Launch Tech DS601 Users Manual
www. matcotools. com
www. maximus3. com
User Manual
(V1.0)
Maximus 3.0 User's Manual
Copyright Information
Copyright © 2018 by LAUNCH TECH. CO., LTD. All rights reserved.
No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior
written permission of LAUNCH. The information contained herein is
designed only for the use of this unit. LAUNCH is not responsible for
any use of this information as applied to other units.
Neither LAUNCH nor its affiliates shall be liable to the purchaser
of this unit or third parties for damages, losses, costs, or expenses
incurred by purchaser or third parties as a result of: Accident,
misuse, or abuse of this unit, or unauthorized modications, repairs,
or alterations to this unit, or failure to strictly comply with LAUNCH
operating and maintenance instructions. LAUNCH shall not be liable
for any damages or problems arising from the use of any options or
any consumable products other than those designated as Original
LAUNCH Products or LAUNCH Approved Products by LAUNCH.
Trademark Information
LAUNCH is a registered trademark of LAUNCH TECH CO., LTD.
(also called LAUNCH for short) in China and other countries.
All other LAUNCH trademarks, service marks, domain names,
logos, and company names referred to in this manual are either
trademarks, registered trademarks, service marks, domain names,
logos, company names of or are otherwise the property of LAUNCH
or its affiliates. In countries where any of the LAUNCH trademarks,
service marks, domain names, logos and company names are not
registered, LAUNCH claims other rights associated with unregistered
trademarks, service marks, domain names, logos, and company
names. Other products or company names referred to in this manual
may be trademarks of their respective owners. You may not use any
trademark, service mark, domain name, logo, or company name
of LAUNCH or any third party without permission from the owner
of the applicable trademark, service mark, domain name, logo, or
company name. You may contact LAUNCH by visiting the website
at www.cnlaunch.com, or writing to LAUNCH TECH. CO., LTD.,
Launch Industrial Park, North of Wuhe Avenue, Banxuegang, Bantian,
Longgang, Shenzhen, Guangdong, P.R.China, to request written
permission to use Materials on this manual for purposes or for all other
questions relating to this manual.
Safety Precautions
Before using Maximus 3.0, please read the following safety information
carefully.
• Never collide, throw, or punch Maximus 3.0, and avoid falling,
extruding and blending it.
• Do not use Maximus 3.0 in exceptionally cold or hot, dusty, damp
or dry environments.
• In places where Maximus 3.0 is forbidden or using Maximus 3.0
may cause interference or generate a potential risk, please turn it
off.
• To ensure a safe driving, please do not use Maximus 3.0 while
driving.
• Turn off Maximus 3.0 before boarding any airplane.
• Do not dismantle Maximus 3.0 by yourself. If there is any inquiry,
please contact the dealer.
• Never place Maximus 3.0 into apparatus with strong
electromagnetic eld.
• Keep Maximus 3.0 far away from magnetic devices because its
radiations may erase the data stored on Maximus 3.0.
• Store Maximus 3.0 out of reach of children and do not allow
children to use it unsupervised.
• Please use the included battery and charger. Otherwise, explosion
I
may happen.
• Do not disconnect power abruptly when Maximus 3.0 is being
formatted or in process of uploading or downloading. Or else it may
result in program error.
Precautions on Using Maximus 3.0
• The ignition switch should be OFF while plugging or unplugging the
VCI device.
• If your vehicle keeps unattended for a week or a long period, it is
suggested to unplug the dongle from vehicle’s DLC to save battery
power.
• While diagnosing a vehicle, you are not advised to use phone
or messaging, because it may cause a data communication
interruption. If it happens, it is abnormal and just try to re-do it.
Precautions on Operating Vehicle’s ECU
• Do not disconnect the vehicle inner consumer when the ignition
switch is ON. High voltage transients may encounter at the moment
of disconnecting, which may damage the sensors and the ECU.
• Protect the computer from magnetic object.
• Do cut off the power supply of ECU system before welding on the
vehicle.
• Pay more attention to the ECU and the sensors when the operation
is next to them.
• Ground yourself when you disassemble PROM, otherwise ECU
and sensors will be damaged by static electricity.
• Do connect ECU harness connector firmly, otherwise electronic
elements, such as IC inside ECU, will be damaged.
Maximus 3.0 User's Manual
II
Maximus 3.0 User's Manual
Table of Contents
1 Introduction ...............................................................................1
1.1 Product Prole ...............................................................................1
1.2 Features ........................................................................................1
1.3 Technical Specications ................................................................2
1.3.1 Maximus 3.0 Tablet ...............................................................2
1.3.2 VCI Dongle (Only for Passenger Vehicle Conguration) ......2
2 Knowledge of Maximus 3.0......................................................3
2.1 Maximus 3.0 Tablet ........................................................................4
2.2 Maximus 3.0 Docking Station ........................................................5
2.3 VCI Dongle (Only for Passenger Vehicle Conguration) ...............6
2.4 Accessory Checklist....................................................................... 7
3 Preparations..............................................................................9
3.1 Charging Maximus 3.0...................................................................9
3.2 On Using Your Battery ...................................................................9
3.3 Power On / Power Off Maximus 3.0 .............................................9
3.3.1 Power on ..............................................................................9
3.3.2 Power off ..............................................................................9
3.4 Tips On Finger Operations ..........................................................10
3.5 Lock & unlock the screen ............................................................10
3.5.1 Lock the screen ..................................................................10
3.5.2 Unlock the screen ...............................................................10
3.6 Locator & Navigation Buttons ......................................................10
3.7 Status Bar .....................................................................................11
3.8 Adjust brightness ..........................................................................11
3.9 Set standby time ...........................................................................11
3.10 Adjust the volume .......................................................................11
3.11 Changing Language ...................................................................11
3.12 WLAN Setting .............................................................................11
4 Initial Use.................................................................................13
4.1 User Registration .........................................................................13
4.2 Basic Operations on Diagnostic App ...........................................15
4.2.1 Switch between different function modules ........................15
4.2.2 How to arrange diagnostic vehicle software icons?............15
4.2.3 How to distinguish if the software is locked or not? ............ 15
4.3 Function Modules ........................................................................15
4.3.1 Diagnostics .........................................................................15
4.3.2 Toolbox ...............................................................................16
4.4 Diagnostics toolbar ......................................................................16
5 Start Diagnostics ....................................................................18
5.1 Connections.................................................................................18
5.1.1 Preparation .........................................................................18
5.1.2 DLC Location ......................................................................18
5.1.3 Vehicle Connection (For Passenger Vehicle Version) ........18
5.2 Communication Setting ...............................................................19
5.2.1 Pairing up via Wireless (BT) communication ...................... 19
5.2.2 USB cable connection ........................................................19
5.3 Start Diagnostics .........................................................................20
5.3.1 AutoDetect (VIN SCAN)......................................................20
5.3.2 Manual Diagnosis ...............................................................23
5.4 Maintenance Reset......................................................................32
5.4.1 Oil Reset Service ................................................................32
5.4.2 Electronic Parking Brake Reset ..........................................33
III
Maximus 3.0 User's Manual
5.4.3 Steering Angle Calibration ..................................................33
5.4.4 ABS Bleeding...................................................................... 33
5.4.5 Tire Pressure Monitor System Reset ..................................33
5.4.6 Gear Learning.....................................................................33
5.4.7 IMMO Service .....................................................................33
5.4.8 Injector Coding ...................................................................34
5.4.9 Battery Maintenance System Reset ................................... 34
5.4.10 Diesel Particulate Filter (DPF) Regeneration ................... 34
5.4.11 Electronic Throttle Position Reset .................................... 35
5.4.12 Gearbox Matching ............................................................35
5.4.13 AFS (Adaptive Front-lighting System) Reset ...................35
5.4.14 Sunroof Initialization .........................................................35
5.4.15 Suspension Calibration ....................................................35
5.5 Diagnostic History (Previous Session) ....................................... 35
5.6 I/M Readiness .............................................................................36
6 Toolbox ....................................................................................37
6.1 Saved Reports .............................................................................37
6.1.1 Health Report .....................................................................37
6.1.2 Remote Report ...................................................................37
6.1.3 Playback .............................................................................37
6.2 Tech-To-Tech ...............................................................................38
6.2.1 Interface Layout ..................................................................38
6.2.2 Add Friends ........................................................................ 39
6.2.3 Start Instant Messaging ......................................................39
6.2.4 Launch Remote Diagnosis (Device-To-Device) ..................40
6.2.5 Launch Remote Diagnosis (Device-To-PC) ........................42
6.3 Feedback .....................................................................................44
6.4 Update .........................................................................................44
6.4.1 Update Diagnostic Software & APP ....................................44
6.4.2 Download software .............................................................45
6.4.3 Renew software subscription..............................................45
6.5 Settings........................................................................................45
6.5.1 General ...............................................................................45
6.5.2 VCI......................................................................................45
6.5.3 VCI Management................................................................46
6.5.4 Activate VCI ........................................................................ 46
6.5.5 Firmware Fix .......................................................................46
6.5.6 Icon Size .............................................................................46
6.5.7 Color Theme ....................................................................... 46
6.5.8 MD Printer Connection .......................................................46
6.5.9 Print Information .................................................................47
6.5.10 Data Stream Sample ........................................................48
6.5.11 Vehicle Voltage ................................................................. 48
6.5.12 Favorites ...........................................................................48
6.5.13 Diagnostic Software Clear ................................................ 48
6.5.14 Backup/Restore ................................................................49
6.5.15 Login/Exit from current account ........................................ 49
6.6 Help .............................................................................................49
7 Applications ............................................................................50
7.1 Sensorbox & Multimeter (Optional) ............................................. 50
7.1.1 Product summary ...............................................................50
7.1.2 Structure and Accessories .................................................. 51
7.1.3 Sensor Simulation ..............................................................52
7.1.4 Multimeter ...........................................................................55
IV
7.2 Batterybox (Optional)...................................................................57
7.2.1 Product Summary ...............................................................57
7.2.2 Test Environment ................................................................ 58
7.2.3 Batterybox Structure and Test Accessories ........................ 58
7.2.4 Connections & Operations..................................................59
7.2.5 Precautions on battery test ................................................61
7.3 Oscilloscope (Optional) ...............................................................62
7.3.1 Introduction .........................................................................62
7.3.2 Structure & Accessories .....................................................63
7.3.3 Connection & Initial Use .....................................................64
7.3.4 Operations ..........................................................................65
7.4 Ignition (Optional) ........................................................................71
7.4.1 Secondary-distributor ignition analysis ............................... 71
7.4.2 Secondary-simultaneous ignition analysis..........................73
7.4.3 Secondary-direct ignition analysis ...................................... 73
7.4.4 Waveform analysis mode ...................................................74
7.5 Videoscope (Optional) .................................................................77
7.5.1 Introduction .........................................................................77
7.5.2 About Videoscope ............................................................... 77
7.5.3 Technical Parameters ......................................................... 78
7.5.4 Connections & Operations..................................................79
Appendix - FAQ ..........................................................................80
Maximus 3.0 User's Manual
V
Maximus 3.0 User's Manual
1 Introduction
1.1 Product Prole
Maximus 3.0 is an evolutionary smart solution for specialized
automotive diagnosis and maintenance. It inherits from LAUNCH’s
advanced diagnosing technology and is characterized by covering a
wide range of vehicles, featuring powerful functions, and providing
precise test result.
Through the wireless communication between VCI dongle and
Maximus 3.0 handset, it achieves full car model and full system
vehicle trouble diagnosis, which include Reading DTCs, Clearing
DTCs, Reading Data Stream, Actuation Test and Special Functions.
Moreover, taking advantage of the mobile Internet, it also integrates
One-click Update, Tech-To-Tech (Remote Diagnosis) and Repair Data,
which helps to diagnose vehicle issues more efficiently, and greatly
increase customer’s retention and boost shop revenue.
Maximus 3.0 adopts a higher performance-price ratio display tablet,
which comes loaded with the powerful 8-core 2GHz processor, 4G
RAM, and a 10.1” sunlight readable capacitive touch screen with a
resolution of 1920 x 1200 pixels.
1.2 Features
1. Diagnose:
• Smart Diagnosis: This module allows you to use the VIN
information of the currently identied vehicle to access its data
(including vehicle information, historical diagnostic records) from
the cloud server to perform quick test.
• Local Diagnosis: To perform diagnosis by executing on-screen
commands step by step. Diagnosis functions include: Read
DTCs, Clear DTCs, Read Data Stream, Special Functions etc.
• Tech-To-Tech (Remote Diagnosis): This option aims to help
repair shops or technicians launch instant messaging and remote
diagnosis, making the repair job getting xed faster.
• Maintenance & Reset: All kinds of common maintenance and
reset items, such as Oil lamp reset, DPF regeneration, ABS
bleeding etc can be done.
• I/M Readiness: I/M refers to Inspection and Maintenance that
is legislated by the Government to meet federal clean-air
standards. I/M Readiness indicates whether or not the various
emissions-related systems on the vehicle are operating properly
and are ready for Inspection and Maintenance testing. Moreover,
this module also has a direct access to generic OBD, saving time
to enter into the system.
• One-click Update: Lets you update your diagnostic software
online.
• Diagnostic History (Previous Session): Provides a quick access
to the tested vehicles and users can choose to view the test
report or resume from previous diagnostic session, without the
necessity of starting from scratch.
• Pre- and Post- Repair Result Comparison: By comparing the prerepair and post-repair report, you can clearly determine which
vehicle issues have been xed and which remained unsolved.
• Diagnostic Feedback: Enables you to submit the vehicle issue to
us for analysis and troubleshooting.
• Vehicle Coverage: Quick dial to view the vehicle models that
Maximus 3.0 covers.
• Backup/Restore: This feature lets you back up the recorded
files to external storage device/restore the recorded data from
external storage device.
2. WLAN connection is supported.
1
Maximus 3.0 User's Manual
3. Web browser: Users can make online search and visit any website.
4. Equipped with multiple universal serial BUS ports for connecting
PC, and other add-on modules such as Scopebox, Sensorbox and
Batterybox.
5. Other Android-based applications can be customized to install or
uninstall.
6. File Manager: Lets you manage les or downloaded les stored in
memory card efciently.
7. Settings: To congure your personalized Maximus 3.0.
1.3 Technical Specications
1.3.1 Maximus 3.0 Tablet
Item Description
Operating system Android 7.1
CPU 8-core processor, 2GHz
Display 10.1 inch capacitive touch screen with
1920 x 1200 resolution
Memory 4GB
Hard disk 64GB
Connectivity
Cameras 8MP front-facing camera + 13MP rear-
• WLAN
• Universal serial BUS Ports (1 x Type-C
• BT 2.1 & 2.4
facing camera
802.11 b/g/n/ac)
(
+ 1 x Type-A)
Sensor Gravity Accelerometer
3-Axis Acceleration Sensor
Power and Battery 9000mAh lithium-polymer battery
Charging via 5V DC power supply
Operating Temperature -10℃ ~ 50℃(14 ~122℉)
Storage Temperature -20℃ ~ 70℃(-4 ~158℉)
1.3.2 VCI Dongle (Only for Passenger Vehicle Conguration)
Item Description
Working temperature -10℃ ~ 50℃(14 ~122℉)
Storage temperature -20℃ ~ 70℃(-4 ~158℉)
Relative humidity 20% ~ 90%
2
2 Knowledge of Maximus 3.0
There are three main components to the Maximus 3.0 system:
• Maximus 3.0 Tablet -- the central processor and monitor for the
system (For details, please refer to Chapter 2.1.)
Fig. 2-1
• Maximus 3.0 Docking Station -- the platform for charging Maximus
3.0 tablet and extending functions (For details, please refer to
Chapter 2.2.)
Maximus 3.0 User's Manual
Fig. 2-3 (Only for Passenger Vehicle Conguration)
Fig. 2-2
• VCI Device -- the device for accessing vehicle data (For details,
please refer to Chapter 2.3.)
3
Maximus 3.0 User's Manual
2.1 Maximus 3.0 Tablet
Fig. 2-4 Maximus 3.0 Tablet (front & side view)
Table 2-1 formulates ports and indicators of Maximus 3.0 tablet:
No. Name & Descriptions
Memory Card Slot -- To store the memory card for storage
1
expansion.
Type C Charging Port -- Reserved for charging the Maximus
2
3.0 tablet.
Power/Screen Lock Button -- To turn the tablet on/off with
3
long press, or lock the screen with short press.
Volume Buttons -- To adjust the volume.
4
*Note: Press and hold [POWER] and [VOL -] key to capture the
current screenshot.
Data Transmission Port -- Reserved for add-on modules
5
(such as Batterybox, Scopebox, Sensorbox and Videoscope),
and other devices with similar port.
6 Microphone
Charging indicator -- It illuminates red while Maximus 3.0
7
tablet is charging. Once charging is nished, it will illuminate
solid green.
8 10.1" Capacitive Touch Screen
9 Ambient Light Sensor
10 Front Camera
4
Maximus 3.0 User's Manual
2.2 Maximus 3.0 Docking Station
Fig. 2-6 Maximus 3.0 Docking Station
Table 2-3 formulates ports of Maximus 3.0 docking station
No. Name & Descriptions
Fig. 2-5 Maximus 3.0 Tablet (rear view)
Table 2-2 formulates parts of Maximus 3.0 tablet (rear):
No. Name & Descriptions
11 Rear Camera
12 Camera Flash
13 Audio Speaker
Adjustable Kickstand - Flip out it to any angle and work
14
comfortable at your desk, or hang it on the steering wheel.
1 Charging Slot -- To charge the tablet.
2 OBD16 Socket -- To store the VCI dongle to avoid loss.
Data Transmission Port -- Reserved for add-on modules,
3
and other devices with similar port.
Type C Charging Port -- Use the power adaptor to supply
4
power to the docking station through connection to AC
outlet.
Power LED -- Illuminates solid green when it is powered
5
up.
5
Maximus 3.0 User's Manual
2.3 VCI Dongle (Only for Passenger Vehicle
Conguration)
The VCI dongle works as a vehicle communication interface device,
which is used to connect to the vehicle’s DLC (Data Link Connector)
directly or via OBD II extension cable to read the vehicle data and
then send it to the Maximus 3.0 handset via wireless communication.
Table 2-4 formulates ports and indicators of VCI dongle:
No. Name & Descriptions
OBD II-16 Diagnostic Connector -- To connect on
1
vehicle’s OBDII DLC.
Data Transmission Port -- To connect to the Maximus 3.0
2
tablet to perform vehicle diagnosis via data cable.
ECU Communication Indicator -- It ashes when the
3
dongle is communicating with the vehicle.
BT/USB Communication Indicator
• BLUE indicates that the dongle is working in wireless
4
5
communication (BT) mode (default mode).
• It illuminates red when the dongle is connected to the
handset via data cable.
Power LED -- It lights up while the dongle is plugged into
the vehicle’s DLC.
Fig. 2-7 VCI dongle
6
2.4 Accessory Checklist
For different product configurations, the included accessories may
vary. For detailed items, please consult from the local agency or check
the package list supplied with Maximus 3.0 together.
Table 2-5 -- Maximus 3.0 common accessories and descriptions
No. Name Qt. Picture
1 Maximus 3.0 Tablet 1
Cigarette Lighter
4
Cable
Battery Clamps
5
Cable
Maximus 3.0 User's Manual
1
(To supply power to non-16pin
dongle via vehicle’s cigarette
lighter receptacle.)
1
(To provide power to the non-16
pin dongle through connection to
the vehicle's battery.)
2 VCI Dongle 1
3 Docking Station 1
(To connect to vehicle’s DLC.)
(To charge the Maximus 3.0
tablet.)
6 Power Adaptor 1
OBD II extension
7
cable
(To supply power to the tablet
through connection to AC outlet.)
1
(To connect the VCI device for
extension purpose.)
7
8 OBDI Adaptor 1
Password
9
Envelope
Non-16pin Dongle
10
Kit
Maximus 3.0 User's Manual
(A adaptor cable for connecting
non-16 pin dongle.)
1
(A piece of paper bearing
Product S/N and Activation
Code, which is required for your
registration.)
(Optional. For detailed non-
16pin dongles, please check the
package box.)
8
Maximus 3.0 User's Manual
3 Preparations
3.1 Charging Maximus 3.0
Choose any of the followings to charge your Maximus 3.0:
A. Use the included 5V power adaptor: Connect one end of the power
adaptor to Type C charging port of the Maximus 3.0 handset, and
the other end to the AC outlet. Never use other similar adaptors to
charge Maximus 3.0.
B. Use the docking station: Follow the steps described as below to
charge your Maximus 3.0:
1. Locate the charging slot on the bottom of Maximus 3.0 tablet and
the docking station. See Fig. 3-1 & Fig. 3-2.
Fig. 3-1 Fig. 3-2
2. Align the charging slots, and then dock the tablet into the station to
ensure that it is rmly seated on the docking station.
3. Insert one end of the included power cord to the charging port
of the docking station, then the other end into the AC outlet. The
charging LED illuminates solid red while charging.
4. Once it illuminates solid green, it indicates that the battery is fully
charged. Disconnect the docking station from the AC outlet.
3.2 On Using Your Battery
• If the battery keeps unused for a long time or battery is completely
discharged, it is normal that it can not be turned on while being
charged. Please charge it for a period and then turn it on.
• Please use the included power adaptor to recharge your Maximus
3.0. We assume no responsibility for damage or loss resulting from
using other similar adaptors other than the specied one.
• The charging time of battery varies with temperature condition and
battery consumption status.
• While Maximus 3.0 has low battery, a beep will sound. If it is very
low, Maximus 3.0 will be switched off automatically.
3.3 Power On / Power Off Maximus 3.0
3.3.1 Power on
Press the POWER key until it is slightly vibrated to turn on Maximus
3.0.
*Note: If it is the rst me you use Maximus 3.0 or Maximus 3.0 keeps idle
for a long me, Maximus 3.0 could fail to be turned on. It results from low
baery. In this case, please recharge your Maximus 3.0 for a while and try
to turn it on.
3.3.2 Power off
1. Press the POWER key for about 3 seconds, an option menu will
pop up on the screen.
2. Tap “Power off” to turn off Maximus 3.0.
9
Maximus 3.0 User's Manual
3.4 Tips On Finger Operations
Actions Results
Single-tap To select a item or launch a program.
Double-tap
Long press
Slide To jump to different pages.
Drag Tap the desktop icon and drop it to other location.
Spread apart /
Pinch together
To zoom in so that the text on a webpage appears
in a column that ts your device’s screen.
Press and hold on the current interface or area
until a contextual menu pops up on the screen,
and then release it.
To zoom in manually, place two fingers on the
screen and then spread them apart. To zoom out,
place two fingers apart on the screen and then
pinch them together.
3.5 Lock & unlock the screen
Many screen lock modes are available on Maximus 3.0. Take the
preset screen-lock mode as example for demonstration.
3.5.1 Lock the screen
• When Maximus 3.0 is ON, press [POWER] key once to lock the
screen;
• The system will lock the screen automatically after Maximus 3.0
remains idle over the preset standby time.
3.5.2 Unlock the screen
Press [POWER] key to activate the screen, and then drag the lock to
“Unlock” position.
*Notes:
1. In case you forgot the screen lock, please refer to Appendix - FAQ for
details. You are not suggested to use the screen lock.
2. If you use “unlock the pattern”, you have to draw the right target
paern to unlock it.
3.6 Locator & Navigation Buttons
1
2
On-screen keys and status bar are as follows:
1 Tap
2 Tap
3
4
5
to return to the previous screen or exit the application.
to navigate to the Android System’s home screen.
Tap
running or recently used. To open an application, tap it. To
remove an application, swipe it upwards.
Tap
screenshots are stored in the Screenshots folder.
the icon will turn highlighted.
to display a list of applications that are currently
to capture the current screen and all captured
: Once some upgradable diagnostic software are detected,
3
Fig. 3-3
4 5 6
10
Maximus 3.0 User's Manual
: Shows whether the VCI device is properly connected or
6
not.
3.7 Status Bar
For some common indicators, please see the following table.
Icons Denitions Icons Denitions
Airplane mode BT is on
Positioning GPS Charging
Battery is fully charged Low battery
New mail
Uploading Downloading
Note: When the icon appears on the status bar, please charge it
*
immediately.
Preparing memory
card
3.8 Adjust brightness
Maximus 3.0 is equipped with a built-in light intensity sensor. It can
adjust the screen brightness according to the ambient light intensity
automatically. Alternatively, you can also adjust it manually.
Tips: Reducing the brightness of the screen is helpful to save the power
of Maximus 3.0.
3.9 Set standby time
If no activities are made within the dened standby period, the screen
will be locked automatically and the system enters sleep mode to save
power.
1. On the main menu screen, tap Settings > Display > Sleep.
2. Choose the desired sleep time.
3.10 Adjust the volume
This option enables you to adjust the volume of the ringtones, media
player, alarm and notice.
1. On the main menu screen, tap Settings > Sound > Volume.
2. Drag the slider to adjust it.
*Note: Alternatively, you can also press the volume keys to control the
volume of the current applicaon.
3.11 Changing Language
Maximus 3.0 supports multiple languages. To change the language of
the tool, please do the following:
1. On the home screen, tap on Settings -> Language & Input ->
Languages.
2. Tap on “Add a language”, and then choose the desired language
from the list.
3. Tap and hold the desired language and drag it to the top of the
screen and then release it, the system will change into the target
language.
1. On the main menu screen, tap Settings > Display > Brightness.
2. Drag the slider to adjust it as desired.
3.12 WLAN Setting
*Note: Once WLAN is set as ON, Maximus 3.0 will consume more
11
power. While it keeps unused, please set it off to save power. While
WLAN keeps unused, please turn it off to conserve battery power.
Maximus 3.0 has built-in Wi-Fi that can be used to get online. Once
you’re online, you can register your tool, update diagnostic software &
APK, browse the Internet, get apps and send email on your network.
1. On the main menu screen, tap Settings > WLAN.
2. Tap or slide the switch to ON, Maximus 3.0 starts searching for all
available wireless LANs.
3. Choose the desired network,
• If the network you chose is open, you can connect on it directly;
• If the selected network is encrypted and secured with WPA, you
have to input the right access password to connect.
When Maximus 3.0 is in range of the WLAN, it will connect to the
previously linked network automatically.
Maximus 3.0 User's Manual
12
Maximus 3.0 User's Manual
4 Initial Use
4.1 User Registration
Users need to experience an sign-up process before using Maximus
3.0.
*Notes:
• Before registering, please make sure that your handset has a strong and
stable Wi-Fi signal.
• While acvang device, the Serial number and Vericaon code can be
found in the included password envelope. To obtain Activation code,
please contact with your dealer.
Follow the steps below to proceed:
1. Tap “Maximus 3.0” on the home screen to Fig. 4-1.
On-screen Buons:
REGISTER UNIT: For new user, tap it to go to step 2.
START DEMO/EOBD MODE: Two free programs (DEMO & EOBD) are
preset in this App. This option enables you to experience the diagnostic
procedures even if you have not acvated your device or VCI dongle is not
used.
2. Fill in your account information and device information and then tap
on “ACTIVATE” to enter Fig. 4-3.
*Note:
Serial number is a 12-digit number starng with 98 -- you can nd it on the
back of your tool.
Vericaon code is a 8-digit number stored in the Private & Condenal
sheet.
Acvaon code is printed on the receipt, or consult your dealer for it.
Fig. 4-1
Fig. 4-2
13
On-screen Buons:
Recover Current Device Activation: If you have already activated your
Maximus 3.0, tap it to navigate to the following screen.
Maximus 3.0 User's Manual
Fig. 4-3
Input Serial number, Email address and Password, and then tap “SUBMIT”
to sign in and go to Fig. 4-3.
Click Here to Reset Password: If you forgot the password, tap it to go to the
following screen.
Follow the on-screen instrucons to reset a new password.
3. Tap “RUN DIAGNOSTICS” to launch diagnostics. See Fig. 4-4.
14
On-screen Buons:
Sign Out: Tap it to log out the system.
Update Prole: Tap it to modify personal informaon.
Update App: If a newer App version is detected, this buon will appear on
the screen. Tap it to keep synchronized with the latest version.
4. Tap “
switch to the Toolbox module. See Fig. 4-5.
” on the top left-hand corner of the screen (Fig. 4-4) to
Maximus 3.0 User's Manual
Fig. 4-4
Fig. 4-5
*Note: If a red dot appears on upper right corner of the Update logo, it
indicates newer soware is available.
5. Tap “Update” to enter the update center.
Fig. 4-6
Make sure all brands are selected, tap “Update” to start updating.
*Note: Download and installaon will take approximately 10 minutes
depending on the internet connecon.
Once downloading is complete, the software package will be installed
automatically.
Tap the “OK” button on the pop-up message box when update is
complete.
4.2 Basic Operations on Diagnostic App
4.2.1 Switch between different function modules
There are 2 function modules available on the Maximus 3.0:
Diagnostics and Toolbox.
15
Fig. 4-7
Swipe in from the left/right edge of the screen to switch between
function modules.
Alternatively, you can also tap
screen to toggle between Diagnostics and Toolbox.
on the upper left corner of the
4.2.2 How to arrange diagnostic vehicle software icons?
All software icons, by default are organized by the system. Many
display rules are available to meet your preference.
To re-organize it, press and hold certain software icon, an option menu
pops up on the screen. Choose the display rule and the system will
arrange the icon as desired.
If you choose “Pin to the top”, the icon will be displayed on the top of
the screen and marked with an orange solid dot.
4.2.3 How to distinguish if the software is locked or not?
If the software is locked, tap it to display the latest software summary.
In this case, you need to purchase the software to unlock its content.
Once it is unlocked, the software icon will turn into orange.
Maximus 3.0 User's Manual
4.3 Function Modules
There are 2 function modules available on the Maximus 3.0:
Diagnostics and Toolbox.
4.3.1 Diagnostics
It mainly includes the following items:
Configures Maximus 3.0 to operate as a
Automotive
Maintenance Reset
Heavy Duty
Previous Session
diagnostic tool exclusively for passenger cars.
Max VIN (VIN Decoding) and Manual
Diagnosis are supported.
To perform all kinds of common repair &
maintenance items, including electronic
throttle position reset, ABS bleeding, oil lamp
reset and DPF regeneration etc.
Configures Maximus 3.0 to operate as a
diagnostic tool exclusively for commercial
vehicles.
*Note: This function requires an extra VCI
module and only applies to the Maximus 3.0 of
Commercial Passenger Edition.
When a vehicle diagnosis is performed,
Maximus 3.0 records the detailed diagnostic
information. This function provides a quick
access to the previously tested vehicles.
Testing can be re sumed from the previous
operation without starting from scratch.
16
Maximus 3.0 User's Manual
4.3.2 Toolbox
It mainly includes the following items:
Includes Health report, Diagnostic
Saved Report
Tech-To-Tech
Feedback
Applications
Videoscope
(Optional)
Oscilloscope
(Optional)
Sensor
(Optional)
Multimeter
(Optional)
Battery
(Optional)
feedback, Waveform Playback and
Remote report.
This option aims to help repair
shops or technicians launch instant
messaging and remote diagnosis,
making the repair job getting fixed
faster even from thousands of miles
away.
This item allows you to feedback
your diagnostic problems to us for
analysis and troubleshooting.
To check unseen or unreachable
parts or components.
To determine vehicle electrical
equipment and circuit trouble.
To diagnose/simulate vehicle ECU
sensor trouble.
To measure physical parameters
such as voltage, resistance,
frequency etc.
To test whether vehicle's battery is
good or not.
Update
Settings
Help
To update vehicle diagnostic software
and APK.
To make some system settings,
including Printer connection, Icon
size, Color theme and Logout etc.
Includes FAQ, Vehicle Coverage,
Quick Start Guide, User Manual and
Function Notes.
4.4 Diagnostics toolbar
The diagnostics toolbar contains a number of buttons that enables
various procedures. It is hidden under
diagnostic screens throughout the diagnostic session. Refer to the
table below for a brief description of the functions of the diagnostics
toolbar buttons.
Tap to print the current screen.
Print
Exit Session Tap to exit the current diagnostic session.
To perform printing, you need to pu rchase an
extra Wi-Fi printer separately.
at the top of the vehicle
17
Maximus 3.0 User's Manual
5 Start Diagnostics
5.1 Connections
5.1.1 Preparation
Normal testing conditions
• Turn on the vehicle power supply.
• Vehicle battery voltage range should be 9-14V and working voltage
of Maximus 3.0 is 5V.
• Throttle should be closed at its close position.
5.1.2 DLC Location
1. For Passenger Cars,
The DLC (Data Link Connector or Diagnostic Link Connector) is the
standardized 16-cavity connector where diagnostic code readers
interface with the vehicle’s on-board computer. The DLC is usually
located 12 inches from the center of the instrument panel (dash),
under or around the driver’s side for most vehicles. If Data Link
Connector is not located under dashboard, a label should be there
telling location. For some Asian and European vehicles, the DLC
is located behind the ashtray and the ashtray must be removed
to access the connector. If the DLC cannot be found, refer to the
vehicle’s service manual for the location.
Fig. 5-1
2. For Commercial Vehicles,
The DLC is generally located in driver’s cab.
5.1.3 Vehicle Connection (For Passenger Vehicle Version)
The method used to connect the VCI device to a vehicle’s DLC
depends on the vehicle’s conguration as follows:
• A vehicle equipped with an OBD II management system supplies
both communication and 12V power through a standardized DLC.
• A vehicle not equipped with an OBD II management system
supplies communication through a DLC connection, and in some
cases supplies 12V power through the cigarette lighter receptacle
or a connection to the vehicle battery.
Follow the steps mentioned below to connect OBD II vehicle:
1. Locate vehicle’s DLC socket.
2. Plug the VCI device into the vehicle’s DLC socket (It is suggested
to use the OBD II extension cable to connect the VCI device and
DLC socket.).
3. Choose one of the two ways to obtain power from:
A. Power adaptor: Connect one end of the included power adaptor
to Power interface of Maximus 3.0 tablet, and the other end to
AC outlet.
B. Internal battery pack: For details on how to recharge Maximus
3.0, see “Chapter 3.1 Charging Maximus 3.0”.
For non-OBDII vehicle, proceed as follows:
1. Locate vehicle’s DLC socket.
2. Select the corresponding non-16pin dongle.
3. Plug the non-16pin end of the dongle into the DLC socket, then
connect the other end to the OBD I adaptor, and then tighten the
captive screws.
4. Connect the other end of the adaptor to the included VCI device.
18
Maximus 3.0 User's Manual
5. To supply power to OBD I adaptor from:
A. Cigaretter Lighter Cable: Connect one end of the cigarette lighter
cable to vehicle’s cigarette lighter receptacle, and the other end to
the power jack of OBDI adaptor.
Fig. 5-2
B. Battery Clamps Cable: Connect one end of the battery clamps
cable to vehicle’s battery, and the other end to the power jack of
OBDI adaptor.
Fig. 5-3
5.2 Communication Setting
There are 2 ways available for Maximus 3.0 to communicate
with the VCI device: BT(wireless) communication and USB cable
connection. User can choose either of the following ways to establish
communication.
5.2.1 Pairing up via Wireless (BT) communication
Refer to Chapter 5.1.3 Vehicle Connection to connect the Maximus 3.0
and VCI device.
1. Enter Bluetooth setting screen (“Settings” -> “BLUETOOTH”),
slide the switch to ON and Maximus 3.0 will start searching for all
available devices.
2. Tap the desired one from the result list to pair and match. By
default, the Bluetooth ID of the VCI dongle starts with 98********00
(where ******** stands for 8 digits).
3. If the pair request pops up on the screen, enter the request pin
code (default code: 0000 or 1234).
4. Once pairing is successfully done, the VCI dongle will be shown on
the top of the “Paired devices” list and the VCI icon on the lower
right corner of the screen will light up.
*Notes:
• If you logged in the account on another diagnostic tool and the VCI
dongle has ever been paired up with that tool, you need to cancel
pairing first before using a different tool to proceed new diagnostic
session. Tap “Seng” -> “Bluetooth” -> the
name, and then tap “FORGET” on the pop-up dialog box to unpair it.
• In case no Bluetooth setting is done before diagnostic software is
launched, you can also configure it while using the App. For details,
please refer to “Chapter 5.3 Start diagnoscs”.
icon next to the device
5.2.2 USB cable connection
1. Connect one end of the USB cable (optional) to the Data I/O port of
the VCI device.
2. Connect the other end to the USB port of the Maximus 3.0 handset.
The power indicator of the VCI device lights up.
19
Maximus 3.0 User's Manual
*Note: The USB connection provides the most stable and fastest
communicaon. When all the communicaon methods are applied at the
same me, the Maximus 3.0 system will use the USB communicaon as the
default priority.
5.3 Start Diagnostics
On the Diagnostics page, tap “Automotive/Heavy Duty” to enter the
vehicle selection page.
2 approaches are provided for you to access the vehicle diagnostic
software.
5.3.1 Max VIN (VIN Decoding)
Through simple wireless (BT) communication between the Maximus
3.0 handset and VCI, you can easily get the VIN (Vehicle Identication
Number) information of the currently identied vehicle. Once the VIN
is successfully identified, the system will retrieve it from the remote
server and then guide you to vehicle information page without the
necessity of step-by-step manual menu selection (Early model may
need manual selection).
The vehicle information page lists all historical diagnostic records of
the vehicle, which lets the technician have a total command of the
vehicle faults. In addition, a quick dial to local diagnosis and diagnostic
function are also available on this page for reducing the roundabout
time and increasing productivity.
*Notes:
• Before using this function, please make sure the VCI is properly
connected to the vehicle’s DLC. For detailed connection, see Chapter
5.1.3 “Vehicle Connecon”.
• A stable network connecon is required for this funcon.
1. Tap “Max VIN” to enter Fig. 5-4.
Fig. 5-4
In this case, automatic scan (OBD VIN), camera and manual input
(INPUT VIN) are available.
a). OBD VIN: In this mode, the VCI device should be plugged into the
vehicle’s DLC rst, and then a wireless (BT) communication should
be established between Maximus 3.0 and the VCI dongle.
Tap “OBD VIN”, the syste m starts decoding the VIN to enter general
information about the vehicle (year, make, model etc.). When the
process is complete, Fig. 5-10 appears.
* Note: If the VCI is not paired up with the Maximus 3.0 handset before
doing this step, an advisory message prompng Bluetooth connecon failure
appears on the screen.
Follow the steps below to proceed.
20
Fig. 5-5
Maximus 3.0 User's Manual
Check all the possible reasons carefully, and then tap “Conrm” to enter the
following screen.
Fig. 5-6
If the VCI was once used with other devices, you need to cancel the pairing
of the VCI rst via either one of the following ways:
• On the Android’s home screen, tap “Sengs” -> “Bluetooth” -> Choose
the desired VCI from the Paired list. Tap “
unpair it.
• Go to “Toolbox“, tap “Settings” -> “VCI Management” -> “Deactivate
matching”.
In Fig. 5-6, tap “Scan” to start searching for the VCI and pairing up with it.
b).Camera: In this mode, you need to place the VIN inside the
viewnder rectangle to scan it.
Fig. 5-7
• If the ambient light is too weak, please turn the camera ash
”, and then tap “FORGET” to
on.
• If you have scanned the VIN of the vehicle, tap VIN record icon
to select it from the record list.
• In case the handset failed to identify it, tap
*Note: In general, vehicle identification numbers are standardized - all
contain 17 characters. VIN characters may be capital letters A through Z
and numbers 1 through 0; however, the leers I, O and Q are never used
in order to avoid mistakes of misreading. No signs or spaces are allowed in
the VIN.
After scanning, the screen automatically displays the result.
Fig. 5-8
• If the VIN scanned is incorrect, tap the result eld to modify it and
then tap “OK”. If the VIN exists on the remote server, the system
will enter the vehicle information screen. See Fig. 5-10.
• To scan it again, tap “REPEAT”.
c). Enter VIN: In this mode, you need to input the VIN manually.
The most recognizable location for this number is in the top left corner
on the vehicle’s dashboard. Other locations include the driver’s door
or post, and the rewall under the hood.
Tap “Enter VIN” and a screen similar to Fig. 5-9 will appear:
to enter it manually.
21
