Manual
Laser Portable Wireless Pill Speaker
SPK-BTPLL
WHAT’S IN THE BOX
1 x SPK-BTPLL Speaker
2 x Micro USB Cables
1 x 3.5mm AUX Cable
1 x User Manual
SPECIFICATION
Bluetooth version
Battery
Battery Runtime Approx 3 hours (at medium volume)
Speaker Driver Size 2 x Φ 52mm
Speaker Power
Frequency Response
Product Dimensions
Charging
V5.0
1200mAh
2 x 5W
150Hz - 20KHz
80 x 80 x 180mm
5V
CONTROLS
7 8
2
1 3
1. Micro USB Charging Port
2. Micro SD Card
3. USB
4. AUX
5.
6.
7.
4
6 5
• Insert one end of cable into the Micro USB Port and the other end into
a USB wall adapter (not included) to start char
ox 8 - 12 hours for a full charge
• Appr
• Only MP3 files on F
• Please try formatting to suggested file system if not detec
• Only MP3 files on FAT32 or exFAT file system are supported
• Please try formatting to suggested file system if not detec
• Use supplied 3.5mm AUX cable
• Tap or hold to decrease volume
• Tap to SKIP between stations in FM mode
• Tap or hold to increase volume
• Tap to SKIP between stations in FM mode
• Tap to switch between Bluetooth, FM, AUX, USB and Micro SD Card modes
AT32 or exFAT file system are supported
ging
ted
ted
• Tap to PLAY/PAUSE when using USB, Micro SD Card or Bluetooth mode
8.
• Tap to start AUTO SEARCH function when using FM Radio
• Press and HOLD to turn speaker ON/OFF
FEATURES
True Wireless Stereo Function (TWS)
Bluetooth Wireless Connectivity
USB – Upto 32gb and FAT32 or
exFAT file system only
Micro SD Card - Upto 32gb and FAT32
or exFAT file system only
FM Radio
AUX IN
Rechargeable Lithium Battery
BLUETOOTH
Turn on Speaker and tap “M” until “BLUETOOTH MODE” is heard
Search for “SPK-BTPLL” under the Bluetooth settings
of device being connected
TIP
If password is requested
enter “0000”
TRUE WIRELESS STEREO - TWS
(2 speakers required)
Turn ON both speakers and switch them into Bluetooth mode
Press and hold M button on one of the speakers
A sound will be heard which indicates the unit is waiting for TWS pairing
Keep the button held for 5 - 10 seconds and another sound will be
heard when TWS is connected successfully
FM RADIO
Tap to start the AUTO SEARCH function
for FM stations
This operation will scan all FM stations and record
them to memory
The scan procedure will take 1 - 2 minutes to complete
and should not be interrupted
Once complete you can tap or to skip between
the saved stations
Connect a Micro USB cable
TIP
into the charging port to
improve FM reception
TROUBLESHOOTING
No Power: Radio not clear:
1. Check battery level and charge if required
2. Try turning on speaker while connected
to power source
3. Try charging with USB Wall Adapter
For more
helpful guides
visit us at
1. Change speaker location
2. Connect a Micro USB cable into the
charging port to improve FM reception
as this doubles as an aerial
3. Isolate speaker from other devices as
this may be caused by interference
LASER
www.youtube.com/LasercoAu
USB or Micro SD Card not
recognised or files not playing:
1. Make sure USB or Micro SD Card
is 32Gb or less
2. Check USB or Micro SD Card has
been formatted to the FAT32 or
exFAT file system. If not please
format on a Windows
based computer
3. Make sure
to only use MP3 music
files copied to the USB or Micro
SD Card
WARRANTY
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have
the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
www.laserco.com.au
