Labconco Rear Interior Storage Shelf User Manual

LABCONCO CORPORATION 8811 Prospect Ave, Kansas City, MO 64132

[phone], Fax [phone]

Rear Interior Storage Shelf Kit No. 5235000

Operation

The Rear Interior Storage Shelf placed in the glove box main chamber maximizes usable space
by adding 240 square inches of storage space or an additional 25%. Bin organizers can be added
and hang from the slots on the rear shelf kit. Not all the shelves need be used, the user may
choose how many shelves are installed. Follow the installation procedure below to assemble the
rear shelf kit.

Installation Procedure

1. The Rear Interior Storage Shelf Kit consists of the rear slotted back panel, right and left

uprights, two shelves, and one bottom shelf. The shelf kit can be assembled inside the
main chamber of the glove box by bringing all the components through the transfer
chamber. Alternatively, the front view window may be temporarily removed to insert the
fully assembled shelf kit.

2. Identify the two uprights, both left and right, along with the rear slotted back shelf and

screws. Remove the protective paper film from all the stainless steel parts. Assemble the
rear slotted shelf on to the two uprights by pushing the shelf with the left and right side
tabs oriented downwards, through the upper slots in the two uprights. Push the shelf
downwards to lock in place. Install a screw on both sides to secure.

3. Next, assemble the lower and middle shelves as needed by pushing the shelf through the

slots in the uprights and push down to lock in place. Install screw on both sides to secure.
A minimum of two shelves are required and you may omit shelves to store taller items or
use hanging bins.

4. Place the shelf kit in the rear of the glove box interior with the lower front ledge resting on

the black work surface and the back ledge resting on the glove box liner.

5. Installation is now complete.
