Page 1
Lenovo S960
Quick Start Guide v1.1
Read this guide carefully before using your phone.
Page 2
Technical specifications
Model
Model: Lenovo S960
①
Size and weight
Height: 144.3 mm Width: 72 mm Depth: 6.95 mm
Weight: 121 g
CPU
CPU: MTK6589W Quad Core 1.5 GHz
Camera
Type: CMOS
Pixels: 13.0 MP (back) + 5.0 MP (front)
Power and battery
Battery: 2050 mAh (Built-in battery)
Display
Size: 5.0 inches (diagonal) Screen: Multi-touch display
Resolution: 1080P LCD type: IPS
Wireless communication
Bluetooth 4.0 WLAN WCDMA, GSM
GPS
① Based on actual measurements.
Page 3
First glance
Receiver+ Speaker
1
Volume down
4
Earphone jack
7
1
2
3
7
8
9
4
56
2
Front camera
Micro USB
5
Back camera
8
3
Volume up
Microphone
6
On/Off button
9
Page 4
Installing the Micro SIM card
You need to insert the Micro SIM card provided by your carrier to use
cellular services. Insert the Micro SIM card as shown.
Step 1. Insert the SIM eject tool into the hole on the Micro SIM card
tray.
Step 2. Pull out the Micro SIM card tray and place the Micro SIM card
in the tray.
Step 3. Carefully replace the tray.
Only Micro SIM card work with your phone.
Do not insert or remove the Micro SIM card while your phone is turned on.
Doing so may permanently damage your Micro SIM card or phone.
Page 5
Charging the battery
Before using your phone, you might need to charge the battery.
Charge the battery as shown.
1
2
Method 1. Connect your phone to a power outlet using the included
cable and USB power adapter.
Method 2. Charge the battery using a computer.
Low battery Fully charged Charging
For more in formati on abou t batter y safet y, see the Important Product
Information Guide.
Page 6
Learn More
For more information about Lenovo Mobile Phone functions,
Regul atory Not ices and o ther use ful manu als, go to
http://support.lenovo.com/.
Legal notices
Lenovo an d the Lenov o logo are tr adema rks of Lenov o in the
United S tates, othe r countr ies, or bo th.
Other c ompany, product, or s ervice nam es may be tradema rks
or ser vice mar ks of other s.
First Edition (April 2014)
© Copyri ght Lenov o 2014.
5SC9A6MY7D
Printed in China
