Page 1
E14/R14/S3 Gen 2
Setup Guide
Page 2
Initial Setup
Page 3
Overview
32 1
1
8
5
4
6
7
9
10
12
13
14
15
11
1. Microphones
2. Camera
* 3. ThinkShutter
* 4. Power button/Fingerprint reader
5. Security-lock slot
6. Ethernet connector
7. USB 2.0 connector
8. Trackpad
For selected models
*
Read the statement on USB transfer rate in the User Guid e. Refer to the Safety and
Warranty Guide for accessing the User Guide.
9. TrackPoint® buttons
10. TrackPoint pointing stick
11. Audio connector
12. HDMI
13. USB 3.1 connector Gen 1
14. Always On USB 3.1 connector
Gen 1
15. USB-C
1)
TM
connector
TM
connector (USB 3.1 Gen
Page 4
Additional information
Technology
Frequency
band [MHz]
Maximu
m
transmit
power
WLAN
802.11b/g/n/ax
2400 -
2483.5
WLAN
802.11a/n/ac/ax
WLAN
802.11a/n/ac/ax
< 13.98
dBm
Bluetooth
BR/EDR/LE
2400 -
2483.5
Specific absorption rate for European Union
YOUR DEVICE MEETS INTERNATIONAL
GUIDELINES FOR EXPOSURE TO RADIO WAVES.
The Europe 10g Specific Absorption Rate (SAR)
limit for mobile devices is 2.0 W/kg. To view your
product specific SAR value, go to
https://support.lenovo.com/us/en/solutions/sar.
If you are interested in further reducing your RF
exposure then you can easily do so by limiting your
usage or simply keeping the device away from the
body.
European Union — compliance with the Radio Equipment Directive
Hereby, Lenovo (Singapore) Pte. Ltd., declares t hat
the radio equipment type ThinkPad E14/R14/S3
Gen 2 is in compliance with Directive 2014/53/EU.
The full text of the system EU declaration o f
conformity is available at the following Internet
address:
https://www.lenovo.com/us/en/compliance/eu doc
This radio equipment operates with the following
frequency bands and maximum radio-frequency
power:
< 20 dBm
5150 - 5725 < 23 dBm
5725 - 5875
< 20 dBm
Page 5
E-manual
First Edition (September 2019)
LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a
General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to
restrictions set forth in Contract No. GS-35F-0 5925.
© Copyright Lenovo 2019.
Reduce I Reuse I Recycle
Printed in China
