Labconco Protector XLE Fume Hoods User Manual

User’s Manual

Protector
Laboratory Fume Hoods

®

XLE

Models
9970400, 9970401, 9970500, 9970501, 9970600,
9970601, 9970700, 9970701, 9970800, 9970801

To receive important product updates,

complete your product registration card

online at register.labconco.com

Labconco Corporation
8811 Prospect Avenue
Kansas City, MO 64132-2696
800-821-5525, 816-333-8811
FAX [phone]
E-MAIL [e-mail]
HOME PAGE www.labconco.com

Please read the User’s Manual before operating the equipment.

Copyright © 2006, 2007 Labconco Corporation. All rights reserved.

The information contained in this manual and the accompanying products are copyrighted and all rights
reserved by Labconco Corporation. Labconco Corporation reserves the right to make periodic design
changes without obligation to notify any person or entity of such change.

Warranty

Labconco provides a warranty on all parts and factory workmanship. The warranty includes areas of
defective material and workmanship, provided such defect results from normal and proper use of the
equipment.

The warranty for all Labconco products will expire one year from date of installation or two years
from date of shipment from Labconco, whichever is sooner, except the following;

• Purifier® Delta® Series Biological Safety Cabinets and PuriCare® Lab Animal Research
Stations carry a three-year warranty from date of installation or four years from date of
shipment from Labconco, whichever is sooner.

• SteamScrubber® & FlaskScrubber® Glassware Washers carry a two-year warranty from
date of installation or three years from date of shipment from Labconco, whichever is sooner.

• Blood Drawing Chairs carry a ten year warranty.

• Carts carry a lifetime warranty.

• Glassware is not warranted from breakage when dropped or mishandled.

This limited warranty covers parts and labor, but not transportation and insurance charges. In the
event of a warranty claim, contact Labconco Corporation or the dealer who sold you the product. If
the cause is determined to be a manufacturing fault, the dealer or Labconco Corporation will repair or
replace all defective parts to restore the unit to operation. Under no circumstances shall Labconco
Corporation be liable for indirect, consequential, or special damages of any kind. This statement may
be altered by a specific published amendment. No individual has authorization to alter the provisions
of this warranty policy or its amendments. Lamps and filters are not covered by this warranty.
Damage due to corrosion or accidental breakage is not covered.

Returned or Damaged Goods

Do not return goods without the prior authorization from Labconco. Unauthorized returns will not be
accepted. If your shipment was damaged in transit, you must file a claim directly with the freight carrier.
Labconco Corporation and its dealers are not responsible for shipping damages.

The United States Interstate Commerce Commission rules require that claims be filed with the delivery
carrier within fifteen (15) days of delivery.

Limitation of Liability

The disposal and/or emission of substances used in connection with this equipment may be governed by
various federal, state, or local regulations. All users of this equipment are required to become familiar with
any regulations that apply in the user’s area concerning the dumping of waste materials in or upon water,
land, or air and to comply with such regulations. Labconco Corporation is held harmless with respect to
user’s compliance with such regulations.

Contacting Labconco Corporation

If you have questions that are not addressed in this manual, or if you need technical assistance, contact
Labconco’s Customer Service Department or Labconco’s Product Service Department at 1-800-821-5525
or 1-816-333-8811, between the hours of 7:00 a.m. and 6:00 p.m., Central Standard Time.

Part #9962000, Rev. B

ECO E618

T

AABBLLEE

T

CHAPTER 1: INTRODUCTION 1
About This Manual 2
Typographical Conventions 3

CHAPTER 2: PREREQUISITES 5
Location Requirements 6
Support Requirements 6
Exhaust Requirements 6
Electrical Requirements 7
Service Line Requirements 7
Space Requirements 7

CHAPTER 3: GETTING STARTED 8
Unpacking Your Laboratory Fume Hood 9
Removing the Shipping Skid 9
Sash Weight Release 10
Install the Protector XLE Hood on a Supporting Structure
and Work Surface 10
Connecting to the Protector XLE Hood Exhaust System 11
Connecting the Electrical Supply Source to the Protector
XLE Fume Hood 12
Connecting the Service Lines to the Protector XLE

Sealing the Protector XLE Fume Hood to the Work Surface 15
Certifying the Protector XLE Fume Hood 15

CHAPTER 4: PERFORMANCE FEATURES AND SAFETY

Performance Features 16
Safety Precautions 19

CHAPTER 5: USING YOUR PROTECTOR XLE 21
Operating the Vertical-Rising Sash 21
Operating the Blower 21
Operating the Lights 21
Working in Your Protector XLE Fume Hood 21

O

O

Fume Hood 14

PRECAUTIONS 16

FF

C

C

OONNTTEENNTTSS

CHAPTER 6: MAINTAINING YOUR PROTECTOR XLE 23
Routine Maintenance Schedule 23
Routine Service Operations 24

CHAPTER 7: MODIFYING YOUR PROTECTOR XLE 25
Installing Work Surfaces 25
Installing Ceiling Enclosures Above the Fume Hood 26
Installing Additional Service Fixtures 26
Installing Airflow Monitors 27
Distillation Grids – Field Installation 27
Installing an Electrical Duplex Receptacle 28

CHAPTER 8: TROUBLESHOOTING 29

APPENDIX A: PROTECTOR XLE COMPONENTS 32

APPENDIX B: PROTECTOR XLE DIMENSIONS 35

APPENDIX C: PROTECTOR XLE SPECIFICATIONS 36

Environmental Conditions 36

APPENDIX D: REFERENCES 38

DECLARATION OF CONFORMITY 41

CChhaapptteerr 11::
IInnttrroodduuccttiioonn

Congratulations on your purchase of a Labconco Protector® XLE Laboratory
Fume Hood. Your Protector XLE Fume Hood is designed to protect you. It is the
result of Labconco’s more than 50 years experience in manufacturing fume hoods,
and users like you suggested many of its features to us.

The Labconco Protector XLE Fume Hood has been engineered to provide
maximum visibility in a laboratory, and effectively contain toxic, noxious, or
other harmful materials when properly installed. The Protector offers many
unique features to enhance safety, performance, and visibility. To take full
advantage of them, please acquaint yourself with this manual and keep it handy
for future reference. If you are unfamiliar with how fume hoods operate, please
review Chapter 4: Performance Features and Safety Precautions before you
begin working in the fume hood. Even if you are an experienced fume hood user,
please review Chapter 5: Using Your Protector XLE, which describes your
Protector Hood’s features so that you can use the hood efficiently.

Product Service 1-800-522-7658

1

Chapter 1: Introduction

About This Manual

This manual is designed to help you learn how to install, use, and maintain your
laboratory fume hood. Instructions for installing optional equipment on your
hood are also included.

Chapter 1: Introduction provides a brief overview of the laboratory fume hood,
explains the organization of the manual, and defines the typographical
conventions used in the manual.

Chapter 2: Prerequisites explains what you need to do to prepare your site before
you install your laboratory fume hood. Electrical and service requirements are
discussed.

Chapter 3: Getting Started contains the information you need to properly unpack,
inspect, install, and certify your laboratory fume hood.

Chapter 4: Performance Features and Safety Precautions explains how the
Protector operates and the appropriate precautions you should take when using the
fume hood.

Chapter 5: Using Your Protector XLE discusses the basic operation of your fume
hood. Information on how to prepare, use and shut down your Protector Hood are
included.

Chapter 6: Maintaining Your Protector XLE explains how to perform routine
maintenance on your fume hood.

Chapter 7: Modifying Your Protector XLE explains how to modify the fume
hood or add accessories.

Chapter 8: Troubleshooting contains a table of problems you may encounter
while using your laboratory fume hood including the probable causes of the
problems and suggested corrective actions.

Appendix A: Protector XLE Components contains labeled diagrams of all of the
components of the fume hoods.

Appendix B: Protector XLE Dimensions contains comprehensive diagrams
showing all of the dimensions for the laboratory fume hoods.

Appendix C: Protector XLE Specifications contains the electrical requirements for
laboratory fume hood. Wiring diagrams are also included.

2

Product Service 1-800-522-7658

)

4'

8'

!

5'

6'

S

A

Chapter 1: Introduction

Appendix D: References lists the various resources available that deal with
laboratory fume hoods.

Typographical Conventions

Recognizing the following typographical conventions will help you understand
and use this manual:

• Book, chapter, and section titles are shown in italic type (e.g., Chapter 3:
Getting Started).

• Steps required to perform a task are presented in a numbered format.

• Comments located in the margins provide suggestions, reminders, and

references.

• Critical information is presented in boldface type in paragraphs that are
preceded by the exclamation icon. Failure to comply with the information
following an exclamation icon may result in injury to the user or permanent
damage to fume hood.

• Critical information is presented in boldface type in paragraphs that are
preceded by the wrench icon. These operations should only be performed by
a trained certifier or contractor. Failure to comply with the information
following a wrench icon may result in injury to the user or permanent damage
to your hood.

• Important information is presented in capitalized type in paragraphs that are
preceded by the pointer icon. It is imperative that the information contained
in these paragraphs be thoroughly read and understood by the user.

• A number icon precedes information that is specific to a particular model of
laboratory fume hood. The 4' icon indicates the text is specific to the 4-foot
wide model. The 5' icon indicates the text is specific to the 5-foot model, etc.

• The S icon indicates the text is specific to the standard model.

• The A icon indicates the text is specific to the A-Style Combination Sash

Model.

Product Service 1-800-522-7658

3

Chapter 1: Introduction

Your Next Step

If your Fume Hood needs to be installed, proceed to Chapter 2: Prerequisites to
ensure your installation site meets all of the requirements. Then, go to Chapter 3:
Getting Started for instructions on how to install your laboratory fume hood and
make all of the necessary connections.

If you would like to review how laboratory fume hoods operate, go to Chapter 4:
Performance Features and Safety Precautions.

For information on the operational characteristics of your laboratory fume hood,
go to Chapter 5: Using Your Protector XLE.

If your laboratory fume hood is installed and you need to perform routine
maintenance on the cabinet, proceed to Chapter 6: Maintaining Your Protector
XLE.

For information on making modifications to the configuration of your fume hood,
go to Chapter 7: Modifying Your Protector XLE.

Refer to Chapter 8: Troubleshooting if you are experiencing problems with your
fume hood.

4

Product Service 1-800-522-7658

CChhaapptteerr 22::
PPrreerreeqquuiissiitteess

Before you install your laboratory fume hood, you need to prepare your site for
installation. Carefully examine the location where you intend to install your
hood. You must be certain that the area is level and of solid construction. In
addition, a dedicated source of electrical power must be located near the
installation site.

Carefully read this chapter to learn the requirements for your installation site:

• The location requirements.

• The support requirements.

• The exhaust requirements.

• The electrical power requirements.

• The service line requirements.

• The space requirements.

Refer to Appendix B: Protector XLE Dimensions for complete fume hood
dimensions.

Refer to Appendix C: Protector XLE Specifications for complete laboratory fume
hood electrical and environmental conditions, specifications and requirements.

Product Service 1-800-522-7658

5

Chapter 2: Prerequisites

Location Requirements

The fume hood should be located away from traffic patterns,

!

doors, windows, fans, ventilation registers, and any other air­handling device that could disrupt its airflow patterns. All
windows in the room should be closed.

Support Requirements

DO NOT install the fume hood on a cart, dolly, or mobile

!

bench. ALL Protector Hood installations must be permanent
and stationary. The supporting structure usually consists of a
base cabinet or stand and chemically-resistant work surface.

Exhaust Requirements

The exhaust duct connection has been designed for 12" nominal duct (12.75" OD)
to allow for minimum static pressure loss while operating at 100 fpm face
velocities. The 12" diameter exhaust duct also allows for proper transport
velocities away from the hood in the 1000 fpm to 2500 fpm range. The proper
exhaust volume and static pressure loss are listed for each hood model:

Latched Sash Full Open 28"

Hood

Size

4' 48" Protector XLE Hood 60 fpm 470 CFM 0.07" H2O

80 fpm 630 CFM 0.12" H2O
100 fpm 790 CFM 0.19" H2O

5' 60" Protector XLE Hood 60 fpm 620 CFM 0.10" H2O

80 fpm 830 CFM 0.18" H2O
100 fpm 1040 CFM 0.28" H2O

6' 72" Protector XLE Hood 60 fpm 770 CFM 0.12" H2O

80 fpm 1020 CFM 0.21" H2O
100 fpm 1280 CFM 0.33" H2O

7' 84" Protector XLE Hood 60 fpm 920 CFM 0.07" H2O

80 fpm 1220 CFM 0.12" H2O
100 fpm 1530 CFM 0.19" H2O

8’ 96" Protector XLEHood 60 fpm 1070 CFM 0.08" H2O

80 fpm 1420 CFM 0.14" H2O
100 fpm 1780 CFM 0.22" H2O

Standard Model Description Face Velocity

Exhaust

Volume

Static

Pressure Loss

6

Product Service 1-800-522-7658

Chapter 2: Prerequisites

Self-Closing 60% Sash Opening 18"

Hood

Size

4' 48" Protector XLE Hood 60 fpm 310 CFM 0.03" H2O

80 fpm 420 CFM 0.06" H2O
100 fpm 520 CFM 0.09" H2O

5' 60" Protector XLE Hood 60 fpm 410 CFM 0.04" H2O

80 fpm 550 CFM 0.08" H2O
100 fpm 690 CFM 0.12" H2O

6' 72" Protector XLE Hood 60 fpm 510 CFM 0.06" H2O

80 fpm 680 CFM 0.10" H2O
100 fpm 850 CFM 0.15" H2O

7' 84" Protector XLE Hood 60 fpm 610 CFM 0.03" H2O

80 fpm 820 CFM 0.06" H2O
100 fpm 1020 CFM 0.09" H2O

8’ 96" Protector XLE Hood 60 fpm 710 CFM 0.04" H2O

80 fpm 940 CFM 0.06" H2O
100 fpm 1180 CFM 0.10" H2O

Standard Model Description Face Velocity

Exhaust

Volume

Static

Pressure Loss

Proper blower selection can be determined from these exhaust requirements and
the total system static pressure loss. Contact Labconco Customer Service for
assistance in sizing a blower system.

Electrical Requirements

The Protector Hood models feature internal wiring for the fluorescent light
assembly and light switch. All internal wiring is terminated at the single point
wiring junction box for hook-up by a qualified electrician. The blower switch,
and light switch wires are also terminated at the single point wiring junction box
for hook-up by a qualified electrician. Refer to Chapter 3: Getting Started and
Appendix C: Protector XLE Specifications for the wiring diagram for proper
electrical installation.

Service Line Requirements

All service lines to the laboratory fume hood should be a minimum of 1/4"
outside diameter (3/8" diameter for a cold water gooseneck), copper (brass for
natural gas), and equipped with an easily accessible shut-off valve, should
disconnection be required. If the service line pressure exceeds 40 PSI, it must be
equipped with a pressure regulator to reduce the line pressure. Please check with
local codes for other requirements.

Space Requirements

The dimensions for the different models are shown in Appendix B: Protector XLE
Dimensions.

Your Next Step

After you have determined that the location you have selected accommodates the
installation and operational requirements of your fume hood, you are ready to
begin installation. Proceed to Chapter 3: Getting Started.

Product Service 1-800-522-7658

7

CChhaapptteerr 33::
GGeettttiinngg SSttaarrtteedd

Now that the site for your laboratory fume hood is properly prepared, you are
ready to unpack, inspect, install, and certify your unit. Read this chapter to learn
how to:

• Unpack and move your Protector Hood.

• Set up the fume hood with the supporting structure and work surface.

• Connect to an exhaust system.

• Connect the electrical supply source.

• Connect the service lines.

• Sealing the Protector Hood to the work surface.

• Arrange certification of your Protector Hood.

Depending upon which model you are installing, you may need common
plumbing and electrical installation tools in addition to 5/16", 3/8", 7/16", and
1/2" wrenches, ratchets, sockets, a nut driver set, a flat-blade screwdriver, a
Phillips screwdriver, and a carpenter level to complete the instructions in the
chapter.

The Protector XLE Hood models weigh between 400 to 800 lbs.
(182-363 kg). The shipping skid allows for lifting with a

!

mechanical lift truck or floor jack. If you must lift the fume
hood manually, follow safe-lifting guidelines. Normally, the
fume hood can be slid off a hydraulic lift table and be placed

into position on top of the work surface. Do not lift by the

front air foil and trough assembly.

8

Product Service 1-800-522-7658

The United
States Interstate
Commerce
Commission
rules require
that claims be
filed with the
delivery carrier
within fifteen
(15) days of
delivery.

Chapter 3: Getting Started

Unpacking Your Laboratory Fume Hood

Carefully remove the shrink-wrap or carton on your fume hood and inspect it for
damage that may have occurred in transit. If your unit is damaged, notify the
delivery carrier immediately and retain the entire shipment intact for inspection
by the carrier.

DO NOT RETURN GOODS WITHOUT THE PRIOR
AUTHORIZATION OF LABCONCO. UNAUTHORIZED

)

)

Do not discard the shipping skid or packing material for your fume hood until you
have checked all of the components and installed and tested the unit.

Do not remove the fume hood from its shipping skid until it is ready to be placed
into its final location. Move the unit by placing a flat, low dolly under the
shipping skid, or by using a floor jack.

!

RETURNS WILL NOT BE ACCEPTED.

IF YOUR HOOD WAS DAMAGED IN TRANSIT, YOU MUST
FILE A CLAIM DIRECTLY WITH THE FREIGHT CARRIER.
LABCONCO CORPORATION AND ITS DEALERS ARE NOT
RESPONSIBLE FOR SHIPPING DAMAGES.

Do not move the hood by tilting it onto a hand truck.

Removing the Shipping Skid

LEAVE THE FUME HOOD ATTACHED TO ITS SHIPPING

)

After you verify the fume hood components, move your hood to the location
where you want to install it. Should you require disassembly to move the hood,
then follow the instructions in Appendix E. Then, follow the steps listed next to
remove the shipping skid from your unit.

1. Remove the side panels by unscrewing the Phillips screws.

Product Service 1-800-522-7658

SKID UNTIL IT IS AS CLOSE TO ITS FINAL LOCATION AS
POSSIBLE. MOVE THE HOOD BY USING A SUITABLE
FLOOR JACK, OR BY PLACING A FURNITURE DOLLY
UNDERNEATH THE SKID. DO NOT MOVE THE HOOD BY
TILTING IT ONTO A HAND TRUCK.

9

Chapter 3: Getting Started

2. Find the hardware (bolts, washers, nuts) that attach the fume hood to
the skid and remove the hardware. Some hardware is on the sides and
some is on the back.

Sash Weight Release

To protect the fume hood from damage in shipment, the sash weight has been
secured to the back of the fume hood with four (4) screws. Simply remove the
screws and make sure the sash cables are on their respective pulleys before
operation of the sash or damage could occur to the sash cable.

NOTE: THE SASH WEIGHT ITSELF WAS INDIVIDUALLY

)

MATCHED FOR THIS SPECIFIC HOOD AND SHOULD NOT BE
EXCHANGED ON ANY OTHER UNIT.

Install the Protector XLE Hood on a
Supporting Structure and Work Surface

The Protector Hood is heavy! Use caution when lifting or

!

When installing the Protector Fume Hood onto a chemically-resistant work
surface or benchtop, ensure that the structure can safely support the combined
weight of the fume hood and any related equipment. The work surface should be
at least as wide as the hood to properly support it. The work surface is aligned

flush with the back of the fume hood for good airflow: this will provide the
correct spacing under the air foil for proper bypass airflow. The front edge
of the trough assembly under the air foil should be located flush with front of
the supporting base cabinet or stand.

!

The following are instructions for mounting a cross support:

1. Level the base cabinets and the work surface. Work surface should be

2. Scribe a line on the wall or back of the base cabinet to locate the

3. Mount the support by attaching it to the wall or base cabinet.

4. Place the hood on top of the work surface and cross support.

moving the unit.

WARNING: It is important to support the rear of the work
surface and fume hood. The cross support provides support
for the bottom of the work surface. Install the cross support
after the base cabinets and work surface are leveled and before
installing the hood.

placed flush with the back of the fume hood as shown in Figure 3-1.

support under the work surface.

10

Product Service 1-800-522-7658

Chapter 3: Getting Started

The work surface should be smooth and durable, such as a chemically-resistant
epoxy resin. The surface should be nonporous and resistant to the acids, solvents,
and chemicals used in conjunction with the Protector Fume Hood. The work
surface should also contain a dished recessed area for containing primary spills.

Figure 3-1

Connecting to the Protector XLE Hood
Exhaust System

WARNING: The weight of the exhaust ductwork system must
be supported independently of the hood superstructure. Do

!

Product Service 1-800-522-7658

not allow this weight to be supported by the hood structure as
damage to the hood may occur.

11

Chapter 3: Getting Started

The exhaust connection on your hood has been designed for 12" nominal pipe
(12.75" OD) to allow for minimum static pressure loss with proper transport
velocities away from the hood. Consult Labconco Customer Service should you
require help sizing your blower for the exhaust volume and total system static
pressure loss.

!

The exhaust connection should be installed by a qualified
HVAC contractor.

The selected exhaust duct material should match the hood
procedures and chemicals used to ensure compatibility.

Connecting the Electrical Supply Source
to the Protector XLE Fume Hood

Prior to connecting any electrical wiring to the fume hood structure, refer to the
hood identification plate for the proper electrical requirements of your specific
model.

WARNING: The building electrical supply system for

!

The identification plate, model number, serial number, and electrical connection
boxes are accessible from the front of the fume hood by removing the front panel.

The Protector XLE Hood is normally wired for 115 Volt, 60 Hz, 20 Amp or
230Volt, 50 Hz, 10 Amp electrical service. Check the I.D. plate behind the front
panel for voltage verification. The number of circuits varies depending on the
model. All of the electrical connections are terminated at the single point internal
junction box for hook-up by a qualified electrician. The single point internal
junction box is used for the connection of the lights, blower, and duplex outlets.
Refer to the wiring diagram for your Protector in Appendix C: Protector XLE

Specifications.

Protector XLE Hoods should include overload protection. A
switch or circuit breaker should be in close proximity to the
equipment and within easy reach of the operator. The switch
or circuit breaker is to be marked as the disconnecting device
for the equipment. Consult the NEC-2002 for proper
installation.

12

Product Service 1-800-522-7658

Chapter 3: Getting Started

Internal Junction Box

Figure 3-2

All wiring for the fume hood SHOULD be performed by a
licensed electrician and conform to all local codes. In most
cases, the hood will require the use of shielded conduit to
protect the wiring into the hood. The grounding connection
shall not be made to the terminal box cover.

The fluorescent light has been mounted outside the top liner panel and is sealed
from vapors inside the hood structure. To change the fluorescent light bulbs in
your hood, you must first remove the front panel from the hood. Next remove the
knock out plugs holding the light fixture in place. Lift fixture up and replace any
defective bulbs. Reverse order to reassemble.

Product Service 1-800-522-7658

13

Chapter 3: Getting Started

Connecting the Service Lines to the
Protector XLE Fume Hood

The hoods with service fixtures have been plumbed from the valve to the hose
connector or gooseneck for your installation convenience. Supply tubing shall be
provided by the qualified installer. Tubing can enter the hood from above,
through the back, or through the work surface to make these connections to the
service fixtures.

NOTE: Inspect all fittings for leakage. Tighten the fittings

!

!

Should access to the hood plumbing fixture bodies be required, remove the
service access plate on the hood front corner posts by loosening their individual
screws. (See item 11 Figure A-1, page 48 and 49) The valve body will now be
fully exposed for any service work that may be necessary. The service fixtures
supplied on your laboratory hood are designed for use with the following services:

• Air • Hot Water • Vacuum

• Cold Water • Natural Gas – See caution below

!

!

slightly if needed.

CAUTION: Do not use oxygen with any standard
service fixture. Contact Labconco Customer
Service for oxygen fixture information.

WARNING: Contact Labconco Customer
Service directly before using any service other
than those listed above in these valves to assure
full compatibility.

CAUTION: Natural gas should be used only in
the service fixture that has been pre-plumbed
with brass tubing. Sulfur content of the gas
could cause deterioration of standard copper
supply lines.

14

Product Service 1-800-522-7658

Chapter 3: Getting Started

Sealing the Protector XLE Fume Hood to
the Work Surface

When the hood has been set in place, ducted, wired, and plumbed, it should be
sealed at the work surface to prevent spilled materials from collecting under the
walls of the hood. Materials such as silicone sealants are recommended to seal
the hood structure.

Certifying the Protector XLE Fume Hood

The combination of your laboratory hood, exhaust ductwork, and exhaust blower
gives you the flexibility to change the airflow at the sash opening of your hood.
To determine the actual face velocity at the sash opening, airflow velocity
readings will need to be taken. This should be done across the sash opening of
the hood in accordance with the Industrial Ventilation Manual section on
laboratory hoods. (See Appendix D – Reference) Labconco recommends an
average face velocity at the sash opening of 80 to 100 feet per minute. Consult
Labconco Customer Service for proper airflow volumes for your particular model.

Your Protector XLE Fume Hood has been tested at the factory per ASHRAE 110-

1995. All hoods achieve an “as manufactured rating” of less than 0.10 part per
million (ppm) at 4 liters per minute (lpm); AM<0.10 (consult Labconco for
individual fume hood ratings). For “field use” ASHRAE testing contact
Labconco Sales Engineering Team or Customer Service for a certified on-site
contractor.

NOTE: Face velocity profiles and smoke testing should be

!

done periodically to ensure safe performance.

Your Next Step

After your Fume Hood has been installed and certified, you are ready to proceed
to Chapter 4: Performance Features and Safety Precautions.

Product Service 1-800-522-7658

15

CChhaapptteerr 44::
PPeerrffoorrm

maannccee FFeeaattuurreess aanndd

SSaaffeettyy PPrreeccaauut

tiioonnss

Performance Features

The Protector® XLE Laboratory Fume Hood is designed to meet the needs of the
laboratory scientist. The laboratory fume hood has been designed to effectively
contain toxic, noxious, or other harmful materials when properly installed. A
fully featured by-pass hood with baffle and air foil, this hood maintains safe
airflow. Optional energy saving A-Style Combination Sash models are also
available. The hood features by-pass airflow design that allows the hood face
velocity to remain relatively stable as the sash is closed. Airflow is diverted
behind the front panel and under the air foil to help control fluctuations in face
velocity, which occur as the sash is closed.

1. Unique sash provides maximum visibility of 35.00" high while
conserving energy by limiting sash travel to 28". Vertical-rising sash
may be raised from a closed position to 28" operating height. Optional
sash stops are available to limit sash height and reduce energy usage. The
sash can be locked open at the 28" height for loading and unloading
operations. When the upper sash lock is released the sash will
automatically lower to its designed operating height at 18". The sash can
be lowered manually to any position lower than the 18" operating position.

2. By-pass airflow design ensures relatively stable face velocities.

3. Large usable interior work depth and interior height of 48" provides
ample working space.

16

Product Service 1-800-522-7658

Chapter 4: Performance Features and Safety Precautions

4. Baffle (not shown) directs airflow to the rear of the interior to provide
efficient airflow. The baffle may be removed for cleaning purposes only.

5. Exterior access cover plates are removable for easy access to plumbing
valves when access through the sides is not available.

6. Lift-Away™ front panel provides easy access to electrical wiring, sash
weights, and lighting fixtures.

7. Energy efficient fluorescent lighting is located behind a laminated safety
glass shield mounted to the top of the hood. The factory-wired instant
start T8 lighting is serviceable from outside the hood cavity.

8. Low mounted, factory-wired light and blower switches are ADA
compliant.

9. Clean-Sweep™ Air Foil allows air to sweep the work surface for
maximum containment.

10. Streamlined corner posts provide maximum visibility and the flexibility
to add services after installation.

11. All hoods are factory prepared for up to 8 service fixtures.

12. Duplex electrical receptacles are mounted on the right and left corner
posts as requested. Receptacles are factory-wired to hood single point
junction box (one on fixtured model).

13. Shipped fully assembled and eliminates the need for costly onsite
assembly.

14. Accessory Guardian™ Digital Airflow Monitor or Guardian Jr.
Monitor continuously monitors face velocity. An audio/visual alarm
alerts the user to low airflow conditions. The right corner post is factory
prepared to accommodate the Guardian Monitor (sold separately).

15. Frame of epoxy-coated steel and aluminum is durable and corrosion
resistant.

16. Exhaust Connection. The hood features 12" (12.75" OD pipe) exhaust
connections sized to allow for a minimum static pressure loss through the
hood structure while providing a good transport velocity through the
exhaust system.

17. Spillstopper™ Solid Epoxy Work Surface is dished to contain spills.
(Work surface is sold separately).

18. Optional Sash Stops provide a means of controlling the operating height
of the sash.

Product Service 1-800-522-7658

17

Chapter 4: Performance Features and Safety Precautions

7

16

6

5

11

1

2

9

8

17

12

10

18

Product Service 1-800-522-7658

Chapter 4: Performance Features and Safety Precautions

Safety Precautions

Although the laboratory hood has been engineered to

!

)

!

maintain optimum operator safety, caution should always
be used while working in the hood. Prior to using the hood,
check to make sure that the exhaust blower is operating
and that air is entering the hood at its specified face
velocity.

USE GOOD HOUSEKEEPING IN THE HOOD AT ALL
TIMES. CLEAN UP SPILLS IMMEDIATELY WITH A
MILD DETERGENT. PERIODICALLY CLEAN HOOD
INTERIOR, INCLUDING FLUORESCENT LIGHT GLASS
PANEL. REPLACE BURNED OUT LIGHT BULBS TO
MAINTAIN MAXIMUM ILLUMINATION.

DO NOT OVERLOAD THE WORK SURFACE WITH
APPARATUS OR WORK MATERIAL. THE SAFE
OPERATION OF THE LABORATORY HOOD IS BASED
UPON HAVING PROPER AIRFLOW THROUGH THE
STRUCTURE. DO NOT PLACE LARGE, BULKY
OBJECTS SUCH AS BLOCK HEATERS, DIRECTLY ON
THE HOOD WORK SURFACE. INSTEAD, ELEVATE THE
OBJECT 2" TO 3" ON BLOCKS TO ALLOW A FLOW OF
AIR UNDER THE OBJECT AND INTO THE LOWER REAR
BAFFLE EXHAUST SLOT. ENSURE BLOCKS ARE
LEVEL AND SECURED IN PLACE.

Blocking the bottom of the baffle at rear of hood will
change the airflow pattern in the hood causing turbulence
and possible leakage at the face of the hood. (Don’t store
containers or supplies against baffles, as this will affect
airflow through the hood).

Avoid placing your head inside hood. Keep hands out of
hood as much as possible.

Always work as far back in hood as possible. It is best to
keep all chemicals and apparatus 6" inside the front of the
hood.

This hood does not feature explosion-proof electrical
components, unless ordered separately. Therefore, use of
flammable or explosive materials in quantities above the
explosive limit are not recommended.

Product Service 1-800-522-7658

19

Chapter 4: Performance Features and Safety Precautions

Do not work with chemicals in this hood without the
exhaust system running. Do not store chemicals in a fume
hood.

Perchloric acid use in this hood is prohibited.

High level radioisotope materials are prohibited for usage
in this hood.

DO NOT PLACE ITEMS ON THE AIRFOIL AS THEY
WILL EFFECT THE HOODS ABILITY TO CONTAIN.

)

!

AVOID CROSS DRAFTS AND LIMIT TRAFFIC IN FRONT
OF THE HOOD. AIR DISTURBANCES CREATED MAY
DRAW FUMES OUT OF THE HOOD.

The use of heat-generating equipment in this hood without
the exhaust system operating properly can cause damage to
the hood.

The Protector Laboratory XLE Hood should be certified by
a qualified certification technician before it is initially used.
The hood should be re-certified whenever it is relocated,
serviced or at least annually thereafter.

Ensure that the unit is connected to electrical service in
accordance with local and national electrical codes. Failure
to do so may create a fire or electrical hazard. Do not
remove or service any electrical components without first
disconnecting the hood from electrical service.

Proper operation of the fume hood depends largely upon
the hood’s location and the operator’s work habits.
Consult the Reference Manual in Appendix D.

Your Next Step

After you understand the theory of operation and safety precautions, you are
ready to proceed to Chapter 5: Using Your Protector XLE.

20

Product Service 1-800-522-7658

S

S A

CChhaapptteerr 55::
UUssiinngg YYoouurr PPrrootteeccttoorr XXLLEE

Operating the Vertical-Rising Sash

Because of the Protector XLE Hood counterbalanced sash mechanism, it will take
only a few pounds of force to move the sash up or down between the fully closed
position and the 18" open position. You can operate the sash smoothly with one
or two hands positioned any where along the handle. The vertical-rising sash may
be raised to a maximum 28" operating height, but the sash will automatically
close back to the 18" opening position unless locked in the full open position.
The airflow requirements should be sized for the 18" operating height.

Operating the Blower

Your Protector Fume Hood utilizes a remote style blower, which can be activated
by turning the blower switch to “ON.” You can validate the hood performance by
watching smoke drawn into the hood face opening.

S

A

Operating the Lights

Your Protector Fume Hood utilizes a factory-wired fluorescent light to illuminate
the hood interior. Simply turn the light switch to “ON” to operate.

Working in Your Protector XLE

Planning

• Thoroughly understand procedures and equipment required before
beginning work.

• Arrange for minimal disruptions, such as room traffic or entry into the
room while the hood is in use.

Product Service 1-800-522-7658

21

Chapter 5: Using Your Protector XLE

Start-up

• Turn on fluorescent light and hood blower.

• Slowly raise the sash to the 18" sash height position.

• Check the baffle air slots for obstructions.

• Allow the hood to operate unobstructed for 5 minutes.

• Wear a long sleeved lab coat and rubber gloves. Use protective eyewear.

Wear a protective mask if appropriate.

Loading Materials and Equipment

• Lock the sash in the upper position to load materials. Do not overload the
hood.

• Do not obstruct the front air foil, or rear baffle slots.

• Large objects should not be placed close together and spaced above the

work surface to permit airflow to sweep under the equipment.

• After loading the hood, wait one minute to purge airborne contaminants
from the work area.

• Release sash stop and allow sash to return to the 18" opening.

Work Techniques

• Keep all materials at least 6 inches inside of the sash, and perform all
contaminated operations as far to the rear of the work area as possible.

• Segregate all clean and contaminated materials in the work area.

• Avoid using techniques or procedures that disrupt the airflow patterns of

the hood.

Final Purging

• Upon completion of work, the hood should be allowed to operate for two
to three minutes undisturbed, to purge airborne contaminants from the
work area before shutting down blower.

Unloading Materials and Equipment

• Objects in contact with contaminated material should be surface
decontaminated before removal from the hood.

• All open trays or containers should be covered before being removed from
the hood.

Shutdown

• Turn off the fluorescent light and hood blower, then close the sash.

Your Next Step

After you understand how to operate and work in the fume hood, you are ready to
proceed to Chapter 6: Maintaining Your Protector XLE.

22

Product Service 1-800-522-7658

CChhaapptteerr 66::
MMaaiinnttaaiinniinngg YYoouurr PPrrootteeccttoorr XXLLEE

Now that you have an understanding of how to work in the fume hood, please
review the suggested maintenance schedule and the common service operations
necessary to maintain your fume hood for peak performance.

Only trained and experienced certification technicians should

!

perform some of the service operations after the fume hood has
been properly decontaminated. DO NOT attempt to perform
these operations if you are not properly trained. The wrench
icon precedes the service operations that require qualified
technicians.

Routine Maintenance Schedule

Weekly

Monthly (or more often as required)

• Using ordinary dish soap to clean the surface inside of the fume hood, and
the work surface.

• Using an appropriate glass cleaner, clean the sash and all glass surfaces.

• Operate the fume hood blower, noting the airflow velocity through the

hood using a source of visible smoke.

• Determine the actual face velocity through the sash opening of the hood
where the average reading should be at the specified velocity. (Use
calibrated thermal anemometer or other approved apparatus).

• Using a damp cloth, clean the exterior surfaces of the hood, particularly
the front of the hood, to remove any accumulated dust.

• Check all service valves, if so equipped, for proper operation.

Product Service 1-800-522-7658

23

S

Chapter 6: Maintaining Your Protector XLE

• The hood baffles should be checked for blockages behind them to ensure
that the hood is maintaining proper airflow.

• All weekly activities.

Annually

• Replace the fluorescent lamps.

• Have the fume hood recertified by a qualified certification technician. See

Certifying the Protector XLE Fume Hood in Chapter 3.

• All monthly activities.

Biannually

• The sash assembly should be checked to ensure proper operation and to
make sure there are no signs of abnormal wear on the sash pulleys, cables
and clamps.

Routine Service Operations

Front Panel Removal:

1. Simply lift the front panel up and then away from the hood to provide access
to the top.

Changing the Fluorescent Lamp:

A

1. Turn light switch to “OFF.”

2. Remove the front panel as noted earlier.

3. Reach over the front header of the hood and remove the knock out plugs at
both ends of fixture. Lift fixture up.

4. Remove the fluorescent lamp by pushing it out of the spring-loaded lamp
socket and swinging it out of the other lamp socket.

5. Install the new lamp by reversing the removal procedure.

Your Next Step

After you understand the maintenance procedures, you are ready to proceed to
Chapter 7: Modifying Your Protector XLE.

24

Product Service 1-800-522-7658

CChhaapptteerr 77::
MMooddiiffyyiinngg YYoouurr PPrrootteeccttoorr XXLLEE

There are several ways to modify the fume hood for your individual requirements.
These include the addition of work surfaces, service fixtures, air monitor,
distillation grids, electrical duplex receptacles and ceiling enclosures.

Installing Work Surfaces

Your Protector XLE Fume Hood requires a work surface to work properly.
Contact Labconco Customer Service for ordering information.

Figure 7-1

Product Service 1-800-522-7658

25

Chapter 7: Modifying Your Protector XLE

Installing Ceiling Enclosures Above the
Fume Hood

Your Protector XLE Fume Hood has mounting holes to accept a ceiling enclosure
to close off the area between the top of the hood and the ceiling. Contact
Labconco Customer Service for ordering information.

Figure 7-2

Installing Additional Service Fixtures

Additional service fixtures can be installed in the available service fixture holes in
both sidewalls and corner posts. The fume hood is factory set to accept up to four
valves per side. Contact Labconco Customer Service for information.

Figure 7-3 - Knob

Figure 7-4 - Valve

Figure 7-5 – Hose Connector

26

Product Service 1-800-522-7658

Chapter 7: Modifying Your Protector XLE

Installing Guardian™ 1000 Digital Airflow
Monitor or Guardian™ Jr. Airflow Monitor

The Guardian Digital Airflow Monitor P/N 9743211 continuously monitors face
velocity through the fume hood opening. The Guardian Jr. Airflow Monitor P/N
9743202 continuously monitors airflow through the exhaust. The fume hood right
corner post is factory prepared to mount either monitor. Contact Labconco
Customer Service to order.

Figure 7-6

Figure 7-7

Distillation Grids – Field Installation

The distillation grid P/N’s 9725200 thru 9725206, have been strategically placed
with the vertical rod center lines in front of the lower baffle and middle baffle.
The distillation grids allow the hood user to mount glassware, motors, stirrers, and
other apparatus. Contact Labconco Customer Service for ordering information.

Product Service 1-800-522-7658

Figure 7-8

27

Chapter 7: Modifying Your Protector XLE

Installing an Electrical Duplex Receptacle

Your Protector Fume Hood can be ordered with duplex outlets, however, if you
ordered a model without an electrical duplex outlet you can have one installed in
the field by a qualified electrician. Contact Labconco Customer Service for
ordering information. (Not acceptable on explosion-proof hoods).

Figure 7-9

Your Next Step

After you understand the modifying procedures, you are ready to proceed to
Chapter 8: Troubleshooting.

28

Product Service 1-800-522-7658

CChhaapptteerr 88::
TTrroouubblleesshhoooottiinngg

Refer to the following table if your fume hood fails to operate properly. If the
suggested corrective actions do not solve your problem, contact Labconco for
additional assistance.

PROBLEM CAUSE CORRECTIVE ACTION

Remote blower and
lights won’t operate

Check connection to control box on top

Circuit breakers

Remote blower won’t
operate, but lights
work

Belt broken. Replace belt.

Blower motor is

Fume hood blower
operates but lights
will not operate

Defective lamp

Wires not connected
at junction boxes or
switches.

tripped in building
electrical supply.

Blower wiring is
disconnected.

defective.

Lamp wiring is
disconnected.

ballasts.

Check connection of switches.

of unit.

Reset circuit breakers.

Inspect blower wiring and switch.

Replace blower motor.

Inspect lamp wiring.

Replace lamp ballasts.

Product Service 1-800-522-7658

29

Chapter 8: Troubleshooting

PROBLEM CAUSE CORRECTIVE ACTION

Contaminants outside
of fume hood

Restriction of the

External factors are

Fume hood has

Vertical sash no
longer operates
smoothly

Pulley bearing is

Cable has slipped off

Weight has broken

Spring assembly. Inspect to make sure spring is still

Electrical duplex
receptacles no longer
have power

Circuit breakers

Improper user
techniques for the
fume hood.

baffle air slots or –
blockage of the
exhaust outlet.

disrupting the fume
hood airflow patterns
or acting as a source
of contamination.

improper face
velocity.

Cable is frayed or
plastic protection is
damaged.

damaged.

the pulleys.

pulleys.

Wires not connected
or faulty duplex.

tripped in building
electrical supply.

See “Certifying the Hood” Chapter 3 and
“Safety Precautions” Chapter 4 sections
in the manual. (Ref. Appendix D)

Remove baffles to check that all air slots,
and the exhaust outlet are unobstructed.
Replace baffles.

See “Location Requirements” Chapter 2,
“Certifying the Hood” Chapter 3, and
“Safety Precautions” Chapter 4 sections
of this manual. (Ref. Appendix D)

Have fume hood re-certified and check
remote blower exhaust system. Hood
should have average face velocity of 80­100 fpm.

Inspect cable and replace cable if worn or
damaged immediately; otherwise injury
could result.

Replace pulley, bearing or add grease.

Re-install, cable must be replaced
immediately if damaged.

Replace weight pulleys.

attached to he sash.

Check wire connection or replace duplex.

Reset circuit breakers.

30

Product Service 1-800-522-7658

Chapter 8: Troubleshooting

PROBLEM CAUSE CORRECTIVE ACTION

Service valves no
longer operate

Valve no longer

Supply line or outlet

Faulty building
supply.

operates.

line has leaks.

Inspect building supply shut off valves
and appropriate pressures below 40 PSI.

Replace valve and check for leaks.

Inspect line for leaks and fix any leaking
plumbing connections.

Product Service 1-800-522-7658

31

AAppppeennddiixx AA::
PPrrootteeccttoorr XXLLEE CCoom

Illustration A-1 indicates the location of the following service parts:

Protector XLE Replacement Parts

Item Quantity Part No. Description

1A 1 9823700 Valve, Labconco (Water) 1/4" Compression Fitting
1B 1 9823701 Valve, Labconco (Water) 3/8" Compression Fitting
1C 1 9817000 Valve, Labconco 1/4" Compression Fitting (AIR, GAS, VAC, NIT, etc.)
1D 1 9817001 Valve, Labconco 3/8" Compression Fitting (AIR, GAS, VAC, NIT, etc.)
1E 1 9823702 Valve, Labconco Deionized 1/4" Compression Fitting
1F 1 9823703 Valve, Labconco Deionized 3/8" Compression Fitting
1G 1 9818000 Nut, Valve Mounting. (Labconco)
2A 1 9826800 WaterSaver Valve/Gooseneck -GRN
2B 1 9826801 WaterSaver Valve/Connector (VAC) – YEL
2C 1 9826802 WaterSaver Valve/Connector (AIR) – ORG
2D 1 9826803 WaterSaver Valve/Connector (GAS) – BLU
2E 1 9826805 WaterSaver Valve/Connector (HOT WATER) – RED
2F 1 9826806 WaterSaver Valve/Connector (CW) – GRN
2G 1 9826807 WaterSaver Valve/Connector (STEAM) – BLK
2H 1 9826808 WaterSaver Valve/Connector (NITROGEN) – BRN

2I 1 9826809 WaterSaver Valve/Connector (OXYGEN) – LIGHT GREEN
2J 1 9826810 Swivel Gooseneck only – GRN

2K 1 9826812 Swivel Gooseneck only – WHITE

3 1 9818700 thru 08 Knobs (GRAY, GRN, BLU, ORG, YEL, RED, WHT, BLK, BRN)
4A 1 9818800 Hose Barb, GRAY – (NEUTRAL OR ARGON) – NOT SHOWN
4B 1 9818801 Hose Barb, GREEN - (COLD WATER) – NOT SHOWN
4C 1 9818802 Hose Barb, BLUE – (GAS) – NOT SHOWN
4D 1 9818803 Hose Barb, ORANGE – (AIR) – NOT SHOWN
4E 1 9818804 Hose Barb, YELLOW – (VACUUM) – NOT SHOWN
4F 1 9818805 Hose Barb, RED – (HOT WATER) – NOT SHOWN
4G 1 9818806 Hose Barb, WHITE – (DEIONIZED WATER) – NOT SHOWN
4H 1 9818807 Hose Barb, BLACK – (NEUTRAL OR STEAM) – NOT SHOWN

4I 1 9818808 Hose Barb, BROWN – (NITROGEN) – NOT SHOWN
4J 1 9819000 Nut, Hose Barb – NOT SHOWN

5 1 9825500 Label, Knob (contains all the labels)

6 1 9818900 Lens, Knob
7A 1 9947100, 01, 02 115V Duplex Receptacle (GRAY) Right, Left 4' - 6', Left 8' w/ wires
7B 1 9818200 Cover Plate 115V Duplex
7C 1 9947103, 04, 05 115V GFCI Duplex Receptacle (GRAY) Right 4' - 6', Left 8' w/ wires
7D 1 9818100 Cover Plate, 115V GFCI
7E 1 9818300 Cover Plate, Blank

mppoonneennttss

32

Product Service 1-800-522-7658

Appendix A: Protector XLE Components

Item Quantity Part No. Description

8A 1 9721901 Lamp, Fluorescent (T8 x 3') – use on 4' & 8' Hoods – NOT SHOWN

8B 1 9721900 Lamp, Fluorescent (T8 x 4') – use on 5', 6' & 7' Hoods – NOT SHOWN
10A 1 1302300 Switch, Rocker
11A 1 9818400 Access Cover
11B 1 9825100 Label, Access Cover (includes all three corner labels)
12B 1 9810801 Side Panel, 30" internal deep hoods
12D 4 1916400 Nut, Retainer #10-24
12E 4 1885512 Screw, Machine #10-24 x .75 Truss Head Stainless
13A 1 9951000 Air Foil 4' Assembly with trough
13B 1 9951001 Air Foil 5' Assembly with trough
13C 1 9951002 Air Foil 6' Assembly with trough
13D 1 9951009 Air Foil 7' Assembly with trough
13E 1 9951003 Air Foil 8' Assembly with trough

14 4 1861400 Pulley, Front or Rear, 1-3/16 Dia. (rear of 4', 5', 6' only) – NOT SHOWN
15 2 4949902 Cable, Sash 130" – NOT SHOWN
16 2 9741900 Sheave, (Rear 8')
17 4 9742100 Bronze Bearing, Flanged Rear – NOT SHOWN
18 4 1920100 Clamp, Cable Replacement – NOT SHOWN
19 2 1972100 S-Hook – NOT SHOWN (to attach weight to cable)

20A 1 9946300 Wiring Harness, Main

21 1 9961500, 01, 02, 03, 04 Front Panel, 4', 5', 6', 7', 8'

Product Service 1-800-522-7658

33

Appendix A: Protector XLE Components

21

11

1

2

3

5

6

13

10

8

20

12

34

7

Figure A-1

Product Service 1-800-522-7658

AAppppeennddiixx BB::
PPrrootteeccttoorr XXLLEE DDiim

A 48.00 60.00 72.00 84.00 96.00
B 38.25 50.25 62.25 74.25 86.25
Duct Spacing C/L

4' 5' 6' 7' 8'

One Duct

meennssiioonnss

XLE Model Widths

C/L

One Duct

C/L

One Duct

42.00

Two Ducts

48.00

Two Ducts

Product Service 1-800-522-7658

35

AAppppeennddiixx CC::
PPrrootteeccttoorr XXLLEE SSppeecciiffiiccaattiioonnss

Environmental Conditions

• Indoor use only.

• Maximum altitude: 10,000 feet (3,048 meters).

• Ambient temperature range: 41° to 104°F (5° to 40°C).

• Maximum relative humidity: 80% for temperatures up to 88°F (31°C),

decreasing linearly to 50% relative humidity at 104°F (40°C).

• Main supply voltage fluctuations not to exceed ±10% of the nominal
voltage.

• Transient over-voltages according to Installation Categories II (Over-
voltage Categories per IEC 1010). Temporary voltage spikes on the AC
input line that may be as high as 1500V for 115V models and 2500V for
230V models are allowed.

• Used in an environment of Pollution degrees 2 (i.e., where normally only
non-conductive atmospheres are present). Occasionally, however, a
temporary conductivity caused by condensation must be expected, in
accordance with IEC 664.

36

Product Service 1-800-522-7658

Appendix C: Protector XLE Specifications

Product Service 1-800-522-7658

37

AAppppeennddiixx DD::
RReeffeerreenncceess

Many excellent reference texts and booklets are currently available. The
following is a brief listing:

Laboratory Ventilation Standards

Federal Register 29 CFR Part 1910

Non-mandatory recommendations from “Prudent Practices.”

• Fume hoods should have a continuous monitoring device

• Face velocities should be between 60-100 linear feet per minute (lfpm)

• Average 2.5 linear feet of hood space per person

Occupational Health and Safety
U.S. Department of Labor
200 Constitution Avenue N.W.
Washington, DC 20210
[phone]

Industrial Ventilation-ACGIH

• Fume hood face velocities between 60-100 lfpm

• Maximum of 125 lfpm for radioisotope hoods

• Duct velocities of 1000-2000 fpm for vapors, gasses and smoke

• Stack discharge height 1.3-2.0 x building height

• Well designed fume hood containment loss, <0.10 ppm

Industrial Ventilation: A Manual of Recommended Practice,

th

25

Edition, 2004
American Conference of Governmental Industrial Hygienists
1330 Kemper Meadow drive
Cincinnati, OH 45240-1634
[phone]

38

Product Service 1-800-522-7658

Appendix D: References

ASHRAE 110-1995 Method of Testing Performance of Fume Hoods

Evaluates fume hood’s containment characteristics

• Three part test: Smoke generation, Face velocity profile, Tracer gas release @ 4 liters

per minute

• Rated As Manufactured (AM), As Installed (AI) and As Used (AU)

American Society of Heating, Refrigerating, and Air Conditioning Engineers
1791 Tullie Circle N.E.
Atlanta, GA 30329
[phone]

ANSI Z9.5-2003 Laboratory Standard

Covers entire laboratory ventilation system.

• Vertical stack discharge @ 2000-3000 fpm

• New and remodeled hoods shall have a monitoring device

• Ductless hoods should only be used with non-hazardous materials

• Fume hood face velocities between 80-120 fpm

American Industrial Hygiene Association
2700 Prosperity Avenue, Suite 250
Fairfax, VA 22031
[phone]

SEFA 1-2002

• Fume hood face velocities based on toxicity levels of chemicals

Class A – 125 to 150 fpm

Class B – 80 to100 fpm

Class C – 75-to 80 fpm

• Test method – face velocity profile and smoke generation

Scientific Equipment & Furniture Association
1028 Duchess Drive
McLean, VA 22102
[phone]

NFPA 45 – 2002 Fire Protection for Laboratories Using Chemicals

• Laboratory hoods should not be relied on for explosion protection

• Exhaust air from fume hoods should not be recirculated

• Services should be external to the hood

• Canopy hoods only for non-hazardous applications

• Materials of construction should have flame spread of 25 or less

• 80 to 120 fpm to prevent escape

NFPA 30 – 2000 Flammable and Combustible Liquids Code

• Approved cabinets may be metal or wood

• Vent location on cabinets are required

• Venting of cabinets not a requirement

National Fire Protection Association
1 Batterymarch Park
P.O. Box 9101
Quincy, MA 02269-9101
[phone]

Product Service 1-800-522-7658

39

Appendix D: References

General References

ASHRAE Standard Committee. ASHRAE Standard Atlanta: ASHRAE Publications
Sales Department, 1995

British Standards Institution, Laboratory Fume Cupboards. Parts 1, 2 and 3, London:
1990

Department of Labor, Occupational Safety and Health Administration, 29 CFR Part
1910, Occupational Exposures to Hazardous Chemicals in Laboratories, Final Rule. Vol.
55, No. 21. Washington D.C.:1990

DiBerardinis. L. et al. Guides for Laboratory Design, Health and Safety Considerations.
Wiley & Sons, 1987

McDermott, Henry, Handbook of Ventilation for Contaminant Control, 2
Butterworth Publishers, 1985.

Miller, Brinton M. et al. Laboratory Safety: Principles and Practices. American Society
for Microbiology, Washington, D.C.: 1986

NIH Guidelines for the Laboratory Use of Chemical Carcinogens. NIH Publication No.
81-2385.

Rayburn, Stephen R. The Foundation of Laboratory Safety, A Guide for the Biomedical
Laboratory. Springer-Verlag, New York: 1990

Sax, N. Irving and Lewis, JR., Richard J. Rapid Guide to Hazardous Chemicals in the
Workplace. Van Nostrand Reinhold, 1987.

Schilt, Alfred A. Perchloric Acid and Perchlorates. The G. Frederick Smith Chemical
Company, Columbus, OH: 1979.

Furr, A. Keith. CRC Handbook of Laboratory Safety, 5

th

Edition. CRC Press, 2000.

nd

Edition.

40

Product Service 1-800-522-7658

DECLARATION OF CONFORMITY

Application Council Directive(s): 73/23/EEC, 89/336/EEC, 2002/95/EC (ROHS),
2002/96/EC (WEEE), 2004/108/EC

Standard(s) to which conformity is declared: EN61010-1, EN61326-1, EN55022,
EN61000-3-2/3

Manufacturer’s Name: Labconco Corporation

Manufacturer’s Address: 8811 Prospect Avenue
Kansas City, MO 64132 USA

Importer’s Name: See Shipping/Customs Documents

Importer’s Address: See Shipping/Customs Documents for your equipment

Type of Equipment: Laboratory Equipment Protector Laboratory Hoods

Model No.:

Premier Models 48700 Series thru 48800 Series 4' Protector Laboratory Hoods

60700 Series thru 60800 Series 5' Protector Laboratory Hoods
72700 Series thru 72800 Series 6' Protector Laboratory Hoods
9674500, 9683000 8' Protector Laboratory Hoods

XL Models 97001, 97002, 97003, 97004 Series Protector Laboratory Hoods
97504, 97505, 97506 Series Protector Laboratory Hoods

XLE Models 99704, 99705, 99706, 99707, 99708 Series Protector Laboratory Hoods

Serial No.: Various – See Individual Declaration

Year of Manufacture: 2002 and subsequent

I, the undersigned, hereby declare that the equipment specified above conforms to the
above Directive(s) and Standard(s).

See individual Declaration of Conformity which
will be signed by the importer for your country.

Place: _______________________________________
(Signature)

Date: _______________________________________
(Full Name)

_______________________________________

(Position)

Labconco P/N 36960-23, Rev. C, ECO E344

Product Service 1-800-522-7658

41
