Page 1

UP TO 40 PPM BLACK

COPY

SCAN

Lexmark XL Series

Lexmark C782n XL Lexmark X782e XL

Lexmark C782dtn XLLexmark C782dn XL

FAX

UP TO 35 PPM COLOR

DUPLEX

NETWORK

Communicate volumes

in color – for less!

Page 2

Enhance Your Business with Color.

Color is one of the most powerful communication tools at your disposal. Pages with color are recognized at a 60 percent higher rate than those without. Color strengthens brand identiﬁ cation up to 70 percent and improves recall up to 60 percent. Color even simpliﬁ es complex information, reducing search time as much as 80 percent. Today it is easier and more affordable than ever to create high impact, professional color documents in-house and on-demand with an innovative color print solution from Lexmark.

Data cited from “Color for Impact: How Color Can Get Your Message Across or Get in the Way” by Jan V. White

Color. It’s what your business craves. But if you print a lot in color, the cost of supplies can be hard to swallow. Lexmark has a solution that lets high-volume workgroups print in color without worrying about the cost of consumables. The Lexmark C782 XL family of color laser printers and the multifunction Lexmark X782e XL combine the power of color with unique cartridge pricing to help you save money and time by printing professional color documents in-house.

Speed and innovation unite

The Lexmark C782 XL family and X782e XL are robust, reliable and incredibly fast. You get the performance and innovations you need to produce brilliant color output in-house, reducing the need for outsourcing.

• Up to 35 ppm in color, 40 ppm in black, ﬁ rst color page out as fast as 13 seconds

• 800MHz processor with 256MB of RAM standard, expandable to 768MB

• Ultra-reliable paper feeding supports diverse media, including card stock, labels, UV-resistant outdoor media, banner paper and more

• State-of-the-art security to protect your data and devices, including numeric pad for secure PIN release of print jobs

Plentiful options

A wide variety of accessories and paper handling options let you tailor these devices to meet your unique requirements. For example, you can add a scanner unit to Lexmark C782 XL models, or you can add paper handling options to the Lexmark X782e XL by placing the scanner unit on an adjacent surface, such as a counter or tabletop.

• Maximize input capacity with extra drawers or high-capacity feeder

• Print banners up to 48 inches wide with the banner media tray

• Add a StapleSmart Finisher, envelope drawer, or outdoor media drawer

• Increase output ﬂ exibility with a 5-bin mailbox or 650-sheet output expander

Raise-the-bar with color

The Lexmark C782 XL family and X782e XL deliver crisp text and graphics and accurate, well-balanced images from ﬁ rst page to last. Like all Lexmark color lasers, they feature Lexmark’s new chemically processed toners for exceptional color and detail.

• True 1200 x 1200 dpi resolution and 4800 Image Quality print mode

• Consistent color balance with Pantone calibration

• Lexmark ColorCare tools to drive additional toner savings

• Front-loading toner cartridges take just seconds to replace

Eco-responsible printing

Printing responsibly means everyone wins – your business, your budget and the environment! All of Lexmark’s XL color lasers are designed with sustainability in mind. They’re incredibly quiet and equipped with a range of eco-conscious features to help you print greener at every level.

• Models with built-in duplex reduce paper consumption

• Use fewer cartridges over the life of your printer with the 16,500*-page replacement toner cartridges

• Multifunction technology lets you move documents digitally, saving paper and transportation energy

• Lexmark Cartridge Collection Program offers fast, free and easy recycling

Page 3

Lexmark XL Series |

While color toner cartridges typically cost more than their black equivalents, all genuine Lexmark XL Extra High Yield Toner Cartridges – black, cyan, yellow and magenta – are offered at the same low price. In addition, these cartridges deliver an impressive 16,500* pages, so you can print longer and use fewer cartridges overall. While your actual cost per page will vary based on the amount of coverage (the percentage of the page covered by black and color toner), your color cost-per-page can drop to just pennies.

The savings add up fast when you print in-house with a Lexmark XL Series printer or MFP. You can print labels, promotional signs, marketing materials and banners on the same device you use for your everyday printing. You’ll save time by maintaining centralized control; save money by printing short-run jobs more economically in-house; and save the planet by printing on demand, eliminating wasteful overruns and disposing of obsolete documents.

Cartridges are all priced the same!

Coverage and Printing Cost Comparisons

Genuine Lexmark XL Extra High Yield

Coverage

Cyan 26.92%

Magenta 32.39%

Yellow 40.15%

Black 0.04%

Printing Costs

C782n XL / X782e XL $0.24 Competitive Color Laser $0.53

Coverage

Cyan 15.67%

Magenta 18.79%

Yellow 29.71%

Black 0.08%

Printing Costs

C782n XL / X782e XL $0.16 Competitive Color Laser $0.34

Coverage

Cyan 13.87%

Magenta 16.07%

Yellow 19.05%

Black 3.63%

Coverage

Cyan 6.90%

Magenta 4.24%

Yellow 4.24%

Black 2.38%

Printing Costs

C782n XL / X782e XL $0.04 Competitive Color Laser $0.09

Coverage

Cyan 3.24%

Magenta 3.40%

Yellow 2.91%

Black 2.39%

Printing Costs

C782n XL / X782e XL $0.03 Competitive Color Laser $0.06

Printing Costs

C782n XL / X782e XL $0.13 Competitive Color Laser $0.27

Printing Costs are determined using toner cartridge street pricing as of November 11, 2008. This information is subject to change without notice.

Page 4

Lexmark XL Series |

Get exactly the performance you need

Lexmark C782dn XL

Low-cost color output for high-volume, in-house printing

• Network ready, duplex standard

• Up to 35 ppm color, 40 ppm black

• Time to ﬁ rst page as fast as 11 seconds in

black, 13 seconds in color

• True 1200 x 1200 dpi resolution or 4800 Color Quality (2400 x 600 dpi)

• 800MHz processor

• 256MB RAM standard, expandable

to 768MB

• Front USB port for walk-up printing

Other Models Available:

C782n XL = network ready C782dtn XL = network ready with built-in duplex and 1,100-sheet standard input capacity

Explore the features that keep you moving

Lexmark X782e XL

Color laser multifunction technology for low-cost color output

• Print, copy, scan and fax

• 768MB memory standard

• 8-inch e-Task color touch screen

• Duplex unit for automatic two-sided printing

• 50-sheet automatic document feeder scans

both sides of your document in one pass

• Paper input capacity of up to 1,600 sheets

• Lexmark Embedded Solutions Framework

Long-lasting toner

16,500*-page genuine Lexmark XL Extra High Yield Toner Cartridges save money, time and the environment

Single-pass duplex scanner

Save time by scanning both sides of your document in one pass

Special delivery

Mailbox option lets you assign users their own output bins

Direct USB

Front USB port lets you print PDF and other image ﬁ les directly from a memory device – no PC needed

Intuitively easy to use

Color e-Task touch screen offers simple one-touch operation

Secure PIN release

Use the numeric pad to release conﬁ dential jobs

Page 5

Lexmark XL Series

Product speciﬁ cations

2000, NT (4.00/4.00 Server), XP, XP x64, Server 2003, Server 2003 running Terminal Services, 2000 Server running Terminal Services, Server

Lexmark C782dn XL Lexmark X782e XL

Printing

Print Technology Color Laser Print Speed Black / Color: Up to 40 ppm / 35 ppm Time to First Page Black / Color: As fast as 11 seconds / 13 seconds Processor 800MHz Print Resolution 4800 Color Quality (2400 x 600 dpi), 1200 x 1200 dpi Memory, Standard / Maximum 256MB / 768MB 768MB / 768MB Acoustics: Noise Level Operating / Idle 53 dBA / 30 dBA 50 dBA / 31 dBA Maximum Month Duty Cycle: Up to 150,000 pages per month Recommended Monthly Page Volume 2,500 - 17,000 5,000 - 17,000

Supplies

Supplies Yield 16,500*-page Black and Color (CMY) XL Extra High Yield Print Cartridges. Ships with 10,000*-page Black and Color (CMY) High Yield Return

Copying

Copy Speed Black/Color: Up to 40 ppm / 35 ppm Time to First Copy Black As fast as 14 seconds

Scanning

Scanning Resolution 600 x 600 dpi (black), 300 X 300 dpi (color) Reduce / Enlarge Range 25% to 400%

Faxing

Modem Speed 33.6 Kbps

Paper Handling

Paper Handling Standard 250-Sheet Output Bin, 500-Sheet Input Tray, Duplex Unit, 100-Sheet

Paper Handling Optional

Paper Input Capacity Standard / Maximum 600 pages 20 lb or 75 gsm bond / 3,100 pages 20 lb or 75 gsm bond 1,600 pages 20 lb or 75 gsm bond / 3,100 pages Paper Output Capacity

Standard / Maximum Copy/Fax/Scan (ADF) Paper Input Capacity Up to 50 pages 20 lb or 75 gsm bond Media Types Supported Plain Paper, Glossy Paper, Card Stock, Labels, Envelopes, Transparencies, Outdoor Media, Banner Paper

Media Sizes Supported Legal, Letter, Statement, Executive, Universal (from 3” x 5” up to 9” x 14”), Folio, Banner (up to 8.27" x 48"), 10 Envelope, 7 3/4 Envelope, 9

Compatibility

Network Protocol Support TCP/IP IPv6, TCP/IP IPv4, IPX/SPX, AppleTalk™, LexLink (DLC) Printer Languages (Standard) PCL 5c Emulation, PCL 6 Emulation, Personal Printer Data Stream (PPDS), PostScript 3 Emulation, PDF 1.5, xHTML, Direct Image Connectivity (standard) Ethernet 10/100BaseTX (RJ-45), One Internal Card Slot, USB Com-

Microsoft Windows Operating Systems Supported

Apple Macintosh Operating Systems Supported

Other Operating Systems Supported IBM iSeries or IBM AS/400® Systems with TCP/IP with OS/400® V3R1 or later using OS/400 Host Print Transform or virtually any platform

General

Function Color Printing Color Printing, Color Copying, Color Scanning, Faxing,

Product Warranty 1-Year Onsite Repair Product Certiﬁ cations Energy Star, CSA, ICES Class A, BSMI Class A, VCCI Class A, FCC

Size (in. - H x W x D) 24.3 x 23.8 x 18.5 55.5 x 26.75 x 23 Weight (lb.) 118.5 215 Speciﬁ ed Operating Environment Temperature: 16 to 32°C (60 to 90°F) Humidity: 8 to 80% Relative Humidity Altitude: 0 - 3048 Meters (10,000 Feet)

Program Print Cartridges. *Average continuous black or continuous composite CMY declared cartridge yield up to this number of standard pages in accordance with ISO/IEC 19798.

Multipurpose Feeder 5-Bin Mailbox, 650-Sheet Output Expander, StapleSmart Finisher, 500-Sheet Drawer, Envelope Drawer, Banner Media Tray, Outdoor Media

Drawer, 2,000-Sheet High Capacity Feeder

250 pages 20 lb or 75 gsm bond / 900 pages 20 lb or 75 gsm bond

Refer to the Card Stock & Label Guide

Envelope, A4, A5, B5 Envelope, C5 Envelope, DL Envelope, JIS-B5

patible with USB 2.0 Speciﬁ cation, USB Direct Interface on Operator Panel

supporting TCP/IP

Class A, UL 60950-1, IEC 60320-1, CE Class A, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, C-tick mark Class A, CCC Class A

2003 x64, Server 2003 x64 running Terminal Services, Vista, Vista x64

Apple Mac OS X, Apple Mac OS 9.x

250-Sheet Output Bin, 500-Sheet Input Tray, Duplex Unit, Two 500-Sheet Drawers, 100-Sheet Multipurpose Feeder

20 lb or 75 gsm

Ethernet 10/100BaseTX (RJ-45), USB Compatible with USB 2.0 Speciﬁ cation, USB Direct interface on Operator Panel

Color Network Scanning

CSA, ICES Class A, BSMI Class A, VCCI Class A, FCC Class A, UL 60950-1, IEC 60320-1, CE Class A, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, C-tick mark Class A, CCC Class A

To add paper handling options to the Lexmark X782e XL the scanner unit must be placed on an adjacent surface, such as a counter or tabletop.

Page 6

Lexmark XL Series

Ordering information

Lexmark C782dn XL

Banner Media Tray

650-Sheet Output Expander

5-Bin Mailbox

250-Sheet Output Bin

500-Sheet Input Tray

Duplex Unit

500-Sheet Drawer

2,000-Sheet Highcapacity Feeder

StapleSmart Finisher

100-Sheet Multipurpose Feeder

500-Sheet Drawer

C77x, C78x Printer Stand

Paper Handling Optional

Paper Handling Standard

Part # Model

10Z0351 Lexmark C782dn XL

Part # Laser Toner/Print Cartridge

C782U1KG C782 XL, X782e XL Black XL Extra High Yield Return Program Print Cartridge C782U2KG C782 XL, X782e XL Black XL Extra High Yield Print Cartridge C782U1CG C782 XL, X782e XL Cyan XL Extra High Yield Return Program Print Cartridge C782U2CG C782 XL, X782e XL Cyan XL Extra High Yield Print Cartridge C782U1MG C782 XL, X782e XL Magenta XL Extra High Yield Return Program Print Cartridge C782U2MG C782 XL, X782e XL Magenta XL Extra High Yield Print Cartridge C782U1YG C782 XL, X782e XL Yellow XL Extra High Yield Return Program Print Cartridge C782U2YG C782 XL, X782e XL Yellow XL Extra High Yield Print Cartridge

Part # Paper and Transparencies

12A5950 Glossy Laser Paper, Letter (200) 12A8240 Color Laser Transparencies, Letter (50) 12A8600 Outdoor Media, Letter (100) 12A8940 Banner Laser Paper (50) - 8.27"

Part # Paper Handling

20B2300 500-Sheet Drawer 20B2373 500-Sheet Tray 20B2700 2,000-Sheet High Capacity Feeder 10Z3100 Envelope Drawer 20B3340 Outdoor Media Drawer 20B3000 5-Bin Mailbox 20B3050 Output Expander 20B3060 StapleSmart™ Finisher 11K3188 Staple Cartridges 20B5000 Banner Media Tray

Part # Furniture

16N1708 Printer Stand 21J0055 Scanner Shelf 16C0700 Scanner Stand with Cabinet

Part # MFP Options

21J0401 Lexmark 4600 MFP Option 21J0421 Lexmark 4600 MFP Option w No Modem

Part # Memory Options

13N1523 128MB DDR-DRAM 13N1524 256MB DDR-DRAM 13N1526 512MB DDR-DRAM 13N1530 Hard Disk (40+GB) 1021208 32MB Flash Card 1021209 64MB Flash Card 1021243 Japanese Font Card 1021240 Korean Font Card 1021241 Simpliﬁ ed.Chinese Font Card 1021242 Traditional.Chinese Font Card

Part # Application Solutions

10Z0400 Bar Code Card 10Z0401 Card for IPDS/SCS/TNe 10Z0402 Forms Card 10Z0403 Lexmark PrintCryption Card

Part # Connectivity

1021294 USB Cable (2 meter) 1021092 RS-232C Serial Interface Card 14T0145 N4050e 802.11g Wireless Print Server 14S0165 MarkNet N8050 802.11g Wireless Print Server 14S0200 MarkNet N8020 Gigabit Ethernet 14S0220 MarkNet N8030 Fiber Ethernet 100BaseFX, 10BaseFL 14T0220 MarkNet N7020e Gigabit Ethernet - 4 USB 1021231 Parallel Cable (10 foot) 1021091 Parallel 1284-B Interface Card 21J0069 Scanner Cable (6 meter)

Part # Extended Warranties

2349404 2-Years Total Onsite Service, Next Business Day 2349405 3-Years Total Onsite Service, Next Business Day 2349406 4-Years Total Onsite Service, Next Business Day 2349408 1-Year Onsite Service Renewal, Next Business Day

Part # User Replaceable Parts

40X1831 Fuser Kit (110-120V) 40X1826 ITU Kit

Other models available

Lexmark C782n XL: Network ready, Part #10Z0320 Lexmark C782dtn XL: Network ready plus duplex with 500-sheet drawer, Part #10Z0374

In the box

Lexmark C782n XL Color Laser Printer, Duplex Unit, Up to 10,000*-Page Black and Color (CMY) High Yield Return Program Print Cartridges, Software and Documentation CD, Power Cord, Setup Guides (network and local attachment), Statement of Limited Warranty, Lexmark Cartridge Collection Program Information

Lexmark X782e XL

Part # Model

21J0700 Lexmark X782e XL

Part # Laser Toner/Print Cartridge

100-Sheet Multipurpose Feeder

Duplex Unit

Second 500-Sheet Drawer

Paper Handling Optional: Accepts all paper handling options for C782 XL family.*

Paper Handling Standard

In the box

Lexmark C782n XL Color Laser Printer (256MB memory); Lexmark 4600 MFP Option (512MB additional memory); Duplex Unit; Two 500-Sheet Drawers; Up to 10,000*-Page Cyan, Magenta, Yellow and Black Return Program Print Cartridges; Scanner Shelf; Printer Stand; Power Cord; MFP, Printer Software and Documentation CDs; Setup Guides (network and local attachment); Statement of Limited Warranty; Lexmark Cartridge Collection Program Information

Lexmark’s guarantee to you

Lexmark’s 1-Year Onsite Service, Next Business Day warranty on the Lexmark XL Series provides added peace of mind. Enhanced ser vice offerings may be available by contacting your Lexmark representative or visiting www.lexmark.com. Optimize your printer’s performance and investment value by using Original Lexmark Supplies, Parts and Service.

250-Sheet Output Bin

500-Sheet Input Tray

500-Sheet Drawer

C782U2YG C782 XL, X782e XL Yellow XL Extra High Yield Print Cartridge

Part # Paper and Transparencies

12A5950 Glossy Laser Paper, Letter (200) 12A8240 Color Laser Transparencies, Letter (50) 12A8600 Outdoor Media, Letter (100) 12A8940 Banner Laser Paper (50) - 8.27"

Part # Paper Handling*

*Requires scanner to be placed adjacent to MFP

Part # Memory Options

1021208 32MB Flash Card 1021209 64MB Flash Card 1021243 Japanese Font Card 1021240 Korean Font Card 1021241 Simpliﬁ ed.Chinese Font Card 1021242 Traditional.Chinese Font Card

Part # Application Solutions

21J0577 Bar Code Card 21J0579 Card for IPDS/SCS/TNe 21J0578 Forms Card 21J0581 Lexmark PrintCryption Card 14T0370 Common Access Card (CAC) Reader

Part # Connectivity

1021294 USB Cable (2 meter) 14T0145 N4050e 802.11g Wireless Print Server 14T0220 MarkNet N7020e Gigabit Ethernet - 4 USB

Part # Extended Warranties

2349416 2349417 3-Years Total Onsite Service, Next Business Day 2349418 4-Years Total Onsite Service, Next Business Day 2349420 1-Year Onsite Service Renewal, Next Business Day

Part # User Replaceable Parts

40X2540 4600 MFP Option Pick Roller 40X2538 4600 MFP Option Separator (Pick) Roll Pad 40X1831 Fuser Kit (110-120V) 40X1826 ITU Kit

2-Years Total Onsite Ser vice, Next Business Day

Environmental commitment

Lexmark believes that the environment is a critical component of responsible business management and clearly demonstrates it by implementing the “4R” strategy: Reduce, Recover, Reuse and Recycle. To learn more about these programs please visit www.lexmark.com/recycle.

Cost-saving and environmental features

- Lexmark C782dn XL and C782dtn XL are Energy Star qualiﬁ ed

- Duplex printing, Print and Hold, multi-up and support of recycled paper help reduce paper consumption

- Power Saver Mode reduces energy consumption

- Extra High Yield Cartridges and Lexmark Cartridge Collection Program help reduce waste
