PORTABLE RADIO WITH iPod DOCKING
IPD-5200
For information and support
IPD5200 iB.indd EN12-EN13 2010-10-11 8:22:44
www.lenco.eu
Eng
Eng
3
When used in the directed manner, this unit has been designed and manufactured to
ensure your personal safety. However, improper use can result in potential electrical
shock or fire hazards. Please read all safety and operating instructions carefully before
installation and use, and keep these instructions handy for future reference. Take
special note of all warnings listed in these instructions and on the unit.
1. Water and Moisture
The unit should not be used near water. For example: near a bathtub, washbowl,
kitchen sink, laundry tub, swimming pool or in a set basement.
2. Ventilation
The unit should be situated so that its location or position does not interfere with its
proper ventilation. For example, it should not be situated on a bed, sofa, rug or similar
surface that may block the ventilation openings. The ventilation should not be impeded
by covering the ventilation openings with items, such as newspapers, table-cloths,
curtains, etc. Also, it should not be placed in a built-in installation, such as a bookcase
or cabinet, which may impede the flow of air through the ventilation openings.
3. Heat & Flame
The unit should be situated away from heat sources such as radiators, heat registers,
stoves or other appliances (including amplifiers) that produce heat.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
4. Power Source
The unit should be connected to a power supply only of the type described in the
operating instructions or as marked on the appliance.
Where the AC/DC Adaptor is used as the disconnect device, the disconnect device
shall remain readily operable.
5. Power Cord Protection
Power supply cords should be routed so that they are not likely to be walked on or
pinched by items placed upon or against them. It is always best to have a clear area
from where the cord exits the unit to where it is plugged into an AC outlet.
6. Cleaning
The unit should be cleaned only as recommended. See the section "Care and
Maintenance" of this manual for cleaning instructions.
7. Object and Liquid Entry
Care should be taken so that objects do not fall and liquids are not spilled into any
openings or vents located on the product. It shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as vases, shall be placed on
the apparatus.
8. Attachments
Do not use attachments no recommended by the product manufacturer.
9. Lightning and Power Surge Protection
Unplug the unit from the wall outlet and disconnect the periods of time. This will
prevent damage to the product due to lightning and power-line surges.
10. Overloading
Do not overload wall outlets, extension cords, or integral convenience receptacles
as this can result in a risk of fire of electric shock.
Important Safety Instructions
Table of content
2
Important Safety Instructions........................................................................................
Features......................................................................................................................
Installation ..................................................................................................................
Description of Parts ....................................................................................................
Listening to iPod.........................................................................................................
Radio Tuner Operation ..............................................................................................
EQ preset, Treble and Bass setting............................................................................
Listening to External Audio Source.............................................................................
Clock Setting...............................................................................................................
Alarm Operation..........................................................................................................
Sleep Timer Function..................................................................................................
Care and Maintenance................................................................................................
Warranty......................................................................................................................
Specifications..............................................................................................................
3
4
5
6-7
8
9-10
10
11
11
12-13
13
14
14
15
IPD5200 iB.indd 2-3 2010-12-18 16:32:32
Eng
Eng
Installation
5
Clock setting battery back-up
A backup battery compartment located at rear of the unit.
(1) Open the main battery compartment lid then open the inner clock battery
compartment lid as well.
(2) For clock setting backup, follow the polarity diagram shown inside the
compartment and install 2 x AAA (UM-4) batteries (purchase separately).
(3) Close the clock battery compartment lid.
Install main battery
(4) For radio, iPod and AUX operation, follow the polarity diagram shown inside
the compartment and install 6 x AA (UM-3) batteries (purchase separately).
(5) Close the main battery compartment lid.
AC-DC Adaptor Connection
The unit can be powered by an external AC-DC Adaptor, required the output DC 9V
1250mA (included).
(1) Firmly and securely plug the adaptor's AC plug into AC main outlet.
(2) Connect the adaptor's DC output plug to the DC-in jack of the unit.
Warnings:
Batteries (battery pack or batteries installed) shall not be exposed to excessive heat
such as sunshine, fire or the like.
11. Damage Requiring Service
This unit should be serviced by qualified service personnel when:
A.The power supply cord or plug has been damaged.
B.Objects have fallen into or liquid has been spilled into the enclosure.
C.The unit has been exposed to rain.
D.The unit has been dropped or the enclosure damaged.
E.The unit exhibits a marked change in performance or does not operate normally.
12. Periods of Nonuse
If the unit is to be left unused for an extended period of time, such as a month or
longer, the power cord should be unplugged from the unit to prevent damage or
corrosion.
13. Servicing
The user should not attempt to service the unit beyond those methods described
in the user's operating instructions. Service methods not covered in the operating
instructions should be referred to qualified service personnel.
Features
iPod, iPod mini, iPod nano, iPod touch, iPod classic and iPod shuffle are trademarks
of Apple Computer Inc., registered in the U.S. and other countries.
iPod is not included.
4
Thank you for purchasing the PORTABLE RADIO iPod DOCKING.
This model incorporates following features :
Different iPod models Player / Re-charger
FM receiver with digital read out on LCD
Clock and Alarm timer function
Wake up to Alarm (Buzzer), Radio or iPod with Snooze function
Sleep timer function
LCD display with back-light
Audio line-in (AUX) for connecting other digital audio player
Built-in 2 High Fidelity Speakers
Preset EQ effect
IPD5200 iB.indd 4-5 2010-12-18 16:32:32
Eng
Eng
Description of Parts
7
1. iPod docking compartment
2. iPod docking connector
3. iPod docking compartment door
4.OPEN button ---- To open the iPod compartment door
5.POWER button ----- To turn the unit on and off
6. Power Status indicator: LED
7. LCD display
8. Handle
9. SLEEP button ---- Select the time duration of the sleep timer
10. iPod / MEM button ---- iPod Play / Pause function ;
Save radio preset station
11. ALARM button ---- Turn the alarm on and off ; Set alarm time and
alarm source
12. V / button ----- Adjust volume level up or down
13. MODE / EQ button ---- In power off mode : Select clock setting and
12/24 hour format
In power on mode: Select EQ preset (CLASSIC/
JAZZ/ROCK/POP) and Treble / Bass setting
14. FM rod antenna
15. PRESET button ---- Select preset radio station
16. T/CH / button ---- In radio mode: Tune the radio frequency up/down
In iPod mode : Skip tracks Forward / Backward;
perform high-speed search
17. FUNC button ---- Select FM stereo / FM mono / iPod / AUX modes
18. SNOOZE / LIGHT -----Activate the snooze function ; turn LCD backlight
DIM / BRIGHT / OFF
19. Speakers
20. DC-in jack -----For the connection of external DC power supply
21. Stereo Phones jack
22. AUX jack ---- Auxiliary audio signal input
23. RESET button ---- For resetting the unit
24. Main battery compartment
25. Inner Clock battery compartment
Main Unit
Description of Parts
6
Main Unit
10
2 1
Top View
Front View
12
13
11
4
16
17
15
9 7 6
14
18
19
19
3
8 5
Rear View
23 22 21 252024
IPD5200 iB.indd 6-7 2010-12-18 16:32:32
Eng
Eng
9
FM Antenna
Fully extend the FM rod antenna for the best FM radio reception.
Radio Tuning
1. Press the POWER button to turn on the unit, where the power
status indicator light on.
2. Press the FUNC button to select FM stereo or FM mono radio receiving
mode.
3. To manually tune to a desired station, repeatedly press the T/CH
/ button.
4. To automatically search for stations with strong signals, press and hold
the T/CH / button until the frequency digits on display begins to
scan then release the button. The tuner will stop on the first strong
signal it finds.
Notes :
- Manual tune to select weaker stations that might be skipped during
automatic tuning.
- If the automatic tuning does not stop on the exact frequency of the station,
for example , it stops on 100.9 MHz instead of 100.8 MHz, use the manual
tuning method to "fine tune" to the exact frequency of the desired station.
Radio Preset Stations
The units allows you to store up to 20 FM stations for easy recall at any time.
Preset Stations
1. Press the POWER button to turn on the unit, where the power status
indicator light on.
2. Press the FUNC button to select FM stereo or FM mono radio receiving
mode.
3. Tune to the radio station you want to store in memory by using the T/CH
/ button.
4. Press the MEM button. The preset channel number appears on display
and blinking.
5. To select desired preset station number, press the T/CH / button.
6. To confirm preset location, press the MEM button.
7. Repeat steps 3 to 6 to store other stations, if apply.
Radio Tuner Operation
8
This model adopts different iPod models. Following steps guide you
listening to iPod music.
1. Press the OPEN button to open the iPod docking compartment door.
2. Your iPod can now be inserted into the docking port by placing the
connector on the bottom of the iPod onto connector in the docking bay.
Caution: Please be careful when seating the iPod into the docking to avoid
damaging the 30-pin connector on the iPod or in the docking system.
3. Slightly push the iPod compartment door upward by hand until it closed
and locked.
4. Press the POWER button once to turn on the unit and the power status
indicator lights on.
5. Press the FUNC button to select iPod mode.
In iPod mode :
- To start playback music, press the iPod button once.
- To pause the music , press the iPod button.
- To resume music , press the iPod button again.
- You may press the V / button to adjust the volume to a desired level.
- When a song playback, press and hold the T/CH / button
to perform high speed search forward / backward.
- To skip to next or previous song, press the T/CH / button.
To turn off the unit, press the POWER button and the power status
indicator will light off.
When the unit is powered by external DC adaptor and once the iPod
connected to the docking station, the unit recharges the iPod battery.
Listening to iPod
Note:
(1) Before docking, set your iPod to album menu or to the shuffle play mode selection.
Once your play mode is set insert the iPod into docking compartment.
You must operate your music selection by using the front right hand side control panel.
(2) Music from the iPhone can also be played in docking compartment. Once iPhone is
placed in docking compartment the iPhone screen will display the following message:
This accessory is not made to work with iPhone
Would you like to turn on Airplane Mode to reduce audio interference?
You will not be able to make or receive calls.
- The above message will disappear from the iPhone screen after few seconds. The
iPhone is still able to receive incoming calls while inserted in docking compartment.
- The iPhone music selection can be operated by using the front right hand side
control panel.
YES NO
IPD5200 iB.indd 8-9 2010-12-18 16:32:33
Eng
Eng
11
Listening to an External Audio Source
1. Connect an audio cable (not included) with 3.5mm stereo plug from
an auxiliary audio device to the AUX jack of the unit.
2. Press the POWER button to turn on the unit.
3. To select auxiliary audio input, press the FUNC button. The "AUX"
indicator show on display.
4. Turn on the external auxiliary audio device.
5. The volume and preset equalizer can now be controlled through the unit.
Operate all other functions on the external device as usual.
Notes: Press the POWER button to turn off the unit when you finish listening.
Don't forget to switch off the power of the external audio device as well.
Clock Setting
When the unit is OFF (power off mode):
Set Clock
1. Press the MODE button until the clock digits blink.
2. Press the V / button to set hour.
3. Press the T/CH / button to set minute.
Set 12/24 Hour format
4. Press the MODE button again entering 12/24 hour format setting mode.
5. Press the T/CH / button to select 12 or 24 hour display format.
Exit setting mode
6. To save all settings and exit the setting mode, press the SNOOZE button.
10
Bass setting :
1. Press and hold the EQ button entering Bass setting mode, the "BASS"
indicator appears on display.
2. To select desired bass level, press the T/CH / button.
Treble setting :
3. Press the EQ button again entering Treble setting mode, the "TRE" indicator
appears on display.
4. To select desired treble level, press the T/CH / button.
5. Press the EQ button to exit bass/treble setting mode.
EQ setting :
The unit is designed to have four EQ presets for your selection , the
CLASSIC , JAZZ, ROCK and POP .
You can select the desired effect by pressing the "EQ" button repeatedly at
following sequence :
EQ preset , Treble and Bass Setting
Radio Tuner Operation
Notes :
1. There is a few seconds delay when programming, after this delay time,
the unit will automatically switch back to normal tuner mode.
2. You can overwrite a preset station by overwriting and storing the new
frequency in its place.
Recalling Preset Station
1. Press the POWER button to turn on the unit, where the power status
indicator light on.
2. Press the FUNC button to select FM stereo or FM mono radio receiving
mode.
3. Press the PRESET button. The preset channel number and PRESET
indicator appear on display.
4. To select desired preset station, press the T/CH / button.
CLASSIC
JAZZ
ROCK POP
OFF (or BASS/TREBLE, if previously set)
IPD5200 iB.indd 10-11 2010-12-18 16:32:33
Eng
Eng
13
Sleep Timer Function
Sleep to timer
This feature allows you to fall asleep to the radio or iPod for up to 120 Minutes.
The unit shuts off automatically when the time expires.
1. Press the POWER button to turn the unit on.
2. Either tune to the desired radio station in radio mode or playback music
from the iPod.
3. To select the sleep timer to turn the unit off after 15, 30, 45, 60, 90 or
120 minutes, press the SLEEP button repeately. The display show the
indicator . The unit plays for the selected length of time then
automatically turns off.
4. To turn the unit off before the sleep timer counts down to zero, press
the POWER button at any time.
Notes :
If you are falling asleep to music from an external device connected to the
AUX input, the sleep timer will shut off the power to this system but it will
not turn off the external device.
Wake to iPod or Radio
When the alarm time is reached, the selected alarm source (iPod or Radio)
will automatically turn on. It starts softly and gradually becomes louder.
It plays for 30 minutes then shuts off and resets itself for the following day.
During the activation of the alarm source, you may press the SNOOZE
button to activate the snooze function. The alarm stops for the snooze time
(around 10 minutes) then turns on again.
To cancel the snooze before it expires, press theALARM button.
This manual snooze operation can be repeated three times. Each time the
alarm turns on, it plays for 30 minutes (without pressing the snooze button).
To stop the alarm immediately after the alarm sounds, you may also press
the POWER button. It resets itself for the following da
y.
Or, when the alarm sounds, you may press the V / or T/CH /
button to continue listening the iPod / Radio, where the alarm will be disable.
12
Alarm Operation
When the unit is OFF (power off mode):
Select wake up alarm source
1. Press and hold the ALARM button until the alarm source indicator blink.
2. Press the T/CH / button to select alarm source BUZ (buzzer) ,
iPod or RAD (radio).
Setting the alarm time
3. Press the ALARM button again, alarm time digits blink.
4. Press the V / button to set alarm hour.
5. Press the T/CH / button to set alarm minute.
Save settings and activate alarm
6. To save all settings and exit the setting mode, press the SNOOZE button.
7. To activate the daily alarm, press the ALARM button and the
corresponding alarm source indicator appears on the LCD display.
Notes :
---If "Wake to iPod" is selected but your iPod has not been docked, the alarm
source will be redirected to the Alarm Buzzer automatically when the alarm
is reached.
---When "Wake to Radio" is selected, make sure the radio station which you
want to wake to is tuned.
Wake to Buzzer
When the alarm time is reached, the buzzer alarm will sound for 3 Minutes.
It goes into Auto-snooze mode if no further button has been pressed.
The display shows the "SNOOZE" indicator. The buzzer turns off for the
snooze time (around 10 minutes) then comes on again. This operation will
be repeated three times. After the fourth alarm is finished, the alarm will
shut off until the same alarm time on the next day.
You may also activate the snooze function manually after the alarm sounds
by pressing the SNOOZE button. The buzzer stops for the snooze time then
comes again.
To cancel the snooze before it expires, press the ALARM button.
The snooze operation (including auto-snooze and manual snooze) can be
repeated by 3 times only.
To stop the alarm immediately after the buzzer sounds, you can also press
the ALARM button. It resets itself for the following day.
IPD5200 iB.indd 12-13 2010-12-18 16:32:33
Eng
Eng
THE SPECIFICATION AND EXTERNAL APPEARANCE OF THE SET ARE
SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
Power Supply
Power Adaptor Input AC 230V ~ 50Hz(For EU)
Output DC 9V 1250mA
Battery Back-up for clock / memory: DC3V--- AAA (UM-4)type x 2 (not included)
Battery for operating the unit: DC9V --- AA (UM-3) type x 6 (not included)
Specifications
15
Speaker Output 2W+2W (Max.)
Power consumption 1 W (Standby)
16 W (Max.)
Dimensions 298 x 210 x 91mm
Weight 959g
o
Operating Temperature -10 ~ + 45 C
and Humidity 70%
For information and support www.lenco.eu
14
Care and Maintenance
- Do not subject the unit to excessive force, shock, dust or extreme temperature.
- Do not tamper the internal components of the unit.
- Clean your unit with a damp (never wet) cloth. Solvent or detergent should never
be used.
- Avoid leaving your unit in direct sunlight or in hot, humid or dusty places.
- Keep your unit away from heating appliances and sources of electrical noise such
as fluorescent lamps or motors.
Resetting the Unit
If the unit experiences a power surge or electric shock, it is possible that the
internal micro-controller may lock up and the unit will not respond to any
commands from the front panel controls.
1.In this event, unplug and then reconnect the AC power plug into the wall outlet.
2.Use a straightened paper clip, toothpick or similar objects to press the RESET
button located at the rear of the main unit (see the below figure). The reset
operation clears the system memory and all of your previous settings will be
erased.
CAUTION: DO NOT USE SHARP, POINTED OBJECT TO PRESS THE RESET
BUTTON. IT MAY DAMAGE THE RESET SWITCH INSIDE THE UNIT.
RESET button
If you have questions regarding the warranty, the length of warranty and the
working method of it, you can find the information on our site www.lenco.eu or
you can directly contact your retailer.
Warranty:
IPD5200 iB.indd 14-15 2010-12-18 16:32:33
DE
TRAGBARES RADIO MIT IPOD-DOCK
IPD-5200
IPD5200 iB.indd DE2:1
Zur information und Unterstützung,
www.lenco.eu
2DE3
DE
Wichtige Sicherheitshinweise
Wenn das Gerät entsprechend der Anweisungen benutzt wird, kann
aufgrund des Gerätedesign Ihre persönliche Sicherheit gewährleistet
wer d e n. Be i un s ach g e mäß e r Be n u tzu n g be s t eht al le r d ing s
Stromschlag- und Brandgefahr. Bitte lesen Sie alle Sicherheits- und
Bedienungshinweise sorgfältig vor der Inbetriebnahme durch und
bewahren Sie dies e Anleitung zum spätere n N achschlagen auf.
Beachten Sie besonders alle Warnhinweise in dieser Anleitung und auf
dem Gerät.
1. Wasser und Feuchtigkeit
Das Gerät darf nicht in der Nähe von Wasser benutzt werden. Beispiel:
in der Nähe von Badewannen, Spülen, Waschbecken. Swimmingpools
oder feuchten Kellerräumen.
2. Belüftung
Das Gerät sollte so aufgestellt werden, dass die Luftzirkulation nicht
beeinträchtigt wird. Das Gerät sollte z. B. nicht auf ein Bett, Sofa,
Bettvorleger oder eine andere weiche Unterlage gestellt werden, bei
der die Ventilationsöffnungen blockiert werden könnten. Vergewissern
Sie sich, dass keine der Ventilationsöffnungen durch Gegenstände wie
z. B. Zeitungen, Tischtücher, Vorhänge o. Ä. abgedeckt ist.Das Gerät
sollte nicht an Orten, wie z. B. Schränke oder Bücherregale, aufgestellt
werden, an denen die Luftzufuhr zu den Venti lationsöffnu ngen
beeinträchtigt werden könnte.
3. Hitze und Flammen
Installieren Sie das Gerät nicht in der Nähe von Hitzequellen, wie z. B.
Heizungen, Herden oder anderen Geräten die Hitze produzieren (z. B.
Verstärker) auf. Gegenstände mit offenen Flammen, wie z. B. Kerzen,
sollten niemals auf das Gerät gestellt werden.
4.Stromversorgung
Das Gerät darf nur mit der auf dem Gerät oder der Bedienungsanleitung
angegebenen Netzspannung betrieben werden Wenn das Netzteil zum
Ein- und Ausschalten des Geräts benutzt wird,achten Sie bitte immer
darauf, dass die Steckdose immer durch den Benutzer erreichbar
bleibt.
5.Netzkabelschutz
Das N etzka bel m uss s o ver legt werde n, da ss es nic ht du rch
Gegenstände eingeklemmt werden kann bzw. darauf gestellt werden.
Achten Sie außerdem darauf, dass niemand auf das Netzkabel treten
kann. Es ist immer sinnvoll den Bereich, an dem das Kabel aus dem
Gerät austritt und den Bereich um die Steckdose herum, frei zu halten.
6. Reinigung
Inhalt
Wichtige Sicherheitshinweise...................................................................3
Eigenschaften und Funktionen.................................................................5
Inbetriebnahme......................................................................................... 5
Beschreibung der Bedienelemente .......................................................6-7
iPod-Musik hören......................................................................................8
Radiobetrieb .......................................................................................9-10
EQ-Einstellung, Höhen und Bässe..........................................................11
Benutzung externer Audiogeräte.............................................................11
Uhrzeiteinstellung...................................................................................12
Weckerfunktion.......................................................................................12
Einschlaf-Timer-Funktion........................................................................14
Pege und Wartung................................................................................14
Garantie..................................................................................................15
Technische Daten...................................................................................16
IPD5200 iB.indd 2-3 2010-12-18 16:32:34
4DE5
DE
Eigenschaften und Funktionen
Vielen Dank für den Kauf dieses TRAGBAREN RADIOS MIT IPOD-DOCK.
Dieses Modell verfügt über die folgenden Leistungsmerkmale:
- Verschiedene iPod-Modelle / Ladegerät
- UKW-Empfänger mit Digitalanzeige auf LCD
- Uhrzeit- und Alarmfunktion
- Aufwac hen zu Alarm (Signal ton), Radio oder iPod mit
Schlummerfunktion
- Einschlaf-Timer-Funktion
- LCD-Anzeige mit Hintergrundbeleuchtung
- Audioeingang (AUX) zum Anschluss externer Audiogeräte
- 2 eingebaute HiFi-Lautsprecher
- Voreingestellte EQ-Effekte
iPod, iPod mini, iPod nano, iPod touch, iPod classic und iPod shufe sind
eingetragene Warenzeichen in den USA und anderen Ländern der Firma
Apple Computer Inc.
Im Lieferumfang ist kein iPod enthalten.
Inbetriebnahme
Einrichten des Reservebatteriesystems
An der Rückseite des Geräts bendet sich ein Reservebatteriefach.
1.Öffnen Sie das Hauptbatteriefach und ebenfalls das innere Uhr-Batteriefach.
2. Um die Uhrzeiteinstellungen mit Reservestrom jederzeit aufrecht erhalten
zu können, folgen Sie der Zeichnung innerhalb des Batteriefachs und legen
Sie 2 Batterien der Größe AAA (UM-4) ein (nicht im Lieferumfang).
3. Schließen Sie das Uhr-Batteriefach wieder.
Einlegen der Hauptbatterien
4. Für den Radio- iPod- und AUX-Betrieb, folgen Sie der Zeichnung innerhalb
des Batteriefachs und legen Sie 6 Batterien der Größe C (UM-2) ein (nicht
im Lieferumfang).
5. Schließen Sie das Hauptbatteriefach wieder.
Anschluss des Netzadapters
Dieses Gerät kann über ein externes Netzteil mit DC 9V, 1.250mA
Ausgangsleistung (im Lieferumfang), mit Strom versorgt werden.
Stecken Sie den Netzstecker des Adapters in einer Steckdose.
Schließen Sie den Ausgangsstecker des Netzadapters an den DC-IN-
Eingang des Geräts an.
Warnung:
Die Batterien (Akkupack oder eingelegte Batterien) dürfen niemals starker
Hitze, wie z. B. Sonnenlicht, Feuer o. Ä. ausgesetzt werden.
Das Gerät darf nur den Anweisungen nach gereinigt werden. Siehe
Abschnitt "Pege und Wartung" dieses Handbuchs für Anweisungen
zur Reinigung des Geräts.
7. Fremdgegenstände und Flüssigkeiten im Gerät
Bitte achten Sie darauf, dass keine Gegenstände und Flüssigkeiten
in die Ventilationsöffnungen des Geräts ge. Dieses Gerät darf keinen
Wassertropfen und -spritzern ausgesetzt werden. Gegenstände
die mit Flüssigkeiten gefüllt sind sollten nicht auf das Gerät gestellt
werden.
8. Zubehör
Verwenden Sie keine Aufsätze, die nicht vom Hersteller angegeben
wurden.
9. Blitz- und Überspannungsschutz
Ziehen Sie den Stecker aus der Steckdose, wenn Sie das Gerät über
einen längeren Zeitraum nicht benutzen. Damit werden aufgrund von
Blitzeinschlägen und Überspannung entstehende Schäden am Gerät
verhindert.
10. Überlastung
Überl ast en Sie niem als Steckdosen, Verlänge run gsk abe l o der
Geräteanschlüsse, da dies zu Feuer- oder Stromschlaggefahr führen
kann.
11. Schäden, die Reparaturen erfordern
Dieses Gerät muss durch entsprechend ausgebildetes Personal
repariert werden, wenn:
A.Das Netzkabel oder der Netzstecker beschädigt sind.
B.Fremdgegenstände oder Flüssigkeiten in das Gehäuse gelangt sind.
C.Wenn das Gerät Regenwasser ausgesetzt wurde.
D.Das Gerät heruntergefallen ist oder das Gehäuse beschädigt wurde.
E.Das Ger ät nich t wi e gewoh nt f unktion iert oder e inen starke n
Leistungsabfall zeigt.
12. Bei Nicht-Benutzung
Wenn das Gerät über einen gewisssen Zeitraum nicht benutzt wird,
um für einen längeren Zeitraum, z. B. einen Monat oder länger, sollten
Sie das Netzkabel aus der Steckdose ziehen, um Schäden oder
Korrosion zu vermeiden.
13. Wartung
D e r Be n utz e r so l lte kei n e Versu c he an ste l len das Gerä t
eigenhändig zu warten, es sei denn es wurde entsprechend in der
Bedienungsanleitung beschrieben. Wartungsmethoden, die nicht
in der Bedienungsanleitung beschrieben werden, dürfen nur von
entsprechend ausgebildetem Fachpersonal ausgeführt werden.
IPD5200 iB.indd 4-5 2010-12-18 16:32:34
6DE7
DE
Beschreibung der Bedienelemente
Hauptgerät
1. iPod-Dock
2. iPod-Docking-Anschluss
3. iPod-Dock-Abdeckung
4. OPEN ---- Öffnen des iPod-Dock-Anschlusses
5. POWER ---- Ein-/Ausschalten des Geräts
6. Kontrolllampe: LED
7. LCD-Anzeige
8. Griff
9. SLEEP –--- Zeiteinstellung des Einschlaf-Timers.
10. iPod /MEM ---- iPod-Wiedergabe/Pause
Radiosender speichern
11.ALARM ---- Ein-/Ausschalten des Weckalarms; Weckzeit und
Alarmsignal einstellen
12.V ----- Lautstärke erhöhen bzw. verringern
13.MODE / EQ ---- Im ausgeschalteten Zustand: Einstellen von Uhrzeit
und 12/24-Stunden-Format
Im eingeschalteten Zustand: Einstellen des Equalizers (Klassik / Jazz
/ Rock / Pop) und Höhen/Bass-Einstellung
14.UKW-Stabantenne
15.PRESET ---- Senderauswahl
16.T/CH ---- Im Radiomodus: Einstellen der Radiofrequenz;
Im iPod-Modus: Titelauswahl; Schnellsuchlauf
17.FUNC ---- Betriebsartauswahl: UKW-Stereo / UKW-Mono / iPod /
AUX
18.SNOOZE / LIGHT ----- Aktivieren der Schlummerfunktion; Einstellen
der LCD-Hintergrundbeleuchtung auf DIM / HELL / AUS
19.Lautsprecher
20.DC-IN – Anschluss der externen Stromversorgung
21.Stereo-Kopfhöreranschluss
22.AUX-Anschluss ---- Zusätzlicher Audiosignaleingang
23.RESET ---- Systemreset des Geräts
24.Hauptbatteriefach
25.Uhr-Batteriefach
Beschreibung der Bedienelemente
Hauptgerät
Oberseitenansicht
Vorderansicht
Rückseitenansicht
2 1
10
12
13
11
4
16
17
15
9 7 6
14
18
19
19
3
8 5
23 22 21 252024
IPD5200 iB.indd 6-7 2010-12-18 16:32:35
Loading...
