Wireless Temperature Station
Model 9245
Congratulations on purchasing this wireless 915 MHz temperature station with indoor and
outdoor temperature. With two easy to use function keys, this innovative product is ide al
for use in the home or office.
LCD displa
Function keys
User Manual
Hanging hole
Battery compartment
Stand
FEATURES:
The Temperature Station
Manual time set (hour and minute)
24-Hour Time Format
Temperature Display in Fahrenheit (°F)
Indoor and Outdoor Temperature with MIN/MAX Records
Low Battery Indicator
Wireless Transmission at 915 MHz
8 Second Signal Reception Interval
Wall Mount or Table Stand
The Outdoor Temperature Transmitter
Wireless 915 MHz Outdoor Temperature Transmitter
Rain-resistant Casing
Wall Mounting or Table Stand
Note: Mount in a sheltered place. Avoid direct rain and
sunshine.
SETUP:
Note: this temperature station can only receive one transmitter only.
1. First, insert batteries into the transmitter (see “How to install and replace
batteries in the Temperature transmitter” below).
2. Within 30 seconds of powering up the transmitter, insert batteries into the
Temperature Station (see “How to install and replace batteries in the
Temperature station” below). Once the batteries are in place, all segments of the
LCD will light up briefly. Following the i ndoor temperature, the time as 0:00 will be
displayed. If they are not shown in the LCD after 60 seconds, remove the batteries
and wait for at least 60 seconds before reinserting them. Once the indoor data is
displayed you may proceed to the next step.
3. After the batteries are inserted, the Temperature Station will start receiving outdoor
temp data from the transmitter. The outdoor temperature should then be displayed
on the Temperature station. If this does not happen after 2 minutes, remove the
batteries from both units and start again f rom step 1.
4. In order to ensure sufficient 915 MHz transmission, the outdoor transmitter should
be placed a distance of no more than 200 feet from the Temperature Station and
the transmitter (see notes on “Positioning” and “915 MHz Reception”).
HOW TO INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE STATION
The Temperature Station uses 2 x AA, IEC LR6 1.5V batteries. When batteries will need
to be replaced, the low battery icon will appear on the LCD.
To install and replace the batteries, please follow the steps
below:
1. Lift up the battery compartme nt cover.
2. Insert batteries observing the correct polarit y (see
marking).
3. Replace compartment cover.
HOW TO INSTALL / REPLACE BATTERIES IN THE OUTDOOR TRANSMITTER
The Temperature transmitter uses 2 x AAA, IEC LR3 1.5V batteries. When batteries need
to be replaced, the low battery icon will appear on the LCD of the Temperature Station. To
install and replace the batteries, please foll ow the steps below:
1. Remove the battery compartment cover.
Page 2
2. Insert the batteries, observing the correct polarity (see marking).
y
r
3. Replace the battery holder to the unit.
Note: When changing batteries in either of the units, all
reset by following the setup procedures. This is because a random
security code is assigned by the transmitter at start-up and this code
must be received and stored by the Temperature Statio n in the first few
BATTERY CHANGE:
It is recommended to replace the batteries in all units regularly to ensure optimum
accuracy of these units. (Battery life –see Specifications)
minutes of power supplying.
Please participate in the preservation o f the environment. Return used
batteries to an authorized depot.
units need to be
FUNCTION KEYS:
The Temperature Station has only two easy to use function keys:
SET ke
SET key
Press and hold for about 3 seconds to enter the Manual setting mode.
+ key
Press to make adjustment in the setting mode.
Press and hold to reset all MIN/MAX records
+ key
LCD SCREEN AND SETTINGS:
Indoor Temperature in °C
Low Battery indicato
Outdoor Temp in °C
* When the signal from the transmitter is successfully received by the Temperature Station,
this icon will be switched on. (If not successful, the icon will not be shown on the LCD).
User can therefore easily see whether the last reception was successful (“ON” icon) or not
(“OFF” icon). On the other hand, the short blinking of the icon shows that a reception is
being done at that time.
Time
(transmitter)
Low Battery indicator (temp station)
MIN/MAX Indoor temperature
Outdoor Reception Signal icon*
MIN/MAX Outdoor temperature
MANUAL TIME SET:
To manually set the time of the Temperature Station:
Hour (flashing)
1. Press and hold the SET key for 3 seconds to enter the manual time setting mode.
2. The hour digit of the time display will be flashing.
3. Press the + key to adjust the hour (press and hold to allow fast advance). Press
SET key to confirm and go to the minute setting.
4. The minute digit will be flashing. Press the + key to adjust the minute (press and
hold to allow fast advance). Press SET key once more to return to normal display.
Note: If no buttons are pressed within appr oximately 8 seconds while in setting mode, the
unit will return to normal operating mode.
Minutes (flashing)
Page 3
r
VIEWING THE INDOOR TEMPERATURE AND MIN/MAX
r
The indoor temperature is displayed in the second sect ion of the LCD along with the
indoor MIN/MAX records:
Notes:
The maximum temperature record for the MIN indoor temperature can only be up to 10ºC, and the MIN/MAX temperature resolution is 1°C.
The resolution of the indoor temper ature is 0.5ºC
MIN indoo
temperature
Indoor temperature
MAX indoor
temperature
VIEWING THE OUTDOOR TEMPER ATURE AND THE MIN/ MAX
The outdoor temperature is displayed in the last section of the LCD along with the outdoor
MIN/MAX records:
Outdoor temperature
Notes:
The minimum/maximum temperature resolution is 1°F.
The resolution of the outdoor temperature is 0.2ºF
MIN outdoo
temperature
MAX outdoor
temperature
TO RESET THE MIN/MAX DATA:
The MIN/MAX temperature can be reset manually by pressing and holding the + key for
about 3 seconds. This will reset all indoor and outdoor MIN/MAX temperature to current
indoor and outdoor temperatures.
LOW BATTERY INDICATOR
Low battery indicator is displayed on the LCD when the batteries require changing.
915 MHz RECEPTION CHECK
The Temperature Station should receive the outdoor temperature data within a few
minutes after setup. If the temperature data are not received about 2 minutes after setup
(the signal reception icon does not appear), please check the following points:
1. The distance of the Temperature Station or transmitter should be at least 1.5 to 2
meters away from any interfering sources such as computer monitors or TV sets.
2. Avoid positioning the Temperature Station onto or in the immediate proximity of
metal window frames.
3. Using other elect r ical products such as headphones or speakers operating on the
same signal frequency (915MHz) may prevent correct signal transmission and
reception.
4. Neighbors using electrical devices operating on the 915MHz signal frequency can
also cause interference.
Note:
When the 915MHz signal is received correctly, do not re-open the battery cover of either
the transmitter or the Temperature Station, as the batteries may spring free from the
contacts and force a false reset. If this happens accidentally, all units must be reset (see
Setting up above) otherwise transmission problems may occur.
The transmission range is about 200 ft. from the transmitter to the Temperature Station (in
open space). However, this depends on the surrounding environment and interference
levels. If no reception is possible despite the obse rvation of these factors, all system units
have to be reset (see Setting up above).
Page 4
POSITIONING THE TEMPERATUR E STATION:
Table standing
The Temperature Station comes attached with a table stand, which
provides the option of table standing the unit in addition to wall
mounting.
To wall mount:
Before wall mounting, please check that the outdoor temperature values
can be received from the desired locations:
1. Fix a screw (not supplied) into the desired wall, leaving the head
extended out by about 5mm.
2. Hang the Temperature Station onto the screw. Remember to
ensure that it locks into place before releasing.
POSITIONING THE REMOTE TEMPERATURE TRANSMITTER:
we recommend not to place the unit on any metal surfaces or in any position where a
large metal or highly polished surface is in the immediate vicinity (garage doors, double
The remote temperature transmitter can be placed onto any flat surface or
wall mounted using the bracket which doubles as a stand or wall mount
base.
To wall mount:
1. Secure the bracket onto a desired wall using the screws
and plastic anchors.
2. Clip the remote temperature transmi tter onto the bracket.
Note:
The mounting surface can affect the transmission range. If, for
instance, the unit is attached to a piece of metal, it may then
either reduce or increase the transmitting range. For this reason,
glazing, etc.). Before securing in place, please ensure that the Temperature Station can
receive the 915MHz signal from the temperature transmitter at the positions that you wish
to place them.
CARE AND MAINTENANCE:
Extreme temperatures, vibrations and shocks should be avoided as these may
cause damage to the unit and give inaccurate forecasts and readings.
When cleaning the display and casings, use a soft damp cloth only. Do not use
solvents or scouring agents as they may mark the LCD and casi ngs.
Do not submerge the units in water. Furthermore, fix all parts in place where the
units are adequately protected against moisture and rain.
Immediately remove all low powered batteries to avoid leakage and damage.
Replace only with new batteries of the recommended type.
Do not make any repair attempts to the unit. Return them to their original point of
purchase for repair by a qualified engineer. Opening and tampering with the unit
may invalidate their guarantee.
Do not expose the units to extreme and sudden temperature changes, this may
lead to rapid changes in forecasts and readings and thereby reduce their accuracy.
SPECIFICATIONS:
Temperature measuring range
Indoor : 14.5ºF to 139.5ºF with 0.5ºF resolution
(“OF.L” displayed if outside this range)
Outdoor : -39.8ºF to +139.8ºF with 0.2ºF resolution
(“OF.L” displayed if outside this range)
Indoor Temperature checking interval : every 20 seconds
Outdoor data checking interval : every 8 seconds
Power consumption
Temperature Station : 2 x AA, IEC LR6, 1.5V
Outdoor Temperature Transmitter : 2 x AAA, IEC LR3, 1.5V
Battery life cycle (Alkaline batteries recommended):
Temperature Station : approximately 24 months
Outdoor Temperature Transmitter : approximately 12 months
Dimensions (L x W x H)
Temperature Station : 3.14" X 5.00" X 1.14"
Outdoor Temperature Transmitter : 1.27" X 3.40" X 0.55"
Page 5
WARRANTY
La Crosse Technology, Ltd provides a 1-year limited warranty on this product against
manufacturing defects in materials and workmanship.
This limited warranty begins on the original date of purchase, is valid only on products
purchased and used in North America and only to the original purchaser of this product.
To receive warranty service, the purchaser must contact La Crosse Technology, Ltd for
problem determination and service procedures. Warranty service can only be performed
by a La Crosse Technology, Ltd authorized service center. The original dated bill of sale
must be presented upon request as proof of purchase to La Crosse Technology, Ltd or La
Crosse Technology, Ltd’s authorized service center.
La Crosse Technology, Ltd will repair or replace this product, at our option and at no
charge as stipulated herein, with new or reconditioned parts or products if found to be
defective during the limited warranty period specified above. All replaced parts and
products become the property of La Crosse Technology, Ltd and must be returned to La
Crosse Technology, Ltd. Replacement parts and products assume the remaining original
warranty, or ninety (90) days, whichever is longer. La Crosse Technology, Ltd will pay all
expenses for labor and materials for all repairs covered by this warranty. If necessary
repairs are not covered by this warranty, or if a product is examined which is not in need
or repair, you will be charged for the repairs or examination. The owner must pay any
shipping charges incurred in getting your La Crosse Technology, Ltd product to a La
Crosse Technology, Ltd authorized service center. La Crosse Technology, Ltd will pay
ground return shipping charges to the owner of the product to a USA address only.
Your La Crosse Technology, Ltd warranty covers al l defects in material and workmanship
with the following specified exceptions: (1) damage caused by accident, un reasonable use
or neglect (including the lack of reasonable a nd necessary maintenance); (2) damage
occurring during shipment (claims must be present ed to the carrier); (3) damage to, or
deterioration of, any accessory or decorative surface; (4) damage resulting from failure to
follow instructions contained in your owner’s manual; (5) damage resulting from the
performance of repairs or alterations by someone other than an authorized La Crosse
Technology, Ltd authorized service center; (6) units used for other than home use (7)
applications and uses that this product was not intended or (8) the products inability to
receive a signal due to any source of interference. This warranty covers only actual
defects within the product itself, and does not cover the cost of installation or removal from
a fixed installation, normal set-up or adjust ments, claims based on misrepresentation by
the seller or performance variations resulting from installation-related circumstances.
LA CROSSE TECHNOLOGY, LTD WILL NOT ASSUME LIABILITY FOR INCIDENTAL,
CONSEQUENTIAL, PUNITIVE, OR OTH ER SI MI LAR DAM A GES ASSOCI A TED W ITH
THE OPERATION OR MALFUNCTION OF THIS PRODUCT. THIS PRODUCT IS NOT
TO BE USED FOR MEDICAL PURPOSES OR FOR PUBLIC INFORMATION. THIS
PRODUCT IS NOT A TOY. KEEP OUT OF CHILDREN’S REACH.
This warranty gives you specific legal rights. You may also have other rights specific to
your State. Some States do not allow the exclusion of consequential or incidental
damages therefore the above exclusion of limitation may not apply to you.
R&TTE Directive 1999/5/EC
For warranty work, technical support, or information contact:
La Crosse Technology, Ltd
www.lacrossetechnology.com/support
2817 Losey Blvd. S
La Crosse, WI 54601
Summary of the Declaration of Conformity: We hereby declare that this wireless
transmission device does comply with the essential requirements of R&TTE Directive
1999/5/EC.
LIABILITY DISCLAIMER:
The electrical and electronic wastes contain hazardous substances. Disposal of
electronic waste in wild country and/or in unauthorized grounds strongly damages
the environment.
Please contact your local or/and regional authorities to retrieve the addresses of
legal dumping grounds with selective collection.
All electronic instruments must from now on be recycled. User shall take an active
part in the reuse, recycling and recovery of the electrical and electronic waste.
The unrestricted disposal of electronic waste may do harm on public health and the
quality of environment .
As stated on the gift box and lab eled on the product, reading the “User manual” is
highly recommended for the benefit o f the user. This product must however not be
thrown in general rubbish collection points.
The manufacturer and supplier cannot accept any responsibility for any incorrect
readings and any consequences that occur should an inaccurate reading take
place.
This product is designed for use in the home only as indication of the temperatur e
and other weather data.
Page 6
This product is not to be used for medical purposes or for public information.
The specifications of this product may change without prior notice.
This product is not a toy. Keep out of the reach of children.
No part of this manual may be reproduced without written authorization of the
manufacturer.
All rights reserved. This handbook must not be reproduced in any form, even in excerpts, or
duplicated or processed using electronic, mechanical or chemical procedures without written
This handbook may contain mistakes and printing errors. The information in this handbook is
regularly checked and corrections made in the next issue. We accept no liability for technical
permission of the publisher.
mistakes or printing errors, or their consequences.
All trademarks and patents are acknowledged.
Loading...
