Warranty
La Crosse Technology, Ltd. provides a 1-year limited time warranty (f ro m date
of purchase) on this product relating to manufacturing defects in mater ial s &
workmanship.
Before returning a product, please contact our friendly customer
support with questions or visit our online he lp (manuals and
FAQS):
Phone: 1-608-785-7920
Email Support: http://www.lacrossetechnology.com/support/alerts/
Register Product:
http://www.lacrossetechnology.com/support/register/
Full warranty details online:
http://www.lacrossetechnology.com/warranty_info.pdf
Warranty Address: Protected under U.S. Patents:
La Crosse Technology , Ltd 5,978,738 | 6,076,044 |RE43903
2830 S. 26
th
St.
La Crosse, WI 54601
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designe d to
provide reasonable protection against harmful inter ference in a residential
installation. This equipment generates , uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruc ti o ns , may
cause harmful interference to radio communications. How e ver, there is no
guarantee that interference will not occur in a particular ins tallation. If this
equipment does cause harmful interference to radio or televisio n reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and rece iver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help .
This device must not be co-located or operating in conjunction with any other
antenna or transmitter. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Caution!
The manufacturer is not responsible for any radio or TV interference ca used by
unauthorized modifications to this equipment. S uch modifications could void the
user authority to operate the equipment.
All rights reserved. This manual may not be reproduced in any form, even in part,
or duplicated or processed using electronic, mecha nic al or chemical process
without the written permission of the publisher .
This booklet may contain errors or misprints. The informatio n it co ntains is
regularly checked and corrections are included in sub seq ue nt ed itio ns . W e disclaim
any responsibility for any technical error or printing e rr or , or their consequences.
All trademarks and patents are recognized. DC: 12/16/2014
Model: TX70U-IT
Quick Start Guide
Pkg:
AddOn Sensor
System Requirements
Smartphone or tablet (mobile device) with Safari on iOS 6+, or
Chrome/Stock on Android 4.0+ (versions subject to change - see
recent at http://support.lacrossealertsmobile.com/requirements
)
Package Contents
1. Sensor TX70U-IT
2. Probe – Water sensor plate (recommended use)
3. Screws & anchors
4. Quick Start Guide (this document)
Not Included
• Mobile device with cellular or wifi service (see
http://www.lacrossetechnology.com/disclaimers/
)
• High speed internet service and router
• 2 AAA IEC LR03 1.5V alkaline batteries
• Two-sided tape (for water sensors only)
• GW1000-U gateway, KA12A200010023U 20V power
adaptor, and cat5 LAN cable
Mobile Application (available online)
• iOS App Store, search La Crosse Alerts Mobile
• Android Play Store, search La Crosse Alerts Mobile
Gateway Hardware Cabling (if not registered*)
• Connect LAN
cable between router &
gateway.
• Insert a/c power
in gateway.
• Watch for 4 red
blinks (if not, see
diagnose gateway)
*a registered gateway shows a solid red light (verif y exi st i n g
status before add sensor)
TX70U-IT http://www.support.lacrossealertsmobile.com TX70U-IT http://www.support.lacrossealertsmobile.com
Sensor Preparation
• Insert (optional)
probe in socket)
• Insert 2 AAA
batteries, see
polarity inside
case
Download La Crosse Mobile App
• iOS App Store, search La Crosse Alerts Mobile
• Android Play Store, search La Crosse Alerts Mobile
Follow directions on the mobile device screen to register;
for assistance, review help within the application.
Factory Reset
(try before support request on unregistered pieces)
Gateway – remove a/c, hold gray button, reinsert a/c, release
button after see: red light on – red light off – red light on; try
registration when red light shows 4 blinks
Sensor – press and hold gray button until segments fill with
18.88; try registration when counting begins
Diagnose Gateway Lights
1 blink – LAN cable missing; cable or port bad
2 blinks – no internet protocol (IP) address from router
3 blinks – no DNS resolve; aka can’t find server
4 blinks – ready to register
Both Blink – existing registration not deleted
No Lights – check a/c power or factory reset
Solid Red – registered gateway
Contact Support
Submit a request for email response at
http://www.lacrossetechnology.com/support/alerts/
Resources
• Product Info: http://www.lacrossealertsmobile.com
• Online help: http://support.lacrossealertsmobile.com
• Email Support:
http://www.lacrossetechnology.com/support/alerts/
• Phone: 608-785-7920
Notes (e.g. record gateway ID, user account name):
____________________________________________________
____________________________________________________
____________________________________________________
____________________________________________________
Specifications
Sensor RF Range 200 feet (60.96m) open space
Temperature -40
o
F to 140oF with 0.2o resolution
Probe (optional) -40
o
F to 140oF with 0.2o resolution
Water H20 or Dry
Size 5.23” H x 0.76” W x 1.44” D
Care and Maintenance
• Do not mix old and new batteries
• Do not mix Alkaline, Standard, Lithium or Rechargeable
Batteries
• Always purchase the correct size and grade of battery most suitable
for intended use.
• Replace a ll batteries of a set at the same time.
• Clea n the battery contacts and also those of the device prior to
battery installation.
• Ensure the batteries are installed with correct polarity (+and -).
• Rem ove batteries from equ ip m ent which is not to be used for an
extended period of time.
• Remov e expired batteries promptly.
TX70U-IT http://www.support.lacrossealertsmobile.com TX70U-IT http://www.support.lacrossealertsmobile.com
