Lenovo W870 User Manual
W870
Bluetooth
Headset
W870
Bluetooth
Headset
User Manual
User Manual
W870
Bluetooth Headset
Product name: Lenovo Bluetooth Headset
Product model: W870
Product standard: Q/HDLCS0103-2012
Manufacturer: Lenovo (Beijing) Co., Ltd
Address: No.6 Chuang Ye Road, Shangdi Information
Industry Base, Haidian District, Beijing, China
Zip Code: 100085
Lenovo website: www.lenovo.com
Cover.indd 1 2012-9-14 15:15:00
W870 Bluetooth Headset User Manual
― 1 ―
I. DESCRIPTION:
Dear customers,
Thank you for selecting high-quality electronic product offered by Lenovo. This headset
is manufactured with internationally advanced Bluetooth wireless audio transmission
technology. This technology is characterized by stable signal, long transmission
distance and Hi- stereo. Its in-built Lithium polymer battery of 380mAh provides a
standby time of 8 hours, allowing you to enjoy the music and chat online freely.
Mobile OS requirements: Android, WM6, WP7, IOS4.1 or above, and Symbian
PC OS requirements: WIN XP, WIN 2000, WIN 7, WIN 8, VISTA, and Apple MAC
Compatible media player: windows media, ttpod, Kugoo, iTunes, and TTPlayer
W870 Bluetooth Headset.indd 1 2012-9-14 15:56:14
W870 Bluetooth Headset User Manual
― 2 ―
II. HEADSET BUTTONS:
USB Charging Port
Bicolor LED
(Red and Blue)
Next/Volume Down
Previous/Volume Up
Multifunction Button
1. Multifunction button
1) Power On: By pressing this button for 2 seconds in power-off state until you hear
a beep in the headset, the blue lamp will ash every 2 seconds and the headset is
started.
2) Power Off: By pressing this button for over 2 seconds and then releasing it in poweron or playing state, the red lamp will ash once and you will hear a beep in the
headset.
3) Pairing: By pressing and holding the multifunction button for 5 seconds in power-off
state, the red and blue lamps of the headset will ash quickly and alternately, and
the mobile phone or computer will enable Bluetooth search. When the mobile phone
or the computer prompts that the headset is found, please click "Connect", but some
devices may require a password "0000".
4) Pause/Play: Press it once quickly in music state.
5) Answer calls: Press it once quickly when there is incoming calls.
6) Hang up calls: Press it once quickly during a call.
2. Previous/Volume +: Press it quickly to switch to the previous song; press and hold it
to increase the volume; when the button is not released after the volume reaches its
maximum, there will be a beep alert.
3. Next/Volume -: Press it quickly to switch to the next song; press and hold it to decrease
the volume; when the button is not released after the volume is lowered to its minimum,
there will be a beep alert.
4. Auto re-connection: In power-off state, press the multifunction button for 2 seconds until
it beeps. The blue lamp will ash every 2 seconds and the headset is on. Release the
button and the headset will by default automatically connect the last paired device; it
will take around 1 minute to get connected.
W870 Bluetooth Headset.indd 2 2012-9-14 15:56:14
W870 Bluetooth Headset User Manual
― 3 ―
III. BICOLOR INDICATOR LAMP:
1. Red LED lamp is the charging indicator. It is on when the device is charged, and is off
when the charging completes.
2. Blue LED lamp is the working state indicator
1) It ashes every 2 seconds in power-on and music states; it ashes twice every 3
seconds during music playing and phone calls.
2) While pairing, the red and blue lamps will ash quickly and alternately.
3) This lamp is off when the device is powered off or runs out of batteries.
IV. MICROPHONE:
Microphone
The microphone is a hidden multi-directional microphone for chatting and phone calls.
W870 Bluetooth Headset.indd 3 2012-9-14 15:56:14
