Lenovo 10SQ006BGE User Manual

ThinkCentre M720 Tower 10SQ006BGE

Product

ThinkCentre M720t Tower

Region

Country/Region

Germany

Machine Type

10SQ

TopSeller

Processor

Intel Core i7-9700 (8C / 8T, 3.0 / 4.7GHz, 12MB)

Chipset

Intel B360 Chipset

Graphics

Integrated Intel UHD Graphics 630

Memory

1x 16GB DDR4-2666

Storage

1x 512GB SSD M.2 2280 PCIe x4 NVMe Opal

Optane Memory

None

Optional Bay

None

Front Access HDD

None

Optical

DVD±RW

Media Reader

7-in-1 Card Reader

Speaker

2Wx1

Ethernet

Integrated 100/1000M

WLAN + Bluetooth

None

Optional Rear Ports

None

Chassis Intrusion Switch

Chassis E-Lock

None

Kensington Cable Lock

None

Smart Cable Clip

None

Dust Filter

None

Carry Handle

None

Color

Black

Stand

None

Keyboard

USB Traditional Keyboard, Black, German

Mouse

USB Calliope Mouse

Power Supply

180W 85%

TUV Low Noise

Monitor Cable

None

System Management

None

Operating System

Windows 10 Pro 64, German

Bundled Software

None

Base Warranty

3-year, Onsite

Bundled Service

None

EAN / UPC / JAN

0193638352884

End of Support

2025-07-25

Announce Date

2019-06-25

Recommended Services Best

4Y Premier Support Upgrade from 3Y Onsite (5WS0T36207)

Better

3Y Premier Support Upgrade from 3Y Onsite (5WS0U26647)

Good

5Y Onsite upgrade from 3Y Onsite (5WS0D81042)

WWW.LENOVO.COM

Lenovo may not offer the products, services or features discussed in this document in other countries. Lenovo may withdraw an offering at any time. Information is subject to change without notice. Consult your local representative for information on offerings available in your area.

Lenovo reserves the right to change specifcations or other product information without notice. Lenovo is not responsible for photographic or typographical errors.

Lenovo provides this publication “as is” without warranty of any kind, either express or implied, including the implied warranties of merchantability or fitness for a particular purpose.

https://psref.lenovo.com

Visit psref website for the latest version of Product Specifcations Reference.

ThinkCentre M720 Tower Platform Speciﬁcations

Product Speciﬁcations Reference (PSREF)

Processor Intel

Memory 64GB max, UDIMM, DDR4-2666*, four 288-pin DIMM sockets, non-ECC,

Storage

Optical

Onboard SATA Media reader

Graphics

Monitor Cable

Chipset

Front ports* (Std.)

Front ports* (Opt.) Rear ports* (Std.)

Rear ports* (Opt.)

Note: The speciﬁcations above may not be available in all regions. Lenovo, April 2020



Celeron, Intel Pentium, or 8th / 9th Gen Intel Core™ i3 / i5 / i7 / i9 Processor

Processor

Celeron G4900 2 / 2 3.1G 2 MB DDR4-2400 UHD 610

Celeron G4920 2 / 2 3.2G 2 MB DDR4-2400 UHD 610 Pentium Gold G5400 2 / 4 3.7G 4 MB DDR4-2400 UHD 610 Pentium Gold G5500 2 / 4 3.8G 4 MB DDR4-2400 UHD 630 Pentium Gold G5600 2 / 4 3.9G 4 MB DDR4-2400 UHD 630

Core i3-8100 4 / 4 3.6G 6 MB DDR4-2400 UHD 630 Core i3-8300 4 / 4 3.7G 8 MB DDR4-2400 UHD 630 Core i5-8400 6 / 6 2.8G / 4.0G 9 MB DDR4-2666 UHD 630 Core i5-8500 6 / 6 3.0G / 4.1G 9 MB DDR4-2666 UHD 630 Core i5-8600 6 / 6 3.1G / 4.3G 9 MB DDR4-2666 UHD 630 Core i7-8700 6 / 12 3.2G / 4.6G 12 MB DDR4-2666 UHD 630 Core i3-9100 4 / 4 3.6G / 4.2G 6 MB DDR4-2400 UHD 630 Core i3-9300 4 / 4 3.7G / 4.3G 8 MB DDR4-2400 UHD 630 Core i3-9320 4 / 4 3.7G / 4.4G 8 MB DDR4-2400 UHD 630 Core i5-9400 6 / 6 2.9G / 4.1G 9 MB DDR4-2666 UHD 630

Core i5-9400F 6 / 6 2.9G / 4.1G 9 MB DDR4-2666 None

Core i5-9500 6 / 6 3.0G / 4.4G 9 MB DDR4-2666 UHD 630

Core i5-9500F 6 / 6 3.0G / 4.4G 9 MB DDR4-2666 None

Core i5-9600 6 / 6 3.1G / 4.6G 9 MB DDR4-2666 UHD 630 Core i7-9700 8 / 8 3.0G / 4.7G 12 MB DDR4-2666 UHD 630 Core i9-9900 8 / 16 3.1G / 5.0G 16 MB DDR4-2666 UHD 630

Cores /

Threads

Frequency

Base/Max(GHz)

Cache

Memory Support

(Up to)

Integrated

Graphics

dual-channel capable * System automatically clocks down for the processors with lower memory controller

Some: Hard Drive / SATA 6.0Gb/s, 2.5" or 3.5", 5400 rpm or 7200 rpm Some: Solid State Drive (SSD) / SATA 6.0Gb/s, 2.5" Some: M.2 SSD (2242 / 2280) / PCIe NVMe, PCIe 3.0 x2 or PCIe 3.0 x4 Some: Intel Optane™ Memory (not support Celeron / Pentium Processor), M.2 Some: DVD-ROM SATA 1.5Gb/s Drive, slim (9.0mm) Some: DVD Burner (DVD±RW), SATA 1.5Gb/s Drive, slim (9.0mm)

Three onboard SATA 6.0Gb/s connectors Optional 7-in-1 media reader

Intel UHD Graphics 610/630 in some processors, uses main memory, DirectX



12, one VGA (up to 2048x1536@50Hz), two DisplayPort™ (up to 4096x2304@60Hz), supports 3 independent displays, more displays support via discrete graphics

Some: NVIDIA Geforce GT 730 (End Of Life), DirectX 12, 2GB, PCIe 2.0 x16, 35 watts, two DisplayPort (up to 3840x2160@60Hz) Some: AMD Radeon™ 520, DirectX 12, 2GB GDDR5, PCIe 3.0 x8, 30 watts, two DisplayPort (up to 4096x2160@60Hz) Some: AMD Radeon RX 550X, DirectX 12, 4GB GDDR5, PCIe 3.0 x8, 50 watts, one DisplayPort (up to 3840x2160@60Hz), one HDMI (up to 4096x2160@60Hz), one VGA (up to 2048x1536@85Hz)

Optional DP to VGA dongle, DP to DVI-D dongle, DP to dual DP dongle (for Collage Display with intel integrated graphics), or DP to HDMI 1.4 dongle

Intel B360 Chipset

2x USB 3.1 Gen2, 2x USB 3.1 Gen1, 1x USB 3.1 Type-C Gen1 (15W charging), 1x microphone (3.5mm), 1x headphone / microphone combo jack (3.5mm)

Optional: 1x media reader 4x USB 2.0, 1x serial (9-pin), 1x ethernet (RJ-45), 1x VGA, 2x DisplayPort, 1x line-out (3.5mm) Optional: 2x USB 3.1 Gen1 via PCIe x1**, 2x USB 3.1 Type-C Gen2 via PCIe x4** (special bid only), 1x 2nd serial (9-pin), 4x serial (9-pin) via PCIe x1, 1x parallel (25-pin), 2x PS/2 ports (keyboard/mouse), additional RJ-45 and video ports available on optional graphics or ethernet card

* Depending on many factors, actual data transfer speed may be lower than theoretical speed ** Choose either 2x USB 3.1 Gen1 or 2x USB 3.1 Type-C Gen2

Audio support High Deﬁnition (HD) Audio, Realtek ALC233VB2 / internal speaker (2 watt )

WLAN

Some: 11ac Wi-Fi + BT 4.2, M.2 Card, Realtek RTL8821CE (dual band), 1x1 Some: 11ac Wi-Fi + BT 4.2, M.2 Card, Realtek RTL8822BE (dual band), 2x2 Some: 11ac Wi-Fi + BT 4.2, M.2 Card, Intel Dual Band Wireless-AC 3165, 1x1 Some: 11ac Wi-Fi + BT 4.2, M.2 Card, Intel Dual Band Wireless-AC 8265, 2x2

Bluetooth™

Ethernet Ethernet (Opt.)

Some: Bluetooth 4.2 wireless, integrated in Wi-Fi + BT combo adapter Gigabit ethernet, Intel Ethernet Connection I219-V (Jacksonville), Wake on LAN

Some: Intel Ethernet Server Adapter I350-T4*, gigabit ethernet, 4x RJ-45, PCIe x4 Some: Bitland BN8E88*, gigabit ethernet, 1x RJ-45, PCIe x1 (special bid only)

* Choose either I350-T4 or BN8E88

Manageability Security chip Security features

None Discrete TPM 2.0, TCG Certiﬁed

● Security slot (in rear for optional Kensington

● Padlock loop



MicroSaver cable)

● Optional cable lock to physically lock both keyboard and mouse

● Optional chassis intrusion switch

● Optional chassis E-Lock (special bid)

● Power-on password

● Administrator password

● Hard disk password

● Boot sequence control

● Boot without keyboard and mouse

● Individual USB port disablement

● Smart USB protection, allows keyboard/

mouse only, blocks all storage devices

Keyboard

Some: Lenovo Calliope Keyboard (USB connector), black Some: Lenovo Traditional Keyboard (USB connector), black Some: Lenovo Calliope Wireless Keyboard (2.4GHz via USB receiver), black

Mouse

Some: Lenovo Keyboard (PS/2 connector), black (only available via special bid) Some: Lenovo Calliope Mouse (USB connector), black Some: Lenovo Fingerprint Mouse (USB connector), Windows Hello support, black Some: Lenovo Calliope Wireless Mouse (2.4GHz via USB receiver), black Some: Lenovo Mouse (PS/2 connector), black (only available via special bid)

Mechanical

●

Tower (15L), black color, metal case

●

(WxDxH) 5.91" X 10.65" X 14.17"; 150mm X 270.5mm X 360mm

●

Approx. 15.21 lb (6.9 kg), weight may vary by conﬁguration

●

Optional dust ﬁlter Bay 1: Slim external ODD bay Bay 2: 3.5", 1" high, internal, HDD/SSD Bay 3: 3.5", 1" high, internal, HDD/SSD (optional bay) Slot 1: half-length full-height (length < 189mm, height < 104mm), PCIe 3.0 x16 Slot 2: half-length full-height (length < 189mm, height < 104mm), PCIe 3.0 x1 Slot 3: half-length full-height (length < 189mm, height < 104mm), PCIe 3.0 x1 Slot 4: no slot, only bracket for optional port extension M.2 card slots: Two (one for WLAN, one for SSD/Optane)

Power supply Some: 180 watts, autosensing, 85% PSU

Some: 210 watts, autosensing, 85% PSU Some: 260 watts, autosensing, 92% PSU (only available via special bid)

Limited warranty3Some: 1-year or 3-year, depot service / service upgrades available

Some: 1-year or 3-year, limited onsite service / service upgrades available

Preload Preloaded operating system

Some: Windows 10 Pro 64-bit Some: Windows 10 Home 64-bit

Preloaded applications (only some listed)

● Lenovo Vantage

● Microsoft Ofﬁce preloaded;

purchase a product key to activate

● Cyberlink PowerDVD (only for models with DVD / DVD±RW)

● Cyberlink Power2GO (only for models with DVD±RW)

● LinkedIn

Environment ENERGY STAR



6.1, EPEAT™ Silver rating (North America), ErP Lot 3, TCO,

TUV low noise veriﬁed (coming soon, on some models), RoHS-compliant

Accessories For compatible accessories, please go to http://smartﬁnd.lenovo.com


