Installation Instructions for
980DERBYWCF
Derby Wall (Compact Fluorescent)
WALL
GENERAL PRODUCT INFORMATION:
This product is suitable for damp locations.
This product can mount either to a 4” square electrical box with a
round plaster ring or an octagon electrical box.
This instruction shows a typical instruction.
CAUTION - RISK OF FIRE
This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURNTHE POWER TO THE
ELECTRICAL BOX OFF.
PW666_CF
1.0
Install the Fixture
1A
MOUNTING
PLATE
SCREW
MOUNTING
PLATE
SCREW
1
Remove the two mounting plate screws located on top
and the bottom of the fixture.
2
Remove the mounting plate.
MOUNTING
PLATE
1B
BALLAST
5
3
Connect the mounting plate ground wire to a suitable
63
ground in accordance to local electrical codes.
Connect the white ballast wire to the neutral power line
64
wire with a wire nut.
65
Connect the black ballast wire to the hot power line
wire with a wire nut.
1
4
1C
#8-32 SCREW
1E
SCREW
WASHER
7 7
6
Properly place all wire, wire connections, and ballast
inside the electrical box.
7
Attach the mounting plate to the electrical box using
the two #8-32 screws provided.
1D
ANCHOR
WASHER
SCREW
Slide a #8 screw through a washer and screw it into an
612
WASHER
SCREW
anchor.
613
Repeat for the other anchors to secure the mounting
plate to the wall.
ANCHOR ANCHOR
8
Verify that the mounting plate is level before continuing.
9
Line up an anchor tip with the center of the mounting
plate hole and push the anchor into the wall up to the
threads.
610
Screw the anchor in the rest of the way.
Repeat steps 4-6 for the other anchors.
611
2
Install the Lamp and Shade
2A
2B
MOUNTING
PLATE
SCREW
LAMP
SOCKET
MOUNTING
PLATE
SCREW
CAUTION: To reduce the risk of a burn or electric
shock during re-lamping, disconnect the power to
the fixture.
Use WattType Quad Tube
MAX 26
G24Q-3 Base Compact Fluorescent Lamp.
1
Push the lamp base completely into the socket.
2
Replace the shade onto the mounting plate and reinstall
the two mounting plate screws. Tighten to secure.
NOTE:To re-lamp, reverse the section 2 instructions.
3
SAVE THESE INSTRUCTIONS!
7400 Linder Ave, Skokie, IL 60077
800.323.3226 - 847.626.6300
www.lbllighting.com
© 2012 LBL Lighting.All rights reserved. The "LBL Lighting" graphic is a
registered trademark of LBL Lighting. LBL Lighting reserves the right to
change specifications for product improvements without notification.
A Generation Brands Company
4
