Lenovo 1112, 3617, 3665, 3662, 3595 User Manual

ThinkCentre
UserGuide

MachineTypes:0896,0958,1112,2116,3498,3593,3595,3597,
3617,3634,3655,3662,3665,and3675

Note:Beforeusingthisinformationandtheproductitsupports,besuretoreadandunderstandthe
“Importantsafetyinformation”onpagevandAppendixA“Notices”onpage117.

ThirdEdition(August2012)

©CopyrightLenovo2012.

LIMITEDANDRESTRICTEDRIGHTSNOTICE:IfdataorsoftwareisdeliveredpursuantaGeneralServicesAdministration
“GSA”contract,use,reproduction,ordisclosureissubjecttorestrictionssetforthinContractNo.GS-35F-05925.

Contents

Importantsafetyinformation......v

Serviceandupgrades.............v

Staticelectricityprevention...........v

Powercordsandpoweradapters........vi

Extensioncordsandrelateddevices.......vi

Plugsandoutlets..............vii

Externaldevices..............vii

Heatandproductventilation.........vii

Operatingenvironment...........viii

Modemsafetyinformation..........viii

Lasercompliancestatement..........ix

Powersupplystatement............ix

Cleaningandmaintenance...........ix

Chapter1.Productoverview......1

Features..................1

Specications................4

Softwareoverview..............4

SoftwareprovidedbyLenovo........5

AdobeReader..............7

Antivirussoftware.............7

Locations..................7

Locatingconnectors,controls,andindicators

onthefrontofyourcomputer........8

Locatingconnectorsontherearofyour

computer................9

Locatingcomponents..........11

Locatingpartsonthesystemboard....11

Locatinginternaldrives.........14

Machinetypeandmodellabel.......15

Chapter2.Usingyourcomputer...17

Frequentlyaskedquestions.........17

Usingthekeyboard.............17

UsingWindowsshortcutkeys.......17

Usingangerprintreader........18

Usingthewheelmouse...........18

Adjustingaudio..............18

Aboutyourcomputeraudio........18

Settingthevolumefromthedesktop....19

SettingthevolumefromControlPanel...19

UsingCDsandDVDs............19

HandlingandstoringCDandDVDmedia..20

PlayingaCDorDVD..........20

RecordingaCDorDVD.........20

Chapter3.Y ouandyourcomputer..23

Accessibilityandcomfort..........23

Arrangingyourworkspace........23

Comfort...............23

Glareandlighting............24

Aircirculation.............24

Electricaloutletsandcablelengths.....24

Registeringyourcomputer..........25

Movingyourcomputertoanothercountryor

region..................25

Voltage-selectionswitch.........25

Replacementpowercords........26

Chapter4.Security..........27

Securityfeatures..............27

Lockingthecomputercover.........28

Attachinganintegratedcablelock.......29

Usingpasswords..............29

BIOSpasswords............29

Windowspasswords..........30

Conguringthengerprintreader.......30

Usingandunderstandingrewalls.......30

Protectingdataagainstviruses........30

Chapter5.Installingorreplacing

hardware...............33

Handlingstatic-sensitivedevices.......33

Installingorreplacinghardware........33

Installingexternaloptions........33

Removingthecomputercover.......34

Removingandreinstallingthefrontbezel..35

InstallingorreplacingaPCIcard......36

Installingorreplacingamemorymodule...39

Installingorreplacingtheopticaldrive...41

Replacingthebattery..........43

Replacingtheheatsinkandfanassembly..44

Replacingthepowersupplyassembly...46

Replacingthemicroprocessor.......47

Installingthesolidstatedrive.......50

Replacingtheprimaryharddiskdrive....51

Replacingtherearfanassembly......53

ReplacingthefrontaudioandUSB

assembly...............55

ReplacingtheWiFiunits.........56

InstallingorremovingtherearWiFiantenna.62

InstallingorremovingthefrontWiFiantenna.63

Replacingthekeyboard.........65

Replacingthemouse..........66

©CopyrightLenovo2012

i

Completingthepartsreplacement.....67

Chapter6.Recoveryinformation...69

Creatingandusingrecoverymedia......69

Creatingrecoverymedia.........69

Usingrecoverymedia..........70

Performingbackupandrecoveryoperations...70

Performingabackupoperation......70

Performingarecoveryoperation......71

UsingtheRescueandRecoveryworkspace...71

Creatingandusingarescuemedium......72

Creatingarescuemedium........72

Usingarescuemedium.........73

Reinstallingpreinstalledapplicationsanddevice

drivers..................73

Reinstallingsoftwareprograms........74

Reinstallingdevicedrivers..........75

Solvingrecoveryproblems..........75

Chapter7.UsingtheSetupUtility

program................77

StartingtheSetupUtilityprogram.......77

Viewingandchangingsettings........77

Usingpasswords..............77

Passwordconsiderations.........78

Power-OnPassword..........78

AdministratorPassword.........78

HardDiskPassword...........78

Setting,changing,anddeletingapassword.78

Erasinglostorforgottenpasswords(clearing

CMOS)................79

Enablingordisablingadevice........79

Selectingastartupdevice..........80

Selectingatemporarystartupdevice....80

Selectingorchangingthestartupdevice

sequence...............80

EnablingErPcompliancemode........80

ExitingfromtheSetupUtilityprogram.....81

Chapter8.Updatingsystem

programs...............83

Usingsystemprograms...........83

Updating(ashing)theBIOSfromadisc....83

Updating(ashing)theBIOSfromyouroperating

system..................84

RecoveringfromaPOST/BIOSupdatefailure..84

Chapter9.Preventingproblems...87

Keepingyourcomputercurrent........87

Gettingthelatestdevicedriversforyour

computer...............87

Updatingyouroperatingsystem......87

UsingSystemUpdate..........88

Cleaningandmaintenance..........88

Basics................88

Cleaningyourcomputer.........89

Goodmaintenancepractices.......90

Movingyourcomputer...........90

Chapter10.Troubleshootingand

diagnostics..............93

Basictroubleshooting............93

Troubleshootingprocedure..........94

Troubleshooting..............94

Audioproblems............95

CDproblems.............96

DVDproblems.............97

Intermittentproblems..........99

Keyboard,mouse,orpointingdevice

problems...............99

Monitorproblems............101

Networkingproblems..........102

Optionproblems............105

Performanceandlockupproblems.....106

Printerproblems............108

Serialportproblems...........109

Softwareproblems...........109

USBproblems.............110

Diagnosticprograms............110

LenovoSolutionCenter.........111

LenovoThinkVantageT oolbox.......111

PC-DoctorforDOS...........111

Chapter11.Gettinginformation,help,

andservice.............113

Informationresources............113

LenovoThinkVantageT ools........113

LenovoWelcome............113

HelpandSupport............113

SafetyandWarranty...........113

LenovoWebsite(http://www.lenovo.com)..113

LenovoSupportWebsite.........114

Helpandservice..............114

Usingthedocumentationanddiagnostic

programs...............114

Callingforservice............114

Usingotherservices..........115

Purchasingadditionalservices......115

AppendixA.Notices.........117

Trademarks................118

iiThinkCentreUserGuide

AppendixB.Regulatory

information.............119

Exportclassicationnotice..........119

Televisionoutputnotice...........119

Electronicemissionsnotices.........119

FederalCommunicationsCommission

DeclarationofConformity........119

Additionalregulatoryinformation.......121

AppendixC.WEEEandrecycling

statements.............123

ImportantWEEEInformation.........123

Recyclinginformation............123

RecyclinginformationforBrazil........124

BatteryrecyclinginformationforT aiwan.....124

BatteryrecyclinginformationfortheEuropean

Union..................125

AppendixD.RestrictionofHazardous

SubstancesDirective(RoHS)....127

ChinaRoHS................127

TurkishRoHS...............127

UkraineRoHS...............127

IndiaRoHS................128

AppendixE.EkBilgiler.......129

AppendixF .Servisistasyonlari...131

Index.................139

©CopyrightLenovo2012

iii

ivThinkCentreUserGuide

Importantsafetyinformation

CAUTION:
Beforeusingthismanual,besuretoreadandunderstandalltherelatedsafetyinformationforthis
product.RefertotheinformationinthissectionandthesafetyinformationintheThinkCentreSafety
andWarrantyGuidethatyoureceivedwiththisproduct.Readingandunderstandingthissafety
informationreducestheriskofpersonalinjuryanddamagetoyourproduct.

IfyounolongerhaveacopyoftheThinkCentreSafetyandWarrantyGuide,youcanobtainaPortable
DocumentFormat(PDF)versionfromtheLenovo
LenovoSupportWebsitealsoprovidestheThinkCentreSafetyandWarrantyGuideandthisThinkCentre
UserGuideinadditionallanguages.

®

SupportWebsiteathttp://www.lenovo.com/support.The

Serviceandupgrades

DonotattempttoserviceaproductyourselfunlessinstructedtodosobytheCustomerSupportCenteror
yourdocumentation.OnlyuseaServiceProviderwhoisapprovedtorepairyourparticularproduct.

Note:Somecomputerpartscanbeupgradedorreplacedbythecustomer.Upgradestypicallyare
referredtoasoptions.ReplacementpartsapprovedforcustomerinstallationarereferredtoasCustomer
ReplaceableUnits,orCRUs.Lenovoprovidesdocumentationwithinstructionswhenitisappropriatefor
customerstoinstalloptionsorreplaceCRUs.Y oumustcloselyfollowallinstructionswheninstallingor
replacingparts.TheOffstateofapowerindicatordoesnotnecessarilymeanthatvoltagelevelsinsidea
productarezero.Beforeyouremovethecoversfromaproductequippedwithapowercord,alwaysmake
surethatthepoweristurnedoffandthattheproductisunpluggedfromanypowersource.Formore
informationonCRUs,refertoChapter5“Installingorreplacinghardware”onpage33
questionsorconcerns,contacttheCustomerSupportCenter.

Althoughtherearenomovingpartsinyourcomputerafterthepowercordhasbeendisconnected,the
followingwarningsarerequiredforyoursafety.

CAUTION:

.Ifyouhaveany

Hazardousmovingparts.Keepngersandotherbodypartsaway.

CAUTION:

BeforereplacinganyCRUs,turnoffthecomputerandwaitthreetoveminutestoletthecomputer
coolbeforeopeningthecover.

Staticelectricityprevention

Staticelectricity,althoughharmlesstoyou,canseriouslydamagecomputercomponentsandoptions.
Improperhandlingofstatic-sensitivepartscancausedamagetothepart.Whenyouunpackanoption

©CopyrightLenovo2012

v

orCRU,donotopenthestatic-protectivepackagecontainingthepartuntiltheinstructionsdirectyou
toinstallit.

WhenyouhandleoptionsorCRUs,orperformanyworkinsidethecomputer,takethefollowingprecautions
toavoidstatic-electricitydamage:

•Limityourmovement.Movementcancausestaticelectricitytobuilduparoundyou.

•Alwayshandlecomponentscarefully.Handleadapters,memorymodules,andothercircuitboardsbythe

edges.Nevertouchexposedcircuitry.

•Preventothersfromtouchingcomponents.

•Whenyouinstallastatic-sensitiveoptionorCRU,touchthestatic-protectivepackagecontainingthe

parttoametalexpansion-slotcoverorotherunpaintedmetalsurfaceonthecomputerforatleasttwo
seconds.Thisreducesstaticelectricityinthepackageandyourbody.

•Whenpossible,removethestatic-sensitivepartfromthestatic-protectivepackagingandinstallthepart

withoutsettingitdown.Whenthisisnotpossible,placethestatic-protectivepackagingonasmooth,
levelsurfaceandplacethepartonit.

•Donotplacethepartonthecomputercoverorothermetalsurface.

Powercordsandpoweradapters

Useonlythepowercordsandpoweradapterssuppliedbytheproductmanufacturer.

Thepowercordsshallbesafetyapproved.ForGermany,itshallbeH05VV-F ,3G,0.75mm
othercountries,thesuitabletypesshallbeusedaccordingly.

Neverwrapapowercordaroundapoweradapterorotherobject.Doingsocanstressthecordinwaysthat
cancausethecordtofray,crack,orcrimp.Thiscanpresentasafetyhazard.

Alwaysroutepowercordssothattheywillnotbewalkedon,trippedover,orpinchedbyobjects.

Protectpowercordandpoweradaptersfromliquids.Forinstance,donotleaveyourpowercordorpower
adapternearsinks,tubs,toilets,oronoorsthatarecleanedwithliquidcleansers.Liquidscancausea
shortcircuit,particularlyifthepowercordorpoweradapterhasbeenstressedbymisuse.Liquidsalsocan
causegradualcorrosionofpowercordterminalsand/ortheconnectorterminalsonapoweradapter,
whichcaneventuallyresultinoverheating.

Alwaysconnectpowercordsandsignalcablesinthecorrectorderandensurethatallpowercord
connectorsaresecurelyandcompletelypluggedintoreceptacles.

Donotuseanypoweradapterthatshowscorrosionattheacinputpinsorshowssignsofoverheating(such
asdeformedplastic)attheacinputoranywhereonthepoweradapter.

Donotuseanypowercordswheretheelectricalcontactsoneitherendshowsignsofcorrosionor
overheatingorwherethepowercordappearstohavebeendamagedinanyway.

2

,orbetter.For

Extensioncordsandrelateddevices

Ensurethatextensioncords,surgeprotectors,uninterruptiblepowersupplies,andpowerstripsthatyouuse
areratedtohandletheelectricalrequirementsoftheproduct.Neveroverloadthesedevices.Ifpowerstrips
areused,theloadshouldnotexceedthepowerstripinputrating.Consultanelectricianformoreinformation
ifyouhavequestionsaboutpowerloads,powerrequirements,andinputratings.

viThinkCentreUserGuide

Plugsandoutlets

Ifareceptacle(poweroutlet)thatyouintendtousewithyourcomputerequipmentappearstobedamaged
orcorroded,donotusetheoutletuntilitisreplacedbyaqualiedelectrician.

Donotbendormodifytheplug.Iftheplugisdamaged,contactthemanufacturertoobtainareplacement.

Donotshareanelectricaloutletwithotherhomeorcommercialappliancesthatdrawlargeamountsof
electricity;otherwise,unstablevoltagemightdamageyourcomputer,data,orattacheddevices.

Someproductsareequippedwithathree-prongedplug.Thisplugtsonlyintoagroundedelectricaloutlet.
Thisisasafetyfeature.Donotdefeatthissafetyfeaturebytryingtoinsertitintoanon-groundedoutlet.If
youcannotinserttheplugintotheoutlet,contactanelectricianforanapprovedoutletadapterortoreplace
theoutletwithonethatenablesthissafetyfeature.Neveroverloadanelectricaloutlet.Theoverallsystem
loadshouldnotexceed80percentofthebranchcircuitrating.Consultanelectricianformoreinformation
ifyouhavequestionsaboutpowerloadsandbranchcircuitratings.

Besurethatthepoweroutletyouareusingisproperlywired,easilyaccessible,andlocatedclosetothe
equipment.Donotfullyextendpowercordsinawaythatwillstressthecords.

Besurethatthepoweroutletprovidesthecorrectvoltageandcurrentfortheproductyouareinstalling.

Carefullyconnectanddisconnecttheequipmentfromtheelectricaloutlet.

Externaldevices

DonotconnectordisconnectanyexternaldevicecablesotherthanUniversalSerialBus(USB)and1394
cableswhilethecomputerpowerison;otherwise,youmightdamageyourcomputer.Toavoidpossible
damagetoattacheddevices,waitatleastvesecondsafterthecomputerisshutdowntodisconnect
externaldevices.

Heatandproductventilation

Computers,poweradapters,andmanyaccessoriescangenerateheatwhenturnedonandwhenbatteries
arecharging.Alwaysfollowthesebasicprecautions:

•Donotleaveyourcomputer,poweradapter,oraccessoriesincontactwithyourlaporanypartofyour
bodyforanextendedperiodwhentheproductsarefunctioningorwhenthebatteryischarging.Your
computer,poweradapter,andmanyaccessoriesproducesomeheatduringnormaloperation.Extended
contactwiththebodycouldcausediscomfortor,potentially,askinburn.

•Donotchargethebatteryoroperateyourcomputer,poweradapter,oraccessoriesnearammable
materialsorinexplosiveenvironments.

•Ventilationslots,fans,andheatsinksareprovidedwiththeproductforsafety,comfort,andreliable
operation.Thesefeaturesmightinadvertentlybecomeblockedbyplacingtheproductonabed,sofa,
carpet,orotherexiblesurface.Neverblock,cover,ordisablethesefeatures.

Inspectyourdesktopcomputerfordustaccumulationatleastonceeverythreemonths.Beforeinspecting
yourcomputer,turnoffthepowerandunplugthecomputer'spowercordfromtheelectricaloutlet;then
removeanydustfromventsandperforationsinthebezel.Ifyounoticeexternaldustaccumulation,then
examineandremovedustfromtheinsideofthecomputerincludingheatsinkinletns,powersupplyvents,
andfans.Alwaysturnoffandunplugthecomputerbeforeopeningthecover.Ifpossible,avoidoperating
yourcomputerwithintwofeetofhigh-trafcareas.Ifyoumustoperateyourcomputerinornearahigh-trafc
area,inspectand,ifnecessary,cleanyourcomputermorefrequently.

©CopyrightLenovo2012

vii

Foryoursafetyandtomaintainoptimumcomputerperformance,alwaysfollowthesebasicprecautions
withyourdesktopcomputer:

•Keepthecoverclosedwheneverthecomputerispluggedin.

•Regularlyinspecttheoutsideofthecomputerfordustaccumulation.

•Removedustfromventsandanyperforationsinthebezel.Morefrequentcleaningsmightberequiredfor
computersindustyorhigh-trafcareas.

•Donotrestrictorblockanyventilationopenings.

•Donotstoreoroperateyourcomputerinsidefurniture,asthismightincreasetheriskofoverheating.

•Airowtemperaturesintothecomputershouldnotexceed35°C(95°F).

•Donotinstallairltrationdevices.Theymayinterferewithpropercooling.

Operatingenvironment

Theoptimalenvironmentinwhichtouseyourcomputeris10°C-35°C(50°F-95°F)withhumidityranging
between35%and80%.Ifyourcomputerisstoredortransportedintemperatureslessthan10°C(50°F),
allowthecoldcomputertoriseslowlytoanoptimaloperatingtemperatureof10°C-35°C(50°F-95°F)before
use.Thisprocesscouldtaketwohoursinextremeconditions.Failuretoallowyourcomputertorisetoan
optimaloperatingtemperaturebeforeusecouldresultinirreparabledamagetoyourcomputer.

Ifpossible,placeyourcomputerinawell-ventilatedanddryareawithoutdirectexposuretosunshine.

Keepelectricalappliancessuchasanelectricfan,radio,high-poweredspeakers,airconditioner,and
microwaveovenawayfromyourcomputerbecausethestrongmagneticeldsgeneratedbythese
appliancescandamagethemonitoranddataontheharddiskdrive.

Donotplaceanybeveragesontopoforbesidethecomputerorotherattacheddevices.Ifliquidisspilledon
orinthecomputeroranattacheddevice,ashortcircuitorotherdamagemightoccur.

Donoteatorsmokeoveryourkeyboard.Particlesthatfallintoyourkeyboardcancausedamage.

Modemsafetyinformation

CAUTION:
Toreducetheriskofre,useonlyNo.26AWGorlarger(forexample,No.24AWG)telecommunication
linecordlistedbyUnderwritersLaboratories(UL)orcertiedbytheCanadianStandardsAssociation
(CSA).

Toreducetheriskofre,electricalshock,orinjurywhenusingtelephoneequipment,alwaysfollowbasic
safetyprecautions,suchas:

•Neverinstalltelephonewiringduringalightningstorm.

•Neverinstalltelephonejacksinwetlocationsunlessthejackisspecicallydesignedforwetlocations.

•Nevertouchuninsulatedtelephonewiresorterminalsunlessthetelephonelinehasbeendisconnectedat
thenetworkinterface.

•Usecautionwheninstallingormodifyingtelephonelines.

•Avoidusingatelephone(otherthanacordlesstype)duringanelectricalstorm.Theremaybearemote
riskofelectricshockfromlightning.

•Donotusethetelephonetoreportagasleakinthevicinityoftheleak.

viiiThinkCentreUserGuide

Lasercompliancestatement

CAUTION:
Whenlaserproducts(suchasCD-ROMs,DVDdrives,beropticdevices,ortransmitters)are
installed,notethefollowing:

•Donotremovethecovers.Removingthecoversofthelaserproductcouldresultinexposureto
hazardouslaserradiation.Therearenoserviceablepartsinsidethedevice.

•Useofcontrolsoradjustmentsorperformanceofproceduresotherthanthosespeciedherein
mightresultinhazardousradiationexposure.

DANGER

SomelaserproductscontainanembeddedClass3AorClass3Blaserdiode.Notethefollowing.

Laserradiationwhenopen.Donotstareintothebeam,donotviewdirectlywithoptical
instruments,andavoiddirectexposuretothebeam.

Powersupplystatement

Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.

Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabelattached.
Therearenoserviceablepartsinsidethesecomponents.Ifyoususpectaproblemwithoneoftheseparts,
contactaservicetechnician.

Cleaningandmaintenance

Keepyourcomputerandworkspaceclean.Shutdownthecomputerandthendisconnectthepower
cordbeforecleaningthecomputer.Donotsprayanyliquiddetergentdirectlyonthecomputeroruse
anydetergentcontainingammablematerialtocleanthecomputer.Spraythedetergentonasoftcloth
andthenwipethecomputersurfaces.

©CopyrightLenovo2012

ix

xThinkCentreUserGuide

Chapter1.Productoverview

Thischapterprovidesinformationaboutthecomputerfeatures,specications,softwareprogramsprovided
byLenovo,andlocationsofconnectors,components,partsonthesystemboard,andinternaldrives.

Features

Thissectionprovidesinformationaboutthecomputerfeatures.Thefollowinginformationcoversavarietyof
models.Forinformationaboutyourspecicmodel,usetheSetupUtilityprogram.SeeChapter7“Using
theSetupUtilityprogram”onpage77

Microprocessor

Yourcomputercomeswithoneofthefollowingmicroprocessors(internalcachesizevariesbymodeltype):

•Intel

®

Core™i3microprocessor

•IntelCorei5microprocessor

•IntelCorei7microprocessor

•IntelCeleron

•IntelPentium

®

microprocessor

®

microprocessor

Memory

.

Yourcomputersupportsupto2doubledatarate3dualinlinememorymodules(DDR3DIMMs).

Internaldrives

•Opticaldrive:DVD-ROMorDVD-R(availableinsomemodels)

•SerialAdvancedT echnologyAttachment(SATA)harddiskdrive

•SATAsolidstatedrive

Videosubsystem

•IntegratedgraphicsforaVideoGraphicsArray(VGA)connectorandaDigitalVideoInterface(DVI)
connector

•PeripheralComponentInterconnect(PCI)Expressx16graphicscardslotonthesystemboardfora
discretegraphicscard

Audiosubsystem

•Integratedhigh-denition(HD)audio

•Audioline-inconnector,audioline-outconnector,andmicrophoneconnectorontherearpanel

•Microphoneconnectorandheadphoneconnectoronthefrontpanel

•Internalspeaker(availableinsomemodels)

Connectivity

•100/1000MbpsintegratedEthernetcontroller

•PCIEx1Faxmodem(somemodels)

Systemmanagementfeatures

©CopyrightLenovo2012

1

•Abilitytostorepower-onself-test(POST)hardwaretestresults

•DesktopManagementInterface(DMI)
DesktopManagementInterfaceprovidesacommonpathforuserstoaccessinformationaboutall

aspectsofacomputer,includingprocessortype,installationdate,attachedprintersandotherperipherals,
powersources,andmaintenancehistory.

•ErPcompliancemode
Theenergy-relatedproductsdirective(ErP)compliancemodereducestheconsumptionofelectricity

whenyourcomputerisinstandbyoroffmode.Formoreinformation,see“EnablingErPcompliance
mode”onpage80.

•PrebootExecutionEnvironment(PXE)
ThePrebootExecutionEnvironmentisanenvironmenttostartcomputersusinganetworkinterface

independentofdatastoragedevices(suchastheharddiskdrive)orinstalledoperatingsystems.

•SystemManagement(SM)BasicInput/OutputSystem(BIOS)andSMsoftware
TheSMBIOSspecicationdenesdatastructuresandaccessmethodsinaBIOSthatallowsauseror

applicationtostoreandretrieveinformationspecicaboutthecomputerinquestion.

•WakeonLAN
WakeonLANisanEthernetcomputernetworkingstandardthatallowsacomputertobeturnedon

orwokenupbyanetworkmessage.Themessageisusuallysentbyaprogramrunningonanother
computeronthesamelocalareanetwork.

•WakeonRing
WakeonRing,sometimesreferredtoasWakeonModem,isaspecicationthatallowssupported

computersanddevicestoresumefromsleeporhibernationmode.

•WindowsManagementInstrumentation(WMI)
WindowsManagementInstrumentationisasetofextensionstotheWindowsDriverModel.Itprovidesan

operatingsysteminterfacethroughwhichinstrumentedcomponentsprovideinformationandnotication.

Input/Output(I/O)features

•9-pinserialport(onestandardandoneoptional)

•SixUniversalSerialBus(USB)connectors(twoonthefrontpanelandfourontherearpanel)

•OneEthernetconnector

•OneDVIconnector

•OneVGAmonitorconnector

•OnePersonalSystem/2(PS/2)keyboardconnector

•OnePS/2mouseconnector

•Threeaudioconnectorsontherearpanel(audioline-inconnector,audioline-outconnector,and
microphoneconnector)

•Twoaudioconnectorsonthefrontpanel(microphoneconnectorandheadphoneconnector)

Formoreinformation,see“Locatingconnectors,controls,andindicatorsonthefrontofyourcomputer”on
page8

and“Locatingconnectorsontherearofyourcomputer”onpage9.

Expansion

•Twoharddiskdrivebays(onestandardandoneoptional)

•Oneopticaldrivebay

•Oneslimcardreaderdrivebay

•TwoPCIExpressx1cardslots

2ThinkCentreUserGuide

•OnePCIExpressx16graphicscardslot

Powersupply

Yourcomputercomeswithoneofthefollowingpowersupplies:

•280-wattpowersupplywithmanualvoltage-selectionswitch

•280-wattautomaticvoltage-sensingpowersupply

•320-wattautomaticvoltage-sensingpowersupply

Securityfeatures

•ComputraceAgentsoftwareembeddedinrmware

•Coverpresenceswitch(alsocalledintrusionswitch)(availableinsomemodels)

•Abilitytoenableordisableadevice

•AbilitytoenableanddisableUSBconnectorsindividually

•Keyboardwithngerprintreader(shippedwithsomemodels)

•Power-onpassword(POP),administratorpassword,andharddiskpasswordtodeterunauthorized
useofyourcomputer

•Startupsequencecontrol

•Startupwithoutkeyboardormouse

•Supportforanintegratedcablelock(Kensingtonlock)

•Supportforapadlock

Formoreinformation,seeChapter4“Security”onpage27

.

Preinstalledsoftwareprograms

Yourcomputerispreinstalledwithsoftwareprogramstohelpyouworkmoreeasilyandsecurely.Formore
information,see“Softwareoverview”onpage4

.

Preinstalledoperatingsystem

Yourcomputerispreinstalledwithoneofthefollowingoperatingsystems:

•Microsoft

®

Windows

•MicrosoftWindowsVista

Operatingsystem(s),certiedortestedforcompatibility

•Linux

®

®

7

®

1

(variesbymodeltype)

•MicrosoftWindowsXPProfessionalSP3

1.Theoperatingsystem(s)listedherearebeingcertiedortestedforcompatibilityatthetimethispublicationgoesto

press.AdditionaloperatingsystemsmightbeidentiedbyLenovoascompatiblewithyourcomputerfollowingthe
publicationofthismanual.Thislistissubjecttochange.Todetermineifanoperatingsystemhasbeencertiedor
testedforcompatibility,checktheWebsiteoftheoperatingsystemvendor.

Chapter1.Productoverview3

Specications

Thissectionliststhephysicalspecicationsforyourcomputer.

Dimensions

Width:160mm(6.3inches)
Height:388mm(15.28inches)
Depth:422mm(16.61inches)

Weight

Maximumcongurationasshipped:8.16kg(17.99lb)(withoutpackage)
Maximumcongurationasshipped:11.66kg(25.71lb)(withpackage)

Environment

•Airtemperature:

Operating:10°Cto35°C(50°Fto95°F)
Non-operating:-40°Cto60°C(-40°Fto140°F)
Non-operating:-10°Cto60°C(14°Fto140°F)(withoutpackage)

•Humidity:

Operating:20%to80%(non-condensing)
Non-operating:20%to90%(non-condensing)

•Altitude:

Operating:-50to10000ft(-15.2to3048m)
Non-operating:-50to35000ft(-15.2to10668m)

Electricalinput

•Inputvoltage:
–Lowrange:

Minimum:100Vac
Maximum:127Vac
Inputfrequencyrange:50to60Hz
Voltage-selectionswitchsetting:115Vac

–Highrange:

Minimum:200Vac
Maximum:240Vac
Inputfrequencyrange:50to60Hz
Voltage-selectionswitchsetting:230Vac

Softwareoverview

Thecomputercomeswithapreinstalledoperatingsystemandseveralsoftwareprogramsprovidedby
Lenovo.

4ThinkCentreUserGuide

SoftwareprovidedbyLenovo

ThefollowingsoftwareprogramsareprovidedbyLenovotohelpyouimproveproductivityandreducethe
costassociatedwithmaintainingyourcomputer.Softwareprogramsprovidedwithyourcomputermight
varydependingonyourcomputermodeltypeandpreinstalledoperatingsystem.

LenovoThinkVantageT ools

TheLenovoThinkVantage
accesstovarioustoolstohelpyouworkmoreeasilyandsecurely.

Note:TheLenovoThinkVantageToolsprogramisonlyavailableoncomputerswiththeWindows7operating
systemfromLenovo.

ToaccesstheLenovoThinkVantageToolsprogram,clickStart➙AllPrograms➙LenovoThinkVantage
Tools.

ThefollowingtableliststheprogramsthatyoucanaccessfromtheLenovoThinkVantageToolsprogram.To
accessaprogram,double-clickthecorrespondingicon.

Table1.ProgramiconnamesinLenovoThinkVantageT ools

CreateRecoveryMedia

FingerprintSoftware(availableonsomemodels)FingerprintReader(availableonsomemodels)

LenovoSolutionCenterorLenovoThinkVantageToolboxSystemHealthandDiagnostics
ThinkVantagePasswordManagerPasswordVault
ThinkVantagePowerManager

ThinkVantageRescueandRecovery

ThinkVantageSystemUpdate
ViewManagerViewManager

®

Toolsprogramguidesyoutoahostofinformationsourcesandprovideseasy

ProgramnameIconnameinLenovoThinkVantageTools

FactoryRecoveryDisks

PowerControls

®

EnhancedBackupandRestore
UpdateandDrives

LenovoWelcome

TheLenovoWelcomeprogramintroducesyoutosomeinnovativebuilt-infeaturesofLenovoandguidesyou
throughafewimportantsetuptaskstohelpyoumakethemostofyourcomputer.

FingerprintSoftware

Theintegratedngerprintreaderprovidedonsomekeyboardsenablesyoutoenrollyourngerprintand
associateitwithyourpower-onpassword,harddiskpassword,andWindowspassword.Asaresult,
ngerprintauthenticationcanreplacepasswordsandenablesimpleandsecureuseraccess.Angerprint
readerkeyboardisavailablewithselectcomputersorcanbepurchasedforcomputersthatsupportthis
option.

LenovoSolutionCenter

Note:Dependingonthedatewhenyourcomputerwasmanufactured,yourcomputerispreinstalledwith

eithertheLenovoSolutionCenterprogramortheLenovoThinkVantageToolboxprogramfordiagnostic
purposes.ForadditionalinformationabouttheLenovoThinkVantageToolboxprogram,see“Lenovo
ThinkVantageToolbox”onpage111.

TheLenovoSolutionCenterprogramenablesyoutotroubleshootandresolvecomputerproblems.It
combinesdiagnostictests,systeminformationcollection,securitystatus,andsupportinformation,along
withhintsandtipsformaximumsystemperformance.See“LenovoSolutionCenter”onpage111
detailedinformation.

Chapter1.Productoverview5

for

LenovoThinkVantageT oolbox

Note:Dependingonthedatewhenyourcomputerwasmanufactured,yourcomputerispreinstalledwith

eithertheLenovoSolutionCenterprogramortheLenovoThinkVantageToolboxprogramfordiagnostic
purposes.ForadditionalinformationabouttheLenovoSolutionCenterprogram,see“LenovoSolution
Center”onpage111.

TheLenovoThinkVantageToolboxprogramhelpsyoumaintainyourcomputer,improvecomputingsecurity,
diagnosecomputerproblems,getfamiliarwiththeinnovativetechnologiesprovidedbyLenovo,andgetmore
informationaboutyourcomputer.See“LenovoThinkVantageToolbox”onpage111fordetailedinformation.

ProductRecovery

TheProductRecoveryprogramenablesyoutorestorethecontentsoftheharddiskdrivetothefactory
defaultsettings.

ThinkVantageClientSecuritySolution

TheThinkVantageClientSecuritySolutionprogramisavailableonselectLenovocomputers.Ithelpsprotect
yourinformation,includingvitalsecurityinformationlikepasswords,encryptionkeys,andelectronic
credentials,whileguardingagainstunauthorizeduseraccesstodata.

Note:TheThinkVantageClientSecuritySolutionprogramisonlyavailableoncomputerswiththeWindows
VistaoperatingsystemfromLenovo.

ThinkVantagePasswordManager

TheThinkVantagePasswordManagerprogramautomaticallycapturesandllsinauthenticationinformation
forWindowsapplicationsandWebsites.

Notes:

•TheThinkVantagePasswordManagerprogramisonlyavailableoncomputerspreinstalledwiththe
Windows7operatingsystemfromLenovo.

•IfthePasswordVaulticonintheLenovoThinkVantageToolsprogramisdimmed,itindicatesthatyou
needtoinstalltheThinkVantagePasswordManagerprogrammanuallybeforeenablingitsfeatures.To
installtheThinkVantagePasswordManagerprogram,dothefollowing:

1.ClickStart➙AllPrograms➙LenovoThinkVantageT ools,anddouble-clickPasswordVault.

2.Followtheinstructionsonthescreen.

3.Whentheinstallationprocesscompletes,thePasswordVaulticonisactivated.

ThinkVantagePowerManager

TheThinkVantagePowerManagerprogramprovidesconvenient,exible,andcompletepowermanagement
foryourThinkCentre®computer.ByusingtheThinkVantagePowerManagerprogram,youcanadjustyour
powersettingstoachievethebestbalancebetweensystemperformanceandpowersaving.

ThinkVantageRescueandRecovery

TheThinkVantageRescueandRecoveryprogramisaonebuttonrecoveryandrestoresolutionthatincludes
asetofself-recoverytoolstohelpyoudiagnosecomputerproblems,gethelp,andrecoverfromsystem
crashes,evenifyoucannotstarttheWindowsoperatingsystem.

Note:IftheEnhancedBackupandRestoreiconintheLenovoThinkVantageToolsprogramisdimmed,it
indicatesthatyouneedtoinstalltheThinkVantageRescueandRecoveryprogrammanuallybeforeenabling
itsfeatures.T oinstalltheThinkVantageRescueandRecoveryprogram,dothefollowing:

1.ClickStart➙AllPrograms➙LenovoThinkVantageTools,anddouble-clickEnhancedBackup
andRestore.

2.Followtheinstructionsonthescreen.

6ThinkCentreUserGuide

3.Whentheinstallationprocesscompletes,theEnhancedBackupandRestoreiconisactivated.

ThinkVantageSystemUpdate

TheThinkVantageSystemUpdateprogramhelpsyoukeepthesoftwareonyourcomputerup-to-dateby
downloadingandinstallingsoftwarepackages(ThinkVantageapplications,devicedrivers,BIOSupdates,
andotherthirdpartyapplications).

ViewManager

TheViewManagerprogramenablesyoutoautomatewindowlocations.Itenhancesproductivityby
providingtheabilitytomovewindowstohotcornersandquicklysnapthemtoapredeterminedsize.
Itenablesyoutoworkacrossmultiplemonitors.

AdobeReader

TheAdobeReaderprogramisatoolusedtoview,print,andsearchPDFdocuments.

Antivirussoftware

Yourcomputercomeswithantivirussoftwarethatyoucanusetodetectandeliminateviruses.Lenovo
providesafullversionofantivirussoftwareonyourharddiskdrivewithafree30-daysubscription.After30
days,youmustrenewthelicensetocontinuereceivingtheantivirusprogramupdates.

Locations

Thissectionprovidesinformationtohelpyoulocatetheconnectorsonthefrontandrearofyourcomputer,
partsonthesystemboard,andcomponentsandinternaldrivesinyourcomputer.

Chapter1.Productoverview7

Locatingconnectors,controls,andindicatorsonthefrontofyour
computer

Figure1“Frontconnector,control,andindicatorlocations”onpage8showsthelocationsoftheconnectors,
controls,andindicatorsonthefrontofyourcomputer.

Figure1.Frontconnector,control,andindicatorlocations

1Harddiskdriveactivityindicator

2Powerindicator6Headphoneconnector
3Powerswitch7Microphoneconnector

4Opticaldriveeject/closebutton8USBconnector(USBport2)

5USBconnector(USBport1)

8ThinkCentreUserGuide

Locatingconnectorsontherearofyourcomputer

Figure2“Rearconnectorlocations”onpage9showsthelocationsoftheconnectorsontherearofyour
computer.Someconnectorsontherearofyourcomputerarecolor-codedtohelpyoudeterminewhereto
connectthecablesonyourcomputer.

Figure2.Rearconnectorlocations

1Voltage-selectionswitch(availableonsome

10PCIExpressx16graphicscardslot

models)

2Powercordconnector

3PS/2keyboardconnector12Integratedcablelock(Kingstonlock)slot
4DVImonitorconnector13Padlockloop

5VGAmonitorconnector14Optionalserialport(Serialport2)

6USBconnectors(USBports3to6)
7Microphoneconnector

8Audioline-outconnector

9Audioline-inconnector

11PCIExpressx1cardslots(2)

15Ethernetconnector

16Serialport(Serialport1)

17PS/2mouseconnector

ConnectorDescription

Audioline-inconnector

Usedtoreceiveaudiosignalsfromanexternalaudiodevice,suchasastereo
system.Whenyouattachanexternalaudiodevice,acableisconnectedbetween
theaudioline-outconnectorofthedeviceandtheaudioline-inconnectorofthe
computer.

Audioline-outconnector

Usedtosendaudiosignalsfromthecomputertoexternaldevices,suchaspowered
stereospeakers(speakerswithbuilt-inampliers),headphones,multimedia
keyboards,ortheaudioline-inconnectoronastereosystemorotherexternal
recordingdevice.

Chapter1.Productoverview9

ConnectorDescription

DVImonitorconnectorUsedtoattachaDVImonitororotherdevicesthatuseaDVImonitorconnector.
Ethernetconnector

Microphoneconnector

PS/2keyboardconnectorUsedtoattachakeyboardthatusesaPS/2keyboardconnector.

PS/2mouseconnectorUsedtoattachamouse,atrackball,orotherpointingdevicesthatuseaPS/2

Serialport

USBconnectorUsedtoattachadevicethatrequiresaUSBconnector,suchasaUSBkeyboard,a

VGAmonitorconnectorUsedtoattachaVGAmonitororotherdevicesthatuseaVGAmonitorconnector.

UsedtoattachanEthernetcableforalocalareanetwork(LAN).
Note:T ooperatethecomputerwithinFCCClassBlimits,useaCategory5Ethernet
cable.

Usedtoattachamicrophonetoyourcomputerwhenyouwanttorecordsoundorif
youusespeech-recognitionsoftware.

mouseconnector.
Usedtoattachanexternalmodem,aserialprinter,orotherdevicesthatusea

9-pinserialport.

USBmouse,aUSBscanner,oraUSBprinter.IfyouhavemorethaneightUSB
devices,youcanpurchaseaUSBhub,whichyoucanusetoconnectadditional
USBdevices.

10ThinkCentreUserGuide

Locatingcomponents

Figure3“Componentlocations”onpage11showsthelocationsofthevariouscomponentsinyour
computer.Toremovethecomputercover,see“Removingthecomputercover”onpage34.

Figure3.Componentlocations

1Heatsinkandfanassembly
2Microprocessor

3Memorymodules

4Frontbezel

5Opticaldrive

6FrontaudioandUSBassembly

7Harddiskdrive(orsolidstatedrive)

8PCIcard(installedinsomemodels)

9Systemboard
10Rearfanassembly
11Powersupplyassembly

Locatingpartsonthesystemboard

Yourcomputercomeswitheitherofthefollowingtypesofsystemboard.

Chapter1.Productoverview11

Figure4“Systemboardpartlocations”onpage12showsthelocationsofthepartsononetypeofsystem
board.

Figure4.Systemboardpartlocations

14-pinpowerconnector

2Microprocessor

12SATAconnectors(3)

13FrontUSBconnector2(forconnectinganadditionalUSB

device)

3Microprocessorfanconnector

14ClearCMOS(ComplementaryMetalOxideSemiconductor)

/Recoveryjumper

4Memoryslot1(DIMM1)

5Memoryslot2(DIMM2)16Coverpresenceswitchconnector(Intrusionswitch

15Battery

connector)

6Thermalsensorconnector

724-pinpowerconnector18Frontaudioconnector
8Powerfanconnector
9Parallelconnector

10Frontpanelconnector(forconnectingLED

17Serial(COM2)connector

19Internalspeakerconnector

20PCIExpressx1cardslots(2)

21PCIExpressx16graphicscardslot

indicatorsandthepowerswitch)

11FrontUSBconnector1(forconnectingUSB

22Systemfanconnector

connectors1and2onthefrontbezel)

12ThinkCentreUserGuide

Figure5“Systemboardpartlocations”onpage13showsthelocationsofthepartsontheothertype
ofsystemboard.

Figure5.Systemboardpartlocations

14-pinpowerconnector

2Microprocessor

13SATAconnectors(4)

14FrontUSBconnector1(forconnectingUSBconnectors1

and2onthefrontbezel)

3Microprocessorfanconnector

15FrontUSBconnector2(forconnectinganadditionalUSB

device)

4Memoryslot1(DIMM1)16Serial(COM2)connector

5Memoryslot2(DIMM2)
6Thermalsensorconnector18Frontaudioconnector
724-pinpowerconnector

8Battery

9Parallelconnector

10Powerfanconnector

17Internalspeakerconnector

19PCIcardslots(2)

20PCIExpressx1cardslot

21PCIExpressx16graphicscardslot

22Coverpresenceswitchconnector(Intrusionswitch

connector)

11ClearCMOS(ComplementaryMetalOxide

23Systemfanconnector

Semiconductor)/Recoveryjumper

12Frontpanelconnector(forconnectingLED

indicatorsandthepowerswitch)

Chapter1.Productoverview13

Locatinginternaldrives

Internaldrivesaredevicesthatyourcomputerusestoreadandstoredata.Youcanadddrivestoyour
computertoincreasestoragecapacityandenableyourcomputertoreadothertypesofmedia.Internal
drivesareinstalledinbays.Inthismanual,thebaysarereferredtoasbay1,bay2,andsoon.

Wheninstallingorreplacinganinternaldrive,itisimportanttonotethetypeandsizeofthedrivethatyou
caninstallorreplaceineachbayandcorrectlyconnectthecablestothedriveinstalled.Refertothe
appropriatesectionin“Installingorreplacinghardware”onpage33forinstructionsonhowtoinstallor
replaceinternaldrivesforyourcomputer.

Figure6“Drivebaylocations”onpage14

Figure6.Drivebaylocations

showsthelocationsofthedrivebays.

1Bay1-Opticaldrivebay(withanopticaldriveinstalledinsomemodels)

2Bay2-Slimcardreaderdrivebay

3Bay3-PrimarySATAharddiskdrivebay(forinstallinga3.5-inchharddiskdriveora2.5-inchsolidstatedrive)

4Bay4-SecondarySATAharddiskdrivebay(forinstallinga3.5-inchharddiskdriveora2.5-inchsolidstatedrive)

14ThinkCentreUserGuide

Machinetypeandmodellabel

Themachinetypeandmodellabelidentiesyourcomputer.WhenyoucontactLenovoforhelp,themachine
typeandmodelinformationhelpssupporttechnicianstoidentifyyourcomputerandprovidefasterservice.

Thefollowingisasampleofthemachinetypeandmodellabel.

Figure7.Machinetypeandmodellabel

Chapter1.Productoverview15

16ThinkCentreUserGuide

Chapter2.Usingyourcomputer

Thischapterprovidesinformationonusingsomeofthecomputercomponents.

Frequentlyaskedquestions

Thefollowingareafewtipsthatwillhelpyouoptimizetheuseofyourcomputer.

CanIgetmyuserguideinanotherlanguage?

TheuserguideisavailableinvariouslanguagesontheLenovoSupportWebsiteat:
http://www.lenovo.com/ThinkCentreUserGuides

Wherearemyrecoverydiscs?

Lenovoprovidesaprogramthatenablesyoutocreaterecoverydiscs.Fordetailsaboutcreatingrecovery
discs,see“Creatingrecoverymedia”onpage69.

Additionally,incaseofaharddiskfailure,youcanorderProductRecoverydiscsfromtheLenovoCustomer
SupportCenter.ForinformationaboutcontactingtheCustomerSupportCenter,seeChapter11“Getting
information,help,andservice”onpage113.BeforeusingtheProductRecoverydiscs,refertothe
documentationthatcomeswiththediscs.

Attention:AProductRecoverydiscpackagemightcontainmultiplediscs.Makesureyouhaveallofthe
discsreadybeforestartingtherecoveryprocess.Duringtherecoveryprocess,youmightbeprompted
tochangediscs.

WherecanIndhelpabouttheWindowsoperatingsystem?

TheWindowsHelpandSupportinformationsystemprovidesyoudetailedinformationaboutusingthe
Windowsoperatingsystemtohelpyougetthemostofyourcomputer.ToaccesstheWindowsHelpand
Supportinformationsystem,clickStart➙HelpandSupport.

Usingthekeyboard

Dependingonyourmodel,yourcomputercomeswitheitherastandardkeyboardorangerprintreader
keyboard.TheMicrosoftWindowsshortcutkeysareprovidedonbothkeyboardtypes.

Thissectionprovidesinformationaboutthefollowingtopics:

•“UsingWindowsshortcutkeys”onpage17

•“Usingangerprintreader”onpage18

UsingWindowsshortcutkeys

Boththestandardkeyboardandthengerprintreaderkeyboardprovidethreekeysyoucanusewithyour
MicrosoftWindowsoperatingsystem.

•ThetwoStartmenukeysarelocatedbesidetheAltkeyoneithersideofthespacebar.Theyfeaturethe
Windowslogo.Whenyoupresseither,theWindowsStartmenuopens.ThestyleoftheWindowslogo
variesdependingonthekeyboardtype.

•Thecontext-menukeyislocatednexttotheCtrlkeyontherightsideoftheSpacebar.Pressingthe
context-menukeyopensthecontextmenufortheactiveprogram,icon,orobject.

©CopyrightLenovo2012

17

Note:YoucanusethemouseortheUpandDownarrowkeystohighlightmenuselections.Youcanclose
theStartmenuorthecontextmenubyclickingthemouseorpressingEsc.

Usingangerprintreader

Somecomputersmightcomewithakeyboardthathasangerprintreader.Formoreinformationaboutthe
ngerprintreader,see“FingerprintSoftware”onpage5.

ToopentheThinkVantageFingerprintSoftwareprogramandusethengerprintreader,dooneofthe
following:

•OntheWindows7operatingsystem,clickStart➙AllPrograms➙LenovoThinkVantageTools➙
FingerprintReader.

•OntheWindowsVistaoperatingsystem,clickStart➙AllPrograms➙ThinkVantage➙ThinkVantage
FingerprintSoftware.

Followtheinstructionsonthescreen.Foradditionalinformation,refertotheThinkVantageFingerprint
Softwarehelpsystem.

Usingthewheelmouse

Thewheelmousehasthefollowingcontrols:

1PrimarymousebuttonUsethisbuttontoselectorstartaprogramormenuitem.
2Wheel

3Secondarymousebutton

Youcanswitchthefunctionoftheprimaryandsecondarymousebuttonsandchangeotherdefaultbehavior
throughthemousepropertiesfunctionintheWindowsControlPanel.

Usethewheeltocontrolthescrollingactionofthemouse.Thedirectioninwhichyou
rotatethewheelcontrolsthedirectionofthescrollingaction.

Usethisbuttontodisplayamenufortheactiveprogram,icon,orobject.

Adjustingaudio

Soundisanimportantpartofthecomputerexperience.Yourcomputerhasadigitalaudiocontrollerbuilt
intothesystemboard.Somemodelsalsohaveahigh-performanceaudioadapterinstalledinoneofthePCI
cardslots.

Aboutyourcomputeraudio

Ifafactory-installed,high-performanceaudioadapterisinstalledinyourcomputer,thesystem-board
audioconnectorsontherearofthecomputeraretypicallydisabled;usetheconnectorsprovidedonthe
audioadapter.

18ThinkCentreUserGuide

Eachaudiosolutionprovidesatleastthreeaudioconnectors:audioline-inconnector,audioline-out
connector,andMicrophoneconnector.Onsomemodels,afourthconnectorisprovidedfortheattachment
ofunpoweredstereospeakers(speakersthatdonotrequireanacpowersource).Theaudioadapter
providesyouwiththeabilitytorecordandplaybacksoundandmusic,aswellastoenjoysoundwith
multimediaapplicationsandworkwithspeech-recognitionsoftware.

Optionally,youcanconnectasetofpoweredstereospeakerstotheaudioline-outconnectortoenjoy
bettersoundwithmultimediaapplications.

Settingthevolumefromthedesktop

Thedesktopvolumecontrolisaccessiblethroughthevolumeiconinthetaskbar,whichislocatedatthe
bottom-rightcorneroftheWindowsdesktop.Clickthevolumeiconandmovethesliderupordownto
controlthevolume,orclicktheMuteicontoturntheaudiooff.Ifthevolumeiconisnotinthetaskbar,see
“Addingthevolumeicontothetaskbar”onpage19.

Addingthevolumeicontothetaskbar

ToaddthevolumeicontothetaskbarontheWindows7operatingsystem,dothefollowing:

1.FromtheWindowsdesktop,clickStart➙ControlPanel➙AppearanceandPersonalization.

2.IntheTaskbarandStartMenutopic,clickCustomizeiconsonthetaskbar.

3.ClickTurnsystemiconsonoroffandchangethevolumebehaviorsfromOfftoOn.

4.ClickOKtosavethenewsettings.

ToaddthevolumeicontothetaskbarontheWindowsVistaoperatingsystem,dothefollowing:

1.FromtheWindowsdesktop,clickStart➙ControlPanel➙AppearanceandPersonalization.

2.IntheTaskbarandStartMenutopic,clickCustomizeiconsonthetaskbar.

3.OntheNoticationAreatab,selectVolumetoallowtheicontodisplay.

4.ClickApplytosavethenewsettings.

SettingthevolumefromControlPanel

YoucansetthecomputervolumefromControlPanel.TosetthecomputervolumefromControlPanel,
dothefollowing:

1.FromtheWindowsdesktop,clickStart➙ControlPanel➙HardwareandSound.

2.IntheSoundtopic,clickAdjustsystemvolume.

3.Movetheslidersupordowntoraiseorlowerthevolumeofyourcomputer.

UsingCDsandDVDs

YourcomputermighthaveaDVDROMdriveorrecordableDVDdriveinstalled.DVDdrivesuse
industry-standard,12cm(4.75-inch)CDmediaorDVDmedia.IfyourcomputercomeswithaDVDdrive,
thedrivecanreadDVD-ROMdiscs,DVD-Rdiscs,DVD-RAMdiscs,DVD-RWdiscs,andalltypesofCDs,
suchasCD-ROMdiscs,CD-RWdiscs,CD-Rdiscs,andaudioCDs.IfyouhavearecordableDVDdrive,
itcanalsorecordonDVD-Rdiscs,DVD-RWdiscs,typeIIDVD-RAMdiscs,CD-RWstandardandhigh
speeddiscs,andCD-Rdiscs.

FollowtheseguidelineswhenusingtheDVDdrive:

•Donotplacethecomputerinalocationwherethedriveisexposedtothefollowing:
–Hightemperature

–Highhumidity

Chapter2.Usingyourcomputer19

–Excessivedust
–Excessivevibrationorsuddenshock
–Aninclinedsurface
–Directsunlight

•DonotinsertanyobjectotherthanaCDorDVDintothedrive.

•Beforemovingthecomputer,removetheCDorDVDfromthedrive.

HandlingandstoringCDandDVDmedia

CDandDVDmediaaredurableandreliable,buttheydorequiresomecareandspecialhandling.When
handlingandstoringaCDorDVD,followtheseguidelines:

•Holdthediscbyitsedges.Donottouchthesurfaceofthesidethatisnotlabeled.

•Toremovedustorngerprints,wipethediscwithaclean,softclothfromthecentertotheoutside.Wiping
thediscinacirculardirectionmightcauselossofdata.

•Donotwriteorstickpaperonthedisc.

•Donotscratchormarkthedisc.

•Donotplaceorstorethediscindirectsunlight.

•Donotusebenzene,thinners,orothercleanerstocleanthedisc.

•Donotdroporbendthedisc.

•Donotinsertdamageddiscsintothedrive.Warped,scratched,ordirtydiscscandamagethedrive.

PlayingaCDorDVD

IfyourcomputercomeswithaDVDdrive,youcanlistentoaudioCDsorwatchDVDmovies.Toplaya
CDorDVD,dothefollowing:

1.PresstheEject/LoadbuttonontheDVDdrivetoopenthetray.

2.Withthetrayfullyextended,inserttheCDorDVDintothetray.SomeDVDdriveshaveasnaphubinthe
centerofthetray.Ifyourdrivehasasnaphub,supportthetraywithonehandandthenpushonthe
centeroftheCDorDVDuntilitsnapsintoplace.

3.PresstheEject/Loadbuttonagainorgentlypushthetrayforwardtoclosethetray.TheCDorDVD
playerprogramstartsautomatically.Foradditionalinformation,refertotheCDorDVDplayerprogram
helpsystem.

ToremoveaCDorDVDfromtheDVDdrive,dothefollowing:

1.Withthecomputeron,presstheEject/Loadbutton.Whenthetrayslidesoutautomatically,carefully
removethedisc.

2.ClosethetraybypressingtheEject/Loadbuttonorbygentlypushingthetrayforward.

Note:IfthetraydoesnotslideoutofthedrivewhenyoupresstheEject/Loadbutton,insertastraightened
paperclipintotheemergency-ejectholelocatedonthefrontoftheDVDdrive.Besurethedriveispowered
offwhenusingtheemergencyeject.UsetheEject/Loadbuttoninsteadoftheemergencyejectexcept
inanemergency.

RecordingaCDorDVD

IfyourcomputercomeswitharecordableDVDdrive,youcanusethedrivetorecordCDsorDVDs.To
recordaCDorDVD,dothefollowing:

1.ClickStart➙AllPrograms➙CorelDVDMovieFactoryLenovoEdition.

2.Followtheinstructionsonthescreen.

20ThinkCentreUserGuide

FordetailedinformationaboutusingtheCorelDVDMovieFactoryprogram,seethehelpsystemforthe
program.

YoucanalsouseWindowsMediaPlayertorecordCDsanddataDVDs.Formoreinformation,see“Helpand
Support”onpage113.

Chapter2.Usingyourcomputer21

22ThinkCentreUserGuide

Chapter3.Youandyourcomputer

Thischapterprovidesinformationaboutaccessibility,comfort,andrelocatingyourcomputertoother
countriesorregions.

Accessibilityandcomfort

Goodergonomicpracticeisimportanttogetthemostfromyourpersonalcomputerandtoavoiddiscomfort.
Arrangeyourworkplaceandtheequipmentyouusetosuityourindividualneedsandthekindofwork
thatyouperform.Inaddition,usehealthyworkhabitstomaximizeyourperformanceandcomfortwhile
usingyourcomputer.

Thefollowingtopicsprovideinformationaboutarrangingyourworkarea,settingupyourcomputer
equipment,andestablishinghealthyworkhabits:

Lenovoiscommittedtoprovidingpeoplewithdisabilitiesgreateraccesstoinformationandtechnology.
Asaresult,thefollowinginformationprovideswaystohelpusersthathavehearing,vision,andmobility
limitationsgetthemostoutoftheircomputerexperience.

Assistivetechnologiesenableuserstoaccessinformationinthemostappropriateway.Someofthese
technologiesarealreadyprovidedinyouroperatingsystem,otherscanbepurchasedthroughvendors,or
accessedthroughtheWorldWideWeb:
http://www.lenovo.com/healthycomputing

Arrangingyourworkspace

Togetthemostfromyourcomputer,arrangeboththeequipmentyouuseandyourworkareatosuityour
needsandthekindofworkyoudo.Yourcomfortisofforemostimportance,butlightsources,aircirculation,
andthelocationofelectricaloutletscanalsoaffectthewayyouarrangeyourworkspace.

Comfort

Althoughnosingleworkingpositionisidealforeveryone,hereareafewguidelinestohelpyounda
positionthatsuitsyoubest.

Sittinginthesamepositionforalongtimecancausefatigue.Thebackrestandseatofyourchairshould
adjustindependentlyandprovidegoodsupport.Theseatshouldhaveacurvedfronttorelievepressureon
thethighs.Adjusttheseatsothatyourthighsareparalleltotheoorandyourfeetareeitheratonthe
oororonafootrest.

Whenusingthekeyboard,keepyourforearmsparalleltotheoorandyourwristsinacomfortableposition.
Usealighttouchonthekeyboardandyourhandsandngersrelaxed.Changetheangleofthekeyboard
formaximumcomfortbyadjustingthepositionofthekeyboardfeet.

©CopyrightLenovo2012

23

Adjustthemonitorsothetopofthescreenisat,orslightlybelow,eyelevel.Placethemonitorata
comfortableviewingdistance,usually51to61cm(20to24inches),andpositionitsoyoucanviewit
withouthavingtotwistyourbody.Also,positionotherequipmentyouuseregularly,suchasthetelephoneor
amouse,withineasyreach.

Glareandlighting

Positionthemonitortominimizeglareandreectionsfromoverheadlights,windows,andotherlightsources.
Reectedlightfromshinysurfacescancauseannoyingreectionsonyourmonitorscreen.Placethe
monitoratrightanglestowindowsandotherlightsources,whenpossible.Reduceoverheadlighting,if
necessary,byturningofflightsorusinglowerwattagebulbs.Ifyouinstallthemonitornearawindow,use
curtainsorblindstoblockthesunlight.Y oucanadjustthebrightnessandcontrastcontrolsonthemonitor
astheroomlightingchangesthroughouttheday.

Whereitisimpossibletoavoidreectionsortoadjustthelighting,anantiglarelterplacedoverthescreen
mightbehelpful.However,theseltersmightaffecttheclarityoftheimageonthescreen;trythemonlyafter
youhaveexhaustedothermethodsofreducingglare.

Dustbuildupcompoundsproblemsassociatedwithglare.Remembertocleanyourmonitorscreen
periodicallyusingasoftclothasdirectedinyourmonitordocumentation.

Aircirculation

Yourcomputerandmonitorproduceheat.Thecomputerhasafanthatpullsinfreshairandforcesouthot
air.Themonitorletshotairescapethroughvents.Blockingtheairventscancauseoverheating,whichmight
resultinamalfunctionordamage.Placethecomputerandmonitorsothatnothingblockstheairvents;
usually,51mm(2inches)ofairspaceissufcient.Also,makesuretheventedairisnotblowingonpeople.

Electricaloutletsandcablelengths

Thelocationofelectricaloutlets,thelengthofpowercordsandcablesthatconnecttothemonitor,printer,
andotherdevicesmightdeterminethenalplacementofyourcomputer.

Whenarrangingyourworkspace:

•Avoidtheuseofextensioncords.Whenpossible,plugthecomputerpowercorddirectlyintoanelectrical
outlet.

•Keeppowercordsandcablesneatlyroutedawayfromwalkwaysandotherareaswheretheymight
getkickedaccidentally.

Formoreinformationaboutpowercords,see“Powercordsandpoweradapters”onpagevi

24ThinkCentreUserGuide

.

Registeringyourcomputer

Whenyouregisteryourcomputer,informationisenteredintoadatabase,whichenablesLenovotocontact
youincaseofarecallorothersevereproblem.AfteryouregisteryourcomputerwithLenovo,youwillreceive
quickerservicewhenyoucallLenovoforhelp.Inaddition,somelocationsofferextendedprivilegesand
servicestoregisteredusers.

ToregisteryourcomputerwithLenovo,dooneofthefollowing:

•ConnectyourcomputertotheInternetandregisteryourcomputerthroughthepreinstalledLenovo
ProductRegistrationprogram.Theprogramlaunchesautomaticallyafteryouhaveusedyourcomputer
foratime.Followtheinstructionsonthescreentoregisteryourcomputer.

•Gotohttp://www.lenovo.com/registerandfollowtheinstructionsonthescreentoregisteryourcomputer.

Movingyourcomputertoanothercountryorregion

Whenyoumoveyourcomputertoanothercountryorregion,youmusttakelocalelectricalstandardsinto
consideration.Thissectionprovidesinformationonthefollowing:

•“Voltage-selectionswitch”onpage25

•“Replacementpowercords”onpage26

Voltage-selectionswitch

Somecomputersareequippedwithavoltage-selectionswitchlocatednearthepower-cordconnection
pointonthecomputerandsomecomputersdonothaveavoltage-selectionswitch.Beforeyouinstall
yourcomputerorrelocateyourcomputertoanothercountryorregion,youmustbecertainthatyouhave
matchedyourcomputertothevoltageavailableatyourelectricaloutlet.

CAUTION:
Youmustknowthevoltageoftheelectricalconnection(outlet)whereyourcomputerwillbe
connected.Ifyoudonotknowthevoltage,contactyourlocalelectriccompanyorrefertoofcial
Websitesorotherliteraturefortravelerstothecountryorregionwhereyouarelocated.

Ifyourcomputerhasavoltage-selectionswitch,youmustsettheswitchtomatchthevoltageavailableat
yourelectricaloutlet.Settingthevoltage-selectionswitchincorrectlywillcausethecomputertomalfunction
andmightcausepermanentdamagetothecomputer.Donotconnectthecomputertoanelectrical
outletuntilyouhaveveriedthatthevoltage-selectionswitchsettingmatchesthevoltageavailableatthe
electricaloutlets.

Ifyourcomputerdoesnothaveavoltage-selectionswitch,inspectthevoltage-ratinglabelonthebottomof
thecomputerandnotethefollowing:

•Ifthevoltage-ratinglabelshowsarangeofeither“100-127V”or“200-240V,”youmustensurethatthe
voltageprovidedattheelectricaloutletmatchesthevoltageratingonthecomputerlabel.Ifitdoes
notmatch,donotattempttoconnectthecomputertotheelectricaloutlet,unlessanexternaldevice
suchasavoltage-convertingtransformerisused.

•Ifthevoltage-ratinglabelshowsadualrangeof“100-127V”and“200-240V,”thissigniesthatthe
computerissuitableforworldwideoperationandthecomputerwillautomaticallyadjusttothevoltageat
theelectricaloutletregardlessofthecountryorregionwherethecomputerisbeingconnected.

Chapter3.Youandyourcomputer25

Replacementpowercords

Ifyourelocateyourcomputertoacountryorregionthatusesanelectricaloutletstyledifferentfromthe
typeyouarecurrentlyusing,youwillhavetopurchaseeitherelectricalplugadaptersornewpowercords.
YoucanorderpowercordsdirectlyfromLenovo.

Forpowercordinformationandpartnumbers,goto:
http://www.lenovo.com/powercordnotice

26ThinkCentreUserGuide

Chapter4.Security

Thischapterprovidesinformationabouthowtoprotectyourcomputerfromtheftandunauthorizeduse.

Securityfeatures

Thefollowingsecurityfeaturesareavailableonyourcomputer:

•ComputraceAgentsoftwareembeddedinrmware
TheComputraceAgentsoftwareisanITassetmanagementandcomputertheftrecoverysolution.

Thesoftwaredetectsifchangeshavebeenmadeonthecomputer,suchashardware,software,or
thecomputercall-inlocation.

Note:YoumighthavetopurchaseasubscriptiontoactivatetheComputraceAgentsoftware.

•Coverpresenceswitch(alsocalledintrusionswitch)
Thecoverpresenceswitchpreventsyourcomputerfromloggingintotheoperatingsystemwhenthe

computercoverisnotproperlyinstalledorclosed.Toenablethecoverpresenceswitchconnector
onthesystemboard,tothefollowing:

1.StarttheSetupUtilityprogram.See“StartingtheSetupUtilityprogram”onpage77.

2.SettheAdministratorPassword.See“Setting,changing,anddeletingapassword”onpage78.

3.FromtheSecuritysubmenu,selectChassisIntrusionDetection➙Enabled.Thecoverpresence
switchconnectoronthesystemboardisenabled.

Whenthecoverpresenceswitchdetectsthatyourcomputercoverisnotproperlyinstalledorclosed
whenyouturnonthecomputer,anerrormessagewillbedisplayed.Tobypasstheerrormessageand
logintotheoperatingsystem,dothefollowing:

1.Properlyinstallorcloseyourcomputercover.See“Completingthepartsreplacement”onpage67.

2.PressF1toentertheSetupUtilityprogram.ThenpressF10tosaveandexittheSetupUtility
program.Theerrormessagewillnotbedisplayedagain.

•AbilitytoenableanddisabledevicesandUSBconnectors
Formoreinformation,see“Enablingordisablingadevice”onpage79

•Integratedngerprintreader(availableonsomemodels)
Dependingonthemodelsofyourcomputer,thekeyboardmayhaveanintegratedngerprintreader.

ByenrollingyourngerprintandassociatingitwithaPower-onPassword,aHardDiskPassword,or
bothpasswordsbeforehand,youcanstartthecomputer,logontothesystem,andentertheSetup
Utilityprogrambyswipingyourngeroverthereader,withouttypingapassword.Thusngerprint
authenticationcanreplacepasswordsandenablesimpleandsecureuseraccess.

•Startupsequencecontrol
Formoreinformation,see“Selectingorchangingthestartupdevicesequence”onpage80

•Startupwithoutkeyboardormouse
Yourcomputerisabletologintotheoperatingsystemwithoutkeyboardormouseconnected.

•TrustedPlatformModule(TPM)
TrustedPlatformModuleisasecurecryptoprocessorthatcanstorecryptographickeysthatprotect

informationstoredinyourcomputer.

.

.

©CopyrightLenovo2012

27

Lockingthecomputercover

Lockingthecomputercoverhelpspreventunauthorizedpeoplefromgainingaccesstotheinsideofyour
computer.Yourcomputercomeswithapadlockloopsothatthecomputercovercannotberemoved
whenapadlockisinstalled.

Figure8.Installingapadlock

28ThinkCentreUserGuide

Attachinganintegratedcablelock

Anintegratedcablelock,sometimesreferredtoastheKensingtonlock,canbeusedtosecureyour
computertoadesk,table,orothernon-permanentxture.Thecablelockattachestotheintegratedcable
lockslotattherearofyourcomputerandisoperatedwithakey.Thecablelockalsolocksthebuttonsused
toopenthecomputercover.Thisisthesametypeoflockusedwithmanynotebookcomputers.Youcan
orderanintegratedcablelockdirectlyfromLenovobysearchingforKensingtonat:
http://www.lenovo.com/support

Figure9.Integratedcablelock

Usingpasswords

YoucansetavarietyofpasswordsthroughtheMicrosoftWindowsoperatingsystemandthroughtheBIOS
ofyourcomputertohelpdeterunauthorizeduseofyourcomputer.

BIOSpasswords

YoucanusetheBIOSSetupUtilityprogramtosetpasswordstopreventunauthorizedaccesstoyour
computeranddata.Thefollowingtypesofpasswordsareavailable:

•Power-OnPassword:WhenaPower-OnPasswordisset,youarepromptedtotypeavalidpassword
eachtimethecomputeristurnedon.Thecomputercannotbeuseduntilthevalidpasswordistyped
in.Formoreinformation,see“Power-OnPassword”onpage78

•HardDiskPassword:SettingaHardDiskPasswordpreventsunauthorizedaccesstothedataonthehard
diskdrive.WhenaHardDiskPasswordisset,youarepromptedtotypeavalidpasswordeachtimeyou
trytoaccesstheharddiskdrive.Formoreinformation,see“HardDiskPassword”onpage78.

.

Chapter4.Security29

•AdministratorPassword:SettinganAdministratorPassworddetersunauthorizedusersfromchanging
congurationsettings.Ifyouareresponsibleformaintainingthecongurationsettingsofseveral
computers,youmightwanttosetanAdministratorPassword.Formoreinformation,see“Administrator
Password”onpage78

Youdonothavetosetanypasswordstouseyourcomputer.However,usingpasswordsimproves
computingsecurity.

.

Windowspasswords

DependingonyourversionoftheWindowsoperatingsystem,youcanusepasswordsforavarietyof
features,includingcontrollingloginaccess,accesstosharedresources,networkaccess,andindividualuser
settings.Formoreinformation,see“HelpandSupport”onpage113

.

Conguringthengerprintreader

Ifyourkeyboardhasangerprintreader,youcancongurethengerprintreaderintheSetupUtilityprogram.

TheFingerprintSetupsubmenuundertheSecuritymenuoftheSetupUtilityprogramprovidesthe
followingoptions:

•PrebootAuthentication:enablesordisablesthengerprintauthenticationforaccessingtheBIOS.

•ErasingFingerprintData:clearsthengerprintdatastoredinangerprintreader.

Tocongurethengerprintreader,dothefollowing:

1.StarttheSetupUtilityprogram.

2.FromtheSetupUtilityprogrammainmenu,selectSecurity➙FingerprintSetup,andpressEnter.
TheFingerprintSetupwindowopens.

3.SelectPrebootAuthenticationorErasingFingerprintDataasdesired,andpressEnter.

4.SelectthedesiredsettingsandpressEnter.

5.PressF10tosavechangesandexittheSetupUtilityprogram.PressEnterwhenpromptedtoconrm
theexit.

Usingandunderstandingrewalls

Arewallcanbehardware,software,oracombinationofbothdependingonthelevelofsecurityrequired.
Firewallsworkonasetofrulestodeterminewhichinboundandoutboundconnectionsareauthorized.If
yourcomputerispreintalledwitharewallprogram,ithelpsprotectagainstcomputerInternetsecurity
threats,unauthorizedaccess,intrusions,andInternetattacks.Italsoprotectsyourprivacy.Formore
informationabouthowtousetherewallprogram,refertothehelpsystemofyourrewallprogram.

TheWindowsoperatingsystempreinstalledonyourcomputerprovidestheWindowsFirewall.Fordetailson
usingtheWindowsFirewall,referto“HelpandSupport”onpage113.

Protectingdataagainstviruses

Yourcomputerispreinstalledwithanantivirusprogramtohelpyouguardagainst,detect,andeliminate
viruses.

Lenovoprovidesafullversionofantivirussoftwareonyourcomputerwithafree30-daysubscription.After
30days,youmustrenewthelicensetocontinuereceivingtheantivirussoftwareupdates.

Note:Virusdenitionlesmustbekeptup-to-datetoguardagainstnewviruses.

30ThinkCentreUserGuide

Formoreinformationabouthowtouseyourantivirussoftware,refertothehelpsystemofyourantivirus
software.

Chapter4.Security31

32ThinkCentreUserGuide

Chapter5.Installingorreplacinghardware

Thischapterprovidesinstructionsonhowtoinstallorreplacehardwareforyourcomputer.

Handlingstatic-sensitivedevices

Donotopenthestatic-protectivepackagecontainingthenewpartuntilthedefectiveparthasbeenremoved
fromthecomputerandyouarereadytoinstallthenewpart.Staticelectricity,althoughharmlesstoyou,can
seriouslydamagecomputercomponentsandparts.

Whenyouhandlepartsandothercomputercomponents,taketheseprecautionstoavoidstatic-electricity
damage:

•Limityourmovement.Movementcancausestaticelectricitytobuilduparoundyou.

•Alwayshandlepartsandothercomputercomponentscarefully.HandlePCIcards,memorymodules,
systemboards,andmicroprocessorsbytheedges.Nevertouchanyexposedcircuitry.

•Preventothersfromtouchingthepartsandothercomputercomponents.

•Beforeyoureplaceanewpart,touchthestatic-protectivepackagecontainingtheparttoametal
expansion-slotcoverorotherunpaintedmetalsurfaceonthecomputerforatleasttwoseconds.This
reducesstaticelectricityinthepackageandyourbody.

•Whenpossible,removethenewpartfromthestatic-protectivepackaging,andinstallitdirectlyinthe
computerwithoutsettingthepartdown.Whenthisisnotpossible,placethestatic-protectivepackage
thatthepartcameinonasmooth,levelsurfaceandplacethepartonit.

•Donotplacethepartonthecomputercoverorothermetalsurface.

Installingorreplacinghardware

Thissectionprovidesinstructionsonhowtoinstallorreplacehardwareforyourcomputer.Youcanexpand
thecapabilitiesofyourcomputerandmaintainyourcomputerbyinstallingorreplacinghardware.

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Notes:

1.UseonlycomputerpartsprovidedbyLenovo.

2.Wheninstallingorreplacinganoption,usetheappropriateinstructionsinthissectionalongwiththe
instructionsthatcomewiththeoption.

Installingexternaloptions

Youcanconnectexternaloptionstoyourcomputer,suchasexternalspeakers,aprinter,orascanner.For
someexternaloptions,youmustinstalladditionalsoftwareinadditiontomakingthephysicalconnection.
Wheninstallinganexternaloption,see“Locatingconnectors,controls,andindicatorsonthefrontofyour
computer”onpage8and“Locatingconnectorsontherearofyourcomputer”onpage9toidentifythe
requiredconnector.Then,usetheinstructionsthatcomewiththeoptiontohelpyoumaketheconnection
andinstallanysoftwareordevicedriversthatarerequiredfortheoption.

©CopyrightLenovo2012

33

Removingthecomputercover

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev

Thissectionprovidesinstructionsonhowtoremovethecomputercover.

CAUTION:

Turnoffthecomputerandwaitthreetoveminutestoletthecomputercoolbeforeremovingthe
computercover.

Toremovethecomputercover,dothefollowing:

1.Removeanymediafromthedrivesandturnoffallattacheddevicesandthecomputer.

2.Disconnectallpowercordsfromelectricaloutlets.

3.Disconnectthepowercords,Input/Outputcables,andanyothercablesthatareconnectedtothe

4.Removeanylockingdevicethatsecuresthecomputercover,suchasapadlockoranintegratedcable

5.Removethetwoscrewsthatsecurethecomputercoverandslidethecomputercovertotherearto

.

computer.See“Locatingconnectors,controls,andindicatorsonthefrontofyourcomputer”onpage8
and“Locatingconnectorsontherearofyourcomputer”onpage9.

lock.See“Lockingthecomputercover”onpage28and“Attachinganintegratedcablelock”onpage29.

removeit.

Figure10.Removingthecomputercover

34ThinkCentreUserGuide

Removingandreinstallingthefrontbezel

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev

Thissectionprovidesinstructionsonhowtoremoveandreinstallthefrontbezel.

Toremoveandreinstallthefrontbezel,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Removethefrontbezelbyreleasingthethreeplastictabsontheleftsideandpivotingthefrontbezel

.

outward.

Figure11.Removingthefrontbezel

Chapter5.Installingorreplacinghardware35

4.T oreinstallthefrontbezel,alignthethreeplastictabsontherightsideofthefrontbezelwiththe
correspondingholesinthechassis,thenpivotthefrontbezelinwardsuntilitsnapsintopositionon
theleftside.

Figure12.Reinstallingthefrontbezel

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67

InstallingorreplacingaPCIcard

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

ThissectionprovidesinstructionsonhowtoinstallorreplaceaPCIcard.

ToinstallorreplaceaPCIcard,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

.

36ThinkCentreUserGuide

3.Attherearofthecomputer,removethescrewthatsecuresthePCIcardlatch.

Figure13.RemovingthescrewthatsecuresthePCIcardlatch

4.DependingonwhetheryouareinstallingorreplacingaPCIcard,dooneofthefollowing:

•IfyouareinstallingaPCIcard,removetheappropriatemetalslotcover.

•IfyouarereplacinganoldPCIcard,grasptheoldcardthatiscurrentlyinstalledandgentlypullit
outoftheslot.

Chapter5.Installingorreplacinghardware37

Figure14.RemovingthePCIcard

Notes:

a.Thecardtstightlyintothecardslot.Ifnecessary,alternatemovingeachsideofthecardasmall

amountuntilitisremovedfromthecardslot.

b.Ifthecardisheldinplacebyaretaininglatch,pressthecardretaininglatch1asshownto

disengagethelatch.Graspthecardandgentlypullitoutoftheslot.

5.RemovethenewPCIcardfromitsstatic-protectivepackage.

6.Installthenewcardintotheappropriateslotonthesystemboard.See“Locatingpartsonthesystem
board”onpage11.

Note:IfyouareinstallingaPCIExpressx16graphicscard,makesurethememoryslotretainingclips
areclosedbeforeyouinstallthegraphicscard.

38ThinkCentreUserGuide

7.PivotthecardlatchtotheclosedpositiontosecurethePCIcard.

Figure15.InstallingaPCIcard

8.ReinstallthescrewtosecurethePCIcardlatchinplace.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

Installingorreplacingamemorymodule

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Thissectionprovidesinstructionsonhowtoinstallorreplaceamemorymodule.

YourcomputerhastwoslotsforinstallingorreplacingDDR3DIMMsthatprovideuptoamaximumof16GB
systemmemory.Wheninstallingorreplacingamemorymodule,use2GB,4GB,or8GBDDR3DIMMs
inanycombinationuptoamaximumof16GB.

Toinstallorreplaceamemorymodule,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Laythecomputeronitssideforeasieraccesstothesystemboard.

4.Locatethememoryslots.See“Locatingpartsonthesystemboard”onpage11.

5.Removeanypartsthatmightpreventyouraccesstothememoryslots.Dependingonyourcomputer
model,youmightneedtoremovethePCIExpressx16graphicscardforeasieraccesstothememory
slots.See“InstallingorreplacingaPCIcard”onpage36

.

Chapter5.Installingorreplacinghardware39

6.Dependingonwhetheryouareinstallingorreplacingamemorymodule,dooneofthefollowing:

•Ifyouarereplacinganoldmemorymodule,opentheretainingclipsandgentlypullthememory
moduleoutofthememoryslot.

Figure16.Removingamemorymodule

•Ifyouareinstallingamemorymodule,opentheretainingclipsofthememoryslotintowhichyou
wanttoinstallthememorymodule.

Figure17.Openingtheretainingclips

40ThinkCentreUserGuide

7.Positionthenewmemorymoduleoverthememoryslot.Makesurethatthenotch1onthememory
modulealignscorrectlywiththeslotkey2onthesystemboard.Pushthememorymodulestraight
downintotheslotuntiltheretainingclipsclose.

Figure18.Installingamemorymodule

8.ReinstallthePCIExpressx16graphicscardifyouhaveremovedit.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67

.

Installingorreplacingtheopticaldrive

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Thissectionprovidesinstructionsonhowtoinstallorreplacetheopticaldrive.

Note:Theopticaldriveisonlyavailableinsomemodels.

Toinstallorreplaceanopticaldrive,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage35.

Chapter5.Installingorreplacinghardware41

4.Removethethreescrewsthatsecuretheopticaldrive.Then,slidetheopticaldriveoutofthefront
ofthecomputer.

Figure19.Removingtheopticaldrive

5.Slidethenewopticaldriveintothedrivebayfromthefrontandalignthescrewholesinthenewoptical
drivewiththecorrespondingholesinthedrivebay.Then,installthethreescrewstosecurethenew
opticaldriveinplace.

Figure20.Installingtheopticaldrive

42ThinkCentreUserGuide

6.Connectoneendofthesignalcabletotherearofthenewopticaldriveandtheotherendtoanavailable
SATAconnectoronthesystemboard.See“Locatingpartsonthesystemboard”onpage11.Then,
locateanavailableve-wirepowerconnectorandconnectittotherearofthenewopticaldrive.

Figure21.ConnectingaSATAopticaldrive

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

Replacingthebattery

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Yourcomputerhasaspecialtypeofmemorythatmaintainsthedate,time,andsettingsforbuilt-infeatures,
suchasparallel-portassignments(conguration).Abatterykeepsthisinformationactivewhenyouturn
offthecomputer.

Thebatterynormallyrequiresnochargingormaintenancethroughoutitslife;however,nobatterylasts
forever.Ifthebatteryfails,thedate,time,andcongurationinformation(includingpasswords)arelost.An
errormessageisdisplayedwhenyouturnonthecomputer.

Refertothe“Lithiumbatterynotice”intheThinkCentreSafetyandWarrantyGuideforinformationabout
replacinganddisposingofthebattery.

Toreplacethebattery,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Locatethebattery.See“Locatingpartsonthesystemboard”onpage11.

4.Removetheoldbattery.

Figure22.Removingtheoldbattery

Chapter5.Installingorreplacinghardware43

5.Installanewbattery.

Figure23.Installinganewbattery

6.Reinstallthecomputercoverandconnectthecables.See“Completingthepartsreplacement”on
page67.

Note:Whenthecomputeristurnedonforthersttimeafterreplacingthebattery,anerrormessage
mightbedisplayed.Thisisnormalafterreplacingthebattery.

7.T urnonthecomputerandallattacheddevices.

8.UsetheSetupUtilityprogramtosetthedate,time,andanypasswords.SeeChapter7“UsingtheSetup
Utilityprogram”onpage77.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

Replacingtheheatsinkandfanassembly

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Thissectionprovidesinstructionsonhowtoreplacetheheatsinkandfanassembly.

CAUTION:

Theheatsinkandfanassemblymightbeveryhot.T urnoffthecomputerandwaitthreetove
minutestoletthecomputercoolbeforeremovingthecomputercover.

Toreplacetheheatsinkandfanassembly,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Laythecomputeronitssideforeasieraccesstothesystemboard.

4.Locatetheheatsinkandfanassembly.See“Locatingpartsonthesystemboard”onpage11.

5.Disconnecttheheatsinkandfanassemblycablefromthemicroprocessorfanconnectoronthesystem
board.See“Locatingpartsonthesystemboard”onpage11

.

44ThinkCentreUserGuide

6.Followthissequencetoremovethefourscrewsthatsecuretheheatsinkandfanassemblytothe
systemboard:

a.Partiallyremovescrew1,thenfullyremovescrew2,andthenfullyremovescrew1.
b.Partiallyremovescrew3,thenfullyremovescrew4,andthenfullyremovescrew3.

Note:Carefullyremovethefourscrewsfromthesystemboardtoavoidanypossibledamagetothe
systemboard.Thefourscrewscannotberemovedfromtheheatsinkandfanassembly.

Figure24.Removingtheheatsinkandfanassembly

7.Liftthefailingheatsinkandfanassemblyoffthesystemboard.

Notes:

a.Youmighthavetogentlytwisttheheatsinkandfanassemblytofreeitfromthemicroprocessor.
b.Donottouchthethermalgreasewhilehandlingtheheatsinkandfanassembly.

8.Positionthenewheatsinkandfanassemblyonthesystemboardsothatthefourscrewsarealigned
withtheholesonthesystemboard.

Note:Positionthenewheatsinkandfanassemblysothattheheatsinkandfanassemblycableis
towardthemicroprocessorfanconnectoronthesystemboard.

9.Followthefollowingsequencetoinstallthefourscrewstosecurethenewheatsinkandfanassembly.
Donotover-tightenthescrews.

a.Partiallytightenscrew1,thenfullytightenscrew2,andthenfullytightenscrew1.
b.Partiallytightenscrew3,thenfullytightenscrew4,andthenfullytightenscrew3.

10.Connecttheheatsinkandfanassemblycabletothemicroprocessorfanconnectoronthesystem
board.See“Locatingpartsonthesystemboard”onpage11

.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

Chapter5.Installingorreplacinghardware45

Replacingthepowersupplyassembly

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev

Thissectionprovidesinstructionsonhowtoreplacethepowersupplyassembly.

Althoughtherearenomovingpartsinyourcomputerafterthepowercordhasbeendisconnected,the
followingwarningsarerequiredforyoursafetyandproperUnderwritersLaboratories(UL)certication.

CAUTION:

Hazardousmovingparts.Keepngersandotherbodypartsaway.

CAUTION:
Neverremovethecoveronapowersupplyoranypartthathasthefollowinglabelattached.

.

Hazardousvoltage,current,andenergylevelsarepresentinsideanycomponentthathasthislabel
attached.Therearenoserviceablepartsinsidethesecomponents.Ifyoususpectaproblemwith
oneoftheseparts,contactaservicetechnician.

Toreplacethepowersupplyassembly,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Disconnectthepowersupplyassemblycablesfromalldrivesandfromthe24-pinpowerconnectorand
4-pinpowerconnectoronthesystemboard.See“Locatingpartsonthesystemboard”onpage11.

Note:Youmightalsoneedtoreleasethepowersupplyassemblycablesfromsomecableclipsorties
thatsecurethecablestothechassis.

46ThinkCentreUserGuide

4.Laythecomputeronitssideandremovethefourscrewsattherearofthechassisthatsecurethe
powersupplyassembly.

Figure25.Removingthescrewsforthepowersupplyassembly

5.Slidethepowersupplyassemblytothefrontofthecomputerandthenliftitoutofthechassis.

6.Makesurethatthenewpowersupplyassemblyisthecorrectreplacement.Somepowersupply
assembliesautomaticallysensethevoltage,somepowersupplyassembliesarevoltagespecic,and
somepowersupplyassemblieshaveavoltage-selectionswitch.Ifyourpowersupplyassemblyhas
avoltage-selectionswitch,makesurethatyousetthevoltage-selectionswitchtomatchthevoltage
availableatyourelectricaloutlet.Ifnecessary,useaballpointpentoslidethevoltage-selectionswitch
tothecorrectposition.

•Ifthevoltagesupplyrangeinyourlocalcountryorregionis100–127Vac,setthevoltage-selection

switchto115V.

•Ifthevoltagesupplyrangeinyourlocalcountryorregionis200–240Vac,setthevoltage-selection

switchto230V.

7.Installthenewpowersupplyassemblyintothechassissothatthescrewholesinthepowersupply
assemblyalignwiththoseinthechassis.

8.Installandtightenthefourscrewstosecurethepowersupplyassembly.

Note:UseonlyscrewsprovidedbyLenovo.

9.Reconnectthepowersupplyassemblycablestothesystemboardandeachofthedrives.

10.Securethepowersupplyassemblycableswiththecableclipsandtiesinthechassis.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

Replacingthemicroprocessor

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Chapter5.Installingorreplacinghardware47

Thissectionprovidesinstructionsonhowtoreplacethemicroprocessor.

CAUTION:

Theheatsinkandmicroprocessormightbeveryhot.T urnoffthecomputerandwaitthreetove
minutestoletthecomputercoolbeforeremovingthecomputercover.

Toreplacethemicroprocessor,dothefollowing:

1.Removeallmediafromthedrivesandturnoffallattacheddevicesandthecomputer.Then,disconnect
allpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtothecomputer.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Laythecomputeronitssideforeasieraccesstothesystemboard.

4.Locatethesystemboardanddisconnectallcablesconnectedtothesystemboard.See“Locating
partsonthesystemboard”onpage11

.

5.Removetheheatsinkandfanassembly.See“Replacingtheheatsinkandfanassembly”onpage44.

Note:Placetheheatsinkandfanassemblyonitssidesothatthethermalgreaseonthebottomofit
doesnotgetincontactwithanything.

6.Liftthesmallhandle1andopentheretainer2toaccessthemicroprocessor3.

Figure26.Accessingthemicroprocessor

7.Liftthemicroprocessorstraightupandoutofthemicroprocessorsocket.

48ThinkCentreUserGuide

Figure27.Removingthemicroprocessor

Notes:

a.Yourmicroprocessorandsocketmightlookdifferentfromtheoneillustrated.
b.Notetheorientationofthemicroprocessorinthesocket.Youcaneitherlookforthesmalltriangle1

ononecornerofthemicroprocessorornotetheorientationofthenotches2onthemicroprocessor.
Thisisimportantwheninstallingthenewmicroprocessoronthesystemboard.

c.Touchonlytheedgesofthemicroprocessor.Donottouchthegoldcontactsonthebottom.
d.Donotdropanythingontothemicroprocessorsocketwhileitisexposed.Thesocketpinsmustbe

keptascleanaspossible.

8.Makesurethatthesmallhandleisintheraisedpositionandthemicroprocessorretainerisfullyopen.

9.Removetheprotectivecoverthatprotectsthegoldcontactsofthenewmicroprocessor.

10.Holdthenewmicroprocessorbyitssidesandalignthesmalltriangleononecornerofthenew
microprocessorwiththecorrespondingsmalltriangleononecornerofthemicroprocessorsocket.

Chapter5.Installingorreplacinghardware49

11.Lowerthenewmicroprocessorstraightdownintothemicroprocessorsocketonthesystemboard.

Figure28.Installingthemicroprocessor

12.Closethemicroprocessorretainerandlockitintopositionwiththesmallhandletosecurethenew
microprocessorinthesocket.

13.Reinstalltheheatsinkandfanassembly.See“Replacingtheheatsinkandfanassembly”onpage44.

14.Reconnectallcablesthatweredisconnectedfromthesystemboard.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage67.

Installingthesolidstatedrive

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Thissectionprovidesinstructionsonhowtoinstallthe2.5-inchsolidstatedrive.

Toinstallthesolidstatedrive,dothefollowing:

50ThinkCentreUserGuide

1.Installthesolidstatedriveintothestorageconverter.Then,installthe4screwstosecurethesolid
statedrivetothestorageconverter.

Figure29.Installingthesolidstatedriveintothestorageconverter

2.Connectthesignalcableandthepowercabletothesolidstatedrive.

3.Installthesolidstatedriveintotheharddiskdrivebay.See“Replacingtheprimaryharddiskdrive”
onpage51.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

Replacingtheprimaryharddiskdrive

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Thissectionprovidesinstructionsonhowtoreplacetheprimaryharddiskdrive.

Note:Dependingonyourmodeltype,yourcomputermightcomewitha2.5-inchsolidstatedrive.T oinstall
thesolidstatedrive,see“Installingthesolidstatedrive”onpage50.

Toreplacetheprimaryharddiskdrive,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Locatetheprimaryharddiskdrive.See“Locatinginternaldrives”onpage14.

Note:Thereisalsoasecondaryharddiskdrivebayforyoutopurchaseandinstallasecondaryhard
diskdrivebyyourself.Ifyouwanttoinstallasecondaryharddiskdrive,usethesamewayofinstalling
theprimaryharddiskdrive.

4.Disconnectthesignalcableandthepowercablefromtheharddiskdrive.

Chapter5.Installingorreplacinghardware51

5.Removethefourscrewsthatsecuretheharddiskdrive.Then,slidetheharddiskdriveoutofthechassis.

Figure30.Removingtheharddiskdrive

52ThinkCentreUserGuide

6.Slidethenewharddiskdriveintotheharddiskdrivebayandalignthescrewholesinthenewhard
diskdrivewiththecorrespondingholesinthedrivebay.Then,installthefourscrewstosecurethe
newharddiskdriveinplace.

Figure31.Installingtheharddiskdrive

7.Connectoneendofthesignalcabletotherearofthenewharddiskdriveandtheotherendtoan
availableSATAconnectoronthesystemboard.See“Locatingpartsonthesystemboard”onpage11
Then,locateanavailableve-wirepowerconnectorandconnectittotherearofthenewharddiskdrive.

Figure32.ConnectingaSATAharddiskdrive

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

Replacingtherearfanassembly

.

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Chapter5.Installingorreplacinghardware53

Thissectionprovidesinstructionsonhowtoreplacetherearfanassembly.

Toreplacetherearfanassembly,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Locatetherearfanassembly.See“Locatingcomponents”onpage11.

4.Disconnecttherearfanassemblycablefromthesystemfanconnectoronthesystemboard.See
“Locatingpartsonthesystemboard”onpage11.

5.Therearfanassemblyisattachedtothechassisbyfourrubbermounts.Removetherearfanassembly
bybreakingorcuttingtherubbermountsandgentlypullingtherearfanassemblyoutofthechassis.

Note:Thenewrearfanassemblywillhavefournewrubbermountsattached.

Figure33.Removingtherearfanassembly

6.Installthenewrearfanassemblybyaligningthenewrubbermountswiththecorrespondingholesinthe
chassisandpushtherubbermountsthroughtheholes.

54ThinkCentreUserGuide

7.Pullonthetipsoftherubbermountsuntiltherearfanassemblyissecuredinplace.

Figure34.Installingtherearfanassembly

8.Connecttherearfanassemblycabletothesystemfanconnectoronthesystemboard.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67

ReplacingthefrontaudioandUSBassembly

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

ThissectionprovidesinstructionsonhowtoreplacethefrontaudioandUSBassembly.

ToreplacethefrontaudioandUSBassembly,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage35.

4.LocatethefrontaudioandUSBassembly.See“Locatingcomponents”onpage11.

5.DisconnectthefrontaudioandUSBassemblycablesfromthesystemboard.See“Locatingpartson
thesystemboard”onpage11.

.

Note:Makesureyounotethelocationsofthecableswhenyoudisconnectthecablesfromthesystem
board.

Chapter5.Installingorreplacinghardware55

6.RemovethescrewthatsecuresthefrontaudioandUSBassemblybrackettothechassistoremove
thebracketfromthechassis.

Figure35.RemovingthescrewthatsecuresthefrontaudioandUSBassemblytothechassis

7.RemovethetwoscrewsthatsecurethefrontaudioandUSBassemblytoitsbracketandremovethe
failingfrontaudioandUSBassemblyfromthebracket.

8.InstallanewfrontaudioandUSBassemblyintothebracketandinstallthetwoscrewstosecurethe
frontaudioandUSBassemblytothebracket.

9.InstallthefrontaudioandUSBassemblybracketintothechassisandalignthescrewholeinthe
bracketwiththecorrespondingholeinthechassis.

10.Installthescrewtosecurethebrackettothechassis.

11.ReconnectthefrontaudioandUSBassemblycablestothefrontaudioconnectorandthefrontUSB
connectoronthesystemboard.See“Locatingpartsonthesystemboard”onpage11.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

ReplacingtheWiFiunits

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

ThissectionprovidesinstructionsonhowtoreplacetheWiFiunits.TheWiFiunitsincludeaWiFiadapter
card,aWiFicardmodule,andarearWiFiantennacable.

ReplacingtheWiFiunitsinvolvesthefollowingoperations:

•“RemovingtheWiFiadaptercard”onpage57

56ThinkCentreUserGuide

•“RemovingtheWiFicardmodule”onpage57

•“InstallingtheWiFiunits”onpage59

RemovingtheWiFiadaptercard

ToremoveaWiFiadaptercard,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Attherearofthecomputer,removethescrewthatsecuresthePCIcardlatch.

4.GrasptheWiFiadaptercardthatiscurrentlyinstalledandgentlypullitoutoftheslot.

Figure36.RemovingtheWiFiadaptercard

Note:Thecardtstightlyintothecardslot.Ifnecessary,alternatemovingeachsideofthecarda
smallamountuntilitisremovedfromthecardslot.

RemovingtheWiFicardmodule

ToremovetheWiFicardmodule,dothefollowing:

Chapter5.Installingorreplacinghardware57

1.RemovetheWiFiadaptercardfromthecomputer,andthendisconnectthefrontandrearWiFiantenna
cablesfromtheWiFicardmodule.

Figure37.RemovingtheWiFiantennacables

2.RemovethetwoscrewsthatsecuretheWiFicardmoduletotheWiFiadaptercard.

Figure38.RemovingthescrewsthatsecuretheWiFicardmodule

58ThinkCentreUserGuide

3.PulltheWiFicardmoduleoutoftheminiPCIExpressslottoremoveitfromtheWiFiadaptercard.

Figure39.RemovingtheWiFicardmodule

InstallingtheWiFiunits

ToinstalltheWiFiunits,dothefollowing:

Chapter5.Installingorreplacinghardware59

1.InserttheWiFicardmoduleintotheminiPCIExpressslot,andtheninstallthetwoscrewstosecure
theWiFicardmoduletotheWiFiadaptercard.

Figure40.InstallingtheWiFicardmodule

60ThinkCentreUserGuide

2.ConnectthefrontantennacableandrearantennacabletotheWiFicardmodule.

Figure41.InstallingtheWiFiantennacables

3.InstalltheWiFiadaptercardintothePCIExpressx1slotonthesystemboard.See“Locatingpartson
thesystemboard”onpage11.

4.PivotthecardlatchtotheclosedpositiontosecuretheWiFiadaptercard.

Figure42.InstallingtheWiFiadaptercard

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

Chapter5.Installingorreplacinghardware61

InstallingorremovingtherearWiFiantenna

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev

ThissectionprovidesinstructionsonhowtoinstallorremovetherearWiFiantenna.

InstallingtherearWiFiantenna

ToinstalltherearWiFiantenna,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.InstalltherearWiFiantennatotherearWiFiantennacableconnectorattachedontherearofthe

3.Adjusttheangleoftherearantennatolowertheriskofbreakingtheantennabyaccident.

.

computer.

Figure43.InstallingtherearWiFiantenna

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

RemovingtherearWiFiantenna

ToremovetherearWiFiantenna,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.StraightentherearWiFiantennasothatitcanbemoreeasilytwisted.

62ThinkCentreUserGuide

3.HoldthethickerendoftherearWiFiantennaandunscrewtheWiFiantennafromtherearofthe
computer.

Figure44.RemovingtherearWiFiantenna

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

InstallingorremovingthefrontWiFiantenna

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

ThissectionprovidesinstructionsonhowtoinstallorremovethefrontWiFiantenna.

InstallingthefrontWiFiantenna

ToinstallthefrontWiFiantenna,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage35.

4.Peeloffthepaperthatprotectsthestickersonthefrontantenna.

Chapter5.Installingorreplacinghardware63

Figure45.Peelingoffthepaperthatprotectsthestickers

5.Stickthefrontantennatothefrontpanelasshown.Theninsertthefrontantennacablethroughthe
holeinthefrontpanel.

Figure46.InstallingthefrontWiFiantenna

6.ConnectthefrontantennacabletotheWiFicardmodule.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

64ThinkCentreUserGuide

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67.

RemovingthefrontWiFiantenna

ToremovethefrontWiFiantenna,dothefollowing:

1.T urnoffthecomputeranddisconnectallpowercordsfromelectricaloutlets.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.Removethefrontbezel.See“Removingandreinstallingthefrontbezel”onpage35.

4.DisconnectthefrontantennacablefromtheWiFicardmodule.

5.Removethefrontantennaandcablefromthefrontofthecomputer.

Figure47.RemovingthefrontWiFiantenna

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage67

Replacingthekeyboard

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Thissectionprovidesinstructionsonhowtoreplacethekeyboard.

Toreplacethekeyboard,dothefollowing:

1.Removeallmediafromthedrives.Then,turnoffallattacheddevicesandthecomputer.

2.Disconnectallpowercordsfromelectricaloutlets.

3.Disconnecttheoldkeyboardcablefromthecomputer.

Chapter5.Installingorreplacinghardware65

.

4.Connectanewkeyboardtotheappropriateconnectoronthecomputer.Yourkeyboardmightbe
connectedtoaPS/2keyboardconnector1oraUSBconnector2.Dependingonwhereyouwant
toconnectyourkeyboard,see“Locatingconnectors,controls,andindicatorsonthefrontofyour
computer”onpage8

Figure48.Keyboardconnectors

or“Locatingconnectorsontherearofyourcomputer”onpage9.

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage67.

Replacingthemouse

Attention:

Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.

Thissectionprovidesinstructionsonhowtoreplacethemouse.

Toreplacethemouse,dothefollowing:

1.Removeallmediafromthedrives.Then,turnoffallattacheddevicesandthecomputer.

2.Disconnectallpowercordsfromelectricaloutlets.

3.Disconnecttheoldmousecablefromthecomputer.

4.Connectanewmousetotheappropriateconnectoronthecomputer.Yourmousemightbeconnected
toaPS/2mouseconnector

1oraUSBconnector2.Dependingonwhereyouwanttoconnectyour

mouse,see“Locatingconnectors,controls,andindicatorsonthefrontofyourcomputer”onpage8
or“Locatingconnectorsontherearofyourcomputer”onpage9.

Figure49.Mouseconnectors

66ThinkCentreUserGuide

Whattodonext:

•Toworkwithanotherpieceofhardware,gototheappropriatesection.

•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage67.

Completingthepartsreplacement

Aftercompletingtheinstallationorreplacementforallparts,youneedtoreinstallthecomputercoverand
reconnectcables.Dependingonthepartsyouinstalledorreplaced,youmightneedtoconrmtheupdated
informationintheSetupUtilityprogram.RefertoChapter7“UsingtheSetupUtilityprogram”onpage77

Toreinstallthecomputercoverandreconnectcablestoyourcomputer,dothefollowing:

1.Makesurethatallcomponentshavebeenreassembledcorrectlyandthatnotoolsorloosescrews
areleftinsideyourcomputer.See“Locatingcomponents”onpage11
componentsinyourcomputer.

2.Ifyouhaveremovedthefrontbezel,reinstallit.See“Removingandreinstallingthefrontbezel”on
page35.

3.Makesurethatthecablesareroutedcorrectlybeforereinstallingthecomputercover.Keepcablesclear
ofthehingesandsidesofthecomputerchassistoavoidinterferencewithreinstallingthecomputer
cover.

4.Positionthecomputercoveronthechassissothattherailguidesonthebottomofthecomputer
coverengagetherailsonthechassis.Then,pushthecovertothefrontofthecomputeruntilitsnaps
intoposition.

forthelocationsofvarious

.

Figure50.Reinstallingthecomputercover

5.Installthescrewstosecurethecomputercover.

Chapter5.Installingorreplacinghardware67

6.Ifthereisapadlockavailable,lockthecomputercover.See“Lockingthecomputercover”onpage28.

7.Ifthereisanintegratedcablelockavailable,lockthecomputer.See“Attachinganintegratedcable
lock”onpage29.

8.Reconnecttheexternalcablesandpowercordstothecomputer.See“Locatingconnectorsontherear
ofyourcomputer”onpage9.

9.T oupdateyourconguration,refertoChapter7“UsingtheSetupUtilityprogram”onpage77.

Note:Inmostareasoftheworld,LenovorequiresthereturnofthedefectiveCustomerReplaceableUnit
(CRU).InformationaboutthiswillcomewiththeCRUorwillcomeafewdaysaftertheCRUarrives.

Obtainingdevicedrivers

Youcanobtaindevicedriversforoperatingsystemsthatarenotpreinstalledat
http://www.lenovo.com/support.Installationinstructionsareprovidedinreadmeleswiththedevice-driver
les.

68ThinkCentreUserGuide

Chapter6.Recoveryinformation

ThischapterprovidesinformationabouttherecoverysolutionsprovidedbyLenovo.

Thischaptercontainsthefollowingtopics:

•Creatingandusingrecoverymedia

•Performingbackupandrecoveryoperations

•UsingtheRescueandRecoveryworkspace

•Creatingandusingarescuemedium

•Installingorreinstallingdevicedrivers

•Solvingrecoveryproblems

Notes:

1.TherecoveryinformationinthischapteronlyappliestothecomputersthathavetheRescueand
RecoveryprogramortheProductRecoveryprograminstalled.IftheEnhancedBackupandRestore
iconintheLenovoThinkVantageToolsprogramisdimmed,itindicatesthatyouneedtoinstall
theRescueandRecoveryprogrammanuallybeforeenablingitsfeatures.ToinstalltheRescueand
Recoveryprogram,dothefollowing:

a.ClickStart➙AllPrograms➙LenovoThinkVantageT ools,anddouble-clickEnhancedBackup

andRestore.
b.Followtheinstructionsonthescreen.
c.Whentheinstallationprocesscompletes,theEnhancedBackupandRestoreiconisactivated.

2.Thereareavarietyofmethodstochoosefromwhenconsideringhowtorecoverintheeventofa
software-orhardware-relatedproblem.Somemethodsvarydependingonthetypeofoperatingsystem
thatisinstalled.

3.Theproductontherecoverymediamaybeusedonlyforthefollowingpurposes:

•Restoretheproductpreinstalledonyourcomputer

•Reinstalltheproduct

•ModifytheproductusingtheAdditionalFiles

Creatingandusingrecoverymedia

Youcanuserecoverymediatorestoretheharddiskdrivetothefactorydefaultstate.Recoverymediaare
usefulifyoutransferthecomputertoanotherarea,sellthecomputer,recyclethecomputer,orputthe
computerinanoperationalstateafterallothermethodsofrecoveryhavefailed.Asaprecautionarymeasure,
itisimportanttocreaterecoverymediaasearlyaspossible.

Note:Therecoveryoperationsyoucanperformusingrecoverymediavarydependingontheoperating
systemfromwhichtherecoverymediawerecreated.Therecoverymediamightcontainabootmedium
andadatamedium.YourMicrosoftWindowslicensepermitsyoutocreateonlyonedatamedium,soitis
importantthatyoustoretherecoverymediainasafeplaceafteryouhavemadethem.

Creatingrecoverymedia

Thissectionprovidesinstructionsonhowtocreaterecoverymediaondifferentoperatingsystems.

©CopyrightLenovo2012

69

Note:OntheWindows7operatingsystem,youcancreaterecoverymediausingdiscsorexternalUSB

storagedevices.OntheWindowsVistaoperatingsystem,youcancreaterecoverymediausingonlydiscs,
sothisoperationisalsocalled“creatingProductRecoverydiscs.”

•TocreaterecoverymediaontheWindows7operatingsystem,clickStart➙AllPrograms➙Lenovo
ThinkVantageTools➙FactoryRecoveryDisks.Then,followtheinstructionsonthescreen.

•TocreateProductRecoverydiscsontheWindowsVistaoperatingsystem,clickStart➙AllPrograms➙

ThinkVantage➙CreateProductRecoveryMedia.Then,followtheinstructionsonthescreen.

Usingrecoverymedia

Thissectionprovidesinstructionsonhowtouserecoverymediaondifferentoperatingsystems.

OntheWindows7operatingsystemandtheWindowsVistaoperatingsystem,youcanuserecoverymedia
torestorethecontentsoftheharddiskdrivetothefactorydefaultstate.Also,youcanuserecoverymediato
putthecomputerinanoperationalstateafterallothermethodsofharddiskdriverecoveryhavefailed.

Attention:Whenyouuserecoverymediatorestorethecontentsoftheharddisktothefactorydefaultstate,
allthelescurrentlyontheharddiskdrivewillbedeletedandreplacedbythefactorydefaultles.

TouserecoverymediaontheWindows7operatingsystemortheWindowsVistaoperatingsystem,
dothefollowing:

1.Dependingonthetypeofyourrecoverymedia,connectthebootmedium(memorykeyorotherUSB
storagedevice)tothecomputer,orinsertthebootdiscintotheopticaldrive.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhenthePleaseselect
bootdevicewindowopens,releasetheF12key.

3.SelectthedesiredstartupdeviceandpressEnter.Therestoreprocessbegins.

4.Followtheinstructionsonthescreentocompletetheoperation.

Note:Afterrestoringyourcomputerharddiskdrivetothefactorydefaultstate,youmighthavetoreinstall
devicedriversforsomedevices.See“Reinstallingdevicedrivers”onpage75.

Performingbackupandrecoveryoperations

TheRescueandRecoveryprogramenablesyoutobackupallyourharddiskdrivecontentsincludingthe
operatingsystem,datales,softwareprograms,andpersonalsettings.Y oucandesignatewherethe
RescueandRecoveryprogramstoresthebackup:

•Inaprotectedareaofyourharddiskdrive

•Onthesecondaryharddiskdriveifasecondaryharddiskdriveisinstalledinyourcomputer

•OnanattachedexternalUSBharddiskdrive

•Onanetworkdrive

•Onrecordablediscs(arecordableopticaldriveisrequiredforthisoption)

Afteryouhavebackedupthecontentsoftheharddiskdrive,youcanrestorethecompletecontentsofthe
harddiskdrive,restoreselectedlesonly,orrestoretheWindowsoperatingsystemandapplicationsonly
whilekeepingtheotherdataonyourharddiskdrive.

Performingabackupoperation

ThissectionprovidesinstructionsonhowtoperformabackupoperationusingtheRescueandRecovery
programondifferentoperatingsystems.

70ThinkCentreUserGuide

•ToperformabackupoperationusingtheRescueandRecoveryprogramontheWindows7operating
system,dothefollowing:

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙LenovoThinkVantageTools➙
EnhancedBackupandRestore.TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoverymainwindow,clicktheLaunchadvancedRescueandRecoveryarrow.

3.ClickBackupyourharddriveandselectbackupoperationoptions.Then,followtheinstructionson
thescreentocompletethebackupoperation.

•ToperformabackupoperationusingtheRescueandRecoveryprogramontheWindowsVistaoperating
system,dothefollowing:

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙ThinkVantage➙RescueandRecovery.
TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoverymainwindow,clickLaunchadvancedRescueandRecovery➙Back
upyourharddrive,andselectbackupoperationoptions.

3.Followtheinstructionsonthescreentocompletethebackupoperation.

Performingarecoveryoperation

ThissectionprovidesinstructionsonhowtoperformarecoveryoperationusingtheRescueandRecovery
programondifferentoperatingsystems.

•ToperformarecoveryoperationusingtheRescueandRecoveryprogramontheWindows7operating
system,dothefollowing:

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙LenovoThinkVantageTools➙
EnhancedBackupandRestore.TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoverymainwindow,clicktheLaunchadvancedRescueandRecoveryarrow.

3.ClicktheRestoreyoursystemfromabackupicon.

4.Followtheinstructionsonthescreentocompletetherecoveryoperation.

•ToperformarecoveryoperationusingtheRescueandRecoveryprogramontheWindowsVistaoperating
system,dothefollowing:

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙ThinkVantage➙RescueandRecovery.
TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoverymainwindow,clickLaunchadvancedRescueandRecovery.

3.ClicktheRestoreyoursystemfromabackupicon.

4.Followtheinstructionsonthescreentocompletetherecoveryoperation.

FormoreinformationaboutperformingarecoveryoperationfromtheRescueandRecoveryworkspace,see
“UsingtheRescueandRecoveryworkspace”onpage71.

UsingtheRescueandRecoveryworkspace

TheRescueandRecoveryworkspaceresidesinaprotected,hiddenareaofyourharddiskdrivethat
operatesindependentlyfromtheWindowsoperatingsystem.Thisenablesyoutoperformrecovery
operationsevenifyoucannotstarttheWindowsoperatingsystem.Youcanperformthefollowingrecovery
operationsfromtheRescueandRecoveryworkspace:

•Rescuelesfromyourharddiskdriveorfromabackup:TheRescueandRecoveryworkspaceenables
youtolocatelesonyourharddiskdriveandtransferthemtoanetworkdriveorotherrecordablemedia,
suchasaUSBdeviceoradisc.Thissolutionisavailableevenifyoudidnotbackupyourlesorif
changesweremadetothelessinceyourlastbackupoperation.Y oucanalsorescueindividuallesfrom
aRescueandRecoverybackuplocatedonyourlocalharddiskdrive,aUSBdevice,oranetworkdrive.

Chapter6.Recoveryinformation71

•RestoreyourharddiskdrivefromaRescueandRecoverybackup:Ifyouhavebackedupyourharddisk
driveusingtheRescueandRecoveryprogram,youcanrestoretheharddiskdrivefromaRescueand
Recoverybackup,evenifyoucannotstarttheWindowsoperatingsystem.

•Restoreyourharddiskdrivetothefactorydefaultstate:TheRescueandRecoveryworkspaceenables
youtorestorethecompletecontentsofyourharddiskdrivetothefactorydefaultstate.Ifyouhave
multiplepartitionsonyourharddiskdrive,youhavetheoptiontorestoretheC:partitionandleavethe
otherpartitionsintact.BecausetheRescueandRecoveryworkspaceoperatesindependentlyfrom
theWindowsoperatingsystem,youcanrestoretheharddiskdrivetothefactorydefaultstateevenif
youcannotstarttheWindowsoperatingsystem.

Attention:IfyourestoretheharddiskdrivefromaRescueandRecoverybackuporrestoretheharddisk
drivetothefactorydefaultsettings,alllesontheprimaryharddiskdrivepartition(usuallydriveC:)willbe
deletedintherecoveryprocess.Ifpossible,makecopiesofimportantles.Ifyouareunabletostartthe
Windowsoperatingsystem,youcanusetherescuelesfeatureoftheRescueandRecoveryworkspaceto
copylesfromyourharddiskdrivetoothermedia.

TostarttheRescueandRecoveryworkspace,dothefollowing:

1.Makesurethecomputeristurnedoff.

2.RepeatedlypressandreleasetheF11keywhenturningonthecomputer.Whenyouhearbeepsor
seealogoscreen,releasetheF11key.

3.IfyouhavesetaRescueandRecoverypassword,typeyourpasswordwhenprompted.TheRescue
andRecoveryworkspaceopensafterashortdelay.

Note:IftheRescueandRecoveryworkspacefailstoopen,see“Solvingrecoveryproblems”onpage75.

4.Dooneofthefollowing:

•Torescuelesfromyourharddiskdriveorfromabackup,clickRescuelesandfollowthe

instructionsonthescreen.

•TorestoreyourharddiskdrivefromaRescueandRecoverybackuportorestoreyourharddiskdrive

tothefactorydefaultsettings,clickRestoreyoursystemandfollowtheinstructionsonthescreen.

FormoreinformationaboutthefeaturesoftheRescueandRecoveryworkspace,clickHelp.

Note:Afterrestoringyourharddiskdrivetothefactorydefaultstate,youmighthavetoreinstalldevice
driversforsomedevices.See“Reinstallingdevicedrivers”onpage75.

Creatingandusingarescuemedium

Witharescuemedium,suchasadiscoraUSBharddiskdrive,youcanrecoverthecomputerfromfailures
thatpreventyoufromgainingaccesstotheRescueandRecoveryworkspaceonyourharddiskdrive.

Notes:

1.Therecoveryoperationsyoucanperformusingarescuemediumvarydependingontheoperating
system.

2.Therescuedisccanbestartedinalltypesofopticaldrives.

Creatingarescuemedium

Thissectionprovidesinstructionsonhowtocreatearescuemediumondifferentoperatingsystems.

•TocreatearescuemediumontheWindows7operatingsystem,dothefollowing:

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙LenovoThinkVantageTools➙
EnhancedBackupandRestore.TheRescueandRecoveryprogramopens.

2.IntheRescueandRecoverymainwindow,clicktheLaunchadvancedRescueandRecoveryarrow.

72ThinkCentreUserGuide

3.ClicktheCreateRescueMediaicon.TheCreateRescueandRecoveryMediawindowopens.

4.IntheRescueMediaarea,selectthetypeoftherescuemediumyouwanttocreate.Youcancreate
arescuemediumusingadisc,aUSBharddiskdrive,orasecondaryinternalharddiskdrive.

5.ClickOKandfollowtheinstructionsonthescreentocreatearescuemedium.

•TocreatearescuemediumontheWindowsVistaoperatingsystem,dothefollowing:

1.FromtheWindowsdesktop,clickStart➙AllPrograms➙ThinkVantage➙CreateRecovery
Media.TheCreateRescueandRecoveryMediawindowopens.

2.IntheRescueMediaarea,selectthetypeoftherescuemediumyouwanttocreate.Youcancreate
arescuemediumusingadisc,aUSBharddiskdrive,orasecondaryinternalharddiskdrive.

3.ClickOKandfollowtheinstructionsonthescreentocreatearescuemedium.

Usingarescuemedium

Thissectionprovidesinstructionsonhowtousetherescuemediumyouhavecreated.

•Ifyouhavecreatedarescuemediumusingadisc,usethefollowinginstructionstousetherescuemedium:

1.T urnoffyourcomputer.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhenthePleaseselect
bootdevicewindowopens,releasetheF12key.

3.InthePleaseselectbootdevicewindow,selectthedesiredopticaldriveastherstbootdevice.
Then,inserttherescuediscintotheopticaldriveandpressEnter.Therescuemediumstarts.

•IfyouhavecreatedarescuemediumusingaUSBharddiskdrive,usethefollowinginstructionsto
usetherescuemedium:

1.AttachtheUSBharddiskdrivetooneoftheUSBconnectorsonyourcomputer.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhenthePleaseselect
bootdevicewindowopens,releasetheF12key.

3.InthePleaseselectbootdevicewindow,selecttheUSBharddiskdriveastherstbootdeviceand
pressEnter.Therescuemediumstarts.

Whentherescuemediumstarts,theRescueandRecoveryworkspaceopens.Thehelpinformationfor
eachfeatureisavailablefromtheRescueandRecoveryworkspace.Followtheinstructionstocomplete
therecoveryprocess.

Reinstallingpreinstalledapplicationsanddevicedrivers

Yourcomputerhasprovisionsthatenableyoutoreinstallselectedfactory-installedapplicationsanddevice
drivers.

Reinstallingpreinstalledapplications

Thissectionprovidesinstructionsonhowtoreinstallpreinstalledapplications.

ToreinstalltheselectedapplicationspreinstalledonyourLenovocomputer,dothefollowing:

1.T urnonthecomputer.

2.UseWindowsExplorerorComputertodisplaythedirectorystructureofyourharddiskdrive.

3.GototheC:\SWTOOLSdirectory.

4.Opentheappsfolder.Withintheappsfolder,thereareseveralsubfoldersnamedforvariousapplications
installedinyourcomputer.

5.Opentheappropriateapplicationsubfolder.

Chapter6.Recoveryinformation73

6.Intheapplicationsubfolder,lookforaSETUP.EXEleorotherappropriateEXElesforsetup.
Double-clicktheleandfollowtheinstructionsonthescreentocompletetheinstallation.

Reinstallingpreinstalleddevicedrivers

Thissectionprovidesinstructionsonhowtoreinstallpreinstalleddevicedrivers.

Attention:Whenyoureinstalldevicedrivers,youarechangingthecurrentcongurationofyourcomputer.
Reinstalldevicedriversonlywhenitisnecessarytocorrectaproblemwithyourcomputer.

Toreinstallthedevicedriverforafactory-installeddevice,dothefollowing:

1.T urnonthecomputer.

2.UseWindowsExplorerorComputertodisplaythedirectorystructureofyourharddiskdrive.

3.GototheC:\SWTOOLSdirectory.

4.OpentheDRIVERSfolder.WithintheDRIVERSfolder,thereareseveralsubfoldersnamedforvarious
devicesinstalledinyourcomputer,suchasAUDIOorVIDEO.

5.Opentheappropriatedevicesubfolder.

6.Dooneofthefollowing:

•Inthedevicesubfolder,lookforaSETUP.exele.Double-clicktheleandfollowtheinstructionson

thescreentocompletetheinstallation.

•Inthedevicesubfolder,lookforaREADME.txtleoralewiththe.txtextension.Thislemightbe

namedaftertheoperatingsystem,suchasWIN98.txt.TheTXTlecontainsinformationabouthowto
installthedevicedriver.Followtheinstructionstocompletetheinstallation.

•Ifthedevicesubfoldercontainsalewiththe.infextensionandyouwanttoinstallthedevice

driverusingtheINFle,refertoyourWindowsHelpandSupportinformationsystemfordetailed
informationabouthowtoinstallthedevicedriver.

Note:Ifyouneedupdateddevicedrivers,see“Gettingthelatestdevicedriversforyourcomputer”on
page87formoreinformation.

Reinstallingsoftwareprograms

Ifasoftwareprogramyouinstalledonyourcomputerisnotworkingcorrectly,youmightneedtoremove
andreinstallit.Reinstallingoverwritestheexistingprogramslesandusuallyxesanyproblemsthat
youmighthavehadwiththatprogram.

Toremoveaprograminyoursystem,seeMicrosoftWindowshelpsystemfordetailedinformation.

Toreinstalltheprogram,dooneofthefollowing:

Note:Themethodofreinstallingaprogramvariesfromprogramtoprogram.Refertothedocumentation
providedwiththeprogramtoseeifyourprogramhasspecialinstallationinstructions.

•Toreinstallmostcommerciallyavailableprogramsinyoursystem,seeMicrosoftWindowshelpsystem
formoreinformation.

•ToreinstallselectedapplicationprogramsthatcamepreinstalledfromLenovo,dothefollowing:

1.T urnonthecomputer.

2.UseWindowsExplorerorComputertodisplaythedirectorystructureofyourharddiskdrive.

3.GototheC:\SWTOOLSdirectory.

4.OpentheAPPSfolder.WithintheAPPSfolder,thereareseveralsubfoldersnamedforvarious
applicationsinstalledinyourcomputer.

74ThinkCentreUserGuide

5.Opentheappropriateapplicationsubfolder.

6.Intheapplicationsubfolder,lookforaSETUP .EXEleorotherappropriateEXElesforsetup.
Double-clicktheleandfollowtheinstructionsonthescreentocompletetheinstallation.

Reinstallingdevicedrivers

Toreinstalladevicedriverforanoptionyouinstalled,refertothedocumentationthatcomeswiththeoption.

Whenyoureinstalldevicedrivers,youarechangingthecurrentcongurationofyourcomputer.Reinstall
devicedriversonlywhenitisnecessarytocorrectaproblemwithyourcomputer.

Formoreinformationaboutreinstallingdevicedriversthatcamewithyourcomputer,see“Reinstalling
preinstalledapplicationsanddevicedrivers”onpage73.

Solvingrecoveryproblems

IfyouareunabletoaccesstheRescueandRecoveryworkspaceortheWindowsenvironment,doone
ofthefollowing:

•UsearescuemediumtostarttheRescueandRecoveryworkspace.See“Creatingandusingarescue
medium”onpage72

•Userecoverymediaifallothermethodsofrecoveryhavefailedandyouneedtorestoretheharddisk
drivetothefactorydefaultsettings.See“Creatingandusingrecoverymedia”onpage69.

.

Note:IfyouareunabletoaccesstheRescueandRecoveryworkspaceortheWindowsenvironmentfrom
arescuemediumorrecoverymedia,youmightnothavetherescuedevice(aninternalharddiskdrive,a
disc,aUSBharddiskdrive,orotherexternaldevices)setastherstbootdeviceinthestartupdevice
sequence.Y oumustrstmakesurethatyourrescuedeviceissetastherstbootdeviceinthestartup
devicesequenceintheSetupUtilityprogram.See“Selectingastartupdevice”onpage80
informationabouttemporarilyorpermanentlychangingthestartupdevicesequence.Formoreinformation
abouttheSetupUtilityprogram,seeChapter7“UsingtheSetupUtilityprogram”onpage77.

Itisimportanttocreatearescuemediumandasetofrecoverymediaasearlyaspossibleandstorethem
inasafeplaceforfutureuse.

fordetailed

Chapter6.Recoveryinformation75

76ThinkCentreUserGuide

Chapter7.UsingtheSetupUtilityprogram

TheSetupUtilityprogramisusedtoviewandchangethecongurationsettingsofyourcomputer,regardless
ofwhichoperatingsystemyouareusing.However,theoperatingsystemsettingsmightoverrideanysimilar
settingsintheSetupUtilityprogram.

StartingtheSetupUtilityprogram

TostarttheSetupUtilityprogram,dothefollowing:

1.Makesureyourcomputeristurnedoff.

2.RepeatedlypressandreleasetheF1keywhenturningonthecomputer.Whenyouhearmultiple
beepsorseealogoscreen,releasetheF1key.

Note:IfaPower-OnPasswordoranAdministratorPasswordhasbeenset,theSetupUtilityprogram
menuwillnotbedisplayeduntilyoutypethecorrectpassword.Formoreinformation,see“Using
passwords”onpage77

WhenthePOSTdetectsthattheharddiskdrivehasbeenremovedfromyourcomputerorthememory
modulesizehasdecreased,anerrormessagewillbedisplayedwhenyoustartthecomputerandyouwillbe
promptedtodooneofthefollowing:

•PressF1toentertheSetupUtilityprogram.

Note:AfteryouentertheSetupUtilityprogram,selectSaveChangesandExitatthebottomofthe
screen.Theerrormessagewillnotbedisplayedagain.

•PressF2tobypasstheerrormessageandlogintotheoperatingsystem.

.

Viewingandchangingsettings

TheSetupUtilityprogrammenulistsvariousitemsaboutthesystemconguration.Tovieworchange
settings,starttheSetupUtilityprogram.See“StartingtheSetupUtilityprogram”onpage77.Then,follow
theinstructionsonthescreen.

YoucanuseeitherthekeyboardorthemousetonavigatethroughBIOSmenuchoices.Thekeysusedto
performvarioustasksaredisplayedatthebottomofeachscreen.

Usingpasswords

ByusingtheSetupUtilityprogram,youcansetpasswordstopreventunauthorizedaccesstoyourcomputer
anddata.Thefollowingtypesofpasswordsareavailable:

•Power-OnPassword

•AdministratorPassword

•HardDiskPassword

Youdonothavetosetanypasswordstouseyourcomputer.However,usingpasswordsimproves
computingsecurity.Ifyoudecidetosetanypasswords,readthefollowingsections.

©CopyrightLenovo2012

77

Passwordconsiderations

Apasswordcanbeanycombinationofupto64alphabeticandnumericcharacters.Forsecurityreasons,it
isrecommendedtouseastrongpasswordthatcannotbeeasilycompromised.T osetastrongpassword,
usethefollowingguidelines:

•Haveatleasteightcharactersinlength

•Containatleastonealphabeticcharacterandonenumericcharacter

•SetupUtilityprogramandharddiskpasswordsarenotcasesensitive

•Notbeyournameoryourusername

•Notbeacommonwordoracommonname

•Besignicantlydifferentfromyourpreviouspasswords

Power-OnPassword

WhenaPower-OnPasswordisset,youarepromptedtotypeavalidpasswordeachtimethecomputeris
turnedon.Thecomputercannotbeuseduntilthevalidpasswordistypedin.

AdministratorPassword

SettinganAdministratorPassworddetersunauthorizedusersfromchangingcongurationsettings.Ifyou
areresponsibleformaintainingthecongurationsettingsofseveralcomputers,youmightwanttosetan
AdministratorPassword.

WhenanAdministratorPasswordisset,youarepromptedtotypeavalidpasswordeachtimeyoutryto
accesstheSetupUtilityprogram.TheSetupUtilityprogramcannotbeaccesseduntilavalidpassword
istypedin.

IfboththePower-OnPasswordandAdministratorPasswordareset,youcantypeeitherpassword.However,
youmustuseyourAdministratorPasswordtochangeanycongurationsettings.

HardDiskPassword

SettingaHardDiskPasswordpreventsunauthorizedaccesstothedataontheharddiskdrive.Whena
HardDiskPasswordisset,youarepromptedtotypeavalidpasswordeachtimeyoutrytoaccessthe
harddiskdrive.

Notes:

•AfteryousetaHardDiskPassword,yourdataontheharddiskdriveisprotectedeveniftheharddisk
driveisremovedfromonecomputerandinstalledinanother.

•IftheHardDiskPasswordisforgotten,thereisnowaytoresetthepasswordorrecoverdatafromthe
harddiskdrive.

Setting,changing,anddeletingapassword

Toset,change,ordeleteapassword,dothefollowing:

1.StarttheSetupUtilityprogram.See“StartingtheSetupUtilityprogram”onpage77.

2.FromtheSetupUtilityprogrammainmenu,selectSecurity.

3.Dependingonthepasswordtype,selectSetPower-OnPassword,SetAdministratorPassword,or
HardDiskPassword.

4.Followtheinstructionsontherightsideofthescreentoset,change,ordeleteapassword.

78ThinkCentreUserGuide

Note:Apasswordcanbeanycombinationofupto64alphabeticandnumericcharacters.Formore

information,see“Passwordconsiderations”onpage78.

Erasinglostorforgottenpasswords(clearingCMOS)

Thissectionprovidesinstructionsonhowtoeraselostorforgottenpasswords,suchasauserpassword.

Toerasealostorforgottenpassword,dothefollowing:

1.Removeallmediafromthedrivesandturnoffallattacheddevicesandthecomputer.Then,disconnect
allpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtothecomputer.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.LocatetheClearCMOS/Recoveryjumperonthesystemboard.See“Locatingpartsonthesystem
board”onpage11.

4.Movethejumperfromthestandardposition(pin1andpin2)tothemaintenanceposition(pin2and
pin3).

5.Reinstallthecomputercoverandconnectthepowercord.See“Completingthepartsreplacement”
onpage67.

6.T urnonthecomputerandleaveitonforapproximately10seconds.Then,turnoffthecomputerby
holdingthepowerswitchforapproximatelyveseconds.

7.Repeatstep1throughstep3.

8.MovetheClearCMOS/Recoveryjumperbacktothestandardposition(pin1andpin2).

9.Reinstallthecomputercoverandconnectthepowercord.See“Completingthepartsreplacement”
onpage67.

Enablingordisablingadevice

Thissectionprovidesinformationonhowtoenableordisableuseraccesstothefollowingdevices:

USBSetupUsethisoptiontoenableordisableaUSBconnector.WhenaUSBconnectoris

disabled,thedeviceconnectedtotheUSBconnectorcannotbeused.

SATAControllerWhenthisfeatureissettoDisable,alldevicesconnectedtotheSATAconnectors

(suchasharddiskdrivesortheopticaldrive)aredisabledandcannotbeaccessed.

ExternalSATAPortWhenthisoptionissettoDisable,thedeviceconnectedtotheExternalSAT A

connectorcannotbeaccessed.

Toenableordisableadevice,dothefollowing:

1.StarttheSetupUtilityprogram.See“StartingtheSetupUtilityprogram”onpage77.

2.FromtheSetupUtilityprogrammainmenu,selectDevices.

3.Dependingonthedeviceyouwanttoenableordisable,dooneofthefollowing:

•SelectUSBSetuptoenableordisableaUSBdevice.

•SelectATADriveSetuptoenableordisableaninternalorexternalSATAdevice.

4.SelectthedesiredsettingsandpressEnter.

5.PressF10tosaveandexittheSetupUtilityprogram.See“ExitingfromtheSetupUtilityprogram”
onpage81.

Chapter7.UsingtheSetupUtilityprogram79

Selectingastartupdevice

Ifyourcomputerdoesnotstartupfromadevicesuchasthediscorharddiskdriveasexpected,dooneof
thefollowingtoselectthestartupdeviceyouwant.

Selectingatemporarystartupdevice

Usethisproceduretoselectatemporarystartupdevice.

Note:Notalldiscsandharddiskdrivesarebootable.

1.T urnoffyourcomputer.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhenthePleaseselect
bootdevicewindowdisplays,releasetheF12key.

3.SelectthedesiredstartupdeviceandpressEnter.Thecomputerwillstartupfromthedeviceyou
selected.

Note:SelectingastartupdevicefromthePleaseselectbootdevicewindowdoesnotpermanentlychange
thestartupsequence.

Selectingorchangingthestartupdevicesequence

Tovieworpermanentlychangetheconguredstartupdevicesequence,dothefollowing:

1.StarttheSetupUtilityprogram.See“StartingtheSetupUtilityprogram”onpage77.

2.FromtheSetupUtilityprogrammainmenu,selectStartup.

3.SelectthedevicesforthePrimaryStartupSequence,theAutomaticStartupSequence,andtheError
StartupSequence.Readtheinformationdisplayedontherightsideofthescreen.

4.PressF10tosaveandexittheSetupUtilityprogram.See“ExitingfromtheSetupUtilityprogram”
onpage81.

EnablingErPcompliancemode

Youcanenabletheenergy-relatedproductsdirective(ErP)compliancemodethroughthePowermenuinthe
SetupUtilityprogramtoreducetheconsumptionofelectricitywhenyourcomputerisinstandbyoroffmode.

ToenableErPcompliancemodeintheSetupUtilityprogram,dothefollowing:

1.Makesureyourcomputeristurnedoff.

2.RepeatedlypressandreleasetheF1keywhenturningonthecomputer.Whenyouhearmultiplebeeps
orseealogoscreen,releasetheF1key.TheSetupUtilityprogramstarts.

Note:IfaPower-OnPasswordoranAdministratorPasswordhasbeenset,theSetupUtilityprogram
mainmenuwillnotbedisplayeduntilyoutypethecorrectpassword.

3.FromtheSetupUtilityprogrammainmenu,selectPower➙EnhancedPowerSavingMode,and
pressEnter.

4.SelectEnabledandpressEnter.

5.FromthePowermenu,selectAutomaticPowerOnandpressEnter.

6.SelectWakeonLanandpressEnter.

7.SelectDisabledandpressEnter.

8.PressF10tosavechangesandexittheSetupUtilityprogram.PressEnterwhenpromptedtoconrm
theexit.

Note:WhenErPcompliancemodeisenabled,youcanwakeupyourcomputerbydoingoneofthefollowing:

80ThinkCentreUserGuide

•Pressingthepowerswitch

•Enablingthewakeuponalarmfeature
Thewakeuponalarmfeatureenablesyourcomputertowakeupatasettime.Toenablethewake

uponalarmfeature,dothefollowing:

1.StarttheSetupUtilityprogram.

2.FromtheSetupUtilityprogrammainmenu,selectPower➙AutomaticPowerOn,andpressEnter.

3.SelectWakeUponAlarmandpressEnter.Thenfollowtheinstructionsonthescreen.

4.PressF10tosavechangesandexittheSetupUtilityprogram.PressEnterwhenpromptedto
conrmtheexit.

•Enablingtheafterpowerlossfeature
Theafterpowerlossfeatureenablesyourcomputertowakeupwhenthepowersupplyresumesaftera

suddenlossofelectricity.Toenabletheafterpowerlossfeature,dothefollowing:

1.StarttheSetupUtilityprogram.

2.FromtheSetupUtilityprogrammainmenu,selectPower➙AfterPowerLoss,andpressEnter.

3.SelectPowerOnandpressEnter.

4.PressF10tosavechangesandexittheSetupUtilityprogram.PressEnterwhenpromptedto
conrmtheexit.

ExitingfromtheSetupUtilityprogram

Afteryounishviewingorchangingsettings,pressEsctoreturntotheSetupUtilityprogrammainmenu.
YoumighthavetopressEscseveraltimes.Dooneofthefollowing:

•Ifyouwanttosavethenewsettings,pressF10tosaveandexittheSetupUtilityprogram.

•Ifyoudonotwanttosavethesettings,selectExit➙DiscardChangesandExit.

•Ifyouwanttoreturntothedefaultsettings,pressF9toloadthedefaultsettings.

Chapter7.UsingtheSetupUtilityprogram81

82ThinkCentreUserGuide

Chapter8.Updatingsystemprograms

ThischapterprovidesinformationaboutupdatingthePOSTandBIOS,andhowtorecoverfromaPOST
andBIOSupdatefailure.

Usingsystemprograms

Systemprogramsarethebasiclayerofsoftwarebuiltintoyourcomputer.Systemprogramsincludethe
POST,theBIOS,andtheSetupUtilityprogram.ThePOSTisasetoftestsandproceduresthatare
performedeachtimeyouturnonyourcomputer.TheBIOSisalayerofsoftwarethattranslatesinstructions
fromotherlayersofsoftwareintoelectricalsignalsthatthecomputerhardwarecanexecute.Youcanuse
theSetupUtilityprogramtovieworchangethecongurationsettingsofyourcomputer.SeeChapter7
“UsingtheSetupUtilityprogram”onpage77

Yourcomputersystemboardhasamodulecalledelectricallyerasableprogrammableread-onlymemory
(EEPROM,alsoreferredtoasashmemory).Y oucaneasilyupdatethePOST,theBIOS,andtheSetup
Utilityprogrambystartingyourcomputerwithasystem-program-updatediscorrunningaspecialupdate
programfromyouroperatingsystem.

LenovomightmakechangesandenhancementstothePOSTandBIOS.Whenupdatesarereleased,they
areavailableasdownloadablelesontheLenovoWebsiteathttp://www.lenovo.com.Instructionsforusing
thePOSTandBIOSupdatesareavailableinaTXTlethatisincludedwiththeupdateles.Formost
models,youcandownloadeitheranupdateprogramtocreateasystem-program-updatediscoranupdate
programthatcanberunfromtheoperatingsystem.

fordetailedinformation.

Updating(ashing)theBIOSfromadisc

Thissectionprovidesinstructionsonhowtoupdate(ash)theBIOSfromadisc.

Note:Y oucandownloadaself-startingbootablediscimage(knownasanISOimage)withthesystem
programupdatestocreateasystem-program-updatedisc.Goto:
http://www.lenovo.com/support

Toupdate(ash)theBIOSfromadisc,dothefollowing:

1.T urnoffyourcomputer.

2.RepeatedlypressandreleasetheF12keywhenturningonthecomputer.WhentheStartupDevice
Menuopens,releasetheF12key.

3.OntheStartupDeviceMenu,selectthedesiredopticaldriveasthestartupdevice.Then,insertthe
discintothisopticaldriveandpressEnter.Theupdatebegins.

4.Whenpromptedtochangetheserialnumber,itissuggestedthatyoudonotmakethischangeby
pressingN.However,ifyoudowanttochangetheserialnumber,pressY,thentypeintheserialnumber
andpressEnter.

5.Whenpromptedtochangethemachinetypeandmodel,itissuggestedthatyoudonotmakethis
changebypressingN.However,ifyoudowanttochangethemachinetypeandmodel,pressY,then
typeinthemachinetypeandmodelandpressEnter.

6.Followtheinstructionsonthescreentocompletetheupdate.Aftertheupdateiscompleted,removethe
discfromtheopticaldrive.

©CopyrightLenovo2012

83

Updating(ashing)theBIOSfromyouroperatingsystem

Note:BecauseLenovomakesconstantimprovementstoitsWebsites,theWebpagecontentsaresubject

tochangewithoutnotice,includingthecontentsreferencedinthefollowingprocedure.

Toupdate(ash)theBIOSfromyouroperatingsystem,dothefollowing:

1.Gotohttp://www.lenovo.com/support.

2.Dothefollowingtolocatethedownloadablelesforyourmachinetype:
a.ClickDownload&Drivers.
b.Intheleftpane,clickDownloadsanddrivers.
c.FromtheBranddrop-downlistbox,selectDesktops.
d.FromtheFamilydrop-downlistbox,selectthefamilyname.
e.ClickContinue.
f.FromtheReneresultsdrop-downlistbox,selectBIOS.
g.ClicktheBIOSupdatelink.

3.ClicktheTXTlethatcontainstheinstructionsforupdating(ashing)theBIOSfromyouroperating
system.

4.Printtheseinstructions.Thisisveryimportantbecausetheseinstructionswillnotbedisplayedon
thescreenafterthedownloadbegins.

5.Followtheprintedinstructionstodownload,extract,andinstalltheupdate.

RecoveringfromaPOST/BIOSupdatefailure

IfthepowertoyourcomputerisinterruptedwhilethePOSTandBIOSisbeingupdated,yourcomputer
mightnotrestartcorrectly.Ifthishappens,performthefollowingproceduretorecoverfromthePOSTand
BIOSupdatefailure.ThisprocedureiscommonlycalledBoot-blockRecovery.

1.Removeallmediafromthedrivesandturnoffallattacheddevicesandthecomputer.Then,disconnect
allpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtothecomputer.

2.Removethecomputercover.See“Removingthecomputercover”onpage34.

3.LocatetheClearCMOS/Recoveryjumperonthesystemboard.See“Locatingpartsonthesystem
board”onpage11.

4.RemoveanycablesthatimpedeaccesstotheClearCMOS/Recoveryjumper.

5.Movethejumperfromthestandardposition(pin1andpin2)tothemaintenanceposition(pin2and
pin3).

6.ReconnectanycablesthatweredisconnectedandreinstallthePCIcardifremoved.

7.Reinstallthecomputercoverandreconnectthepowercordsforthecomputerandmonitortoelectrical
outlets.See“Completingthepartsreplacement”onpage67.

8.T urnonthecomputerandtheninsertthePOSTandBIOSupdate(ashupdate)discintotheoptical
drive.Waitafewminutes.Then,therecoverysessionbegins.Therecoverysessionwilltaketwoto
threeminutes.Duringthistime,awarningmessagewillbedisplayedandnoactionisneededfromyou.

9.Aftertherecoverysessioniscompleted,therewillbenovideo,andyourcomputerwillautomatically
turnoff.

10.Repeatstep1throughstep4.

11.MovetheClearCMOS/Recoveryjumperbacktothestandardposition(pin1andpin2).

12.ReconnectanycablesthatweredisconnectedandreinstallthePCIcardifremoved.

13.Reinstallthecomputercoverandreconnectanycablesthatweredisconnected.

84ThinkCentreUserGuide

14.T urnonthecomputertorestarttheoperatingsystem.

Chapter8.Updatingsystemprograms85

86ThinkCentreUserGuide

Chapter9.Preventingproblems

Thischapterprovidesinformationthatcanhelpyouavoidcommonproblemsandkeepyourcomputer
runningsmoothly.

Keepingyourcomputercurrent

Insomesituationsyoumaynditnecessarytohavethemostcurrentsoftwareprograms,devicedrivers,or
operatingsystem.Thissectionexplainshowtogetthelatestupdatesforyourcomputer.

Selectanyofthefollowingtopics:

•“Gettingthelatestdevicedriversforyourcomputer”onpage87

•“Updatingyouroperatingsystem”onpage87

•“UsingSystemUpdate”onpage88

Gettingthelatestdevicedriversforyourcomputer

Note:BecauseLenovomakesconstantimprovementstoitsWebsites,theWebpagecontentsaresubject

tochangewithoutnotice,includingthecontentsreferencedinthefollowingprocedure.

YoucandownloadandinstallupdateddevicedriversfromtheLenovoWebsitebydoingthefollowing:

Attention:DonotdownloadupdateddevicedriversfromtheWindowsUpdateWebsite.Thedevice
driversprovidedontheWindowsWebsitehavenotbeentestedbyLenovoandusingthemmightcause
unexpectedproblems.ObtainupdateddevicedriversfromLenovo.

1.Gotohttp://www.lenovo.com/support.

2.ClickDownloadsanddrivers.

3.Selectthemachinetypeofyourcomputerfromthemachinetypelist.

4.Clickthecategoryofdeviceforwhichyouneedthedevicedriver.

5.Clicktheappropriatedevicedriver.

6.Downloadandinstallthedevicedriver.

Updatingyouroperatingsystem

MicrosoftmakesupdatesavailableforthevariousWindowsoperatingsystemsthroughtheMicrosoft
WindowsUpdateWebsite.TheWebsiteautomaticallydetermineswhatWindowsupdatesareavailablefor
yourspeciccomputerandliststhoseupdatesonly.Updatescouldincludesecurityxes,newversionsof
Windowscomponents(suchasMediaPlayer),xestootherportionsoftheWindowsoperatingsystem,
orenhancements.

Attention:DonotdownloadupdateddevicedriversfromtheWindowsWebsite.Thedevicedrivers
providedontheWindowsWebsitehavenotbeentestedbyLenovoandusingthemmightcauseunexpected
problems.ObtainupdateddevicedriversfromLenovo.See“Gettingthelatestdevicedriversforyour
computer”onpage87

ToaccesstheMicrosoftWindowsUpdatesite,dothefollowing:

1.Gotohttp://windowsupdate.microsoft.com/.

2.Followtheinstructionsonthescreen.

©CopyrightLenovo2012

formoreinformation.

87

UsingSystemUpdate

TheSystemUpdateprogramhelpsyoukeepthesoftwareonyourcomputerup-to-date.Updatepackages
arestoredonLenovoserversandcanbedownloadedfromtheLenovoSupportWebsite.Updatepackages
cancontainapplications,devicedrivers,BIOSashes,orsoftwareupdates.WhentheSystemUpdate
programconnectstotheLenovoSupportWebsite,theSystemUpdateprogramautomaticallyrecognizes
themachinetypeandmodelofyourcomputer,theinstalledoperatingsystem,andthelanguageofthe
operatingsystemtodeterminewhatupdatesareavailableforyourcomputer.TheSystemUpdateprogram
thendisplaysalistofupdatepackagesandcategorizeseachupdateascritical,recommended,and
optionaltohelpyouunderstandtheimportance.Y ouhavecompletecontrolofwhichupdatestodownload
andinstall.Afteryouselecttheupdatepackagesyouwant,theSystemUpdateprogramautomatically
downloadsandinstallstheupdateswithoutanyfurtherinterventionfromyou.

TheSystemUpdateprogramispreinstalledonmostLenovocomputersandisreadytorun.Theonly
prerequisiteisanactiveInternetconnection.Youcanstarttheprogrammanually,oryoucanusethe
schedulefeaturetoenabletheprogramtosearchforupdatesautomaticallyatspeciedintervals.Y oualso
canpredenescheduledupdatestosearchbyseverity(criticalupdates,criticalandrecommendedupdates,
orallupdates)sothelistyouchoosefromcontainsonlythoseupdatetypesthatareofinteresttoyou.

IftheSystemUpdateprogramcamewithyourcomputer,youcanopenitbycompletingthefollowing
procedure:

OntheWindowsVistaoperatingsystem,dothefollowing:

1.ClickStart➙AllPrograms➙ThinkVantage.

2.ClickSystemUpdate.

OntheWindows7operatingsystem,dothefollowing:

1.ClickStart➙LenovoThinkVantageT ools.

2.Double-clickUpdateandDrivers.

IftheSystemUpdateprogramisnotcurrentlyinstalledonyourcomputer,youcandownloaditfromthe
LenovoSupportWebsiteathttp://www.lenovo.com/support.

Cleaningandmaintenance

Withappropriatecareandmaintenanceyourcomputerwillserveyoureliably.Thefollowingtopicsoffer
informationtohelpyoukeepyourcomputerintopworkingorder.

•“Basics”onpage88

•“Cleaningyourcomputer”onpage89
–“Computer”onpage89

–“Keyboard”onpage89
–“Opticalmouse”onpage89
–“Displayscreen”onpage90

•“Goodmaintenancepractices”onpage90

Basics

Herearesomebasicpointsaboutkeepingyourcomputerfunctioningproperly:

•Keepyourcomputerinaclean,dryenvironment.Makesureitrestsonaat,steadysurface.

88ThinkCentreUserGuide
