La Crosse WS-6002U User Manual

WS-6002U

Atomic Clock

Instruction Manual

              

TABLE OF CONTENTS
Topic Page

Inventory of Contents/ Additional Equipment 3
About WWVB 3
Quick Set-Up Guide 4
Detailed Set-Up Guide
Battery Installation 5
Program Mode
Function Buttons 6
Time Zone Setting 7
DST (Daylight Saving Time) Setting 7-8
Language Selection 8
Time Setting 8
Calendar Setting 9
12/24-Hour Setting 9
Selecting °F or °C
Features & Operations
Displaying the Seconds 10
Indoor Temperature 10
Mounting 11-12
Maintenance & Care 12
Troubleshooting 12-13
Specifications 13
Warranty Information 14-15

10

2

INVENTORY OF CONTENTS

1) WS-6002U

2) Instruction manual and warranty card.

ADDITIONAL EQUIPMENT (not included)

1) Two fresh 1.5V AA batteries.

2) Three wall-hanging screws.

3) Appropriate screwdriver for screws.

ABOUT WWVB (Radio Controlled Time)

The NIST (National Institute of Standards and Technology—Time

and Frequency Division) WWVB radio station is located in Ft.
Collins, Colorado, and transmits the exact time signal continuously
throughout the United States at 60 kHz. The signal can be
received up to 2, 000 miles away through the internal antenna in
the Atomic Clock. However, due to the nature of the Earth’s
Ionosphere, reception is very limited during daylight hours. The
Atomic Clock will search for a signal every night when reception
is best. The WWVB radio station derives its signal from the NIST
Atomic clock in Boulder, Colorado. A team of atomic physicists is
continually measuring every second, of every day, to an accuracy
of ten billionths of a second per day. These physicists have created
an international standard, measuring a second as 9,192,631,770
vibrations of a Cesium-133 atom in a vacuum. This Atomic Clock
regulates the WWVB transmitter.

3

QUICK SET-UP GUIDE

1) Insert two AA batteries into the Atomic Clock.

2) Wait 15 minutes for WWVB reception.

3) If there is no WWVB reception, manually set the time and date
(instructions in the Program Mode).

4) Program the settings.

5) Mount the WS-6002U in a suitable location, where WWVB
signals can be received.

4

DETAILED SET-UP GUIDE

I) BATTERY INSTALLATION

Note: To avoid start-up problems make sure that the batteries
do not spring free.

Battery Compartment

SET

Battery Cover

A) ATOMIC CLOCK

1) Remove the battery cover, located on the backside of the
function buttons.

2) Observe the correct polarity, and install 2 AA batteries.

3) Replace the battery cover.

Note: After the batteries have been installed all the LCD’s
(Liquid Crystal Display) will briefly light up. Then the indoor
temperature, the date as “1/ 1” and the weekday as “MON”
will be displayed. Also, the time will appear as “-:--” for
approximately 1 minute. Then the WWVB search is
automatically initiated, and a tower icon appears and flashes
with the time colon (no tower icon will appear if the WWVB is
too weak to be detected). While the WWVB search is being
conducted various numbers will appear in the time display.
The numbers “0”, “1”, or “8” will appear in the hour position
and the seconds will appear in the minute display. The Atomic
Clock will either display the WWVB time, or discontinue the

5
