Page 1
FCS-4051 Version: 1
Mounting kits are to be ordered separately.
PTZ IP Network Camera, 2-Megapixel, 20X Optical
Zoom, Indoor/Outdoor, IR LEDs, two-way audio,
802.3at PoE
The LevelOne FCS-4051 is a PTZ IP surveillance camera designed for use outdoors, boasting 2-Megapixel
resolution and a 20X optical zoom. The camera features motorized Pan and Tilt features as well, enabling it
to focus in a variety of directions and zoom in on a specific viewing area. The camera is also PoE, enabling
it to run both power and data on the one Cat.5 cable, making deployments easy and efficient. An IP66-rated
weatherproof casing allows for safe, reliable operation in outdoor conditions such as rain, heat, dust, snow
and humidity.
Key Features
2-Megapixel (1920 x 1080) high-definition resolution
Video compression: H.264/MJPEG
Supports PTZ/preset point/preset sequence
Built-in infrared LEDs for night viewing up to 100m
Built-in Micro SD/SDHC card slot for local storage
Supports 20X optical zoom
Dual power support: 12V DC/PoE (IEEE 802.3at)
-
Specifications
System Specifications
Standards & Protocols:
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,
UPnP,SMTP, SNMP, IGMP, 802.1X, QoS, IPv6,IPv4
Image Sensor:
1/2.8" Progressive Scan CMOS
Lens:
4.7-94mm ,20X Zoom, F1.6~F3.5,
16X Digital Zoom
Connectors and Cabling:
1 x RJ-45 10/100 Mbps PoE port
1 x Power Connector
1 x MicroSDHC/ MicroSDXC card slot
1 x Line in/Out terminal block
www.level1.com Page 1 of 5
Page 2
Button/Knob:
Reset Button
Indicator:
Power
IR Cut Filter:
Support
IR LED:
100 Meter
Shutter Time:
1-1/10,000s
Angle of View:
58.3°-3.2°
Pan/Tilt/Zoom:
Pan:360° endless; Tilt: -15°~90°(Auto Flip)
Pan Manual Speed: 0.1°~80°/s, Pan Preset Speed: 80°/s
Tilt Manual Speed: 0.1°~80°/s, Tilt Preset Speed: 80°/s
Video Compression:
H.264/ MJPEG
Resolution:
50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ;
60Hz: 30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720)
Video Format:
AVI
Audio Compression:
G.711/G.722/G.726/MP2L2
Power Input:
12 VDC or PoE(802.3at, class4), Max.20W
Power Consumption:
Max.20W
Data Transfer Rate:
32 Kbps to 16 Mbps
Features
General:
Digital Wide Dynamic Range (DWDR),rotate mode. Brightness, contrast, saturation, and sharpness are
adjustable via web browser.Dual Stream,SDK
PoE:
802.3at, class4
Security:
One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark,IP Address
Filter ,Motion Detection
Video:
Auto scan / Frame scan / Random scan / Patrol / Pattern / Preset / Panorama scan / Tilt scan /Dome reboot
/ Dome adjust
8 patrols, up to 32 presets per patrol Number of Preset
Performance
www.level1.com Page 2 of 5
Page 3
Number of Clients:
16
Storage Capacity:
Support up to 128GB Micro SD/SDHC/SDXC card
Frame Rate (fps):
50Hz:25fps (1920×1080,1280×960,1280×720), 50fps (1280×960,1280×720) ;
60Hz: 30fps(1920×1080,1280×960,1280×720), 60fps (1280×960,1280×720)
Minimum illumination:
F1.6, AGC On: Color: 0.05 lux, B/W : 0.01 lux, 0 lux with IR
Environment
Temperature (°C):
-30°C ~ 65°C (-22°F ~ 149°F)
Humidity (Non-condensing):
90% or less
Physical Specifications
Dimensions (W x D x H mm):
?164.5 × 295
Weight (g):
2kg (4.41lbs)
Color:
White/Black
Approval and Compliance
EMI/EMS:
CE/FCC
Safety:
UL
Environmental Test:
IP66
Others:
RoHS
Others
Viewing Systems:
WIN 7/8/10 Internet Explorer 9 or above
Compatibility:
Onvif,ISO-9001 certified factory
Order Information
FCS-4051
Package Contents
FCS-4051
Resource CD (User Manual, Utility, 64-CH Monitoring Software)
Power adapter with power cord
www.level1.com Page 3 of 5
Page 4
Optional Accessory
CAS-7331
Wall Mount Bracket
CAS-7332
Pole Mount Bracket
CAS-7333
Corner Mount Bracket
CAS-7334
Wall mount bracket with Junction Box
CAS-7335
Pole Mount Bracket with Junction Box
CAS-7336
Corner Mount Bracket with Junction Box
CAS-7337
Gooseneck surface mount bracket
CAS-7338
Pendant Mount Bracket
www.level1.com Page 4 of 5
Page 5
CAS-7339
Pendant Mount Bracket
CAS-7340
Ceiling Mount Bracket
CAS-7341
Parapet Mount Bracket
