BATTERY CHARGER
BEFORE USING OUR BATTERY CHARGER, READ IN DETAILS
ALL INSTRUCTIONS CONTAINED IN THIS MANUAL. KEEP
THIS MANUAL IN A SAFE PLACE AS YOU MAY NEED TO USE
IT LATER.
We draw the attention of all users of this device: please follow
the safety and maintenance instructions which are part of this
manual. Also read the caution markings on the charger, the
manual, and the gift box.
Instruction Manual
15
INTRODUCTION:
Congratulations on purchasing this intelligent charging unit which
enables definitely quick and optimum charging to “AA” and “AAA”
rechargeable batteries. With charging functions as well as individual
LCD displays for the charging compartments, this charging unit is
reliable, user-friendly and ideal for use in the home, office or on journey.
The Charging unit
CAUTIONS:
1. The charger is restricted to charging NiCd and NiMH
rechargeable batteries only. Never adopt this charger to other
types of batteries, such as alkaline, lithium, carbon zinc battery or
other types of battery that is not specified.
16
2. The charging unit shall only be used at normal indoor room
conditions.
3. Always follow the charging instructions for the rechargeable
battery. Observe the recommended charging current of the
rechargeable batteries.
4. Never use other kinds of the power cable and transformer apart
from those originally supplied with the charging unit.
5. The rechargeable battery may become hot during charging. User
should take extra care when taking out the battery after charging.
6. Unplug the charging unit from the power source when it is not in
use.
FEATURES:
The Charging unit
Charging the rechargeable battery in around 250mA charging
current
Individual LCD display for different compartments
Charging both “AA” and “AAA” rechargeable batteries
simultaneously
Minus delta voltage (-dV) detection for charge termination
Defect batteries detection
The charging function can be launched independently and
17
simultaneously to each rechargeable battery in the compartments
The display of terminal voltage (in V) and percentage (in %) will
alternate during charging
Trickle charging is available after the rechargeable battery is fully
charged
To prevent overcharge, charger timer is available to limit the
charging time to 18 hours for each newly installed battery
INVENTORY OF CONTENTS
1. Charging unit
2. Transformer
3. Instruction Manual
OPERATING STAGES OF THE CHARGING UNIT
The charge stage and the trickle charging are the only two operating
stages of this charging unit.
CHARGE STAGE
The unit can charge up the rechargeable battery. It will automatically
switch to trickle charging after the rechargeable battery is fully charged.
18
During the process of charging, the display of voltage and percentage
will alternate on the LCD. The item of percentage will show the
percentage of the battery charged while the item of voltage will show the
voltage of battery. Once the battery is full, the voltage will display
permanently with the “Full” sign. The trickle charging will start shortly
afterwards.
Charging current that is around 250mA is the only default value in the
charging process.
The estimated charging time of different battery size is tabulated in
Table 1.
Table 1. Charging Time with Two Types of Battery Size
Size of
battery
AAA 1000mAh
Battery
Capacity
AA 2600mAh
Charging current (mA) Estimated
around 250mA
charging time
12 hrs
6 hrs
19
Note:
It may be necessary to charge and discharge the new
rechargeable batteries for several times in the beginning in order
to obtain the optimum capacity of the rechargeable batteries.
However, this charger does not provide the discharge function.
Users may need to discharge the new rechargeable batteries
themselves.
When the transformer has been plugged to the power source, the
version number of the charger (for example “14” ) will display
after all the segments light up momentarily. The “--” sign (figure 1)
will show before the batteries are placed. If the defect batteries
are placed to the charging unit, the “DEF“ sign (figure 2) will show
on the LCD of charger.
The “DEF” sign will flash for a while on the LCD when the charger
detects the battery condition. When the defective condition of the
battery is confirmed, the “DEF” sign will turn on permanently.
“--” displays - No battery is placed to the
charging unit (figure 1)
20
If attempting to recharge the alkaline or carbon batteries, it may
cause rupture, explosion or the leakage of hazardous liquids.
During the charging process, the “Charge” sign will show if any
rechargeable batteries are placed into the unit. Users should
make sure that the charged batteries are either NiCd or NiMH
type and should not use the alkaline or carbon batteries.
Carbon or Alkaline batteries may be the cause of the defect.
Those types of batteries are NOT suitable for this charger.
Another defect cause may come from the rechargeable batteries
which voltage is too low.
TRICKLE CHARGING
After the rechargeable battery is fully charged, the charger will give a
small amount of current to the rechargeable batteries to maintain the
fully charged level. This stage is automatically launched after
rechargeable batteries are fully charged and kept at the charging unit.
The “Full” sign will display on the LCD.
“DEF” displays – A defect battery is
placed into the charging unit (figure 2)
21
START CHARGING THE RECHARGEABLE BATTERIES
Indication of
battery
charging
After the transformer has been plugged to
the power source, user should insert a
rechargeable battery into the charging unit
and plug the DC jack into the battery
charger. Shortly afterwards, the battery
voltage (for example, “1.38V”) will display.
Then the “Charge” sign will show on LCD
within 5 seconds, indicating that the
charging process with around 250mA is
going to start.
During charging, terminal voltage (in V)
(figure 3) and percentage (in %) (figure 4)
are the two items that will alternate to show
on the LCD.
Terminal voltage
(Figure 3)
22
The battery
(Figure 5)
Indication of
battery
After the rechargeable battery is fully charged, “Full” sign (figure 5) will
show on the display and the user may take them out at this time. Or if
the rechargeable batteries are kept placing at the compartments, trickle
charging will start. The trickle charging current is around 10% duty cycle
of the charging current to keep the rechargeable batteries full.
Note :
charging
The charging current of the rechargeable batteries depends on
battery condition. It cannot be selected by the user.
In case the power source terminates, the charger will reset. Once
the power source is back to normal, the batteries will be taken as
newly installed batteries in the charger.
Percentage
(Figure 4)
“Full” sign shows is fully charged
23
For proper reset, unplug the DC jack and wait for 5 seconds
before plugging it into the charger.
CARE AND MAINTENANCE:
Extreme temperatures, vibration and shock should be avoided as
these may cause the damage to the unit
When cleaning the displays and casings, use a soft damp cloth
only. Do not wet the exposed metal part of the charging unit. Do
not use solvents or scouring agents as they may mark the LCD
and casing.
Do not spill water to the charging unit.
Do not make any repair attempt to the units. Take it back to its
original point of purchase for repair by a qualified engineer.
Opening and tampering with the units may invalidate its
guarantee.
Do not expose the unit to extreme and sudden temperature
changes. This may lead to the damage to the electronic parts of
the unit.
SPECIFICATIONS:
Input voltage for AC/DC adapter : 230V AC 50Hz
Charging current : around 250mA (for each battery)
24
Max charging capacity
(capacity of rechargeable batteries): 2600mAh
Dimensions (L x H x W)
Charging unit: 66 x 109.8 x 22.3 mm
LIABILITY DISCLAIMER:
The manufacturer and supplier will not accept any responsibility
on the improper or incorrect use that makes any consequence
occur.
Any performance of repairs or alternations by any person other
than the original supplier will invalidate the warranty.
This product is designed to be used only by people who have
read and understood this instruction manual.
The specifications of this product may be subject to change
without any prior notice.
This product is not a toy. Keep the children from it.
User cannot reproduce any part of this manual without the written
consent of the manufacturer.
CAUTION - SAFETY INSTRUCTIONS :
Attention of users should be drawn to the following important
safety instructions:
25
•
As stated in the manual above, only use NiCd or NiMH
rechargeable batteries.
•
The unit is for indoor use only. Do not expose it to humidity.
Do not place it in water or submit it to rain and/or snow. Do
not store or use it near an extreme heat. Keep batteries away
from the fire.
•
Do not use any accessory not supplied with the charger. The
user should never use any power cable and transformer
other than those originally supplied with the charging unit.
•
Disconnect the AC/DC adapter when the unit is not in use.
•
Do not operate the charger if it has received a blow or has
been subject to any damage.
•
Do not use the Battery charger for other purposes than the
Only one originally forecasted.
•
Do not open or/and disassemble the charger: such handling
may result in the risk of electric shock or fire.
•
User can reset the function of the product that is subject to
the electrostatic discharge disturbance and surge. Please
follow the instruction described in this manual to reset the
function for normal operation.
