Lantronix SDS1101, SDS2101 User Manual

SDS1101/2101

User Guide

Part Number 900-451

Revision C February 2010

© 2009 and 2010, Lantronix. All rights reserved. No part of the contents of this book may be transmitted or reproduced in any form or by any means without the written permission of Lantronix. Printed in the United St ates of Am eric a.

Ethernet is a trademark of XEROX Corporation. UNIX is a registered trademark of The Open Group. Windows 95, Windows 98, Windows 2000, and Windows NT are trademarks of Microsoft Corp. Netscape is a trademark of Netscape Communications Corporation.

Contacts

Lantronix

167 Technology Drive Irvine, CA 92618 USA Toll Free: 800-526-8766 Phone: 949-453-3990 Fax: 949-450-7249

Technical Support Online:

Sales Offices For a current list of our domestic and international sales offices, go to the Lantronix Web site at

www.lantronix.com/support .

http://www.lantronix.com/about/contact/index.html .

Disclaimer

Operation of this equipment in a residential area is likely to cause interference in which case the user, at his or her own expense, will be required to take whatever measures may be required to correct the interference.

Note: This product has been designed to comply with the limits for a Class A

digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against such interference when operating in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with this guide, may cause harmful interference to radio communications.

Changes or modifications to this device not ex plic it l y approv ed b y Lantron ix will v oid the user's authority to operate this device.

The information in this guide may change without notice. The manufacturer assumes no responsibility for any errors that may appear in this guide.

Note: Export Control Classification Number 5A002, License exception ENC. The

following export agreement is required for encryption: I agree that I will not export or re-export this product or firmware to a national resident

of Cuba, Iran, Iraq, Libya, North Korea, Sudan, Syria or any other country to which the United States has embargoed goods; or to anyone on the US Treasury Department's list of Specially Designated Nationals and Blocked Persons, US Commerce Department's Table of Denial Orders and Entitles List, or the US State Department's Debarred List. By receiving this product, I am agreein g to the foregoi ng and I am representing and warranting that I am not located in, under the control of, or a national or resident of any such country or on any such list.

SDS1101 /2101 User Guide 2

Revisions

Date

Rev.

Comments

8/06

Initial document

1/09

Include SDS2101 product; updated to firmware v6.5.0.0

2/10

Update document with corrections.

SDS1101/2101 User Guide 3

Contents

1: Using This Guide 9

Purpose and Audience ________________________________________________ 9 Chapter Summary ___________________________________________________ 9 Additional Documentation_____________________________________________ 10

2: Introduction 11

Applications _______________________________________________________ 11 Application Examples ________________________________________________ 11 Protocol Support ____________________________________________________ 13 Additional Features __________________________________________________ 13 Configuration Methods _______________________________________________ 13 Product Information Label ____________________________________________ 14

3: Getting Started 15

Package Contents __________________________________________________ 15 Installing the SDS ___________________________________________________ 16 Required Information ________________________________________________ 17

Assigning the IP Address: DeviceInstaller ________________________________ 18

Assigning the IP Address: Serial Port Login _______________________________ 21

Hardware Address _______________________________________________ 17 IP Address _____________________________________________________ 17

Installing DeviceInstaller __________________________________________ 18 Assigning an IP Address __________________________________________ 18 Adding the Unit to the Manage List __________________________________ 19 Accessing the SDS1101/2101 Using DeviceInstaller ____________________ 19 Viewing the Current Configuration ___________________________________ 19 Next Step ______________________________________________________ 21

4: Configuration Using Web-Manager 23

Accessing SDS1101/2101 Us ing Dev iceIns t al ler ___________________________ 23 Network Configuration _______________________________________________ 24

Automatic IP Address Configuration _________________________________ 25 Static IP Address Configuration _____________________________________ 25

Ethernet Configuration ____________________________________________ 26 Server Configuration _________________________________________________ 26 Host List Configuration _______________________________________________ 28 Channel 1 & Channel 2 (SDS2101 only) Configuration ______________________ 29

Serial Settings __________________________________________________ 29

Connection Settings - TCP ________________________________________ 32

Connection Settings - UDP ________________________________________ 35 Apply Settings ______________________________________________________ 37 Apply Factory Defaults _______________________________________________ 37

5: Configuration via Telnet or Serial Port (Setup Mode) 38

Accessing Setup Mode _______________________________________________ 38

Telnet Connection _______________________________________________ 38

SDS1101/2101 User Guide 4

Contents

Serial Port Connection ____________________________________________ 39 Exiting Setup Mode _________________________________________________ 39

6: Setup Mode: Server Configuration 41

Server Configuration (Option 0) ________________________________________ 41 IP Address ________________________________________________________ 41 Set Gateway IP Address _____________________________________________ 41 Netmask: Number of Bits for Host Part __________________________________ 42 Change Telnet Configuration Password __________________________________ 42 DHCP Name _______________________________________________________ 42

7: Setup Mode: Channel Configuration 44

Channel 1 (Option 1) & Channel 2 (Option 2 on SDS2101 only) _______________ 44 Baudrate __________________________________________________________ 44 I/F (Interface) Mode _________________________________________________ 45 Flow _____________________________________________________________ 45 Port Number _______________________________________________________ 46 Connect Mode _____________________________________________________ 46

a) Incoming Connection ___________________________________________ 47

b) Response ____________________________________________________ 48

c) Active Startup _________________________________________________ 48

d) Datagram Type _______________________________________________ 51

e) Modem Mode _________________________________________________ 51 Send the Escape Sequence (+++) in Modem Mode ________________________ 54 Show IP addr after 'RING' ____________________________________________ 54 Auto Increment Source Port ___________________________________________ 54 Remote IP Address _________________________________________________ 54 Remote Port _______________________________________________________ 54 DisConnMode ______________________________________________________ 54 Flush Mode (Buffer Flushing) __________________________________________ 55 Pack Control _______________________________________________________ 56

Packing Interval _________________________________________________ 57

Trailing Characters _______________________________________________ 57

Send Characters ________________________________________________ 57 DisConnTime (Inactivity Timeout) ______________________________________ 57 Send Characters ____________________________________________________ 57 Telnet Terminal Type ________________________________________________ 58 Channel (Port) Password _____________________________________________ 58

8: Setup Mode: Advanced Settings 59

Expert Settings (Option 5) ____________________________________________ 59

ARP Cache timeout in seconds _____________________________________ 59

CPU Performance (SDS2101 only) __________________________________ 59

Disable Monitor Mode at bootup ____________________________________ 59

HTTP Port Number ______________________________________________ 60

MTU Size ______________________________________________________ 60

Enable alternate MAC ____________________________________________ 60

Ethernet connection type __________________________________________ 60 Security Settings (Option 6) ___________________________________________ 60

Disable SNMP __________________________________________________ 61

SNMP Community Name __________________________________________ 61

Disable Telnet Setup _____________________________________________ 61

SDS1101/2101 User Guide 5

Contents

Disable TFTP Firmware Update ____________________________________ 61

Disable Port 77FE (Hex) __________________________________________ 62

Disable Web Server ______________________________________________ 62

Disable Web Setup ______________________________________________ 62

Disable ECHO Ports _____________________________________________ 62

Enable Enhanced Password _______________________________________ 62

Enable Encryption _______________________________________________ 62 Default Settings (Option 7) ____________________________________________ 64

Channel 1 Configuration Defaults ___________________________________ 64

Channel 2 Configuration Defaults (SDS2101 only) ______________________ 64

Expert Settings Defaults __________________________________________ 64

Security Settings Defaults _________________________________________ 65

9: Firmware Upgrades 66

Obtaining Firmware _________________________________________________ 66 Reloading Firmware _________________________________________________ 66

Using TFTP: Graphical User Interface ________________________________ 66

Using TFTP: Command Line Interface _______________________________ 67

Recovering the Firmware Using the Serial Port and DeviceInstaller _________ 67

10: Monitor Mode 69

Entering Monitor Mode Using the Serial Port __________________________ 69

Entering Monitor Mode Using the Network Port ________________________ 69

Monitor Mode Commands _________________________________________ 69

11: Troubleshooting and Contact Information 71

SDS1101 LEDs ____________________________________________________ 71 SDS2101 LEDs ____________________________________________________ 72 Problems and Error Messages _________________________________________ 72 Technical Support ___________________________________________________ 74

12: SDS1101 Connections and Pinouts 76

Serial Port _____________________________________________________ 76

Serial Connector Pinouts __________________________________________ 76

Modem Cable ___________________________________________________ 77

Network Port ___________________________________________________ 78

Ethernet Connector Pinouts ________________________________________ 79

Power Plug _____________________________________________________ 79

13: SDS2101 Connections and Pinouts 80

SDS2101 Serial Por ts ____________________________________________ 80

Serial Connector Pinouts __________________________________________ 80

Network Port ___________________________________________________ 81

Reset Button ___________________________________________________ 81

Ethernet Connector Pinouts ________________________________________ 81

Power Plug _____________________________________________________ 81

14: SDS1101 Technical Specifications 82 15: SDS2101 Technical Specifications 84

SDS1101/2101 User Guide 6

Figures

Contents

A: Alternative Ways to Assign an IP Address 87

DHCP _________________________________________________________ 87

AutoIP ________________________________________________________ 87

BOOTP ________________________________________________________ 88

ARP and Telnet _________________________________________________ 88

B: Binary to Hexadecimal Conversions 89

Converting Binary to Hexadec imal ______________________________________ 89

Conversion Table ________________________________________________ 89

Scientific Calculator ______________________________________________ 90

C: Warranty 91 D: Compliance and Disclaimer 92 Index 95

Figure 2-1. Serial Tunneling Example _____________________________________ 12 Figure 2-2. Direct TCP/IP or Redirector Configuration Figure 2-3. Sample Hardware Address Figure 3-1. SDS1101 Connected to Serial Device and Network Figure 4-1. Lantronix Web-Manager Figure 4-2. Network Settings Figure 4-3. Server Settings Figure 4-4. Hostlist Settings Figure 4-5. Channel Serial Settings Figure 4-6. TCP Connection Settings Figure 4-7. UDP Connection Settings Figure 5-1. MAC Address Figure 5-2. Setup Menu Options Figure 6-1. Network Settings Figure 6-2. Change Telnet Configuration Password Figure 7-1. Serial Port Settings Figure 7-2. Hostlist Option Figure 8-1. Expert Settings Figure 8-2. Security Settings Figure 8-3. Encryption Ke ys Figure 9-1. TFTP Window Figure 12-1. Serial Interface Figure 12-2. DB25 Female DCE Interface RS232 Figure 12-3. DB25 Female Interface RS422 (4 wire mode) Figure 13-1. Serial Interface Figure 13-2. DB9 Male RS232 Serial DTE Connector Figure 13-3. Network Interface

_________________________ 12 ____________________________________ 14 _________________ 16 ______________________________________ 24 ____________________________________________ 24 ______________________________________________ 27 _____________________________________________ 29 _______________________________________ 30 ______________________________________ 33 _____________________________________ 36 _______________________________________________ 39 _________________________________________ 39 ____________________________________________ 41 __________________________ 42 __________________________________________ 44 ______________________________________________ 50 ______________________________________________ 59 ____________________________________________ 61 _____________________________________________ 63 ______________________________________________ 67 _____________________________________________ 76 ____________________________ 76 _____________________ 77 _____________________________________________ 80 _________________________ 80 ___________________________________________ 81

Tables

Table 6-1. BootP/DHCP/Au toIP opt ions ____________________________________ 41 Table 6-2. Standard IP Network Netmasks Table 7-1. Interface Mode Options Table 7-2. Common Interface Mode Settings Table 7-3. Flow Control Options

SDS1101/2101 User Guide 7

_________________________________ 42 ________________________________________ 45 ________________________________ 45 __________________________________________ 46

Contents

Table 7-4. Reserved Port Numbers _______________________________________ 46 Table 7-5. Connect Mode Optio ns Table 7-6. Manual Connection Address Example Table 7-7. Modem Mode Messages Table 7-8. Modem Mode Commands Table 7-9. Disconnect Mode Options Table 7-10. Flush Mode Options Table 7-11. Pack Control Options Table 9-1. Firmware Files Table 10-1. Monitor Mode Commands Table 10-2. Command Response Codes Table 11-1. SDS1101 LEDs Table 11-2. SDS2101 LEDs Table 11-3. Problems and Error Messages Table 14-1. SDS1101 Technical Specifications Table 15-1. SDS2101 Technical Specifications

________________________________________ 47 ____________________________ 49 _______________________________________ 52 ______________________________________ 53 ______________________________________ 55 _________________________________________ 56 ________________________________________ 56 _______________________________________________ 66 _____________________________________ 70 ___________________________________ 70 _____________________________________________ 71 _____________________________________________ 72 _________________________________ 72 ______________________________ 82 ______________________________ 84

SDS1101/2101 User Guide 8

2: Introduction

Describes the main features of the SDS and the protocols it

3: Getting Started

Provides information for installing your unit and getting it up and

4: Configuration Using Web-

Details using the Web-Manager to set parameters such as port

5: Configuration via Telnet or

Provides instructions for accessing Setup Mode (command line

11:: UUssiinngg TThhiiss GGuuiiddee

Purpose and Audience

This guide provides the information needed to configure, use, and update the SDS1101 & SDS2101 device servers. It is for system administrators and those responsible for installing and maintaining the SDS.

Chapter Summary

The remaining chapters in this guide include:

Manager

Serial Port (Setup Mode)

supports.

running using DeviceInstaller or a serial port connection.

and server properties.

interface) using a Telnet connection through the network or a terminal or terminal emulation progra m through the ser ial por t.

6: Setup Mode: Server Configuration

7: Setup Mode: Channel Configuration

8: Setup Mode: Advanced Settings

9: Firmware Upgrades

10: Monitor Mode

11: Troubleshooting and Contact Information

12: SDS1101 Connections and Pinouts

13: SDS2101 Connections and Pinouts

14: SDS1101 Technical Specifications

Details the network (server) settings

Details the serial port settings.

Details expert and security settings and explains how to reset the unit to factory default values.

Provides instructions for obtaining the latest firmware and updating the SDS.

Provides instructions for accessing and using the command line interface to monitor the network and diagnose problems.

Describes common problems and error messages and how to contact Lantronix Technical Support.

Provides descriptions and illust ratio ns of conne cti on hardware.

Lists technical specifications for the SDS1101.

SDS1101/2101 User Guide 9

15: SDS2101 Technical

Specifications

Lists technical specifications for the SDS2101.

A: Alternative Ways to Assign an

Provides detailed information about us ing DHC P, Au toIP,

B: Binary to Hexadecimal

Provides instructions for converting binary val ues to

SDS1101 & SDS2101 Quick Start

DeviceInstaller Online Help

Provides instructions for using the Window s-ba sed uti lity to

Com Port Redirector User Guide

1: Using This Guide

IP Address

Conversions

Additional Documentation

Visit the Lantronix web site at www.lantronix.com/support/documentation for the latest documentation and the foll o wing add it ion al doc umentation:

BOOTP ARP, and Telnet to assign an IP address.

hexadecimals.

Provides the steps for getting the SDS1101/2101 up and running.

configure the SDS1101/2101 and other Lantronix device servers.

Provides information on using the Window s-ba sed uti lity to create a virtual com port.

SDS1101/2101 User Guide 10

22:: IInnttrroodduuccttiioonn

The SDS1101 is a single-port device server and the SDS21 01 is a dual port dev ice server that provide a quick, simple, and cost-effective wa y to bring the adva ntag e s of data accessibility and remote management to devices not currently connected to a network.

Applications

The SDS family of Device Servers allows serial devices, such as those listed below, to connect and communicate over Ethernet networks using the IP protocol family (TCP for connection-oriented stream applications and UDP for datagram applications).

The SDS1100/2101 Secure Device Server offers secure data communications using Rijndael Advanced Encr yption Stan dar ds (A ES) and is certified by the National Institute of Standard and Technology (NIST) to meet Federal Information Processing Standards (FIPS) required for data communication on US government and government contractor’s networks.

 Security alarms

 Access control devices

 Fire control panels

 Time/attendance clocks and terminals

 ATM machines

 Data collection devices

 RFID readers

 Universal Power Supply (UPS) management units

 Telecommunications equipment

 Data display devices

 Virtually any asynchronous RS-232, RS422, or RS485 device

Application Examples

Using a method called serial tunneling, the SDS encapsulates serial data into packets and transports them over Ethernet. Using two SDS units, connected by a network, virtual serial connections can extend across a facility or around the world.

SDS1101/2101 User Guide 11

2: Introduction

SDS

Figure 2-1. Serial Tunneling Example

Device Servers

The Com Port Redirector software included on the product CD simplifies the integration process by extending the functionality of COM-port-based Windows™ applications. Virtual COM ports, mapped to remote device servers on the network, can replace direct serial connections.

Figure 2-2. Direct TCP/IP or Redirector Configuration

Device Server

Note: For step-by-step instructions on configuring the SDS for serial tunneling or for

use with the Com Port Redirector, see SDS Configuration Tutorials on the Lantronix web site:

www.lantronix.com/support.

SDS1101/2101 User Guide 12

Protocol Support

The SDS uses the Internet Protocol (IP) for network communications and the Transmission Control Protocol (TCP) to assure that no data is lost or duplicated and that everything sent to the connection arrives correctly at the target.

Supported protocols include:

 ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, and SNMP for

network communications.

 TCP, UDP, and Telnet for connections to the serial port.

 TFTP for firmware updates.

 IP for addressing, routing, and data block handling over the network.

 User Datagram Protocol (UDP) for typical datagram applications in which

devices interact with other devic es witho ut a point-to-point connection.

Additional Features

Modem Emulation: In modem emulation mode, the SDS can replace dial-up

modems. The unit accepts modem AT commands on the serial port and then establishes a network connection to the end device. This arrangement leverages network connections and bandwidth to eliminate dedicated modems and phone lines.

2: Introduction

Built-in Web Server: The SDS includes a built-in web server for configuring the unit and displaying operating and troubleshooting information on the attached links to online support.

Configuration Methods

After installation, the SDS requires configuration. For the unit to operate correctly on a network, it must have a unique IP address on the network. There are three basic methods for logging into the SDS and ass ign ing IP addr es ses and other configurable settings:

DeviceInstaller: Configure the IP address and other network settings on the SDS using a Graphical User Interface (GUI) on a PC attached to a network. (See Assigning the IP Address: DeviceInstaller )

Web-Manager: Through a web browser, configure the SDS settings using the Lantronix Web-Manager. (See 4: Configuration Using Web-Manager.)

Serial and Telnet Ports: Use Setup Mode, a command line interface. There are two approaches to accessing Setup Mode: making a Telnet connection to the network port (9999) or connecting a terminal (or a PC running a terminal emulation program) to the unit’s serial port. (See 5: Configuration via Telnet or Serial Port (Setup Mode).

SDS1101/2101 User Guide 13

Product Information Label

00-20-4A-14-01-18 or 00:20:4A:14:01:18

The product information label on the underside of the unit contains the following information about your specific unit:

 Bar code

 Serial number

 Product ID (name)

 Product description

 Hardware address (also referred to as the Ethernet or MAC address)

The first three bytes of the hardware address are fixed and read 00-20-4A, identif yin g the unit as a Lantronix product. The fourth, fifth, and sixth bytes are unique numbers assigned to each unit.

Figure 2-3. Sample Hardware Address

2: Introduction

SDS1101/2101 User Guide 14

33:: GGeettttiinngg SSttaarrtteedd

This chapter describes how to get your SDS up and running in the shortest possible time.

Package Contents

Verify and inspect the contents of the SDS1101/2101 package using the following list. If any item is missing or damaged, contact your place of purchase immediately.

 SDS1101 or SDS2101

 Six-foot DB9F-to-DB25M modem cable (SDS1101) or DB9F to DB9F Null

Modem Cable (SDS2101)

 Power supply

 CD with documentation and software utilities

 Fastening kit

 Quick Start Guide

SDS1101/2101 User Guide 15

Installing the SDS

Figure 3-1. SDS1101 Connected to Serial Device and Network

3: Getting Started

To install the unit: Complete the following steps in order. Refer to the numbers in the figure above.

Note: See the sections that follow for details about connectors and pinouts.

1. Connect a serial device to your unit.

2. Connect an Ethernet cable to the RJ45 port.

3. Supply power to your unit using the power supply that was included in the

packaging.

Note: The required input voltage is 9-30 VDC (center +) or 10-24 VAC

(1.5W maximum power required).

4. Supply power to the serial device.

Note: If you encounter a problem, please see LEDs for diagnostic

information.

SDS1101/2101 User Guide 16

Required Information

Before configuring the SDS, have the following information available:

Hardware Address

Take note of the unit’s hardware address (also known as the Ether net or MAC address). It is on the product label, in the format: 00-20-4a-XX-XX-XX, where the XXs are unique numbers assigned to the product (see Product Information Label).

Hardware Address: 00-20-4a-_____-_____-_____

IP Address

The SDS must have a unique IP address on your network. This address references the specific unit. By default, the unit is DHCP-enabled and automatically assigned an IP address on DHCP-enabled networks. If you are assigning a static IP address, the systems administrator generally provides the IP address, subnet mask, and gateway.

Note: The factory default IP address is 0.0.0.0 to enable DHCP, BOOTP,

and AutoIP. When the units boots, it sends a DHCP broadcast to try and get an IP address. If it receives no reply from a DHCP server, the SDS tries BOOTP. If the SDS does not receive a response from BOOTP, it reverts to an AutoIP address.

3: Getting Started

IP Address: _______ _______ _______ _______

Subnet Mask: ___

____ _______ _______ _______

Gateway: _______ _______ _______ _______

You have several options for assigning an IP address and related network settings to your unit. This chapter provides information about using the DeviceInstaller (graphical user interface) and serial port login (command line interface) methods.

Note: For information about other methods of assigning the IP address, such

as DHCP, AutoIP, ARP, and Telnet, see Alternative Ways to Assign an IP

Address.

SDS1101/2101 User Guide 17

Assigning the IP Address: DeviceInstaller

This chapter covers the steps for getting the SDS1101/2101 device server online and for viewing its current configuration.

Note: DeviceInstaller online Help provides more deta iled infor m ati on on

using DeviceInstaller.

Installing DeviceInstaller

To use the DeviceInstaller utility, first install it from the product CD.

1. Insert the product CD into your CD-ROM drive. The Lantronix DeviceInstaller

window displays.

2. If the CD does not launch automatically:

a) Click the Start button on the Task Bar and select Run.

b) Enter your CD drive letter, colon, backslash, Launch.exe (e.g.,

D:\Launch.exe).

3. Click the DeviceInstaller button.

3: Getting Started

4. Respond to the installation wizard prompts.

Assigning an IP Address

The unit’s IP address must be configured before it can work correctly on a network. The unit’s IP address is normally set to 0.0.0.0 at the factory. The hardware address is on the product label. The unit is DHCP enabled as the default.

To assign an IP address manually:

1. Click StartPrograms  LantronixDeviceInstallerDeviceInstaller. If your

PC has more than one network adapter, a message displays. Select an adapter

and click OK.

Note: If the unit already has an IP address (e.g., DHCP has assigned an

IP address), click the Search icon

Lantronix device servers on the local network.

2. Click the Assign IP icon

3. If prompted, enter the hardware address (on the product label) and click Next.

4. Select Assign a specific IP address and click Next.

5. Enter the IP address. The Subnet mask displays automatically based on the IP

address; if desired, you may change it. On a local network, you can leave the

Default gateway blank (all zeros). Click Next.

and select the unit from the list of

6. Click the Assign button and wait several seconds until a confirmation message

displays. Click Finish.

SDS1101/2101 User Guide 18

7. Select the device from the main window list and select Ping from the Tools

Name

Configurable field. A name that identifies the SDS.

Group

Configurable field. A group name to categorize the SDS.

menu. The Ping Device dialog box shows the IP address of the selected unit.

8. From the Tools menu, click the Ping button. The results display in the Status

window. Click the Clear Status button to clear the window so you can ping the

device again.

Note: If you do not receive “Reply” messages, make sure the unit is

attached to the network properly and the IP address assigned is valid for

the particular network segment you are working with. If you are not sure,

check with your systems administrator.

9. Click the Close button to close the dialog box and return to the main window.

Adding the Unit to the Manage List

Now add the unit to the list of similar Lantronix devices on the network so you can manage and configure it. To perform this step, click the Search icon .

DeviceInstaller locates the unit and adds it to the list. Now you can manage (configure) the unit so it works with the serial device on the network.

Accessing the SDS1101/2101 Using DeviceInstaller

3: Getting Started

1. Click StartPrograms  LantronixDeviceInstallerDeviceInstaller.

2. Click the SDS folder. The list of available Lantronix SDS1101 & SDS2101

devices displays.

3. Expand the list of SDS1101s or SDS2101s by clicking the + symbol next to the

SDS1101 or SDS2101 icon. Select the SDS unit by clicking on its IP address to

view its configuration.

Viewing the Current Configuration

DeviceInstaller provides a view of the unit's configuration.

To view the unit's current settings:

1. Follow the instructions above to locate the SDS1101 or SDS2101.

2. In the right pane, click the Device Details tab. The current SDS1101/2101

configuration displa ys:

Double-click the field, type in the value, and press Enter to complete. This name is not visible on other PCs or laptops using DeviceInstaller.

Double-click the field, type in the value, and press Enter to complete. This group name is not visible on other PCs or laptops using DeviceInstaller.

Comments Configurable field. Information about the SDS. Double-click

SDS1101/2101 User Guide 19

the field, type in the value, and press Enter to complete. This description or comment is not visible on other PCs or laptops using DeviceInstaller.

3: Getting Started

Device F amily

Non-configurable field. Displays the SDS1101’s and

Non-configurable field. Displays the SDS’s ID embedded

Hardware Address

Non-configurable field. Displays the SDS’s hardware (or MAC)

Firmware Version

Non-configurable field. Displays the firmware currently IP Address was obtained

Statically

Number of Ports

Non-configurable field. Displays the number of ports on the

TCP Keepalive

Non-configurable field. Displays the SDS’s TCP keepalive Telnet Enabled

Non-configurable field. Permits Telnet sessions.

Web Enabled

Non-configurable field. Permits configuration through Web-

Web Port

Non-configurable field. Displays the SDS port for Web-

Maximum Baud Rate

Non-configurable field. Displays the SDS’s max imum baud Firmware Upgradeable

Non-configurable field. Displays True, indicating the SDS’s

Non-configurable field. Displays False.

SDS2101’s device family type as SDS.

Type Non-configurable field. Displays the device type as SDS1101

or SDS2101.

within the box.

address.

installed on the SDS.

Extended Firmware

Version

Online Status Non-configurable field. Displays the SDS status as online,

IP Address Non-configurable field. Displays the SDS’s current IP address.

Subnet Mask Non-configurable field. Displays the SDS’s current subnet

Gateway Non-configurable field. Displays the SDS’s current gateway.

Number of COB partitions

supported

Non-configurable field. Displays the full version nomenclature of the firmware.

offline, unreachable (the SDS is on a different subnet), or busy (the SDS is currently performing a task).

To change the IP address, see Assigning an IP Address

mask. To change the subnet mask, see Assign ing an IP

Address.

To change the gateway, see Assigning an IP Address. Non-configurable field. Displays the number of COB partitions

supported.

SDS.

value. The value is in the range 1-65s, and the default setting is 45.

Telnet Port Non-configurable field. Displays the SDS port for telnet

Supported

Supports Configurable

Pins

SDS1101/2101 User Guide 20

sessions.

Manager.

Manager configuration.

rate. Note: The SDS1101/2101 may not currently be running at this rate.

firmware is upgradeable as newer version become available.

Supports Email Triggers

Non-configurable field. Displays False.

Supports AES Data

Stream

Non-configurable field. Displays True.

Supports 485

Non-configurable field. Displays True. The SDS supports the

Supports 920K Baudrate

Non-configurable field. Displays False for SDS1101 which Supports HTTP Server

Non-configurable field. Displays True.

Supports HTTP Setup

Non-configurable field. Displays True.

True

Non-configurable field. Displays False.

3: Getting Started

RS-485 protocol.

supports baud rates up to 230400. Displays True for

SDS2101 which supports a baud rate of 921600.

Next Step

Now that the SDS has an IP address and other initial settings, you can configure it. You have the following options:

To configure the unit using a Web browser:

1. Click the Web Configuration tab.

2. Do one of the following:

3. By default, no user and password are configured, so just press OK.

4. Continue with 4: Configuration Using Web-Manager.

Supports 230K Baud Rate

Supports GPIO

 To view the Web Manager in the current DeviceInstaller window, click the Go

Non-configurable field. Displays rate of 230400.

. SDS supports a baud

button.

 To open the Web Manager in a web browser, click the External Browser

button. The Web Manager displays. A user and password dialog box displays.

Note: To assign Security settings, you must use the Setup Mode

window in a Telnet session.

To configure the unit using a Telnet session:

1. Click the Telnet Configuration tab. The Setup Mode window displays.

2. Press Enter within 5 seconds.

3. Continue with step 4 in 5: Configuration via Telnet or Serial Port (Setup Mode).

Assigning the IP Address: Serial Port Login

To assign the IP address and other network settings using a serial connection:

1. Connect a console terminal or a PC running a terminal emulation program to the

unit's serial port. The default serial port settings are 9600 baud, 8 bits, no

parity, 1 stop bit, no flow control.

SDS1101/2101 User Guide 21

3: Getting Started

2. To enter Setup Mode, cycle the unit's power (power off and back on). After

power-up, the self-test begins and the red Diagnostic LED starts blinking. You

have one second to enter thr ee lo wer cas e x characters.

Note: The easiest way to enter Setup Mode is to hold down the x key at

the terminal (or emulation) while powering up the unit.

3. Select 0 (Server Configuration) and follow the prompts until you get to

IP address.

4. Enter the new IP address, subnet mask , and gateway (if applicable).

5. Do one of the following:

 Continue with 5: Configuration via Telnet or Serial Port (Setup Mode).

 Select 9 to save and exit Setup Mode. The unit performs a power reset.

SDS1101/2101 User Guide 22

44:: CCoonnffiigguurraattiioonn UUssiinngg WWeebb--MMaannaaggeerr

You must configure the unit so it can communicate on a network with your serial device. For example, you must set the way the unit will respo nd to ser ial and net w ork traffic, how it will handle serial packets, and when to start or close a connection.

The unit’s configuration is stored in nonvolatile memory and is retained without power. You can change the configuration at any time. The unit performs a reset after you change and store the configuration.

In this chapter, we describe how to configure the SDS using Web-Manager, Lantronix’s browser-based configuration tool. (For information on using Setup Mode, our command line configuration interface, see 5: Configuration via Telnet or Serial

Port (Setup Mode).

Note: The examples in this section show a typical device. Your device may have

different configuration options.

Accessing SDS1101/2101 Using DeviceInstaller

Note: Make note of the hardware (MAC) address. You will need it to locate

the SDS using DeviceInstaller. For more information on the hardware address, see Hardware Address.

Follow the instructions on the product CD to install and run DeviceInstaller.

1. Run DeviceInstaller and search for the list of available Lantronix device servers.

2. Click the SDS folder. The list of available SDS products displays.

3. Expand the list of SDS1101s by clicking the + symbol next to the SDS1101 icon.

Likewise, expand the list of SDS2101s by clicking the + symbol next to the

SDS2101 icon.

4. Select the specific SDS unit by clicking its hardware address.

5. In the right pane, click the Web Configuration tab.

6. To view the SDS’s Web-Manager in the current DeviceInstaller window, click the

Go button. To open the Web-Manager in a web browser, click the External

Browser button. The Web-Manager displays.

Note: Alternatively, to open Web-Manager, open your web browser and

enter the IP address of the SDS. A user and password dialog box displays. By default, no username and password are

configured.

SDS1101/2101 User Guide 23

Figure 4-1. Lantronix Web-Manager

The main menu is in the left pane of the Web-Manager window for both the SDS1101 and SDS2101.

Network Configurati on

The unit’s network values display when you select Network from the main menu. The following sections describe the conf ig urab le par ameters on the Network Settings page.

Figure 4-2. Network Settings

4: Configuration Using Web-Manager

SDS1101/2101 User Guide 24

Automatic IP Address Configuration

DHCP

Select Enable to permit the Dynamic Host Configuration

AutoIP

Select Enable to permit the SDS to generate an IP in the DHCP Host Name

Enter the name of the host on the network providing the IP

IP Address

If DHCP is not used to assign IP addresses, enter it manual ly Subnet Mask

A subnet mask defines the number of bits taken from the IP

Default Gateway

The gateway address, or router, allows communication to

An IP address can be assig ned automatically. You then enter related network settings.

To assign an IP address automatically:

1. On the main menu, click Network.

2. Select Obtain IP address automatically.

3. Enter the following (as necessary):

BOOTP Select Enable to permit the Bootstrap Protocol (BOOTP)

server to assign the IP address from a pool of addresses automatically. Enable is the default.

Protocol (DHCP) to assign a leased IP address to the SDS unit automatically. Enable is th e default.

169.254.x.x address range with a Class B subnet. Enable is the default.

4: Configuration Using Web-Manager

address.

Note: Disabling BOOTP, DHCP, and AutoIP (all thr ee chec k box es) is not

advised as the only available IP assignment method will then be ARP or serial port.

4. When you are finished, click the OK button.

5. On the main menu, click Apply Settings.

Static IP Address Configuration

You can manually assign an IP address to the unit and enter related network settings.

To assign an IP address manually:

1. On the main menu, click Network.

2. Select Use the following IP configuration.

3. Enter the following (as necessary):

in decimal-dot notation. The IP address must be set to a unique value in the network.

SDS1101/2101 User Guide 25

address that are assigned for the host part.

other LAN segments. The gateway address should be the IP address of the router connected to the same LAN segment as the unit. The gateway address must be within the local network.

Auto Negotiate

With this option, the Ethernet port auto-negotiates the speed

4. When you are finished, click the OK button.

5. On the main menu, click Apply Settings.

Ethernet Configuration

You must specify the speed and direction of data transmission.

To specify how data will be transmitted:

1. On the main menu, click Network.

2. Enter the following (as necessary):

4: Configuration Using Web-Manager

and duplex with the hardware endpoint to which it is connected. This is the default.

If this option is not selected, complete the fields that become available:

 Speed: The speed of data transmis sio n. The default

setting is 100 Mbps.

 Duplex: The direction of data transmis si on. The

default setting is Full.

3. When you are finished, click the OK button.

4. On the main menu, click Apply Settings.

Server Configuration

The unit’s server values display when you select Server from the main menu. The following sections describe the configurable parameters on the Server Settings page.

SDS1101/2101 User Guide 26

4: Configuration Using Web-Manager

Telnet Password

Enter the password required for Telnet access.

TCP Keepalive (secs)

TCP Keepalive time defines how many seconds the unit waits

Figure 4-3. Server Settings

To configure the SDS’s device server settings:

1. On the main menu, click Server.

2. Configure or modify the following fields:

Server Configuration

Retype Password Re-enter the password required for Telnet access.

Advanced

ARP Cache Timeout

(secs)

When the unit communicates with another device on the network, it adds an entry into its ARP table. ARP Cache timeout defines the number of seconds (1-600) before it refreshes this table. The default setting is 600.

during an inactive connection bef ore ch ec king its status. If the unit does not receive a response, it drops that connection. Enter a value between 0 and 60 seconds. 0 disables keepalive. The default sett ing i s 45.

SDS1101/2101 User Guide 27

4: Configuration Using Web-Manager

Monitor Mode @ Bootup

Select Disable to disable en try into the monitor mod e using

HTTP Server Port

This option allows the configuration of the web server port

the yyy or xx1 key sequence at startup. This field prevents the unit from entering monitor mode by interpreting the stream of characters that are received during the device server's initialization at startup. The d efault setting is Enable.

CPU Performance Mode

(SDS2101 Only)

MTU Size The Maximum Transmission Unit (MTU) is the largest physical

3. When you are finished, click the OK button.

4. On the main menu, click Apply Settings.

Host List Configurati on

The SDS scrolls through the host list until it connects to a device listed in the host list table. After a successful connection, the unit stops trying to connect to any others. If this connection fails, the unit continues to scroll through the table until the next successful connection.

The host list supports a minimum of 1 and a maximum of 12 entries. Each entry contains an IP address and a port number.

Note: The host list is disabled for Manual and Modem Mode. The unit does

not accept a data connection from a remote device when the hostlist option is enabled.

Select the SDS2101's performance mode. Higher performance settings require more energy . Low is 26 Mhz. Regular is 48 Mhz; High is 88 Mhz. The default is Regular.

number. The valid range is 1-65535. The default sett ing is 80.

packet size a network can transmit for TCP and UDP. Enter between 512 and 1400 byte s. T he default setting is 1400

bytes.

To configure the host list:

1. On the main menu, click Hostlist.

SDS1101/2101 User Guide 28

4: Configuration Using Web-Manager

Host Address

Enter or modify the host’s IP address.

Figure 4-4. Hostlist Settings

2. Enter or modify the following fields:

Retry Settings

Retry Counter Enter the value for the number of times the SDS should

attempt to retry connecting to the host list. The default setting is 3.

Retry Timeout Enter the duration (in seconds) the SDS should abandon

attempting a connection to the host list. The default sett ing is

250.

Host Information

Port Enter the target port number.

3. When you are finished, click the OK button.

4. On the main menu, click Apply Settings.

Channel 1 & Channel 2 (SDS2101 only) Configuration

The Channel configuration defines how the serial port responds to network and serial communication.

Serial Settings

To configure the channel’s serial settings:

SDS1101/2101 User Guide 29

4: Configuration Using Web-Manager

Disable Serial Port

When selected, disables communication through the serial

Protocol

From the drop-down menu, select the protocol type for the

Baud Rate

The unit and attached serial device, such as a modem, must

The SDS2101 also supports 460800 and 921600 baud. The

1. On the main menu, click Serial Settings (under Channel 1) to display the Serial

Settings window.

Figure 4-5. Channel Serial Settings

2. In the available fields, enter the following information:

Channel 1

port. The serial port is enabled by default.

Note: This feature is not available on single port device

servers.

Port Settings

selected channel. The default setting is RS232.

Flow Control Flow control manages data flow between devices in a network

to ensure it is processed efficiently. Too much data arriving before a device is prepared to manage it causes lost or retransmitted data. None is the default.

agree on a speed or baud rate to use for the serial connection. Valid baud rates are 300, 600, 1200, 2400, 4800, 9600 (default), 19200, 38400, 57600, 115200, and 230400 baud.

SDS1101/2101 User Guide 30

default setting is 9600.

Data Bits

Indicates the number of bits in a transmitted data package. Parity

Checks for the parity bit. The default setting is None.

Stop Bits

The stop bit follows the data and parity bits in serial

Pack Control

Enable Packing

Select to enable packing on the SDS.

Idle Gap Time

Select the maximum time for inactivity. The default time is

Match Bytes

Use to indicate the end of a series of data to be sent as one

With Active Connect

Select Yes to clear the input buffer with a connection that is With Passive Connect

Select Yes to clear the input buffer with a connection initiated

At Time of Disconnect

Select Yes to clear the input buffer when the network

4: Configuration Using Web-Manager

The default setting is 8.

communication. It indicates the end of transmission. The default setting is 1.

Two firmware-selectable packing algorithms define how and when packets are sent to the network.

The standard algorithm is optimized for applications in which the unit is used in a local environment, allowing for very small delays for single characters, while keeping the packet count low.

The alternate packing algorithm minimizes the packet count on the network and is especially useful in applications in a routed Wide Area Network (WAN). Adjusting parameters in this mode can economize the network data stream.

Disabled by default.

12 milliseconds.

Match 2 Byte Sequence Use to indicate the end of a series of data to be sent as one

group. The sequence must occur sequentially to indicate end of the data collection to the SDS. The default setting is No.

group. Set this value to 00 if specific functions are not needed.

Send Frame Only After the detection of the byte sequence, indicates whether to

send the data frame or the entire buffer. Select Yes to send only the data frame. The default setting is No.

Send Trailing Bytes Select the number of bytes to send after the end-of-sequence

characters. The default setting is None.

Flush Input Buffer (Serial to Network)

initiated from the device to the network. The default setting is No.

from the network to the device. The default setting is No.

connection to or from the device is disconnected. The default setting is No.

SDS1101/2101 User Guide 31

Flush Output Buffer (Network to Serial)

With Active Connect

Select Yes to clear the output buffer with a connection that is

At Time of Disconnect

Select Yes to clear the output buffer when the network

With Passive Connect Select Yes to clear the output buffer with a connection initiated

3. When you are finished, click the OK button.

4. On the main menu, click Apply Settings.

Connection Settings - TCP

To configure a channel’s TCP settings:

1. On the main menu, click Connection. The Connection Settings window for the

channel displays.

4: Configuration Using Web-Manager

initiated from the device to the network. The default setting is No.

from the network to the device. The default sett ing is No.

connection to or from the device is disconnected. The default setting is No.

SDS1101/2101 User Guide 32

4: Configuration Using Web-Manager

Protocol

From the drop-down menu, select TCP.

Accept I ncoming

Select Yes to accept incoming connections. The default

Password Required

Determines whether a password is required for an incoming Password

If Password Required was set to Yes, enter the password for

Figure 4-6. TCP Connection Settings

2. In the available fields, enter or modify the following information:

Connect Protocol

Connect Mode: Passive Connection

SDS1101/2101 User Guide 33

setting is Yes.

passive connection. This field is not available when a password is set for Telnet mode. The default set ting is No.

passive connections.

4: Configuration Using Web-Manager

Modem Escape Sequence

Disable or enable the unit's ability to send the escape Start Character

If Active Connect is set to With Start Character, enter the start

Modem Mode

Indicates the on-screen response type when in Modem Mode (if

Show IP Address After

Indicates whether to display the remote IP address upon

Auto increment for active

Select to auto-increment the local port number for new

Remote Port

Enter the remote port number.

Remote Host

Enter the IP address of the remote device.

Telnet Com Port Cntrl

This field is available for configuration only when Active

Terminal Name

This field is available for configuration only when Telnet Com

Pass Through

sequence. The default is Y (Yes) (send the escape sequence).

Connect Mode: Active Connection

Active Connect

Select None (default) to disable Active Connect. Otherwise, indicate the connection type from the drop-down list:

 With Any Character: Attempts to connect when any

character is received from the serial port.

 With Active Mdm Ctrl In: Accepts external connection

requests only when the Modem Control In input is asserted.

 With Start Character: Attempts to connect when it

receives a specific start character from the serial port. The default start character is carriage return.

 Manual Connection: Attempts to connect when

directed by a command string received from the serial port.

 Auto Start: Automatically connects to the remote IP

address and port after booting up.

character in this field. The default setting is 0D.

Modem Mode is enabled). The default setting is None.

Ring

connection. The default setting is Yes.

Endpoint Configuration

Local Port Enter the local port number.

connect

outgoing connections. The range of auto-incremented port numbers is 50,000 to 59,999 and loops back to the beginning when the maximum range is reached. Disabled by default.

Common Options

Connect is set to None. Select Enable to permit Telnet communication to the SDS unit. The Telnet Com Port Cntrl feature is used in conjunction with the Com Port Redirector (CPR) utility. (See the CPR online Help for details.)

SDS1101/2101 User Guide 34

Port Cntrl is set to Enable.

4: Configuration Using Web-Manager

If this option is set to True, the device server scrolls through

Select Blink for the status LEDs to blink upon connection, or

On Mdm_Ctrl_In Drop

Set to Yes for the network connection to or from the serial port When set to Yes, the TCP connection closes even if the

With EOT

Select Yes to drop the connection when Ctrl-D or Hex 04 is

Inactivity Timeout

Use this parameter to set an inactivity timeout. The unit drops

Use the terminal name for the Telnet terminal type. Enter only one name. When this option is enabled, the unit also reacts to the end of record (EOR) and binary options, which can be used for applications such as terminal emulation to IBM hosts.

Connect Response A single character is transmitted to the serial port when there

is a change in connection state. The default setting is None.

Use Hostlist

the host list until it connects to a device listed in the host list table. Once it connects, the unit stops trying to connect to any others. If this connection fails, the unit continues to scroll through the table until it connects to another IP in the host list.

The host list is disabled for Manual Mode and for Modem Mode. The unit will not accept a data connection from a remote device when the host list option is enabled.

LED

select None for no LED output. The default setting is Blink.

Disconnect Mode

Hard Disconnect

3. When you are finished, click the OK button.

4. On the main menu, click Apply Settings.

Connection Settings - UDP

To configure a channel’s UDP settings:

1. On the main menu, click Connection. The Connection Settings window for the

selected channel displays.

to disconnect (drop) when Modem Control In (DSR for SDS1101) transitions from a high state to a low state. The default setting is No.

remote site does not acknowledge the disconnect request.

detected. Both Telnet Com Port Cntrl and Check EOT (Ctrl+ D) must be enabled for Disconne ct with EOT to function properly. Ctrl+D is only detected going from the serial port to the network. The default setting is No.

the connection if there is no activity on the serial line before the set time expires. Enter time in the format mm:ss, where m is the number of minutes and s is the number of seconds. To disable the inactivity timeout, enter 00:00.

2. In the available fields, enter or modify the following information:

SDS1101/2101 User Guide 35

4: Configuration Using Web-Manager

Local Port

Enter the local port number.

Figure 4-7. UDP Connection Settings

Connect Protocol

Protocol Select UDP from the drop-down menu.

Datagram Mode

Datagram Type Configures the remote IP or network broadcast address and

Accept I ncoming Select Yes to accept incoming UDP datagrams. The default

Endpoint Configuration

SDS1101/2101 User Guide 36

the remote port. Enter 01 for directed or broadcast UDP. The default setting is 00.

setting is Yes.

Remote Port

Enter the port number of the remote device.

Remote Host

Enter the IP address of the remote device.

Use Broadcast

Select to broadcast the UDP datagram. Datagrams of type 01

Device Address Table

The table is enabled when Datagram Type is set to FD. Enter

3. When you are finished, click the OK button.

4. On the main menu, click Apply Settings.

Apply Settings

4: Configuration Using Web-Manager

can be sent as a broadcast by enabling this option. The default is not to broadcast.

Note: Datagrams are sent as subnet-directed broadcasts.

values between 1 and 255 to identify units on the local network of device servers.

Note: Lantronix Tech Support supports Datagram type 01.

Datagram Type FD is for OEM use.

1. To save and apply the configuration changes to the device server, click the

Apply Settings button.

Note: Clicking OK on each page does not change the configuration on the device.

OK tells the SDS what changes to use; Apply Settings makes the changes

permanent and reboots the SDS.

Apply Factory Defaults

1. Click the Apply Defaults button to set the device server back to the default

settings. For details see Default Settings (Option 7).

2. Click Yes to set factory settings, or click No to cancel.

SDS1101/2101 User Guide 37

55:: CCoonnffiigguurraattiioonn vviiaa TTeellnneett oorr SSeerriiaall PPoorrtt

((SSeettuupp MMooddee))

You must configure the unit so it can communicate on a network with your serial device. As an alternative to using a web browser, as described in the previous chapter, you can use the following procedures remotely or locally:

 Use a Telnet connection to configure the unit over the network.

 Use a terminal or terminal emulation program to access the serial port locally.

The series of prompts at which you enter configuration settings is called Setup Mode.

Note: Detailed information about other setup methods is available from your

Lantronix Sales Associate.

The unit’s configuration is stored in nonvolatile memory and is retained without power. You can change the configuration at any time. The unit performs a reset after the configuration has been changed and stored.

This chapter tells you how to access Setup Mode and the general procedure for using it. To complete the configuration, continue with 6: Setup Mode: Server

Configuration, 7: Setup Mode: Channel Configuration, and 8: Setup Mode: Advanced Settings.

Note: The menus in the configuration chapters show a typical device. Your

device may have different configuration options.

Accessing Setup Mode

Telnet Connection

To configure the unit over the network, establish a Telnet connection to port 9999.

Note: You can also use DeviceInstaller to access Telnet. Select the device

from the main window list, and click the Telnet Configuration tab. Skip steps 1 and 2.

To establish a Telnet connection:

1. From the Windows Start menu, click Run and type the following command,

where x.x.x.x is the IP address, and 9999 is the unit’s fixed network configuration

port number:

Windows: telnet x.x.x.x 9999

UNIX: telnet x.x.x.x 9999

2. Click OK. The following information displays.

SDS1101/2101 User Guide 38

5: Configuration via Telnet or Serial Port (Setup Mode)

Figure 5-1. MAC Add ress

3. To enter Setup Mode, press Enter within 5 seconds. The configuration settings

display, followed by the Change Setup menu.

Figure 5-2. Setup Menu Options

4. Select an option on the menu by entering the number of the option in the Your

choice ? field and pressing Enter.

5. To enter a value for a parameter, type the value and press Enter, or to confirm a

current value, just press Enter.

6. When you are finished, save the new configuration (option 9). The unit reboots.

Serial Port Connection

To configure the unit through a serial connection:

1. Connect a console terminal or PC running a terminal emulation program to your

unit's serial port. The default serial port settings are 9600 baud, 8 bits, no

parity, 1-stop bit, no flow control.

Note: The SDS always uses the above serial settings at bootup.

2. Reset the SDS unit by cycling the unit's power (turning the power off and back

on). Immediately upon resetting the device, enter three lowercase x characters

(xxx).

Note: The easiest way to enter Setup Mode is to hold down the x key at

the terminal (or emulation) while resetting the unit. You must do this

within three seconds of resettin g th e SDS.

At this point, the screen display is the same as when you use a Telnet connection. To continue, go to step 3 in Telnet Connection, above.

Exiting Setup Mode

To exit setup mode, use one of the following two o p tions:

SDS1101/2101 User Guide 39

5: Configuration via Telnet or Serial Port (Setup Mode)

 To save all changes and reboot the device, select option 9 Save and exit from

the Change Setup menu. All values are stored in nonvolatile memory.

 To exit the configuration mode without saving any changes or rebooting. select

option 8 Exit without save from the Change Setup menu.

SDS1101/2101 User Guide 40

Value

DHCP

BootP

66:: SSeettuupp MMooddee:: SSeerrvveerr CCoonnffiigguurraattiioonn

This chapter explains how to configure the network settings.

Note: Current values display in parentheses.

Server Configuration (Opt ion 0)

The unit’s basic network parameters display when you select Server configuration (option 0). The IP Address, Set Gateway IP Address, and Netmask fields display the current values.

Figure 6-1. Network Settings

IP Address : (000) .(000) .(000) .(000)

Set Gateway IP Address (N)

Netmask: Number of Bits for Host Part (0=default) (0)

Change telnet config password (N)

IP Address

If DHCP is not used to assign IP addresses, enter the IP address manually. The IP address must be set to a unique value in the network . Enter each oc tet and pr ess Enter between each section. The current value displays in parentheses.

IP Address : (000) (000) (000) (000) _

If DHCP is used, the third octet of the IP address sets the BootP/DHCP/AutoIP options. The following table shows the bits you can manually configure to force the SDS to disable AutoIP, DHCP, or BootP . To disable an option, set the appropriate bit.

Table 6-1. BootP/DHCP/AutoIP options

Options Bit

AutoIP 0 1

For example, if the third octet is 0.0.5.0, the AutoIP and BootP options are disabled; only DHCP is enabled. (The value 5 results from adding the binary equivalents of 0 and 2.) This is the most common setting when using DHCP.

Set Gateway IP Address

The gateway address, or router, allows communication to other LAN segments. The gateway address should be the IP address of the router connected to the same LAN segment as the unit. The gateway address must be within the local network. The

SDS1101/2101 User Guide 41

6: Setup Mode: Server Configuration

Network Class

Host Bits

Netmask

255.0.0.0

255.255.0.0

default setting is N (No), meaning the gateway address has not been set. To set the gateway address, type Y and enter the address.

Set Gateway IP Address (N) ? Y Gateway IP addr (000) (000) (000) (000)_

Netmask: Number of Bits f or Host Par t

A netmask defines the number of bits taken from the IP address that are assigned for the host part.

Netmask: Number of Bits for Host Part (0=default) (0) _

Note: Class A: 24 bits; Class B: 16 bits; Class C: 8 bits

The unit prompts for the number of host bits to be entered, then calculates the netmask, which appears in standard dec imal-dot notation (for example,

255.255.255.0) when the saved parameters display. The default setting is 0.

Table 6-2. Standard IP Network Netmasks

C 8 255.255.255.0

Change Telnet Configuration Password

Setting the Telnet configuration password prevents unauthorized access to the setup menu through a Telnet connection to port 9999 or through web pages. The password must have 4 characters. The default setting is N (No).

Figure 6-2. Change Telnet Configuration Password

Change telnet config password (N) ? _

An enhanced password setting (for Telnet access only) of 16 characters is available under Security Settings (Option 6).

Note: You do not need a password to access the Setup Mode window by a

serial connection.

DHCP Name

If a DHCP server has automatically assigned the IP address and network settings, you can discover the unit by using the DeviceInstaller network search feature or Monitor Mode (see 10: Monitor Mode).

Note: When you enter Monitor Mode from the serial port with network

connection enabled and issue the NC (Network Communication) command, you see the unit’s IP configuration.

SDS1101/2101 User Guide 42

6: Setup Mode: Server Configura tio n

There are three methods for assigning DHCP names to the unit.

 Default DHCP Name: If you do not change the DHCP name, and you are

using an IP of 0.0.0.0, then the DHCP name defaults to XX.XX.XX.XX (XXXXXX is the last 6 digits of the MAC address shown on the label on the bottom/side of the unit). For example, if the MAC address is 00-20-4A-12-3456, then the default DHCP name is C123456.

 Custom DHCP Name: You can create your own DHCP name. If you are using

an IP address of 0.0.0.0, then the last option in Server configuration is Change DHCP device name. This option allows you to change the DHCP name to an alphanumeric name (LTX in our example).

Change DHCP device name (not set) ? (N) Y Enter new DHCP device name : LTX

 Numeric DHCP Name: You can change the DHCP name by specifying the last

octet of the IP address. When you use this method, the DHCP name is LTXYY where YY is what you chose for the last octet of the IP address. If the IP address you specify is 0.0.0.12, then the DHCP name is LTX12. This method only works with 2 digit numbers (01-99).

SDS1101/2101 User Guide 43

77:: SSeettuupp MMooddee:: CChhaannnneell CCoonnffiigguurraattiioonn

This chapter explains how to configure the serial port.

Notes:

 Current values display in parenthesis.

 You must enter some values in hexadecimal notation. (See 0 .)

Channel 1 (Option 1) & Channel 2 (Opti on 2 on S DS 2101 only)

Select Channel 1 (option 1) or Channel 2 (option 2 on SDS2101) from the Change Setup menu to define how the serial port responds to network and serial communications. The following sections describe the configurable parameters within the Channel configur ati on menu.

Figure 7-1. Serial Port Settings

Baudrate

The unit and attached serial device, such as a modem, must agree on a speed or baud rate to use for the serial connection. Valid baud rates are 300, 600, 1200, 2400, 4800, 9600 (default), 19200, 38400, 57600, 115200, and 230400 baud. The SDS2101 also supports 460800 and 921600 baud.

Baudrate (9600) ? _

SDS1101/2101 User Guide 44

I/F (Interface) Mode

I/F Mode Option

RS-232C

(1)

7 Bit

8 Bit

Even Parity

Odd Parity

2 stop bits

(1)

Common I/F Mode Setting

Binary

Hex

The Interface (I/F) Mode is a bit-coded b yte entere d in hexadecimal notation. The default setting is 4C.

I/F Mode (4C) ? _

The following table displays available I/F Mode options:

Note: All bit positions in the table that are blank represent “don’t care” bits

for that particular option, which can be set to either a 0 or 1 value.

RS-422/485 4-wire 0 1 RS-485 2-wire 1 1

7: Setup Mode: Channel Configur at io n

Table 7-1. Interface Mode Options

(1)

Flow

No Parity 0 0

1 stop bit 0 1

2 stop bits are implemented by the software. This might influence performance.

The following table demonstrates how to build some common Interface Mode settings:

Table 7-2. Common Interface Mode Settings

RS-232C, 8-bit, No Parity, 1 stop bit 0100 1100 4C RS-232C, 7-bit, Even Parity, 1 stop bit 0111 1000 78 RS-485 2-wire, 8-bit, No Parity, 1 stop bit 0100 1111 4F RS-422, 8-bit, Odd Parity, 1 stop bit 0101 1101 5D

Flow control sets the local handshaking method for stopping serial input/output. The default setting is 00.

Flow (00) ? _

SDS1101/2101 User Guide 45

Use the following table to select flow control options:

Flow Control Option

Hex

Hardware handshake with RTS/CTS lines

XON/XOFF pass characters to host

Port Numbers

Reserved for

1 – 1024

Reserved (well known ports)

Port Number

The setting represents the source port number in TCP connections. It is the number that identifies the channel for remote initiating connections.

Port No (10001) ? _

The default setting for Port 1 is 10001, and for Port 2 is 10002 (SDS2101 only). The range is 1-65535, except for the following reserved port numbers:

7: Setup Mode: Channel Configur at io n

Table 7-3. Flow Control Options

No flow control 00 XON/XOFF flow control 01

Table 7-4. Reserved Port Numbers

9999 Telnet setup 14000-14009 Reserved for Redirector 30704 Reserved (77F0h) 30718 Reserved (77FEh)

Warning: We recommend that you not use the reserve d p o rt numbers

for this setting as incorrect operation may result.

Use Port 0 for the outgoing local port to change with each connection. The port range is 50,000-59,999. Each subsequent connection increments the number by 1 (it wraps back around to 50,000).

Only use this automatic port increment feature to initiate a connection using T C P. Set the port to a non-zero value when the unit is in a passive mode or when using UDP instead of TCP.

Connect Mode

Connect Mode defines how the unit makes a connection, and how it reacts to incoming connections over the network.

ConnectMode (C0) ? _

Enter Connect Mode options in hexadecimal notation. The default setting is C0.

Note: All bit positions in the table that are blank represent “don’t care” bits for

that particular option, which can be set to either a 0 or 1 value.

SDS1101/2101 User Guide 46

7: Setup Mode: Channel Configur at io n

Connect Mode Option

7 6 5 4 3 2 1

Never accept incoming

0 0 0

Accept with DTR Active

0 1 0 Always Accept

1 1 0

No active startup

0 0 0 0 With any character

0 0 0

With DTR Active

0 0 1

With a specific start character

0 0 1 1 Manual connection

0 1 0

Autostart

0 1 0

No Echo

0 0 1 1

Data Echo & Modem Response

Data Echo & Modem Response Modem Response Only (Numeric)

0 0 1 1 1 1 Modem Response Only (Verbose)

0 0 1 1 1

Never Accept Incom ing

Rejects all external connection attempts.

Accept with DTR Active

Accepts external connection requests only when the DTR input Always Accept

Accepts any incoming connection when a connection is not

Table 7-5. Connect Mode Options

a) Incoming Connection

b) Response Nothing (quiet) 0 Character response (C=connect,

D=disconnect, N=unreachable) c) Active Startup

Hostlist 0 0 1 0 d) Datagram Type

Directed UDP 1 1 0 0 e) Modem Mode

(Numeric)

0 1 1 1 1

(Verbose)

a) Incoming Connection

SDS1101/2101 User Guide 47

0 1 1 1 0

is asserted. Cannot be used with Modem Mode.

already established. Default setting.

b) Response

Character Response

A single character is transmitted to the serial port when there is a

No Active Startup

Does not attempt to initiate a connection under any

With DTR Active

Attempts to connect when the DTR input changes from not

With a Specific Start

Attempts to connect when it receives a specific start character

c) Active Startup

With Any Character Attempts to connect when any character is received from the

7: Setup Mode: Channel Configur at io n

change in connection state: C = connected, D = disconnected, N = host unreachable. This option is overridden when the Active Start Modem Mode or

Active Start Host List is in effect. Default setting is Nothing (quiet).

circumstance. Default setting.

serial port.

asserted to asserted.

Character Manual Connection Attempts to connect when directed by a command string

from the serial port. The default start character is carriage return.

received from the serial port. The first character of the command string must be a C (ASCII 0x43), and the last character must be either a carriage return (ASCII 0x0D) or a line feed (0x0A). No blanks or space characters may be in the command string. Between the first and last command string characters must be a full or partial destination IP address and may be a destination port number.

The IP address must be in standard decimal-dot notation and may be a partial address, representing the least significant 1, 2, or 3 bytes of the remote IP address. The period is required between each pair of IP address numbers.

If present, the port number must follow the IP address, must be presented as a decimal number in the range 1-65535, and must be preceded by a forward slash (ASCII 0x2F). The slash separates the IP address and the port number. If you omit the port number from a command string, the internally stored remote port number starts a connection.

If a partial IP address is presented in a command string, it is interpreted to be the least significant bytes of the IP address and uses the internally stored remote IP address to provide the most significant bytes of the IP address. If the IP address entered is

0.0.0.0/0, the device server enters Monitor Mode.

For example, if the remote IP address already config ured in the unit is 129.1.2.3, then an example command string would be C3/7. (This would connect to 129.1.2.3 and port 7.) You may also use a different ending for the connection string. For example, C50.1/23 would connect you to 129.1.50.1 and port 23.

SDS1101/2101 User Guide 48

7: Setup Mode: Channel Configur at io n

Command String

Result if remote IP is 129.1.2.3 and remote port is 1234

Complete override; connection is started with host 121.2.4.5,

Autostart (Automatic

If you enable Autostart, the unit automatically connects to the

Table 7-6. Manual Connection Address Example

C121.2.4.5/1

C5 Connects to 129.1.2.5, port 1234. C28.10/12 Connects to 129.1.28.10, port 12. C0.0.0.0/0 Enters Monitor Mode.

port 1.

Connection)

Hostlist If you enable this option, the device server scrolls through the

remote IP address and remote port specified when the firmware starts.

hostlist until it connects to a device listed in the hostlist table. Once it connects, the unit stops trying to connect to any others. If this connection fails, the unit continues to scroll through the table until it is able to connect to another IP in the hostlist.

Hostlist supports a minimum of 1 and a maximum of 12 entries. Each entry contains the IP address and the port number.

The hostlist is disabled for Manual and Modem Modes. The unit does not accept a data connection from a remote device when the hostlist option is enabled.

SDS1101/2101 User Guide 49

7: Setup Mode: Channel Configur at io n

Figure 7-2. Hostlist Option

SDS1101/2101 User Guide 50

To enable the hostlist:

Without Echo

In Modem Mode, echo refers to the echo of all of the characters

1. Enter a Connect Mode of 0x20 (2X), where X is any digit. The menu shows you

a list of current entries already defined in the product.

2. To delete, modify, or add an entry, select Yes. If you enter an IP address of

0.0.0.0, that entry and all others after it are deleted.

3. After completing the hostlist, repeat the previous step if necessary to edit the

hostlist again.

4. For Retrycounter, enter the number of times the Lantronix unit should try to

make a good network connection to a hostlist entry that it has successfully

ARPed. The range is 1-15, with the default set to 3.

5. For Retrytimeout, enter the number of seconds the unit should wait before

failing an attempted connection. The time is stored as units of milliseconds in the

range of 10-65535. The default setting is 250.

d) Datagram Type

Directed UDP When selecting this option, you are prompted for the Datagram type.

7: Setup Mode: Channel Configur at io n

Enter 01 for directed or broadcast UDP. Datagrams of type 01 can be sent as a broadcast by enabling the Send as Broadcast option. The default is not to broadcast.

Note: Datagrams are sent as subnet-directed broadcasts.

When the UDP option is in effect, the unit never attempts to initiate a TCP connection because it uses UDP datagrams to send and receive data.

e) Modem Mode

In Modem (Emulation) Mode, the unit presents a modem interface to the attached serial device. It accepts AT-style modem commands and handles the modem signals correctly.

Normally, there is a modem connected to a local PC and a modem connected to a remote machine. A user must dial from the local PC to the remote machine, accumulating phone charges for each connection. Modem Mode allows you to replace modems with SDSs, and to use an Ethernet connection instead of a phone call. By not having to change communications applications, you avoid potentially expensive phone calls.

To select Modem Mode, set the Connect Mode to C6 (no echo), D6 (echo with full verbose), D7 (echo with numeric response), CF (modem responses only, numeric response), or CE (modem responses only, full verbose).

Note: If the unit is in Modem Mode, and the serial port is idle, the unit can still accept network TCP connections to the serial port if C on nect Mode is set to C6 (no echo), D6 (echo w ith full verb os e) , D7 (echo with numeric response, CF (modem responses only, numeric response), or CE (modem responses only, full verbose).

entered in command mode; it does not mean to echo data that is

SDS1101/2101 User Guide 51

7: Setup Mode: Channel Configur at io n

transferred. Quiet Mode (without echo) refers to the modem not

Message

Meaning

Command was executed without error.

NO CARRIER

A network connection has been closed.

A remote device, having IP address n.n.n.n, is connecting to this Numeric Response

Connected

Ring

Error

sending an answer to the commands received (or displaying what was typed).

Data Echo & Modem Response

Modem Responses Only

Full Verbose: The unit echoes mode m comman ds and resp o nds to a command with a message string shown in the table below.

Numeric Response: The unit echoe s mode m comman ds and responds to a command with a numeric response.

Full Verbose: The unit does not echo modem commands and responds to a command with a message string shown in the table below.

Numeric Response: The unit does not echo modem commands and responds to a command with a numeric response.

Table 7-7. Modem Mode Messages

Full Verbose

CONNECT A network connection has been established.

RING n.n.n.n.

device.

0 OK

3 No Carrier

Received commands must begin with the two-character sequence AT and be terminated with a carriage return character.

The unit ignores any character sequence received not s tar ting wit h AT, and only recognizes and processes singl e AT-style commands. The unit treats compound AT commands as unrecognized commands.

If the Full Verbose option is in effect, the unit responds to an unrecognized command string that is otherwise formatted correctly (begins with AT and ends with carriage return) with the "OK" message and takes no further action.

If the Numeric Response option is in effect, the unit responds to an unrecognized command string that is otherwise formatted correctly with a "0" message and takes no further action.

SDS1101/2101 User Guide 52

7: Setup Mode: Channel Configur at io n

Modem Mode Command

Function

Enables or disables connections from the network going to the serial

Enables numeric response or full verbose.

When an active connection is in effect, the unit transfers data and does not process commands received from the serial interface.

When a connection is terminated or lost, the unit reverts to command mode. When an active connection is in effect, the unit terminates the connection if it

receives the following sequence from the attached serial device:

 No serial data is received for one second.

 The character sequence +++ is received, with no more than one second

between each two characters.

 No serial data is received for one second after the last + character. At this time,

the unit responds affirmatively per the selected echo/response mode.

 The character string ATH is received, terminated with a carriage return. The

unit responds affirmatively according to the selected echo/response mode and drops the network connection. The serial interface reverts to accepting command strings.

If this sequence is not followed, the unit remains in data transfer mode.

Table 7-8. Modem Mode Commands

ATDTx.x.x.x,pppp or ATDTx.x.x.x/pppp

ATDTx.x.x.x

ATD0.0.0.0

ATD

ATDx.x.x.x

ATH Hangs up the connection (Entered as +++ATH ).

ATS0=n

ATEn

Makes a connection to an IP address (x.x.x.x) and a remote port number (pppp).

Makes a connection to an IP address (x.x.x.x) and the remote port number defined within the unit.

Forces the unit into Monitor Mode if a remote IP address and port number are defined within the unit.

Forces the unit into Monitor Mode if a remote IP address and port number are not defined within the unit.

Makes a connection to an IP address (x.x.x.x) and the remote port number defined within the unit.

port. n=0 disables the ability to make a connection from the network to the

serial port. n=1-9 enables the ability to make a connection from the network to

the serial port. n>1-9 is invalid.

Enables or disables character echo and responses. n=0 disables character echo and responses. n=1 enables character echo and responses.

ATVn

SDS1101/2101 User Guide 53

n=0 enables numeric response. n=1 enables full verbose.

7: Setup Mode: Channel Configur at io n

Note: The unit recognizes these AT commands as single commands such as

ATE0 or ATV1; it does not recognize compound commands such as ATE0V.

Send the Escape Sequence (+++) i n Mode m M ode

Send ‘+++’ in Modem Mode (Y) ? _

Disable or enable the SDS’s ability to send the escape sequence. The default setting is Y (Yes) (send the escape sequence).

Show IP addr after 'RING'

Show IP addr after ‘RING’ <Y> ?

Disable or enable the SDS's ability to show the IP address after RING in Modem Mode. The default is Y (Yes), to show the IP address.

Auto Increment Source Port

Auto increment source port (N) ? _

Y (Yes) auto increment the source port. The SDS increments the port number used with each new connection.

Remote IP Address

This is the destination IP address used with an outgoing connection.

Remote IP Address : (000) (000) (000) (000)_

Note: This option does not display when Hostlist is enabled from the

ConnectMode prompt (see Connect Mode for more information).

Remote Port

You must set the remote TCP port number for the unit to make outgoing connections. This parameter defines the port number on the target host to which a connection is attempted.

Remote Port (0) ? _

To connect an ASCII terminal to a host using the unit for login purposes, use the remote port number 23 (Internet standard port number for Telnet services).

Note: This option does not display when Hostlist is enabled from the

ConnectMode prompt (see Connect Mode for more information).

DisConnMode

This setting determines the conditions under which the unit will cause a network connection to terminate. The default setting is 00.

SDS1101/2101 User Guide 54

7: Setup Mode: Channel Configur at io n

Disconnect Mode Option

7 6 5

3 2 1

Disconnect with Modem Control In drop

(6)

Ignore DTR

(1)

(2)

(3)

Disable hard disconnect

(4)

(5)

DisConnMode (00) ? _

Notes:

 In DisConnMode (Disconnect Mode), DTR drop either drops the connection or

is ignored.

 All bit positions in the table that are blank represent “don’t care” bits for that

particular option, which can be set to either a 0 or 1 value.

Table 7-9. Disconnect Mode Options

Telnet Com Port Cntrl and terminal type setup Channel (port) password Hard disconnect

State LED off with connection Disconnect with EOT (^D)

(1) The Telnet Com Port Control feature is used in conjunction with Com Port Redirector.

The SDS sends the "Termi nal Type" upon an outgoing connection. (2) A password is required for a connection to the serial port from the network. (3) The TCP connection closes even if the remote site does not acknowledge the

disconnection. (4) When there is a network connection to or from the serial port, the stat e LED turns off

instead of blinking. (5) When Ctrl+D or Hex 04 is detected, the connection is dropped. Both Teln et Com

Port Cntrl and Disconnect w ith EOT must be enabled for Disconnect with EOT to

function properly. Ctrl+D is onl y detected going from the serial port to the network. (6) When Modem Control In t ransitions from a high state to a low state, the network

connection to or from the serial port drops.

Flush Mode (Buffer Flushing)

Using this parameter, you can control line handling and network buffers with connection startup and disconnect. The default setting is 00.

FlushMode (00) ? _

You can also select between two different packing algorithms.

Note: All bit positions in the table that are blank represent “don’t care” bits for

that particular option, which can be set to either a 0 or 1 value.

SDS1101/2101 User Guide 55

7: Setup Mode: Channel Configur at io n

Function

7 6 5 4 3

2 1 0

Input Buffer (Serial to Network)

Clear with a connection initiated from the network to the device

1 Clear when the network connection to or from the device is disconnected

Clear with a connection initiated from the device to the network

Clear with a connection initiated from the network to the device

Alternate Packing Algorithm (Pack Control)

Enable

Option

Packing Interval

None

One

Two

Table 7-10. Flush Mode Options

Clear with a connection initiated from the devic e to the netw or k 1

Output Buffer (Network to Serial)

Clear when the network connection to or from the device is disconnected 1

Pack Control

The packing algorithms define how and when packets are sent to the network. The standard algorithm is optimized for applications in which the unit is used in a local environment, allowing for very small delays for single characters, while keeping the packet count low. The alternate packing algorithm minimizes the packet count on the network and is especially useful in applications in a routed Wide Area Network (WAN). Adjusting parameters in this mode can economize the network data stream.

Pack control settings are enabled in Flush Mode. Set this value to 00 if you do not need specific functions.

Note: All bit positions in the table that are blank represent “don’t care” bits for

that particular option, which can be set to either a 0 or 1 value.

Table 7-11. Pack Control Options

Interval: 12 msec 0 0 Interval: 52 msec 0 1 Interval: 250 msec 1 0 Interval: 5 sec 1 1

Trailing Characters

Send Characters

SDS1101/2101 User Guide 56

Option

2-Byte Send Character Sequence

Send Immediately After Send chars

Packing Interval

Packing Interval defines how long the unit should wait before sending accumulated characters. This wait period is between successive network segments containing data. For alternate packing, the default interval is 12 ms.

Trailing Characters

In some applications, CRC, Checksum, or other trailing characters follow the end-ofsequence character; this option helps to adapt frame transmission to the frame boundary. The default setting is 00 (none).

Send Characters

 If 2-Byte Send Character Sequenc e is enabled, the unit interprets the

sendchars as a 2-byte sequence; if this option is not enabled, the unit interprets them independently. The default setting is 0 (disabled).

7: Setup Mode: Channel Configur at io n

 If Send Immediately After Characters is not set, any characters already in

the serial buffer are included in the transmission after a "transmit" condition is found. If this option is set, the unit sends immediately after recognizing the transmit condition (sendchar or timeout). The default setting is 0.

Note: A transmission might occur if status information needs to be

exchanged or an acknowledgment needs to be sent.

DisConnTime (Inacti vi ty Timeout)

Use this parameter to set an inactivity timeout. The unit drops the connection if there is no activity on the serial line before the set time expires. Enter time in the format mm:ss, where m is the number of minutes and s is the number of seconds.

DisConnTime (00:00) ?:

To disable the inactivity timeout, enter 00:00. Range is 0 (disabled) to 5999 seconds (99 minutes, 59 seconds). Default setting is 0.

Send Characters

Enter up to two characters in hexadecimal representation in sendchar.

SendChar 1 (00) ? _ SendChar 2 (00) ? _

If the unit receives a character on the serial line that matches one of these characters, it sends the character immediately, along with any awaiting characters, to the TCP connection. This action minimizes the response time for specific protocol characters on the serial line (for example, ETX, EOT). Setting the first sendchar to 00

SDS1101/2101 User Guide 57

disables the recognition of the characters. Alternatively, the unit can interpret two characters as a sequence (see Pack Control). The default setting is 00.

Telnet Terminal Type

This parameter displays only if you enabled the terminal type option in Disconnect Mode. With this option enabled, you can use the terminal name for the Telnet terminal type. Enter only one name.

With terminal type option enabled, the unit also reacts to the EOR (end of record) and binary options, useful for applications like terminal emulation to IBM hosts.

Channel (Port) Password

This parameter appears only if the channel (port) password option is enabled in Disconnect Mode. With this option enabled, you can set a password on the serial port. The default setting is all 0s.

7: Setup Mode: Channel Configur at io n

SDS1101/2101 User Guide 58

88:: SSeettuupp MMooddee:: AAddvvaanncceedd SSeettttiinnggss

Expert Settings (Option 5)

Note: You can change these settings using Telnet or serial connections, but

not all of them are available on the Web-Manager.

Caution: Changing the expert settings can drastically affect the

performance and access to the product. These settings should only be changed by an experienced network administrator.

Figure 8-1. Expert Settings

This option allows you to change how many seconds the unit waits during a silent connection before attempting to see if the currently connected network device is still on the network. If the unit gets no response, it drops that connection. The default setting is 45.

TCP Keepalive time in s (1s – 65s; 0s=disable): (45)? _

ARP Cache timeout in seconds

Whenever the unit communicates with another device on the network, it adds an entry into its ARP table. The ARP Cache timeout option allows you to define how many seconds (1-600) the unit will wait before timing out this table. The default setting is 600.

ARP Cache timeout in s (1s – 600s): (600)? _

CPU Performance (SDS2101 only)

Select the SDS2101’s performance mode. Higher performance settings require more energy. Low is 26 Mhz; Regular is 48 Mhz; High is 88 Mhz. The default is Regular.

CPU performance (0=Regular, 1=Low, 2=High): (0)

Disable Monitor Mode at bootup

This option allows you to disable all entries into Monitor Mode during startup, except for the ‘xxx’ sequence. This prevents entry using yyy, zzz, xx1, and yy1 key

SDS1101/2101 User Guide 59

sequences (only during the bootup sequence). The default for Disable Monitor Mode at bootup is N (No). (See 10: Monitor Mode.)

Monitor Mode @ bootup : enabled

HTTP Port Number

This option allows the configuration of the web server port number. The valid range is 1-65535. The default HTTP port number is 80.

HTTP Port Number : (80) ? _

MTU Size

The Maximum Transmission Unit (MTU) is the largest physical packet size a network can transmit for TCP and UDP. Enter between 512 and 1400 bytes. The default setting is 1400 bytes.

MTU Size: (1400) ? _

Enable alternate MAC

8: Setup Mode: Advanced Settings

If necessary, enable the alternate MAC address (if specified in the OEM setup record). The default setting is N (No).

Enable alternate MAC (N) ? _

Ethernet connection type

The SDS allows for the Ethernet speed and duplex to be manually configured. Enter 0 for auto-negotiation (default). To select the speed and duplex, enter one of the following: 2 (10Mbit/half duplex), 3 (10Mbit/full duplex), 4 (100Mbit/half duplex), or 5 (100Mbit/full duplex).

Ethernet connection type: (0) ? _

Security Settings (Option 6)

You can change security settings by means of Telnet or serial connections only, not on the Web-Manager. We recommend that you set security over the dedicated network or over the serial setup to prevent eavesdropping.

Caution: Disabling both Telnet Setup and Port 77FE will prevent users

from accessing the setup menu from the network. Disabling Port 77FE also disables the Web from configuring th e device.

Select 6 to configure security settings.

SDS1101/2101 User Guide 60

Disable SNMP (N) ? SNMP Community Name (public): Disable Telnet Setup (N) ?

Disable TFTP Firmware Update (N) ? Disable Port 77FEh (N) ? Disable Web Server (N) ? Disable Web Setup (N) ? Disable ECHO ports (Y) ? Enable Encryption (N) ?

Enable Enhanced Password (N) ?

Disable SNMP

This setting allows you to disable the SNMP protocol on the unit for security reasons. The default setting is N (No).

8: Setup Mode: Advanced Settings

Figure 8-2. Security Settings

Disable SNMP (N) ?

SNMP Community Name

The SNMP Community Name is a required field for NMS to read or write to a device. Enter a string of 1 to 13 characters. The default setting is public.

SNMP Community Name (public):

The default entry is public. The current value is displayed in parentheses.

Disable Telnet Setup

Note: If you choose to disable this option, keep in mind that disabling both

Telnet Setup and Port 77FE will prevent users from accessing the setup menu from the network.

This setting defaults to the N (No) option. The Y (Yes) option disables access to Setup Mode by Telnet (port 9999). It only allows access locally using the web pages and the serial port of the unit.

Disable Telnet Setup (N) ?

Disable TFTP Firmware Update

This setting defaults to the N (No) option. The Y (Yes) option disab les t he use of TFTP to perform network firmware upgrades. With this option, you can download firmware upgrades over the serial port using DeviceInstaller’s Recover Firmware procedure. (See 9: Firmware Upgrades.)

Disable TFTP Firmware Update (N) :

SDS1101/2101 User Guide 61

Disable Port 77FE (Hex)

Note: If you choose to disable this option, keep in mind that disabling both

Telnet Setup and Port 77FE will prevent users from accessing the setup menu from the network.

Port 77FE is a setting that allows DeviceInstaller, Web-Manager, and custom programs to configure the unit remotely. You may wish to disable this capability for security purposes.

Disable Port 77FEh (N) ?

The default setting is the N (No) option, which enables remote configuration. You can configure the unit by using DeviceInstaller, web pages, Telnet, or serial configuration.

The Y (Yes) option disables remote configuration and web sites.

Disable Web Server

This setting defaults to the N (No) option. The Y (Yes) option disables the web server.

Disable Web Server (N) ?

8: Setup Mode: Advanced Settings

Disable Web Setup

The Y (Yes) option disables configuration using the Web-Manager. This setting defaults to the N (No) option.

Disable Web Setup (N) ?

Disable ECHO Ports

This setting controls whether port 7 echoes characters it receives. The default setting is Y (Yes), which disables ECHO ports.

Disable ECHO ports (Y) ?

Enable Enhanced Password

This setting defaults to the N (No) option, which allows you to set a 4-character password that protects Setup Mode by means of Telnet and web pages. The Y (Yes) option allows you to set an extended security password of 16-characters for protecting Telnet and Web Page access.

Enable Enhanced Password (N) ?

Enable Encryption

Rijndael is the block cipher algorithm chosen by the National Institute of Science and Technology (NIST) as the Advanced Encryption Standard (AES) to be used by the US government. The SDS supports 128-, 192-, and 256-bit encryption key lengths.

NOTE: Configuring encryption should be done through a local connection to

the serial port of the SDS, or via a secured network connection. Initial

SDS1101/2101 User Guide 62

8: Setup Mode: Advanced Settings

configuration information including the encryption key are sent in clear text over the network.

To configure AES encryption on the SDS:

Figure 8-3. Encryption Keys

1. When prompted to enable encryption, press Y.

2. Enter the encryption key length when prompted. The SDS supports 128-, 192-, and 256-bit encryption key lengths.

3. When prompted to change keys, press Y.

4. At the Enter Keys prompts, enter your encryption key. The encryption keys are entered in hexadecimal. The hexadecimal values are echoed as asterisks to prevent onlookers from seeing the key. Hexadecimal values are 0-9 and A-F.

 For a 128-bit key length, enter 32 hexadecimal characters.  For a 192-bit key length, enter 48 hexadecimal characters.  For a 256-bit key length, enter 64 hexadecimal characters

5. Continue pressing Enter until you return to the Change Setup menu.

6. At the Change Setup menu, select option 9 to save and exit.

Encryption only applies to the port selected for data tunneling (default 10001), regardless of whether you are using TCP or UDP.

Generally, one of these situations applies:

 Encrypted SDS-to-SDS communication. Be sure to configure both SDS

devices with the same encryption key.

 Third-party application to SDS-encrypted communication: SDS uses standard

AES encryption protocols. To communicate successfully, products and applications on the peer side must use the same protocols and the same encryption key as the SDS. Developers can license the Lantronix Encryption Library suite.

 Lantronix Secure Com Port Redirector provides an encrypted connection from

Windows-based applications to the SDS. A 30-day trial version of SCPR is included on the CD.

NOTE: For more information about the Lantronix Encryption Library Suite

and SCPR see

SDS1101/2101 User Guide 63

www.lantronix.com/device-networking/utilities-tools/.

Baudrate

9600

Own TCP port number

10001

Connect Mode

C0 (always accept incoming connection; no active Hostlist retry counter

Start character for serial channel 1

0x0D (CR)

Baudrate

9600

I/F Mode

4C (1 stop bit, no parity, 8 bit, RS-232C)

Connect Mode

C0 (always accept incoming connection; no active Hostlist retry counter

Hostlist retry timeout

250 (msec)

All other parameters

ARP Cache timeout in s

600

Disable Monitor Mode @ bootup

Default Settings (Option 7 )

Select 7 to reset the unit’s Channel 1 configuration and expert settings to the default settings. The server configuration settings for IP address, gateway IP address, and netmask remain unchanged. The configurable pins’ settings also remain unchanged. The specific settings that this option changes are listed below:

Channel 1 Configuration Defaults

I/F Mode 4C (1 stop bit, no parity, 8 bit, RS-232C)

Hostlist retry timeout 250 (msec)

8: Setup Mode: Advanced Settings

connection startup)

All other parameters 0

Channel 2 Configuration Defaults (SDS2101 only)

Own TCP port number 10002

connection startup)

Start character for serial channel 2 0x0D (CR)

Expert Settings Defaul ts

TCP Keepalive time in s 45

HTTP Port Number 80

SDS1101/2101 User Guide 64

(1-65535)

MTU Size (512 – 1400)

0 (resulting in an operational value of 1400)

Enable alternate MAC No ( for OEM use only)

Ethernet Connection Type

0 (auto-negotiate)

SNMP community name

public

Disable Telnet setup

Disable Port 77FEh

Disable Web Server

Disable ECHO ports

Yes

Enable Enhanced Password

Security Settings Defaults

Disable SNMP No

Disable TFTP Firmware Update No

Disable Web Setup No

8: Setup Mode: Advanced Settings

Enable Encryption No

SDS1101/2101 User Guide 65

ROM File

COB

SDS2101_6500.rom

SDS2101_webm_1600.cob

99:: FFiirrmmwwaarree UUppggrraaddeess

Obtaining Firmware

You can obtain the most up-to-date firmware and release notes for the unit from the Lantronix web site (

ftp.lantronix.com).

(

Reloading Firmware

There are several ways to update the unit's internal operational code (*.ROM): using DeviceInstaller (the preferred way), using TFTP, or using the serial port. You can also update the unit's internal Web interface (*.COB) using TFTP or DeviceInstaller.

Here are typical names for those files. Check the Lantronix web site for the latest versions and release notes.

SDS1101_6102.rom SDS1101_webm_1404.cob

Please refer to the DeviceInstaller online Help for information about reloading firmware using DeviceInstaller. The other methods are discussed below.

www.lantronix.com) or by using anonymous FTP

Table 9-1. Firmware Files

Using TFTP: Graphical User Interface

To download new firmware from a computer:

1. Use a TFTP client to send a binary file to the unit (*.ROM to upgrade the unit's internal operational code and *.COB to upgrade its internal Web interface).

Note: TFTP requires the .ROM (binary) version of the unit's internal

operational code.

2. In the TFTP server field, enter the IP address of the unit being upgraded.

3. Select Upload operation and Binary format.

4. Enter the full path of the firmware file in the Local file name field.

5. In the Remote file name field, enter the current internal operational code (D3 for SDS1101 or D4 for SDS2101) or WEB1 for the internal Web interface.

6. Click the Upload Now button to transfer the file to the unit.

SDS1101/2101 User Guide 66

9: Firmware Upgrades

Figure 9-1. TFTP Window

After the firmware has been loaded and stored (approximately 8 seconds to complete) the unit performs a power reset.

Using TFTP: Command Line Interface

To download new firmware from a computer, enter the following from a TFTP command line interface:

tftp –i <ip address> put <local filename> <destination file name>

The following examples demonstrate the TFTP command sequence to download the .rom file and the .cob file:

SDS1101

tftp –i 192.168.1.111 put SDS1101_6102.rom D3 tftp –i 192.168.1.111 put SDS1101_webm_1404.cob WEB1

SDS2101

tftp –i 192.168.1.121 put SDS2101_6500.rom D4 tftp –i 192.168.1.121 put SDS2101_webm_1600.cob WEB1

Recovering the Firmware Using the Serial Port and DeviceInstaller

If for some reason the firmware is damaged, you can recover the firmware file by using DeviceInstaller to download the *.ROM file over the serial port.

To recover firmware:

1. Start DeviceInstaller. If your PC has more than one network adapter, a message displays. Select an adapter and click OK.

SDS1101/2101 User Guide 67

9: Firmware Upgrades

2. From the Tools menu, select Advanced/Recover Firmware. The Serial Port Firmware Upgrade window displ a ys.

3. For Port on PC, enter the COM port on the PC that is connected to the serial port of the Lantronix unit.

4. For Device Model, be sure the appropriate device (e.g. SDS1101) displays.

5. For Firmware File, click the Browse button and go to the location where the firmware file resides.

Note: Make sure the SDS1101/2101 on which you are recovering firmware is

connected to this selected port on your PC.

6. Click OK to download the file.

7. When prompted, reset the device. Status messages and a progress bar at the bottom of the screen show the progress of the file transfer. When the file transfer completes, the message “Successful, Click OK to Close” displays.

8. Click the OK button to complete this procedure.

SDS1101/2101 User Guide 68

1100:: MMoonniittoorr MMooddee

Monitor Mode is a command-line interface used for diagnostic purposes. There are two ways to enter Monitor Mode: locally using the serial port or remotely

using the network.

Entering Monitor Mode Using the Serial Port

To enter Monitor Mode locally:

1. Follow the same steps used for setting the serial configuration parameters (see Serial Port).

2. Instead of typing three x keys, however: a) Type zzz (or xx1) to enter Monitor Mode with network connections. b) Type yyy (or yy1) to enter Monitor Mode without network connections.

A 0> prompt indicates that you have successfully entered Monitor Mode.

Entering Monitor Mode Using the Network Port

To enter Monitor Mode using a Telnet connection:

1. Establish a Telnet session to the configuration port (9999). The following is an example of the message that appears:

2. Type M (upper case) immediately. A 0> prompt indicates that you have successfully entered Monitor Mode.

Monitor Mode Commands

The following commands are available in Monitor Mode. Many commands have an IP address as an optional parameter (xxx.xxx.xxx.xxx). If you enter the IP address, the command is applied to another unit with that IP address. If you do not enter the IP address, the command is executed locally.

Note: All commands must be in capital letters. Responses to some of the

commands are in Intel Hex format.

SDS1101/2101 User Guide 69

10: Monitor Mode

Command

Command Name

Function

ARP Table

Shows the unit’s ARP table entries.

TCP Connection Table

Shows all incoming and outgoing TCP connections.

Network Connection

Shows the unit’s IP configuration.

Reset

Resets the unit’s power.

Set Security record

Sets the Security record without the encryption key and NS

Network Status

Reports the network interfaces ’ status es. Inc lud es pote ntia lly

Response

Meaning

OK; no error

No answer from remote device

Wrong parameter(s)

Invalid command

Table 10-1. Monitor M ode Commands

VS x.x.x.x Version Queries software header record (16 bytes) of unit with IP

address x.x.x.x.

GC x.x.x.x Get Configuration Gets configuration of unit with IP address x.x.x.x as hex

records (120 bytes).

SC x.x.x.x Send Configuration Sets configuration of unit with IP address x.x.x.x from hex

records.

PI x.x.x.x Ping Pings unit with IP address x.x.x.x to check device status.

QU Quit Exits diagnostics mode.

G0, G1, ....,Ge, Gf Get configuration from

memory page

S0, S1,...,Se, Sf Set configuration to

memory page

GM Get MAC address Shows the unit's 6-byte MAC address.

Gets a memory page of configuration information from the device.

Sets a memory page of configuration information on the device.

length parameters. The entire record must still be written, but the encryption-specific bytes do not need to be provided (they can be null since they are not overwr itten).

negotiated parameters like speed/duplex for Ethernet or BSSID, encryption, authentication for wireless interfaces.

Note: Entering any of the commands listed above generates one of the

following command response codes:

Table 10-2. Command Response Codes

2> Cannot reach remote device or no answer

SDS1101/2101 User Guide 70

Condition

Diagnostic LED

Channel 1 Status LED

No Errors

OFF

N/A

1111:: TTrroouubblleesshhoooottiinngg aanndd CCoonnttaacctt IInnffoorrmmaattiioonn

This chapter discusses how you can diagnose and fix errors quickly without having to contact a dealer or Lantronix. It helps to connect a terminal to the serial port while diagnosing an error to view summary messages that may display. When troubleshooting, always ensure that the physical connections (power cable, network cable, and serial cable) are secure.

Note: Some unexplained errors might be caused by duplicate IP addresses on the

network. Make sure that your unit's IP address is unique.

When troubleshooting the following problems, make sure that the SDS is powered up. Confirm that you are using a good network connection.

SDS1101 LEDs

The SDS1101 has the following LEDs, which help you diagnose problems.

 Power LED (green)  Ethernet 10/100 Link (yellow = 10 Mb/green = 100 Mb)  Ethernet Half/Full Duplex Activity (yellow = Half Duplex/green = Full Duplex)  Diagnostic (red)  Status (green)

Simultaneously lit Diagnostic (red) and Status (green) LEDs mean something is wrong. If the Diagnostic LED is lit or blinking, count the number of times the Status LED blinks between its pauses. The following table explains the LED functions:

Table 11-1. SDS1101 LEDs

Network controller error ON Blinks 3x/4 seconds

Serial number storage checksum error

Duplicate IP address present ON Blinks 5x/4 seconds

No DHCP response Blinks 2x/second Blinks 5x/4 seconds

Setup menu active

SDS1101/2101 User Guide 71

ON Blinks 4x/4 seconds

Blinks 2x/second

Follows Diagnostic LED for 2 seconds, off for 2 seconds

SDS2101 LEDs

LEDs

Meaning

Off = No data activity

Problem/Message

Reason

Solution

When you issue the ARP –S

Your currently logged-in

Have someone from your IT

The following LEDs are on the top of the SDS2101:

 Power / Diagnostic (Blue)  RX Serial 1 Activity LED (Green)  TX Serial 1 Activity LED (Yellow)  RX Serial 2 Activity LED (Green) 

The following LEDs are on the RJ45 Ethernet connector:

 Ethernet Link LED on the left (Bi-color, 10Mbps = Yellow, 100 Mbps = Green)

Ethernet Activities LED on the right (Bi-color, Half Duplex = Yello w , Full Duplex = Green)

Power/Diagnostic (Blue)

11: Troubleshooting and Contact Information

TX Serial 2 Activity LED (Yellow)

Table 11-2. SDS2101 LEDs

Steady On = Power OK Blinking 2x = No DHCP response Blinking 2x = Setup Menu active

RX Serial 1 Activity LED (Green) TX Serial 1 Activity LED (Yellow) RX Serial 2 Activity LED (Green) TX Serial 2 Activity LED (Yellow)

Ethernet Link LED on the left (Bi-color)

Ethernet Activity LED on the right (Bi-color)

Problems and Error Messages

Table 11-3. Problems and Error Messages

Blinking = Data being received by SDS2101 on channel 1 Off = No data activity

Blinking = data being transmitted from SDS2101 on channel 1

Blinking = data being received by SDS2101 on chan nel 2

Blinking = Data being transmitted from SDS2101 on channel 2 Off = No Ethernet link established Solid Yellow = 10Mbps Ethernet link established Solid Green = 100 Mbps Ethernet Link established Off = No data activity Blinking Yellow = Half Duplex data activity Blinking Green = Full Duplex data activity

command in Windows, the "ARP entry addition failed: 5" message displays.

SDS1101/2101 User Guide 72

user does not have the correct rights to use this command on this PC.

department log you in with sufficient rights.

11: Troubleshooting and Contact Information

Problem/Message

Reason

Solution

When you attempt to assign an IP

When you Telnet to port 1

Telnet back to Port 1. Wait for it to

When you Telnet to port 9999, the

You did not press Enter

Telnet to port 9999 again, but press

When you Telnet to port 1 to

You may have entered the

Confirm that the Ethernet address

The IP address you are

Confirm that your PC has an IP

The device server may not

Make sure that the Link LED is lit. If

The device server is not

The most likely reason is

The serial settings for the serial

address to the unit by the ARP method, the "Press Enter to go into Setup Mode" error "(described below) message displays. Now when you Telnet to the device server, the connection fails.

"Press Enter to go into Setup Mode" message displays. However, nothing happens when you press Enter, or your connection is closed.

assign an IP address to the device server, the Telnet window does not respond for a long time.

on the device server, you are only assigning a temporary IP address. When you Telnet into port 9999 and do not press Enter quickly, the device server reboots, causing it to lose the IP address.

quickly enough. You only have 5 seconds to press Enter before the connection is closed.

Ethernet address incorrectly with the ARP command.

trying to assign is not on your logical subnet.

fail, then Telnet to port 9999 again. Make sure you press Enter quickly.

Enter as soon as you see the "Press Enter to go into Setup Mode" message.

that you entered with the ARP command is correct. The Ethernet address may only include numbers 0-9 and letters A-F. In Windows and usually in Unix, the segments of the Ethernet address are separated by dashes. In some forms of Unix, the Ethernet address is segmented with colons.

address and that it is in the same logical subnet that you are trying to assign to the device server.

When you try to assign an IP with DeviceInstaller, you get the following :

"No response from device! Verify the IP, Hardware Address and Network Class. Please try again."

communicating with the serial device to which it is attached.

be plugged into the network properly.

The cause is most likely one of the following:

The hardware address you specified is incorrect.

The IP address you are trying to assign is not a valid IP for your logical subnet.

You did not choose the correct subnet mask.

the wrong serial settings were chosen.

the Link LED is not lit, then the device server is not properly plugged into the network.

Double-check the parameters that you specified.

Note: You cannot assign an IP

address to a device server through a router.

device and the device server must match. The default serial settings for the device server are RS-232, 9600 baud, 8 character bits, no parity, 1 stop bit, no flow control.

SDS1101/2101 User Guide 73

11: Troubleshooting and Contact Information

Problem/Message

Reason

Solution

When you try to enter the setup

The issue is most likely

Double-check everything in the

You can ping the device server,

There may be an IP

Turn the device server off and then

The device server appears to be

If you are sure that the

On SDS1101 you can check to see

mode on the device server using the serial port, you get no response.

but not Telnet to the device server on port 9999.

With DeviceInstaller, you get the Wrong Password error when you try to upgrade the firmware.

set up correctly, but you are not communicating with your device attached to the device server across the network.

something covered in the previous problem, or possibly, you have Caps Lock on.

address conflict on your network

You are not Telneting to port 9999.

The Telnet configuration port (9999) is disabled within the device server security settings.

The file you are attempting to load is the incorrect firmware file for the SDS.

serial port setting is correct, then you may not be connecting to the correct socket of the device server.

Another possibility is that the device server is not set up correctly to make a good socket connection to the network.

problem above. Confirm that Caps Lock is not on.

issue the following commands at the DOS prompt of your computer:

ARP -D X.X.X.X (X.X.X.X is the I P of the device server).

PING X.X.X.X (X.X.X.X is the IP of the device server).

If you get a response, then there is a duplicate IP address on the network. If you do not get a response, use the serial port to verify that Telnet is not disabled.

Download the correct firmware file from the Lantronix website.

whether there is a socket connection to or from the SDS by looking at the Status LED.

If the Status LED is blinking consistently, then there is a good socket connection.

For SDS1101/2101, use the Conne ct Mode option C0 for making a connection to the SDS from the network. Use Connect Mode option C1 or C5 for a connection to the network from the SDS.

When connecting to the WebManager within the device server, the "No Connection With The Device Server" message displ ay s.

Technical Support

If you are experiencing an error that is not described in this chapter, or if you are unable to fix the error, you have the following options:

To check our online knowledge base or send a question to Technical Support, go to

http://www.lantronix.com/support.

SDS1101/2101 User Guide 74

Your computer is not able to connect to port 30718 (77FEh) on the device server.

Make sure that port 30718 (77FEh) is not blocked with any router that you are using on the network. Also, make sure that port 77FEh is not disabled within the Security settings of the device server.

11: Troubleshooting and Contact Information

Technical Support Europe, Middle East, and Africa

Phone: +33 (0) 1 39 30 41 72 Email:

eu_techsupp@lantronix.com or eu_support@lantronix.com

Firmware downloads, FAQs, and the most up-to-date documentation are available at:

www.lantronix.com/support

When you report a problem, please provide the following information:

 Your name, and your company name, address, and phone number   Lantronix model number  Lantronix MAC number  Software version (on the first screen shown when you T elnet to port 9999)  Description of the problem

Status of the unit when the problem occurred (please try to include information on user and network activity at the time of the problem)

SDS1101/2101 User Guide 75

DB25 Serial Port

1122:: SSDDSS11110011 CCoonnnneeccttiioonnss aanndd PPiinnoouuttss

Serial Port

The SDS1101 has a female DCE DB25 serial port that supports RS-232 and RS485/422 serial standards (software selectable) up to 230 Kbaud.

Figure 12-1. Serial Interface

Serial Connector Pinouts

The unit’s female DB25 connector provides an RS-232C, RS-485, or RS-422 DCE serial port. The default serial port settings are 9600 baud, 8 bits, no parit y, and 1 stop bit.

Figure 12-2. DB25 Female DCE Interface RS232

SDS1101/2101 User Guide 76

12: SDS1101 Connections and Pinouts

Figure 12-3. DB25 Female Interface RS422 (4 wire mode)

Figure 12-4. DB25 Female Interface RS485 (2 wire mode)

Modem Cable

When attaching the DB25 of the SDS1101 to the DB9 com port on a PC, use a standard straight-through serial cable. The figure below shows the pinouts for a DB25 to DB9 straight-through cable, often referred to as a "Modem Cable".

To configure the SDS using the DB9 serial port, you need only pin out the TXD, RXD, and GND signals.

SDS1101/2101 User Guide 77

12: SDS1101 Connections and Pinouts

Figure 12-5. Modem Cable

Network Port

The unit's back panel contains a power plug and an RJ45 (10/100) Ethernet port.

Figure 12-6. Network Interface

RJ45 Ethernet Port Power Plug

SDS1101/2101 User Guide 78

12: SDS1101 Connections and Pinouts

Ethernet Connector Pinouts

The SDS1101 supports 10/100 Mbps half or full duplex Ethernet through an RJ45 connector.

Figure 12-7. RJ45 Ethernet Connector

Power Plug

Power input on the power plug is 9 -30 VDC (center +) or 10-24 VAC (1.5W maximum power required).

SDS1101/2101 User Guide 79

Male DB9 Serial Ports

1133:: SSDDSS22110011 CCoonnnneeccttiioonnss aanndd PPiinnoouuttss

SDS2101 Serial Ports

The SDS2101 has two male DB9 DTE serial ports that support RS-232C/RS-422 (4wire)/RS-485 (2-wire) serial standards up to 230 Kbps (and up to 921 Kbps if high performance is selected).

Figure 13-1. Serial Interface

Male DB9 Serial Ports

Serial Connector Pinouts

The two Male DB9 DTE connectors provide an RS-232C/RS-422 (4-wire)/ RS-485 (2-wire) interface. The default serial port settings are 9600 baud, 8 bits, no parity, 1 stop bit, no flow control.

Figure 13-2. DB9 Male RS232 Serial DTE Connector

SDS1101/2101 User Guide 80

Network Port

The unit's back panel contains a 9-30VDC power plug and an RJ45 (10/100) Ethernet port.

RJ45 Ethernet Port Reset Button Power Plug

Reset Button

You can reset the unit to factory defaults, including clearing the network settings (IP address, gateway, and netmask are set to 00s).

13: SDS2101 Connections and Pinouts

Figure 13-3. Network Interface

To reset the unit to factory defaults:

1. Place the end of a paper clip or similar object into the reset opening and press for a minimum of 3 seconds.

2. Release the button and remove the paper clip. The firmware restores factory default settings to the configuration and invokes a reset (internally).

Ethernet Connector Pinouts

Power Plug

Power input on the power plug is 9-30 VDC (center +) (1.8W maximum power).

SDS1101/2101 User Guide 81

Category

Description

Internal CPU Memory

256 KB zero wait state SRAM

Flash

2 MB Flash

EEPROM

2 KB EEPROM

Serial Line Formats

Characters: 7 or 8 data bits Flow Control

Hardware: CTS/RTS

Power Input

9-30 VDC or 9-24 VAC on barrel connector (1.5 Watts maximum consumption)

Network Interface

1 RJ45 10Base-T/100Base-TX Ethernet port

Dimensions

Height: 2.3 cm (0.9 in)

Weight

0.20 kg (0.45 lb)

Temperature

Operating range: 0° to 60° C (32° to 140° F)

Serial login

1144:: SSDDSS11110011 TTeecchhnniiccaall SSppeecciiffiiccaattiioonnss

Table 14-1. SDS1101 Technical Specifications

CPU Lantronix DSTNI-EX 48 MHz clock

Serial Interface 1 DB25F DCE serial port

Software-selectable baud rate from 300 to 230 KBaud Software-selectable RS232, RS422 or RS485 (2 and 4 wire support)

Stop bits: 1 or 2 Parity: odd, even, none

Modem Control DTR, DSR

Software: XON/XOFF

9-30 VDC on DB25F serial interface

Software selectable Ethernet speed 10/100/Auto Software selectable Half/Full/Auto duplex

Width: 6.4 cm (2.5 in) Depth: 9.0 cm (3.5 in)

Note: Operating range for SDS1101-IAP only: -40° to 70° C (-40° to 158° F)

Storage -40° to 85° C (-40 to 185° F)

Relative Humidity Operating 10% to 90% non-condensing, 40% to 60% recommended

Storage 10% to 90% non-condensing

Case Metal enclosure with integrated wall mounts

Optional 35 mm Din Rail mount available Protocols Supported ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP, and HTTP Installable Industrial

Protocols Management Internal web server

ModBus TCP, ModBus ASCII/RTU, DF1 Multi-Master (IAP version only)

SNMP (read only)

SDS1101/2101 User Guide 82

14: SDS1101 Technical Specifications

Category

Description

Telnet login

System Software

DeviceInstaller, Windows® 95/98/ME/NT/2000/ XP-based configuration software

LEDs

Power

Isolation

Designed with protections against transients and ESD for use under harsh

Agency Approvals

UL, CSA, FCC, CE, TUV, CTick, VCCI

DeviceInstaller software

Com Port Redirector, Windows® 98/NT/2000/XP-based virtual com port software

10/100 Mb Link

10/100 Activity

Diagnostic

Status Emissions FCC Part 15 Subpart B Class A Radiated Emissions 30MHz – 1000MHz

ICES-003 Issue 4 February 2004 Class A Radiated Emissions 30MHz – 1000MHz

AS/NZS CISPR 22: 2004 Class A Radiated Emissions 30MHz – 1000MHz

EN55022: 1998 + A1: 2000 + A2: 2003 Class A Rad iate d E missio ns 30MHz –

1000MHz

VCCI V-3/2005.04 Class A Radiated Emissions 30M Hz – 1000MHz

EN61000-3-2: 2000 Class A Harmonic Current Emissions

EN61000-3-3: 1995 + A1: 2001 Fluctuations and Flicker Immunity EN55024: 1998 +A1: 2001 +A2: 2003

IEC_61000-4-2: 1995 ESD 8KV Air Discharge (Direct), 4KV Contact Discharge

(Direct/Indirect)

IEC_61000-4-3: 1995 Radiated Immunity 3.0V/m, 1KHz AM Sine Wave at 80%

IEC_61000-4-4: 1995 EFT/Burst 1.0KV Power Lines, 0.5KV I/O Lines

IEC_61000-4-5: 1995 Surge Immunity 1.0KV Common Mode, 1.0 KV Differential

Mode

IEC_61000-4-6: 1996 Conducted Immunity 3.0 Vrms, 80% AM Modulated (1KHz)

IEC_61000-4-8: 1993 Magnetic Field Immunity 50Hz 1.0 Arms/m

IEC_61000-4-11: 1994 Voltage Dips and Interrupts (>95%, 0.5 periods), (30%, 25

periods), (>95%, 250 periods)

environments

Serial Port: 15 KV ESD protection on RS232 and RS422/485 transceivers

Power Input: Up to non-repeated 600 W 10/100 usec pulse protection against transient

over voltages

Ethernet Port: 1500 VAC isolation shielded with shield connected to chassis ground for

signal integrity and ESD protection

SDS1101/2101 User Guide 83

Category

Description

Internal CPU

256 KB zero wait state SRAM Flash

2 MB Flash

EEPROM

2 KB EEPROM

Serial Line Formats

Characters: 7 or 8 data bits Modem Control

DTR, Modem Control In

Flow Control

Hardware: CTS/RTS Power Input

9-30 VDC on barrel connector (1.8W maximum consumption)

Network Interface

1 RJ45 10Base-T/100Base-TX Ethernet port

Dimensions

Height: 2.3 cm (0.9 in)

Weight

0.26 kg ( 0.6 lb)

Temperature

Operating range: 0° to 60° C (32° to 140° F) Case

Metal enclosure with integrated wall mounts

Protocols Supported

ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP, and

1155:: SSDDSS22110011 TTeecchhnniiccaall SSppeecciiffiiccaattiioonnss

Table 15-1. SDS2101 Technical Specifications

CPU Lantronix DSTNI-EX 48 MHz clock

Memory

Serial Interface 2 DB9M DTE serial ports

Software-selectable baud rate from 300 to 921K baud (when High

Performance is selected)

Software-selectable RS232, RS422 or RS485 (2 and 4 wire support)

Stop bits: 1 or 2

Parity: odd, even, none

Software: XON/XOFF

Software selectable Ethernet speed 10/100/Auto

Software selectable Half/Full/Auto duplex

Width: 7.3 cm (2. 9 in)

Length : 9.5 cm ( 3.75 in)

Note: Operating range for SDS2101-IAP only: -40° to 70° C (-40° to 158° F)

Storage -40° to 85° C (-40 to 185° F) Relative Humidity Operating 10% to 90% non-condensing, 40% to 60% recommended

Storage 10% to 90% non-condensing

Optional 35 mm Din Rail mount available

HTTP

SDS1101/2101 User Guide 84

Category

Description

Installable Industrial

Protocols

ModBus TCP, ModBus ASCII/RTU, DF1 Multi-Master (IAP version onl y)

System Software

DeviceInstaller, Windows® 95/98/ME/NT/2000/XP-based configuration

LEDs

Power

Emissions

FCC Part 15 Subpart B Class A Radiated Emissions 30MHz – 1000MHz

Immunity

EN55024: 1998 +A1: 2001 +A2: 2003

Isolation

Designed with protections against transients and ESD for use under harsh

Power Input: Up to non-repeated 600 W 10/100 usec pulse protection against

Management Internal web server

SNMP (read only)

Serial login

Telnet login

DeviceInstaller software

software

Com Port Redirector, Windows® 98/NT/2000/XP-based virtual com port

software

10/100 Mb Link on RJ45

10/100 Activity on RJ45

Diagnostic

RX Serial 1 Activity

TX Serial 1 Activity

RX Serial 2 Activity

TX Serial 2 Activity

15: SDS2101 Technical Specifications

ICES-003 Issue 4 February 2004 Class A Radiated Emissions 30MHz –

1000MHz

AS/NZS CISPR 22:2006 Class A Radiated Emissions 30MHz – 1000MHz

EN55022: 1998 + A1: 2000 + A2: 2003 Class A Radiated Emissions 30MHz –

1000MHz

VCCI V-3/2006.04 Class A Radiated Emissions 30MHz – 1000MHz

EN61000-3-2: 2000 Class A Harmonic Current Emissions

EN61000-3-3: 1995 + A1: 2001 Fluctuations and Flicker

IEC_61000-4-2: 1995 ESD 8KV Air Discharge (Direct), 4KV Contact

Discharge (Direct/Indirect)

IEC_61000-4-3: 1995 Radiated Immunity 3.0V/m, 1KHz AM Sine Wave at

80%

IEC_61000-4-4: 1995 EFT/Burst 1.0KV Power Lines, 0.5KV I/O Lines

IEC_61000-4-5: 1995 Surge Immunity 1.0KV Common Mode, 1.0 KV

Differential Mode

IEC_61000-4-6: 1996 Conducted Immunity 3.0 Vrms, 80% AM Modulated

(1KHz)

IEC_61000-4-8: 1993 Magnetic Field Immunity 50Hz 1.0 Arms/m

IEC_61000-4-11: 1994 Voltage Dips and Interrupts (>95%, 0.5 periods), (30%,

25 periods), (>95%, 250 periods)

SDS1101/2101 User Guide 85

environments

Serial Port: 15 KV ESD protection on RS232 and RS422/485 transceivers

15: SDS2101 Technical Specifications

Category

Description

transient over voltages

Agency Approvals

UL, CSA, FCC, CE, TUV, CTick, VCCI

Ethernet Port: 1500 VAC isolation shielded with shield connected to chassis

ground for signal integrity and ESD protection

SDS1101/2101 User Guide 86

AA:: AAlltteerrnnaattiivvee WWaayyss ttoo AAssssiiggnn aann IIPP AAddddrreessss

Earlier chapters describe how to assign a static IP address using DeviceInstaller, Web Manager, and Setup Mode (through a Telnet or serial connection). This section covers other methods for assigning an IP address over the network.

DHCP

The unit ships with a default IP address of 0.0.0.0, which automatically enables DHCP. If a DHCP server exists on the network, it provides the unit with an IP address, gateway address, and subnet mask when the unit boots up.

You can use the DeviceInstaller software to search the network for the DHCPassigned IP address and add it to the list of devices retrieved.

Note: This DHCP address does not appear in the unit ’s Setup Mode or in

Web Manager. You can determine your unit’s DHCP-ass igned IP addres s in Monitor Mode. When you enter Monitor Mode from t he serial port with network connection enabled and issue the NC (Network Communication) command, you see the unit’s IP configuration.

AutoIP

The unit ships with a default IP address of 0.0.0.0, which automatically enables Auto IP within the unit. AutoIP is an alternative to DHCP that allows hosts to obtain an IP address automatically in smaller networks that may not have a DHCP server. A range of IP addresses (from 169.254.0.1 to 169.254.255.1) has been explicitly reserved for AutoIP-enabled devices. Do not use this range of Auto IP addresses over the Internet.

 If your unit cannot find a DHCP server, and you have not manually assigned an

IP address to it, the unit automatically selects an address from the AutoIP reserved range. Then, your unit sends out a (ARP) request to other nodes on the same network to see whether the selected address is being used.

 If the selected address is not in use, then the unit uses it for local subnet

communication.

 If another device is using the selected IP address, the unit selects another

address from the AutoIP range and reboots. After reboot, the unit sends out another ARP request to see if the selected address is in use, and so on.

AutoIP does not replace DHCP. The unit continues to look for a DHCP server on the network. If it finds a DHCP server, the unit switches to the DHCP server-provided address and reboots.

Note: If a DHCP server is found, but it denies the request for an IP address,

the unit does not attach to the network, but waits and retries.

AutoIP can be disabled by setting the unit’s IP address to 0.0.1.0. This setting enables DHCP but disables AutoIP.

SDS1101/2101 User Guide 87

BOOTP

Similar to DHCP, but for smaller networks. Automatically assigns the IP address for a specific duration of time.

ARP and Telnet

If the unit has no IP address, you can use Address Resolution Protocol (ARP) method from UNIX and Windows-based systems to assign a temporary IP address.

To assign a temporary IP address:

1. On a UNIX or Windows-based host, create an entry in the host's ARP table using the intended IP address and the hardware address of the unit (on the product label on the bottom of the unit).

arp -s 191.12.3.77 00-20-4a-xx-xx-xx (Windows)

Note: For the ARP command to work on Windows 95, the ARP table

on the PC must have at least one IP address defined other than its own.

A: Alternative Ways to Assign an IP Address

arp -s 191.12.3.77 00:20:4a:xx:xx:xx (Unix)

2. If you are using Windows 95, type ARP -A at the DOS command prompt to verify that there is at least one entry in the ARP table. If the local machine is the only entry, ping another IP address on your network to build a new entry in the ARP table; the IP address must be a host other than the machine on which you are working. Once there is at least one additional entry in the ARP table, use the following command to ARP an IP address to the unit:

arp -s 191.12.3.77 00-20-4a-xx-xx-xx

3. Open a Telnet connection to port 1. The connection fails quickly, but the unit temporarily changes its IP address to the one designated in this step.

telnet 191.12.3.77 1

4. Open a Telnet connection to port 9999, and press Enter within five seconds to go into Setup Mode. If you wait longer than five seconds, the unit reboots.

telnet 191.12.3.77 9999

Note: The IP address you just set is temporary and reverts to the default

value when the unit’s power is reset, unless you configure the unit with a static IP address and store the changes permanently.

SDS1101/2101 User Guide 88

Decimal

Binary

Hex

0000

0011

0100

0101

0110

0111

1010

1011

1100

1101

BB:: BBiinnaarryy ttoo HHeexxaaddeecciimmaall CCoonnvveerrssiioonnss

Many of the unit’s configuration procedures require assembling a series of options (represented as bits) into a complete command (represented as a byte). Convert the resulting binary value to a hexadecimal representation.

Converting Binary to Hexadecimal

Following are two simple ways to convert binary numbers to hexadecimals.

Conversion Table

Hexadecimal digits have values ranging from 0 to F, which are represented as 0-9, A (for 10), B (for 11), etc. To convert a binary value (for example, 0100 1100) to a hexadecimal representation, the upper and lower four bits are treated separately, resulting in a two-digit hexadecimal number (in this case, 4C). Use the following table to convert values from binary to hexadecimal.

1 0001 1 2 0010 2

8 1000 8 9 1001 9

14 1110 E 15 1111 F

SDS1101/2101 User Guide 89

Scientific Calculator

Another simple way to convert binary to hexadecimals is to use a scientific calculator, such as the one available on Windows’ operating systems. For example:

1. On the Windows’ Start menu, click ProgramsAccessoriesCalculator.

2. On the View menu, select Scientific. The scientific calculator displays.

3. Select Bin (Binary), and type the number to convert.

B: Binary to Hexadecimal Conversions

4. Click Hex. The hexadecimal value displays.

SDS1101/2101 User Guide 90

CC:: WWaarrrraannttyy

For details on the Lantronix warranty replacement policy, please go to our Web site

www.lantronix.com/support/warranty.

SDS1101/2101 User Guide 91

DD:: CCoommpplliiaannccee aanndd DDiissccllaaiimmeerr

Manufacturer’s Name & Address

Lantronix 167 Technology Drive

Irvine, CA 92618 USA

Declares that the following product:

Product Name Model: SDS1101 and SDS2101 Device Servers

Conforms to the following standards or other normative documents:

Safety

UL 60950-1 CSA 22.2. No 60950-1-03 EN 60950-1 TUV VCCI C-TICK

Electromagnetic Emissions

FCC Part 15 Subpart B Class A ICES-003 Issue 4 February 2004 Class A AS/NZS CISPR 22: 2004 Class A EN55022: 1998 + A1: 2000 + A2: 2003 CLASS A EN61000-3-2: 2000 Class A EN61000-3-3: 1995 +A1: 2001 VCCI V-3/2006.04 Class A (SDS2101 only)

Electromagnetic Immunity

EN55024: 1998 +A1: 2001 +A2: 2003 IEC 61000-4-2: 1995 IEC 61000-4-3: 1995 IEC 61000-4-4: 1995 IEC 61000-4-5: 1995 IEC 61000-4-6: 1996 IEC 61000-4-8: 1993

SDS1101/2101 User Guide 92

D:Compliance and Disclaimer

Lead (Pb)

Mercury (Hg)

Polybrominated biphenyls (PBB)

Cadmium (Cd)

Hexavalent Chromium (Cr (VI))

Polybrominated diphenyl eth ers (PB DE)

Product Family Name

Toxic or hazardous Substances and Elements

Lead

Mercury

Cadmium

Hexavalent (Cr (VI))

Polybrominated

Polybrominated diphenyl UDS1100 and 2100

0 0 0 0 0

EDS 0 0 0 0 0 0

MSS100 0 0 0 0 0 0

IntelliBox 0 0 0 0 0 0

XPress DR & XPress-DR+

0 0 0 0 0

SecureBox 1101 & 2101

0 0 0 0 0

WiBox 0 0 0 0 0 0

UBox 0 0 0 0 0 0

MatchPort

0 0 0 0 0

SLC 0 0 0 0 0 0

XPort 0 0 0 0 0 0

WiPort 0 0 0 0 0 0

SLB 0 0 0 0 0 0

SLP 0 0 0 0 0 0

SCS 0 0 0 0 0 0

SLS 0 0 0 0 0 0

DSC 0 0 0 0 0 0

IEC 61000-4-11: 1994

RoHS Notice

All Lantronix products in the following families are China RoHS-compliant and free of the following hazardous substances and elements:

•

(Pb)

O: toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit requirement in SJ/T11363-2006. X: toxic or hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement in SJ/T11363-2006.

(Hg)

(Cd)

Chromium

biphenyls (PBB)

ethers (PBDE)

Disclaimer and Supplementary Information

This product has been designed to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against such interference when operating in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with this guide, may cause harmful interference to radio communications. Operation of this equipment of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at user own expense.

This Class A digital apparatus complies with Canadian ICES-003 Cet appareil num′erique de la classe A est conforme à la norme NMB-003 du Canada. The product complies with the requirements of the Low Voltage Directive 72/23/EEC and

the EMC Directive 89/336/EEC. Encryption: This product includes AES encryption certified by the National Institute of

Standard and Technology to FIPS-197 standard certification #120. Export Control Classification Number 5A002, License exception ENC. Changes or modifications to this device not explicitly approved by Lantronix will void the

user's authority to operate this device. The information in this guide may change without notice. The manufacturer assumes no responsibility for any errors that may appear in this guide.

SDS1101/2101 User Guide 93

Manufacturer’s Contact

167 Technology Drive Irvine, CA 92618 USA Toll Free: 800-526-8766 Phone: 949-453-3990 Fax: 949-450-7249

D:Compliance and Disclaimer

SDS1101/2101 User Guide 94

Index

Applications, 11 ARP and Telnet, 88 AutoIP, 17, 87 Binary to hexadecimal conversions, 89 BOOTP, 17, 88 Channel settings, 29, 44 Command line interface, 38 Configuration methods, 13 Connect Mode, 46 Connection settings

TCP, 32

UDP, 35 Connectors, 76, 80 Contacts, 2 CPU Performance, 59 Default settings

applying in Setup Mode, 64

applying in Web-Manager, 37 DeviceInstaller

accessing the unit, 23

assigning the IP address, 18

installing from product CD, 18 DHCP, 17, 87 DHCP name. See Error messages, 72 Ethernet address, 14 Expert settings, 59 Firmware

recovering, 67

upgrading, 66 Gateway, 41 Getting started, 15 Hardware address, 14, 17 Host list settings

Setup Mode, 49

Web-Manager , 28 Installation, 16 Internal web server, 13 IP address

assigning, 18, 25, 41

automatic assignment, 25

factory default, 17

D:Compliance and Disclaimer

gateway, 41 other ways to assign, 87 requirement, 17 searching for on the network, 19

show after ring, 54 Label, 14 LEDs, 71, 72 MAC address, 14 Modem emulation, 13 Modem Mode, 51 Monitor Mode, 69 Netmask, 42 Network settings, 24 Null modem cable, 77 Package contents, 15 Password for Telnet configuration, 42 Pinouts, 76, 80

Ethernet connector, 79

serial connector, 76 Power plug, 78 Problems, 72 Protocols, 13 Redirection software, 12 Required information, 17 RJ45 Ethernet port, 78 RoHS notice, 93 RS-232 and RS-485/422 standards, 76 Security settings, 60 Serial port

accessing Setup Mode, 21

Setup Mode, 41

Web-Manager , 26 Setup Mode, 38

accessing by serial port connection, 39

accessing by Telnet. See SNMP, 61 TCP settings, 32 Technical specifications Technical Support, 74

SDS1101/2101 User Guide 95

TFTP, 66 Troubleshooting, 9, 71 UDP settings, 35

Warranty, 91 Web-Manager , 23

SDS1101/2101 User Guide 96

Lantronix SDS1101, SDS2101 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
