Page 1
E
590
/R590
Setup Guide
设置指南
設定手冊
セットアップ・ガイド
설치 설명서
Page 2
Initial Setup
初始设置 I 首次安裝 I 初期セットアップ I 초기 설정
Page 3
Overview
1 2 1
3
4
5
6
7
8
9
1010
11
12
13
14
15
16
17
18
概述 I 概觀 I 概要 I 개요
Page 4
1. Microphones
2. Camera
3. Power button
4. Security-lock slot
5. Ethernet connector
6. USB 2.0 connector
7. microSD card slot
8. Numeric keypad
* 9. Fingerprint reader
10. Speakers
* For selected models
1. 麦克风
2. 摄像头
3. 电源按钮
4. 安全锁插槽
5. 以太网接口
6. USB 2.0 接口
7. microSD 卡插槽
8. 数字小键盘
* 9. 指纹读取器
10. 扬声器
* 适用于特定型号
1. 麥克風
2. 攝影機
3. 電源按鈕
4. 安全鎖插槽
5. 乙太網路連接器
6. USB 2.0 接頭
7. microSD 卡插槽
8. 數字鍵盤
* 9. 指紋辨識器
10. 喇叭
* 僅限特定型號
11. TrackPad
12. TrackPoint® buttons
13. Audio connector
14. USB 3.1 connector Gen 1
15. Always On USB 3.1 connector
Gen 1
16. HDMI
17. USB-C
TM
connector
TM
connector
18. TrackPoint pointing stick
11. 轨迹板
12. TrackPoint® 按键
13. 音频接口
14. USB 3.1 接口 Gen 1
15. Always On USB 3.1
接口 Gen 1
TM
16. HDMI
17. USB-C
18. TrackPoint 指点杆
接口
TM
接口
11. 軌跡板
12. TrackPoint® 按鈕
13. 音訊接頭
14. USB 3.1 接頭 Gen 1
15. Always On USB 3.1
接頭 Gen 1
TM
16. HDMI
17. USB-C
接頭
TM
接頭
18. TrackPoint 指標按桿
Page 5
1. マイクロホン
2. カメラ
3. 電源ボタン
4. セキュリティー・
ロック・スロット
5. イーサネット・
コネクター
6. USB 2.0 コネクター
7. microSD カード・
スロット
8. テンキーパッド
* 9. 指紋センサー
10. スピーカー
* 一部のモデル
11. トラックパッド
12. TrackPoint® ボタン
13. オーディオ・コネクター
14. USB 3.1 コネクター
Gen 1
15. Always On USB 3.1 コネクター
Gen 1
TM
16. HDMI
17. USB-C
コネクター
TM
コネクター
18. TrackPoint ポインティング・ステ
ィック
1. 마이크
2. 카메라
3. 전원 버튼
4. 보안 잠금 장치 슬롯
5. 이더넷 커넥터
6. USB 2.0 커넥터
7. microSD 카드 슬롯
키패드
8. 숫자
* 9. 지문 판독기
11. 트랙 패드
12. TrackPoint® 버튼
13. 오디오 커넥터
14. USB 3.1 커넥터 Gen 1
15. Always On USB 3.1 커넥터 Gen 1
16. HDMI
17. USB-C
18. TrackPoint 포인팅 스틱
10. 스피커
* 일부 모델의 경우
TM
커넥터
TM
커넥터
Page 6
Additional information
Technology
Frequency
band [MHz]
Maximum
transmit
power
WLAN
802.11b/g/n
WLAN
802.11a/n/ac
WLAN
802.11a/n/ac
Bluetooth
BR/EDR/LE
其他安全信息 I 其他資訊 I その他の情報 I 추가 정보
Specific Absorption Rate (ICNIRP)
YOUR DEVICE MEETS INTERNATIONAL
GUIDELINES FOR EXPOSURE TO RADIO WAVES.
Your device is a radio transmitter and receiver. It is
designed not to exceed the limits for exposure to
radio waves (radio frequency electromagnetic
fields) recommended by international guidelines.
The guidelines were developed by an independent
scientific organization (ICNIRP) and include a
substantial safety margin designed to assure the
safety of all persons, regardless of age and healt h.
The radio wave exposure guidelines use a unit of
measurement known as the Specific Absorption
Rate, or SAR. The Europe 10g SAR limit for mobile
devices is 2.0 W/kg. Tests for SAR are conducted
using standard operating positions with the device
transmitting at its highest certified power level in
all tested frequency bands. The highest SAR values
under the ICNIRP guidelines for your device are as
follows:
Maximum body-worn SAR with 0 mm separation
distance: 0.43 6 W/kg
During use, the actual SAR values for your device
are usually well below the values stated. This is
because, for purposes of system efficiency and to
minimize interference on the network, the
operating power of your mobile device is
automatically decreased when full power is not
needed for the data connection. The lower the
power output of the device, the lower its SA R
value.
If you are interested in further reducing your RF
exposure then you can easily do so by limiting your
usage or simply keeping the device away from the
body.
European Union — compliance with the Radio Equipment Directive
Hereby, Lenovo (Singapore) Pte. Ltd., declares t hat
the radio equipment type ThinkPad E590/R590 is
in compliance with Directive 2014/53/EU.
The full text of the system EU declaration of
conformity and the EU wireless module
declarations are available at the following Intern et
addresses:
• For notebook computers:
https://www.lenovo.com/eu-doc-notebooks
• For tablets:
https://www.lenovo.com/eu-doc-tablets
This radio equipment operates with the following
frequency bands and maximum radio-frequency
power:
中国无线电型号核准信息
本产品型号核准代码通过电子标签显示，请参照《安全与
保修指南》之法规信息标签查找电子标签。
电子标签样式如下：
CMIIT ID: 2018AP7044
2400 - 2483.5 < 20 dBm
5150 - 572 5 < 23 dBm
5725 - 58 75 < 13.98 dBm
2400 - 2483.5 < 20 dBm
Page 7
E-manual
电子手册 | 電子手冊 | 電子マニュアル | 전자 문서
First Edition (December 2018)
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a
General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to
restrictions set forth in Contract No. GS-35F-0 5925.
© Copyright Lenovo 2018.
Reduce I Reuse I Recycle
Printed in China
PN: SP40Q51828
