Levana ALEXA User Manual

Alexa

™

www.mylevana.com

Digital Baby Video Monitor

MANUAL

CAUTION: Keep small parts away from children.

Caution: keep small parts away from children.

Strangulation hazard: children can become entangled in cords. Power cords should be kept more than 3 feet away from the crib and baby’s

reach at all times. Baby monitors and cameras with power cords should never be hung on or near the crib.

This product is not a toy and should be kept out of children’s reach.

This product contains small parts. Exercise care when unpacking and assembling the product.

Read and keep instructions: all the safety and operating instructions should be read before operating the video baby monitor.

This product cannot replace responsible adult supervision.

Water and moisture: this product is designed for indoor use only. The unit should not be exposed to rain, moisture, dripping or splashing. No

objects ﬁlled with liquid should be placed on top of, or beside the product, such as a glass or vase. This item should not be used near water.

Non-use periods: always unplug the AC adapters from the wall outlets during long periods of non-use.

Ventilation: this baby monitor should not be used on a bed, sofa, rug or similar surface that may block the ventilation openings. Do not place in

an enclosed area, such as a book case or drawer that may impede air ﬂow.

Keep away from sources of heat: this unit should not be exposed to direct heat sources such as a candle, ﬁreplace, radiator, heat register, stove

or other appliances that emit heat. The unit should not be left in direct sunlight.

Power source: this unit should only be used with the AC power adapters included in this package (rated 5.9v/6v 800mA).

SAFETY INSTRUCTIONS & DISCLAIMERS

Damage requiring service: this unit should be serviced by qualiﬁed personnel only when:

A. Objects have fallen or liquid has been spilled into the unit.

B. The units have been exposed to liquids or moisture.

C. The units do not appear to operate normally or exhibit a distinct change in performance.

D. The units have been dropped or the enclosure damaged.

Please note that the above mentioned are not covered under the unit warranty.

Disclaimers

Optimum range is 150 ft when signal is passing through walls or ﬂoors. Microwave ovens (when in use) may cause signal disruption at close range. Buildings with metal frames may also cause signal disruption. Maximum transmission range is 500 ft.

Night vision range is up to 12 ft under ideal conditions. Objects at or beyond this range may be partially or completely obscured, depending on the camera application.

Battery life of 12 hours based on power save mode. Battery lasts an average of 8 hours with continuous audio/video usage.

Strangulation hazard: children can become entangled in cords. Power cords should be kept more than 3 feet away from the crib and baby’s

reach at all times. Failure to do so could be fatal. Baby monitors/cameras with power cords should never be hung on or near the crib.

SAFETY INSTRUCTIONS & DISCLAIMERS

FCC STATEMENT

FCC CAUTION:

Any Changes or modiﬁcations not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

FCC RADIATION EXPOSURE STATEMENT:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment .

This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

IC WARNING

This device complies with CNR Industry Canada license-exempt devices. Operation is subject to the following two conditions:

(1) this device may not cause interference, and

(2) this device must accept any interference, including interference that may cause undesired operation of the device.

The device is compliance with RF exposure guidelines, users can obtain Canadian information on RF exposure and compliance. The minimum distance from body to use the device is 20cm.

IC STATEMENT

We take quality very seriously. This is why all of our products come with a one-year warranty from the original purchase date against defects in workmanship and materials. If you have warranty or support issues please contact us using any of the following methods:

Web: www.mylevana.com

Support: www.mylevana.com/Support_Center.eng.html

LEVANA Canada

4080 Montrose Road

Niagara Falls, ON

Canada L2H 1J9

SUPPORT

LEVANA USA

840 Aero Drive

Cheektowaga, NY

USA 14225

LEVANA® products are guaranteed for a period of one year from the date of purchase against defects in workmanship and materials. This warranty is limited to the repair, replacement or refund of the purchase price at LEVANA®’s options.

This warranty becomes void if the product shows evidence of having been misused, mishandled or tampered with contrary to the applicable instruction manual.

Routine cleaning, normal cosmetic and mechanical wear and tear are not covered under the terms of this warranty.

The warranty expressly provided for herein is the sole warranty provided in connection with the product itself and no other warranty, expressed or implied is provided. LEVANA assumes no responsibilities for any other claims not speciﬁcally mentioned in this warranty.

This warranty does not cover the shipping cost, insurance or any other incidental charges.

You MUST contact LEVANA at www.mylevana.com/Support_Center.eng.html before sending any product back for repair. You will be sent a Return Authorization form with return instructions. When returning the product for warranty service, please pack it carefully in the original box with all supplied accessories, and enclose your original receipt or copy, and a brief explanation of the problem (include RA #).

This warranty is valid only in Canada and the continental U.S.

This warranty cannot be re-issued.

Please visit our website at www.mylevana.com for additional information about your product’s warranty.

WARRANTY

TABLE OF CONTENTS

Safety Instructions & Disclaimers ............................................................................................................................................................................................2

Support ......................................................................................................................................................................................................................................... 6

Warranty .......................................................................................................................................................................................................................................7

What’s Included ........................................................................................................................................................................................................................10

Let’s Get Started ........................................................................................................................................................................................................................11

Monitor and Camera Features ............................................................................................................................................................................................................11

Battery Installation .................................................................................................................................................................................................................................12

Getting the Most Out of Your Rechargeable Battery ...................................................................................................................................................................12

Connecting Power to the Monitor / Charging the Battery .......................................................................................................................................................13

Connecting Power to the Camera .....................................................................................................................................................................................................13

Placement of the Monitor ....................................................................................................................................................................................................................14

Placement of the Camera .....................................................................................................................................................................................................................14

Mounting the Camera on a Tabletop Safely ...................................................................................................................................................................................14

Mounting the Camera on a Wall Safely ............................................................................................................................................................................................15

Night Vision ..............................................................................................................................................................................................................................................16

Adjusting the Camera Angle ...............................................................................................................................................................................................................16

Pairing .......................................................................................................................................................................................................................................................16

Volume .......................................................................................................................................................................................................................................................17

Talk to Baby

...........................................................................................................................................................................................................................................18

Menu Icons ...............................................................................................................................................................................................................................................19

TABLE OF CONTENTS

Menu Functions ........................................................................................................................................................................................................................19

Menu ......................................................................................................................................................................................................................................................... 20

Feed Timer ................................................................................................................................................................................................................................................21

Brightness ................................................................................................................................................................................................................................................. 23

Camera Views ......................................................................................................................................................................................................................................... 23

Power Save Mode ................................................................................................................................................................................................................................... 25

Temperature ............................................................................................................................................................................................................................................ 28

Pairing........................................................................................................................................................................................................................................................ 30

Time Set .................................................................................................................................................................................................................................................... 32

Troubleshooting .......................................................................................................................................................................................................................35

Speciﬁcations ............................................................................................................................................................................................................................37

• Baby Video Monitor

• Night Vision Camera

• Rechargeable Battery

• 2 Power Adapters

• Camera Angle Wedge

• Instruction Manual

• 1 Year Warranty

• Lifetime Live Customer Support

This product is not a toy. This product contains small parts. Exercise care when unpacking and assembling the product. This product does not replace responsible adult supervision. Check on your child at regular intervals and make sure your monitor is always adequately charged. Failure to do so can be fatal.

We reserve the right to change models, conﬁguration, or speciﬁcations without notice or liability.

Product may not be exactly as shown.

This is not a medical product. If there is a problem with the child/baby, please call emergency services immediately.

WHAT’S INCLUDED

1. Power On/O Button

2. Pairing Button

3. Power Indicator Light

4. Light Sensor

5. Power Input

6. Speaker

7. Temperature Sensor

MONITOR AND CAMERA FEATURES

1. Power (Video O) Button

2. Push To Talk

(Press and hold to talk, release

to listen)

3. Back/Exit

4. Up/Down Arrows

5. Left/Right Arrows

6. Menu/Conﬁrm

7. Volume Up/Down

8. LED On Screen Indicator

(LED lights show dierent levels

of sound)

9. Antenna

10. Speaker

11. Stand

12. Battery Compartment

13. LCD Screen

LET’S GET STARTED

BATTERY INSTALLATION

1. Slide the battery compartment cover down to remove.

2. Insert the battery. The battery connectors will line up with the connectors inside the battery compartment.

3. Slide the battery compartment cover back on, to lock into place.

NOTE: For extended periods of

non-use, Levana recommends removing the battery from the monitor.

GETTING THE MOST OUT OF YOUR RECHARGEABLE BATTERY

• Fully charge the battery (3-7 hours) before ﬁrst use

• To maximize battery life, charge the battery before the battery is fully drained

• Avoid extreme heat or cold as this will aect the life of the battery

• Turn the LCD screen o; press the power button on the top of the monitor once

Sleep Mode: When sleep mode is enabled, the monitor automatically sleeps after 20 seconds of inactivity.

Adjustable Brightness: Decreasing the brightness will extend the battery life.

LET’S GET STARTED
