Lenco IPD-4500 User Manual

IPD-4500

Pouch Speaker
for iPhone and iPod

For information and support, www.lenco.eu

The exclamation mark inside an equilateral triangle is intended to remind the user: Please note

the important operating and maintenance (servicing) instructions in the manual that comes with the

equipment.

Precaution: To prevent electric shock, please do not use a two-prong plug with an extension cord,

receptacle or other power supply outlet, unless the plug is completely inserted to prevent prong

exposure.

Warning: In order to reduce the risk of fire or electric shock, please do not expose this equipment

to rain or humid environments.

IMPORTANT IPD-4500 SAFETY INSTRUCTIONS

1. Please read all safety and operating instructions before operating the equipment.

2. Please retain the operating instructions in a safe place for future reference.

3. All warnings on the equipment and in the operating instructions should be heeded.

4. All operating instructions and use should be complied with.

5. Moisture and humidity – Please do not use this equipment in or near a bathtub, washbasin, kitchen

sink, damp basement or swimming pool.

6. Outdoor use – Warning: In order to reduce the risk of fire or electric shock, please do not expose this

equipment to rain or humid environments.

7. Location – the equipment should be installed in a stable location.

8. Ventilation – The location or position of installation should not affect normal ventilation. For

example, the equipment should not be placed on a bed, sofa, carpet, or similar surface, since that

may block the air vents; it also should not be placed in an enclosed space, such as an unventilated

bookcase or cabinet, etc.

9. Heat sources – The equipment should be kept far away from electric heaters, radiators, ovens, or

other heat generating equipment (including waste heat from other equipment).

10. Power supply – The power supply to which the equipment is connected should be of the type

described in the operating instructions or identified on the equipment itself.

11. Protecting the power cord – The power cord should be arranged so that it will be protected as much

as possible from being walked on, crushed, or squeezed by other objects. Special attention should

be paid to the plug cord, convenient socket cord, and their attachment outside of the equipment.

12. Grounding or polarization – There should be proper preventive measures for grounding and

polarization to prevent electrical problems.

13. Cleaning – The equipment should only be cleaned using a polishing cloth or a soft dry cloth. Never

clean this equipment using furniture wax, benzene, pesticide, or any other liquid with volatile

solvents as they will corrode the unit.

14. Periods of disuse – If this equipment is not to be used for a long time, the power cord should be

unplugged from the socket.

15. Lightning and thunderstorm weather – In lightning and thunderstorms, please unplug the special

adaptor plug.

16. Intrusion of foreign objects or liquids – Be careful to prevent foreign objects and liquids from

entering openings in the external casing.

17. Accessories – Only use attachment accessories.

18. Service is required in case of the following types of damages, at which time the equipment will need

to be serviced by designated professional service personnel:

• Damage to the power cord or plug

• Foreign objects falling into or liquid splashing into the equipment.

• The equipment being exposed to rain.

• The equipment not working normally or having noticeable changes in its performance.

• The equipment being dropped or the external casing damaged.

19. Servicing – The user should not attempt servicing. Servicing should be handled by qualified service

personnel or a distributor.

Contents of the package

IPD-4500 system main unit Power supply adapter Stereo sound cable Remote control

Instructions Quick use guide

●IPD-4500 portable speaker system main unit

● External 9 V DC@ 2 A power supply adapter

● Ø 3.5 mm stereo sound cable

● Remote control

● Manual

● Quick use guide

IPD-4500 Diagram:

1. Speaker unit

2. External power supply jack

3. Audio source input jack

4. Power switch

5. Battery/headphone/remote control storage compartment

6. Remote control signal receiving window

7. Hinge

8. iPod®/iPhone® 30PIN socket

9. Battery indicator light

10. Sound volume control button

Placement of the IPD-4500 system

It is best to place the IPD-4500 system on a horizontal flat surface close to you (1-2.5 meters). The IPD-

4500 system can be placed near video display equipment such as a television and computer monitor

without resulting in graphic distortion.

iPod®/iPhone® connection

Warning: Ensure that the IPD-4500 system is in the POWER OFF mode before making any connections and

before docking the iPod®/iPhone® into the IPD-4500 system. In order to guarantee that the system works

properly on first use, please carefully follow the connection sequence as described below and in the order

indicated.

An iPod®/iPhone® model with a 30PIN connector can be directly inserted into the special socket in the

IPD-4500 system, while for an iPod®/iPhone® model without a 30PIN connector or any other kind of

player, a 3.5 mm stereo cable is used to connect with the AUDIO IN port on the operating panel of the

IPD-4500 system, thus accomplishing a signal input connection between the player and the IPD-4500

system.

The IPD-4500 system can be used when either of these connections is completed and it has been

confirmed that the built-in rechargeable batteries have sufficient power or there is an external power

supply.

Power supply

Power for the IPD-4500 system can be supplied from the built-in rechargeable batteries provided inside

the main unit or from an external AC power source through an external 9 V DC@ 2A power supply adapter.
