PROTOCOL SOLUTIONS GROUP 3385 SCOTT BLVD SANTA CLARA, CA 95054

Application Program Interface (API)

Conquest

Manual

Version 7.40

For Software Version 7.40

September 2008

Document Disclaimer

di spo s al and rec ycl ing r egulat ion s that vary by country and region. Many countr ies prohibit the disposal of wa ste elec tronic equip m ent in stan dar d waste receptacles. For more information about pr oper di spo s al and rec ycl ing of y our Ca t al yst product, please visit www.getcatalyst.com/recycle.

The information in this document has been carefully checked and is believed to be reliable. However, no responsibility can be assumed for inaccuracies that may not have been detected.

LeCroy reserves the right to revise the information in this document without notice or penalty.

Trademarks

LeCroy and Conquest are trademarks of LeCroy Corporation. Universal Serial Bus and On-The-Go are registered trademarks of USB-IF. Microsoft and Windows are registered trademarks, and Visual C++ and Visual Basic are trademarks, of

Microsoft Corporation. Borland and Delphi are trademarks of Borland Corporation.

All other trademarks and registered trademarks are property of their respective owners.

this copyright notice.

Part number: 400-0066-001

WEEE Program

This elec t r onic product is su bject to

Contents

Introduction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1

Using the Library - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1 Object Hierarchy - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -1

IUsbGeneral Services Interface - - - - - - - - - - - - - - - - - - - - - - - - - - - 2

SetPort- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 IsHardwareStoped - - - - - - - - - - - - - - - - - - - - - - - - - 2 SaveOutFiles- - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 EnableProtocolError - - - - - - - - - - - - - - - - - - - - - - - - 3 IsEnableProtocolError - - - - - - - - - - - - - - - - - - - - - - - 3 GetMaxMemorySize - - - - - - - - - - - - - - - - - - - - - - - - 3 AttachDevice- - - - - - - - - - - - - - - - - - - - - - - - - - - - 3 AttachToDevice - - - - - - - - - - - - - - - - - - - - - - - - - - 4 GetDeviceIDList - - - - - - - - - - - - - - - - - - - - - - - - - - 4 DetachDevice - - - - - - - - - - - - - - - - - - - - - - - - - - - 4 SaveSmpAsText - - - - - - - - - - - - - - - - - - - - - - - - - - 4

IusbEasyDataCapturePrj Interface- - - - - - - - - - - - - - - - - - - - - - - - - 5

GetCaptureAndTrigger - - - - - - - - - - - - - - - - - - - - - - - 6 GetExerciser - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6 GetSetting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6 Open- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 6 Save - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7 Run - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7 Stop - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7 SetAnalyzerType - - - - - - - - - - - - - - - - - - - - - - - - - - 7 GetAnalyzerType- - - - - - - - - - - - - - - - - - - - - - - - - - 8 SetPAOutFile - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 GetPAOutFile - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 SetTAOutFile- - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 GetTAOutFile - - - - - - - - - - - - - - - - - - - - - - - - - - - 8 SetPreTrigger - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 GetPreTrigger - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 SetEntireMemory- - - - - - - - - - - - - - - - - - - - - - - - - - 9 IsSetEntireMemory - - - - - - - - - - - - - - - - - - - - - - - - - 9 SetSamplesNo - - - - - - - - - - - - - - - - - - - - - - - - - - - 9 GetSamplesNo- - - - - - - - - - - - - - - - - - - - - - - - - - -10 SetRunExerciser - - - - - - - - - - - - - - - - - - - - - - - - - -10 IsSetRunExerciser - - - - - - - - - - - - - - - - - - - - - - - - -10

iii

Contents

CaptureAndTrigger - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 11

SetTriggerType - - - - - - - - - - - - - - - - - - - - - - - - - - 12 GetTriggerType - - - - - - - - - - - - - - - - - - - - - - - - - - 12 SetManualTrig- - - - - - - - - - - - - - - - - - - - - - - - - - - 12 IsSetManualTrig - - - - - - - - - - - - - - - - - - - - - - - - - - 12 SetTriggerDeviceAddress - - - - - - - - - - - - - - - - - - - - - 13 GetTriggerDeviceAddress - - - - - - - - - - - - - - - - - - - - - 13 SetTriggerEndPoint - - - - - - - - - - - - - - - - - - - - - - - - 13 GetTriggerEndPoint - - - - - - - - - - - - - - - - - - - - - - - - 13 SetTriggerDataPacket - - - - - - - - - - - - - - - - - - - - - - - 14 GetTriggerDataPacket - - - - - - - - - - - - - - - - - - - - - - - 14 SetDataCapture1 - - - - - - - - - - - - - - - - - - - - - - - - - 15 GetDataCapture1 - - - - - - - - - - - - - - - - - - - - - - - - - 15 SetDataCapture2 - - - - - - - - - - - - - - - - - - - - - - - - - 16 GetDataCapture2 - - - - - - - - - - - - - - - - - - - - - - - - - 16 SetDataCapture3 - - - - - - - - - - - - - - - - - - - - - - - - - 17 GetDataCapture3 - - - - - - - - - - - - - - - - - - - - - - - - - 17 ExcludeNakedTransactions - - - - - - - - - - - - - - - - - - - - 17 IsExcludeNakedTransactions - - - - - - - - - - - - - - - - - - - 18 ExcludeNYETedTransactions - - - - - - - - - - - - - - - - - - - 18 IsExcludeNYETedTransactions - - - - - - - - - - - - - - - - - - 18 ExcludeKeepAliveEvents - - - - - - - - - - - - - - - - - - - - - 18 IsExcludeKeepAliveEvents- - - - - - - - - - - - - - - - - - - - - 18 ExcludeSOFPackets- - - - - - - - - - - - - - - - - - - - - - - - 19 IsExcludeSOFPackets - - - - - - - - - - - - - - - - - - - - - - - 19 SetTimingPattern - - - - - - - - - - - - - - - - - - - - - - - - - 19 GetTimingPattern - - - - - - - - - - - - - - - - - - - - - - - - - 19

IExerciser - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 20

AddCommand - - - - - - - - - - - - - - - - - - - - - - - - - - - 21 AddUserDefineCommand - - - - - - - - - - - - - - - - - - - - - 22 InsertCommand - - - - - - - - - - - - - - - - - - - - - - - - - - 23 InsertUserDefineCommand - - - - - - - - - - - - - - - - - - - - 24 DeleteCommand- - - - - - - - - - - - - - - - - - - - - - - - - - 24 DeleteAllCommands - - - - - - - - - - - - - - - - - - - - - - - - 25 SetStartOfLoop - - - - - - - - - - - - - - - - - - - - - - - - - - 25 SetEndOfLoop- - - - - - - - - - - - - - - - - - - - - - - - - - - 25 SetRepeatCommand - - - - - - - - - - - - - - - - - - - - - - - 25 FindDevice - - - - - - - - - - - - - - - - - - - - - - - - - - - - 26 GetFoundDevicesNo- - - - - - - - - - - - - - - - - - - - - - - - 26 GetDeviceEndPointsNo - - - - - - - - - - - - - - - - - - - - - - 26 GetEndPointType - - - - - - - - - - - - - - - - - - - - - - - - - 26 GetEndPointDirection - - - - - - - - - - - - - - - - - - - - - - - 27 GetEndPointNo - - - - - - - - - - - - - - - - - - - - - - - - - - 27

Contents

IsDeviceHub - - - - - - - - - - - - - - - - - - - - - - - - - - - -27 SetStartExerciserWith - - - - - - - - - - - - - - - - - - - - - - -28

ISetting - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 29

SetAnalyzerSpeed - - - - - - - - - - - - - - - - - - - - - - - - -30 GetAnalyzerSpeed - - - - - - - - - - - - - - - - - - - - - - - - -30 SetExerciserLoopCounter - - - - - - - - - - - - - - - - - - - - -30 Get ExerciserLoopCounter - - - - - - - - - - - - - - - - - - - - -30 SetExternalTriggerType - - - - - - - - - - - - - - - - - - - - - -31 GetExternalTriggerType - - - - - - - - - - - - - - - - - - - - - -31 EnableNonStdClock - - - - - - - - - - - - - - - - - - - - - - - -31 IsEnableNonStdClock - - - - - - - - - - - - - - - - - - - - - - -31 SetNonStdClockRateType - - - - - - - - - - - - - - - - - - - - -31 GetNonStdClockRateType - - - - - - - - - - - - - - - - - - - - -32 EnableSecondPort - - - - - - - - - - - - - - - - - - - - - - - - -32 IsEnableSecondPort - - - - - - - - - - - - - - - - - - - - - - - -32 SetSecondPortStore - - - - - - - - - - - - - - - - - - - - - - - -32 GetSecondPortStore - - - - - - - - - - - - - - - - - - - - - - - -32 EnableHighSpeedTestMode - - - - - - - - - - - - - - - - - - - -33 IsEnableHighSpeedTestMode - - - - - - - - - - - - - - - - - - -33 SetInfiniteExerciserLoopCounter - - - - - - - - - - - - - - - - - -33 IsInfiniteExerciserLoopCounter - - - - - - - - - - - - - - - - - - -33

API Constants- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 34

Analyzer Type definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -34 Analyzer Speed definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 34 Trigger Items definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -34 Data Packet Type definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -35 Timing Analyzer Pattern Type definitions - - - - - - - - - - - - - - - - - - - - - - - - - - 35 Capturing Items definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 35 Exerciser Command Type definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - -36 HUB Features definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -36 HUB Port Features definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 36 Port definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -36 Protocol Error Type definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -37 External Trigger Type definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -37 Non Standard Clock Rate Type definitions - - - - - - - - - - - - - - - - - - - - - - - - -37 Second Port Capturing Items definitions - - - - - - - - - - - - - - - - - - - - - - - - - -37 Endpoint Type definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 38

Contents

Endpoint Direction Definitions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 38 Exerciser Start With event definition - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 38

API Errors - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 39 Exerciser Command Parameters - - - - - - - - - - - - - - - - - - - - - - - - - 40

Introduction

IUSBEasyDataCapturePrj

IUSBGeneralService

IExerciser

ISetting

ICaptureAndTrigger

Introduction

The Conquest™ Application Program Interface (API) is a collection (library) of COM objects. The API enables programmers to use most of the Conquest Suite software functionality in their programs for the hardware, to execute a specific project with an event sequence and program selections. The software is for use with applications developed under

COM Supported Platforms such as Microsoft®Visual C++™, Borland®Delphi™, and Microsoft Visual Basic™.

Using the Library

To use the library:

1. Copy the Conquest SystemData folder into the system32 folder of the Windows directory of the PC.

2. Import usb.tlb into your software project.

3. Create a dispatch USBGeneralServices interface. See page 2.

Object Hierarchy

Objects are organized in a hierarchy of interfaces, with a set of methods for each.

4. Create a dispatch USBEasyDataCapturePrj interface. See page 5.

5. Use the API functions for required settings.

Note: You must run the Conquest Suite software before using the API.

Figure 1 Object Hierarchy Definition

IUsbGeneral Services Interface

Method Description

SetPort Set hardware attached port. IsHardwareStoped Is hardware stopped? SaveOutFiles Save output file of last run project. EnableProtocolError Enable or disable protocol errors by Type. IsEnableProtocolError Is protocol error type enabled or not. GetMaxMemorySize Get the maximum size of memory. AttachDevice Attach device. DetachDevice Detach device. SaveSmpAsText Save captured data in a text file.

SetPort

Declaration: long SetPort(short sPortType) Input(s): sPortType specifies hardware port type.

Valid port types are introduced in API Constants.

Return Value: Zero if the SetPort was successful. Otherwise, non-zero.

Each non-zero value indicates an error code.

Remark: This method sets the port type and connects the software to the

hardware.

See Also API Errors

IsHardwareStoped

Declaration: long IsHardwareStoped(BOOL* bIsStoped) Input(s): bIsStoped specifies hardware stop flag. Return Value: Zero if the IsHardwareStoped was successful. Otherwise, non-zero.

Each non-zero value indicates an error code.

Remark: This function sets bIsStoped to TRUE if hardware is stopped.

Otherwise, sets to FALSE. Returns error code if an error occurs.

See Also API Errors

IUsbGeneral Services Interface

SaveOutFiles

Declaration: longSaveOutFiles() Input(s): None Return Value: Zero if the SaveOutFiles was successful. Otherwise, non-zero.

Each non-zero value indicates an error code.

Remark: This method saves the output file for Protocol analyzer,

Timing analyzer, or both.

See Also API Errors

EnableProtocolError

Declaration: long EnableProtocolError(short sProtocolErrorType, BOOL bEnable) Input(s): sProtocolErrorType specifies type of protocol error.

Valid types are introduced in API Constants. bEnable specifies status of selected protocol error type.

Return Value: Zero if the EnableProtocolError was successful.

Otherwise, non-zero. Each non-zero value indicates an error code. Remark: Enables or disables a protocol error type. See Also API Errors

IsEnableProtocolError

Declaration: BOOL IsEnableProtocolError(short sProtocolErrorType) Input(s) sProtocolErrorType specifies the type of protocol error.

Valid types are introduced in API Constants. Return Value: Zero if IsEnableProtocolError was successful. Otherwise, non-zero.

Each non-zero value indicates an error code. Remark: Returns true if protocol error tspecified by sProtocolErrorType is

enabled. Otherwise, it returns false. See Also API Errors

GetMaxMemorySize

Declaration: long GetMaxMemorySize(long* lMaxSize) Input(s): lMaxSize specifies maximum available memory size. Return Value: Zero if GetMaxMemorySize was successful. Otherwise, non-zero.

Each non-zero value indicates an error code. Remark: This method sets lMaxSize to available memory size. See Also API Errors

AttachDevice

Declaration: long AttachDevice() Input(s): None Return Value: Zero if AttachDevice was successful. Otherwise, non-zero.

Each non-zero value indicates an error code. Remark: This function attaches the device to the analyzer. See Also API Errors

IUsbGeneral Services Interface

AttachToDevice

Declaration: long AttachToDevice(LPCTSTR lpctstrMacAddress) Input(s): lpctstrMacAddress specifies hardware MAC address. Return Value: Zero if AttachToDevice was successful. Otherwise, non-zero.

Each nonzero value indicates an error code.

Remark: This method attaches the software to the requested hardware

specified by its MAC address.

See Also API Errors

GetDeviceIDList

Declaration: BSTR GetDeviceIDList(long nPortType) Input(s): nPortType specifies hardware port type.

Valid port types are listed below.

Return Value: Each Device ID is separated with ',', and each Device ID number is in

hexadecimal format, such as "0200000E850002D8,0400000E85000131".

Remark: This method enumerates all available devices on the selected port

and returns available device IDs in string format.

CEIHAL_PORT_USB 0x02 CEIHAL_PORT_TCP 0x04 CEIHAL_PORT_EPP 0x08

DetachDevice

Declaration: long DetachDevice() Input(s): None Return Value: Zero if the DetachDevice was successful. Otherwise, non-zero.

Each non-zero value indicates an error code. Remark: This function detaches the device from the analyzer. See Also API Errors

SaveSmpAsText

Declaration: long SaveSmpAsText(LPCTSTR strSmpFilePath,

LPCTSTR strTextFilePath) Input(s): strSmpFilePath specifies path of sample file (.smp).

Return Value: Zero if the SaveSmpAsText was successful. Otherwise, non-zero.

Remark: This function converts smp file to text file and saves it. See Also: API Errors

strTextFilePath specifies path of out text file.

Each non-zero value indicates an error code.

IusbEasyDataCapturePrj Interface

This interface allows you to create an Easy Data Capture project or open and modify an existing Easy Data Project.

Method Description

GetCaptureAndTrigger Get capture and trigger interface. GetExerciser Get easy exerciser interface. GetSetting Get project setting interface. Open Open easy capture project (.ecp) file. Save Save easy capture project (.ecp) file. Run Run easy capture project. Stop Stop easy capture project. SetAnalyzerType Set analyzer type. GetAnalyzerType Get analyzer type. SetPAOutFile Set Protocol Analyzer output file name. GetPAOutFile Get Protocol Analyzer output file name. SetTAOutFile Set Timing Analyzer output file name. GetTAOutFile Get Timing Analyzer output file name. SetPreTriggger Set pre-trigger value. GetPreTriggger Get pre-trigger value. SetEntireMemmory Set use entire available memory. IsSetEntireMemmory Is use entire available memory set? SetSamplesNo Set capture samples number. GetSamplesNo Get capture samples number. SetRunExerciser Set run the easy exerciser. IsSetRunExerciser Is run the easy exerciser set?

IusbEasyDataCapturePrj Interface

GetCaptureAndTrigger

Declaration: ICaptureAndTrigger GetCaptureAndTrigger() Input(s): None Return Value: Capture and Trigger interface. Remark: Returns interface of CaptureAndTrigger object.

Do not use CreateDispatch to create CaptureAndTrigger interface.

GetExerciser

Declaration: IExerciser GetExerciser() Input(s): None Return Value: Exerciser interface Remark: Returns interface of Exerciser object.

Do not use CreateDispatch to create Exerciser interface.

GetSetting

Declaration: ISetting GetSetting() Input(s): None. Return Value Setting interface Remark: Returns interface of Setting object.

Do not use CreateDispatch to create Setting interface.

Open

Declaration: long Open(LPCTSTR strFilePath) Input(s): strFilePath specifies path to a file. Return Value: Zero if the open was successful. Otherwise, non-zero.

Each non-zero value indicates an error code. Remark: Opens easy capture project (.ecp) file. See Also API Errors

IusbEasyDataCapturePrj Interface

Save

Declaration: long Save(LPCTSTR strFilePath) Input(s): strFilePath points to the fully qualified path to save the file. Return Value: Zero if the save was successful. Otherwise, non-zero.

Each non-zero value indicates an error code. Remark: Saves current easy capture project (.ecp) file. See Also API Errors

Run

Declaration: long Run() Input(s): None Return Value Zero if project can run. Otherwise, non-zero.

Each non-zero value indicates an error code. Remark: Checks data entries before run and runs easy data capture project. See Also API Errors

Stop

Declaration: long Stop() Input(s): None Return Value: Zero if project can stop. Otherwise, non-zero.

Each non-zero value indicates an error code. Remark: Stops easy data capture project. See Also API Errors

SetAnalyzerType

Declaration: long SetAnalyzerType(short sAnalyzerType) Input(s): sAnalyzerType specifies type of analyzer.

Valid analyzer types are introduced in API Constants. Return Value: Error code or zero (no error) Remark: This attribute specifies type of analyzer. See Also API Errors

IusbEasyDataCapturePrj Interface

GetAnalyzerType

Declaration: short GetAnalyzerType() Input(s): None Return Value: Returns selected Analyzer type.

Valid analyzer types are introduced in API Constants.

Remark: Identifies type of analyzer.

SetPAOutFile

Declaration: long SetPAOutputFile(LPCTSTR strPAOutputFile) Input(s): strPAOutputFile specifies protocol analyzer output file name. Return Value: Error code or zero (no error) Remark: Specifies name of protocol analyzer output file. See Also API Errors

GetPAOutFile

Declaration: CString GetPAOutputFile() Input(s): None Return Value: Protocol Analyzer output file name Remark: Specifies name of protocol analyzer output file.

SetTAOutFile

Declaration long SetTAOutputFile(LPCTSTR strTAOutputFile) Input(s): strTAOutputFile specifies timing analyzer output file name. Return Value Error code or zero (no error) Remark: Specifies name of timing analyzer output file. See Also API Errors

GetTAOutFile

Declaration: CString GetTAOutputFile() Input(s): None Return Value: Timing Analyzer output file name Remark: Specifies name of timing analyzer output file.

IusbEasyDataCapturePrj Interface

SetPreTrigger

Declaration: long SetPreTrigger(short sPreTigger) Input(s): sPreTigger sets pre-trigger percent. It can be between 1 and 99. Return Value: Error code or zero (no error) Remark: Specifies pre-trigger percent.

Value of this attribute can be between 1 and 99. See Also API Errors

GetPreTrigger

Declaration: short GetPreTrigger() Input(s): None Return Value: Pre-trigger value. It is a short value between 1 and 99. Remark: Returns pre-trigger percent setting.

SetEntireMemory

Declaration: void SetEntireMemory(BOOL bEntireMemory) Input(s): bEntireMemory sets entire the memory for capturing. Output(s) None Return Value Error code or zero (no error) Remark: If set to TRUE, the system uses entire installed memory.

Otherwise, it uses number specified by SamplesNo.

IsSetEntireMemory

Declaration: BOOL IsSetEntireMemory() Input(s): None Return Value: Use entire memory flag status. Remark: Reports if entire memory flag is set.

SetSamplesNo

Declaration: long SetSamplesNo(long lSamplesNo) Input(s): lSamplesNo specifies the number of samples to capture. Return Value Error code or zero (no error) Remark: Specifies the number of samples to capture.

Note that if EntireMemory property has been set to FALSE, the

system uses this attribute. See Also API Errors

IusbEasyDataCapturePrj Interface

GetSamplesNo

Declaration: long GetSamplesNo() Input(s): None Output(s) None Return Value Samples number Remark: Returns the number of samples used in the capture.

SetRunExerciser

Declaration: void SetRunExerciser(BOOL bRun) Input(s): bRun sets the run exerciser flag. Outputs(s): None Remark: If set to TRUE, exerciser also runs.

If set to FALSE, only analyzer runs.

IsSetRunExerciser

Declaration: BOOL IsSetRunExerciser() Input(s): None Return Value Run exerciser flag status. Remark: If set to TRUE, exerciser is set to run.

If it set to FALSE, only analyzer is set to run.

CaptureAndTrigger

This interface sets the Easy Capture Project parameters (for example, Trigger point and capture data). (This is equivalent to Data Captur e And T rigger page in Easy capture project in the software).

When you instantiate the IEsbEasyDataCapturePrj interface, the ICaptureAndTrigger interface instantiates automatically in IEsbEasyDataCapturePrj.

You can get ICaptureAndTrigger interface from IEsbEasyDataCapturePrj by calling the IEsbEasyDataCapturePrj ::GetCaptureAndTrigger method.

Method Description

SetTriggerType Set trigger type. GetTriggerType Get trigger type. SetManualTrig Set trigger manually. IsSetManualTrig Is set to trigger manually? SetTriggerDeviceAddress Set trigger device address. GetTriggerDeviceAddress Get trigger device address. SetTriggerEndPoint Set trigger endpoint. GetTriggerEndPoint Get trigger endpoint. SetTriggerDataPacket Set trigger data packet type. GetTriggerData Packet Get trigger data packet type. SetDataCapture1 Set data capture item 1. GetDataCapture1 Get data captur e ite m 1. SetDataCapture2 Set data capture item 2. GetDataCapture2 Get data captur e ite m 2. SetDataCapture3 Set data capture item 3. GetDataCapture3 Get data captur e ite m 3. ExcludeNakedTransactions Exclude NAK’ed transactions from capturing. IsExcludeNakTransactions Are NAK’ed transactions excludedfrom capturing? ExcludeNYETedTransactions Exclude NYET’ed transactions from capturing. IsExcludeNYETedTransactions Are NYET’ed transactions excluded from capturing? ExcludeKeepAliveEvents Exclude Keep Alive events from capturing. IsExcludeKeepAliveEvents Is exclude Keep Alive events from capturing

CaptureAndTrigger

ExcludeSOFPackets Exclude SOF packets from capturing. IsExcludeSOFPackets Are Keep SOF packets excluded from capturing? SetTimmingPattern Set timing analyzer pattern. GetTimmingPattern Get timing analyzer pattern.

SetTriggerType

Declaration: long SetTriggerType(short sTriggerType) Input(s): sTriggerType specifies type of USB object on which to trigger the

hardware. Valid trigger types are in API Constants. Return Value: Error code or zero (no error) Remark: Sets trigger type. Trigger types are as same as Trigger combo

contents on Easy page. See Also API Errors

GetTriggerType

Declaration: short GetTriggerType() Input(s) None Return Value Type of USB object on which the hardware is set to trigger Remark: Returns trigger type.

SetManualTrig

Declaration: void SetManualTrig(BOOL bManualTrig) Input(s): bManualTrig sets use of manual trigger in place of trigger type. Return Value None Remark: Sets the hardware to respond to manual trigger.

IsSetManualTrig

Declaration: BOOL IsSetManualTrig() Input(s) None Return Value Status of manual trig flag Remark: Reports if the hardware is set to trigger manually.

SetTriggerDeviceAddress

Declaration: long SetTiggerDeviceAddress(LPCTSTR strDeviceAddress) Input(s): strDeviceAddress specifies device address of trigger item.

Length of this parameter is 7 characters in binary mode, where each

character is one of 0, 1, x, or X (as do not care). Return Value Error code or zero (no error) Remark: Sets the device address on which to trigger.

Note that the passed device address must be exclusive with the

trigger type that is specified with the SetTrigger method beforehand. See Also API Errors

GetTriggerDeviceAddress

Declaration: CString GetTriggerDeviceAddress() Input(s): None Return Value: Device address of trigger item.

Length of this parameter is 7 characters in binary mode, where each

character is one of 0, 1, x, or X (as do not care).

CaptureAndTrigger

Remark: Returns device address of trigger item.

SetTriggerEndPoint

Declaration: long SetTriggerEndPoint(LPCTSTR strEndPoint) Input(s) strEndPoint specifies end point of trigger item. Return Value: Error code or zero (no error) Remark: This method sets endpoint of trigger item. See Also API Errors

GetTriggerEndPoint

Declaration: CString GetTriggerEndPoint() Input(s): None Return Value: Endpoint number of trigger item Remark: Returns endpoint of trigger item. See Also API Errors

CaptureAndTrigger

SetTriggerDataPacket

Declaration: long SetTriggerDataPacket(short sDataPacketType,

LPCTSTR strData, BOOL bIsDataBlock)

Input(s): sDataPacketType sets data packet type. Valid data packe t types are

presented in API Constants.

strData specifies data payload of data packet. bIsDataBlock specifies strData is data block item name or not.

Return Value: Error code or zero (no error) Remark: Sets type and data of data packet on which to trigger. Note: To trigger on data packet, set trigger type to data packet by calling

the SetTrigger function with the API_TRIG_DATA_PACKETS parameter.

See Also API Errors

GetTriggerDataPacket

Declaration: void GetTriggerDataPacket(short* sDataPacketType,

BSTR* strData, BOOL* bIsDataBlock)

Input(s): sDataPacketType specifies data packet type.

strData specifies data of data packet. bIsDataBlock specifies whether strData is Data Block item name.

Return Value: Error code or zero (no error) Remark: Returns the type and data of data packet on which to trigger. See Also API Errors

CaptureAndTrigger

SetDataCapture1

Declaration: long SetDataCapture1(short sCaptureType, LPCTSTR

strDeviceAddress, LPCTSTR strEndPoint) Input(s): sCaptureType specifies type of capture item 1.

Valid capture item types are in API Constants.

strDeviceAddress specifies device address of capture item if

capture type is one of transaction types.

strEndPoint specifies endpoint of capture item if capture type is one

of transaction types. Return Value Error code or zero (no error) Remark: Identifies type of data, device address, and endpoint number o f data

on which to capture. Type of data can be a value specified in the

Data Capture combo box in the Easy data capture page. If type of

data is set to everything or any transaction, the give n device address

and endpoint number do not have any effect. See Also API Errors

GetDataCapture1

Declaration: void GetDataCapture1(short* sCaptureType, BSTR*

strDeviceAddress, BSTR* strEndPoint) Input(s): sCaptureType specifies type of capture item 1.

Valid capture item types are in API Constants.

strDeviceAddress specifies device address of capture item if

capture type is one of transaction types.

strEndPoint specifies endpoint of capture item if capture type is one

of transaction types. Return Value: None Remark: Returns data capture type 1, its device address, and its endpoint

number.

CaptureAndTrigger

SetDataCapture2

Declaration: long SetDataCapture2(short sCaptureType, LPCTSTR

Input(s): sCaptureType specifies type of capture item 2.

Return Value Error code or zero (no error) Remark: Identifies the type of data, device address, and endpoint number of

strDeviceAddress, LPCTSTR strEndPoint)

Valid capture item types are in API Constants. strDeviceAddress specifies device address of capture item if

capture type is one of transaction types. strEndPoint specifies endpoint of capture item if capture type is one

of transaction types.

data on which to capture. T ype of data can be a value specified in the Data Capture combo box on the Easy data capture page. If type of data is set to everything or any transaction, the give n device address and endpoint number do have not any effect.

See Also API Errors

GetDataCapture2

Declaration: void GetDataCapture2(short* sCaptureType, BSTR*

strDeviceAddress, BSTR* strEndPoint)

Input(s): sCaptureType specified type of capture item 2.

Valid capture item types are in API Constants. strDeviceAddress specified device address of capture item if

capture type is one of transaction types. strEndPoint specified endpoint of capture item if capture type is one

of transaction types. Return Value None Remark: Returns data capture type 2, its device address, and its endpoint

number.

CaptureAndTrigger

SetDataCapture3

Declaration: long SetDataCapture3(short sCaptureType, LPCTSTR

strDeviceAddress, LPCTSTR strEndPoint)

Input(s): sCaptureType specifies type of capture item 3.

Valid capture item types are in API Constants. strDeviceAddress specifies device address of capture item if

capture type is one of transaction types. strEndPoint specifies endpoint of capture item if capture type is one

of transaction types. Return Value Error code or zero (no error) Remark: Sets the type of data, device address, and endpoint number of data

on which to capture. The type of data can be a value specified in the

Data Capture combo box on the Easy data capture page. If type of

data is set to everything or any transaction, the give n device address

and endpoint number do have not any effect. See Also API Errors

GetDataCapture3

Declaration: void GetDataCapture3(short* sCaptureType, BSTR*

strDeviceAddress, BSTR* strEndPoint) Input(s): sCaptureType specifies type of capture item 3.

Valid capture item types arein API Constants.

strDeviceAddress specifies device address of capture item if

capture type is one of transaction types.

strEndPoint gets endpoint of capture item if capture type is one of

transaction types. Return Value: None Remark: This method returns data capture type 3, its device address, and its

endpoint number.

ExcludeNakedTransactions

Declaration: void ExcludeNAKedTransactions(BOOL bExclude) Input(s): bExclude sets exclude NAK’ed transactions flag. Return Value: None Remark: Excludes NAK’ed transactions if TRUE.

Includes NAK’ed transactions if FALSE.

CaptureAndTrigger

IsExcludeNakedTransactions

Declaration: BOOL IsExcludeNAKedTransactions() Input(s): None Return Value: Status of exclude NAK’ed transactions flag Remark: Returns TRUE if exclude Nak transactions flag is selected.

Returns FALSE if not.

ExcludeNYETedTransactions

Declaration: void ExcludeNYETedTransactions(BOOL bExclude) Input(s): bExclude sets exclude Return Value None Remark: Excludes NYET transactions if TRUE.

Includes NYET transactions if FALSE.

NYET’ed transactions flag.

IsExcludeNYETedTransactions

Declaration: BOOL IsExcludeNYETedTransactions() Input(s): None Return Value: Status of exclude NYET’ed transactions flag. Remark: Returns TRUE if exclude NYETed transactions flag is selected.

Returns FALSE if not.

ExcludeKeepAliveEvents

Declaration: void ExcludeKeepAliveEvents(BOOL bExclude) Input(s) bExclude sets exclude KeepAlive events flag. Return Value None Remark: Excludes KeepAlive events if TRUE.

Includes KeepAlive events if FALSE.

IsExcludeKeepAliveEvents

Declaration: BOOL IsExcludeKeepAliveEvents() Input(s): None Return Value: Status of exclude KeepAlive Events flag Remark: TRUE if exclude KeepAlive Events flag is set.

FALSE if not.

ExcludeSOFPackets

Declaration: void ExcludeSOFPackets(BOOL bExclude)

CaptureAndTrigger

Input(s): bExclude sets exclude Return Value: None Remark: Excludes SOF packets if set to TRUE.

Includes SOF packets when set to FALSE.

SOF packets flag.

IsExcludeSOFPackets

Declaration: BOOL IsExcludeSOFPackets() Input(s): None Return Value: Status of exclude SOF Packets flag Remark: TRUE if exclude SOF Packets flag is set.

FALSE if not.

SetTimingPattern

Declaration: long SetTimingPattern(short sPatternType, LPCTSTR strPattern) Input(s): sPatternType sets timing analyzer pattern type.

Valid types are in API Constants.

StrPattern sets timing analyzer pattern. Length of this pattern for

full speed patterns is eight characters, and for high-speed patt erns is

four characters. Each character can be 0, 1, x, or X. Return Value Error code or zero (no error) Remark: Sets timing patterns for timing analyzer. See Also API Errors

GetTimingPattern

Declaration: CString GetTimingPattern(short sPatternType) Input(s): sPatternType sets timing analyzer pattern type.

Valid types are in API Constants. Return Value: Pattern of specified pattern type Remark: Returns pattern of specified timing analyzer pattern type.

IExerciser

This interface creates an exerciser program for an easy data capture project(This isequivalent to the Exerciser page in an Easy capture project in the software).

When you instantiate the IEsbEasyDataCapturePrj interface, the IExerciser interface instantiates automatically in IEsbEasyDataCapturePrj.

You can get the IExerciser interface from IEsbEasyDataCapturePrj by calling IEsbEasyDataCapturePrj ::GetExerciser method.

Method Description

AddCommand Add exerciser command. AddUserDefineCommand Add exerciser user-defined command. InsertCommand Insert exerciser command. InsertUserDefineCommand Insert exerciser user-defined command. DeleteCommand Delete exerciser command. DeleteAllCommands Delete allexerciser commands. SetStartOfLoop Set exerciser command to start of loop. SetEndOfLoop Set exerciser command to end of loop. SetRepeatCommand Set exerciser command to re pea t . FindDevice Find attached devices. GetFoundDevicesNo Get found devices number. GetDeviceEndPointsNo Get endpoints number of a device. GetEndPointTyp e Get type of endpoint. GetEndPointDirection Get direction of an endpoint. GetEndPointNo Get number of an endpoint. IsDeviceHub Is device HUB? SetStartExerciserWith Set exerciser start event type.

AddCommand

Declaration: long AddCommand(short sCommandType, short sDeviceIndex,

const VARIANT& vtParam1, const VARIANT& vtParam2,

const VARIANT& vtParam3) Input(s): sCommandType selects the exerciser command type that you want

to send to the device.

Valid command types are in API Constants.

sDeviceIndex sets the found device index.

vtParam1 sets the first parameter of exerciser command.

vtParam2 sets the second parameter of exerciser command.

vtParam3 sets the third parameter of exerciser command.

Return Value: Error code or zero (no error) Remark: Adds a command to exerciser program. A command can use none,

one, or more parameters defined in Exerciser Command

Parameters.

IExerciser

See Also API Errors

IExerciser

AddUserDefineCommand

Declaration: long AddUserDefineCommand(short sS peed, short sDeviceAddress,

short sEndpointNo, short sEndpointType, short sCommandType, const VARIANT& vtParam1, const VARIANT& vtParam2, const VARIANT& vtParam3)

Input(s): sSpeed sets speed of device.

Valid speed types are in API Constants.

sDeviceAddress sets device address of the device. sEndpointNo sets endpoint number. sEndpointType sets type of the endpoint.

Valid endpoint type arein API Constants. sCommandType sets the exerciser command type that you want to

send to the device. Valid command types are in API constants.

sDeviceIndex specifies device index. vtParam1 specifies the first parameter of the exerciser command. vtParam2 specifies the second parameter of the exerciser

command.

vtParam3 specifies the third parameter of the exerciser command. Return Value Error code or zero (no error). Remark: Adds a user-defined command to the exerciser program. A

command can use none, one, or more parameters defined in

Exerciser Command Parameters See Also API Errors

InsertCommand

Declaration: long InsertCommand(short sInsertAt, short sCommandType,

short sDeviceIndex, const VARIANT& vtParam1, const VARIANT& vtParam2, const VARIANT& vtParam3)

Input(s): sInsertAt sets index of exerciser command for this command.

sCommandType sets exerciser command type that you want to send to the device. Valid types are defined in API Constants.

sDeviceIndex sets device index. vtParam1 sets first parameter of the exerciser command. vtParam2 sets second parameter of the exerciser command. vtParam3 sets third parameter of the exerciser command.

Return Value Error code or zero (no error) Remark: Adds a command to the exerciser program. A command can use

none, one, or more parameters defined in Exerciser Command Parameters.

IExerciser

See Also API Errors

IExerciser

InsertUserDefineCommand

Declaration: long InsertUserDefineCommand(short sInsertAt, short sSpeed,

short sDeviceAddress, short sEndpointNo, short sEndpointType,

short sCommandType, const VARIANT& vtParam1,

const VARIANT& vtParam2, const VARIANT& vtParam3) Input(s) sInsertAt sets index of exerciser command fo which this command

inserts a replacement.

sSpeed sets speed of device.

Valid speed types are in API Constants.

sDeviceAddress sets device address.

sEndpointNo sets endpoint number.

sEndpointType sets type of the endpoint.

Valid endpoint type are in API Constants.

sCommandType sets exerciser command type that you want to

send to the device. Valid types are defined in API Constants.

sDeviceIndex sets device index.

vtParam1 sets first parameter of the exerciser command.

vtParam2 sets second parameter of the exerciser command.

vtParam3 sets third parameter of the exerciser command.

Return Value: Error code or zero (no error) Remark: Adds a user-defined command to the exerciser program. A

command can use none, one, or more parameters defined in

Exerciser Command Parameters. See Also API Errors

DeleteCommand

Declaration: long DeleteCommand(short sCommandIndex) Input(s): sCommandIndex is index of exerciser command. Return Value: Error code or zero (no error) Remark: Deletes specified exerciser command (with index) from exerciser

program. See Also API Errors

DeleteAllCommands

Declaration: long DeleteAllCommands() Input(s): None Return Value: Error code or zero (no error) Remark: Deletes all exerciser commands from exerciser program. See Also API Errors

SetStartOfLoop

Declaration: long SetStartOfLoop(short sCommandIndex, long bSet) Input(s): sCommandIndex sets index of exerciser command.

bSet sets status of start of loop flag for exerciser command. Return Value: Error code or zero (no error) Remark: Sets a specified command (with Index) as start of a loop.

IExerciser

See Also API Errors

SetEndOfLoop

Declaration: long SetEndOfLoop(short sCommandIndex, long bSet) Input(s): sCommandIndex sets index of exerciser command.

bSet sets status of end of loop flag of exerciser command. Return Value: Error code or zero (no error) Remark: Sets a specified command (with Index) as end of a loop. See Also: API Errors

SetRepeatCommand

Declaration: long SetRepeatCommand(short sCommandIndex, long bSet) Input(s): sCommandIndex sets index of exerciser command.

bSet sets status of repeat flag of exerciser command. Return Value: Error code or zero (no error) Remark: Sets a specified command (with index) to repeat loop. See Also: API Errors

IExerciser

FindDevice

Declaration: long FindDevice() Inputs: None Return Value: Error code or zero (no error) Remark: This function finds any devices that are attached to the exerciser. See Also: API Errors

GetFoundDevicesNo

Declaration: short GetFoundDevicesNo() Input(s): None Return Value: Number of devices found Remark: This function returns the number of devices found. Note: Use this function after a call to the FindDevice function.

GetDeviceEndPointsNo

Declaration: long GetDeviceEndPointsNo(short sDeviceIndex,

short* sEndPointsNo)

Input(s): sDeviceIndex sets index of device.

sEndPointsNo sets the number of endpoints of the device and fills in

the function if the device index exists. Return Value: Error code or zero (no error) Remark: This function fills sEndPointsNo if the passed device index exists. See Also API Errors

GetEndPointType

Declaration: long GetEndPointType(short sDeviceIndex, short sEndPointIndex,

short* sEndpointType) Input(s): sDeviceIndex sets index of found device.

sEndPointIndex sets index of endpoint of a found device.

sEndpointType sets endpoint type of specified endpoint. This

parameter fills if the device index and endpoint index exist. Return Value: Error code or zero (no error) Remark: This function fills sEndPointT ype if passed device index and end point

See Also: API Errors

EnableNonStdClock

Declaration: void EnableNonStdClock(BOOL bEnable) Input(s): bEnable sets status of non-standard clock flag. Return Value: None Remark: This function enables (disables) the non-standard clock.

IsEnableNonStdClock

Declaration: BOOL IsEnableNonStdClock() Input(s): None Return Value: Status of the non-standard clock flag Remark: This function returns the non-standard clock status.

SetNonStdClockRateType

Declaration: long SetNonStdClockRateType(short sClockRateType) Input(s): sClockRateType sets the non-standard clock rate.

Valid types are defined in API Constants. Return Value: Zero if the SetNonStdClockRate was successful.

Otherwise, non-zero. Each non-zero value indicates an error code. Remark: This function sets rate of the non-standard clock. See Also: API Errors

ISetting

GetNonStdClockRateType

Declaration: short GetNonStdClockRateType() Input(s): None Return Value: Non-standard clock rate type.

Valid types are defined in API Constants.

Remark: This function returns the type of non-standard clock rate.

EnableSecondPort

Declaration: void EnableSecondPort(BOOL bEnable) Input(s): bEnable set status of second port. Return Value: None Remark: This function enables (disables) second port.

IsEnableSecondPort

Declaration: BOOL IsEnableSecondPort() Input(s): None Return Value: TRUE if second port is enabled. Otherwise, returns FALSE. Remark: This function returns status of second port.

SetSecondPortStore

Declaration: long SetSecondPortStore(short sStoreType) Input(s): sStoreType sets the second port store type.

Valid types are defined in API Constants.

Return Value: Zero if the SetSecondPortStore was successful.

Otherwise, non-zero. Each non-zero value indicates an error code. Remark: This function sets the second port store type. See Also: API Errors

GetSecondPortStore

Declaration: short GetSecondPortStore() Input(s): None Return Value: Second port store type. Valid types are defined in API Constants. Remark: This function returns the second port store type.

EnableHighSpeedTestMode

Declaration: void EnableHighSpeedTestMode(BOOL bEnable) Input(s): bEnable sets status of the high-speed test mode flag. Return Value: None Remark: This function enables (disables) the high-speed test mode.

IsEnableHighSpeedTestMode

Declaration: BOOL IsEnableHighSpeedTestMode() Input(s): None Return Value: Status of high-speed test mode flag Remark: This function returns the status of the high-speed test mode flag.

SetInfiniteExerciserLoopCounter

Declaration: void SetInfiniteExerciserLoopCounter(BOOL bInfinite)

ISetting

Input(s): bInfinite sets exerciser loop counter to infinite or finite value. Return Value: None Remark: This function sets the exerciser loop counter to infinite or finite count.

IsInfiniteExerciserLoopCounter

Declaration: BOOL IsInfiniteExerciserLoopCounter() Input(s): None Return Value: Status of exerciser loop counter Remark: This function returns exerciser loop counter setting.

API Constants

Pre-defined API constants are in the SBAEAPIConstants.h file The following constants are used as parameters by some functions.

Analyzer Type definitions

API_MAX_ANLYZER_TYPES 3 API_ANLYZER_TYPE_PA 0 //Protocol Analyzer API_ANLYZER_TYPE_TA 1 //Timing Analyzer API_ANLYZER_TYPE_BOTH 2

Analyzer Speed definitions

API_MAX_ANLYZER_SPEEDS 3 API_ANLYZER_SPEED_HIGH 0 API_ANLYZER_TYPE_FULL_LOW 1 API_ANLYZER_TYPE_AUTO 2

Trigger Items definitions

API_MAX_TRIG_ITEMS 26 API_TRIG_SNAP_SHOT 0 API_TRIG_ANY_TRANS 1 API_TRIG_DATA_PACKETS 2 API_TRIG_BUS_RESET 3 API_TRIG_RESUME 4 API_TRIG_SUSPEND 5 API_TRIG_CHIRP 6 API_TRIG_HNP 7 API_TRIG_SRP 8 API_TRIG_SESSION 9 API_TRIG_PE 10 //Protocol Error API_TRIG_SETUP_TRANS 1 1 API_TRIG_IN_TRANS 12 API_TRIG_OUT_TRANS 13 API_TRIG_PING_TRANS 14 API_TRIG_SETUP_SPLIT_TRANS 15 API_TRIG_BULK_IN_SPLIT_TRANS 16 API_TRIG_BULK_OUT_SPLIT_TRANS 17 API_TRIG_INT_IN_SPLIT_TRANS 18 API_TRIG_INT_OUT_SPLIT_TRANS 19 API_TRIG_ISO_IN_SPLIT_TRANS 20 API_TRIG_ISO_OUT_SPLIT_TRANS 21 API_TRIG_SETUP_PREAMBLE_TRANS 22 API_TRIG_ASYNC_IN_PREAMBLE_TRANS 23 API_TRIG_ASYNC_OUT_PREAMBLE_TRANS 24 API_TRIG_TA_PATTERNS 25

API Constants

Data Packet Type definitions

API_MAX_TRIG_DATA_PACKET_TYPES 5 API_DATA_PACKET_TYPE_ANY 0 API_DATA_PACKET_TYPE_DATA0 1 API_DATA_PACKET_TYPE_DATA1 2 API_DATA_PACKET_TYPE_DATA2 3 API_DATA_PACKET_TYPE_MDATA 4

Timing Analyzer Pattern Type definitions

API_MAX_TA_PATTERN_TYPES 5 API_TA_FLS_TRIG_PATTERN_DP 0 //Full/Low Speed D+ Pattern API_TA_FLS_TRIG_PATTERN_DM 1 //Full/Low Speed D- Pattern API_TA_FLS_TRIG_PATTERN_RCV 2 //Full/Low Speed RCV Pattern API_TA_HS_TRIG_PATTERN_DP 3 //High Speed D+ Pattern API_TA_HS_TRIG_PATTERN_DM 4 //High Speed D- Pattern

Capturing Items definitions

API_MAX_CAPTURE_ITEMS 17 API_CAP_NO_CAPTURE 0 //None API_CAP_ANY 1 //Everything API_CAP_ANY_TRANS 2 //Any Transactions API_CAP_SETUP_TRANS 3 API_CAP_ASYNC_IN_TRANS 4 API_CAP_ASYNC_OUT_TRANS 5 API_CAP_PING_TRANS 6 API_CAP_SETUP_SPLIT_TRANS 7 API_CAP_BULK_IN_SPLIT_TRANS 8 API_CAP_BULK_OUT_SPLIT_TRANS 9 API_CAP_INT_IN_SPLIT_TRANS 10 API_CAP_INT_OUT_SPLIT_TRANS 11 API_CAP_ISO_IN_SPLIT_TRANS 12 API_CAP_ISO_OUT_SPLIT_TRANS 13 API_CAP_SETUP_PREAMBLE_TRANS 14 API_CAP_ASYNC_IN_PREAMBLE_TRANS 15 API_CAP_ASYNC_OUT_PREAMBLE_TRANS 16

API Constants

Exerciser Command Type definitions

API_MAX_EXR_COMMAND_TYPES 18 API_EXR_COMMAND_GET_CONFIGURATION 0 API_EXR_COMMAND_GET_DESCRIPTO 1 API_EXR_COMMAND_GET_INTERFACE 2 API_EXR_COMMAND_GET_DEVICE_STATUS 3 API_EXR_COMMAND_SET_ADDRESS 4 API_EXR_COMMAND_SET_CONFIGURATION 5 API_EXR_COMMAND_CLEAR_HUB_FEATURE 6 API_EXR_COMMAND_CLEARE_HUB_PORT_EATURE 7 API_EXR_COMMAND_GET_HUB_CLASS_DESCRIPTOR 8 API_EXR_COMMAND_GET_HUB_STATUS 9 API_EXR_COMMAND_SET_HUB_FEATURE 10 API_EXR_COMMAND_SET_HUB_PORT_FEATURE 11 API_EXR_COMMAND_CLEAR_HUB_TT_BUFFER 12 API_EXR_COMMAND_REASET_HUB_TT 13 API_EXR_COMMAND_GET_HUB_TT_STATUS 14 API_EXR_COMMAND_STOP_HUB_TT 15 API_EXR_COMMAND_DATA_IN 16 API_EXR_COMMAND_DATA_OUT 17

HUB Features definitions

API_MAX_HUB_FEATURES 2 API_HUB_FEA TURE_LOCAL_POWER 0 API_HUB_FEA TURE_OVER_CURRENT 1

HUB Port Features definitions

API_MAX_HUB_PORT_FEATURES 9 API_HUB_FEATURE_CONNECTION 0 // port connection API_HUB_FEATURE_ENABLE 1 // port enable API_HUB_FEATURE_SUSPEND 2 // port suspend API_HUB_FEATURE_OVER_CURRENT 3 // port over current API_HUB_FEATURE_RESET 4 // port reset API_HUB_FEATURE_POWER 5 // port power API_HUB_FEATURE_LS 6 // port low speed API_HUB_FEATURE_TEST 7 // port test API_HUB_FEATURE_INDICATOR 8 // port indicator

Port definitions

API_MAX_SBAE_PORTS 5 API_SBAE_PORT_ALL 0 API_SBAE_PORT_LPT1 1 API_SBAE_PORT_LPT2 2 API_SBAE_PORT_LPT3 3 API_SBAE_PORT_USB 4

API Constants

Protocol Error Type definitions

API_MAX_PROTOCOL_ERROR_TYPES 13 API_PE_BIT_STUFF 0 API_PE_PID_CHECK 1 API_PE_PID_UNKNOWN 2 API_PE_SYNCH 3 API_PE_CRC5 4 API_PE_CRC16 5 API_PE_FRAME_LEN 6 API_PE_BABBLE 7 API_PE_DATA_TOGGLE 8 API_PE_FALSE_EOP 9 API_PE_ACT_LOSS 10 // loss of activity API_PE_TIME_OUT 11 API_PE_BUS_ERR 12 //bus error

External Trigger Type definitions

API_MAX_EXTERNAL_TRIGGER_TYPE 5 API_EXT_TRG_MASK 0 // No external trigger API_EXT_TRG_LEVEL_1 1 // Trigger on level one of signal API_EXT_TRG_LEVEL_0 2 // Trigger on level zero of signal API_EXT_TRG_EDGE_P 3 // Trigger on positive edge of signal API_EXT_TRG_EDGE_N 4 // Trigger on negative edge of signal

Non Standard Clock Rate Type definitions

API_MAX_NON_STD_CLOCK_RATE_TYPES 5 API_NON_STD_CLOCK_RATE _125K 0 API_NON_STD_CLOCK_RATE _250K 1 API_NON_STD_CLOCK_RATE _500K 2 API_NON_STD_CLOCK_RATE _1M 3 API_NON_STD_CLOCK_RATE _EXTERNAL 4

Second Port Capturing Items definitions

API_MAX_SP_CAP_ITEMS 9 API_SP_CAP_ALL 0 API_SP_CAP_ALL_PACKETS 1 API_SP_CAP_NONE 2 API_SP_CAP_IDLE 3 API_SP_CAP_RESUME 4 API_SP_CAP_RESET 5 API_SP_CAP_DISCONNECT 6 API_SP_CAP_KEEPALIVE 7 API_SP_CAP_SUSPEND 8

API Constants

Endpoint Type definitions

API_MAX_ENDPOINT_TYPES 4 API_ENDPOINT_TYPE_CONTROL 0 API_ENDPOINT_TYPE_ISO 1 // Isochronous API_ENDPOINT_TYPE_BULK 2 API_ENDPOINT_TYPE_INT 3 // interrupt

Endpoint Direction Definitions

API_MAX_ENDPOINT_DIRECTIONS 3 API_DATA_DIRECTION_NONE 0 API_DATA_DIRECTION_IN 1 API_DATA_DIRECTION_OUT 2

Exerciser Start With event definition

API_MAX_EXRCISER_START_WITH_EVENTS 2 API_EXR_START_WITH_RESUME 0 API_EXR_START_WITH_RESET 1

API Errors

Error codes are in the SBAEAPIErrors.h file. They are returned by some functions upon an error condition.

IDE_NO_ERROR 0 IDE_INVALID_PORT_NO 1 IDE_ERROR_IN_DETECTING_HW 2 IDE_ERROR_HW_NOT_FOUND 3 IDE_CAN_NOT_OPEN_FILE 4 IDE_CAN_NOT_SAVE_FILE 5 IDE_TA_HS_TRIG_ON_SE1 6 IDE_HW_IS_BUSY 7 IDE_EXERCISER_PROGRAM_ERROR 8 IDE_SYSTEM_DATA_IS_CORRUPTED 9 IDE_CANNOT_RUN_PROJECT 10 IDE_NOT_AUTHORIZED_TA_SPEED 11 IDE_IS_NOT_ABLE_TO_SAVE 12 IDE_HW_IS_NOT_STOPPED 13 IDE_BAD_DATA_ENTRY 14 IDE_HIGH_SPEED_TEST_MODE_IN_FULL_LOW 15 IDE_NON_STD_CLOCK_IN_NO_FULL_LOW_SPEED 16 IDE_TIMMING_TRIG_WHEN_TA_ISNOT_ENABLE 17 IDE_NO_MATCH_TRIG_ITEM_WITH_ANALYZER_SPEED 18 IDE_NO_MATCH_CAP_ITEM_WITH_ANALYZER_SPEED 19 IDE_NO_MATCH_TRIG_CAPTURE_ITEMS_SPEED 20 IDE_NO_MATCH_EXCLUDE_NYET_WITH_ANALYZER_SPEED 21 IDE_NO_MATCH_EXCLUDE_KEEPALIVE_WITH_ANALYZER_SPEED 22 DE_NO_MATCH_EXCLUDE_KEEPALIVE_WITH_TRIG_OR_CAP_ITEMS_SPEED 23 IDE_NO_MATCH_EXCLUDE_NYET_WITH_TRIG_OR_CAP_ITEMS_SPEED 24 IDE_NO_MATCH_EXCLUDE_NAK_WITH_TRIG_ITEMS 25 IDE_NO_MATCH_EXCLUDE_NYET_WITH_TRIG_ITEMS 26 IDE_NO_MATCH_EXCLUDE_SOF_OR_KEEP_ALIVE_WITH_CAP_ITEMS 27 IDE_NO_MATCH_CAPT URE_ITEM0_WITH_OTHERS 28 IDE_CANNOT_FILL_CAPTURE_ITEM3_WHEN_CAPTURE_ITEM2_IS_NONE 29 IDE_CANNOT_SELECT_MORE_THAN_TWO_SPLIT 30 IDE_CANNOT_FILL_CAPTURE_ITEM3_WHEN_SELECT_SPLIT 31 IDE_FULL_LOW_SPEED_NOT_AUTHORIZED 32 IDE_HIGH_SPEED_NOT_AUTHORIZED 33 IDE_TA_FULL_LOW_SPEED_NOT_AUTHORIZED 34 IDE_TA_HIGH_SPEED_NOT_AUTHORIZED 35 IDE_SECOND_PORT_NOT_AUTHORIZED 36 IDE_EXTERNAL_CLOCK_NOT_AUTHORIZED 37 IDE_CANNOT_FIND_DEVICE 38 IDE_CANNOT_READ_DESCRIPTORS 39 IDE_ISNOT_MEMORY_ENOUGH 40 IDE_IS_SET_PORT_BEFORE 41 IDE_EXR_USE_HUB_COMMAND_FOR_NON_HUB_DEVICE 42

Exerciser Command Parameters

The following exerciser commands require no parameters. These commands do not use vtParam1, vtParam2, and vtParam3.

• API_EXR_COMMAND_GET_CONFIGURATION

• API_EXR_COMMAND_GET_INTERFACE

• API_EXR_COMMAND_GET_HUB_CLASS_DESCRIPTOR

• API_EXR_COMMAND_GET_HUB_STATUS

• API_EXR_COMMAND_CLEAR_HUB_TT_BUFFER

• API_EXR_COMMAND_GET_HUB_TT_STATUS

• API_EXR_COMMAND_STOP_HUB_TT

Exerciser Command Parameters

The following exerciser commands use vtParam1: API_EXR_COMMAND_GET_DESCRIPTOR - vtParam1 should be a short variable that

identifies descriptor type. Valid descriptor types are Device Descriptor and Configuration Descriptor.

API_EXR_COMMAND_SET_ADDRESS - vtParam1 should be a short variable that identifies new device address.

API_EXR_COMMAND_SET_CONFIGURATION - vtParam1 should be a short variable that identifies configuration value.

API_EXR_COMMAND_CLEAR_HUB_FEATURE - vtParam1 should be a short variable that identifies selector type. (Valid selectors are in API Constants.)

API_EXR_COMMAND_SET_HUB_ FEATURE - vtParam1 should be a short variable that identifies selector type. (Valid selectors are in API Constants.)

API_EXR_COMMAND_CLEAR_HUB_PORT_FEATURE - vtParam1 should be a short variable that identifues selector type. (V alid selectors are in API Constants.) vtParam2 should be a short variable that identifies port number.

API_EXR_COMMAND_SET_HUB_ PORT_FEATURE - vtParam1 should be a short variable that identifies selector type. (Valid selectors are in API Constants.) vtParam2 should be a short variable that identifies port number.

API_EXR_COMMAND_DATA_OUT - vtParam1 should be a short variable that identifies endpoint index of selected device index. vtParam2 should be a string variable that identifes data to be output. This data is in hexadecimal base, and if it is a data block, should be the data block name. vtParam3 should be a boolean variable that identifies whether data is a data block item.

API_EXR_COMMAND_DATA_IN - vtParam1 should be a short variable that identifies endpoint index of selected device index.

Exerciser Command Parameters

LeCroy Conquest User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
