USeR MANUAL
www.myLevana.com
Model #: LV-TW502
Safe N’ See™ Advanced
Digital Video Monitor
With Talk To Baby™ Intercom
2
Need
heLp?
DO NOT RETURN THIS
PRODUCT TO THE STORE
Please contact a Levana customer support representative regarding any additional information on product
features, specications or if you need any help with set-up, we are available 24/7!
Please contact us via one of the methods below:
Toll free telephone:
1.866.946.7828
For more product information visit www.mylevana.com
Email:
support@mylevana.com
Online live web chat:
Visit www.mylevana.com
Toll free fax:
1.888.771.1701
Note: This is manual version 1.0 for this product, you may nd updated versions by visiting our website
IMPORTANT! PLEASE READ
3
INTRODUCTION
NEED HELP? ...................................................................................................................................................2
INTRODUCTION ............................................................................................................................................ 3
FEATURES ..................................................................................................................................................... 4
BUTTONS AND CONNECTIONS - MONITOR ..................................................................................................... 6
BUTTONS AND CONNECTIONS - CAMERA ....................................................................................................... 8
CAMERA SETUP AND MOUNTING GUIDE ....................................................................................................... 10
SETTING UP YOUR SYSTEM .......................................................................................................................... 11
BATTERY OPERATION ................................................................................................................. 11
ATTACHING POWER TO THE CAMERA ......................................................................................... 11
INSTALLING THE RECHARGEABLE BATTERY ................................................................................. 12
CHARGING THE MONITOR AND RECHARGEABLE BATTERY ........................................................... 12
CAMERA OPERATION .................................................................................................................................. 12
SWITCHING THE CAMERA ON/OFF ............................................................................................. 12
NIGHT VISION ............................................................................................................................ 13
MONITOR OPERATION ................................................................................................................................ 13
SWITCHING THE MONITOR ON/OFF ............................................................................................. 13
SETTING THE BRIGHTNESS ......................................................................................................... 14
ADJUSTING THE TEMPERATURE DISPLAY .................................................................................... 14
SWITCHING THE NIGHT LIGHT ON/OFF........................................................................................ 14
SELECTING A LULLABY ............................................................................................................... 14
ADJUSTING THE VOX SENSITIVITY .............................................................................................. 15
INTERCOM FEATURE ................................................................................................................... 15
RANGE ...................................................................................................................................... 15
ADJUSTING THE VOLUME............................................................................................................ 15
PAIRING ..................................................................................................................................................... 16
TROUBLESHOOTING .................................................................................................................................... 17
SPECIFICATIONS ......................................................................................................................................... 18
FCC STATEMENT ......................................................................................................................................... 19
SAFETY INSTRUCTIONS ............................................................................................................................... 20
PRODUCT WARRANTY INFORMATION .......................................................................................................... 21
TABLE OF CONTENTS
Congratulations on your purchase of the Levana TW502 Digital Video
Baby Monitor! This monitor uses advanced Clearvu® digital technology
that will deliver a crystal clear view of your baby’s room on the 3.5"
LCD screen, from anywhere in your home! Feel free to relax and take
comfort in knowing that your child is in good hands with Levana.
4
FEATURES
ClearVu® Digital Wireless Technology
ClearVu® technology ensures outstanding image and sound clarity so that you can
watch and listen to your child up to 500ft away1. Feel free to move around the house and no matter where
you go, you will always see your baby. With Levana, you’ll never miss a moment.
Large LCD for Superior Viewing Quality
Imagine what you will catch your baby doing on this bright and clear, large 3.5” LCD screen. With an LCD of
this size you will be able to set the monitor down and still see your baby clearly!
Temperature Monitoring to Ensure Safety
Studies indicate that your baby’s room should be between 61-68° F (16-20° C). This system is equipped
with temperature monitoring so you can monitor the temperature in your baby’s room and know they are
always comfortable.
Talk to Baby Intercom
Soothe your baby from a distance with the talk-to-baby intercom. With the simple press of a button you
can let your baby know you are on your way to their nursery or simply talk to them until they fall back to
sleep without having to go into his or her room.
Five Soothing Lullabies
Choose from ve dierent lullabies to soothe your baby to sleep. Turn lullabies on and o as well as change
the song being played all from the parent unit with the simple push of a button. Choose from Rock-a-Bye
Baby, Hush Little Baby, Itsy-Bitsy Spider, Sleep Baby Sleep and Twinkle Twinkle.
Night Vision
The built-in night vision allows you to see your child, even in complete darkness up to 10ft away. When the
lights go down the system automatically adjusts to the level of light. The camera can be placed anywhere
in your child’s room while still displaying a precise image of your baby2.
Relaxing Nightlight
The baby unit has a gentle nightlight that you are able to turn on and o from the parent unit. Turn the
light on if your baby is getting restless to calm them and turn it o when your baby is asleep, all without
going into the baby’s room.
Voice Activated Control
Conserve battery power and sleep well at night with VOX activation. VOX allows you to turn o the monitor
while your child is safe and sound. It will only turn on when they make noise. You have the ability to adjust
the level of sound needed in order for your monitor to turn on.
Rechargeable Monitor
Enjoy up to four hours of continuous audio and video monitoring with a fully charged unit3.
5
FEATURES
LED Noise Level Indication Lights
The monitor has LED lights on it that light up to display up to ve dierent levels of sound.
This means you can turn the volume all the way down, relax and still know when and how much noise your
baby is making.
All-in-One Table Stand and Belt Clip
The table-stand also functions as a belt clip for ultra usability. Place the monitor upright with the table
stand when you are in the same room. You can also carry the monitor with you and still have both hands
available by using the belt clip.
Energy Ecient Power Adapter
The power adapters save you on power all while saving the environment. They are rated with a Level
V eciency standard which means they are 30% more energy ecient then other conventional power
adapters.
Wall Mount on Baby Camera for the Best Viewing Angle
The camera can be wall mounted so you can easily view your baby in its crib as well as see all other parts of
the nursery.
24/7 Lifetime Live Customer Support
Our customer support team can be reached by phone 24/7 or by email and live web chat services, so you
always have access to an expert.
Disclaimers
1. Optimum range is 150ft when signal is passing through walls or oors. Microwave ovens (when in use) may cause signal
disruption at close range. Buildings with metal frames may also cause signal disruption. Maximum transmission range is
500ft.
2. Night vision range up to 10ft under ideal conditions. Objects at or beyond this range may be partially or completely obscured,
depending on the camera application.
3. Battery life of 4 hours based on full duration testing. Battery life may vary depending on usage.
4. Product may not be exactly as shown on the package. Some images are used for illustration purposes only.
Notes
• Levana does not endorse any of its products for illegal activities. Levana is not responsible or liable in any way for any damage,
vandalism, theft or any other action that may occur while a Levana product is in use by the purchaser.
• For safety reasons, baby monitors with power cords should never be hung on or near the crib. Power cords should be kept at
least 3 feet away from the crib and baby’s reach at all times.
6
BUTTONS AND CONNECTIONS - MONITOR
7
1. Antenna
Transmits and receives signals
2. Rechargeable Battery Compartment
Insert the rechargeable battery here
3. Belt Clip and Support Stand
Flip up to use as a belt clip, or down to use as a support stand
4. Speaker
5. ON/OFF Button
Turns the unit ON and OFF
6. Talk Button
Enables you to speak through the camera intercom
7. Menu Button
Brings up the menu options
8. Power LED
Indicates the amount of battery left, green means the battery is charged, red means the battery
power is low
9. VOX LED
Illuminates green when VOX is enabled
10. Volume Level LEDs
Indicates the amount of sound being heard by the camera
11. Microphone
Press the talk button and speak into the microphone to talk to your baby
12. Volume Buttons
Increases/decreases the volume through the speakers; adjust settings in the menu
13. Play/Pause
Plays or pauses the lullaby playing through the camera
14. Lullaby Selector
Selects the lullaby that the camera will play
15. LCD Screen
Displays video of your baby
BUTTONS AND CONNECTIONS - MONITOR
