Lenco MMS-201 User Manual

MMS-201

MP3 Player Speaker Box Set

User manual

English

For information and support, www.lenco.eu

1. Basic controls and interfaces of the player

Item Description Item Description

1 Speaker

Button

MENU Button (Menu / Enter)

REC Button

MODE Button

Button

(Mono)

Button

(Play/ Pause, Power On/Off)

(Record, Record Stop and Save)

(Change mode)

(Back, Fast-Backward, Down)

(Next, Fast-Forward, Up)

(Volume Down)

Button

LCD Display

11 Memory Card Slot

12 USB Port

13 Mini USB Port

14 Battery Compartment

15 Line In Jack

16 Earphone

(Volume Up)

(SD Card)

(for USB Disk)

(PC Connection / Charge)

2. Detachable Rechargeable Battery

The player comes with a detachable rechargeable lithium battery. When using the device for

the first time, charging it for 3 - 4 hours or until the battery icon is show the battery is in full.

Battery Is In Full

A. Install the Rechargeable Battery:

• Open the cover door of battery compartment which located at the back of the player. And then

place the rechargeable lithium battery into battery compartment.

• Make sure contact plate is inserted into the pins connector correctly.

• Close the cover door.

Note: The player continues to use battery power after it’s been turned to off, if unit isn’t used for a

while, the battery might need to be charged.

B. Charging the Battery:

You can charge the player battery in two ways:

• Connect player to your computer.

• Use the USB power charger. (not included)

C. Connection and Charging:

• Once you have connected player with computer / Power charger, then you will see the

“Connecting Mode” or any one of the “Mode” screen on LCD display.

• In connect / mode screen, you can see the bar levels are running in battery icon, the battery is

in charging.

• The battery icon will show “Full” when the charging is completed. Disconnect the USB cable

when it is done.

Connecting Mode Screen

Important: The battery cannot be charged when your computer is in sleep mode. The USB port on

most keyboards does not provide enough power to charge the player. Connect player direct to a

USB port on your computer only to prevent charging problem.

3. Insert Micro SD Memory Card / USB Disk

MMS-201 is design without an internal memory, it need to have a USB disk or a SD memory

card insert into the USB port or the card slot. Upload your desired music files to the USB disk / SD

memory card direct from the computer then insert to player.

Important: When both SD card and / or the USB disk have inserted to device and the device is

connected to the computer by uses the USB cable; only a “Removable Driver” of SD card can be

detected and use for data transfer with the computer. Due to the same data pins are used as sharing

in-between the mini USB and the computer, the USB disk is cannot be detected and use for data

transfer.

• “Card/USB is pulled” message will show when you remove the SD memory card / USB disk

from player.

• “Format Error” message may show when you insert the SD memory card / USB disk in not

good way or incorrectly. Take them out and plug them in again.

• “No file in disk” message will show, if you do not put Micro SD memory card / USB disk into

the player’s memory card slot / USB port, when you want to change mode to music play.

Note: The player functional may dead halt if you plug and unplug the card or USB incorrectly.

Power reset the player by take out the rechargeable battery if happened.

4. Connecting and Disconnecting

Connect the player to your computer to upload music files to your player, or to download

recorded voice memos to your computer, when the SD memory card or USB disk is in use.

A. Connecting the player

• Plug the USB cable to the Player’s mini USB port and into a USB port on your computer, then

the computer will detect and install the driver automatically. Once the installation is complete

the player will be displayed in “My Computer” or for MAC users on the desktop.

• Now the player is ready for music files upload / download with your computer.

• Transfer the music files by using the computer mouse use drag and place, or copy and paste, in

between the player and your computer. Disconnect it when you’re done.

Note: The player will disconnect with PC and go into clock display mode or operation mode, when

press / Pressing “MENU” button if in connecting mode. Unplug the USB cable and plug it in again

to return to connecting mode if you want.

B. Disconnecting the player

• Do not disconnect the player while it’s uploading or downloading files with your computer.

• Windows system PC, disconnect the player by clicking the “Safely Remove Hardware” icon in

the Windows system tray.

• Mac system PC, disconnect the player by dragging the player icon on the desktop to the Trash.

• Now it is safe to unplug the USB cable.

Note: If you do not “Safely remove hardware” before disconnecting, data can be lost!

5. Getting Started

A. Turning the player ON and OFF

• Press and hold button to turn the player “On and Off”.

• When the player is turned On, first the opening screen and then it will enter to “Radio / Music

/ Line In” mode which is available.

• Example, the player will enter to Radio mode, if no SD memory card and USD disk is in use.

• When you turn Off the player, the last status will be recorded and the last status shall be recall,

when you start up the player again.

Note: The last status memory will be changed if you have take away the SD memory card and / or

USB disk.

B. Change Function Mode

• Press the “MODE” button to change to “FM Radio or Music” function mode here is in easily

way.

C. Auto Mode

• The player has designed “Auto Mode” function, the player will direct switch to related mode,

when you plug in the source of SD memory card, USB disk or Line In cable. This means that

the mode will change according to the last source have plugged.

D. Enter to Clock Display and Mode Menu

• In function mode, press and hold the “MENU” button to enter to clock display and mode menu,

then you will see the clock is displaying.

Clock Display

• In clock display mode, press “MENU / / / ” button will enter to mode menu.

• Then you can find “Calendar / Music / Recorder / FM Radio / System” mode menu here to

choose. Press / button to select your desired mode and press “MENU” button to

enter.

Mode Menu

Note: In menu mode, Press button to back to previous item / menu, press “MENU” button to

enter the selected item. Press and hold “MENU” button to return to “Clock Display” mode.

E. Mode Menu

Calendar

• In mode menu, choose “Calendar” to view the Year, Month, Date and Time” in one screen.

Music

• In mode menu, choose “Music” to enter to music mode.

Recorder
