UserGuide

ThinkPadX131e

Notes:Beforeusingthisinformationandtheproductitsupports,besuretoreadandunderstandthe
following:

•Safety,Warranty,andSetupGuide

•RegulatoryNotice

•“Importantsafetyinformation”onpagevi

•AppendixE“Notices”onpage147

TheSafety,Warranty,andSetupGuideandtheRegulatoryNoticehavebeenuploadedtotheWebsite.T o
refertothem,gotohttp://www.lenovo.com/ThinkPadUserGuidesandclickUserGuides&Manuals,then
followtheinstructionsonthescreen.

ThirdEdition(August2012)

©CopyrightLenovo2012.

LIMITEDANDRESTRICTEDRIGHTSNOTICE:IfdataorsoftwareisdeliveredpursuantaGeneralServicesAdministration
“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionssetforthinContractNo.GS-35F-05925.

Contents

Readthisrst..............v

Importantsafetyinformation..........vi

Conditionsthatrequireimmediateaction..vii

Safetyguidelines............vii

Chapter1.Productoverview......1

Locatingcomputercontrols,connectors,and

indicators..................1

Frontview................1

Right-sideview..............3

Left-sideview..............4

Bottomview...............5

Statusindicators.............6

Locatingimportantproductinformation......9

Machinetypeandmodellabel........9

FCCIDandICCerticationnumberlabel...9

CerticateofAuthenticitylabel......10

Features.................10

Specications...............11

Operatingenvironment...........12

Lenovoprograms.............13

AccessingLenovoprogramsontheWindows

7operatingsystem...........13

AccessingLenovoprogramsontheWindows

8operatingsystem...........14

AnintroductiontoLenovoprograms....15

Chapter2.Usingyourcomputer...19

Registeringyourcomputer..........19

Frequentlyaskedquestions.........19

Specialkeysandbuttons..........21

Functionkeycombinations........21

Windowskey.............23

UsingtheUltraNavpointingdevice.......23

UsingtheTrackPointpointingdevice....23

Usingthetouchpad...........25

DisablingtheUltraNavpointingdeviceand

usinganexternalmouse.........26

AddingtheUltraNavicontotheWindows

noticationarea............26

Powermanagement............26

Checkingthebatterystatus........26

Usingtheacpoweradapter........27

Chargingthebattery..........27

Maximizingthebatterylife........27

Managingthebatterypower.......28

Power-savingmodes..........28

Handlingthebattery...........29

Connectingtothenetwork..........31

Ethernetconnections..........31

Wirelessconnections..........31

Presentationsandmultimedia.........35

Changingdisplaysettings........35

Connectingaprojectororanexternal

monitor................35

Usingdualdisplays...........36

Usingaudiofeatures............38

Usingtheintegratedcamera.........38

Usingaashmediacard...........39

Insertingaashmediacard........39

Removingaashmediacard.......40

Chapter3.Youandyourcomputer..41

Accessibilityandcomfort..........41

Ergonomicinformation..........41

Comfort...............42

Accessibilityinformation.........42

Travelingwithyourcomputer.........43

Traveltips...............43

Travelaccessories...........43

Chapter4.Security..........45

Attachingamechanicallock.........45

Usingpasswords..............45

Passwordsandsleepmode........45

Typingpasswords...........45

Power-onpassword...........46

Harddiskpasswords..........46

Supervisorpassword..........48

Harddisksecurity.............50

Settingthesecuritychip...........50

Noticeondeletingdatafromyourharddiskdrive

orsolid-statedrive.............51

Usingrewalls...............52

Protectingdataagainstviruses........52

Chapter5.Recoveryoverview....53

RecoveryoverviewfortheWindows7operating

system..................53

Creatingandusingarecoverymedia....53

Performingbackupandrecoveryoperations.54

UsingtheRescueandRecoveryworkspace.55

Creatingandusingarescuemedium....56

Reinstallingpreinstalledprogramsanddevice

drivers................57

Solvingrecoveryproblems........57

©CopyrightLenovo2012

i

RecoveryoverviewfortheWindows8operating

system..................58

Chapter6.Replacingdevices.....61

Staticelectricityprevention..........61

Replacingthebattery............61

ReplacingtheSIMcard...........63

Replacingtheharddiskdriveorsolid-statedrive.65
ReplacingaPCIExpressMiniCardforwireless

LANconnection..............68

ReplacingaPCIExpressHalfMiniCardfor

wirelessWANconnection..........70

Replacingamemorymodule.........74

Replacingthekeyboard...........76

Replacingthebackupbattery.........81

Chapter7.Advancedconguration..85

Installinganewoperatingsystem.......85

Beforeyoubegin............85

InstallingtheWindows7operatingsystem..86
InstallingtheWindows8operatingsystem..87

Installingdevicedrivers...........87

Installingthedriverforthe4-in-1mediacard

reader................87

InstallingthedriverforUSB3.0onthe

Windows7operatingsystem.......88

InstallingtheThinkPadmonitorlefor
Windows2000/XP/Vista/7/8ontheWindows

7operatingsystem...........88

Installingotherdevicedriversandsoftwareon

theWindows7operatingsystem......88

ThinkPadSetup..............89

Mainmenu..............89

Congmenu..............90

Date/Timemenu............94

Securitymenu.............95

Startupmenu.............99

Restartmenu.............102

UpdatingyoursystemUEFIBIOS.....102

Usingsystemmanagement..........102

Systemmanagement..........103

Settingmanagementfeatures.......103

Chapter8.Preventingproblems..105

Generaltipsforpreventingproblems......105

Makingsuredevicedriversarecurrent.....106

Takingcareofyourcomputer.........107

Cleaningthecoverofyourcomputer....108

Chapter9.Troubleshootingcomputer

problems..............111

Diagnosingproblems............111

Troubleshooting..............111

Computerstopsresponding.......111

Spillsonthekeyboard..........112

Errormessages............112

Errorswithoutmessages.........114

Beeperrors..............115

Memorymoduleproblems........115

Networkingproblems..........116

Problemswiththekeyboardandotherpointing

devices................117

Problemswiththedisplayandmultimedia

devices................118

Batteryandpowerproblems.......123

Problemswithdrivesandotherstorage

devices................126

Asoftwareproblem...........127

Problemswithportsandconnectors....127

Chapter10.Gettingsupport....129

BeforeyoucontactLenovo..........129

Gettinghelpandservice...........129

Usingdiagnosticprograms........130

LenovoSupportWebsite.........130

CallingLenovo.............130

FindingThinkPadoptions........131

Purchasingadditionalservices........131

AppendixA.Regulatory

information.............133

Wirelessrelatedinformation.........133

LocationoftheUltraConnectwireless

antennas...............134

Locatingwirelessregulatorynotices....135

Exportclassicationnotice..........135

Electronicemissionnotices..........135

FederalCommunicationsCommission

DeclarationofConformity........135

IndustryCanadaClassBemissioncompliance

statement...............136

EuropeanUnion-Compliancetothe

ElectromagneticCompatibilityDirective...136

GermanClassBcompliancestatement...136

KoreaClassBcompliancestatement....137

JapanVCCIClassBcompliancestatement..137

Japancompliancestatementforproducts

whichconnecttothepowermainswith

ratedcurrentlessthanorequalto20Aper

phase................137

Lenovoproductserviceinformationfor

Taiwan................137

AppendixB.WEEEandrecycling

statements.............139

ImportantWEEEInformation.........139

iiUserGuide

BatteryrecyclinginformationforJapan.....139

BatteryrecyclinginformationforBrazil.....140

BatteryrecyclinginformationforTaiwan.....140

BatteryrecyclinginformationfortheEuropean

Union..................140

BatteryrecyclinginformationfortheUnitedStates

andCanada................141

AppendixC.ENERGYSTARmodel

information.............143

AppendixD.RestrictionofHazardous

SubstancesDirective(RoHS)....145

ChinaRoHS................145

TurkishRoHS...............145

UkraineRoHS...............145

IndiaRoHS................146

AppendixE.Notices.........147

Trademarks................148

©CopyrightLenovo2012

iii

ivUserGuide

Readthisrst

Besuretofollowtheimportanttipsgivenheretogetthemostuseandenjoymentoutofyourcomputer.
Failuretodosomightleadtodiscomfortorinjury,orcauseyourcomputertofail.

Protectyourselffromtheheatthatyourcomputergenerates.

Whenyourcomputeristurnedonorthebatteryischarging,thebase,thepalm
rest,andsomeotherpartsmaybecomehot.Thetemperaturetheyreach
dependsontheamountofsystemactivityandthelevelofchargeinthebattery.

Extendedcontactwithyourbody,eventhroughclothing,couldcause
discomfortorevenaskinburn.

•Avoidkeepingyourhands,yourlap,oranyotherpartofyourbodyin
contactwithahotsectionofthecomputerforanyextendedtime.

•Periodicallytakehandsfromusingthekeyboardbyliftingyourhandsfrom
thepalmrest.

Protectyourselffromtheheatgeneratedbytheacpoweradapter.

Whentheacpoweradapterisconnectedtoanelectricaloutletandyour
computer,itgeneratesheat.

Extendedcontactwithyourbody,eventhroughclothing,maycauseaskin
burn.

•Donotplacetheacpoweradapterincontactwithanypartofyourbody
whileitisinuse.

•Neveruseittowarmyourbody.

Preventyourcomputerfromgettingwet.

Protectthecablesfrombeingdamaged.

Toavoidspillsandthedangerofelectricalshock,keepliquidsawayfromyour
computer.

Applyingstrongforcetocablesmaydamageorbreakthem.

Routecommunicationlines,orthecablesofanacpoweradapter,amouse,a
keyboard,aprinter,oranyotherelectronicdevice,sothattheycannotbewalked
on,trippedover,pinchedbyyourcomputerorotherobjects,orinanyway
subjectedtotreatmentthatcouldinterferewiththeoperationofyourcomputer.

©CopyrightLenovo2012

v

Protectyourcomputeranddatawhenmovingit.

Beforemovingacomputerequippedwithaharddiskdrive,dooneofthe
following,andmakesurethatthepowerbuttonisofforisblinking:

•Turnitoff.

•Putitinsleepmode.

•Putitinhibernationmode.

Thiswillhelptopreventdamagetothecomputer,andpossiblelossofdata.

Handleyourcomputergently.

Donotdrop,bump,scratch,twist,hit,vibrate,push,orplaceheavyobjectson
yourcomputer,display,orexternaldevices.

Carryyourcomputercarefully.

•Useaqualitycarryingcasethatprovidesadequatecushioningandprotection.

•Donotpackyourcomputerinatightlypackedsuitcaseorbag.

•Beforeputtingyourcomputerinacarryingcase,makesurethatitisoff,insleep
mode,orinhibernationmode.Donotputacomputerinacarryingcasewhileit
isturnedon.

Importantsafetyinformation

Note:Readtheimportantsafetyinformationrst.

Thisinformationcanhelpyousafelyuseyournotebookcomputer.Followandretainallinformationincluded
withyourcomputer.Theinformationinthisdocumentdoesnotalterthetermsofyourpurchaseagreement
ortheLenovo
andSetupGuidethatcomeswithyourcomputer.

Customersafetyisimportant.Ourproductsaredevelopedtobesafeandeffective.However,personal
computersareelectronicdevices.Powercords,poweradapters,andotherfeaturescancreatepotential
safetyrisksthatcanresultinphysicalinjuryorpropertydamage,especiallyifmisused.Toreducethese
risks,followtheinstructionsincludedwithyourproduct,observeallwarningsontheproductandinthe
operatinginstructions,andreviewtheinformationincludedinthisdocumentcarefully.Bycarefullyfollowing
theinformationcontainedinthisdocumentandprovidedwithyourproduct,youcanhelpprotectyourself
fromhazardsandcreateasafercomputerworkenvironment.

Note:Thisinformationincludesreferencestopoweradaptersandbatteries.Inadditiontonotebook
computers,someproducts(suchasspeakersandmonitors)shipwithexternalpoweradapters.Ifyouhave
suchaproduct,thisinformationappliestoyourproduct.Inaddition,computerproductscontainacoin-sized
internalbatterythatprovidespowertothesystemclockevenwhenthecomputerisunplugged,sothe
batterysafetyinformationappliestoallcomputerproducts.

®

LimitedWarranty.Formoreinformation,see“WarrantyInformation”intheSafety,Warranty,

viUserGuide

Conditionsthatrequireimmediateaction

Productscanbecomedamagedduetomisuseorneglect.Someproductdamageisseriousenough
thattheproductshouldnotbeusedagainuntilithasbeeninspectedand,ifnecessary,repairedby
anauthorizedservicer.

Aswithanyelectronicdevice,paycloseattentiontotheproductwhenitisturnedon.Onveryrare
occasions,youmightnoticeanodororseeapuffofsmokeorsparksventfromyourproduct.Oryou
mighthearsoundslikepopping,crackingorhissing.Theseconditionsmightmerelymeanthatan
internalelectroniccomponenthasfailedinasafeandcontrolledmanner.Or ,theymightindicate
apotentialsafetyissue.However,donottakerisksorattempttodiagnosethesituationyourself.
ContacttheCustomerSupportCenterforfurtherguidance.ForalistofServiceandSupportphone
numbers,seethefollowingWebsite:
http://www.lenovo.com/support/phone

Frequentlyinspectyourcomputeranditscomponentsfordamageorwearorsignsofdanger.Ifyou
haveanyquestionabouttheconditionofacomponent,donotusetheproduct.ContacttheCustomer
SupportCenterortheproductmanufacturerforinstructionsonhowtoinspecttheproductand
haveitrepaired,ifnecessary.

Intheunlikelyeventthatyounoticeanyofthefollowingconditions,orifyouhaveanysafetyconcerns
withyourproduct,stopusingtheproductandunplugitfromthepowersourceandtelecommunication
linesuntilyoucanspeaktotheCustomerSupportCenterforfurtherguidance.

•Powercords,plugs,poweradapters,extensioncords,surgeprotectors,orpowersuppliesthatare
cracked,broken,ordamaged.

•Signsofoverheating,smoke,sparks,orre.

•Damagetoabattery(suchascracks,dents,orcreases),dischargefromabattery,orabuildupofforeign
substancesonthebattery.

•Acracking,hissingorpoppingsound,orstrongodorthatcomesfromtheproduct.

•Signsthatliquidhasbeenspilledoranobjecthasfallenontothecomputerproduct,thepowercordor
poweradapter.

•Thecomputerproduct,powercord,orpoweradapterhasbeenexposedtowater.

•Theproducthasbeendroppedordamagedinanyway.

•Theproductdoesnotoperatenormallywhenyoufollowtheoperatinginstructions.

Note:Ifyounoticetheseconditionswithaproduct(suchasanextensioncord)thatisnotmanufacturedfor
orbyLenovo,stopusingthatproductuntilyoucancontacttheproductmanufacturerforfurtherinstructions,
oruntilyougetasuitablereplacement.

Safetyguidelines

Alwaysobservethefollowingprecautionstoreducetheriskofinjuryandpropertydamage.

Serviceandupgrades

DonotattempttoserviceaproductyourselfunlessinstructedtodosobytheCustomerSupportCenteror
yourdocumentation.OnlyuseaServiceProviderwhoisapprovedtorepairyourparticularproduct.

Note:Somecomputerpartscanbeupgradedorreplacedbythecustomer.Upgradestypicallyare
referredtoasoptions.ReplacementpartsapprovedforcustomerinstallationarereferredtoasCustomer
ReplaceableUnits,orCRUs.Lenovoprovidesdocumentationwithinstructionswhenitisappropriatefor
customerstoinstalloptionsorreplaceCRUs.Youmustcloselyfollowallinstructionswheninstallingor
replacingparts.TheOffstateofapowerindicatordoesnotnecessarilymeanthatvoltagelevelsinsidea
productarezero.Beforeyouremovethecoversfromaproductequippedwithapowercord,alwaysmake

©CopyrightLenovo2012

vii

surethatthepoweristurnedoffandthattheproductisunpluggedfromanypowersource.Ifyouhave
anyquestionsorconcerns,contacttheCustomerSupportCenter.

Althoughtherearenomovingpartsinyourcomputerafterthepowercordhasbeendisconnected,the
followingwarningsarerequiredforyoursafety.

CAUTION:
Hazardousmovingparts.Keepngersandotherbodypartsaway.

CAUTION:

BeforereplacinganyCRUs,turnoffthecomputerandwaitthreetoveminutestoletthecomputer
coolbeforeopeningthecover.

Powercordsandpoweradapters

DANGER

Useonlythepowercordsandpoweradapterssuppliedbytheproductmanufacturer.

Thepowercordsshallbesafetyapproved.ForGermany,itshallbeH05VV-F,3G,0.75mm
better.Forothercountries,thesuitabletypesshallbeusedaccordingly.

Neverwrapapowercordaroundapoweradapterorotherobject.Doingsocanstressthecordin
waysthatcancausethecordtofray,crack,orcrimp.Thiscanpresentasafetyhazard.

Alwaysroutepowercordssothattheywillnotbewalkedon,trippedover,orpinchedbyobjects.

Protectpowercordsandpoweradaptersfromliquids.Forinstance,donotleaveyourpowercord
orpoweradapternearsinks,tubs,toilets,oronoorsthatarecleanedwithliquidcleansers.
Liquidscancauseashortcircuit,particularlyifthepowercordorpoweradapterhasbeenstressed
bymisuse.Liquidsalsocancausegradualcorrosionofpowercordterminalsand/ortheconnector
terminalsonapoweradapter,whichcaneventuallyresultinoverheating.

Alwaysconnectpowercordsandsignalcablesinthecorrectorderandensurethatallpowercord
connectorsaresecurelyandcompletelypluggedintoreceptacles.

Donotuseanypoweradapterthatshowscorrosionattheacinputpinsorshowssignsof
overheating(suchasdeformedplastic)attheacinputpinsoranywhereonthepoweradapter.

2

,or

Donotuseanypowercordswheretheelectricalcontactsoneitherendshowsignsofcorrosionor
overheatingorwherethepowercordappearstohavebeendamagedinanyway.

viiiUserGuide

Extensioncordsandrelateddevices

Ensurethatextensioncords,surgeprotectors,uninterruptiblepowersupplies,andpowerstripsthatyouuse
areratedtohandletheelectricalrequirementsoftheproduct.Neveroverloadthesedevices.Ifpowerstrips
areused,theloadshouldnotexceedthepowerstripinputrating.Consultanelectricianformoreinformation
ifyouhavequestionsaboutpowerloads,powerrequirements,andinputratings.

Plugsandoutlets

DANGER

Ifareceptacle(poweroutlet)thatyouintendtousewithyourcomputerequipmentappearstobe
damagedorcorroded,donotusetheoutletuntilitisreplacedbyaqualiedelectrician.

Donotbendormodifytheplug.Iftheplugisdamaged,contactthemanufacturertoobtain
areplacement.

Donotshareanelectricaloutletwithotherhomeorcommercialappliancesthatdrawlargeamounts
ofelectricity;otherwise,unstablevoltagemightdamageyourcomputer,data,orattacheddevices.

Someproductsareequippedwithathree-prongedplug.Thisplugtsonlyintoagrounded
electricaloutlet.Thisisasafetyfeature.Donotdefeatthissafetyfeaturebytryingtoinsertitinto
anon-groundedoutlet.Ifyoucannotinserttheplugintotheoutlet,contactanelectricianforan
approvedoutletadapterortoreplacetheoutletwithonethatenablesthissafetyfeature.Never
overloadanelectricaloutlet.Theoverallsystemloadshouldnotexceed80percentofthebranch
circuitrating.Consultanelectricianformoreinformationifyouhavequestionsaboutpowerloads
andbranchcircuitratings.

Besurethatthepoweroutletyouareusingisproperlywired,easilyaccessible,andlocatedclose
totheequipment.Donotfullyextendpowercordsinawaythatwillstressthecords.

Besurethatthepoweroutletprovidesthecorrectvoltageandcurrentfortheproductyouare
installing.

Carefullyconnectanddisconnecttheequipmentfromtheelectricaloutlet.

Powersupplystatement

DANGER

Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.

Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabel
attached.Therearenoserviceablepartsinsidethesecomponents.Ifyoususpectaproblemwith
oneoftheseparts,contactaservicetechnician.

©CopyrightLenovo2012

ix

Externaldevices

CAUTION:
DonotconnectordisconnectanyexternaldevicecablesotherthanUSBcableswhilethecomputer
powerison;otherwise,youmightdamageyourcomputer .Toavoidpossibledamagetoattached
devices,waitatleastvesecondsafterthecomputerisshutdowntodisconnectexternaldevices.

Generalbatterynotice

DANGER

PersonalcomputersmanufacturedbyLenovocontainacoincellbatterytoprovidepowerto
thesystemclock.Inaddition,manymobileproducts,suchasnotebookcomputers,utilizea
rechargeablebatterypacktoprovidesystempowerwheninportablemode.Batteriessuppliedby
Lenovoforusewithyourproducthavebeentestedforcompatibilityandshouldonlybereplaced
withapprovedparts.

Neverattempttoopenorserviceanybattery.Donotcrush,puncture,orincineratebatteriesor
shortcircuitthemetalcontacts.Donotexposethebatterytowaterorotherliquids.Onlyrecharge
thebatterypackstrictlyaccordingtoinstructionsincludedintheproductdocumentation.

Batteryabuseormishandlingcancausethebatterytooverheat,whichcancausegassesorame
to“vent”fromthebatterypackorcoincell.Ifyourbatteryisdamaged,orifyounoticeany
dischargefromyourbatteryorthebuildupofforeignmaterialsonthebatteryleads,stopusingthe
batteryandobtainareplacementfromthebatterymanufacturer.

Batteriescandegradewhentheyareleftunusedforlongperiodsoftime.Forsomerechargeable
batteries(particularlyLithiumIonbatteries),leavingabatteryunusedinadischargedstatecould
increasetheriskofabatteryshortcircuit,whichcouldshortenthelifeofthebatteryandalsocan
poseasafetyhazard.DonotletrechargeableLithium-Ionbatteriescompletelydischargeorstore
thesebatteriesinadischargedstate.

Rechargeablebatterynotice

DANGER

Donotattempttodisassembleormodifythebatterypack.Attemptingtodosocancausean
explosion,orliquidleakagefromthebatterypack.Abatterypackotherthantheonespeciedby
Lenovo,oradisassembledormodiedbatterypackisnotcoveredbythewarranty.

Iftherechargeablebatterypackisincorrectlyreplaced,thereisdangerofanexplosion.Thebattery
packcontainsasmallamountofharmfulsubstances.Toavoidpossibleinjury:

•ReplaceonlywithabatteryofthetyperecommendedbyLenovo.

•Keepthebatterypackawayfromre.

•Donotexposeittowaterorrain.

•Donotattempttodisassembleit.

•Donotshort-circuitit.

•Keepitawayfromchildren.

•Donotdropthebatterypack.

Donotputthebatterypackintrashthatisdisposedofinlandlls.Whendisposingofthebattery,
complywithlocalordinancesorregulations.

xUserGuide

Thebatterypackshouldbestoredatroomtemperature,chargedtoapproximately30to50%
ofcapacity.Werecommendthatbatterypackbechargedaboutonceperyeartoprevent
overdischarge.

Lithiumcoincellbatterynotice

DANGER

Dangerofexplosionifbatteryisincorrectlyreplaced.

Whenreplacingthelithiumcoincellbattery,useonlythesameoranequivalenttypethatis
recommendedbythemanufacturer.Thebatterycontainslithiumandcanexplodeifnotproperly
used,handled,ordisposedof.

Donot:

•Throworimmerseintowater

•Heattomorethan100°C(212°F)

•Repairordisassemble

Disposeofthebatteryasrequiredbylocalordinancesorregulations.

ThefollowingstatementappliestousersinthestateofCalifornia,U.S.A.

CaliforniaPerchlorateInformation:

Productscontainingmanganesedioxidelithiumcoincellbatteriesmaycontainperchlorate.

PerchlorateMaterial-specialhandlingmayapply,See
www.dtsc.ca.gov/hazardouswaste/perchlorate

Heatandproductventilation

DANGER

Computers,acpoweradapters,andmanyaccessoriescangenerateheatwhenturnedonandwhen
batteriesarecharging.Notebookcomputerscangenerateasignicantamountofheatduetotheir
compactsize.Alwaysfollowthesebasicprecautions:

•Whenyourcomputeristurnedonorthebatteryischarging,thebase,thepalmrest,andsome
otherpartsmaybecomehot.Avoidkeepingyourhands,yourlap,oranyotherpartofyour
bodyincontactwithahotsectionofthecomputerforanyextendedlengthoftime.Whenyou
usethekeyboard,avoidkeepingyourpalmsonthepalmrestforaprolongedperiodoftime.
Yourcomputergeneratessomeheatduringnormaloperation.Theamountofheatdependson
theamountofsystemactivityandthebatterychargelevel.Extendedcontactwithyourbody,
eventhroughclothing,couldcausediscomfortorevenaskinburn.Periodicallytakebreaks
fromusingthekeyboardbyliftingyourhandsfromthepalmrest;andbecarefulnottouse
thekeyboardforanyextendedlengthoftime.

•Donotoperateyourcomputerorchargethebatterynearammablematerialsorinexplosive
environments.

©CopyrightLenovo2012

xi

•Ventilationslots,fansand/orheatsinksareprovidedwiththeproductforsafety,comfort,and
reliableoperation.Thesefeaturesmightinadvertentlybecomeblockedbyplacingtheproducton
abed,sofa,carpet,orotherexiblesurface.Neverblock,cover,ordisablethesefeatures.

•Whentheacpoweradapterisconnectedtoanelectricaloutletandyourcomputer ,itgenerates
heat.Donotplacetheadapterincontactwithanypartofyourbodywhileusingit.Neverusethe
acpoweradaptertowarmyourbody.Extendedcontactwithyourbody,eventhroughclothing,
maycauseaskinburn.

Foryoursafety,alwaysfollowthesebasicprecautionswithyourcomputer:

•Keepthecoverclosedwheneverthecomputerispluggedin.

•Regularlyinspecttheoutsideofthecomputerfordustaccumulation.

•Removedustfromventsandanyperforationsinthebezel.Morefrequentcleaningsmightbe
requiredforcomputersindustyorhigh-trafcareas.

•Donotrestrictorblockanyventilationopenings.

•Donotoperateyourcomputerinsidefurniture,asthismightincreasetheriskofoverheating.

•Airowtemperaturesintothecomputershouldnotexceed35°C(95°F).

Electricalcurrentsafetyinformation

DANGER

Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.

Toavoidashockhazard:

•Donotuseyourcomputerduringalightningstorm.

•Donotconnectordisconnectanycablesorperforminstallation,maintenance,orreconguration
ofthisproductduringanelectricalstorm.

•Connectallpowercordstoaproperlywiredandgroundedelectricaloutlet.

•Connecttoproperlywiredoutletsanyequipmentthatwillbeattachedtothisproduct.

•Wheneverpossible,useonehandonlytoconnectordisconnectsignalcables.

•Neverturnonanyequipmentwhenthereisevidenceofre,water,orstructuraldamage.

•Disconnecttheattachedpowercords,batterypack,andallthecablesbeforeyouopenthe
devicecovers,unlessinstructedotherwiseintheinstallationandcongurationprocedures.

•Donotuseyoucomputeruntilallinternalpartsenclosuresarefastenedintoplace.Neveruse
thecomputerwheninternalpartsandcircuitsareexposed.

DANGER

Connectanddisconnectcablesasdescribedinthefollowingprocedureswheninstalling,moving,
oropeningcoversonthisproductorattacheddevices.

Toconnect:

1.TurneverythingOFF .

2.First,attachallcablestodevices.

3.Attachsignalcablestoconnectors.

4.Attachpowercordstooutlets.

5.TurndevicesON.

Todisconnect:

1.TurneverythingOFF .

2.First,removepowercordsfromoutlets.

3.Removesignalcablesfromconnectors.

xiiUserGuide

4.Removeallcablesfromdevices.

Thepowercordmustbedisconnectedfromthewalloutletorreceptaclebeforeinstallingallother
electricalcablesconnectedtothecomputer .

Thepowercordmaybereconnectedtothewalloutletorreceptacleonlyafterallotherelectrical
cableshavebeenconnectedtothecomputer.

Liquidcrystaldisplay(LCD)notice

CAUTION:
Theliquidcrystaldisplay(LCD)ismadeofglass,androughhandlingordroppingthecomputercan
causetheLCDtobreak.IftheLCDbreaksandtheinternaluidgetsintoyoureyesoronyour
hands,immediatelywashtheaffectedareaswithwaterforatleast15minutes;ifanysymptomsare
presentafterwashing,getmedicalcare.

Note:Forproductswithmercury-containinguorescentlamps(forexample,non-LED),theuorescentlamp

intheLiquidcrystaldisplay(LCD)containsmercury;disposeofaccordingtolocal,state,orfederallaws.

Usingheadphonesorearphones

CAUTION:
Excessivesoundpressurefromearphonesandheadphonescancausehearingloss.Adjustmentof
theequalizertomaximumincreasestheearphoneandheadphoneoutputvoltageandthesound
pressurelevel.Therefore,toprotectyourhearing,adjusttheequalizertoanappropriatelevel.

Excessiveuseofheadphonesorearphonesforalongperiodoftimeathighvolumecanbedangerousifthe
outputoftheheadphoneorearphoneconnectorsdonotcomplywithspecicationsofEN50332-2.The
headphoneoutputconnectorofyourcomputercomplieswithEN50332-2Subclause7.Thisspecication
limitsthecomputer’smaximumwidebandtrueRMSoutputvoltageto150mV.Tohelpprotectagainst
hearingloss,ensurethattheheadphonesorearphonesyouusealsocomplywithEN50332-2(Clause7
limits)forawidebandcharacteristicvoltageof75mV.UsingheadphonesthatdonotcomplywithEN
50332-2canbedangerousduetoexcessivesoundpressurelevels.

IfyourLenovocomputercamewithheadphonesorearphonesinthepackage,asaset,thecombinationof
theheadphonesorearphonesandthecomputeralreadycomplieswiththespecicationsofEN50332-1.
Ifdifferentheadphonesorearphonesareused,ensurethattheycomplywithEN50332-1(Clause6.5
LimitationValues).UsingheadphonesthatdonotcomplywithEN50332-1canbedangerousdueto
excessivesoundpressurelevels.

Additionalsafetyinformation

DANGER

Plasticbagscanbedangerous.Keepplasticbagsawayfrombabiesandchildrentoavoiddanger
ofsuffocation.

Noticefortabletpersonalcomputerusers

SafetynoticeforusersinAustralia

DANGER

Donotconnectphonelinewhileusingtabletmode.

©CopyrightLenovo2012

xiii

NoticeforusersintheU.S.A.

Manypersonalcomputerproductsandaccessoriescontaincords,cablesorwires,suchaspowercordsor
cordstoconnecttheaccessorytoapersonalcomputer.Ifthisproducthassuchacord,cableorwire,then
thefollowingwarningapplies:

WARNING:Handlingthecordonthisproductorcordsassociatedwithaccessoriessoldwiththisproduct
willexposeyoutolead,achemicalknowntotheStateofCaliforniatocausecancer,andbirthdefectsor
otherreproductiveharm.Washhandsafterhandling.

Savetheseinstructions.

xivUserGuide

Chapter1.Productoverview

Thischapterprovidesinformationaboutthelocationsofconnectors,locationsofimportantproductlabels,
computerfeatures,specications,operatingenvironment,andpreinstalledprograms.

Thischaptercontainsthefollowingtopics:

•“Locatingcomputercontrols,connectors,andindicators”onpage1

•“Locatingimportantproductinformation”onpage9

•“Features”onpage10

•“Specications”onpage11

•“Operatingenvironment”onpage12

•“Lenovoprograms”onpage13

Locatingcomputercontrols,connectors,andindicators

Thissectionintroducesthecomputerhardwarefeaturestogiveyouthebasicinformationyouwillneed
tostartusingthecomputer.

Frontview

Figure1.ThinkPadX131efrontview

1Integratedcamera

3TrackPoint

5TrackPointpointingstick6Built-inmicrophone

7Powerbutton

©CopyrightLenovo2012

®

buttons4Touchpad

2Systemstatusindicator(illuminatedThinkPad

®

logo)

1

1Integratedcamera

Usetheintegratedcameratotakepicturesorholdavideoconference.Formoreinformation,see“Usingthe
integratedcamera”onpage38.

2Systemstatusindicator(illuminatedThinkPadlogo)

TheilluminatedThinkPadlogoonthepalmrestfunctionsasasystemstatusindicator.Yourcomputerhas
severalstatusindicators.Formoreinformation,see“Systemstatusindicators”onpage6.

UltraNav

3TrackPointbuttons
4T ouchpad
5T rackPointpointingstick

®

pointingdevice

ThekeyboardcontainstheLenovouniqueUltraNavpointingdevice.Pointing,selecting,anddraggingare
allpartofasingleprocessthatyoucanperformwithoutmovingyourngersfromatypingposition.For
moreinformation,see“UsingtheUltraNavpointingdevice”onpage23.

6Built-inmicrophone

Thebuilt-inmicrophonecapturessoundandvoicewhenusedwithaprogramcapableofhandlingaudio.

7Powerbutton

Usethepowerbuttontoturnonthecomputer.

Toturnoffthecomputer,usetheStartmenushutdownoptionontheWindows

®

7operatingsystem.For
theWindows8operatingsystem,movethecursortothetop-rightorbottom-rightcornerofthescreento
displaythecharms.ThenclickSettings➙Power➙Shutdown.

Ifyourcomputerstopsrespondingandyoucannotturnitoff,pressandholdthepowerbuttonforfour
secondsormore.Ifthecomputerstillisnotresponding,removetheacpoweradapterandthebattery
toresetthecomputer.

Youalsocanprogramthepowerbuttonsothatbypressingthepowerbuttonyoucanshutdownthe
computerorputitintosleeporhibernationmode.Toachievethis,youneedtochangeyourpowerplan
settings.Toaccesspowerplansettings,dothefollowing:

•ForWindows7:StartthePowerManagerprogramandthenclickthePowerPlantab.Forinstructionson

howtostartthePowerManagerprogram,see“AccessingLenovoprogramsontheWindows7operating
system”onpage13

.

•ForWindows8:ClickthebatterystatusiconfromtheWindowsnoticationareaandclickMorepower

options.ThenclickChoosewhatthepowerbuttonsdo.

2UserGuide

Right-sideview

Figure2.ThinkPadX131eright-sideview

1Mediacardreaderslot2HDMIport

3AlwaysOnUSBconnector

5Powerjack

1Mediacardreaderslot

4Power-statusindicator

6Securitykeyhole

Dependingonthemodels,yourcomputermighthaveamediacardreaderslot.Formoreinformationabout
thesupportedcards,see“Usingaashmediacard”onpage39

2HDMIport

.

Yourcomputersupportsthehigh-denitionmultimediainterface(HDMI)port,adigitalaudioandvideo
interfacethatcanconnectacompatibledigitalaudiodeviceorvideomonitor,suchasanHDTV.

3AlwaysonUSBconnector

Bydefault,theAlwaysOnUSBconnectorenablesyoutochargesomemobiledigitaldevicesand
smartphoneswhenyourcomputerisinsleeporhibernationmode.

Ifyouwanttochargethesedeviceswhenyourcomputeristurnedoff,dothefollowing:

1.Connectthecomputertoanacpowersupply.

2.GotoThinkPadSetupandenableAlwaysOnUSBChargeinoffmode.Formoreinformation,see
“Congmenu”onpage90.

3.Dooneofthefollowing:

•ForWindows7:StartthePowerManagerprogramandclicktheGlobalPowerSettingstab.Then

selecttheEnableAlwaysOnUSBcheckbox.

•ForWindows8:PresstheWindowskeytogototheStartscreen.ClickLenovoSettings➙Power.

ThenselecttheEnablewhenthecomputerisoffcheckbox.

Chapter1.Productoverview3

4Power-statusindicator

Yourcomputerhasapowerstatusindicatortoshowtheacpoweradapterstatusofyourcomputer.For
moreinformation,see“Powerstatusindicator”onpage8.

5Powerjack

Connecttheacpoweradaptertothepowerjacktoprovideacpowertothecomputerandchargethebattery.

Anindicatortotheleftoftheconnectorshowsthestatusofacpower.Whentheacpoweradapteris
connected,theindicatorislit.Ifabatteryisinstalledinthecomputer,theindicatorisgreenwhenthe
batterycharges.

6Securitykeyhole

Purchaseasecuritycablelockthattsthiskeyholetolockyourcomputertoastationaryobjecttoprotect
yourcomputerfromtheft.

Left-sideview

Figure3.ThinkPadX131eleft-sideview

1Videographicsarray(VGA)connector

3USB3.0connectors

5Comboaudiojack

1Videographicsarray(VGA)connector

2Fanlouver

4Ethernetconnector

AttachaVGAcompatiblemonitororprojectortoyourcomputertodisplaythecomputeroutput.

2Fanlouver

Theinternalfanandlouverenablesairtocirculateinthecomputerandcoolthecentralprocessor.

Note:Toavoidimpedingairow,donotplaceanyobstacleinfrontofthefan.

4UserGuide

3USB3.0connectors

TheUniversalSerialBus(USB)3.0connectorsareusedforconnectingdevicescompatiblewithaUSB
interface,suchasaUSBprinteroradigitalcamera.

Note:WhenyouattachaUSBcabletotheconnector,makesurethattheUSBmarkisfacingupward.
Otherwisetheconnectormightbedamaged.

4Ethernetconnector

ConnectyourcomputertoaLANwiththeEthernetconnector.

DANGER

Toavoidtheriskofelectricalshock,donotconnectthetelephonecabletotheEthernetconnector.
YoucanonlyconnectanEthernetcabletothisconnector.

Twoindicators,totheupperrightandleftoftheconnector,showthestatusofthenetworkconnection.
WhenyourcomputerconnectstoaLANandasessionwiththenetworkisavailable,theupperleftindicator
issteadygreen.Whiledataisbeingtransmitted,theupperrightindicatorblinksyellow.

5Comboaudiojack

Tolistentothesoundfromyourcomputer,connectaheadphoneoraheadsetthathasa3.5mm4-pole
plugtothecomboaudiojack.

Notes:

•Ifyouareusingaheadsetwithafunctionswitch,forexample,aheadsetforaniPhone

®

mobiledigital
device,donotpressthisswitchwhileusingtheheadset.Ifyoupressit,theheadsetmicrophonewillbe
disabled,andtheintegratedmicrophonesonthecomputerwillbeenabledinstead.

•Thecomboaudiojackdoesnotsupportaconventionalmicrophone.Formoreinformation,see“Using
audiofeatures”onpage38

.

Bottomview

Figure4.ThinkPadX131ebottomview

Chapter1.Productoverview5

1Battery

3Memoryupgradeslot

5PCIExpressMiniCardslotforwirelessLANorWiMax

card

1Battery

2SIMcardslot

4PCIExpressMiniCardslotforwirelessWANcard

6Harddiskdriveorsolid-statedrive

Useyourcomputerwiththebatterypowerwheneveracpowerisunavailable.

2SIMcardslot

IfyourcomputerhasawirelessWANfeature,itmightrequireaSubscriberIdenticationModule(SIM)card
toestablishawirelessWideAreaNetwork(WAN)connection.Dependingonthecountryofdelivery,theSIM
cardmightalreadybeinstalledintheSIMcardslot.

3Memory-upgradeslot

Youcanincreasetheamountofmemoryinyourcomputerbyinstallingamemorymoduleinthe
memory-upgradeslot.MemorymodulesareavailableasoptionsfromLenovo.

4PCIExpressMiniCardslotforwirelessWANcard

Yourcomputermighthavea(WAN)cardinstalledinthePCIExpressMiniCardslotforwirelessWAN
connections.

5PCIExpressMiniCardslotforwirelessLANorWiMAXcard

Yourcomputerincludesawirelesslocalareanetwork(LAN)cardorWorldwideInteroperabilityforMicrowave
Access(WiMAX)cardinthePCIExpressMiniCardslotforyoutoestablishwirelessLANorWiMAX
connections.

6Harddiskdriveorsolid-statedrive

Dependingonmodels,yourcomputermighthavealarge-capacity,customer-upgradableharddiskdrive
thatcanmeetavarietyofstoragedemands.

Somemodelsareequippedwithasolid-statedrivefordatastorage,makingyourcomputerlighter,smaller,
andfaster.

Note:Thehiddenservicepartitionisthereasonwhythereislessfreespacethanexpectedonyourhard
diskdriveorsolid-statedrive.Thisreductionismorenoticeableonthesolid-statedrivebecauseofits
smallercapacity.

Statusindicators

Thestatusindicatorsshowthecurrentstatusofyourcomputer.

Systemstatusindicators

TheilluminateddotintheThinkPadlogoontheouterlidofyourcomputerandonthepalmrestworks
asasystemstatusindicator.

6UserGuide

Themeaningoftheindicatorisasfollows:

•Red:Thecomputerison(innormalmode).

•Fastblinkingred:Thecomputerisenteringsleeporhibernationmode.

•Slowblinkingred:Thecomputerisinsleepmode.

•Off:Thecomputerisofforinhibernationmode.

Chapter1.Productoverview7

Wirelessstatusindicator

Thewirelessstatusindicatorislocatedontheouterlidofthecomputer.

Themeaningoftheindicatorisasfollows:

•Solidgreen:Thewirelessfeaturesofthecomputerareon.

•Off:Thewirelessfeaturesofthecomputerareoff.

Powerstatusindicator

Yourcomputerhasanindicatorthatshowsthestatusofacpower.

Themeaningoftheindicatorisasfollows:

•Green:Theacpoweradapterisconnected.

•Off:Theacpoweradapterisnotconnected.

CapsLockindicator

PresstheCapsLockkeytoenabletheCapsLockmodetotypeallalphabeticcharacters(A-Z)inuppercase
directly.WhentheCapsLockmodeisenabled,theCapsLockindicatorisdisplayedonthescreen.

8UserGuide

Locatingimportantproductinformation

Thissectionprovidesinformationtohelpyoulocateyourmachinetypeandmodellabel,FCCIDandIC
Certicationlabel,andtheMicrosoft

®

CerticateofAuthenticity(COA)label.

Machinetypeandmodellabel

Themachinetypeandmodellabelidentiesyourcomputer.WhenyoucontactLenovoforhelp,themachine
typeandmodelinformationhelpssupporttechnicianstoidentifyyourcomputerandprovidefasterservice.

Youcanndthemachinetypeandmodelofyourcomputeronthelabelasshownbelow:

FCCIDandICCerticationnumberlabel

ThereisnoFCCIDorICCerticationnumberforthePCIExpressMiniCardshownontheenclosureof
yourcomputer.TheFCCIDandICCerticationnumberlabelisafxedonthecardinstalledinthePCI
ExpressMiniCardslotofyourcomputer.

Chapter1.Productoverview9

IfyouhavepurchasedawirelessWANenabledcomputer,thewirelessWANPCIExpressHalfMiniCardis
preinstalledatthefactory.Ifyouneedtoremovethiscardforrepairorreplacement,followtheprocedurein
“ReplacingaPCIExpressMiniCardforwirelessLANconnection”onpage68.

Note:OnlyLenovoauthorizedwirelessLANorwirelessWANcardsareallowedtobeusedinyourcomputer.
IfyouinstallanunauthorizedPCIExpressMiniCardthatisnotapprovedforuseinyourcomputer,the
computerwillnotstart,butwillonlydisplayanerrormessageandemitaudiblebeeps.

CerticateofAuthenticitylabel

TheCerticateofAuthenticitylabelforthepreinstalledoperatingsystemisattached.Printedonthislabelare
theproductIDandtheproductkeyinformationforyourcomputer.Recordthisinformationandkeepitina
safeplace.Y oumightneedthesenumberstostartyourcomputerorreinstalltheoperatingsystem.

Note:TheCerticateofAuthenticitylabelappliesonlytocomputerspreinstalledwiththeWindows7
operatingsystem.

TheCerticateofAuthenticitylabelofyourcomputerisshownasbelow:

Features

Thistopicliststhefeaturesofyourcomputer.

Processor

•Toviewtheprocessorinformationofyourcomputer,dothefollowing:

–ForWindows7:ClickStart,right-clickComputer.ThenclickProperties.

10UserGuide

–ForWindows8:Movethecursortothetop-rightorbottom-rightcornerofthescreentodisplaythe

charms.ThenclickSettings➙PCinfo.

Memory

•Doubledatarate3synchronousdynamicrandomaccessmemorymodules(DDR3SDRAM)

Storagedevice

•2.5-inch(7mmheight)harddiskdriveor2.5-inch(7mmheight)solid-statedrive

Display

ThecolordisplayusestheTFTtechnology.

•Size:11.6inches(294.64mm)

•Resolution:

–LCD:Upto1366x768
–Externalmonitor:Upto2048x1536(VGA)orupto2560x1600(HDMI)

•Brightnesscontrol

•Integratedcamera

Keyboard

•6-rowkeyboard

•UltraNavpointingdevice(TrackPointandmulti-touchtouchpad)

•Fnkey

Interface

•Externalmonitorconnectors(VGAconnectorandHDMIconnector)

•Comboaudiojack

•TwoUSB3.0connectors

•OneAlwaysonUSBconnector

•RJ45Ethernetconnector

•4-in-1digitalmediacardreader

Wirelessfeatures

•IntegratedwirelessLAN

•IntegratedwirelessWAN(onsomemodels)

•IntegratedWiMAX(onsomemodels)

•IntegratedBluetooth(onsomemodels)

Specications

Thissectionliststhephysicalspecicationsforyourcomputer.

Size

•Width:293.4mm(11.55inches)

•Depth:216mm(8.50inches)

Chapter1.Productoverview11

•Height:32.3mm(1.27inches)

Heatoutput

•65W(222Btu/hr)maximum

Powersource(acpoweradapter)

•Sine-waveinputat50to60Hz

•Inputratingoftheacpoweradapter:100to240Vac,50to60Hz

Batterypack

•Lithium-ion(Li-Ion)batterypack

Batterylife

•Forthepercentageofremainingbatterypower,checkthebatterystatusiconintheWindowsnotication
area.

Operatingenvironment

Thissectionprovidesinformationaboutyourcomputeroperatingenvironment.

Environment:

•Maximumaltitudewithoutpressurization:3048m(10000ft)

•Temperature

–Ataltitudesupto2438m(8000ft)

–Operating:5.0°Cto35.0°C(41°Fto95°F)
–Storage:5.0°Cto43.0°C(41°Fto109°F)

–Ataltitudesabove2438m(8000ft)

–Maximumtemperaturewhenoperatingundertheunpressurizedcondition:31.3°C(88°F)

Note:Whenyouchargethebatterypack,itstemperaturemustbeatleast10°C(50°F).

•Relativehumidity:

–Operating:8%to80%
–Storage:5%to95%

Ifpossible,placeyourcomputerinawell-ventilatedanddryareawithoutdirectexposuretosunshine.

Keepelectricalappliancessuchasanelectricfan,radio,airconditioner,andmicrowaveovenawayfrom
yourcomputerbecausethestrongmagneticeldsgeneratedbytheseappliancescandamagethemonitor
anddataontheharddiskdrive.

Donotplaceanybeveragesontopoforbesidethecomputerorotherattacheddevices.Ifliquidisspilledon
orinthecomputeroranattacheddevice,ashortcircuitorotherdamagemightoccur.

Donoteatorsmokeoveryourkeyboard.Particlesthatfallintoyourkeyboardcancausedamage.

12UserGuide

Lenovoprograms

YourcomputercomeswithLenovoprogramstohelpyouworkmoreeasilyandsecurely.Dependingon
theWindowsoperatingsystempreinstalled,theprogramsmightvary.

TolearnmoreabouttheprogramsandothercomputingsolutionsofferedbyLenovo,goto
http://www.lenovo.com/support.

AccessingLenovoprogramsontheWindows7operatingsystem

OntheWindows7operatingsystem,youcanaccessLenovoprogramsfromeithertheLenovoThinkVantage
ToolsprogramorfromControlPanel.

AccessingLenovoprogramsfromtheLenovoThinkVantageToolsprogram
ToaccessLenovoprogramsfromtheLenovoThinkVantageToolsprogram,clickStart➙AllPrograms➙

LenovoThinkVantageTools.Thendouble-clickaprogramicontoaccesstheprogram.

Note:IfaprogramiconintheLenovoThinkVantageToolsprogramnavigationwindowisdimmed,it

indicatesthatyouneedtoinstalltheprogrammanually.Toinstalltheprogrammanually,double-clickthe
programicon.Then,followtheinstructionsonthescreen.Whentheinstallationprocesscompletes,the
programiconwillbeactivated.

Table1.ProgramsintheLenovoThinkVantageToolsprogram

ProgramIconname

AccessConnections™InternetConnection

ActiveProtectionSystem™

ClientSecuritySolutionEnhancedSecurity

CommunicationsUtilityWebConferencing

FingerprintSoftware

GPSEnablerGPS

LenovoSolutionCenterSystemHealthandDiagnostics

MobileBroadbandConnect3GMobileBroadband

PasswordManagerPasswordVault

PowerManager

RecoveryMediaFactoryRecoveryDisks

RescueandRecovery

SimpleTapSimpleTap

SystemUpdate

®

AirbagProtection

FingerprintReader

PowerControls

EnhancedBackupandRestore

UpdateandDrivers

Note:Dependingonyourcomputermodel,someoftheprogramsmightnotbeavailable.

AccessingLenovoprogramsfromControlPanel

ToaccessLenovoprogramsfromControlPanel,clickStart➙ControlPanel.Thendependingonthe
programyouwanttoaccess,clickthecorrespondingsectionandthenclickthecorrespondinggreentext.

Note:IfyoudonotndtheprogramyouneedinControlPanel,opentheLenovoThinkVantageTools
programnavigationwindowanddouble-clickthedimmedicontoinstalltheprogramyouneed.Then,

Chapter1.Productoverview13

followtheinstructionsonthescreen.Whentheinstallationprocesscompletes,theprogramiconwillbe
activated,andyoucanndtheprograminControlPanel.

TheprogramsandthecorrespondingsectionsandgreentextsinControlPanelarelistedinthefollowing
table.

Table2.ProgramsinControlPanel

Program

AccessConnections

ActiveProtectionSystemSystemandSecurity

ClientSecuritySolutionSystemandSecurityLenovo-EnhancedSecurity

CommunicationsUtilityHardwareandSoundLenovo-WebConferencing

FingerprintSoftwareSystemandSecurity

GPSEnabler

LenovoSolutionCenterSystemandSecurityLenovo-SystemHealthand

MessageCenterPlus

MobileBroadbandConnect

PasswordManager

PowerManager

RecoveryMedia

SimpleTap

SystemUpdateSystemandSecurity

RescueandRecovery

ControlPanelsectionGreentextinControlPanel

NetworkandInternet

HardwareandSound

HardwareandSound

NetworkandInternet

Programs

NetworkandInternet

SystemandSecurity
UserAccountsandFamilySafety

HardwareandSound
SystemandSecurity

SystemandSecurity

Programs

SystemandSecurity

Lenovo-InternetConnection

Lenovo-AirbagProtection

Lenovo-FingerprintReader
or
Lenovo-NotebookFingerprint

Reader

Lenovo-GPS

Diagnostics

MessagesfromLenovo

Lenovo-3GMobileBroadband

Lenovo-PasswordVault

Lenovo-PowerControls

Lenovo-FactoryRecoveryDisks

Lenovo-SimpleTap

Lenovo-UpdateandDrivers

Lenovo-EnhancedBackupand
Restore

Note:Dependingonyourcomputermodel,someoftheprogramsmightnotbeavailable.

AccessingLenovoprogramsontheWindows8operatingsystem

IfyourcomputerispreinstalledwiththeWindows8operatingsystem,youcanaccessLenovoprogramsby
doingeitherofthefollowing:

•ClicktheLenovoQuickLaunchiconfromthetaskbar.Alistofprogramsisdisplayed.Double-clicka
Lenovoprogramtolaunchit.Ifadesiredprogramisnotinthelist,clicktheplusicon+.

•PresstheWindowskeytogototheStartscreen.ClickaLenovoprogramtolaunchit.Ifyoucannotnd
theprogramyouneed,Movethecursortothetop-rightorbottom-rightcornerofthescreentodisplaythe
charms.ThenclicktheSearchcharmtosearchforthedesiredprogram.

YourcomputersupportsthefollowingLenovoprograms:

•ActiveProtectionSystem

14UserGuide

•FingerprintSoftware

•LenovoCompanion

•LenovoSettings

•LenovoMobileAccess

•LenovoSolutionCenter

•LenovoQuickLaunch

•LenovoSupport

•LenovoThinkVantageT ools

•PasswordManager

•SystemUpdate

Note:ThePasswordManagerprogramisnotpreinstalledonyourWindows8computers.Youcandownload
itfromtheLenovoSupportWebsitehttp://www.lenovo.com/support.

Foranintroductiontotheseprograms,see“AnintroductiontoLenovoprograms”onpage15

.

AnintroductiontoLenovoprograms

ThistopicprovidesabriefintroductiontosomeLenovoprograms.

Note:Dependingonyourcomputermodel,someoftheprogramsmightnotbeavailable.

•AccessConnections
TheAccessConnectionsprogramisaconnectivityassistantprogramforcreatingandmanaginglocation

proles.EachlocationprolestoresallthenetworkandInternetcongurationsettingsneededfor
connectingtoanetworkinfrastructurefromaspeciclocationsuchasahomeoranofce.

Byswitchingbetweenlocationprolesasyoumoveyourcomputerfromplacetoplace,youcanquickly
andeasilyconnecttoanetworkwithnoneedtorecongureyoursettingsmanuallyandrestartthe
computereachtime.

•ActiveProtectionSystem
TheActiveProtectionSystemprogramprotectsyourharddiskdrivewhentheshocksensorinsideyour

computerdetectsaconditionthatcoulddamagethedrive,suchassystemtilt,excessivevibration,or
shock.Theharddiskdriveislessvulnerabletodamagewhenitisnotoperating.Thisisbecausewhen
theharddiskdriveisnotoperating,thesystemstopsitfromspinning,andmightalsomovetheread
andwriteheadsofthedrivetoareasthatdonotcontaindata.Assoonastheshocksensorsenses
thattheenvironmentisstableagain(minimalchangeinsystemtilt,vibration,orshock),itturnsthe
harddiskdriveon.

•ClientSecuritySolution
TheClientSecuritySolutionprogramprotectsyourcomputerbysecuringclientdataanddeecting

securitybreachattempts.Italsocanhelpmanageyourpasswords,recoveraforgottenpassword,
monitorsecuritysettingsonyourcomputer,andsuggesthowtoenhanceyourcomputersecurity.

•CommunicationsUtility
UsetheCommunicationsUtilityprogramtoconguresettingsfortheintegratedcameraandaudiodevices.

•FingerprintSoftware
Ifyoursystemcomeswithangerprintreader,theFingerprintSoftwareprogramenablesyoutoenroll

yourngerprintandassociateitwithyourWindowspassword.Asaresult,thengerprintauthentication
canreplaceyourpasswordandenablesimpleandsecureuseraccess.

•GPSEnabler

Chapter1.Productoverview15

IfthePCIExpressMiniCardinstalledinyourcomputersupportsGPS,yourcomputercanreceivesignals
fromGPSsatellitesanddetermineitslocation.IfyourcomputerisconnectedtotheInternet,youcannd
yourlocationonareal-timemapprovidedbyGoogleMapsorMicrosoftBing™Maps.

•LenovoCompanion
ThroughtheLenovoCompanionprogram,youcangettheinformationabouttheaccessoriesforyour

computer,viewbolgsandarticlesaboutyourcomputer,andcheckforotherrecommendedprograms.

•LenovoSettings
UsetheLenovoSettingsprogramtoenhanceyourcomputingexperiencebyturningyourcomputerintoa

portablehotspot,conguringcameraandaudiosettings,optimizingyourpowersettings,andcreating
andmanagingmultiplenetworkproles.

•LenovoMobileAccess
TheLenovoMobileAccessprogramenablesyoutomanageyourmobilebroadbandconnection.You

cancreateanaccount,addmoneytotheaccount,andpurchasemobilebroadbandsessionsusing
youraccount.

•LenovoSolutionCenter
TheLenovoSolutionCenterprogramenablesyoutotroubleshootandresolvecomputerproblems.It

combinesdiagnostictests,systeminformationcollection,securitystatus,andsupportinformation,along
withhintsandtipsformaximumsystemperformance.

•LenovoQuickLaunch
TheLenovoQuickLaunchprogramprovidesyouwithquickaccesstoprogramsinstalledonyour

computer,includingLenovoprograms,Microsoftprograms,andotherthirdpartyprograms.

•LenovoSupport
TheLenovoSupportprogramenablesyoutoregisteryourcomputerwithLenovo,checkthecomputer

healthconditionandbatterystatus,downloadandviewusermanualsforyourcomputer,getthewarranty
informationofyourcomputer,andexplorehelpandsupportinformation.

•LenovoThinkVantageT ools
TheLenovoThinkVantageToolsprogramhelpsyouworkmoreeasilyandsecurelybyprovidingeasy

accesstovariousprograms,suchasFingerprintSoftware,LenovoSolutionCenter,andsoon.

•MessageCenterPlus
TheMessageCenterPlusprogramautomaticallydisplaysmessagestoinformyouaboutimportantnotices

fromLenovo,suchasalertsonsystemupdatesandalertsonconditionsthatrequireyourattention.

•MobileBroadbandConnect
TheMobileBroadbandConnectprogramenablesyourcomputertoconnecttothemobilebroadband

(3G)networkthroughasupportedwirelessWANcard.

•PasswordManager
ThePasswordManagerprogramautomaticallycapturesandllsinauthenticationinformationfor

WindowsprogramsandWebsites.

•PowerManager
ThePowerManagerprogramprovidesconvenient,exible,andcompletepowermanagementforyour

computer.Itenablesyoutoadjustyourcomputerpowersettingstoachievethebestbalancebetween
performanceandpowersaving.

•RecoveryMedia
TheRecoveryMediaprogramenablesyoutorestorethecontentsoftheharddiskdrivetothefactory

defaultsettings.

•RescueandRecovery

16UserGuide

TheRescueandRecoveryprogramisaone-buttonrecoveryandrestoresolutionthatincludesasetof
self-recoverytoolstohelpyoudiagnosecomputerproblems,gethelp,andrecoverfromsystemcrashes,
evenifyoucannotstarttheWindowsoperatingsystem.

•SimpleT ap
TheSimpleTapprogramprovidesyouwithaquickwaytocustomizesomebasiccomputersettingssuch

asmutingthespeakers,adjustingthevolume,lockingthecomputeroperatingsystem,launchinga
program,openingaWebpage,openingale,andsoon.YoualsocanusetheSimpleTapprogramto
accesstheLenovoAppShop,fromwhichyoucandownloadvariousprogramsandcomputersoftware.

TostarttheSimpleTapprograminaquickway,clicktheredSimpleTaplaunchpointonthedesktop.
TheredlaunchpointisavailableonthedesktopafteryouhavelaunchedtheSimpleTapprogramfor
thersttime.

Note:TheSimpleTapprogramisonlyavailableoncertainmodelspreinstalledwiththeWindows7
operatingsystem.IfyourWindows7modelisnotpreinstalledwiththeSimpleTapprogram,youcan
downloaditfromhttp://www.lenovo.com/support.

•SystemUpdate
TheSystemUpdateprogramhelpsyoukeepthesoftwareonyourcomputerup-to-datebydownloading

andinstallingsoftwareupdatepackages(Lenovoprograms,devicedrivers,UEFIBIOSupdates,and
otherthirdpartyprograms).

Chapter1.Productoverview17

18UserGuide

Chapter2.Usingyourcomputer

Thischapterprovidesinformationonusingsomeofthecomputercomponents.

Thischaptercontainsthefollowingtopics:

•“Registeringyourcomputer”onpage19

•“Frequentlyaskedquestions”onpage19

•“Specialkeysandbuttons”onpage21

•“UsingtheUltraNavpointingdevice”onpage23

•“Powermanagement”onpage26

•“Connectingtothenetwork”onpage31

•“Presentationsandmultimedia”onpage35

•“Usingaudiofeatures”onpage38

•“Usingtheintegratedcamera”onpage38

•“Usingaashmediacard”onpage39

Registeringyourcomputer

Whenyouregisteryourcomputer,informationisenteredintoadatabase,whichenablesLenovotocontact
youincaseofarecallorothersevereproblem.AfteryouregisteredyourcomputerwithLenovo,youwill
alsoreceivequickerservicewhenyoucallLenovoforhelp.Inaddition,somelocationsofferextended
privilegesandservicestoregisteredusers.

ToregisteryourcomputerwithLenovo,dooneofthefollowing:

•Gotohttp://www.lenovo.com/registerandfollowtheinstructionsonthescreentoregisteryourcomputer.

•ConnectyourcomputertotheInternetandregisteryourcomputerthroughapreinstalledregistration
program:

–ForWindows7:ThepreinstalledLenovoProductRegistrationprogramlaunchesautomaticallyafteryou

haveusedyourcomputerforatime.Followtheinstructionsonthescreentoregisteryourcomputer.

–ForWindows8:OpentheLenovoSupportprogram.ThenclickRegistrationandfollowtheinstructions

onthescreentoregisteryourcomputer.

Frequentlyaskedquestions

Thefollowingareafewtipsthatwillhelpyouoptimizetheuseofyourcomputer.

Toensurethatyoureceivethebestperformancefromyourcomputer,gotothefollowingWebpage
tondinformationsuchasaidsfortroubleshootingandanswerstofrequentlyaskedquestions:
http://www.lenovo.com/support/faq

CanIgetmyuserguideinanotherlanguage?

•Todownloadtheuserguideinanotherlanguage,goto:http://www.lenovo.com/support.Thenfollow
theinstructionsonthescreen.

Howtousethebatterypowermoreeffectively?

©CopyrightLenovo2012

19

•Toconservepower,ortosuspendoperationwithoutexitingprogramsorsavingles,see“Power-saving
modes”onpage28.

•Toachievethebestbalancebetweenperformanceandpowersaving,changepowerplansettings.

•Ifyourcomputerwillbeturnedoffforanextendedperiodoftime,youcanpreventbatterypower
fromdrainingbyremovingthebattery.Lookformoreinformationaboutusingthebatteryin“Power
management”onpage26.

Concernedaboutsecurityorneedtosecurelydisposeofdatastoredonyourharddiskdriveor
solid-statedrive?

•StudyChapter4“Security”onpage45

tondouthowyoucanprotectyourcomputerfromtheftand

unauthorizeduse.

•UsethePasswordManagerprogramtoprotectthedatastoredonyourcomputer.Fordetails,seethe
helpinformationsystemoftheprogram.

•Beforeyoudisposeofthedataontheharddiskdriveorsolid-statedrive,besuretoread“Noticeon
deletingdatafromyourharddiskdriveorsolid-statedrive”onpage51.

Isgettingconnectedindifferentlocationsachallenge?

•Totroubleshootawirelessnetworkingissue,goto:
http://www.lenovo.com/support/faq

•TakeadvantageofthenetworkingfeaturesprovidedbytheAccessConnectionsprogram(onthe
Windows7operatingsystem)orLocationAwarenessintheLenovoSettingsprogram(ontheWindows8
operatingsystem).

•Tolearnmoreaboutusingthewirelessfeaturesofyourcomputer,referto“Wirelessconnections”on
page31

.

•Totravelmorecondently,besuretocheckthetipsin“Travelingwithyourcomputer”onpage43.

•PressFn+F5toenableordisablethewirelessfeatures.

Needtogivepresentationsorattachanexternalmonitoroften?

•Makesurethatyoufollowtheprocedurefor“Attachinganexternalmonitor”onpage35

.

•WiththeExtenddesktopfunction,youcandisplayoutputonboththecomputerdisplayandanexternal
monitor.

Needtoattachorreplaceadevice?

•SeeChapter6“Replacingdevices”onpage61

formoreinformationaboutreplacingthedevicesof

yourcomputer.

Youhavebeenusingyourcomputerforsometimealready,anditisgettingslower?

•Follow“Generaltipsforpreventingproblems”onpage105.

•Youcandiagnoseproblemsyourselfbyusingthepreinstalleddiagnosticsoftware.

•CheckforrecoverysolutionsinChapter5“Recoveryoverview”onpage53

.

Printthefollowingsectionsandkeepthemwithyourcomputerincaseyouareunabletoaccessthisonline
userguidewhennecessary.

•“Installinganewoperatingsystem”onpage85

•“Computerstopsresponding”onpage111

•“Powerproblems”onpage124

20UserGuide

Specialkeysandbuttons

Yourcomputerhasseveralspecialfunctionkeysandbuttonstohelpyouworkmoreeasilyandeffectively.

Functionkeycombinations

TousetheFnfunctionkeycombinations,pressandholdtheFnkey1;thenpressoneofthefunction
keys2.Releasebothkeys.

Volumeandmutebuttons

Toquicklyadjustthevolumeofthesoundfromyourcomputer,mutethesoundentirely,orsetthe
microphonetomute,pressoneofthefollowingkeycombinations.

•Fn+Esc:Speakermute

•Fn+F1:Speakervolumedown

•Fn+F2:Speakervolumeup

•Fn+F3:Microphonemute

Note:Ifyoumutethesoundbeforeyouturnoffthecomputer,thesoundwillremainmutedwhenyou
turnonyourcomputeragain.Tounmutethesound,pressthespeakervolumeuporspeakervolume
downkeycombination.

Powerconservation

•Fn+F4

Putyourcomputerintosleepmode.Toreturntonormaloperation,presstheFnkeyonly.

Ifyouwanttousethecombinationtoputthecomputerintohibernationmode,youneedtochangeyour
powerplansettings.T oaccesspowerplansettings,dothefollowing:

•ForWindows7:StartthePowerManagerprogramandthenclickthePowerPlantab.Forinstructionson
howtostartthePowerManagerprogram,see“AccessingLenovoprogramsontheWindows7operating
system”onpage13

•ForWindows8:Right-clickthebatterystatusiconfromtheWindowsnoticationareaandclickPower
Options.ThenclickChangeplansettingsthatisnexttoyourpowerplan.

.

Chapter2.Usingyourcomputer21

Wirelessfeatures

•Fn+F5

Enableordisablethebuilt-inwirelessnetworkingfeatures.

Launchingthecameraandaudiosettings

•Fn+F6

–ForWindows7:OpentheCommunicationssettingswindow,inwhichyoucanpreviewyourvideo

image,takeasnapshotofyourcurrentimage,andchangethecameraandaudiosettings.

–ForWindows8:StarttheLenovoSettingsprogram.Tousethecameraorchangethecamerasettings,

clickCamera.Toadjusttheaudiosettings,clickAudio.

Switchingthedisplayoutputlocation

•Fn+F7

PressFn+F7toswitchbetweenthecomputerdisplayandanexternalmonitor.Afteryoupressthiskey
combination,thefollowingoptionswillbedisplayed:

•Computerdisplayonly(LCD)

•Computerdisplayandexternalmonitor(duplicatedimage)

•Computerdisplayandexternalmonitor(theExtendeddesktopfunction)

•Externalmonitoronly

Note:TheWindows+PkeycombinationcanachievethesamefunctionalityasFn+F7.

Adjustingthebrightnesslevelofthecomputerdisplay

•Fn+F8:Thecomputerdisplaybecomesdimmer.

•Fn+F9:Thecomputerdisplaybecomesbrighter.

Note:Thisfunctionchangesthebrightnessleveltemporarily.Tochangethedefaultbrightnesslevel,change
thesettingsthroughthePowerManagerprogram.

Multimediacontrols

•Fn+F10:Previoustrack/scene

•Fn+F11:Playorpause

•Fn+F12:Nexttrack/scene

Legacyfunctionkeys

•Fn+B:HasthesamefunctionsastheBreakkeyontheconventionalkeyboard.

•Fn+K:HasthesamefunctionsastheScrLkkeyontheconventionalkeyboard.

•Fn+P:HasthesamefunctionsasthePausekeyontheconventionalkeyboard.

•Fn+S:HasthesamefunctionsastheSysRqkeyontheconventionalkeyboard.

22UserGuide

Windowskey

OntheWindows7operatingsystem,presstheWindowskeytoopentheStartmenu.OntheWindows8
operatingsystem,presstheWindowskeytoswitchbetweenthecurrentworkspaceandtheStartscreen.

YoualsocanusetheWindowskeytogetherwithanotherkeytoachieveotherfunctions.Formore
information,refertothehelpinformationsystemoftheWindowsoperatingsystem.

UsingtheUltraNavpointingdevice

YourcomputercomeswiththeUltraNavpointingdevice.TheUltraNavpointingdeviceconsistsofthe
TrackPointpointingdeviceandthetouchpad,eachofwhichisitselfapointingdevicewithbothbasicand
extendedfunctions.Youcancongurebothdevicesbychoosingthesettingsyoupreferasfollows:

•SetboththeTrackPointpointingdeviceandthetouchpadaspointingdevices.
ThissettingenablestheuseofallthebasicandextendedfunctionsoftheTrackPointpointingdevice

andthetouchpad.

•SettheT rackPointpointingdeviceasthemainpointingdeviceandthetouchpadforextended

functionsonly.

ThissettingenablestheuseofallbasicandextendedfunctionswiththeTrackPointpointingdevicewhile
limitingtheuseofthetouchpadtoscrolling,tapzones,andslow-motionpointerfunctions.

•SettheTrackPointpointingdeviceasthemainpointingdevice,anddisablethetouchpad.

•Setthetouchpadasthemainpointingdevice,anddisabletheTrackPointpointingdevice.

ChangingtheUltraNavpointingdevicesettings
TochangeyourUltraNavpointingdevicesettings,gotoControlPanelandclickHardwareandSound➙

Mouse➙UltraNav.Thenchangethesettingsasdesired.

UsingtheTrackPointpointingdevice

TheTrackPointpointingdeviceconsistsofapointingstick1onthekeyboardandthreeclickbuttonsatthe
bottomofthekeyboard.T omovethepointer5onthescreen,youapplypressuretothenonslipcaponthe
pointingstickinanydirectionparalleltothekeyboard;thepointingstickitselfdoesnotmove.Thespeedat
whichthepointermovesdependsonthepressureyouapplytothepointingstick.Thefunctionsoftheleft4
andright2clickbuttonscorrespondtothoseoftheleftandrightmousebuttonsonaconventionalmouse.

Chapter2.Usingyourcomputer23

TheTrackPointcenterbutton3,calledthescrollbar,enablesyoutoscrollWebpagesordocumentsinany
directionwithnoneedtousethegraphicscrollbarsonthesideofthewindow.

IfyouarenotfamiliarwiththeTrackPointpointingdevice,theseinstructionswillhelpyougetstarted:

1.Placeyourhandsinthetypingposition,andpressgentlywithanindexngeroramiddlengeronthe
pointingstickinthedirectioninwhichyouwantthepointertomove.

Tomovethepointer,pressthepointingstickawayfromyoutomoveitup,towardyoutomoveit
down,toonesideortheothertomoveitsideways.

Note:Thepointermightdrift.Thisisnotadefect.StopusingtheTrackPointpointingdeviceforafew
seconds;thepointerwillstopmoving.

2.T oselectanddragasrequiredbyyoursoftware,presstheleftorrightclickbuttonwitheitherthumb
andmovetheTrackPointpointingstick.

CustomizingtheTrackPointpointingdevice

YoucancustomizetheTrackPointpointingdeviceanditsbuttonsasfollows:

•Switchthefunctionsoftheleftandrightbuttons.

•ChangethesensitivityoftheTrackPointpointingdevice.

•EnabletheTrackPointScrollingTips.

Changingthecap

Thecap1ontheendoftheT rackPointpointingstickisremovable.Youcanreplaceitasshownin
thedrawing.

24UserGuide

Note:Ifyoureplacethekeyboard,anewkeyboardisshippedwiththedefaultcap.Ifyouwish,youcan

keepthecapfromyouroldkeyboardanduseitonthenewone.

Usingthetouchpad

Thetouchpadisapad1belowtheT rackPointbuttonsatthebottomofthekeyboard.Tomovethepointer

2onthescreen,slideyourngertipoverthepadinthedirectioninwhichyouwantthepointertomove.

Theleftandrightbottomofthepadworkasclickbuttons.Thefunctionscorrespondtothoseoftheleft
andrightmousebuttonsonaconventionalmouse.

Usingthemulti-touchtouchpad

Thetouchpadofyourcomputersupportsmulti-touchwithwhichyoucanzoomin,zoomout,scroll,or
rotateonthescreenwhilebrowsingtheInternetorreadingoreditingadocument.

Fordetails,refertotheUltraNavhelpinformationsystem.

Customizingthetouchpad

Tocustomizethetouchpad,dothefollowing:

1.GotoControlPanelandclickHardwareandSound➙Mouse➙UltraNav.

2.IntheT ouchPadsection,changesettingsasdesired.

Chapter2.Usingyourcomputer25

DisablingtheUltraNavpointingdeviceandusinganexternalmouse

IfyouattachanexternalmousetoaUSBconnector,youcanusetheexternalmousesimultaneouslywith
theT rackPointpointingdeviceandthetouchpad.

DisablingtheTrackPointpointingdeviceorthetouchpad

TodisabletheTrackPointpointingdeviceorthetouchpad,dothefollowing:

1.GotoControlPanelandclickHardwareandSound➙Mouse➙UltraNav.

2.T odisabletheTrackPointpointingdevice,clearthecheckboxforEnableTrackPoint.Todisablethe
touchpad,clearthecheckboxforEnableT ouchPad.

3.ClickOK.

AddingtheUltraNavicontotheWindowsnoticationarea

ForeasyaccesstotheUltraNavproperties,youcanenablethedisplayoftheUltraNaviconintheWindows
noticationarea.

ToenablethedisplayoftheUltraNaviconintheWindowsnoticationarea,dothefollowing:

1.GotoControlPanelandclickHardwareandSound➙Mouse➙UltraNav.

2.SelectthecheckboxforShowUltraNavicononthesystemtray.

3.ClickOK.YoucannowchangethepropertiesoftheUltraNavpointingdevicebyclickingtheUltraNav
iconintheWindowsnoticationarea.

Note:IfyoucannotseetheUltraNavicon,clickthetriangulariconintheWindowsnoticationarea
toshowhiddenicons.

Powermanagement

Whenyouneedtouseyourcomputerawayfromelectricaloutlets,youdependonbatterypowertokeep
yourcomputerrunning.Differentcomputercomponentsconsumepoweratdifferentrates.Themoreyou
usethepower-intensivecomponents,thefasteryouconsumebatterypower.

SpendmoretimeunpluggedwithThinkPadbatteries.Mobilityhasrevolutionizedbusinessbyallowing
youtotakeyourworkwhereveryougo.WithThinkPadbatteries,youwillbeabletoworklongerwithout
beingtiedtoanelectricaloutlet.

Checkingthebatterystatus

ThebatterystatusiconintheWindowsnoticationareadisplaysthepercentageofbatterypowerremaining.

Therateatwhichyouusebatterypowerwilldeterminehowlongyoucanusethebatteryofyourcomputer
betweencharges.Becauseeachcomputeruserhasdifferenthabitsandneeds,itisdifculttopredicthow
longabatterychargewilllast.Therearetwomainfactors:

•Howmuchenergyisstoredinthebatterywhenyoubegintowork.

•Thewayyouuseyourcomputer.Forexample:

–Howoftenyouaccesstheharddiskdrive.
–Howbrightyoumakethecomputerdisplay.
–Howoftenyouusethewirelessfeatures.

Tocheckfordetailedbatterystatusinformation,dothefollowing:

•ForWindows7:OpenthePowerManagerprogramandclicktheBatterytab.

26UserGuide

•ForWindows8:OpentheLenovoSupportprogramandclickBatteryHealth,oropentheLenovo
SettingsprogramandclickPower.

Usingtheacpoweradapter

Thepowertorunyourcomputercancomeeitherfromthelithium-ion(Li-ion)batterypackprovidedwithit,
orfromacpowerthroughtheacpoweradapter.Whileyouuseacpower,thebatterychargesautomatically.

Theacpoweradapterthatcomeswithyourcomputerhastwobasiccomponents:

•Thetransformerpackthatconvertsacpoweradapterforusewiththecomputer.

•Thepowercordthatplugsintotheacoutletandintothetransformerpack.

Attention:Usinganimproperpowercordcouldcauseseveredamagetoyourcomputer.

Connectingtheacpoweradapter

Tousetheacpoweradapter,dothefollowing.Besuretotakethesestepsintheorderinwhichtheyare
givenhere.

1.Connecttheacpoweradaptertothepowerjackofthecomputer.

2.Connectthepowercordtothetransformerpack.

3.Plugthepowercordintoanelectricaloutlet.

Tipsonusingtheacpoweradapter

Youcancheckthestatusofyourbatteryatanytimebylookingatthebatterymeteratthebottomofyour
display.

•Whentheacpoweradapterisnotinuse,disconnectitfromtheelectricaloutlet.

•Donotbindthepowercordtightlyaroundtheacpoweradaptertransformerpackwhenitisconnectedto
thetransformer.

•Beforeyouchargethebattery,makesurethatitstemperatureisatleast10°C(50°F).

•Youcanchargethebatterywhentheacpoweradapterisconnectedtothecomputerandthebatteryis
installed.Youneedtochargeitinanyofthefollowingconditions:

–Whenyoupurchaseanewbattery
–Ifthebatterymeteratthebottomofyourdisplayshowsthebatterychargeislow
–Ifthebatteryhasnotbeenusedforalongtime

Chargingthebattery

Whenyoucheckbatterystatusandndthatthepercentageofpowerremainingisloworwhenthepower
alarmalertsyouthattheremainingpowerislow,youneedtochargeyourbatteryorreplaceitwitha
chargedbattery.

Ifanacoutletisconvenient,plugtheacpoweradapterintoit,andtheninsertthejackintothecomputer.
Thebatterywillbefullychargedinabout3to6hours.Thisisaffectedbythebatterysizeandthephysical
environment.Thebatterystatusindicatorwillletyouknowthatthebatteryischarging,andwillalsonotify
youwhenthebatteryisfullycharged.

Note:Toincreasethelifeofthebattery,thecomputerdoesnotstartrechargingthebatteryiftheremaining
powerisgreaterthan95%.

Maximizingthebatterylife

Tomaximizethelifeofthebattery,dothefollowing:

Chapter2.Usingyourcomputer27

•Usethebatteryuntilthechargeiscompletelydepleted;thatis,usethebatteryuntilthebatterystatus
indicatorstartsblinkingorange.

•Rechargethebatterycompletelybeforeusingit.Thebatteryisfullychargedifthebatteryindicatorshows
greenwhentheacpoweradapterispluggedin.

•Alwaysusepowermanagementfeaturessuchaspowermodes,screenblank,sleep,andhibernation.

Managingthebatterypower

Toachievethebestbalancebetweenperformanceandpowersaving,adjustyourpowerplansettings.
Toaccesspowerplansettings,dothefollowing:

•ForWindows7:StartthePowerManagerprogramandthenclickthePowerPlantab.Forinstructionson
howtostartthePowerManagerprogram,see“AccessingLenovoprogramsontheWindows7operating
system”onpage13.

•ForWindows8:Right-clickthebatterystatusiconfromtheWindowsnoticationareaandclickPower
Options.ThenclickChangeplansettingsthatisnexttoyourpowerplan.

Formoreinformation,refertothehelpinformationsystemoftheprogram.

Power-savingmodes

Thereareseveralpower-savingmodesthatyoucanuseatanytimetoconservepower.Thissection
introduceseachmodeandgivestipsontheeffectiveuseofthebatterypower.

Introducingthepower-savingmodes

•Screenblank(fortheWindows7operatingsystemonly)
Thecomputerdisplayrequiresconsiderablebatterypower.T oturnoffpowertothedisplay,dothe
following:

1.Right-clickthePowerManagerbatterygaugeonthetaskbar.

2.SelectPoweroffdisplay.

•Sleep
Insleepmode,yourworkissavedtomemory,andthenthesolid-statedriveortheharddiskdriveandthe
computerdisplayareturnedoff.Whenyourcomputerwakesup,yourworkisrestoredwithinseconds.T o
putyourcomputerintosleepmode,pressFn+F4.Toreturnfromsleepmode,pressFnkey.

Dependingonthecomputermodel,yourcomputermightsupportthe30DayStandbyfunction.Whenthis
functionisenabled,thecomputerconsumesevenlesspowerinsleepmodeandtakesonlyseconds
toresumenormaloperationwhenyoupressthepowerbutton.Formoreinformationaboutthe30Day
Standbyfunction,dothefollowing:

–ForWindows7:RefertothehelpinformationsystemofthePowerManagerprogram.Forinstructions

onhowtostartthePowerManagerprogram,see“AccessingLenovoprogramsontheWindows7
operatingsystem”onpage13

–ForWindows8:OpentheLenovoSettingsprogramandclickPower.

•Hibernation
Byusingthismode,youcanturnoffyourcomputercompletelywithoutsavinglesorexitingfromany
programsthatarerunning.Whenthecomputerentershibernation,allopenprograms,folders,andles
aresavedtotheharddisk,andthenthecomputerturnsoff.

Toputthecomputerintohibernationmode,changeyourpowerplansettings.Toaccesspowerplan
settings,dothefollowing:

–ForWindows7:StartthePowerManagerprogramandthenclickthePowerPlantab.Forinstructions

onhowtostartthePowerManagerprogram,see“AccessingLenovoprogramsontheWindows7
operatingsystem”onpage13

28UserGuide

.

.

–ForWindows8:Right-clickthebatterystatusiconfromtheWindowsnoticationareaandclickPower

Options.ThenclickChangeplansettingsthatisnexttoyourpowerplan.

•Wirelessoff
Whenyouarenotusingthewirelessfeatures,suchasBluetoothorwirelessLAN,turnthemoff.Thiswill
helpconservepower.Toturnoffthewirelessfeatures,pressFn+F5orusethewirelessradioswitch.

Enablingthewakeupfunction

Ifyouputyourcomputerintohibernationmode,andthewakeupfunctionisdisabled(thisisthedefault
setting),thecomputerdoesnotconsumeanypower.Ifthewakeupfunctionisenabled,itconsumesa
smallamountofpower.

Toenablethefunction,dothefollowing:

1.GotoControlPanelandclickSystemandSecurity➙AdministrativeT ools.

2.Double-clickTaskScheduler.Ifyouarepromptedforanadministratorpasswordorconrmation,type
thepasswordorprovideconrmation.

3.Fromtheleftpane,selectthetaskfolderforwhichyouwanttoenablethewakeupfunction.The
scheduledtasksaredisplayed.

4.Clickascheduledtask,andthenclicktheConditionstab.

5.UnderPower,selectthecheckboxforWakethecomputertorunthistask.

EnablingthebatteryalarmontheWindows7operatingsystem

FortheWindows7operatingsystem,youcanprogramyourcomputersothatwhenthebatterypowerfalls
belowacertainlevel,threeeventsoccur:

•Thealarmgoesoff.

•Awarningmessageisdisplayed.

•TheLCDisturnedoff.

Toenablethebatteryalarm,dothefollowing:

1.StartthePowerManagerprogram.

2.ClicktheGlobalPowerSettingstab.

3.ForLowbatteryalarmorCriticallylowbatteryalarm,setthepercentageofthepowerlevelandset
theaction.

Note:Ifyourcomputerenterssleeporhibernationmodewhenthebatteryislow,butthealarmmessage
hasnotyetbeendisplayed,themessagewillbedisplayedwhenthecomputerresumes.Toresumenormal
operation,clickOK.

Handlingthebattery

ThissystemsupportsonlybatteriesspeciallydesignedforthisspecicsystemandmanufacturedbyLenovo
oranauthorizedbuilder.Thesystemdoesnotsupportunauthorizedbatteriesorbatteriesdesignedforother
systems.Ifanunauthorizedbatteryorabatterydesignedforanothersystemisinstalled,thesystemwill
notcharge.

Attention:Lenovohasnoresponsibilityfortheperformanceorsafetyofunauthorizedbatteries,and
providesnowarrantiesforfailuresordamagearisingoutoftheiruse.

Note:Ifanunauthorizedbatteryisinstalled,thefollowingmessagewillbedisplayed:“Thebatteryinstalled
isnotsupportedbythissystemandwillnotcharge.PleasereplacethebatterywiththecorrectLenovo
batteryforthissystem.”

Chapter2.Usingyourcomputer29

DANGER

Donotattempttodisassembleormodifythebatterypack.

Attemptingtodosocancauseanexplosion,orliquidleakagefromthebatterypack.

AbatterypackotherthantheonespeciedbyLenovo,oradisassembledormodiedbattery
packisnotcoveredbythewarranty.

DANGER

Iftherechargeablebatterypackisincorrectlyreplaced,thereisdangerofanexplosion.Thebattery
packcontainsasmallamountofharmfulsubstances.Toavoidpossibleinjury:

•ReplaceonlywithabatteryofthetyperecommendedbyLenovo.

•Keepthebatterypackawayfromre.

•Donotexposeittoexcessiveheat.

•Donotexposeittowaterorrain.

•Donotshort-circuitit.

•Storeitinacooldryplace.

•Keepitawayfromchildren.

Thebatterypackisaconsumablesupply.Ifyourbatterybeginstodischargetooquickly,replacethe
batterypackwithanewoneofthetyperecommendedbyLenovo.Formoreinformationonreplacingthe
batterypack,contactyourCustomerSupportCenter.

DANGER

Donotdrop,crush,puncture,orsubjecttostrongforces.Batteryabuseormishandlingcancause
thebatterytooverheat,whichcancausegassesorameto“vent”fromthebatterypackorcoin
cell.Ifyourbatteryisdamaged,orifyounoticeanydischargefromyourbatteryorthebuildup
offoreignmaterialsonthebatteryleads,stopusingthebatteryandobtainareplacementfrom
thebatterymanufacturer.

DANGER

Onlyrechargethebatterypackstrictlyaccordingtoinstructionsincludedintheproduct
documentation.

DANGER

Donotputthebatterypackintrashthatisdisposedofinlandlls.Whendisposingofthebattery,
complywithlocalordinancesorregulationsandyourcompany'ssafetystandards.

30UserGuide

DANGER

Thereisadangerofanexplosionifthebackupbatteryisincorrectlyplaced.Thelithiumbattery
containslithiumandcanexplodeifitisnotproperlyhandled,ordisposedof.Replaceonlywitha
batteryofthesametype.Toavoidpossibleinjuryordeath,donot:(1)throworimmerseintowater,
(2)allowittoheattomorethan100°C(212°F),or(3)attempttorepairordisassembleit.Disposeof
itasrequiredbylocalordinancesorregulationsandyourcompany'ssafetystandards.

Connectingtothenetwork

YourcomputerhasoneormorenetworkadaptersforconnectingtotheInternetortoyourcompany'swired
LANorwirelessLANnetwork.

Note:Somemodelscomewithabuilt-inwirelessWANcardenablingyoutoestablishwirelessconnections
overremotepublicorprivatenetworks.

Ethernetconnections

YoucanconnecttoyourlocalnetworkorabroadbandconnectionbyuseoftheEthernetfeaturebuiltinto
yourcomputer.IfyouareusingtheWindows7operatingsystem,theAccessConnectionsprogramalso
enablesyoutomanageyourlocationproles.Formoreinformation,see“AccessingLenovoprograms
ontheWindows7operatingsystem”onpage13

DANGER

.

YourcomputerhasanEthernetconnector.T oavoidtheriskofelectricalshock,donotconnect
thetelephonecabletotheEthernetconnector.

Wirelessconnections

Wirelesscommunicationisthetransferofdatawithouttheuseofcablesbutbymeansofradiowavesonly.

Dependingonthewirelessdeviceusedinyourcomputer,youmightbeabletoconnecttothefollowing
categoriesofwirelessnetworks.

WirelessLAN

Awirelesslocalareanetwork(LAN)coversarelativelysmallgeographicarea,suchasanofcebuildingora
house.Devicesbasedonthe802.11standardscanconnecttothisnetwork.

Yourcomputercomeswithabuilt-inwirelessnetworkcardandacongurationutilitytohelpyoumake
wirelessconnectionsandmonitorthestatusofyourconnection,sothatyoucanstayconnectedtoyour
networkwhileyouareintheofce,inameetingroom,orathome,withnoneedforawiredconnection.

TipsforusingthewirelessLANfeature

Toachievethebestconnection,usethefollowingguidelines:

•PlaceyourcomputersothatthereareasfewobstaclesaspossiblebetweenthewirelessLANaccess
pointandthecomputer.

•Openyourcomputerdisplaytoanangleofslightlymorethan90degrees.

•Ifyouusethewirelessfeature(the802.11standard)ofyourcomputersimultaneouslywithaBluetooth
option,thedatatransmissionspeedcanbedelayedandtheperformanceofthewirelessfeaturecanbe
degraded.

Chapter2.Usingyourcomputer31

WirelessWAN

WirelessWideAreaNetwork(wirelessWAN),usingcellularnetworksfordatatransmission,enablesyou
toestablishwirelessconnectionsoverremotepublicorprivatenetworks.Theseconnectionscanbe
maintainedoveralargegeographicalarea,suchasacityoranentirecountry,byuseofmultipleantenna
sitesorsatellitesystemsmaintainedbywirelessserviceproviders.

SomeThinkPadnotebookcomputerscomewithabuilt-inwirelessWANcardintegratingsomewireless
WANtechnologies,suchas1xEV-DO,HSPA,3G,GPRSorL TE.Byusingthebuilt-inwirelessWANcardand
thecongurationutilitythatcomeswithyourcomputer,youcanestablishwirelessWANconnectionsand
monitorthestatusofyourconnection.

Note:WirelessWANserviceisprovidedbyauthorizedserviceprovidersinsomecountries.

TipsforusingthewirelessWANfeature

Toachievethebestconnection,usethefollowingguidelines:

•Keepyourcomputerawayfromyourbody.

•Placeyourcomputeronaatsurfaceandopenyourcomputerdisplaytoanangelofslightlymore
than90degrees.

•Placeyourcomputerawayfromconcreteorbrickwallsthatmightdampencellularsignals.

•Bestreceptionwillbeavailablenearwindowsandotherlocationswherecellularphonereceptionisthe
strongest.

WiMAX

SomeThinkPadnotebookcomputerscomewithabuilt-inwirelessLANcardintegratingWiMAXtechnology.

Thislong-rangewirelessdatatransmissiontechnologybasedonthe802.16standardisexpectedtoprovide
theusera“lastmile”broadbandconnectivitysimilartothatprovidedbycableorADSL,butwithouttheneed
tophysicallyconnectacabletothepersonalcomputer.

Bluetooth

Bluetoothisoneofanumberoftechnologiesusedtocreateawirelesspersonalareanetwork.Bluetooth
canconnectdevicesashortdistancefromoneanother,andiscommonlyusedforconnectingperipheral
devicestoacomputer,transferringdatabetweenhand-helddevicesandapersonalcomputer,orremotely
controllingandcommunicatingwithdevicessuchasmobilephones.

Establishingawirelessconnection

Toestablishawirelessconnection,dothefollowing:

1.PressFn+F5toturnonthewirelessfeature.

2.ClickthewirelessnetworkconnectionstatusiconintheWindowsnoticationarea.Alistofavailable
wirelessnetworksisdisplayed.

3.Double-clickanetworktoconnecttoit.Providerequiredinformationifneeded.

Ifyouneedtoconnecttodifferentwirelessnetworksindifferentlocations,usethefollowingsoftwareto
managemultiplenetworkprolessothatthecomputerconnectstoanavailablenetworkautomaticallywhen
thelocationchanges:

•ForWindows7:UsetheAccessConnectionsprogram.ForinstructionsonhowtostarttheAccess
Connectionsprogram,see“AccessingLenovoprogramsontheWindows7operatingsystem”onpage13

•ForWindows8:OpentheLenovoSettingsprogramandclickLocationAwareness.

.

Attention:

32UserGuide

•Ifyouwanttousethewirelessfeaturesonanairplane,checkthewirelessserviceswiththeairlinebefore
boardingtheairplane.

•Iftherearerestrictionsontheuseofcomputerwirelessfeaturesonanairplane,youneedtodisableyour
computerwirelessfeaturesbeforeboarding.Todisablethewirelessfeatures,see“DisablingtheUltraNav
pointingdeviceandusinganexternalmouse”onpage26.

UsingBluetooth

SomemodelsareequippedwithaBluetoothcardthatiscompliantwithBluetoothSpecication4.0.

ToenabletheBluetoothfeatureontheWindows7operatingsystem,pressFn+F5toopenthewireless
radioswitchboard.ThenturnontheBluetoothradio.FortheWindows8operatingsystem,theBluetooth
featureisonbydefault.

SendingdatatoaBluetooth-enableddevice

TosenddatatoaBluetooth-enableddevice,dothefollowing:

1.EnabletheBluetoothfeature.

2.Right-clickthedatathatyouwanttosend.

3.SelectSendT o➙BluetoothDevices.

4.SelectaBluetoothdeviceandthenfollowtheinstructionsonthescreen.

Note:Ifyouusethewirelessfeature(the802.11standard)ofyourcomputersimultaneouslywithaBluetooth
option,thedatatransmissionspeedcanbedelayedandtheperformanceofthewirelessfeaturecanbe
degraded.

FormoreinformationaboutusingtheBluetoothfeature,refertotheWindowshelpinformationsystemand
theBluetoothhelpinformationsystem.

Checkingthewirelessnetworkconnectionstatus

Youcancheckyourcomputerwirelessnetworkconnectionstatusandwirelesssignalstrengththroughthe
wirelessnetworkconnectionstatusiconintheWindowsnoticationarea.Themorebarsencompassed,the
betterthesignal.

FortheWindows7operatingsystem,youalsocanchecktheAccessConnectionsgauge,theAccess
Connectionsstatusicon,ortheAccessConnectionswirelessnetworkconnectionstatusiconinthe
Windowsnoticationarea.

AccessConnectionsgauge

OntheWindows7operatingsystem,theAccessConnectionsgaugeintheWindowsnoticationarea
displaysthestatusandsignalstrengthofyourwirelessconnection.

Youcanndmoredetailedinformationaboutthestatusandsignalstrengthofyourwirelessconnection
byopeningtheAccessConnectionsprogramorbyright-clickingtheAccessConnectionsgaugeinthe
WindowsnoticationareaandselectingViewStatusofWirelessConnection.

•AccessConnectionsgaugestates:wirelessLAN

–Powertothewirelessradioisoffornosignal.

–

improvethesignalstrength,moveyourcomputerclosertothewirelessaccesspoint.

Powertothewirelessradioison.Thesignalstrengthofthewirelessconnectionispoor.To

–Powertothewirelessradioison.Thesignalstrengthofthewirelessconnection

ismarginal.

Chapter2.Usingyourcomputer33

–Powertothewirelessradioison.Thesignalstrengthofthewirelessconnectionis

excellent.

•AccessConnectionsgaugestates:wirelessWAN

–Nosignal

–Signallevel1

–Signallevel2

–

Signallevel3

AccessConnectionsstatusicon

TheAccessConnectionsstatusicondisplaysgeneralconnectionstatus.

•AccessConnectionsstatusiconstates

–Nolocationproleisactiveornoneexists.

–Currentlocationproleisdisconnected.

Currentlocationproleisconnected.

–

AccessConnectionswirelessstatusicon

TheAccessConnectionswirelessstatusicondisplaysthestatusandsignalstrengthofyourwireless
connection.

Youcanndmoredetailedinformationaboutthestatusandsignalstrengthofyourwirelessconnection
eitherbyopeningtheAccessConnectionsprogramorbydouble-clickingtheAccessConnectionswireless
statusiconintheWindowsnoticationarea.

•Wirelessstatusiconstates:wirelessLAN

–Powertothewirelessradioisoff.

Powertothewirelessradioison.Noassociation.

–

–Powertothewirelessradioison.Nosignal.

–

Powertothewirelessradioison.Thesignalstrengthofthewirelessconnectionisexcellent.

Powertothewirelessradioison.Thesignalstrengthofthewirelessconnectionismarginal.

–

–Powertothewirelessradioison.Thesignalstrengthofthewirelessconnectionispoor.Toimprove

thesignalstrength,moveyourcomputerclosertothewirelessaccesspoint.

•Wirelessstatusiconstates:wirelessWAN

–Powertothewirelessradioisoff.
–Noassociation
–Nosignal

–

Signallevel1

–Signallevel2

–Signallevel3

Note:Ifyouhavetroubleinmakingaconnection,trymovingyourcomputerclosertoyourwirelessaccess
point.

34UserGuide

Enablingordisablingthewirelessfeatures

Toenableordisablethewirelessfeatures,dooneofthefollowing:

•ForWindows7:PressFn+F5toopenthewirelessradioswitchboard.Turnonorturnoffthewireless
featureasdesired.

•ForWindows8:PressFn+F5toenableordisabletheAirplanemode.WhentheAirplanemodeisenabled,
allofyourwirelessdevicesareturnedoff.

Youalsocanusethewirelessradioswitchtoturnonorturnoffthewirelessradiosofallthewirelessdevices
onyourcomputer.

Presentationsandmultimedia

Youcanconnectyourcomputertoaprojectortogivepresentationsoryoucanconnectyourcomputer
toanexternalmonitortoexpandyourworkspace.

Changingdisplaysettings

Youcanchangethedisplaysettings,suchasthedisplayresolution,fontsize,andsoon.

Tochangethedisplaysettings,dothefollowing:

1.OpenControlPanelandclickAppearanceandPersonalization.

2.ClickDisplayforfurtherconguration.

Connectingaprojectororanexternalmonitor

Thistopicprovidesinformationaboutconnectingaprojectororanexternalmonitor.

Attachinganexternalmonitor

Note:Ifyouattachanexternalmonitor,avideointerfacecablewithaferritecoreinstalledonthecable

isrequired.

Yourcomputercansupportamaximumvideoresolutionofupto2048x1536(withanexternalmonitor
attachedtotheVGAconnector)orupto2560x1600(withanexternalmonitorattachedtotheHDMI
connector),providedthattheexternalmonitoralsosupportsthatresolution.Formoredetails,referto
themanualsprovidedwithyourmonitor.

Youcansetanyresolutionforeitherthecomputerdisplayortheexternalmonitor.Whenyouusebothatthe
sametime,theresolutionofbothisthesame.Ifyousetahigherresolutionforthecomputerdisplay,you
canseeonlypartofthescreenatatime.YoucanseeotherpartsbymovingtheimagewiththeTrackPoint
pointingdeviceoranotherpointingdevice.

Youcanswitchthedisplayoutputbetweenthecomputerdisplayandtheexternalmonitor,orevenoutput
thedisplaytobothofthecomputerdisplayandtheexternalmonitorbychangingthecongurationin
theDisplaySettingswindow.

Connectinganexternalmonitor

Toattachanexternalmonitor,dothefollowing:

1.Connecttheexternalmonitortothemonitorconnector;thenconnectthemonitortoanelectricaloutlet.

2.T urnontheexternalmonitor.

3.ChangethedisplayoutputlocationbypressingFn+F7.Thisenablesyoutoswitchbetweenviewing
outputontheexternalmonitor,thecomputermonitor,andbothmonitors.

Chapter2.Usingyourcomputer35

Note:Ifyourcomputercannotdetecttheexternalmonitor,right-clickonthedesktop,thenselectScreen
resolution.ClicktheDetectbutton.

Settingthemonitortype

Tosetyourmonitortype,dothefollowing:

1.Connecttheexternalmonitortothemonitorconnector,andthenconnectthemonitortoanelectrical
outlet.

2.T urnontheexternalmonitor.

3.Right-clickonthedesktop,andclickScreenresolution.

Note:Ifyourcomputercannotdetecttheexternalmonitor,clicktheDetectbutton.

4.Clicktheiconforthedesiredmonitor(theMonitor-2iconisfortheexternalmonitor).

5.SetResolution.

6.ClickAdvancedSettings.

7.ClicktheMonitortab.Checkthemonitorinformationwindowtomakesurethatthemonitortypeis
correct.Ifitis,clickOKtoclosethewindow;otherwiseproceedwiththefollowingsteps.

8.Ifmorethantwomonitortypesaredisplayed,selectGenericPnPMonitororGenericNon-PnP
Monitor.

9.ClickProperties.Ifyouarepromptedforanadministratorpasswordorconrmation,typethepassword
orprovideconrmation.

10.ClicktheDrivertab.

11.ClickUpdateDriver.

12.ClickBrowsemycomputerfordriversoftware,andthenclickLetmepickfromalistofdevice
driversonmycomputer.

13.CleartheShowcompatiblehardwarecheckbox.

14.SelectManufacturerandModelforyourmonitor.Ifyoucannotndyourmonitoronthelist,stopthe
installationofthisdriverandusethedrivershippedwithyourmonitor.

15.Afterupdatingthedriver,clickClose.

16.FortheWindows7operatingsystem,tochangethecolorsettings,right-clickonthedesktop,andclick
Screenresolution.ClickAdvancedSettings,selecttheMonitortab,thensetColors.

17.ClickOK.

Considerationsforattachinganexternalmonitor

•Wheninstallinganoperatingsystem,youmustinstallthedisplaydriverforyourmonitorthatissupplied
withthecomputer,andthemonitorINFlethatissuppliedwiththeexternalmonitor.

•Ifyousetaresolutionhigherthantheresolutionyouareusingonthecomputermonitor,andusean
externalmonitorthatdoesnotsupportthatresolution,takeadvantageofthevirtualscreenfunction,
whichenablesyoutodisplayonlyapartofthehigh-resolutionscreenimageyourcomputerproduces.
YoucanseeotherpartsoftheimagebymovingthescreenwiththeTrackPointpointingdeviceoranother
pointingdevice.

•Iftheexternalmonitoryouareusingisoutdated,theresolutionandtherefreshratemightbelimited.

Usingdualdisplays

ThissectionintroducestheExtenddesktopfunctionthatenablesyoutodisplayoutput(thesameordifferent)
onboththecomputerdisplayandanexternalmonitor.

36UserGuide

UsingtheExtenddesktopfunction

YourcomputersupportsafunctionnamedtheExtenddesktop.WiththeExtenddesktopfunction,you
candisplayoutputonboththecomputerdisplayandanexternalmonitor.Youalsocandisplaydifferent
desktopimagesoneachmonitor.

YoucanusetheExtenddesktopfunctionwithoutchanginganysettings.Ifthefunctiondoesnotwork,refer
to“EnablingtheExtenddesktopfunction”onpage37toenableit.

ConsiderationsforusingtheExtenddesktopfunction

•IfyouwanttoshowDOSfull-screenwhileintheExtenddesktopmode,onlytheprimarydisplayshows
DOS;theotherdisplayisblackedout.

•IfyourcomputerhastheIntel

®

graphicscard,youcandesignatetheotherdisplayastheprimarydisplay

bydoingthefollowing:

1.Right-clickonthedesktopandselectScreenResolution.

2.ClickthedesireddisplayimageandselecttheMakethismymaindisplaycheckbox.

3.ClickOK.

•IfyourcomputerhastheAMD

®

graphicscard,youcandesignatetheotherdisplayastheprimarydisplay

bydoingthefollowing:

1.Right-clickonthedesktop,thenselectScreenresolution.

2.SelectExtendthesedisplaysinMultipleDisplays.

3.Changethesettingtodesignatetheprimarydisplay.

•WhenaprogramusingDirectDraworDirect3Displayedinfull-screenmode,itisshownonlyonthe
primarydisplay.

•YoucannotusethedisplayswitchingfunctionwhenyouareintheExtenddesktopmode.

EnablingtheExtenddesktopfunction

ToenabletheExtenddesktopfunction,dothefollowing:

1.Connecttheexternalmonitortothemonitorconnector;thenconnectthemonitortoanelectricaloutlet.

2.T urnontheexternalmonitor.

3.PressFn+F7,thenselectExtend.

Tochangetheresolutionforeachmonitor,dothefollowing:

1.Right-clickonthedesktop,andclickScreenresolution.

2.ClicktheMonitor-1icon(fortheprimarydisplay,thecomputerdisplay).

3.Settheresolutionfortheprimarydisplay.

4.ClicktheMonitor-2icon(forthesecondarydisplay,theexternaldisplay).

5.Settheresolutionforthesecondarydisplay.

6.Placetheiconsforthemonitorssothattheytouch.

Note:Youcansetthemonitorsinanyrelativeposition,buttheiconsmusttoucheachother.

7.ClickOKtoapplythechanges.

Note:Tochangethecolorsettings,right-clickonthedesktop,andclickScreenresolution.ClickAdvanced
Settings,selecttheMonitortab,thensetColors.

Chapter2.Usingyourcomputer37

Usingaudiofeatures

Yourcomputerisequippedwiththefollowing:

•Comboaudiojack,1/8inch(3.5mm)indiameter

•Built-instereospeakers

•Built-indigitalmicrophone

Yourcomputeralsohasanaudiochipthatenablesyoutoenjoyvariousmultimediaaudiofeatures:

•CompliantwithIntelHighDenitionAudio

•RecordingandplaybackofPCMandWAVlesin16-bitor24-bitformat

•PlaybackofaWAVleatasamplerateof44.1KHzto192KHz

•PlaybackofMIDIlesthroughaWavetablesynthesizerunderMicrosoftWindowsoperatingsystems

•PlaybackofMP3lesthroughtheWindowsMediaPlayerorasoftwareMP3player

•Recordingfromvarioussoundsources

Note:Thecomboaudiojackdoesnotsupportaconventionalmicrophone.

Thefollowingtableshowswhichfunctionsoftheaudiodevicesattachedtothejacksonyourcomputerare
supported.

Table3.Audiofeaturelist

JackHeadsetwitha3.5mm

4-poleplug

Comboaudiojack

Headphoneand
microphonefunctions
supported

ConventionalheadphoneConventionalmicrophone

Headphonefunction
supported

Notsupported

Conguringforsoundrecording

Tocongurethemicrophoneforoptimizedsoundrecording,usetheRealtekHDAudioManagerprogram.To
starttheprogram,gotoControlPanelandclickHardwareandSound➙RealtekHDAudioManager.

Usingtheintegratedcamera

Ifyourcomputerhasanintegratedcamera,youcanusethecameratopreviewyourvideoimageand
takeasnapshotofyourcurrentimage.

Tostartthecamera,dothefollowing:

•ForWindows7:PressFn+F6toopentheCommunicationssettingswindow.

•ForWindows8:PressFn+F6tostarttheLenovoSettingsprogram.ThenclickCamera.

Whenthecameraisstarted,thegreencamera-in-useindicatorturnson.

Youalsocanusetheintegratedcamerawithotherprogramsthatprovidefeaturessuchasphotographing,
videocapturing,andvideoconferencing.Tousetheintegratedcamerawithotherprograms,openoneofthe
programsandstartthephotographing,videocapturing,orvideoconferencingfunction.Then,thecamera
willstartautomaticallyandthegreencamera-in-useindicatorwillturnon.Formoreinformationaboutusing
thecamerawithaprogram,refertothehelpinformationsystemoftheprogram.

38UserGuide

Conguringcamerasettings

Youcancongurethecamerasettingstomeetyourneeds,suchasadjustingthequalityofthevideooutput.

Tocongurethecamerasettings,dothefollowing:

•ForWindows7:PressFn+F6.TheCommunicationssettingswindowopens.ClicktheManageSettings
buttonandcongurethecamerasettingsasdesired.

•ForWindows8,dooneofthefollowing:

–Congurethecamerasettingsdirectlyfromtheprogramthatisusingthecamera.Fordetails,seethe

helpinformationsystemoftheprogram.

–ClickLenovoSettingsfromtheStartscreen.ThenclickCamera.Followtheinstructionsonthe

screentocongurethecamerasettingsasdesired.

Usingaashmediacard

Yourcomputerhasonemediacardreaderslot.

Themediacardreaderslotsupportsthefollowingfourtypesofcards:

•SecureDigital(SD)card

•SecureDigitalHigh-Capacity(SDHC)card

•SecureDigitaleXtended-Capacity(SDXC)card

•MultiMediaCard(MMC)

Note:Whiletransferringdatatoorfromamediacard,suchasanSDcard,donotputyourcomputerinto
sleeporhibernationmodebeforethedatatransferiscomplete;otherwise,yourdatacouldbecomedamaged.

Formoreinformationaboutashmediacards,refertoanyofthefollowingtopics:

•“Insertingaashmediacard”onpage39

•“Removingaashmediacard”onpage40

Insertingaashmediacard

Attention:Beforeyoustartinstallinganyofthefollowingcards,touchametaltableoragroundedmetal

object.Thisactionreducesanystaticelectricityfromyourbody.Thestaticelectricitycoulddamagethecard.

•SDcard

•SDHCcard

•SDXCcard

•MultiMediaCard

Toinsertaashmediacardintothe4-in-1mediacardreaderslot,dothefollowing:

1.Makesurethatthecardiscorrectlyoriented.

2.Insertthecardrmlyintothe4-in-1mediacardreaderslot.Thecardmightstopbeforeitiscompletely
installedintotheslot.

Iftheashmediacardisnotplugandplay,dothefollowing:

1.OpenControlPanel.

2.ClickHardwareandSound.

Chapter2.Usingyourcomputer39

3.ClickDeviceManager.Ifyouarepromptedforanadministratorpasswordorconrmation,typethe
passwordorprovideconrmation.

4.FromtheActionmenu,selectAddlegacyhardware.TheAddHardwareWizardstarts.

5.Followtheinstructionsonthescreen.

Removingaashmediacard

Toremoveaashmediacard,dothefollowing:

1.ClickthetriangulariconintheWindowsnoticationareatoshowhiddenicons.Then,right-clickthe
SafelyRemoveHardwareandEjectMediaicon.

2.SelectthecorrespondingitemtoejectthecardfromtheWindowsoperatingsystem.

3.Pressthecardtoejectitfromyourcomputer.

4.Removethecardfromyourcomputerandstoreitsafelyforfutureuse.

Note:IfyoudonotremovethecardfromyourcomputerafteryouejectthecardfromtheWindows
operatingsystem,thecardcannolongerbeaccessed.Toaccessthecard,youmustremoveitonce,
theninsertitagain.

40UserGuide

Chapter3.Y ouandyourcomputer

Thischapterprovidesinformationaboutaccessibility,comfort,andtravelingwithyourcomputer.

Accessibilityandcomfort

Goodergonomicpracticeisimportanttogetthemostfromyourpersonalcomputerandtoavoiddiscomfort.
Arrangeyourworkplaceandtheequipmentyouusetosuityourindividualneedsandthekindofwork
thatyouperform.Inaddition,usehealthyworkhabitstomaximizeyourperformanceandcomfortwhile
usingyourcomputer.

Thefollowingtopicsprovideinformationaboutarrangingyourworkarea,settingupyourcomputer
equipment,andestablishinghealthyworkhabits.

Lenovoiscommittedtoprovidingthelatestinformationandtechnologytoourcustomerswithdisabilities.
Refertoouraccessibilityinformationwhichoutlinesoureffortsinthisarea.

Ergonomicinformation

Workinginthevirtualofcemightmeanadaptingtofrequentchangesinyourenvironment.Forexample,
adaptingtothesurroundinglightsources,properseating,andtheplacementofyourcomputerhardware
canhelpyouimproveyourperformanceandachievegreatercomfort.

Thisexampleshowssomeoneinaconventionalsetting.Evenwhennotinsuchasetting,youcanfollow
manyofthesetips.Developgoodhabits,andtheywillserveyouwell.

Generalposture:Makeminormodicationsinyourworkingposturetodetertheonsetofdiscomfortcaused
bylongperiodsofworkinginthesameposition.Frequent,shortbreaksfromyourworkalsohelptoprevent
minordiscomfortassociatedwithyourworkingposture.

Display:Positionthedisplaytomaintainacomfortableviewingdistanceof510-760mm(20-30inches).
Avoidglareorreectionsonthedisplayfromoverheadlightingoroutsidesourcesoflight.Keepthedisplay
screencleanandsetthebrightnesstolevelsthatenableyoutoseethescreenclearly.PressFn+F8
orFn+F9toadjustdisplaybrightness.

©CopyrightLenovo2012

41

Headposition:Keepyourheadandneckinacomfortableandneutral(vertical,orupright)position.

Chair:Useachairthatgivesyougoodbacksupportandseatheightadjustment.Usechairadjustmentsto

bestsuityourdesiredposture.

Armandhandposition:Ifavailable,usechairarmrestsoranareaonyourworkingsurfacetoprovide
weightsupportforyourarms.Keepyourforearms,wrists,andhandsinarelaxedandneutral(horizontal)
position.Typewithasofttouchwithoutpoundingthekeys.

Legposition:Keepyourthighsparalleltotheoorandyourfeetatontheoororonafootrest.

Whatifyouaretraveling?

Itmightnotbepossibletoobservethebestergonomicpracticeswhenyouareusingyourcomputerwhile
onthemoveorinacasualsetting.Regardlessofthesetting,trytoobserveasmanyofthesetipsas
possible.Sittingproperlyandusingadequatelighting,forexample,willhelpyoumaintaindesirablelevels
ofcomfortandperformance.

Questionsaboutvision?

ThevisualdisplayscreensofThinkPadnotebookcomputersaredesignedtomeetthehigheststandards
andtoprovideyouwithclear,crispimagesandlarge,brightdisplaysthatareeasytosee,yeteasyonthe
eyes.Ofcourse,anyconcentratedandsustainedvisualactivitycanbetiring.Ifyouhavequestionsoneye
fatigueorvisualdiscomfort,consultavisioncarespecialistforadvice.

Comfort

Observethefollowingguidelinestoachievegreatercomfortandimproveperformance.

Activesittingandrestbreaks:Thelongeryousitandworkwithyourcomputer,themoreimportantitisto
observeyourworkingposture.Follow“Ergonomicinformation”onpage41
avoiddiscomfortassociatedwithyourworkingpostures.Makingminorvoluntaryposturalchangesand
takingshortfrequentworkbreaksarethekeyingredientsforhealthycomputing.Y ourcomputerislightand
mobile;youcaneasilyrepositionyourworkingsurfacetoaccommodatemanyposturemodications.

Workareasetupoptions:Familiarizeyourselfwithallofyourofcefurnituresothatyouknowhowto
adjustyourworksurface,seat,andotherworktoolstoaccommodateyourpreferencesforcomfort.
Ifyourworkareaisnotinanofcesetting,besuretotakespecialnoteofemployingactivesitting
andtakingworkbreaks.ManyThinkPadproductsolutionsareavailabletohelpyoumodifyandexpand
yourcomputertobestsuityourneeds.AccessthefollowingWebsitetoviewsomeoftheseoptions:
http://www.lenovo.com/accessories/services/index.html.Exploreyouroptionsfordockingsolutionsand
externalproductsthatprovidetheadjustabilityandfeaturesthatyouwant.

andpractice“activesitting”to

Accessibilityinformation

Lenovoiscommittedtoprovidingpeoplewithdisabilitiesgreateraccesstoinformationandtechnology.
Asaresult,thefollowinginformationprovideswaystohelpusersthathavehearing,vision,andmobility
limitationsgetthemostoutoftheircomputerexperience.

Assistivetechnologiesenableuserstoaccessinformationinthemostappropriateway.Someofthese
technologiesarealreadyprovidedinyouroperatingsystem.Otherscanbepurchasedthroughvendors,or
accessedthroughtheWorldWideWebhttp://www.lenovo.com/healthycomputing.

42UserGuide

Assistivetechnologies

SomeaccessibilitytechnologiesareavailablethroughtheAccessibilityOptionsprogram.Depending
onyouroperatingsystem,thenumberofaccessibilityoptionsavailablevaries.Ingeneral,accessibility
optionsenhancethewayuserswithhearing,vision,ormobilitylimitationsnavigateandusetheircomputer.
Forexample,someusersmightnothavethenemotorskillsrequiredtouseamouseorselectkey
combinations.Otherusersmightrequirelargerfontsorhigh-contrastdisplaymodes.Insomecases,
magniersandbuilt-inspeechsynthesizersareavailable.Fordetailedinformationabouteachofthese
features,consulttheMicrosofthelpinformationsystem.

TousetheAccessibilityOptionsprogram,openControlPanelandclickEaseofAccess➙Easeof

AccessCenter.

Screen-readertechnologies

Screen-readertechnologiesareprimarilyfocusedonsoftwareprograminterfaces,helpinformationsystems,
andavarietyofonlinedocuments.However,inthecasewhereascreenreadercannotreaddocuments,
thedocumentmustrstgothroughaconversionprocess.OnesolutionconvertsAdobePDFlesintoa
formatthatisreadbythescreen-readerprograms.ThissolutionisaWeb-basedserviceprovidedbyAdobe
SystemsIncorporated.Throughhttp://access.adobe.com,AdobePDFdocumentscanbeconvertedto
HTMLorplaintextinmanylanguages.OneconversionoptionconvertsPDFdocumentsontheInternet.A
secondoptionenablesuserstosubmittheURLofanAdobePDFlethroughe-mailtoconvertittoHTMLor
ASCIItext.AdobePDFlesonalocalharddiskdrive,localCD-ROM,orLANalsocanbeconvertedby
attachingtheAdobePDFletoane-mailmessage.

Travelingwithyourcomputer

Thistopicprovidesinformationtohelpyouworkwithyourcomputerwhenyouaretraveling.

Traveltips

Usethefollowingtraveltipstotravelmorecondentlyandefcientlywithyourcomputer.

•Althoughitissafetoallowyourcomputertogothroughthex-raymachinesatairportsecuritystations,it
isimportanttokeepyoureyesonthecomputeratalltimestopreventtheft.

•Considerbringinganelectricaladapterforuseinanairplaneorautomobile.

•Ifyoucarryanacpoweradapter,detachtheaccordfromittoavoiddamagingthecord.

Traveltipsonairplanes

Ifyoucarryyourcomputerintoanairplane,takenoteofthefollowingtips:

•Ifyouintendtouseyourcomputerorwirelessservices(suchasInternetandBluetooth),checkwiththe
airlineforrestrictionsandavailabilityofservicesbeforeboardingtheairplane.Iftherearerestrictions
ontheuseofcomputerswithwirelessfeaturesontheairplane,youmustabidebythoserestrictions.If
necessary,disablewirelessfeaturesbeforeboarding.

•Becarefulabouttheseatinfrontofyouonairplanes.Angleyourcomputerdisplaysothatitdoesnotget
caughtwhenthepersoninfrontofyouleansback.

•Whentakingoff,remembertoturnoffyourcomputerorputitintohibernationmode.

Travelaccessories

Thefollowingisachecklistofitemstoconsiderpackingwhenyouaregoingtotravel:

•ThinkPadacpoweradapter

•ThinkPadAC/DCComboAdapter

Chapter3.Youandyourcomputer43

•Externalmouse,ifyouareaccustomedtousingone

•Ethernetcable

•Extrabattery,charged

•Aqualitycarryingcasethatprovidesadequatecushionandprotection

•Externalstoragedevice

Ifyouaretravelingtoanothercountry,youmightwanttoconsideranacpoweradapterforthecountryto
whichyouaretraveling.

Topurchasetravelaccessories,gotohttp://www.lenovo.com/accessories.

44UserGuide

Chapter4.Security

Thischapterprovidesinformationabouthowtoprotectyourcomputerfromtheftandunauthorizeduse.

•“Attachingamechanicallock”onpage45

•“Usingpasswords”onpage45

•“Harddisksecurity”onpage50

•“Noticeondeletingdatafromyourharddiskdriveorsolid-statedrive”onpage51

•“Usingrewalls”onpage52

•“Protectingdataagainstviruses”onpage52

Attachingamechanicallock

Youcanattachamechanicallocktoyourcomputertohelppreventitfrombeingremovedwithoutyour
permission.

Attachamechanicallocktothekeyholeofthecomputer;thensecurethechainonthelocktoastationary
object.Refertotheinstructionsshippedwiththemechanicallock.

Note:Y ouareresponsibleforevaluating,selecting,andimplementingthelockingdevicesandsecurity
features.Lenovomakesnocomments,judgments,orwarrantiesaboutthefunction,quality,orperformance
oflockingdevicesandsecurityfeatures.

Usingpasswords

Byusingpasswords,youcanhelppreventyourcomputerfrombeingusedbyothers.Onceyouseta
password,apromptisdisplayedonthescreeneachtimeyouturnonthecomputer.Enteryourpasswordat
theprompt.Youcannotusethecomputerunlessyouenterthevalidpassword.

Passwordsandsleepmode

Ifyouhavesetpasswordsandyouputyourcomputerintosleepmode,theprocedureforresuming
operationisasfollows:

•Youarenotpromptedtotypethepasswordwhenresumingoperation.

•Ifanyharddiskdriveorsolid-statedrivehasapassword,itisunlockedautomaticallywhenyouresume
operation.

Note:IfaWindowspasswordhasbeenset,youwillbepromptedtoenterit.

Typingpasswords

Ifthisiconisdisplayed,typeapower-onpasswordorasupervisorpassword.

Ifthisiconisdisplayed,typeauserharddiskpassword.Ifyouwanttotypeamasterharddisk

password,dothefollowing:

1.PressF1.Theiconchangestothis:

2.T ypethemasterharddiskpassword.

©CopyrightLenovo2012

45

Note:Toreturntotheicon,pressF1again.

Note:PresstheBackspacekeyifyouenterawrongpasswordwhileyouaretypingyourpassword.

Power-onpassword

Youcansetapower-onpasswordtohelpprotectyourcomputeragainstaccessbyunauthorizedusers.

Ifyousetapower-onpassword,thepasswordpromptisdisplayedonthescreenwheneveryouturnonthe
computer.Youmustenterthecorrectpasswordtostartusingthecomputer.

Settingapower-onpassword

1.Printtheseinstructions.

2.Saveallopenles,andexitallprograms.

3.T urnyourcomputeroffandthenturnitonagain.

4.Whenthelogoscreenisdisplayed,pressF1.TheThinkPadSetupprogrammainmenuopens.

5.SelectSecurity,usingthecursordirectionalkeystomovedownthemenu.

6.SelectPassword.

7.SelectPower-onPassword.

8.IntheEnterNewPasswordeld,typeadesiredpassword,andpressEnter.

9.IntheConrmNewPasswordeld,retypethepasswordandpressEnter.

Attention:Youmightwanttonotedownyourpower-onpasswordinasafeplace.Otherwise,ifyou
forgetit,youhavetotakeyourcomputertoaLenovoreselleroramarketingrepresentativetohave
thepasswordcanceled.

10.IntheSetupNoticewindowthatisdisplayed,pressEntertocontinue.

11.PressF10.TheSetupConrmationwindowopens.SelectY estosavecongurationchangesandexit.

Changingorremovingthepower-onpassword
Tochangethepower-onpassword,followsteps1through7.Enteryourcurrentpassword.WhentheEnter

NewPasswordeldisdisplayed,typeanewpasswordintheeldandthenretypeittoverify.Toremove

thepassword,followsteps1through7.Typeyourcurrentpassword.WhentheEnterNewPasswordeld
isdisplayed,leaveitblankandpressEntertwice.

Harddiskpasswords

Twotypesofharddiskpasswordshelpprotecttheinformationstoredontheharddiskdrive:

•Userharddiskpassword

•Masterharddiskpassword,whichrequiresauserharddiskpassword

Ifauserharddiskpasswordhasbeenset,butnomasterharddiskpasswordhasbeen,theusermustenter
theuserharddiskpasswordinordertogainaccesstolesandprogramsontheharddiskdrive.

Themasterpasswordcanbesetandusedonlybyasystemadministrator.Likeamasterkey,itenablesthe
administratortogetaccesstoanyharddiskdriveinasystem.Theadministratorsetsthemasterpassword;
nooneelseknowsit.Thentheadministratorsetsauserpasswordforeachcomputerinthenetwork,and
tellseachuserthepasswordforhisorhercomputer.Theusercanthenchangetheuserpasswordas
desired,buttheadministratorstillcangetaccessbyusingthemasterpassword.

46UserGuide

Note:Whenamasterharddiskpasswordisset,onlytheadministratorcanremovetheuserharddisk

password.

Settingaharddiskpassword

1.Printtheseinstructions.

2.Saveallopenles,andexitallprograms.

3.T urnyourcomputeroffandthenonagain.

4.Whenthelogoscreenisdisplayed,pressF1.TheThinkPadSetupprogrammainmenuopens.

5.SelectSecurity,usingthecursordirectionalkeystomovedownthemenu.

6.SelectPassword.

7.SelectHardDisk1Password.

8.Apasswordwindowopens.YouarepromptedtoselectUserorUser+Master.SelectUserifyouwant
tosetonlyoneharddiskpassword.Ifyouareanadministratororsupervisor,youcanselectUser+
Mastertosettwopasswords.(Theusercanchangetheuserpasswordlater.)

•IfyouselectUser+Master,dothefollowing:

a.Whenawindowfortypingthenewuserharddiskpasswordopens,typeyournewpasswordin

theEnterNewPasswordeld.PressEnter.
b.IntheConrmNewPasswordeld,retypethepasswordyoujustenteredtoverifyit.PressEnter.
c.Amessagewindowopensandpromptsyoutosetthemasterharddiskpassword.PressEnterto

continue.
d.Awindowfortypingthenewmasterharddiskpasswordopens.Typeyournewpasswordin

theEnterNewPasswordeld.PressEnter.
e.IntheConrmNewPasswordeld,retypethepasswordyoujustenteredtoverifyit.PressEnter.

•IfyouselectUseronly,dothefollowing:
a.Whenawindowfortypingthenewpasswordopens,typeyournewpasswordintheEnterNew

Passwordeld.PressEnter.

Notes:

–YoucansettheminimumlengthofaharddiskpasswordthroughtheSecuritymenu.
–Ifyousetaharddiskpasswordofoversevencharacters,theharddiskdrivecanbeusedonly

withacomputerthatcanrecognizeaharddiskpasswordofoversevencharacters.Ifyouthen
installtheharddiskdriveinacomputerthatcannotrecognizeaharddiskpasswordthat
containsmorethansevencharacters,youcannotgetaccesstothedrive.

b.IntheConrmNewPasswordeld,retypethepasswordyoujustenteredtoverifyit.PressEnter.

Attention:Youmightwanttonotedownyourpasswordsandkeeptheminasafeplace.Otherwise,if
youforgettheuserpassword,orbothuserandmasterpasswords,Lenovocannotresetyourpasswords
orrecoverdatafromtheharddiskdrive.Y oumusttakeyourcomputertoaLenovoresellerora
marketingrepresentativetohavetheharddiskdrivereplaced.Proofofpurchaseisrequired,andafee
willbechargedforpartsandservice.

9.IntheSetupNoticewindowthatisdisplayed,pressEntertocontinue.

10.PressF10.TheSetupConrmationwindowopens.SelectY estosavecongurationchangesandexit.

Thenexttimeyouturnonyourcomputer,youwillhavetotypetheuserormasterharddiskpasswordin
ordertostartyourcomputerandgetaccesstoyouroperatingsystem.

Chapter4.Security47

Changingorremovingaharddiskpassword

Followsteps1through7in“Settingaharddiskpassword”onpage47,typingyourpasswordtogetaccess
totheThinkPadSetupprogram.

Tochangeorremovetheuserharddiskpassword,dothefollowing:

•Tochangetheharddiskpassword,typethecurrentpasswordintheEnterCurrentPasswordeld.Then
typethenewpasswordintheEnterNewPasswordeld,andretypethepasswordyoujustenteredto
verifyitintheConrmNewPasswordeld.PressEnter,andaSetupNoticewindowisdisplayed.Press
EntertoexitfromtheSetupNoticewindow.Theuserharddiskpasswordwillbechanged.

•Toremovetheharddiskpassword,typethecurrentpasswordintheEnterCurrentPasswordeld.Then
leavetheEnterNewPasswordandConrmNewPasswordeldsblank,andpressEnter.ASetup
Noticewindowisdisplayed.PressEntertoexitfromtheSetupNoticewindow.Theuserharddisk
passwordwillberemoved.

TochangeorremovetheUser+Masterharddiskpasswords,selectUserHDPorMasterHDP.

IfyouchooseUserHDP,dothefollowing:

•Tochangetheuserharddiskpassword,typethecurrentuserharddiskpasswordorthecurrentmaster
harddiskpasswordintheEnterCurrentPasswordeld.Thentypethenewuserharddiskpasswordin
theEnterNewPasswordeld,andretypethepasswordyoujustenteredtoverifyitintheConrmNew
Passwordeld.PressEnter,andaSetupNoticewindowisdisplayed.PressEntertoexitfromtheSetup
Noticewindow.Theuserharddiskpasswordischanged.

•Toremovetheuserharddiskpassword,typethecurrentmasterharddiskpasswordintheEnterCurrent
Passwordeld.ThenleavetheEnterNewPasswordandConrmNewPasswordeldsblank,and
pressEnter.ASetupNoticewindowisdisplayed.PressEntertoexitfromtheSetupNoticewindow.Both
theuserandmasterharddiskpasswordswillberemoved.

IfyouchooseMasterHDP,dothefollowing:

•Tochangethemasterharddiskpassword,typethecurrentmasterharddiskpasswordintheEnter
CurrentPasswordeld.ThentypethenewmasterharddiskpasswordintheEnterNewPassword
eld,andretypethepasswordyoujustenteredtoverifyitintheConrmNewPasswordeld.Press
Enter,andaSetupNoticewindowisdisplayed.PressEntertoexitfromtheSetupNoticewindow.The
masterharddiskpasswordischanged.

•Toremovethemasterharddiskpassword,typethecurrentmasterharddiskpasswordintheEnter
CurrentPasswordeld.ThenleavetheEnterNewPasswordandConrmNewPasswordeldsblank,
andpressEnter.ASetupNoticewindowisdisplayed.PressEntertoexitfromtheSetupNoticewindow.
Boththeuserandmasterharddiskpasswordswillberemoved.

Supervisorpassword

ThesupervisorpasswordprotectsthesysteminformationstoredinThinkPadSetup.Withoutit,noonecan
changethecongurationofthecomputer.Itprovidesthefollowingsecurityfeatures:

•Ifasupervisorpasswordisset,apasswordpromptisdisplayedwhenyoutrytostarttheThinkPadSetup
program.Unauthorizeduserscannotgetaccesstocongurationdata.

•Thesystemadministratorcanusethesupervisorpasswordtogetaccesstoacomputereveniftheuserof
thatcomputerhassetapower-onpassword.Thesupervisorpasswordoverridesthepower-onpassword.

•Ifbothasupervisorpasswordandapower-onpasswordareset,youcandothefollowingonlyifyou
havethesupervisorpassword:

–Deletingthepower-onpassword
–Changingordeletingthesupervisorpassword

48UserGuide

–EnablingordisablingtheWakeonLANandFlashoverLANfeatures
–EnablingordisablingtheInternalNetworkOptionROMfeature
–Changingdateandtime
–EnablingordisablingtheLockUEFIBIOSSettingsfeature
–EnablingordisablingthePasswordatunattendedbootfeature
–Specifyingtheminimumlengthforpower-onpasswordsandharddiskpasswords
–EnablingordisablingtheBootDeviceListF12Optionfeature
–EnablingordisablingtheBootOrderLockfeature
–EnablingordisablingtheFlashBIOSUpdatingbyEnd-Usersfeature
–Enablingordisablingtheinternalnetworkdevice
–Enablingordisablingtheinternalwirelessdevice
–EnablingordisablingtheinternalBluetoothdevice
–EnablingordisablingtheinternalwirelessWANdevice
–EnablingordisablingtheSecuritymode

Notes:

•ThesystemadministratorcansetthesamesupervisorpasswordonmanyThinkPadnotebookcomputers
tomakeadministrationeasier.

•ByenablingtheLockUEFIBIOSSettingsfeatureonthePasswordmenuwhenyousetthesupervisor
password,youmakeitimpossibleforanyonebutyoutomakechanges.

Setting,changing,orremovingasupervisorpassword

Onlyasystemadministratorcanset,change,orremoveasupervisorpassword.

Toset,change,orremoveasupervisorpassword,dothefollowing:

1.Printtheseinstructions.

2.Saveallopenles,andexitallprograms.

3.T urnyourcomputeroffandthenturnitonagain.

4.Whenthelogoscreenisdisplayed,pressF1.TheThinkPadSetupprogrammainmenuopens.

5.SelectSecurity,usingthecursordirectionalkeystomovedownthemenu.

6.SelectPassword.

7.SelectSupervisorPassword.

8.Awindowopens,promptingyoutoenteranewpassword.Dependingonyourneeds,dooneofthe
following:

•Tosetapassword,dothefollowing:

a.IntheEnterNewPasswordeld,typeadesiredpasswordandpressEnter.
b.IntheConrmNewPasswordeld,retypethepasswordandpressEnter.

•Tochangeapassword,dothefollowing:

a.IntheEnterCurrentPasswordeld,typethecurrentsupervisorpasswordandpressEnter.
b.IntheEnterNewPasswordeld,typethenewsupervisorpassword;thenretypethepassword

youjustenteredtoverifyitintheConrmNewPasswordeld.PressEnter.

•Toremoveapassword,dothefollowing:

a.IntheEnterCurrentPasswordeld,typethecurrentsupervisorpasswordandpressEnter.

Chapter4.Security49

b.LeavetheEnterNewPasswordandConrmNewPasswordeldsblank.PressEnter.

Attention:Youmightwanttonotedownyourpasswordandkeepitinasafeplace.Ifyouforgetyour
supervisorpassword,Lenovocannotresetyourpassword.YoumusttakeyourcomputertoaLenovo
reselleroraLenovomarketingrepresentativetohavethesystemboardreplaced.Proofofpurchaseis
required,andafeewillbechargedforpartsandservice.

9.IntheSetupNoticewindowthatisdisplayed,pressEntertocontinue.

10.PressF10.TheSetupConrmationwindowopens.SelectY estosavecongurationchangesandexit.

ThenexttimeyouopentheThinkPadSetupprogram,youwillbepromptedtotypeyourpasswordtoproceed.

Harddisksecurity

Toprotectpasswordsfromunauthorizedsecurityattacks,severalofthelatesttechnologiesandalgorithms
areintegratedintoUEFIBIOSandhardwaredesignofThinkPadnotebookcomputers.

Tomaximizesecurity,dothefollowing:

1.Setapower-onpasswordaswellasaharddiskpasswordforyourinternalsolid-statedriveorharddisk
drive.Refertotheproceduresin“Power-onpassword”onpage46and“Harddiskpasswords”onpage

.Forsecurity,alongerpasswordisrecommended.

46

2.IfaDiskEncryptionharddiskdriveoraDiskEncryptionsolid-statedriveisinstalledinyourcomputer,
besuretoprotectthecontentsofyourcomputermemoryfromunauthorizedaccessesbyuseofdrive
encryptionsoftware.

3.Beforeyoudisposeof,sell,orhandoveryourcomputer,besuretodeletedatastoredonit.Referto
“Noticeondeletingdatafromyourharddiskdriveorsolid-statedrive”onpage51.

Note:TheharddiskdrivebuiltintoyourcomputercanbeprotectedbyUEFIBIOS.

DiskEncryptionharddiskdriveandEncryptionsolid-statedrive

SomemodelscontaintheDiskEncryptionharddiskdriveorEncryptionsolid-statedrive.Thisfeature
helpstoprotectyourcomputeragainstsecurityattacksonmedia,NANDashordevicecontrollersbyuse
ofahardwareencryptionchip.Fortheefcientuseoftheencryptionfeature,besuretosetaharddisk
passwordfortheinternalstoragedevice.

Settingthesecuritychip

Strictsecurityrequirementsareimposedonnetworkclientcomputersthattransfercondentialinformation
electronically.Dependingontheoptionsyouordered,yourcomputermighthaveanembeddedsecuritychip,
acryptographicmicroprocessor.WiththesecuritychipandClientSecuritySolution,youcandothefollowing:

•Protectyourdataandsystem

•Strengthenaccesscontrols

•Securecommunications

Settingthesecuritychip

ThechoicesofferedontheSecurityChipsubmenuundertheSecuritymenuofThinkPadSetupareas
follows:

•SecurityChip:activate,inactivate,ordisablethesecuritychip.

•SecurityReportingOptions:enableordisableeachsecurityreportingoption.

•ClearSecurityChip:cleartheencryptionkey.

50UserGuide

Notes:

1.BesurethatthesupervisorpasswordhasbeensetinThinkPadSetup.Otherwiseanyonecanchange
thesettingsforthesecuritychip.

2.IfyouareusingClientSecuritySolution,handlethesecuritychipbydoingthefollowing:

•Donotclearthesecuritychip.Ifyoudo,thefunctionsassignedtothekeyswillbeerased.

•Donotdisablethesecuritychip.Ifyoudo,ClientSecuritySolutionwillnotwork.

3.Ifthesecuritychipisremovedorreplaced,oranewonehasbeenadded,thecomputerwillnotstart.
Youwillhearfourcyclesoffourbeepseach,oryouseeerrormessage0176or0192.

4.Ifthesecuritychipisinactiveordisabled,theClearSecurityChipoptionwillnotbedisplayed.

5.Whenyouclearthesecuritychip,besuretoturnyourcomputeroffandthenturnitonagainafteryou
setthesecuritychiptoActive.Otherwise,theClearSecurityChipoptionisnotdisplayed.

TosetanitemontheSecurityChipsubmenu,dothefollowing:

1.Printtheseinstructions.

2.Saveallopenles,andexitallprograms.

3.T urnyourcomputeroffandthenturnitonagain.

4.Whenthelogoscreenisdisplayed,pressF1.TheThinkPadSetupprogrammainmenuopens.

5.Usingthecursorkeys,movetoSecurity.TheSecuritymenuopens.

6.Usingthecursorkeys,movetoSecurityChip,andpressEnter.TheSecurityChipsubmenuopens.

7.Usingthecursorkeys,movetoanitemyouwanttoset.Whentheitemishighlighted,pressEnter.

8.Setotheritemsthatyouwanttoset.

9.PressF10tosavechangesandexit.

10.PressEnterintheSetupConrmationwindowtoconrmtheexit.

Tosetthesecuritychip,youhavetostartClientSecuritySolution,andfollowtheinstructionsonthescreen.

Note:ClientSecuritySolutionisnotpreinstalledonyoursystem.Tocongurethesecuritychip,youneed
todownloadthelatestversionofClientSecuritySolutionfromtheLenovoWebsite.TodownloadClient
SecuritySolution,gotohttp://www.lenovo.com/support.Thenfollowtheinstructionsonthescreen.

Noticeondeletingdatafromyourharddiskdriveorsolid-statedrive

Ascomputersspreadintoeverycorneroflife,theyprocessmoreandmoreinformation.Thedataonyour
computer,someofwhichmightbesensitive,isstoredonaharddiskdriveorsolid-statedrive.Beforeyou
disposeof,sell,orhandoveryourcomputer,besuretodeletedatastoredonit.

Handingyourcomputerovertosomeoneelsewithoutdeletingtheloadedsoftware,suchasoperating
systemsandprogramsoftware,mightevenviolatelicenseagreements.Youareadvisedtocheckthe
termsandconditionsofthoselicenseagreements.

Therearemethodsthatseemtodeletethedata:

•Movethedatatotherecyclebin,andthenclickEmptyrecyclebin.

•UsetheDeleteoption.

•Formatyourharddiskdriveorsolid-statedrive,usingthesoftwareforinitializingit.

•Usingtherecoveryprogram,providedbyLenovo,bringtheharddiskdriveorsolid-statedrivebackto
thefactorydefaultsettings.

Chapter4.Security51

Theseoperations,however,onlychangetheleallocationofthedata;theydonotdeletethedataitself.In
otherwords,thedataretrievalprocessingisdisabledunderanoperatingsystemsuchasWindows.The
dataisstillthere,eventhoughitseemstobelost.Thus,itissometimespossibletoreadthedatabyuseof
specialsoftwarefordatarecovery.Thereisariskthatpeopleofbadfaithmightreadandmisusethecritical
dataonharddiskdrivesorsolid-statedrivesforunexpectedpurposes.

Topreventleakageofdata,itbecomesveryimportantthatyoutakeresponsibilityfordeletingallthedata
fromtheharddiskdriveorsolid-statedrivewhenyoudisposeof,sell,orhandoveryourcomputer.Y ou
candestroythedataphysicallybysmashingtheharddiskdriveorsolid-statedrivewithahammer,or
magneticallybymeansofstrongmagneticpower,thusmakingthedataunreadable.Butwerecommend
thatyoumakeuseofthesoftware(payware)orservice(payservice)specicallydevelopedforthepurpose.

Fordisposingofdataontheharddiskdriveorsolid-statedrive,LenovoprovidestheSecureDataDisposal
tool.Todownloadtheprogram,goto:
http://www.lenovo.com/support

Note:Runningeitherprogramwilltakeacoupleofhours.

Ifyouusesoftwaredesignedforusewiththeharddiskdrivetodeletedatastoredonthesolid-statedrive,it
willeraseonlydatathatisaccessiblebynormaloperation.Itmaynoterasethehiddenareaoftheash
chip.Therefore,sometimesitmaystillbepossibletoreadthedatabyuseofspecialequipmentora
specialtool.Topreventleakageofdatafromthesolid-statedrive,itisrecommendedthatyoudelete
alldataontheashchipsbyuseofaprogramprovidedbyLenovo.ThisprogramcalledtheThinkPad
SetupMenuExtensionUtilitymakesitpossibletoeraseallthedataontheashchipsofthesolid-state
drivefromtheThinkPadSetupwithinaminute.T odownloadthisprogram,gototheLenovoWebsite
http://www.lenovo.com/support.

IfEncryptionsolid-statedriveorDiskEncryptionharddiskdriveissupportedandinstalledinyourcomputer,
youcanlogicallydisposeofallthedataonadeviceinaveryshorttimebyerasingthecryptographickey.
Thedataencryptedwiththeoldkeyisnotphysicallyerasedbutremainsonthedisk;however,itcannotbe
decryptedwithouttheoldkey.ThisfeatureisenabledbytheThinkPadSetupMenuExtensionUtilityandis
availableasamenuitemintheThinkPadSetup.

Usingrewalls

Ifyoursystemispreinstalledwitharewallprogram,itprotectsagainstcomputerInternetsecuritythreats,
unauthorizedaccesses,intrusions,andInternetattacks.Italsoprotectsyourprivacy.

Formoreinformationabouthowtousetherewallprogram,refertothehelpinformationsystemthat
comeswiththeprogram.

Protectingdataagainstviruses

Yourcomputerispreinstalledwithanantivirusprogramsoyoucandetectandeliminateviruses.The
antivirusprogramisdesignedtohelpyoudetectandeliminateviruses.

Lenovoprovidesafullversionofantivirussoftwareonyourcomputerwithafree30-daysubscription.After
30days,youmustrenewthelicensetocontinuereceivingtheantivirussoftwareupdates.

Formoreinformationabouthowtouseyourantivirussoftware,refertothehelpinformationsystemof
yourantivirussoftware.

52UserGuide

Chapter5.Recoveryoverview

Thischapterprovidesinformationabouttherecoverysolutions.

•“RecoveryoverviewfortheWindows7operatingsystem”onpage53

•“RecoveryoverviewfortheWindows8operatingsystem”onpage58

RecoveryoverviewfortheWindows7operatingsystem

ThissectionprovidesinformationabouttherecoverysolutionsprovidedbyLenovoontheWindows7
operatingsystem.

Notes:

•Thereareavarietyofmethodstochoosefromwhenconsideringhowtorecoverintheeventofa
software-relatedorhardware-relatedproblem.Somemethodsvarydependingonthetypeofyour
operatingsystem.

•Theproductontherecoverymediamightbeusedonlyforthefollowingpurposes:

–Restoretheproductpreinstalledonyourcomputer
–Reinstalltheproduct
–ModifytheproductusingtheAdditionalFiles

Notes:Topreventpotentialperformancerisksorunexpectedbehaviorthatmightbecausedbythenew
harddiskdrivetechnology,itisrecommendedthatyouuseoneofthefollowingback-upsoftwareprograms:

•ThinkVantageRescueandRecoveryversion4.3orlater

•SymantecNortonGhostversion15orlater

Notes:Tousethisprogram,dothefollowing:

1.ClickStart➙Run.TheRunwindowopens.

2.T ypecmdintheeld.ThenclickOK.

3.T ypeghost-align=1mbandpressEnter.

•AcronisT rueImage2010orlater

•ParagonBackup&Recovery10Suiteorlater,ParagonBackup&Recovery10Homeorlater

Creatingandusingarecoverymedia

Youcanuserecoverymediatorestoretheharddiskdrivetothefactorydefaultsettings.Recoverymedia
areusefulifyoutransferthecomputertoanotherarea,sellthecomputer,recyclethecomputer,orputthe
computerinanoperationalstateafterallothermethodsofrecoveryhavefailed.Asaprecautionarymeasure,
itisimportanttocreaterecoverymediaasearlyaspossible.

Note:Therecoveryoperationsyoucanperformusingrecoverymediavarydependingontheoperating
systemfromwhichtherecoverymediawerecreated.Therecoverymediamightcontainabootmedium
andadatamedium.Y ourMicrosoftWindowslicensepermitsyoutocreateonlyonedatamedium,soitis
importantthatyoustoretherecoverymediainasafeplaceafteryouhavemadethem.

Creatingrecoverymedia

Thissectionprovidesinstructionsonhowtocreaterecoverymedia.

©CopyrightLenovo2012

53

Note:YoucancreaterecoverymediausingdiscsorexternalUSBstoragedevices.

Tocreaterecoverymedia,clickStart➙AllPrograms➙LenovoThinkVantageTools➙FactoryRecovery
Disks.Then,followtheinstructionsonthescreen.

Usingrecoverymedia

Youcanuserecoverymediatorestorethecomputertothefactorydefaultsettingsonly.Youcanuse
recoverymediatoputthecomputerinanoperationalstateafterallothermethodsofrecoveryhavefailed.

Attention:Whenyouuserecoverymediatorestorethecomputertothefactorydefaultsettings,alltheles
currentlyontheharddiskdrivewillbedeletedandreplacedbythefactorydefaultsettings.

Touserecoverymedia,dothefollowing:

1.Dependingonthetypeofyourrecoverymedia,connectthebootmedium(memorykeyorotherUSB
storagedevice)tothecomputer,orinsertthebootdiscintotheexternalopticaldrive.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhentheBootMenuwindow
opens,releasetheF12key.

3.SelectthedesiredstartupdeviceandpressEnter.Therestoreprocessbegins.

4.Followtheinstructionsonthescreentocompletetheoperation.

Notes:

1.Afterrestoringyourcomputertothefactorydefaultsettings,youmighthavetoreinstalldevicedrivers
forsomedevices.See“Reinstallingpreinstalledprogramsanddevicedrivers”onpage57.

2.SomecomputerscomewithMicrosoftOfceorMicrosoftWorkspreinstalled.Ifyouneedtorecover
orreinstallyourMicrosoftOfceorMicrosoftWorksprograms,youmustusetheMicrosoftOfceCD
orMicrosoftWorksCD.ThesediscsareprovidedonlywithcomputerspreinstalledwithMicrosoft
OfceorMicrosoftWorks.

Performingbackupandrecoveryoperations

TheRescueandRecoveryprogramenablesyoutobackupallyourharddiskdrivecontentsincludingthe
operatingsystem,datales,softwareprograms,andpersonalsettings.Y oucandesignatewherethe
RescueandRecoveryprogramstoresthebackup:

•Inaprotectedareaofyourharddiskdrive

•OnanattachedexternalUSBharddiskdrive

•Onanetworkdrive

•Onrecordablediscs(arecordableopticaldriveisrequiredforthisoption)

Afteryouhavebackedupthecontentsontheharddiskdrive,youcanrestorethecompletecontentsofthe
harddiskdrive,restoreonlytheselectedles,orrestoreonlytheWindowsoperatingsystemandprograms.

Performingabackupoperation

ThissectionprovidesinstructionsonhowtoperformabackupoperationusingtheRescueandRecovery
program.

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙LenovoThinkVantageTools➙Enhanced
BackupandRestore.TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoverymainwindow,clicktheLaunchadvancedRescueandRecoveryarrow.

3.ClickBackupyourharddriveandselectbackupoperationoptions.Then,followtheinstructionson
thescreentocompletethebackupoperation.

54UserGuide

Performingarecoveryoperation

ThissectionprovidesinstructionsonhowtoperformarecoveryoperationusingtheRescueandRecovery
program.

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙LenovoThinkVantageTools➙Enhanced
BackupandRestore.TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoveryprogrammainwindow,clicktheLaunchadvancedRescueandRecovery
arrow.

3.ClicktheRestoreyoursystemfromabackupicon.

4.Followtheinstructionsonthescreentocompletetherecoveryoperation.

FormoreinformationaboutperformingarecoveryoperationfromtheRescueandRecoveryworkspace,see
“UsingtheRescueandRecoveryworkspace”onpage55.

UsingtheRescueandRecoveryworkspace

TheRescueandRecoveryworkspaceresidesinaprotected,hiddenareaofyourharddiskdrivethat
operatesindependentlyfromtheWindowsoperatingsystem.Thisenablesyoutoperformrecovery
operationsevenifyoucannotstarttheWindowsoperatingsystem.Y oucanperformthefollowingrecovery
operationsfromtheRescueandRecoveryworkspace:

•Rescuelesfromyourharddiskdriveorfromabackup
TheRescueandRecoveryworkspaceenablesyoutolocatelesonyourharddiskdriveandtransfer

themtoanetworkdriveorotherrecordablemedia,suchasaUSBdeviceoradisc.Thissolutionis
availableevenifyoudidnotbackupyourlesorifchangesweremadetothelessinceyourlastbackup
operation.YoualsocanrescueindividuallesfromaRescueandRecoverybackuplocatedonyourlocal
harddiskdrive,aUSBdevice,oranetworkdrive.

•RestoreyourharddiskdrivefromaRescueandRecoverybackup
IfyouhavebackedupyourharddiskdriveusingtheRescueandRecoveryprogram,youcanrestorethe

harddiskdrivefromaRescueandRecoverybackup,evenifyoucannotstarttheWindowsoperating
system.

•Restoreyourharddiskdrivetothefactorydefaultsettings
TheRescueandRecoveryworkspaceenablesyoutorestorethecompletecontentsofyourharddiskdrive

tothefactorydefaultsettings.Ifyouhavemultiplepartitionsonyourharddiskdrive,youhavetheoption
torestorethefactorydefaultsettingstotheC:partitionandleavetheotherpartitionsintact.Becausethe
RescueandRecoveryworkspaceoperatesindependentlyfromtheWindowsoperatingsystem,youcan
restorethefactorydefaultsettingsevenifyoucannotstarttheWindowsoperatingsystem.

Attention:IfyourestoretheharddiskdrivefromaRescueandRecoverybackuporrestoretheharddisk
drivetothefactorydefaultsettings,alllesontheprimaryharddiskdrivepartition(usuallydriveC:)willbe
deletedintherecoveryprocess.Ifpossible,makecopiesofimportantles.Ifyouareunabletostartthe
Windowsoperatingsystem,youcanusetherescuelesfeatureoftheRescueandRecoveryworkspaceto
copylesfromyourharddiskdrivetoothermedia.

TostarttheRescueandRecoveryworkspace,dothefollowing:

1.Makesurethatthecomputeristurnedoff.

2.RepeatedlypressandreleasetheF11keywhenturningonthecomputer.Whenyouhearbeepsor
seealogoscreen,releasetheF11key.

3.IfyouhavesetaRescueandRecoverypassword,typeyourpasswordwhenprompted.TheRescue
andRecoveryworkspaceopensafterashortdelay.

Note:IftheRescueandRecoveryworkspacefailstoopen,see“Solvingrecoveryproblems”onpage57

Chapter5.Recoveryoverview55

.

4.Dooneofthefollowing:

•Torescuelesfromyourharddiskdriveorfromabackup,clickRescuelesandfollowthe
instructionsonthescreen.

•TorestoreyourharddiskdrivefromaRescueandRecoverybackuportorestoreyourharddiskdrive
tothefactorydefaultsettings,clickRestoreyoursystemandfollowtheinstructionsonthescreen.

FormoreinformationaboutthefeaturesoftheRescueandRecoveryworkspace,clickHelp.

Notes:

1.Afterrestoringyourharddiskdrivetothefactorydefaultsettings,youmighthavetoreinstalldevice
driversforsomedevices.See“Reinstallingpreinstalledprogramsanddevicedrivers”onpage57.

2.SomecomputerscomewithMicrosoftOfceorMicrosoftWorkspreinstalled.Ifyouneedtorecover
orreinstallyourMicrosoftOfceorMicrosoftWorksprograms,youmustusetheMicrosoftOfceCD
orMicrosoftWorksCD.ThesediscsareprovidedonlywithcomputerspreinstalledwithMicrosoft
OfceorMicrosoftWorks.

Creatingandusingarescuemedium

Witharescuemedium,suchasadiscoraUSBharddiskdrive,youcanrecoverthecomputerfromfailures
thatpreventyoufromgainingaccesstotheRescueandRecoveryworkspaceonyourharddiskdrive.

Notes:

1.Therecoveryoperationsyoucanperformusingarescuemediumvarydependingontheoperating
system.

2.Therescuedisccanbestartedinalltypesofexternalopticaldrives.

Creatingarescuemedium

Thissectionprovidesinstructionsonhowtocreatearescuemedium.

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙LenovoThinkVantageTools➙Enhanced
BackupandRestore.TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoverymainwindow,clicktheLaunchadvancedRescueandRecoveryarrow.

3.ClicktheCreateRescueMediaicon.TheCreateRescueandRecoveryMediawindowopens.

4.IntheRescueMediaarea,selectthetypeoftherescuemediumyouwanttocreate.Youcancreatea
rescuemediumusingadiscoraUSBharddiskdrive.

5.ClickOKandfollowtheinstructionsonthescreentocreatearescuemedium.

Usingarescuemedium

Thissectionprovidesinstructionsonhowtousetherescuemediumyouhavecreated.

•Ifyouhavecreatedarescuemediumusingadisc,usethefollowinginstructionstousetherescuemedium:

1.T urnoffyourcomputer.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhentheBootMenu
windowopens,releasetheF12key.

3.IntheBootMenuwindow,selectthedesiredopticaldriveastherstbootdevice.Then,insertthe
rescuediscintotheexternalopticaldriveandpressEnter.Therescuemediumstarts.

•IfyouhavecreatedarescuemediumusingaUSBharddiskdrive,usethefollowinginstructionsto
usetherescuemedium:

1.AttachtheUSBharddiskdrivetooneoftheUSBconnectorsonyourcomputer.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhentheBootMenu
windowopens,releasetheF12key.

56UserGuide

3.IntheBootMenuwindow,selecttheUSBharddiskdriveastherstbootdeviceandpressEnter.
Therescuemediumstarts.

Whentherescuemediumstarts,theRescueandRecoveryworkspaceopens.Thehelpinformationfor
eachfeatureisavailablefromtheRescueandRecoveryworkspace.Followtheinstructionstocomplete
therecoveryprocess.

Reinstallingpreinstalledprogramsanddevicedrivers

Yourcomputerhasprovisionsthatenableyoutoreinstallselectedfactory-installedprogramsanddevice
drivers.

Reinstallingpreinstalledprograms

Toreinstallselectedprograms,dothefollowing:

1.T urnonyourcomputer.

2.GototheC:\SWTOOLSdirectory.

3.OpentheAPPSfolder.Initareseveralsubfoldersnamedforthevariouspreinstalledprograms.

4.Openthesubfolderfortheprogramyouarereinstalling.

5.Double-clickSetup,andthenfollowtheon-screenstepstoreinstalltheprogram.

Reinstallingpreinstalleddevicedrivers
Attention:Whenyoureinstalldevicedrivers,youarechangingthecurrentcongurationofyourcomputer.

Reinstalldevicedriversonlywhenitisnecessarytocorrectaproblemwithyourcomputer.

Toreinstalladevicedriverforafactory-installeddevice,dothefollowing:

1.T urnonyourcomputer.

2.GototheC:\SWTOOLSdirectory.

3.OpentheDRIVERSfolder.WithintheDRIVERSfolderareseveralsubfoldersnamedforthevarious
devicesinstalledinyourcomputer(forexample,AUDIOandVIDEO).

4.Openthesubfolderforthedevice.

5.Reinstallthedevicedriverbyoneofthefollowingmethods:

•Inthesubfolderforthedevice,lookforatextle(alewiththeextension.txt).Thetextlecontains

informationonhowtoreinstallthatdevicedriver.

•Ifthesubfolderforthedevicecontainsaleofsetupinformation(alewiththeextension.inf),you

canusetheAddNewHardwareprogram(intheWindowsControlPanel)toreinstallthedevicedriver.
Notalldevicedriverscanbereinstalledbyuseofthisprogram.IntheAddNewHardwareprogram,
whenpromptedforthedevicedriveryouwanttoinstall,clickHaveDiskandBrowse.Thenselect
thedevicedriverlefromthedevicesubfolder.

•Inthesubfolderforthedevice,lookfortheexecutablele(alewiththeextension.exe).Double-click

thele,andfollowtheinstructionsonthescreen.

Attention:Ifyouneedupdateddevicedrivers,donotdownloadthemfromtheWindowsUpdateWebsite.
ObtainthemfromLenovo.Formoreinformation,see“Makingsuredevicedriversarecurrent”onpage106.

Solvingrecoveryproblems

IfyouareunabletoaccesstheRescueandRecoveryworkspaceortheWindowsenvironment,doone
ofthefollowing:

•UsearescuemediumtostarttheRescueandRecoveryworkspace.See“Creatingandusingarescue
medium”onpage56.

Chapter5.Recoveryoverview57

•Userecoverymediaifallothermethodsofrecoveryhavefailedandyouneedtorestoretheharddisk
drivetothefactorydefaultsettings.See“Creatingandusingarecoverymedia”onpage53.

Note:IfyouareunabletoaccesstheRescueandRecoveryworkspaceortheWindowsenvironmentfrom
arescuemediumorrecoverymedia,youmightnothavetherescuedevice(aninternalharddiskdrive,a
disc,aUSBharddiskdrive,orotherexternaldevices)setastherstbootdeviceinthestartupdevice
sequence.Y oumustrstmakesurethatyourrescuedeviceissetastherstbootdeviceinthestartup
devicesequenceintheThinkPadSetupprogram.See“Startupmenu”onpage99
abouttemporarilyorpermanentlychangingthestartupdevicesequence.

Itisimportanttocreatearescuemediumandasetofrecoverymediaasearlyaspossibleandstorethem
inasafeplaceforfutureuse.

fordetailedinformation

RecoveryoverviewfortheWindows8operatingsystem

Thissectionprovidesinformationabouttherecoverysolutionsprovidedoncomputerspreinstalledwiththe
Windows8operatingsystem.

Refreshingyourcomputer

Ifyourcomputerdoesnotperformwellandtheproblemmightbecausedbyarecentlyinstalledprogram,
youcanrefreshyourcomputerwithoutlosingyourpersonallesorchangingyoursettings.

Attention:Ifyourefreshyourcomputer,theprogramsthatcamewithyourcomputerandtheprogramsthat
youinstalledfromWindowsStorewillbereinstalled,butallotherprogramswillberemoved.

Torefreshyourcomputer,dothefollowing:

1.Moveyourcursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms.Click
Settings➙ChangePCsettings➙General.

2.IntheRefreshyourPCwithoutaffectingyourlessection,clickGetstarted.

Resettingyourcomputertothefactorydefaultsettings

Youcanresetyourcomputertothefactorydefaultsettings.Resettingthecomputerwillreinstallthe
operatingsystem,andreinstallalltheprogramsandsettingsthatcamewithyourcomputer.

Attention:Ifyouresetyourcomputer,allyourpersonallesandsettingswillbedeleted.Toavoiddataloss,
makeabackupcopyofallthedatathatyouwanttokeep.

Toresetyourcomputer,dothefollowing:

1.Moveyourcursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms.Click
Settings➙ChangePCsettings➙General.

2.IntheRemoveeverythingandreinstallWindowssection,clickGetstarted.

Advancedstartupoptions

AdvancedstartupoptionsenableyoutochangethestartupsettingsofyourWindowsoperatingsystem,
startthecomputerfromanexternaldevice,orrestoretheWindowsoperatingsystemfromasystemimage.

Tousetheadvancedstartupoptions,dothefollowing:

1.Moveyourcursortothetop-rightorbottom-rightcornerofthescreentodisplaythecharms.Click
Settings➙ChangePCsettings➙General.

2.IntheAdvancedstartupsection,clickRestartnow➙Troubleshoot➙Advancedoptions.

3.Restartyourcomputerfollowingtheinstructionsonthescreen.

58UserGuide

FormoredetailsabouttherecoverysolutionsprovidedoncomputerspreinstalledwiththeWindows8
operatingsystem,refertothehelpinformationsystemoftheWindows8operatingsystem.

Chapter5.Recoveryoverview59

60UserGuide

Chapter6.Replacingdevices

Thischapterprovidesinstructionsonhowtoinstallorreplacehardwareforyourcomputer.

•“Staticelectricityprevention”onpage61

•“Replacingthebattery”onpage61

•“ReplacingtheSIMcard”onpage63

•“Replacingtheharddiskdriveorsolid-statedrive”onpage65

•“ReplacingaPCIExpressMiniCardforwirelessLANconnection”onpage68

•“ReplacingaPCIExpressHalfMiniCardforwirelessWANconnection”onpage70

•“Replacingamemorymodule”onpage74

•“Replacingthekeyboard”onpage76

•“Replacingthebackupbattery”onpage81

Staticelectricityprevention

Staticelectricity,althoughharmlesstoyou,canseriouslydamagecomputercomponentsandoptions.
Improperhandlingofstatic-sensitivepartscancausedamagetothepart.Whenyouunpackanoptionor
aCRU,donotopenthestatic-protectivepackagecontainingthepartuntiltheinstructionsdirectyou
toinstallit.

WhenyouhandleoptionsorCRUs,orperformanyworkinsidethecomputer,takethefollowingprecautions
toavoidstatic-electricitydamage:

•Limityourmovement.Movementcancausestaticelectricitytobuilduparoundyou.

•Alwayshandlecomponentscarefully.Handleadapters,memorymodules,andothercircuitboardsbythe
edges.Nevertouchexposedcircuitry.

•Preventothersfromtouchingcomponents.

•Whenyouinstallastatic-sensitiveoptionorCRU,touchthestatic-protectivepackagecontainingthe
parttoametalexpansion-slotcoverorotherunpaintedmetalsurfaceonthecomputerforatleasttwo
seconds.Thisreducesstaticelectricityfromthepackageandyourbody.

•Whenpossible,removethestatic-sensitivepartfromthestatic-protectivepackagingandinstallthepart
withoutsettingitdown.Whenthisisnotpossible,placethestatic-protectivepackagingonasmooth,
levelsurfaceandplacethepartonit.

•Donotplacethepartonthecomputercoverorothermetalsurface.

Replacingthebattery

Beforeyoustart,printtheseinstructions.

ThissystemsupportsonlybatteriesspeciallydesignedforthisspecicsystemandmanufacturedbyLenovo
oranauthorizedbuilder.Thesystemdoesnotsupportunauthorizedbatteriesorbatteriesdesignedforother
systems.Ifanunauthorizedbatteryorabatterydesignedforanothersystemsisinstalled,thesystemwill
notcharge.

Attention:Lenovohasnoresponsibilityfortheperformanceorsafetyofunauthorizedbatteries,and
providesnowarrantiesforfailuresordamagearisingoutoftheiruse.

©CopyrightLenovo2012

61

Note:Ifanunauthorizedbatteryisinstalled,thefollowingmessagewillbedisplayed:“Thebatteryinstalled

isnotsupportedbythissystemandwillnotcharge.PleasereplacethebatterywiththecorrectLenovo
batteryforthissystem.”

DANGER

Iftherechargeablebatterypackisincorrectlyreplaced,thereisdangerofanexplosion.Thebattery
packcontainsasmallamountofharmfulsubstances.Toavoidinjury:

•ReplaceonlywithabatteryofthetyperecommendedbyLenovo.

•Keepthebatterypackawayfromre.

•Donotexposethebatterytoexcessiveheat.

•Donotexposethebatterytowaterorrain.

•Donotshort-circuitthebattery.

•Donotdrop,crush,puncture,orsubjecttostrongforces.Batteryabuseormishandlingcan
causethebatterytooverheat,whichcancausegassesorameto“vent”fromthebattery
packorcoincell.

Toreplacethebattery,dothefollowing:

1.T urnoffthecomputer,orenterhibernationmode.Thendisconnecttheacpoweradapterandallcables
fromthecomputer.

2.Closethecomputerdisplayandturnthecomputerover.

3.Unlockthebatterylatch1.Holdingthebatterylockleverintheunlockedpositionandremovethe
batterypack2.

62UserGuide

4.Insertafullychargedbatteryuntilitclicksintoplace1,andthenslidethebatterylatchtothelocked
position2.

5.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

ReplacingtheSIMcard

Beforeyoustart,printtheseinstructions.

YourcomputermightrequireaSIMcardtoestablishwirelessWANconnections.Dependingonthecountry
ofdelivery,youmightneedtopurchaseaSIMcardoraSIMcardmightalreadybeinstalledinyourcomputer
orispartoftheshippingcontentsthatcomewithyourcomputer.

IfyoundaSIMcardincludedintheshippingcontents,adummycardisinstalledintheSIMcardslot.Then
proceedwiththefollowinginstructions.

Note:TheSIMcardisidentiedbytheICchipmountedononesideofthecard.

ToreplacetheSIMcard,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.

2.Closethecomputerdisplaylid,andturnitover.

3.Removethebattery.See“Replacingthebattery”onpage61.

4.LocatetheSIMcarddoorattherearofthecomputer.GentlypivottheSIMcarddoorupwards.

Chapter6.Replacingdevices63

5.PushtheSIMcardinward1,andthenreleaseit.TheSIMcardejects.GentlyslidetheSIMcard
outoftheslot2.

6.InserttheSIMcardrmlyintotheslot.

7.ClosetheSIMcarddooruntilitsnapsintoposition.

64UserGuide

8.Reinstallthebattery.See“Replacingthebattery”onpage61.

9.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Ifyoundthedummycardintheshippingcontents,theSIMcardisalreadyinstalledintheSIMcardslot,
andnoinstallationisneeded.

Replacingtheharddiskdriveorsolid-statedrive

Beforeyoustart,printtheseinstructions.

Attention:Theharddiskdriveorsolid-statedriveisverysensitive.Incorrecthandlingcancausedamage
andpermanentlossofdata.Observethefollowingguidelines:

•Replacetheharddiskdriveorsolid-statedriveonlyifyouupgradeitorhaveitrepaired.Theconnectors
andslotoftheharddiskdriveorsolid-statedrivearenotdesignedforfrequentchanges,ordrive
swapping.

•Donotdropthedriveorsubjectittophysicalshocks.Putthedriveonamaterial,suchassoftcloth,that
absorbsanyphysicalshocks.

•Donotapplypressuretothecoverofthedrive.

•Donottouchtheconnector.

•Beforeremovingtheharddiskdriveorsolid-statedrive,makeabackupcopyofalltheinformation
onit,andthenturnthecomputeroff.

•Neverremovethedrivewhilethecomputerisoperating,insleepmode,orinhibernationmode.

Toreplacetheharddiskdriveorsolid-statedrive,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.

2.Closethecomputerdisplay,andturnthecomputerover.

3.Removethebattery.See“Replacingthebattery”onpage61.

Chapter6.Replacingdevices65

4.Loosenthescrews1,andthenremovethecover2.

5.Removethescrews1,andthenslidetheharddiskdriveorsolid-statedriveout2.

6.Removetheharddiskdriveorsolid-statedrivebyliftingitsleftside.

66UserGuide

7.Placethenewharddiskdriveorsolid-statedriveintotheharddiskdriveorsolid-statedrivebay.

8.Slidetheharddiskdriveorsolid-statedrivermlyintotheconnector1,andthenreinstallthescrews2.

9.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

10.Reinstallthebattery.See“Replacingthebattery”onpage61.

11.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Chapter6.Replacingdevices67

ReplacingaPCIExpressMiniCardforwirelessLANconnection

Beforeyoustart,printtheseinstructions.

DANGER

Duringelectricalstorms,donotconnectthecabletoordisconnectitfromthetelephoneoutlet
onthewall.

DANGER

Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.Toavoidshock
hazard,disconnectthecablesbeforeopeningthecoverofthisslot.

Attention:BeforeyoustartinstallingaPCIExpressMiniCard,touchametaltableoragroundedmetal

object.Thisactionreducesanystaticelectricityfromyourbody.Thestaticelectricitycoulddamagethecard.

ToreplacethePCIExpressMiniCardforwirelessLANconnection,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.Wait
threetoveminutestoletthecomputercool.

2.Closethecomputerdisplay,andturnthecomputerover.

3.Removethebattery.See“Replacingthebattery”onpage61.

4.Loosenthescrews1,andthenremovethecover2.

68UserGuide

5.Ifatoolforremovingconnectorsisincludedinthepackagewiththenewcard,useittodisconnectthe
cablesfromthecard.Ifnosuchtoolisincluded,disconnectthecablesbypickinguptheconnectors
withyourngersandgentlyunpluggingthem.

6.Removethescrew1.Thecardpopsup2.Removethecard.

7.AlignthecontactedgeofthenewPCIExpressMiniCardwiththecorrespondingsocket1.Pivotthe
carduntilyoucansnapitintoplace.Securethecardwiththescrew2.

Chapter6.Replacingdevices69

8.ConnecttheantennacablestothenewPCIExpressMiniCard.Besuretoattachthegraycabletothe
connectormarked“MAIN”or“M”onthecard,andtheblackcabletotheconnectormarked“AUX”or“A.”

9.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

10.Reinstallthebattery.See“Replacingthebattery”onpage61.

11.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

ReplacingaPCIExpressHalfMiniCardforwirelessWANconnection

Beforeyoustart,printtheseinstructions.

Dependingonthemodel,yourcomputermighthaveawirelessWANcardinstalledinthePCIExpressHalf
MiniCardslot.T oreplacethePCIExpressHalfMiniCardwithanewone,readthefollowingprerequisites.

DANGER

Duringelectricalstorms,donotconnectthecabletoordisconnectitfromthetelephoneoutlet
onthewall.

70UserGuide

DANGER

Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.Toavoidshock
hazard,disconnectthecablesbeforeopeningthecoverofthisslot.

Attention:BeforeyoustartinstallingaPCIExpressHalfMiniCard,touchametaltableoragroundedmetal

object.Thisactionreducesanystaticelectricityfromyourbody.Thestaticelectricitycoulddamagethecard.

ToreplacethePCIExpressHalfMiniCardforwirelessWANconnection,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.Wait
threetoveminutestoletthecomputercool.

2.Closethecomputerdisplay,andturnthecomputerover.

3.Removethebattery.See“Replacingthebattery”onpage61.

4.Loosenthescrew1,andthenremovethecover2.

5.Ifatoolforremovingconnectorsisincludedinthepackagewiththenewcard,useittodisconnectthe
cablesfromthecard.Ifnosuchtoolisincluded,disconnectthecablesbypickinguptheconnectors
withyourngersandgentlyunpluggingthem.

Chapter6.Replacingdevices71

6.Removethescrew1.Thecardpopsup2.Removethecard.

7.DetachthemetalhousingfromthePCIExpressHalfMiniCard.

8.AttachthemetalhousingtothenewPCIExpressHalfMiniCard.

72UserGuide

9.AlignthecontactedgeofthenewPCIExpressHalfMiniCardwiththecorrespondingsocket1.Pivot
thecarduntilyoucansnapitintoplace.Securethecardwiththescrew2.

10.ConnecttheantennacablestothenewPCIExpressHalfMiniCard.Besuretoattachtheredcabletothe
connectormarked“MAIN”or“M”onthecard,andthebluecabletotheconnectormarked“AUX”or“A.”

11.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

Chapter6.Replacingdevices73

12.Reinstallthebattery.See“Replacingthebattery”onpage61.

13.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Replacingamemorymodule

Beforeyoustart,printtheseinstructions.

Increasingmemorycapacityisaneffectivewaytomakeprogramsrunfaster.Toreplaceoraddamemory
module,readthefollowingprerequisites,andthentheinstructions.

Whenreplacingamemorymodule,besuretofollowtheprecautions.

Note:Theoperatingspeedofthememorymodulehasdependencyonthesystemconguration.Insome
conditions,thememorymoduleinyourcomputermightnotbeabletooperateatthemaximumspeed.

Attention:Beforeyoustartinstallingamemorymodule,touchametaltableoragroundedmetalobject.This
actionreducesanystaticelectricityfromyourbody.Thestaticelectricitycoulddamagethememorymodule.

Toreplaceamemorymodule,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.

2.Closethecomputerdisplay,andturnitover.

3.Removethebattery.See“Replacingthebattery”onpage61.

4.Loosenthescrews1,andthenremovethecover2.

74UserGuide

5.Iftwomemorymodulesarealreadyinthememoryslots,pressoutonthelatchesonbothedgesof
thesocketatthesametime1,andthenremoveamemorymodule2tomakeroomforthenewone.
Savetheremovedmemorymoduleforfutureuse.

6.Findthenotchonthecontactedgesideofthememorymoduleyouareinstalling.

Attention:Toavoiddamagingthememorymodule,donottouchitscontactedge.

7.Withthenotchedendofthememorymoduletowardthecontactedgesideofthesocket,insertthe
memorymodule

1intothesocketatanangleofabout20degrees;thenpressitinrmly2.

8.Pivotthememorymoduledownwarduntilitsnapsintoplace.

9.Makesurethatthememorymoduleisrmlyinstalledintheslotandcannotbemovedeasily.

Chapter6.Replacingdevices75

10.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

11.Reinstallthebattery.See“Replacingthebattery”onpage61.

12.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Replacingthekeyboard

Beforeyoustart,printtheseinstructions.

DANGER

Duringelectricalstorms,donotconnectthecabletoordisconnectitfromthetelephoneoutlet
onthewall.

DANGER

Electriccurrentfrompower,telephone,andcommunicationcablesishazardous.Toavoidshock
hazard,disconnectthecablesbeforeopeningthecoverofthisslot.

Removingthekeyboard

Toremovethekeyboard,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.

2.Closethecomputerdisplay,andturnthecomputerover.

3.Removethebattery.See“Replacingthebattery”onpage61.

76UserGuide

4.Loosenthescrews1,andthenremovethecover2.

5.Removethescrewsthatsecurethekeyboard.

6.T urnthecomputeroverandopenthedisplay.

Chapter6.Replacingdevices77

7.Pushhardinthedirectionshownbythearrows1tounlatchthefrontsideofthekeyboard.The
keyboardwillbedetachedslightly2.

8.Removethecables2and4byippingtheconnectors1and3upwards.Removethekeyboard.

Installingthekeyboard

Toinstallthekeyboard,dothefollowing:

78UserGuide

1.Attachthecables1and3byippingtheconnectors2and4downwards.

2.Insertthekeyboard.Makesurethattherearedgeofthekeyboardisundertheframe.

Chapter6.Replacingdevices79

3.Slidethekeyboardinthedirectionshownbythearrows,untilthekeyboardissecuredinplace.

4.Reinstallthescrews.

5.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

80UserGuide

6.Reinstallthebattery.See“Replacingthebattery”onpage61.

7.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Replacingthebackupbattery

Beforeyoustart,printtheseinstructions.

Prerequisitesfortheprocedure

DANGER

Ifthebackupbatteryisincorrectlyreplaced,thereisdangerofanexplosion.Thebackupbattery
containsasmallamountofharmfulsubstances.T oavoidpossibleinjury:

•ReplaceonlywithabatteryofthetyperecommendedbyLenovo.

•Keepthebatterypackawayfromre.

•Donotexposeittoexcessiveheat.

•Donotexposeittowaterorrain.

•Donotshort-circuitit.

•Donotdrop,crush,puncture,orsubjecttostrongforces.Batteryabuseormishandlingcan
causethebatterytooverheat,whichcancausegassesorameto“vent”fromthebattery
packorcoincell.

Toremovethebackupbattery,dothefollowing:

1.T urnoffthecomputer;thendisconnecttheacpoweradapterandallcablesfromthecomputer.Wait
threetoveminutestoletthecomputercool.

2.Closethecomputerdisplay,andturnthecomputerover.

3.Removethebattery.See“Replacingthebattery”onpage61.

4.Loosenthescrew1,andthenremovethecover2.

\

Chapter6.Replacingdevices81

5.Detachtheconnector1.Thenremovethebackupbattery2.

Toinstallthebackupbattery,dothefollowing:

1.Installthebackupbattery1.Thenattachtheconnector2.

2.Attachthecover1andpivotitdownwards2.Thentightenthescrews3.

82UserGuide

3.Reinstallthebattery.See“Replacingthebattery”onpage61.

4.T urnthecomputeroveragain.Connecttheacpoweradapterandallcables.

Chapter6.Replacingdevices83

84UserGuide
