FOREWORD
i
Congratulations on your selection of this Lexus. In Lexus vehicles we have invested all our engineering and design resources; all
the know–how we have gained in over 60 years of making automobiles; the highest motivation of our most talented employees; and
our tradition of incessant striving toward ever greater quality.
This Owner’s Manual explains the features of your new Lexus. Please read it and follow the instructions carefully so that you can
enjoy many years of safe motoring.
When it comes to service, remember that your Lexus dealer knows your vehicle very well and is interested in your complete
satisfaction. Your Lexus dealer will provide quality maintenance and any other assistance you may require.
If there is not a Lexus dealer near you, or you need emergency assistance for any reason, please call the following number:
U.S. OWNERS
When traveling in the U.S. mainland or Canada:
Lexus Roadside Assistance 1–800–25–LEXUS (Toll–Free)
(1–800–255–3987)
HAWAII:
Lexus Customer Service Assistance 1–800–25–LEXUS (Toll–Free)
(1–800–255–3987)
CANADIAN OWNERS
When traveling in Canada or the U.S. mainland:
Lexus Roadside Assistance/Customer Service1–800–26–LEXUS (Toll–Free)
(1–800–265–3987)
Please leave this Owner’s Manual in this vehicle at the time of resale. The next owner will need this information also.
All information and specifications in this manual are current at the time of printing. However, because of the Lexus policy
of continual product improvement, we reserve the right to make changes at any time without notice.
Please note that this manual applies to all models and explains all equipment, including options. Therefore, you may find
some explanations for equipment not installed on your vehicle.
IMPORTANT INFORMATION ABOUT YOUR LEXUS
ii
IMPORTANT INFORMATION ABOUT
YOUR LEXUS
Occupant restraint systems
Lexus encourages you and your family to take the time to read
Section 1–6 of this Owner’s Manual carefully. In terms of
helping you understand how you can receive the maximum
benefit of the occupant restraint systems this vehicle provides,
Section 1–6 of this Owner’s Manual is the most important
section for you and your family to read.
Section 1–6 describes the function and operation concerning
seats, seat belts, SRS airbags and child restraint systems of
this vehicle and some potential hazards you should be aware
of. These systems work together along with the overall
structure of this vehicle in order to provide occupant restraint
in the event of a crash. The effect of each system is enhanced
when it is used properly and together with other systems. No
single occupant restraint system can, by itself, provide you or
your family with the equal level of restraint which these
systems can provide when used together. That is why it is
important for you and your family to understand the purpose
and proper use of each of these systems and how they relate
to each other.
The purpose of all occupant restraint systems is to help reduce
the possibility of death or serious injury in the event of a
collision. None of these systems, either individually or
together, can ensure that there is no injury in the event of
collision. However, the more you know about these systems
and how to use them properly, the greater your chances
become of surviving an accident without death or serious
injury.
Seat belts provide the primary restraint to all occupants of the
vehicle, and every occupant of the vehicle should wear seat
belts properly at all times. Children should always be secured
in child restraint systems that are appropriate for their age and
size. SRS (Supplemental Restraint System) airbags are, as
their names i m p l y, designed to work with, and be supplemental
to, seat belts and are not substitutes for them. SRS airbags
can be very effective in reducing the risk of head and chest
injuries by preventing contact of the head and chest with
interior portions of the vehicle.
In order to be effective, the SRS airbags must deploy with
tremendous speed. The rapid deployment of the SRS airbags
makes the SRS airbags thems elves potential sources of
serious injury if an occupant is too close to an airbag, or if an
object or s o m e p a r t o f his or her body has been placed between
the occupant and the airbag at the time of deployment. This
is just one example of how the instructions in Section 1–6 of
this Owner’s Manual will help ensure proper use of the
occupant restraint systems, and increase the safety they can
provide to you and your family in the event of an accident.
Lexus recommends you to read the provisions in Section 1–6
carefully and refer to them as needed during your time of
ownership of this vehicle.
IMPORTANT INFORMATION ABOUT YOUR LEXUS
iii
Event data recorder
Your vehicle has computers that monitor and control certain
aspects of your vehicle. These computers assist in driving and
maintaining optimal vehicle performance. Besides storing
data useful for troubleshooting, there is a system to record data
in a crash or a near car crash event. This is called an Event
Data Recorder (EDR).
The SRS airbag sensor assembly contains the EDR. In a
crash or a near car crash event, this device records some or
all of the following information:
Engine speed
Whether the brake pedal was applied or not
Vehicle speed
To what extent the accelerator pedal was depressed
Position of the transmission selector lever
Whether the driver and front passenger wore the seat belts
or not
Driver’s seat position
Front passenger’s occupant classification
SRS airbag deployment data
SRS airbag system diagnostic data
The information above is intended to be used for the purpose
of improving vehicle safety performance. Unlike general data
recorders, the EDR does not record sound data such as
conversation between passengers.
Lexus will not disclose the data recorded in an EDR to a third
party except when:
An agreement from the vehicle’s owner (or the leasing
company for a leased vehicle) is obtained
Officially requested by the police or other authorities
Used as a defense for Lexus in a law suit
Ordered by the court
However, if necessary Lexus will:
Use the data for research on Lexus vehicle safety
performance
Disclose the data to a third party for research purposes
without disclosing details of the vehicle owner, and only
when it is deemed necessary
Disclose summarized data cleared of vehicle identification
information to a non–Lexus organization for research
purposes
New vehicle warranty
Your new vehicle is covered by the following Lexus limited
warranties:
New vehicle warranty
Emission control systems warranty
Others
For further information, please refer to the “Owner’s Guide”,
“Owner’s Manual Supplement” or “Warranty Booklet”.
IMPORTANT INFORMATION ABOUT YOUR LEXUS
iv
Your responsibility for maintenance
It is the owner’s responsibility to make sure the specified
maintenance is performed. Section 5 of this Owner’s Manual
gives details of these maintenance requirements. Included in
Section 6 is general maintenance. For scheduled
maintenance infor m a t i o n , p l ease refer to the “Owner’s Manual
Supplement / Scheduled Maintenance”.
Important health and safety information about
your Lexus
CAUTION
WARNING: Engine exhaust, some of its constituents,
and a wide variety of automobile components
contain or emit chemicals known to the State of
California to cause cancer and birth defects and
other reproductive harm. In addition, oils, fuels and
fluids contained in vehicles as well as waste
produced by component wear contain or emit
chemicals known to the State of California to cause
cancer and birth defects or other reproductive harm.
Battery posts, terminals and related accessories
contain lead and lead compounds. Wash your hands
after handling. Used engine oil contains chemicals
that have caused cancer in laboratory animals.
Always prot e c t your skin by washing thoroughly with
soap and water.
Accessories, spare parts and modification of
your Lexus
A wide variety of non–genuine spare parts and accessories for
Lexus vehicles are currently available in the market. You
should know that Toyota does not warrant these products and
is not responsible for their performance, repair, or
replacement, or for any damage they may cause to, or adverse
effect they may have on, your Lexus vehicle.
IMPORTANT INFORMATION ABOUT YOUR LEXUS
v
This vehicle should not be modified with non–genuine Lexus
products. Modification with non–genuine Lexus products
could af fect its performance, safety or durability, and may even
violate governmental regulations. In addition, damage or
performance problems resulting from the modification may not
be covered under warranty.
Spark ignition system of your Lexus
The spark ignition system in your Lexus meets all
requirements of the Canadian Interference–Causing
Equipment Standard.
Installation of a mobile two–way radio system
As the installation of a mobile two–way radio system in your
vehicle could affect electronic systems such as the multiport
fuel injection system/sequential multiport fuel injection system,
cruise control system, anti–lock brake system, SRS airbag
system and seat belt pretensioner system, be sure to check
with your Lexus dealer for precautionary measures or special
instructions regarding installation.
Tires and loading on your Lexus
Underinflated or overinflated tire pressure and the
excess load may result in the deterioration of steering
ability and braking ability, leading to an accident. Check
the tire inflation pressure periodically and be sure to
keep the load limits given in this Owner’s Manual. For
details about tire inflation pressure and load limits, see
page 292 and 214.
Scrapping of your Lexus
The SRS airbag and seat belt pretensioner devices in your
Lexus contain explosive chemicals. If the vehicle is scrapped
with the airbags and seat belt pretensioners left as they are,
this may cause an accident such as fire. Be sure to have the
systems of the SRS airbag and seat belt pretensioner removed
and disposed of by a qualified service shop or by your Lexus
dealer before you scrap your vehicle.
HOW TO USE THIS MANUAL
vi
HOW TO USE THIS MANUAL
The contents of this manual are explained briefly on this
page to help you make the best use of the manual. Please
read this page and the rest of the Owner’s Manual
carefully to make sure you fully understand the operation
of your vehicle.
This will help you enjoy safe and comfortable driving.
TABLE OF CONTENTS
The table of contents and the pictorial index provide easy
reference to the appropriate pages.
BASIC OPERATION – QUICK REFERENCE
Operation of basic equipment is briefly explained in an easily
understandable way for quick reference.
SECTION 1 – INSTRUMENTS AND CONTROLS
The vehicle’s equipment is divided into the 7 groups listed
below. Use of the equipment is explained, including any points
you should pay particular attention to.
1. Keys and doors
2. Switches
3. Gauges, meters and service reminder indicators
4. Interior equipment
5. Exterior equipment
6. Occupant restraint systems
7. Steering wheel and mirrors
SECTION 2 – AIR CONDITIONING AND AUDIO
The features of the vehicle’s air conditioning and audio are
explained in detail. Be sure to read this section so that you can
make full use of them.
SECTION 3 – STARTING AND DRIVING
Starting the engine, driving, stopping, operation of features
affecting vehicle handling, hints on vehicle safety and safe
driving techniques are all explained. Please read everything
in this section, and remember – drive safely!
SECTION 4 – IN CASE OF AN EMERGENCY
This section explains what to do in the event of an urgent
situation such as the engine not starting or getting a flat tire,
etc. If such a problem occurs, check the contents of this
Owner’s Manual and follow the instructions given.
SECTION 5 – MAINTENANCE
This section explains the importance of regular maintenance.
Regular and periodic inspection and maintenance of your
Lexus will help to keep your vehicle in its best condition.
SECTION 6 – SERVICE PROCEDURES AND
SPECIFICATIONS
Simple maintenance procedure and service data are provided
here for your reference should you wish to perform inspection
and maintenance yourself.
HOW TO USE THIS MANUAL
vii
INDEX
The page number is listed for each item in the Owner’s Manual
so that you can rapidly find the item and page you are
searching for.
GAS STATION INFORMATION
The information you need to know for appropriate servicing at
the gas station is provided here.
QUICK INDEX
This is designed so that you can quickly find the needed
information when an urgent situation arises.
Safety symbol
In this manual, you will also see a circle with a slash through
it. This means ”Do not”, ”Do not do this”, or ”Do not let this
happen”.
Safety and vehicle damage warnings
In this manual you will see CAUTION and NOTICE warnings.
These are used in the following ways:
CAUTION
This is a warning against anything which may cause
injury to people if the warning is ignored. You are
informed about what you must or must not do in order
to reduce the risk of injury to yourself and others.
NOTICE
This is a warning against anything which may cause
damage to the vehicle or its equipment if the warning is
ignored. Y ou are informed about what you must or must
not do in order to avoid or reduce the risk of damage to
your Lexus and its equipment.
Your Lexus Owner’s Manual provides you with a
considerable amount of information. To use this
information most effectively, please take the time to
familiarize yourself with the contents and use of the
manual.
HOW TO USE THIS MANUAL
viii
cm–1
You should know as much about the quality and
importance of proper maintenance of your new
vehicle as the people who built it.
The Lexus authorized Repair Manual tells you
how to maintain your vehicle and enables you to
correctly perform your own maintenance.
The best way to keep your new vehicle in top running
order is to maintain it properly from the moment you
drive it off the showroom floor.
The Lexus authorized Repair Manual is packed with
literally everything you need to know to perform your
own maintenance in virtually every area of your new
vehicle.
cm–2
Maintenance procedures for the engine, chassis,
body, electrical system, and more, are clearly
explained and illustrated.
Periodic maintenance and tune–up
Periodic maintenance and tune–up helps to prevent small
problems from growing into larger ones later on. The repair
manual outlines exactly what maintenance is required and
clearly explains how to do the work yourself step–by–step.
Areas covered include such things as spark plug replacement,
valve clearance adjustment and engine oil and filter
replacement.
Where to obtain the
Repair Manual
The repair manual for GS430, GS300 may be purchased from
any Lexus dealer or call the Material Distribution Center. To
purchase the repair manual, please contact your Lexus dealer
or the Material Distribution Center toll–free at
1–800–622–2033.
GAS STATION INFORMATION
Fuel selection:
Select premium unleaded gasoline with an Octane Rating
of 91 (Research Octane Number 96) or higher for optimum
engine performance. However, if such premium type
cannot be obtained, you may temporarily use unleaded
gasoline with an Octane Rating as low as 87 (Research
Octane Number 91).
Fuel tank capacity:
75 L (19.8 gal., 16.5 lmp.gal.)
Engine oil:
“Toyota Genuine Motor Oil” or equivalent
Oil grade: API grade SL “Energy–Conserving” or ILSAC
multigrade engine oil.
Recommend oil viscosity – SAE 5W–30 if normal
temperatures are below 38C (100F)
Oil capacity: L (qt., lmp.qt.)
Drain and refill GS430 GS300
with filter 5.2 (5.5, 4.6) 5.4 (5.7, 4.8)
without filter 4.9 (5.2, 4.3) 5.1 (5.4, 4.5)
See page 270 for detailed information.
Engine coolant:
Capacity: GS430: 9.0 L (9.5 qt., 7.9 lmp.qt.)
GS300: 7.7 L (8.1 qt., 6.8 lmp.qt.)
Coolant type – ”Toyota Super Long Life Coolant” or similar
high quality ethylene glycol based non–silicate, non–amine,
non–nitrite, and non–borate coolant with long–life hybrid
organic acid technology (Coolant with long–life hybrid
organic acid technology is a combination of low phosphates
and organic acids.)
Do not use plain water alone.
For checking the engine coolant, see page 274.
Automatic transmission:
Fluid type – “Toyota Genuine ATF Type T–IV”
See page 280 or 284 for detailed information.
Tire information:
See page 292 through 311 for detailed information.
Tire inflation pressure:
Tire size: GS430 – 225/55R16 94V or 235/45ZR17
GS300 – P215/60R16 94V or 225/55R16 94V
Tire inflation pressure: cold tires
kPa (kgf/cm
2
or bar, psi)
Tire size Front Rear
P215/60R16 94V 210 (2.1, 30) 210 (2.1, 30)
225/55R16 94V 220 (2.2, 32) 220 (2.2, 32)
235/45ZR17 230 (2.3, 33) 230 (2.3, 33)
For sustained high speeds above 160 km/h (100 mph), in
countries where such speeds are permitted by law, add the
tire inflation pressure given below to the front tires and rear
tires, but never exceed the maximum cold tire inflation
pressure molded on the tire sidewall.
P215/60R16 94V 90kPa (0.9 kgf/cm
2
or bar, 13 psi)
225/55R16 94V 80kPa (0.8 kgf/cm
2
or bar, 12 psi)
235/45ZR17 70kPa (0.7 kgf/cm
2
or bar, 10 psi)
PG100
PICTORIAL INDEX
x
INSTRUMENT PANEL (Vehicles with navigation system)
For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xi
Page
1
Door lock switch and power window
switches 20, 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
Driving position memory switch 128. . . . . . . . . . . . . .
3
Instrument panel light control 52. . . . . . . . . . . . . . . . .
4
Side vents 152. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
Security indicator light 21. . . . . . . . . . . . . . . . . . . . . . .
6
Coin box (Vehicles sold in U.S.A.) 64. . . . . . . . . . . . .
Headlight cleaner switch
(Vehicles sold in Canada) 32. . . . . . . . . . . . . . . . . . . . .
7
Headlight, turn signal and fog light
switches 26, 28, 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
Wiper and washer switches 30. . . . . . . . . . . . . . . . . . .
9
Automatic air conditioning controls 142. . . . . . . . . .
10
Emergency flasher switch 37. . . . . . . . . . . . . . . . . . . .
11
Clock 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
12
Front passenger’s seat belt reminder light 45. . . . .
13
Center vents 152. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
14
Navigation system including air conditioning
controls and audio system . . . . . . . . . . . . . . . . . . . . . .
(See “Navigation System Owner’s Manual”). . . . . . .
Page
15
Audio system 156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
16
Glove box/CD automatic changer 59/168. . . . . . . . . .
17
Ashtray 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18
Cup holders 63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19
Vehicle stability control system
OFF switch 200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20
Seat heater switches 37. . . . . . . . . . . . . . . . . . . . . . . . .
21
Driving pattern selector switch 187. . . . . . . . . . . . . . .
22
Automatic transmission selector
lever 187. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23
Ignition switch 184. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
24
Cruise control switch 196. . . . . . . . . . . . . . . . . . . . . . .
25
Steering pad switch 173. . . . . . . . . . . . . . . . . . . . . . . . .
26
Parking brake release lever 185. . . . . . . . . . . . . . . . . .
27
Hood lock release lever 68. . . . . . . . . . . . . . . . . . . . . .
28
Trunk lid opener 69. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29
Parking brake 185. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
30
Fuel filler door opener 71. . . . . . . . . . . . . . . . . . . . . . . .
31
Power rear view mirror control switches 134. . . . . .
PG005g
PICTORIAL INDEX
xii
INSTRUMENT PANEL (Vehicles without navigation system)
For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xiii
Page
1
Door lock switch and power window
switches 20, 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
Driving position memory switch 128. . . . . . . . . . . . . .
3
Instrument panel light control 52. . . . . . . . . . . . . . . . .
4
Side vents 152. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
Security indicator light 21. . . . . . . . . . . . . . . . . . . . . . .
6
Coin box (Vehicles sold in U.S.A.) 64. . . . . . . . . . . . .
Headlight cleaner switch
(Vehicles sold in Canada) 32. . . . . . . . . . . . . . . . . . . . .
7
Headlight, turn signal and fog light
switches 26, 28, 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
Wiper and washer switches 30. . . . . . . . . . . . . . . . . . .
9
Emergency flasher switch 37. . . . . . . . . . . . . . . . . . . .
10
Clock 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11
Front passenger’s seat belt reminder light 45. . . . .
12
Center vents 152. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
13
Automatic air conditioning controls 142. . . . . . . . . .
Page
14
Audio system 156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15
Glove box/CD automatic changer 59/168. . . . . . . . . .
16
Ashtray 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
17
Cup holders 63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
18
Vehicle stability control system
OFF switch 200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
19
Seat heater switches 37. . . . . . . . . . . . . . . . . . . . . . . . .
20
Driving pattern selector switch 187. . . . . . . . . . . . . . .
21
Automatic transmission selector
lever 187. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22
Ignition switch 184. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23
Cruise control switch 196. . . . . . . . . . . . . . . . . . . . . . .
24
Steering pad switch 173. . . . . . . . . . . . . . . . . . . . . . . . .
25
Parking brake release lever 185. . . . . . . . . . . . . . . . . .
26
Hood lock release lever 68. . . . . . . . . . . . . . . . . . . . . .
27
Trunk lid opener 69. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28
Parking brake 185. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
29
Fuel filler door opener 71. . . . . . . . . . . . . . . . . . . . . . . .
30
Power rear view mirror control switches 134. . . . . .
PG006b
PICTORIAL INDEX
xiv
INSTRUMENT CLUSTER (GS430 sold in U. S. A.)
For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xv
Page
1
Tachometer 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
Turn signal indicator light 28. . . . . . . . . . . . . . . . . . . .
3
Odometer and trip meter 42. . . . . . . . . . . . . . . . . . . . .
4
Engine coolant temperature gauge 40. . . . . . . . . . . .
5
Automatic transmission indicator lights 187. . . . . .
6
Fuel gauge 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
ODO/TRIP, RESET button 42. . . . . . . . . . . . . . . . . . . . .
8
Low fuel level warning light 50. . . . . . . . . . . . . . . . . . .
9
Headlight indicator light 26. . . . . . . . . . . . . . . . . . . . . .
10
Headlight high beam indicator light 28. . . . . . . . . . .
11
Slip indicator light 199, 200. . . . . . . . . . . . . . . . . . . . . .
12
Low washer fluid warning light 50. . . . . . . . . . . . . . . .
13
Brake system warning light 44. . . . . . . . . . . . . . . . . . .
14
Low engine oil pressure warning light 47. . . . . . . . .
15
Discharge warning light 46. . . . . . . . . . . . . . . . . . . . . .
Page
16
Driver’s seat belt reminder light 45. . . . . . . . . . . . . . .
17
SRS warning light 46. . . . . . . . . . . . . . . . . . . . . . . . . . . .
18
Open door warning light 50. . . . . . . . . . . . . . . . . . . . . .
19
Vehicle stability control system
OFF indicator light 200. . . . . . . . . . . . . . . . . . . . . . . . . .
20
Anti–lock brake system warning light 49. . . . . . . . . .
21
Vehicle stability control system
warning light 201. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22
Snow mode indicator light 195. . . . . . . . . . . . . . . . . . .
23
Power mode indicator light 195. . . . . . . . . . . . . . . . . .
24
Cruise control indicator light 196. . . . . . . . . . . . . . . .
25
Rear light failure warning light 50. . . . . . . . . . . . . . . .
26
Automatic headlight leveling system
warning light 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27
Low engine oil level warning light 47. . . . . . . . . . . . .
28
Malfunction indicator lamp 48. . . . . . . . . . . . . . . . . . .
PG016e
PICTORIAL INDEX
xvi
INSTRUMENT CLUSTER (GS300 sold in U. S. A.)
For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xvii
Page
1
Tachometer 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
Turn signal indicator light 28. . . . . . . . . . . . . . . . . . . .
3
Shift position indicator for manual control 191. . . .
4
Odometer and trip meter 42. . . . . . . . . . . . . . . . . . . . .
5
Engine coolant temperature gauge 40. . . . . . . . . . . .
6
Automatic transmission indicator lights 187. . . . . .
7
Fuel gauge 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
ODO/TRIP, RESET button 42. . . . . . . . . . . . . . . . . . . . .
9
Low fuel level warning light 50. . . . . . . . . . . . . . . . . . .
10
Headlight indicator light 26. . . . . . . . . . . . . . . . . . . . . .
11
Headlight high beam indicator light 28. . . . . . . . . . .
12
Slip indicator light 199, 200. . . . . . . . . . . . . . . . . . . . . .
13
Low washer fluid warning light 50. . . . . . . . . . . . . . . .
14
Brake system warning light 44. . . . . . . . . . . . . . . . . . .
15
Low engine oil pressure warning light 47. . . . . . . . .
Page
16
Discharge warning light 46. . . . . . . . . . . . . . . . . . . . . .
17
Driver’s seat belt reminder light 45. . . . . . . . . . . . . . .
18
SRS warning light 46. . . . . . . . . . . . . . . . . . . . . . . . . . . .
19
Open door warning light 50. . . . . . . . . . . . . . . . . . . . . .
20
Vehicle stability control system
OFF indicator light 200. . . . . . . . . . . . . . . . . . . . . . . . . .
21
Anti–lock brake system warning light 49. . . . . . . . . .
22
Vehicle stability control system
warning light 201. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23
Snow mode indicator light 195. . . . . . . . . . . . . . . . . . .
24
Power mode indicator light 195. . . . . . . . . . . . . . . . . .
25
Cruise control indicator light 196. . . . . . . . . . . . . . . .
26
Rear light failure warning light 50. . . . . . . . . . . . . . . .
27
Automatic headlight leveling system
warning light 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28
Low engine oil level warning light 47. . . . . . . . . . . . .
29
Malfunction indicator lamp 48. . . . . . . . . . . . . . . . . . .
PG007f
PICTORIAL INDEX
xviii
INSTRUMENT CLUSTER (GS430 sold in Canada)
For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xix
Page
1
Tachometer 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
Turn signal indicator light 28. . . . . . . . . . . . . . . . . . . .
3
Odometer and trip meter 42. . . . . . . . . . . . . . . . . . . . .
4
Engine coolant temperature gauge 40. . . . . . . . . . . .
5
Automatic transmission indicator lights 187. . . . . .
6
Fuel gauge 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7
ODO/TRIP, RESET button 42. . . . . . . . . . . . . . . . . . . . .
8
Low fuel level warning light 50. . . . . . . . . . . . . . . . . . .
9
Tail light indicator light 26. . . . . . . . . . . . . . . . . . . . . . .
10
Headlight high beam indicator light 28. . . . . . . . . . .
11
Slip indicator light 199, 200. . . . . . . . . . . . . . . . . . . . . .
12
Low washer fluid warning light 50. . . . . . . . . . . . . . . .
13
Brake system warning light 44. . . . . . . . . . . . . . . . . . .
14
Low engine oil pressure warning light 47. . . . . . . . .
15
Discharge warning light 46. . . . . . . . . . . . . . . . . . . . . .
Page
16
Driver’s seat belt reminder light 45. . . . . . . . . . . . . . .
17
SRS warning light 46. . . . . . . . . . . . . . . . . . . . . . . . . . . .
18
Open door warning light 50. . . . . . . . . . . . . . . . . . . . . .
19
Vehicle stability control system OFF
indicator light 200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
20
Anti–lock brake system warning light 49. . . . . . . . . .
21
Vehicle stability control system
warning light 201. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
22
Snow mode indicator light 195. . . . . . . . . . . . . . . . . . .
23
Power mode indicator light 195. . . . . . . . . . . . . . . . . .
24
Cruise control indicator light 196. . . . . . . . . . . . . . . .
25
Rear light failure warning light 50. . . . . . . . . . . . . . . .
26
Automatic headlight leveling system
warning light 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
27
Low engine oil level warning light 47. . . . . . . . . . . . .
28
Malfunction indicator lamp 48. . . . . . . . . . . . . . . . . . .
PG017g
PICTORIAL INDEX
xx
INSTRUMENT CLUSTER (GS300 sold in Canada)
For detailed information, refer to the description given in each Section.
PICTORIAL INDEX
xxi
Page
1
Tachometer 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2
Turn signal indicator light 28. . . . . . . . . . . . . . . . . . . .
3
Shift position indicator for manual control 191. . . .
4
Odometer and trip meter 42. . . . . . . . . . . . . . . . . . . . .
5
Engine coolant temperature gauge 40. . . . . . . . . . . .
6
Automatic transmission indicator lights 187. . . . . .
7
Fuel gauge 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8
ODO/TRIP, RESET button 42. . . . . . . . . . . . . . . . . . . . .
9
Low fuel level warning light 50. . . . . . . . . . . . . . . . . . .
10
Tail light indicator light 26. . . . . . . . . . . . . . . . . . . . . . .
11
Headlight high beam indicator light 28. . . . . . . . . . .
12
Slip indicator light 199, 200. . . . . . . . . . . . . . . . . . . . . .
13
Low washer fluid warning light 50. . . . . . . . . . . . . . . .
14
Brake system warning light 44. . . . . . . . . . . . . . . . . . .
15
Low engine oil pressure warning light 47. . . . . . . . .
Page
16
Discharge warning light 46. . . . . . . . . . . . . . . . . . . . . .
17
Driver’s seat belt reminder light 45. . . . . . . . . . . . . . .
18
SRS warning light 46. . . . . . . . . . . . . . . . . . . . . . . . . . . .
19
Open door warning light 50. . . . . . . . . . . . . . . . . . . . . .
20
Vehicle stability control system OFF
indicator light 200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
21
Anti–lock brake system warning light 49. . . . . . . . . .
22
Vehicle stability control system
warning light 201. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
23
Snow mode indicator light 195. . . . . . . . . . . . . . . . . . .
24
Power mode indicator light 195. . . . . . . . . . . . . . . . . .
25
Cruise control indicator light 196. . . . . . . . . . . . . . . .
26
Rear light failure warning light 50. . . . . . . . . . . . . . . .
27
Automatic headlight leveling system
warning light 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
28
Low engine oil level warning light 47. . . . . . . . . . . . .
29
Malfunction indicator lamp 48. . . . . . . . . . . . . . . . . . .
PG003b
PICTORIAL INDEX
xxii
SEAT AND STEERING WHEEL
Page
1
Tilt and telescopic steering
adjustment switch 132. . . . . . . . . . . . .
2
Seat position, seat cushion angle
and height control switch 79, 80. . . .
3
Seatback angle control switch 79. . .
4
Lumbar support control switch 80. .
For detailed information, refer to the
description given in each Section.
PG020f
PICTORIAL INDEX
xxiii
EXTERIOR VIEW
Page
1
Rear window defogger 33. . . . . . . . . .
2
Trunk lid 69. . . . . . . . . . . . . . . . . . . . . . .
3
Moon roof 72. . . . . . . . . . . . . . . . . . . . .
4
Wiper and washer 30, 325. . . . . . . . . .
5
Fuel filler door 71. . . . . . . . . . . . . . . . .
6
Outside rear view mirror 133. . . . . . .
7
Door 19. . . . . . . . . . . . . . . . . . . . . . . . . .
8
Tire and wheel 292. . . . . . . . . . . . . . . .
9
Headlights 26, 331. . . . . . . . . . . . . . . . .
10
Hood 68. . . . . . . . . . . . . . . . . . . . . . . . . .
For detailed information, refer to the
description given in each Section.
PICTORIAL INDEX
xxiv
BASIC OPERATION
1
QUICK REFERENCE
Driver’s seat 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering wheel 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission (GS430) 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic transmission (GS300) 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight and turn signal switches 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiper switch 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
QUICK REFERENCE
2
1. DRIVER’S SEAT
BG001–3
Seat adjustment
Seat
position
Seat
cushion
angle
Seat cushion
height
Head restraint
height
Seatback
angle
Lumbar
support
Head restraint
angle
2. STEERING WHEEL
TILT STEERING WHEEL
BG002c
To tilt the steering wheel up or down to the desired angle,
push the control switch in the required direction and
release the button when the steering wheel reaches the
desired angle.
TELESCOPIC STEERING WHEEL
BG003c
To move the steering wheel to the desired position, push
the control switch away from you or pull it toward you until
the steering wheel reaches the desired position.
BG007b
BG018a
Shift while pressing the brake pedal. (Ignition
switch must be in the ”ON” position.)
QUICK REFERENCE
3
3. AUTOMATIC TRANSMISSION(GS430)
OPERATION OF SELECTOR LEVER
SELECTOR LEVER POSITION
P: Parking, engine starting and key removal
R: Reverse
N: Neutral
D: Normal driving (with overdrive on)
4: Engine braking*
3, 2: Stronger engine braking
L: Maximum engine braking
*When the cruise control is being used, even if you downshift from ”D” to “4”, engine braking will not be enabled because
the cruise control is not cancelled. For the operation to decrease the vehicle speed, see page 198.
BG020b
BG023
Shift while pressing the brake pedal. (Ignition
switch must be in the ”ON” position.)
QUICK REFERENCE
4
AUTOMATIC TRANSMISSION(GS300)
OPERATION OF SELECTOR LEVER
SELECTOR LEVER POSITION
P: Parking, engine starting and key removal
R: Reverse
N: Neutral
D: Normal driving (with overdrive on)
M: Manual shifting up or down shifting*
3, 2: Stronger engine braking
L: Maximum engine braking
*When the cruise control is being used, even if you downshift from ”D” to “4”, engine braking will not be enabled because
the cruise control is not cancelled. For the operation to decrease the vehicle speed, see page 198.
00L013
00L013
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights also turn on.
Automatic light control
Parking, tail, license plate,
side marker and instrument
panel lights turn on.
Headlights also turn on
at full intensity.
Automatic light control
00L015
00L014
Right or left turn
Lane change
(Right or left)
High beam
Headlight flasher
QUICK REFERENCE
5
4. HEADLIGHT AND TURN SIGNAL
SWITCHES
HEADLIGHT SWITCH
With the ignition OFF
With the engine started and parking brake
released
HEADLIGHT DIMMER SWITCH
TURN SIGNAL SWITCH
00L016
QUICK REFERENCE
6
5. WIPER SWITCH
Mist wiper operation
Intermittent operation
Low speed operation
High speed operation
Washer on
SECTION 1 –
1
7
INSTRUMENTS AND CONTROLS
Keys and doors
Keys 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine immobilizer system 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wireless remote control 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Doors 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Theft deterrent system 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
KEYS AND DOORS
8
KEYS
11g045a
1
Master keys (black) – These keys work in every lock.
For your Lexus dealer to make a new key with a
built–in transponder chip, your dealer will need one
of them.
2
Sub key (gray) – This key will not open the trunk,
trunk main switch and the glove box. For your Lexus
dealer to make a new key with built–in transponder
chip, your dealer will need it.
3
Key number plate – Keep the plate in a safe place
such as your wallet, not in the vehicle.
A transponder chip for the engine immobilizer system has
been placed in the head of the master and sub keys. These
chips are required for the system to function correctly, so be
careful not to lose these keys. If you make your own duplicate
key, you will not be able to cancel the system or start the
engine.
To protect items locked in the trunk or glove box when using
valet parking, leave the sub key with the attendant.
Since the doors and trunk lid can be locked without a key , you
should always carry a spare master key in case you
accidentally lock your keys inside the vehicle.
If you should lose your keys or if you need additional keys,
duplicates can be made by a Lexus dealer using the key
number.
We recommend writing down the key number and storing it in
a safe place.
KEYS AND DOORS
9
Flat key
11g039c
As a transponder chip is built in its key case, you can start
the engine with this key.
The flat key works in every lock.
A transponder chip for the engine immobilizer system has
been placed in the key case of the flat key. This chip is required
for the system to function correctly, so be careful not to lose this
key. If you make your own duplicate key, you will not be able
to cancel the system or start the engine.
Insert your key plate in its key case as shown. We recommend
that you always carry this with you for emergency use. Do not
leave it in your vehicle.
Starting the engine using a flat key
11g036c
1. Remove the key plate from the key case.
2. Insert the key plate into the ignition switch. The indicator
light keeps flashing.
3. Bring the key case closer to the ignition switch within 10
seconds as indicated by the arrow head. The indicator light
goes out. This means the engine immobilizer system is
automatically canceled. (For details, see “Engine immobilizer
system” on page 1 1.) You can put the key case away then. Y ou
cannot cancel the engine immobilizer system if 10 seconds
have passed after you inserted the key plate. You need to
remove the key plate from the ignition switch and try it again
from the step 2.
4. Start the engine within 60 seconds after the security
indicator light goes out. You cannot start the engine if 60
seconds have passed after the security indicator went off. You
need to remove the key plate from the ignition switch and try
it again from the step 2.
KEYS AND DOORS
10
NOTICE
Do not let the key case become bent as the key plate
may fall out or become bent also.
The flat key is designed for emergency use only. So
do not use it regularly instead of other master keys.
11L021-2
When using a key containing a transponder chip,
observe the following precautions:
When starting the engine, do not use the key with a
key ring resting on the key grip and do not press the
key ring against the key grip. Doing so may prevent
the engine from starting, or may cause the engine to
stop soon after it starts.
11R055
When starting the engine, do not use the key in
proximity with other transponder keys (including the
flat key and keys of other vehicles), and do not press
other key plates against the key grip. Doing so may
prevent the engine from starting, or may cause the
engine to stop soon after it starts. If this happens,
remove the key once and then insert it again after
removing other transponder keys (including the flat
key and keys of other vehicles) from the ring or while
gripping or covering them with your hand to start the
engine.
KEYS AND DOORS
11
11G035c
Do not bend the key grip or flat key.
Do not cover the key grip or flat key with any material
that cuts off electromagnetic waves.
Do not knock the key or flat key hard against other
objects.
Do not leave the key or flat key exposed to high
temperatures for a long period, such as on the
dashboard or hood under direct sunlight.
Do not put the key or flat key in water or wash it in an
ultrasonic washer.
Do not use the key or flat key with electromagnetic
materials.
ENGINE IMMOBILIZER SYSTEM
w11L016
The engine immobilizer system is a theft prevention
system. When you insert the key in the ignition switch, the
transponder chip in the key’s head transmits an electronic
code to the vehicle. The engine will start only when the
electronic code in the chip corresponds to the registered
ID code for the vehicle.
The system is automatically set when the key is removed from
the ignition switch. At this time, the security indicator light
flashes. When you insert the key in the ignition switch, the
security indicator light goes out and the system is canceled
automatically, which enables the engine to start.
The transponder chip of the flat key is in its key case. You can
cancel the engine immobilizer system using the flat key . (For
details, see “Flat key” on page 9.)
KEYS AND DOORS
12
For your Lexus dealer to make you a new key with a built–in
transponder chip, your dealer will need your key number and
master key or the flat key. However, there is a limit to the
number of additional keys your Lexus dealer can make for you.
If you make your own duplicate key, you will not be able
to cancel the system or start the engine.
For vehicles sold in U.S.A.
FCC ID: MOZ RI–4ATY
MADE IN JAPAN
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
CAUTION
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
For vehicles sold in Canada
This device complies with RSS–210 of Industry
Canada. Operation is subject to the following two
conditions:
(1) This device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation of the
device.
KEYS AND DOORS
13
WIRELESS REMOTE CONTROL*
11L027b
1
Locking the doors and sounding an alarm
2
Unlocking the doors and opening the windows and
moon roof
3
Indicator light
4
Unlocking the trunk lid
NOTE: *This feature can be deactivated as vehicle theft
deterrent measure in case of the loss of the wireless remote
control key. Ask your Lexus dealer for details.
When you operate any button on the key, push it slowly and
surely. At this time, the indicator light on the key grip flashes
once.
The operational range of the wireless remote control is
approximately 1 meter (3 ft.). The effective range may vary
with different conditions. To activate the wireless remote
control without fail, do it approximately 1 meter (3 ft.) from your
Lexus.
In the following cases, the battery in the key may be
discharged. If this is the case, replace it using a special
screwdriver.
The remote control does not work.
The operational range of wireless remote control becomes
extremely short.
The indicator light on the key is dimmed or does not come
on.
For the replacement of the battery, see ”Replacing the battery”
on page 17. You can also have the battery of the key replaced
by your Lexus dealer.
If you lose the wireless key, contact your Lexus dealer as soon
as possible to avoid the possibility of theft, or an accident.
Y ou can use up to 4 wireless remote control keys for the same
vehicle. Contact your Lexus dealer for detailed information.
The wireless remote control key is an electronic
component. Observe the following instructions in order
not to cause damage to the key.
Do not leave the wireless remote control key in places
where the temperature becomes high such as on the
dashboard.
Do not disassemble it.
Avoid knocking it hard against other objects or dropping it.
Avoid putting it in water.
KEYS AND DOORS
14
Locking/Unlocking the doors
When you push the ”LOCK” button on the key briefly, all
the doors can be locked from outside the vehicle.
When they are locked securely, the emergency flashers will
flash and one beep will sound.* However, when you push the
”LOCK” button with any door not closed securely, the buzzer
sounds for 10 seconds.** To stop the buzzer, close all the
doors securely or push the ”UNLOCK” button. If the key is in
the ignition switch, locking cannot be done.
Make sure all the doors are locked when you leave the vehicle.
Push the ”LOCK” button once again. If they were already
locked, the turn signal lights will flash.***
NOTE: *The emer g e ncy flashers can be set not to flash and
beep volume can be changed. **The buzzer can be set not
to sound if a door is not closed securely. ***The turn signal
lights can be set not to flash. Ask your Lexus dealer for
details.
NOTICE
Do not push the ”LOCK” button any longer than 2 to 3
seconds. Pushing the button longer activates an alarm.
For details, see page 15.
When you push the ”UNLOCK” button, the driver’s door
is unlocked. Pushing that button once again within 3
seconds from the first push, all other doors are also
unlocked.*
NOTE: *The 2–step unlocking function can be changed.
Ask your Lexus dealer for details.
At this time, the emergency flashers will flash twice and two
beeps will sound.* Together with the activation of unlocking,
the interior light comes on for 15 seconds if the interior light
switch is in ”DOOR” position.** However, this function does
not work when the ignition key is in the ”ON” position. For
further information, see ”Interior lights” on page 55.
You have 30 seconds to open a door after using the wireless
remote unlock feature.*** If a door is not opened by then, all
the doors will be automatically locked again.
Even if the ”LOCK” or ”UNLOCK” button is kept pressed in, the
locking or unlocking operation is not repeated. Release the
button and then push again.
NOTE: *The emergency flashers can be set not to flash and
beep volume can be changed. **The interior light can be set
not to come on or the duration of lighting can be changed.
***The time before automatic re–locking can be changed.
Ask your Lexus dealer for details.
KEYS AND DOORS
15
Unlocking the trunk lid
11G013d
When you keep the button pushed for about 1 second, you
can unlock the trunk lid.* One beep sounds.
This function does not work when the ignition key is in the ”ON”
position.
NOTE: *The operation method can be changed. Ask your
Lexus dealer for details.
Sounding an alarm*
11G002b
When you push the ”PANIC” button for about 2 to 3
seconds, an alarm sounds to deter any person trying to
break into or damage your vehicle.
If you want to stop the alarm, push any button.
This function does not work when the ignition key is in the ”ON”
position.
NOTE: *The alarm can be set not to sound. Ask your Lexus
dealer for details.
KEYS AND DOORS
16
Operating the windows and moon roof
The windows and moon roof can be operated using a
wireless key from outside the vehicle.*
NOTE: *The windows can be deactivated. The moon roof
can be set to slide open, tilt up or deactivated. Ask your
Lexus dealer for details.
11G048a
Push the ”UNLOCK” button until the windows and moon roof
start to move. When you release the button, the windows and
moon roof stop operating.
This function will work even with the window lock switch
pressed in.
For vehicles sold in U.S.A.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
NOTICE:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
radio communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can
be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit differ-
ent from that to which the receiver is connected.
KEYS AND DOORS
17
Consult the dealer or an experienced radio / TV techni-
cian for help.
FCC WARNING:
Changes or modifications not expressly approved
by the party responsible for compliance could void
the user’s authority to operate the equipment.
For vehicles sold in Canada
Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this
device must accept any interference, including
interference that may cause undesired operation of the
device.
Replacing the battery
When you replace the battery, prepare a lithium battery
CR1616 or equivalent and a special screwdriver.
CAUTION
Special care should be taken to prevent small children
from swallowing the removed battery or components.
NOTICE
When replacing the battery, be careful not to lose the
components, screws and O–ring.
Replace only with the same or equivalent type
recommended by a Lexus dealer.
Dispose of used batteries according to the local laws.
11L028–1
1. Remove the screw, and then the cover while pushing it in the
arrow direction.
KEYS AND DOORS
18
11L029–1
2. Remove the module from the key frame.
11L030–1
3. Remove the 2 screws to take out the lid of the module.
4. Take out the discharged battery and put in a new battery
with the positive side up.
NOTICE
Make sure the positive side and negative side of the
battery are faced correctly.
Do not replace the battery with wet hands. Water may
cause unexpected rust.
Do not touch or move any components inside the
transmitter, or it may interfere with proper operation.
Be careful not to bend the electrode when inserting
the battery and that dust or oils do not adhere to the
inside of the module.
Take care not to lose the screws and O–ring.
5. Install the lid with the 2 screws.
NOTICE
Take care not to damage or bend the O–ring when
installing.
6. Install the module into the key frame and secure the cover
with the screw.
7. When pushing any switch on the wireless key, make sure
the indicator light comes on.
KEYS AND DOORS
19
DOORS
Locking with key
11G003–1
1
Lock 2Unlock
Turn the key towards the front of the vehicle to lock and
towards the back to unlock.
The doors lock and unlock simultaneously with either front
door. I n the driver’s door lock, turning the key once will unlock
the driver’s door and twice in succession will unlock all doors
simultaneously .* I n the passenger’s door lock, turning the key
once will unlock all doors simultaneously.
NOTE: *The 2–step unlocking function can be changed.
Ask your Lexus dealer for details.
If a wrong key is used, the key cylinder rotates freely to isolate
inside mechanism. So, door locking is protected from thieves.
The windows and moon roof can be opened and closed from
outside the vehicle using the key. For details, see “Power
window switches” on page 34 and “Moon roof” on page 72.
Locking with inside lock button
11G004
1
Lock 2Unlock
Push in the lock button to lock and unlock the door.
The front doors can be opened by pulling the inside handles
even if the lock buttons are in the locked position.
CAUTION
Do not pull the inside handle of the front doors while
driving. The doors will open and an accident may occur.
Lexus strongly recommends that all children be placed
in the rear seat of the vehicle.
KEYS AND DOORS
20
Closing the door with the lock button pushed in will also lock
the door. Be careful not to lock your keys in the vehicle. Doors
cannot be locke d when either front door is open and the key is
in the ignition.
If the vehicle is subjected to a severe frontal, rear or side
impact with the ignition switch turned to the “ON” position, all
the doors will unlock automatically after a few seconds.
CAUTION
Before driving, make sure the doors are closed and
locked, especially when small children are in the
vehicle. Along with the proper use of seat belts, locking
the doors helps prevent the driver and passengers from
being thrown out from the vehicle during an accident.
It also helps prevent the doors from being opened
unintentionally.
Locking with power door lock switch
11G005a
1
Lock 2Unlock
To lock all the doors simultaneously, push the power door
lock switch down on the front side. Pushing down on the
rear side will unlock them.
The same switch is also found on the front passenger’s side.
Auto door locking function*: Al l the do ors wi ll lo ck
automatically when the selector lever is moved out of “P”
position. This auto door locking function is operable while the
ignition switch is turned to the “ON” position.
NOTE: * This auto door locking function can be disabled or
changed. Ask your Lexus dealer for details.
KEYS AND DOORS
21
Locking with rear door child–protector
11G006d
1
Unlock 2Lock
Whenever small children are in the vehicle, lock the rear
door so that it does not open by the inside door handle.
To do this, turn the knob to the ”LOCK” position as shown
and then close the door.
THEFT DETERRENT SYSTEM
17g005
To deter theft of the vehicle, this system is designed to
sound an alarm if any of the doors, trunk or hood is
forcibly unlocked or the battery terminal is disconnected
and then reconnected while the vehicle is locked.
The alarm blows the vehicle’s horn and intermittently flashes
the headlights, tail lights and other exterior lights.
KEYS AND DOORS
22
17G001a
Security indicator light
Setting the system
1. Turn the ignition key to the ”LOCK” position and
remove it.
The engine immobilizer system causes the indicator light to
flash.
2. Close and lock all the doors, trunk and hood using an
ignition key or wireless remote control.
The flashing indicator light will remain on when all the doors,
trunk and hood are closed and locked.
3. After 30 seconds, the indicator starts flashing and the
system is set.
Cancelling the system
When you unlock any door or trunk using an ignition key
or wireless remote control, the system is cancelled.
Activating the system
The alarm sounds for 60 seconds if any of the following are
operated:
Unlocking any door or trunk without using an ignition key or
wireless remote control.
Opening the hood forcibly.
Reconnecting the battery.
If any door is unlocked during the alarm sounding, its door is
automatically locked.
To stop the alarm: Use either of the following methods.
Unlock the door or trunk using an ignition key or wireless
remote control.
Turn the ignition switch on.
KEYS AND DOORS
23
Testing the system
1. Open all the windows.
2. Set the system as described above.
The front doors should be locked with the ignition key or
wireless remote control. Be sure to wait until the indicator light
starts flashing.
3. Unlock one of the doors from the inside through one of
the opened windows.
The system should activate the alarm.
4. Unlock any of the doors with a key or the wireless
remote control to cancel the system.
5. Repeat this operation for the other doors, trunk and
hood.
When testing the hood, also check that the system is activated
when the battery terminal is disconnected and then
reconnected.
If the system does not work properly , have it checked by your
Lexus dealer.
NOTICE
Disconnecting the battery may result in the erasure of
information you have set in the computer memory . Afte r
reconnecting the battery, check that the memorized
data has been retained. If it has been erased, input it into
the computer once more.
KEYS AND DOORS
24
SECTION 1 –
2
25
INSTRUMENTS AND CONTROLS
Switches
Headlight switch 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight dimmer and turn signal switches 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog light switch 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield wiper and washer switches 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlight cleaner switch 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear window and outside rear view mirror defogger switch 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power window switches 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Emergency flasher switch 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat heater switches 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SWITCHES
26
HEADLIGHT SWITCH
12L001
To turn the lights on, twist the knob on the end of the lever .
FIRST CLICKSTOP: Only the parking, tail, license plate, side
marker and instrument panel lights turn on.
SECOND CLICKSTOP: Headlights also turn on.
THIRD CLICKSTOP (”AUTO”): The headlights and all other
lights automatically turn on depending on the darkness of the
surroundings.*
Vehicles sold in U.S.A.: When the headlights are on, the
headlight indicator lights up in the instrument cluster.
Vehicles sold in Canada: When the tail lights are on, the tail
light indicator lights up in the instrument cluster.
Manually twist the knob to the second clickstop to turn on
the headlights if they are needed immediately when
entering a dark tunnel, parking structure, etc.
When the headlight switch is turned to the first or second
clickstop, the brightness of the instrument cluster will be
reduced slightly unless the instrument panel light control knob
is turned fully on.
NOTE: *The operating condition or sensitivity can be
changed. Ask your Lexus dealer for details.
SWITCHES
27
12G001
The automatic light control sensor is on top of the driver’s side
instrument panel.
Do not place anything on the instrument panel, and/or do not
affix anything on the windshield to block this sensor.
When the headlights come on, the lights automatically turn off
about 30 seconds after any of the doors is opened and closed
with the ignition key turned to the ”ACC” or ”LOCK” position.*
T o turn them on again, turn the ignition key to the ”ON” position,
or turn the headlight switch off and then twist the knob until the
first or second clickstop. If you are going to park for over one
week, make sure the headlight switch is off.
When the headlight switch is on with all the doors locked,
pushing the ”LOCK” button on the wireless remote control key
turns off the headlights.
NOTE: *The time before turning off the lights can be
changed. Ask your Lexus dealer for details.
Daytime Running Light System
The headlights turn on at reduced intensity when the parking
brake is released with the engine started, even with the light
switch in the ”OFF” position. They will not go off until the
ignition switch is turned off.
To turn on the other exterior lights and instrument panel lights,
twist the knob to the first clickstop.
Twist the knob to the second clickstop to turn on the headlights
to full intensity for driving at night.
When setting the knob to the third clickstop (”AUTO”), the
headlights will automatically adjust to full intensity and/or turn
on the other lights depending on the darkness of the
surroundings. Likewise, as the surroundings become brighter,
the headlights will turn to reduced intensity, ultimately turning
off the other lights.
NOTICE
To prevent the battery from being discharged, do not
leave the lights on longer than necessary when the
engine is not running.
SWITCHES
28
Automatic headlight leveling system
(Vehicles with discharge headlight only)
12G012
The headlight beam level is always maintained automatically
at the proper level in all loading conditions so that your
headlights do not dazzle other road users.
If this system fails, the warning light in the instrument cluster
comes on. If this occurs, have your vehicle checked by Lexus
dealer.
HEADLIGHT DIMMER AND TURN
SIGNAL SWITCHES
12L003
For high beam, push the lever forward. Pull it back for low
beam. For the headlight flasher, pull it further back.
A blue light in the instrument cluster indicates high beam or
headlight flasher is on.
The headlight flasher works even when the headlight switch is
off.
SWITCHES
29
12L004
For signaling turns, move the lever up or down in the
conventional manner.
The ignition key must be in the ”ON” position.
The turn signal is self–cancelling after a turn, but after a lane
change, you may have to cancel it by hand. You can also signal
a lane change by moving the turn signal lever partway and
holding it there.
If the green light in the instrument cluster flashes faster than
normal, it indicates that the front or rear turn signal bulb has
burned out. If this indicator light does not come on, the fuse
or the indicator light itself has probably failed.
FOG LIGHT SWITCH
12L005
To turn on the fog lights, turn the switch to the ”ON”
position. They will come on only when the headlights are
on low beam.
SWITCHES
30
WINDSHIELD WIPER AND WASHER
SWITCHES
12L006–1
1
Interval adjuster 2Washer on
To turn the wipers on, move the lever down until you reach
the desired speed setting.
The ignition key must be in the ”ON” position.
There are 3 settings:
”INT” position: Intermittent operation
”LO” position: Low speed operation
”HI” position: High speed operation
T wist the interval adjuster upward to increase the wiping
time interval between sweeps, and downward to decrease
it.
The wiper lever must be in the ”INT” position.
For mist wiper operations (a single wipe), pull the lever
toward you and release it.
To make the washer squirt, push the button on the end of
the lever.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes very low.
For information on adding washer fluid, see ”Adding washer
fluid” on page 325.
In cold weather, warm the windshield with the defroster before
using the washer. This will help prevent icing, which could
block your vision.
NOTICE
Do not operate the wipers if the windshield is dry. It m a y
scratch the glass.
SWITCHES
31
Shifting the windshield wiper position
12G006
1
Rest position 2Retracted position
The wiper blades retract under the hood when the wipers are
turned off.
In the following cases, the wipers should be shifted from the
retracted position to the rest position above the hood level.
When cleaning the windshield
When inspecting or replacing the wipers
When the retraction may be obstructed by snow, etc., at the
bottom of the windshield
Other than the above cases, keep the wipers in the retracted
position.
12G007c
More than 10 cm (3.9 in.)
To shift the windshield wipers from retracted to rest
position, hold the connection of the wiper arm and wiper
blade and pull it upward along the windshield glass with
the force of about 98 N (10 kgf, 22 lbf.).
NOTICE
To prevent the wiper blades from being deformed, be
sure to hold the connection of the wiper arm and wiper
blade securely.
SWITCHES
32
12G008b
To return the windshield wipers to retracted position,
push the connection of the wiper arm and wiper blade
downward.
NOTICE
To prevent the wiper blades from being deformed, be
sure to hold the connection of the wiper arm and wiper
blade securely.
HEADLIGHT CLEANER SWITCH
(CANADA ONLY)
12G009
To spray fluid on the headlights, push the switch with the
headlights on.
The ignition key must be in the ”ON” position.
The low washer fluid warning light in the instrument cluster
comes on when the fluid level in the tank becomes very low.
For information on adding washer fluid, see ”Adding washer
fluid” on page 325.
NOTICE
Do not turn the headlight cleaner on with the washer
fluid tank empty. It may cause the cleaner motor to
overheat.
SWITCHES
33
REAR WINDOW AND OUTSIDE
REAR VIEW MIRROR DEFOGGER
SWITCH
12G010
To turn the electric rear window defogger on, push the
switch.
The ignition key must be in the ”ON” position.
The thin heater wires on the inside of the rear window and the
heater panels in the outside rear view mirrors will quickly clear
the surface. Keep your hands off the mirror faces when the
switch is on. An indicator light is on when the defogger is
operating.
The system will automatically shut off when the defogger has
operated about 15 minutes.
CAUTION
Since the mirror surfaces can get hot, do not touch them
when the switch is on.
If further defrosting or defogging is desired, simply actuate the
switch again. When the surface has cleared, push the switch
once again to turn the defogger off. Continuous use may cause
the battery to discharge, especially during stop–and–go
driving. The defogger is not designed to dry rain water or to
melt snow.
If the outside rear view mirrors are heavily coated with ice, use
a spray de–icer before operating the switch.
NOTICE
When cleaning the inside of the rear window, be
careful not to scratch or damage the heater wires or
connectors.
To prevent the battery from being discharged, turn
the switch off when the engine is not running.
SWITCHES
34
POWER WINDOW SWITCHES
12G003a
1
For driver’s window
2
For front passenger’s window
3
For left rear window
4
For right rear window
To raise or lower the windows, use the switch on each
door. The passengers’ windows can also be controlled by
the switches on the driver’s door.
The power windows work when the ignition key is in the ”ON”
position.
Key off operation: Even if the ignition key is turned to the
”ACC” or ”LOCK” position, the window can be operated until
any of the doors is opened (or for about 45 seconds).
12L010
Operating the switches
To raise or lower the window, pull the switch halfway up
or push it halfway down.
Automatic operation: To fully raise or lower the window
automatically, pull the switch fully up or push it fully down.
To stop the window partway, lightly push or pull the switch in
the opposite direction and then release it.
SWITCHES
35
Operating the window lock switch
12G004a
Indicator light
With the window lock switch pressed in, only the driver’s
window can be raised or lowered.
The indicator lights on the switch tell you which of the switches
can be operated.
Even with the window lock switch pressed in, the windows will
be opened from outside the vehicle using an ignition key or
wireless remote control.
Operating the windows from outside the
vehicle
The windows can be operated using an ignition key.*
NOTE: *This feature can be deactivated. Ask your Lexus
dealer for details.
12L043–1
Insert the ignition key into the key hole on the driver’s
side.
To close the windows: Turn the key in the locking direction
and hold it.
After the door is locked, the windows begin to close. To stop
in the middle, return the key.
To open the windows: Turn the key in the unlocking direction
and hold it.
After the door is unlocked, the windows begin to open. To stop
in the middle, return the key.
SWITCHES
36
This function will work even with the window lock switch
pressed in.
Jam protection function
If something gets caught between the window and window
frame during automatic raising operation, key off raising
operation or raising operation using the ignition key from the
outside, the window stops and is lowered.
If the window receives a strong impact, this function may work
even if nothing is caught.
CAUTION
To avoid serious personal injury, you must do the
following.
Before you close the power windows, always make
sure there is nobody around the power windows. You
must also make sure the heads, hands and other
parts of the bodies of all occupants are kept
completely inside the vehicle. If someone’s neck,
head or hands get caught in a closing window, it
could result in death or serious injury. When anyone
closes the power windows, make sure he or she
operates the windows safely.
When small children are in the vehicle, never let them
use the power window switches without supervision.
Use the window lock switch to prevent them from
making unexpected use of the switches.
Be sure to remove the ignition key when you leave
your vehicle.
Never leave anyone (particularly a small child) alone
in your vehicle, especially with the ignition key still
inserted. Otherwise, he/she could use the power
window switches and get trapped in a window.
Unattended person ( p articularly a small child) can be
involved in a serious accident.
Never try jamming any part of your body to activate
the jam protection function intentionally.
The jam protection function may not work if
something gets caught just before the window fully
closed.
SWITCHES
37
EMERGENCY FLASHER SWITCH
12G005
To turn on the emergency flashers, push the switch.
All the turn signal lights will flash. The emergency flashers will
work with the engine running or off and with or without the
ignition key.
Turn on the emergency flashers to warn other drivers if you
must stop your vehicle where it might be a traffic hazard.
Always pull your vehicle as far off the road as possible.
The turn signal light switch will not work when the emergency
flashers are in operation.
NOTICE
To prevent the battery from being discharged, do not
leave the switch on longer than necessary when the
engine is not running.
SEAT HEATER SWITCHES
12G011b
1
For driver’s seat 2For front passenger’s seat
There is a heater switch for each front seat. Push the front
of the switch to turn the heater on and push the rear side
to turn it off.
The ignition key must be in the ”ON” position.
SWITCHES
38
CAUTION
Occupants must use caution when operating the seat
heater because they may experience minor burns even
at low temperatures. Use extra caution for;
Babies, small children, elderly persons, sick persons
or persons with physical disabilities
Persons who have delicate skin
Persons who are exhausted
Persons who have taken alcohol or drugs which
induce sleep (sleeping drug, cold remedy, etc.)
To prevent the seat from overheating, do not use the
seat heater with a blanket, cushion, or other insulating
objects which cover the seat.
NOTICE
Do not put unevenly weighted objects on the seat and
do not stick sharp objects (needles, nails, etc.) into
the seat.
When cleaning the seats, do not use organic
substances (paint thinner, benzine, alcohol,
gasoline, etc.). They may damage the heater and seat
surface.
To prevent the battery from being discharged, turn
the switches off when the engine is not running.
SECTION 1 –
3
39
INSTRUMENTS AND CONTROLS
Gauges, meters and service reminder
indicators
Fuel gauge 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine coolant temperature gauge 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Odometer and trip meter 42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service reminder indicators and warning buzzers 42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument panel light control 52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAUGES, METERS AND SERVICE REMINDER INDICATORS
40
FUEL GAUGE
13G001a
The gauge indicates the approximate quantity of fuel
remaining in the tank when the ignition switch is on.
It is a good idea to keep the tank over 1/4 full.
If the fuel level approaches ”E” or the low fuel level warning light
comes on, fill the fuel tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the fuel gauge needle may fluctuate or the low fuel level
warning light may come on earlier than usual.
If the fuel tank is completely empty, the malfunction indicator
lamp comes on. Fill the fuel tank immediately.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible.
See the inner back cover for fuel capacity and recommended
fuel selection.
ENGINE COOLANT
TEMPERATURE GAUGE
13G009a
Normal range
The gauge indicates the engine coolant temperature when
the ignition switch is on. The engine operating
temperature will vary with changes in weather and engine
load.
If the needle points to the red zone or higher, stop your vehicle
and allow the engine to cool.
Y our vehicle may overheat during severe operating conditions,
such as:
Driving up a long hill on a hot day.
Reducing speed or stopping after high speed driving.
Idling for a long period with the air conditioning on in
stop–and–go traffic.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
41
NOTICE
Do not remove the thermostat in the engine cooling
system as this may cause the engine to overheat. The
thermostat is designed to control the flow of coolant
to keep the temperature of the engine within the
specified operating range.
Do not continue driving with an overheated engine.
See ”If your vehicle overheats” on page 225.
TACHOMETER
13G006d
The tachometer indicates engine speed in thousands of
rpm (revolutions per minute). Use it while driving to
prevent engine over–revving.
Driving with the engine running too fast causes excessive
engine wear and poor fuel economy. Remember, in most
cases the slower the engine speed, the greater the fuel
economy.
NOTICE
Do not let the indicator needle get into the red zone. This
may cause severe engine damage.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
42
ODOMETER AND TRIP METER
13G004
This meter displays the odometer and two trip meters. To
change the mode indication, push the ”ODO/TRIP”
button.
The odometer records the total distance the vehicle has
been driven. The twin trip meter records two different
distances independently.
For example, you can use one meter to calculate the fuel
economy and the other to measure the distance on each trip.
To change the trip meter indication from one trip to the
other, push the ”ODO/TRIP” button. T o set the A trip meter
to zero, display the A meter reading, then push the
”RESET” button. The same applies for the B trip meter.
The data of trip meters will be cancelled if the electrical power
source is disconnected.
SERVICE REMINDER INDICATORS
AND WARNING BUZZERS
IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(a)
or
(Indicator and buzzer)
If parking brake is off,
stop immediately and
contact Lexus dealer.
(b)
(Indicator and buzzer)
Fasten driver’s seat
belt.
(c)
Fasten front
passenger’s seat belt.
(d)
Take vehicle to Lexus
dealer immediately.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
43
IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(e)
Stop and check.
(f)
Stop and check.
(g)
Add engine oil.
(h)
or
Take vehicle to Lexus
dealer.
(i)
or
Take vehicle to Lexus
dealer.
If brake system
warning light is also
on, stop immediately
and contact Lexus
dealer.
IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(j)
(Indicator and buzzer)
Close all doors.
(k)
Replace bulb.
(l)
Add washer fluid.
(m)
Fill up tank.
(n)
Take vehicle to Lexus
dealer.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
44
IF THIS INDICATOR OR
BUZZER COMES ON ...
DO THIS.
(o)
and
Take vehicle to Lexus
dealer.
(p)
Key reminder
buzzer
Remove key.
(a) Brake System Warning Light and Buzzer
This light comes on in the following cases when the ignition key
is in the “ON” position.
When the parking brake is applied ...
This light comes on for a few seconds when the ignition key is
turned to the “ON” position even after the parking brake is
released.
If you drive your vehicle without releasing the parking brake,
the buzzer sounds.
When the brake fluid level is low ...
CAUTION
It is dangerous to continue driving normally when the
brake fluid level is low.
When the hydraulic brake booster fails ...
If the hydraulic booster causes a problem resulting in poor
braking performance, the warning light comes on and buzzer
sounds continuously.
Have your vehicle checked at your Lexus dealer in the
following cases:
The light does not come on even if the parking brake is
applied when the ignition key is turned to the “ON” position.
The light does not come on even if the ignition key is turned
on with the parking brake released.
A warning light turned on briefly during operation does not
indicate a problem.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
45
CAUTION
If either of the following conditions occurs, immediately
stop your vehicle at a safe place and contact your Lexus
dealer.
The light does not turn off even after the parking
brake is released while the engine is running.
The warning buzzer comes on together with the
warning light.
In either case, this can indicate that the brakes may not
work properly and your stopping distance will become
longer. Depress the brake pedal firmly and bring the
vehicle to an immediate stop.
Any of the following conditions may occur, but do not
indicate the malfunction:
The light may stay on for about 60 seconds after the ignition
key is turned to the “ON” position. It is normal if it turns off
after a while.
Depressing the brake pedal repeatedly may turn on the
warning light and buzzer. It is normal if the light turns of f and
the buzzer stops sounding after a few seconds.
You may hear a small sound in the engine compartment
after the engine is started or the brake pedal is depressed
repeatedly. This is a pump pulsating sound of the brake
system, and it is not a malfunction.
(b) Driver’s Seat Belt Reminder Light and
Buzzer
The light and buzzer act as a reminder to have the driver buckle
up the seat belt.
Once the ignition key is turned to ”ON” or ”START”, the
reminder light flashes and buzzer sounds if the driver’s seat
belt is not fastened. Unless the driver fastens the belt, the light
continues flashing and the buzzer stops after about 4 to 8
seconds.
(c) Front Passenger’s Seat Belt Reminder
Light
The light acts as a reminder to have the front passenger buckle
up the seat belt.
Once the ignition key is turned to ”ON” or ”START”, the
reminder light flashes if a passenger sits in the front passenger
seat and does not fasten the seat belt. Unless the front
passenger fastens the belt, the light continues flashing.
However, if a front passenger uses an additional seat cushion,
the light may not flash even when the seat belt is not buckled
up.
If luggage or other load is placed on the front passenger seat,
depending on its weight and how it is placed on the seat,
built–in sensors in the seat cushion may detect the pressure,
causing the reminder light to flash.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
46
(d) SRS Warning Light
The indicator comes on when the ignition key is turned to
the ”ON” position. It goes off after about 6 seconds. This
means the SRS airbags and seat belt pretensioners are
operating properly.
The SRS warning light system monitors the airbag sensor
assembly, front airbag sensors, side and curtain shield airbag
sensor assemblies, occupant detection sensor, seat belt
buckle switch, front seat belt pretensioner assemblies,
inflators, warning light, interconnecting wiring and power
sources.
If either of the following conditions occurs, this indicates a
malfunction somewhere in the parts monitored by the warning
light system. Contact your Lexus dealer as soon as possible
to service the vehicle.
When the ignition key is turned to the “ON” position, the light
does not come on, remains on for more than 6 seconds or
flashes.
The light comes on or flashes while driving.
If the light stays on, it indicates that the SRS driver and front
passenger airbags have a problem. If the light flashes, the
SRS side and curtain shield airbags and/or seat belt
pretensioners have a problem.
(e) Discharge Warning Light
This light warns that the battery is being discharged.
If it comes on while you are driving, stop the vehicle, turn off the
engine, and check for the cause. Look first at the engine drive
belt.
If it is loose or broken, the generator will not charge the
battery properly.
If the belt is O.K., there is a problem somewhere in the
charging system.
The engine ignition will continue to operate, however, until the
battery is discharged. Turn off the air conditioning, blower,
radio, etc., and drive directly to the nearest Lexus dealer or
repair shop.
NOTICE
Do not continue driving if the engine drive belt is broken
or loose.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
47
(f) Low Engine Oil Pressure Warning Light
This light warns that the engine oil pressure is too low.
If it flickers or stays on while you are driving, pull off the road
to a safe place and stop the engine immediately. Call a Lexus
dealer or qualified repair shop for assistance.
The light may occasionally flicker when the engine is idling or
it may come on briefly after a hard stop. There is no cause for
concern if it then goes out when the engine is accelerated
slightly.
The light may come on when the oil level is extremely low. It
is not designed to indicate low oil level, and the oil level must
be checked using the oil level dipstick.
NOTICE
Do not drive the vehicle with the warning light on – even
for one block. It may ruin the engine.
(g) Low Engine Oil Level Warning Light
This light warns that the engine oil level is too low. Add oil as
soon as possible. (For instructions, see ”Checking the engine
oil level” on page 270.)
While driving on steep inclines or rough roads which causes
the vehicle to substantially sway or on curves, this light may
come on due to the movement of engine oil in the engine.
In normal conditions, due to engine oil consumption, this light
may come on earlier than the specified service interval of the
scheduled maintenance. This is because the engine oil is
consumed to the low level within the scheduled maintenance
interval and does not indicate a problem. (For detailed
information, see “Facts about engine oil consumption” on page
268.)
NOTICE
Continued engine operation with low engine oil will
damage the engine.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
48
(h) Malfunction Indicator Lamp
This lamp comes on when the ignition key is turned to the
“ON” position and goes off after the engine starts. This
means that the warning light system is operating properly.
If the lamp remains on, or the lamp comes on while
driving, first check the followings:
Empty fuel tank
If the fuel tank is empty, refuel immediately.
Loose fuel tank cap
If the fuel tank cap is loose, securely tighten it.
These cases are temporary malfunctions. The malfunction
indicator lamp will go off after taking several driving trips.
If the lamp does not go off even after several trips, contact your
Lexus dealer as soon as possible.
If the fuel tank is not empty or the fuel tank cap is not
loose...
There is a problem somewhere in the engine, emission
control system, electronic throttle control system, automatic
transmission electrical system or warning light system itself.
Contact your Lexus dealer as soon as possible to service the
vehicle.
GS430
If this lamp comes on and engine speed does not increase
when the accelerator pedal is depressed, there may be a
problem somewhere in the electronic throttle control system.
At this time, vibration may occur. However, if you depress the
accelerator pedal more firmly and slowly, you can drive your
vehicle at low speeds. Have your Lexus checked by your
Lexus dealer as soon as possible.
Even if the a b n o r m a lity of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to “ACC” or “LOCK” position.
GS300
If this lamp comes on and engine speed does not increase
when the accelerator pedal is depressed down to about the
middle position, there may be a problem somewhere in the
electronic throttle control system.
At this time, if you depress the accelerator pedal more firmly
and slowly, you can drive your vehicle at low speeds. Have
your Lexus checked by your Lexus dealer as soon as possible.
Even if the a b n o r m a lity of the electronic throttle control system
is corrected during low speed driving, the system may not be
recovered until the engine is stopped and the ignition key is
turned to “ACC” or “LOCK” position.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
49
Emissions inspection and maintenance (I/M) programs
Your vehicle may not pass a state emission inspection if the
malfunction indicator lamp remains on. Contact your Lexus
dealer to check your vehicle’s emission control system and
OBD (On–Board Diagnostics) system before taking your
vehicle for the inspection.
For details, see “Emissions inspection and maintenance (I/M)
programs” on page 247.
(i) ”ABS” Warning Light
The light comes on when the ignition key is turned to the “ON”
position. If the anti–lock brake system and the brake assist
system work properly, the light turns off after a few seconds.
Thereafter, if either of the systems malfunctions, the light
comes on again.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti–lock brake system, the brake
assist system, the traction control system and/or the vehicle
stability control system do/does not operate, but the brake
system still operates conventionally.
When the “ABS” warning light is on (and the brake system
warning light is off), the anti–lock brake system does not
operate so that the wheels could lock up during a sudden
braking or braking on slippery road surfaces.
If either of the following conditions occurs, this indicates
a malfunction somewhere in the parts monitored by the
warning light system. Contact your Lexus dealer as soon
as possible to service the vehicle.
The light does not come on when the ignition key is turned
to the “ON” position, or remains on.
The light comes on while you are driving.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
50
A warning light turning on briefly during operation does not
indicate a problem.
Either of the following conditions may occur, but do not
indicate the malfunction:
The light may stay on for about 60 seconds after the ignition
key is turned to the “ON” position. It is normal if it turns off
after a while.
Depressing the brake pedal repeatedly may turn on the
light. It is normal if it turns off after a few seconds.
(j) Open Door Warning Light and Buzzer
This light remains on until all the doors are completely closed.
The buzzer sounds if you drive your vehicle with the doors not
closed completely.
(k) Rear Light Failure Warning Light
If this light comes on when the headlight switch is turned on (at
the first or second clickstop), it indicates that one or more of the
tail lights are burned out.
If it comes on when the brake pedal is depressed, one or more
stop lights are burned out.
Have defective bulbs replaced as soon as possible.
(l) Low Washer Fluid Warning Light
This light comes on when the fluid level in the tank becomes
very low. Fill the tank as soon as possible.
(m) Low Fuel Level Warning Light
This light comes on when the fuel level in the tank becomes
very low. Fill the tank as soon as possible.
On inclines or curves, due to the movement of fuel in the tank,
the low fuel level warning light may come on earlier than usual.
(n) Automatic Headlight Leveling System
Warning Light
This light warns that there is a problem somewhere in the
automatic headlight leveling system.
If it comes on, have your vehicle checked by your Lexus dealer.
GAUGES, METERS AND SERVICE REMINDER INDICATORS
51
(o) Vehicle Stability Control System Warning
Lights
These lights warn that there is a problem somewhere in the
vehicle stability control system or traction control system.
If the ”VSC” warning light and ”VSC OFF” indicator light come
on, have your vehicle checked by Lexus dealer as soon as
possible.
The lights will come on when the ignition key is turned to ”ON”,
and will go off after about a few seconds.
The lights may stay on for 60 seconds after the ignition key is
turned to the “ON” position. It is normal if they go out after a
while.
Depressing the brake pedal repeatedly may turn on the lights.
It is normal if they go out after a few seconds.
If the ”VSC” warning light and ”VSC OFF” indicator light come
on, the vehicle stability control system does not activate,
however, it is no problem to continue your driving.
(p) Key Reminder Buzzer
This buzzer acts as a reminder to remove the key when you
open the driver’s door with the ignition key in the ”ACC” or
”LOCK” position.
How to check all the service reminder
indicators
(except the low fuel level warning light):
1. Apply the parking brake.
2. Open the door.
The following service reminder indicator should come on. It
goes off when you close the door completely.
3. Turn the ignition key to ”ON”.
The following service reminder indicators should come on.
or
or
or
GAUGES, METERS AND SERVICE REMINDER INDICATORS
52
The following service reminder indicators go off after a few
seconds.
or
The following service reminder indicator goes off after about 6
seconds.
The lights other than the slip indicator light may stay on for
about 60 seconds after the ignition key is turned to the “ON”
position. It is normal if they go out after a while.
If any service reminder indicator or warning buzzer does not
function as described above, have it checked by your Lexus
dealer as soon as possible.
INSTRUMENT PANEL LIGHT
CONTROL
13G005
The brightness of the instrument panel lights is
automatically adjusted depending on the brightness of
your surroundings. T o adjust the brightness as you like,
turn the knob. However , if the brightness is automatically
adjusted at the maximum, turning the knob cannot change
the brightness.
When the headlight switch is in the first or second click stop,
you can also adjust the brightness of the displays on the audio
and air conditioning systems using this knob.
SECTION 1 –
4
53
INSTRUMENTS AND CONTROLS
Interior equipment
Vanity mirrors 54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior lights 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Personal lights 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition switch light 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Clock 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette lighter and ashtray 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power outlet 58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear console box 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glove box 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Garage door opener 60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cup holders 63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coin box 64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tie–down hooks 64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Floor mat 65. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First–aid kit holder 66. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INTERIOR EQUIPMENT
54
VANITY MIRRORS
14G001
To use the vanity mirrors, swing the sun visor down and
open the cover.
The vanity light comes on when you open the cover.
Sun visors
14G002
1
To block out glare from the front , swing the sun visor
down.
2
To block out glare from the side, remove the sun visor
from the hook and swing it to the side.
3
To block out glare coming obliquely from behind you,
slide the visor backwards.
At this position, the vanity light does not come on.
INTERIOR EQUIPMENT
55
INTERIOR LIGHTS
14G003a
To turn on the interior light, slide the switch.
With the switch in the ”DOOR” position, the light comes on
when any door is opened. After all the doors are closed, the
light remains on for about 15 seconds and then goes out.
However, in the following cases, the light goes out
immediately:
1. All the doors are closed when the ignition key is in ”ACC” or
”ON” position.
2. The ignition key is turned to ”ACC” or ”ON” when the light
is still on.
3. All the doors are locked when the light is still on.
4. One door is closed with the lock button pushed in while the
other doors are locked.
PERSONAL LIGHTS
Front
14G004a
Rear
14G006
To turn on the personal light, push the switch. To turn it
off, push the switch again.
INTERIOR EQUIPMENT
56
IGNITION SWITCH LIGHT
14G005
For easy access to the ignition switch, the ignition switch
light comes on when any of the doors are opened.
The light remains on for about 15 seconds and goes out after
all the doors are closed. However, the light goes out
immediately when all the doors are locked or the ignition key
is in the ”ACC” or ”ON” position.
CLOCK
14G007
The digital clock indicates the time with the ignition key at
the ”ACC” or ”ON” position. T o reset the hour, press the
”H” button. To reset the minutes, press the ”M” button.
To adjust the time to the nearest hour, press the ”:00”
button.
For example, if the ”:00” button is pressed when the time is
between 9:30 – 9:59 or between 10:01 – 10:29, the time will
change to 10:00.
With the tail lights on, the background brightness of the time
indication will be reduced.
If the electrical power source has been disconnected from the
clock, the time display will automatically be set to 1:00.
INTERIOR EQUIPMENT
57
CIGARETTE LIGHTER AND
ASHTRAY
14G008e
Front cigarette lighter and ashtray
To use the cigarette lighter and ashtray, first push against
the ashtray cover. Then when the ashtray opens out,
press in the cigarette lighter. After it finishes heating up,
it automatically pops out ready for use.
Do not hold the cigarette lighter pressed in.
If the engine is not running, the ignition key must be in the
”ACC” position to use the lighter.
When finished with your cigarette, thoroughly extinguish it in
the ashtray to prevent other cigarette butts from catching fire.
After using the ashtray, push it back in completely.
To remove the ashtray, just pull it up.
Use a Lexus genuine cigarette lighter or equivalent for
replacement.
14G009
Rear ashtray
To use the ashtray, pull on the lid.
When finished with your cigarette, thoroughly extinguish it in
the ashtray to prevent other cigarette butts from catching fire.
After using the ashtray, push it back in or close the lid
completely.
To remove the ashtray, just pull it up.
CAUTION
To reduce the chance of injury in case of an accident or
sudden stop while driving, always close the ashtray
completely after use.
INTERIOR EQUIPMENT
58
POWER OUTLET
14L020a
The power outlet is designed for power supply for car
accessories.
The ignition key must be in the ”ACC” or ”ON” position for the
power outlet to be used.
NOTICE
To prevent the fuse from being blown, do not use the
electricity over the total vehicle capacity of 12V 3.5A.
To prevent the battery from being discharged, do not
use the power outlet longer than necessary when the
engine is not running.
Close the power outlet lid when the power outlet is
not in use. Inserting anything other than an
appropriate plug that fits the outlet, or allowing any
liquid to get into the outlet may cause electrical
failure or short circuits.
INTERIOR EQUIPMENT
59
REAR CONSOLE BOX
14g029a
1
For upper box 2For lower box
To use the rear console box, open as shown in the
illustration.
GLOVE BOX
14G010
1
Unlock 2Open 3Lock
To open the glove box door, pull the lever. To lock the
glove box door, insert the master key and turn it
clockwise.
With the tail lights on, the glove box light will come on when the
glove box door is open.
CAUTION
To reduce the chance of injury in case of an accident or
a sudden stop, always keep the glove box door closed
while driving.
INTERIOR EQUIPMENT
60
GARAGE DOOR OPENER
The garage door opener (
Universal
Transceiver) is manufactured under license from
HomeLink
and can be programmed to operate garage
doors, gates, entry doors, door locks, home lighting
systems, and security systems, etc.
(a) Programming the HomeLink
14G015–1
1
Buttons 2Indicator light
The HomeLink in your vehicle has 3 buttons and you can
store one program for each button.
To ensure correct programming into the HomeLink
, install a
new battery in the hand–held transmitter prior to programming.
The battery side of the hand–held transmitter must be pointed
away from the HomeLink
during the programming process.
For Canadian users, follow the procedure in “Programming an
entrance gate/Programming all devices in the Canadian
market”.
1. Decide which of 3 HomeLink
buttons you want to program.
2. Place your hand–held garage transmitter 25 to 75 mm (1 to
3 in.) away from the surface of the HomeLink
.
Keep the indicator light on the HomeLink in view while
programming.
3. Simultaneously press and hold the hand–held garage
transmitter button along with the selected HomeLink
button.
4. When the indicator light on the HomeLink
changes from a
slow to a rapid flash after 20 seconds, you can release both
buttons.
5. T est the operation of the HomeLink
by pressing the newly
programmed button. If programming a garage door opener,
check to see if the garage door opens and closes.
If the garage door does not operate, identify if your garage
transmitter is of the “Rolling Code” type. Press and hold the
programmed HomeLink
button. The garage door has the
rolling code feature if the indicator light (on the HomeLink
)
flashes rapidly and then remains lit after 2 seconds. If your
garage transmitter is the “Rolling Code” type, proceed to the
heading “Programming a rolling code system”.
6. Repeat steps 2 through 5 for each remaining HomeLink
button to program another device.
INTERIOR EQUIPMENT
61
Programming a rolling code system
If your device is “Rolling Code” equipped, it is necessary
to follow steps 1 through 4 under the heading
“Programming the HomeLink
” before proceeding with
the steps listed below.
1. Locate the “training” button on the ceiling mounted garage
door opener motor. The exact location and color of the button
may vary by brand of garage door opener. Refer to the owner’s
guide supplied by the garage door opener manufacturer for the
location of this “training” button.
2. Press the “training” button on the ceiling mounted garage
door opener motor.
Following this step, you have 30 seconds in which to initiate
step 3 below.
3. Press and release the vehicle’s programmed HomeLink
button twice. The garage door may open. If the door does
open, the programming process is complete. If the door does
not open, press and release the button a third time. This third
press and release will complete the programming process by
opening the garage door.
The ceiling mounted garage door opener motor should now
recognize the HomeLink
unit and be able to activate the
garage door up/down.
4. Repeat steps 1 through 3 for each remaining HomeLink
button to program another rolling code system.
Programming an entrance gate /
Programming all devices in the Canadian
market
1. Decide which of the 3 HomeLink buttons you want to
program.
2. Place your hand–held gate/device transmitter 25 to 75 mm
(1 to 3 in.) away from the surface of the HomeLink
.
Keep the indicator light on the HomeLink
in view while
programming.
3. Press and hold the selected HomeLink
button.
4. Continuously press and release (cycle) the hand–held
gate/device transmitter button every two seconds until step 5
is complete.
5. When the indicator light on the HomeLink
changes from a
slow to a rapid flash after 20 seconds, you can release both
buttons.
6. T est the operation of the HomeLink
by pressing the newly
programmed button. Check to see if the gate/device operates
correctly.
7. Repeat steps 1 through 6 for each remaining HomeLink
button to program another device.
Programming other devices
To program other devices such as home security systems,
home door locks or lighting, contact your authorized Lexus
dealer for assistance.
This device complies with Part 15 of the FCC Rules
and with RSS–210 of the IC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may cause undesired operation.
WARNING: This transmitter has been tested and
complies with FCC and IC rules. Changes or
modifications not expressly approved by the
party responsible for compliance could void the
user’s authority to operate the device.
INTERIOR EQUIPMENT
62
Reprogramming a button
Individual HomeLink
buttons cannot be erased, however, t o
reprogram a single button, follow the procedure “Programming
the HomeLink
”.
(b) Operating the HomeLink
To operate the HomeLink, press the appropriate HomeLink
button to activate the programmed device. The HomeLink
indicator light should come on. The HomeLink continues to
send the signal for up to 20 seconds as long as the button is
pressed.
(c) Erasing the entire HomeLink memory
(all three programs)
To erase all previously programmed codes at one time, press
and hold down the 2 outside buttons for 20 seconds until the
indicator light flashes.
If you sell your vehicle, be sure to erase the programs stored
in the HomeLink
memory.
CAUTION
When programming the HomeLink Universal
Transceiver, you may be operating a garage door or
other device. Make sure people and objects are out
of the way of the garage door or other device to
prevent potential harm or damage.
Do not use this HomeLink Universal Transceiver
with any garage door opener that lacks the safety
stop and reverse feature as required by federal safety
standards. (This includes any garage door opener
model manufactured before April 1, 1982.) A garage
door opener which cannot detect an object
(signaling the door to stop and reverse), does not
meet current federal safety standards. Using a
garage door opener without these features increases
risk of serious injury or death.
INTERIOR EQUIPMENT
63
CUP HOLDERS
14G011b
Front
To use the cup holder, push the cup holder lid.
You can use it as an accessory box by removing the holder
inside.
CAUTION
Do not place anything else other than cups or
drink–cans in the cup holder, as such items may be
thrown about in the compartment and possibly injure
people in the vehicle during sudden braking or in an
accident.
To reduce the chance of injury in case of an accident
or sudden stop while driving, keep the cup holder
closed when not in use.
14G012
Rear
To use the cup holder, push the cup holder portion of the
center armrest in the rear seat.
The cup holder is designed for holding cups or drink–cans
securely.
CAUTION
Do not place anything else other than cups or
drink–cans in the cup holder, as such items may be
thrown about in the compartment and possibly injure
people in the vehicle during sudden braking or in an
accident.
To reduce the chance of injury in case of an accident
or sudden stop while driving, keep the cup holder
closed when not in use.
INTERIOR EQUIPMENT
64
COIN BOX
(U.S.A.ONLY)
14g030
To use the coin box, push against the coin box cover.
CAUTION
Keep the coin box closed when not in use.
TIE–DOWN HOOKS
14G049a
To secure your luggage, use the tie–down hooks as
shown above.
See “Cargo and luggage” on page 215 for precautions in
loading luggage.
CAUTION
To avoid personal injury, keep the tie–down hooks
stored under the carpet when not in use.
INTERIOR EQUIPMENT
65
FLOOR MAT
14G025a
Use a floor mat of the correct size.
If the floor carpet and floor mat have 2 holes, then they are
designed for use with locking clips. Fix the floor mat with
locking clips into the holes in the floor carpet.
14G013–1
CAUTION
Make sure the floor mat is properly placed on the floor
carpet. If the floor mat slips and interferes with the
movement of the pedals during driving, it may cause an
accident.
INTERIOR EQUIPMENT
66
FIRST–AID KIT HOLDER
14G050
1
To loosen 2To tighten
This belt is designed to hold the first–aid kit.
To loosen: Pull the buckle forward.
To tighten: Pull on the belt.
Make sure the first–aid kit is securely held.
SECTION 1 –
5
67
INSTRUMENTS AND CONTROLS
Exterior equipment
Hood 68. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trunk lid 69. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel tank cap 71. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Moon roof 72. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
EXTERIOR EQUIPMENT
68
HOOD
15G001
1. To open the hood, pull the hood lock release lever
under the instrument panel. The hood will spring up
slightly.
15G013b
2. Insert your fingers under the hood, push up the
auxiliary catch lever and lift the hood.
Before closing the hood, check to see that you have not
forgotten any tools, rags, etc. Then lower the hood and make
sure it locks.
CAUTION
Before driving, be sure that the hood is closed and
securely locked. Otherwise, the hood may open
unexpectedly while driving and an accident may occur.
EXTERIOR EQUIPMENT
69
TRUNK LID
15G003–1
To unlock the trunk lid, insert the master key and turn it
clockwise.
To close the trunk lid, lower it and press down on it. After
closing the trunk lid, try pulling it up to make sure it is securely
closed.
The trunk lid can be unlocked using the wireless remote control
key. For details, see page 15.
CAUTION
Keep the trunk lid closed while driving. This not only
keeps the luggage from being thrown out, but also
prevents exhaust gases from entering the vehicle.
Always lock the trunk lid and all doors, and keep
away the vehicle keys out of children’s reach.
Never leave children unattended in the vehicle. Un
supervised children may lock themselves in the
vehicles or tru n k a n d s u ffer serious injuries or death.
Trunk lid opener
15G004
1
Main switch 2Operative 3Inoperative
To open the trunk lid while sitting in the driver’s seat, pull
the lever with the main switch not pushed in.
EXTERIOR EQUIPMENT
70
15G005
1
If you do not want to activate the trunk lid opener
system, push in the main switch.
2
To activate the system, insert the master key and turn
it counterclockwise.
To protect things put in the trunk, when you have your vehicle
parked, push in the main switch.
Internal trunk release handle
15g027a
If a person is locked in the trunk, he/she can pull down the
phosphorescent handle on the inside of trunk lid to open
the trunk lid.
The phosphorescent (glow–in–the–dark) handle will continue
to glow for a time after the trunk lid is closed. Exposing the
handle to stronger light will cause it to glow longer.
EXTERIOR EQUIPMENT
71
FUEL TANK CAP
15G006
1. To open the fuel filler door, pull the lever under the
instrument panel.
When refueling, turn off the engine.
CAUTION
Do not smoke, cause sparks or allow open flames
when refuelling. The fumes are flammable.
When opening the cap, do not remove the cap
quickly. In hot weather, fuel under pressure could
cause injury by spraying out of the filler neck if the
cap is suddenly removed.
15G007a
2. To remove the fuel tank cap, turn the cap slowly
counterclockwise, then pause slightly before removing it.
The removed cap can be stored on the back side of the fuel
filler door.
It is not unusual to hear a slight swoosh when the cap is
opened. When installing the cap, turn the cap clockwise until
you hear a click.
If the cap is not installed securely, the malfunction indicator
lamp comes on. Make sure the cap is installed securely.
The indicator lamp goes off after driving several times. If the
indicator lamp does not go off, contact your Lexus dealer as
soon as possible.
EXTERIOR EQUIPMENT
72
CAUTION
Make sure the cap is installed securely to prevent fuel
spillage in the event of an accident.
Use only a genuine Lexus fuel tank cap for
replacement. It is designed to regulate fuel tank
pressure.
In case the opener is not actuated
15G008a
Pull the manual lever toward the back.
This is used in case the fuel filler door cannot be opened due
to a discharged battery or other trouble.
MOON ROOF
15G011–1
1
Open 2Close
To slide open the moon roof, push the switch toward the
back. The moon roof will fully open. To stop partway,
push the same switch or ”TILT” switch.
The sun shade can be opened or closed manually . However,
if you open the moon roof, the sun shade will be opened with
the moon roof.
To close the moon roof, push the switch toward the front.
The moon roof will fully close. To stop partway, push the
same switch or ”TILT” switch.
EXTERIOR EQUIPMENT
73
15G012–1
1
Tilt up 2Lower
To tilt up the rear end of the moon roof fully, push the
switch on the rear side or on the front side to lower it.
To operate the moon roof, the ignition key must be in the ”ON”
position.
Key off operation: Even if the ignition key is turned to the
”ACC” or ”LOCK” position, the moon roof can be operated until
any of the doors is opened (or for about 45 seconds).
Operating the moon roof from outside the
vehicle
The moon roof can be closed or opened using an ignition key.*
Insert the ignition key into the key hole on the driver’s
door.
To close the moon roof: Turn the key in the locking direction
and hold it.
After the door is locked, the moon roof begins to close. To stop
in the middle, return the key.
To open the moon roof: Turn the key in the unlocking
direction and hold it.
After the door is unlocked, the moon roof begins to open. To
stop in the middle, return the key.
NOTE: *This feature can be set inoperative, or sliding open
or tilting up can be selected. Ask your Lexus dealer for
details.
EXTERIOR EQUIPMENT
74
Jam protection function
If something gets caught into the roof opening during closing
operation, the moon roof stops and is open.
If the moon roof receives a strong impact, this function may
work even if nothing is caught.
CAUTION
To avoid serious personal injury, you must do the
following.
While the vehicle is moving, always keep the heads,
hands and other parts of the bodies of all occupants
away from the roof opening. Otherwise, they could
be seriously injured if the vehicle stops suddenly or
if the vehicle is involved in an accident.
Before you close the moon roof, always make sure
there is nobody around the moon roof. You must also
make sure nobody places his or her head, hands and
other parts of the body in the roof opening. If
someone’s neck, head or hands get caught in the
closing roof, it could result in death or serious injury .
When anyone closes the moon roof, first make sure
it is safe to do so.
Be sure to remove the ignition key when you leave
your vehicle.
Never leave anyone (particularly a small child) alone
in your vehicle, especially with the ignition key still
inserted. Otherwise, he/she could use the moon roof
switches and get trapped in the roof opening.
Unattended person ( p articularly a small child) can be
involved in a serious accident.
Never sit on top of the vehicle around the roof
opening.
Never try jamming any part of your body to activate
the jam protection function intentionally.
The jam protection function may not work if
something gets caught just before the moon roof
fully closed.
Loading...
