshield may crack.
● All of the doors will be unlocked. (P. 110)
● Fuel supply to the engine will be stopped. (P. 510)
● For Lexus Enform Safety Connect subscribers, if any of the following situations occur,
the system is designed to send an emergency call to the response center, notifying
them of the vehicle’s location (without needing to push the “SOS” button) and an agent
will attempt to speak with the occupants to ascertain the level of emergency and assistance required. If the occupants are unable to communicate, the agent automatically
treats the call as an emergency and helps to dispatch the necessary emergency services. (P. 71)
• An SRS airbag is deployed.
• A seat belt pretensioner is activated.
• The vehicle is involved in a severe rear-end collision.
43
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 44
44
■ SRS airbag deployment conditions (SRS front airbags)
● The SRS front airbags will deploy in the event of an impact that exceeds the set thresh-
1-1. For safe use
old level (the level of force corresponding to an approximately 12 - 18 mph [20 - 30
km/h] frontal collision with a fixed wall that does not move or deform).
However, this threshold velocity will be considerably higher in the following situations:
• If the vehicle strikes an object, such as a parked vehicle or sign pole, which can move
or deform on impact
• If the vehicle is involved in an underride collision, such as a collision in which the
front of the vehicle “underrides”, or goes under, the bed of a truck
● Depending on the type of collision, it is possible that only the seat belt pretensioners will
activate.
● The SRS front airbags for the front passenger will not activate if there is no passenger
sitting in the front passenger seat. However, the SRS front airbags for the front passenger may deploy if luggage is put in the seat, even if the seat is unoccupied.
■ SRS airbag deployment conditions (SRS side and curtain shield airbags)
● The SRS side and curtain shield airbags will deploy in the event of an impact that
exceeds the set threshold level (the level of force corresponding to the impact force
produced by an approximately 3300 lb. [1500 kg] vehicle colliding with the vehicle
cabin from a direction perpendicular to the vehicle orientation at an approximate
speed of 12 - 18 mph [20 - 30 km/h]).
● Both SRS curtain shield airbags will deploy in the event of vehicle rollover.
● All SRS side and curtain shield airbags will deploy in the event of a severe frontal colli-
sion.
■ Conditions under which the SRS airbags may deploy (inflate), other than a collision
The SRS front airbags, SRS side and curtain shield airbags may also deploy if a serious
impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
● Hitting a curb, edge of pavement or hard sur-
face
● Falling into or jumping over a deep hole
● Landing hard or falling
The SRS curtain shield airbags may also deploy under the situations shown in the illustration.
● The angle of vehicle tip-up is marginal
● The vehicle skids and hits a curb stone
GX460_OM_OM60R27U_(U)
Page 45
1-1. For safe use
■ Types of collisions that may not deploy the SRS airbags (SRS front airbags)
The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear
collision, if it rolls over, or if it is involved in a low-speed frontal collision. But, whenever a
collision of any type causes sufficient forward deceleration of the vehicle, deployment of
the SRS front airbags may occur.
● Collision from the side
● Collision from the rear
● Vehicle rollover
■ Types of collisions that may not deploy the SRS airbags
(SRS side and curtain shield airbags)
The SRS side and curtain shield airbags may not activate if the vehicle is subjected to a
collision from the side at certain angles, or a collision to the side of the vehicle body other
than the passenger compartment.
● Collision from the side to the vehicle body
other than the passenger compartment
● Collision from the side at an angle
45
1
For safety and security
The SRS side airbags do not generally inflate if the vehicle is involved in a rear collision, if
it rolls over, or if it is involved in a low-speed side or low-speed frontal collision.
● Collision from the rear
● Vehicle rollover
The SRS curtain shield airbags do not generally inflate if the vehicle is involved in a rear
collision, if it pitches end over end, or if it is involved in a low-speed side or low-speed
frontal collision.
● Collision from the rear
● Pitching end over end
GX460_OM_OM60R27U_(U)
Page 46
46
■ When to contact your Lexus dealer
1-1. For safe use
In the following cases, the vehicle will require inspection and/or repair. Contact your
Lexus dealer as soon as possible.
● Any of the SRS airbags have been inflated.
● The front of the vehicle is damaged or
deformed, or was involved in an accident that
was not severe enough to cause the SRS front
airbags to inflate.
● A portion of a door or its surrounding area is
damaged or deformed, or the vehicle was
involved in an accident that was not severe
enough to cause the SRS side and curtain
shield airbags to inflate.
● The pad section of the steering wheel, dash-
board near the front passenger airbag or
lower portion of the instrument panel is
scratched, cracked, or otherwise damaged.
● The surface of the seats with the SRS side air-
bag is scratched, cracked or otherwise damaged.
● The portion of the front pillars, rear pillars or
roof side rail garnishes (padding) containing
the SRS curtain shield airbags inside is
scratched, cracked, or otherwise damaged.
GX460_OM_OM60R27U_(U)
Page 47
1-1. For safe use
U.S.A.
Canada
Front passenger occupant classification system
Your vehicle is equipped with a front passenger occupant classification system. This system detects the conditions of the front passenger seat and activates or deactivates the front passenger airbag, front passenger knee airbag,
and front passenger’s seat belt pretensioner.
47
1
For safety and security
1
SRS warning light
2
Front passenger’s seat belt reminder light
3
“AIR BAG OFF” indicator light
4
“AIR BAG ON” indicator light
GX460_OM_OM60R27U_(U)
Page 48
48
1-1. For safe use
Condition and operation in the front passenger occupant classification
system
■ Adult*
1
Indicator/
warning light
Devices
■ Child*
Indicator/
warning light
Devices
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
SRS warning light Off
Front passenger’s seat belt reminder light Off*2 or flashing*
Front passenger airbag
Front passenger’s seat belt pretensioner
4
or child restraint system*
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
SRS warning light Off
Front passenger’s seat belt reminder light
Front passenger airbag
Front passenger knee airbag
“AIR BAG ON”
3
ActivatedFront passenger knee airbag
5
“AIR BAG OFF”*
Off*2 or
flashing*
6
3
Deactivated
GX460_OM_OM60R27U_(U)
Front passenger’s seat belt pretensioner Activated
Page 49
■ Unoccupied
1-1. For safe use
49
“AIR BAG ON” and “AIR BAG OFF”
indicator lights
Indicator/
warning light
Front passenger’s seat belt reminder light
Devices
Front passenger’s seat belt pretensioner
■ There is a malfunction in the system
“AIR BAG ON” and “AIR BAG OFF”
Indicator/
warning light
Front passenger’s seat belt reminder light
Devices
SRS warning light
Front passenger airbag
Front passenger knee airbag
indicator lights
SRS warning light
Front passenger airbag
Front passenger knee airbag
Not illuminated
Off
Deactivated
Activated*7
or
eactivated*
d
“AIR BAG OFF”
Deactivated
8
On
1
For safety and security
GX460_OM_OM60R27U_(U)
Front passenger’s seat belt pretensioner Activated
Page 50
50
1-1. For safe use
1
*
: The system judges a person of adult size as an adult. When a smaller adult sits in
the front passenger seat, the system may recognize him/her as a child depending
on his/her physique and posture.
2
*
: In the event the front passenger is wearing a seat belt.
3
*
: In the event the front passenger does not wear a seat belt
4
*
: When a larger child who has outgrown a child restraint system sits in the front pas-
senger seat, the system may recognize him/her as an adult depending on his/her
physique or posture.
5
*
: Never install a rear-facing child restraint system on the front passenger seat. A for-
ward-facing child restraint system should only be installed on the front passenger
seat when it is unavoidable. (P. 54)
6
*
: In case the indicator light is not illuminated, consult this manual on how to install the
child restraint system properly. (P. 58)
7
*
: In the event of a side collision.
8
*
: In the event of a frontal collision or rollover.
GX460_OM_OM60R27U_(U)
Page 51
1-1. For safe use
WARNING
■ Front passenger occupant classification system precautions
Observe the following precautions regarding the front passenger occupant classification system.
Failure to do so may cause death or serious injury.
● Wear the seat belt properly.
● Make sure the front passenger’s seat belt plate has not been left inserted into the
buckle before someone sits in the front passenger seat.
● Make sure the “AIR BAG OFF” indicator light is not illuminated when using the seat
belt extender for the front passenger seat. If the “AIR BAG OFF” indicator light is illuminated, disconnect the extender tongue from the seat belt buckle, and reconnect
the seat belt. Reconnect the seat belt extender after making sure the “AIR BAG ON”
indicator light is illuminated. If you use the seat belt extender while the “AIR BAG
OFF” indicator light is illuminated, the SRS airbags for the front passenger will not
activate, which could cause death or serious injury in the event of a collision.
● Do not apply a heavy load to the front passenger seat or equipment (e.g. seatback
pocket).
● Do not put weight on the front passenger seat by putting your hands or feet on the
front passenger seat seatback from the rear passenger seat.
● Do not let a rear passenger lift the front passenger seat with their feet or press on the
seatback with their legs.
● Do not put objects under the front passenger seat.
51
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 52
52
WARNING
■ Front passenger occupant classification system precautions
1-1. For safe use
● Do not recline the front passenger seatback so far that it touches a rear seat. This may
cause the “AIR BAG OFF” indicator light to be illuminated, which indicates that the
SRS airbags for the front passenger will not activate in the event of a severe accident.
If the seatback touches the rear seat, return the seatback to a position where it does
not touch the rear seat. Keep the front passenger seatback as upright as possible
when the vehicle is moving. Reclining the seatback excessively may lessen the effectiveness of the seat belt system.
● If an adult sits in the front passenger seat, the “AIR BAG ON” indicator light is illumi-
nated. If the “AIR BAG OFF” indicator is illuminated, ask the passenger to sit up
straight, well back in the seat, feet on the floor, and with the seat belt worn correctly. If
the “AIR BAG OFF” indicator still remains illuminated, either ask the passenger to
move to the rear seat, or if that is not possible, move the front passenger seat fully
rearward.
● When it is unavoidable to install a forward-facing child restraint system on the front
passenger seat, install the child restraint system on the front passenger seat in the
proper order. (P. 58)
● Do not modify or remove the front seats.
● Do not kick the front passenger seat or subject it to severe impact. Otherwise, the
SRS warning light may come on to indicate a malfunction of the front passenger
occupant classification system. In this case, contact your Lexus dealer immediately.
● Child restraint systems installed on the rear seat should not contact the front seat-
backs.
● Do not use a seat accessory, such as a cushion and seat cover, that covers the seat
cushion surface.
● Do not modify or replace the upholstery of the front seat.
GX460_OM_OM60R27U_(U)
Page 53
1-1. For safe use
WARNING
Safety information for children
Observe the following precautions when children are in the vehicle.
Use a child restraint system appropriate for the child, until the child becomes
large enough to properly wear the vehicle’s seat belt.
● It is recommended that children sit in the rear seats to avoid accidental con-
tact with the shift lever, wiper switch etc.
● Use the rear door child-protector lock or the window lock switch to avoid
children opening the door while driving or operating the power window accidentally. (P. 107, 156)
● Do not let small children operate equipment which may catch or pinch body
parts, such as the power window, hood, back door, seats etc.
Never leave children unattended in the vehicle, and never allow children to have or use
the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is also a
danger that children may injure themselves by playing with the windows, the moon roof
or other features of the vehicle. In addition, heat build-up or extremely cold temperatures inside the vehicle can be fatal to children.
53
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 54
54
1-1. For safe use
Child restraint systems
A child restraint system for a small child or baby must itself be properly
restrained on the seat with the LATCH anchors or the lap portion of the lap/
shoulder belt.
The laws of all 50 states of the U.S.A. and Canada now require the use of child
restraint systems.
Points to remember
Studies have shown that installing a child restraint on a rear seat is much safer
than installing one on the front passenger seat.
● Choose a child restraint system that suits your vehicle and is appropriate to
the age and size of the child.
● For installation details, follow the instructions provided with the child restraint
system.
General installation instructions are provided in this manual. (P. 58)
GX460_OM_OM60R27U_(U)
Page 55
1-1. For safe use
Types of child restraints
Child restraint systems are classified into the following 3 types according to the
age and size of the child:
55
Rear facing Infant seat/convert-
ible seat
Booster seat
Forward facing Convertible
seat
1
For safety and security
■ Selecting an appropriate child restraint system
● Use a child restraint system appropriate for the child until the child becomes large
enough to properly wear the vehicle’s seat belt.
● If the child is too large for a child restraint system, sit the child on a rear seat and use the
vehicle’s seat belt. (P. 30)
GX460_OM_OM60R27U_(U)
Page 56
56
WARNING
■ Child restraint precautions
1-1. For safe use
● For effective protection in automobile accidents and sudden stops, a child must be
properly restrained, using a seat belt or child restraint system depending on the age
and size of the child. Holding a child in your arms is not a substitute for a child restraint
system. In an accident, the child can be crushed against the windshield, or between
you and the vehicle’s interior.
● Lexus strongly urges the use of a proper child restraint system that conforms to the
size of the child, installed on the rear seat. According to accident statistics, the child is
safer when properly restrained in the rear seat than in the front seat.
● Never install a rear-facing child restraint system on the front passenger seat even if
the “AIR BAG OFF” indicator light is illuminated.
In the event of an accident, the force of the rapid inflation of the front passenger airbag can cause death or serious injury to the child if the rear-facing child restraint system is installed on the front passenger seat.
● A forward-facing child restraint system may be installed on the front passenger seat
only when it is unavoidable. A child restraint system that requires a top tether strap
should not be used in the front passenger seat since there is no top tether strap
anchor for the front passenger seat. Adjust the seatback as upright as possible and
always move the seat as far back as possible even if the “AIR BAG OFF” indicator
light is illuminated, because the front passenger airbag could inflate with considerable
speed and force. Otherwise, the child may be killed or seriously injured.
● Do not use the seat belt extender when installing a child restraint system on the front
or rear passenger seat. If installing a child restraint system with the seat belt extender
connected to the seat belt, the seat belt will not securely hold the child restraint system, which could cause death or serious injury to the child or other passengers in the
event of a sudden stop, sudden swerve or accident.
● Do not allow the child to lean his/her head or any part of his/her body against the
door or the area of the seat, front, center and rear pillars or roof side rails from which
the SRS side airbags or SRS curtain shield airbags deploy even if the child is seated in
the child restraint system. It is dangerous if the SRS side airbags and curtain shield airbags inflate, and the impact could cause death or serious injury to the child.
● Make sure you have complied with all installation instructions provided by the child
restraint manufacturer and that the system is properly secured. If it is not secured
properly, it may cause death or serious injury to the child in the event of a sudden
stop, sudden swerve or accident.
GX460_OM_OM60R27U_(U)
Page 57
1-1. For safe use
WARNING
■ When children are in the vehicle
Do not allow children to play with the seat belt. If the seat belt becomes twisted around
a child’s neck, it may lead to choking or other serious injuries that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to cut the
belt.
■ When the child restraint system is not in use
● Keep the child restraint system properly secured on the seat even if it is not in use. Do
not store the child restraint system unsecured in the passenger compartment.
● If it is necessary to detach the child restraint system, remove it from the vehicle or
store it securely in the luggage compartment. This will prevent it from injuring passengers in the event of a sudden stop, sudden swerve or accident.
57
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 58
58
1-1. For safe use
Installing child restraints
Follow the child restraint system manufacturer’s instructions. Firmly secure
child restraints to the seats using the LATCH anchors or a seat belt. Attach the
top tether strap when installing a child restraint.
The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Children) system.
Child restraint LATCH anchors
7-passenger models
LATCH anchors are provided for the
right side second seat and between the
center and left side second seats. (Buttons displaying the location of the
anchors are attached to the seats.)
6-passenger models
LATCH anchors are provided for both
second seats. (Buttons displaying the
location of the anchors are attached to
the seats.)
Seat belts equipped with a child
restraint locking mechanism (ALR/
ELR belts except driver’s seat belt)
(P. 32)
GX460_OM_OM60R27U_(U)
Page 59
Anchor brackets (for top tether strap)
7-passenger models
An anchor bracket is provided for each
second seat.
6-passenger models
Anchor brackets are provided for both
second seats and right side third seat.
1-1. For safe use
59
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 60
60
1
Canada only
2
1-1. For safe use
Installation with LATCH system
Fold the seatback forward. Then
return the seatback and secure it at
the first lock position (most upright
position). (P. 130)
Type A
Flip the cover, and latch the hooks of
the lower straps onto the LATCH
anchors. If the child restraint has a
top tether strap, the top tether strap
should be latched onto the top
tether strap anchor. (P. 66)
For owners in Canada:
The symbol on a child restraint system indicates the presence of a
lower connector system.
GX460_OM_OM60R27U_(U)
Page 61
Type B
Canada only
2
Flip the cover, and latch the buckles
onto the LATCH anchors. If the child
restraint has a top tether strap, the
top tether strap should be latched
onto the top tether strap anchor.
(P. 66)
For owners in Canada:
The symbol on a child restraint system indicates the presence of a
lower connector system.
1-1. For safe use
61
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 62
62
1
2
3
4
1-1. For safe use
Installing child restraints using a seat belt (child restraint lock function
belt)
■ Rear-facing Infant seat/convertible seat
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). (P. 130)
Place the child restraint system
on the seat facing the rear of the
vehicle.
Run the seat belt through the
child restraint system and insert
the plate into the buckle. Make
sure that the belt is not twisted.
Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt cannot be extended.
GX460_OM_OM60R27U_(U)
Page 63
While pushing the child restraint
512
system down into the seat, allow
the shoulder belt to retract until
the child restraint system is
securely in place.
After the shoulder belt has retracted
to a point where there is no slack in
the belt, pull the belt to check that it
cannot be extended.
■ Forward-facing Convertible seat
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). (P. 130)
Place the child restraint system
on the seat facing the front of the
vehicle.
1-1. For safe use
63
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 64
64
3
4
5
6
1-1. For safe use
Run the seat belt through the
child restraint system and insert
the plate into the buckle. Make
sure that the belt is not twisted.
Fully extend the shoulder belt and
allow it to retract to put it in lock
mode. In lock mode, the belt cannot be extended.
While pushing the child restraint
system into the seat, allow the
shoulder belt to retract until the
child restraint system is securely
in place.
After the shoulder belt has retracted
to a point where there is no slack in
the belt, pull the belt to check that it
cannot be extended.
If the child restraint has a top tether strap, the top tether strap should be
latched onto the top tether strap anchor. (P. 66)
GX460_OM_OM60R27U_(U)
Page 65
■ Booster seat
1
2
3
Fold the seatback forward. Then
return the seatback and secure it
at the first lock position (most
upright position). (P. 130)
Place the child restraint system
on the seat facing the front of the
vehicle.
Sit the child in the child restraint
system. Fit the seat belt to the
child restraint system according
to the manufacturer’s instructions
and insert the plate into the
buckle. Make sure that the belt is
not twisted.
Check that the shoulder belt is correctly positioned over the child’s
shoulder and that the lap belt is as
low as possible. (P. 30)
1-1. For safe use
65
1
For safety and security
Removing a child restraint installed with a seat belt
Push the buckle release button and fully
retract the seat belt.
GX460_OM_OM60R27U_(U)
Page 66
66
1
2
2
1-1. For safe use
Child restraint systems with a top tether strap (second seats)
Secure the child restraint system
using the seat belt or LATCH
anchors and move the head restraint
in place at the upmost position.
7-passenger models
Open the anchor bracket cover,
latch the hook onto the anchor
bracket and tighten the top tether
strap.
Make sure the top tether strap is
securely latched.
6-passenger models
Latch the hook onto the anchor
bracket and tighten the top tether
strap.
Make sure the top tether strap is
securely latched.
GX460_OM_OM60R27U_(U)
Page 67
1-1. For safe use
1
2
Child restraint systems with a top tether strap (right side third seat for
6-passenger models)
Lift up the head restraint system until
it locks and secure the child restraint
system using the seat belt.
Latch the hook onto the anchor
bracket and tighten the top tether
strap.
Make sure the top tether strap is
securely latched.
67
1
For safety and security
■ Laws and regulations pertaining to anchorages
The LATCH system conforms to FMVSS225 or CMVSS210.2.
Child restraint systems conforming to FMVSS213 or CMVSS213 specifications can be
used.
This vehicle is designed to conform to the SAE J1819.
GX460_OM_OM60R27U_(U)
Page 68
68
WARNING
● If the driver’s seat interferes with the child
restraint system and prevents it from being
attached correctly, attach the child restraint
system to the right-hand rear seat.
● Adjust the front passenger seat so that it does
not interfere with the child restraint system.
● Child restraint system installed on the third
seat should not contact the second seatbacks.
● Only put a forward-facing child restraint sys-
tem on the front seat when unavoidable.
When installing a forward-facing child
restraint system on the front passenger seat,
move the seat as far back as possible even if
the “AIR BAG OFF” indicator light is illuminated. Failure to do so may result in death or
serious injury if the airbags deploy (inflate).
■ When installing a booster seat
1-1. For safe use
To prevent the belt from going into ALR lock mode, do not fully extend the shoulder
belt. ALR mode causes the belt to tighten only. This could cause injury or discomfort to
the child. (P. 32)
■ When installing a child restraint system
Follow the directions given in the child restraint system installation manual and fix the
child restraint system securely in place.
If the child restraint system is not correctly fixed in place, the child or other passengers
may be seriously injured or even killed in the event of sudden braking, sudden swerving
or an accident.
● When installing a child restraint system in the center second seat, adjust both seat-
backs at the same angle.
● When using the LATCH anchors for a child restraint system, move the seat as far
back as possible (second seat only), with the seatback close to the child restraint system.
GX460_OM_OM60R27U_(U)
Page 69
1-1. For safe use
WARNING
■ When installing a child restraint system
● When a booster seat is installed, always ensure that the shoulder belt is positioned
across the center of the child’s shoulder. The belt should be kept away from the child’s
neck, but not so that it could fall off the child’s shoulder. Failing to do so may result in
death or serious injury in the event of sudden braking, sudden swerving or an accident.
● Ensure that the belt and plate are securely locked and the seat belt is not twisted.
● Shake the child restraint system left and right, and forward and backward to ensure
that it has been securely installed.
● After securing a child restraint system, never adjust the seat.
● Follow all installation instructions provided by the child restraint system manufacturer.
● When securing some types of child restrain systems in second or third row seats, it
may not be possible to properly use the seat belts in positions next to the child
restraint without interfering with it or affecting seat belt effectiveness. Be sure your
seat belt fits snugly across your shoulder and low on your hips. If it does not, or if it
interferes with the child restraint, move to a different position. Failure to do so may
result in death or serious injury.
■ Do not use a seat belt extender
If a seat belt extender is used when installing a child restraint system, the seat belt will
not securely hold the child restraint system, which could cause death or serious injury
to the child or other passengers in the event of sudden braking, sudden swerving or an
accident.
■ To correctly attach a child restraint system to the anchors
When using the LATCH anchors, be sure that there are no foreign objects around the
anchors and that the seat belt is not caught behind the child restraint system. Make sure
the child restraint system is securely attached, or it may cause death or serious injury to
the child or other passengers in the event of a sudden stop, sudden swerve or accident.
69
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 70
70
WARNING
1-1. For safe use
Exhaust gas precautions
Harmful substance to the human body is included in exhaust gases if inhaled.
Exhaust gases include harmful carbon monoxide (CO), which is colorless and odorless.
Observe the following precautions.
Failure to do so may cause exhaust gases enter the vehicle and may lead to an accident
caused by light-headedness, or may lead to death or a serious health hazard.
■ Important points while driving
● Keep the back door closed.
● If you smell exhaust gases in the vehicle even when the back door is closed, open the
windows and have the vehicle inspected at your Lexus dealer as soon as possible.
■ When parking
● If the vehicle is in a poorly ventilated area or a closed area, such as a garage, stop the
engine.
● Do not leave the vehicle with the engine running for a long time.
If such a situation cannot be avoided, park the vehicle in an open space and ensure
that exhaust fumes do not enter the vehicle interior.
● Do not leave the engine running in an area with snow build-up, or where it is snowing.
If snowbanks build up around the vehicle while the engine is running, exhaust gases
may collect and enter the vehicle.
■ Exhaust pipe
The exhaust system needs to be checked periodically. If there is a hole or crack caused
by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle
inspected and repaired by your Lexus dealer.
GX460_OM_OM60R27U_(U)
Page 71
1-2. LEXUS Enform
71
LEXUS Enform Safety Connect
Safety Connect is a subscription-based telematics service that uses Global
Positioning System (GPS) data and embedded cellular technology to provide
safety and security features to subscribers. Safety Connect is supported by
Lexus’ designated response center, which operates 24 hours per day, 7 days
per week.
Safety Connect service is available by subscription on select, telematics hardware-equipped vehicles.
By using the Safety Connect service, you are agreeing to be bound by the
Telematics Subscription Service Agreement and its Terms and Conditions, as
in effect and amended from time to time, a current copy of which is available
at Lexus.com. All use of the Safety Connect service is subject to such thenapplicable Terms and Conditions.
System components
1
Microphone
2
LED light indicators
3
“SOS” button
1
For safety and security
GX460_OM_OM60R27U_(U)
: If equipped
Page 72
72
1-2. LEXUS Enform
Services
Subscribers have the following Safety Connect services available:
● Automatic Collision Notification*
Helps drivers receive necessary response from emergency service providers.
(P. 74)
*: U.S. Patent No. 7,508,298 B2
● Stolen Vehicle Location
Helps drivers in the event of vehicle theft. (P. 74)
● Emergency Assistance Button (“SOS”)
Connects drivers to response-center support. (P. 74)
● Enhanced Roadside Assistance
Provides drivers various on-road assistance. (P. 74)
Subscription
After you have signed the Telematics Subscription Service Agreement and are
enrolled, you can begin receiving services.
A variety of subscription terms is available for purchase. Contact your Lexus
dealer, call the following or push the “SOS” button in your vehicle for further subscription details.
• The United States
1-800-25-LEXUS (1-800-255-3987)
•Canada
1-800-26-LEXUS (1-800-265-3987)
•Puerto Rico
1-877-539-8777
GX460_OM_OM60R27U_(U)
Page 73
1-2. LEXUS Enform
73
■ Safety Connect Services Information
● Phone calls using the vehicle’s Bluetooth
®
technology will not be possible during
Safety Connect.
● Safety Connect is available beginning Fall 2009 on select Lexus models (in the contig-
uous United States only). Contact with the Safety Connect response center is dependent upon the telematics device being in operative condition, cellular connection
availability, and GPS satellite signal reception, which can limit the ability to reach the
response center or receive emergency service support. Enrollment and Telematics
Subscription Service Agreement required. A variety of subscription terms is available;
charges vary by subscription term selected and location.
● Automatic Collision Notification, Emergency Assistance and Stolen Vehicle Location
will function in the United States, including Hawaii and Alaska, Puerto Rico and in Canada, and Enhanced Roadside Assistance will function in the United States, Puerto Rico
and in Canada.
● Automatic Collision Notification, Emergency Assistance, Stolen Vehicle and Enhanced
Road Assistance will not function in the United States Virgin Islands.
For vehicles first sold in the USVI, no Safety Connect services will function in and outside the United States Virgin Islands.
● Safety Connect services are not subject to section 255 of the Telecommunications Act
and the device is not TTY compatible.
■ Languages
The Safety Connect response center will offer support in multiple languages. The Safety
Connect system will offer voice prompts in English, Spanish, and French. Please indicate
your language of choice when enrolling.
■ When contacting the response center
You may be unable to contact the response center if the network is busy.
1
For safety and security
Safety Connect LED light Indicators
When the engine switch is turned to IGNITION ON mode, the red indicator
light comes on for 2 seconds then turns off. Afterward, the green indicator light
comes on, indicating that the service is active.
The following indicator light patterns indicate specific system usage conditions:
● Green indicator light on = Active service
● Green indicator light flashing = Safety Connect call in process
● Red indicator light (except at vehicle start-up) = System malfunction (contact
your Lexus dealer)
● No indicator light (off) = Safety Connect service not active
GX460_OM_OM60R27U_(U)
Page 74
74
1-2. LEXUS Enform
Safety Connect services
■ Automatic Collision Notification
In case of either airbag deployment or severe rear-end collision, the system is
designed to automatically call the response center. The responding agent
receives the vehicle’s location and attempts to speak with the vehicle occupants to assess the level of emergency. If the occupants are unable to communicate, the agent automatically treats the call as an emergency, contacts the
nearest emergency services provider to describe the situation, and requests
that assistance be sent to the location.
■ Stolen Vehicle Location
If your vehicle is stolen, Safety Connect can work with local authorities to
assist them in locating and recovering the vehicle. After filing a police report,
call the Safety Connect response center at 1-800-25-LEXUS (1-800-255-
3987) in the United States, 1-877-539-8777 in Puerto Rico or 1-800-2653987 in Canada, and follow the prompts for Safety Connect to initiate this
service.
In addition to assisting law enforcement with recovery of a stolen vehicle,
Safety-Connect-equipped vehicle location data may, under certain circumstances, be shared with third parties to locate your vehicle. Further information is available at Lexus.com.
■ Emergency Assistance Button (“SOS”)
In the event of an emergency on the road, push the “SOS” button to reach the
Safety Connect response center. The answering agent will determine your
vehicle’s location, assess the emergency, and dispatch the necessary assistance required.
If you accidentally press the “SOS” button, tell the response-center agent that you
are not experiencing an emergency.
■ Enhanced Roadside Assistance
Enhanced Roadside Assistance adds GPS data to the already included warranty-based Lexus roadside service.
Subscribers can press the “SOS” button to reach a Safety Connect responsecenter agent, who can help with a wide range of needs, such as: towing, flat
tire, fuel delivery, etc. For a description of the Roadside Assistance services
and their limitations, please see the Safety Connect Terms and Conditions,
which are available at Lexus.com.
GX460_OM_OM60R27U_(U)
Page 75
1-2. LEXUS Enform
Safety information for Safety Connect
Important! Read this information before using Safety Connect.
■ Exposure to radio frequency signals
The Safety Connect system installed in your vehicle is a low-power radio
transmitter and receiver. It receives and also sends out radio frequency (RF)
signals.
In August 1996, the Federal Communications Commission (FCC) adopted
RF exposure guidelines with safety levels for mobile wireless phones. Those
guidelines are consistent with the safety standards previously set by the following U.S. and international standards bodies.
● ANSI (American National Standards Institute) C95.1 [1992]
● NCRP (National Council on Radiation Protection and Measurement)
Report 86 [1986]
● ICNIRP (International Commission on Non-Ionizing Radiation Protection)
[1996]
Those standards were based on comprehensive and periodic evaluations of
the relevant scientific literature. Over 120 scientists, engineers, and physicians from universities, and government health agencies and industries
reviewed the available body of research to develop the ANSI Standard
(C95.1).
The design of Safety Connect complies with the FCC guidelines in addition to
those standards.
75
1
For safety and security
■ Certification for Lexus Enform Safety Connect
GX460_OM_OM60R27U_(U)
Page 76
76
1-3. Theft deterrent system
Engine immobilizer system
The vehicle’s keys have built-in transponder chips that prevent the engine
from starting if a key has not been previously registered in the vehicle’s onboard computer.
Never leave the keys inside the vehicle when you leave the vehicle.
This system is designed to help prevent vehicle theft but does not guarantee
absolute security against all vehicle thefts.
The indicator light flashes after the
engine switch has been turned off to
indicate that the system is operating.
The indicator light stops flashing after
the engine switch has been turned to
ACCESSORY or IGNITION ON
mode to indicate that the system has
been canceled.
■ System maintenance
The vehicle has a maintenance-free type engine immobilizer system.
■ Conditions that may cause the system to malfunction
● If the grip portion of the key is in contact with a metallic object
● If the key is in close proximity to or touching a key to the security system (key with a
built-in transponder chip) of another vehicle
■ Certifications for the engine immobilizer system
For vehicles sold in the U.S.A., Hawaii, Guam, Saipan and Puerto Rico
GX460_OM_OM60R27U_(U)
Page 77
1-3. Theft deterrent system
NOTICE
For vehicles sold in Canada
■ To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation of
the system cannot be guaranteed.
77
1
For safety and security
GX460_OM_OM60R27U_(U)
Page 78
78
1-3. Theft deterrent system
Alarm
The alarm
The alarm uses light and sound to give an alert when an intrusion is detected.
The alarm is triggered in the following situations when the alarm is set:
● A locked door or glass hatch is unlocked or opened in any way other than
using the entry function, wireless remote control or mechanical key. (The
doors will lock again automatically.)
● The hood is opened.
Setting the alarm system
Close the doors, glass hatch and hood,
and lock all the doors. The system will
be set automatically after 30 seconds.
The indicator light changes from being
on to flashing when the system is set.
Deactivating or stopping the alarm
Do one of the following to deactivate or stop the alarms:
● Unlock the doors.
● Turn the engine switch to ACCESSORY or IGNITION ON mode, or start
the engine. (The alarm will be deactivated or stopped after a few seconds.)
GX460_OM_OM60R27U_(U)
Page 79
1-3. Theft deterrent system
NOTICE
■ System maintenance
The vehicle has a maintenance-free type alarm system.
■ Items to check before locking the vehicle
To prevent unexpected triggering of the alarm and vehicle theft, make sure of the following.
● Nobody is in the vehicle.
● The windows and moon roof are closed before the alarm is set.
● No valuables or other personal items are left in the vehicle.
■ Triggering of the alarm
The alarm may be triggered in the following situations:
(Stopping the alarm deactivates the alarm system.)
● A person inside the vehicle opens a door or
hood, or unlocks the vehicle using an inside
lock button.
● The battery is recharged or replaced when the
vehicle is locked. (P. 544)
79
1
For safety and security
■ Alarm-operated door lock
In the following cases, depending on the situation, the door may automatically lock to
prevent improper entry into the vehicle:
● When a person remaining in the vehicle unlocks the door and the alarm is activated.
● While the alarm is activated, a person remaining in the vehicle unlocks the door.
● When recharging or replacing the battery.
■ Alarm memory function
After the alarm is activated, when you unlock any door using a entry function, wireless
remote control or mechanical key, the tail lights turn on for about 2 seconds to inform
you that the system was activated.
■ To ensure the system operates correctly
Do not modify or remove the system. If modified or removed, the proper operation of
the system cannot be guaranteed.
GX460_OM_OM60R27U_(U)
Page 80
80
1-3. Theft deterrent system
GX460_OM_OM60R27U_(U)
Page 81
81
Instrument cluster
2
2. Instrument cluster
Warning and indicators
lights ................................................82
Gauges and meters.....................88
Multi-information display ............91
Fuel consumption
information ...................................98
GX460_OM_OM60R27U_(U)
Page 82
82
2. Instrument cluster
Warning and indicators lights
The warning and indicators lights on the instrument cluster and center panel
inform the driver of the status of the vehicle’s various systems.
For the purpose of explanation, the following illustrations display all warning
lights and indicators illuminated.
The units used on the speedometer may differ depending on the target region.
GX460_OM_OM60R27U_(U)
Page 83
2. Instrument cluster
Warning lights
Warning lights inform the driver of malfunctions in any of the vehicle’s systems.
83
(U.S.A.)
(Canada)
(U.S.A.)
(Canada)
1
*
Brake system warning light
(P. 511)
1
*
Brake system warning light
(P. 511)
1
*
Charging system warning
light (P. 511)
2
*
High coolant temperature
warning light (P. 511)
2
*
Low engine oil pressure
warning light (P. 511)
1
*
Malfunction indicator lamp
(P. 511)
1
*
Malfunction indicator lamp
(P. 511)
1
*
SRS warning light
(P. 511)
(flashes or
illuminates)
(flashes)
(flashes)
1
*
PCS warning light
(P. 512)
1
*
Slip indicator light
(P. 512)
1
Kinetic dynamic suspension
*
system warning light
(P. 512)
Low speed four-wheel
drive indicator light
(P. 513)
Center differential lock
indicator light (P. 513)
Open door warning light
(P. 513)
Low fuel level warning light
(P. 513)
Seat belt reminder light
(P. 513)
2
Instrument cluster
1
*
ABS warning light
(P. 512)
(U.S.A.)
1
*
ABS warning light
(P. 512)
(Canada)
GX460_OM_OM60R27U_(U)
1
*
Tire pressure warning light
(P. 513)
2
*
LDA indicator (P. 514)
Page 84
84
2. Instrument cluster
Parking brake indicator
(flashes)
(U.S.A.)
(P. 512)
Brake Override System
2
*
warning light /Drive-Start
Control warning light
(P. 514)
Parking brake indicator
(flashes)
(Canada)
1
*
: These lights turn on when the engine switch is turned to IGNITION ON mode to
(P. 512)
indicate that a system check is being performed. They will turn off after the engine is
on, or after a few seconds. There may be a malfunction in a system if the lights do not
turn on, or turn off. Have the vehicle inspected by your Lexus dealer.
2
*
: This light is displayed on the multi-information display.
GX460_OM_OM60R27U_(U)
Page 85
2. Instrument cluster
Indicators
The indicators inform the driver of the operating state of the vehicle’s various systems.
1
Turn signal indicator
(P. 207)
Headlight indicator
(P. 209)
(U.S.A.)
*
Dynamic radar cruise
control indicator (P. 254)
1
*
LDA indicator (P. 248)
85
2
(Canada)
(if equipped)
*
Tail light indicator
(P. 209)
Headlight high beam
indicator (P. 210)
Automatic High Beam
indicator (P. 212)
Fog light indicator
(P. 217)
2
Eco Driving Indicator
Light (P. 96)
1
*
Cruise control indicator
(P. 254)
1
*
Cruise control “SET”
indicator (P. 254)
(flashes)
2, 3
*
*
(if equipped)
(if equipped)
*
(if equipped)
1
*
LDA indicator (P. 248)
Slip indicator (P. 352)
2
VSC OFF indicator
(P. 353)
1
*
Multi-terrain Select
indicator (P. 284)
1
*
Crawl Control indicator
(P. 344)
2
Downhill assist control
system indicator
(P. 348)
“2nd STRT” indicator
(P. 203)
Instrument cluster
GX460_OM_OM60R27U_(U)
Page 86
86
2. Instrument cluster
(if equipped)
2, 4
*
(if equipped)
5, 6
*
(if equipped)
1, 7
*
Low speed four-wheel
drive indicator light
(P. 340)
Center differential lock
indicator (P. 341)
Intuitive parking assist
indicator (P. 266)
PCS warning light
(P. 238)
1
*
Smart access system with
push-button start indicator
(P. 196)
BSM indicator (P. 357)
BSM (Blind Spot Monitor)
outside rear view mirror
indicators (P. 357)
Low outside temperature
indicator (P. 88)
*
(if equipped)
(if equipped)
(if equipped)
(if equipped)
(if equipped)
(if equipped)
2
TRAC OFF indicator
(P. 353)
1
*
MUD & SAND mode
indicator (P. 285)
1
*
MOGUL mode indicator
(P. 285)
1
*
ROCK mode indicator
(P. 285)
1
*
LOOSE & ROCK mode
indicator (P. 285)
1
*
ROCK & DIRT mode
indicator (P. 285)
1
*
MTS AUTO indicator
(P. 285)
2, 8
*
(U.S.A.)
2, 8
*
(Canada)
GX460_OM_OM60R27U_(U)
“AIR BAG ON/
OFF” indicator
(P. 47)
“AIR BAG ON/
OFF” indicator
(P. 47)
Page 87
2. Instrument cluster
WARNING
1
*
: This light is displayed on the multi-information display.
2
*
: These lights turn on when the engine switch is turned to IGNITION ON mode to
indicate that a system check is being performed. They will turn off after the engine is
on, or after a few seconds. There may be a malfunction in a system if the lights do not
turn on, or turn off. Have the vehicle inspected by your Lexus dealer.
3
*
: The light flashes to indicate that the system is operating.
4
*
: The light comes on when the system is turned off.
5
*
: In order to confirm operation, the BSM outside rear view mirror indicators illumi-
nate in the following situations:
• When the engine switch is turned to IGNITION ON mode while the system is set
to on.
• When the system is set to on while the engine switch is in IGNITION ON mode.
If the system is functioning correctly, the BSM outside rear view mirror indicators
will turn off after a few seconds.
If the BSM outside rear view mirror indicators do not illuminate or do not turn off,
there may be a malfunction with the system.
If this occurs, have the vehicle inspected by your Lexus dealer.
6
*
: This light illuminates on the outside rear view mirrors.
7
*
: When the outside temperature is approximately 37°F (3°C) or lower, the indicator
will flash for approximately 10 seconds, then stay on.
8
*
: This light illuminates on the center panel.
87
2
Instrument cluster
■ If a safety system warning light does not come on
Should a safety system light such as the ABS/Multi Terrain ABS and the SRS warning
light not come on when you start the engine, this could mean that these systems are not
available to help protect you in an accident, which could result in death or serious
injury. Have the vehicle inspected by your Lexus dealer immediately if this occurs.
GX460_OM_OM60R27U_(U)
Page 88
88
6
7
2. Instrument cluster
Gauges and meters
The units used on the speedometer may differ depending on the target region.
1
Tachometer
Displays the engine speed in revolutions per minute
2
Engine coolant temperature gauge
Displays the engine coolant temperature
3
Shift position and shift range
Displays the selected shift position or selected shift range (P. 202)
4
Outside temperature
Displays the outside temperature within the range of -40°F (-40°C) to 122°F
(50°C). Low outside temperature indicator comes on when the ambient temperature
is 37°F (3°C) or lower.
5
Fuel gauge
Displays the quantity of fuel remaining in the tank
Speedometer
Displays the vehicle speed
Multi-information display
Presents the driver with a variety of driving-related dataP. 91)
GX460_OM_OM60R27U_(U)
Page 89
2. Instrument cluster
8
Odometer, trip meter and maintenance required information display
Odometer:
Displays the total distance the vehicle has been driven
Trip meter:
Displays the distance the vehicle has been driven since the meter was last reset. Trip
meters A and B can be used to record and display different distances independently.
Maintenance required information:
• Displays the maintenance required information when the engine switch is in IGNITION ON mode.
• It can be reset from of the multi-information display. (P. 91)
9
Rear height control air suspension display (if equipped)
Displays the rear height mode selected (P. 335)
Changing the display
Switches between odometer, trip meter
and maintenance required information
displays. When the trip meter is displayed, pressing and holding the button
will reset the trip meter.
89
2
Instrument cluster
Instrument cluster light control switch
The brightness of the instrument cluster lights can be adjusted.
1
Brighter
2
Darker
GX460_OM_OM60R27U_(U)
Page 90
90
WARNING
NOTICE
■ The meters and display illuminate when
2. Instrument cluster
The engine switch is in IGNITION ON mode.
■ Instrument cluster brightness adjustment
The instrument cluster brightness levels when the tail lights are on and off can be
adjusted.
■ The brightness of the instrument cluster lights
When the tail lights are on, the brightness will change. However, when the surroundings
are bright (daytime, etc.) turning on the tail lights will not change the instrument cluster
brightness.
In addition, the brightness of the instrument cluster lights is automatically adjusted based
on the light sensor detecting how bright the surroundings are.
■ Customization
The meter display can be customized on the multi-information display. (P. 576)
■ The information display at low temperatures
Allow the interior of the vehicle to warm up before using the liquid crystal information
display. At extremely low temperatures, the information display monitor may respond
slowly, and display changes may be delayed.
For example, there is a lag between the driver’s shifting and the new gear number
appearing on the display. This lag could cause the driver to downshift again, causing
rapid and excessive engine braking and possibly an accident resulting in death or
injury.
■ To prevent damage to the engine and its components
● Do not let the indicator needle of the tachometer enter the red zone, which indicates
the maximum engine speed.
● The engine may be overheating if the engine coolant temperature gauge is in the red
zone (H). In this case, immediately stop the vehicle in a safe place, and check the
engine after it has cooled completely. (P. 546)
GX460_OM_OM60R27U_(U)
Page 91
Multi-information display
Display contents
The following information will be displayed when a menu icon is selected.
(P. 92)
Some of the information may be displayed automatically depending on the
situation.
Drive information
Select to display various drive data. (P. 93)
Vehicle information display
Select to display the vehicle information. (P. 94)
Driving assist system information
2. Instrument cluster
91
2
Instrument cluster
Select to display the operational status of the following systems:
• Dynamic radar cruise control (P. 254)
• LDA (Lane Departure Alert) (P. 246)
Warning message display
Select to display warning messages and measures to be taken if a malfunction is
detected. (P. 520)
Settings display
Select to change the meter display settings and the operation settings of some
vehicle functions. (P. 95)
GX460_OM_OM60R27U_(U)
Page 92
92
1
2. Instrument cluster
Operating the meter control switches
The multi-information display is operated using the meter control switches.
:Switch menu
: Change displayed con-
tent, scroll up/down the
screen and move the
cursor up/down
2
Press: Enter/Set
Press and hold: Reset
3
Return to the previous screen
4
Press: Displays the screen registered to
When no screen has been registered, the drive information screen will be displayed.
Press and hold: Registers the currently displayed screen to
When the confirmation screen is displayed, select yes to register the screen. If the
selected screen cannot be registered, a registration failure message will be shown.
GX460_OM_OM60R27U_(U)
Page 93
2. Instrument cluster
Drive information
● Current fuel consumption (bar type)
Displays the current rate of fuel consumption.
● Average fuel consumption (after reset*
2
/after start/after refuel)*
Displays the average fuel consumption since the function was reset, the
engine was started, and the vehicle was refueled, respectively.
● Average vehicle speed (after reset*
2
/after start)
Displays the average vehicle speed since the function was reset and the
engine was started, respectively.
● Elapsed time (after reset*
2
/after start)
Displays the elapsed time since the function was reset and the engine was
started, respectively.
● Distance (driving range)
Displays the estimated maximum distance that can be driven with the quantity
of fuel remaining.
• This distance is computed based on your average fuel consumption.
As a result, the actual distance that can be driven may differ from that displayed.
• When only a small amount of fuel is added to the tank, the display may not
be updated.
When refueling, turn the engine switch off. If the vehicle is refueled without
turning the engine switch off, the display may not be updated.
1
*
: Use the displayed average fuel consumption as a reference.
2
*
: The function can be reset by pressing for longer than 1 second when the item to
reset is displayed. If there is more than one item that can be reset, the item selection
screen will appear.
1
93
2
Instrument cluster
GX460_OM_OM60R27U_(U)
Page 94
94
■ Eco Indicator (Eco Driving Indicator Zone Display)
2. Instrument cluster
P. 96
■ Speed
Displays the vehicle speed.
■ Sway warning
Detects the sway of the vehicle within a lane, which is often associated with a
decrease in the driver’s attention level, and displays the decrease in attention
using a bar display.
The shorter the bar length, the more the driver may need to rest.
This display is a part of the LDA (Lane Departure Alert) system. The display is
enabled when the operating conditions of the vehicle sway warning function are
met. (P. 246)
■ Blank screen (display off)
Drive information is not displayed.
Vehicle information
■ Front tire angle
Displays the direction of the front tires.
The tire direction is displayed in 3 stages for both left and right, in accordance with
the angle of the tire.
If a battery terminal is disconnected and reconnected, the display may be disabled
temporarily. After driving the vehicle for a while, the display will be enabled.
■ Tire inflation pressure
Displays inflation pressure of each tire.
The inflation pressure of the spare tire will also be displayed.
GX460_OM_OM60R27U_(U)
Page 95
2. Instrument cluster
Settings display
The settings of the following items can be changed. (P. 576)
For functions that can be enabled or disabled, the function switches between on and
off each time is pressed.
■ LDA (Lane Departure Alert) (P. 246)
■ BSM (Blind Spot Monitor)* (P. 357)
95
■ PCS (Pre-Collision System) (P. 235)
■ Intuitive parking assist* (P. 266)
■ Vehicle settings
● Tire pressure warning system (P. 465)
● Scheduled maintenance* (P. 441)
● Oil maintenance (P. 454)
■ Meter settings
Select to set the following items.
● Language
Select to change the language on the display.
● Units
Select to change the unit for measure.
● Eco Driving Indicator Light
Select to activate/deactivate the Eco Driving Indicator Light.
● Switch settings
You can register 1 screen as the top screen. To register, press and hold
while the desired screen is displayed.
● Initialization
Registered or changed meter settings will be deleted or returned to their
default setting.
*: If equipped
2
Instrument cluster
GX460_OM_OM60R27U_(U)
Page 96
96
■ Eco Driving Indicator
1
2. Instrument cluster
Eco Driving Indicator Light
During Eco-friendly acceleration operation
(Eco driving), the Eco Driving Indicator Light
will turn on. When the acceleration exceeds
Zone of Eco driving, or when the vehicle is
stopped, the light turns off.
2
Eco Driving Indicator Zone Display
Suggests the Zone of Eco driving with current
Eco driving ratio based on acceleration.
3
Eco driving ratio based on acceleration
If the acceleration exceeds Zone of Eco driv-
ing, the right side of Eco Driving Indicator
Zone Display will illuminate.
4
Zone of Eco driving
Eco Driving Indicator will not operate under the
following conditions:
● The shift lever is in any position other than D.
● Vehicles with adaptive variable suspension system: The driving mode is set to sport
mode.
● The vehicle speed is approximately 81 mph (130 km/h) or higher.
■ When disconnecting and reconnecting battery terminals
The drive information other than the current fuel consumption will be reset.
■ Tire inflation pressure
● It may take a few minutes to display the tire inflation pressure after the engine switch is
turned to IGNITION ON mode. It may also take a few minutes to display the tire inflation pressure after inflation pressure has been adjusted.
● “---” may be displayed if the tire information cannot be determined due to unfavorable
radio wave conditions.
● Tire inflation pressure changes with temperature. The displayed values may also be dif-
ferent from the values measured using a tire pressure gauge.
■ When setting up the display
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P.
■ Suspension of the settings display
In the following situations, the settings display using the meter control switches will be
suspended.
● When a warning message appears on the multi-information display
● When the vehicle begins to move
■ Liquid crystal display
Small spots or light spots may appear on the display. This phenomenon is characteristic
of liquid crystal displays, and there is no problem continuing to use the display.
GX460_OM_OM60R27U_(U)
Page 97
2. Instrument cluster
WARNING
NOTICE
■ Caution for use while driving
For safety, avoid operating the meter control switch while driving as much as possible,
and do not look continuously at the multi-information display while driving. Stop the
vehicle and operate the meter control switch. Failure to do so may cause a steering
wheel operation error, resulting in an unexpected accident.
■ Cautions while setting up the display
As the engine needs to be running during setting up the display, ensure that the vehicle
is parked in a place with adequate ventilation. In a closed area such as a garage,
exhaust gases including harmful carbon monoxide (CO) may collect and enter the
vehicle. This may lead to death or a serious health hazard.
■ While setting up the display
To prevent battery discharge, ensure that the engine is running while setting up the display features.
97
2
Instrument cluster
GX460_OM_OM60R27U_(U)
Page 98
98
2. Instrument cluster
Fuel consumption information
Fuel consumption information can be displayed on the multimedia screen or
navigation system screen.
Press the “INFO”/“APPS” button, and then select “Fuel consumption”/“Eco” on
the screen.
1
Resetting the consumption data
2
Fuel consumption in the past 30
minutes
3
Cruising range
Average fuel consumption for the past 30 minutes is divided by color into past
averages and averages attained since the engine switch was last turned to
IGNITION ON mode. Use the displayed average fuel consumption as a reference.
The image is an example only.
■ Resetting the data
The data can be deleted by selecting “Clear”.
■ Cruising range
Displays the estimated maximum distance that can be driven with the quantity of fuel
remaining.
This distance is computed based on your average fuel consumption. As a result, the
actual distance that can be driven may differ from that displayed.
GX460_OM_OM60R27U_(U)
Page 99
Operation of
each component
99
3
3-1. Key information
Keys.................................................. 100
3-2. Opening, closing and
locking the doors
Side doors...................................... 104
Back door.......................................... 111
Glass hatch......................................116
Smart access system with
push-button start........................121
3-3. Adjusting the seats
Front seats...................................... 128
Rear seats....................................... 130
Driving position memory...........141
Head restraints ............................ 146
3-4. Adjusting the steering
wheel and mirrors
Steering wheel ............................. 149
Inside rear view mirror ...............151
Outside rear view mirrors....... 153
3-5. Opening, closing the windows
and moon roof
Power windows ........................... 156
Moon roof...................................... 159
GX460_OM_OM60R27U_(U)
Page 100
100
3-1. Key information
Keys
The keys
The following keys are provided with the vehicle.
1
Electronic keys
• Operating the smart access system
with push-button start (P. 121)
• Operating the wireless remote control function
2
Mechanical keys
3
Key number plate
Wireless remote control
1
Locks the doors (P. 104)
2
Unlocks the doors (P. 104)
3
Opens the windows and moon roof
(P. 104)
4
Opens the glass hatch (P. 116)
5
Sounds the alarm (P. 101)
*
*: These settings must be customized at your Lexus dealer.
GX460_OM_OM60R27U_(U)
Loading...
