Lexmark KM330, KM630 User Manual

910 Series Photo Jetprinter™
Setup Solutions
Edition: September 2004
The following paragraph does not apply to any country where suc h provisions are inconsiste nt with local law : LEXMARK INTERNATIONAL, INC., PROVIDES THIS
PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRE SS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain transactions; therefore, this statement may not apply to you.
This publication could include technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in later editions. Improvements or changes in the products or the programs described may be made at any time.
Comments about this publication may be addressed to Lexmark International, Inc., Department F95/032-2, 740 West New Circle Road, Lexington, Kentucky 40550, U .S.A. In the United Kingdom and Eire, send to Lexmark International Ltd., Marketing and Services Department, Westhorpe House, Westhorpe, Marlow Bucks SL7 3RQ. Lexmark may use or distribute any of the information you supply in any way it believes appropriate without incurring any obligation to you. You can purchase additional copies of publications related to this product by calling 1-800-553-9727. In the United Kingdom and Eire, call +44 (0)8704 440 044. In ot her countries, contact your point of purchase.
References in this publication to products, programs, or services do not imply that the manufacturer intends to make these available in all countries in which it operat es. Any reference to a product, program, or service is not intended to state or imply that only that product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any existing intellectual property right may be used instead. Evaluation and verification of operation in conjunction with other products, programs, or services, except those expressly designated by the manufacturer , are the user’s responsibility.
Lexmark and Lexmark with diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. Photo Jetprinter is a trademark of Lexmark International, Inc.
Other trademarks are the property of their respective owners.
© 2004 Lexmark International, Inc. All rights reserved.
UNITED STATES GOVERNMENT RIGHTS
This software and any accompanying documentation provided under this agreement are commercial computer software and documentation developed exc lusively at private expense.
Contents
English ................................................................................ 5
English .............................................................................. 11
English .............................................................................. 17
English .............................................................................. 23
English .............................................................................. 29
English .............................................................................. 35
English .............................................................................. 41
English .............................................................................. 47
English .............................................................................. 53
3
4
English
Contents checklist
Verify that these items are in the box with your printer:
Note: Contents may vary based on geography.
6
5
4
3
2
English
1
1 Power supply and power cord 4 Photo print cartridge 2 Setup sheet 5 User’s Guide 3 Color print cartridge 6 Software CD
Note: Remove the photo cartridge from the print cartridge storage unit before installing it. Keep new cartridges in the storage unit.
5
Safety information
Use only the power supply provided with this product or the
manufacturer's authorized replacement power supply.
Connect the power supply cord to an electrical outlet that is near
English
the product and easily accessible.
Refer service or repairs, other than those described in the user
documentation, to a professional service person.
CAUTION: Do not set up this product or make any electrical or
cabling connections, such as the power supply cord, during a lightning storm.
Setup troubleshooting
Should your printer have a problem, this section helps you find the solution.
Symptom Solution
The Power light does not come on when the Power button is pressed
Printer is not communicating with the computer
Make sure the power cord is pushed all the way into the printer.
Disconnect the po wer cord from the wall outlet, an d t hen from the printer. Reconnect the power cord by pushing it all the way into the connector on the printer.
Make sure the printe r is us in g a working electrical out let. Connect it to one that other devices have been using.
Make sure your operating system is compatible with the printer, which supports these operating systems:
Windows 98
Windows Me
Windows 2000
Windows XP
Mac OS X version 10.1.5
Mac OS X versions 10.2.310.2.8, 10.3.010.3.4
Is your printer con ne cte d to your computer through another device, such as a USB hub or switch box? If so, disconnect the USB cable from any other devices and directly connect it between the printer and your computer.
Make sure t he USB c ab le is s ecurel y att ached to the printer and computer.
6
Symptom Solution
The printer is not functioning properly or a communications error message appears when you try to use your printer
The printer is displaying the wrong language
Alignment page or test page will not print
Check to see if the software was installed correctly:
For Windows
From your desktop, click Start Programs.
If Lexmark P910 Series does not appear in your list of programs, see Removing and reinstalling the software on page 9.
For Mac OS X
Is there a Lex mark 91 0 Series folder on your desktop? If not, see Removing and reinstalli ng the software on page 9.
1 If a memory card is inserted, remove it. 2 Turn the printer off and back on. 3 Press 4 Press the down arrow repeatedly until you reach the last
5 Press the 6 Press the right a r row until your language is displaye d. 7 Press Note: Press Menu to see the new language displayed.
Menu.
item.
up arrow twice.
Select.
1
Æ Programs or All
1
English
2
Verify that you removed the transparent tape from the bottom of each print ca rtridge.
Make sure the cartridges are installed correctly. The photo cartridge should be secure in the left carrier and the color cartridge should be secure in the right carrier.
2
7
Symptom Solution
Alignment page or test page will not print
English
(See more alignment page troubleshooting on page 7)
Press the Power button. If the Power light does not come on, see The P ow er light does not come on w hen the P o wer button is pressed symptom.
Check to see if the printer is set as the default printer.
For Windows
1 Click Start
2000). Click Start
(Windows XP).
2 Unless there is a check mark next to the printer
(indicating it is already set as the default printer), right-click Lexmark P910 Series and select Set as
Default Printer.
1 On your desktop, check to see if there is a Lexmark 910
Series folder. If it does not appear on your desktop, install the printer software.
2 Select Go
the Print Center icon.
– OS 10.2.3 or later: double-click Printer Setup Utility.
3 Select your printer in the Printer List and click Printers
Æ Settings Æ Printers (Windows 98, Me,
Æ Control Panel Æ Printers and Faxes
For Mac OS X
Æ Applications Æ Utilities and doub l e-c li ck
Æ Make Default.
– OS 10.2.3 or later: click the Make Default button on
the toolbar .
If the install screen did not appear:
1 From y our des ktop , doub le-cli ck the 910 Series Insta ller
icon.
2 Double-click Install and follow the instructions on your
screen.
8
Removing and reinstalling the software
For Windows:
1 From your desktop, click Start Æ Programs or All Programs Æ
Lexmark P910 Series Æ Uninstall Lexmark P910 Series.
2 Follow instructions on your screen to remove the printer software. 3 Restart your computer before reinstalling the printer software. 4 Insert the CD, and then follow the instructions on your screen to
install the software.
If the install screen does not appear:
1 Click Cancel on any New Hardware screens. 2 Eject and reinsert the printer software CD.
If the printer software installation screen does not appear:
a From your desktop, double-click My Computer (Windows 98,
Me, 2000). Windows XP users, click Start Æ My Computer.
b Double-click the CD-ROM drive icon. If necessary, double-click
Setup.
c When the printer software installation screen appears, click
Install or Install Now.
d Follow the instructions on your screen to complete the
installation.
English
For Mac OS X:
1 From your desktop, double-click the Lexmark 910 Series folder. 2 Double-click the 910 Series Uninstaller application. 3 Follow the instructions on your screen to remove the printer
software.
4 Restart your computer before reinstalling the printer software. 5 Insert the CD, click 910 Series Installer and follow the instructions
on your screen to install the software.
9
Finding more information
If these solutions do not solve your problem:
Refer to the Setup sheet that comes with your printer.
Refer to the User’s Guide or Help for your operating system:
English
For Windows: double-click the Lexmark P910 Series User’s Guide icon on your desktop.
Note: If you did not copy the User’s Guide to your computer
during the software installation, reinsert the printer software CD and click the View Users Guide icon.
For Mac OS X:
1 From your desktop, click the Lexmark 910 Series folder. 2 Double-click Lexmark 910 Series Utility. 3 Click the Help button.
Refer to the Lexmark Solution Center software:
For Windows:
1 Click Start Æ Programs or All Programs Æ Lexmark P910
Series Æ Lexmark Solution Center.
2 Click the Troubleshooting tab on the left side of the screen.
For Mac OS X:
1 From your desktop, double-click the Lexmark 910 Series folder
icon.
2 Double-click the Lexmark 910 Series Help alias. 3 Click the Troubleshooting topic link.
Go to http://support.lexmark.com/ for help.
