MINI LABROLLER ROTATOR
User Manual
H5500
H5500-230V-EU
Lit M00056 Rev. 1 April, 2012
H5500-230V-UK
1.0 GENERAL SPECIFICATIONS
Electrical requirements:
115 volt model 115V ±10% 50/60Hz, 0.03A
230 Volt model 230V ± 10% 50/60Hz, 0.015A
Speed:
115 volt model 24 rpm
230 Volt model 20 rpm
Motion Rotating
Maximum Capacity
H5500-02 36 x 1.5ml or 2.0 ml tubes
H5500-15 10 x 15ml tubes
12 x 5/7ml tubes
H5500-50 6 x 50 ml tubes
Dimensions WxLxH 21.3 X 10.2 X 12.6 cm
Included accessories Rotisserie 36 x 1.5ml or 2.0 ml tubes
(H5500-02)
Weight 0.8 kg
Operating conditions 4ºC to 65ºC, up to 85% RH, non-
condensing
2.0 INSTALLATION OF THE ROTATOR
2.1 UNPACKING
Before starting the installation, carefully examine the rotator:
Open the box and carefully remove the padding. Check to see that
the rotator has not been damaged during transportation. Keep the
packing material until you are sure the rotator works properly.
Make sure that all of the accessories are included.
Carefully lift the unit from the box.
Be sure that the following information is included on the serial number
located on the bottom of the unit: Serial number, Product number,
Electrical rating.
Check that the power cord has the correct configuration that matches
the outlet according to your local standards.
If any damage occurred during transportation, contact your carrier
immediately.
2.2 STARTING UP THE ROTATOR
Place the rotator on a level and stable surface. Connect the plug into a
grounded outlet. Avoid lines where line surges may occur, i.e.
refrigerators and similar devices are connected, Use the on/off switch to
control the rotator.
1
Use caution when plugging into a grounded outlet!
DO NOT touch the plug with wet hands!
DO NOT unplug the unit by pulling the power cord!
3.0 LOADING THE ROTISSERIE
The rotisserie supplied with the unit is designed to hold
standard 1.5ml or 2.0ml microcentrifuge tubes (Fig 1).
There are two other rotisseries available separately for
different size tubes. Each rotisserie consists of a
rotisserie plate with bar keys for placement into the
apparatus and a two piece rotisserie rod with bar key
Figure 1
on either end.
Install the rotisserie rod by screwing the two elements together through the hole
in the center of the rotisserie plate. Insert the tubes into the tube holders. Mount
the rotisserie in the apparatus in either the vertical position, using the rotisserie
rod, or the horizontal position, using the bar keys on the plate. The side opposite
to the driving mechanism is flexible to allow inserting the rotisserie without tools.
Insert the bar key on the rotisserie rod or plate into the drive mechanism. The
other end of the rotisserie is suspended in the bushing located in the opposite
side of the unit. Be sure to distribute tubes evenly across the rotisserie carrier to
achieve smooth rotating motion.
2.1 Tumbling
To create tumbling motion, load the tubes and mount
the rotisserie so the tubes are held in a vertical position.
Legs supporting
the rotator when
set to create
tumbling motion
Then rest the unit on its end making sure that it is
supported by the black side legs (Fig.2). The unit can
be rested on either end. Setting the unit on the end with
the power switch will create more vigorous tumbling
motion than when it is rested on the opposite end.
Figure 2
2.2 Mixing Plates
Any of the rotisseries can be used for mixing in
microplates. Remove the rotisserie rod if it is installed.
Seal the microplates completely to avoid leakage. Make
sure the microplate lines up with locking dimples.
Fasten the plate (or plates) with rubber bands or small
bungee cords (not supplied with the unit). Maximum of
Figure 3
two deep well plates can be mixed at a time. For all
2
other types of motion, two plates should be placed on the rotisserie for proper
balance.
4.0 ROUTINE MAINTANCE/ CLEANING
No routine maintenance or lubrication is required
Keeping the rotator clean will the help to maintain it in proper operating
condition.
4.1 CLEANING
The outside housing can be cleaned with a soft, damp cloth when needed.
DO NOT use any aggressive or abrasive cleaners (acetone, nitro, polish etc.).
This may permanently damage the rotator finish.
Before cleaning the rotator, always unplug the power cord.
Warnings:
DO NOT use the rotator near water sources. Be sure that water
does not get on the device, especially during cleaning procedures.
DO NOT expose the rotator to aggressive solvents.
Hazardous samples should be mixed only in appropriate
containment vessels.
DO NOT mix flammable or explosive samples!
NOTE: Misuse or unauthorized modifications will waive the warranty rights.
If the equipment is used in a manner not specified by the manufacture, the
safety features of the rotator may be impaired
5.0. TROUBLESHOOTING GUIDE / SERVICE
Be sure to disconnect the rotator from the main power source immediately in
case of any signs of malfunction and contact Labnet International, Inc. Service
Department at (732) 417-0700; Monday through Friday; 8.30a.m. - 5.00p.m.
EST.
Problem Explanation / Solution
Rotator does not START Check the power connection,
Check if the rotisserie is properly
inserted into the drive mechanism
Call Labnet Service Department
3
6.00 APPENDIX
6.1 Symbols and Conventions
The following chart is an illustrated glossary of the symbols that may be used in
this manual or on the product.
The electrical warning indicates the presence of a potential hazard which could
result in electrical shock.
CAUTION This symbol refers you to important operating and maintenance
(servicing) instructions within the product Instruction Manual. Failure to heed this
information may present a risk of damage or injury to persons or equipment.
This symbol identifies a Protective Earth (PE) terminal, which is provided for
connection of the supply system’s protective earth (green or green/yellow)
conductor.
EQUIPMENT DISPOSAL
This equipment is marked with the crossed out wheeled bin symbol to
indicate that this equipment must not be disposed of with unsorted waste.
Instead it’s your responsibility to correctly dispose of your equipment at
lifecycle-end by handing it over to an authorized facility for separate collection
and recycling. It’s also you responsibility to decontaminate the equipment in
case of biological, chemical and/or radiological contamination, so as to
protect from health hazards the persons involved in the disposal and
recycling of the equipment.
For more information about where you can drop off your waste equipment,
please contact your local dealer from whom you originally purchased this
equipment.
By doing so, you will help to conserve natural and environmental resources and you will
ensure that your equipment is recycled in a manner that protects human health.
Thank you
Labnet International, Inc,.
31 Mayfield Ave., Edison, NJ 08837
(P) +732-417-0700 (F) +732-417-1750
Email: labnetinfo@corning.com
www.labnetinternational.com
4
Declaration of Conformity
Number: CE 00056
Manufacturer: Labnet International, Inc,., 31 Mayfield Ave., Edison, NJ 08837 USA
Labnet International declares that the devices described below are in conformity
with the EC directives listed. In the event of unauthorized modification of any of the
devices listed below, this declaration becomes invalid.
Device Name:
Device Models Numbers:
H5500-230V-EU
H5500-230V-UK
Relevant EC Directives: Low Voltage Directive 2006/95/EC
EMC Directive 2004/108/EC
WEEE 2002/96/EC
Harmonized Standards: IEC 61010-1 Issued:2001/02/01Ed:2
IEC 61326-1 Issued:2005/12/0 Ed:1.0
IEC 61000-3-2:2000
IEC 61000-3-3:2002
IEC 61000-4-2:2001
IEC 61000-4-3:2002
IEC 61000-4-4:2004
IEC 61000-4-5:2001
IEC 61000-4-6:2003
IEC 61000-4-11:2004
Date: March 21, 2012
______________________________
Amin Brihmat
Global Marketing Manager
Mini LabRoller Rotator
