This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
LP772_-CF
1.0
Install the Mounting Plate
1A
CANOPY
MOUNTING
PLATE
STRAIN RELIEF
HOUSING
1B
MOUNTING
PLATE
2
Mount the mounting plate assembly to the electrical box
with the two provided #8-32 screws.
22
#8-32
SCREW
1
Remove the mounting plate from the canopy by
completely unscrewing the mounting plate from strain
relief housing.
1
Page 2
Install the Fixture
2A
HOUSING CAP
STRAIN RELIEF
STRAIN RELIEF
HOUSING
1
Remove the strain relief from the housing by unscrewing
the housing cap and pulling the strain relief out.
2B
2D
4"
6
Leave 6" of the cord behind the canopy for power
connections. Cut the excess cord.
7
From the end of the cord, strip the insulation 4" using a
sharp knife..Make sure not to nick the inner wires
8
Strip the end of the wires.
2E
SET SCREW
2
Loosenthe set screw on the strain(Do Not Remove)
relief.
2C
3
4
3
Adjust the fixture height (from bottom of the fixture
shade to top of the canopy) by moving the canopy and
strain relief up or down.
4
When the desired height is achieved, tighten the set
screw on the strain relief.
CANOPY
CORD
10
11
9
9
Feed the fixture wires through the mounting plate
12
12
TAB
center hole and then pull them out of the electrical box.
Note: If the cord has a cloth cover, peel back or remove
the cloth where the secondary strain relief is installed.
10
Install the secondary strain relief by first feeding the
power cord through it.
11
Snap the strain relief tab into place.
5
Mark the cord underneath the strain relief.
12
Pull the cord to take up the slack and fit the rest of the
cord in the strain relief’s openings.
2
Page 3
2F
2G
15
15
13
14
BALLAST
213
10
Connect the yellow ballast wire to the insulated
pendant wire with the white tracer with a wire nut.
214
Connect the red ballast wire to the other insulated
pendant wire with a wire nut.
15
2
Connect the fixture and the crossbar ground wire to a
suitable ground in accordance with local electrical
codes.
16
2
Connect the white ballast wire to the neutral power line
wire.
17
2
Connect the black ballast wire to the hot power line
wire.
16
17
SET SCREW
STRAIN RELIEF
CORD
STRAIN RELIEF
HOUSING
NOTE:It is recommended that one person hold the
fixture while the electrician finishes the installation.
18
Place all wires, wire nut connections, and the secondary
strain relief properly inside the electrical box.
Loosen the set screw on the primary strain relief.
19
20
Align the canopy center hole with the mounting plate
center hole.
21
Slide the canopy up against the ceiling and secure it in
place by tightening the primary strain relief into the
crossbar. Do not turn the cord.
22
Push the cord into the canopy and line up the marked
point on the cord with bottom of the primary strain
relief.
23
Tighten the plastic set screw to secure the cord.
24
Screw the strain relief housing back onto the housing
cap.
3
Page 4
Install the Shade
Install the Lamp
3A
2
COLLAR NUT
SOCKET
1
Expose the socket by raising the outer shade.
2
Raise the inner shade and feed the cord until the socket
is exposed at the bottom.
3
Screw the collar nut onto the socket until only a couple
threads remain.
3
OUTER SHADE
1
INNER SHADE
THREAD
5A
SOCKET
LAMP
CAUTION: To reduce the risk of a burn or electric
shock during relamping, disconnect the power to
the fixture.
