Land Pride RCR25 User Manual

DUAL SPINDLE

A perfect fit for any size farm.

Land Pride’s New 25 Series 8’ and 10’ Rotary Cutters

Land Pride’s RCR25 Series 8’ and 10’ Rotary Cutters are
suited just perfect for those medium sized chores. Designed
for excellent performance in pastures, set aside acres,
roadsides and routine farm maintenance, we have a model
to fit your 30-110 HP tractor. Both sizes are available in a
3-Point or Pull-Type model.

Standard with two stump jumpers, each with two free
swinging heat-treated blades, these cutters are designed to
cut grass, weeds and saplings up to 1” in diameter. Front
and rear guarding must be selected, and are available in
rubber or chain. 15 1/4” Laminated tires are standard on
the 3-point model, while the pull-type offers a selection of
24” aircraft tires, 15” wheel rims or 21” laminated tires.

Pull-type — The Pull-type model features two leveling rods
that connect the rear axle to the front tongue. This enables

www.landpride.com

the deck to stay level during uneven ground conditions.
The height controlling axle cylinder is attached to two deck

6

springs which help cushion the cutter in rough terrain.

3-Point — The 3-point unit utilizes two castering laminated
tailwheels for smooth, trouble-free performance. The easy to
attach clevis hitch is designed to fit Cat. 1 or 2 tractors on
the 96” model, and Cat. 2 or 3 tractors on the 10’ model.

RCR25 SERIES

Pull-Type: 30 - 110 HP — 8’ 10’
3-Point: 50 - 110 HP — 8’ 10’

• Clevis hitch on 3-point

• Narrow tongue on pull-type

• Stump jumpers are standard

• Choice of tires

• High blade tip speed

• All-welded deck

• RCR2510 in 540 or 1000 RPM

Available in:

year

5

Limited

Gearbox Warranty

*

Sturdy Deck Design — The all-welded, 10 ga. deck features
side to side, and front to rear channels for overall support.

Pull-Type: Laminated tires or airplane tires
3-Point: Laminated tires

Front and rear guarding is highly recommended
in any application. Please be sure you understand
how your Rotary Cutter is equipped upon purchase.
All Land Pride Rotary Cutters are tested and pass
rigorous voluntary testing requirements as specified
by ANSI, ASAE and SAE.
