Lexmark C792 Family color laser printers

Flexible, robust color printing

Models

Lexmark C792 Family

The Lexmark C792 Family color laser printers combine robust design with brilliant color printing, exceptional media handling, flexible finishing options and an intuitive color touch screen.

Other available models: Lexmark C792e: Enjoy the benefits of workgroup color laser printing through a robust design

combined with exceptional media handling and an intuitive color touch screen.

Lexmark C792de: Includes duplex Lexmark C792dte: Includes duplex and additional 550-sheet drawer Lexmark C792dhe: Includes duplex, hard disk, three additional 550-sheet

drawers,1GB memory and caster base

1]Z]`

Touch screen

Solutions

Up to 50 ppm

Duplex*

Network

* Duplex not available on C792e model.

Page 2

Lexmark C792 Family: key features

Lexmark C792dhe color laser printer shown with optional ﬁnisher

Features that help you optimize your work

2) Flexible output options

Choose from four output options, including a ﬁve-bin mailbox, an offset stacker, a staple ﬁnisher, and a staple with hole punch ﬁnisher.

5) Expandable input

Print on multiple paper types and boost total capacity up to 3,200 sheets.

3) Direct USB

A front USB port allows for convenient walk-up preview and printing and is compatible with most printable image ﬁle formats.

6) Long-lasting toner

The Lexmark Extra High Yield Print Cartridge delivers up to 20,000* pages, reducing interventions, cartridge waste and cost.

1) Intuitive color touch screen

The 4.3-inch color touch screen allows you to operate your printer with ease and conﬁdence through smart and intuitive navigation, easy access to workﬂow solutions and shortcuts, and the ability to preview your documents and print jobs at the device.

4) Lexmark solutions

Reduce unnecessary printing and simplify work processes through solutions applications preloaded on your device. Choose additional Lexmark solutions to ﬁt your unique workﬂow needs.

7) Eco-friendly features

Easy-to-access features make it easy to print responsibly, including Eco-Mode to reduce paper and toner consumption, and the Sleep button and Hibernate Mode to help you save energy.

*Average continuous black or composite CMY declared cartridge yield in accordance with ISO/IEC 19798.

Page 3

Lexmark C792 Family: overview

Robust Color Printing

Designed for medium to large workgroups, the Lexmark C792 Family meets the demands of your busy color-printing environment. Vibrant, professional-quality output and the ability to print on a wide variety of media allow you to do more color printing in-house. With the advanced color laser technology of the C792 Family, you’ll get excellent, consistent color from the ﬁrst page to the last.

●

Lexmark Extra High Yield Print Cartridge available, offering yields of up to 20,000* pages

●

Print and duplex** speeds as fast as 50 ppm in both black and color

●

PANTONE® calibration for consistent color tones

●

Named Color Replacement for easy color matching

●

Lexmark Color Care Technology to manage color usage and control costs

●

Instant warm-up fuser to help reduce energy consumption and improve time to ﬁrst page

Flexibility

Choose from a variety of models to best serve your needs. Select from a number of expandability options and ﬁnishing features you would expect from more expensive products.

●

Ultra-reliable paper feeding to support diverse media, including card stock, labels, UV-resistant outdoor media, banner media and more

●

Robust output options, including a ﬁve-bin assignable mailbox, an offset stacker, a staple ﬁnisher, and a staple with hole punch ﬁnisher

●

Input capacity expandable to up to 3,200 sheets with the high-capacity feeder and an extra drawer

●

Connectivity and application solution cards allow integration into most IT environments

Easy and Intuitive

The Lexmark C792 Family is designed for easy operation and maintenance.

●

4.3-inch color touch screen provides audible feedback to make completing tasks intuitive

●

Print Preview features help you select documents or speciﬁc pages within a document

●

Directional lights on the device provide visual cues to guide you through tasks and maintenance operations

●

Ability to change settings such as duplex** or stapling at the device

●

Available device ﬂeet management software

●

Sleep button and Hibernate Mode, helping to reduce energy costs

*Average continuous black or composite CMY declared cartridge yield in accordance with ISO/IEC 19798. ** Duplex not available on C792e model.

Page 4

Lexmark C792 Family: solutions

Print Less. Save More.

Print less? This may seem like a surprising message for a company dedicated solely to printing. But when you consider that businesses spend on average up to 6% of their revenue on printing and that active print management can cut ofﬁce print costs by up to 30%*, it makes a lot of sense. Lexmark products, solutions and services provide innovative ways to save you time, drive down costs and reduce your impact on the environment. We are committed to helping you print less and save more.

Solutions

Save time and money through solutions

Reduce unnecessary printing and simplify work processes with Lexmark solutions. The C792 Family features the Lexmark Embedded Solutions Framework (eSF), our platform that enables you to add a wide range of software applications directly onto the device. Solutions are designed with your productivity in mind, helping you streamline—or even eliminate—paper intensive business processes.

Below are solutions that come preloaded on the C792 Family. A diverse portfolio of additional Lexmark solutions is available to help accommodate your workﬂow needs.

Forms and Favorites

Eliminate waste and inefﬁciencies associated with preprinted forms. Store frequently printed forms, marketing materials or other documents online, then print them on demand.

Eco-Settings

Choose from multiple print settings that help reduce energy, paper and toner consumption.

Background and Idle Screen

Change the touch screen background to your corporate logo, a unique message, or select one of the four screens that are preloaded on the device.

Change Language**

Easily switch the language displayed on the touch screen – 18 languages supported.

Showroom

Display a customizable, scrolling slideshow on the color touch screen to promote your business or products, or to communicate important messages to your customers or employees.

* Source: InfoTrends/CapVentures, Network Document Solutions Forecast 2007-2012, Network Document Solutions Consulting Service, August 2008 ** Opt-in to Change Language during installation

Page 5

Lexmark C792 Family: highlights

Make a lasting impression with award-winning color

The documents you print deﬁne an important image – yours. That’s why Lexmark color lasers help businesses be more productive and stand out with vibrant color. With the ability to print professional quality color in-house, you can add instant impact and save costs by virtually eliminating the need to outsource print jobs. Lexmark also offers a host of color-access and control tools to manage costs.

Functions

The right touch

The Lexmark e-Task color touch screen is a key access point to your printer. The customizable 4.3-inch interface gives you the ability to preview thumbnails of documents prior to printing, as well as change print jobs at the device. You can even view, select and print speciﬁc pages within a document directly from the touch screen. Its easy-to-use, intuitive navigation provides fast access to the functions, shortcuts and workﬂows you use most. New interactive sensory features provide audible feedback, helping to guide you through each operation, conﬁrming a touch has registered and indicating an action is transpiring.

Protecting your information

From the data traveling through your network to the pages being printed, Lexmark’s innovative security controls give you peace of mind that your valuable corporate data is protected at every stage.

●

Cutting-edge user authentication and authorization controls, including LDAP, help protect your device and data

●

Card reader option to add an extra layer of security

●

Hard disk encryption protects sensitive data on the disk drive

True Image Always

Lexmark is dedicated to designing and manufacturing products that deliver exceptional quality and reliable performance. Maximize the return on your investment, extend the service life of your Lexmark printing equipment and make a lasting impression by always insisting on Lexmark Genuine Supplies, Service and Parts. Lexmark C792 Family color laser printers are backed by a one-year base warrany For further protection against unexpected expenses or downtime, extended warranty offerings are available.

●

Automatic, scheduled or manual disk wiping

●

IPSec, SNMPv3 and 802.1x network security supported

●

Security-audit logging to help track and identify security risks

Page 6

Lexmark C792 Family: ordering information

Lexmark C792de

Integrated Duplex

500-Sheet Output Bin

100-Sheet Multipurpose Feeder

550-Sheet Drawer 550-Sheet Drawer

2,000-Sheet High-Capacity

Feeder

500-Sheet Offset Stacker 500-Sheet Staple Finisher 5-Bin Mailbox500-Sheet Staple Punch Finisher

Spacer Caster Base (Required for ﬂoor

550-Sheet Input Tray

standing conﬁguration)

Standard

Optional

Eco-responsible printing

Printing responsibly means everyone wins – your business, your budget and the environment. Lexmark’s award-winning products are designed for ease of use, high quality output and reliable performance, with innovative capabilities that help you minimize the number of cartridges you use over the life of the printer and conserve paper and energy. Our goal is to design, package and deliver innovative products and solutions in an environmentally responsible manner.

Page 7

Lexmark C792 Family: ordering information

Lexmark C792e

Part # Model

47B0000 Lexmark C792e

Part # Laser Toner/Print Cartridge

C792X1KG C792 Black Extra High Yield Return Program Print Cartridge C792X1CG C792 Cyan Extra High Yield Return Program Print Cartridge C792X1MG C792 Magenta Extra High Yield Return Program Print Cartridge C792X1YG C792 Yellow Extra High Yield Return Program Print Cartridge C792A1KG C792, X792 Black Return Program Print Cartridge C792A1CG C792, X792 Cyan Return Program Print Cartridge C792A1MG C792, X792 Magenta Return Program Print Cartridge C792A1YG C792, X792 Yellow Return Program Print Cartridge C792X2KG C792 Black Extra High Yield Print Cartridge C792X2CG C792 Cyan Extra High Yield Print Cartridge C792X2MG C792 Magenta Extra High Yield Print Cartridge C792X2YG C792 Yellow Extra High Yield Print Cartridge C792X77G C792, X792 Waste Toner Bottle 25A0013 Staple Cartridges (3 pack)

Part # Paper Handling

47B0110 C792, X792 550-Sheet Drawer

Lexmark C792de

Part # Model

47B0001 Lexmark C792de

Part # Laser Toner/Print Cartridge

Part # Paper Handling

47B0110 C792, X792 550-Sheet Drawer

47B0111 C792, X792 2000-Sheet High Capacity Feeder 47B1101 C792, X792 5-Bin Mailbox 47B1102 C792, X792 500-Sheet Offset Stacker 47B1100 C792, X792 500-Sheet Staple Finisher 47B1103 C792, X792 500-Sheet Staple, Hole Punch Finisher 47B0112 C792, X792 Spacer 47B0113 C792, X792 Banner Media Tray

Part # Furniture

47B0114 C792, X792 Caster Base

Part # Extended Warranties

2353754 C792 2-Years Total Onsite Service, Next Business Day 2353755 C792 3-Years Total Onsite Service, Next Business Day 2353756 C792 4-Years Total Onsite Service, Next Business Day 2353757 C792 5-Years Total Onsite Service, Next Business Day 2353758 C792 1-Year Onsite Service Renewal, Next Business Day

Part # Installation Service

2353761 C792 Install, De-Install Service

Part # Furniture

47B0114 C792, X792 Caster Base

Part # Extended Warranties

Part # Installation Service

2353761 C792 Install, De-Install Service

In the box

Lexmark C792e color laser printer, Up to 11,000*page Cyan, Magenta, Yellow Starter Print Cartridges, Up to 8,500*-page Black Starter Print Cartridge, Software and Documentation CD, Power Cord(s), Setup Guides (network and local attachment), Statement of limited warranty, Lexmark Cartridge Collection Program information

In the box

Lexmark C792de color laser printer, Up to 11,000*page Cyan, Magenta, Yellow Starter Print Cartridges, Up to 8,500*-page Black Starter Print Cartridge, Software and Documentation CD, Power Cord(s), Setup Guides (network and local attachment), Statement of limited warranty, Lexmark Cartridge Collection Program information

Lexmark C792dte

Part # Model

47B0002 Lexmark C792dte

Part # Laser Toner/Print Cartridge

Part # Paper Handling

47B0110 C792, X792 550-Sheet Drawer

Lexmark C792dhe

Part # Model

47B0003 Lexmark C792dhe

Part # Laser Toner/Print Cartridge

Part # Paper Handling

47B1101 C792, X792 5-Bin Mailbox

Part # Furniture

47B0114 C792, X792 Caster Base

Part # Extended Warranties

Part # Installation Service

2353761 C792 Install, De-Install Service

47B1102 C792, X792 500-Sheet Offset Stacker 47B1100 C792, X792 500-Sheet Staple Finisher 47B1103 C792, X792 500-Sheet Staple, Hole Punch Finisher 47B0113 C792, X792 Banner Media Tray

Part # Extended Warranties

Part # Installation Service

2353761 C792 Install, De-Install Service

In the box

Lexmark C792de color laser printer, Up to 11,000*page Cyan, Magenta, Yellow Starter Print Cartridges, Up to 8,500*-page Black Starter Print Cartridge, 550-Sheet drawer, Software and Documentation CD, Power Cord(s), Setup Guides (network and local attachment), Statement of limited warranty, Lexmark Cartridge Collection Program information

In the box

Lexmark C792de color laser printer, Up to 11,000*page Cyan, Magenta, Yellow Starter Print Cartridges, Up to 8,500*-page Black Starter Print Cartridge, Hard disk, 3x 550-Sheet drawers, Caster base, Software and Documentation CD, Power Cord(s), Setup Guides (network and local attachment), Statement of limited warranty, Lexmark Cartridge Collection Program information

Page 8

Lexmark C792 Family: product specifications

Lexmark C792e Lexmark C792de Lexmark C792dte Lexmark C792dhe

Printing Print Technology

Print Speed (Letter, Black): Up to

Print Speed (Letter, Color): Up to

Time to First Page (Black)

Time to First Page (Color)

Print Resolution, Black

Print Resolution, Color

Memory, Standard

Memory, Maximum

Hard Disk

Print Noise Level, Operating

Noise Level, Idle

Maximum Monthly Duty Cycle: Up to

Recommended Monthly Page Volume

Supplies Supplies Yield

(*Average continuous black or continuous

composite CMY declared cartridge yield up to

this number of standard pages in accordance

with ISO/IEC 19798.)

Paper Handling Paper Handling Standard

1200 x 1200 dpi, 4800 Color Quality (2400 x 600 dpi)

512 MB 512 MB 512 MB 1024 MB

Option available Option available Option available Included in conﬁguration

6,000*-page (CMYK) Print Cartridges, 20,000*-page (CMYK) Extra High Yield Print Cartridges

500-Sheet Output Bin, 100-Sheet Multi-

purpose Feeder, 550-Sheet Input Tray

500-Sheet Output Bin, Integrated Duplex,

100-Sheet Multipurpose Feeder, 550-

Sheet Input Tray

1200 x 1200 dpi, 4800 Color Quality (2400 x 600 dpi)

As fast as 8 seconds

As fast as 8.5 seconds

150000 pages per month

2500 - 17000 pages

Color Laser

50 ppm

1536 MB

52 dBA

29 dBA

500-Sheet Output Bin, Integrated Duplex,

100-Sheet Multipurpose Feeder, 550-

Sheet Drawer, 550-Sheet Input Tray

500-Sheet Output Bin, Integrated Duplex,

100-Sheet Multipurpose Feeder, 550-

Sheet Input Tray, 3 x 550-Sheet Drawers

Paper Handling Optional

Paper Input Capacity, Standard: Up to

Paper Input Capacity, Maximum: Up to

Media Types Supported

General Function

Product Warranty

Product Certiﬁcations

Speciﬁed Operating Environment

Size (in. - H x W x D)

Weight (lb.)

Furniture Caster Base

Spacer

5-Bin Mailbox, 550-Sheet Drawer,

Optional furniture required., 2,000-Sheet

High-Capacity Feeder, 500-Sheet Offset

Stacker, 500-Sheet Staple Finisher, 500-

Sheet Staple Punch Finisher

650 pages 20 lb or 75 gsm bond 650 pages 20 lb or 75 gsm bond 1200 pages 20 lb or 75 gsm bond 2300 pages 20 lb or 75 gsm bond

3200 pages 20 lb or 75 gsm bond 3200 pages 20 lb or 75 gsm bond 3200 pages 20 lb or 75 gsm bond 2300 pages 20 lb or 75 gsm bond

Card Stock, Dual Web Labels, Envelopes, Glossy Paper, Integrated Labels, Paper Labels, Plain Paper, Polyester Labels, Transparencies, Vinyl Labels, Refer to the Card Stock &

Temperature: 16 to 32°C (60 to 90°F), Humidity: 8 to 80% Relative Humidity, Altitude: 0 - 3048 Meters (10,000 Feet)

20.3 x 22.3 x 20.2 in. 20.3 x 22.3 x 20.2 in. 25.5 x 22.3 x 20.2 in. 40.5 x 26.1 x 25.9 in.

110 lb. 110 lb. 131 lb. 231 lb.

Optional, (Required for ﬂoor standing

conﬁguration)

Available Available Available

5-Bin Mailbox, 550-Sheet Drawer,

Optional furniture required., 2,000-Sheet

High-Capacity Feeder, 500-Sheet Offset

Stacker, 500-Sheet Staple Finisher, 500-

Sheet Staple Punch Finisher

Label Guide, Outdoor Media, Banner Paper

Color Printing

1-Year Onsite Service, Next Business Day

www.lexmark.com

Optional, (Required for ﬂoor standing

conﬁguration)

5-Bin Mailbox, 550-Sheet Drawer, Optio-

nal furniture required., Banner Media Tray,

2,000-Sheet High-Capacity Feeder, 500-

Sheet Offset Stacker, 500-Sheet Staple

Finisher, 500-Sheet Staple Punch Finisher

Optional, (Required for ﬂoor standing

conﬁguration)

5-Bin Mailbox, Banner Media Tray, 500-

Sheet Offset Stacker, 500-Sheet Staple

Finisher, 500-Sheet Staple Punch Finisher

(Included)

Recommended Monthly Page Volume

«Recommended Monthly Page Volume» is a range of pages that helps customers evaluate Lexmark’s product offerings based on the average number of pages customers plan to print on the device each month. Lexmark recommends that the number of pages per month be within the stated range for optimum device performance, based on factors including: supplies replacement intervals, paper loading intervals, speed, and typical customer usage.

Maximum Monthly Duty Cycle

«Maximum Monthly Duty Cycle» is deﬁned as the maximum number of pages a device could deliver in a month using a multishift operation. This metric provides a comparison of robustness in relation to other Lexmark printers and MFPs.

Print Less. Save More.

www.lexmark.com

Trademarks

Lexmark and Lexmark with the diamond design are trademarks of Lexmark International, Inc., registered in the United States and/or other countries. All other trademarks are the property of their respective owners. ENERGY STAR® is a U.S. registered mark. Information in this document is subject to change without notice. PANTONE® is a registered trademark of Pantone, Inc. This product features Adobe® Flash® technology. For further information, visit http://www.adobe. com/software/ﬂash/about/
