Installation Instructions for
980DOMSIGSP
Dome-S-I Grande
Suspension
GP I :ENERAL RODUCT NFORMATION
This product is suitable for indoor dry locations only.
This product can be dimmed with a standard incandescent dimmer.
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
HS246_SC2G60
1.0
Install the Glass Shield and Lamp
1A
CORD
THREADED NIPPLE
ASSEMBLY
1
PLASTIC WASHER
INNER GLASS
SHADE
PLASTIC WASHER
1B
THREADED NIPPLE
PLASTIC WASHER
SOCKET
BRACKET
2
Secure the inner glass shade by tightening the threaded nipple
assembly to the socket bracket.
2
ASSEMBLY
PLASTIC WASHER
INNER GLASS
SHADE
11
Feed the socket assembly cord through a plastic washer, inner
glass shade, another plastic washer and threaded nipple
assembly respectively.
NOTE:Do not over tighten the threaded nipple assembly
which may cause the glass shade to break.
1
1C
1E
CORD
3
3
4
THREADED
NIPPLE ASSEMBLY
3
From the end of the cord, carefully slide the outer glass shade
CAP
OUTER GLASS
SHADE
INNER GLASS
SHADE
and cap completely down and lay it on the threaded nipple
assembly.
4
Secure the outer glass shade in place by tightening the cap to
threaded nipple assembly
6
SOCKET
LAMP
NOTE:To reduce the risk of a burn or electric shock
during relamping, disconnect the power to the fixture.
NOTE:The G9 lamp has an integral glass envelope and is
thus safe to be used without a lamp shield.
1D
STEM
5
5
From the end of the cord slide the stem completely down into
the cap.
CORD
Use 120 Volt, WattType T4,MAX 60
G9 Base, Bi-Pin Halogen Lamp.
6
Push the lamp pins completely into the socket holes .
7
Refer to the instructions provided with the canopy to install
the fixture.
2
IMPORTANT SAFETY INSTRUCTIONS
Halogen Lamp General Information
To reduce the risk of fire, electrical shock, exposure to
excessive UV radiation, or injury to person:
– Use this fixture indoors only.
– Do not look directly at the lighted lamp.
– Do not remain in light if skin feels warm.
– Risk of fire: Use only the type of lamp and maximum
wattage indicated in this instruction manual.
– Never cover the halogen lamp and never place flammable
material close to your fixture.
– Never turn the fixture on and off by connecting and
disconnecting the halogen lamp.
– Do not touch the fixture shade while the fixture is on.
This surface may be HOT.
– A new halogen lamp may smoke slightly when it is used for
the first time.This is perfectly normal; the protective
coating is simply being vaporized.
TwoTips For Prolonging Halogen
Lamp Life
– First avoid touching the lamp with bare hands during
installation.Any contaminant,even the oil from your
hands can deteriorate the lamp. Rubbing alcohol can be
used to remove any contaminant.
– Second, do not run the lamps at full power when you do
not need to. However, if dimming the fixture for an
extended period of time, occasionally bring the light up to
full brightness for a few minutes to complete the halogen
cycle.
3
SAVETHESE INSTRUCTIONS!
7400 Linder Ave, Skokie, IL 60077
800.323.3226 - 847.626.6300
www.lbllighting.com
© 2014 LBL Lighting.All rights reserved. The "LBL Lighting" graphic is a
registered trademark of LBL Lighting. LBL Lighting reserves the right to
change specifications for product improvements without notification.
4
