MS820e Series
Reliability. Security. Productivity.
MS826de
This is a Class A device according to international electromagnetic emissions standards (i.e. FCC Rules, EN 55022/EN 55032, etc.). Class A products are
intended for use in non-residential/non-domestic environments. Use of a Class A product in residential/domestic environments may cause interference to
radio communications and require corrective measures.
18KDO8036
Page 2
Lexmark MS820e Series
Large workgroups need maximum performance and the Lexmark MS820e Series delivers with a first page as fast as 4 seconds and
output up to 70 pages per minute*. A 4.3-inch/10.9-cm e-Task touch screen supports productivity-enhancing apps while Ultra High
Yield replacement toner** and flexible input and output options keep things going for the longhaul.
Ready when you are
} Long-life fuser and imaging components extend uptime.
} Unison™ Toner replacement cartridges deliver up to 55,000
pages** of high-quality printing.
} Steel frame and durable design stands up to heavy use and
harsh environments.
Get more done
} Powerful 1-GHz dual-core processor and up to 5 GB of
memory drives printing at up to 70 ppm.*
} Robust paper handling includes reliable feeding of a wide
range of media types and sizes, up to 4400 sheets of
standard input and optional finishing.
} Connect via Ethernet, USB, or simple mobile printing options.
Interact with ease
} Intuitive 4.3-inch/10.9-cm color touch screen offers smooth,
tablet-like interaction with customizable convenience and
productivity apps.
} Front access to the paper path and power button means
you’ll virtually never have to access the back of the device,
allowing placement in or on cabinets.
} Innovative serviceability features, starting with single-
door access to parts and supplies, help you resolve
problems quickly.
Full-spectrum security
} Lexmark’s full-spectrum security architecture helps keep
your information safe—in the document, on the device and
over the network.
} Keypoint Intelligence - Buyers Lab honored Lexmark
with a prestigious BLI PaceSetter award for Document
Imaging Security***.
Built for planet earth
} Energy management features reduce power consumption in
active use or sleep mode.
} Standard two-sided printing saves paper.
} Device is rated EPEAT® Silver and ENERGY STAR® certified.
} Recycle cartridges through the award-winning Lexmark
Cartridge Collection Program (LCCP).
*Print an d copy speeds mea sured in accordance with ISO/IEC 2473 4 and ISO/IEC 24735 resp ectively ( ESAT). For more informati on see: www.lexmark .com/ISOspe eds.
**Average sta ndard page yiel d value declared i n accordance with I SO/IEC 19752. Ultra High Y ield cartridge not availab le for all models .
***Award bas ed on North Ame rica and/or Wester n Europe data
lexmark.com
18KDO8036
2
Page 3
Lexmark MS820e Series
1 Printer with 4.3-inch (10.9 cm)
e-Task color touch screen
17.4 x 16.85 x 20.1 inches
441 x 428 x 510 mm
2 100-sheet multipurpose feeder
Dimensions included as part of base model
3 550-sheet tray
Dimensions included as part of base model
4 550-sheet tray
4.3 x 16.85 x 20.1 inches
110 x 428 x 510 mm
5 2100-sheet tray
13.8 x 16.85 x 20.1 inches
350 x 428 x 510 mm
6 Caster base
5 x 20.5 x 27.3 inches
126 x 521 x 693 mm
Note 1: Supports up to 4 optional trays. For maximum paper input capacity, install 3 optional 550-sheet trays and one optional 2100-sheet tray. When a 2100-sheet tray is
installed, it must be the bot tom tray, and a caster base isrequired.
Note 2: Supports many output configurations, including: any combination of up to three output expanders and 4-bin mailboxes; OR staple finisher with 4-bin mailbox; OR staple
finisher with output expander; OR output expander with high capacity output expander; OR the staple, hole punch finisher; OR any single output option by itself. When installing
the optional stapler, it must always be on top. When installing the optional high capacity output expander, it must always be on the bottom.
Note 3: All measurements are shown as height x width x depth. For more information about supported configurations, refer to the Printer, Option and Stand Compatibility Guide
athttp://www.lexmark.com/publications/furniture_safety/
7 Staple, hole punch finisher
10.3 x 18.2 x 20.0 inches
263 x 462 x 507 mm
8 Staple finisher
9.7 x 17.1 x 16.3 inches
246 x 435 x 414 mm
9 Output expander
6.5 x 16.6 x 15.0 inches
165 x 421 x 380 mm
10 4-Bin mailbox
10.7 x 16.6 x 15.1 inches
272 x 421 x 384 mm
11 High capacity output expander
12.2 x 16.6 x 13 .2 inches
310 x 421 x 335 mm
12 250-sheet tray
3.2 x 16.85 x 20.1 inches
80 x 428 x 510 mm
13 550-sheet lockable tray
4.3 x 16.85 x 20.1 inches
110 x 428 x 510 mm
14 250-sheet lockable tray
3.2 x 16.85 x 20.1 inches
80 x 428 x 510 mm
15 Swivel cabinet
10.4 x 18.7 x 23.6 inches
263 x 476 x 600 mm
16 Adjustable printer stand
23 x 23.5 x 23.5
584.2 x 596.9 x 596.9
17 Spacer to add additional height
4.3 x 16.85 x 20.1 inches
110 x 428 x 510 mm
Standard
Optional
© 2018 Lexma rk. All rights reserved .
Lexmar k, the Lexma rk logo and Uniso n are trademark s of Lexmark Intern ational, Inc. , registered in t he United States and/or other cou ntries. AirPr int® and the Ai rPrint Logo® are trad emarks of Apple , Inc. ENERGY
STA R® is a U.S. re gistered mark . Google Cloud Pr int™ is a trademark o f Google, Inc. M OPRIA®, the Mopria® Logo™ and the Mopria® Allian ce logos are trade marks, serv ice marks, and ce rtification ma rks of Mopria
Allian ce, Inc. in the Unit ed States and ot her countries. A ll other tradem arks are the prop erty of their re spective owner s. All other trademarks ar e the propert y of their respec tive owners.
This pro duct includes s oftware devel oped by the OpenS SL Project for use i n the Open SSL Toolkit ( http://www.openss l.org/).
lexmark.com
18KDO8036
3
Page 4
Product specifications Lexmark MS822de Lexmark MS826de
Printing
Display
Print Speed: Up to
Time to First Page: As fast as
Print Resolution
Memory
Hard Disk
Recommended Monthly Page Volume
Maximum Monthly Duty Cycle: Up to
Supplies
Laser Cartridge Yields (up to)
Imaging Unit Estimated Yield: Up to
Cartridge(s) Shipping with Product
6
2
3
7
1
1
Paper Handling
Included Paper Handling
Optional Paper Handling
Paper Input Capacity: Up to
Paper Output Capacity: Up to
Media Types Supported
Media Sizes Supported
General Information
Standard Ports
Optional Network Ports / Optional Local Ports
Noise Level: Operating
Specified Operating Environment
Limited Warranty - See Statement of Limited Warranty
Size (in. - H x W x D) / Weight (lb.)
4
Lexmark e-Task 4.3-inch (10.9 cm) color touch screen Lexmark e-Task 4.3-inch color touch screen
Black: 55 ppm Black: 70 ppm
Black: 4.5 seconds Black: 4.0 seconds
Black: 1200 Image Quality, 1200 x 1200 dpi, 2400 Image Quality, 300 x 300 dpi, 600 x 600 dpi
Standard: 1024 MB / Maximum: 5120 MB
Option available
3000 - 50000 pages 5000 - 100000 pages
250000 pages per month 350000 pages per month
7,500-page Cartridge, 15,000-page High Yield Cartridge 7,500-page Cartridge, 15,000-page High Yield Cartridge,
35,000-page Extra High Yield Cartridge, 55,000-page Ultra
High Yield Cartridge
150000 pages, based on 3 average letter/A4-size pages per print job and ~ 5% coverage
11,000-page Starter Return Program Toner Cartridge
550-Sheet Input, 100-Sheet Multipurpose Feeder, 550-Sheet Output Bin, Integrated Duplex
250-Sheet Tray, 550-Sheet Tray, 2100-Sheet Tray, 250-Sheet Lockable Tray, 550-Sheet Lockable Tray, 4-Bin Mailbox, Staple
Finisher, Staple Punch Finisher, High Capacity Output Expander, Output Expander
Standard: 650 pages 20 lb or 75 gsm bond / Maximum: 4400 pages 20 lb or 75 gsm bond
Standard: 550 pages 20 lb or 75 gsm bond / Maximum: 2550 pages 20 lb or 75 gsm bond
Card Stock, Dual Web Labels, Envelopes, Integrated Labels, Paper Labels, Plain Paper, Transparencies, Refer to the Paper &
10 Envelope, 7 3/4 Envelope, 9 Envelope, A4, A5, B5 Envelope, C5 Envelope, DL Envelope, Executive, Folio, JIS-B5, Legal,
One Internal Card Slot, USB 2.0 Specification Hi-Speed Certified (Type B), Gigabit Ethernet (10/100/1000), Front USB 2.0
Specification Hi-Speed Certified port (Type A), Rear USB 2.0 Specification Hi-Speed Certified Port (Type A)
Marknet N8370 WiFi Option, MarkNet N8230 Fiber Ethernet
Print Server / Internal RS-232C serial, Internal 1284-B
Bidirectional Parallel
Specialty Media Guide
Letter, Statement, Universal, Oficio, A6
Internal MarkNet N8350 802.11b/g/n Wireless / Internal RS-
232C serial, Internal 1284-B Bidirectional Parallel
Print: 57 dBA Print: 58 dBA
Humidity: 8 to 80% Relative Humidity, Temperature: 10 to 32°C (50 to 90°F), Altitude: 0 - 2896 Meters (9,500 Feet)
1-Year Advanced Exchange, Next Business Day
17.4 x 16.85 x 20.1 in. / 56.4 lb.
All information in this brochure is subject to change without notice. Lexmark is not liable for any errors or omissions. Some models may
be available without duplex.
This is a Class A device according to international electromagnetic emissions standards (i.e. FCC Rules, EN 55022/EN 55032, etc.).
Class A products are intended for use in non-residential/non-domestic environments. Use of a Class A product in residential/
domestic environments may cause interference to radio communications and require corrective measures.
1
Average s tandard pag e yield value dec lared in acco rdance with ISO/IEC 19752 . 2”Recommended Monthly Page Volu me” is a range of pages that help s customers evalu ate Lexmark’s product of ferings ba sed on the
average number of pa ges customers plan to pr int on the devi ce each month. Lex mark recommen ds that the numbe r of pages per mont h be within the s tated range for optimum device perform ance, based on factors
includ ing: supplies re placement inte rvals, paper l oading interv als, spee d, and typical cu stomer usa ge. 3”Maximum Monthly Duty Cycle” is de fined as the ma ximum number of p ages a device could d eliver in a month
using a mu ltishift oper ation. This met ric provides a comp arison of robus tness in rel ation to other Lexm ark printers an d MFPs. 4Printer s are sold subjec t to certain licen se/agr eement condit ions. See w ww.lexmark.
com/printerlicense for details. 5Actual Y ield may vary ba sed on other factors such as de vice speed, pap er size and feed ori entation, tone r coverage, tray so urce, percentag e of black-only prin ting and average p rint
job complexity. 6Print and c opy speeds meas ured in accordan ce with ISO/IEC 24734 and I SO/IEC 24735 respe ctively (ESAT). For more infor mation see: ww w.lexmark.com/I SOspeeds. 7Produc t functions on ly with
replac ement car tridges de signed for use in a specific geo graphical regi on. See www.lex mark.com/region s for more details .
