About your printer

Finding information about the printer

The Quick Reference Guide contains basic instructions on how to accomplish common printer tasks like printing, copying, and scanning. It also includes information on troubleshooting common printer setup problems.

For additional information about the printer, see the following:

What are you looking for? Find it here

Initial setup instructions

Additional setup and instructions for using the printer

• Quick Setup Sheet

• Hardware Setup Wizard

Comprehensive User's Guide installed automatically with the printer software.

After installing your printer, you can access the User's Guide from the printer program folder:

For Windows users

1 Click or Start. 2 Click All Programs or Programs, and then select the printer

program folder from the list.

3 Select View User's Guide.

For Macintosh users

1 From the Finder desktop, double-click the printer folder. 2 Double-click User's Guide.

Help using the printer software

The latest supplemental information, updates, online technical support, and telephone support

Available on the installation software CD and on the Lexmark Web site at www.lexmark.com/publications/.

Software Help installed automatically with the printer software. Click Help from any printer software program or application.

Support Web site—support.lexmark.com

Minimizing your printer's environmental impact

We are committed to protecting the environment and are continually improving our printers to reduce their environmental impact. By selecting certain printer settings or tasks, you may be able to reduce your printer's environmental impact even further.

Conserving energy

• Activate Eco-Mode. This feature sets the screen brightness to low and sets the printer to change to Power Saver

mode after the printer is left idle for 10 minutes.

• Select the lowest Power Saver timeout. The Power Saver feature puts the printer in a minimum-power standby

mode after the printer has been idle for a set amount of time (the Power Saver timeout).

About your printer

• Share your printer. Wireless/network printers allow you to share a single printer among multiple computers,

thus conserving energy and other resources.

Conserving paper

• Activate Eco-Mode. On selected printer models, this feature sets the printer to automatically print on both sides

of the paper (duplex) for copy and fax jobs and for printing in Windows.

• Print more than one page image on one side of the paper. The “Pages per sheet” feature allows you to print

multiple pages on one sheet. You can print up to 8 page images on one side of a sheet of paper.

• Print on both sides of the paper. Duplexing lets you print on both sides of the paper manually or automatically

(depending on your printer model).

• Preview print jobs before printing. Use the preview features found in Toolb ars, the Print or Print Preview dialog,

or the printer display (depending on your printer model).

• Scan and save. To avoid printing multiple copies, you can scan documents or photographs and save them to a

computer program, application, or flash drive for presentation.

• Use recycled paper.

Conserving ink

• Use Quick Print or Draft Mode. These modes can be used to print documents using less ink than normal and

are ideal for printing documents that are mostly text.

• Use High Yield cartridges. Inks in High-Yield cartridges allow you to print more pages with fewer cartridges.

• Clean the printhead. Before replacing and recycling your ink cartridges, try using the “Clean Printhead” and

“Deep Clean Printhead” features. These features clean the printhead nozzles to improve the quality of your prints.

Recycling

• Return ink cartridges for reuse or recycling through the Lexmark Cartridge Collection Program. To return

an ink cartridge, go to www.lexmark.com/recycle. Follow the instructions to request a postage-paid bag.

• Recycle the product packaging.

• Recycle your old printer instead of throwing it away.

• Recycle paper from discarded print jobs.

• Use recycled paper.

To read the Lexmark Environmental Sustainability Report, see www.lexmark.com/environment.

Printer models

The installation software CD that came with your printer works for the following printer models:

• Lexmark Pro805

• Lexmark Pro803

About your printer

Printer features

Your printer comes with full features that will help you manage and accomplish printing and imaging tasks:

• Wireless or Ethernet networking. Print and scan from virtually anywhere in your home or office over a secure

wireless or Ethernet network, as well as share the printer among multiple computers.

• Intuitive touch screen. Use the full-featured color touch screen for fast, easy access to all the printer menus. The

large screen also allows you to view, edit, and print photos directly from your digital camera or memory device without using a computer.

• Print. Print documents and PDFs faster from a computer, from a USB flash drive, or from a Bluetooth device.

Built-in two-sided printing lets you save money and the environment.

• Copy. Copy documents and photos with one-touch, computer-free black or color copying. Enjoy 25% to 400%

reduction and enlargement capacity.

• Scan. Scan thick books, reports, and other multiple-page documents easily with the high resolution scanner.

Easily scan to a memory device or to multiple laptops or PCs over a secure wireless network with up to 1200 x 4800 optical resolution.

• Photo printing. Print high quality, long-lasting photos directly from digital memory cards, PictBridge-enabled

digital cameras, and USB flash drives. Select photos to print using the proof sheet for computer-free printing.

• SmartSolutions. Simplify printer tasks that you frequently repeat by creating and customizing your printer

solutions. Using the SmartSolutions toolkit on the Web, you can choose the printer tasks that you often perform, apply your custom settings, and download them to your printer as shortcuts that you can easily access anytime. You can also customize your printer with solutions that display your online calendars, RSS feeds, and more.

• Eco-Mode. Save energy and paper by activating Eco-Mode. It automatically dims the printer display light, puts

the printer into Power Saver mode after 10 minutes of inactivity, and prints on both sides of the paper for copy jobs and for printing in Windows.

About your printer

Understanding the parts of the printer

Use the To

Scanner lid Access the scanner glass.

Scanner glass Scan and copy photos and documents.

3 Automatic Document Feeder (ADF) Scan, copy, or fax multiple-page letter-, legal-, and A4-size documents.

ADF tray Load original documents in the ADF. Recommended for scanning, copying,

or faxing multiple-page documents.

Note: Do not load postcards, photos, small items, or thin media (such as magazine clippings) into the ADF. Place these items on the scanner glass.

ADF paper guide Keep paper straight when feeding it into the ADF.

Note: Adjust the paper guide on the ADF tray to the width of the original

document.

ADF output tray Hold documents as they exit from the ADF.

Wi-Fi indicator Check wireless status.

Memory card slot Insert a memory card.

PictBridge and USB port Connect a PictBridge-enabled digital camera, a USB Bluetooth adapter, or a

flash drive to the printer.

Printer control panel Operate the printer.

Paper tray Load paper.

Paper exit tray Hold paper as it exits.

About your printer

Use the To

Scanner unit

• Access the ink cartridges and printhead.

• Remove paper jams.

Printhead Install, replace, or remove ink cartridges.

3 Ethernet port Connect your printer to a computer, a local network, an external DSL, or a cable modem.

USB port Connect the printer to a computer using a USB cable.

Warning—Potential Damage: Do not touch the USB port except when plugging in or

removing a USB cable or installation cable.

Power supply with port Connect the printer to a power source.

Duplex unit

• Print on both sides of a sheet of paper.

• Remove paper jams.

Using the printer control panel

The following diagrams explain the sections of the printer control panel:

Note: The icons are displayed when they are selectable on the current screen. If an icon is not displayed, then the function is not available.

About your printer

Use To

1 Power

• Turn the printer on and off.

• Switch to Power Saver mode.

Note: When the printer is on, press

for three seconds to turn

2 Back

Saver mode. Press and hold off the printer.

• Return to the previous screen.

• Exit from one menu level to a higher one.

Touch screen display

Note: The display is turned off in Power Saver mode.

• Navigate the printer menus.

• Change settings.

• View printer messages and animation.

Start Start a job, depending on which mode is selected.

Cancel Cancel the current job or task.

Help Display Help text and animation.

7 Home Return to the home screen.

to switch to Power

Understanding the home screen

After the printer is turned on and a short warm-up period occurs, the display shows the following basic screen which is referred to as the home screen. Use the home screen selections to initiate an action, such as copying or scanning, or to change printer settings.

About your printer

Display item Description

Copy Access the copy menu and make copies.

Scan Access the scan menu and scan documents.

Memory Device

PictBridge

SmartSolutions Open the SmartSolutions menu.

Ink levels

View, select, print, or attach photos and documents to e-mail.

Note: This icon appears only when you return to the home screen while a memory card, flash drive, or PictBridge-enabled camera is connected to the printer.

• Display the current ink levels of the installed tanks.

• Access cartridge maintenance and information functions.

6 Setup Access the setup menu and change printer settings.

About your printer

Display item Description

2-Sided Print on both sides of a sheet of paper.

Eco-Mode Activate Eco-Mode to select the following options:

• Print on both sides of the paper (duplex).

• Change to Power Saver mode after the printer is left idle for 10 minutes.

• Set screen brightness to low.

Navigating menus using the printer control panel

Touch-screen models

• To perform a new task, always start from the home screen. Touch to open the home screen.

• To scroll through the menus, drag the scroll bar or touch the arrows on the display.

• To open a menu or submenu, touch the menu name or icon.

• To select a setting, touch a menu item, and then touch Accept or OK to save the setting.

Arrow-button models

• To scroll through the men us, use the ar row buttons on the printer control panel, and then press to open menus

and submenus.

• Press to select and save a setting.

About your printer

Using memory cards and flash drives

Using a memory card or flash drive with the printer

Memory cards and flash drives are storage devices frequently used with cameras and computers. You can remove the memory card from the camera or the flash drive from the computer and insert it directly into the printer.

1 Insert a memory card into the card slot or a flash drive into the USB port.

Inserting a memory card Inserting a flash drive

Notes:

• Insert the card with the brand name label facing right.

• Make sure any arrows on the card point toward the

printer.

• If necessary, connect the memory card to the adapter

that came with it.

• Make sure that the memory card inserted is supported

by the printer. For more information, see “Supported memory cards and file types” on page 14.

Warning—Potential Damage: Do not touch any cables, any network adapter, any connector, the memory device, or the printer in the areas shown while actively printing, reading, or writing from the memory device. A loss of data can occur.

2 The Memory Device screen appears on the display.

Notes:

• The flash drive uses the same port that is used for a

PictBridge camera cable.

• An adapter may be necessary if your flash drive does

not fit directly into the port.

Notes:

• If the printer does not recognize the memory device, then remove and reinsert it.

• If a flash drive or a digital camera set to mass storage mode is inserted into the USB port while a memory card is

in the card slot, then a message appears on the display prompting you to choose which memory device to use.

About your printer

Supported memory cards and file types

Memory Card File Type

• Secure Digital (SD)

• Secure Digital High Capacity (SDHC)

• Micro Secure Digital (with adapter) (Micro SD)

• Mini Secure Digital (with adapter) (Mini SD)

• MultiMedia Card (MMC)

• Reduced Size MultiMedia Card (with adapter) (RS-MMC)

• MultiMedia Card mobile (with adapter) (MMCmobile)

• Memory Stick

• Memory Stick PRO

• Memory Stick Duo (with adapter)

• Memory Stick PRO Duo (with adapter)

• xD-Picture Card

• xD-Picture Card (Type H)

• xD-Picture Card (Type M)

Documents:

• .doc (Microsoft Word)

• .xls (Microsoft Excel)

• .ppt (Microsoft PowerPoint)

• .pdf (Adobe Portable Document Format)

• .rtf (Rich Text Format)

• .docx (Microsoft Word Open Document Format)

• .xlsx (Microsoft Excel Open Document Format)

• .pptx (Microsoft PowerPoint Open Document Format)

• .wpd (WordPerfect)

Images:

• JPEG

• TIFF

About your printer

+ 31 hidden pages
