Lenovo RD430 User Manual

ThinkServerRD430
UserGuide

MachineTypes:3057,3059,3061,3064,3065,3069,3070,3071,
and4306

Note:

Beforeusingtheinformationandtheproductitsupports,besuretoreadandunderstandthefollowing:

•TheReadMeFirstthatcomeswithyourproduct

•“Safetyinformation”onpageiii

•AppendixA“Notices”onpage189

FourthEdition(September2013)

©CopyrightLenovo2012,2013.

LIMITEDANDRESTRICTEDRIGHTSNOTICE:IfdataorsoftwareisdeliveredpursuantaGeneralServicesAdministration
“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionssetforthinContractNo.GS-35F-05925.

Contents

Safetyinformation..........iii

Chapter1.Generalinformation.....1

Introduction.................1

Serverdocumentation.............2

Chapter2.Serversetuproadmap...5

Chapter3.Productoverview......7

Serverpackage...............7

Features..................8

Specications...............11

Software.................12

ThinkServerEasyStartup.........12

ThinkServerEasyUpdateFirmwareUpdater.12

LenovoThinkServerEasyManage.....12

BIOSandTMMupdateutilities......12

RAIDcongurationutilities........12

Remotemanagementsoftware......12

LenovoRackPlanner..........12

ThinkServerSmartGridTechnology....13

Diagnosticprograms..........13

Locations.................13

Machinetype,model,andserialnumber

label.................13

Frontviewoftheserver.........15

Frontpanel..............21

Diagnosticmodule...........23

Rearviewoftheserver.........28

Servercomponents...........32

Hot-swapharddiskdrivestatusLEDs...36

RAIDcard...............37

Expandercard.............38

Hot-swapharddiskdrivebackplane....39

Mini-SAStomini-SASsignalcable

connections..............43

Systemboardcomponents........48

Systemboardjumpersandswitches....51

SystemboardLEDs...........55

Chapter4.T urningonandturningoff

theserver...............57

Turningontheserver............57

Turningofftheserver............57

Chapter5.Conguringtheserver..59

UsingtheSetupUtilityprogram........59

StartingtheSetupUtilityprogram.....59

ViewinginformationintheSetupUtility

program...............59

SetupUtilityprograminterface......60

Settingthesystemdateandtime.....62

Usingpasswords............63

Selectingastartupdevice........64

ConguringtheTPMfunction.......64

SettingthemodeoftheEthernetconnector

0..................65

ExitingtheSetupUtilityprogram......65

UpdatingorrecoveringtheBIOS......65

UsingtheThinkServerEasyStartupprogram...67

FeaturesoftheThinkServerEasyStartup

program...............68

StartingtheThinkServerEasyStartup

program...............68

UsingtheThinkServerEasyStartupprogram

onaWindowsoperatingsystem......70

ConguringRAID..............70

AboutRAID..............70

ConguringRAIDusingtheThinkServer

EasyStartupprogram..........72

ConguringtheThinkServerRAID300...72
ConguringtheadvancedSATA/SAShardware

RAID.................78

ConguringtheEthernetcontrollers......78

Updatingthermware............79

UsingtheFirmwareUpdaterprogram....79

UsingtheLenovoThinkServerEasyManage

program.................79

Chapter6.Installing,removing,or

replacinghardware..........81

Guidelines................81

Precautions..............81

Handlingstatic-sensitivedevices.....82

Systemreliabilityguidelines........83

Workinginsidetheserverwiththepoweron.83

Removingtheservercover..........83

Removingandreinstallingthefrontbezel....85

Installing,removing,orreplacinghardware...86

Removingandreinstallingtherackhandles.87

Removingandreinstallingthecooling

shroud................91

Removingandreinstallingtheleftcage...93

Installingorremovingamemorymodule...95

InstallingorremovingtheRAIDcard....101

InstallingorremovingtheThinkServerRAID

500UpgradeKeyforAdvancedRAID....105

©CopyrightLenovo2012,2013

i

InstallingorremovingtheThinkServerRAID

700Battery..............107

Installingorremovingtheexpandercard...110
InstallingorremovinganEthernetcard...114
InstallingorremovingtheThinkServerRAID

300UpgradeKeyforAdvancedRAID....119

InstallingorremovingtheThinkServer

ManagementModulePremium......123

InstallingorremovingtheThinkServerT rusted

PlatformModule............126

Installingorreplacingahot-swapredundant

powersupply.............129

Installingorreplacingaheatsink......133

Installingorreplacingthemicroprocessor..135
Installingorreplacingtheopticaldrive...143
Installingorreplacingahot-swapharddisk

drive.................148

Replacingthehot-swapharddiskdrive

backplane...............152

Replacingtherisercardassembly1....159

Replacingtherisercardassembly2....161

Replacingthefrontpanelboard......163

Replacingthediagnosticmodule.....167

Replacingasystemfan.........170

Replacingthesystemboardbattery....172

Completingthepartsreplacement.......174

Reinstallingtheservercoverandreconnecting

cables................174

Updatingtheserverconguration.....177

Chapter7.T roubleshootingand

diagnostics.............179

Troubleshootingprocedure..........179

ViewingthestatusanddiagnosticLEDs.....179

Usingadiagnosticprogram.........180

Viewingthesystemeventlog.........180

Basictroubleshootingtables.........180

ThinkServerEasyStartupprogram

problems...............180

Opticaldriveproblems..........181

Harddiskdriveproblems.........182

Memorymoduleproblems........183

Keyboard,mouse,andUSBdevice

problems...............184

Chapter8.Gettinginformation,help,

andservice.............185

Informationresources............185

Usingthedocumentation.........185

ThinkServerWebsite..........185

LenovoSupportWebsite.........185

Helpandservice..............186

Beforeyoucall.............186

Callingforservice............186

Usingotherservices..........187

Purchasingadditionalservices......187

AppendixA.Notices.........189

Trademarks................190

Importantnotes..............190

PolyvinylChloride(PVC)cableandcordnotice..190

Recyclinginformation............190

Batteryreturnprogram..........191

Requirementforbatteriescontaining

perchlorate..............191

Particulatecontamination..........192

ImportantWEEEinformation.........192

GermanOrdinanceforWorkglossstatement...193

Exportclassicationnotice..........193

Electronicemissionnotices..........193

FederalCommunicationsCommission(FCC)

Statement...............193

ENERGYSTARmodelinformation.......195

Index.................197

iiThinkServerRD430UserGuide

Safetyinformation

Note:Beforeusingtheproduct,besuretoreadandunderstandthemultilingualsafetyinstructionsonthe

documentationDVDthatcomeswiththeproduct.

Antesdeusaroproduto,leiaeentendaasinstruçõesdesegurançamultilínguesnoDVDdedocumentação
queoacompanha.

Предидаизползватетозипродукт,задължителнопрочететеивникнетевмногоезичнитеинструкции
забезопасноствDVDдискасдокументация,койтосепредоставяспродукта.

PrijeupotrebeovogproizvodaobaveznopročitajtevišejezičnesigurnosneuputekojesenalazenaDVD-us
dokumentacijomkojidobivateuzproizvod.

PředpoužitímproduktujetřebasipřečístaporozumětbezpečnostnímpokynůmuvedenýmnadiskuDVDs
dokumentací,kterýjedodávánsproduktem.

Førdubrugerproduktet,skaldusørgeforatlæseogforstådesikkerhedsforskrifter,derndespåere
sprog,pådendokumentations-dvd,derfølgermedproduktet.

LuetuotteenmukanatoimitetullaDVD-tietolevylläolevatmonikielisetturvaohjeetennentämäntuotteen
käyttöä.

Avantd'utiliserleproduit,veillezàbienlireetcomprendrelesinstructionsdesécuritémultilinguesgurant
surleDVDdedocumentationfourniavecleproduit.

Πρινχρησιμοποιήσετετοπροϊόν,βεβαιωθείτεότιέχετεδιαβάσεικαικατανοήσειτιςοδηγίεςασφάλειας,οι
οποίεςείναιδιαθέσιμεςσεδιάφορεςγλώσσεςστοDVDτεκμηρίωσηςπουσυνοδεύειτοπροϊόν.

VorVerwendungdesProduktssolltenSieunbedingtdiemehrsprachigenSicherheitsanweisungenaufder
Dokumentations-DVDlesen,dieimLieferumfangdesProduktsenthaltenist.

AtermékhasználataelőttmindenképpenolvassaelésértelmezzeatermékhezkapottdokumentációsDVD
lemezentalálható,többnyelvenelolvashatóbiztonságielőírásokat.

Primadiutilizzareilprodotto,accertarsidileggereecomprendereleinformazionisullasicurezzamultilingue
disponibilisulDVDdidocumentazionefornitoconilprodotto.

製品をご使用になる前に、製品に付属のDocumentationDVDに収録されているマルチリンガルの「安
全に正しくご使用いただくために」を読んで理解してください。

제품을사용하기전에제품과함께제공되는문서DVD의다국어안전지침을주의깊게읽어보십시오.

Voordatuhetproductgebruikt,moetuervoorzorgendatudemeertaligeveiligheidsinstructiesopde
documentatie-dvdvanhetproducthebtgelezenenbegrijpt.

©CopyrightLenovo2012,2013

iii

Przedskorzystaniemzproduktunależyzapoznaćsięzwielojęzycznymiinstrukcjamibezpieczeństwa
znajdującymisięnapłycieDVDzdokumentacjądostarczonąwrazzproduktem.

Antesdeutilizaroproduto,leiaatentamenteasinstruçõesdesegurançamultilinguesqueconstamno
DVDdedocumentaçãofornecidocomoproduto.

Înaintedeautilizaprodusul,asiguraţi-văcăaţicititşiînţelesinstrucţiuniledesiguranţăînmaimultelimbide
peDVD-ulcudocumentaţiecareînsoţeşteprodusul.

Førdubrukerproduktet,måduleseogforstådenerspråkligesikkerhetsinformasjonenpåDVDenmed
dokumentasjonsomfølgermedproduktet.

Преждечемиспользоватьэтотпродукт,внимательноознакомьтесьсинструкциямипотехнике
безопасностинаразныхязыках,которыеможнонайтинаDVD-дискесдокументациейвкомплектес
продуктом.

在使用本产品之前，请务必先阅读和了解产品附带的文档DVD中的多语言安全说明。

Prenegotoupotrebiteproizvodobaveznopaljivoproitajteiprouiteviejezikouputstvozabezbednostna
dokumentacionomDVD-ukojistedobiliuzproizvod.

PredpouvanmproduktusipretajteviacjazynbezpenostnpokynynadiskuDVDsdokumentcioudodanoms
produktom.

Predenzačneteuporabljatiizdelek,jepomembno,daprebereteinrazumetevečjezičnavarnostnanavodila
naDVD-juzdokumentacijo,kistegaprejeliskupajzizdelkom.

Antesdeutilizarelproducto,asegúresedeleerycomprenderlasinstruccionesdeseguridadmultilingüesdel
DVDdedocumentaciónqueseproporcionaconelproducto.

Varnogamedattläsasäkerhetsinstruktionernapådokumentations-DVD-skivansomföljermedprodukten
innandubörjaranvändaprodukten.

使用本產品之前，請務必閱讀並瞭解產品隨附的文件DVD上的多國語言版本安全資訊。

Buürünükullanmadanönce,ürünlebirliktegönderilenbelgeDVD'siüzerindekiçokdiliçerengüvenlik
yönergeleriniokuyupanladýðýnýzdaneminolun.

Передвикористаннямцьогопродуктууважноознайомтесязінструкціямизтехнікибезпекинарізних
мовах,щоможназнайтинаDVD-дискуздокументацієювкомплектізпродуктом.

Important:Thecautionanddangerstatementsinthisdocumentarelabeledwithnumbers.Eachnumber
identiesanEnglish-languagecautionordangerstatementthatreferstotranslatedversionsofthecaution
ordangerstatementintheSafetyInformationdocument.Forexample,ifadangerstatementislabeled
“Statement1,”translationsforthisdangerstatementareintheSafetyInformationdocumentunder
“Statement1.”

Ensurethatyoureadandunderstandallcautionanddangerstatementsinthisdocumentbeforeyouperform
theprocedures.Readandunderstandanyadditionalsafetyinformationthatisincludedwiththeserveror
optionaldevicebeforeyouinstall,remove,orreplacethedevice.

ivThinkServerRD430UserGuide

Statement1

DANGER

Electricalcurrentfrompower,telephone,andcommunicationcablesishazardous.

Toavoidashockhazard:

•Donotconnectordisconnectanycablesorperforminstallation,maintenance,orrecongurationofthis

productduringanelectricalstorm.

•Connectallpowercordstoaproperlywiredandgroundedelectricaloutlet.

•Ensurethatallpowercordconnectorsaresecurelyandcompletelypluggedintoreceptacles.

•Connecttoproperlywiredoutletsanyequipmentthatwillbeattachedtothisproduct.

•Whenpossible,useonehandonlytoconnectordisconnectsignalcables.

•Neverturnonanyequipmentwhenthereisevidenceofre,water ,orstructuraldamage.

•Disconnecttheattachedpowercords,telecommunicationssystems,networks,andmodemsbeforeyou

openthedevicecovers,unlessinstructedotherwiseintheinstallationandcongurationprocedures.

•Connectanddisconnectcablesasdescribedinthefollowingtablewheninstalling,moving,oropening

coversonthisproductorattacheddevices.

Toconnect:Todisconnect:

1.TurneverythingOFF.

2.First,attachallcablestodevices.

3.Attachsignalcablestoconnectors.

4.Attachpowercordstooutlet.

5.TurndevicesON.

1.TurneverythingOFF.

2.First,removepowercordsfromoutlet.

3.Removesignalcablesfromconnectors.

4.Removeallcablesfromdevices.

Statement2

DANGER

Dangerofexplosionifbatteryisincorrectlyreplaced.

Whenreplacingthelithiumcoincellbattery,useonlythesameoranequivalenttypethatis
recommendedbythemanufacturer .Thebatterycontainslithiumandcanexplodeifnotproperly
used,handled,ordisposedof.

Donot:

•Throworimmerseintowater

•Heattomorethan100°C(212°F)

•Repairordisassemble

Disposeofthebatteryasrequiredbylocalordinancesorregulations.

©CopyrightLenovo2012,2013

v

Statement3

CAUTION:
Whenlaserproducts(suchasCD-ROMs,DVDdrives,beropticdevices,ortransmitters)are
installed,notethefollowing:

•Donotremovethecovers.Removingthecoversofthelaserproductcouldresultinexposureto
hazardouslaserradiation.Therearenoserviceablepartsinsidethedevice.

•Useofcontrolsoradjustmentsorperformanceofproceduresotherthanthosespeciedherein
mightresultinhazardousradiationexposure.

DANGER

SomelaserproductscontainanembeddedClass3AorClass3Blaserdiode.Notethefollowing:

Laserradiationwhenopen.Donotstareintothebeam,donotviewdirectlywithoptical
instruments,andavoiddirectexposuretothebeam.

Statement4

≥18kg(39.7lb)≥32kg(70.5lb)≥55kg(121.2lb)
<32kg(70.5lb)<55kg(121.2lb)<100kg(220.5lb)

CAUTION:
Usesafepracticeswhenlifting.

Statement5

CAUTION:
Thepowercontrolbuttononthedeviceandthepowerswitchonthepowersupplydonotturnoff
theelectricalcurrentsuppliedtothedevice.Thedevicealsomighthavemorethanonepower
cord.Toremoveallelectricalcurrentfromthedevice,ensurethatallpowercordsaredisconnected
fromthepowersource.

viThinkServerRD430UserGuide

Statement6

CAUTION:
Ifyouinstallastrain-reliefbracketoptionovertheendofthepowercordthatisconnectedtothe
device,youmustconnecttheotherendofthepowercordtoapowersourcethatiseasilyaccessible
incaseitneedstobedisconnected.

Statement7

CAUTION:
Ifthedevicehasdoors,ensurethatyouremoveorsecurethedoorsbeforemovingorliftingthe
devicetoprotectagainstpersonalinjury.Thedoorswillnotsupporttheweightofthedevice.

Statement8

CAUTION:
Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.

Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabel
attached.Therearenoserviceablepartsinsidethesecomponents.Ifyoususpectaproblemwith
oneoftheseparts,contactaservicetechnician.

Statement9

CAUTION:
Disconnectthehot-swapfancablesbeforeremovingthefanfromthedevicetoprotectagainst
personalinjury.

Statement10

CAUTION:
Thefollowinglabelindicatesasharp-edgehazard.

©CopyrightLenovo2012,2013

vii

Statement11

CAUTION:
Thefollowinglabelindicatesapotentialheathazard.

Statement12

DANGER

Overloadingabranchcircuitisapotentialrehazardandashockhazardundercertainconditions.To
avoidthesehazards,ensurethatyoursystemelectricalrequirementsdonotexceedbranchcurrentratings
attheinstallationsite.

Statement13

CAUTION:
Ensurethattherackissecuredproperlytoavoidtippingwhentheserverunitisextendedontherails.

Statement14

CAUTION:
SomeaccessoryoroptionboardoutputsexceedClass2orlimitedpowersourcelimits.Y ou
mustinstalltheappropriateinterconnectingcablinginaccordancewithyourlocalelectricalcode
requirements.

Statement15

CAUTION:
Thepower-controlbuttononthedevicemayputthedeviceinstandbymodeinsteadofturningoff
thedevice.Inaddition,thedevicemighthavemultipleconnectionstodcpower.Toremoveall
electricalcurrentfromthedevice,ensurethatallconnectionstodcpoweraredisconnectedat
thedcpowerinputterminals.

viiiThinkServerRD430UserGuide

Statement16

CAUTION:
Toreducetheriskofelectricshockorenergyhazards:

•Thisequipmentmustbeinstalledbytrainedservicepersonnelinarestricted-accesslocation,as
denedbyyourlocalelectricalcodeandthelatesteditionofIEC60950.

•Connecttheequipmenttoareliablyearthedsafetyextralowvoltage(SEL V)source.AnSELV
sourceisasecondarycircuitthatisdesignedsothatnormalandsinglefaultconditionsdonot
causethevoltagestoexceedasafelevel(60Vdirectcurrent).

•Thebranchcircuitovercurrentprotectionmustberatedinaccordancewithlocalelectricalcode
requirements.

•Use1.3mm

2

or16AmericanWireGauge(AWG)copperconductoronly,notexceeding3meters

inlength.

•T orquethewiring-terminalscrewsto1.4newton-metersor12inch-pounds.

•Provideareadilyavailable,approvedandrateddisconnectdeviceintheeldwiring.

Statement17

CAUTION:
ThisproductcontainsaClass1Mlaser.Donotviewdirectlywithopticalinstruments.

Statement18

CAUTION:
Donotplaceanyobjectontopofrack-mountedproducts.

Statement19

CAUTION:
Hazardousmovingparts.Keepngersandotherbodypartsaway.

©CopyrightLenovo2012,2013

ix

Statement20

CAUTION:
Alithiumionbatteryisprovided.T oavoidpossibleexplosion,donotburnthebattery.Replacethe
batteryonlywiththeLenovo-approvedpart.Recycleordiscardthebatteryasinstructedbylocal
regulations.

xThinkServerRD430UserGuide

Chapter1.Generalinformation

Thischapterprovidessomegeneralinformationaboutyourproduct.

Thischaptercontainsthefollowingitems:

•“Introduction”onpage1

•“Serverdocumentation”onpage2

Introduction

ThisuserguideforyourLenovo
specications,componentlocations,congurationinstructions,hardwarereplacementprocedures,and
basictroubleshootinganddiagnostics.

YourservercomeswithadocumentationDVDthatcontainsvariousserverdocumentstohelpyouuseand
maintaintheserver.Meanwhile,yourservercomeswithaThinkServerEasyStartupDVDthatprovidesa
convenientsolutionforconguringtheserverandinstallinganoperatingsystem.

TheLenovoLimitedWarranty(LLW)containsthewarrantytermsthatapplytotheproductyoupurchasedfrom
Lenovo.ReadtheLLWonthedocumentationDVDthatcomeswithyourserver.Aprintablegenericversion
ofthelatestLLWalsoisavailableinmorethan30languagesathttp://www.lenovo.com/warranty/llw_02.If
youcannotobtaintheLLWthroughthedocumentationDVDorLenovoWebsite,contactyourlocalLenovo
ofceorresellertoobtainaprintedversionoftheLLW,freeofcharge.

®

ThinkServer

®

productcontainsinformationabouttheserverfeatures,

Forwarrantyservice,consulttheworldwideLenovoSupporttelephonelist.Telephonenumbersaresubject
tochangewithoutnotice.Themostup-to-datetelephonelistforLenovoSupportisalwaysavailableonthe
Websiteathttp://www.lenovo.com/support/phone.Ifthetelephonenumberforyourcountryorregionisnot
listed,contactyourLenovoresellerorLenovomarketingrepresentative.

Toobtainthemostup-to-dateinformationabouttheserver,goto:
http://www.lenovo.com/thinkserver

LenovomaintainspagesontheWorldWideWeb,whereyoucangetthelatesttechnicalinformationand
downloaddocumentationordevicedriversandupdates.ToaccesstheLenovoSupportWebsite,goto:
http://www.lenovo.com/support

©CopyrightLenovo2012,2013

1

Recordinformationaboutyourserverinthefollowingtable.Youwillneedtheinformationifyoueverneed
tohaveyourserverserviced.

Forwheretondtheproductinformationlabelonthechassis,see“Machinetype,model,andserialnumber
label”onpage13.

Productname

Machinetypeandmodel(MT-M)

Serialnumber(S/N)

Dateofpurchase

______________________________________________

______________________________________________

______________________________________________

______________________________________________

YoucanregisteryourserverwithLenovobyfollowingtheinstructionsat:
http://www.lenovo.com/register

Whenyouregisteryourserver,informationisenteredintoadatabase,whichenablesLenovotocontact
youincaseofarecallorothersevereproblem.AfteryouregisteryourserverwithLenovo,youwillreceive
quickerservicewhenyoucallLenovoforhelp.Inaddition,somelocationsofferextendedprivilegesand
servicestoregisteredusers.

Serverdocumentation

Thistopicprovidesageneraldescriptionofeachdocumentforyourserverandinstructionsonhow
toobtainallthedocuments.

Printeddocuments

Thefollowingdocumentsareprintedoutandincludedinyourserverpackage.

•ReadMeFirst
Thisisamultilingualdocumentyoushouldreadrst.Thisdocumentguidesyoutoreadthecomplete

warranty,support,andsafetyinformationonthedocumentationDVDthatcomeswithyourserverbefore
usingtheproduct.Thisdocumentalsoprovidesinformationabouthowtondthemostup-to-date
informationontheLenovoSupportWebsite.

•ImportantNotices
Thisdocumentincludessafetyandlegalnoticesthatyoushouldreadandunderstandbeforeusing

theserver.

•RackInstallationInstructions
Thisdocumentprovidesinstructionsonhowtoinstallyourserverintoastandardrackcabinetbyusing

therailkitshippedwiththeserver.

Note:Thisdocumentisavailableinvelanguages.AprintedEnglishversionisincludedinyourserver
package.APDFversionofFrench,German,Italian,andSpanishareprovidedonthedocumentationDVD
thatcomeswiththeserver.

2ThinkServerRD430UserGuide

DocumentationDVD

ThedocumentationDVD,whichcomeswithyourserver,containsvariousdocumentsforyourserverin
PortableDocumentFormat(PDF)andHyperT extMarkupLanguage(HTML).ThedocumentationDVDisnot
bootable.ToviewthedocumentsontheDVD,youwillneedacomputerwithaWebbrowserandtheAdobe
Readerprogram,whichisavailablefordownloadat:
http://www.adobe.com

TostartthedocumentationDVD,inserttheDVDintotheopticaldrive.TheDVDisAutoPlayenabledand
startsautomaticallyinmostMicrosoft

®

Linux

operatingsystem,openthelaunch.htmlelocatedintherootdirectoryoftheDVD.

®

Windows

®

environments.IftheDVDfailstostartorifyouareusinga

Note:LenovomaintainspagesontheWorldWideWeb,whereyoucangetthelatesttechnicalinformation
anddownloaddocumentationordevicedriversandupdates.Someinformationinthedocumentsonthe
documentationDVDmightchangewithoutnoticeaftertherstreleaseoftheDVD.Youcanalwaysobtainall
themostup-to-datedocumentationforyourserverfromtheLenovoWebsiteat:
http://www.lenovo.com/ThinkServerUserGuides

ThefollowingdocumentsareonthedocumentationDVDthatcomeswithyourserver:

•SafetyInformation
Thisisamultilingualdocumentthatincludesallthesafetystatementsforyourproductinmorethan30

languages.Besuretoreadandunderstandallthesafetystatementsbeforeusingtheproduct.

•WarrantyandSupportInformation
ThisdocumentincludestheLenovowarrantystatement,CustomerReplaceableUnits(CRUs)information,

andinformationabouthowtocontacttheLenovoCustomerSupportCenter.

•LenovoLicenseAgreement
ThisdocumentincludesthetermsandconditionsoftheLenovoLicenseAgreement.

•UserGuide
Thisdocumentprovidesdetailedinformationtohelpyougetfamiliarwithyourserverandhelpyouuse,

congure,andmaintainyourserver.

•RackInstallationInstructions
Thisdocumentprovidesinstructionsonhowtoinstallyourserverintoastandardrackcabinetbyusing

therailkitshippedwiththeserver.

•ThinkServerManagementModuleUserGuide
Thisdocumentprovidesinformationaboutserverremotemanagement.ThisdocumentisinEnglishonly.

YoumightndthisdocumentonthedocumentationDVDthatcomeswithyourserver.Ifnot,downloadit
fromtheLenovoWebsiteat:
http://www.lenovo.com/ThinkServerUserGuides

Note:Toobtainadvancedremotemanagementfunctions,installaThinkServerManagementModule
Premium(TMMPremium)ontheTMMPremiumconnectoronthesystemboard.See“Installingor
removingtheThinkServerManagementModulePremium”onpage123

.

•MegaRAIDSASSoftwareUserGuide
ThisdocumentprovidesinformationaboutRedundantArrayofIndependentDisks(RAID)andhowto

usetheutilityprogramstocongure,monitor,andmaintainyourserverRAIDandrelateddevices.This
documentisinEnglishonly.

Note:RefertothisdocumentforhardwareRAIDinformationifyourserverhasasupportedRAIDcard
installed.See“RAIDcard”onpage37

.ForinformationabouttheThinkServerRAID300(alsoknownas

onboardSASsoftwareRAID),see“ConguringtheThinkServerRAID300”onpage72.

Chapter1.Generalinformation3

Documentonlyfortrainedservicepersonnel

ThefollowingdocumentisintendedonlyfortrainedservicepersonnelofLenovo.

HardwareMaintenanceManual

Thisdocumentprovidesinformationaboutcomponentlocations,replacementproceduresformajorField
ReplaceableUnits(FRUs),andtroubleshootinganddiagnostics.Thisdocumentisupdatedfrequently,and
themostup-to-dateversionisalwaysavailableinEnglishontheLenovoWebsiteat:
http://www.lenovo.com/ThinkServerUserGuides

4ThinkServerRD430UserGuide

Chapter2.Serversetuproadmap

Thischapterprovidesageneralroadmaptoguideyouthroughsettingupyourserver.

Theserversetupprocedurevariesdependingonthecongurationoftheserverwhenitwasdelivered.In
somecases,theserverisfullyconguredandyoujustneedtoconnecttheservertothenetworkandanac
powersource,andthenyoucanturnontheserver.Inothercases,theserverneedstohavehardwaredevices
installed,requireshardwareandrmwareconguration,andrequiresanoperatingsystemtobeinstalled.

Thegeneralprocedureforsettingupyourserveris:

1.Unpacktheserverpackage.See“Serverpackage”onpage7.

2.Installanyrequiredhardwareorserveroptions.SeetherelatedtopicsinChapter6“Installing,removing,
orreplacinghardware”onpage81.

3.Installtheserverintoastandardrackcabinetbyusingtherailkitshippedwiththeserver.SeetheRack
InstallationInstructionsthatcomeswiththeserver.

4.ConnecttheEthernetcable(s)andpowercord(s)totheserver.See“Rearviewoftheserver”onpage

tolocatetheconnectors.

28

5.Turnontheservertoverifyoperation.See“Turningontheserver”onpage57.

6.ReviewtheUniedExtensibleFirmwareInterface(UEFI)BasicInputOutputSystem(BIOS)settingsand
customizeasneeded.See“UsingtheSetupUtilityprogram”onpage59

7.CongureRAIDandinstalltheoperatingsystemanddevicedrivers.See“UsingtheThinkServer
EasyStartupprogram”onpage67

8.Installanyadditionaldriversrequiredforaddedfeatures.Refertotheinstructionsthatcomewith
thehardwareoption.

9.CongureEthernetsettingsintheoperatingsystembyreferringtotheoperatingsystemhelp.Thisstep
isnotrequirediftheoperatingsystemwasinstalledusingtheThinkServerEasyStartupprogram.

10.Checkforrmwareupdates.See“Updatingthermware”onpage79.

11.Installmanagementapplicationsandanyotherapplications.Refertothedocumentationthatcomes
withtheapplicationsthatyouwanttoinstall.

and“ConguringRAID”onpage70.

.

©CopyrightLenovo2012,2013

5

6ThinkServerRD430UserGuide

Chapter3.Productoverview

Thischapterprovidesinformationabouttheserverpackage,features,specications,softwareprograms,
andcomponentlocations.

Thischaptercontainsthefollowingitems:

•“Serverpackage”onpage7

•“Features”onpage8

•“Specications”onpage11

•“Software”onpage12

•“Locations”onpage13

Serverpackage

Theserverpackageincludestheserver,powercord(s),arailkit,printeddocumentation,adocumentation
DVD,andsoftwaremedia.

Note:Dependingonthemodel,yourservermightlookslightlydifferentfromthefollowingillustration.

Figure1.Serverpackage

1Server
2Materialbox,includingpowercord(s),printeddocumentation,adocumentationDVD,andsoftwaremedia
3Railkit

©CopyrightLenovo2012,2013

7

Features

Thistopicprovidesgeneralinformationabouttheserverfeaturesforavarietyofmodels.Dependingonyour
specicmodel,somefeaturesmightvaryorunavailable.Forinformationaboutyourspecicmodel,usethe
SetupUtilityprogram.See“ViewinginformationintheSetupUtilityprogram”onpage59

Microprocessor

.

OneortwoIntel

®

®

Xeon

quad-core,hexa-core,orocta-coremicroprocessors(internalcachesizevaries

bymodel)

ForalistoftheThinkServermicroprocessoroptions,goto:
http://www.lenovo.com/thinkserver

Memory

Yourserverhas12memoryslots.Formoreinformation,see“Memorymoduleinstallationrules”onpage95

Powersupply

Oneortwo800-watthot-swapredundantpowersupplies(Universalinputandcompliantwith80PLUSGold)

Systemfan

Asystemfancagewithfourhot-swapsystemfansandtwodummysystemfans

Internaldrive

Internaldrivesaredevicesthatyourserverusestoreadandstoredata.Theinternaldrivessupported
byyourservervarybymodel.

•Harddiskdrive
–Uptoeight3.5-inchhot-swapSerialAdvancedTechnologyAttachment(SATA)orSerialAttachedSCSI

(SAS)harddiskdrives(SCSIistheacronymforSmallComputerSystemInterface)
–Upto123.5-inchhot-swapSATAorSASharddiskdrives
–Uptoeight2.5-inchhot-swapSASharddiskdrivesorSATAsolid-statedrives
–Upto162.5-inchhot-swapSASharddiskdrivesorSATAsolid-statedrives

.

Note:Theterm“2.5-inchhot-swapharddiskdrives”or“2.5-inchharddiskdrives”hereinafterreferstoall
thesupportedtypesof2.5-inchharddiskdrives,includingthesolid-statedrives.

•Opticaldrive
–OneslimSATAopticaldriveinsomemodels

Expansionslot

•Tworisercardassemblyslotsonthesystemboard

•TwoPeripheralComponentInterconnect(PCI)Expresscardslotsontherisercardassembly1

•ThreePCIExpresscardslotsontherisercardassembly2

Fordetailedinformation,see“Rearviewoftheserver”onpage28

.

8ThinkServerRD430UserGuide

Input/Output(I/O)features

•Oneserialconnectorontherearpanel

•OneVideoGraphicsArray(VGA)connectoronthefrontpanelinsomemodelsandoneVGAconnector
ontherearpanel

•SixUSB2.0connectors(twoonthefrontpanelandfourontherearpanel)

•ThreeRJ-45Ethernetconnectorsontherearpanel(Ethernetconnector0isforsystemmanagement)

Forthelocationinformationabouttheconnectors,refertotherelatedtopicsin“Locations”onpage13.

Videosubsystem

AnintegratedgraphicscontrollerintheThinkServerManagementModule(TMM),whichalsoisknown
astheBaseboardManagementController(BMC)chip,onthesystemboardtosupportVGAconnectors
forconnectingvideodevices

Ethernetconnectivity

ThreeRJ-45Ethernetconnectorsontherearpanelwith10megabitspersecond(Mbps),100Mbps,or
1000Mbpsnetworkconnectivity.

•OnboardIntel82574LGigabitEthernetcontrollerfordedicatedorsharedlocalareanetwork(LAN)
managementinterface(Ethernetconnector0isforsystemmanagement)

•OnboardIntelGigabitDualPortEthernetcontrollerforEthernetconnector1andEthernetconnector2

Formoreinformation,see“Rearviewoftheserver”onpage28.

Reliability,availability,andserviceability

Reliability,availability,andserviceability(hereinafterreferredtoasRAS)arethreeimportantserverdesign
features.TheRASfeatureshelpyoutoensuretheintegrityofthedatastoredontheserver,theavailabilityof
theserverwhenyouneedit,andtheeasewithwhichyoucandiagnoseandcorrectproblems.

YourserverhasthefollowingRASfeatures:

•Securityfeatures
–Administratorpasswordanduserpasswordtohelpyouprotectunauthorizedaccesstotheserver

(see“Usingpasswords”onpage63

)

–Hot-swapredundantpowersuppliestoprotectagainstsignicantinterruptiontotheoperationofthe

systemwhenapowersupplyfails(forservermodelsthatcomewithonepowersupply,youcan
purchaseahot-swapredundantpowersupplyoptionfromLenovoandinstallitintoyourserverasthe
secondpowersupplyforredundancy)

–RedundantArrayofIndependentDisks(RAID)congurationforimprovingdatastoragereliabilityand

faulttolerance(see“ConguringRAID”onpage70

)
–Remotemonitoringorcontrolbyanadministratortoprovideprotectionorhelp
–ThinkServerTrustedPlatformModule(TPM),whichisasecuritychip,tohelpenhanceserversecurity

Note:TheTPMisonlyavailableinsomemodels.

•Basicsystemmanagementfeatures
–Abilitytostorethepower-onself-test(POST)hardwaretestresults

–BIOSSetupUtilityprogram

Chapter3.Productoverview9

TheBIOSSetupUtilityprogramhelpsyouviewtheserverinformationandconguretheserverinthe
pre-operatingsystemenvironment.See“UsingtheSetupUtilityprogram”onpage59.

–TMM(alsoknownasBMC)andIntelligentPlatformManagementInterface(IPMI)2.0

ThesystemboardplatformmanagementsubsystemisbasedontheintegratedTMMfeatures.The
TMMisamanagementchipthatisintegratedonthesystemboardofyourserver.WiththeTMM,no
matterwhatconditiontheserveroperatingsystemisinandnomatteriftheserverisonoroff,aslong
astheserverisconnectedtonetworkandanacpowersource,theinteractionwiththeTMM-controlled
serverscanbeachievedthroughsystemnetwork.Theusercanobtaintheserverhardwarehealth
informationandsystemeventlog(SEL),andisabletoconducttheoperationsincludingturningonor
offtheserver,restartingtheserver,andsoon.Thispartofservermanagementisindependentofthe
operatingsystemandiscalledout-of-bandmanagement.

ThesystemboardplatformmanagementsubsystemconsistsoftheintegratedTMM,communication
buses,sensors,theBIOS,andservermanagementrmware.Itisresponsibleforerrorreporting,
systempowercontrol,thermalmonitoring,systemfancontrol,andothermanagementfeatures.The
TMMprovidessystemmanagementandmonitoringfeaturesbasedontheIPMI2.0specication.IPMI
helpslowertheoverallcostsofservermanagement.YoucanndmoreinformationaboutIPMI2.0
fromtheWebsiteofIntel.TheTMMalsosupportssomenon-IPMIfeatures,suchastheDynamicHost
CongurationProtocol(DHCP)andthePlatformEnvironmentControlInterface(PECI),toprovide
moresystemmanagementfunctions.

Formoreinformation,refertotheThinkServerManagementModuleUserGuide,whichisavailablefor
downloadat:
http://www.lenovo.com/ThinkServerUserGuides

–Hot-swapfeature

Yourserversupportshot-swapharddiskdrives,hot-swapsystemfans,andhot-swapredundant
powersupplies.Withthehot-swapfeature,youcaninstall,remove,orreplaceahot-swapdevice
withoutturningofftheserver.

–PrebootExecutionEnvironment(PXE)

TheIntelPXEtechnologyenablesyoutobootyourcomputers,loadanoperatingsystem,ordeploy
executableimagesfromaremoteserverbyusinganetworkinterface.Theoperationcanbedone
independentlyoflocaldatastoragedevices(suchasharddiskdrives)oroperatingsystems.

–RAID

YourserversupportsThinkServerRAID300(alsoknownasonboardSASsoftwareRAID)and
advancedSATA/SAShardwareRAIDifarequiredRAIDcardisinstalled.Fordetailedinformation,
see“ConguringRAID”onpage70

.

–Statuslight-emittingdiodes(LEDs)anddiagnosticLEDs

FormoreinformationabouttheLEDsforyourserver,refertotherelatedtopicsin“Locations”on
page13.

–Softwareprograms

Formoreinformationaboutthesoftwareprograms,see“Software”onpage12.

–WakeonLAN

WhentheWakeonLANfeatureisenabledonacomputerthatisconnectedtoaLAN,anetwork
administratorcanremotelyturnonorwakeupthecomputerfromamanagementconsoleusingremote
networkmanagementsoftware.Besides,manyotherfunctions,suchasdatatransferandsoftware
updates,canbeperformedremotelywithoutremoteattendanceandcanbedoneafternormalworking
hoursandonweekendstosavetimeandincreaseproductivity.

•Advancedsystemmanagementfeatures
TheadvancedsystemmanagementfeaturesareonlyavailablewhentheTMMdetectsthepresenceofa

ThinkServerManagementModulePremium(TMMPremium),whichalsoisknownasintegratedkeyboard,
video,andmouse(iKVM)key.TheTMMPremiumisaremotemanagementmodule.Youcanpurchase

10ThinkServerRD430UserGuide

aTMMPremiumfromLenovoandinstallitontheTMMPremiumconnector(alsoknownasiKVM
connector)onthesystemboardofyourservertoenabletheiKVMfunctionandactivatetheadvanced
systemmanagementfeatures.

Formoreinformationaboutadvancedsystemmanagement,refertotheThinkServerManagementModule
UserGuide,whichisavailablefordownloadat:
http://www.lenovo.com/ThinkServerUserGuides

Specications

Thistopicliststhephysicalspecicationsforyourserver.

Dimensions

Widthwithoutrackhandles:442mm(17.4inches)
Widthwithrackhandles:482.4mm(19inches)
Depthwithoutrackhandles:720.6mm(28.37inches)
Depthwithrackhandles:734mm(28.9inches)
Height:87.6mm(3.45inches)

Weight

Theproductweightvariesdependingondifferentsystemcongurations.

Rangeofproductweightwithoutpackage:16kg(35.27lb)to28kg(61.73lb)
Rangeofproductweightwithpackage:19kg(41.89lb)to35kg(77.16lb)

Environment

•Airtemperature:
Operating:10°Cto35°C(50°Fto95°F)

Storage:-40°Cto70°C(-40°Fto158°F)inoriginalshippingpackage

•Altitude:0to3048m(0to10000ft)inanunpressurizedenvironment

•Humidity:
Operating:8%to80%(non-condensing)

Storagewithoutpackage:8%to80%(non-condensing)
Storagewithpackage:8%to90%(non-condensing)

Electricalinput

•Universalinput:

–Lowrange:

Minimum:100Vac
Maximum:127Vac
Inputfrequencyrange:50to60Hz

–Highrange:

Minimum:200Vac
Maximum:240Vac
Inputfrequencyrange:50to60Hz

Chapter3.Productoverview11

Software

Thistopicprovidesinformationaboutthesoftwareprogramsthatyoucanusetohelpyousetup,use,
andmaintaintheserver.

ThinkServerEasyStartup

TheThinkServerEasyStartupprogramsimpliestheprocessofconguringRAIDandinstallingsupported
MicrosoftWindowsandLinuxoperatingsystemsanddevicedriversonyourserver.Thisprogramisprovided
withyourserveronaself-starting(bootable)ThinkServerEasyStartupDVD.Theuserguidefortheprogram
alsoisontheDVDandcanbeaccesseddirectlyfromtheprograminterface.Fordetailedinformation,see
“UsingtheThinkServerEasyStartupprogram”onpage67

.

ThinkServerEasyUpdateFirmwareUpdater

TheThinkServerEasyUpdateFirmwareUpdaterprogram(hereinafterreferredtoastheFirmwareUpdater
program)enablesyoutomaintainyourserverrmwareup-to-dateandhelpsyouavoidunnecessaryserver
outages.TheFirmwareUpdaterprogramisprovidedontheLenovoSupportWebsite.Formoreinformation
aboutdownloadingandusingtheFirmwareUpdaterprogram,see“Updatingthermware”onpage79

LenovoThinkServerEasyManage

TheLenovoThinkServerEasyManageprogramenablesenterpriseuserstoremotelycontrolandmonitor
multipleLenovoserverswithinaLAN.

.

Fordetailedinformation,see“UsingtheLenovoThinkServerEasyManageprogram”onpage79

.

BIOSandTMMupdateutilities

TheBIOSandTMM(alsoknownasBMC)rmwarekeepsupdatingaftertheshipmentoftheserver.
LenovomaintainspagesontheSupportWebsiteandprovidestheBIOSandTMMupdateutilitieswith
instructionsfordownloadtohelpyouupdatetheBIOSandTMMrmwareifneeded.Formoreinformation,
see“UpdatingorrecoveringtheBIOS”onpage65

and“Updatingthermware”onpage79.

RAIDcongurationutilities

WithsomeRAIDcongurationutilities,yourserversupportsThinkServerRAID300andadvancedSATA/SAS
hardwareRAIDifarequiredRAIDcardisinstalled.Fordetailedinformation,see“ConguringRAID”
onpage70.

Remotemanagementsoftware

TheintegratedTMMprovidesbasicremotemanagementfeaturesfortheserver.Theadd-onTMMPremium
optionprovidesadvancedremotemanagementfeaturesfortheserver.

Fordetailedinformationabouttheremotemanagementsoftwareandserverremotemanagement,referto
theThinkServerManagementModuleUserGuide,whichisavailablefordownloadat:
http://www.lenovo.com/ThinkServerUserGuides

LenovoRackPlanner

Racksandserversareusuallydeployedonalargescale.Whendeployingtheequipment,equipment
managersneedalotofreferenceparameterstocalculatepowerconsumptionandelectriccurrentvalues
underdifferentcongurations.TheLenovoRackPlannerprogramprovidesdatamaintenance,power

12ThinkServerRD430UserGuide

consumptionandelectriccurrentcalculations,andreportstohelpequipmentmanagerssignicantly
increaseefciencyindeployingtheequipmentandconvenientlymanagetheequipment.

TodownloadtheLenovoRackPlannerprogram,gotohttp://www.lenovo.com/driversandfollowthe
instructionsontheWebpage.

FordetailedinformationaboutusingtheLenovoRackPlannerprogram,refertothehelpsystemforthe
program.

ThinkServerSmartGridT echnology

TheThinkServerSmartGridT echnologyprogramhelpsadministratorstomonitorandmanageserver
performance,especiallythepowerconsumptionforgroupsofserversequippedwiththeIntelIntelligent
PowerNodeManagertechnology.

LenovoprovidesatrialversionoftheThinkServerSmartGridTechnologyprogramwithafree90-day
subscription.After90days,youmustrenewthelicensetocontinueusingtheprogram.Youcanpurchase
thelicensefromLenovotoactivatetheThinkServerSmartGridTechnologyprogramandexpandthe
managementcapabilityoftheprogramwhenthefreetrialends.

TodownloadtheThinkServerSmartGridTechnologyprogram,gotohttp://www.lenovo.com/driversand
followtheinstructionsontheWebpage.

FordetailedinformationaboutusingtheThinkServerSmartGridTechnologyprogram,refertothehelp
systemfortheprogram.

Diagnosticprograms

Thefollowingdiagnosticprogramsareavailableforyoutodiagnoseserverproblems:

•ThinkServerDiagnosticTool

•ThinkServerSystemProleCollectionTool

Formoreinformation,see“Usingadiagnosticprogram”onpage180

.

Locations

Thistopicprovidesinformationtohelpyoulocateyourservercomponents.

Machinetype,model,andserialnumberlabel

Thistopichelpsyoutolocatethelabelthatcontainsthemachinetype,model,andserialnumberinformation
foryourserver.

WhenyoucontactLenovoforhelp,themachinetype,model,andserialnumberinformationhelpssupport
technicianstoidentifyyourserverandprovidefasterservice.

Theillustrationsinthistopicshowthemachinetype,model,andserialnumberlabelsonservermodelswith
differentharddiskdrivecongurations.Dependingonthemodel,yourservermightlookslightlydifferent
fromtheillustrationsinthistopic.

Chapter3.Productoverview13

Themachinetype,model,andserialnumberlabelisattachedonthepull-outinformationcardinthe
followingservermodels:

•Servermodelswitheight3.5-inchharddiskdrivebays

•Servermodelswith2.5-inchharddiskdrivebays
Thepull-outinformationcardisasmallplastictabandcanbeslidoutofthefrontofthechassis.

Figure2.Labelonservermodelswitheight3.5-inchharddiskdrivebays

Figure3.Labelonservermodelswith2.5-inchharddiskdrivebays

14ThinkServerRD430UserGuide

Forservermodelswith123.5-inchharddiskdrivebays,themachinetype,model,andserialnumberlabelis
attachedontheleftsideoftheserver.

Figure4.Labelonservermodelswith123.5-inchharddiskdrivebays

Frontviewoftheserver

Thistopicprovidesinformationtohelpyoulocatethepartsonthefrontoftheserver.

Thefrontviewoftheservervariesbymodel.Theillustrationsinthistopicshowtheserverfrontviews
basedonthesupportedharddiskdrives:

•“Frontviewofservermodelswitheight3.5-inchharddiskdrivebays”onpage16

•“Frontviewofservermodelswith123.5-inchharddiskdrivebays”onpage17

•“Frontviewofservermodelswith2.5-inchharddiskdrivebays”onpage20

Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.

Chapter3.Productoverview15

Frontviewofservermodelswitheight3.5-inchharddiskdrivebays

Thefollowingillustrationshowsthefrontviewofservermodelswitheight3.5-inchharddiskdrivebays.

Figure5.Frontviewofservermodelswitheight3.5-inchharddiskdrivebays

13.5-inchharddiskdrivearea
2Rackhandle(left)6Slimopticaldrive(availableinsomemodels)
3Pull-outinformationcard
4Frontpanel

13.5-inchharddiskdrivearea

5Diagnosticpanel(variesbymodel)

7Rackhandle(right)

TheElectromagneticInterference(EMI)integrityandcoolingoftheserverareprotectedbyhavingalldrive
bayscoveredoroccupied.Thenumberoftheinstalledharddiskdrivesinyourservervariesbymodel.The
vacantharddiskdrivebaysareoccupiedbydummyharddiskdrivetrays.

Forservermodelswitheight3.5-inchharddiskdrivebays,theharddiskdrivebaynumbersaremarkedon
thetopedgeofthefrontbezel.

Figure6.3.5-inchharddiskdrivebaynumbers(topviewoftheserver)

2Rackhandle(left)

7Rackhandle(right)

Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestohelpyouslidetheserverout
oftherackcabinet;orusetherackhandlesandscrewstosecuretheserverintherackcabinetsothat
theservercannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRack
InstallationInstructionsthatcomeswithyourserver.

16ThinkServerRD430UserGuide

3Pull-outinformationcard

Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage13.

4Frontpanel

Fordetailedinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage21.

5Diagnosticpanel

Thediagnosticpanelvariesbymodel.Fordetailedinformation,see“Diagnosticmodule”onpage23.

6Slimopticaldrive

SomeservermodelscomewithaslimSATAopticaldrive.

Frontviewofservermodelswith123.5-inchharddiskdrivebays

Thefollowingillustrationshowsthefrontviewofservermodelswith123.5-inchharddiskdrivebays.

Figure7.Frontviewofservermodelswith123.5-inchharddiskdrivebays

13.5-inchharddiskdrivearea
2Rackhandle(left)7NIC2statusLED
3FrontUSBconnectors(2)8SystemerrorLED
4PowerswitchwithpowerstatusLED
5Systemidenticationbutton(IDbutton)withIDLED

6NetworkInterfaceController(NIC)1statusLED

9Rackhandle(right)

Chapter3.Productoverview17

13.5-inchharddiskdrivearea

TheEMIintegrityandcoolingoftheserverareprotectedbyhavingalldrivebayscoveredoroccupied.The
numberoftheinstalledharddiskdrivesinyourservervariesbymodel.Thevacantharddiskdrivebaysare
occupiedbydummyharddiskdrivetrays.

Forservermodelswith123.5-inchharddiskdrivebays,theharddiskdrivebaynumbersaremarkedon
thetopedgeofthefrontbezel.

Figure8.3.5-inchharddiskdrivebaynumbers(topviewoftheserver)

2Rackhandle(left)

9Rackhandle(right)

Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestohelpyouslidetheserverout
oftherackcabinet;orusetherackhandlesandscrewstosecuretheserverintherackcabinetsothat
theservercannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRack
InstallationInstructionsthatcomeswithyourserver.

Forservermodelswith123.5-inchharddiskdrivebays,thefrontUSBconnectorsareintegratedintotheleft
rackhandle;andthefrontcontrolsandLEDsareintegratedintotherightrackhandle.

3FrontUSBconnectors

UsedtoattachaUSB-compatibledevice,suchasaUSBkeyboard,mouse,scanner,orprinter.Ifyou
havemorethansixUSBdevices,youcanpurchaseaUSBhub,whichyoucanusetoconnectadditional
USBdevices.

4PowerswitchwithpowerstatusLED

Youcanpressthepowerswitchtoturnontheserverwhenyounishsettinguptheserver.Youalsocan
holdthepowerswitchforseveralsecondstoturnofftheserverifyoucannotturnofftheserverfromthe
operatingsystem.SeeChapter4“T urningonandturningofftheserver”onpage57

.ThepowerstatusLED

helpsyoutodeterminethecurrentpowerstatus.

18ThinkServerRD430UserGuide

PowerstatusLED

Blinking

5IDbuttonwithIDLED

OnGreen
Off

Color

Theserverison.

None

GreenTheserverisinACPIS1mode,whichalsoisknown

Theserverisoff.

asPowerOnSuspend(POS)mode.Inthismode,
themicroprocessor(s)arenotworkingwhileother
hardwaredevicesarestillworking.

Description

WhenyoupresstheIDbutton,theIDLEDsonboththefrontandrearoftheserverarelittohelpyoulocate
theserveramongotherservers.YoualsocanturnontheIDLEDsusingaremotemanagementprogram
forserverpresencedetection.

6NIC1statusLED

7NIC2statusLED

IDLED

On
Off

Color

Blue

None

Theserverisidentied.
TheIDLEDisnotinuseortheserverisnotidentied.

Description

TheNIC1statusLEDindicatestheLANstatusfortheEthernetconnector1ontherearoftheserver.

TheNIC2statusLEDindicatestheLANstatusfortheEthernetconnector2ontherearoftheserver.

Description

8SystemerrorLED

NICstatusLEDColor

OnGreen
Off

Blinking

TheserverisconnectedtoaLAN.

None

Green

TheserverisdisconnectedfromaLAN.
TheLANisconnectedandactive.

ThesystemerrorLEDhelpsyoutodetermineifthereareanysystemerrors.

SystemerrorLEDColor

On

Off

Amber

None

Oneormoresystemerrorshaveoccurredandthe
systemislikelytofail.

Theserverisoffortheserverisonandisworking
correctly.

Description

Chapter3.Productoverview19

Frontviewofservermodelswith2.5-inchharddiskdrivebays

Thefollowingillustrationshowsthefrontviewofservermodelswith2.5-inchharddiskdrivebays.

Figure9.Frontviewofservermodelswith2.5-inchharddiskdrivebays

12.5-inchharddiskdrivearea(rightcage)5Rackhandle(left)

22.5-inchharddiskdrivearea(middlecage)6Diagnosticpanel(variesbymodel)
3Pull-outinformationcard
4Slimopticaldrive(availableinsomemodels)8Rackhandle(right)

12.5-inchharddiskdrivearea(rightcage)

7Frontpanel

22.5-inchharddiskdrivearea(middlecage)

Thefrontofservermodelswith2.5-inchharddiskdrivebaysconsistsofthreecages:

•Theleftcageconsistsofthefrontpanelboard,thefrontVGADB-15connector,thediagnosticmodule,
thepull-outinformationcard,andtheslimopticaldrivebay.

•Themiddlecageconsistsofthenumber0tonumber7harddiskdrivebays.Thereiseithera2.5-inch
hot-swapharddiskdriveora2.5-inchdummyharddiskdrivetrayinstalledineachbay.

•Therightcageconsistsofthenumber8tonumber15harddiskdrivebays.Thereiseithera2.5-inch
hot-swapharddiskdriveora2.5-inchdummyharddiskdrivetrayinstalledineachbay.Iftheserver
supportsuptoeightharddiskdrives,therewillbeanEMI-protectivepanelthatcoverstherightcage
asawhole.

Figure10.RightcagewithanEMI-protectivepanel

Note:Theharddiskdrivebaynumber(0-15)ismarkedaboveeach2.5-inchharddiskdrivebayonthe
frontbezel.

3Pull-outinformationcard

Themachinetype,model,andserialnumberlabeloftheserverisattachedonthepull-outinformationcard.
See“Machinetype,model,andserialnumberlabel”onpage13

.

20ThinkServerRD430UserGuide

4Slimopticaldrive

ID

SomeservermodelscomewithaslimSATAopticaldrive.

5Rackhandle(left)

8Rackhandle(right)

Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestohelpyouslidetheserverout
oftherackcabinet;orusetherackhandlesandscrewstosecuretheserverintherackcabinetsothat
theservercannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRack
InstallationInstructionsthatcomeswithyourserver.

6Diagnosticpanel

Thediagnosticpanelvariesbymodel.Fordetailedinformation,see“Diagnosticmodule”onpage23

7Frontpanel

.

Fordetailedinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage21.

Frontpanel

Thistopicappliesonlytothefollowingservermodels:

•Servermodelswitheight3.5-inchharddiskdrivebays

•Servermodelswith2.5-inchharddiskdrivebays
Forservermodelswith123.5-inchharddiskdrivebays,thefrontUSBconnectorsareintegratedintotheleft

rackhandle;andthefrontcontrolsandLEDsareintegratedintotherightrackhandle.See“Frontviewof
servermodelswith123.5-inchharddiskdrivebays”onpage17

Thefollowingillustrationshowsthecontrols,connectors,andLEDsonthefrontpaneloftheserver.T olocate
thefrontpanel,see“Frontviewofservermodelswitheight3.5-inchharddiskdrivebays”onpage16and
“Frontviewofservermodelswith2.5-inchharddiskdrivebays”onpage20.

fordetailedinformation.

Figure11.Frontpanel

1PowerswitchwithpowerstatusLED
2IDbuttonwithIDLED
3NIC1statusLED7VGADB-15connector
4NIC2statusLED

5SystemerrorLED
6FrontUSBconnectors(2)

Chapter3.Productoverview21

1PowerswitchwithpowerstatusLED

Youcanpressthepowerswitchtoturnontheserverwhenyounishsettinguptheserver.Youalsocan
holdthepowerswitchforseveralsecondstoturnofftheserverifyoucannotturnofftheserverfromthe
operatingsystem.SeeChapter4“T urningonandturningofftheserver”onpage57.ThepowerstatusLED
helpsyoutodeterminethecurrentpowerstatus.

PowerstatusLED

Blinking

2IDbuttonwithIDLED

OnGreen
Off

Color

Theserverison.

None

GreenTheserverisinACPIS1mode,whichalsoisknown

Theserverisoff.

asPowerOnSuspend(POS)mode.Inthismode,
themicroprocessor(s)arenotworkingwhileother
hardwaredevicesarestillworking.

Description

WhenyoupresstheIDbuttononthefrontpanel,theIDLEDsonboththefrontandrearoftheserverare
littohelpyoulocatetheserveramongotherservers.YoualsocanturnontheIDLEDsusingaremote
managementprogramforserverpresencedetection.

3NIC1statusLED

4NIC2statusLED

IDLED

On
Off

Color

Blue

None

Theserverisidentied.
TheIDLEDisnotinuseortheserverisnotidentied.

Description

TheNIC1statusLEDindicatestheLANstatusfortheEthernetconnector1ontherearoftheserver.

TheNIC2statusLEDindicatestheLANstatusfortheEthernetconnector2ontherearoftheserver.

NICstatusLEDColor

OnGreen
Off

Blinking

TheserverisconnectedtoaLAN.

None

Green

TheserverisdisconnectedfromaLAN.
TheLANisconnectedandactive.

Description

22ThinkServerRD430UserGuide

5SystemerrorLED

ThesystemerrorLEDhelpsyoutodetermineifthereareanysystemerrors.

SystemerrorLEDColor

On

Off

DescriptionAction

Thetemperatureoftheserverreached
thenon-criticaltemperaturethreshold.

Thevoltageoftheserverreachedthe
non-criticalvoltagethreshold.

Afanhasbeendetectedtoberunningat
lowspeed.

Ahot-swapfanhasbeenremoved.1.Ensurethatthesystemfansare

Amber

Thepowersupplyhasacriticalerror.
Thepowercordhasbeendisconnected

fromonepowersupplyoraredundant
powersupplyhasbeenremoved.

TheTHERMTRIP#signalisasserted
becausethesystemisoverheated.

None

Theserverisoffortheserverisonand
isworkingcorrectly.

ChecktheBMCforerrorsandcheckthe
systemfans.

Replacethesystemboard.
Note:Thisproceduremustbeperformed
onlybytrainedservicepersonnelof
Lenovo.SeeChapter8“Getting
information,help,andservice”onpage

.

185
Checkthesystemfans.

connectedsecurelytothesystem
board.

2.Reinstalltheremovedfanorinstalla
newfantoreplacetheremovedfan.

ChecktheBMCfordetailedinformation.

1.Ensurethatthepowersuppliesare
installedsecurelyintheserver.

2.Ensurethatthepowercordsare
connectedsecurelytothepower
supplies.

3.Installanewpowersupplyto
replacetheremovedone.

ChecktheBMCforerrorsandthen
checkthesystemfans.

6FrontUSBconnectors

UsedtoattachaUSB-compatibledevice,suchasaUSBkeyboard,mouse,scanner,orprinter.Ifyou
havemorethansixUSBdevices,youcanpurchaseaUSBhub,whichyoucanusetoconnectadditional
USBdevices.

7VGADB-15connector

UsedtoattachaVGA-compatiblevideodevice,suchasaVGAmonitor.

Diagnosticmodule

Thistopicappliesonlytothefollowingservermodels:

•Servermodelswitheight3.5-inchharddiskdrivebays

•Servermodelswith2.5-inchharddiskdrivebays

ThistopicprovidesinformationaboutthediagnosticmoduleandthediagnosticLEDsonthepanelofthe
module.T olocatethediagnosticpanel,see“Frontviewoftheserver”onpage15.

Chapter3.Productoverview23

Someservermodelscomewithoneofthefollowingdiagnosticmodules:

•IntelligentDiagnosticsModule(IDM)

•IntelligentDiagnosticsModulePremium(IDMPremium)

ManyerrorsarerstindicatedbyaliterrorLEDonthediagnosticpaneloftheserver.IfanLEDislit,oneor
moreLEDselsewhereintheservermightalsobelittodirectyoutothesourceoftheerror.See“System
boardLEDs”onpage55.

IntelligentDiagnosticsModule(IDM)

TheIDMisavailableinsomemodelstoprovidebasicdiagnosticfunctions.Thefollowingillustrationshows
thediagnosticLEDsontheIDMpanel.

Figure12.IDMpanel

LED

1Powersupplyerror

LED

2Ambienttemperature

limitLED

3SystemfanerrorLED

Status

Solidoff

Solidon(amber)

Solidoff

Solidon(amber)

Solidoff

Solidon(amber)Oneormoresystemfansare

Thepowersupplyisworking
correctly.

Thepowersupplyislikelytofail
orhasfailed.

Theserverisrunningatanormal
temperature.

Theambienttemperatureisbelow
7°C(44.6°F)orover40°C(104°F).

Thesystemfansareoperating
correctly.

runningatlowspeedorhave
beenremoved.

DescriptionAction

ChecktheBMCforerrorsand
runthediagnosticprograms.See
“Usingadiagnosticprogram”on
page180
Note:Toidentifythefailingpower
supply,checkthestatusLED
nearthepowercordconnector
ontheredundantpowersupply.

ChecktheBMCforerrorsand
runthediagnosticprograms.See
“Usingadiagnosticprogram”on
page180

ChecktheBMCforerrorsand
runthediagnosticprograms.See
“Usingadiagnosticprogram”on
page180
Note:Toidentifythefailing
systemfans,checkthestatus
LEDsonthesystemboard.See
“SystemboardLEDs”onpage
55

.

.

.

.

24ThinkServerRD430UserGuide

4Memorymodule

statusLED

LED

Solidoff

Status

Thememorymodules
areoperatingatanormal

DescriptionAction

temperature.

Solidon(amber)Oneormorememorymodules

areoverheated.

ChecktheBMCforerrorsand
runthediagnosticprograms.See
“Usingadiagnosticprogram”on
page180

5Microprocessor

statusLED(alsoknown
asCPUerrorLED)

Solidoff

Solidon(amber)Oneormoremicroprocessorsare

Themicroprocessorsare
operatingatanormal
temperature.

overheated.

ChecktheBMCforerrorsand
runthediagnosticprograms.See
“Usingadiagnosticprogram”on
page180

IntelligentDiagnosticsModulePremium(IDMPremium)

TheIDMPremiumisavailableinsomemodelstoprovideadvanceddiagnosticfunctions.Thefollowing
illustrationshowsthediagnosticLEDsontheIDMPremiumpanel.

.

.

Figure13.IDMPremiumpanel

1SystemfanerrorLEDs
2CPU1DIMMstatusLEDs
3CPU2DIMMstatusLEDs

4AmbienttemperaturelimitLED
5MicroprocessorstatusLEDs
6PowersupplyerrorLEDs

Chapter3.Productoverview25

1SystemfanerrorLEDs

LED

SystemfanerrorLED

Status

Solidoff

Solidon(amber)Oneormoresystemfansare

Thesystemfansareoperating
correctly.

runningatlowspeedorhave
beenremoved.

DescriptionAction

ChecktheBMCforerrorsand
runthediagnosticprograms.See
“Usingadiagnosticprogram”on
page180
Note:Toidentifythefailing
systemfans,checkthestatus
LEDsonthesystemboard.See
“SystemboardLEDs”onpage

.

55

Thefollowingillustrationshowsthesystemfansandtheirnumbers.

Notes:

•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustration.

•Yourserverhasfoursystemfans.Thecallout3andcallout6indicatedummysystemfans.

.

Figure14.Systemfans

26ThinkServerRD430UserGuide

2CPU1DIMMstatusLEDs

3CPU2DIMMstatusLEDs

WhenaDIMMstatusLEDislitinamber,itindicatesthatthecorrespondingmemorymoduleisoverheated.
Thefollowingillustrationshowsthememorymodulesandtheirnumbers.

Figure15.DIMMstatusLEDsandDIMMs

4AmbienttemperaturelimitLED

LED

Ambienttemperature
limitLED

Solidoff

Solidon(amber)

Status

Theserverisrunningatanormal
temperature.

Theambienttemperatureisbelow
7°C(44.6°F)orover40°C(104°F).

5MicroprocessorstatusLEDs(alsoknownasCPUstatusLEDs)

LED

Microprocessorstatus
LED

Solidoff

Status

Themicroprocessorsare
operatingatanormal
temperature.

Solidon(amber)Oneormoremicroprocessorsare

overheated.

DescriptionAction

ChecktheBMCforerrorsand
runthediagnosticprograms.See
“Usingadiagnosticprogram”on
page180

DescriptionAction

ChecktheBMCforerrorsand
runthediagnosticprograms.See
“Usingadiagnosticprogram”on
page180

.

.

Chapter3.Productoverview27

6PowersupplyerrorLEDs

LED

PowersupplyerrorLED

Solidoff

Status

Thepowersupplyisworking

DescriptionAction

correctly.

Solidon(amber)

Thepowersupplyislikelytofail
orhasfailed.

ChecktheBMCforerrorsand
runthediagnosticprograms.See
“Usingadiagnosticprogram”on
page180.
Note:Toidentifythefailingpower
supply,checkthestatusLED
nearthepowercordconnector
ontheredundantpowersupply.

Rearviewoftheserver

Thistopicprovidesinformationtohelpyoulocatetheconnectorsandcomponentsontherearofyourserver.

Thefollowingillustrationshowstherearviewoftheserver.

Figure16.Rearviewoftheserver

1Hot-swapredundantpowersupply2(availablein

somemodels)

2Hot-swapredundantpowersupply1
3PCIExpresscardareaforcardsontherisercard

assembly2

4PCIExpresscardareaforcardsontherisercard

assembly1

5Ethernetconnector2(RJ-45)
6FourUSBconnectors

7VGADB-15connector

8Ethernetconnector1(RJ-45)
9Ethernetconnector0forsystemmanagement(RJ-45)

10Serialport

11IDLED

28ThinkServerRD430UserGuide

1Hot-swapredundantpowersupply2(availableinsomemodels)

2Hot-swapredundantpowersupply1

Thehot-swapredundantpowersupplieshelpyouavoidsignicantinterruptiontotheoperationofthe
systemwhenapowersupplyfails.Youcanpurchaseahot-swapredundantpowersupplyoptionfrom
Lenovoandinstallthepowersupplytoprovidepowerredundancywithoutturningofftheserver.

Oneachhot-swapredundantpowersupply,thereisastatusLEDnearthepowercordconnector.Whenthe
LEDislitingreen,itindicatesthatthehot-swapredundantpowersupplyisworkingcorrectly.WhentheLED
islitinamber,itindicatesthatthehot-swapredundantpowersupplyislikelytofailorhasfailed.

3PCIExpresscardareaforcardsontherisercardassembly2

TherearethreePCIExpresscardslotsontherisercardassembly2forinstallingEthernetcardsorother
supportedPCIExpresscards.

Figure17.Risercardassembly2

Note:Theslot1andslot2aresupportedonlyinservermodelswithtwomicroprocessors.Forserver
modelswithonemicroprocessor,theslot1andslot2arecovered.Ifyouinstallthesecondmicroprocessor
intheserver,youneedtoremovethecoversthatprotecttheslot1andslot2beforeinstallingany
supportedcardsintotheslots.

PCIExpresscardslot

1

2

3

PhysicallinkwidthNegotiablelinkwidth

x16x8,x4,x2,x1
x8x8,x4,x2,x1
x8x4,x2,x1

Supportedcardlengthandheight

Half-length,full-heightcard
Half-length,full-heightcard
Low-prolecard

Chapter3.Productoverview29

4PCIExpresscardareaforcardsontherisercardassembly1

TherearetwoPCIExpresscardslotsontherisercardassembly1.

Figure18.Risercardassembly1

Note:ForaRAIDcard,itmustbeinstalledintotheupperslot(callout2)ontherisercardassembly1.For
anexpandercard,itmustbeinstalledintothelowerslot(callout1)ontherisercardassembly1.

PCIExpresscardslot

1

2

Physicallinkwidth

x8x4,x2,x1

x16x16,x8,x4,x2,x1

Negotiablelink

width

Supportedcardlengthandheight

Half-length,full-heightcard
(recommendedforinstallingan
expandercard)

Half-length,full-heightcard
(recommendedforinstallinga
supportedRAIDcard)

30ThinkServerRD430UserGuide

589Ethernetconnectors(RJ-45)

UsedtoattachanEthernetcableforaLAN.EachEthernetconnectorhastwostatusLEDstohelpyou
identifytheEthernetconnectivity,activity,andconnectionspeed.

Notes:

•TheEthernetconnector0(callout9)markedwith“MGMT”isforsystemmanagement.Ifyouwanttouse
remotemanagementfunctions,youneedtoconnectanEthernetcabletotheEthernetconnector0.

•TheEthernetconnector0forsystemmanagementis82574Lbydefault.Ifyouhaveselectedshare
modeforthe82574LEthernetconnectorintheSetupUtilityprogram,youcanusetheconnector
asanordinaryEthernetconnectorwith100Mbpsnetworkconnectivity.However,teamingwithother
EthernetconnectorsisnotsupportedifthemanagementEthernetconnectorisusedasanordinary
Ethernetconnector.FordetailedinformationaboutsettingthemodeoftheEthernetconnectorforsystem
management,see“SettingthemodeoftheEthernetconnector0”onpage65

Figure19.EthernetstatusLEDs

.

EthernetstatusLED

1Left

2Right

6USBconnectors

ColorStatus

Amber
GreenOn
None
GreenOn
None
Green

On

Off

Off
BlinkingTheLANisconnectedandactive.

Theconnectionspeedis1000Mbps.
Theconnectionspeedis100Mbps.
Theconnectionspeedis10Mbps.
TheserverisconnectedtoaLAN.
TheserverisdisconnectedfromaLAN.

Description

UsedtoattachaUSB-compatibledevice,suchasaUSBkeyboard,mouse,scanner,orprinter.Ifyou
havemorethansixUSBdevices,youcanpurchaseaUSBhub,whichyoucanusetoconnectadditional
USBdevices.

7VGADB-15connector

UsedtoattachaVGA-compatiblevideodevice,suchasaVGAmonitor.

10Serialport

Usedtoattachadevicethatusesa9-pinserialport.

Chapter3.Productoverview31

11IDLED

WhenyoupresstheIDbuttononthefrontoftheserver,theIDLEDsonboththefrontandrearoftheserver
arelittohelpyoulocatetheserveramongotherservers.Y oualsocanturnontheIDLEDsusingaremote
managementprogramforserverpresencedetection.

IDLED

On
Off

Color

Blue

None

Theserverisidentied.
TheIDLEDisnotinuseortheserverisnotidentied.

Description

Servercomponents

Thistopicprovidesinformationtohelpyoulocatethecomponentsofyourserver.Formoreinformation
aboutmajorcomponents,seetherelatedtopicsin“Locations”onpage13.

Toremovetheservercoverandgainaccesstotheinsideoftheserver,see“Removingtheservercover”
onpage83.

Thechassiscongurationvariesbymodel.Thefollowingillustrationsshowthethreemainchassis
congurationsbasedonthesupportedharddiskdrives.

•“Componentsofservermodelswitheight3.5-inchharddiskdrivebays”onpage33

•“Componentsofservermodelswith123.5-inchharddiskdrivebays”onpage34

•“Componentsofservermodelswith2.5-inchharddiskdrivebays”onpage35

Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.

32ThinkServerRD430UserGuide

Componentsofservermodelswitheight3.5-inchharddiskdrivebays

Figure20.Componentsofservermodelswitheight3.5-inchharddiskdrivebays

1Coolingshroud
2Powersupplycoolingshroud
3Risercardassembly214Frontpanelboard
4Oneortwohot-swapredundantpowersupplies

12Pull-outinformationcard
13Rackhandle(left)

15Backplaneforservermodelswitheight3.5-inchharddisk

drivebays

5PCIExpresscard(s)(availableinsomemodels)16Systemfans(4)
6Heatsink(s)withmicroprocessor(s)underneath17CPU1DIMMs(varybymodel)
7Slimopticaldrive(availableinsomemodels)18CPU2DIMMs(varybymodel)
8Rackhandle(right)19Systemboard

93.5-inchharddiskdrivearea
10Diagnosticmodule(variesbymodel)21PCIExpresscard(s)(availableinsomemodels)
11VGADB-15connector

20Systemboardbattery

22Risercardassembly1

Chapter3.Productoverview33

Componentsofservermodelswith123.5-inchharddiskdrivebays

Figure21.Componentsofservermodelswith123.5-inchharddiskdrivebays

1Coolingshroud

10Backplaneforservermodelswith123.5-inchharddisk

drivebays

2Powersupplycoolingshroud
3Risercardassembly2
4Oneortwohot-swapredundantpowersupplies13CPU2DIMMs(varybymodel)
5PCIExpresscard(s)(availableinsomemodels)14Systemboard
6Heatsink(s)withmicroprocessor(s)underneath15Systemboardbattery
7Rackhandle(right)withfrontcontrolsandLEDs

83.5-inchharddiskdrivearea17RAIDcard
9Rackhandle(left)withfrontUSBconnectors

11Systemfans(4)
12CPU1DIMMs(varybymodel)

16Expandercard

18Risercardassembly1

34ThinkServerRD430UserGuide

Componentsofservermodelswith2.5-inchharddiskdrivebays

Figure22.Componentsofservermodelswith2.5-inchharddiskdrivebays

1Coolingshroud13Slimopticaldrive(availableinsomemodels)
2Powersupplycoolingshroud
3Risercardassembly2
4Oneortwohot-swapredundantpowersupplies
5PCIExpresscard(s)(availableinsomemodels)17Systemfans(4)
6Heatsink(s)withmicroprocessor(s)underneath18CPU1DIMMs(varybymodel)
7Backplane(s)forservermodelswith2.5-inch

14Diagnosticmodule(variesbymodel)
15Rackhandle(left)
16Frontpanelboard

19CPU2DIMMs(varybymodel)

harddiskdrivebays

8Rackhandle(right)20Systemboard

92.5-inchharddiskdrivearea(rightcage)21Systemboardbattery

102.5-inchharddiskdrivearea(middlecage)22PCIExpresscard(s)(availableinsomemodels)
11Pull-outinformationcard
12VGADB-15connector

23Risercardassembly1

Chapter3.Productoverview35

Hot-swapharddiskdrivestatusLEDs

Eachhot-swapharddiskdrivehastwostatusLEDsonthefront.

Figure23.3.5-inchhot-swapharddiskdrivestatusLEDs

Figure24.2.5-inchhot-swapharddiskdrivestatusLEDs

1HarddiskdriveactivityLED2HarddiskdriveRAIDstatusLEDDescription

OffOff

On,greenOff

Blinking,green

On,greenBlinkingrapidly(aboutfourashes

On,greenOn,amber

Blinking,green

Off

persecond),amber

Blinkingslowly(aboutoneashper
second),amber

36ThinkServerRD430UserGuide

Theharddiskdrivehasfailedoris
notpresent.

Theharddiskdriveispresentbutnot
inuse.

Theharddiskdriveisactiveanddata
isbeingtransferred.

TheRAIDcontrollerisidentifyingthe
harddiskdrive.

TheRAIDarrayhasfailedandcannot
berecovered.Youneedtorecreatea
newarray.

Theharddiskdriveisbeingrebuilt.

RAIDcard

ThistopicprovidesinformationtohelpyoulocatetheconnectorsontheRAIDcardifyourserverhasaRAID
cardinstalledinthelongerslotoftherisercardassembly1.

SomeservermodelscomewithaRAIDcardtoprovideadvancedSATA/SAShardwareRAIDfunctions.You
alsocanpurchaseasupportedRAIDcardfromLenovoandinstallitintotheserver.See“Installingor
removingtheRAIDcard”onpage101.

Notes:

•TheoptionkitforaRAIDcardisdesignedfordifferenttypesofserversandmightcontainadditional
cablesthatarenotrequiredforyourserver.

•TheservermusthaveaRAIDcardandanexpandercardinstalledtosupportmorethaneighthard
diskdrives.

YourserversupportsthefollowingRAIDcards:

•ThinkServerRAID500Adapter(alsoknownasThinkServer9240-8iRAID0/1Adapter)

•ThinkServerRAID700Adapter(alsoknownasThinkServer9260-8iSASRAIDAdapter)

ThinkServerRAID500Adapter(alsoknownasThinkServer9240-8iRAID0/1Adapter)

ThefollowingillustrationshowstheconnectorsontheThinkServerRAID500Adapter.

Figure25.ThinkServerRAID500Adapter

1Port03RAID5keyconnector
2Port1

1Port0

Usedtoconnectamini-SASsignalcable.See“Mini-SAStomini-SASsignalcableconnections”onpage43

2Port1

Usedtoconnectamini-SASsignalcable.See“Mini-SAStomini-SASsignalcableconnections”onpage43.

3RAID5keyconnector

UsedtoconnectaThinkServerRAID500UpgradeKeyforAdvancedRAID.See“Installingorremovingthe
ThinkServerRAID500UpgradeKeyforAdvancedRAID”onpage105

.

Chapter3.Productoverview37

.

ThinkServerRAID700Adapter(alsoknownasThinkServer9260-8iSASRAIDAdapter)

ThefollowingillustrationshowstheconnectorsontheThinkServerRAID700Adapter.

Figure26.ThinkServerRAID700Adapter

1Ports7-43Board-to-boardconnector
2Ports3-0

1Ports7-4

Usedtoconnectamini-SASsignalcable.See“Mini-SAStomini-SASsignalcableconnections”onpage43.

2Ports3-0

Usedtoconnectamini-SASsignalcable.See“Mini-SAStomini-SASsignalcableconnections”onpage43

3Board-to-boardconnector

UsedtoconnectaThinkServerRAID700Battery.See“InstallingorremovingtheThinkServerRAID700
Battery”onpage107.

Expandercard

Thistopicprovidesinformationtohelpyoulocatetheconnectorsontheexpandercardifyourserverhas
oneinstalledintheshorterslotoftherisercardassembly1.

TheexpandercardworkstogetherwiththeRAIDcardbyexpandingtheportsontheRAIDcardsothat
theservercansupportupto16harddiskdrives.

Note:TheservermusthaveaRAIDcardandanexpandercardinstalledtosupportmorethaneighthard
diskdrives.

.

38ThinkServerRD430UserGuide

Thefollowingillustrationshowstheconnectorsontheexpandercard.Eachconnectorontheexpander
cardisusedtoconnectamini-SAStomini-SASsignalcable.Fordetailedinformation,see“Mini-SASto
mini-SASsignalcableconnections”onpage43.

Figure27.Expandercard

1Connector14Connector4
2Connector25Connector5
3Connector36Connector6

Hot-swapharddiskdrivebackplane

Yourservercomeswithoneofthefollowinghot-swapharddiskdrivebayandbackplanecongurations:

•Eight3.5-inchharddiskdrivebaysandonebackplane

•123.5-inchharddiskdrivebaysandonebackplane

•Eight2.5-inchharddiskdrivebaysandonebackplane

•162.5-inchharddiskdrivebaysandtwobackplanes

Tolocatethebackplane(s),see“Servercomponents”onpage32

Backplaneforservermodelswitheight3.5-inchharddiskdrivebays

Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplaneforservermodels
witheight3.5-inchharddiskdrivebays.

.

Chapter3.Productoverview39

Thefollowingillustrationsshowtheconnectorsonthebackplaneforservermodelswitheight3.5-inchhard
diskdrivebays.

Figure28.Frontviewofthebackplaneforservermodelswitheight3.5-inchharddiskdrivebays

1Slot0fora3.5-inchharddiskdrive5Slot7fora3.5-inchharddiskdrive
2Slot2fora3.5-inchharddiskdrive6Slot5fora3.5-inchharddiskdrive
3Slot4fora3.5-inchharddiskdrive7Slot3fora3.5-inchharddiskdrive
4Slot6fora3.5-inchharddiskdrive8Slot1fora3.5-inchharddiskdrive

Figure29.Rearviewofthebackplaneforservermodelswitheight3.5-inchharddiskdrivebays

18-pinpowerconnector
28-pinpowerconnector
3Opticaldrivepowerconnector

128-pinpowerconnector

4Mini-SASports4-7
5Mini-SASports0-3

Usedtoconnectapowercabletoprovidepowertothebackplane.

3Opticaldrivepowerconnector

Usedtoconnectthepowercablefortheslimopticaldriveiftheserverhasoneinstalled.

4Mini-SASports4-7

Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive4toharddiskdrive7.

5Mini-SASports0-3

Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive0toharddiskdrive3.

40ThinkServerRD430UserGuide

Backplaneforservermodelswith123.5-inchharddiskdrivebays

Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplaneforservermodels
with123.5-inchharddiskdrivebays.

Thefollowingillustrationsshowtheconnectorsonthebackplaneforservermodelswith123.5-inchhard
diskdrivebays.

Figure30.Frontviewofthebackplaneforservermodelswith123.5-inchharddiskdrivebays

1Slot0fora3.5-inchharddiskdrive7Slot6fora3.5-inchharddiskdrive
2Slot1fora3.5-inchharddiskdrive8Slot7fora3.5-inchharddiskdrive
3Slot2fora3.5-inchharddiskdrive9Slot8fora3.5-inchharddiskdrive
4Slot3fora3.5-inchharddiskdrive10Slot9fora3.5-inchharddiskdrive
5Slot4fora3.5-inchharddiskdrive11Slot10fora3.5-inchharddiskdrive
6Slot5fora3.5-inchharddiskdrive12Slot11fora3.5-inchharddiskdrive

Figure31.Rearviewofthebackplaneforservermodelswith123.5-inchharddiskdrivebays

1Signalcableconnector5Signalcableconnector
2Mini-SASports8-11
3Mini-SASports4-7
4Mini-SASports0-3

1Signalcableconnector

68-pinpowerconnector
78-pinpowerconnector

UsedtoconnectthesignalcableforthefrontcontrolsandLEDsontherightrackhandle.

2Mini-SASports8-11

Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive8toharddiskdrive11.

Chapter3.Productoverview41

3Mini-SASports4-7

Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive4toharddiskdrive7.

4Mini-SASports0-3

Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive0toharddiskdrive3.

5Signalcableconnector

UsedtoconnectthesignalcableforthefrontUSBconnectorsontheleftrackhandle.

678-pinpowerconnector

Usedtoconnectapowercabletoprovidepowertothebackplane.

Backplaneforservermodelswith2.5-inchharddiskdrivebays

Thistopicprovidesinformationtohelpyoulocatetheconnectorsonthebackplaneforservermodelswith

2.5-inchharddiskdrivebays.

Thefollowingillustrationsshowtheconnectorsonthebackplaneforservermodelswith2.5-inchhard
diskdrivebays.

Figure32.Frontviewofthebackplaneforservermodelswith2.5-inchharddiskdrivebays

1Slot0fora2.5-inchharddiskdriveorsolid-state

drive

2Slot1fora2.5-inchharddiskdriveorsolid-state

drive

3Slot2fora2.5-inchharddiskdriveorsolid-state

drive

4Slot3fora2.5-inchharddiskdriveorsolid-state

drive

5Slot4fora2.5-inchharddiskdriveorsolid-statedrive

6Slot5fora2.5-inchharddiskdriveorsolid-statedrive

7Slot6fora2.5-inchharddiskdriveorsolid-statedrive

8Slot7fora2.5-inchharddiskdriveorsolid-statedrive

42ThinkServerRD430UserGuide

Figure33.Rearviewofthebackplaneforservermodelswith2.5-inchharddiskdrivebays

18-pinpowerconnector
2Mini-SASports4-74Opticaldrivepowerconnector

18-pinpowerconnector

3Mini-SASports0-3

Usedtoconnectapowercabletoprovidepowertothebackplane.

2Mini-SASports4-7

Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupport
theharddiskdrive4toharddiskdrive7;ortosupporttheharddiskdrive12toharddiskdrive15ifthe
backplaneisforharddiskdrivesintherightcageoftheserver.

3Mini-SASports0-3

Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive0toharddiskdrive3;ortosupporttheharddiskdrive8toharddiskdrive11ifthebackplane
isforharddiskdrivesintherightcageoftheserver.

4Opticaldrivepowerconnector

Usedtoconnectthepowercablefortheslimopticaldriveiftheserverhasoneinstalled.

Mini-SAStomini-SASsignalcableconnections

Thistopicprovidesinstructionsonhowtoconnectthemini-SAStomini-SASsignalcables.Thistopic
containsthefollowingitems:

•“ConnectingcablesfromtheRAIDcardtothebackplane”onpage43

•“ConnectingcablesfromtheRAIDcardtotheexpandercard,andthenfromtheexpandercardto
thebackplane(s)”onpage44

•“Connectingcablesfromthesystemboardtothebackplane”onpage47

ConnectingcablesfromtheRAIDcardtothebackplane

IfyourserverhasasupportedRAIDcardinstalled,youcanconnectcablesfromtheRAIDcardtothe
backplanetosupportuptoeightharddiskdrivesandadvancedhardwareRAIDfunctions.

Chapter3.Productoverview43

Note:TheoptionkitforaRAIDcardisdesignedfordifferenttypesofserversandmightcontainadditional
cablesthatarenotrequiredforyourserver.

ToconnectcablesfromtheRAIDcardtothebackplane,dooneofthefollowingdependingonthetypeof
yourRAIDcard:

•IfyouareusingaThinkServerRAID500Adapter,dothefollowing:

1.Usethemini-SAStomini-SASsignalcable.Connectthemini-SASconnector1totheport0onthe
RAIDcard.Then,connectthemini-SASconnector

2tothemini-SASports0-3onthebackplane.

2.Ifyourserverhasmorethanfourharddiskdrivesinstalled,usetheothermini-SAStomini-SAS
signalcable.Connectthemini-SASconnector

3totheport1ontheRAIDcard.Then,connectthe

mini-SASconnector4tothemini-SASports4-7onthebackplane.

•IfyouareusingaThinkServerRAID700Adapter,dothefollowing:

1.Useonemini-SAStomini-SASsignalcable.Connectthemini-SASconnector3totheports3-0on
theRAIDcard.Then,connectthemini-SASconnector4tothemini-SASports0-3onthebackplane.

2.Ifyourserverhasmorethanfourharddiskdrivesinstalled,usetheothermini-SAStomini-SASsignal
cable.Connectthemini-SASconnector1totheports7-4ontheRAIDcard.Then,connectthe
mini-SASconnector2tothemini-SASports4-7onthebackplane.

Figure34.ConnectingcablesfromtheRAIDcardtothebackplane

Refertothefollowingtopicsforinformationabouttheconnectorlocationsandthepowercableconnections:

•“Hot-swapharddiskdrivebackplane”onpage39

•“RAIDcard”onpage37

•“Systemboardcomponents”onpage48

ConnectingcablesfromtheRAIDcardtotheexpandercard,andthenfromthe
expandercardtothebackplane(s)

Tosupportmorethaneightandupto123.5-inchharddiskdrivesorupto162.5-inchharddiskdrives,your
servermusthaveasupportedRAIDcardandanexpandercardinstalled.Youneedtoconnectcablesfrom
theRAIDcardtotheexpandercard,andthenfromtheexpandercardtothebackplane(s).

UsethefollowinginstructionstoconnectcablesfromtheRAIDcardtotheexpandercardrst:

•IfyouareusingaThinkServerRAID500Adapter,dothefollowing:

1.Useamini-SAStomini-SASsignalcableandconnectthemini-SASconnectorononeendofthe
cabletotheport0ontheThinkServerRAID500Adapter.Then,connectthemini-SASconnectoron
theotherendofthecabletotheconnector1ontheexpandercard.

44ThinkServerRD430UserGuide

2.Useanothermini-SAStomini-SASsignalcableandconnectthemini-SASconnectorononeendof
thecabletotheport1ontheThinkServerRAID500Adapter.Then,connectthemini-SASconnector
ontheotherendofthecabletotheconnector2ontheexpandercard.

•IfyouareusingaThinkServerRAID700Adapter,dothefollowing:

1.Useamini-SAStomini-SASsignalcableandconnectthemini-SASconnectorononeendofthe
cabletotheports3-0ontheThinkServerRAID700Adapter.Then,connectthemini-SASconnector
ontheotherendofthecabletotheconnector1ontheexpandercard.

2.Useanothermini-SAStomini-SASsignalcableandconnectthemini-SASconnectorononeend
ofthecabletotheports7-4ontheThinkServerRAID700Adapter.Then,connectthemini-SAS
connectorontheotherendofthecabletotheconnector2ontheexpandercard.

RefertothefollowingtopicsforinformationabouttheconnectorlocationsontheRAIDcardandexpander
card:

•“RAIDcard”onpage37

•“Expandercard”onpage38

Chapter3.Productoverview45

Usethefollowinginstructionstoconnectcablesfromtheexpandercardtothebackplanesfor2.5-inch
harddiskdrives:

1.Forharddiskdrive0toharddiskdrive3,useamini-SAStomini-SASsignalcableandconnectthe
mini-SASconnector1ononeendofthecabletotheconnector3ontheexpandercard.Then,connect
themini-SASconnectorontheotherendofthecabletothemini-SASports0-3onthebackplane
for2.5-inchharddiskdrivesinthemiddlecage.

2.Forharddiskdrive4toharddiskdrive7,useamini-SAStomini-SASsignalcableandconnectthe
mini-SASconnector2ononeendofthecabletotheconnector4ontheexpandercard.Then,connect
themini-SASconnectorontheotherendofthecabletothemini-SASports4-7onthebackplane
for2.5-inchharddiskdrivesinthemiddlecage.

3.Forharddiskdrive8toharddiskdrive11,useamini-SAStomini-SASsignalcableandconnectthe
mini-SASconnector

3ononeendofthecabletotheconnector5ontheexpandercard.Then,connect

themini-SASconnectorontheotherendofthecabletothemini-SASports0-3onthebackplane
for2.5-inchharddiskdrivesintherightcage.

4.Ifyourserverhasmorethan12harddiskdrivesinstalled,forharddiskdrive12toharddiskdrive15,
useamini-SAStomini-SASsignalcableandconnectthemini-SASconnector4ononeendofthe
cabletotheconnector6ontheexpandercard.Then,connectthemini-SASconnectorontheotherend
ofthecabletothemini-SASports4-7onthebackplanefor2.5-inchharddiskdrivesintherightcage.

Figure35.Connectingcablesfromtheexpandercardtothebackplanesfor2.5-inchharddiskdrives

Refertothefollowingtopicsforinformationabouttheconnectorlocationsandthepowercableconnections:

•“Hot-swapharddiskdrivebackplane”onpage39

•“Expandercard”onpage38

•“Systemboardcomponents”onpage48

46ThinkServerRD430UserGuide

Usethefollowinginstructionstoconnectcablesfromtheexpandercardtothebackplanefor123.5-inch
harddiskdrives:

1.Forharddiskdrive0toharddiskdrive3,useamini-SAStomini-SASsignalcableandconnectthe
mini-SASconnector1ononeendofthecabletotheconnector3ontheexpandercard.Then,connect
themini-SASconnectorontheotherendofthecabletothemini-SASports0-3onthebackplanefor

123.5-inchharddiskdrives.

2.Forharddiskdrive4toharddiskdrive7,useamini-SAStomini-SASsignalcableandconnectthe
mini-SASconnector2ononeendofthecabletotheconnector4ontheexpandercard.Then,connect
themini-SASconnectorontheotherendofthecabletothemini-SASports4-7onthebackplanefor

123.5-inchharddiskdrives.

3.Forharddiskdrive8toharddiskdrive11,useamini-SAStomini-SASsignalcableandconnectthe
mini-SASconnector

3ononeendofthecabletotheconnector5ontheexpandercard.Then,connect

themini-SASconnectorontheotherendofthecabletothemini-SASports8-11onthebackplanefor

123.5-inchharddiskdrives.

Figure36.Connectingcablesfromtheexpandercardtothebackplanefor123.5-inchharddiskdrives

Refertothefollowingtopicsforinformationabouttheconnectorlocationsandthepowercableconnections:

•“Hot-swapharddiskdrivebackplane”onpage39

•“Expandercard”onpage38

•“Systemboardcomponents”onpage48

Connectingcablesfromthesystemboardtothebackplane

YourserverhastwoSASconnectorsonthesystemboardtosupportuptoeightharddiskdrives.

Ifyouconnectthemini-SAStomini-SASsignalcablesfromthesystemboardtothebackplane,youcan
congureRAIDfortheharddiskdrivesusingthefunctionsoftheThinkServerRAID300(alsoknownasthe
onboardSASsoftwareRAID).

Usethefollowinginstructionstoconnectcablesfromthesystemboardtothebackplane:

1.Forharddiskdrive0toharddiskdrive3,useamini-SAStomini-SASsignalcableandconnectthe
mini-SASconnectorononeendofthecabletotheSASconnector0-3onthesystemboard.Then,

Chapter3.Productoverview47

connectthemini-SASconnectorontheotherendofthecabletothemini-SASports0-3onthe
backplane.

2.Ifyourserverhasmorethanfourharddiskdrivesinstalled,forharddiskdrive4toharddiskdrive7,use
anothermini-SAStomini-SASsignalcableandconnectthemini-SASconnectorononeendofthe
cabletotheSASconnector4-7onthesystemboard.Then,connectthemini-SASconnectoronthe
otherendofthecabletothemini-SASports4-7onthebackplane.

Refertothefollowingtopicsforinformationabouttheconnectorlocationsandthepowercableconnections:

•“Hot-swapharddiskdrivebackplane”onpage39

•“Systemboardcomponents”onpage48

Systemboardcomponents

Thefollowingillustrationshowsthecomponentlocationsonthesystemboard.

Figure37.Systemboardcomponents

1Frontpanelconnector
2InternalUSBconnector1
3InternalUSBconnector2
4Diagnosticmoduleconnector19Redundantpowersupplyconnector1
5FrontVGAconnector
6SATAconnector0

16ThinkServerManagementModule
17Risercardassembly1slot
18Risercardassembly2slot

20Redundantpowersupplyconnector2
21Backplanepowerconnector1

48ThinkServerRD430UserGuide

7SASconnector4-7
8SASconnector0-3
9Systemboardbattery24Systemfan5connector
10PlatformControllerHub(PCH)25Memoryslots(6)
11InternalUSBTypeAconnector226Systemfan4connector
12TMMPremiumconnector27Microprocessorsocket1
13InternalUSBTypeAconnector128Systemfan2connector
14TPMconnector
15iButtonsocket

1Frontpanelconnector

22Backplanepowerconnector2
23Microprocessorsocket2

29Memoryslots(6)
30Systemfan1connector

Usedtoconnectthefrontpanelcableifyourserverhasafrontpanelboardinstalled.

2InternalUSBconnector1

UsedtoconnectthefrontpanelUSBcableifyourserverhasafrontpanelboardinstalled.

3InternalUSBconnector2

Reservedforthemanufacturer.

4Diagnosticmoduleconnector

Usedtoconnectthecableofthediagnosticmoduleifyourserverhasadiagnosticmoduleinstalled.

5FrontVGAconnector

UsedtoconnectthecableoftheVGADB-15connectoronthefrontpanelofsomeservermodels.

6SA TAconnector0

Usedtoconnectthesignalcableoftheslimopticaldriveifyourserverhasaslimopticaldriveinstalled.

7SASconnector4-7

Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive4toharddiskdrive7.

8SASconnector0-3

Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive0toharddiskdrive3.

9Systemboardbattery

Yourserverhasaspecialtypeofmemorythatmaintainsthedate,time,andcongurationinformationfor
built-infeatures.Thesystemboardbatterykeepstheinformationactivewhenyouturnofftheserver.

Chapter3.Productoverview49

10PlatformControllerHub(PCH)

Thischipsupportsandprovidesmanyfeatures.ItservesasaPCH,whichprovidesthedatabufferingand
interfacearbitrationrequiredtoensurethatsysteminterfacesoperateefcientlyandprovidesthebandwidth
necessaryforthesystemtoachievepeakperformance.

11InternalUSBTypeAconnector2

13InternalUSBTypeAconnector1

UsedtoconnectadevicethatusesaUSBTypeAconnector.Forexample,insomesituations,youmight
wanttoconnectaUSBkeydirectlytothesystemboard.Inthiscase,youcanconnectittoaninternal
USBTypeAconnector.

12TMMPremiumconnector

UsedtoconnectaserveroptionnamedasThinkServerManagementModulePremium(TMMPremium)to
enableadvancedremotemanagementfunctionsonyourserver.See“InstallingorremovingtheThinkServer
ManagementModulePremium”onpage123.

14TPMconnector

UsedtoconnectaTPM,whichisasecuritychip,toenhanceserversecurity.See“Installingorremovingthe
ThinkServerTrustedPlatformModule”onpage126.

15iButtonsocket

YourserversupportsThinkServerRAID300,whichincludesonboardSASsoftwareRAIDlevels0,1,and10.
YoualsocanactivateonboardSASsoftwareRAID5byinstallingaThinkServerRAID300UpgradeKeyfor
AdvancedRAIDintheiButtonsocket.Formoreinformation,see“InstallingorremovingtheThinkServer
RAID300UpgradeKeyforAdvancedRAID”onpage119.

16ThinkServerManagementModule

WiththeintegratedThinkServerManagementModule(alsoknownastheBMCchip),nomatterwhat
conditiontheserveroperatingsystemisinandnomatteriftheserverisonoroff,aslongastheserver
isconnectedtonetworkandanacpowersource,theinteractionwiththeTMMcontrolledserverscanbe
achievedthroughsystemnetwork.TheusercanobtaintheserverhardwarehealthinformationandSEL,
andisabletoconducttheoperationsincludingturningonorofftheserver,restartingtheserver,andso
on.Thispartoftheservermanagementisindependentoftheoperatingsystemandiscalledout-of-band
management.

17Risercardassembly1slot

Usedtoinstalltherisercardassembly1.

18Risercardassembly2slot

Usedtoinstalltherisercardassembly2.

19Redundantpowersupplyconnector1

20Redundantpowersupplyconnector2

Usedtoconnectahot-swapredundantpowersupply.

50ThinkServerRD430UserGuide

21Backplanepowerconnector1

22Backplanepowerconnector2

Usedtoconnectthepowercable(s)fromthebackplane.

24262830Systemfanconnectors

Therearefourhot-swapsystemfansandtwodummysystemfansinstalledinthesystemfancageinyour
server.Eachsystemfanconnectorisusedtoconnectacorrespondinghot-swapsystemfan.

23Microprocessorsocket2

27Microprocessorsocket1

Iftheserverhastwomicroprocessors,eachofthemicroprocessorissecuredinthemicroprocessorsocket
onthesystemboardandaheatsinkisinstalledabovethemicroprocessortoprovidecooling.Iftheserver
hasonlyonemicroprocessor,themicroprocessorsocket2isprotectedbyamicroprocessorsocketcover.

2529Memoryslots

Thereare12memoryslotsonthesystemboard.Fordetailedinformation,see“Memorymoduleinstallation
rules”onpage95.

Systemboardjumpersandswitches

Thistopicprovidesinformationaboutthejumpersandswitchesonthesystemboard.

Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.

Ajumperisashortlengthofconductorusedtosetuporadjustaprintedcircuitboard,suchasthesystem
boardofacomputer.Ajumperusuallyisencasedinanon-conductiveblockofplasticforconvenientuse
andtoavoidanypossibledamagetoalivecircuit.Jumperpinsarrangedingroupsonthesystemboardare
calledjumperblocks.Whentwoormorejumperpinsarecappedwithajumper,anelectricalconnectionis
madebetweenthemandtheequipmentisthusinstructedtoactivatecertainsettingsaccordingly.

Thefollowingillustrationshowsajumperinthedefaultsettingposition(pin1andpin2).Thisisthecorrect
positionfornormaloperation.

Figure38.Defaultjumpersetting

Chapter3.Productoverview51

Thefollowingillustrationshowsthestatusofthejumpersandswitchesonthesystemboardofyourserver.
Youcancongure,recover,enable,ordisablesomespecicfeaturesofthesystemboardbysettingthe
jumpersandswitches.

Figure39.Systemboardjumpersandswitches

1ClearCMOS(ComplementaryMetalOxideSemiconductor)jumper
2TMMEnable/Disablejumper(alsoknownasBMCEnable/Disablejumper)
3Systemboardswitches

Attention:Tosetthejumpersorswitches,youneedtoremovetheservercoverandgainaccesstothe
systemboard.Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safety
information”onpageiii

1ClearCMOSjumper

and“Guidelines”onpage81.

UsedtoclearCMOSandturntheBIOSsettingsintothefactorydefaultsettings.

Note:ClearingCMOSdoesnoteraseyourBIOSpasswords.

ToclearCMOS,dothefollowing:

1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.

52ThinkServerRD430UserGuide

2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.

3.Removetheservercover.See“Removingtheservercover”onpage83.

4.Ifnecessary,removethecoolingshroud.See“Removingandreinstallingthecoolingshroud”onpage

91.

5.LocatetheClearCMOSjumperonthesystemboard.Then,removeanypartsanddisconnectany
cablesthatmightimpedeyouraccesstothejumper.

6.MovetheClearCMOSjumperfromthedefaultnormalposition(pin1andpin2)totheshort-circuited
position(pin2andpin3).

7.Waitmorethan10secondsandthenmovetheClearCMOSjumperbacktothenormalposition(pin1
andpin2).

8.Reinstallanypartsandreconnectanycables.Then,reinstalltheservercover.See“Completingthe
partsreplacement”onpage174

.

9.Connecttheservertoanacpowersourceandwaitabout30seconds.Then,turnontheserver.The
BIOSsettingsturntothefactorydefaultsettings.

2TMMEnable/Disablejumper(alsoknownasBMCEnable/Disablejumper)

WhentheTMMEnable/Disablejumperisinthedefaultnormalposition(pin1andpin2),theserverneeds
about30secondsfortheTMMtoinitializewheneveryouconnecttheservertoanacpowersource.Ifyou
pressthepowerswitchonthefrontofthechassisduringthisperiod,theserverwillnotstartimmediately;it
willstartaftertheTMMinitializationnishes.

IfyoumovetheTMMEnable/Disablejumpertopin2andpin3,theTMMfunctionisnotavailableandthe
serverwillbedirectlyturnedonwhenyoupressthepowerswitchwithoutwaitingfortheTMMtobeready.

Chapter3.Productoverview53

3Systemboardswitches

Therearefourswitchesonthesystemboardofyourserver.

Figure40.Systemboardswitches

1BIOSrecoveryswitch3ManagementEngine(ME)inforceupdateswitch
2Clearpasswordswitch

1BIOSrecoveryswitch

4Reservedforthemanufacturer

UsedtorecovertheBIOSifthepowertoyourserverisinterruptedwhiletheBIOSisbeingupdatedandyour
servercannotstartcorrectly.

TorecovertheBIOS,see“RecoveringfromaBIOSupdatefailure”onpage66

2Clearpasswordswitch

.

Usedtoeraseforgottenpasswords,suchastheBIOSpasswords.

Toclearpasswords,dothefollowing:

54ThinkServerRD430UserGuide

1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.

2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.

3.Removetheservercover.See“Removingtheservercover”onpage83.

4.LocatetheClearpasswordswitchonthesystemboard.Then,removeanypartsanddisconnectany
cablesthatmightimpedeyouraccesstotheswitch.

5.MovetheClearpasswordswitchfromthedefaultoffpositiontotheonposition.

6.WaitmorethanvesecondsandthenmovetheClearpasswordswitchbacktotheoffposition.

7.Reinstallanypartsandreconnectanycables.Then,reinstalltheservercover.See“Completingthe
partsreplacement”onpage174

8.Connecttheservertoanacpowersourceandwaitabout30seconds.Then,turnontheserver.The
BIOSpasswordsareerased,includingtheadministratorpasswordanduserpassword.

9.Tosetnewpasswords,see“Usingpasswords”onpage63.

3MEinforceupdateswitch

Usedtoupdate(ash)theME.

TheMEupdatingprocessusuallyiscontainedintheBIOSupdating(ashing)process.

Note:OnlysomeBIOSversionscontaintheparametersforupdatingtheME.IfyouwanttoupdatetheME,
ensurethatyourBIOSversioncontainstherequiredparameters.

.

ToupdatetheME,dothefollowing:

1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.

2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.

3.Removetheservercover.See“Removingtheservercover”onpage83.

4.LocatetheMEinforceupdateswitchonthesystemboard.Then,removeanypartsanddisconnectany
cablesthatmightimpedeyouraccesstotheswitch.

5.MovetheMEinforceupdateswitchfromthedefaultoffpositiontotheonposition.

6.Reinstallanypartsandreconnectanycables.Then,reinstalltheservercover.See“Completingthe
partsreplacement”onpage174.

7.Connecttheservertoanacpowersource.Then,updatetheBIOS.See“Updating(ashing)theBIOS”
onpage66

8.Repeatstep1throughstep4.

9.MovetheMEinforceupdateswitchbacktotheoffposition.

10.Reinstallanypartsandreconnectanycables.Then,reinstalltheservercover.See“Completingthe
partsreplacement”onpage174

11.Connecttheservertoanacpowersourceandturnontheserver.TheBIOSandMEhavebeen
updated.YouneedtocheckandconguretheBIOSsettingsforyourspecicneeds.See“Using
theSetupUtilityprogram”onpage59.

.

.

SystemboardLEDs

ThistopichelpsyoutolocatetheLEDsonthesystemboard.

Chapter3.Productoverview55

Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.

TheserverisdesignedsothatLEDsremainlitwhentheserverisconnectedtoanacpowersourcebutis
notturnedon,providedthatthepowersupplyisoperatingcorrectly.Thishelpsyoutoisolateproblems
whentheserverisnotturnedon.ManyerrorsarerstindicatedbyaliterrorLEDonthediagnosticpanelof
someservermodels.IfanLEDislit,oneormoreLEDselsewhereintheservermightalsobelittodirect
youtothesourceoftheerror.

ThefollowingillustrationshowstheTMMstatusLEDandsystemfanerrorLEDsonthesystemboard.

Figure41.SystemboardLEDs

1TMMstatusLED(alsoknownasBMCstatusLED)

ThisLEDindicatesthestatusoftheonboardThinkServerManagementModule(TMM,alsoknownasBMC).

TMMstatusLED

OnGreen
Off

Blinking

2-5SystemfanerrorLEDs

Color

TheTMMisnotready.

None

Green

TheTMMhasnopowerorhasfailed.
TheTMMisworking.

Description

WhenasystemfanerrorLEDonthesystemboardislit,itindicatesthatthecorrespondingsystemfanis
operatingslowlyorhasfailed.T osolvetheproblem,youmightneedtoreinstallorreplacethesystemfan.
See“Replacingasystemfan”onpage170

.Ifitisasystemboardproblem,contacttheLenovoCustomer

SupportCenter.

56ThinkServerRD430UserGuide

Chapter4.Turningonandturningofftheserver

Thischapterprovidesinformationaboutturningonandturningofftheserver.

Turningontheserver

Theservercanbeturnedoninoneofthefollowingways:

•Afteryounishunpackingandsettinguptheserver,connectittoanacpowersource.Pressthepower
switchonthefrontofthechassistoturnontheserver.Theserverneedsabout30secondsforthe
ThinkServerManagementModule(TMM,alsoknownasBMC)toinitializewheneveryouconnectthe
servertoanacpowersource.Ifyoupressthepowerswitchduringthisperiod,theserverwillnotstart
immediately;itwillstartaftertheTMMinitializationnishes.

•WhentheWakeonLANfeatureisenabledontheserverthatisconnectedtoanacpowersourceanda
LAN,anetworkadministratorcanremotelyturnonorwakeuptheserverfromamanagementconsole
usingremotenetworkmanagementsoftware.

•YoualsocanusetherelatedTMMfeaturetoremotelyturnontheserverthroughthemanagementLAN.
FormoreinformationabouttheTMM,refertotheThinkServerManagementModuleUserGuide,whichis
availablefordownloadat:
http://www.lenovo.com/ThinkServerUserGuides

Turningofftheserver

CAUTION:
Thepowercontrolbuttononthedeviceandthepowerswitchonthepowersupplydonotturnoff
theelectricalcurrentsuppliedtothedevice.Thedevicealsomighthavemorethanonepower
cord.Toremoveallelectricalcurrentfromthedevice,ensurethatallpowercordsaredisconnected
fromthepowersource.

Theservercanbeturnedoffinoneofthefollowingways:

•Turnofftheserverfromtheoperatingsystemifyouroperatingsystemsupportsthisfeature.Afteran
orderlyshutdownoftheoperatingsystem,theserverwillturnoffautomatically.Forinstructionsonhow
toshutdownyourspecicoperatingsystem,refertotherelateddocumentationorhelpsystemfor
theoperatingsystem.

•Pressthepowerswitchonthefrontofthechassistostartanorderlyshutdownoftheoperatingsystem
andturnofftheserver,ifyouroperatingsystemsupportsthisfeature.

•Ifyourserverstopsrespondingandyoucannotturnitoff,pressandholdthepowerswitchonthefront
ofthechassisforfoursecondsormore.Ifyoustillcannotturnofftheserver,disconnectallpower
cordsfromtheserver.

•IftheserverisconnectedtoaLAN,anetworkadministratorcanremotelyturnofftheserverfroma
managementconsoleusingremotenetworkmanagementsoftware.

•YoualsocanusetherelatedTMMfeaturetoremotelyturnofftheserverthroughthemanagementLAN.
FormoreinformationabouttheTMM,refertotheThinkServerManagementModuleUserGuide,whichis
availablefordownloadat:
http://www.lenovo.com/ThinkServerUserGuides

©CopyrightLenovo2012,2013

57

•Theservermightbeturnedoffasanautomaticresponsetoacriticalsystemfailure.

Notes:

•Whenyouturnofftheserverandleaveitconnectedtoanacpowersource,theserveralsocanrespond
toaremoterequesttoturnontheserver.Toremoveallpowerfromtheserver,youmustdisconnect
theserverfromtheacpowersource.

•Forinformationaboutyourspecicoperatingsystem,refertotherelateddocumentationorhelpsystem
fortheoperatingsystem.

58ThinkServerRD430UserGuide

Chapter5.Conguringtheserver

Thischapterprovidesthefollowinginformationtohelpyouconguretheserver:

•“UsingtheSetupUtilityprogram”onpage59

•“UsingtheThinkServerEasyStartupprogram”onpage67

•“ConguringRAID”onpage70

•“ConguringtheEthernetcontrollers”onpage78

•“Updatingthermware”onpage79

•“UsingtheLenovoThinkServerEasyManageprogram”onpage79

UsingtheSetupUtilityprogram

ThistopicprovidesinformationaboutusingtheSetupUtilityprogram.

TheSetupUtilityprogramispartoftheserverrmware.Y oucanusetheSetupUtilityprogramtoviewand
changethecongurationsettingsofyourserver,regardlessofwhichoperatingsystemyouareusing.
However,theoperatingsystemsettingsmightoverrideanysimilarsettingsintheSetupUtilityprogram.

StartingtheSetupUtilityprogram

ThistopicprovidesinstructionsonhowtostarttheSetupUtilityprogram.

TostarttheSetupUtilityprogram,dothefollowing:

1.Connecttheservertoanacpowersourceandpressthepowerswitchonthefrontpaneltoturnonthe
server.See“Turningontheserver”onpage57.

2.PresstheF1keyassoonasyouseethelogoscreen.Then,waitforseveralseconds,andtheSetup
Utilityprogramopens.Ifyouhavesetapassword,youneedtotypethecorrectpasswordtoenterthe
SetupUtilityprogram.Forpasswordinformation,see“Usingpasswords”onpage63.

ViewinginformationintheSetupUtilityprogram

TheSetupUtilityprogrammenulistsvariousitemsaboutthesystemconguration.Selectadesireditem
toviewinformationorchangesettings.

WhenworkingwiththeSetupUtilityprogram,youmustusethekeyboard.Thekeysusedtoperformvarious
tasksaredisplayedontherightbottompaneofeachscreen.Y oualsocanpresstheF1keyforgeneralhelp
aboutthekeys.Formostitems,thecorrespondinghelpmessageisdisplayedontherighttoppaneofthe
screenwhentheitemisselected.Iftheitemhassubmenus,youcandisplaythesubmenusbypressingEnter.

YoucanviewthefollowinginformationaboutyourspecicservermodelintheSetupUtilityprogram:

•TheMainmenulistsinformationabouttheBIOSandTMM(alsoknownasBMC),totalmemorysize,and
systemdateandtime.

•OntheAdvancedmenu:
–SelectProcessorCongurationandfollowtheinstructionsonthescreentoviewinformationabout

theinstalledmicroprocessoranditssupportedtechnologies.

–SelectMemoryCongurationandfollowtheinstructionsonthescreentoviewinformationaboutthe

installedmemorymodules.

©CopyrightLenovo2012,2013

59

–SelectSATA/SASCongurationandfollowtheinstructionsonthescreentoviewinformationabout

theinstalledSATAorSASdevices,suchasaharddiskdriveoranopticaldrive.

•OntheServerManagementmenu,selectSystemInformationtoviewinformationaboutyoursystem.

SetupUtilityprograminterface

ThistopicprovidesgeneralinformationaboutthemenusanditemsintheSetupUtilityprogram.

DependingontheBIOSversionofyourserver,somemenuoriteminformationmightdifferslightlyfrom
theinformationinthistopic.

Notes:

•Thedefaultsettingsalreadyareoptimizedforyou.Usethedefaultvalueforanyitemyouarenotfamiliar
with.Donotchangethevalueofunfamiliaritemstoavoidunexpectedproblems.Ifyouconsider
changingtheserverconguration,proceedwithextremecaution.Settingthecongurationincorrectly
mightcauseunexpectedresults.IfyoucannotturnontheserverbecauseofincorrectBIOSsettings,
usetheClearCMOSjumpertorestoretheBIOSsettingstothefactorydefaultsettings.See“System
boardjumpersandswitches”onpage51

•Ifyouhavechangedanyhardwareintheserver,youmightneedtoreashtheBIOS,theTMMrmware,
andtheFRU/SensorDataRecords(SDR).

TheSetupUtilityprogrammaininterfaceconsistsofthefollowingmenus:

•“Mainmenu”onpage60

•“Advancedmenu”onpage60

•“Securitymenu”onpage61

•“ServerManagementmenu”onpage61

•“BootOptionsmenu”onpage62

•“BootManagermenu”onpage62

•“Save&Exitmenu”onpage62

.

LenovoprovidestheBIOSupdateutilityontheLenovoSupportWebsite.YoucandownloadtheBIOS
updateutilitytoupdatetheBIOSifthenewerBIOSversionspecicallysolvesaproblemyouhave.See
“UpdatingorrecoveringtheBIOS”onpage65.

IfthepowertoyourserverisinterruptedwhiletheBIOSisbeingupdatedandyourservercannotstart
correctly,usetheBIOSrecoveryswitchtorecoverfromaBIOSupdatefailure.See“Systemboardjumpers
andswitches”onpage51.

Mainmenu

AfterenteringtheSetupUtilityprogram,youcanseetheMainmenu,whichlistsbasicinformationabout
theBIOSandBMC,totalmemorysize,andsystemdateandtime.

TosetthesystemdateandtimeontheMainmenu,see“Settingthesystemdateandtime”onpage62

Advancedmenu

YoucanvieworchangevariousservercomponentsettingsontheAdvancedmenuintheSetupUtility
program.TheAdvancedmenucontainsvariouscongurationsubmenusanditems.Oneachsubmenu,
pressEntertoshowselectableoptionsandselectadesiredoptionbyusingtheupanddownarrow
keysortypedesiredvaluesfromthekeyboard.Someitemsaredisplayedonthemenuonlyiftheserver
supportsthecorrespondingfeatures.

60ThinkServerRD430UserGuide

.

Notes:

•Enabledmeansthatthefunctioniscongured.

•Disabledmeansthatthefunctionisnotcongured.

TheAdvancedmenucontainsthefollowingsubmenus.Formoreinformation,enterthecorresponding
submenuandrefertotheinstructionsonthescreen.

•PCIConguration:ViewandsetPCIcongurationparameters.

•ACPIConguration:ViewandsetACPIcongurationparameters.

•ProcessorConguration:Viewinformationabouttheinstalledmicroprocessorsandsetmicroprocessor
congurationparameters.

•MemoryConguration:Viewinformationabouttheinstalledmemorymodulesandsetmemory
congurationparameters.

•ChipsetConguration:Viewandsetchipsetcongurationparameters.

•SA TA/SASConguration:ViewinformationabouttheinstalledSATAorSASdevicesandsetSATAor
SAScongurationparameters.

•IntelTXT(L T -SX)Conguration:ViewandsetTPM,TXT,VT,andVT-dcongurationparameters.

•USBConguration:ViewandsetUSBcongurationparameters,suchasenablingordisablingUSB
devices.

•SuperIOConguration:Viewandsetserialportcongurationparameters.

•SerialPortConsoleRedirection:Viewandsetcongurationparametersfortheserialportconsole
redirection.

•NetworkStack:ViewandsetUEFIIpv4PXEandUEFIIpv6PXEcongurationparameters.

Securitymenu

YoucansetpasswordsandconguretheTPMfunctionontheSecuritymenuintheSetupUtilityprogram.
Foreachmenuitem,pressEntertoshowselectableoptionsandselectadesiredoptionbyusingtheupand
downarrowkeysortypedesiredvaluesfromthekeyboard.Someitemsaredisplayedonthemenuonlyif
theserversupportsthecorrespondingfeatures.

Notes:

•Enabledmeansthatthefunctioniscongured.

•Disabledmeansthatthefunctionisnotcongured.

TheSecuritymenucontainsthefollowingitems:

•AdministratorPassword:Setanadministratorpasswordtoprotectagainstunauthorizedaccessto
yourserver.See“Usingpasswords”onpage63

•UserPassword:Setauserpasswordtoprotectagainstunauthorizedaccesstoyourserver.See“Using
passwords”onpage63.

•TPM/TCM:ConguretheTPMfunctionifyourserverhasaTPMinstalledintheTPMconnectoronthe
systemboard.See“ConguringtheTPMfunction”onpage64

.

.

ServerManagementmenu

YoucanviewsysteminformationandvieworchangeeventlogandBMCsettingsontheServer
ManagementmenuintheSetupUtilityprogram.Oneachsubmenu,pressEntertoviewtheinformationor

showselectableoptionsandselectadesiredoptionbyusingtheupanddownarrowkeys.Someitemsare
displayedonthemenuonlyiftheserversupportsthecorrespondingfeatures.

Chapter5.Conguringtheserver61

TheServerManagementmenucontainsthefollowingsubmenus.Formoreinformation,enterthe
correspondingsubmenuandrefertotheinstructionsonthescreen.

•EraseSEL:Erasesystemeventlog(SEL).

•SystemInformation:Viewbasicinformationaboutyourserver.

•BMCNetworkConguration:SetBMCcongurationparameters.

BootOptionsmenu

TheBootOptionsmenuintheSetupUtilityprogramprovidesaninterfacetohelpyouvieworchangethe
serverstartupoptions,includingthestartupsequenceandbootpriorityforvariousdevices.Changesinthe
startupoptionstakeeffectwhentheserverstarts.

Thestartupsequencespeciestheorderinwhichtheserverchecksdevicestondabootrecord.Theserver
startsfromtherstbootrecordthatitnds.Forexample,youcandeneastartupsequencethatchecksa
discintheopticaldrive,thencheckstheharddiskdrive,andthenchecksanetworkdevice.Forinformation
aboutsettingthestartupsequenceorselectingastartupdevice,see“Selectingastartupdevice”onpage64

BootManagermenu

TheBootManagermenuintheSetupUtilityprogramlistsallthebootabledevicesinstalledinyourserver
andthelisteditemsvarydependingonyourserverconguration.Ifyouselectadesireddevicelistedonthis
menu,theserverwillstartfromthedeviceyouselect.

YoucanpressF12whenturningontheserverandselectatemporarystartupdevicefromthebootdevice
selectionwindow.See“Selectingastartupdevice”onpage64

.

.

Save&Exitmenu

AfteryounishviewingorchangingsettingsintheSetupUtilityprogram,youcanchooseadesired
actionfromtheSave&Exitmenutosavechanges,discardchanges,orloaddefaultvalues,andexitthe
program.PressEntertoselecttheitemontheSave&ExitmenuandthenselectY eswhenpromptedto
conrmtheaction.ForinformationaboutexitingtheSetupUtilityprogram,see“ExitingtheSetupUtility
program”onpage65

TheSave&Exitmenucontainsthefollowingitems:

•SaveChangesandExit:SavechangesandexittheSetupUtilityprogram.

•SaveChangesandReset:SavechangesandthencontinuewiththecongurationintheSetupUtility
program.

•DiscardChangesandExit:Discardchanges,loadpreviousvalues,andthenexittheSetupUtility
program.

•DiscardChanges:Discardchangesandloadpreviousvalues.

•RestoreDefaults:Returntotheoptimizeddefaultsettings.

•SaveasUserDefaults:Savethecurrentsettingsasuserdefaultvalues.

•RestoreUserDefaults:Restoretheuserdefaultvaluesforalltheitems.

.

Settingthesystemdateandtime

ThistopicprovidesinstructionsonhowtosetthesystemdateandtimeintheSetupUtilityprogram.

TosetthesystemdateandtimeintheSetupUtilityprogram,dothefollowing:

1.StarttheSetupUtilityprogram.See“StartingtheSetupUtilityprogram”onpage59.

2.OntheMainmenu,selectSystemDateorSystemTime.

62ThinkServerRD430UserGuide

3.UsetheT abkeytoswitchbetweendataelementsandtypethenumbersfromthekeyboardtosetthe
systemdateandtime.

4.PressF10tosavesettingsandexittheSetupUtilityprogram.

Usingpasswords

ByusingtheSetupUtilityprogram,youcansetapasswordtopreventunauthorizedaccesstoyourserver.

Youdonothavetosetapasswordtouseyourserver.However,usingapasswordimprovescomputing
security.Ifyoudecidetosetapassword,readthefollowingtopics.

SetupUtilityprogrampasswordtypes

ThefollowingtypesofpasswordsareavailableintheSetupUtilityprogram:

•Administratorpassword
Settinganadministratorpassworddetersunauthorizedusersfromchangingcongurationsettings.Ifyou

areresponsibleformaintainingthecongurationsettingsofseveralcomputers,youmightwanttoset
anadministratorpassword.Whenanadministratorpasswordisset,youarepromptedtotypeavalid
passwordeachtimeyoutrytoaccesstheSetupUtilityprogram.TheSetupUtilityprogramcannot
beaccesseduntilavalidpasswordistypedin.

•Userpassword
Whenauserpasswordisset,theservercannotbeuseduntilavalidpasswordistypedin.

Note:Ifboththeadministratorpasswordanduserpasswordareset,youcantypeeitherpasswordtouse
theserver.However,youmustuseyouradministratorpasswordtochangeanycongurationsettings.

Passwordconsiderations

Forsecurityreasons,itisrecommendedtouseastrongpasswordthatcannotbeeasilycompromised.

Notes:

•TheSetupUtilityprogrampasswordsarenotcasesensitive.

•TheserversupportsSetupUtilityprogrampasswordsthatconsistofthreeto20characters.

Tosetastrongpassword,usethefollowingguidelines:

•Haveatleasteightcharactersinlength

•Containatleastonealphabeticcharacterandonenumericcharacter

•Notbeyournameoryourusername

•Notbeacommonwordoracommonname

•Besignicantlydifferentfromyourpreviouspasswords

Besidesthealphabeticcharacters(a-z)andnumericcharacters(0-9),theserveralsosupportscharacters
typedusingspecialkeysonthekeyboardforapassword.Refertothehelpmessageonthescreenwhen
settingapasswordtodeterminethevalidspecialcharacters.

Setting,changing,ordeletingapassword

Thistopicprovidesinstructionsonhowtoset,change,ordeleteapasswordintheSetupUtilityprogram.

Toset,change,ordeleteapasswordintheSetupUtilityprogram,dothefollowing:

1.StarttheSetupUtilityprogram.See“StartingtheSetupUtilityprogram”onpage59.

Chapter5.Conguringtheserver63

2.OntheSecuritymenu,selectAdministratorPasswordtosetanadministratorpasswordorselect
UserPasswordtosetauserpassword.

3.See“Passwordconsiderations”onpage63.Then,followtheinstructionsonthescreentosetor
changeapassword.

4.Ifyouwanttodeleteapassword,typeyourcurrentpassword.PressEnterwhenyouareprompted
totypeanewpassword.Then,pressEntertoconrmthenewpassword.Thepreviouspassword
willbecleared.

Note:Forsecurityreasons,itisrecommendedthatyoualwayssetapasswordforyourserver.

5.PressF10tosavesettingsandexittheSetupUtilityprogram.

Ifyouhaveforgottenthepassword,youcanusetheClearpasswordswitchonthesystemboardtoerasethe
password.See“Systemboardjumpersandswitches”onpage51.Then,setanewpasswordfortheserver.

Selectingastartupdevice

Ifyourserverdoesnotstartupfromadesireddevicesuchasthediscorharddiskdriveasexpected,doone
ofthefollowingtoselectthestartupdeviceyouwant.

Note:Notalldiscs,harddiskdrives,orotherremovabledevicesarebootable.

•Toselectatemporarystartupdevice,dothefollowing:

Note:Selectingastartupdeviceusingthefollowingmethoddoesnotpermanentlychangethestartup
sequence.

1.Turnonorrestartyourserver.

2.Whenyouseethelogoscreen,pressF10ifyourserverisconnectedtoanetworkandyouwantto
startuptheserverfromthenetwork.Otherwise,pressF12todisplaythebootmenu.Theboot
deviceselectionwindowopens.

3.Inthebootdeviceselectionwindow,usetheupanddownarrowkeysonthekeyboardtoswitch
betweentheselections.PressEntertoselectthedeviceofyourchoice.Then,theserverwillstart
upfromtheselecteddevice.

•Tovieworpermanentlychangetheconguredstartupdevicesequence,dothefollowing:

1.StarttheSetupUtilityprogram.See“StartingtheSetupUtilityprogram”onpage59.

2.OntheBootOptionsmenu,followtheinstructionsonthescreentosetthestartupdeviceforBoot
Option#1toBootOption#5dependingonyourneeds.Youalsocansetthebootpriorityforvarious
devices.See“BootOptionsmenu”onpage62

3.PressF10tosavesettingsandexittheSetupUtilityprogram.Theserverwillfollowthestartupdevice
sequenceyouhaveseteachtimeyouturnontheserver.

.

ConguringtheTPMfunction

TheTPMworksasahardwaresecuritysolutiontohelpyoutoencryptdataandprotecttheserver.The
TPMfunctionisonlyavailablewhenthereisaTPMinstalledinyourserver.See“InstallingtheTPM”on
page126.YoucanpurchaseaTPMfromLenovo.

AfterinstallingaTPM,youneedtocheckiftheTPMfunctionisenabledintheSetupUtilityprogram.

ToenabletheTPMfunctionintheSetupUtilityprogram,dothefollowing:

1.StarttheSetupUtilityprogram.See“StartingtheSetupUtilityprogram”onpage59.

2.OntheSecuritymenu,selectTPM/TCM➙TPMSupport.EnsurethatTPMSupportissettoEnabled.

3.WhenTPMSupportissettoEnabled,theTPMStateitemisdisplayed.SetTPMStatetoEnabled.

64ThinkServerRD430UserGuide

4.PressF10tosavesettingsandexittheSetupUtilityprogram.Theserverwillrestarttoenablethe
TPMfunction.

SettingthemodeoftheEthernetconnector0

TheEthernetconnector0ontherearoftheserverisforsystemmanagement.Ifyouwanttouseremote
managementfunctions,youneedtoconnectanEthernetcabletotheEthernetconnector0.See“Rear
viewoftheserver”onpage28.

TheEthernetconnector0forsystemmanagementis82574Lbydefault.Ifyouhaveselectedsharemode
forthe82574LEthernetconnectorintheSetupUtilityprogram,youcanusetheconnectorasanordinary
Ethernetconnectorwith100Mbpsnetworkconnectivity.However,teamingwithotherEthernetconnectors
isnotsupportedifthemanagementEthernetconnectorisusedasanordinaryEthernetconnector.

TosetthemodeoftheEthernetconnector0intheSetupUtilityprogram,dothefollowing:

1.StarttheSetupUtilityprogram.See“StartingtheSetupUtilityprogram”onpage59.

2.OntheServerManagementmenu,selectBMCNetworkConguration➙BMCLANShareSetting.

3.Dooneofthefollowing:

•IfyouwanttousetheEthernetconnector0asanordinaryEthernetconnector,selectShared.

•IfyouwanttousetheEthernetconnector0asadedicatedsystemmanagementEthernetconnector,

selectDedicated.

4.PressF10tosavesettingsandexittheSetupUtilityprogram.

ExitingtheSetupUtilityprogram

Afteryounishviewingorchangingsettings,pressEsctoreturntotheSetupUtilityprogrammaininterface.
Ifyouareonanestedsubmenu,pressEscrepeatedlyuntilyoureachthemaininterface.Then,youcando
oneofthefollowingtoexittheSetupUtilityprogram:

•IfyouwanttosavethenewsettingsandexittheSetupUtilityprogram,pressF10orselectSave&Exit➙
SaveChangesandExit.Otherwise,yourchangeswillnotbesaved.

•Ifyoudonotwanttosavethenewsettings,selectSave&Exit➙DiscardChangesandExit.

•Ifyouwanttoreturntothedefaultsettings,pressF9orselectSave&Exit➙RestoreDefaults.

FormoreinformationabouttheSave&ExitmenuintheSetupUtilityprogram,see“Save&Exitmenu”
onpage62

.

UpdatingorrecoveringtheBIOS

ThistopicprovidesinstructionsonhowtoupdatetheBIOSandhowtorecoverfromaPOSTandBIOS
updatefailure.

Systemprogramsarethebasiclayerofsoftwarebuiltintoyourserver.SystemprogramsincludethePOST,
theUEFIBIOS,theSetupUtilityprogram,andtheTMMrmware.ThePOSTisasetoftestsandprocedures
thatareperformedeachtimeyouturnonyourserver.TheUEFIBIOSisalayerofsoftwarethattranslates
instructionsfromotherlayersofsoftwareintoelectricalsignalsthattheserverhardwarecanexecute.You
canusetheSetupUtilityprogramtovieworchangethecongurationsettingsofyourserver.See“Usingthe
SetupUtilityprogram”onpage59.TheTMMrmwareprovidesremotemanagementfeatures.

LenovomightmakechangesandenhancementstotheBIOSandTMMrmware.Whenupdatesarereleased,
theyareavailablefordownloadontheLenovoWebsiteathttp://www.lenovo.com/drivers.Y oucanupdate
theserverrmwarebydownloadinganupdatepackageandfollowingtheinstructionsontheWebpage.

Chapter5.Conguringtheserver65

YoualsocanusetheFirmwareUpdaterprogramtohelpyoukeeptheserverrmwareup-to-date.See
“Updatingthermware”onpage79.

Updating(ashing)theBIOS

Thistopicprovidesinstructionsonhowtoupdate(ash)theBIOS.

Notes:

•UpdatetheBIOSonyourserveronlyifthenewerBIOSversionspecicallysolvesaproblemyouhave.
WedonotrecommendBIOSupdatesforserversthatdonotneedthem.Youcanviewtheupdated
informationforthenewBIOSversionintheinstallationinstructionsfortheBIOSupdateutilityprogram.

•DowngradingtheBIOStoanearlierversionisnotrecommendedandmightnotbesupported.Anearlier
BIOSversionmightnotsupportthelatestsystemcongurations.

•IfthepowertoyourserverisinterruptedwhilethePOSTandBIOSarebeingupdated,yourservermight
notrestartcorrectly.EnsurethatyouperformtheBIOSupdateprocedureinanenvironmentwitha
steadypowersupply.Besides,ensurethatyourservercanrestartsuccessfullywithoutencountering
hardwareproblems.

•IfyouhaveupdatedtheBIOSrmware,alltheBIOSsettingsbecomethedefaultsettingsoftheupdated
BIOSversion.YouneedtocheckandreconguretheBIOSsettingsforyourspecicneeds.Y oucan
selectSaveasUserDefaultsontheSave&ExitmenuintheSetupUtilityprogramtosaveyourcurrent
BIOSsettingsasuserdefaultvaluesbeforeupdatingtheBIOS.Then,youcanselectRestoreUser
DefaultsontheSave&ExitmenuintheSetupUtilityprogramtorestoretheuserdefaultvaluesafter
updatingtheBIOS.Inthiscase,youcankeepyourpreviousBIOSsettingsanddonotneedtorecongure
thesettingsafterupdatingtheBIOS.Y oualsocanrecordyourspecicBIOSsettingsbeforeupdatingthe
BIOSforaneasierrecongurationinthenewBIOSversion.

Toupdate(ash)theBIOS,dothefollowing:

1.Gotohttp://www.lenovo.com/driversandfollowtheinstructionsontheWebpagetolocatetheBIOS
updatepackage.

2.DownloadtheBIOSupdatepackageandtheinstallationinstructionsinaTXTle.

3.PrinttheTXTlethatcontainstheinstallationinstructionsandfollowtheinstructionstoupdate(ash)
theBIOS.

4.DooneofthefollowingaftertheBIOSupdateprocessiscompleted:

•IfyouhavesavedyourBIOSsettingsasuserdefaultvaluesbeforeupdatingtheBIOS,selectRestore

UserDefaultsontheSave&ExitmenuintheSetupUtilityprogramtorestoretheuserdefault
values.Then,checkiftheuserdefaultvaluesmeetyourcurrentrequirements.

•CheckandreconguretheBIOSsettingsforyourspecicneedsbasedonyournoteorreferto

“UsingtheSetupUtilityprogram”onpage59.

RecoveringfromaBIOSupdatefailure

IfthepowertoyourserverisinterruptedwhiletheBIOSisbeingupdated,yourservermightnotrestart
correctly.Ifthishappens,performthefollowingproceduretorecoverfromtheBIOSupdatefailure.

Note:IftheoperatingsystemofyourserverisinstalledunderEFImode,youneedtoreinstalltheoperating
systemafterrecoveringtheBIOS.

TorecoverfromaBIOSupdatefailure,dothefollowing:

1.Gotohttp://www.lenovo.com/driversandfollowtheinstructionsontheWebpagetodownloadaBIOS
updatepackage.Then,puttheamiboot.romlecontainedinthepackageintotherootdirectoryof
abootableUSBkey.

66ThinkServerRD430UserGuide

2.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.

3.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.

4.Removetheservercover.See“Removingtheservercover”onpage83.

5.LocatetheBIOSrecoveryswitchonthesystemboard.See“Systemboardjumpersandswitches”on
page51.Then,removeanypartsanddisconnectanycablesthatmightimpedeyouraccesstothe
switch.

6.MovetheBIOSrecoveryswitchfromthedefaultoffpositiontotheonposition.

7.Reinstallanypartsandreconnectanycables.Then,reinstalltheservercover.See“Completingthe
partsreplacement”onpage174.

8.ConnecttheservertoanacpowersourceandthenstarttheserverfromthebootableUSBkeythat
containstheamiboot.romle.Therecoveryprocessstarts.Aftertherecoveryprocessiscompleted,
yourserverwillautomaticallyturnoff.

9.Repeatstep2throughstep5.

10.MovetheBIOSrecoveryswitchbacktotheoffposition.

11.Reinstallanypartsandreconnectanycables.Then,reinstalltheservercover.See“Completingthe
partsreplacement”onpage174

12.Connecttheservertoanacpowersourceandturnontheserver.TheBIOSsettingsrecovertothe
factorydefaultsettings.YouneedtocheckandconguretheBIOSsettingsforyourspecicneeds.See
“UsingtheSetupUtilityprogram”onpage59

.

.

Note:IfyoucannotrecovertheBIOSafterusingtheinstructionsinthistopic,theBIOSread-onlymemory
(ROM)mightbedamagedandyouneedtoreplacethesystemboard.ContacttheLenovoCustomer
SupportCenter.

UsingtheThinkServerEasyStartupprogram

ThistopicguidesyoutousetheThinkServerEasyStartupprogramtosetupandcongureyourserver.

TheThinkServerEasyStartupprogramsimpliestheprocessofconguringRAIDandinstallingsupported
WindowsandLinuxoperatingsystemsanddevicedriversonyourserver.Theprogramworksinconjunction
withyourWindowsorLinuxoperatingsysteminstallationdisctoautomatetheprocessofinstallingthe
operatingsystemandassociateddevicedrivers.Thisprogramisprovidedwithyourserveronaself-starting
(bootable)ThinkServerEasyStartupDVD.TheuserguidefortheprogramalsoisontheDVDandcanbe
accesseddirectlyfromtheprograminterface.

IfyoudonothaveaThinkServerEasyStartupDVD,youalsocandownloadanISOimagefromtheLenovo
SupportWebsiteandmakeadiscbyyourself.

TodownloadtheThinkServerEasyStartupprogramimageandburnitintoadisc,dothefollowing:

1.Gotohttp://www.lenovo.com/driversandfollowtheinstructionsontheWebpagetolocatethe
ThinkServerEasyStartupprogram.

2.DownloadtheISOimagefortheThinkServerEasyStartupprogramandthereadmele.Thereadmele
containsimportantinformationabouttheThinkServerEasyStartupprogram.

3.Printthereadmeleandreaditcarefully.

4.UseanopticaldriveandanyDVDburningsoftwaretocreateabootablediscwiththeISOimage.

Chapter5.Conguringtheserver67

FeaturesoftheThinkServerEasyStartupprogram

ThistopicliststhefeaturesoftheThinkServerEasyStartupprogram.

TheThinkServerEasyStartupprogramhasthefollowingfeatures:

•Containedinaself-starting(bootable)DVD

•Easy-to-use,language-selectableinterface

•Integratedhelpsystemanduserguide

•Automatichardwaredetection

•ContainstheRAIDcongurationutility

•Providesdevicedriversbasedontheservermodelanddetecteddevices

•DownloadsdevicedriversfromtheThinkServerEasyStartupDVDaccordingtotheoperatingsystem
oradd-ondevice

•Selectablepartitionsizeandlesystemtype

•Supportformultipleoperatingsystems

•Abilitytoinstalltheoperatingsystemanddevicedriversinanunattendedmodetosavetime

•AbilitytocreateareuseableresponselethatcanbeusedwithsimilarlyconguredLenovoserversto
makefutureinstallationsevenfaster

StartingtheThinkServerEasyStartupprogram

ThistopicprovidesinstructionsonhowtostarttheThinkServerEasyStartupprogram.Afteryoustartthe
programandenterthemaininterface,clickUserGuidefordetailedinformationabouthowtousethis
programtohelpyouconguretheserverandinstallanoperatingsystem.

TostarttheThinkServerEasyStartupprogram,dothefollowing:

1.InserttheThinkServerEasyStartupDVDintoanopticaldrive,settheopticaldriveastherststartup
device,andstartyourserverfromtheDVDintheopticaldrive.See“Selectingastartupdevice”on
page64

2.Waitfortheprogramtoload.Then,youwillbepromptedforthefollowingselections:

•Thelanguageinwhichyouwanttoviewtheprogram

•Thelanguageofthekeyboardlayoutyouwillbeusingwiththeprogram

Note:ThesupportedlanguagesandkeyboardlayoutsfortheThinkServerEasyStartupprogramare
Dutch,English,French,German,Italian,Japanese,Russian,Spanish,andTurkish.YourThinkServer
EasyStartupDVDmightbeEnglishonly.Inthiscase,thekeyboardlayoutshouldbeEnglish.

3.Afterselectingthelanguageandkeyboardlayout,clickOK.Then,youwillseeoneormorereminders
ormessagesaboutconguringstoragedevices.ClickNextuntilyouarepresentedwiththeLenovo
LicenseAgreement.ReadtheLenovoLicenseAgreementcarefully.Inordertocontinue,youmust
acceptthetermsbyclickingAgree.Then,theDateandtimewindowopens.

4.SetthecurrentdateandtimeandclickOK.TheStartoptionwindowopens.

5.TheStartoptionwindowprovidesthefollowingselections:

•Continuetothemaininterface.

•Installtheoperatingsystemusingapre-existingresponsele.

•CongureRAIDusingapre-existingresponsele.

.

68ThinkServerRD430UserGuide

Readtheexplanationsonthescreenandselectadesiredoption.Then,followtheinstructionsonthe
screen.IfthisisthersttimeyouareusingtheThinkServerEasyStartupprogram,selecttheoptionto
continuetothemaininterfaceandviewthecompatibilitynotesanduserguide.

Notes:

•FunctionalityandsupportedoperatingsystemsvarydependingontheversionoftheThinkServer
EasyStartupprogram.Fromthemaininterfaceoftheprogram,clickCompatibilitynotestoviewthe
informationabouttheRAIDcontrollers,operatingsystems,andservercongurationssupportedbythe
specicversionoftheprogram;andclickUserGuidetoviewthevariousfunctionsandlearnhowto
usetheprogram.

•BeforeusingtheThinkServerEasyStartupprogramtoinstallanoperatingsystem,ensurethatanyexternal
storagedevicesandberchannelsareconguredcorrectly.

TheThinkServerEasyStartupprogrammaininterfaceprovidesthefollowingmenusontheleftpaneof
thescreen:

•Home
Thismenuisthewelcomepagethatcontainssomegeneraldescriptionsabouttheprogramandthe

Lenovocopyrightandtrademarkstatements.

•Compatibilitynotes
ThismenuprovidesinformationabouttheRAIDcontrollers,operatingsystems,andservercongurations

supportedbytheversionoftheprogramyouareusing.

•UserGuide
Thismenuprovidesinformationaboutthefeaturesoftheprogramandinstructionsonhowtousethe

program.

•Hardwarelist
Thismenudisplaysalistofhardwaredevicesdetectedbytheprogram.

•CongureRAID
ThismenuguidesyoutocongureRAIDorviewthecurrentRAIDcongurationandmakechanges

ifneeded.

•Installoperatingsystem
Thismenudisplaysaseriesofchoicesandpromptstocollectinformationrequiredforoperatingsystem

installation,preparestheharddiskdriveforinstallation,andtheninitiatestheinstallationprocessusing
youroperatingsysteminstallationdisc.

•Downloaddrivers
ThismenuhelpsyoudownloadtherequireddevicedriversfromtheThinkServerEasyStartupDVDtoa

removablestoragedevicesothatyoucaneasilygetthedriversforservercongurationwhenyouneed
them.

Note:Themostup-to-datedevicedriversforvariousservermodelsarealwaysavailablefordownloadon
theLenovoSupportWebsiteat:
http://www.lenovo.com/drivers

•About
Thismenuprovidestheversioninformationandlegalnotices.

Chapter5.Conguringtheserver69

UsingtheThinkServerEasyStartupprogramonaWindowsoperating system

YoucanruntheThinkServerEasyStartupDVDonaWindowsoperatingsystemwiththeInternetExplorer
Webbrowseroralaterversioninstalled.EntertheoperatingsystemandinserttheThinkServerEasyStartup
DVDintoaninternalorexternalopticaldrive.TheDVDstartsautomaticallyinmostenvironments.IftheDVD
failstostart,openthelaunch.exelelocatedintherootdirectoryoftheDVD.

Notes:

•YoushouldreadandaccepttheLenovoLicenseAgreementwhenprompted.

•OntheMicrosoftWindowsServer
Locator(URL)fortheThinkServerEasyStartupprogramWebpagetothetrustedWebsitelistsothat
thepagecanopencorrectly.

YoucandothefollowingwhenusingtheThinkServerEasyStartupprogramonaWindowsoperatingsystem.
Fordetailedinformation,refertothehelpsystem.

•ViewageneralintroductiontoyourThinkServerservermodelandthespecicserverconguration
information.

•ViewgeneralguidanceonhowtousetheThinkServerEasyStartupDVD.

•Downloadtherequireddevicedriverstoaremovablestoragedevicesothatyoucaneasilygetthe
driversforservercongurationwhenyouneedthem,especiallywhenyounishinstallinganoperating
systemwithoutusingtheThinkServerEasyStartupDVDandneedappropriatedevicedriverstocongure
yourserver.

•InstalltherequireddevicedriversdirectlyontheserveronwhichyouarerunningtheThinkServer
EasyStartupDVD.

•ViewinformationaboutallservermodelssupportedbytheThinkServerEasyStartupprogramand
informationaboutthedevicedriversforeachservermodel,includingthedriverversionsanddriver
locationsintherootdirectoryoftheThinkServerEasyStartupDVD.

®

2003operatingsystem,youmightneedtoaddtheUniformResource

®

6.0

Note:Themostup-to-datedevicedriversforvariousservermodelsarealwaysavailablefordownloadon
theLenovoSupportWebsiteat:
http://www.lenovo.com/drivers

ConguringRAID

ThistopicprovidesinformationaboutRAIDandtheutilityprogramsthatareavailableforyoutocongure
RAID.

Thistopiccontainsthefollowingitems:

•“AboutRAID”onpage70

•“ConguringRAIDusingtheThinkServerEasyStartupprogram”onpage72

•“ConguringtheThinkServerRAID300”onpage72

•“ConguringtheadvancedSATA/SAShardwareRAID”onpage78

AboutRAID

RAID,anacronymforRedundantArrayofIndependentDisks,isatechnologythatprovidesincreased
storagefunctionsandreliabilitythroughredundancy.Thisisachievedbycombiningmultipleharddiskdrives
intoalogicalunit,wheredataisdistributedacrossthedrivesinoneofseveralwayscalledRAIDlevels.

70ThinkServerRD430UserGuide

WhenagroupofindependentphysicalharddiskdrivesaresetuptouseRAIDtechnology,theyareinaRAID
array.Thisarraydistributesdataacrossmultipleharddiskdrives,butthearrayappearstothehostserveras
onesinglestorageunit,knownasavirtualdrive.CreatingandusingRAIDarraysprovideshighperformance,
suchastheexpeditedI/Operformance,becauseseveraldrivescanbeaccessedsimultaneously.

RAIDdrivegroupsalsoimprovedatastoragereliabilityandfaulttolerancecomparedwithsingle-drive
storagesystems.Datalossresultingfromadrivefailurecanbepreventedbyreconstructingmissingdata
fromtheremainingdrives.

ThefollowinglistdescribessomeofthemostcommonlyusedRAIDlevels:

•RAID0:block-levelstripingwithoutparityormirroring
SimplestripesetsarenormallyreferredtoasRAID0.RAID0usesstripingtoprovidehighdata

throughput,especiallyforlargelesinanenvironmentthatdoesnotrequirefaulttolerance.RAID0hasno
redundancyanditprovidesimprovedperformanceandadditionalstoragewithoutfaulttolerance.Any
drivefailuredestroysthearrayandthelikelihoodoffailureincreaseswithmoredrivesinthearray.RAID
0doesnotimplementerrorchecking,soanyerrorisuncorrectable.Moredrivesinthearraymeans
higherbandwidth,butgreaterriskofdataloss.

RAID0requiresaminimumnumberoftwoharddiskdrives.

•RAID1:mirroringwithoutparityorstriping
RAID1usesmirroringsothatdatawrittentoonedriveissimultaneouslywrittentoanotherdrive.Thisis

goodforsmalldatabasesorotherapplicationsthatrequiresmallcapacitybutcompletedataredundancy.
RAID1providesfaulttolerancefromdiskerrorsorfailuresandcontinuestooperateaslongasatleast
onedriveinthemirroredsetisfunctioning.Withappropriateoperatingsystemsupport,therecanbe
increasedreadperformanceandonlyaminimalwriteperformancereduction.

RAID1requiresaminimumnumberoftwoharddiskdrives.

•RAID5:block-levelstripingwithdistributedparity
RAID5usesdiskstripingandparitydataacrossalldrives(distributedparity)toprovidehighdata

throughput,especiallyforsmallrandomaccess.RAID5distributesparityalongwiththedataandrequires
alldrivesbutonetobepresenttooperate;drivefailurerequiresreplacement,butthearrayisnot
destroyedbyasingledrivefailure.Upondrivefailure,anysubsequentreadoperationscanbecalculated
fromthedistributedparitysothatthedrivefailureismaskedfromtheenduser.Thearraywillhavedata
lossintheeventofaseconddrivefailureandisvulnerableuntilthedatathatwasonthefailingdriveis
rebuiltontoareplacementdrive.Asingledrivefailureinthesetwillresultinreducedperformanceof
theentiresetuntilthefailingdrivehasbeenreplacedandrebuilt.

RAID5requiresaminimumnumberofthreeharddiskdrives.

•RAID10:acombinationofRAID0andRAID1
RAID10consistsofstripeddataacrossmirroredspans.ARAID10drivegroupisaspanneddrive

groupthatcreatesastripedsetfromaseriesofmirroreddrives.RAID10allowsamaximumofeight
spans.YoumustuseanevennumberofdrivesineachRAIDvirtualdriveinthespan.TheRAID1
virtualdrivesmusthavethesamestripesize.RAID10provideshighdatathroughputandcompletedata
redundancybutusesalargernumberofspans.

RAID10requiresaminimumnumberoffourharddiskdrivesandalsorequiresanevennumberofdrives,
forexample,sixharddiskdrivesoreightharddiskdrives.

Chapter5.Conguringtheserver71

•RAID50:acombinationofRAID0andRAID5
RAID50usesdistributedparityanddiskstriping.ARAID50drivegroupisaspanneddrivegroupin

whichdataisstripedacrossmultipleRAID5drivegroups.RAID50worksbestwithdatathatrequires
highreliability,highrequestrates,highdatatransfers,andmedium-to-largecapacity.

Note:HavingvirtualdrivesofdifferentRAIDlevels,suchasRAID0andRAID5,inthesamedrivegroupis
notallowed.Forexample,ifanexistingRAID5virtualdriveiscreatedoutofpartialspaceinanarray,the
nextvirtualdriveinthearrayhastobeRAID5only.

RAID50requiresaminimumnumberofsixharddiskdrives.

FordetailedinformationaboutRAID,referto“IntroductiontoRAID”intheMegaRAIDSASSoftwareUser
GuideonthedocumentationDVDthatcomeswithyourserver.

ConguringRAIDusingtheThinkServerEasyStartupprogram

TheThinkServerEasyStartupprogramsimpliestheprocessofconguringsupportedRAIDandinstalling
supportedWindowsandLinuxoperatingsystemsanddevicedriversonyourserver.Theuserguideforthe
programcanbeaccesseddirectlyfromtheprograminterface.

TheThinkServerEasyStartupprogramhasthefollowingfeaturesforRAIDconguration:

•ForusewithallsupportedRAIDcontrollers

•AutomaticallydetectshardwareandlistsallsupportedRAIDcongurations

•Conguresoneormorediskarrayspercontrollerdependingonthenumberofdrivesattachedtothe
controllerandtheRAIDlevelselected

•Supportshot-sparedrives

•CreatesaRAIDresponselethatcanbeusedtocongureRAIDcontrollersonsimilarlycongured
Lenovoservers

See“UsingtheThinkServerEasyStartupprogram”onpage67andviewtheuserguidefromthemain
interfaceoftheprogram.

SomeRAIDmanagementsoftwarealsoisprovidedontheThinkServerEasyStartupDVDtohelpyoumanage
RAIDarraysandRAIDcontrollersinanoperatingsystemenvironment.Afteryouentertheoperatingsystem,
inserttheThinkServerEasyStartupDVDintotheopticaldrive.Theinstallationpackagesfortheprograms
arelocatedintheUtilitiesandOthersfolderintherootdirectoryoftheDVD.TheThinkServerEasyStartup
DVDisdesignedfordifferenttypesofserversandtheUtilitiesandOthersfoldermightcontainadditional
installationpackagesthatarenotrequiredtobeinstalledonyourserver.

ConguringtheThinkServerRAID300

TheThinkServerRAID300(alsoknownasonboardSASsoftwareRAID)isintegratedinthePCHon
thesystemboard.Ifyouconnectthemini-SAStomini-SASsignalcablesfromthesystemboardtothe
backplane,youcancongureRAIDfortheharddiskdrivesusingtheLSISoftwareRAIDCongurationUtility
program,independentlyoftheoperatingsystem.TheThinkServerRAID300supportsRAIDlevels0,1,and
10bydefault.Y oualsocanactivateRAID5byinstallingaThinkServerRAID300UpgradeKeyforAdvanced
RAID.See“InstallingorremovingtheThinkServerRAID300UpgradeKeyforAdvancedRAID”onpage119

YoucaninstallandusetheMegaRAIDStorageManagerprogramtomanagetheRAIDarrayandRAID
controllerinanoperatingsystemenvironment.

.

72ThinkServerRD430UserGuide

BeforeconguringRAIDforyourserver,observethefollowingprecautions:

•Useharddiskdrivesthatareofthesametype(SATAorSAS)andhavethesamecapacitywithina
singleRAIDarray.

•ThetotaldrivecapacityoftheprimaryRAIDarraymightbelimitedto2TB.

RAIDarraystatus

Whenyouturnontheserver,theRAIDcontrollerROMversion,theRAIDarraystatus,andthelistofthe
availableharddiskdriveswillbedisplayedduringthePOST.

TheRAIDarraystatuscanbeoneofthefollowing:

•Online
Thisisthenormalstatus,whichindicatesthattheRAIDarrayisworkingcorrectly.

•Degrade
ThisstatusindicatesthatmorethanoneharddiskdriveintheRAIDarraycannotbesynchronizedorhave

failed.Youneedtoreplacethefailingharddiskdrivesandrebuildthedata.See“Installingorreplacinga
hot-swapharddiskdrive”onpage148and“Rebuildingaphysicaldrive”onpage76.

•Ofine
ThisstatusindicatesthattheRAIDarrayhasfailedandcannotberebuilt.YouneedtocreateanewRAID

array.See“Creating,adding,ordeletingaRAIDarray”onpage75.

StartingtheLSISoftwareRAIDCongurationUtilityprogram

ThistopicprovidesinstructionsonhowtostarttheLSISoftwareRAIDCongurationUtilityprogram.

TostarttheLSISoftwareRAIDCongurationUtilityprogram,dothefollowing:

1.Turnontheserver.

2.DuringthePOST,whenyouseethemessage“PressCtrl-MorEntertorunLSISoftwareRAIDSetup
Utility,”immediatelypressCtrl+MtostarttheLSISoftwareRAIDCongurationUtilityprogram.

LSISoftwareRAIDCongurationUtilityprograminterface

ThistopicprovidesinformationaboutthemenusanditemsintheLSISoftwareRAIDCongurationUtility
program.Dependingontheversionoftheprogram,somemenuoriteminformationmightdifferslightlyfrom
theinformationinthistopic.

WhenworkingwiththeLSISoftwareRAIDCongurationUtilityprogram,youmustusethekeyboard.
Thekeysusedtoperformvarioustasksaredisplayedonthebottomofeachscreen.Useupanddown
arrowkeystonavigatebetweenitems.Formostitems,thecorrespondinghelpmessageisdisplayed
onthebottomofthescreenwhentheitemisselected.Iftheitemhassubmenus,youcandisplaythe
submenusbypressingEnter.

Chapter5.Conguringtheserver73

AfterenteringtheLSISoftwareRAIDCongurationUtilityprogram,youcanseetheManagementMenuon
thescreen.TheManagementMenucontainsthefollowingmenuitems:

•Congure
ThismenucontainsitemstohelpyoucreateaRAIDarray,viewthecurrentRAIDconguration,addanew

RAIDarray,deleteanexistingRAIDarray,andselectabootvirtualdrive.

•Initialize
Thismenuhelpsyouinitializevirtualdrive(s).

Note:Initializingavirtualdriveerasesalldataonthevirtualdrive.Backupanydatayouwanttokeepand
ensurethattheoperatingsystemisnotinstalledonthevirtualdrivebeforetheinitialization.

•Objects
ThismenuhelpsyoucongureparametersfortheRAIDcontroller,thevirtualdrive(s),andthephysical

drive(s).

•Rebuild
ThismenuhelpsyourebuildaphysicaldriveinaRAIDarrayintheeventofaphysicaldrivefailure.

Youcanchoosetorebuildthedataonthefailingdriveifthedriveisstilloperational.Ifthedriveisnot
operational,itmustbereplacedandthedataonthefailingdrivemustberebuiltonanewdrivetorestore
thesystemtofaulttolerance.

•CheckConsistency
Thismenuhelpsyoudoconsistencycheckforthevirtualdrive(s).Theconsistencycheckveriesthe

correctnessofthedataonvirtualdrive(s)thatuseRAID1,5,and10.

ThefollowingtableshowsthevariousmenusanditemsintheLSISoftwareRAIDCongurationUtility
program.Oneachmenu,presstheEnterkeytoshowselectableoptionsandselectadesiredoptionby
usingupanddownarrowkeysortypedesiredvaluesfromthekeyboarddirectly.

Table1.LSISoftwareRAIDCongurationUtilityprogrammenuitems

Congure

Initialize

Objects

Rebuild

CheckConsistency

Menuitem

EasyCongurationCreatephysicalarrays.Anarraywill

NewCongurationCleartheexistingcongurationand

View/AddConguration

ClearCongurationCleartheexistingconguration.
SelectBootDriveSelectabootvirtualdrive.

Variesbyconguration.

Adapter

VirtualDrive

PhysicalDrive

Variesbyconguration.
Variesbyconguration.

SubmenuitemComments

automaticallybecomeavirtualdrive.

startanewconguration.
Viewtheexistingcongurationoradda

newconguration.

Initializevirtualdrives.
Setadapterrelatedparameters,such

asrebuildrate,consistencycheckrate,
auto-rebuild,andsoon.

Setvirtualdriveparameters.
Setphysicaldriveparameters,suchas

creatingahot-sparedriveforthevirtual
drive,makingafailingdriveasonline,
changingadrivestate,andviewingthe
specicationsofaphysicaldrive.

Rebuildphysicaldrive(s).
Checkconsistencyofvirtualdrive(s).

74ThinkServerRD430UserGuide

Creating,adding,ordeletingaRAIDarray

Thistopicprovidesinstructionsonhowtocreate,add,ordeleteaRAIDarrayusingtheLSISoftwareRAID
CongurationUtilityprogram.

Note:BeforeyoucreateaRAIDarrayusingtheLSISoftwareRAIDCongurationUtilityprogram,ensurethat
theservermeetstherequiredhardwareconguration.Forexample,theserverneedstohavetherequired
numberofharddiskdrivesinstalledandconnectedtothesystemboard.See“AboutRAID”onpage70
forinformationabouttherequirednumberofharddiskdrivesforeachRAIDlevel.Ifyouwanttocreatea
RAID5arrayusingtheLSISoftwareRAIDCongurationUtilityprogram,theserveralsoneedstohavea
ThinkServerRAID300UpgradeKeyforAdvancedRAID.See“InstallingorremovingtheThinkServerRAID
300UpgradeKeyforAdvancedRAID”onpage119

Tocreate,add,ordeleteaRAIDarrayusingtheLSISoftwareRAIDCongurationUtilityprogram,dothe
following:

1.StarttheLSISoftwareRAIDCongurationUtilityprogram.See“StartingtheLSISoftwareRAID
CongurationUtilityprogram”onpage73.

2.Onthemaininterfaceoftheprogram,dooneofthefollowingdependingonyourneeds:

•IfyouwanttocreateaRAIDarray,selectEasyCongurationandthenfollowtheinstructionson

thescreen.

•IfyouwanttoaddasecondaryRAIDarray(ifsupportedbyyourserver),selectView/Add

Congurationandthenfollowtheinstructionsonthescreentoviewthecurrentcongurationand
addanewRAIDarray.

•IfyouwanttodeletetheexistingRAIDarray,exittheprogramandbackupallyourdataonthe

harddiskdrives.Afterbackingupallyourdata,entertheprogrammaininterfaceandselectClear
Conguration.SelectY eswhenpromptedandfollowtheinstructionsonthescreen.

.

Attention:DeletinganexistingRAIDarrayerasesalldataonthearray.Ensurethatyoubackupall
databeforedeletingtheRAIDarray.IftheoperatingsystemisinstalledontheRAIDarrayyouwantto
delete,youneedtoreinstalltheoperatingsystemafterdeletingtheRAIDarray.

•IfyouwanttodeletetheexistingRAIDarrayandcreateanewRAIDarray,exittheprogramandback

upallyourdataontheharddiskdrives.Afterbackingupallyourdata,entertheprogrammain
interfaceandselectNewConguration.SelectYeswhenpromptedtoproceedandthenfollowthe
instructionsonthescreen.

Attention:DeletinganexistingRAIDarrayerasesalldataonthearray.Ensurethatyoubackupall
databeforedeletingtheRAIDarray.IftheoperatingsystemisinstalledontheRAIDarrayyouwantto
delete,youneedtoreinstalltheoperatingsystemafterdeletingtheRAIDarray.

Initializingavirtualdrive

ThistopicprovidesinstructionsonhowtoinitializeavirtualdriveusingtheLSISoftwareRAIDConguration
Utilityprogramaftercompletingthecongurationprocess.

Virtualdriveinitializationistheprocessofwritingzerostothedataeldsofavirtualdriveand,infault-tolerant
RAIDlevels,generatingthecorrespondingparitytoputthevirtualdriveinareadystate.Initializationerases
alldataonthevirtualdrive.Drivegroupswillworkwithoutbeinginitialized,buttheycanfailaconsistency
checkbecausetheparityeldshavenotbeengenerated.

Notes:

•Ensurethatyoubackupanydatayouwanttokeepbeforeinitializingavirtualdrive.

•Ensurethattheoperatingsystemisnotinstalledonthevirtualdriveyouareinitializing.Otherwise,you
needtoreinstalltheoperatingsystemafterinitializingthevirtualdrive.

Chapter5.Conguringtheserver75

ToinitializeavirtualdriveusingtheLSISoftwareRAIDCongurationUtilityprogram,dothefollowing:

1.StarttheLSISoftwareRAIDCongurationUtilityprogram.See“StartingtheLSISoftwareRAID
CongurationUtilityprogram”onpage73.

2.Onthemaininterfaceoftheprogram,selectInitializeandfollowtheinstructionsonthescreen.

Settingahot-sparedrive

Thistopicprovidesinstructionsonhowtosetaharddiskdriveasahot-sparedriveusingtheLSISoftware
RAIDCongurationUtilityprogram.

Ahot-sparedriveisanextra,unuseddrivethatispartofthedisksubsystem.Itisusuallyinstandbymode
andreadyforserviceifaharddiskdrivefails.Fordetailedinformationabouthot-sparedrives,referto
“IntroductiontoRAID”intheMegaRAIDSASSoftwareUserGuideonthedocumentationDVDthatcomes
withyourserver.

Tosetaharddiskdriveasahot-sparedriveusingtheLSISoftwareRAIDCongurationUtilityprogram,
dothefollowing:

1.StarttheLSISoftwareRAIDCongurationUtilityprogram.See“StartingtheLSISoftwareRAID
CongurationUtilityprogram”onpage73

2.Dooneofthefollowing:

•IfyouwanttocreateoraddanewRAIDarray,youcansetahot-sparedriveduringtheconguration

processbyfollowingtheinstructionsonthescreen.

•Ifyouwanttosetahot-sparedriverightaftertheconguration,selectObjects➙PhysicalDrive

fromtheprogrammaininterface.Then,selecttheharddiskdrivethatyouwanttosetasahot-spare
driveandpressEnter.Asubmenuisdisplayed.SelectMakeHotSparefromthesubmenuandthen
selectY eswhenpromptedtosettheharddiskdriveasahot-sparedrive.

.

Rebuildingaphysicaldrive

ThistopicprovidesinstructionsonhowtorebuildaphysicaldriveusingtheLSISoftwareRAIDConguration
UtilityprogramwhenaphysicaldriveinaRAIDarrayfails.

WhenaphysicaldriveinaRAIDarrayfails,youcanrebuildthedrivebyrecreatingthedatathatwasstored
onthedrivebeforeitfails.Ifthedriveisnotoperational,itmustbereplacedandthedataonthefailingdrive
mustberebuiltonanewdrivetorestorethesystemtofaulttolerance.

TheRAIDcontrollerrecreatesthedatausingthedatastoredonotherdrivesinthedrivegroup.Rebuilding
canbedoneonlyindrivegroupswithdataredundancy,suchasRAID1,RAID5,andRAID10arrays.For
detailedinformationaboutdiskrebuild,referto“IntroductiontoRAID”intheMegaRAIDSASSoftwareUser
GuideonthedocumentationDVDthatcomeswithyourserver.

TorebuildaphysicaldriveusingtheLSISoftwareRAIDCongurationUtilityprogramwhenaphysicaldrive
inaRAIDarrayfails,dothefollowing:

1.StarttheLSISoftwareRAIDCongurationUtilityprogram.See“StartingtheLSISoftwareRAID
CongurationUtilityprogram”onpage73.

2.Onthemaininterfaceoftheprogram,selectRebuildandfollowtheinstructionsonthescreen.

Note:Runaconsistencycheckimmediatelyaftertherebuildcompletestoensuredataintegrityforthevirtual
drives.See“Runningaconsistencycheck”onpage77.

Therebuildrateisthepercentageofthecomputingcyclesdedicatedtorebuildingfailingdrives.Therebuild
ratecanbeconguredbetween0percentand100percent.At0percent,therebuildisdoneonlyifthesystem
isnotdoinganythingelse.At100percent,therebuildhasahigherprioritythananyothersystemactivity.

76ThinkServerRD430UserGuide

ToconguretherebuildrateusingtheLSISoftwareRAIDCongurationUtilityprogram,dothefollowing:

Note:Usingarebuildrateof0or100percentisnotrecommended.Thedefaultvalueis30percent.

1.StarttheLSISoftwareRAIDCongurationUtilityprogram.See“StartingtheLSISoftwareRAID
CongurationUtilityprogram”onpage73

2.Onthemaininterfaceoftheprogram,selectObjects➙Adapter➙RebuildRate.

3.Settherebuildratebytypingadesiredvaluefromthekeyboarddirectly.

.

Runningaconsistencycheck

ThistopicprovidesinstructionsonhowtorunaconsistencycheckforvirtualdrivesusingtheLSISoftware
RAIDCongurationUtilityprogram.

TheconsistencycheckoperationveriesthatallstripesonavirtualdrivewitharedundantRAIDlevel(RAID
1,RAID5,andRAID10)areconsistentandthedateonthevirtualdriveiscorrect.Forexample,inasystem
withparity,checkingconsistencymeanscomputingthedataononedriveandcomparingtheresultsto
thecontentsoftheparitydrive.

Youshouldrunaconsistencycheckonfault-tolerantvirtualdrivesperiodically.Itisrecommendedthatyou
runaconsistencycheckatleastonceamonth.Y oumustrunaconsistencycheckifyoususpectthatthe
virtualdrivedatamightbecorrupted.Ensurethatyoubackupthedatabeforerunningaconsistencycheck
ifyoususpectthatthedatamightbecorrupted.

TorunaconsistencycheckusingtheLSISoftwareRAIDCongurationUtilityprogram,dothefollowing:

1.StarttheLSISoftwareRAIDCongurationUtilityprogram.See“StartingtheLSISoftwareRAID
CongurationUtilityprogram”onpage73

2.Onthemaininterfaceoftheprogram,selectCheckConsistencyandfollowtheinstructionsonthe
screen.

.

Theconsistencycheckrateistherateatwhichconsistencycheckoperationsarerunonasystem.The
consistencycheckratecanbeconguredbetween0percentand100percent.At0percent,theconsistency
checkisdoneonlyifthesystemisnotdoinganythingelse.At100percent,theconsistencycheckhasa
higherprioritythananyothersystemactivity.

ToconguretheconsistencycheckrateusingtheLSISoftwareRAIDCongurationUtilityprogram,do
thefollowing:

Note:Usingaconsistencycheckrateof0or100percentisnotrecommended.Thedefaultvalueis30
percent.

1.StarttheLSISoftwareRAIDCongurationUtilityprogram.See“StartingtheLSISoftwareRAID
CongurationUtilityprogram”onpage73

2.Onthemaininterfaceoftheprogram,selectObjects➙Adapter➙ChkConstRate.

3.Settheconsistencycheckratebytypingadesiredvaluefromthekeyboarddirectly.

.

InstallingandusingtheMegaRAIDStorageManagerprogram

YoucaninstallandusetheMegaRAIDStorageManagerprogramtomanagetheRAIDarrayandRAID
controllerinanoperatingsystemenvironmentafterconguringRAID.

TheinstallationpackagefortheMegaRAIDStorageManagerprogramisontheThinkServerEasyStartup
DVD.Afteryouentertheoperatingsystem,inserttheThinkServerEasyStartupDVDintotheopticaldrive.
TheinstallationpackagefortheMegaRAIDStorageManagerprogramislocatedintheUtilitiesandOthers
folderintherootdirectoryoftheDVD.

Chapter5.Conguringtheserver77

ToinstallandusetheMegaRAIDStorageManagerprogram,refertothefollowingchaptersintheMegaRAID
SASSoftwareUserGuideonthedocumentationDVDthatcomeswithyourserver:

Note:SomeinformationinthesechaptersmightbeintendedfortheadvancedSATA/SAShardwareRAID
congurationsandmightnotapplytotheThinkServerRAID300congurations.

•“MegaRAIDStorageManagerOverviewandInstallation”

•“MegaRAIDStorageManagerWindowandMenus”

•“MonitoringSystemEventsandStorageDevices”

•“MaintainingandManagingStorageCongurations”

TheMegaRAIDSASSoftwareUserGuidealsoisavailableontheLenovoWebsiteat:
http://www.lenovo.com/ThinkServerUserGuides

ConguringtheadvancedSA T A/SAShardwareRAID

BeforeconguringRAIDforyourserver,observethefollowingprecautions:

•Useharddiskdrivesthatareofthesametype(SATAorSAS)andhavethesamecapacitywithina
singleRAIDarray.

•ThetotaldrivecapacityoftheprimaryRAIDarraymightbelimitedto2TB.

SomeservermodelscomewithaRAIDcardtoprovideadvancedSATA/SAShardwareRAIDfunctions.You
alsocanpurchaseasupportedRAIDcardfromLenovoandinstallitintotheserver.See“RAIDcard”
onpage37.

TheRAIDcardprovidestheWebBIOSCongurationUtilityprogramtohelpyoucongureRAID
independentlyoftheoperatingsystem.YoualsocaninstalltheMegaRAIDStorageManagerprogramand
theMegaCLICongurationUtilityprogramtohelpyoumanagetheRAIDarrayandRAIDcontrollerinan
operatingsystemenvironment.

TheinstallationpackagesfortheMegaRAIDStorageManagerprogramandtheMegaCLIConguration
UtilityprogramareontheThinkServerEasyStartupDVD.Afteryouentertheoperatingsystem,insertthe
ThinkServerEasyStartupDVDintotheopticaldrive.Theinstallationpackagesfortheprogramsarelocatedin
theUtilitiesandOthersfolderintherootdirectoryoftheDVD.

Note:TheThinkServerEasyStartupDVDisdesignedfordifferenttypesofserversandtheUtilitiesandOthers
foldermightcontainadditionalinstallationpackagesthatarenotrequiredtobeinstalledonyourserver.

ForinstructionsonhowtocongureandmanagetheadvancedSATA/SAShardwareRAID,refertothe
MegaRAIDSASSoftwareUserGuideonthedocumentationDVDthatcomeswithyourserver.This
documentalsoisavailableontheLenovoWebsiteat:
http://www.lenovo.com/ThinkServerUserGuides

ConguringtheEthernetcontrollers

TheEthernetcontrollersareintegratedonthesystemboard.Theyprovideaninterfaceforconnectingto
a10Mbps,100Mbps,or1000Mbpsnetworkandprovidefull-duplex(FDX)capability,whichenables
simultaneoustransmissionandreceptionofdataonthenetwork.

YoudonothavetosetanyjumpersorconguretheEthernetcontrollers.However,youmustinstalladevice
drivertoenabletheoperatingsystemtorecognizethecontrollers.

78ThinkServerRD430UserGuide

TheThinkServerEasyStartupprogramsimpliestheprocessofconguringRAIDandinstallingsupported
operatingsystemsanddevicedriversonyourserver.See“UsingtheThinkServerEasyStartupprogram”
onpage67.

ThedevicedriversforonboardEthernetcontrollersalsoareavailablefordownloadat:
http://www.lenovo.com/drivers

Updatingthermware

ThermwareintheserverisperiodicallyupdatedandisavailablefordownloadontheLenovoWebsite.

Gotohttp://www.lenovo.com/driversandfollowtheinstructionsontheWebpagetocheckforthelatest
levelofrmware,suchastheBIOSupdatesanddevicedrivers.

Whenyoureplaceadeviceintheserver,youmighthavetoeitherupdatetheserverwiththelatestversionof
thermwarethatisstoredinmemoryonthedeviceorreashtheBIOS,theTMMrmware,andtheFRU/SDR.

UsingtheFirmwareUpdaterprogram

TheFirmwareUpdaterprogramenablesyoutomaintainyoursystemrmwareup-to-dateandhelpsyou
avoidunnecessaryoutages.

ToupdateyoursystemrmwareusingtheFirmwareUpdaterprogram,dothefollowing:

Note:Beforedistributingthermwareupdatestoaserver,ensurethatyourservercanrestartsuccessfully
withoutencounteringhardwareproblems.

1.Gotohttp://www.lenovo.com/driversandfollowtheinstructionsontheWebpagetolocatethe
FirmwareUpdaterprogram.

2.DownloadtheISOimagefortheFirmwareUpdaterprogramandtheinstallationinstructionsinaTXTle.

3.UseanyCDorDVDburningsoftwaretocreateabootablediscwiththeISOimage.

4.PrinttheTXTlethatcontainstheinstallationinstructionsandfollowtheinstructionstousetheFirmware
Updaterprogramtoupdateyoursystemrmware.

UsingtheLenovoThinkServerEasyManageprogram

TheLenovoThinkServerEasyManageprogramenablesenterpriseuserstoremotelycontrolandmonitor
multipleLenovoserverswithinaLAN.Theprogramprovidesaninterfacetodisplayallseversbeing
managed,whichenablestheadministratortoconvenientlysearchfor,monitor,andmanageservers.

TodownloadtheLenovoThinkServerEasyManageprogram,gotohttp://www.lenovo.com/driversand
followtheinstructionsontheWebpage.

FordetailedinformationaboutusingtheLenovoThinkServerEasyManageprogram,refertothehelpsystem
fortheprogram.

Chapter5.Conguringtheserver79

80ThinkServerRD430UserGuide

Chapter6.Installing,removing,orreplacinghardware

Thischapterprovidesinstructionsonhowtoinstall,remove,orreplacehardwareforyourserver.

Thischaptercontainsthefollowingitems:

•“Guidelines”onpage81

•“Removingtheservercover”onpage83

•“Removingandreinstallingthefrontbezel”onpage85

•“Installing,removing,orreplacinghardware”onpage86

•“Completingthepartsreplacement”onpage174

ForalistoftheThinkServeroptions,goto:
http://www.lenovo.com/thinkserver

Guidelines

Thistopicprovidessomeguidelinesthatyoushouldreadandunderstandbeforeusingyourserver.

Precautions

Beforeusingtheserver,ensurethatyoureadandunderstandthefollowingprecautions:

•Beforeusingtheproduct,ensurethatyoureadandunderstandthemultilingualsafetyinstructionsandthe
LenovoLimitedWarranty(LLW)onthedocumentationDVDthatcomeswiththeproduct.Readingand
understandingthesafetyinstructionsreducestheriskofpersonalinjuryanddamagetoyourproduct.

•Whenyouinstallyournewserver,taketheopportunitytodownloadandapplythemostrecentrmware
updates.Thisstepwillhelptoensurethatanyknownissuesareaddressedandthatyourserveris
readytofunctionatmaximumlevelsofperformance.Todownloadrmwareupdatesforyourserver,go
tohttp://www.lenovo.com/driversandfollowtheinstructionsontheWebpage.See“Updatingthe
rmware”onpage79

•Beforeyouinstalloptionalhardwaredevices,ensurethattheserverisworkingcorrectly.Iftheserver
isnotworkingcorrectly,seeChapter7“T roubleshootinganddiagnostics”onpage179todobasic
troubleshooting.Iftheproblemcannotbesolved,seeChapter8“Gettinginformation,help,andservice”
onpage185

•Observegoodhousekeepingintheareawhereyouareworking.Putremovedcoversandotherparts
inasafeplace.

•Ifyoumustturnontheserverwhiletheservercoverisremoved,ensurethatnooneisneartheserver
andthatnotoolsorotherobjectshavebeenleftinsidetheserver.

•Donotattempttoliftanobjectthatyouthinkistooheavyforyou.Ifyouhavetoliftaheavyobject,
observethefollowingprecautions:

.

formoreinformation.

–Ensurethatyoucanstandsafelywithoutslipping.
–Distributetheweightoftheobjectequallybetweenyourfeet.
–Useaslowliftingforce.Nevermovesuddenlyortwistwhenyouliftaheavyobject.
–Toavoidstrainingthemusclesinyourback,liftbystandingorbypushingupwithyourlegmuscles.

•Ensurethatyouhaveanadequatenumberofproperlygroundedelectricaloutletsfortheserver,monitor,
andotherdevices.

•Backupallimportantdatabeforeyoumakechangestodrives.

©CopyrightLenovo2012,2013

81

•Haveasmallat-bladescrewdriveravailable.

•Youdonothavetoturnofftheservertoinstallorreplaceahot-swapredundantpowersupply,hot-swap
harddiskdrives,orhot-plugUSBdevices.However,youmustturnofftheserverbeforeperforming
anystepsthatinvolveinstalling,removing,orreplacingadaptercablesornon-hot-swapdevicesor
components.

•ToviewtheLEDsonthesystemboardandinternalcomponents,leavetheserverconnectedtopower.

•Whenyouarenishedworkingontheserver,reinstallallsafetyshields,guards,labels,andgroundwires.

Handlingstatic-sensitivedevices

Attention:Donotopenthestatic-protectivepackagethatcontainsthenewpartuntilthedefectiveparthasbeen

removedfromtheserverandyouarereadytoinstallthenewpart.Staticelectricity,althoughharmlesstoyou,
canseriouslydamageservercomponentsandparts.

Anyserverpartcontainingtransistorsorintegratedcircuits(ICs)shouldbeconsideredsensitiveto
electrostaticdischarge(ESD).ESDdamagecanoccurwhenthereisadifferenceinchargebetweenobjects.
ProtectagainstESDdamagebyequalizingthechargesothatthemachine,thepart,theworkmat,andthe
personhandlingthepartareallatthesamecharge.

Notes:

•Useproduct-specicESDprocedureswhentheyexceedtherequirementsnotedhere.

•EnsurethattheESDprotectivedevicesyouusehavebeencertied(ISO9000)asfullyeffective.

Whenyouhandleserverpartsandcomponents,taketheseprecautionstoavoidstatic-electricitydamage:

•Limityourmovement.Movementcancausestaticelectricitytobuilduparoundyou.

•Alwayscarefullyhandlethepartsandothercomponents(suchasPCIExpresscards,memorymodules,
systemboards,andmicroprocessors)byedgesorframe.Donottouchsolderjoints,pins,orexposed
circuitry.

•Donotleavethedevicewhereotherscanhandleandpossiblydamagethedevice.

•Beforeyoureplaceanewpart,touchthestatic-protectivepackagecontainingthenewparttoan
unpaintedmetalpartoftheserverforatleasttwoseconds.Thisreducesstaticelectricityfromthe
packageandyourbody.

•Removethenewpartfromthestatic-protectivepackageanddirectlyinstallitintheserverwithout
placingitonanyothersurface.Ifitishardforyoutodothisinyourspecicsituation,placethe
static-protectivepackageofthenewpartonasmooth,levelsurface,andthenplacethenewparton
thestatic-protectivepackage.

•Donotplacethepartontheservercoverorothermetalsurface.

•Takeadditionalcarewhenhandlingdevicesduringcoldweather.Heatingreducesindoorhumidity
andincreasesstaticelectricity.

•Useagroundedworkmattoprovideastatic-freeworksurface.Thematisespeciallyusefulwhen
handlingESD-sensitivedevices.

•Preventthepartfromtouchingyourclothing.Mostclothingisinsulativeandretainsachargeevenwhen
youarewearingawriststrap.

•Theuseofagroundingsystemisrecommended.Forexample,itisrecommendedtowearanelectrostatic
discharge(ESD)wriststrap,ifoneisavailable.EnsurethatyouworkinanESD-safearea.Selecta
groundingsystem,suchasthoselistedbelow,toprovideprotectionthatmeetsthespecicservice
requirement.

Note:TheuseofagroundingsystemtoguardagainstESDdamageisdesirablebutnotnecessary.

82ThinkServerRD430UserGuide

–AttachtheESDgroundcliptoanyframeground,groundbraid,orgreen-wireground.
–Whenworkingonadouble-insulatedorbattery-operatedsystem,useanESDcommongroundor

referencepoint.Youcanusecoaxorconnector-outsideshellsonthesesystems.

–Usethegroundprongoftheacplugonac-operatedservers.

Systemreliabilityguidelines

Tohelpensurepropercoolingandsystemreliability,strictlyfollowtheseguidelines:

•Eachofthedrivebayshasadriveoradummytrayinstalled;orthereisanelectromagneticinterface(EMI)
protectivepanelorEMIshieldinstalledtoprotectthedrivecage.

•Iftheserversupportshot-swapredundantpowersupplies,eachofthepowersupplybayhasaredundant
powersupplyinstalled,oronebayhasaredundantpowersupplyinstalledwhiletheotherbayiscovered
byashield.

•Leaveadequatespacearoundtheservertoensurethattheservercoolingsystemworkswell.Leave
approximately50mm(2inches)ofopenspacearoundthefrontandrearoftheserver.Donotplace
objectsinfrontofthefans.Forpropercoolingandairow,installtheservercoverbeforeyouturnon
theserver.Operatingtheserverforextendedperiodsoftime(morethan30minutes)withtheserver
coverremovedmightdamageservercomponents.

•Properlyroutethecables.Forsomeoptions,suchasPCIcards,followthecablinginstructionsthatcome
withtheoptionsinadditiontotheinstructionsinthismanual.

•Whenreplacingahot-swapdrive,installthenewhot-swapdrivewithintwominutesofremoval.

•Ifyourserverhasairductsorairbafes,donotremovethemwhiletheserverisrunning.Operatingthe
serverwithouttheairductsorairbafesmightcausethemicroprocessor(s)tooverheat.

•Forserversthatsupportuptotwomicroprocessors,ensurethatthesecondmicroprocessorsocket
alwayscontainsamicroprocessororisprotectedbyamicroprocessorsocketcover.

Workinginsidetheserverwiththepoweron

Attention:Staticelectricitythatisreleasedtointernalservercomponentswhentheserveristurnedonmightcause

theservertohalt,whichmightresultinthelossofdata.Toavoidthispotentialproblem,alwaysuseanESDwriststrap
orothergroundingsystemwhenyouworkinsidetheserverwiththepoweron.

Theserversupportshot-swapdevicesandisdesignedtooperatesafelywhileitisturnedonandthecoveris
removed.Followtheseguidelineswhenyouworkinsidetheserverwiththepoweron:

•Avoidwearingloose-ttingclothingonyourforearms.Buttonlong-sleevedshirtsbeforeworkinginside
theserver;donotwearcufflinkswhileyouareworkinginsidetheserver.

•Donotallowyournecktieorscarftohanginsidetheserver.

•Removejewelry,suchasbracelets,necklaces,rings,andloose-ttingwristwatches.

•Removeitemsfromyourshirtpocket,suchaspensandpencils.Theseitemsmightfallintotheserveras
youleanoverit.

•Avoiddroppinganymetallicobjectsintotheserver,suchaspaperclips,hairpins,andscrews.

Removingtheservercover

Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”

onpageiiiand“Guidelines”onpage81.

Thistopicprovidesinstructionsonhowtoremovetheservercover.

Chapter6.Installing,removing,orreplacinghardware83

Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.

Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.

Toremovetheservercover,dothefollowing:

1.Removeallmediafromthedrives.Then,turnoffallattacheddevicesandtheserver.

2.Disconnectallpowercordsfromelectricaloutlets.

3.Disconnectthepowercord(s),Input/Output(I/O)cables,andallothercablesthatareconnectedto
theserver.

4.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.

5.Pressthereleasebutton1inthedirectionasshown.

Figure42.Pressingthereleasebutton

84ThinkServerRD430UserGuide

6.Fullyopenthecoverlatch1andslidetheservercovertotherearuntilitisdisengagedfromthechassis.
Then,lifttheservercoveroffthechassisandsetitaside.

Note:Itisrecommendedthatyouwaitthreetoveminutestolettheservercoolbeforeremoving
theservercover.

Figure43.Removingtheservercover

Attention:Forpropercoolingandairow,installtheservercoverbeforeturningontheserver.Operatingthe
serverformorethan30minuteswiththeservercoverremovedmightdamageservercomponents.

Toreinstalltheservercover,see“Reinstallingtheservercoverandreconnectingcables”onpage174.

Removingandreinstallingthefrontbezel

Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”

onpageiii

Thistopicprovidesinstructionsonhowtoremoveandreinstallthefrontbezel.

Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.

Notes:

•Thistopicappliesonlytoservermodelsthatsupport2.5-inchhot-swapharddiskdrives.

•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.

Toremoveandreinstallthefrontbezelforservermodelswith2.5-inchhot-swapharddiskdrives,dothe
following:

and“Guidelines”onpage81.

Chapter6.Installing,removing,orreplacinghardware85

1.Removethethreescrews1thatsecurethefrontbezelandthenpivotthefrontbezeloutwardto

ID

MEM 1

PSU 1 2

1 2 3 4 5 6 7 8

MEM 2

1 2 3 4 5 6 7 8 9

10

CPU 1 2

1 2 3 4 5 6 7 8 9

10

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

removeitfromthechassis.

Figure44.Removingthefrontbezel

2.Toreinstallthefrontbezel,alignthetabsonthebottomedgeofthefrontbezelwiththecorresponding
holesinthechassis.Then,pivotthefrontbezelinwarduntilitsnapsintopositionandthethreescrew

1inthetopedgeofthefrontbezelarealignedwiththecorrespondingholesinthetopofthe

holes
chassis.Installthethreescrewstosecurethefrontbezelinplace.

Figure45.Installingthefrontbezel

Installing,removing,orreplacinghardware

Thistopicprovidesinstructionsonhowtoinstall,remove,orreplacehardwareforyourserver.Youcan
expandthecapabilitiesofyourserverbyaddingnewhardwaredevices,suchasmemorymodules,PCI
Expresscards,orotherserveroptions,andmaintainyourserverbyreplacingthefailinghardwaredevices.

Ifyouarehandlingaserveroption,refertotheappropriateinstallationandorremovalinstructionsinthis
topicalongwiththeinstructionsthatcomewiththeoption.

86ThinkServerRD430UserGuide

Notes:

•UseonlypartsprovidedbyLenovo.

•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.

TheEMIintegrityandcoolingoftheserverareprotectedbyhavingalldrivebaysandPCIcardslotscovered
oroccupied.WhenyouinstallaninternaldriveoraPCIcard,savetheEMIshieldordummytrayfromthe
drivebayorsavethePCIcardslotbracketintheeventthatyoulaterremovethedevice.

Attention:AnunoccupieddrivebayorPCIcardslotwithoutacover,shield,dummytray,ller,orany
otherprotectionmightimpacttheEMIintegrityandcoolingoftheserver,whichmightresultinoverheating
orcomponentdamage.

Removingandreinstallingtherackhandles

Thistopicprovidesinstructionsonhowtoremoveandreinstalltherackhandles.Thistopiccontainsthe
followingitems:

•“Removingandreinstallingtherackhandlesforservermodelswith123.5-inchharddiskdrivebays”
onpage87

•“Removingandreinstallingtherackhandlesforservermodelswitheight3.5-inchharddiskdrivebays
andservermodelswith2.5-inchharddiskdrivebays”onpage90

Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.

Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.

Removingandreinstallingtherackhandlesforservermodelswith123.5-inchhard
diskdrivebays

Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”

onpageiiiand“Guidelines”onpage81.

Toremoveandreinstalltherackhandlesforservermodelswith123.5-inchharddiskdrivebays,dothe
following:

1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.

2.Iftheserverisinstalledinarackcabinet,removetheserverfromtherackcabinetandplaceitonaat,
clean,andstatic-protectivesurface.SeetheRackInstallationInstructionsthatcomeswiththeserver.

3.Removetheservercover.See“Removingtheservercover”onpage83.

4.Locatethebackplane.See“Componentsofservermodelswith123.5-inchharddiskdrivebays”
onpage34.

Chapter6.Installing,removing,orreplacinghardware87

5.Disconnectthefollowingsignalcablesfromthesignalcableconnectorsonthebackplaneforserver
modelswith123.5-inchharddiskdrivebays.

•SignalcableforthefrontcontrolsandLEDsontherightrackhandle

•SignalcableforthefrontUSBconnectorsontheleftrackhandle

Figure46.Disconnectingtherackhandlesignalcablesfromthebackplane

6.Oneachsideoftheserver,removethescrewthatsecurestherackhandleandthenremovetherack
handlefromthechassis.

Note:Carefullypullthesignalcableofeachrackhandleoutoftheholeinthechassiswhenyouare
removingtherackhandles.

Figure47.Removingtherackhandlesforservermodelswith123.5-inchharddiskdrivebays

7.Toreinstalltherackhandlesforservermodelswith123.5-inchharddiskdrivebays,dothefollowing:

88ThinkServerRD430UserGuide
