L2 Plus Managed Switch 48 GE with 4 Combo SFP + 4 10GE SFP Plus

GTL-5280

H/W Version: 1

LevelOne GTL-5280 is a Layer 2-Plus Managed switch, provides 48 x 1000Base-T ports associated with 4 x SFP (Small Form Factor Pluggable) and 4 x 10 Gigabit SFP Plus slots. Despite its aordable pricing, the GTL5280 is equipped with advanced features such as Single IP Management which allows users to manage up to 32 switches under the same web interface, Easy Conguration Port (ECP), IPv6, IEEE 802.1D/w/ s Spanning Tree, IEEE 802.1X Access Control, IEEE

802.3az Green Ethernet and more. An ideal network solution for workgroups and edge deployments, or anyone looking for an aordable and ecient way to expand their network.

IP Clustered Stacking Solution

With the design and implementation of SIP (Single IP Management), network administrators are allowed to virtually stack GEL-1072, GTL-2880, GTP-2880, and GTL-5280 together and manage them as one logical unit through a single IP address regardless of geographical locations of those switches. Comparing to traditional stacking, IP clustering eliminates the use of costly cables and connectors. Furthermore, it minimizes the impact of any single point of failure.

LevelOne Easy Conguration Port (ECP) Technology

Each switch port can now be fully optimized through a predened role and settings which are based on the type of a device such as an IP camera or a VoIP phone

to be connected to. For instance, even if a surveillance system integrator who lacks of IT administration skills, can still easily enables the role and applies settings like VLAN, QoS, port security and spanning tree to all connected IP cameras on a single Web UI within a few minutes. Hence, simplifying network deployment and ensuring consistent congurations across the network.

Enhanced Security Measures

We are always committed to providing the highest level of protection for your network resources against intrusion attacks and unauthorized access. Delivering robust access control, each Access Control List (ACL) consists of up to 512 entries, allowing you to congure a ne-grained restriction policy based on frame type, TCP/UDP ports, MAC address and VLAN ID in order to get deep inspection on your network trac. In addition, with the implementation of portbased authentication (IEEE 802.1X), messages can be encrypted, therefore preventing intruders from getting authentication credentials.

1. LED Indicators

2. Mode Button

3. 10/100/1000Mbps RJ-45 LAN Ports

4. SFP (Mini-GBIC) Slot

1 2

3 4 4 5 6

5. RS-232 Port

6. Power Socket

Page 2

L2 Managed GE

www.level1.com

one world_one brand_one level_

Standard Compliance

IEEE 802.3 10-BASE-T (Ethernet) IEEE 802.3u 100-BASE-TX (Fast Ethernet) IEEE 802.3ab 1000BASE-T (Gigabit Ethernet) IEEE 802.1D MAC Bridges IEEE802.1p priority tags IEEE802.1Q VLAN IEEE802.3ac VLAN tagging IEEE802.3ad Link aggregation control protocol IEEE802.1w Fast Spanning Tree IEEE802.1X authentication IEEE802.3az Energy Ecient Ethernet

Performance

Switching Capacity:

176 Gbps switching fabric with up to 131 Mbps forwarding rates 8K MAC addresses entries with auto-learning function Supports Jumbo frame, up to 9.8K

Network Interface

44 x RJ-45 10/100/1000BASE-T ports 4x Gigabit RJ-45/SFP (Mini-GBIC) shared slots 4x 10G Gigabit SFP Plus slots

Software

Layer 2 feature

Spanning Tree Protocol:

- IEEE 802.1D Spanning Tree Protocol (STP)

- IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)

- IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) Trunking:

- IEEE 802.3ad Link Aggregation Control Protocol (LACP)

- Trunk groups: 26, up to 8 ports per group VLAN:

- Support up to 4K VLANS simultaneously (1~4094 VLAN IDs)

- IEEE 802.1q tag-base VLAN

- protocol-based VLAN

- MAC-based VLAN

- Management VLAN

- GVRP Supported DHCP Relay (Layer 2):

- Relay of DHCP trac to DHCP server in dierent VLAN IGMP Snooping:

- IGMP v1/v2/v3 snooping

- IGMP Queried

- IGMP Proxy

Security

SSH v1/v2 supported HTTPS/SSL IEEE 802.1X Dynamic VLAN assignment PVE: L2 isolation between clients in the same VLAN Port based/MAC based/ IP address based security Radius/Tacacs+ authentication supports Storm control: Prevents trac on a LAN from being disrupted by a broadcast, multicast, or unicast storm on a port ACLs: Support for up to 512 entries

QoS

Priority Queues: 8 hardware queues per port Trac classication based on IEEE 802.1p CoS, IP Precedence, DSCP, Supports Layer 4 TCP/UDP port and ToS classication Rate Limiting: Ingress policer; egress shaping and rate control

Technical Specication

Management

Switch Management: CLI via console port or Telnet Web management SNMP v1, v2c, v3 user-based security model (USM) Firmware & Conguration: Dual rmware images Firmware upgrade via web browser (HTTP/HTTPS) and TFTP server, or console port Port mirroring RMON (groups 1, 2, 3 and 9) Easy Conguration Port (ECP) can congure client’s QoS and security capabilities Single IP management (SIP): Single IP management for a virtual stack function of up to 32 switches of GTL-2880/GTL-5280/GTP-2880/GTL-1072 UPnP s-Flow Event / Error Log / Syslog LLDP IPv6 feature:

- IPv6 host mode

- IPv6 stateless address auto-conguration

- Duplicate address detection (DAD)

- ICMP version6

- IPv6 QoS Prioritize IPv6 packets in hardware

Green Ethernet

IEEE 802.3az Energy Ecient function: Automatically turns o Ethernet port when detecting link down or Idle of client Cable length detection:

- Adjusts the signal strength based on the cable length

- Reduces the power consumption for cables shorter

Hardware

LED Indication

System LED, Link/Act, Speed, Gigabit Port activity LED and SFP/ SFP+ Module LED

Dimension

442mm (W) x 300mm (D) x 44mm (H)

Weight

4.1Kg

Power Supply

100-240 VAC 50~60 Hz, internal , universal

Temperature

Operating: 0°C ~ 45°C Storage: -20°C ~ 70°C

Humidity

Operating: 10% ~ 90% (Non-condensing)

Certications

CE, FCC

Page 3

Product Diagram

Ethernet Cable (RJ-45)

Fiber

Virtual stack (SIP ) with

GTL-5280, GTL-2880, GTP-2880, GEL-1072

Server Farm

Fiber connection (1G SFP: up to 120km) (10G SFP Plus: up to 40km)

GTL-5280 GTL-5280

LAN

Key Features

- 48 Gigabit Ethernet ports with 4 shared SFP slots and 4 10 Gigabit SFP plus slots

- Single IP management supports up to 32 switches (GTL-2880/ GTL-5280/GTL-1072/GTP-2880)

- Easy Conguration Port (ECP) for easy deployment of network devices such as IP phone or network camera

- Managed and deployed at IPv6 network operation

- IEEE 802.1X port-based authentication with Access Control List (ACL) of up to 512 entries for easy network security

- IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) and port mirroring

- Minimize carbon footprint with advanced Energy Ecient Technology (IEEE 802.3az)

- IEEE 802.1Q VLAN allows network segmentation to enhance performance and security

- IEEE 802.3ad LACP for auto port aggregation of up to 26 groups, 8 ports per group

- Supports Dual Firmware Image which protects against failed rmware upgrade

- Provides QoS control based on ToS/DSCP for advanced trac prioritization and bandwidth management

- DDMI SFP transceiver supported
